SHOID: A Secure Herd of IoT Devices Firmware Update Protocol

eric Ruell

, Quentin Guella

and Arnaud Rosay

STMicroelectronics, 11 Rue Pierre F

elix Delarue, Le Mans, France

Keywords:

Group of IoT Devices, Secure Firmware Update, Secure Group Communication, Device Management.

Abstract:

The Internet Of Things (IoT) movement puts more and more objects on the ﬁeld, which raises critical pro-

blems related to device management and security, especially for resource-constrained nodes. In this paper, we

propose a method for the devices to create self-organized groups autonomously. We demonstrate how we can

leverage this group concept to improve the robustness of a key device management procedure: the over-the-air

ﬁrmware update. Experiments have been conducted with micro-controller based objects addressing a typical

smart sensor use-case. Finally, ways of improvements arise and further study items are identiﬁed.

1 INTRODUCTION

Internet Of Things (IoT) is a major trend we can ob-

serve in almost all business areas. Bringing internet

connectivity to all sorts of traditional devices is rad-

ically changing the way the internet is accessed and

the way devices can be used. All these new connected

objects can exchange data and commands with remote

servers, also known as the cloud. As data exchanges

are not always initiated by an explicit user request,

security becomes a critical topic for the IoT. Hack-

ers can access such devices remotely to steal data,

use them as botnets to conduct other attacks like Dis-

tributed Denial Of Service attack, or misuse them in

various manners. The Mirai botnet is an example of

such attacks, and highlights the difﬁculty to thwart

them without appropriate procedures (Kambourakis

et al., 2017). Moreover, the number of attacks on IoT

devices is increasing (Demeter et al., 2019). There-

fore, IoT security is now a major topic that is also

dealt with by laws (Kelly, 2020; European Commis-

sion, 2022). Professionals do insist on the critical im-

portance of one procedure to secure IoT: the ﬁrmware

update (Adams, 2021). So, many security companies

and academics address this topic (ProvenRUN, 2022;

K.Zandberg et al., 2019).

In addition to this security aspect, we observe

the deployment of large ﬂeets of resource-constrained

devices in the area of smart lighting, smart build-

ing, smart cities, smart industries, and smart health-

https://orcid.org/0000-0002-4593-5032

https://orcid.org/0000-0002-0372-072X

https://orcid.org/0000-0001-5937-5331

care. Smart sensors have been deﬁned some time ago

(B.F. Spencer et al., 2004), but the domain evolves

(Gervais-Ducouret, 2011). Nevertheless, the require-

ments for this class of devices are still the same: low

production cost, battery powered device operating for

years with low maintenance costs, limited data com-

munication rates. These economical constraints in-

duce strong technical constraints: limited memory

and computing capacity, necessity to operate in low

power modes with reduced data volumes. These re-

quirements are key to deploy such sensors, and leve-

rage all the beneﬁts they bring: improved reactivity

to real-time events, cost-efﬁcient infrastructures mon-

itoring and administration. Last but not least, due to

the criticity of the envisioned applications, security is

key, but must come at the lowest possible cost.

As the smart sensors of a same ﬂeet share similar

characteristics and run the same use-cases, we leve-

rage these commonalities to improve the security of

a group of devices by deﬁning a synchronized secure

ﬁrmware update procedure. Hence, we create a Se-

cure Herd Of IoT Devices (SHOID), bringing extra

security, but still meeting the economical and techni-

cal requirements listed above.

Our contribution applies to ﬂeets of homogeneous

objects sharing the same hardware, ﬁrmware and ex-

changing data with a same cloud infrastructure. We

focus on the ﬁrmware distribution and validation by

the devices. First, we review some existing tech-

niques to create a secure group of IoT devices, and

provide a secure ﬁrmware update service. Secondly,

we propose an approach to group automatically and

autonomously IoT nodes on the ﬁeld, and make the

Ruellé, F., Guellaën, Q. and Rosay, A.

SHOID: A Secure Herd of IoT Devices Firmware Update Protocol.

