Mitigating the Zero Biased Steering Angles in Self-driving Simulator

Datasets

Muhammad Ammar Khan

, Khawaja Ghulam Alamdar

, Aiman Junaid

and Muhammad Farhan

DSSE-Dhanani School of Science & Engineering, Habib University, Pakistan

Keywords:

Autonomous Cars, Self Driving, Udacity Simulator, Zero-bias Steering Angle.

Abstract:

Autonomous or self-driving systems require rigorous training before making it to the roads. Deep learning is

at the forefront of the training, testing, and validation of such systems. Self-driving simulators play a vital role

in this process not only due to the data-intensiveness of the deep learning algorithm but also due to several

parameters involved in the system. The data generated from self-driving car simulators have an inherent

problem of large zero-bias due to the discrete nature of computation arising from computer input devices. In

this paper, we analyze this problem and propose ﬁltering to make the steering angles in the dataset smoother

and to remove random ﬂuctuations that make our model learn better. After such processing, the test run on

simulators showed promising results using a signiﬁcantly small dataset and a relatively shallow network.

1 INTRODUCTION

With the growing ﬁeld of autonomous learning, self-

driving cars are emerging as a center of focus for au-

tomobile industries. The current trend of the auto-

motive industry combined with research by the major

tech companies e.g., Apple, Ford, NVIDIA, proves

that self-driving cars are the future (Greenblatt, 2016).

Google is one of the leaders in self-driving cars, based

on its strong foundation in artiﬁcial intelligence. It al-

ready tested two self-driving cars on the road in June

2015. The current development is that Google vehi-

cles have accumulated more than 3.2 million km of

tests, becoming the closest to the actual use. Tesla is

another company that has made signiﬁcant progress

in this ﬁeld. It was the ﬁrst company to devote self-

driving technology to production. Followed by the

Tesla models series, its “auto-pilot” technology has

made breakthroughs in recent years. There are sev-

eral other Car and Internet companies like Zenuity, es-

tablished by the collaboration of Sweden, Volvo, and

Autoliv, committed to the security of self-driving cars

and have devoted their research towards this growing

ﬁeld (Coelingh et al., 2018).

https://orcid.org/0000-0002-7591-7548

https://orcid.org/0000-0002-2137-7208

https://orcid.org/0000-0002-4394-6133

https://orcid.org/0000-0002-8244-8313

One of the major aspect in success of self-driving

cars hinges on learning human sub-cognitive skills.

Behavioral cloning is a method through which it is

done and in recent years, several deep learning-based

behavioral cloning approaches have been developed

in the context of self-driving cars. Training such deep

networks requires a large dataset which is difﬁcult

to gather. Moreover, extensive testing in a real set-

ting is very hard since a lot of conditions are needed

to be validated by the model i.e., different weathers,

climates, and topographies, which makes it hard for

the researchers to collect dataset for such scenarios

and also test it physically (Hars, 2010). The research

groups trying to build their autonomous car proto-

types run into the same problems, however, this could

pave the way for more productive research including

new sensor setups (i.e. LiDARS) and command and

control systems.

Another challenge in the development of au-

tonomous vehicles is that every day, test ﬂeets around

the world create petabytes of data. Multiple teams

working simultaneously must process, sample, and

utilize this data. Additional design iterations may be

generated by every update during the development cy-

cle. Therefore, simulation remains the best method to

tackle these challenges. Moreover, with the simula-

tor, the beneﬁts and drawbacks of various algorithms

could be thoroughly examined conveniently and with-

out imposing risk to any life in case of model failure

470

Khan, M., Alamdar, K., Junaid, A. and Farhan, M.

Mitigating the Zero Biased Steering Angles in Self-driving Simulator Datasets.

DOI: 10.5220/0010839900003124

In Proceedings of the 17th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2022) - Volume 4: VISAPP, pages

470-475

ISBN: 978-989-758-555-5; ISSN: 2184-4321

(Sharma et al., 2020).

