Local Explanations for Clinical Search Engine Results

Edeline Contempr

, Zolt

an Szl

avik

, Majid Mohammadi

, Erick Velazquez

Annette ten Teije

and Ilaria Tiddi

Vrije Universiteit Amsterdam, De Boelelaan 1105, 1081 HV Amsterdam, The Netherlands

Keywords:

Explainability, Search, Health Care, Crowdsourcing, Treatment Search.

Abstract:

Health care professionals rely on treatment search engines to efﬁciently ﬁnd adequate clinical trials and early

access programs for their patients. However, doctors lose trust in the system if its underlying processes are

unclear and unexplained. In this paper, a model-agnostic explainable method is developed to provide users

with further information regarding the reasons why a clinical trial is retrieved in response to a query. To

accomplish this, the engine generates features from clinical trials using by using a knowledge graph, clinical

trial data and additional medical resources. Moreover, a crowd-sourcing methodology is used to determine

features’ importance. Grounded on the proposed methodology, the rationale behind retrieving the clinical trials

is explained in layman’s terms so that healthcare processionals can effortlessly perceive them. In addition, we

compute an explainability score for each of the retrieved items, according to which the items can be ranked.

The experiments validated by medical professionals suggest that the proposed methodology induces trust in

targeted as well as in non-targeted users, and provide them with reliable explanations and ranking of retrieved

items.

1 INTRODUCTION

Health care professionals (HCPs) increasingly rely on

Artiﬁcial Intelligence (AI) models to diagnose and,

ultimately, save patients’ lives. In order to use a treat-

ment search engine, HCPs need to gain trust in the

system to ﬁnd treatment options for their patients.

While accuracy, performance, and design are essen-

tial to ensure trust, more may be needed to reach a

threshold where HCPs trust the system enough to use

it in critical scenarios.

Search engines typically provide a ranked list of

the related items with regards to a certain query. How-

ever, lack of explanations could lead to a lack of trust

from users as they would not understand the underly-

ing logic of retrieving an item in response to a query.

In the medical domain, where the pressure to make no

mistakes is high, incorrectly attributing the cause of a

mistake could be fatal. As a result, without the ability

to interpret the model, HCPs’ trust in the model de-

https://orcid.org/0000-0002-1767-121X

https://orcid.org/0000-0002-2781-3795

https://orcid.org/0000-0002-7131-8724

https://orcid.org/0000-0001-9449-8265

https://orcid.org/0000-0002-9771-8822

https://orcid.org/0000-0001-7116-9338

creases and will, ultimately, not use the model’s out-

puts (Pu and Chen, 2006). In addition, due to com-

pliance regulations, most search engines in the med-

ical domain provide unordered lists of related items

in response to a query, making it difﬁcult for users

to look into or distinguish the most relevant items for

their needs. In addition, for an efﬁcient and thorough

search, a status/date/title-based ordering may not al-

ways be the most practical for end users as they tend

to scatter similar results from each other.

A potential solution to provide explanations to

end-users is to apply current explainable methods.

However, providing HCPs with user-friendly, reli-

able, and easy-to-understand explanations is a cur-

rent challenge in the ﬁeld. A major drawback of

current explainability techniques, such as LIME (Das

and Rad, 2020), is that these techniques tend to focus

on aiding users with technical backgrounds to inter-

pret the system, and are designed for machine learn-

ing problems such as classiﬁcation and regression.

HCPs are not universally expected to understand the

detailed workings of a complex retrieval model. Thus,

HCPs require explanations that are high level and un-

derstandable. This opens up an opportunity in which

explanation models can be built in a way that they

are not sensitive to minor changes in the model of a

ContemprÃl’, E., SzlÃ ˛avik, Z., Mohammadi, M., Velazquez, E., Teije, A. and Tiddi, I.

Local Explanations for Clinical Search Engine Results.