DOI: 10.5220/0011628000003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 373-380

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

373

ﬁrmware update more secure. Thirdly, we describe

the experimentation we conducted to validate these

concepts.

2 RELATED WORK

Securing IoT nodes is a well-known challenge and

many contributions propose some ways of doing it.

The most common measures, fully relying on the de-

vice hardware, are: disk encryption, cryptoproces-

sor, signed boot and encrypted boot (Johnston et al.,

2016). Our objective is to explore other solutions

based on device cooperation instead of working at sin-

gle device level.

2.1 Ofﬂoad Security Measures to Edge

Nodes

IoT nodes security can be addressed by delegating

the security measures to some trusted network ele-

ments (Kuusij

arvi et al., 2016). This approach con-

centrates the countermeasures in one place, and it be-

comes easy to upgrade these security functions. Ne-

vertheless, this adds extra nodes in the system. Be-

sides, the trusted Network Edge Device acts as an IoT

gateway or supervises an IoT gateway. This requires

signiﬁcant computing power as the proposal is to use

virtualized security functions. Deploying such power-

ful edge nodes does not meet some economical con-

straints.

Security measures can be ofﬂoaded to edge nodes

with some Mobile Edge Computing nodes cooperat-

ing to share their defense resources and relax the bud-

get constraints in each device (Li et al., 2021). But

this requires extra components like the Cooperative

Defense Orchestrator and complex scheduling algo-

rithms. This approach, though lowering the cost per

node, introduces speciﬁc elements and complexity.

2.2 Group Cryptographic Keys

Using groups is a common practice in the IoT as

this enables convenient communication patterns like

broadcast and multicast. Securing group communi-

cations, for instance to maintain the conﬁdentiality of

the exchanges, is key: encryption and hash algorithms

bring conﬁdentiality and integrity (Vinayaga Sun-

daram et al., 2015). To do so, cryptographic group

keys are required.

A set of IoT nodes can agree on a group key (Ge-

bremichael et al., 2018). This method requires a gate-

way collecting some secret numbers provided by the

nodes joining the group. A beneﬁt is that most of the

complex operations are computed by the gateway, not

the IoT devices. Nevertheless, this approach requires

a dedicated functionality in a gateway and a secure

communication channel between the gateway and the

nodes. Besides, at device level, even when using

some precomputed inputs from the gateway, the Ellip-

tic Curve Point Multiplication is required. The Ellip-

tic Curve Cryptography (ECC) induces performance

overheads in terms of time, memory, and bandwidth

penalty for authentication and encryption/decryption

in Wireless Sensor Network applications (Shah et al.,

2010).

An alternative to ECC is Advanced Encryption

Standard (AES) Galois Counter Mode (GCM), which

is suitable for IoT applications (Sung et al., 2018).

AES is lighter than ECC (Mota et al., 2017). Another

approach consists in using the block chain technol-

ogy (Chen et al., 2021). Block chain is distributed

and secure but involves additional infrastructure on

top of the IoT network. Multicast techniques can

also be used with symmetric keys, but speciﬁc actors

like Network Multicast Managers can lead to a single

point of failure issue as all elements do not play the

same role (Carlier et al., 2018).

2.3 Managing Groups of Devices

Various methods exist to handle groups of objects

from a communication and device management per-

spectives. Studies of secure IoT group communica-

tion state of the art are available, with a special focus

on commercial smart lighting (Park et al., 2019).

One can group devices by assigning a speciﬁc role

to one particular device (Park et al., 2018).

2.4 Firmware Update Methods

The secure ﬁrmware update of an IoT device is the

number one requirement to enhance IoT security.

A distributed ﬁrmware update architecture based on

the blockchain provides the following beneﬁts: de-

centralization, transparency, irreversibility (Choi and

Lee, 2020). This solution implies the creation of

various blockchain nodes with speciﬁc roles. An-

other blockchain based ﬁrmware update solution can

use concepts like smart contracts, and gateways as

block-chain clients (Tsai et al., 2020). The Ethereum

blockchain platform can also be leveraged (Choi and

Lee, 2020). These methods induce costs, and may

require distribution incentives (Fukuda and Omote,

2021).