To aid the current research on self-driving cars,

it is necessary to make simulation test-beds for the

trained models which proves to be faster, less expen-

sive, and much more insightful than a regular and

physical prototype. Developing a real-time simula-

tion environment for automatic cars however poses

interesting computing challenges that will enhance re-

search on efﬁcient algorithm building as well.

In this paper, we analyze the inherent problem

with the simulator datasets and propose the method-

ology to deal with it. Utilizing the processed dataset

with the existing architectures for end-to-end learn-

ing yields better results. The rest of the paper is or-

ganized as follows. Section 2 highlights the problem

with the simulator datasets and presents a literature

review on existing techniques to solve the problem.

Section 3 discusses in detail the rationale of the prob-

lem and presents the proposed methodology to solve

it. Section 4 discusses the obtained results and Sec-

tion 5 concludes the paper.

2 LITERATURE REVIEW

When driving a car, we usually experience a straight

road that is being followed for a longer period and

thus, the driver conditionally takes a turn, enabling

the steering wheel to rotate in either direction. This

phenomenon causes the car to usually stay at zero

turn and therefore, during data collection, we get

highly zero biased data, which affects the learning

process. Therefore, the procured dataset needs few

pre-processing steps in order to minimize its negative

effect.

A very simple approach to deal with the over-

represented zero steering angles uses a threshold

which results in elimination of excess zero steering

angles (Upamanyu and I., 2021; Tripathi et al., 2019;

Sokipriala, 2021). Different thresholds are experi-

mented and one that performs the best is selected. A

possible problem in this approach is that there is a

very large bias in simulator datasets which means a

signiﬁcant reduction in dataset. Lokhande et al. elim-

inated 15000 out of 20000 of its data-set. (Lokhande

et al., 2021). Samak et all eliminated seventy per-

cent of the zero-steering data. (Samak et al., 2021)

Due to signiﬁcant reduction in dataset, most of the

authors that used this thresholding method have used

data-augmentation to increase their dataset.

Data augmentation techniques without threshold-

ing method are also used to tackle the issue of zero

bias. Since more turns are desired to be present within

the data, we can simply ﬂip the images with turns

and multiply the steering angle by -1. This would

also ensure that we get same amount of left and right

turns(Koci´c et al., 2019; Bojarski et al., 2018). Fur-

thermore, the images of road turns can be further aug-

mented by adding shadows, dark-spots, or adjusting

brightness to avoid over-ﬁtting of the model while

reusing the same images thus allowing larger dataset

with turns and not just zero angles.

Another method used for eliminating zero bias

is using probabilistic dropping of over-represented

steering angles. In this approach bins of steering an-

gles are created and the average number of samples

per bin is computed. Then a keep probability is cre-

ated for each bin. Keep probability is 1 for bins that

have less samples than the average number of sam-

ples and for others it is number of samples for each

bin divided by average samples per bin(Farag and

Saleh, 2017). This way the over-represented steer-

ing angles are dropped proportionally with their over-

representation. This is a contrasting approach to the

data augmentation approach. A major advantage here

is that the dataset does not increase which makes

learning faster as unnecessary over-represented an-

gles that make learning hard for the model are de-

creased.

A unique technique was also used where during

the dataset collection mode of the simulator, the driver

forcefully kept the car on the edge of the road which

enabled the dataset to be generated with fewer steep

angles and a smooth steering trend overall. This also

minimized the zero bias as mostly the car was taking

small turns instead of being kept in its steady state

(Koci´c et al., 2019). However, this would negatively

impact the overall learning as the model would be

over-ﬁtted on taking turns only at the edge of road

and thus, it would rarely run at the center of the road

and this creates a higher chance of the car getting off

the road.

Each of the above-stated methods have different

disadvantages. In the following Section, we dis-

cuss the inherent problem that causes zero bias in the

dataset that is not addressed by the methods used in

literature.

