Automatic General Metadata Extraction and Mapping in an HDF5

Use-case

Benedikt Heinrichs

1 a

, Nils Preuß

2 b

, Marius Politze

1 c

, Matthias S. M

uller

1 d

and Peter F. Pelz

2 e

IT Center, RWTH Aachen University, Seffenter Weg 23, Aachen, Germany

Chair of Fluid Systems, Technical University of Darmstadt, Darmstadt, Germany

Keywords:

Research Data Management, Metadata Extraction, Metadata Generation, Metadata Mapping, Linked Data.

Abstract:

Extracting interoperable metadata from data entities is not an easy task. A method for this would need to

extract non-interoperable metadata values ﬁrst and then map the extracted metadata to some sensible repre-

sentation. In the case of HDF5 ﬁles, metadata annotation is already an option, making it an easy target for

extracting these non-interoperable metadata values. This paper describes a use-case, that utilizes this property

to automatically annotate their data. However, the issue arises, that these metadata values are not reusable,

due to their missing interoperability, and validatable since they do not follow any deﬁned metadata schema.

Therefore, this paper provides a solution for mapping the deﬁned metadata values to interoperable metadata

by extracting them ﬁrst using a general metadata extraction pipeline and then proposing a method for mapping

them. This method can receive a number of application proﬁles and creates interoperable metadata based on

the best ﬁt. The method is validated against the introduced use-case and shows promising results for other

research domains as well.

1 INTRODUCTION

Research data is a fundamental building block for sci-

entiﬁc discovery. Hence, it should be supported by

adequate management processes. The ﬁeld of Re-

search Data Management (RDM) therefore receives

more and more attention by researchers and funding

agencies. Accordingly, this improvement is driven

by adhering to the so-called FAIR principles (Wilkin-

son et al., 2016) which describe that data and its

metadata should be ﬁndable, accessible, interopera-

ble and reusable. Metadata is understood as a data

record describing the data that serves to make it in-

terpretable. A standardized representation of meta-

data, furthermore, makes this information machine-

readable and interoperable. Especially the creation of

metadata produces a major challenge for researchers

when they want to adhere to the FAIR principles.

Commonly, metadata is only sometimes stored and

not easily reusable since no real ﬁtting interopera-

https://orcid.org/0000-0003-3309-5985

https://orcid.org/0000-0002-6793-8533

https://orcid.org/0000-0003-3175-0659

https://orcid.org/0000-0003-2545-5258

https://orcid.org/0000-0002-0195-627X

ble schema is deﬁned and the creation of interoper-

able metadata creates a large overhead. This creates

problems when trying to ﬁnd and reuse research data

by looking at the available metadata. A further chal-

lenge is that even if metadata is created, there is often

no validation which conﬁrms if it adheres to a cer-

tain schema. Over the past years several technologies

evolved to record metadata. Eventually, the W3C de-

ﬁned RDF as a standardized framework for the ex-

act purpose of describing data. Solutions exist to cre-

ate schemas and interoperable metadata which can be

validated with RDF, but they require a lot of knowl-

edge about ontologies and the semantic web which

creates an accessibility problem. Furthermore, cre-

ation of these schemas and metadata is often a tedious

manual process which is not realistic in a scaling envi-

ronment. Since there is work being performed to ease

the creation of these schemas as so-called application

proﬁles as described by (Gr

onewald et al., 2021), this

paper aims to remove the overhead knowledge neces-

sary for creating the interoperable metadata and uti-

lize these application proﬁles. Furthermore, the man-

ual nature of metadata creation is put into question

and an automatic model is utilized which creates the

needed metadata. The approach is assumed to be

usable across different research domains and is val-

172

Heinrichs, B., Preuß, N., Politze, M., Müller, M. and Pelz, P.

Automatic General Metadata Extraction and Mapping in an HDF5 Use-case.

DOI: 10.5220/0010654100003064

In Proceedings of the 13th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2021) - Volume 1: KDIR, pages 172-179

ISBN: 978-989-758-533-3; ISSN: 2184-3228

idated on a real-life use-case which deals with the

mentioned issues and is described in section 2.

