Towards a Pattern-based Approach for Transforming Legacy COBOL

Applications Into RESTful Web Services

Christoph Gaudl

and Philipp Brune

2,1

SQ Solutions GmbH, Platz der Einheit 2, 60327 Frankfurt / Main, Germany

Neu-Ulm University of Applied Sciences, Wileystraße 1, 89231 Neu-Ulm, Germany

Keywords:

Legacy Application Modernization, Microservices, Web Services, REST, Java, COBOL.

Abstract:

Many aspects of modern life still depend on large-scale, monolithic legacy applications, e.g. in ﬁnancial ser-

vices, transport or public administration. Typically, these applications are written in ancient programming

languages such as COBOL and use proprietary transaction processing monitors like CICS. While the modern-

ization or replacement of these legacy application has been discusses in literature and practice for decades, still

no universal solution exists. In many cases, an evolutionary modernization strategy has shown to be successful

in practice, allowing to modernize the software architecture as well, not only the program code. Therefore, in

this paper an analysis pattern is derived for transforming stateful, transactional COBOL programs into state-

less RESTful web services. This pattern is evaluated by analyzing and transforming an example COBOL

application to Java. While the approach shows to be useful in case of the example application, it needs to be

further investigated in a broader range of real-world scenarios.

1 INTRODUCTION

In recent years, it became more an more obvious that

not only legacy systems and COBOL applications still

form the backbone of a large part of mission-critical

enterprise IT, but also will continue to do so in the fu-

ture, as their replacement or modernization is a com-

plex and time-consuming task. E.g., in the United

States, 43 percent of banking systems are built on

COBOL, 80 percent of in-person transaction and 95

percent of ATM transactions rely on COBOL code

(Reuters, 2022).

In example, in 2020, during to the pandemic, the

case of the unemployment insurance in the US re-

ceived worldwide media attention, when suddenly a

large number of people tried to ﬁll out their unem-

ployment forms and the system went down. The sys-

tems managing these forms had been developed in

COBOL and not updated for quiet some time (Mak-

ena, 2020). However, the main reason for this col-

lapse was not COBOL as a programming language,

but the fact that the systems where not updated and

the COBOL code was not modernized for quite some

time (Gregori, 2020). Also the neccessary invest-

ments for modernizing these appliactions had been

considered too high for many years (Allyn, 2020).

This is one example of software aging (Huang

et al., 1995): Not actively maintaining program code

for a longer period of time leads to code degeneration

and reduces its quality, until the code is considered

legacy. This not only applies to ancient programm

languages like COBOL or FORTRAN. but can also

hold true for more modern ones like Java or C++

(Sneed, 2006; Srinivas et al., 2016; Knoche and Has-

selbring, 2018).

Therefore, as most legacy systems are mission

critical (Sneed and Erdos, 1996), their moderniza-

tion remains an important and ongoing challenge

in practice.In this paper, we discuss an evolution-

ary approach focusing on breaking up monolithic,

transcational COBOL applications into web services

(Knoche and Hasselbring, 2018), which then could be

modernized and encapsulated. Today, various tech-

nological platforms exist for afterwards implement-

ing and hosting such web services, be it on or off the

mainframe platform (Sherill, 2015; Gohil et al., 2017;

Brune, 2018).

While most early approaches for modernizing a

legacy system nowadays could be considered legacy

systems themselves (Canfora et al., 2008; Sneed,

2006), more recent works discussing a manual trans-

formation into web services mainly focus on a

lift-and-shift approach for non-transactional servics

(Knoche and Hasselbring, 2018; De Lauretis, 2019),

Gaudl, C. and Brune, P.

Towards a Pattern-based Approach for Transforming Legacy COBOL Applications Into RESTful Web Services.

DOI: 10.5220/0011575300003318

In Proceedings of the 18th International Conference on Web Information Systems and Technologies (WEBIST 2022), pages 159-165

ISBN: 978-989-758-613-2; ISSN: 2184-3252

159

moving the functionality off the mainframe com-

pletely.

