Predicting Visible Terms from Image Captions using Concreteness and

Distributional Semantics

Jean Charbonnier

and Christian Wartena

Hochschule Hannover, Germany

Keywords:

Information Retrieval, Concreteness, Distributional Semantics.

Abstract:

Image captions in scientiﬁc papers usually are complementary to the images. Consequently, the captions contain

many terms that do not refer to concepts visible in the image. We conjecture that it is possible to distinguish

between these two types of terms in an image caption by analysing the text only. To examine this, we evaluated

different features. The dataset we used to compute tf.idf values, word embeddings and concreteness values

contains over 700 000 scientiﬁc papers with over 4,6 million images. The evaluation was done with a manually

annotated subset of 329 images. Additionally, we trained a support vector machine to predict whether a term

is a likely visible or not. We show that concreteness of terms is a very important feature to identify terms in

captions and context that refer to concepts visible in images.

1 INTRODUCTION

In the NOA prject, we collected over 4.6 million im-

ages from scientiﬁc open access publications. The

nature of this image collection is completely different

from classical image collections, as a large proportion

of the images are close ups, X-Rays and CRT-scans,

etc. Thus image recognition is not a solution to anno-

tate these images and make them available for retrieval.

Instead we select words from the image captions and

from sentences referring to the image. We need to

include sentences mentioning the image since in many

publications the captions are extremely short and do

not contain any terms referring to visible concepts.

Annotation of the images with good keywords is in

turn important to organise the images and to enable

efﬁcient search.

Image-caption pairs in scientiﬁc publications differ

in two ways from image-caption pairs in most datasets.

In the ﬁrst place the nature of the images is differ-

ent from the kind of images in most image analysis

datasets (see e.g. Figure 1). In the second place, in

most datasets we have captions that describe the image.

In terms of Unsworth’s taxonomy (Unsworth, 2007),

the image and the caption are concurrent. For most

image-caption pairs extracted from scientiﬁc publica-

tions the image and the caption are (at least partially)

https://orcid.org/0000-0001-6489-7687

https://orcid.org/0000-0001-5483-1529

complementary and usually the text extends the image.

E.g. in Figure 2 we see that the caption gives a lot of

additional information that is not present in the image.

In a text that is complementary to the correspond-

ing image we will ﬁnd terms that refer to concepts

visible in the image and terms that do not refer to

depicted concepts but deal with the additional, com-

plementary information. In the rest of the paper we

will call the former ones visible terms.

We believe that the text in a complementary image-

text pair gives some clear cues, what words are visible

terms and which are not. Besides typical patterns to

refer to concepts in the image, we expect to see word

concreteness (Paivio et al., 1968) as a key feature to

identifying these words. Thus, our main hypothesis is,

that for image-caption pairs in which text and image

are complementary, concepts in the text represented

by words with high concreteness values are likely to

appear in the image as well.

To verify this hypothesis, we used our corpus of

over 710 000 scientiﬁc papers to train word embed-

dings and generate values for concreteness and idf.

These where then tested on a manually annotated col-

lection of 239 images trying to predict, what terms

from the caption and from the surrounding text de-

scribe objects visible on the image. We do not analyse

the image in any way, but just want to understand the

text and get cues to ﬁnd out which terms describe the

image and which terms give additional information. It

turns out that concreteness of a term is an important

Charbonnier, J. and Wartena, C.

Predicting Visible Terms from Image Captions using Concreteness and Distributional Semantics.

DOI: 10.5220/0011351400003335

In Proceedings of the 14th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2022) - Volume 1: KDIR, pages 161-169

ISBN: 978-989-758-614-9; ISSN: 2184-3228

161


Caption

Photographs displaying microwave irradiated

synthesis of titled compounds.

Terms

photograph, microwave, derivative, reaction

time, result, water, heat, substance, wall, sol-

vent, energy, molecule, mixture, rise, tempera-

ture, thermal conductivity, superheating, rotation,

radiation, research, biginelli reaction, thiourea,

attempt, powers, ﬁnal product, targets, chloro-

form, ethyl acetate, factor, ranges, spectrum, ab-

sorption band, region, stretching, vibration, pro-

ton, signal

Figure 1: Image and caption from Sahoo, Biswa Mohan et al.

"Ecofriendly and Facile One-Pot Multicomponent Synthesis

of Thiopyrimidines under Microwave Irradiation", Journal

of Nanoparticles (doi:10.1155/2013/780786). With terms

extracted from caption and sentences referring to the image.