3 METHODOLOGY

In the ﬁrst subsection we discuss the problem inher-

ent in self driving simulator datasets and the reason

why the earlier described methods from the literature

are unable to cater to them. The subsequent section

focuses on the methodologies to tackle the problem.

Mitigating the Zero Biased Steering Angles in Self-driving Simulator Datasets

471

(a) Challenge Dataset (b) Simulator Dataset

Figure 1: Udacity Dataset Steering Angle Histogram.

(a) Reality (b) Simulator

Figure 2: Driving a Car in Reality vs Simulator.

3.1 The Issues with the Simulator

Datasets

There are two datasets for Udacity self driving cars:

one is the Udacity Challenge Dataset, that comprises

real life driving images, and the second is the Udacity

simulator dataset where data is collected while driv-

ing in the simulator. When the histogram of steering

angles for the two datasets is plotted, the zero-bias

problem seems a bit more exaggerated in the simula-

tor dataset. However, when we increase the quantiza-

tion bins of the histogram, the unique issue with the

simulator dataset is quite visible as shown in Figure

There is a huge zero bias in the simulator dataset

which suggests there must be another reason for it in

the simulator dataset. The zero bias in Udacity chal-

lenge dataset is because of majority of turns being

very mild, whereas the zero bias in simulator dataset

is because of how the data is collected. While driving

on a real road, the driver adjusts the steering angle

continuously and swiftly as shown in Figure 2a. Here

the steering wheel is not rotated drastically but makes

small swift changes. However, driving in a simulator

pressing the turn right/left keys discretely creates a lot

of zero bias as shown in Figure 2b.

As can be seen in the Figure 3, the road has a right

turn. In the simulator the driver presses the turning

keys 4 times in total and the car seems to be correctly

navigating the turn. This is causing the corruption of

our dataset. e.g., if we collect 20 images, they will

all be of a right turn. However, a majority of the cor-

responding steering angles collected will be 0. This

means that the correlation between images and steer-

ing angle is corrupted. Now even if we augment the

images, or drop the images probabilistically to de-

crease zero bias, this problem will be inherent in our

data where many images that are visibly turning right,

will have zero steering angle.

The problem with the simulator dataset was iden-

tiﬁed by (Farag and Saleh, 2017) as well but the ac-

tual problem that causes some data points to make the

learning harder for the model was not discussed. They

created a subroutine to display those frames from the

dataset on which the model does not perform well.

These data-points were found to be miss-labelled and

were manually corrected. Despite this technique be-

ing tedious, it helped improve the results to some ex-

tent. It is apparent that the problem faced by them was

because of the zero bias problems with the simulator

dataset as can be seen in Figure 3.

In Figure 4 a lot of random ﬂuctuations to 0 can

be seen. Although the two techniques of data aug-

mentation and probabilistic dropping work well to re-

duce zero bias in Udacity challenge dataset, they fail

to address the main problem in the Udacity simulator

dataset as stated above. Apart from this, another issue

is the frame sequence preservation. Both the prepro-

cessing methods disrupt the temporal frame sequence

of the data. A growing number of papers have used

LSTMs recently to capture the temporal information

in the data as well since it consists of frames of a tem-

poral video. They have also shown that LSTMs out-

performs its non-LSTM counterpart models. So there

is a need for preserving temporal sequence of data

while addressing the zero bias problem in simulator

datasets.

3.2 Filtering to Smoothen Steering

Angles

We propose smoothing the steering angles as an al-

ternative to data augmentation and probabilistic drop-

ping of data to remove zero bias. We achieve this by

Figure 3: Discrete Turns in Simulator Dataset Creates Zero

Bias.

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

472

a moving average ﬁlter that acts as a low pass ﬁlter

and removes the high ﬂuctuations of angles. We have

used a ﬁlter with n length and all ﬁlter coefﬁcients as

Figure 4: Affect of Moving Average Filter.

Since we are changing y-labels (steering angles),

when we change our length of ﬁlter the input is not

constant hence we can not compare the loss of differ-

ent models with ﬁlters of different n. So we had to

analytically observe how well the car is driving using

the Simulator.