2 USE-CASE

In this use-case, a test rig is utilized for the experi-

mental validation of an efﬁciency model of positive

displacement pumps. The test rig meets the require-

ments of ISO 4409 that speciﬁes the measurement

procedure, the testing methods and the experimental

setup of pump efﬁciency measurements. The setup

comprises the following instrumentation: At the in-

let and outlet of the pump under investigation, the

pressure and temperature are measured by means of

a pressure transmitter based on a piezo resistive sil-

icon sensor and a Pt100 resistance thermometer, re-

spectively. Between the electric motor and the pump,

a torque meter measures the torque momentum and

the rotating speed based on strain gauge technol-

ogy. Furthermore, a volume ﬂow meter on the high-

pressure side of the pump measures the volume ﬂow

by means of the screw pump principle. Figure 1

shows a schematic of the pump test rig.

Figure 1: Positive displacement pump test rig utilized for

validation of efﬁciency models.

In the scope of measurements conducted on the in-

troduced test rig, the unit under test, as well as the hy-

draulic oil, are replaced many times. With these com-

ponents, the resulting correlation of measured quanti-

ties and system state quantities changes as well. For

example, the material properties of the hydraulic oil,

viscosity and density, depend on the temperature in

the hydraulic system and therefore the operating point

of the investigated pump. Similarly, characteristics

of the investigated pump are computed dependent on

geometric dimensions or other parameters in conjunc-

tion with measured quantities. Additionally, measure-

ment equipment needs to be replaced depending on

their measuring range in contrast to the range of oper-

ating points to be investigated.

It is therefore imperative to organize test rig data

of the use-case as self-documenting data products:

Complete data packages that contain raw data inter-

linked with derived result data as well as correspond-

ing metadata, providing all the information needed for

the interpretation of the data contents. Section 4.4 de-

scribes the data model and ﬁle structure utilized to

achieve this. Due to the need for frequent adjustments

of the test rig setup, this use-case illustrates the need

for machine-readable metadata, that is interoperable

and applicable across multiple heterogeneous experi-

ment setups. The heterogeneity of data and metadata

proliferates further with evolving setup, or when con-

sidering a larger scope of multiple test rigs. There-

fore, methods and technologies are needed to support

the creation of semantically correct metadata which

can be validated.

3 CURRENT STATE AND

RESEARCH GOAL

The challenge of creating, extracting and mapping

metadata is not a new one and has been looked into

from different angles. This section therefore de-

scribes the current state of the created methods and

other use-cases to paint a clearer picture of the identi-

ﬁed research gap.

3.1 Metadata Representation

Metadata, in this context, is information that states

some fact about a speciﬁc (digital) resource. These

facts can be used by machines or people to under-

stand the actual dataset. The Resource Description

Framework (RDF), described by (Wood et al., 2014),

is one of the data models conceived by the W3C for

the representation of such information on the web.

It originates from the context of the Semantic Web

and provides a well-structured way to express meta-

data in the form of triples (subject-predicate-object)

which form a graph. For this reason, RDF offers a

reasonable way to map metadata: A resource (sub-

ject) is assigned a term or a value (object) within a

speciﬁc category (predicate). It makes with that, fur-

thermore, a great candidate for describing vocabular-

Automatic General Metadata Extraction and Mapping in an HDF5 Use-case

173

ies and ontologies with the help of the Web Ontology

Language (OWL) described by (W3C, 2012). Addi-

tionally, since a need for validated metadata was de-

scribed, the Shapes Constraint Language (SHACL) is

an ideal candidate and was described by (Kontokostas

and Knublauch, 2017). By describing the require-

ments for a given metadataset it can be used as an

implementation of metadata schemas as so-called ap-

plication proﬁles.

3.2 Metadata Annotation

Manual metadata annotation based on some kind of

schematic is a common reality. Platforms like MetaS-

tore described by (Prabhune et al., 2018) and Coscine

described by (Politze et al., 2020) allow users to man-

ually annotate their datasets with metadata using user

or machine operable interfaces. Both platforms make

use of some kind of schema which deﬁnes the struc-

ture and requirements for a metadataset. The different

schemas used for individual metadata records allow

building a semi-structured metadata database. This

database, or knowledge graph, then contains metadata

from a variety of scientiﬁc disciplines as validated sub

sets. The difference between them is, that MetaStore

makes use of JSON and XML schemas while Coscine

makes use of the RDF language and SHACL applica-

tion proﬁles. While this is a technical hurdle, in the

context of metadata, JSON and XML schemas and

SHACL are widely equivalent in terms of expressive-

ness as discussed by (Labra Gayo et al., 2017).

