Transfer, Measure and Extend Maintainability Metrics for Web

Component based Applications to Achieve Higher Quality

Tobias M

unch

and Rainer Roosmann

University of Applied Sciences Osnabr

uck, Albrechtstraße 30, 49076 Osnabr

uck, Germany

Keywords:

Maintainability, Measure, Web Components, Component-based-software-development, Web Applications.

Abstract:

The last few years have seen an increased interest in web components composite W3C standard. These can

be used without or with frameworks like Angular or React. Modern web applications get developed by the

principles of component-based software development (CBSD). Therefore, a Web-Application is a composi-

tion of multiple web components, which are connected. In order to operate and continuously extend a web

application successfully in the long term, the non-functional requirement of maintainability has crucial impor-

tance. This paper describes a model to collect, measure and compare maintainability in web components and

web applications. These consist of object-oriented language (OOP) and a bound HTML-Fragment. Previous

knowledge of maintainability gets extended to the interconnection between OOP and HTML-Fragments. Es-

pecially the coupling and cohesion between web components get analyzed. Through the developed model, the

maintainability of web components can be speciﬁed in more detail. This allows web developers to analyze the

quality of their web applications and reach a higher software-quality level.

1 INTRODUCTION

Modern web applications can be found in several do-

mains like e-commerce, applications in the industry

or even applications for consumers. JavaScript has

reached the ﬁnal frontier space by a web application

for the SpaceX operating system (Schiemann, 2020).

This system has to be maintainable in long a term life-

cycle.

Web components, which are a composite standard

of W3C from 2014, have currently an upswing by

the alternative approach frameworkless development

(Strazzullo, 2019). This approach focuses on min-

imizing external dependencies to increase maintain-

ability and security. This paper aims to offer methods

and tools to measure maintainability in web compo-

nents and web applications.

Modern web applications are developed by

the principles of component-based-software-

development (CBSD) (Brown et al., 2002). There-

fore, web applications consist of many composed

web components. This principle matches the current

development approach with frameworks.

The vast majority of the work in this area has fo-

https://orcid.org/0000-0001-9424-6201

https://orcid.org/0000-0002-8625-2289

cused on maintainability in object-oriented program-

ming (OOP). For OOP, characteristics such as inheri-

tance, coupling, cohesion and polymorphism have to

be used in addition (Riaz et al., 2009). The well-

known metric suites from Chidamber and Kemerer

or Li can be used (Pressman, 2014). Heitlager et al.

have connected these indexes to the previous ISO/IEC

9126 standard (Heitlager et al., 2007). These metrics

can be transferred to web components because they

are implemented partly in an OOP.

To date, no study has looked speciﬁcally at the

maintainability of web components, especially for

coupling and cohesion between them. Although,

there is limited research investigating the intercon-

nection between web components. This research leak

leads to the questions:

RQ1: Which aspects of the maintainability index

can be transferred to web components?

RQ2: How can maintainability be measured in-

side a web component, which consists of a Class and

a HTML fragment?

RQ3: How can maintainability be measured in

a web application, which is the composition of web

components?

Münch, T. and Roosmann, R.

Transfer, Measure and Extend Maintainability Metrics for Web Component based Applications to Achieve Higher Quality.

DOI: 10.5220/0011511100003318

In Proceedings of the 18th International Conference on Web Information Systems and Technologies (WEBIST 2022), pages 105-112

ISBN: 978-989-758-613-2; ISSN: 2184-3252

105

2 BASICS

In difference to native apps, web applications or

web apps can be written once and be executed ev-

erywhere (Mikkonen and Taivalsaari, 2011; Biørn-

Hansen et al., 2017; Heitk

otter et al., 2012). A web

application is a software application which is based on

HTML5 standards and is developed by the principles

of CBSD (Brown et al., 2002). Therefore, it consists

of standard and custom web components (Strazzullo,

2019; Brown et al., 2002).

Web Components. can be described as custom,

encapsulated and reusable components which can

be used in web pages or applications. They are

interpreted and executed in modern web browsers

such as Google Chrome, Mozilla Firefox, Opera

and Apple Safari. Web components are based on

the web platform APIs Custom-Elements, Shadow-

DOM, ES-Modules and HTML-Templates. Today,

these APIs are included in the Web Hypertext Appli-

cation Technology Working Group (WHATWG) stan-

dard (WHATWG, 2022).

