Ontology for the Semantic Enhancement, Database Definition and

Management and Revision Control

Edward S. Blurock

Blurock Consulting AB, Lund, Sweden

Keywords: Ontology Use Case, Database System, Chemical Kinetics, Experimental Data, Chemical Modelling.

Abstract: This paper describes the use of ontologies interacting with a noSQL database (Google Cloud Firestore) in

multiple capacities in the database system CHEMCONNECT. The motivation is to implement the ‘Data on

the Web Best Practices” as recommended by the W3C (https://www.w3.org/TR/2017/REC-dwbp-20170131/,

2017) in an application within the physical chemistry and instrumentation. First, the ontology provides

semantic enhancement to each database object through meta-data, standard vocabularies and data object

relationships. There is a one-to-one correspondence between the database objects and the ontology objects.

Another use of the ontology is to provide a data-driven model for the creation, provenance and versioning of

database objects. One aspect of this is the use of domain specific templates to guide the construction of the

database objects. The definition of each database object is in a hierarchy of catalog objects, record objects

and components (using the DCAT ontology model). Within each of these object definitions is a link describing

how a create a set of automatically generated RDF objects within the CHEMCONNECT database. The RDFs

facilitate searching the database. To facilitate versioning, data source tracking and data quality control,

operations on the database are organized as transactions. In CHEMCONNECT a transaction has a one to one

correspondence with the underlying JAVA operation in the implementation. Within the transaction definition,

the set of prerequisites and the output of the operation is defined. The use of transactions helps organize and

give semantic enhancement to the set of individual operations within the implementation. The work in this

paper is on-going and as the first use-case is concentrating experimental and theoretical information in the

chemical domain. The implementation is written in JAVA and is using Google Cloud firestore as the database.

1 INTRODUCTION

CHEMCONNECT is database application within the

chemical and instrumentation domain. The

motivation for using ontologies within

CHEMCONNECT (E. S. Blurock 2019; E. Blurock

2021) stems from the W3C recommendations, ‘Data

on the Web Best Practices (Caroline Burle Lóscio

2017). The uses of ontologies with

CHEMCONNECT have multiple roles and goals:

• Ontology Based Data Management: There is a

one-to-one correspondence between ontology

objects and (JAVA) data objects. The ontology

defines objects (Maali and Erickson 2014),

processes (Timothy Lebo, Satya Sahoo, Deborah

McGuinness 2013) and transactions (Ciccarese et

al. 2013). Each object has semantic enhancements

https://orcid.org/0000-0001-9487-3141

to facilitate provenance, data quality, the use of

standard vocabularies, formatting and versioning

within the database.

• Ontology Templates: The ontology provides

templates containing domain specific information

that can be inserted into standard database objects

within the database. In this way the domain

specific knowledge can be enhanced without

having to update the JAVA database

implementation.

• Ontology Driven Data Manipulation: The

JAVA implementation interprets and is driven by

the ontology. All processes, including

transactions, are defined within the ontology.

There is a one-to-one correspondence between all

the functions provided by the web API and the

ontology. The ontology defines the prerequisites

226

Blurock, E.

Ontology for the Semantic Enhancement, Database Deﬁnition and Management and Revision Control.

DOI: 10.5220/0010714300003064

In Proceedings of the 13th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2021) - Volume 2: KEOD, pages 226-233

ISBN: 978-989-758-533-3; ISSN: 2184-3228

(input) needed and the output expected from the

process. The hierarchy of processes and the

human and machine-readable vocabularies within

the process definitions provide meta-data

semantic enhancement. Transactions are a special

case of processes used to promote versioning, data

tracking and data quality within the database.

• Static versus Dynamic Knowledge: The role of

the ontology within CHEMCONNECT is to

capture ‘static’ knowledge, particularly data

structures. The database captures the expanding

data and knowledge within the domain.

The ontology gives a semantic context to the data

in the database following the principles of Ontology

Based Data Management (Lenzerini 2011;

Dehainsala, Pierra, and Bellatreche 2007). In this

respect, the ontology supplements the data within the

database by providing additional information about a

data object that is fixed for all data objects of the same

type. The database object can be seen as an instance

of this object.

The human readable meta-data provided by all

ontology objects provides documentation, comments

and labels that can be used by the user-interface.