Therefore, in this paper an analysis pattern for

transforming transactional COBOL programs written

for the IBM CICS transaction monitor into stateless

web services is proposed and evaluated by means of a

semi-realistic sample application. This approach is in

principle agnostic with respect to the objectives of the

modernization, be it a re-use of the existing COBOL

code as part of a web service or a re-write in another

language, and hosted on or off the legacy platform.

The rest of this paper is organized as follows: In

section 2 the related work and previous modernization

efforts are described in detail. Section 3 describes the

proposed analysis pattern, which is evaluated by ap-

plying it to a semi-realistic example in section 4. Sec-

tion 5 illustrates the actual re-implementation of the

web services in Java. We conclude with a summary

of our ﬁndings.

2 RELATED WORK

Legacy modernization has been discussed in the lit-

erature for a long time. Nevertheless, it remains an

ongoing challenge for research and practice.

(Chiang and Bayrak, 2006) describe a process for

extracting and reusing business rules from a given

program. In this approach, program slicing is used.

To ﬁnd which components could be reused, the pro-

gram code is divided into smaller parts. These parts

are used to look into speciﬁc operation categories of

the application. The ﬁrst category is the user inter-

face, the second category are database operations and

the third is the business logic. The program point to

slice must be the last statement for the respective cat-

egory.

In (Comella-Dorda et al., 2000), the need for mod-

ernization is motivated by the goal of avoiding redun-

dant code, and its adaptability to changing business

requirements. System evolution can be achieved by

maintenance, modernization and replacement of soft-

ware components. Modernization is in between main-

tenance and replacement. It is used, when bigger

changes to the software are needed, such as system

restructuring, important functional enhancements or

adding new software attributes. But in contrast to a

replacement, by modernization major business values

are preserved.

(Canfora et al., 2008) differentiate between three

methods for modernization: redevelopment, wrap-

ping and migration. Unlike (Comella-Dorda et al.,

2000), redevelopment here is considered a form of

modernization, deﬁned as re-build of a software from

scratch, on new hardware and with a modern archi-

tecture. Migration is deﬁned as the process of moving

the system to a new platform, while retaining the orig-

inal data and functionalities. Wrapping refers to the

encapsulation of existing data, programs, applications

and interfaces with new interfaces.

For modernization on the mainframe platform it-

self, IBM earlier introduced e.g. the CICS Asyn-

chronous API (Gohil et al., 2017). The basic principle

of the asynchronous API is the parent-child model.

A parent task can run multiple child tasks to execute

logic asynchronously from the parent. Therefore, the

logic executed by the children must be independent

from the other children. Because all the parent and

child tasks are CICS transaction themselves, the lack

of transactional guarantees as mentioned in (Knoche

and Hasselbring, 2018) is no problem here. The trans-

actional guarantees are provided by CICS.

However, nowadays microservices are the state-

of-the-art in application architecture. According to

(Dragoni et al., 2017), a microservice is a cohe-

sive and independent process, which is interacting

via messages. In (Newman, 2021), a microservice

is deﬁned as a small and autonomous service, which

works together with other microservices. Such ser-

vices are the next step in softwae development, re-

placing the earlier after SOA paradigm. Therefore,

in recent years predominantly the transformation of

monolithic legacy applications into microservice ar-

chitectures is discussed by many authors.

(Wolfart et al., 2021) give an overview by

analysing multiple studies to derive a roadmap for

modernizing legacy systems with microservices. The

proposed roadmap consists of eight steps, grouped

into four major phases: initiation, planing, execution

and monitoring of the developed microservices.

Another approach was proposed by (De Lauretis,

2019). Here, the proposed strategy is based on ﬁve

steps to go from the monolithic to the microservice

architecture. The ﬁrst step is the function analysis

of the existing architecture. In the second step Busi-

ness functionalities are identiﬁed and analysed in the

third step. In the following fourth step the business

functionalities are theoretically assigned to new mi-

croservices, and in the last step the microservices are

implemented.