The ISO/IEC international standard 25010 deﬁnes

the product quality model (PQM) for applications,

which is deﬁned by the sub-categories functional sta-

bility, performance efﬁciency, compatibility, usabil-

ity, reliability, security, portability and maintainability

(Standard, 2022).

Maintainability. gets described by the PQM as

”degree of effectiveness and efﬁciency with which a

product or system can be modiﬁed by the intended

maintainers” (Standard, 2022). It consists of the sub-

characteristics: modularity, reusability, analysability,

modiﬁability, and testability (Standard, 2022).

3 RELATED WORKS

Recent research shows that web applications can

be developed client-side or server-side (Heitk

otter

et al., 2012). The traditional approach is server-

side-rendering, where an application server ren-

ders a HTML document, which is executed in the

web browser on a client (Mikkonen and Taivalsaari,

2011). These documents are less interactive than rich-

components web apps. JavaScript and web compo-

nents can be used to build a more interactive client-

side document (Braga et al., 2012).

Web Components. have been widely explained in

the last century. Krug and Gaedke have discussed

the communication between different web compo-

nents and proposed a communication bus in the pa-

per “SmartComposition: Bringing Component-Based

SoftwareEngineering to the Web” to simplify commu-

nication and thereby the composition of a web appli-

cation (Krug and Gaedke, 2015).

In the paper ”Self-contained web components

through serverless computing”, Ast and Gaedke

have demonstrated how serverless computing and

web components can be combined to create self-

component serverless web components (Ast and

Gaedke, 2017). They conclude that their approach

can be applied to reduce time and costs while inte-

grating web components.

Maintainability. has been systematically reviewed

by Riaz et al., and they collected evidence on predic-

tion and metrics (Riaz et al., 2009). Their study tar-

gets at software quality attributes of maintainability,

as opposed to the process of software maintenance.

The conclusion is that commonly used maintainabil-

ity prediction models are based on algorithmic tech-

niques with the sub-characteristics size, complexity

and coupling.

Ghosheh and Black have proposed new design

metrics measuring maintainability in heterogeneous

web applications (Ghosheh et al., 2008). The Web

Application Extension (WAE) for UML is used for

these metrics to measure the design attributes: size,

complexity, coupling and reusability (Ghosheh et al.,

2008).

4 METHODOLOGY

This section outlines the speciﬁc methods used within

our research. To describe the maintainability, sub-

characteristics have to be measured with source code

characteristics. Heitlager et al. have described the

connection between them for for ISO/IEC 9126 (Heit-

lager et al., 2007). These results are transferable to

ISO/IEC 25010.

4.1 Source Code Characteristics

Coupling. is deﬁned by the metrics coupling be-

tween objects (CBO), afferent coupling (Ca) and ef-

ferent coupling (C

) (Pressman, 2014; Anwer et al.,

2017). The CBO deﬁnes “a count of the number

of couples with other classes” for a class (Pressman,

2014). CBO has the theoretical basis that an object

uses methods or variables from another object. The

metric C

measures how many other classes call a

speciﬁc class (Anwer et al., 2017). C

is deﬁned as

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

106

vice versa as how many other classes are called from

a speciﬁc class. Based on the results from Heitlager

and ISO/IEC 25010, the coupling can be used for the

system quality characteristic’s modularity, reusability,

analysability and testability.