DOI: 10.5220/0010982000003123

In Proceedings of the 15th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2022) - Volume 5: HEALTHINF, pages 735-742

ISBN: 978-989-758-552-4; ISSN: 2184-4305

735

search engine. For instance, with a treatment search

engine, we may offer a local explanation such as “the

queried disease is mentioned in the retrieved clinical

trial’s title”. Hence, we use a generic explanation

method that can be tailored to individual search en-

gines’ features.

In this paper, an explainability method is devel-

oped which provides tailored explanations to med-

ical practitioners for retrieved items. To that end,

meaningful features from clinical trials are extracted

from different data sources, and preferences of dif-

ferent users are elicited by utilizing a crowdsourcing-

based methodology. We then put forward a method

to translate preferences into importance level of fea-

tures. Based on features’ importance levels, tailored

explanations are acquired for each speciﬁc query, ac-

cording to which we develop a sentence template in

order to present them to users. In addition, we in-

troduce explainability scores, according to which we

order retrieved items. The results suggest that the use

of local explainability on clinical search engines pro-

mote HCPs trust, search experience, and result order-

ing satisfaction.

2 RELATED WORK

To clarify our vision of explainability, we identi-

ﬁed three main dimensions of explainability that can

be observed throughout researchers’ deﬁnitions: au-

dience, understanding, and transparency. Under-

standing refers to the user’s ability to understand the

model’s results. However, not all users can interpret

all models using explainability as models can be do-

main speciﬁc. For example, users without knowledge

in biology would struggle to understand highly bio-

logical terms generated by a model’s explainability

attempting to diagnose a certain type of lung can-

cer. Likewise, explainable AI (XAI) could use simple

terms, leading to a lack of details for the doctor as-

sessing the diagnosis. The user is therefore required

to have a certain amount of knowledge to understand

the explanation itself, making it crucial for developers

using explainability to target their audience (Rosen-

feld and Richardson, 2019). Lastly, an explainable

method should increase the model’s transparency by

making it more interpretable for its users, and not try

to generate seemingly arbitrary explanations that do

not ﬁt with how the model works (Dimanov et al.,

2020).

Current state-of-the-art local explainability tech-

niques do not use user-friendly explanations. These

current local explainability techniques are either

based on feature importance such as LIME (Das and

Rad, 2020) and SHAP (Lundberg and Lee, 2017),

rule-based (Verma and Ganguly, 2019), saliency maps

(Mundhenk et al., 2019), prototypes (Gee et al., 2019)

example based (Dave et al., 2020), or on counterfac-

tual explanations (Dave et al., 2020). Up to date, fea-

ture importance (Zhang et al., 2019) and rule-based

techniques (Verma and Ganguly, 2019) were used on

search engines, but do not meet the criteria that these

should be user friendly.

LIME is a type of local explainability method

aiming to increase transparency for speciﬁc decisions

given by an opaque model. It explains single result

by letting users know why they are getting this spe-

ciﬁc result over another (Verma and Ganguly, 2019).

Although LIME offers one way to solve the black-

box problem, it has a few limitations. The ﬁrst lim-

itation of using LIME is that it is most commonly

used for linear or classiﬁcation models (Arrieta et al.,

2020). This limits the degree to which the model

can be meaningfully applied to, and restricts itself

to non-user-friendly explanations. Consequently, this

research does not use LIME methods, but developed a

local explainability method to order and generate user

friendly explanations.

3 EXPLAINABLE SEARCH

ENGINE

This section presents the proposed model that pro-

vides explanations for its users, as well as how it

orders a clinical search engine’s results. This en-

ables users to efﬁciently ﬁnd potential relevant clin-

ical trials while understanding the underlying pro-

cesses of the model. The proposed method also gen-

erates local explainability scores for each clinical trial

and uses these scores to order the search engine’s re-

sults. Moreover, users are provided with user-friendly

explanations delivering descriptions of the features

available in each clinical trial.

