Learning Behavior Analysis of MOOC Learners Based on

Multivariate Meta-Analysis Model

Yang Le

College of Computer and Information Engineering, Jiangxi Agriculture University, Nanchang, China

Keywords: Multivariate Meta-Analysis Model, MOOC, Behaviour Model, Learning Effectiveness, Influence.

Abstract: MOOC is promoting another innovation in human education, which realizes a broad increase in educational

participation. MOOC supports and facilitates learners’ autonomous personalized learning process and

learning outcomes, and MOOC learners have diversified learning behaviour patterns. Many studies have

pointed out that online learning behaviour patterns are highly correlated with learning outcomes. This study

proposes a learning behaviour analysis architecture for MOOC learners based on multivariate meta-analysis,

taking the "Web System Development and Design" course as an example, online learning behaviour data of

the MOOC learners are processed and analysed to obtain the desired result effect value, and merging all the

effect values by multivariate analysis, finally obtaining a valid conclusion. According to the results of data

analysis, relevant improvement strategies and suggestions are put forward for different stakeholders. By

discovering the problems hidden in the online learning process of MOOC learners, prompting and warnings

in a timely manner, and adjusting the teaching plan in a targeted manner.

1 INTRODUCTION

Since the outbreak of novel coronavirus pneumonia

(COVID-19) at the end of 2019, the development of

online learning has been greatly accelerated. As a

new form of education, MOOC has attracted much

attention for its large-scale, open, free learning

platform services and other characteristics. It

transcends the limitation of time and space and

realizes the wide participation of education. In the

context of "Internet +", big data is rapidly flooding

all walks of life, and the field of education is no

exception. With the development of learning

analysis and artificial intelligence technology, it has

become an irresistible trend to use online learning

behaviour data of student to evaluate students’

learning performance and provide better services for

students (Francisco, 2018; Tsai 2018; Gold 2020).

The online learning platform will record the basic

information of MOOC learners, the update of

teaching resources and the learning behaviour data

of learners, that is, the online learning platform

stores the learning behaviour data of MOOC learners

from the beginning to the end of learning. In the face

of massive data, how to collect, process and analyse

the data so as to truly understand MOOC learners’

course learning situation, value orientation and

psychological state of MOOC learners, making

MOOC teaching more attractive and spreadable, is

one of the key tasks to be completed urgently to

discover and use the value of online learning

behaviour data, and to provide strong data support,

method compliance and practical guidance for

promoting educational informatization to help

families, schools and society cooperate in educating

people

Jovanovic et al. used the K-means algorithm to

construct evaluation criteria to distinguish learners

into three categories: good, general and poor. On

this basis, they continued to use the cognitive

characteristics of learners collected by the scale and

made further analysis and exploration (Jovanovic

2012). Using the back propagation (BP) neural

network method, Wang et al. developed an English

learning system that matches the learner 's learning

situation. This system could recommend learning

resources suitable for each learner based on different

learner’s personality traits, gender, and learner

learning anxiety (Wang 2011). Rajendran et al.

comprehensively analyzed the relevant theories of

pedagogy and psychology, and they found that if

learners encounter difficulties in the process of

learning, the learners will be frustrated. Then, they

130

Le, Y.

Learning Behavior Analysis of MOOC Learners Based on Multivariate Meta-Analysis Model.

DOI: 10.5220/0011901400003613

In Proceedings of the 2nd International Conference on New Media Development and Modernized Education (NMDME 2022), pages 130-136

ISBN: 978-989-758-630-9

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

analyzed the situation of learners using intelligent

auxiliary systems, collected the reasons for their

learning difficulties and established a linear model to

achieve the goal of judging the emotional state of

learners when using intelligent auxiliary systems,

and timely reminded teachers to resolve the

difficulties encountered by learners and changed the

current situation that learners are not conducive to

learning (Rajendran 2013). Aher et al. used the K-

means algorithm to cluster the basic situation of

learners, then, they used the Apriori algorithm to

analyze the correlation of learners in each category,

and obtained the course categories that learners like

to learn, so as to push their favorite learning content

to learners (Aher 2013). Chen implemented a multi-

label classification algorithm to classify tweets that

reflect student issues, selecting about 35,000 tweets

from Purdue University to train a problem detector,

demonstrating how informal social media data

provides insights into student experiences and

strategies (Chen 2014). Patil gathered information

about all engineering students' online interactions on

Twitter, analyzed problems such as heavy learning

burdens, negative emotions, lack of social

engagement, and drowsiness. At the same time, he

used Bayesian algorithms to process the data and

tried to solve this problem (Patil 2018). Guo

proposed a multiple learning behavior analysis

framework. Based on the perspective of multiple

frameworks, she systematically analyzed the

learning behavior of MOOC learners participating in

X course, and discussed the strategies for optimizing

the design of MOOC courses (Guo 2017). Shen et al.