Studies depicting the landscape of ﬁrmware up-

date solutions for IoT devices insist on the importance

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

374

of designing a comprehensive approach to ensure the

integrity and an efﬁcient management of the updating

process (J.L.Hern

andez-Ramos et al., 2020). Another

survey of the ﬁrmware update landscape provides a

prototype based on a client-server approach and lists

its challenges and the possible attacks (K.Zandberg

et al., 2019). This architecture from the Software

Updates for Internet of Things working group is de-

ployed by major cloud providers like Microsoft or

Amazon. Our contribution concerns this architecture.

2.5 Attacks

Many attacks against the ﬁrmware update procedure

exist: tampered ﬁrmware, ﬁrmware replay, ofﬂine de-

vice attack, ﬁrmware mismatch, ﬂash memory loca-

tion mismatch, unexpected precursor image, reverse

engineering, resource exhaustion (K.Zandberg et al.,

2019).

The main silicon vendors provide device-level so-

lutions to implement a secure ﬁrmware update. They

usually offer software packages leveraging the hard-

ware capabilities of the microcontrollers (NXP, 2020;

STMicroelectronics, 2021b), so that low-end smart

sensors cannot be cloned at a reasonable cost.

Nevertheless, these techniques are not sufﬁcient

when it comes to ofﬂine device attacks, denial of

service attacks, or even tampered ﬁrmware injection.

The dimension we leverage is the group, as we target

ﬂeets of devices sharing similar hardware and soft-

ware capabilities, producing and processing similar

sets of data. This group concept is the starting point of

our contribution, enabling the deﬁnition of the secure

synchronized ﬁrmware update procedure.

3 FIRMWARE UPDATE FOR

DEVICE GROUPS

The IoT implies security challenges concerning the

device communication and the device management.

These challenges are particularly complex when it

comes to resource-constrained devices such as smart

sensors. We deﬁne a method for these devices to agree

on a common cryptographic key, without using com-

plex operations and speciﬁc infrastructures or dedi-

cated provisioning mechanisms. This cryptographic

key is the root of trust to deﬁne a protocol allow-

ing the devices to group themselves autonomously,

constituting self-organized groups of IoT nodes. The

synchronized ﬁrmware update leverages these groups,

enhancing the security of this key procedure in the

context deﬁned below.

3.1 System Security Perimeter

Our primary target is to increase the security level of

a group of connected devices by making the ﬁrmware

update procedure more secure. We focus on logical

attacks exploiting the communication capabilities of

the IoT nodes. Still, a certain level of resistance to

physical attacks is required to prevent the leakage of

critical security assets from the devices. We use the

fortiﬁed solutions presented in 2.5 to secure the sys-

tem assets against electronic board level attacks. We

consider that the IoT nodes groups operate in multi-

cast networking, like in a smart-building context (Li

et al., 2013).

3.2 Group Key Creation

The devices to be grouped are homogeneous, imply-

ing that they come from the same vendor and run the

same ﬁrmware version. This assumption can be re-

laxed by authorizing devices from various vendors, as

long as they share enough commonalities evolving in

a consistent and synchronized manner. Indeed, the

group key creation mechanism relies on two assets:

a secret cryptographic key, and a ﬁrmware image or

a data image characterizing a set of devices. The se-

cret cryptographic key can be an Original Equipment

Manufacturer (OEM) key, provisioned for the needs

of device-level secure boot and secure ﬁrmware up-

date solutions (STMicroelectronics, 2021b). This key

ensures the conﬁdentiality, authenticity and integrity

of the ﬁrmware images. It brings, by deﬁnition, a

common secret shared by all similar devices. This se-

crecy is a primary security property while the appli-

cation’s ﬁrmware image is a source of diversity. By

combining these two elements, we obtain an updat-

able common secret for the devices sharing these ar-

tifacts. Should an attacker purchase a same product

model, still he has no guarantee that the product has

been provisioned with the same OEM key and that it

contains the exact same ﬁrmware image and data. So,

we have both a strong secret, already provisioned for

the purpose of the secure boot, and some variability,

the ﬁrmware image, which brings a commonality be-

tween all the sensors of a same type. A secret key is

derived from these elements. This key is common to

a group of objects and evolves over the devices’ life-

time. No further provisioning is required, but we need

an algorithm processing these elements without requi-

ring too much computing power. The use of Hash and

Key Derivation Functions meets this objective.

