Exploring the Test Driven Development of a Fraud Detection

Application using the Google Cloud Platform

Daniel Staegemann

, Matthias Volk

, Maneendra Perera and Klaus Turowski

Magdeburg Research and Competence Cluster VLBA, Otto-von-Guericke University Magdeburg, Magdeburg, Germany

Keywords: Test Driven Development, TDD, Microservice, Big Data, Google Cloud Platform, GCP, Fraud Detection.

Abstract: The concept of big data hugely impacts today’s society and promises immense benefits when utilized correctly,

yet the corresponding applications are highly susceptible to errors. Therefore, testing should be performed as

much and rigorous as possible. One of the solutions proposed in the literature is the test driven development

(TDD) approach. TDD is a software development approach with a long history but has not been widely

applied in the big data domain. Nevertheless, a microservice-based test driven development concept has been

proposed in the literature, and the feasibility of applying it in actual projects is explored here. For that, the

fraud detection domain has been selected and a proof-of-concept online fraud detection platform is

implemented, which processes real-time streaming data and filters fraudulent and legitimate transactions.

After the implementation, an evaluation was carried out regarding test coverage and code quality. The

automatic code analysis reports revealed that TDD had produced very reliable, maintainable, and secure code

at the first attempt that is ready for production. Finally, the evaluation revealed that it is highly feasible to

develop big data applications using the concept mentioned. However, choosing suitable services, tools,

frameworks, and code coverage solutions can make it more manageable.

1 INTRODUCTION

Due to the ever-increasing importance of knowledge

and information, the concept of big data (BD) hugely

impacts today’s society and promises immense

benefits when utilized correctly (Müller et al. 2018).

While there are several slightly varying explanations

of BD, the most prominent one is provided by the

National Institute of Standards and Technology

(NIST), which states that big data “consists of

extensive datasets primarily in the characteristics of

volume, velocity, variety, and/or variability that

require a scalable architecture for efficient storage,

manipulation, and analysis” (Chang and Grady 2019).

The potential use cases for BD are manifold (Volk et

al. 2020), leading to its adoption in numerous

domains and industries. However, the corresponding

applications are highly susceptible to errors.

Therefore, testing should be performed as much and

rigorous as possible. One of the solutions proposed in

the literature is the test driven development (TDD)

https://orcid.org/0000-0001-9957-1003

https://orcid.org/0000-0002-4835-919X

approach (Staegemann et al. 2020) that is further

detailed in the following section.

To assure a comprehensive quality assurance, the

testing should be performed on all levels, namely

method, subcomponent (a single microservice),

component (a group of microservices that

contentually belong together), and the system in its

entirety.

For the application of TDD in the BD domain, the

use of microservices has been suggested (Staegemann

et al. 2020). The core objective of those is to allow

loosely coupled, self-contained modules or services

that are created to solve one specific task, have their

own resources and can be deployed separately.

Several asynchronous communication patterns can be

used among services and messaging; the event-driven

approach and RESTful connections are some widely

used patterns in software engineering. Also, since

they are independent components, different

programming languages can be used for the

implementation (Shakir et al. 2021).

Staegemann, D., Volk, M., Perera, M. and Turowski, K.

Exploring the Test Driven Development of a Fraud Detection Application using the Google Cloud Platform.

DOI: 10.5220/0011559000003335

In Proceedings of the 14th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2022) - Volume 3: KMIS, pages 83-94

ISBN: 978-989-758-614-9; ISSN: 2184-3228

While the application of TDD in BD has already

been demonstrated (Staegemann et al. 2022), the

corresponding body of literature is still relatively

sparse. Therefore, the publication at hand aims to

expand it by presenting an additional use case from a

complex and demanding domain. Therefore, fraud

detection was chosen as the application area.

Moreover, since cloud offerings such as the Google

Cloud Platform (GCP), Amazon Web Services

(AWS), and Microsoft Azure are highly popular,

instead of building a solution completely from

scratch, in this project, the GCP is used to explore the

approach’s applicability when using a cloud provider

and (at least partly) its provided tools (e.g. Pub/Sub

and Dataflow). Consequently, the focus of this paper

is also on the realization of the TDD itself and not on

the optimization of the fraud detection algorithm’s

accuracy.

2 TEST DRIVEN DEVELOPMENT

In the literature (Staegemann et al. 2021), the

application of TDD is highlighted as a promising way

to improve the quality of an implementation as long

as the associated increase in development time and

effort is considered an acceptable trade-off.

The approach aims at improving the quality of the

product under consideration by mainly influencing

two aspects. On the one hand, it aims to increase test

coverage, which helps to find and subsequently fix

problems that occurred during the implementation of

the artifact in question. On the other hand, TDD also

influences the design process itself by leading to a

more manageable and pre-planned structure that

helps to avoid bugs and incompatibilities (Crispin

2006; Shull et al. 2010). The main application area is

software development, but the special case of

implementing BD applications (Staegemann et al.

2020), process modelling (Slaats et al. 2018), or

developing ontologies (Davies et al. 2019; Keet and

Ławrynowicz 2016) are also found in the literature.

In the "traditional" way of software development,

once a function or change is envisioned to be realized,

it is implemented and then tested. In contrast, in the

test-driven approach, the order of implementation and

testing is reversed. That is, after the desired change is

conceived, it is broken down into its smallest

meaningful parts (Fucci et al. 2017). For these, one or

more tests are written to ensure that the required

functionality is provided. Then, the tests are executed

and are expected to fail because the actual

functionality is not yet implemented (Beck 2015).

Only then is the productive code written to provide

the new functionality. Factors such as the elegance of

the code are not yet considered; instead, the simplest

solution is sought. Once the code is ready, it must

pass the previously written tests (Crispin 2006). If it

is successful, the code is refactored to improve

aspects such as readability or compliance with

standards and best practices (Beck 2015). In the

process, functionality is constantly validated against

the tests.