The bold terms were identiﬁed by the annotators as terms

representing concepts visible in the image.

predictor for a term to appear in the image. Moreover,

we see that inverse document frequency is not a good

predictor.

After discussing the related work in section 2 we

present our dataset in section 3. In section 4 we de-

scribe our approach how to select visual concepts fol-

lowed by a description of our results and ﬁnish in

section 6 with our conclusion and future work.

2 RELATED WORK

Unsworth (2007) studies the relations that can exists

between text and images and deﬁnes a classiﬁcation of

image-text relations. These classes are investigated in

detail in (Martinec and Salway, 2005) and (Otto et al.,

2019).

Concept detection in images and automatic cap-


Caption

Fig. 2 Metal pole (hook) used to pull the crab out

by the catchers in Mucuri-Bahia State

Terms

ﬁgs, metal, poles, hook, crab, catcher, length,

burrow, productivity

Figure 2: Image and caption from Firmo, Angélica M.S.

et al. "Habits and customs of crab catchers in southern

Bahia, Brazil", Journal of Ethnobiology and Ethnomedicine

(doi:10.1186/s13002-017-0174-7). With terms extracted

from caption and sentences referring to the image. The

bold terms were identiﬁed by the annotators as terms repre-

senting concepts visible in the image.

tion generation is a very popular ﬁeld of research. A

widely used dataset with image-caption pairs is Mi-

crosoft COCO (Lin et al., 2014). In this dataset all

captions were written as descriptions of the image.

Thus, these captions are not comparable to captions in

scientiﬁc papers. In fact, for COCO we can assume,

that each term mentioned in the caption refers to a

concept visible in the image: the relation between im-

age and text in COCO and similar datasets is a very

speciﬁc one, not suited to verify our hypothesis.

A huge amount of research was done on image

analysis and object and keyword detection using image

data. This is not the topic of the present paper. For

an overview of work in this area we refer to (Zhao

et al., 2019), who provides an overview of state of the

art methods of object detection with a focus on deep

learning.

Our goal to identify words referring to depicted

terms is most similar to keyword extraction. Algo-

rithms for keyword extractions are well researched.

Turney (2000) and Frank et al. (1999) used a decision

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

162

tree to extract keyphrases based on various features in-

dicating the importance of a term. Besides the classic

features for salience and importance, inverted docu-

ment and term frequency Salton et al. (1975), they also

introduce new features like the position of a word in

the text and features indicating the ’keywordness’, the

suitability of a word as keyword.

Srihari et al. (2000) developed a multimedia in-

formation retrieval system, using various textual and

visual features from the images as well as from their

caption and context. For the image they used face

detection, colour histogram matching and background

similarity. From the text they extract named entities

and picture attributes using Wordnet and tf.idf weight-

ing. Gong et al. (2006) collected 12,000 web pages

with images which were annotated by 5 experts for

their topic. They select keywords for images by com-

bining the importance of a word in a text block and

the distance between the text block and the image.

Gong and Liu (2009) extend this idea and add features

from the images, especially textures generated by a

Daubechies wavelet transformation and a HSL color

histogram. These were then used to get positive and

negatives sets of images for words using a Gaussian

Mixture Model.

Leong and Mihalcea (2009) and Leong et al. (2010)

explore the possibility of automatic image annotation

using only textual features. They use features from

the text, like frequency (tf.idf) and the part of the text

in which the term occurs, as well as features of terms

computed on other datasets, like Flickr and Wikipedia.

These features should help to determine what words

are suited to describe images. Leong and Mihalcea

(2009) coin the likelihood of a term to be used as an

image tag on Flickr the Flickr picturability. Flickr

picturability seems to be very similar to concreteness

and visualness, two well studied properties of words

that are discussed below and that we will use to ex-

tract terms from captions. The main difference to our

work is the different nature of web images and images

from scientiﬁc papers. Flickr picturability does not

ﬁt to our data, while concreteness is a more general,

domain independent concept and also not dependent

on a commercial black box API.