All devices conﬁgured with the same OEM key

and the same ﬁrmware image obtain the same secret

key to protect their communications. It gives a ba-

SHOID: A Secure Herd of IoT Devices Firmware Update Protocol

375

sis to set up a group of IoT nodes communicating in

a secure manner. The devices must have the same

ﬁrmware image, but personalization is possible by

keeping out of the hash perimeter some speciﬁc mem-

ory sections.

3.3 Group Creation Protocol

Our contribution groups devices of a same kind, so

that they can cooperate to improve the security of

the group. Devices sharing a same OEM key and a

same ﬁrmware image compute a common secret key.

Besides, we use symmetric cryptography for perfor-

mances reasons. In this area, Authenticated Encryp-

tion with Associated Data algorithms combine au-

thentication and encryption to ensure source authen-

tication, as well as data integrity, in addition to con-

ﬁdentiality. These techniques are interesting (Bellare

and Namprempre, 2000), and AES GCM is an efﬁ-

cient solution for Cortex-M based devices (Driscoll,

2018; Koteshwara et al., 2019; Sovyn et al., 2020).

It generates two outputs: an encrypted version of the

data it processes, and a tag allowing to authenticate

this data. These properties ensure the conﬁdentiality,

authenticity and integrity of the messages exchanged

between the IoT nodes sharing the same secret key.

This secret key is used to select the IoT devices

that can join a same group, without deﬁning this

group a priori, and without any node playing a spe-

ciﬁc role. Devices deployed on the ﬁeld create groups

autonomously. This self organizing network of IoT

nodes requires a common channel that devices use to

discover each other. This channel can be a multicast

channel to restrict the considered perimeter to a given

area. The way to deﬁne it depends on the deployment

model selected for the system. Several groups can use

the same common channel if they have different secret

keys. A common channel can be deﬁned for a build-

ing or a district. Let’s take the example of a smart

building: all devices deployed in the building share

the same common channel. But, the connected ther-

mostats have a secret key while the smart light bulbs

share another secret key. Hence, autonomously, the

devices group themselves, and each time a new device

is commissioned it joins the proper group automati-

cally, without any supervisor overseeing the system.

The protocol to do so is a set of messages made of

two parts: a non-encrypted header (plain text) provid-

ing all the information required to use the payload,

and an encrypted and authenticated payload. AES

GCM may also use the clear header as Additional

Authenticated Data, so that the entire message is au-

thenticated. The encrypted payload carries the sen-

sitive information: the identiﬁers of the sender and

receiver of the message, a sequence number against

replay attacks, the value of the message and a signa-

ture to authenticate the sender. On message reception,

the device uses the clear header and the secret key to

perform the AES GCM decryption and the authenti-

cation tag veriﬁcation. When processing the payload,

another level of veriﬁcation is performed thanks to the

signature, to make sure the sender has not been imper-

sonated.

The group creation and update relies on two mes-

sages. On one hand, a HELLO message is sent by

a newcomer on the common channel. This message

indicates that the device is active and ready to re-

ceive notiﬁcations from group members. On the other

hand, the members of the group send a HELLO RE-

SPONSE message to the newcomer so he can dis-

cover them. As these messages are encrypted, only

the devices with the appropriate secret key can un-

derstand them. This is how the group is built and

maintained over time. These messages carry informa-

tion about their sender: its identiﬁer and its personal

communication channel. Only the node owning the

personal channel posts on it, and the signature ﬁeld

of the message ensures this. All other devices of the

group listen to this channel. This system uses a com-

mon channel to create and maintain the group, and a

device-speciﬁc channel, so that nodes can send spe-

ciﬁc information to the listeners.