(Knoche and Hasselbring, 2018) also propose a

ﬁve step modernization process: In the ﬁrst step, an

External Service Facade is deﬁned, so microservices

can have entry points to the system. In the second

step, these External Service Facade are adapted to

the existing application. In a third step, the clients

is connected to the new Service Facade. In the fourth

step, an Internal Service Facade is developed. This

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

160

step could also be completed parallel to the ﬁrst three

steps.

The authors chose not to do this, because of the

lack of resources and the high risk to failure. In the

last step, the old services can be replaced by microser-

vices, which still are based on COBOL but are only

accessed through well deﬁned interfaces. These steps

where all done manually and took almost four years

to complete. With this method, so far mainly read-

only operations where converted, because of the lack

transactional guarantees microservices can provide.

The analysis of the related work revealed a major

difference between older (> 5 years) and newer re-

search: While in the older work the focus was more

on the development of an explicit solutions for mod-

ernization of a given application, in the newer papers

the focus is on developing patterns for modernization

in general.

Therefore, in this paper the question is addressed,

how these approaches could be combined to modern-

ize a given application with the use of microservices,

using a generic pattern while still preserving transac-

tional guarantees, such that read and write functional-

ities could be implemented.

3 A PATTERN FOR LEGACY

COBOL CODE ANALYSIS

The ﬁrst step in modernizing any legacy system is the

analysis of the given application. This analysis is nec-

essary to identify the business logic of the given code.

After the business logic of the code is analysed, the

code sections could be identiﬁed, which could be used

for creating a microservice-like structure.

For CICS COBOL programs, these sections can

be identiﬁed by using the embedded EXEC CICS

statements. These statements deﬁne the different

types of functions executed in the transaction. There

are a variety of possible functions used in transac-

tions. Depending on the functions different mod-

ernization options are possible. To get away from a

monolithic application, in a ﬁrst step user interface

and data operations need to be separated. This is

needed to implement a client-server structure. Here,

the server should become stateless, so that the process

state is only implemented in the client and the server

only handles the data operations. The communication

between server and client then works with web APIs.

To achieve this, the following sequence of three

generic steps is proposed:

1. Analyze the user interface maps or mask deﬁni-

tions (UI screens), so that the user interface can be

implemented in the client. If the application, like

the one used in this paper, depends on user inputs,

the ﬁelds in the map can be mapped to input ﬁelds

in a web form.

2. Identify the so called interface commands. These

are given by the EXEC CICS RECEIVE and

EXEC CICS SEND functions (see ﬁgure 1 for an

example). These functions are used to take data

from the mask or send data to the mask. For the

client server structure, these mark the communi-

cation points between server and client.

3. Analyze the other EXEC CICS statements, so the

possible services can be identiﬁed. This step is

highly individual for each given application. But

in this work, a roadmap on how to analyse a given

application is presented in the following.

4 EVALUATION

The evaluation was performed by transforming a

semi-realistic sample CICS COBOL application pro-

vided by SimoTime Technologies for educational pur-

poses (Simotime, 2022). As this is one of the few

available non-trivial CICS example applications on

the web, it is has been used also in other papers as

well (Brune, 2018). It consist of three top-level pro-

grams, which were analyzed in this study.

The COBOL fragment in ﬁgure 1 as taken from

the customer inquiry program, one of these three sam-

ple programs. In the following, this is analyzed as an

example. A similar analysis was performed for all

three programs.

The code in ﬁgure 1 shows the typical use of a UI

map or mask, which allows the user to view any ex-

isting customer VSAM datasets by inserting the cus-

tomer number. Like in many other COBOL and CICS

implementations, the UI and the programming logic

are not separated between host and client. So the ﬁrst

part of the PROCEDURE DIVISION is used to man-

age the masks and get back to a mask higher up in

the hierarchy. This section of the code, which only

contains UI logic, in a modern application would be

implemented in the client, so the server would remain

stateless.

The next section of the code gets the customer in-

formations for a given customer number and arranges

it so the information can be displayed by the mask.