However, this approach not only affects test

coverage, but also the design of the software by using

small work packages instead of large tasks. In

addition, this focus on incremental changes (Williams

et al. 2003), which intertwines testing and

implementation, provides more immediate feedback

to the developer by resulting in short test cycles

(Janzen and Saiedian 2005). Although most tests are

written specifically for these small units, other tests

such as integration, system, or acceptance tests can

also be used in TDD (Sangwan and Laplante 2006).

In addition, to fully exploit the potential of TDD

without tying up the developer's attention by forcing

him to manually execute the tests, TDD is often used

in conjunction with test automation in a continuous

integration (CI) context (Karlesky et al. 2007; Shahin

et al. 2017). To ensure that the latest code addition or

change does not negatively impact existing parts of

the implementation, a CI server automatically starts

and re-executes all applicable tests when a new code

commit is registered by the versioning system.

3 THE IMPLEMENTATION

The developed solution consists of multiple

microservices, and creating the application is divided

into three major parts. The first step deals with the

development of a machine learning model. It is used

to identify a given transaction as fraudulent or

genuine. Here, tasks like selecting suitable training

data, pre-processing those data, creating the machine

learning model, training the machine learning model,

and deploying the machine learning model for online

predictions are carried out.

Afterwards, the rule engine, which validates the

transaction is developed. There are different ways to

identify fraud, and traditionally rule-based fraud

detection approaches have been used before

introducing machine learning application approaches

(Mekterović et al. 2021). Rule-based systems use

conditions, and if the corresponding state is matched,

the transaction will be marked as fraud or potential

fraud. Therefore, this work uses machine learning and

rule engine-related fraud detection to improve

KMIS 2022 - 14th International Conference on Knowledge Management and Information Systems

prediction accuracy. Further, by introducing a rule

engine, it is also aimed to identify the feasibility of

applying TDD in the rule engine microservice.

Finally, the online fraud detection platform is

developed. This is the place where the microservices

are connected with each other for the final goal of

identifying the transaction as fraudulent or not. An

online fraud detection platform is a streaming

application that initiates the analysis as soon as a

transaction is received and sends the transaction

status as the outcome. The design and implementation

of the streaming pipeline are carried in this step.

3.1 Machine Learning Model

Fraud detection is a binary classification problem that

categorizes the transaction as fraudulent or legitimate

(Maniraj et al. 2019). The GCP platform provides

several tools and services to build classification

machine learning models. However, for building such

a model, a suitable dataset is needed. Therefore, at

first, a domain-specific dataset was chosen from

Kaggle

was selected for the project, which is one of

the most popular online communities for people

interested in machine learning and data science. This

dataset contains a simulated credit card transaction

database that was created using the Sparkov data

generator

, and it contains legitimate and fraudulent

transactions from 1st Jan 2019 to 31st Dec 2020. It

covers credit cards of 1000 customers doing

transactions with a pool of 800 merchants. The

dataset's features are known, and the documentation

of the dataset concerning the features is self-

explaining. The dataset contains fraudTest.csv and

fraudTrain.csv, dividing the dataset into two parts.

However, the dataset is highly imbalanced because

fraudulent transactions are only 0.52% out of all the

transactions. This data distribution needs extra

attention when building the machine learning model

because the classification machine learning model’s

performance and accuracy strongly depend on the

distribution of classes.

3.1.1 Pre-processing

The quality of machine learning models is highly

dependent on the quality of the input provided for the

model. Data is highly error-prone and needs cleaning

and transformation before using them in the model

training. Incomplete data, inconsistent data, and

missing data are prevalent issues visible in datasets,

and 70%-90% of project efforts are utilized for data

wrangling, which is data understanding and

transformation (Nauck 2019).

Pre-processing is the first step carried out in the

model creation, and the GCP has several tools that

can be used for cleansing and transforming data. Yet,

Table 1: The performed pre-processing steps.

Step Activity

1 Scan raw dataset to check if there are any missing values in the TARGET column, is_fraud, and

remove the rows where the TARGET is missing.

2 Search columns with a high number of missing values and remove those where half of the rows have

missing values.

3 Delete duplicate

ows and columns with a single value as they do not add value to the machine

learning model’s creation.

4 Categorical data columns are transformed into numerical. (Even though this was not used for the

fraud detection dataset as the finally used AutoML Tables can handle absolute values, the tests and

implementation are available for this pre-

rocessin

step.)

5 Missing values are imputed using the strategy mean in

klearn.impute.SimpleImpute

, which replaces

the missin

values with the mean of each column.

6 Perform outlier removal using the

nter Quartile Range mechanism, the most trusted mechanism for

removing unusual data points [4]. (The inter quartile range depicts a measure in descriptive statistics

that tells the middle ran

e of the dataset.)

7 Select the top features for the machine learning model by calculating correlations between the

columns and the target. Apart from the above automatic pre-processing, manual pre-processing is

also done to remove duplicate columns like merchant latitude and merchant longitude as longitude

and latitude columns are alread

present.

8 Add a new data column named data_spli

(explained in the following section)

9 Write the cleaned data to a CSV file.

https://www.kaggle.com/kartik2112/fraud-detection

https://github.com/namebrandon/Sparkov_Data_Generation

Exploring the Test Driven Development of a Fraud Detection Application using the Google Cloud Platform

when applying TDD, internal constraints would have

increased the complexity and, therefore, another

approach was needed. Using Python libraries like

sklearn, pandas, and numpy to process and transform

data is another popular and widely used method in

machine learning, and it was well suited for TDD.

Hence, the following cleansing and transformation

steps were carried out using the abovementioned

libraries, following the steps outlined in Table 1.

3.1.2 Machine Learning Model

After pre-processing, the second step of building the

machine learning model is selecting a suitable GCP

tool and implementing the fraud detection

classification model. AutoML Tables is a popular

GCP tool that automatically builds and deploys a

machine learning model (Google 2022a). It has a

simplified process, and it automatically selects the

best model for the dataset provided. Furthermore, it

maximizes the quality of the model by increasing the

accuracy, and decreasing the Root Mean Square Error

(RMSE), without manual intervention for feature

engineering, assembling, etc. (Google 2022a).