Another role of the ontology is as the basis of the

data-driven paradigm of CHEMCONNECT. The

design philosophy is to minimize the catalog object

specificity in the (JAVA) programming by having the

definitions within the ontology drive the data object

manipulation. Within the implementation, the

ontology objects instances are represented as JSON

objects within the database and within the JAVA

implementation. This and the standard meta-data

requirements of each data object promotes domain

specific enhancements through ontology

development rather than JAVA development.

Domain data can be updated in the ontology without

any addition JAVA programming.

The information within the ontology can provide:

• Definition: The ontology provides the definition

of database objects with its sub-parts. The

database object is a specific instance of the object

defined in the ontology. The basic ontology

objects are divided in three types, components,

records and catalog objects.

• Templates: Templates are generalized

information used to fill in domain information,

such as data formats, chemical properties,

instrument properties, procedure steps, etc., into

the general catalog database object instances.

• Concepts: This is the hierarchy of domain

specific concepts and classifications. The

concepts are also used to fill in domain

information in the template.

• Relationships: Within the ontology object, RDF

relationships are defined to link data within

catalog object to facilitate searching for the data.

The ontology information is used for the

automatic creation of database RDFs. These

mapping definitions are provided at every level

of the object definition.

• Transactions: Transactions are the key to data

tracking and versioning. The transaction

definition within the ontology defines

prerequisite (input) objects, essential defining

information, output objects and relationships.

The transaction information provides the

roadmap to automate the creation, manipulation

and ultimately versioning of database objects.

Each database object originates from a

transaction process. In this way, the entire history

of the object, versioning, is documented.

The ontology provides static information

common to each data type within the database. The

database itself is instances of these abstract objects.

The ontology in is used in several capacities.

1.1 Database-Ontology Interaction

The purpose of the ontology definitions is to give

semantic context to objects within the database. The

ontology represents static information giving

definitions, relationships and semantic enhancements

to the objects in the database.

Figure 1: The ontology definition of NameOfPerson.

For example, the ontological definition of a

person’s name (NameOfPerson a record in the

ontology with the identifier, foaf:name) says that

the name should have three components as shown in

Figure 1, where:

• UserTitle: A classification representing the

title of the person (Mr, Dr. Ms., etc.) with the

identifer, foaf:title.

• givenName: A string representing the name of

the person with the identifier,

foaf:givenName.

NameOfPerson

dcterms:hasPart givenName

dcterms:hasPart familyName

dcterms:hasPart UserTitle

Ontology for the Semantic Enhancement, Database Deﬁnition and Management and Revision Control

227

• familyName: A string representing the family

name of the person with the identifier,

foaf:familyName.

A specific database instance of this information,

for example the name “Dr. Edward Blurock”, would

be represented (as a JSON object) as shown in

Figure

Figure 2: A specific instance of NameOfPerson in JSON

format.

Within the database instance, only the ‘essential’

information is given. In the ontology semantic

enhancements are given. Within the database

instance, the (unique) identifiers point to the

corresponding ontology object. For example,

foaf:name points to the NameOfPerson

ontology object. The ontology object gives additional

(static) information about the name of the person:

• rdfs:label: “Name of Person”

• rdfs:comment: “The full name of a

person (including title)”

• dcterms:identifier: “foaf:name”

• skos:altlabel: “pname”

• dc:type: NameOfPerson

In addition, using the

skos:mappingRelation two database RDF’s

(see section RDFGeneration) linking the last name

and the given name to the catalog object.

2 DATA OBJECT DEFINITION

Within the data object definitions are semantic

enhancements promoting the use of descriptive and

structural meta-data and data object formatting as

recommended by the W3C (Caroline Burle Lóscio

2017).

Identifiers and vocabularies, standard when

available, are used within every data object and

component. The meta-data within the data object are

both machine readable and human readable.

The ontology also provides the machine

interpretable formats of each data object, process and

transaction. This is also the key to the use of the

ontology in a data-driven capacity. The JAVA

implementation interprets the ontology which, in

turn, drives the processes.

Through the placement within the ontology

hierarchies of classes and subclasses, structural meta-

data is provided. Data is within the component,

record and catalog structures(Maali and

Erickson 2014), templates are within the Concept

hierarchy(Miles and Bechhofer 2008), processes are

within the prov:SoftwareAgent (Timothy Lebo,

Satya Sahoo, Deborah McGuinness 2013) and

transaction are within the Event(Dublin Core 2012)

hierarchy.