An important indicator for the likelihood of a con-

cept to appear in an image is the visualness of a con-

cept as pointed out by Jeong et al. (2012). Visualness,

often also called imageability or imagery, has been

studied extensively for decades in the psycholinguistic

community. Friendly et al. (1982) deﬁne visualness

as the ease to which a word arouses a mental image

when perceived. Visualness is one of the so called

affective norms that were determined experimentally

for many words. Many studies have shown a very

high correlation between visualness and concreteness

(Paivio et al., 1968; Algarabel et al., 1988; Clark and

Paivio, 2004; Charbonnier and Wartena, 2019). Since

much more data are available for concreteness, we will

use concreteness rather than visualness below. Brys-

baert et al. (2014) describe concreteness as the degree

to which a concept denoted by a word refers to a per-

ceptible entity; Similarly, Friendly et al. (1982) deﬁne

concrete words as words that "refer to tangible objects,

materials or persons which can be easily perceived

with senses". With the help of distributional similar-

ity between words or word embeddings as features

for words, it is possible to predict the concreteness

of words using supervised learning algorithms with a

very high accuracy (Turney, 2000; Charbonnier and

Wartena, 2019).

Concreteness has been used before in multimodal

datasets. Kehat and Pustejovsky (2017) use the occur-

rence of words in such a dataset to predict the con-

creteness of words. Similarly, Hessel et al. (2018)

determine a dataset speciﬁc concreteness for words

using image-text relations and show that retrieval per-

formance is higher for more concrete concepts.

3 DATASET

The dataset that we use for training contains full texts

from over 710k scientiﬁc papers and over 4.6 million

images and their captions from these papers. For eval-

uation 329 images from this collection were manually

annotated with concepts that are visible on the image

(visual terms) and general keywords that describe the

image but that are not necessarily depicted directly.

3.1 Source and Selection

In the NOA project 4.608 million images from 710 000

scientiﬁc publications were collected Most images

are charts, graphs, CT-scans, microscopy images etc.

About 10% of the collected images are photographs

(Sohmen et al., 2018). For each image we took the

image caption and all sentences with a reference to

that image. It was necessary to extend the captions

with referring sentences for two reasons. In the ﬁrst

place in many publications the captions are too short,

consisting just of two or three words. In the second

place, even if the caption is meaningful, the context

might give additional synonyms and related terms that

can be helpful for further processing. From these ex-

tended captions we selected all terms that are used as a

title of an article in the English Wikipedia. Thus, terms

can be a single word or consist of multiple words. The

average number of terms extracted for the images in

Predicting Visible Terms from Image Captions using Concreteness and Distributional Semantics

163

the annotated data set is 25.22. The number of terms

per image ranges from 2 to 226. Table 1 gives the

numbers of terms extracted from the original captions

and from the context.

From the extracted terms the annotators selected

visible terms and keywords. In most cases the over-

lap between keywords and visible terms is very low:

the average Jaccard coefﬁcient between keywords and

visible terms is 0.029.

3.2 Annotation

The images were annotated by two student assistants.

Only images that were classiﬁed as photographs were

presented to the annotators. The annotators were asked

to select visible terms from a list of candidate terms

and keywords, that do not necessarily denote depicted

concept, but are suited to characterise the image as a

whole.

The main guideline for selecting visible terms was

to select any term denoting a concept or thing that is

easily and clearly locatable on the image. I.e. there

should be a clear region on the image depicting the

term. E.g. if we have a picture of a bride and a groom

in a church, we can identify a bride, a priest, etc.,

but not a wedding. However, wedding would be a

good keyword. Usually objects, people, animals etc.

or parts of those turn out to be good candidates for

visible terms. On the other hand adjectives usually are

not suited as visible terms. Also general terms like

object, structure, sphere, surface, coloured are usually

not suited.

The second instruction was, that interpretation and

use of the common knowledge is allowed. If there is

e.g. a human with a shepherd’s crook, in front of sheep,

the term shepherd is justiﬁable.

For keywords the annotators were asked to select

terms that describe the image. Thus a term that is visi-

ble, but is not the main topic of the image should not

be selected. Here more general and abstract concepts

often ﬁt very well.

The annotators were free to skip any image, but

each annotator was obliged to annotate all images se-

lected by the other annotator. We explicitly asked

the annotators to skip images consisting of several

sub-images and images containing text. Most other

skipped images were not annotated because the anno-

tators could not identify anything, either because of

bad image quality or because they were not familiar

with the technical objects on the picture. In total the

annotators selected descriptive terms for 329 images.

An example of an easy to annotate image with a small

number of terms is given in Figure 2.

The complete dataset of annotated images can be

downloaded from http://textmining.wp.hs-hannove

r.de/datasets. Table 2 gives an overview of the main

characteristics of the data set.

The annotation process was perceived as extremely

difﬁcult and time consuming by the annotators, as they

were unfamiliar with many speciﬁc scientiﬁc terms.

