A Probe into the Influence of Major Infectious Diseases on the Grain

Yield of Each Province based on ε-SVR Method

Xiaoxing Tong

, Liang Meng

and Guo Yu

Department of information technology, Jiaxing Technician Institute, Zhejiang, China

School of Environmental and Geographical Sciences, Shanghai Normal University, Shanghai, China

Keywords: ε-SVR, Major Infectious Diseases, The Grain Yield of The Province That Year, Prediction.

Abstract: The influence of major infectious diseases to the grain yield of the province was investigated by establishing

a new prediction method based on ε-support vector regression(ε-SVR). the train model was built from

historical data, including the grain yield of Beijing, Tianjing etc affected by SARS-CoV in 2003, Guangzhou

in 1961 affected by cholera, Xinjiang in 1986 affected by Hepatitis E. It is proved that γ in radial basis kernel

function is 0.01, penalty coefficient C is 1.0e + 7, loss function P is 10, the average relative error of model

fitting is 1.96%, and the decisive coefficient is 0.99. We predict the production data of Gansu, Shanxi and

Guangdong affected by SARS in 2003 and that of Guangdong affected by break-bone fever in 1978.The

average relative error was 3.27%. However, after removing the two factors of the proportion of the infected

population and the proportion of dead population, the model was built again. The average relative error of

model fitting was 1.97%, and the average relative error of prediction was 3.31%. It shows that the major

infectious diseases only have a small impact on grain yield. This model provides a new method for regional

grain yield prediction and national macro-control in the short term.

1 INTRODUCTION

At the beginning of 2020, the global outbreak of

COVID-19 caused the spread of the virus and the

number of infected people. Due to its robust

infection, the global multi national declaration issued

in early April to stop grain exports to ensure its food

supply. Under the epidemic situation, accurate

prediction of the current year's grain output can help

countries and regions better grasp the development

trend of agricultural ecology, preserve the basic

requirements of people's life, and even stabilize the

people's hearts. Therefore, under the current

situation, the analysis of the relationship between the

epidemic situation and the current year's grain output

has become an urgent questioned relating to people's

livelihood. Although there are many grain prediction

methods in the market, such as Nerlove model,

system dynamics model, IPSO-BP model, time series

model, there are still few studies on regional grain

yield prediction under large-scale infectious diseases,

and lack of theoretical basis for the government to

provide grain macro-control.

In recent years, with the development of artificial

intelligence and machine learning technology, SVM,

an algorithm with strong generalization ability and

wide applicability, has been widely used in the fields

of agricultural production prediction, classification

and image recognition, such as drip irrigation emitter

flow prediction, identification of corn, soybean and

rice, modern Agrometeorological analysis, research

on irrigated cultivated land, research on topographic

data of tea garden, and the final solution of SVM is

convex quadratic programming problem, which is

superior to neural network in dealing with local

extreme value. In this research project, due to the

differences of epidemic viruses, there are some

characteristics, such as more serious outbreaks in

individual regions and mild outbreaks in individual

regions. SVM algorithm is easier to get the global

optimal solution. The traditional SVM algorithm is

only limited to binary classification, ε- SVR is an

algorithm that can expand the regression problem on

the basis of traditional binary classification.

Tong, X., Meng, L. and Yu, G.

A Probe into the Inﬂuence of Major Infectious Diseases on the Grain Yield of Each Province based on E-SVR Method.

DOI: 10.5220/0011356500003440

In Proceedings of the International Conference on Big Data Economy and Digital Management (BDEDM 2022), pages 895-899

ISBN: 978-989-758-593-7

895

2 THEORETICAL BASIS

2.1 SVR and Its Kernel Function

As a binary classification model (non-zero is 1), SVM

is based on the linear classifier with the largest

interval in the feature space. In order to make SVM

use of continuous values as regression prediction, the

SVR model is proposed after optimization by

multiple classification iterations. The existing SVR

models can be divided into the following categories:

Linear kernel function

xxxxK ⋅=),(

(1)

Multiform kernel function

xxxxK ]1)[(),( +⋅=

(2)

Where q is the order of polynomials, the resulting

classifier is a polynomial of order Q.

(3) Radial basis function (RBF)

}||γexp{),(

xxxxK −−=

(3)

The feature of radial basis function (RBF)

classifier is that the center of each basis function

corresponds to a support vector, and the output

weights are automatically determined by the

algorithm. The inner product function is similar to the

neural center characteristics of human brain, and

different S-parameter values have different

classification surfaces.

