Intrusion Detection Systems based on Machine Learning

Oumaima Chentoufi

and Khalid Chougdali

National School of Applied Sciences of Kenitra, Ibn Tofail University, Kenitra, Morocco

Department of Computing, National School of Applied Sciences, Ibn Tofail University, Kenitra, Morocco

Keywords: Intrusion detection system, machine learning, classifiers, Principal Component analyses.

Abstract: This paper contains an introduction to intrusion detection systems known as IDS. There are two types of

techniques to detect an intrusion, misuse detection and anomaly detection; both can be used in a

complementary way to increase the system’s efficiency is used for EMERALD, JiNao... It was determined

that using machine learning for IDS is an efficient way to detect attacks, and this paper will provide

information about machine learning and its classifiers.

1 INTRODUCTION

Over the years, the number of attacks on different

networks has increased exponentially, and even

though companies do their best to protect their

network, the intruders always find a loophole, a fault

in the system that they analyse and use to their

advantage in order to attack a system. The constant

growth in technology leads to the appearance of new

and different security techniques, and that is done

either by encrypting the data, using firewalls, or

obtaining an Intrusion Detection System, or many

other techniques to protect the network.

Even though the word “intrusion” is typically

used to describe an attack that has been successful

from the victims’ prospect, an IDS detects attacks no

matter their status, and companies usually use

detection systems not only to protect their network

but also to be informed about the status of the

network in order to correct its vulnerabilities. The

primary purpose of the intrusion detection systems is

to detect if an attack has taken place, whether it is

successful or not, and this system can be in the form

of a software or hardware device; it can also be both

of them. We should make the difference between an

IDS and IPS, the first one being a passive system

that analyses and locates abnormal activities in our

system, the second one (Intrusion Prevention

Systems) is an active system that analyses the

activities, anticipates and prevents the attack based

on the configuration. Intrusion detection can be

manual, which means using a resource to analyse

every activity in our network or automatic. After

detecting an attack, the IDS must save all the

information to help later while generating an alert.

We can identify multiple types of IDS, there are

Network-based IDS (NIDS) where the IDS interpret

and analyse the packets circulating in the network,

Host-based IDS (HIDS) where the IDS analyse

exclusively the information concerning this host,

Network-Node IDS (NNIDS), and this type of IDS

works like NIDS except that it concerns only the

packets intended for a node of the network. There

are also Application-based IDS (ABIDS) where the

IDS controls the interactions between the user and a

program. Finally, the Hybrid IDS (hybrid intrusion

detection system) is a system that analyses

information coming from the machines and the

network; combining both allows us to have better

attack detection.

The purpose of this paper is to explain how we

can make intrusion detection systems more efficient.

In order to do that, we must find a solution to reduce

the dimensionality of the data while still having the

most relevant features.

2 STATE OF THE ART

Intrusion Detection System (IDS) is one of many

efficient ways to protect a network; they are based

on misuse detection or anomaly detection; it can also

use both to have a more efficient system. The first

one is a type of IDS that contains a database of

different signatures of known attacks and tries to

identify an attack by comparing the signatures with

Chentouﬁ, O. and Chougdali, K.

Intrusion Detection Systems based on Machine Learning.

DOI: 10.5220/0010734300003101

In Proceedings of the 2nd International Conference on Big Data, Modelling and Machine Learning (BML 2021), pages 355-359

ISBN: 978-989-758-559-3

355

the collected data. This database should be updated

every time; if an attack signature is not in that

database, we cannot identify the attack later on, and

if not, the number of false negatives increases. The

second one is Anomaly detection, and this type of

IDS analyses the system and defines the “normal”

behaviour; if there is any change in the performance,

it identifies it as an attack, even if it is not, which

means that the number of false positives increases.

Intrusion detection systems are composed of three

principal components.

Figure 1: Schematic model of an intrusion detection

system

The first component being the SENSOR; this

part of the IDS is responsible for collecting the data,

which is later on analysed by the ANALYSER; it

receives all the collected data and defines if an

attack occurred. The third component is the USER

INTERFACE; it displays the data to determine the

system’s behaviour.