Figure 1 shows the pipeline of steps conducted

for the proposed methodology. The search engine

takes as input the user’s query, and returns an out-

put with explainability-based ordered results with ex-

planations. Figure 1 shows that the local explainabil-

ity search engine combines resources with the HCP’s

query to engineer features. These features are, there-

upon, attributed local explainability scores which are

used to order the list of clinical trials. In addition, the

engineered features’ outputs ﬁll template sentences.

These explanations provide information to the user on

how much of this clinical trial can the search engine

explain. In the following sub-sections, each module

in Figure 1 is discussed and explained in more detail.

HEALTHINF 2022 - 15th International Conference on Health Informatics

736

Figure 1: Overview of the methods’ pipeline. Resources in-

clude the knowledge graph, data from UMLS, clinical trials

from CT.gov, and data from Pubmed.

3.1 Feature Engineering

Before engineering the features linked to clinical tri-

als, we ﬁrst present the data sources according to

which features for each clinical trial are extracted.

Table 1 provides an overview of the data sources

used in the proposed model. First, we used data from

UMLS (Uniﬁed Medical Language System) (Boden-

reider, 2004), which is an ofﬁcial medical database

where all conditions, diseases, infections, and more,

are associated to Concept Unique Identiﬁers (CUIs).

Second, different clinical trial sources such as clini-

caltrials.gov

are used as it is the biggest clinical trial

repository. Third, the database comprises Pubmed

publications, as it saves medical papers. Lastly, it

comprises data from the company’s conditions graph

(knowledge graph) where parent-child relations be-

tween diseases are deﬁned, terms are speciﬁed, as

well as the clariﬁcation of terms and their synonyms.

Table 1: Description of the data sources for the feature en-

gineering.

Data source Data

UMLS Concept Unique Identiﬁers, disease

terms, and relations between these

clinicaltrials.gov Clinical trials’ detailed descrip-

tions, summaries, phase, title, over-

all status, primary purpose

Pubmed Publications associated to clinical

trials

Knowledge graph Parent-child relationships between

diseases taken from UMLS, dis-

ease concepts (with the diseases’

preferred term and synonyms), lan-

guage.

Table 1 shows the properties, from different data

sources, that were used to engineer features. The

https://www.clinicaltrials.gov/

properties, by themselves, do not measure how ex-

plainable a clinical trial is. Therefore, features were

created using the conditions graph, the UMLS and

pubmed databases to assess how much of a clinical

trial the AI can explain. The engineered features are

provided in Table 2.

Table 2: Classiﬁcation of features created for the local ex-

plainability based search engine.

Feature out-

put type/

Query de-

pendency

Query dependent Query independent Output

Binary query in title, preferred term

in title

clinical stage present, stage

is recruiting, overall status

given

0 or 1

Numeric query in summary, preferred

term in summary, preferred

term in detailed description,

query in detailed description

number of publications Between 0

and inﬁnity

To facilitate the explainability-based calculations,

features were assigned to various categories. Table

2 shows different classiﬁcations where the ﬁrst cate-

gory is based on the user’s query: the feature is either

query dependent or query independent. For example,

the feature query in title is a query dependent feature

as the feature depends on a match between a query

and the title of the clinical trial. In contrast, query

independent features do not depend on the query as

regardless of what the query is, its score remains un-

changed. For example, the feature number of publi-

cations attributed to a clinical trial remains ﬁxed, re-

gardless of user’s query. Second, Table 2 shows en-

gineered features have two distinct outputs which are

either binary or numeric. Binary features assess the

presence of a feature in a study. On the other hand,

numeric features count the occurrence of a feature.

3.2 Feature Importance Identiﬁcation:

A Crowdsourcing Approach

We created a statistical approach to determine the

weights of our features, and conducted a crowdsourc-

ing task on Amazon Sagemaker as an alternative

method to collect data on feature importance. Com-

pliance regulations prohibits pharmaceutical compa-

nies to retain data on its users, especially when these

relate to drugs. However, previous research has

shown that crowdsourcees provided equal quality an-

swers when conducting medical labeling tasks com-

pared to domain experts (Dumitrache et al., 2013; Du-

mitrache et al., 2017). Hence, in this experiment,

1116 responses were collected from participants to

determine users’ feature preferences and, thereupon,

use these to order and explain results returned by the

clinical search engine.