obtained a lot of MOOC learners' learning behavior

data from relevant platforms, constructed a model of

students' online learning behavior and online

learning performance evaluation, and then they

conducted sampling stepwise regression to

understand the impact of students ' online learning

behavior on their academic performance (Shen

2020). Based on the perspective of network learning

resources, Zhao et al. empirically studied the

learning behavior pattern of online learners and its

influence on learning effectiveness, indicating that

the behavior pattern of accessing network learning

resources is related to learning effectiveness (Zhao

2019). Li focused on the learning behavior of

MOOC learners, explored the impact of MOOC

learners' learning behavior patterns on learning

effectiveness, and provided effective suggestions for

improving the learning effectiveness of MOOC

learners (Li 2020). Cheng et al. combined the course

of "Principles of Systems Engineering" on the

military vocational education platform to collect

online learning data for analyzing the learning

behavior of MOOC learners in military education,

and proposed the optimization method of MOOC

design in military education based on learning

behavior analysis (Cheng 2022).

These studies have systematically analysed the

learning behaviour data of MOOC learners, to a

certain extent; can effectively promote the learning

completion rate of MOOC courses. But based on the

perspective of multivariate meta-analysis to study

the learning behaviour of MOOC learners, there is

less involved. Therefore, this paper studies the

analysis of MOOC learners' online learning

behaviour data in the multivariate meta-analysis

environment, constructs the analysis framework of

MOOC learners' online learning behaviour based on

multivariate meta-analysis, and combines chapter

learning and video learning to empirically analyze

MOOC learners' online learning behaviour, so as to

provide operational opinions and suggestions for

improving MOOC learners ' learning effectiveness.

2 CONSTRUCT MULTIVARIATE

META-ANALYSIS

FRAMEWORK FOR MOOC

LEARNERS' LEARNING

BEHAVIOR

Taking MOOC learners who take the course of

"Web System Development and Design" as samples,

the system log data of MOOC platform and the basic

information of learners are collected to analyse the

preliminary influence relationship between MOOC

learners' learning behaviour and learning effect.

Firstly, the analysis framework of MOOC learners'

learning behaviour is designed, and MOOC learners'

learning behaviour is divided into five categories:

(1) Resource learning behaviour: such as the total

number of platform login, the total duration of

platform login, the total number of resource

learning, the total duration of resource learning,

resource learning completion rate, resource learning

interval, resource learning hops, whether learners

learn resources in order, resource learning repetition

rate and so on; (2) Homework learning behaviour:

such as job scoring rate, job completion rate, number

of repeated jobs, number of repeated submission

tests and so on; (3) Interactive learning behaviour:

such as the number of MOOC learners browsing

posts, the total number of posts, the total number of

replies, the number of posts, and the number of

replies and so on; (4) Learning time preference

Learning Behavior Analysis of MOOC Learners Based on Multivariate Meta-Analysis Model

131

behaviour: such as the number and time of morning

study, the number and time of afternoon study, the

number and time of evening study, the number and

time of study in the early hours of the morning and

so on; (5) Page access behaviour: such as course

announcement access times, courseware access

times, course scoring standard access times, other

page access times, etc.

Before the empirical analysis framework, this

study first used confirmatory factor analysis to

evaluate the various latent variables in the research

model, and used reliability analysis to measure the

adequacy of the model. Cronbach’s coefficient (

)

and composite reliability (CR) were used to evaluate

the reliability of the measurement model. It can be

seen from Table 1 that these two indicators are

greater than the critical value of 0.70 in each latent

variable, indicating that the measurement model of

each latent variable has good internal consistency, so

the MOOC learner learning behaviour analysis

framework of multivariate meta-analysis constructed

in this study has good reliability.