2.1 Common Catalog Information

The ontology structures have a one-to-one

correspondence with data, interface and persistent

database structures. There are basically three levels of

data structures:

 Catalog Structures: These are based on the

DCAT Catalog structure (Maali and Erickson

2014). These are the structures representing the

main data objects to represent the domain.

 Record Structures: Base on the

dcat:record from the DCAT ontology, these

are the records of the catalog. Each record

structure contains several pieces of 'primitive'

information.

 Components: These are basically single string

primitives that make up the record. Numerical

values are strings in the database, but can be

interpreted as numerical objects.

Catalog objects are the top-level objects within

the database. Both catalog objects and records are

compound objects consisting of records and

components.

The total catalog object definition is a hierarchy

of records and components. In the JAVA

implementation and the database, a catalog object is

manipulated and stored as a JSON object.

All catalog instances are subclasses of

SimpleCatalogObject which has the following

information:

• CatalogObjectAccessModify: This is a

reference to which users can modify the catalog

object.

• CatalogObjectAccessRead: This is a

reference to which users can read the catalog

object. If this is “Public”, then all users,

including guest, can access the information.

• CatalogObjectKey: This is a unique key for

the catalog object instance.

foaf:name: {

foaf:title: “Mr.”,

foaf:givenName: “Edward”,

foaf:familyName: “Blurock”

}

KEOD 2021 - 13th International Conference on Knowledge Engineering and Ontology Development

228

• TransactionID: This is a reference to the

transaction (see Section 0) that created the object.

• CatalogObjectOwner: This is the owner of

the catalog object.

This information is key to determining who has

access to the catalog object and how the catalog

object was created.

2.1.1 Access Rights

The access rights, meaning who can read, modify or

even delete the catalog object, is determined by

several keys as shown in Section 0. The keyword in

each these fields (including the owner) has the

following forms:

• Username: This is the username of the account

which has the access rights.

• Consortium: This is a list of usernames have the

same access rights to a set of objects.

• Public: This is everybody.

If several user accounts can access the accounts,

then a consortium is built. The consortium keyword

points to a list of usernames. If the access is a

consortium keyword, then the specific user account

must be in the list.

In searching through the database, part of the

search expression involves joining all the possible

combinations of access rights to the

CatalogObjectAccessRead field. The list of

valid consortiums is formed by those which include

the user account. Basically, an OR operation with this

list of consortiums and the username is appended to

the rest of the search expression.

2.2 Semantic Enhancements

The standard basic information associated with every

ontological object representing data is:

• Labels (rdfs:label) and Comments

(rdfs:comment): These are human

interpretable strings that give semantic

enhancement to the data. These are also useful in

the GUI or in human readable printout.

• Identifiers (dcterms:identifier): This is

a unique ontological identifier specifying that

what follows is the specific data type.

• Alternative label (skos:altlabel): This is

a short label uniquely identifying the data type.

• Type (dc:type): This is the pointer to the datatype

of the object.

2.3 Templates

The ontology in CHEMCONNECT provides

templates to help build and fill in the information in

the catalog objects. There are several important

classes of templates:

• Choices and Classifications: For a given

parameter there could be a list or tree hierarchy

of possible choices.

• Domain Information: The database catalog

object is designed to be very general. The domain

specific information within the ontology is used

to fill in and structure these general catalog data

objects.

• Transactions: This is a set of templates for

operations on the database (see Section 0).

An example of domain specific information is the

specification needed for a scientific instrument. In

CHEMCONNECT, a device is viewed as a system of

subsystems. Within a system definition there are the

set of sub-systems (each with its own system

definition), concepts and keywords associated with

the system’s purpose and domain, and finally a set of

parameters describing specific attributes of the

device. The set of these attributes are designed by the

domain experts as being important characteristics to

distinguish, for example, the ‘same’ instrument from

one lab from another. For a particular system these

attributes could be, for example, dimensions,

configuration, operating ranges, etc.. These attributes

are a condensation and machine-readable form of the

information found in the ‘Experimental Setup’

section of a scientific paper.