Features’ importance were measured using a cold

start implicit strategy, where we asked participants to

Local Explanations for Clinical Search Engine Results

737

rate explainability sentences. The rating consisted of

assessing sentences on a 5-point Likert-scale, from

”Not convincing at all” to ”Very convincing”. Each

sentence explained the prominence or availability of

a feature mentioned in Table 2.

To identify user-friendly sentence formulations,

we changed the format of the sentences to implic-

itly measure which sentence format was most pre-

ferred to users. The three formulation dimensions

measured were: numeric vs. non-numeric (using en-

tities ‘3 times’ vs. ‘multiple times’ in an explanatory

sentences), action-oriented versus fact-driven formu-

lations (‘retrieved’ versus ‘clearly mentioned’), and

disease speciﬁc versus non-disease speciﬁc outputs

(‘HIV’ versus ‘condition’). Therefore, when partic-

ipants were asked to rate how convincing an explana-

tion was to continue to read the clinical trial in further

detail, we were implicitly measuring how important a

certain feature was for our users.

We hypothesized that search features are not

equally preferred by users. In addition, we hypoth-

esized that the formulation of explanations were not

equally preferred.

3.2.1 Results

Table 3: Features’ means and standard deviations.

Features Mean Std dev

Query in detailed description 3.69 0.82

Query in summary 3.53 0.91

Primary purpose availability 3.53 0.84

Number of publications 3.51 0.92

Stage availability 3.44 0.99

Query in title 3.15 0.93

Trial is recruiting 3.13 1

The results suggest that, in response to feature im-

portance, partial ordering can be obtained via crowd-

sourcing tasks and statistical tests. The results in Ta-

ble 3 illustrate that the feature with the highest mean

score (3.69, on a 5-point Likert scale) was Query in

detailed description, whereas the two least convinc-

ing features were Query in title, and Trial is recruit-

ing (3.15, and 3.13, respectively). We determined the

weights of our features using χ

tests. Table 4 pro-

vides the results of these chi-square tests where, for

example, the features Query in title and Query in sum-

mary were not equally preferred (as the results reveal

a p-value of 0.007).

Table 4: Results of feature labeling task. Note: the results

in bold are statistically signiﬁcant under the assumption p

<0.05.

Features Title Summary Description Publications Stage Recruiting Primary purpose

Title / / / / / / /

Summary 0.007 / / / / / /

Description 0.00002 0.51 / / / / /

Publications 0.02 0.61 0.35 / / / /

Stage 0.038 0.67 0.15 0.88 / / /

Recruiting 0.81 0.006 0.00001 0.01 0.054 / /

Primary purpose 0.012 0.82 0.42 0.82 0.43 0.006 /

Data obtained in response to feature importance

shows that there is at least a partial ordering that can

be obtained via the crowdsourcing (based on statis-

tical tests). We determined the features’ weight, us-

ing χ

tests, based on statistical values. If two fea-

tures were, for example, not statistically equally pre-

ferred, these two features would be attributed differ-

ent weights.

Table 5: Experiment results for entities. Note: the results

in bold are statistically signiﬁcant under the assumption p

<0.05.

Entity x(1) x(2) P-value

(1) Non-numerical

(2) Numerical

3.7 3.34 0.01

(1) Clearly mentioned

(2) Retrieved

3.65 3.33 0.036

(1) Specify disease

(2) Not specify disease

3.4 3.48 0.44

When it comes to results for the three formulation

dimensions (Table 5), when performing χ

tests, we

found that:

• Users prefer explanations without non-numerical

sentences (e.g. sentences mentioning that there

are ’multiple’ articles linked to the clinical trial

vs. ’2’).

• Users prefer factual sentences (‘clearly men-

tioned’) compared to actions related to the search

procedure (‘retrieved’).