(4) S-shaped kernel function

])(tanh[),( cxxvxxK

+⋅=

(4)

The kernel function consists of a multilayer

perceptron network with a hidden layer. The weights

of the network and the number of nodes in the hidden

layer are automatically determined by the algorithm,

and there is no problem of local minima bothering the

neural network.

Christopher J.C. Burges has experimented and

compared linear kernel function, polynomial kernel

function and radial basis function, and different

kernel functions have their own advantages and

disadvantages for different databases. There are also

studies based on UCI benchmark database data

analysis, which show that the performance of radial

basis function is slightly better.

In this paper, the radial basis function (RBF) is

determined to be the best kernel function of the

model.

2.2 Important Parameters in Kernel

Function γ, C, P

γ: Set up kernel function γ Value of, with γ The results

show that the test set has a bad effect on classification

and good training classification effect. It is easy to

generalize the error of fit, generally 0.01.

C: Penalty factor C represents how much you

value outliers, the greater C values, the less you want

to lose them. When the value of C is large, the

punishment for error classification increases, while

the punishment for error classification decreases

when the value of C is high. When C is larger and

approaches infinity, it means that the classification

error is not allowed and it is easy to over fit; when C

tends to 0, we are no longer concerned about whether

the classification is correct and is easy to be

undefeated. In this study, the effect of large-scale

infectious diseases can not be ignored because of the

small sample, so the value of C is larger, when the

value is 1.0e+7, the fitting degree of the model

prediction value and original value is the highest.

P represents the parameter B in the loss function

of SVM. The loss function in SVM is defined as the

sum of hinge loss function and a regularization term.

3 GRAIN YIELD PREDICTION

MODEL

3.1 Training Sample

In this paper, the data of grain output of 21 provinces

including Beijing, Tianjin, Hebei, Shanxi and Inner

Mongolia during the SARS epidemic in 2003,

Guangdong Province during the cholera epidemic in

1961 and Xinjiang Province during the hepatitis E

epidemic in 1986 were selected as training samples.

Among them, the number of SARS virus infected in

Beijing was 2434 in 2003, the number of cholera

infected in Guangdong Province was 4319 in 1961,

and the number of hepatitis E infected in Xinjiang

was 119280 in 1986. The absolute number of

infectious diseases was large, which can enhance the

wide applicability of the model.

3.2 Forecast Sample

In this paper, the data of grain output in Guangdong,

Shaanxi and Gansu during the SARS epidemic in

2003 and the data of grain output in Guangdong

during the dengue epidemic in 1978 were selected as

the prediction samples.

BDEDM 2022 - The International Conference on Big Data Economy and Digital Management

896

4 DATA PREPROCESSING AND

METHOD ANALYSIS

4.1 Data Preprocessing

According to the existing research, for the machine

learning method to study the influencing factors of

grain yield, the main factors are the sowing area of

grain crops, the amount of chemical fertilizer, the

effective irrigation area of grain crops and so on.

Considering that the main purpose of this paper is to

study the prediction of grain yield under the epidemic

situation, the factors of epidemic degree, the number

of local farmers (number of rural employees) and the

change trend are added. In recent years, the

development trend of grain yield can cover other

secondary factors such as fertilizer application.

To sum up, the main factors are finally classified

into the following four categories: 1) epidemic

impact: because of the differences in the population

of each province, it can not accurately explain the

severity of the epidemic simply by the two

dimensions of infected population and dead

population, so the proportion of infected population

and dead population in the total population at the end

of the year is selected as the index of the severity of

the epidemic; 2) In recent years, the grain sown area

has changed according to the policy, and the impact

on grain yield is also very intuitive and obvious; 3)

Agricultural population: the "rural employed

population" is used to replace the "rural employed

population". The rural employed population in recent

five years can better represent the change trend of

agricultural population; 4) The local grain output of

the previous year can be used as one of the most direct

basis for the prediction of the grain output of that

year. In order to better reflect the trend of grain output

change, the local grain output data in recent four

years are selected.

Table 1: Training sample data.