Initially, both annotators selected visible terms and

keywords for each image. After this ﬁrst annotation

phase the inter-annotator agreement measured by Krip-

pendorf’s

(Krippendorff, 1970) was

0.57

for key-

words and

0.58

for visual terms. Since the annotators

felt uncertain about their annotations for the visual

terms and were sure to have made many mistakes in

the ﬁrst annotations, we have shown them all images

a second time. In this second phase they worked to-

gether, could discuss the annotations and remove in-

correctly selected terms but not add new terms to their

selection. The inter-annotator agreement for the visual

terms after this correction phase is

0.78

. In the follow-

ing we will always use the union of the selected terms

from both annotators, i.e. we consider a term as a good

visual term (respectively keyword) if it was selected

by one of the annotators.

4 SELECTING VISIBLE

CONCEPTS

One of the most common methods to select character-

istic terms from a text is to use the inverse document

frequency (idf). This is in fact a kind of unsupervised

learning, since the idf values of each term have to be

computed on a collection of training data, but without

any supervision. Other features can be computed in

a similar way. In the classical supervised keyword

extraction approach, discussed above, a supervised

method is used to combine these features in an opti-

mal way. This is of course only possible if enough

training data are available. In order to investigate the

potentials and usefulness of each feature, however, no

training data are required and a smaller set of test data

sufﬁces. For keyword extraction from news texts or

abstracts of scientiﬁc papers idf is known to be always

one of the best features. In the following we will inves-

tigate whether this holds for image captions as well, or

whether other features give better results.

In order to evaluate features, we rank the terms

according to each feature and evaluate these rankings.

For some features we have many terms that get a de-

fault value for that feature. In these cases we cannot

sort the terms when we use only that feature. To solve

this problem, we always randomly shufﬂe all terms

with the same value.

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

164

Table 1: Average number of terms from caption and context per image.

all data annotated data

terms terms vis. term keywords

caption only 6.15 3.31 0.29 0.45

context only 19.77 21.26 1.21 0.50

capt. + cont. 4.20 2.49 0.71 1.14

total 21.49 25.22 2.22 2.10

Table 2: Main characteristics of the data set of scientiﬁc

images, captions, extracted and selected terms.

Number of images 329

Number of extracted terms 8296

Number of selected visual terms 729

Number of selected keywords 691

Number of annotators 2

Inter-annotator agreement (vis. terms) 0.78

Inter-annotator agreement (keywords) 0.57

IDF. We compute the inverse document frequency

on the whole collection of 4.6 Million image terms,

where the set of image terms for each image consists of

all Wikipedia terms extracted from caption and refer-

ring text as described above. We compute the idf value

for a term

idf(t) = log

N−d f (t)

d f (t)

where

d f (t)

is the

number of documents containing

and

the total num-

ber of documents. As a feature we ﬁnally use the nor-

malized idf-value, that is computed as idf

(t) =

idf(t)

logN

Caption Similarity. In the sentences referring to the

image, but also in the caption, we might ﬁnd words

that are not representative for the caption. We measure

the degree of representativity of a term

by computing

the cosine of the word embedding of

and the averaged

embedding of all words in the caption. For this pur-

pose we computed word embeddings using word2vec

(Mikolov et al., 2013) on the full text of over 2 million

papers in our collection.

Concreteness. We assume that concrete words in the

caption are more likely to refer to concepts depicted in

the image than abstract words (see also section 2). We

compute the concreteness of each term using a model

trained on the concreteness values for 37,058 words

from (Brysbaert et al., 2014) as described by Charbon-

nier and Wartena (2019). If, for some reason, we have

no word embeddings for a term, we cannot compute

the concreteness and use the average concreteness over

all words. For terms consisting of several words we

use the maximum of all concreteness values of the indi-

vidual words, assuming that a phrase becomes usually

more concrete when we add additional information.

Pattern. Many captions explicitly mention what is

depicted by using phrases like Picture of an X. In order

to exploit this information we search for the regular

expression:

(photograph(ie|y)?|ct|CT|view|scan|

picture|image)s? of (the|a|an)?

If both the pattern and a term

are found in the cap-

tion, we determine the position of the pattern,

pos

pat

and

pos(t)

the position of

in the caption. We use

pos(t)−pos

pat

as the value for this feature. If either the

term or the pattern is not found the value is

. For most

captions we do not ﬁnd such a pattern and if the pat-

tern is found, most words usually come from referring

sentences and are not found in the caption. Thus this

feature usually is

. The pattern was found only in 18

of 329 captions and thus only can have a small impact

on the overall result.