In addition to these components, IDS may be

propped by a honeypot that stays visible to the

intruder; it is like a trap that notifies the defenders of

an attempt to access the honeypot by an

unauthorized user. We can use it to identify and

explore the flaws in our system (only if an attack

occurs) while also reducing the false alerts.

The positioning of an ID system must be

optimized and efficient. The IDS can be installed

right before the firewall. This way, the IDS can

identify all the attacks, the downside of this is that

the analysis is too complicated. The IDS can also be

installed in the DMZ, and this way, we can identify

the attacks that were not detected by the firewall.

The third option is to have it right after the firewall,

and it will filter any attacks since most of them are

done from the inside. Moreover, for the usage of

multiple IDS, there are two approaches, the first one

being the centralized approach which simplifies the

implementation and the second one decentralized

approach it helps to reduce the dependence on a

single ID system.

After implanting an IDS, there should be some

type of evaluation to identify if the system is

working. We can identify two techniques of

evaluating an IDS, the first one being TEST

EVALUATION; this test uses not only sequential

intrusions from a single attack but also simultaneous

intrusions from several sessions. This test aims for

three significant objectives: Stress testing, Intrusion

identification, and resource use. The second

technique is the ANALYTICAL EVALUATION;

this evaluation allows us to master the model by

defining the methods. It consists of: Classifying

attacks based on the observed characteristics by the

IDS, collecting and analysing the data and

determining if a particular type of attack can be

detected by the IDS.

We can define two types of vulnerabilities to

take advantage of to create attacks, Network

vulnerabilities, and application vulnerabilities, the

first one is due to a fault in the protocol or its

implementation; it allows the intruder to have

information about the system, while the second one

is due to a software fault.

We can define four general types of attacks:

DOS (denial of service): The IDS is saturated by

data, to avoid this, it is necessary to filter and

correctly stock the data.

R2L: Unauthorized access from a remote machine.

U2R: Unauthorized access to local superuser (root).

Probing: Port scanning.

Furthermore, like any other attack, the intruder

must detect the IDS to attack it. This system can

either be online, which means it detects the attack

simultaneously, or offline, which means the

execution is done periodically and we can only see

the results.

3 MACHINE LEARNING

Machine learning includes building a model from

data through an algorithm. The implementation of

machine learning is based on five big steps:

1/ Obtaining the data

2/ Model realization

3/ Learning phase

4/ Validation phase

5/ Execution phase.

We can identify two types of learning,

supervised and unsupervised learning.

For

supervised learning, the machine learns under

SECURITY

ADMINIST

RATOR

DATA

SENSOR

ANALYZER

USER

INTERFACE

BML 2021 - INTERNATIONAL CONFERENCE ON BIG DATA, MODELLING AND MACHINE LEARNING (BML’21)

356

guidance. We are giving the input data while

knowing exactly how the output should be. We can

identify two types of data, the first one being

Numerical data which is the most used one, and the

second one the categorical data which contains

characters rather than numbers.

For supervised learning, we have Classification

or regression, which will be later on explained. For

unsupervised learning, we do not supervise the

model; in other words we let the model work on its

own to discover the information. It uses machine

learning algorithms that conclude unlabelled data.

For this type of learning, we have clustering, it finds

patterns and groupings from unlabelled data.

Unsupervised learning has more difficult

algorithms than supervised learning, which is logical

since we know little to no information about the

outcome. With unsupervised learning, we are

looking to perform dimensionality reduction.

As already mentioned, classification and

regression are part of supervised learning.

Regression is about continuous values, mapping the

input to some real number as an output.

Classification is the process of taking an input

and mapping it to an output, which will be some

discreet label. The main goal of classification is to

identify the category or class the new data will fall

under. There are six types of classification

algorithms:

KNN (K-nearest neighbours), also known as lazy

learners, is the laziest algorithm in machine learning;

there is little or no prior knowledge about the

distribution of data.

Decision Tree: Starts with a single node, which

branches into possible outcomes forming additional

nodes that lead into other possibilities, this gives it a

tree-like shape. They can be used to map out an

algorithm that predicts the best choice

mathematically.