SN Province Year

Infectious

disease

Proportion of

infected

persons

Proportion of

deaths

Grain yield in

the n-4 year

(10000 tons)

Grain yield

of the year

(10000 tons)

1 Beijing 2003 SARS 1.67E-04 1.01E-05 201.0 58.0

2 Tianjin 2003 SARS 1.74E-05 1.19E-06 174.9 119.3

3 Hebei 2003 SARS 3.10E-06 1.48E-07 2746.3 2387.8

4 Shanxi 2003 SARS 1.34E-05 6.04E-07 821.7 958.9

5 Neimenggu 2003 SARS 1.21E-05 1.05E-06 1428.5 1360.7

… ……

… … … … … …

21 Ningxia 2003 SARS 1.03E-06 1.72E-07 293.3 270.2

22 Guangdong 1961 cholera 1.07E-04 1.06E-05 1230.0 990.5

23 Xinjiang 1986 Hepatitis E 1.68E-02 9.93E-05 407.5 547.7

4.2 Method Analysis

After experiments, the kernel function is analyzed γ

Make adjustments when γ= 01, the average relative

error of training sample is about 2% γ> The average

relative error of the training samples is still about 2%,

but the average relative error of the prediction

samples increases obviously γ< 01 and continued to

decrease, the average relative error of training

samples gradually increased, indicating that the

fitting degree decreased.

When C < 1.0E+5, the average relative error of

training sample is about 5%, and the smaller C is, the

lower fitting degree is. When C > 1.0E+5 and

gradually increases, the average relative error of the

training sample is gradually reduced. When C is

1.0E+7, the average relative error of the training

sample is 1.96%, and the average relative error of

prediction sample is 3.27%, The average relative

error of training samples decreases slightly, but the

average relative error of prediction samples increases

greatly, which indicates that the prediction effect

decreases.

P represents to adjust the parameter B in the loss

function. When p > 10 and gradually increases, the

average relative error of training samples gradually

increases and the fitting degree decreases. When p <

10 and gradually decreases, the average relative error

of training samples gradually decreases, but the

average relative error of prediction samples increases

greatly, which indicates that the prediction effect

decreases.

A Probe into the Inﬂuence of Major Infectious Diseases on the Grain Yield of Each Province based on E-SVR Method

897

5 PREDICTION RESULTS OF

GRAIN YIELD OF

PREDICTION SAMPLES IN

THE CURRENT YEAR

It turns out that when γ= 0.01, C = 1.0E+7, P = 10,

the average relative error of training samples is

1.96%, the coefficient of determination is 99.0%, and

the average relative error of prediction samples is

3.27%, which can meet the demand of regional grain

yield prediction in the year of infectious diseases,

while the average relative error of prediction samples

is 3.27% ε- SVR has strong generalization ability due

to its modeling of a small number of cases and

parameter optimization, so it is based on SVR ε- SVR

grain yield model can provide accurate reference data

for regional short-term grain yield prediction.

Table 2: Training sample results.

Province

Infectio

disease

Actual

grain

yield of

that

year(1000

0 tons)

Fitted

Grain

yield that

year(1000

0 tons)

1 Beijing SARS 58.0 56.1

2 Tianjin SARS 119.3 121.0

3 Hebei SARS 2387.8 2384.7

4 Shanxi SARS 958.9 950.9

Neimengg

SARS 1360.7 1345.9

… … … … …

21 Ningxia SARS 270.2 267.1

Guangdon

cholera 990.5 1003.2

23 Xinjiang

Hepatiti

s E

547.7 544.0

Table 3: Forecast results.

Provinc

Infectio

disease

Actual

grain

yield of

that

year(1000

0 tons)

Fitted

Grain

yield that

year(1000

0 tons)

1 Gansu SARS 789.3 767.4

2 Shanxi SARS 968.4 964.1

Guangd

ong

SARS 1430.4 1319.0

Guangd

ong

break-

bone

fever

1632.0 1665.9

In order to study whether the large-scale

infectious diseases have a significant impact on grain

production in that year, the original samples were

modeled again by removing the two parameters of the

epidemic degree (the proportion of infected

population and the proportion of deaths). The results

show that the average relative error of training

samples is 1.97%. The average relative error of

prediction samples is 3.31%, and the coefficient of

determination also reaches 0.99. The model also has

a good reference value for short-term grain yield

prediction.

Table 4: Forecast results Including and Excluding epidemic

data.

Provi

nce

Infecti

ous

disease

Including

epidemic data

Excluding

epidemic data

Actu

grain

yield

that

year(

1000

tons

)

Fitte

Grai

yield

that

year(

1000

tons

)

Actu

grain

yield

that

year(

1000

tons

)

Fitte

Grai

yield

that

year(

1000

tons

)

Gans

SARS

789.

767.

789.

765.

Shan

SARS

968.

964.

968.

964.

Guan

gdon

SARS

1430

1319

1430

1317

Guan

gdon

break-

bone

feve

1632

1665

1632

1664

6 CONCLUSION

6.1 Prediction Model Reliability

Due to the limited samples of large-scale infectious

diseases in China, it belongs to small sample data

analysis, ε- The SVR method has excellent ability of

fitting and generalization for a small number of

samples.