Position. We assume that image captions follow a

structure where the beginning of the caption describes

the visible content of the image and the end gives more

explanation and back-ground information. Therefor

we expect to ﬁnd the best visual terms/keywords in the

beginning of the caption and weight the terms relative

to their position using

1 −

pos(t)+1

len(caption)

. If the word is not

found in the caption the value is set to

−1

, which is the

case for a large fraction of all terms. The position of a

word in a text is also a common feature for keyword

extraction.

Source. As we can see in Table 1, terms that are

found as well in the caption as in the context are ex-

tremely likely to be a keyword or a visible term. Thus

we introduce a binary feature telling whether the term

was found in one (caption or context) or in two sources

(caption and context). Whether a term is found in the

caption or not is already coded indirectly in the fea-

tures Position and partially in Caption Similarity.

Predicting Visible Terms from Image Captions using Concreteness and Distributional Semantics

165

5 RESULTS AND DISCUSSION

5.1 Results

The effectiveness of each feature for extracting visible

terms and key terms in the test set is given in Table 3

and 4, respectively. Here we report the Area under the

ROC Curve (AUC) and precision and recall for the top

3 results. Furthermore, we also calculated Spearman’s

rank correlation between the results given by each

feature. These results are given in Table 5.

Table 3: Results for the prediction of visible terms. All

values are averages with their standard deviations from the

extraction for 329 captions.

Method AUC Prec@3 Rec@3

IDF 0.57 ± 0.23 0.16 ± 0.21 0.26 ± 0.38

similarity 0.67 ± 0.27 0.26 ± 0.26 0.39 ± 0.49

concr. 0.80 ± 0.19 0.25 ± 0.25 0.52 ± 0.38

pattern 0.52 ± 0.24 0.16 ± 0.21 0.25 ± 0.36

position 0.58 ± 0.25 0.22 ± 0.22 0.35 ± 0.38

source 0.64 ± 0.26 0.22 ± 0.22 0.37 ± 0.39

Table 4: Results for the prediction of keywords. All values

are averages with their standard deviations from the extrac-

tion for 317 captions.

Method AUC Prec@3 Rec@3

IDF 0.64 ± 0.23 0.22 ± 0.24 0.34 ± 0.37

similarity 0.74 ± 0.24 0.35 ± 0.27 0.49 ± 0.37

concr. 0.59 ± 0.25 0.20 ± 0.24 0.29 ± 0.35

pattern 0.54 ± 0.24 0.17 ± 0.23 0.26 ± 0.35

position 0.63 ± 0.26 0.29 ± 0.25 0.42 ± 0.36

source 0.72 ± 0.25 0.36 ± 0.89 0.51 ± 0.39

5.2 Discussion

For the kind of image-text pairs that we consider, we

ﬁnd terms in the text (caption and sentences with an

explicit reference to the image) referring to concepts

visible in the image as well as to concepts not present

in the image. Our hypothesis was, that we can distin-

guish these terms by analysing only the text. We did

Table 5: Spearman correlation between results of each fea-

ture. For the binary features (pattern and source) results with

the same value are ordered randomly.

IDF sim. concr. pattern position

IDF -

sim. 0.328 -

concr. 0.194 0.142 -

pattern 0.017 0.010 0.004 -

position 0.021 0.067 0.065 0.029 -

source 0.057 0.184 0.058 0.057 0.174

not ﬁnd a single feature that perfectly separates the

terms, but concreteness turns out to be a good predictor

for the appearance in the image: In Table 4 we see that

the ranking of terms only according to concreteness

already gives an AUC of 0.80. For selecting good key-

words concreteness is on contrary almost useless. If a

term is mentioned both in the caption and in referring

sentences, it seems indeed to be an important term for

the image and is highly likely to be either a key term

or a visible term. This feature is somewhat speciﬁc

for images in scientiﬁc papers, where we always have

a caption and explicit references to a ﬁgure. A fur-

ther good and more general feature for both extraction

tasks is the similarity of a word with the averaged word

vector of the terms in the caption.

The regular expression described in section 4 is

of course a strong indication if the pattern is present,

unfortunately in most captions no matching pattern is

found at all and thus this feature does not contribute

a lot to the result. Nevertheless, in an application it is

important to use this feature, as no user will understand

that a term X is not present as descriptive term while

the captions explicitly says that it is “a picture of X”.