BigQuery ML is also another candidate for model

creation. However, since the main focus is on

increasing the model quality rather than model

experimentation, the AutoML Tables are used.

In AutoML Tables, the dataset is split

automatically with 80% for training, 10% for

validation, and the other 10% for testing.

Nevertheless, AutoML recommends a manual split

for highly unbalanced datasets as an automatic split

may result in fewer samples of the minority class for

the testing split (Google 2022a). Therefore, a new

column was added to the dataset called data_split,

which contains three categorical values TRAIN,

VALIDATE and TEST, constructing a custom split

during model creation.

Finally, the updated pre-p

rocessed fraud dataset

CSV file is uploaded to a storage bucket

via

Terrafo

to be able to access AutoML Tables.

After uploading the CSV file, to create an AutoML

Table dataset and create the model, Python SDK was

used as Terraform still does not support AutoML

Tables. Once the model is created, it is deployed (for

this purpose, the google-cloud-automl_v1beta1

Python module was used) in the Artificial Intelligence

(AI) platform for online prediction. The GCP AI

platform supports creating, training, and hosting the

built machine learning model. Furthermore, it

supports monitoring the online predictions and

maintaining the model and versions.

3.2 Rule Engine

After creating the machine learning model and

deploying it in the AI platform for online prediction,

the second step was implementing the rule engine.

There are two main models, rule-based and

algorithmic models that are used to detect fraud. In

rule-based models, multiple conditions identify the

transaction as fraudulent or legitimate. This project

uses the rule engine as a microservice hosted in a

compute engine. It is the first component of the

platform where the online transaction gets validated,

and it has several rules for unusual attributes. In real-

time, when a transaction is initiated, Pub/Sub will

create a message and pass it to Dataflow. Then

Dataflow will invoke the rule engine application.

The rule engine was developed as a RESTful web

service using Spring Boot. It has a POST endpoint

called “/api/isTransactionValid” and invoking the

endpoint with the transaction details will return the

transaction validity. It must be deployed on a server

to use the web service. Therefore, a virtual machine

is created in Compute Engine as the first step. Then

Tomcat, the server software, and MySQL 8.0 are

installed as the web service uses it. After performing

all these installations, the web service is bundled as a

Table 2: Checks performed by the rule engine.

Rule Threshol

Check if the transaction amount exceeds the daily transaction amoun

500

Check if the daily transaction total exceeds the daily transaction total 1000

Check if the daily transaction count exceeds the daily transaction coun

Check if the time difference of the subsequent daily transactions is greater than the minimum

time difference

5 seconds

Check if the distance of the subsequent daily transactions is lesser than the maximum distance 1000 k

Sto

rage buckets are containers that can hold data so that

other GCP services can connect to these containers and

access the data.

Terraform is an infrastructure as code tool that enables the

infrastructure's safe and efficient building and

maintenance.

KMIS 2022 - 14th International Conference on Knowledge Management and Information Systems

Web Application Resources (WAR) file and

deployed on the server. When the transaction details

are sent to the web service, it will validate the details

against the five rules depicted in Table 2, which are

created based on common factors used in fraud

detection models (Huoh 2017).

After validating the transaction against the rules,

the rule engine sends a status to the dataflow

component. Regardless of the status being valid or

invalid, it will be forwarded to the hosted ML model

via Dataflow to further processing. The web service

is developed using the Controller Service Repository

pattern, a widely used design pattern. It breaks the

business layer into the repository layer, which

connects to the database, and the service layer, where

actual business logic is implemented (Jones 2019).

Moreover, it provides a more flexible architecture and

allows to write unit tests quickly (Jones 2019).

3.3 Online Fraud Detection Platform

The final phase of creating the application is the

development of the microservice-based online fraud

detection platform using GCP products. It is designed

to handle real-time streaming transaction data,

process it immediately, and send the result to the

relevant notification services. The selection decision

for each service is discussed in the respective section.

3.3.1 Pub/Sub

In the fraud detection platform, transaction details

come from different services like desktop computers,

mobile phones, or laptops. Also, the final status of the

transaction should be sent to different sources which

initiated the transaction. Therefore, Pub/Sub

messaging is appropriate for this scenario as all the

initiating devices can send the transaction details to a

single topic. Furthermore, once the processing is

completed in the system, the same devices can

subscribe to a single topic to determine the conclusive

status of the transaction. Again, it is capable of

ingesting data to streaming pipelines like Dataflow.

Hence, Pub/Sub is selected, a real-time asynchronous

messaging service provided by GCP. It is utilized to

ingest transactions into the system and send the fraud

transaction notifications from the system. Foremost,

two topics and their respective subscripts are created

in the cloud project via Terraform script. Then the

Java code is written for message publishing and

subscribing.

Here a topic called transaction-topic exists and all

publishers are publishing transactions on this topic.

Furthermore, this topic has a subscription called

transaction-subscription, and Dataflow retrieves all

the messages from this subscription and processes

them either as fraud or legitimate. Then the fraud

transaction details are written to the fraud-status-

topic, and legitimate transaction details are written to

the transaction-status-topic. Then a cloud trigger can

be attached to the fraud-status-topic so that when a

new message comes, a notification (e.g., a SMS) can

be sent to the relevant parties.

3.3.2 Dataflow

Fraud detection should be done in real-time.

Therefore, a service capable of handling transaction

details in real-time, processing, and then sending the

response to the relevant parties is required to fulfil

this scenario. Dataflow comes in handy in this

situation, and it is a service of GCP capable of

processing different data patterns. It executes the

batch and streaming pipelines developed using

Apache Beam SDK, an open-source programming

model (Google 2022b). Therefore, Dataflow is used

in the project, and the message received from the

Pub/Sub is transferred to process it and take necessary

actions.