Table 1: Reliability analysis of Analysis framework.

Classification Average Standard deviation

Resource learnin

behaviou

3.732 0.891 0.882 0.892

Homework learning

ehaviou

3.043 0.878 0.788 0.853

Interactive learning behaviou

2.987 0.868 0.796 0.782

Learning time preference

ehaviou

2.961 0.845 0.789 0.799

Page access behaviou

3.661 0.816 0.852 0.815

3 AN EMPIRICAL ANALYSIS OF

MOOC LEARNERS'

LEARNING BEHAVIOUR

3.1 MOOC Learner Learning

Behaviour Data Processing

The collected data of MOOC learners' online

learning behaviour are derived from the explicit

behaviour of “Web System Development and

Design” course. Firstly, all the data are desensitized

to ensure the personal privacy of MOOC learners.

Part of the MOOC learners' online learning

behaviour data collected is the personal basic

information of MOOC learners, including name,

education, major, etc. The other part is the explicit

behaviour data of MOOC learners, including the

number of course task points completed, audio and

video viewing details, discussion details, chapter

learning times, assignments, comprehensive grades,

etc. This paper will select the appropriate model

through the above data to explore MOOC learners'

online learning behaviour and the degree of mastery

of the course, understand the relationship between

course learning grades, and put forward

corresponding conclusions and problem-solving

measures for MOOC learners, teachers, teaching

designers and teaching managers. Firstly, based on

the idea of the distribution lag nonlinear model, the

nonlinear exposure-response relationship between

each explicit behaviour-performance was fitted

respectively. The natural cubic spline function was

used to control the confounding of audio and video,

discussion, the number of chapters learning and

grade. After the effect of single explicit behaviour

was obtained, the effect value of the result was

merged and analysed by multivariate Meta random

effect model.

3.2 MOOC Learner Learning

Behaviour Data Processing

There are many data in the analysis framework of

MOOC learners' learning behaviour, among which

chapter learning and video learning in resource

learning behaviour are the most representative,

which have the greatest impact on MOOC learners'

learning effectiveness. After processing the data of

MOOC learners' learning behaviour, the multivariate

Meta random effect model is used to fit the

relationship between the deviation of chapter

learning times and the comprehensive performance.

The main task of this stage is to estimate the effect

of individual explicit behaviour, construct Poisson

regression and correct the underestimation of

standard error. And then, the result effect value was

combined and analysed by using the random effect

model of multivariate meta-analysis after obtaining

the result effect value of a single class.

NMDME 2022 - The International Conference on New Media Development and Modernized Education

132

3.2.1 Multivariate Meta-Analysis of the

Number of Chapters and Grades

The number of chapters in the resource learning

behaviour can reflect the degree of completion and

enthusiasm of MOOC learners for course learning.

A multivariate meta-analysis of the number of

chapters and academic grades is conducted to know

the implicit influence between the two, understand

the inherent problems of MOOC learners' online

learning, and better improve the teaching of MOOC

courses. The number of chapters is shown in Table

2. The multivariate meta-analysis model is used to

process the compiled chapter learning data, and the

results are shown in Table 3 and Table 4.

Table 2 Statistics table of chapter learning times.

Chapter data

Sample size 8065

Minimum number of learning 1073

Maximum number of learnin

4077

Average

2503

Deviation 60

Table 3 Results Estimated effect coefficient of Chapter

Learning.

Estimate -0.3796 -0.4628 -0.7585 -0.0712

Std. Erro

0.0466 0.0447 0.0977 0.0268

z -8.1390 -10.3612 -7.7617 -2.6595

(

0.000* 0.000* 0.000* 0.0078

95%ci.lb -0.4711 -0.5504 -0.9501 -0.1238

95%ci.ub -0.2882 -0.3753 -0.5670 -0.0187

Table 4 Variance components of Chapter Learning.

Std. Dev Cor

1 0.1368

2 0.1273 1.0000

3 0.2787 0.9955 0.9959

4 0.0590 0.9029 0.9029 0.8581

Table 5 Multivariate meta-analysis of online learning

behaviour data heterogeneity.