The position of the word in the caption also seems to

be informative, as was noticed in various studies on

keyword extraction.

Interestingly, we see that inverse document fre-

quency is not a useful feature for the extraction of

visible terms. This contrasts almost all other appli-

cations of keyword extraction. The reason is clear,

when we look at the images and captions in more de-

tail: something quite general can be seen on the image,

e.g., an oak forest, but the caption uses a lot of speciﬁc

terms about experiments or observations not visible on

the picture. In a concrete example of such an image

(Figure 4 of https://www.hindawi.com/journals/isrn/20

11/787181/) the caption contains the following phrase

. . . sites selected for sampling in the wildlife bovine TB

transmission areas: (a) an oak forest where deer fecal

pellets were collected; . . . .

Finally, we see that almost all features are com-

pletely unrelated. For the binary features this is not

surprising since all results with the same feature value

were ordered randomly. Remarkable is the weak cor-

relation between the binary source feature and the sim-

ilarity of word embeddings from the keyword and the

caption: both methods favor frequent words and words

appearing in the caption over words only appearing in

the context. The highest correlation is found between

idf and the similarity feature. This suggests that the

inﬂuence of salient words on the average word em-

bedding of the caption is larger than that of common

words.

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

166

5.3 Supervised Classiﬁcation

Finally, we want to know how good a supervised classi-

ﬁer would perform combining all features. The amount

of training data seems to be quite small. However, the

number of features is small as well and as we consider

the problem of selecting visible terms (and keywords)

as a binary classiﬁcation problem (each term has to be

classiﬁed as being a visible term (or keyword) or not),

we have enough instances to train and evaluate a classi-

ﬁer. As we have selected 8,296 candidate terms for all

images (see Table 2, we have in principle 8,296 cases

to train and evaluate the classiﬁer on. Additionally,

the features for idf, word embeddings and concrete-

ness contain information from much larger datasets.

We evaluate the classiﬁers per image-caption pair and

compute typical measures like precision and recall per

image, since the overall accuracy of course is very

high due to the fact that almost every term is not a

visible term (or keyword).

As a simple, but robust and usually good classiﬁer

we used logistic regression. We also trained Support

Vector Machines (SVM). We used a rbf kernel with the

following hyper parameters

, both for classiﬁcation of

visual terms and key terms:

γ = 1 · 10

−2

C = 10

. In

order to rank the the binary classiﬁcation results, we

sort the terms according to the conﬁdence scores given

by the classiﬁer.

The results for classiﬁcation are given in Table 6.

If we compare these results to those in Table 3

and 4 we see that the combination of he features in-

deed gives better results. For the visible terms there

is only a moderate improvement of the AUC over the

result from concreteness only, emphasising again the

strength of this feature.

If we take a closer look at the results, in many cases

we ﬁnd that the classiﬁer selects a lot of terms that are

too general. E.g. we have an image of a milling cutter

and a setup for automatic visual analysis of a surface

(https://www.hindawi.com/journals/JOPTI/2015/

192030.fig.001b.jpg). Here only the term machine

was selected manually. While machine is already very

general, the classiﬁer selects even more general terms:

’machine’, ’wear’, ’system’, ’tool’.

Another frequent type of error is, that the classiﬁer

predict too many terms, as becomes clear when we

compare Table 1 with Table 6. A typical example is an

image showing the erosion of vegetation on the shore

after a tsunami (https://www.the-cryosphere.net/10/

995/2016/tc-10-995-2016-f07.jpg). The annotators

selected one visible term: cliff. The SVM predicted

a large number of very concrete terms, that indeed

are likely to appear on an image: ’glacier terminus’,

Determined using grid search

’shore’, ’port’, ’tsunami’, ’waves’, ’sea level’, ’beach’,

’lagoon’, ’vegetation’, ’boat’, ’birch’, ’bay’, ’cliff’,

’glacier’, ’shores’, ’ice’. Only shores is here a correct

suggestion, that, however, was not selected by the

annotators in this case.

We also trained a logistic regression classiﬁer that

gave almost the same results as the support vector clas-

siﬁer. In addition now the coefﬁcients learned for each

feature (see Table 7) give some additional insight in the

usefulness of each feature. The coefﬁcients (though

computed only on a small part of the whole dataset)

conﬁrm the picture that we already had: For ﬁnding vi-

sual terms concreteness turns out to be very important.