3.3 Metadata Mapping Languages

Since manual metadata annotation might not be feasi-

ble and in certain use-cases metadata might already

be created, just not in RDF, methods were deﬁned

to create a mapping between a speciﬁc and standard-

ized representation. R2RML described by (Das et al.,

2012) or the extension of it called RML and described

by (Ben De Meester et al., 2021) allow the creation of

mapping rules for mapping non-interoperable meta-

data to an interoperable representation. Approaches

like the one described by (Iglesias et al., 2020) imple-

ment these rules and can automatically interpret and

map metadata based on it.

3.4 Ontology Mapping

A familiar ﬁeld for mapping between concepts is on-

tology mapping. The idea is that between two differ-

ent concepts the similarity is determined and it is eval-

uated how two given ontologies are linked between

each other. The researchers in (Harrow et al., 2019)

discuss different methods and the challenges for this

ﬁeld. Since the presented problem and the ﬁeld of on-

tology mapping is similar, these kinds of methods can

inspire an adoption to this area.

3.5 Direct Metadata Mapping

Moving from deﬁned mapping languages and map-

ping concepts, software like (AtomGraph, 2019)

promises the direct conversion from JSON data to

RDF. This kind of conversion maps the given key-

value pairs to a static preﬁx which can be chosen.

This however fails to map the data to some ontology

for creating some meaning in the generated metadata,

but still makes it usable with RDF metadata stores

and SPARQL endpoints. Furthermore, in the domain

of object-triple mapping libraries, approaches spec-

ify their classes with annotations and by that estab-

lish a direct mapping as described by (Ledvinka and

Kremen, 2020). Additionally, works like the one de-

scribed in (Verborgh and Taelman, 2020) try to create

an abstraction layer for interacting with RDF and pro-

duce a mapping between web technologies and RDF

and SPARQL. They aim to solve part of the usabil-

ity problems of the semantic web and achieve that by

creating their language called LDﬂex.

3.6 Direct Domain-based Metadata

Mapping

For mapping metadata automatically, several ap-

proaches have been pursued, however most of them

are very domain-speciﬁc. The approach described in

(TopQuadrant, 2021) lets users translate their non-

interoperable metadata to RDF when the targeted

SHACL application proﬁle is provided, however re-

quires their proprietary software to be used and as-

sumes a direct mapping using the RDF term sufﬁx.

Furthermore, researchers described in (Souza et al.,

2017) a method to automatically map JSON data

to domain-dependent vocabularies. This method as-

sumes knowledge of an applicable ontology for the

metadata, making the inclusion of a domain-expert

necessary. It is aligned to the proposed research goal,

however does not consider the use of application pro-

ﬁles for creating interoperable metadata. Lastly, the

W3C provides in (W3C, 2021) a list of tools which

convert application data to RDF based on speciﬁc for-

mats and custom implementations.

3.7 Research Goals

Based on the current state of the art, the follow-

ing question is being proposed: How can a domain-

KDIR 2021 - 13th International Conference on Knowledge Discovery and Information Retrieval

174

independent method be used to convert metadata in

domain-dependent formats into RDF based on appli-

cation proﬁles without the need of a domain-expert?

This question raises the following goals for this paper:

1. Provide a method to extract discipline-speciﬁc

metadata from HDF5 ﬁles

2. Provide an algorithm to map discipline-speciﬁc

metadata to an application proﬁle

4 APPROACH

Following the proposed research goal, a method has

to be created, which can automatically generate inter-

operable metadata based on some kind of initial appli-

cation proﬁles. In the work of (Heinrichs and Politze,

2020) a pipeline was proposed that can deal with the

automatic extraction of interoperable metadata, how-

ever still leaves the mapping of metadata very open

and only has some suggestions for it. Therefore, the

aim here is to ﬁll this gap and validate it on the use-

case.