Afterwards, the program reads the information en-

tered by the users into the mask. This can be identiﬁed

by the EXEC CICS RECEIVE statement. This is the

point where the user input is checked, if it applies to

all the rules for a customer number. The fact that this

Towards a Pattern-based Approach for Transforming Legacy COBOL Applications Into RESTful Web Services

161

******************************** * * * * * * * * * * * * * * * * * * * * * * * * *********

END−OF−PROGRAM−12.

EXEC CICS SEND

FROM ( EOJ−MESSAGE)

LENGTH ( 5 0 )

ERASE

END−EXEC

EXEC CICS SEND

CONTROL FREEKB

END−EXEC

EXEC CICS RETURN

END−EXEC

e x i t .

******************************** * * * * * * * * * * * * * * * * * * * * * * * * *********

GET−CUSTOMER−INFORMATION .

p e r f o r m GET−CUSTOMER−NUMBER

p e r f o r m GET−CUSTOMER−RECORD

p e r f o r m POSSIBLE−SPECIAL−HANDLING

p e r f o r m SEND−INQUIRY−SCREEN

Sh o u l d n e v e r g e t t o h e r e . . .

e x i t .

******************************** * * * * * * * * * * * * * * * * * * * * * * * * *********

GET−CUSTOMER−NUMBER.

EXEC CICS RECEIVE

MAP ( ’ CU2INQ1 ’ )

MAPSET ( ’ CU2INQ1 ’ )

RESP (WS−RESPONSE )

RESP2 (WS−REASON−CODE)

END−EXEC .

i f REQNUMBL > ZERO

move REQNUMBI t o Z−WORK−12

p e r f o r m Z−RIGHT−ADJUST−Z−WORK−12

move Z−WORK−12 t o REQNUMBI

move REQNUMBI t o LS−CUSTNO

e l s e

move ’ P l e a s e e n t e r a 12 d i g i t c u s t o m e r number . . . 3 ’

t o MSG−LINES

p e r f o r m RECOVERY−ROUTINE

end− i f .

e x i t .

Listing 1: COBOL code fragment from (Simotime, 2022) illustrating the use of EXEC CICS statements.

check appears similar in two programs makes this sec-

tion a good part to be implemented as a microservice,

as it is small in size and used multiple times.

The next routine which follows is GET-

CUSTOMER-RECORD. In this routine the customer

dataset is ﬁrst read form the dataset of customers and

then mapped to the ﬁelds on the mask of the UI. The

ﬁrst part if reading from the dataset is identiﬁed by

the EXEC CICS read statement. In a microservice

architecture this can be represented by sending a

message with the customer number to a microservice,

which searches a database or dataset and then returns

the dataobject.

The second part of this routine assigns the re-

ceived data to the equivalent positions on the mask.

This part could be solved on the client site in a mod-

ernized approach, because this assignment only is

used for display purposes. The keywords to identify

such a functionality is the ‘MOVE [..] TO‘ combina-

tion.

The following routine SEND-INQUIRY-

SCREEN is also a routine to display the output

onto the screen. This part of the code could also be

handled on the client side of a modern architecture,

e.g. with a JavaScript client.

The two routines Z-RIGHT-ADJUST-Z-WORK-

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

162

12 and Z-GET-DATE-AND-TIME also exists in all

three of the programs analyzed in this work, so an

approach to design them as a microservice is obvi-

ous. The ﬁrst of these two routines takes the user

input of the customer number and adjusts it so that

the length is always 12 characters. The second rou-

tine is used to set the current time onto the screen for

the user. The last routine Z-GET-DATE-AND-TIME-

CICS uses the build in CICS method ASKTIME to

update the time to the current time and not the initial

time, when the task started.

After a deeper look into the code fragments, en-

try points for microservices were identiﬁed. The ﬁrst

pattern which should be looked for are the EXEC

CICS SEND and RECEIVE statements. Between

these parts of the code, normally operations on data

are executed. This is a typical task for the server and

not the client.

Another pattern to look for are the ‘MOVE [...]