First, transactions should be ingested into the real-

time stream pipeline to start the streaming job. Then,

the transaction details are published to the described

transaction topic, and Dataflow gets them for further

processing. Therefore, Dataflow reads the messages

in the transaction topic as the first job.

After getting the transaction details, the actual

business process of identifying the transaction as

fraudulent or legitimate should be initiated. For that,

Dataflow invokes the Rule Engine hosted in the

Compute Engine. Then the response is retrieved from

the RESTful endpoint about the transaction validity

and whether the transaction is valid. This information

is kept in the memory to initiate the next step.

Here, the transaction fraud status is retrieved from

the machine learning model. Both algorithmic and

rule-based methods identify fraudulent transactions

in this online fraud detection platform. In the previous

step, the rule engine was invoked, and here the same

is done with the machine learning model, which is

hosted in the AI platform to predict whether the

transaction is fraudulent. Then the response retrieved

from the machine learning model is kept in memory,

and both the machine learning response and the rule

engine response are carried to the next step of the job.

The responses obtained from both models are

essential to identify the transaction as fraudulent or

legitimate. Furthermore, it is important to persist the

results and the transaction details for future use.

Exploring the Test Driven Development of a Fraud Detection Application using the Google Cloud Platform

Therefore, in the following step, transaction details

are written to the BigQuery table called

transaction_fraud_status_data_table for future

reference. For example, when the table row count

exceeds a certain threshold, a new machine learning

model can be trained using the old dataset and the

persisted data in the BigQuery ML table.

After saving the fraud status, it is essential to send

the transaction status to the platforms that initiated the

transactions, whether to continue processing or

terminate the process if the transaction is potentially

fraud suspicious. Therefore, filtering of the

transactions happens as the next step. First,

transactions are filtered as fraud or genuine, and in

this step, Dataflow produces a new message with

fraud transaction details along with the fraud status

and sends it to the topic called fraud-status-topic.

In the filtering process, if the transaction is

considered genuine based on the machine learning

response and rule engine response, Dataflow

produces a message with transaction details and

transaction status. It is published on a topic called

transaction-status-topic. Then the platforms

subscribed to this topic can retrieve the data and

continue processing the transaction.

123 4

3.3.3 BigQuery

Fraud detection is a dynamic process that does not

have an ending. Organizations should continually

monitor fraud detection systems and make necessary

enhancements to the systems to adapt to the trends

(Wedge et al. 2019). Continuous monitoring, learning

from the incidents, and incorporating knowledge

gained from the past incident are essential. Therefore,

keeping track of indicants and their response should

be mandatory, and for this, BigQuery can play a

significant role. BigQuery is a data warehouse that is

cost-effective and scalable. Also, it is the input source

for most of the model creation services like BigQuery

ML and AutoML Tables. After invoking the rule

engine and machine learning model in this pipeline,

the transaction details with their validation and

prediction status are written to a BigQuery table for

future reference and use. In the project, a table called

transaction_fraud_status_data_table is created using

Terraform and writing data to the table is

implemented using Java inside the Dataflow

transform. The data written to tables can be harnessed

for different analytical purposes.

To save costs, this can be done using a small test dataset,

since only the connectivity but not the AutoML can and

need (since it is a proven component) to be tested.

3.4 The Testing

After the previous section introduced the developed

application, in the following, it is outlined how the

test driven approach has been realized.

3.4.1 TDD in the Machine Learning Model

Since the focus of the conducted project is on the

application of TDD, it is essential to understand the

test structure and test cases precisely. Therefore,

Python unittest is employed instead of Pytest as the

tests are easily understandable. Tests written for pre-

processing functions are executed locally in the

Eclipse IDE. However, this is not possible for all parts

of the application, leading to varying testing

approached outlined in the following. However, it is

impossible to run the AutoML Table's related tests

locally as they need to be executed in real

environments. Some of the GCP services like

Pub/Sub, Bigtable, and Spanner provide emulators

which provide the capability of developing and

testing the application locally in a simulated

environment (Google 2022c). However, since the

AutoML Tables do not have the emulation option,

tests were executed in the real environment

. Before

creating the AutoML Table model, datasets should be

imported to a storage bucket or a BigQuery table. In

the project, the datasets are uploaded to a storage

bucket called fraud_detection_data_bucket and then

imported to the AutoML Table. To create the storage

bucket and upload the CSV files, Terraform was used,

and before that, Chef InSpec

tests (controls) were

written to verify the outputs. Chef InSpec GCP is a

resource pack that can be used to write tests for GCP

resources. Afterwards, the Terraform scripts are

written and executed, and then again, Chef InSpec

tests are executed to verify that the resource creation

is successful.

3.4.2 TDD in the Rule Engine

During the development of the rule engine, TDD is

used, and JUnit Jupiter and spring-restdocs-mockmvc

libraries are used to write the tests. They are the

general libraries used in writing tests in Spring Boot

RESTful web service applications. Since the

Controller Service Repository pattern is used, the

repository tests are first created, and then the

repository layer is implemented. Afterwards, the

https://github.com/inspec/inspec-gcp

KMIS 2022 - 14th International Conference on Knowledge Management and Information Systems

service tests are written mocking the repository layer,

and then the service layer is implemented. Finally,

controller tests are written mocking the service and

repository, and then the controller is implemented,

which has the POST endpoint. After writing the code,

the controller is tested using POSTMAN.

Following the local testing, the code is bundled as

a WAR file (a collection of Java classes and all

necessary resources to be deployed on a server) and

deployed in the compute engine. Before creating the

compute engine virtual machine instance in the GCP,

the Chef InSpec test is written for testing the resource

creation. Subsequently, the compute engine instance

is created using Terraform. After creating the virtual

machine, the Chef InSpec test was executed to verify

the resource exists in GCP with specific properties

(e.g., machine type). Then in the VM, Java, Tomcat,

and MySQL are installed to be able to run the web

service and the WAR file is deployed. After

deployment, POSTMAN was used to send the

requests to the REST API and verify that the

deployment was successful.