Figure 5: Steering Angle Histogram After Moving Average

Filter.

As can be seen in the histogram in Figure 5, the

steering angle distribution becomes unbiased. How-

ever, our samples still have very few right turns which

could be improved by having larger dataset.

As can be seen in Section 4, the results from the

averaging ﬁlters were acceptable so we also explored

a Gaussian ﬁlter with weighted coefﬁcients. It de-

creases the impact of neighbouring steering angles on

the computation of the current steering angle. Gaus-

sian ﬁlters have been used in preprocessing of self-

driving datasets (Kim and Canny, 2017), but they are

only used to remove sensor noise and mild driver

steering angle ﬂuctuations and did not target the zero

bias issue in simulator datasets that is addressed in

this paper.

The coefﬁcients of simple averaging ﬁlter and

Gaussian ﬁlter coefﬁcients, for a variance of 10 and

length of 40, are shown in Figure 6. The length as

well as the variance of the Gaussian ﬁlter was varied

to observe the performance on the Udacity Simulator

and the results are summarized in Section 4.

(a) Averaging Filter (b) Gaussian Filter

Figure 6: Simple Averaging vs Gaussian Filter Coefﬁcients

for n = 1/40, Variance = 10.

3.3 NVIDIA Architecture

Here we outline the network architecture, used to test

the proposed ﬁltering methodology, which is a minor

revision of the architecture released by NVIDIA for

self-driving cars as shown in Figure 7. The network

consists of 9 layers, including a normalization layer,

5 convolutional layers and 3 fully connected layers.

The input image is split into YUV planes and passed

to the network. Here we omit the ﬁrst layer of the

actual network which performs image normalization

because our preprocessing method already normal-

izes the images before feeding it into the architecture.

The ﬁve convolutional layers were designed to per-

form feature extraction. We use strided convolutions

in the ﬁrst three convolutional layers with a 2×2 stride

and a 5×5 kernel and a non-strided convolution with

a 3×3 kernel size in the last two convolutional layers.

The ﬁve convolutional layers were followed by

three fully connected layers which then output the

steering angles. In order to reduce over-ﬁtting,

dropout (0.2) layer was used. Adam optimizer was

Mitigating the Zero Biased Steering Angles in Self-driving Simulator Datasets

473

Figure 7: NVIDIA Architecture (Bojarski et al., 2018).

used for optimization which requires little or no tun-

ing as the learning rate is adaptive(Bojarski et al.,

2018).

3.4 Post-processing

Since the dataset was initially zero biased, the applied

ﬁlter reduced the proportional gain of the steering an-

gles, causing the car to take accurate but smaller turns.

As a result, the model’s output needed to be tuned so

that the predicted value could be given an appropriate

gain and bias to make it as effective as it was in its

original state.

The results were obtained after such post-

processing as the simulator variables were tuned to

make the car steer near perfectly. Different ﬁlters re-

quired unique tuning. The equation below maps the

acceleration of the car based on steering angle and

speed of the car.

T = 1.0 − (SA)

− (

)

Here, T is throttle, SA is steering angle, S is speed,

and SL is speed limit. Since the ﬁlter was applied

onto the steering angles and is an irreversible opera-

tion, simple manual tuning could be done to attenu-

ate and bias the prediction from the model towards a

much better result. Therefore, the Steering angle was

calculated using following equation:

SA = (predict(image) ∗M) + B,

where predict(image) function sends the captured im-

age to the model and outputs the steering angle, M is

an attenuating constant, and B is a bias. This equa-

tion can be manually tuned to get better results as by

default, M is 1 and B is 0.

4 RESULTS

Since the input to different lengths of averaging ﬁlters

are different, we can not effectively compare losses

between them to determine which works best. The

losses only give us the idea that which ﬁltered data,

the particular value of n, is being learned well by

model. The losses at different values of n ﬁlter length

are shown in Figure 8.