4.1 General Pipeline Deﬁnition

A visual representation of the proposed general

pipeline is shown in ﬁgure 2 and contains a couple

of steps. The ﬁrst step is some kind of general ex-

traction to retrieve metadata that is already attached

to the given data entity like a creation date or a cre-

ator. This step is additionally responsible to extract

some possible text values and feed this and the data

entity itself to the next step. The next step is some

kind of MIME-Type-Based extraction method which

can be provided by the executing person and is con-

ﬁgurable. This kind of method should create some

domain-based metadata and deal with the text extrac-

tion for speciﬁc formats that the general extraction

method does not work with. The ﬁnal step is the text

extraction which is based on the idea, that even if no

valid metadata has been created yet, at least some kind

of text representation of the data entity might exist

which can be translated to some facts and represented

in RDF as metadata. Finally, all the combined created

metadata is pushed through a mapping and validate

step which for now is still very open. The results shall

then be stored in some kind of metadata store.

4.2 HDF5 Pipeline Deﬁnition

Following the general pipeline deﬁnition, it can be de-

ﬁned more concretely in the case of HDF5 ﬁles. The

general extraction step can be performed by the appli-

Figure 2: A proposed general metadata extraction pipeline

by (Heinrichs and Politze, 2020).

cation Apache Tika described by (Mattmann and Zit-

ting, 2011) which supports numerous ﬁle types and

can extract the attached metadata. The MIME-Type-

Based extraction method is here represented by an

HDF5 Structure Descriptor which can understand the

folder-based structure of an HDF5 ﬁle and creates in-

teroperable metadata from this. It furthermore can ex-

tract the custom provided non-interoperable metadata

from the use-case which will be described in section

4.4. The whole method is described in detail in sec-

tion 4.3. The mapping step then makes use of pro-

vided application proﬁles and will be discussed more

in detail in section 4.5. The resulting metadata is pro-

vided to a metadata store.

4.3 HDF5 Structure Descriptor

While the main focus is to derive metadata for a single

dataset according to application proﬁles, HDF5 ﬁles

provide an internal structure that can be used to break

down the single ﬁle into multiple datasets and groups.

In order to adequately describe the ﬁle, it is therefore

necessary to ﬁnd an adequate and interoperable rep-

resentation of this internal structure in RDF. The vo-

cabulary dcat described by (Perego et al., 2020) can

be utilized to describe so-called data catalogs which

further can hold some datasets or other data catalogs.

This makes it an ideal ﬁt for representing the HDF5

ﬁle type, since it can be used to make a direct descrip-

tion of the given structure. The idea is that by describ-

ing a group with the property of “dcat:Catalog“, it can

be linked to other groups with the term “dcat:catalog“.

Different datasets can be described with the property

of “dcat:Dataset“ and can be referenced by a group

with the term “dcat:dataset“.

Furthermore, additional attributes can be extracted

from different groups and datasets. Especially the

custom speciﬁed metadata values are extracted from

the attribute key-value pairs and mapped to the re-

spective groups or datasets with a placeholder preﬁx

to label it for a later mapping to an application pro-

ﬁle. This additionally synergizes with the later pro-

posed mapping since the custom speciﬁed metadata

values are all linked to a unique subject representing

the speciﬁc group or dataset.

Automatic General Metadata Extraction and Mapping in an HDF5 Use-case

175

4.4 HDF5 Use-case Structure

The general design of the ﬁle structure employed in

the use-case is the result of the object-oriented mod-

elling method. Relevant entities in the experiment are

identiﬁed and related to each other, e.g. arbitrary sets

of instruments, their conﬁguration and the generated

datasets. This structure of objects and their properties

is represented as a structure of groups in an HDF5 ﬁle,

objects are designated by the “CLASS” attribute.

A core example is the class “Pipeline”, extend-

ing the concept of I/O-channels in Hardware APIs,

which typically represent the conﬁguration of the I/O-

hardware per signal as well as the corresponding data.

Each “Pipeline” relates a dataset to the set of instru-

ments that it was produced by. Each object of class

“Instrument” is in turn described by a set of infor-

mational attributes and a model. An object of class

“Model” represents the conﬁguration of the software

routine that implements the data conversion of the

corresponding instrument (e.g. the I/O-Hardware). In

the case of a “Pipeline” related to processed data, the

“origin” attribute holds a reference (URL or URI) to

the “Pipeline” that relates to the raw data. Figure 3

illustrates this data model.

Figure 3: Example of the use-case’s class-based structure.

Based on this generic base model, highly diverse

experimental setups can be represented. This cov-

ers different test rigs of different projects as well as

adjustments of one and the same test rig over time.