Stay γ= 0.01, C = 1.0E+7, P = 10, the model can

better fit the sample data, and the prediction effect is

also better ε- The grain yield model of SVR is

accurate and reliable.

BDEDM 2022 - The International Conference on Big Data Economy and Digital Management

898

6.2 The Impact of Infectious Diseases

After removing the two parameters of the proportion

of the infected population and the proportion of dead

population representing the epidemic degree, the new

model can still better fit the modeling sample data and

forecast the target sample. Although the average

relative error is slightly larger than that of the model

with epidemic parameters, it is based on the existing

domestic large-scale infectious disease epidemic data

modeling. The epidemic situation had limited

influence on the grain yield in the area of that year.

This method can provide a theoretical reference

for the national macro-control of food production,

and it is a new research direction.

REFERENCES

Burges C J C.A tutorial on support vector machines for

pattern rec-ognition [J]. Data Mining and Knowledge

Discovery, 1998 (2) :121-167.

Chen Xiaolu, Wang Yanfang, Zhang Hongmei, Liu

Fenggui, Shen Yanjun Extraction method of irrigated

arable land in the Chahannur Basin based on the

ESTARFM NDVI [J] Chinese Journal of ecological

agriculture (Chinese and English), 2021,29 (06): 1105-

1116 DOI: 10.13930/j.cnki. cjea. 200880.

CHENG Peng, WANG Xi-li. Influence of SVR Parameter

on Non-linear Function Approximation[J]. Computer

Engineering, 2011,37(03):189+191+194.

Gao Xinyi, Han Fei Grain yield prediction of support

Vector Machine Based on hybrid intelligent algorithm

[J] Journal of Jiangsu University (NATURAL

SCIENCE EDITION) ,2020,41(03):301-306.

Guo Lin, Bai Dan, Wang Xinduan, et al. Establishment and

validation of flow rate prediction model for drip

irrigation emitter based on support vector machine [J].

Transactions of the Chinese Society of Agricultural

Engineering, 2018,34(02):74-82.

Hu Chenglei, Liu Yonghua, Gao Juling Research on

prediction method of grain yield based on IPSO-BP

mode [J] China Journal of agricultural chemistry,

2021,42 (03): 136-141.

Li Donglin, Zuo Qiting, Zhang Wei, Ma Junxia

Agricultural water resources allocation model in Tarim

River Basin based on Nerlove approach [J] water

resources protection,2021,37(02):75-80.

Li Tong, Dong Weihong, Zhang Qichen, Wen chuanlei

Analysis and prediction of grain water footprint in

Heilongjiang province based on time series model [J]

Journal of drainage and irrigation mechanical

engineering, 2020,38 (11): 1152-1159.

Li Ying, Chen huailiang Review of Machine Learning

Approaches for Modern Agrometeorology [J] Journal

of Applied Meteorology, 2020,31 (03): 257-266.

Liang Ji, Zheng Zhenwei, Xia shiting, Zhang Xiaotong,

Tang Yuanyuan Crop recognition and evaluationusing

red edge features of GF-6 satellite [J] Journal of remote

sensing, 2020,24 (10): 1168-1179.

LIN Sheng-liang, LIU Zhi. Parameter selection in SVM

with RBF kernel function[J]. Journal of Zhejiang

University of Technology, 2007(02):163-167.

Vapnik V N.The nature of statistical learning

theory[M].New York:Springer, 1999.

Wang Qian, Huang Kai Simulation of Agricultural Water

Footprint and Analysis of Influencing Factors in

Beijing Based on System Dynamics [J] systems

engineering,2021,39(03):13-24.

Wu Danhua, Zhou Limei Grain yield prediction based on

BP neural network [J] Agricultural Engineering

Technology,2020,40(27):51-53. DOI:

10.16815/j.cnki.11-5436/s.2020.27.008.

XIAN Guang- ming, ZENG Bi- qing. ε- SVR algorithm and

its application[J]. Computer Engineer ing and

Applications, 2008(17):40-42.

Xiong H L, Zhou X C, Wang X Q, et al. Mapping the spatial

distribution of tea plantations with 10 m resolution in

Fujian province using Google Earth Engine [J] Journal

of Earth Information Science, 2021,23 (07): 1325-

1337.

A Probe into the Inﬂuence of Major Infectious Diseases on the Grain Yield of Each Province based on E-SVR Method

899