Cohesion. is traditionally measured as the interre-

latedness between portions of a program (Pressman,

2014). In the manner of OOP, it measures the relation-

ship between methods and instance variables. Cohe-

sion is measured by the term lack of cohesion in meth-

ods (LCOM). Chidamer et al. assumed a class with a

n methods M

,...M

and each method uses a set

of instance variables I

,...I

. Let P = I

∩ I

0 and Q = I

∩ I

6= 0 be deﬁned. From there

LCOM for a class is deﬁned as

LCOM = |P| − |Q| i f |P| > |Q|

LCOM = 0 otherwise

This metric is also known as LCOM1. It has been

updated through several releases to the LCOM5 met-

ric, which was introduced by Satwinder and Kahlon

(Singh and Kahlon, 2011). LCOM5 is calculated by

the following function:

LCOM5 =

∑

j=1

µ(A

) − m

(1 − m)

a = number of attributes or instance variables

µ(A

) = number of methods that access attribute

m = number of methods in the class

µ(A

) is summed over all the attributes j = 1 − n

Satwinder and Kahlon described the result range as

“LCOM5 is normalized in the range 0 to 1 under

the assumption that each attribute of a class is ref-

erenced by at least one method” (Singh and Kahlon,

2011). Based on the results of Heitlager et al., the

coupling metric links to the system quality character-

istic’s reusability and analysability.

Complexity. can be measured by different methods,

and it shows how complex the source code structure

is (Coleman et al., 1994). The cyclomatic complexity

(CC) is also known as the McCabe metric. CC can

be applied to functions, modules, methods or classes

of a program. Besides CC, the Cognitive Complexity

(CogC) exists, which calculates how difﬁcult a unit of

code is to understand. The complexity metric links to

the system quality characteristic’s modiﬁability and

testability. Heitlager et al. introduced this intercon-

nection.

Size. of a software project is traditionally measured

in Lines of Code (LoC) (Coleman et al., 1994). These

are a part of the overall source code lines (SLOC),

which can be divided into LoC, comment lines, and

blank lines (Bhatt et al., 2012). Based on the results

of Heitlager et al., the size metric links to the system

quality characteristic’s analysability and testability.

Code Duplication. measures how much code exists

duplicated inside a software system codebase. Rieger

et al. proposed the metrics a) LCC - the amount

of copied code in the source ﬁles, b) LIC - lines of

code copied ﬁle-internally and c) LEC - lines of code

copied ﬁle-externally (Rieger et al., 2004). These

metrics are based on the LOC of the software code-

base. A higher LCC indicates a lower maintainabil-

ity (Rieger et al., 2004; Sjøberg et al., 2012). Based

on the results of Heitlager et al., the code duplica-

tion metric links to the system quality characteristic’s

modularity, analysability and modiﬁability.

Test Coverage. is also known as code coverage

measures to which degree a source code is executed

by a test suite. In practical code coverage tools, the

typical code coverage metrics are statement, branch

and path coverage, which are oriented at the con-

trol ﬂow (Elbaum et al., 2001). It is measured how

much per cent of the coverage type is covered (El-

baum et al., 2001). Based on the results of Heitlager et

al., the test coverage metric links to the system qual-

ity characteristic’s reusability, analysability, modiﬁa-

bility and testability.

4.2 Web Component

The measurement of complexity, size, code duplica-

tion and test coverage described above applies to web

components. CC and CogC can be used to measure

the complexity of source code written in JavaScript

or TypeScript. All ﬁles written in JavaScript, Type-

Script or HTML are evaluated to measure the met-

ric size. The SLOC metric measures the lines of

JavaScript or TypeScript and HTML ﬁles. Lines of

comments are recognized in both languages. LOC

only applies to JavaScript or TypeScript. The LCC,

LIC and LEC metrics can be used in HTML Markup

and JavaScript or Typescript to measure the character-

istic code-duplication. Test-Coverage applies to the

source code in JavaScript or Typescript. According to

current research, test coverage is not transferable to

HTML fragments.

Source code characteristics of coupling and cohe-

sion only can be applied inside a web component if it

contains multiple classes. Then CBO, C

and C

are

Transfer, Measure and Extend Maintainability Metrics for Web Component based Applications to Achieve Higher Quality

107

used to measure coupling between these classes, like

in other oop languages. In the same way, LCOM can

be used to measure cohesion.

4.3 Web Application

A web application consists of web components.

Therefore the metrics size, code duplication and test

coverage can be aggregated to apply to a web appli-

cation.