Based on the embedded information, data process-

ing actions corresponding to utilized instruments and

their calibration can be conﬁgured and re-run.

4.5 Proposed Mapping Algorithm

The proposed mapping algorithm makes use of the

previous steps, which include the creation of custom

provided metadata values. After they have been ex-

tracted, they have to be mapped to a given number

of application proﬁles. For this, an algorithm is pro-

posed which shall deal with such a mapping. The al-

gorithm is assumed to be used for any range of use-

cases and not just the HDF5 use-case, even though it

will be validated on it. It receives an application pro-

ﬁle as an input and the not yet mapped metadata val-

ues. The closeness of each application proﬁle is then

determined by the algorithm and the closest output is

then chosen to be used for mapping the values.

It is to note that the algorithm can only be as good

as the input is. If the input metadata (seen as key-

value pairs) is obscured to the point that a mapping

is not really possible, or the application proﬁles are

not ﬁtting, then the output will not yield great results.

However, the assumption is, if the input is not that

obscured and the application proﬁles contain ﬁtting

terms, then the output will yield a good representa-

tion.

4.6 Mapping Metadata Values to an

Application Proﬁle

The idea to map a metadata value to an application

proﬁle is presented in Algorithm 1. The base is a

function that receives as input values an application

proﬁle as a graph and a metadata value as an RDF

triple “t” with a subject “t.sub”, predicate “t.pred”

and object “t.obj”. This metadata value is coming

from the previous metadata extraction and is in the

structure of an identifying subject pointing with the

custom mapped attribute key to its value. An exam-

ple of this would be: ?s custom:CLASS “Pipeline”.

The provided graph can have any number of triples

and shall offer some ﬁlter functionality. The triples

of the application proﬁle graph all have a subject rep-

resented as “sub”, a predicate represented as “pred”

and an object represented as “obj”. Based on the in-

put, the algorithm then tries to see if the given triple

contains the term “class” in the predicate. The as-

sumption is that such a term will indicate that the

given triple’s object will contain the speciﬁc class

value, making a mapping to certain classes possi-

ble. In the application proﬁle graph, every triple with

the “sh:targetClass” property is then iterated through.

Note that this iteration has to furthermore support im-

plicit class targets, which are deﬁned by being an in-

stance of “sh:NodeShape“ and “rdfs:Class“. If a sim-

ilar match between the iterated triple class identiﬁer

and the triple class identiﬁer can be made, a deﬁni-

tion describing that the triple subject is an instance

of (“a”) the iterated triple class identiﬁer is returned.

This similarity is further being extended by looking

KDIR 2021 - 13th International Conference on Knowledge Discovery and Information Retrieval

176

at the label deﬁnition of the iterated triple subject and

matching this to the triple class identiﬁer. If a simi-

lar match can be made, the instance deﬁnition is also

being returned.

Algorithm 1: An algorithm for mapping metadata values to

an application proﬁle.

1: function APMAPPING

2: applicationProﬁle ← RDF as Graph

3: t ← RDF Triple

4: if t.pred contains “class” then

5: for tar ← Triples with “sh:targetClass”

in applicationProﬁle do

6: if t.obj similar to tar.obj then

7: return (t.sub, a, tar.obj)

8: for label ← Triples with tar.sub

and “rdfs:label” in applicationProﬁle do

9: if t.obj similar to label.obj then

10: return (t.sub, a, tar.obj)

11: else

12: for tar ← Triples with “sh:path”

in applicationProﬁle do

13: if t.pred similar to tar.obj then

14: return (t.sub, tar.obj, t.obj)

15: for label ← Triples with tar.sub

and “sh:name” in applicationProﬁle do

16: if t.pred similar to label.obj then

17: return (t.sub, tar.obj, t.obj)

18: return Null

If the given triple did not contain the term class,

the matching continues by iterating through all prop-

erty deﬁnitions in an application proﬁle and listing ev-

ery triple with a “sh:path” predicate. For every prop-

erty deﬁnition, the object of “sh:path” is compared to

the predicate of the input triple and on similarity, a

deﬁnition of the input triple subject, “sh:path” object

and input triple object is returned since a ﬁtting prop-

erty has been found. When this is not the case, the

“sh:name” deﬁnitions of the “sh:path” subject are it-

erated through and a comparison between the resulted

objects and the input triple predicate is made. If a

similar match can be made, the previous deﬁnition is

returned. The ﬁnal return value, when no similarity

could be determined, is null.