3.4.3 TDD in the Online Fraud Detection

Platform

Corresponding to the description of the platform, its

testing also comprises three components, namely

Pub/Sub, Dataflow, and BigQuery. Prior to the

creation of the Pub/Sub topics and subscriptions,

Chef InSpec tests are written to assure the resource

exists in the GCP project. Before executing the

Terraform scripts they failed but were passed after

running it. Then, before writing the Java code to

publish and subscribe messages, JUnit tests were

written for every function. The tests are executed

locally and in the actual environment. GCP provides

a Pub/Sub emulator, which helps develop and test

applications locally without connecting to the actual

production environment. The emulator supports the

creation of topics and subscriptions, publishing

messages, and subscribing messages (Google 2022a).

Dataflow is the streaming platform that integrates

all other services and produces the final result. First,

it receives input data from the Pub/Sub, and finally,

the result is written to BigQuery and relevant Pub/Sub

notification channels. Different services use different

data formats, and Dataflow transforms them

accordingly to be used in the job. Handling different

data formats and transforming them is complex and

highly error prone. Thus, it is essential to test all these

transformation steps to verify that no issues are

introduced during the process. Furthermore,

Dataflow integrates all the services, and it is essential

to verify that all the integrations happen successfully

without any issues. Consequently, transformations

and integrations need thorough testing. The Apache

Beam SDK supports these two types of local testing,

testing transformers that transform input data to

another format to be processed in the next step and

testing the end-to-end pipeline (The Apache Software

Foundation 2021). It has a runner called

DirectRunner, which runs the pipeline locally on a

small scale. In the project, an instance of TestPipeline

is created, primarily used for testing transformers. All

the data transformations are tested using PAssert

statements, which can verify the content inside

collections. Once all the PTransforms are tested, the

end-to-end pipeline testing was done, using a test that

executes all the PTransforms in the pipeline. This

verifies that all the integrations are working without

any issue. However, all these above tests are executed

locally, and it is necessary to test the entire pipeline

in the actual environment. Therefore finally, a test has

been written to execute the entire pipeline in the

actual GCP project and verify the successful

execution via asserting the pipeline result state.

Dataflow writes the transaction details and the

fraud status to the BigQuery table for future reference

in the online fraud detection platform. First, verifying

that the transaction fraud data table exists in the GCP

environment is necessary. Hence, as the first step, the

Chef InSpec test is written to verify the table's

existence. Initially, the test failed before executing

Terraform script, which creates the BigQuery table,

and it was passed after the resource had been created.

Once it is assured that the table exists in the

cloud, it is essential to test the functionality

of converting the transaction details to a table row.

In the Dataflow job, transaction details are converted

to a table row, the input for a BigQuery table,

and written using the following properties:

BigQueryIO.Write.CreateDisposition.CREATE_NE

VER and

BigQueryIO.Write.CreateDisposition.WRITE_APPE

ND.

The Apache beam SDK provides some classes like

FakeBigQueryServices (a fake implementation of

BigQuery's query service), FakeDatasetService (a

fake dataset service that can be serialized for use in

testReadFromTable), FakeJobService (a fake

implementation of BigQuery's job service.), which

simulate the real environment without connecting to

the GCP project to test the BigQuery related

functionalities locally. Therefore, JUnit tests are

written using the above libraries to test the BigQuery

table writing options.

Exploring the Test Driven Development of a Fraud Detection Application using the Google Cloud Platform

4 DISCUSSION

By implementing the above-described project, it has

been shown that the application of TDD in the given

context is possible. However, to further evaluate its

use, several aspects, such as the test coverage or the

code quality, are regarded in the following, which is

succeeded by some further observations.

4.1 Evaluation

While it is not feasible to specify each developed test

case, as it would go beyond the scope, Table 3 gives

a quantitative overview of the distribution of the

tested aspects (those might, in turn, have more than

one test case devoted to them).

In machine learning, testing as many aspects as

possible is recommended (Nauck 2019), therefore,

for the machine learning model, the tests comprise,

inter alia, data quality and completeness, feature

quality, and checks regarding data errors and

consistency.

Dataflow is the main component of the online

fraud detection model, and many tests have been

written for it. Thorough pipeline testing is crucial to

building effective data processing; testing the

transformation functions and the end-to-end pipeline

are the most critical steps for building a pipeline. In

this project, tests are written for every transformation

function, composite transformation function, and

finally, test the end-to-end pipeline as suggested in

the Apache Beam documentation (The Apache

Software Foundation 2021).

The rule engine is created using the controller,

service, and repository design pattern. It is essential

to write tests for all three layers independently and

then finally test as a whole. Therefore, tests are

written for each layer mocking the other interacting

layers, and finally, the entire system is tested using

POSTMAN.

Overall, as shown in

Table 4, the four testing levels

(method, subcomponent, component, system) that are

outlined in (Staegemann et al. 2020) could all be

covered, emphasizing the feasibility of the

proposition.

While the indicators of code coverage are

somewhat tangible, assessing the code quality is less

clear. There are various metrics in code quality, and

different projects use different metrics based on their

context.

For example, in TDD, overall quality,

maintainability (Madeyski 2010; Shrivastava and

Jain 2011), number of bugs (Borle et al. 2018;

Khanam and Ahsan 2017), reliability, and code

coverage by tests (Causevic et al. 2012; Madeyski

2010) are some of the widely used metrics. There are

many online tools available to measure the code

quality, and in this project, SonarQube is used, an

open-source code review tool developed by Sonar

Source. The tool has a free community version, and it

can be installed locally to inspect the local project's

code. It supports analyzing both Java and Python

source code used in the project. Therefore, it was well

suited for this context. Furthermore, SonarQube has

numerous static code analysis tools supporting code

quality and code security, considering aspects

such as complexity, duplications, detected issues,

Table 3: The implemented test cases.