A web application is a composition of web com-

ponents, which in turn can contain other web com-

ponents. These components are connected by HTML

fragments or are initialized dynamically and inserted

in the document object model (DOM). At present,

there is no standard procedure or methodology for

measuring the coupling and cohesion between web

components in the DOM or HTML fragments. To

measure these new types of coupling, input proper-

ties CP and used event-listener CL are used. The

CP is deﬁned analogical to the C

because the DOM

sets a property from another component. CL registers

an event listener to a class instance, which is calling

the method afterwards, so this can be described as a

combination of C

and C

. Additionally, the exist-

ing metrics CBO, C

and C

measure coupling in the

JavaScript or Typescript part of a web component.

The metric CP differs into static HTML bindings

in markup like constant values CP

const

and dynamic

usage in JavaScript or TypeScript code CP

dyn

. For ex-

ample, implemented event listener often uses proper-

ties of the targeted web component. CP can be com-

pared to C

. All accesses on properties are computed

into the metric CP. The event-listeners, which are

bind by HTML markup CL

const

or JavaScript CL

dyn

are counted into CL. Therefore, our metrics are

CP = CP

dyn

+CP

const

CL = CL

dyn

+CL

const

In order to compare two component coupling met-

rics, these metrics have to be relative. Therefore, n is

introduced as the amount of other used components

and this leads to:

rel

The following code snippet illustrates a used web

component, which is accessed by some JavaScript

code. This example is used to explain these new met-

rics.

<html>

<body>

<my-input type="text" onclick="sayHello()">

</my-input>

function sayHello() {console.log("Hello")}

const myInput = document

.getElementById("input");

myInput.addEventListener(’keyup’,

(event) => {

console.log(event.target.value)

});

</script>

</body>

</html>

In the web component my-input the property type

is used (CP

const

+ = 1 ) and an event-listener is reg-

istered to the ’click’-event (CL

const

+ = 1). The func-

tion sayHello prints out the target value (CP

dyn

+ = 1).

Additionally, an event listener is registered to the

’keyup’-event in JavaScript (CL

dyn

+ = 1). In the

anonymous function of the listener, the value of my-

input is used (CP

dyn

+ = 1). These measurements lead

to the result:

CP = 2 + 1 = 3

CL = 1 + 1 = 2

From this the following relative values CP

rel

and

rel

can be derived:

rel

= 3/1 = 3

rel

= 2/1 = 2

Like the other coupling metrics like CBO CP and

CL states to how strong web components are coupled.

If CP = 0 and CL = 0, then the web components are

not coupled. The higher the value, the stronger the

coupling.

4.4 Tools

In order to measure the code characteristics, Sonar-

Qube and embold are used. It analyses the source

code characteristics complexity, size, code duplica-

tion and test coverage.

In order to have two measurement suites, embold

is selected (https://embold.io/). It has similar features

then SonarQube and is focused on DevOps.

Both tools can interpret test coverage, which is

generated, for example, by the test framework jest. In

our paper, we used free tooling for public repositories,

which is common for open-source projects.

5 RESULTS

5.1 Case Study

European Regional Development Fund (ERDF) has

funded Vet:ProVieh to reduce the use of antibiotics

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

108

in Lower Saxony. The project is an industry 4.0

software for veterinaries in the ﬁeld of animal hus-

bandry (https://github.com/Vet-ProVieh/). Through

Vet:ProVieh, veterinary care is connected with antibi-

otics monitoring and action planning.

The Vet:ProVieh System is developed as a mi-

croservice architecture. A veterinary interacts with

the system through a component-based PWA, which

is structured by the domain-driven design (DDD)

from Eric Evans. It follows the principles of frame-

workless development and consists of many web

components. These must have a high degree of

maintainability to reduce such long-term maintenance

costs. Especially the sub-characteristics modularity,

reusability and testability are relevant for a growing

software system.

The Progressive Web App (PWA) of Vet:ProVieh

is structured in several packages. It consists of the

professional domains of veterinary care (careplans),

action planning (measures) and antibiotics monitor-

ing (drugTreatments). The shared domain provides

inputs, buttons, speech recognition for inputs and

other user elements across all professional disci-

plines. Besides, the base packages vetprovieh-shared,

vetprovieh-list, vetprovieh-select, formt-validation

and vetprovieh-pager provide functionalities such as

paging, interactive lists and select-inputs, annotations

and form validation.