Random Forest: Uses many decision trees; each one

is different from the other. When we get new data,

we take the majority vote of the ensemble to get the

result.

Naïve Bayes: Works on the principle of Bayes

Theorem and finds the probability of an event

occurring given the probability of another event that

has already happened.

Support Vector Machine (SVM): The Maximal-

Margin classifier is a hypothetical classifier. In

SVM, a hyperplane is selected to best separate the

points in the input variable space by their class.[5]

Logistic Regression: Input values are combined

linearly using weights or coefficient values to

predict an output different from linear regression

because the output being modelled is binary instead

of continuous.

We can take as an example Intrusion detection

systems using a hybrid system DSSVM, meaning

the use of both SVM (Support Vector Machine) and

the distance sum, this approach has been discussed

by Chun Guo, Yajian Zhou, Yuan Ping, Zhongkun

Zhang, Guole Liu and Yixian Yang in the paper A

distance sum-based hybrid method for intrusion

detection. DSSVM is based on integrating two

techniques; the first is used to optimize the learning

performance, and the second to predict. For the

implementation part, they used the KDD’99 dataset

to demonstrate that the detection rate using K-NN is

lower than SVM, and they are both lower than the

detection rate of DSSVM. We can also quote the

paper DDoS Attack Detection Based On Neural

Network written by Jin Li, Yong Liu and Lin Gu,

where they proposed a DDOS detection method

using Learning Vector Quantisation Neural Network

(LVQ NN) where they achieved a 99.732%

recognition rate for host anomaly detection and

compared it to BP Neural network with 89.9%

recognition rate. They have set two types of results;

the first category was normal and the second one

attack. They identified five implementing phases:

Data Set collect system, pre-processing Data Set,

Determining the LVQ NN, training System, and

testing system. The results were obtained by redoing

the same thing ten times for both LVQ neural

network and BP neural network to improve the

authenticity of the results.

4 PROPOSED APPROACH

The Principal Component Analyses (PCA) is used to

reduce the number of variables. The main idea of

PCA is to identify patterns in a data set so it can be

transformed into another data set with lower

dimensions without losing any vital information; the

same is done by altering the variables, also known as

Principal Components (PCs) and are orthogonal.

They are ordered so that the retention of variation

present in the original variables decreases as we

move down the order. So, in general, PCA is a tool

used to reduce features and to lower dimensions

while retraining most of the information and finding

patterns in the data of high dimensions. PCAs’ key

advantages are their low voice sensibility, reduce the

need for capacity and memory.

Let us consider a data set of X= [x

,…,x

where d is the dimensionality of data and n is the

number of training samples. The covariance matrix

Intrusion Detection Systems based on Machine Learning

357

is defined as follow:

∑

HH

1

Where H is defined by:

H





x1µ,x2µ,….,xnµ 2

And µ is the centroid of training data and defined

by:

µ





∑

𝑥𝑖





3

The covariance matrix ∑

is a symmetric matrix. If

the dimensionality is large (d>> n), with n the

number of training samples, then the computation of

EVD (eigenvalue decomposition) of ∑

becomes a

slow procedure. In this case, we can use either the

SVD based PCA or QR based PCA.

SVD stands for Singular Value Decomposition,

and it is a technique for dimension reduction using

multiple mathematical transformations to classify

the data into simpler linearly independent

components and minimize the reconstruction errors.

So, for the SVD based PCA, the decomposition will

be applied to the matrix H.

Furthermore, based on what has been discussed

by Alok Sharma, Kuldip K. Paliwal, Seiya Imoto

and Satoru Miyano, on the paper Principal

component analysis using QR decomposition, QR

based PCA uses the rectangular matrix (where d>>n)

to carry out the eigenvalue decomposition (EVD) of

the covariance matrix in a numerically stable

manner. The rectangular matrix H defining the

covariance matrix can be decomposed into

orthogonal matrix Q

and upper triangle matrix R

using QR decomposition, which will give:

H Q

4

Substituting it in the first equation of the covariance

matrix, they will have:

∑

 Q

5

Moreover, by using SVD, the matrix R

will be

written as follow:

 U

6

The final equation for the covariance matrix is:

∑

 Q

7

Or ∑

 Q

8

Based on their implementation and simulation parts,

it has been concluded that using QR based PCA is

computationally more efficient and faster than the

SVD based PCA.