Service Type of test case Tested aspects

Machine Learning Model

Pre-processing test cases 16

Model creation test cases 12

Infrastructure test cases 2

Rule Engine

Infrastructure test cases 3

Controller test cases 2

Service test cases 23

Repository test cases 14

Pub/Sub

General 4

Dataflow

General 1

Data transforming test cases 15

Pipeline test cases 5

BigQuery

General 3

Infrastructure test cases 4

Online Fraud Detection Platform

General 4

Total

108

KMIS 2022 - 14th International Conference on Knowledge Management and Information Systems

Table 4: The test levels.

Testin

Level Testin

Process

Metho

Unit tests are written for each microservice to assure the algorithm's correctness. They

covered each feature like pre-processing and machine learning model creation. Furthermore,

tests are composed for infrastructure creation and availability. Unit tests are written for each

layer mocking the other dependencies in the rule engine microservice. In the fraud detection

application, tests are created to verify dataflow pipeline creation, BigQuery table insertions,

ush notification sending, and subscriptions.

Subcomponen

Complete pre-

rocessing and AutoML Tables functionality can be considered

subcomponents of the machine learning part, and these are covered using the collection of

unit tests. In other parts, the collection of unit tests can also be considered subcomponent

tests when summed up. For example, the subcomponents tests will be all tests related to the

layers of the rule engine, BigQuery table functionality, Pub/Sub functionality, and Dataflow

functionalit

Componen

The communication between the microservices is tested using Dataflow Pipeline, and

different scenarios are written to verify that fraud transactions are identified accurately. In

addition, the POSTMAN tool was used to test whether the REST endpoint is working

correctly in the rule engine.

While(Staegemann et al. 2020) has mentioned the assurance of the performance

requirements like processing speed and capacity with benchmarking. However, no tests are

written separately for speed and capacity as they can be directly monitored via GCP reports.

Syste

Finally, system tests are written considering the en

-user requirements to validate the system

as a single unit. The Cucumber framework was used to verify that the system works as

expected.

maintainability, quality gates, reliability, security,

size, and test coverage. In the following, the analysis

the initial code quality of the projects without fixing

any issues highlighted in the analysis.

Concerning the analysis for the rule engine,

QUALITY GATE STATUS=PASSED assures that it is

production ready.

Moreover, the analysis report reveals that its

maintainability and security are at the highest level.

In the report, two issues are visible, related to

asserting dissimilar types.

However, those are minor issues that can be fixed

quickly and do not impact the actual fraud detection

logic when reviewed. Furthermore, the analysis

shows 121 lines to cover. Yet, when reviewed, they

are Plain Old Java Object (POJO) classes, servlet

initialization code, and object transformation code

that are not generally covered via tests and have a

very low priority in testing. Therefore, the test

coverage of the actual business logic can also be

considered at a higher level.

The machine learning model is created using

Python and SonarQube does not directly support the

code coverage and analysis. Hence, the Coverage

Tool is incorporated to assess the code coverage. The

Code Coverage Tool generates a coverage XML

which records the code coverage by tests and is then

imported to SonarQube to view the complete

analysis. For the analysis, thirty-seven python tests

are executed via the tool. According to the results, the

machine learning model creation project is also

QUALITY GATE STATUS=PASSED which assures

that the project is production-ready at the first

development version without modifications.

Additionally, reliability, security, and

maintainability ratings are at the highest level, being

rated with an A, according to the analysis. The

analysis report shows a code coverage of 67.2%, but

when checking the not covered lines, some of them

are Chef InSpec controls files, which are the tests for

Terraform scripts, and some of the lines shown in the

analysis are print statements that do not need the tests.

So finally, 173 lines needed to be covered, which

show as 485 in the report. When excluding the files

whose tests are not essential, code coverage increased

to 78.9%, which is good coverage for the first

attempt. Further, it is very close to the code coverage

rating A level, which is 80%.

The online fraud detection platform was also

developed as a Java application, and according to the

analysis, it also shows as QUALITY GATE

STATUS=PASSED. That reveals it is ready to be

deployed in production. However, the analysis shows

seven bugs, but five are related to exception handling,

which can be fixed easily when deep into the issue.

The other two issues are also not critical and can be

fixed easily. Security is an essential aspect of fraud

detection systems as it deals with sensitive data,

which needs higher protection. Measuring the

security aspects with the code coverage tool, the

Exploring the Test Driven Development of a Fraud Detection Application using the Google Cloud Platform

analysis shows ten security hotspots. When checking

the detailed analysis, all of them are generated

because of the statement e.printStackTrace(). In the

analysis, maintainability shows as a rating A, which

is one of the factors expected to be achieved via TDD.

The test case count is different from the actual count

as Cucumber tests and Inspect GCP controls are not

picked up by the coverage tool. Three hundred sixty-

nine lines needed to be covered in the code coverage,

but when checked, some lines are covered via

TestPipeline tests. They are not identified via the code

coverage tools due to its handling in Apache Beam

SDK. Therefore, considering the above fact, the

precise lines to be covered are less than 100, which

could be achieved quickly.

4.2 Further Observations

Many tools and services are available in GCP for

developing big data applications. However, not all

tools support TDD for different reasons, like not

having well-defined APIs and the design of the

service being unsuitable for TDD. Consequently,

tools should be evaluated before using them in big

data applications, and only the most suitable tools

should be used for the purpose. Further, the GCP only

provides limited support to test apps locally, and the

provided emulators are also in the beta stage (Google

2022a). For this reason, most tests are executed in the

actual production environment, and they incur costs.

Furthermore, it will create the same resource multiple

times, which is not demanded. Thus, not having a test

environment to test the big data application is a

limitation that needs to be resolved in the future.

After implementing the big data application, code

coverage tools have been used to evaluate the project.

For example, in the evaluation report of the fraud

detection application, it was noticeable that the code

related to Apache beam SDK transforms and

function-related classes was marked as not covered in

the report. However, those functions are covered

using multiple tests and the code coverage tool was

not always able to identify them accurately because

of the structure of the code. Therefore, it is evident

that code coverage tools cannot identify some of the

complex code structures of big data applications.