5.2 Measurement Results

5.2.1 Web Component

To measure maintainability in web components,

we focus on the components vetprovieh-list and

vetprovieh-detail (see RQ2). Vetprovieh-list was de-

veloped to create an interactive user interface for pick-

ing or selecting entries. How an entry will be rendered

can be deﬁned outside the component with a template.

Vetprovieh-detail is a form frame to edit an object and

send it afterwards to a RESTful-Webservice. It in-

cludes form validation, callbacks and a generic tem-

plate. For the results, we recognize only source code

in the lib folders by our measurement environment.

The measurement results for the vetprovieh-list

are based on the introduced source-code characteris-

tics (see table 1). It has been measured a CC of 102

and a CogC of 36. The component has an overall of

810 source code lines, which consists of 431 LOC and

283 comment lines (CL). There are 131 statements,

67 functions and six classes in seven ﬁles with zero

code duplications. Test coverage of 88.5% has been

achieved, which can be divided into a line coverage

of 93.1% and a condition coverage of 79.6%.

Table 1: Comparison of measurement results between

SonarQube and embold for vetprovieh-list.

Metric SonarQube Embold

SLOC 810 802

LOC 431 428

CL 283 283

CC 102 31

CogC 36 -

Test-Coverage 93.1% 93.1%

LCC 0 0

The second web component, vetprovieh-detail,

has a complexity of CC 129 and CogC 56 (see ta-

ble 2). It consists of 888 source code lines divided

into 516 LOC and 267 comment lines. This com-

ponent implements 203 statements, 88 functions and

ﬁve classes in six ﬁles. No code duplications have

occurred. Test coverage of 80.4% has been achieved,

which can be divided into a line coverage of 88.2%

and a condition coverage of 75.9%.

Table 2: Comparison of measurement results between

SonarQube and embold for vetprovieh-detail.

Metric SonarQube Embold

SLOC 888 879

LOC 516 513

CL 267 274

CC 129 45

CogC 56 -

Test-Coverage 85.9% 85.9%

LCC 0 0

The metrics for coupling and cohesion can not

be automatically measured with the selected tools.

SonarQube has removed the metric LCOM4 because

of many false-positive results (son, 2022). Embold

should support CBO and LCOM for TypeScript and

JavaScript according to the documentation, but in

our case study, no results are measured (Embold,

2022). In an explorative study, Open-Source Projects

on GitHub and NPM are examined to ﬁnd different

tools to measure these metrics. We found some repos-

itories like cats from Thom Wright, but they are not

usable yet (ThomWright, 2022).

5.2.2 Web Application

We examine the introduced web application

Vet:ProVieh on the described metrics. Complexity,

size and test coverage are measured in the same way

as web components. The results are illustrated in

table 3. Vetprovieh-app has a complexity of CC 1731

and CogC 606. It consists of 17096 source code

lines divided into 10423 LOC and 3115 comment

lines. This component implements 2619 statements,

Transfer, Measure and Extend Maintainability Metrics for Web Component based Applications to Achieve Higher Quality

109

1194 functions and 173 classes in 310 ﬁles. A small

amount code-duplications have occurred, and there is

refactoring needed. Test coverage of 40.3% has been

achieved, which can be divided into a line coverage

of 43.0% and a condition coverage of 29.4%.

Table 3: Comparison of measurement results be-

tween SonarQube and embold for the web application

Vet:ProVieh.

Metric SonarQube Embold

SLOC 17096 19154

LOC 10846 12705

CL 4223 4584

CC 1731 752

CogC 606 -

Test-Coverage 39.8% 39.8%

LCC 544 1683

Like the results of web components, metrics for

coupling and cohesion can not be automatically mea-

sured with the selected tools. Additionally, the com-

plexity measurement from Kaur et al. can not be au-

tomatically calculated.