A device that fails to perform its ﬁrmware update

while the rest of the group succeeds to do so is, by

construction, kicked out of the group. This descrip-

tion focuses on the principles to create the group and

skips the messages required for dealing with situa-

tions where a device becomes unreachable, out of or-

der, or replaced.

3.4 Synchronized Firmware Update

The group of devices is the foundation for improv-

ing the overall security of the ﬂeet. The ﬁrmware up-

date is a critical operation for managing IoT nodes

and maintaining their security mechanisms up to date.

But, this feature offers an attack surface for DoS at-

tacks or malicious code injection attacks. In order to

address these issues, we deﬁne one group procedure:

the synchronized ﬁrmware update. This contribution

focuses on this sole procedure, but additional proce-

dures can be used to maintain the group’s validity over

time.

Concept. The synchronized ﬁrmware update con-

sists in two steps: ﬁrst making sure all devices of

the group have received the same update request, then

electing a device that runs the update ﬁrst to conﬁrm

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

376

its validity. If the devices receiving the ﬁrmware up-

date request do not receive the update response mes-

sages from the other group members then the request

is discarded. The entire ﬂeet must be updated at once

for the update request to be considered trustworthy.

As the group key is based on the ﬁrmware image, a

partial update of the ﬂeet would result in breaking the

group. Some devices can be unreachable, due to sleep

mode, out of order state, or replacement. This might

create a security breach, so more reﬁned heuristics are

required at deployment stage. To sum up, this system

prevents a hacker from targeting one single device: he

needs to ﬁnd out the group members, and attack them

all in a synchronized manner. Moreover, the system

relies on group decisions, so hijacking one device is

not sufﬁcient to control the decisions. To avoid a mis-

use of the group decisions, it is important to limit the

number of new devices joining the group simultane-

ously. This risk is managed by enabling device-level

protections to prevent devices cloning or counterfeit-

ing.

When this synchronized request is received, a de-

vice is elected to run the ﬁrmware update ﬁrst. This

device plays the role of a scout, and must conﬁrm

the update success before the group carries on with

the update. This lowers the risks of incorrect update,

without involving any supervision. No operator is

needed to select a test device before propagating the

ﬁrmware update to the entire ﬂeet. All devices are

addressed at once, and they handle the update them-

selves. For an attacker, it is very complicated to guess

who is going to be chosen as the scout. While the

test device performs its update, the other devices put

their own update procedures on hold, but they can

still receive commands and run their use-cases. Af-

ter a successful update, the test device conﬁrms the

validity of the new ﬁrmware to the group. If this con-

ﬁrmation is not received within a guard period, then

the other devices discard the update request, black-

list the candidate ﬁrmware version, notify the cloud

of this erroneous update and of the faulty test device

that might run a malicious code, enter a silent period

where all subsequent ﬁrmware update requests are ig-

nored. Hence, the rest of the ﬂeet is not updated, the

server is notiﬁed and can launch the appropriate coun-

termeasures. If the conﬁrmation is received within the

guard period, then all the other devices of the group

proceed with the ﬁrmware update.

The procedure starts when an UPDATE RE-

QUEST message is received by each device, and

speciﬁes the new ﬁrmware image to be installed. Each

node runs the algorithm 1 on top of the generic al-

gorithm 2. Once the ﬁrmware update has been com-

pleted successfully, the test device has a new ﬁrmware

image in place, so it generates a new group key.

Therefore, this device must recompute the previous

group key to send the conﬁrmation messages before

the entire herd moves to the new ﬁrmware image and

its associated group key.

Threats Towards the Group Itself. An attacker

might try to break the group itself to circumvent the

synchronized ﬁrmware update procedure. Therefore,

the communications are protected (conﬁdentiality, au-

thenticity and integrity) and replay attacks are pre-

vented by the use of messages sequence numbers.

Last but not least, device level protections and moni-

toring procedures are additional layers of security pre-

venting the hacker from hijacking a device, and using

it to dismantle the group.