Hence, extra attention should be needed to select

suitable tools for big data applications before

selecting the tools.

The online fraud detection platform consists of

different microservices. They are developed using

different languages and using different frameworks.

Because of this, a single test library is not sufficient

for writing tests. In traditional projects, the JUnit and

mocking libraries are sufficient to write all tests.

However, different libraries are needed for big data

applications due to their complexity. JUnit, unittest,

Apache beam testing libraries, and BigQuery fake

services are used to write tests in this project.

Consequently, the developers should have the

competencies to handle all these libraries.

Finally, in the literature it is considered best

practice to execute all tests again after a single test

failure. However, it was not feasible due to the

incurring costs, and, therefore, the process was

altered by executing only relevant feature tests after a

test failure.

5 CONCLUSION

With today’s society being more and more data

driven, the concept of BD also gains significance.

However, while the correct utilization promises

immense benefits, assuring the quality of the

corresponding systems is a challenging task. Aiming

to facilitate it, the application of TDD in the BD

domain has been suggested. Therefore, a project was

conducted to further explore the general concept,

show it in a fraud detection use case, and also

examine it in the context of cloud provider services

(such as the GCP in this case). In doing so it was

shown that it is not only possible, but also yields good

results regarding the test coverage and code quality,

further substantiating the concept.

However, there were also some open challenges

and starting points for future research that became

apparent during the project. As indicated in the

previous section, proper tooling is still an open issue

that has plenty of potential for improvement. Further,

some of the tests, like overfitting and underfitting, are

not covered in the projects because they are not

directly retrievable via AutoML responses. However,

covering these types of tests adds more value to

increase the quality, and in the future, research can be

carried out to find a way to retrieve these values. For

example, model hyperparameters-related information

is logged in AutoML logs, and they can be analyzed

to retrieve model training data. Finally, in this work,

the feasibility of TDD is explored by applying it in

the fraud detection domain. However, this approach

for big data can be applied to other use cases so that

more comprehensive insights can be gained, and

collective insights will help for a better TDD process

design.

KMIS 2022 - 14th International Conference on Knowledge Management and Information Systems

REFERENCES

Beck, K. (2015). Test-Driven Development: By Example,

Boston: Addison-Wesley.

Borle, N. C., Feghhi, M., Stroulia, E., Greiner, R., and

Hindle, A. (2018). “Analyzing the effects of test driven

development in GitHub,” Empirical Software

Engineering (23:4), pp. 1931-1958 (doi:

10.1007/s10664-017-9576-3).

Causevic, A., Punnekkat, S., and Sundmark, D. (2012).

“Quality of Testing in Test Driven Development,” in

Proceedings of the 2012 Eighth International

Conference on the Quality of Information and

Communications Technology, Lisbon, Portugal.

03.09.2012 - 06.09.2012, IEEE, pp. 266-271 (doi:

10.1109/QUATIC.2012.49).

Chang, W. L., and Grady, N. (2019). “NIST Big Data

Interoperability Framework: Volume 1, Definitions,”

Special Publication (NIST SP), Gaithersburg, MD:

National Institute of Standards and Technology.

Crispin, L. (2006). “Driving Software Quality: How Test-

Driven Development Impacts Software Quality,” IEEE

Software (23:6), pp. 70-71 (doi: 10.1109/MS.2006.157).

Davies, K., Keet, C. M., and Lawrynowicz, A. (2019).

“More Effective Ontology Authoring with Test-Driven

Development and the TDDonto2 Tool,” International

Journal on Artificial Intelligence Tools (28:7) (doi:

10.1142/S0218213019500234).

Fucci, D., Erdogmus, H., Turhan, B., Oivo, M., and Juristo,

N. (2017). “A Dissection of the Test-Driven

Development Process: Does It Really Matter to Test-

First or to Test-Last?” IEEE Transactions on Software

Engineering (43:7), pp. 597-614 (doi:

10.1109/tse.2016.2616877).

Google. (2022a). “AutoML Tables-Dokumentation,”

available at https://cloud.google.com/automl-tables/

docs, accessed on May 9 2022.

Google. (2022b). “Dataflow Documentation,” available at

https://cloud.google.com/dataflow/docs, accessed on

May 10 2022.

Google. (2022c). “Testing apps locally with the emulator,”

available at https://cloud.google.com/pubsub/docs/

emulator, accessed on May 10 2022.

Huoh, Y.-J. (2017). “Algorithmic and rules-based fraud

models: A high-level look at two fraud models

employed by financial service providers,” available at

https://fin.plaid.com/articles/algorithmic-and-rules-

based-fraud-models/, accessed on May 9 2022.

Janzen, D., and Saiedian, H. (2005). “Test-driven

development concepts, taxonomy, and future direction,”

Computer (38:9), pp. 43-50 (doi:

10.1109/MC.2005.314).

Jones, M. (2019). “The Repository-Service Pattern with DI

and ASP.NET 5.0,” available at

https://exceptionnotfound.net/the-repository-service-

pattern-with-dependency-injection-and-asp-net-core/,

accessed on May 9 2022.

Karlesky, M., Williams, G., Bereza, W., and Fletcher, M.

(2007). “Mocking the Embedded World: Test-Driven

Development, Continuous Integration, and Design

Patterns,” in Embedded Systems Conference, San Jose,

California, USA. 01.04.2007 - 05.04.2007, UBM

Electronics.

Keet, C. M., and Ławrynowicz, A. (2016). “Test-Driven

Development of Ontologies,” in The Semantic Web.

Latest Advances and New Domains, H. Sack, E.

Blomqvist, M. d'Aquin, C. Ghidini, S. P. Ponzetto and

C. Lange (eds.), Cham: Springer International

Publishing, pp. 642-657 (doi: 10.1007/978-3-319-

34129-3_39).

Khanam, Z., and Ahsan, N. (2017). “Evaluating the

Effectiveness of Test Driven Development: Advantages

and Pitfalls,” International Journal of Applied

Engineering Research (12:18), pp. 7705-7716.