3 RDF GENERATION

One type of database object is a Resource Description

Framework (RDF) triplet. The database RDFs are not

static like the ones in the ontology defintion, but grow

with the addition of database objects. A

corresponding RDF database instance (a subclass of

RDFTriple) is added to the database using the

information within the data object. The RDF

definition defines how to create a link between two

pieces of data within the catalog object. Part of the

transaction process is, after the catalog object is

created, to create the corresponding RDFs.

The purpose of the database RDFs is to facilitate

searching and to link up database object instances.

We view the RDF to be an object linked to a

subject by a predicate:

Object -> Predicate -> Subject

Ontology for the Semantic Enhancement, Database Deﬁnition and Management and Revision Control

229

Figure 3: Excerpt from DatabasePerson ontology object.

Figure 4: Excerpt from PersonalDescription Ontology.

Within the ontology RDF definition, a subclass of

RDFMappingDefinition, the class name is the

Predicate name. Within this definition the Object is

identified with skos:member and the Subject is

identified with prov:entity. The object pointed

to by the Subject and Object is searched for within the

current catalog object and its value is substituted in

the RDFTriplet object.

Within a source object, which can be a catalog

object, record object or even a component object, the

RDF defining class is identified with

skos:mappingRelation. The ontology object

that the Object and Subject refer to are either directly

in the source object definition or in the catalog object

where the source object is found.

For example, in Figure 3 we see that one of the records

(dcat:record) in the ontology catalog object

DatabasePerson is PersonalDescription.

Furthermore, looking at the definition of

PersonalDescription in Figure 4, we see that

NameOfPerson is a record. In addition to the components

(dcterms:hasPart) of NameOfPerson (as seen in

Figure 1), there is an additional mapping with the identifier

skos:mappingRelation to the RDF object,

RDFPersonFamilyName, with the elements shown in

Figure 5. Since there are two skos:member links, this

produces two RDFTriple objects. The first has the

following form:

• Object: CatalogObjectKey (a component)

• Predicate: RDFPersonFamilyName

• Subject: familyName (a component)

Since both the Object and Subject are simple

component strings, the catalog object that is produced

is RDFSubjectObjectPrimitive (see

Figure 6)

where the Object, Predicate and Subject are stored in

the ShortStringKey (with identifier

foaf:LabelProperty), RDFPredicate (with

identifer RDFpredicate) and

RDFSubjectClassName (with identifier

rdfsubjectclassname) fields, respectively.

Figure 5: Excerpt from RDFPersonFamilyName.

Figure 6: Excerpt from RDFSubjectObjectPrimitive

ontology.

Using the example that the name of the person is

“Dr. Edward Blurock”, the

RDFSubjectObjectPrimitive, a catalog object, that

would be formed (in JSON form) is shown in Figure

Figure 7: Excerpt from RDFSubjectObjectPrimitive

database object. The entry “catalogkey” represents the

actual unique key for the database object.

The other RDF that is formed is different in two

ways. First it involves a record object as the subject,

namely FirestoreCatalogID. The second is

that this record is not a member of

NameOfPerson, but is found in another place in

the total catalog object DatabasePerson (see

Figure 3). But since the identifiers are unique, the

database object needs only to be systematically

searched for the corresponding element.

Since the subject is a record, it would produce a

RDFSubjectPrimitiveObjectRecord

object, schematically shown in Figure 8 where the

record object is identified as

dcat:CatalogRecord and the actual record for

FirestoreCatalogID is identified with

firestorecatalog.

DatabasePerson

dcat:record PersonalDescription

dcat:record FirestoreCatalogID

dcat:record CatalogObjectKey

PersonalDescription

Dcat:record NameOfPerson

RDFPersonFamilyName

skos:member CatalogObjectKey

skos:member FirestoreCatalogID

prov:entity familyName

RDFSubjectObjectPrimitive

dcterms:hasPart ShortStringKey

dcterms:hasPart RDFPredicate

dcterms:hasPart

RDFSubjectObjectPrimitive {

foaf:LabelProperty: “Blurock”

RDFPredicate: “RDFPersonFamilyName“

rdfsubjectclassname: “catalogkey”

}

KEOD 2021 - 13th International Conference on Knowledge Engineering and Ontology Development

230

Figure 8: Schematic of JSON object

RDFSubjectPrimitiveObjectRecord.