The number of attacks has grown exponentially,

which means that we must always be up to date in

our defending mechanisms. Using intrusion

detection systems is one of many efficient ways to

protect a network, and machine learning is becoming

the most training field of this century; it is starting to

redefine the way we live. So, using IDS and

combining it with machine learning will make a more

efficient system. Moreover, we can combine a

classification method and principal component

Analyses. The QR based PCA will be used to

optimize the data while the classifier will be used as

a model for the prediction of the output, i.e., to

define if it is a true negative (TN), false negative

(FN), false positive (FP), or false negative (FN),

which means it will identify if there was an actual

attack or just a false alarm. We will have two sets of

data, and from the training data we will extract the

features using QR based PCA to compare then with

the information from the test data by using a

classifier to define the output.

Figure 2: Schematic model of the proposed approach

We can define the efficiency of IDS by its detection

rate (DR) and the false positive rate (FPR); the first

one should be high and the second one low.

𝐷𝑅 





∗100 9

𝐹𝑃𝑅 





∗100 10

TRAINING

DATA

RESULTS

CLASSIFIER

FEATURES PCA

TEST

DATA

PCA

BML 2021 - INTERNATIONAL CONFERENCE ON BIG DATA, MODELLING AND MACHINE LEARNING (BML’21)

358

5 CONCLUSION

This paper introduces the intrusion detection

systems explaining their functioning, the principal

component analyses, and machine learning. The

main obstacle is the high dimensionality of the

collected data, which is why the use of different

techniques of dimensionality reduction will help us

have the most efficient Intrusion Detection System.

In order to do so, we can use a hybrid classifier and

that is by combining several machine learning

techniques which will provide high classification

accuracy. So, we will use the QR based PCA

because it will be faster and more efficient, and there

will not be any loss of important information, and

we will use another classifier. This technique will

help us obtain a FPR as low as possible and the

highest possible DR.

REFERENCES

Winursito, A., Hidayat, R., Bejo, A., & Utomo, M. N. Y.

(2018). Feature Data Reduction of MFCC Using PCA

and SVD in Speech Recognition System. 2018

International Conference on Smart Computing and

Electronic Enterprise.

Hadri, A., Chougdali, K., & Touahni, R. (2016). Intrusion

detection system using PCA and Fuzzy PCA

techniques. 2016 International Conference on

Advanced Communication Systems and Information

Security (ACOSIS).

Li, J., Liu, Y., & Gu, L. (2010). DDoS attack detection

based on neural network. 2010 2nd International

Symposium on Aware Computing

Sharma, A., Paliwal, K. K., Imoto, S., & Miyano, S.

(2012). Principal component analysis using QR

decomposition. International Journal of Machine

Learning and Cybernetics, 4(6), 679–683.

Guo, C., Zhou, Y., Ping, Y., Zhang, Z., Liu, G., & Yang,

Y. (2013). A distance sum-based hybrid method for

intrusion detection. Applied Intelligence, 40(1), 178–

188.

Doctorat de l’Université de Toulouse : Evaluation des

systèmes de détection d’intrusion. Soutenue par

Mohammed El-Sayed GADELRAB(2008).

Nathalie Dagorn. Rapport de recherche Détection et

prévention d’intrusion : présentation et limites

Liran LERMAN, Université libre de Bruxelles _Les

systèmes de détection d'intrusion basés sur du

machine learning.

J.Allen ,A. Christie ,W. Fithen, J. McHugh, J. Pickel &Ed

Stoner(January 2000) State of the Practice of Intrusion

Detection Technologies.

Labib, K., & Vemuri, V. R. (2006). An application of

principal component analysis to the detection and

visualization of computer network attacks. Annals of

Telecommunications - Annales Des

Télécommunications, 61(1-2), 218–234.

Math.univ-toulouse.Analyse en composante Principal.

Andy Liaw and Matthew Wiener (December 2002).

Classification and Regression by randomForest.

Intrusion Detection Systems based on Machine Learning

359