This algorithm is built to scale and therefore pre-

existing solutions for providing the application pro-

ﬁles can be used as a data-source. Therefore, services

like application proﬁle databases could be integrated

to provide the data. Furthermore, since application

proﬁles have a user-deﬁned nature which is not pos-

sible with ontologies, the mapping can be improved

by application proﬁles which ﬁt into the speciﬁc use-

cases (e.g. ﬁtting names for the to be mapped meta-

data).

5 RESULTS

Following the approach, the proposed pipeline and

mapping algorithms were programmed and applied to

the described HDF5 use-case. The source code can

be found under this URL: https://git.rwth-aachen.de/

coscine/research/semanticmapper.

5.1 Outcomes

For the mapping, it was important to further deﬁne

a ﬁtting application proﬁle, since the terms being

used in the use-case were quite specialized so that

given ontologies did not really ﬁt most of the time.

Only sometimes, general terms like “version” could

be mapped to ontologies like “schema.org” (deﬁned

with https://schema.org/version). Therefore, the cre-

ated application proﬁle followed the in section 4.4

deﬁned use-case class structure and contains a num-

ber of deﬁnitions which describe the class relations

and the properties. In ﬁgure 4 part of the class-

based structure is shown. The main focus here is

the “Pipeline” class. Some properties like “origin”,

“units” and “variable” are deﬁned for it and every-

thing is mapped to a custom preﬁx, since no ﬁtting

ontology could be found. Such application proﬁle and

the proposed use-case terms could, however, be pub-

lished in an application proﬁle database, ensuring the

interoperability.

Following the deﬁnition for the “Pipeline” class,

the mapped metadataset utilizing this application pro-

ﬁle can be seen in ﬁgure 5. The similarity method

used here was just a plain string comparison, which

returns true if the values are equal and false if

they are not. The resulting metadataset describes a

group of the HDF5 ﬁle which is represented with

“dcat:Catalog”, maps the previous deﬁned custom

metadata attributes to the metadata properties in the

application proﬁle and links to other groups using

“dcat:catalog”. Furthermore, the class “Pipeline” is

linked to this part of the metadataset using the pred-

icate and object “a ns3:Pipeline” where “ns3” is just

the preﬁx linking to the same base URL as the one de-

ﬁned in the application proﬁle. Lastly, the subject is

a unique identiﬁer describing the unique part of the

HDF5 ﬁle, utilizing a so-called persistent identiﬁer

(PID).

It is important to note that these results are also re-

trieved on a dataset level, where the entry is assigned a

“dcat:Dataset“ class. For these datasets, further appli-

Automatic General Metadata Extraction and Mapping in an HDF5 Use-case

177

custom:PipelineShape

a sh:NodeShape ;

sh:targetClass custom:Pipeline ;

sh:property [

sh:path custom:origin ;

sh:datatype xsd:string ;

sh:name "Origin" ;

sh:maxCount 1 ;

sh:minCount 1 ;

] ;

sh:property [

sh:path qudt:unit ;

sh:datatype xsd:string ;

sh:name "Units" ;

sh:maxCount 1 ;

sh:minCount 1 ;

] ;

sh:property [

sh:path custom:variable ;

sh:datatype xsd:string ;

sh:name "Variable" ;

sh:maxCount 1 ;

sh:minCount 1 ;

] .

Figure 4: A part of the application proﬁle representing a

“Pipeline” class.

hdl:{identifier} a ns3:Pipeline,

dcat:Catalog ;

ns5:pipelineVersion "1.0" ;

ns3:origin "this" ;

qudt:unit "volts" ;

ns3:variable "voltage" ;

dct:identifier "{identifier}" ;

dcat:catalog hdl:{identifier2},

hdl:{identifier3} .

Figure 5: A part of the metadataset which represents a cat-

alog.

cation proﬁles are deﬁned, which detail the respective

properties and classes.