3.1 Searching RDFs

The objects in the database are in a complex

hierarchical structure. Unless one knows where in this

structure the desired object is within the hierarchy,

finding the object may be difficult. The purpose of the

database RDFs is to provide an efficient search

mechanism to find, primarily through keywords,

objects in the database.

The RDF definitions in the ontology as outlined

in the previous section provides an automatic

mechanism to facilitate simple searches through key

objects in the database. The RDFs which are

generated should reflect useful and efficient searches

of the database. For each data object, especially

catalog objects, the designer should decide how the

object will be accessed and what is the most efficient

way to access this information. For example, which

keywords within the information within the catalog

object can be used to access the information.

In the previous example, an RDF was made

linking the last name, “Blurock”, with the full

information of the user (DatabasePerson). In this

case the keyword “Blurock” would be searched in all

the Object fields of the stored RDF, the

foaf:LabelProperty of the RDFs. The question this

RDF answers is ‘Find me all the users with the last

name of Blurock’.

4 TRANSACTIONS

Operations on the database, such as creation,

modification or deletion, are defined within

CHEMCONNECT as transactions. The main

motivation of the use of transactions (a sub-class of

Event, in the dublin-core ontology (Dublin Core

2012)) is to satisfy the W3C requirements (Caroline

Burle Lóscio 2017) for versioning. A

CHEMCONNECT transaction has an associated

process (function), the list of prerequisite transactions

for the process and the output object of the process.

The tree of transactions gives the exact history of the

data. There are transactions for the creation and also

the manipulation, transformation and updating of data

objects. Data quality can be assessed through the

transaction history because the sources can be traced.

Within the implementation there is a one-to-one

correspondence between an operation on the database

and a transaction. The transactions keep track of what

is needed to perform the operation and then what

catalog objects are created by the operation.

Defining operations as transactions gives each

operation an organizational and semantic context.

Database modification through transactions also

gives the history and dependence of the catalog

objects. If an object is dependent on another object

which has been modified, there is the possibility to

reflect the modification of the modified object on

those objects which are dependent on them.

A transaction is defined within the ontology

hierarchy in the ontology as a subclass of dc:Event.

The transaction definition within the ontology has the

following elements:

• The set of prerequisite transactions that need to

be performed before the current transaction can

be executed (dcterms:requires).

• An additional data object having the input

information needed to perform the current

transaction (dcterms:source).

• The catalog object that the transaction produces

(hasOutput).

The prerequisite transaction information can be

used to find the output data (hasOutput) from

previous operations needed to process the current

operation.

The additional data (dcterms:source) links to a

data object giving additional information, not found

in the prerequisites, needed to perform the operation.

This information can, for example come from the user

interface.

Figure 9: Excerpt from CatalogObjectUserAccountEvent.

For example, Figure 9 shows the fields of the

CatalogObjectUserAccountEvent that is

RDFSubjectObjectPrimitive {

foaf:LabelProperty: “Blurock”

RDFPredicate: “RDFPersonFamilyName“

dcat:CatalogRecord: {

firestorecatalog: {

}

CatalogObjectUserAccountEvent

dcterms:requires

CreateDatabasePersonEvent

dcterms:source

ActivityCatalogUserAccount

hasOutput: UserAccount

Ontology for the Semantic Enhancement, Database Deﬁnition and Management and Revision Control

231

needed to create a new user account. This event

requires that the user (DatabasePerson) already

exists and this is ensured by requiring that a specific

CreateDatabasePersonEvent has already

been executed. The corresponding database object

has some of the information needed, such as the

person’s name and other details, but there is some

extra information needed. This is provided by the link

(dcterms:source) to an

ActivityCatalogUserAccount record (see

Figure 11: Excerpt from TransactionEventObject).

All of these records containing the extra information

for transactions are found as a subclass of

ActivityInformationRecord which, in turn

is a subclass of dcat:CatalogRecord. In this

example, this is information needed for the new

account that is not found in the DatabasePerson.

Figure 10: Excerpt from ActivityCatalogUserAccount.

Within the ontology, the general transaction is

defined. In the ontology definition, the ontology

object class is pointed to (by the identifiers shown in

parenthesis above). After each transaction, the

catalog object instance,

TransactionEventObject (see Figure 11), is

created. For a specific transaction instance, specific

objects of that class within the database are pointed to

(again by the same corresponding identifier). The

three records pointed to are links, through database

IDs, to the required transaction instances, the addition

information instance and the output instance. These

IDs are enough to find the respective information.