For the key terms the distributional similarity between

a keyword and the average of all caption words is the

feature with the highest weight. IDF is not important

for either of the tasks. Finally, the pattern looking for

an explicit phrase ’Picture of . . . ’ gets a high weight.

This is not contradicting the low performance of this

feature. If the feature is present, it is a very strong in-

dicator that the following word is depicted, but usually

the pattern is not found it gives no information.

6 CONCLUSIONS AND FUTURE

WORK

We have created a dataset with image-caption pairs

extracted from scientiﬁc open access publications. All

texts and images have a CC-BY or similar liberal copy-

right and can be reused freely. For each image we

extract concepts from the caption and from sentences

referring to the image. For each extracted concept two

annotators decided whether the concept is visible in

the image. The dataset differs from other datasets with

images and captions both in the nature of the images

and in the type of relation between image and text.

We have shown, that we can predict with a consid-

erable level of accuracy what terms from the text are

likely to represent concepts visible in the image with-

out analysing the image. We found that concreteness

of words is a key property for this prediction.

The extraction of visual terms and key terms was

used to annotate our dataset. Some of the images

from the dataset along with the extracted keywords

and categories derived from that were uploaded semi-

automatically to Wikimedia Commons (https://comm

ons.wikimedia.org/wiki/Category:Uploads

from

project). Since all terms are titles from Wikipedia

articles we can collect the wikipedia categories of these

classes. Classes that are covering several keywords

and visual terms are very likely to ﬁt well to the image

and are proposed as a category when the image was

uploaded.

Predicting Visible Terms from Image Captions using Concreteness and Distributional Semantics

167

Table 6: Results for the prediction of visible terms. All values are averages with their standard deviations from the extraction

for 329 captions (317 for keywords) using 5-fold cross validation.

Method AUC Prec Rec # of pred.

Vis. terms 0.84 ± 0.17 0.37 ± 0.28 0.80 ± 0.32 7.4 ± 8.6

Key terms 0.80 ± 0.24 0.44 ± 0.32 0.64 ± 0.38 4.4 ± 3.2

Table 7: Coefﬁcients for features in the logistic regression

models.

Vis. Term Keyword

Feature Coefﬁcient Coefﬁcient

idf 0.00 ± 0.00 0.05 ± 0.01

caption similarity 3.75 ± 0.17 4.49 ± 0.18

concreteness 8.63 ± 0.18 0.47 ± 0.07

pattern 3.03 ± 0.67 1.57 ± 0.57

position 0.39 ± 0.03 1.03 ± 0.31

For future work we plan to use contextualised word

embeddings as features for the term classiﬁcation. We

expect e.g. that the term Fish bone will have different

embeddings in the context Picture of a ﬁsh bone than

in the context . . . extracted from ﬁsh bone. We expect

that a classiﬁer can use these differences to distinguish

depicted from other concepts.

REFERENCES

Algarabel, S., Ruiz, J. C., and Sanmartin, J. (1988). The

University of Valencia’s computerized word pool. Be-

havior Research Methods, Instruments, & Computers,

20(4):398–403.

Brysbaert, M., Warriner, A. B., and Kuperman, V. (2014).

Concreteness ratings for 40 thousand generally known

English word lemmas. Behavior Research Methods,

46(3):904–911.

Charbonnier, J. and Wartena, C. (2019). Predicting word

concreteness and imagery. In Proceedings of the 13th

International Conference on Computational Semantics

- Long Papers, pages 176–187, Gothenburg, Sweden.

Association for Computational Linguistics.

Clark, J. M. and Paivio, A. (2004). Extensions of the Paivio,

Yuille, and Madigan (1968) norms. Behavior Research

Methods, Instruments, & Computers, 36(3):371–383.

Frank, E., Paynter, G. W., Witten, I. H., Gutwin, C.,

and Nevill-Manning, C. G. (1999). Domain-Speciﬁc

Keyphrase Extraction. In Proceedings of the Sixteenth

International Joint Conference on Artiﬁcial Intelli-

gence, IJCAI ’99, pages 668–673, San Francisco, CA,

USA. Morgan Kaufmann Publishers Inc.

Friendly, M., Franklin, P. E., Hoffman, D., and Rubin, D. C.

(1982). The Toronto Word Pool: Norms for imagery,

concreteness, orthographic variables, and grammatical

usage for 1,080 words. Behavior Research Methods &

Instrumentation, 14(4):375–399.

Gong, Z., Cheang, C. W., et al. (2006). Web image indexing

by using associated texts. Knowledge and information

systems, 10(2):243–264.