Synchronized Firmware Update Beneﬁts. A ﬁrst

beneﬁt concerns the maintenance of the ﬂeet. The

ﬂeet owner does not need to maintain explicitly a list

of his groups of devices. He can send a general up-

date request to deploy a new ﬁrmware version. The

devices are self-organized per groups and each group

elects a test device. This test device makes sure the

new ﬁrmware is correct (self-tests) before authoriz-

ing the update of the peers. If one device cannot

update for any reason, then it is automatically re-

moved from the group, as it cannot compute the new

group key, and this failure is reported to the server.

A second beneﬁt concerns the security of the herd,

as an attacker needs to attack all devices of a group at

once. First, he needs to determine the group members.

Then, he must update the binary image he is using as

soon as a ﬁrmware version is blacklisted, and forge

a valid ﬁrmware image able to send the UPDATE

CONFIRMATION message. Infecting the other de-

vices of the group requires knowing the group, com-

puting the proper group key and forging the proper

acknowledgement message. Hence, the synchronized

ﬁrmware update procedure raises the bar for attack-

ers: code injection and DoS attacks are thwarted. Last

but not least, it brings an automatic device manage-

ment capability.

4 EXPERIMENTATION

IoT Node. We conducted experiments with micro-

controllers to verify the feasibility of the system

and its efﬁciency. We used STMicroelectronics’

STM32L4 Discovery kit IoT node B-L475E-IOT01A

(STMicroelectronics, 2021c) because it is representa-

tive of a mid-range connected sensor. It provides an

IEEE 802.11 (Wi-Fi) connectivity to establish a link

SHOID: A Secure Herd of IoT Devices Firmware Update Protocol

377

Algorithm 1: Synchronized Firmware Update.

The device is part of the group G

The Firmware Update Request R carries

ﬁrmware version R.erson = N + 1

Function processUpdateRequest(R:

request):

erson ← R.erson

nmber ← rndomnmber

create UPDATE RESPONSE message

with erson and nmber

start guard timer TG for group responses

for device in G do

send UPDATE RESPONSE to device

end

Wait for all responses to be received

if all responses received then

Stop guard timer TG

if my random number is the highest

one in G then

memorize that an update is in

progress with

UpdtenProgress ﬂag

perform the ﬁrmware update

procedure

Reset()

else

Start guard timer TC for test

device conﬁrmation

Wait for test device to send the

UPDATE CONFIRMATION

message

if UPDATE CONFIRMATION

received then

stop TC

perform the ﬁrmware update

procedure

Reset()

else

TC expires

Abort the synchronized

ﬁrmware update procedure

Notify the server that a

synchronized ﬁrmware

update procedure failed

else

Cancel the update procedure when

TG expires

Notify the server that an abnormal

update request has been received

and aborted

return

Algorithm 2: Device generic loop.

The device runs OEM Firmware N

The device has the OEM ﬁrmware key K

OEM

Function Main():

initialization: compute the group key

cr

and establish the group G if

needed

if UpdtenProgress ﬂag is set then

validate the new ﬁrmware image

reset the UpdtenProgress ﬂag

compute the former group key K

pre

create UPDATE CONFIRMATION

message using K

pre

for device in G do

send UPDATE CONFIRMATION

to device

end

while True do

do use-case processing

get message M

if M.type == UPDATE REQUEST

then

processUpdateRequest(M)

end

return

with a remote cloud server. Besides, it also provides

a Media Access Control address we can use as the

device identiﬁer within the group. Many sensors are

available on this board so we can develop a realistic

use-case: a connected thermostat. On software side,

we implement our system on top of two STM32 pack-

ages (STMicroelectronics, 2021a; STMicroelectron-

ics, 2021b).