• No preferences were found between specifying

the condition in a sentence (e.g. the condition

‘HIV’ was mentioned in the title) versus (‘the con-

dition’).

3.3 Explainability Score: Ordering

Retrieved Items

In this section, we used the importance of the ex-

tracted features to compute the explainability score

for each of the clinical trials and order them ac-

cordingly. To achieve this, features were assigned a

weight, which were then used to calculate the explain-

ability score and, ultimately, the clinical trials were

ordered based on these scores.

Each clinical trial was attributed an explainabil-

ity score based on its features’ availability or occur-

rences. Certain scores were ﬁxed, while others de-

pended on the user’s query. The former are deﬁned as

query independent features, and the latter as query de-

pendent features. As such, query dependent and query

independent features were separately calculated (Ta-

ble 2 reports which features belong to each category).

Although query dependent and query independent

scores were separately calculated, all explainability

HEALTHINF 2022 - 15th International Conference on Health Informatics

738

feature scores, shown as e

, were calculated in the

same manner:

= w ∗ f

where the explainability score for each feature is

determined by the weight w (which depends on if the

feature is binary or numeric, and if it is high or low

importance), and the feature’s score f

. Binary f

scores are identically determined for all binary fea-

tures. If the feature is present; f

= 1, and if the fea-

ture is unavailable; f

= 0. However, numerical fea-

tures f

scores are calculated based on each feature’s

occurrence.

As previously mentioned, the process to calculate

the scores differ for query dependent and query inde-

pendent features. For query dependent features, be-

cause all the terms related to one CUI refer to the

same condition, all e

scores related to one CUI were

grouped per clinical trial:

dtc

∑

dtc

where the explainability scores E for features be-

longing in the category query dependent d were calcu-

lated by grouping features’ score per CUI c for each

clinical trial t. On the other hand, features’ scores

belonging to the query independent category i scores

were calculated as:

∑

where all the E

scores are attributed to their re-

spective studies, and linked to all the study’s CUIs.

Therefore, as long as the HCP queries a condition re-

lated to the clinical trial, the E

score attributed to

that clinical trial will remain unchanged. Finally, this

score will be summed per CUI with its E

, which

will give us our ﬁnal explainability per clinical trial

per CUI:

= E

+ E

dtc

where E

was used to order the clinical trials

by conducting linear feature ranking. Explainability

scores E

range between 0 and 1, where clinical tri-

als with scores close to 1 reﬂect that the search en-

gine can explain more about these clinical trials com-

pared to clinical trials with a score close to 0. Hence,

the clinical trials linked to a CUI (that is queried by

the user) with the highest explainability scores for that

CUI appear higher in the results’ list.

Therefore, the algorithm orders the clinical trials

by their explainability scores e f . To do so, the algo-

rithm takes as input the HCP’s query condition. The

algorithm will then search for the query term in the

database, and identify the CUI associated to the con-

dition. Secondly, the algorithm ﬁlters all clinical trials

to keep studies related to that CUI, therefore provid-

ing a list of all articles related to the condition the

HCP queried. Lastly, the list will be ordered based on

explainability scores e f , where the highest explain-

able scores will receive the highest ordering position,

and the lowest explainability scores will receive the

lowest position.

3.4 Retrieval Explanations

Having extracted the features and computed their im-

portance, this section is dedicated on how to explain

the retrieved items in response to a user’s query. The

explanations must be written in a way that the HCP

can understand them. Therefore, we developed a tem-

plate list of sentences as shown in Table 6. These sen-

tences are simple, user-friendly, hierarchically struc-

tured, short and straightforward.

Table 6: Template sentences created for the explainability

based search engine.