TO‘ statements. These statements normally are used

when data is assigned to different variables, either for

operative purpose or displaying purpose. In a mi-

croservice architecture these are the communication

points. Here the client sends the information via mes-

sage to the server and the corresponding microservice,

so the speciﬁc operation can be executed.

This analysis demonstrates, how complex even

such small projects are, when implemented as a

monolithic application. The disadvantages of the

monolithic approach can also be seen in the doubling

of the routine to adjust a customer number to 12 digits

and the routine to get the current time.

In an approach using microservices, these routines

would be only implemented once and then can be

used by other applications that needs this function-

ality.

5 TRANSFORMATION OF THE

APPLICATION

To demonstrate a possible microservice implemen-

tation, the identiﬁed services were implemented as

RESTful services with Java and JAX-RS, using the

OpenLiberty application server

The OpenLiberty server was chosen, because this

application server could also be run on a mainframe

under z/OS. For the purpose of this work, the func-

tionality only was tested on a local machine.

In the ﬁrst step, an OpenLiberty application server

was set up on a local machine using version 22.0.0.5

with the Eclipse IDE version 2022-03(4.23.0). For

https://openliberty.io

the client, a simple JavaScript web client was imple-

mented. The underlying database is an ObjectDB

database. ObjectDB is an open source Object-

Oriented Database Management System implement-

ing the Java Persistence API (JPA)

The ﬁrst Java class to be implemented is the cus-

tomer record. This class was build after the template

of the respective COBOL copybook. So all required

values from the customer ﬁles in the CICS application

could be accessed in this application and saved into a

database. For JPA, this class is used as the JPA entity.

After the customer class, the services needed be

implemented. To replicate the given CICS code, the

services to ﬁnd and create a customer must be imple-

mented. For each of this services, an extra method

was written. Figure 2 shows the respective Java code

fragment for this service class, built using JAX-RS.

The ﬁrst service is the createCustomer method.

The service can be accessed from the client by send-

ing a POST request over the given API. With this call

all the needed customer informations are sent from

the client to the server, by the use of the service API.

Then in the function it is checked if the customer al-

ready exists. If not then the newly created customer

is saved to the ObjectDB database using the Entity-

Manger. After that the created customer is sent back

to the client so it can be displayed for the user.

The second service is the ﬁndCustomer method.

This service can be accessed by a GET request over

the given API. The client sends the Id to the server

over the API. The function then uses the EntityMan-

ager to ﬁnd the wanted Customer using the Id. If the

customer is found it is returned to the client so it can

be displayed for the user.

The routine Z-RIGHT-ADJUST-Z-WORK-12 in

the program in ﬁgure 1 can be replaced by the min-

length and maxlength option on the input label in the

HTML5 frontend. This options only allows inputs

that are exactly 12 digits long. So the user cannot

input an ID which not complies with the length of 12.

In this way, the application was re-implemented

completely in Jakarta EE with the use of an OpenLib-

erty server. This makes the application more open for

future changes to the application. For example, to add

the functionality of updating customers, now only an

extra service needs to be added into the existing ap-

plication. Then the client needs to be adjusted so the

new service can be accessed. After that the User can

access the service over the client and not need to ac-

cess an other sub program like in the CICS version.

https://www.objectdb.com

Towards a Pattern-based Approach for Transforming Legacy COBOL Applications Into RESTful Web Services

163

@ S t a t e l e s s

@Path ( ” s e r v e r ” )

@Consumes ( MediaType . APPLICATION JSON )

p u b l i c c l a s s S e r v e r E J B {

@ P e r s i s t e n c e C o n t e x t ( unitName =” CustomerDB ” )

p r i v a t e E n t i t y M a n a g e r em ;

p r i v a t e s t a t i c f i n a l J s o n b j s o n b = J s o n b B u i l d e r . c r e a t e ( ) ;

@POST

@Path ( ” c r e a t e / { i d } / { fn } / { mn} / { l n } / { a1 }/ { a2 } / { c } / { s } / { pc }/ { ph } / { pw } / { p ce }” )