5.2 Discussion

Utilizing the presented mapping approach, the in the

use-case described entities could be mapped to appli-

cation proﬁles. The resulted metadata is of course

only as good as the provided application proﬁles are

and this can be seen in the resulting ﬁgures pretty

well. Furthermore, the results show that the map-

ping between application proﬁles has the advantage

that the requirements can be easily described across

different ontologies, opening up a larger variability

and additionally, because of the customizable nature

of application proﬁles, they can be adjusted or cre-

ated with the to be mapped metadata in mind. This

can be seen in ﬁgure 4 where multiple ontologies are

targeted in an application proﬁle and the names are

used to ﬁt with the to be mapped metadata. Such a

possible combination eliminates part of the need to

deﬁne a full custom ontology for the use-case. How-

ever, there are some downsides since the mapping for

now only supports structures, where there is a key-

value structure that does not need any further link-

ing. When the values specify an instance, the map-

ping currently is too limited to represent this structure.

As an example, a deﬁnition like “qudt:unit” expecting

a “qudt:Unit” instance will not be mapped correctly,

however a future extension of the application proﬁle

mapping could have the potential to tackle such an is-

sue. Lastly, the current dcat structure is deﬁned manu-

ally by the HDF5 Structure Descriptor by linking ev-

ery key-value pair to a speciﬁc group or dataset and

adding the necessary terms. This, however, could also

be deﬁned automatically by the proposed mapping

algorithms if the ﬁtting key-value pairs are present.

Suppose the HDF5 Structure Descriptor would pro-

vide the keys of “identiﬁer”, “dataset”, “catalog”

and “class” tied with the values of “Catalog” and

“Dataset”, the application proﬁle shapes provided for

the dcat ontology would map these entries to their

intended representation. These shapes can be found

here: https://github.com/SEMICeu/DCAT-AP.

6 CONCLUSION

In this paper a method for automatically extracting

and mapping metadata values was presented and val-

idated on an HDF5 use-case. The presented method

makes use of previous work which created a general

pipeline deﬁnition for extracting metadata and ex-

tended it by giving a concrete implementation of the

metadata mapping part. This novel concrete metadata

mapping implementation method can receive applica-

tion proﬁles and based on them produces interopera-

ble metadata by looking at the closest matches. The

results of this approach show promise and validate the

mapping’s operationality. Therefore, this approach

has implications for generally mapping metadata val-

ues when a number of ﬁtting application proﬁles are

present.

7 FUTURE WORK

Following on this work, a couple of open questions

are still left which can be answered by some future

work. First, this method assumes to be generally us-

able when given ﬁtting application proﬁles, however

KDIR 2021 - 13th International Conference on Knowledge Discovery and Information Retrieval

178

validating this on a couple of other use-cases with e.g.

more detailed application proﬁles would be interest-

ing to see the limitations and the computational ef-

ﬁciency. Comparing the “FAIRness” of datasets by

utilizing or not utilizing this method could addition-

ally show the effectiveness. Furthermore, the current

similarity determination is very simple. Therefore, it

might be interesting how different similarity measures

compare against each other in the approach. Things

like checking if a label only contains certain words

or going further and determining similarity based on

a created word embedding might all be valid options

which could improve the method and ease its use. The

method could furthermore be extended to addition-

ally utilize RML mapping deﬁnitions, this was in this

work however a bit out of scope. Lastly, the current

implementation and results utilize labels which are ﬁt-

ting based on the deﬁned name in the HDF5 ﬁle which

could be improved by a custom mapping property.

ACKNOWLEDGEMENTS

The work was partially funded with resources granted

by Deutsche Forschungsgemeinschaft (DFG, Ger-

man Research Foundation) – Project-ID 432233186

– AIMS.

REFERENCES

AtomGraph (2019). JSON2RDF. https://github.com/

AtomGraph/JSON2RDF.

Ben De Meester, Pieter Heyvaert, and Thomas Delva

(2021). RDF Mapping Language (RML).

Das, S., Sundara, S., and Cyganiak, R. (2012). R2RML:

RDB to RDF mapping language. W3C recommenda-

tion, W3C. https://www.w3.org/TR/2012/REC-r2rml-

20120927/.

onewald, M., Mund, P., Bodenbrenner, M., Fuhrmans,

M., Heinrichs, B., M

uller, M. S., Pelz, P. F., Marius,

P., Preuß, N., Schmitt, R. H., and St

acker, T. (in press

2021). Mit AIMS zu einem Metadatenmanagement

4.0: FAIRe Forschungsdaten ben

otigen interoperable

Metadaten.