Feature Template sentence

Query in title The condition is mentioned in the title

Preferred term in title The preferred term of the condition is mentioned in the title

Query in summary The condition is mentioned in the summary

Preferred term in summary The preferred term of the condition is mentioned in the summary

Query in detailed description The condition is mentioned in the detailed description

Preferred term in detailed description The preferred term of the condition is mentioned multiple times in the description

Number of publications The clinical trial has multiple publications

Stage availability The clinical trial’s stage is clearly mentioned

Overall status availability The clinical trial’s status is clearly mentioned

Trial is recruiting The clinical trial’s status is recruiting

Sentences were created in the following manner:

1. A maximum of Three Sentences at a Time Are Dis-

played. We assume that, given the limited amount

of time HCPs spend on the search engine, a max-

imum of three sentences will be enough for the

HCP to read.

2. Sentences Are Only Displayed If Certain Condi-

tions Are Met. Given the limited time this research

has, thresholds are determined based on intuitive

knowledge. This allows users to only see relevant

explanations.

3. Sentences Are Ordered by Feature Preference.

The ordering at which sentences are displayed

rely on the results of the experiment described in

sub-section 3.2.1.

4. The Sentences Are Kept Simple. To understand

which formulation of sentences users prefer, we

researched entity preferences as described in sub-

section 3.2.

4 MODEL EVALUATION

We evaluated our model by comparing it to other sim-

ulated clinical search engines based on users’ trust,

search experience, and result ordering satisfaction.

Our hypotheses were that all search engines were

Local Explanations for Clinical Search Engine Results

739

equally preferred in all three dimensions. We, there-

fore, simulated 5 different search engines with differ-

ent city names, where each engine queried either lyme

disease, breast cancer, or HIV:

1. Amsterdam: Search engine with ordered results

and with explainable sentences

2. Berlin: Search engine with ordered results and

without explainable sentences

3. Copenhagen: Search engine without ordered re-

sults and with explainable sentences

4. Dublin: Search engine without ordered results

and without explainable sentences

5. Edinburgh: Search engine with titles ordered by

alphabetical order

The engines used data from myTomorrows

in order

to create scenarios as realistic as possible. The dif-

ferent query concepts were queried in each search en-

gine, for which the top 10 results were extracted and

put into the simulated environments to imitate the ﬁrst

page of a search engine showing 10 results at a time.

4.1 Experiment Setup

55 participants (HCPs and non-HCPs) were recruited

using different social media platforms such as Face-

book, Linkedin, or recruited in the company itself.

Participants received a link to one of the 9 question-

naires focusing on one of the query concepts (either

lyme disease, HIV, or invasive breast cancer). In each

questionnaire, participants were shown one by one the

different simulated search engines related to the query

concept. The different search engines were shown in

a random order. Additionally, participants were asked

to:

• Assess if they trusted the search engine.

– Question asked: When looking at the search en-

gine, how much do you trust the search engine?

– Possible answers: 5-point likert-scale from I

trust this engine very much to I do not trust this

search engine at all.

• Assess if they were satisﬁed with the ordering of

the search engines’ results

– Question asked: When looking at the search en-

gine, are you satisﬁed with the ordering of clin-

ical trials?

– Possible answers: 5-point likert-scale from I

am very satisﬁed with the ordering to I am

highly not satisﬁed with the ordering.

https://search.mytomorrows.com/public

• Assess their search experience while using the

search engine

– Question asked: What is your search experi-

ence when using the search engine?

– Possible answers: 5-point likert-scale from I

have a great search experience to My search

experience is not good at all.

In the end of the questionnaire, participants were

asked to order the different search engines by:

• Trust: users had to order the search engines from

most trustworthy to least trustworthy.

• Result Ordering Satisfaction: users were asked to

order of search engines they preferred from high-

est result ordering satisfaction to lowest result or-

dering satisfaction.

• Search Experience: users were asked to order

the search engines from best search experience to

least favourite search experience.

An example of one of the simulated search en-

gines is shown in Figure 2.

Figure 2: Example of a simulated search engine.

4.2 Results

Table 7: χ

results of the comparison of all search engines

to each other.

All participants HCPs Non-HCPs

Trust 0.29 0.44 0.62

Search experience 0.04∗ 0.09 0.37

Ordering satisfaction 0.31 0.40 0.48

Note: the results in bold italic with a * are statistically signiﬁcant

under the assumption p <0.05. By all participants, we mean

the combination of results of HCPs and non-HCPs.