Results. The microcontroller takes 483 ms to com-

pute the group key, with Secure Hash Algorithm 256

bits, when running at 80 MHz with a 251 kB ﬁrmware

image in FLASH. With a group of n devices with

n = 4, the system generates 12 MQTT messages for

a total of around 1500 bytes exchanged over the net-

work. This is n × (n − 1) messages, so the number

of messages goes in O(n

) , showing that group size

matters. The duration to establish the HTTP connec-

tion to the update server, then download the 251 kB

ﬁrmware image and deem it is invalid is a few tens

of seconds. During this period, a Wi-Fi IoT Node is

in a TX state. According to a study of IoT power

consumption, an IoT node operating in this TX state

drains a current of 0.38 A from a 3.3 V power supply

(Guegan and Anne-C

ecile, 2019). Therefore, skip-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

378

ping these useless steps induces signiﬁcant energy

savings. Besides, the update server processes only 1

instead of n connections. For a ﬂeet of 4 devices, al-

most 750 kB of useless data transfer is saved. These

energy and bandwidth savings evolve in O(n), so

the result is worth the messaging overhead. The sys-

tem adds 10 kB of code in FLASH, for a reference

ﬁrmware size of 237 kB (sensor management code,

MQTT, TLS and device drivers libraries) and no ex-

tra RAM budget is required.

5 CONCLUSION

In this paper, we studied a way to group IoT de-

vices to strengthen the security of the ﬁrmware up-

date procedure. The method establishes a common

cryptographic key, and uses it to group IoT nodes.

This technique requires no compute-intensive pro-

cessing and no speciﬁc provisioning of the devices.

The secure group concept is used to create a syn-

chronized ﬁrmware update procedure. Besides, this

system requires very few server interactions as being

fully based on a device to device approach. This prop-

erty brings additional autonomy and robustness bene-

ﬁts.

In future work, a more efﬁcient device to de-

vice communication could be exploited to improve

power consumption and server independence, by us-

ing Long Range Wide Area Network (LoRaWAN) or

Bluetooth Mesh networking. Last but not least, we

may reﬁne the heuristics to improve the system efﬁ-

ciency: guard periods, unreachable devices manage-

ment, power saving impact on procedures.

ACKNOWLEDGEMENTS

The authors would like to thank Julien Montmasson

(ST Microelectronics) and G

eraud Plagne (ST Micro-

electronics) for their valuable comments and sugges-

tions to improve this contribution. The authors would

also like to thank Eloise Cheval (ST Microelectron-

ics) for her thorough reviews of this paper.

REFERENCES

Adams, E. (2021). Protect your customers with a secure

iot updating process. https://blog.securityinnovation.

com/secure-iot-updating-process. Last checked on

Oct 05, 2022.

Bellare, M. and Namprempre, C. (2000). Authenticated en-

cryption: Relations among notions and analysis of the

generic composition paradigm. In Okamoto, T., ed-

itor, Advances in Cryptology — ASIACRYPT 2000,

pages 531–545, Berlin, Heidelberg. Springer Berlin

Heidelberg.

B.F. Spencer, J., Ruiz-Sandoval, M. E., and Kurata, N.

(2004). Smart sensing technology: Opportunities

and challenges. https://citeseerx.ist.psu.edu/viewdoc/

download?doi=10.1.1.88.3329&rep=rep1&type=pdf.

Last checked on Oct 05, 2022.

Carlier, M., Steenhaut, K., and Braeken, A. (2018).

Symmetric-key based security for multicast communi-

cation in wireless sensor networks. In 2018 4th Inter-

national Conference on Cloud Computing Technolo-

gies and Applications (Cloudtech).

Chen, C.-M., Deng, X., Gan, W., Chen, J., and Islam, S.

K. H. (2021). A secure blockchain-based group key

agreement protocol for iot. The Journal of Supercom-

puting, 77(8):9046–9068.

Choi, S. and Lee, J.-H. (2020). Blockchain-based dis-

tributed ﬁrmware update architecture for iot devices.

IEEE Access, 8:37518–37525.

Demeter, D., Preuss, M., and Yaroslav, S. (2019).

Iot: a malware story. https://securelist.com/

iot-a-malware-story/94451/. Last checked on Oct 05,

2022.