5.2.3 New Coupling Metric

To have results for our introduced metrics CP and

CL, we have measured some web components with-

out an automatic code analysis. We choose a part of

the domain ‘measures‘, which is illustrated in Fig-

ure 1. Only interactions between custom web com-

ponents are taken into account. The ‘vp-measure‘

is connected with ‘vetprovieh-notiﬁcation‘, ‘measure-

pdf-button‘ and ‘vp-objectives‘. In the source code,

there is no event listener between these components,

therefore CL = 0. There are several property usages,

and the result is

CP = CP

const

+CP

dyn

= 1 + 3 = 4

These values can be described in a more detailed way.

The connection to ‘vetprovieh-notiﬁcation‘ can be de-

scribed with the values CP

const

= 1 and CP

dyn

= 0,

‘measure-pdf-button‘ with CP

const

= 0 and CP

dyn

= 1

and ‘vp-objectives‘ with CP

const

= 0 and CP

dyn

= 2.

The seconds examined web component is ‘vp-

objectives‘, which is connected to ‘vp-objective-

item‘, ‘select-button‘ and ‘objective-modal‘. Cou-

pling with ‘vp-objective-item‘ can be described with

const

= 0, CP

dyn

= 8, CL

dyn

= 1 and C L

const

0. The connection to ‘select-button‘ is shown up as

const

= 5, CP

dyn

= 2, CL

dyn

= 0 and CL

const

= 0.

The usage of ‘objective-modal‘ can be described as

const

= 0, CP

dyn

= 2, CL

dyn

= 1 and CL

const

= 0.

These details can be aggregated to:

CP = CP

dyn

+CP

const

= 11 + 5 = 16

Figure 1: Evaluted web components of Vet:Provieh PWA.

CL = CL

dyn

+CL

const

= 2 + 0 = 2

The third examined web component is ‘vp-

objective-item‘ with its interconnection to ‘vp-stars‘

and ‘objective-modal‘. The connection to ‘vp-stars‘

can be described with CP

const

= 1, CP

dyn

= 1, CL

dyn

1 and CL

const

= 0. The coupling to the component

‘objective-modal‘ is measured as CP

const

= 1, CP

dyn

2, CL

dyn

= 1 and CL

const

= 0. These detail results can

be summed up to:

CP = CP

dyn

+CP

const

= 3 + 1 = 4

CL = CL

dyn

+CL

const

= 2 + 0 = 2

In order to compare these values, we have to

compare them realtive to the amount of used com-

ponents. On the component ‘vp-measure‘ has used

three other components and so CP

rel

= CP/n = 4/3.

‘objective-item‘ uses two other components and so

rel

=CP/n = 4/2 = 2 and CL

rel

=CL/n = 2/2 = 1.

‘vp-objectives‘ uses three other components and so

rel

= CP/n = 16/3 = 5,33 and CL

rel

= CL/n =

2/3 = 0, 66 It can be concluded that ‘vp-objectives‘

is closer coupled to its sub-components then ‘vp-

measure‘ and ‘objective-item‘.‘

5.3 Discussion

Our test measurement data of Vet:Provieh and its

web components provide convincing evidence that

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

110

the code characteristics complexity, size, code-

duplications and test coverage can be applied to the

OOP part of web components. Additionally, the used

tools SonarQube and embold have measured quite

similar results for these characteristics. Contrary to

our expectations, SonarQube and embold could not

measure coupling and cohesion between web com-

ponents. Therefore, the “RQ1 - Which aspects of

the maintainability index can be transferred to web

components?” can be answered. So the characteris-

tic’s complexity, size, code-duplications and test cov-

erage can be applied to web components written in

JavaScript or TypeScript. Size also includes HTML

documents.

There are signiﬁcant differences in the results

for source code size between SonarQube and em-

bold. These differences exist because embold cal-

culates CC and LOC in another way than Sonar-

qube. Embold uses the original McCabe algorithm,

and SonarQube uses a self-implemented algorithm for

JavaScript measure CC. Their algorithm counts func-

tion, if statements, conditional expressions, loops,

switch case statements and throw catch statements.

To answer the “RQ2 - How can maintainability

be measured inside a web component, which con-

sists of a class and a HTML fragment?” it can be

concluded that metrics for coupling, cohesion, size,

complexity, code duplication and test coverage can be

used for web components. Still, only size, complex-

ity, code-duplication and test coverage are currently

automatically measurable. We calculated the results

on our own by using a proposed algorithm to mea-

sure coupling between web components. This algo-

rithm can be used to measure the connection between

classes and their coupling inside a markup language

like HTML. We would encourage researchers to ex-

amine the composition between markup language and

object-oriented language in more detail to provide a

static code analysis to measure our proposed metrics.