In the experiment, we asked participants to evaluate

the different search engines one by one and report

their experience. We conducted the χ

test to test

HEALTHINF 2022 - 15th International Conference on Health Informatics

740

our hypotheses that all search engines are equally pre-

ferred in all three dimensions. Table 7 reports the re-

sults and shows that when combining the responses

of HCPs and non-HCPs, the null hypothesis that all

search engines have equal search experience is re-

jected as the test returned a p-value of 0.04. This

suggests that users have different search experiences

when, distinctively, facing the search engines.

The results of the task asking participants to or-

der the search engines from most trusted to least

trusted, and best to worst search experience suggest

that users, both HCPs and non-HCPs, report more

trust and better search experience while using the

search engines using explainability sentences (Ams-

terdam and Copenhagen) compared to search engines

not explaining its results (Berlin, Dublin and Edin-

burgh). The results displayed in Figure 3 demonstrate

these preferences. However, when users scored the

search engines based on their ordering satisfaction,

HCPs ranked last the search engine with explainabil-

ity based ordering without explanations (Berlin) (see

Figure 4). This further demonstrates that failing to ex-

plain how the results’ ordering works leads to reduced

result ordering satisfaction.

Figure 3: Results: order the search engines from most

trusted to least trusted. Note: Results close to 1 indicate

the most preferred search engines. On the contrary, results

close to 5 are the least preferred search engines.

5 DISCUSSION

This research aimed to measure the inﬂuence of

explainability based search engines on users’ trust,

search experience and result ordering satisfaction.

Two experiments were conducted, where the ﬁrst ex-

periment was created to order explainability based

features based on importance. The results were trans-

lated to weights for features to order the results re-

turned by the search engine. The second experiment

evaluated the explainability based search engine by

Figure 4: Results of ordering task: order the search engines

from best ordering satisfaction to worst ordering satisfac-

tion. Note: Results close to 1 indicate the most preferred

search engines. On the contrary, results close to 5 are the

least preferred search engines.

measuring users’ experience with the engine. Over-

all, the results suggest that search engines with expla-

nations are more trusted, provide greater user expe-

rience, and increased ordering satisfaction, compared

to search engines without explanations. In addition,

users are satisﬁed with explainability based ordering

of results if these have explanations, where not ex-

plaining the ordering of results decreases users’ trust,

search experience and ordering satisfaction. Thus, the

results urge developers to explain search engine re-

sults.

When asked to report the preferred order of

search engines, participants consistently preferred in

all three dimensions the search engines Amsterdam

and Copenhagen. The two search engines include

explainability based sentences and ordering, and ex-

plainability based sentences, respectively. However,

we noticed that search engine Berlin scored low, even

last in the dimension of ordering satisfaction with

HCPs. This suggests that explainability based or-

dering is preferred when explained with user-friendly

sentences. This is in line with research in (Pu and

Chen, 2006) as authors demonstrated that explainabil-

ity overall increases trust. A reason is that without ex-

plainability sentences, users understand less the logic

behind the model, and therefore attribute lower scores

to the search engine Berlin. This reasoning is further

emphasized by the signiﬁcant difference in ordering

preference between Dublin and Edinburgh for non-

HCPs, where these prefer Edinburgh given that the

logic of the search engine is straightforward, which

can increase user satisfaction.

Although the model is scalable and generalizable,

the features created for this use case are not transfer-

able to other search engines. Features need to adapt

to other models’ use cases as most features created in

this research are speciﬁc to clinical trials. For exam-

ple, a search engine returning a list of travel destina-

tions would not beneﬁt from the feature ’the clinical

Local Explanations for Clinical Search Engine Results

741

trial is recruiting’. Transferring the model as-it-is to

another set of data would, therefore, require adapt-

ing the method to the different use-case. In addition,

developers would need to collect data on feature pref-

erences for their use-case.