From the transaction instances, when needed, the

respective output objects from these transactions can

be retrieved.

Figure 11: Excerpt from TransactionEventObject.

4.1 TransactionID

Every catalog object created has the transaction ID as

one of its fields. This provides information about the

objects origins and history through the creating

transaction and its dependencies through the chain of

prerequisites found in the transactions. It also can

provide a search tool for finding all the objects

created by the transaction.

5 CONCLUSION

This paper has outlined several aspects of the

ontology-based database CHEMCONNECT. The

ontology provides information about the database

object instances. The ontology provides semantic

enhancement of database objects through annotations

and relationships defined within the ontology. The

ontology also provides, as in the case of RDF triplet

generation, an automation of the database object

creation. Through transaction definitions, the

ontology also provides a semantic context and

organization to the operations of database

management.

This work is on-going and in a preliminary phase.

The use-case domain is chemical kinetics and

physical organic chemistry.

REFERENCES

Blurock, Edward. 2021. “Use of Ontologies in Chemical

Kinetic Database CHEMCONNECT.” In , 240–47.

https://www.scitepress.org/PublicationsDetail.aspx?ID

=ai7xFiBEN8E=&t=1.

Blurock, Edward S. 2019. “CHEMCONNECT: An

Onotology-Based Repository of Experimental Devices

and Observations.” In . Copenhagen, Denmark.

https://icaita2019.org/index.html#home.

Caroline Burle Lóscio, Bernadette Farias, Newton Calegari.

2017. “Data on the Web Best Practices.” January 2017.

https://www.w3.org/TR/2017/REC-dwbp-20170131/.

Ciccarese, Paolo, Stian Soiland-Reyes, Khalid Belhajjame,

Alasdair JG Gray, Carole Goble, and Tim Clark. 2013.

“PAV Ontology: Provenance, Authoring and

Versioning.” Journal of Biomedical Semantics 4 (1):

37. https://doi.org/10.1186/2041-1480-4-37.

Dehainsala, Hondjack, Guy Pierra, and Ladjel Bellatreche.

2007. “OntoDB: An Ontology-Based Database for Data

Intensive Applications.” In Advances in Databases:

Concepts, Systems and Applications, edited by

Ramamohanarao Kotagiri, P. Radha Krishna, Mukesh

Mohania, and Ekawit Nantajeewarawat, 497–508.

Lecture Notes in Computer Science. Berlin,

ActivityCatalogUserAccount

dcterms:hasPart AuthorizationType

dcterms:hasPart username

TransactionEventObject

dcat:record

RequiredTransactionIDAndType

dcat:record

ActivityInformationRecord

dcat:record

DatabaseObjectIDOutputTransaction

KEOD 2021 - 13th International Conference on Knowledge Engineering and Ontology Development

232

Heidelberg: Springer. https://doi.org/10.1007/978-3-

540-71703-4_43.

Dublin Core. 2012. “Dublin Core Metadata Initiative.”

Dublin Core Metadata Initiative. June 12, 2012.

http://dublincore.org/.

Lenzerini, Maurizio. 2011. “Ontology-Based Data

Management.” In Proceedings of the 20th ACM

International Conference on Information and

Knowledge Management, 5–6. CIKM ’11. New York,

NY, USA: Association for Computing Machinery.

https://doi.org/10.1145/2063576.2063582.

Maali, Fadi, and John Erickson. 2014. “Data Catalog

Vocabulary (DCAT).” January 16, 2014.

https://www.w3.org/TR/vocab-dcat/.

Miles, Alisair, and Sean Bechhofer. 2008. “SKOS Simple

Knowledge Organization System Namespace

Document 30 July 2008 ‘Last Call’ Edition.” August

20, 2008. https://www.w3.org/TR/2008/WD-skos-

reference-20080829/skos.html.

Timothy Lebo, Satya Sahoo, Deborah McGuinness. 2013.

“PROV-O: The PROV Ontology.” 2013.

https://www.w3.org/TR/prov-o/.

Ontology for the Semantic Enhancement, Database Deﬁnition and Management and Revision Control

233