Multivariate Cochran Q test for heterogeneit

Q = 98.7166 (df = 36)

-value = 0.000*

I-s

uare statistic = 63.5%

The results of Table 3 showed that the

coefficients of the nonlinear result effect curves of

the number of chapter’s deviation are statistically

significant because the P values are less than 0.001

and the P values of b4 are less than 0.01, which can

promote MOOC learners to make further efforts in

learning. The heterogeneity analysis results of

multivariate meta-analysis of online learning

behaviour data are shown in Table 5, where

Q=98.7166, heterogeneity size I

=63.5%, and

P<0.001, it is explained that the heterogeneity of the

collected MOOC learner online learning behaviour

data can analyse whether there is a correlation

between different learning behaviour patterns and

learning outcomes of MOOC learners, and how

correlated they are, and promote the construction of

high-quality online learning resources and platforms.

3.2.2 Multivariate Meta-Analysis of Time to

View Learning Video and

Comprehensive Scores

For the explicit behaviour analysis of MOOC

learners' online learning behaviour, an important

indicator to judge the degree of course learning

completion and learning autonomy is the viewing

time of course video. A simple multivariate meta-

analysis using correlation fitting models to explore

the deeper relationship between the time to view

learning video and comprehensive scores is an

important part of online learning behaviour analysis.

Firstly, the collected MOOC learners' learning

behaviour data are summarized. According to the

characteristics of course video viewing time, the

data are sorted out to make simple descriptive

statistic, as shown in Table 6. The results showed

that MOOC learners have significant differences in

the total duration of course video viewing, and the

results of multivariate meta-analysis model are

shown in Table 7 and 8.

Table 6 Statistics table of learning video viewing time.

Video data

Sample size 9165

The shortest viewing time（

minute）

48.1

The lon

est viewin

time

(

minute

)

1027.8

Average (minute) 595.5

Deviation (minutes) 159.5

Table 7 Results Estimated effect coefficient of Video

learning.

b1 b2 b3 b4

Estimate -0.5908 -0.6150 -0.7517 -0.8004

Std. Error 0.0478 0.0381 0.0449 0.0409

z -12.3522 -16.1320 -16.7346 -19.5799

Pr (>|z|) 0.000* 0.000* 0.000* 0.000*

95%ci.lb -0.6845 -0.6897 -0.8387 -0.8806

95%ci.ub -0.4970 -0.5403 -0.6636 -0.7203

Learning Behavior Analysis of MOOC Learners Based on Multivariate Meta-Analysis Model

133

Table 8 Variance components of Video learning.

Std. Dev Cor

1 0.0917

2 0.0729 .9461

3 0.0905 0.9704 0.9963

4 0.0652 0.6983 0.8924 0.8505

Table 9 Heterogeneity of online learning behaviour data.

Multivariate Cochran Q test for hetero

eneit

Q = 103.2740

(

df = 45

)

-value = 0.000***

I-square statistic = 56.4%

The P values in Table 7 are all less than 0.001,

indicating that the coefficient of the nonlinear result

effect curve of learning video viewing time has

important analytical significance for improving the

stickiness of MOOC learners. In Table 9, Q =

103.2740, heterogeneity size I

= 56.4%, and P <

0.001, indicating that the heterogeneity of students'

online learning behaviour data collected can

promote the improvement of teaching video, attract

MOOC learners to learn courses, and is conducive to

the completion rate of MOOC courses.

4 IMPROVEMENT STRATEGIES

FOR MOOC LEARNING

According to the analysis framework of MOOC

learners' learning behaviour and the empirical

analysis experiment of MOOC learners' learning

behaviour, the problems faced by ordinary MOOC

learners in the process of learning MOOC courses

are revealed to some extent. Therefore, from the

perspective of different stakeholders, this paper puts

forward suggestions and strategies to optimize the

construction of MOOC courses and to benefit

MOOC learners ' learning.

(1) Diversified construction of MOOC learning

resources and balanced promotion of the application

of various resources.

The study found that the frequency of MOOC

learners using various types of learning resources is:

video learning resources, picture learning resources,

document learning resources, job resources and

interactive behaviour. The frequency of MOOC

learners browsing learning resources, the total length

of browsing and the total number of times determine

the learning efficiency of MOOC learners.