Harrow, I., Balakrishnan, R., Jimenez-Ruiz, E., Jupp, S.,

Lomax, J., Reed, J., Romacker, M., Senger, C., Splen-

diani, A., Wilson, J., and Woollard, P. (2019). On-

tology mapping for semantically enabled applications.

Drug Discovery Today, 24(10):2068–2075.

Heinrichs, B. and Politze, M. (2020). Moving Towards a

General Metadata Extraction Solution for Research

Data with State-of-the-Art Methods. 12th Interna-

tional Conference on Knowledge Discovery and In-

formation Retrieval.

Iglesias, E., Jozashoori, S., Chaves-Fraga, D., Collarana,

D., and Vidal, M.-E. (2020). SDM-RDFizer. Pro-

ceedings of the 29th ACM International Conference

on Information & Knowledge Management.

Kontokostas, D. and Knublauch, H. (2017). Shapes Con-

straint Language (SHACL). W3C recommenda-

tion, W3C. https://www.w3.org/TR/2017/REC-shacl-

20170720/.

Labra Gayo, J., Prud’hommeaux, E., Boneva, I., and Kon-

tokostas, D. (2017). Validating rdf data. Synthesis

Lectures on the Semantic Web: Theory and Technol-

ogy, 7:1–328.

Ledvinka, M. and Kremen, P. (2020). A comparison

of object-triple mapping libraries. Semantic Web,

11:483–524.

Mattmann, C. and Zitting, J. (2011). Tika in Action.

Perego, A., Beltran, A. G., Albertoni, R., Cox, S., Brown-

ing, D., and Winstanley, P. (2020). Data Catalog

Vocabulary (DCAT) - Version 2. W3C recommen-

dation, W3C. https://www.w3.org/TR/2020/REC-

vocab-dcat-2-20200204/.

Politze, M., Claus, F., Brenger, B. D., Yazdi, M. A., Hein-

richs, B., and Schwarz, A. (2020). How to Manage IT

Resources in Research Projects? Towards a Collabo-

rative Scientiﬁc Integration Environment. European

journal of higher education IT, 1(2020/1):5.

Prabhune, A., Stotzka, R., Sakharkar, V., Hesser, J., and

Gertz, M. (2018). MetaStore: an adaptive meta-

data management framework for heterogeneous meta-

data models. Distributed and Parallel Databases,

36(1):153–194.

Souza, D., Freire, F., and Freire, C. (2017). Enhanc-

ing JSON to RDF Data Conversion with Entity Type

Recognition.

TopQuadrant (2021). Importing Data using Active Data

Shapes. http://www.datashapes.org/active/import.

html#json.

Verborgh, R. and Taelman, R. (2020). Ldﬂex: A read/write

linked data abstraction for front-end web developers.

In Pan, J. Z., Tamma, V., d’Amato, C., Janowicz, K.,

Fu, B., Polleres, A., Seneviratne, O., and Kagal, L.,

editors, The Semantic Web – ISWC 2020, pages 193–

211, Cham. Springer International Publishing.

W3C (2012). OWL 2 Web Ontology Language Doc-

ument Overview (Second Edition). Technical re-

port, W3C. https://www.w3.org/TR/2012/REC-owl2-

overview-20121211/.

W3C (2021). ConverterToRdf - W3C Wiki. https://www.

w3.org/wiki/ConverterToRdf.

Wilkinson, M. D., Dumontier, M., Aalbersberg, I. J. J.,

Appleton, G., Axton, M., Baak, A., Blomberg, N.,

Boiten, J.-W., da Silva Santos, L. B., Bourne, P. E.,

Bouwman, J., Brookes, A. J., Clark, T., Crosas, M.,

Dillo, I., Dumon, O., Edmunds, S., and Evelo, Chris

T. ... Mons, B. (2016). The FAIR Guiding Principles

for scientiﬁc data management and stewardship. Sci-

entiﬁc data, 3:160018.

Wood, D., Lanthaler, M., and Cyganiak, R. (2014). RDF 1.1

Concepts and Abstract Syntax. W3C recommenda-

tion, W3C. https://www.w3.org/TR/2014/REC-rdf11-

concepts-20140225/.

Automatic General Metadata Extraction and Mapping in an HDF5 Use-case

179