@Produces ( MediaType . APPLICATION JSON )

p u b l i c C u s t omer c r e a t e C u s t o m e r (

@PathParam ( ” i d ” ) Long cusn umber ,

@PathParam ( ” f n ” ) S t r i n g f i r s t n a m e ,

@PathParam ( ” mn” ) S t r i n g midname ,

@PathParam ( ” l n ” ) S t r i n g l a s t n a m e ,

@PathParam ( ” a1 ” ) S t r i n g a d d r e s s 1 ,

@PathParam ( ” a2 ” ) S t r i n g a d d r e s s 2 ,

@PathParam ( ” c ” ) S t r i n g c i t y ,

@PathParam ( ” s ” ) S t r i n g s t a t e ,

@PathParam ( ” pc ” ) S t r i n g p o s t a l c o d e ,

@PathParam ( ” ph ” ) S t r i n g phone home ,

@PathParam ( ” pw ” ) S t r i n g p hone w o r k ,

@PathParam ( ” pce ” ) S t r i n g p h o n e c e l l ) {

Custo m e r c u s t o m e r = new C u stome r ( cusn umber , f i r s t n a m e ,

midname , l a s t n a m e , a d d r e s s 1 , a d d r e s s 2 , c i t y , s t a t e ,

p o s t a l c o d e , phone home , phone w o rk , p h o n e c e l l ) ;

Custo m e r t e s t c u s t o m e r ;

t e s t c u s t o m e r = em . f i n d ( Cu s t omer . c l a s s , cusnum b e r ) ;

i f ( t e s t c u s t o m e r == n u l l ) {

em . p e r s i s t ( c u s t o m e r ) ;

}

r e t u r n c u s t o m e r ;

}

@GET

@Path ( ” f i n d / { c usnum b e r } ” )

@Produces ( MediaType . APPLICATION JSON )

p u b l i c C u s t omer f i n d C u s t o m e r ( @PathParam ( ” cu s n u m ber ” ) l o n g cusnu m b e r ) {

Custo m e r c = em . f i n d ( Custom e r . c l a s s , cus n u m b er ) ;

r e t u r n c ;

}

Listing 2: Java code fragment of the new implemenation of the customer service.

6 CONCLUSION

In conclusion, in this paper a pattern to transform

monolithic transactional COBOL applications into

stateless web services was proposed. It was evalu-

ated by breaking down the given code of an existing

semi-realistic sample application into pieces, which

later where used to implement a modern application.

This method could be used for any CICS application.

After the explanation on how to break down and

ﬁnd the modernization points in an application, a

methodolgy to modernize the application was shown.

In this case, a new Java application was developed,

with the OpenLiberty server taking over the part of

WEBIST 2022 - 18th International Conference on Web Information Systems and Technologies

164

the CICS transaction monitor. To retain the full func-

tionality of the original application, also a web client

was implemented, which uses the services provided

by the server. This client took over the functionality

of the maps in the old application.

With this implementation, a microservice-based

client-server architecture was achieved. Because of

the use of microservices, new functionalities only

need to add an API so that the client can access them,

and the data required by the client must be deﬁned.

Then the client can be adopted to the new services. So

the development of the logic, which is handled by the

client, and the operations on the data are separated,

and the server becomes stateless.

The next step for this application should be an in-

tegration of the CICS with the Liberty Server itself, so

it can be shown that a modernization can be possible

with reusing the underlying COBOL and CICS code.

Another promising possibility could be the de-

velopment of an automated pattern recognition algo-

rithm, following the pattern presented in this work,

which could make use of machine learning techniques

to further automate legacy modernization.

REFERENCES

Allyn, B. (2020). ’cobol cowboys’ aim to rescue sluggish

state unemployment systems. https://www.npr.org/

2020/04/22/841682627/cobol-cowboys-aim-to-resc

ue-sluggish-state-unemployment-systems. visited:

07/06/2022.