Madeyski, L. (2010). “The impact of Test-First

programming on branch coverage and mutation score

indicator of unit tests: An experiment,” Information and

Software Technology (52:2), pp. 169-184 (doi:

10.1016/j.infsof.2009.08.007).

Maniraj, S. P., Saini, A., Ahmed, S., and Sarkar, S. D.

(2019). “Credit Card Fraud Detection using Machine

Learning and Data Science,” IJERT (International

Journal of Engineering Research & Technology)

(08:09) (doi: 10.17577/IJERTV8IS090031).

Mekterović, I., Karan, M., Pintar, D., and Brkić, L. (2021).

“Credit Card Fraud Detection in Card-Not-Present

Transactions: Where to Invest?” Applied Sciences

(11:15), p. 6766 (doi: 10.3390/app11156766).

Müller, O., Fay, M., and Vom Brocke, J. (2018). “The

Effect of Big Data and Analytics on Firm Performance:

An Econometric Analysis Considering Industry

Characteristics,” Journal of Management Information

Systems (35:2), pp. 488-509 (doi: 10.1080/

07421222.2018.1451955).

Nauck, D. (2019). “Test-Driven Machine Learning,”

available at https://www.infoq.com/presentations/tdd-

ml/, accessed on May 9 2022.

Sangwan, R. S., and Laplante, P. A. (2006). “Test-Driven

Development in Large Projects,” IT Professional (8:5),

pp. 25-29 (doi: 10.1109/MITP.2006.122).

Shahin, M., Ali Babar, M., and Zhu, L. (2017). “Continuous

Integration, Delivery and Deployment: A Systematic

Review on Approaches, Tools, Challenges and

Practices,” IEEE Access (5), pp. 3909-3943 (doi:

10.1109/ACCESS.2017.2685629).

Shakir, A., Staegemann, D., Volk, M., Jamous, N., and

Turowski, K. (2021). “Towards a Concept for Building

a Big Data Architecture with Microservices,” in

Proceedings of the 24th International Conference on

Business Information Systems, Hannover,

Germany/virtual. 14.06.2021 - 17.06.2021, pp. 83-94

(doi: 10.52825/bis.v1i.67).

Shrivastava, D. P., and Jain, R. C. (2011). “Unit test case

design metrics in test driven development,” in

Proceedings of the 2011 International Conference on

Communications, Computing and Control Applications

(CCCA), Hammamet, Tunisia. 03.03.2011 - 05.03.2011,

IEEE, pp. 1-6 (doi: 10.1109/CCCA.2011.6031205).

Shull, F., Melnik, G., Turhan, B., Layman, L., Diep, M.,

and Erdogmus, H. (2010). “What Do We Know about

Exploring the Test Driven Development of a Fraud Detection Application using the Google Cloud Platform

Test-Driven Development?” IEEE Software (27:6), pp.

16-19 (doi: 10.1109/MS.2010.152).

Slaats, T., Debois, S., and Hildebrandt, T. (2018). “Open to

Change: A Theory for Iterative Test-Driven Modelling,”

in Business Process Management, M. Weske, M.

Montali, I. Weber and J. Vom Brocke (eds.), Cham:

Springer International Publishing, pp. 31-47 (doi:

10.1007/978-3-319-98648-7_3).

Staegemann, D., Volk, M., Byahatti, P., Italiya, N.,

Shantharam, S., Chandrashekar, A., and Turowski, K.

(2022). “Implementing Test Driven Development in the

Big Data Domain: A Movie Recommendation System

as an Exemplary Case,” in Proceedings of the 7th

International Conference on Internet of Things, Big

Data and Security, Online Streaming/Prague.

22.04.2022 - 24.04.2022, pp. 239-248 (doi:

10.5220/0011085600003194).

Staegemann, D., Volk, M., Jamous, N., and Turowski, K.

(2020). “Exploring the Applicability of Test Driven

Development in the Big Data Domain,” in Proceedings

of the ACIS 2020, Wellington, New Zealand.

01.12.2020 - 04.12.2020.

Staegemann, D., Volk, M., Lautenschläger, E., Pohl, M.,

Abdallah, M., and Turowski, K. (2021). “Applying Test

Driven Development in the Big Data Domain – Lessons

From the Literature,” in Proceedings of the 2021

International Conference on Information Technology

(ICIT), Amman, Jordan. 14.07.2021 - 15.07.2021,

IEEE, pp. 511-516 (doi: 10.1109/ICIT52682.

2021.9491728).

The Apache Software Foundation. (2021). “Test Your

Pipeline,” available at https://beam.apache.org/

documentation/pipelines/test-your-pipeline, accessed

on May 10 2022.

Volk, M., Staegemann, D., Trifonova, I., Bosse, S., and

Turowski, K. (2020). “Identifying Similarities of Big

Data Projects–A Use Case Driven Approach,” IEEE

Access (8), pp. 186599-186619 (doi: 10.1109/ACCESS.

2020.3028127).

Wedge, R., Kanter, J. M., Veeramachaneni, K., Rubio, S.

M., and Perez, S. I. (2019). “Solving the False Positives

Problem in Fraud Prediction Using Automated Feature

Engineering,” in Machine Learning and Knowledge

Discovery in Databases, U. Brefeld, E. Curry, E. Daly,

B. MacNamee, A. Marascu, F. Pinelli, M. Berlingerio

and N. Hurley (eds.), Cham: Springer International

Publishing, pp. 372-388 (doi: 10.1007/978-3-030-

10997-4_23).

Williams, L., Maximilien, E. M., and Vouk, M. (2003).

“Test-driven development as a defect-reduction

practice,” in Proceedings of the 14th ISSRE, Denver,

Colorado, USA. 17.11.2003 - 20.11.2003, IEEE, pp.

34-45 (doi: 10.1109/ISSRE.2003.1251029).

KMIS 2022 - 14th International Conference on Knowledge Management and Information Systems