We can transfer the methods from the ﬁrst two

research questions to web applications to measure

maintainability. Therefore, we can connect the re-

sults of RQ1 and RQ2 to answer the “RQ3 - How

can maintainability be measured in a web application,

which is the composition of web components?”. The

relationship between composed web components can

be measured by the results of RQ2 and be aggregated

to a result for a web application like our results have

shown. Our results cannot check the sub-aspect CP

dyn

because it was not used in the Vet:ProVieh project.

Our case study has a small scope and needs to be ver-

iﬁed through empirical research. In addition, the re-

sults of RQ1 can be transferred in precisely the same

way.

We can not measure coupling and cohesion au-

tomatically inside web applications with the selected

tools. After explorative research for other instruments

or GitHub repositories, none has been found.

6 CONCLUSIONS

The main conclusion that can be drawn is that well-

described traditional metrics complexity, size, code-

duplications and test coverage can be used for the

OOP part of web components and web applications.

These can describe the quality characteristic main-

tainability of the ISO/IEC 25010 well. We used tools

like SonarQube and embold to collect data for these

metrics.

The code characteristic coupling has been ex-

tended to measure the connection between web com-

ponents inside the DOM because web application

links their components in this way. We propose a

new metric, how to collect data for this extension,

to describe it in a more detailed way. The usage of

this metric has to be proven in multiple open source

projects because our experiment has only a small

scope. To apply our metrics to a greater area, they

have to be evaluated automatically.

Current tools like SonarQube can not automati-

cally measure coupling and cohesion between or in-

side web components. This lack of measurement and

the algorithms below is a possible research gap in web

development.

Therefore, the measurement of maintainability in

web applications is not yet up to the standard as in

other high-level languages such as Java or C#.

7 FUTURE WORK

Future research should consider the potential of mea-

suring the complexity of composing web components

inside a web component more carefully, for example,

to measure the cohesion between web components in-

side a web application. Especially we can not rec-

ognize dynamic DOM manipulations trivially inside

static code analysis.

Furthermore, we are looking forward to deﬁne

how our proposed metrics can be aggregated in web

applications to have an overall score.

Additionally, the metric suites from Chidamber

and Kemerer are not implemented for TypeScript or

JavaScript, which are implemented in an OOP style.

Therefore additional research and implementation are

needed to transfer the metric suite to web applications

and its components. This includes further questions

Transfer, Measure and Extend Maintainability Metrics for Web Component based Applications to Achieve Higher Quality

111

about how static and dynamic code analysis can be

used to measure coupling and cohesion in web appli-

cations and web components.

This is necessary because, with such tools, web

developers can increase the maintainability of web

applications, so long-term and high-reliability appli-

cations can be developed for the industry.

In Addition, this automation enables an empiri-

cal study to validate our proposed metrics in a more

detailed way. For this study, several open source

projects have to be selected.

REFERENCES

(2022). [SONAR-4853] Remove support of LCOM4

- SonarSource. https://jira.sonarsource.com/browse/

SONAR-4853. [Online; accessed 5. May 2022].

Anwer, S., Adbellatif, A., Alshayeb, M., and Anjum, M. S.

(2017). Effect of coupling on software faults: An em-

pirical study. In 2017 International Conference on

Communication, Computing and Digital Systems (C-

CODE), pages 211–215. IEEE.

Ast, M. and Gaedke, M. (2017). Self-contained web com-

ponents through serverless computing. In Proceedings

of the 2nd International Workshop on Serverless Com-

puting, pages 28–33.

Bhatt, K., Tarey, V., Patel, P., Mits, K. B., and Ujjain, D.

(2012). Analysis of source lines of code (sloc) met-

ric. International Journal of Emerging Technology

and Advanced Engineering, 2(5):150–154.

Biørn-Hansen, A., Majchrzak, T. A., and Grønli, T. M.