Therefore, it is suggested to make multi-dimensional

video learning resources to guide MOOC learners to

learn video in order and regularly. The balanced

development of various course learning resources

can promote MOOC learners to use and learn

various resources from multiple angles and

perspectives.

(2) Build a MOOC learning community and

enhance the activity of the platform.

The learning method of 'time and space

separation' causes MOOC learners to need more

social interaction, and MOOC learners from all over

the world gather through the MOOC platform with a

common goal. Building a MOOC learning

community can narrow the interaction distance of

social interaction and achieve effective learning.

MOOC learning community refers to a virtual

learning group composed of teachers and students in

the learning process of MOOC courses. Through

mutual help, mutual influence, communication and

discussion, cooperation and sharing with other, they

experience learning and jointly complete the

learning tasks of MOOC courses, which will help to

effectively improve the teaching effect of the course.

At the same time, we should encourage MOOC

learners to carry forward the spirit of 'co-creation

and sharing', build multi-participation and multi-win

network learning resources on the platform, and

jointly build rich and diverse curriculum learning

resources.

(3) Constructing diversified homework

assessment mode to embody knowledge transferable

skills.

Homework learning behaviour has a great

positive impact on MOOC learners' learning

performance, and the completion rate of homework

is obviously conducive to the improvement of final

grades. Therefore, in the process of MOOC

teaching, we should grasp the key factors that affect

the learning effect, that is, the proportion of

homework completion and the quality of homework

completion. There is a significant gap between this

influencing factor and other factors, and it is even

more important than other influencing factors.

Therefore, in order to fully reflect the professional

knowledge and skills of students, it should be

decided to abandon the simple scheme of using the

final exam results as the final score of the course,

and it is necessary to establish a scientific and

diversified assessment method to reflect the

knowledge transferability of MOOC learners. In the

process of MOOC teaching, teachers should pay

special attention to the design, submission,

evaluation and other aspects of the homework part,

and urge and ensure that MOOC learners complete

their homework on time and efficiently.

(4) Establishing MOOC teaching community to

improve course teaching interaction design.

NMDME 2022 - The International Conference on New Media Development and Modernized Education

134

Good curriculum teaching interaction design

effect will significantly affect MOOC learner

stickiness, and a diverse teaching team can ensure

the quality of curriculum teaching interaction design.

The purpose of forming the MOOC Teaching

Community is to strengthen cooperation, dialogue

and sharing among teachers, find effective practices

in the teaching process of MOOC courses, and

ensure the learning quality of MOOC learners.

Teachers need to frequently review the questions

raised by MOOC learners and solve problems

encountered in the teaching process of MOOC

courses. Teachers should lead MOOC learners to

discuss and answer questions in a timely manner,

and design more reasonable course teaching

interactions based on learner satisfaction (Yang

2020). The teaching community must strengthen the

cultivation of teachers' informatization ability and

strengthen the teaching design skills of MOOC

courses. Teachers can carry out a variety of

interactive activities (such as timely response,

instant communication, etc.), so that learners get a

higher sense of participation and enhance learners '

participation in generative resources.

(5) MOOC instructional design and instructional

administrators provide personalized learning support

services.

MOOC instructional design and teaching

management mechanism need to take some

measures to optimize the presentation of learning

activities, to provide MOOC learners with more

personalized learning support and services, thereby

enhancing the effectiveness of MOOC learners. For

different types of MOOC learners, the learning

situation of MOOC learners is predicted according

to MOOC big data, and an autonomous personalized

learning trajectory is recommended for MOOC

learners. MOOC learners independently select other

learning resources according to their own

preferences in the learning process, and formulate

appropriate learning strategies and learning plans

(Yang 2016). In the teaching design of MOOC

course, it provides learning resources that adapt to

the learning methods and habits of MOOC learners,

so as to improve the utilization of MOOC course

resources by MOOC learners, so as to improve the

learning effect of MOOC learners. The design of

learning activities is diversified, and the evaluation

method of learning effectiveness is more scientific

and reasonable, so as to achieve the goal of

enhancing the stickiness of MOOC courses.

5 CONCLUSIONS

MOOC learners with different goals, preferences

and learning motivations may show different levels

of participation and behaviour patterns in learning,

and different levels of participation and behaviour

patterns will in turn affect learning effectiveness.