Gong, Z. and Liu, Q. (2009). Improving keyword based

web image search with visual feature distribution and

term expansion. Knowledge and Information Systems,

21(1):113–132.

Hessel, J., Mimno, D., and Lee, L. (2018). Quantifying the

visual concreteness of words and topics in multimodal

datasets. In Proceedings of the 2018 Conference of

the North American Chapter of the Association for

Computational Linguistics: Human Language Tech-

nologies, Volume 1 (Long Papers), pages 2194–2205,

New Orleans, Louisiana. Association for Computa-

tional Linguistics.

Jeong, J.-W., Wang, X.-J., and Lee, D.-H. (2012). Towards

measuring the visualness of a concept. In Proceedings

of the 21st ACM international conference on Informa-

tion and knowledge management, pages 2415–2418.

ACM.

Kehat, G. and Pustejovsky, J. (2017). Integrating vision

and language datasets to measure word concreteness.

In Proceedings of the Eighth International Joint Con-

ference on Natural Language Processing (Volume 2:

Short Papers), pages 103–108, Taipei, Taiwan. Asian

Federation of Natural Language Processing.

Krippendorff, K. (1970). Estimating the reliability, system-

atic error and random error of interval data. Educa-

tional and Psychological Measurement, 30(1):61–70.

Leong, C. W. and Mihalcea, R. (2009). Explorations in

automatic image annotation using textual features. In

Proceedings of the Third Linguistic Annotation Work-

shop (LAW III), pages 56–59.

Leong, C. W., Mihalcea, R., and Hassan, S. (2010). Text

mining for automatic image tagging. In Coling 2010:

Posters, pages 647–655.

Lin, T.-Y., Maire, M., Belongie, S., Hays, J., Perona, P.,

Ramanan, D., Dollár, P., and Zitnick, C. L. (2014).

Microsoft coco: Common objects in context. In Euro-

pean conference on computer vision, pages 740–755.

Springer.

Martinec, R. and Salway, A. (2005). A system for image–text

relations in new (and old) media. Visual communica-

tion, 4(3):337–371.

Mikolov, T., Sutskever, I., Chen, K., Corrado, G., and Dean,

J. (2013). Distributed representations of words and

phrases and their compositionality. In Proceedings of

the 26th International Conference on Neural Informa-

tion Processing Systems - Volume 2, NIPS’13, pages

3111–3119, USA. Curran Associates Inc.

Otto, C., Springstein, M., Anand, A., and Ewerth, R. (2019).

Understanding, categorizing and predicting seman-

tic image-text relations. In Proceedings of the 2019

on International Conference on Multimedia Retrieval,

ICMR ’19, pages 168–176, New York, NY, USA.

ACM.

KDIR 2022 - 14th International Conference on Knowledge Discovery and Information Retrieval

168

Paivio, A., Yuille, J. C., and Madigan, S. A. (1968). Con-

creteness, imagery, and meaningfulness values for 925

nouns. Journal of Experimental Psychology, 76(1,

Pt.2):1–25.

Salton, G., Yang, C.-S., and Yu, C. T. (1975). A theory

of term importance in automatic text analysis. Jour-

nal of the American society for Information Science,

26(1):33–44.

Sohmen, L., Charbonnier, J., Blümel, I., Wartena, C., and

Heller, L. (2018). Figures in scientiﬁc open access

publications. In Méndez, E., Crestani, F., Ribeiro, C.,

David, G., and Lopes, J. C., editors, Digital Libraries

for Open Knowledge, pages 220–226, Cham. Springer

International Publishing.

Srihari, R. K., Zhang, Z., and Rao, A. (2000). Intelligent

indexing and semantic retrieval of multimodal docu-

ments. Information Retrieval, 2(2):245–275.

Turney, P. D. (2000). Learning Algorithms for Keyphrase

Extraction. Inf. Retr., 2(4):303–336.

Unsworth, L. (2007). Image/text relations and intersemio-

sis: Towards multimodal text description for multilit-

eracies education. In Proceedings of the 33rd IFSC:

International Systemic Functional Congress. Pontifícia

Universidade Católica de São Paulo.

Zhao, Z.-Q., Zheng, P., Xu, S.-t., and Wu, X. (2019). Ob-

ject detection with deep learning: A review. IEEE

transactions on neural networks and learning systems.

Predicting Visible Terms from Image Captions using Concreteness and Distributional Semantics

169