(2017). Progressive web apps: The possibleweb-

native uniﬁer for mobile development. WEBIST

2017 - Proceedings of the 13th International Confer-

ence on Web Information Systems and Technologies,

(Webist):344–351.

Braga, J. C., Damaceno, R. J. P., Leme, R. T., and Dotta,

S. (2012). Accessibility study of rich web interface

components. In ACHI 2012, The Fifth International

Conference on Advances in Computer-Human Inter-

actions, pages 75–79.

Brown, A., Johnston, S., and Kelly, K. (2002). Using

service-oriented architecture and component-based

development to build web service applications. Ra-

tional Software Corporation, 6:1–16.

Coleman, D., Ash, D., Lowther, B., and Oman, P. (1994).

Using metrics to evaluate software system maintain-

ability. Computer, 27(8):44–49.

Elbaum, S., Gable, D., and Rothermel, G. (2001). The im-

pact of software evolution on code coverage informa-

tion. In Proceedings IEEE International Conference

on Software Maintenance. ICSM 2001, pages 170–

179. IEEE.

Embold (2022). Metrics overview - embold help-center.

https://docs.embold.io/de/metrics/. Accessed: 2022-

04-23.

Ghosheh, E., Black, S., and Qaddour, J. (2008). Design

metrics for web application maintainability measure-

ment. In 2008 IEEE/ACS International Conference on

Computer Systems and Applications, pages 778–784.

IEEE.

Heitk

otter, H., Hanschke, S., and Majchrzak, T. A. (2012).

Evaluating cross-platform development approaches

for mobile applications. In International Conference

on Web Information Systems and Technologies, pages

120–138. Springer.

Heitlager, I., Kuipers, T., and Visser, J. (2007). A practical

model for measuring maintainability. In 6th interna-

tional conference on the quality of information and

communications technology (QUATIC 2007), pages

30–39. IEEE.

Krug, M. and Gaedke, M. (2015). Smartcomposition:

bringing component-based software engineering to

the web. In Proceedings of the 17th International

Conference on Information Integration and Web-

based Applications & Services, pages 1–4.

Mikkonen, T. and Taivalsaari, A. (2011). Apps

vs. Open Web: The Battle of the Decade.

http://www.w3.org/TR/ofﬂinewebapps/.

Pressman, R. S. (2014). Software engineering: a practi-

tioner’s approach. McGraw-Hill Education.

Riaz, M., Mendes, E., and Tempero, E. (2009). A system-

atic review of software maintainability prediction and

metrics. In 2009 3rd international symposium on em-

pirical software engineering and measurement, pages

367–377. IEEE.

Rieger, M., Ducasse, S., and Lanza, M. (2004). Insights

into system-wide code duplication. In 11th Working

Conference on Reverse Engineering, pages 100–109.

IEEE.

Schiemann, D. (2020). JavaScript Reaches the Final Fron-

tier: Space. https://www.infoq.com/news/2020/06/

javascript-spacex-dragon.

Singh, S. and Kahlon, K. S. (2011). Effectiveness of encap-

sulation and object-oriented metrics to refactor code

and identify error prone classes using bad smells.

ACM SIGSOFT Software Engineering Notes, 36(5):1–

10.

Sjøberg, D. I., Yamashita, A., Anda, B. C., Mockus, A.,

and Dyb

a, T. (2012). Quantifying the effect of code

smells on maintenance effort. IEEE Transactions on

Software Engineering, 39(8):1144–1156.

Standard, I. I. (2022). Systems and software en-

gineering — systems and software quality re-

quirements and evaluation (square) - system and

software quality models - iso/iec 25010:2011(e),

vol. 2011. https://www.iso.org/obp/ui/#iso:std:iso-

iec:25010:ed-1:v1:en. Accessed: 2022-04-01.

Strazzullo, F. (2019). Frameworkless front-end develop-

ment.

ThomWright (2022). cats. https://github.com/ThomWright/

cats. [Online; accessed 5. May 2022].

WHATWG (2022). Dom - living standard - last updated

22 march 2022. https://dom.spec.whatwg.org/. Ac-

cessed: 2022-03-27.

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

112