Brune, P. (2018). An open source approach for moderniz-

ing message-processing and transactional cobol appli-

cations by integration in java ee application servers. In

International Conference on Web Information Systems

and Technologies, pages 244–261. Springer.

Canfora, G., Fasolino, A. R., Frattolillo, G., and Tramon-

tana, P. (2008). A wrapping approach for migrating

legacy system interactive functionalities to service ori-

ented architectures. Journal of Systems and Software,

81(4):463–480.

Chiang, C.-C. and Bayrak, C. (2006). Legacy software

modernization. In 2006 IEEE international confer-

ence on systems, man and cybernetics, volume 2,

pages 1304–1309. IEEE.

Comella-Dorda, S., Wallnau, K. C., Seacord, R. C., and

Robert, J. E. (2000). A survey of black-box modern-

ization approaches for information systems. In icsm,

pages 173–183.

De Lauretis, L. (2019). From monolithic architecture to

microservices architecture. In 2019 IEEE Interna-

tional Symposium on Software Reliability Engineering

Workshops (ISSREW), pages 93–96. IEEE.

Dragoni, N., Giallorenzo, S., Lafuente, A. L., Mazzara, M.,

Montesi, F., Mustaﬁn, R., and Saﬁna, L. (2017). Mi-

croservices: yesterday, today, and tomorrow. Present

and ulterior software engineering, pages 195–216.

Gohil, P., Horn, J., He, J., Papageorgiou, A., Poole, C., et al.

(2017). IBM CICS Asynchronous API: Concurrent

Processing Made Simple. IBM Redbooks.

Gregori, S. (2020). Cobol isn’t the issue: A misinterpreted

crisis. https://hackaday.com/2020/04/20/cobol-isnt-th

e-issue-a-misinterpreted-crisis/. visited: 07/06/2022.

Huang, Y., Kintala, C., Kolettis, N., and Fulton, N. D.

(1995). Software rejuvenation: Analysis, module and

applications. In Twenty-ﬁfth international symposium

on fault-tolerant computing. Digest of papers, pages

381–390. IEEE.

Knoche, H. and Hasselbring, W. (2018). Using microser-

vices for legacy software modernization. IEEE Soft-

ware, 35(3):44–49.

Makena, K. (2020). Unemployment checks are being held

up by a coding language almost nobody knows. https:

//www.theverge.com/2020/4/14/21219561/coronavi

rus-pandemic-unemployment-systems-cobol-legacy-

software-infrastructure. visited: 07/06/2022.

Newman, S. (2021). Building microservices. ” O’Reilly

Media, Inc.”.

Reuters (2022). Cobol blues. http://ﬁngfx.thomsonreuters

.com/gfx/rngs/USA-BANKS-COBOL/010040KH18

J/index.html. visited: 07/06/2022.

Sherill, S. (2015). Building an api bridge to your ibm z

systems applications and data.

Simotime (2022). Cics cobol example application. http:

//www.simotime.com/sim4home.htm. visited:

16/05/2022.

Sneed, H. M. (2006). Integrating legacy software into a ser-

vice oriented architecture. In Conference on Software

Maintenance and Reengineering (CSMR’06), pages

11–pp. IEEE.

Sneed, H. M. and Erdos, K. (1996). Extracting business

rules from source code. In WPC’96. 4th Workshop on

Program Comprehension, pages 240–247. IEEE.

Srinivas, M., Ramakrishna, G., Rao, K. R., and Babu, E. S.

(2016). Analysis of legacy system in software appli-

cation development: A comparative survey. Interna-

tional Journal of Electrical & Computer Engineering

(2088-8708), 6(1).

Wolfart, D., Assunc¸

ao, W. K., da Silva, I. F., Domingos,

D. C., Schmeing, E., Villaca, G. L. D., and Paza, D.

d. N. (2021). Modernizing legacy systems with mi-

croservices: A roadmap. In Evaluation and Assess-

ment in Software Engineering, pages 149–159.

Towards a Pattern-based Approach for Transforming Legacy COBOL Applications Into RESTful Web Services

165