Figure 8: Loss with Different Filter lengths.

Analytically, we ran all the models on Udacity

Simulator to observe which ﬁlter worked the best.

We observed the simulations for the averaging ﬁlter

length n between 10 and 100. The simulations were

run multiple times for each n, and average was taken

to calculate the average time a car stays on track with-

out crashing. The results are summarized in the Fig-

ure 9.

Figure 9: Performance of Car on Udacity Simulator with

Different Filter Lengths.

Then we evaluated the performance of our Gaus-

sian ﬁlter preprocessing method. Performance on the

Udacity simulator was observed for different param-

eters (length and variance) and the length of 40 and

variance of 10 were found optimal where the car took

VISAPP 2022 - 17th International Conference on Computer Vision Theory and Applications

474

multiple laps smoothly over the track. These results

were obtained with a dataset of just 3500 images and

was ran on the NVIDIA architecture for 10 epochs.

This makes the performance even more commend-

able.

5 CONCLUSION

In this paper we analyzed the inherent problem of zero

bias with self driving simulator datasets that was not

adequately addressed before. We proposed ﬁltering

strategies for solving the issue and the results were

found to be acceptable. The zero bias issue can be

further reduced by creating input devices that has less

latency and more frequent feedback from its sensor.

With such devices, our proposed solution could fur-

ther enhance the performance of the model as it par-

ticipates in making the dataset more unbiased com-

pared to its earlier form and therefore, assisting in

simulator based training of such applications.

REFERENCES

Bojarski, M., Testa, D., and et al. (2018). End to end learn-

ing for self-driving cars. In CoRR. arXiv.

Coelingh, E., Nilsson, E., and Buffum, J. (2018). Driving

tests for self-driving cars. In IEEE Spectrum. IEEE.

Farag, W. and Saleh, Z. (2017). Safe-driving cloning by

deep learning for autonomous cars. In International

Journal of Advanced Mechatronic Systems, page 390.

Greenblatt, N. (2016). Self-driving cars and the law. In

IEEE Spectrum. IEEE.

Hars, A. (2010). Autonomous cars: The next revolution

looms. In Thinking outside the box: Inventivio Inno-

vation Briefs. Inventivio.

Kim, J. and Canny, J. (2017). Interpretable learning for

self-driving cars by visualizing causal attention. pages

2961–2969.

Koci´c, J., Jovici’c, N., and Drndarevi´c, V. (2019). Adriver

behavioral cloning using deep learning. In Proceed-

ings of the 17th International Symposium INFOTEH-

JAHORINA (INFOTEH), pages 1–5.

Lokhande, S., Khan, M., and Pandey, G. (2021). Decision

system for a self-driven car. In Journal of Science and

Technology, Vol. 06, Special Issue 01, pages 365–370.

Journal of Science and Technology.

Samak, T., Samak, C., and Kandhasamy, S. (2021). Robust

behavioral cloning for autonomous vehicles usingend-

to-end imitation learning. In arXiv preprint. arXiv.

Sharma, C., Bharathiraja, S., and Anusooya, G. (2020). Self

driving car using deep learning technique. In Inter-

national Journal of Engineering Research & Technol-

ogy. IJERT.

Sokipriala, J. (2021). Prediction of steering angle for au-

tonomous vehicles using pre-trained neural network.

In European Journal of Engineering and Technology

Research, pages 171–176.

Tripathi, R., Vyas, S., and Tewari, A. (2019). Behavioral

cloning for self-driving carsusing deep learning. In

Proceedings of International Conference on Big Data,

Machine Learning and their Applications (ICBMA),

pages 197–209. Lecture Notes in Networks and Sys-

tems.

Upamanyu, K. and I., R. (2021). Effects of image augmen-

tation on efﬁciency of a convolutional neural network

of a self-driving car. In Journal of Student Research.

Vol. 10 issue 2.

Mitigating the Zero Biased Steering Angles in Self-driving Simulator Datasets

475