This paper studies the data of MOOC learners '

learning behaviour, and conducts an empirical

analysis of MOOC learners ' chapter learning and

video learning based on the multivariate Meta

random effect model to explore learners ' different

behaviour patterns and the influence of different

behaviour patterns on learning effectiveness. It

provides useful information for MOOC instructional

designers, and then improves the existing

instructional design, teaching content arrangement

and online learning resource presentation. At the

same time, it can also guide MOOC instructional

designers to put forward instructional design

problems from the perspective of learning theory,

and provide a way to answer questions for

instructional design, and then develop a personalized

learning support system. Combined with the

empirical analysis of the results of MOOC learners '

online learning behaviour, it provides effective

strategies for improving the learning effectiveness of

MOOC learners, and provides reasonable

suggestions for the promotion and development of

MOOC in the future.

ACKNOWLEDGEMENTS

This work was supported by the 14th Five-years

Plan of Jiangxi science of education the key

Research topics (No. 22ZD014).

REFERENCES

Aher S B, Lobo LMRJ. Combination of machine learning

algorithms for recommendation of courses in E-

Learning System based on historical data[J].

Knowledge-Based Systems, 2013, 51(10):1-14.

Chen X, Vorvoreanu M, Madhavan K. Mining Social

Media Data for Understanding Students’ Learning

Experiences [J]. IEEE Transactions on Learning

Technologies, 2014, 7(3):246-259.

Cheng Zhijun, Peng Juan. Research on the Learning

Behavior and the Teaching Design of MOOCs for

Military Professional Education [J]. Journal of Higher

Education Research, 2022, 45(2):65-71.

Learning Behavior Analysis of MOOC Learners Based on Multivariate Meta-Analysis Model

135

Francisco J, García P, Ángel F B, et al. Anadaptive hybrid

MOOC model: Disrupting the MOOC concept in

higher education [J]. Telematics and Informatics,

2018, 35(4):1018-1030.

Gold R, Hemberg E, O’Reilly U M. Analyzing K-12

Blended MOOC Learning Behaviors [C]. Seventh

(2020) ACM Conference on Learning, 2020, 8: 12-14.

Guo Xinyue. Analyzing MOOC Learning Behavior under

A Multi-Analysis Framework [J]. Journal of Open

Learning, 2017, 22(4):21-28.

Jovanovic M, Vukicevic M, Milovanovic M, et al. Using

data mining on student behavior and cognitive style

data for improving e-learning systems: a case study

[J]. International Journal of Computational Intelligence

Systems, 2012, 5(3):597-610.

Li Min. A Study on the Influence of Learning Behavior

Patterns on Learning Effectiveness in MOOCs [D].

Wuhan: Central China Normal University, 2020.

Patil S, Kulkarni S. Mining Social Media Data for

Understanding Students’ Learning Experiences using

Memetic algorithm [J]. Materials Today Proceedings,

2018, 5(1):693-699.

Rajendran R, Iyer S, Murthy S, et al. A Theory-Driven

Approach to Predict Frustration in an ITS [J]. IEEE

Transactions on Learning Technologies, 2013,

6(4):378-388.

Shen Xinyi, Liu Meichen, Wu Jianwei, Dong Xianlei..

Towards a model for evaluating students online

learning behaviors and learning performance [J].

Distance education in China, 2020, (10),1-8,76.

Tsai Y H, Lin C H, Hong J C, et al. the effects of

metacognition on online learning interest and

continuance to learn with MOOCs[J]. Computers &

Education, 2018, 121:18-29.

Wang Y H, Liao H C.Data mining for adaptive learning in

a TESL-based e-learning system [J]. Expert Systems

with Applications, 2011,38(6):6480-6485.

Yang le. The Model of Social Interactions ’Influence on

the Stickiness of MOOC Learners [J]. Journal of

Jiangxi Radio & TV University, 2020,9:19-24.

Yang le. Modeling Personalized and Self-regulated in

MOOC [J]. Contemporary Educational Science,

2016(5):40-42.

Zhao Chengling, Li Min, Shu Fengfang, Huang Yan.

Research on Models of Participation in Online

Learning Resources and Learning Effectiveness [J].

Modern Distance Education, 2019(4):20-27.

NMDME 2022 - The International Conference on New Media Development and Modernized Education

136