6 FUTURE WORK

Although our model provides explainability sen-

tences, these are not personalized to the proﬁle of

the HCP. In order to make it more personal, results

could be ordered based on the HCP’s proﬁle and pref-

erences. To achieve this, future work should collect

data on user proﬁles, and use machine learning to

identify users’ personal preferences. Moreover, this

could be combined with knowledge graphs to create

a relationship between clinical trials and users’ pro-

ﬁles as shown in (Catherine et al., 2017), where users

were provided personal explanations using a knowl-

edge graph based on item reviews and user proﬁle.

REFERENCES

Arrieta, A. B., D

ıaz-Rodr

ıguez, N., Del Ser, J., Bennetot,

A., Tabik, S., Barbado, A., Garc

ıa, S., Gil-L

opez, S.,

Molina, D., Benjamins, R., et al. (2020). Explainable

artiﬁcial intelligence (xai): Concepts, taxonomies, op-

portunities and challenges toward responsible ai. In-

formation Fusion, 58:82–115.

Bodenreider, O. (2004). The uniﬁed medical language sys-

tem (umls): integrating biomedical terminology. Nu-

cleic acids research, 32(suppl 1):D267–D270.

Catherine, R., Mazaitis, K., Eskenazi, M., and Cohen,

W. (2017). Explainable entity-based recommen-

dations with knowledge graphs. arXiv preprint

arXiv:1707.05254.

Das, A. and Rad, P. (2020). Opportunities and challenges

in explainable artiﬁcial intelligence (xai): A survey.

arXiv preprint arXiv:2006.11371.

Dave, D., Naik, H., Singhal, S., and Patel, P. (2020). Ex-

plainable ai meets healthcare: A study on heart dis-

ease dataset. arXiv preprint arXiv:2011.03195.

Dimanov, B., Bhatt, U., Jamnik, M., and Weller, A. (2020).

You shouldn’t trust me: Learning models which con-

ceal unfairness from multiple explanation methods. In

SafeAI@ AAAI, pages 63–73.

Dumitrache, A., Aroyo, L., and Welty, C. (2017). Crowd-

sourcing ground truth for medical relation extraction.

arXiv preprint arXiv:1701.02185.

Dumitrache, A., Aroyo, L., Welty, C., Sips, R.-J., and

Levas, A. (2013). Dr. detective”: combining gamiﬁ-

cation techniques and crowdsourcing to create a gold

standard in medical text. In Proceedings of the 1st In-

ternational Conference on Crowdsourcing the Seman-

tic Web, volume 1030.

Gee, A. H., Garcia-Olano, D., Ghosh, J., and Paydarfar,

D. (2019). Explaining deep classiﬁcation of time-

series data with learned prototypes. arXiv preprint

arXiv:1904.08935.

Lundberg, S. and Lee, S.-I. (2017). A uniﬁed approach

to interpreting model predictions. arXiv preprint

arXiv:1705.07874.

Mundhenk, T. N., Chen, B. Y., and Friedland, G. (2019). Ef-

ﬁcient saliency maps for explainable ai. arXiv preprint

arXiv:1911.11293.

Pu, P. and Chen, L. (2006). Trust building with explanation

interfaces. In Proceedings of the 11th international

conference on Intelligent user interfaces, pages 93–

100.

Rosenfeld, A. and Richardson, A. (2019). Explainability in

human–agent systems. Autonomous Agents and Multi-

Agent Systems, 33(6):673–705.

Verma, M. and Ganguly, D. (2019). Lirme: locally inter-

pretable ranking model explanation. In Proceedings

of the 42nd International ACM SIGIR Conference on

Research and Development in Information Retrieval,

pages 1281–1284.

Zhang, Y., Mao, J., and Ai, Q. (2019). Sigir 2019 tutorial

on explainable recommendation and search. In Pro-

ceedings of the 42nd International ACM SIGIR Con-

ference on Research and Development in Information

Retrieval, pages 1417–1418.

HEALTHINF 2022 - 15th International Conference on Health Informatics

742