Driscoll, K. (2018). Lightweight crypto for lightweight un-

manned arial systems. In 2018 Integrated Communi-

cations, Navigation, Surveillance Conference (ICNS),

pages 1–15.

European Commission (2022). Cyber resilience act.

https://digital-strategy.ec.europa.eu/en/library/

cyber-resilience-act. Last checked on Oct 04, 2022.

Fukuda, T. and Omote, K. (2021). Efﬁcient blockchain-

based iot ﬁrmware update considering distribution in-

centives. In 2021 IEEE Conference on Dependable

and Secure Computing (DSC), pages 1–8.

Gebremichael, T., Jennehag, U., and Gidlund, M. (2018).

Lightweight iot group key establishment scheme us-

ing one-way accumulator. In 2018 International Sym-

posium on Networks, Computers and Communica-

tions (ISNCC), pages 1–7.

Gervais-Ducouret, S. (2011). Next smart sensors genera-

tion. In 2011 IEEE Sensors Applications Symposium,

pages 193–196.

Guegan, L. and Anne-C

ecile, O. (2019). Estimating the

end-to-end energy consumption of low-bandwidth.

J.L.Hern

andez-Ramos, G.Baldini, S.N.Matheu, and

A.Skarmeta (2020). Updating iot devices: challenges

and potential approaches. In 2020 Global Internet of

Things Summit (GIoTS).

Johnston, S. J., Scott, M., and Cox, S. J. (2016). Recom-

mendations for securing internet of things devices us-

ing commodity hardware. In 2016 IEEE 3rd World Fo-

rum on Internet of Things (WF-IoT), pages 307–310.

Kambourakis, G., Kolias, C., and Stavrou, A. (2017). The

mirai botnet and the iot zombie armies. In MILCOM

2017-2017 IEEE Military Communications Confer-

ence (MILCOM), pages 267–272. IEEE.

Kelly, R. (2020). H.r.1668 - iot cybersecurity improve-

ment act of 2020. https://www.congress.gov/bill/

SHOID: A Secure Herd of IoT Devices Firmware Update Protocol

379

116th-congress/house-bill/1668. Last checked on Oct

05, 2022.

Koteshwara, S., Das, A., and Parhi, K. K. (2019). Archi-

tecture optimization and performance comparison of

nonce-misuse-resistant authenticated encryption algo-

rithms. IEEE Transactions on Very Large Scale Inte-

gration (VLSI) Systems, 27(5):1053–1066.

Kuusij

arvi, J., Savola, R., Savolainen, P., and Evesti, A.

(2016). Mitigating iot security threats with a trusted

network element. In 2016 11th International Con-

ference for Internet Technology and Secured Transac-

tions (ICITST), pages 260–265.

K.Zandberg, K.Schleiser, F.Acosta, H.Tschofenig, and

E.Baccelli (2019). Secure ﬁrmware updates for con-

strained iot devices using open standards: A reality

check.

Li, D., Aung, A., Sampalli, S., Williams, J., and Sanchez,

A. (2013). Privacy preservation scheme for multicast

communications in smart buildings of the smart grid.

Smart Grid and Renewable Energy, 4(4):313–324.

Li, H., Yang, C., Wang, L., Ansari, N., Tang, D., Huang,

X., Xu, Z., and Hu, D. (2021). A cooperative defense

framework against application-level ddos attacks on

mobile edge computing services. IEEE Transactions

on Mobile Computing. Publisher Copyright: IEEE.

Mota, A. V., Azam, S., Shanmugam, B., Yeo, K. C., and

Kannoorpatti, K. (2017). Comparative analysis of dif-

ferent techniques of encryption for secured data trans-

mission. In 2017 IEEE International Conference on

Power Control Signals and Instrumentation Engineer-

ing (ICPCSI).

NXP (2020). Lpc55s00 security solutions for iot.

https://www.nxp.com/docs/en/application-note/

AN12278.pdf. Last checked on Oct 05, 2022.

Park, E., Kim, K., and Kim, N. (2018). Group management

scheme to support robustness service in iot environ-

ment. volume 118, pages 1183–1194.

Park, J., Jung, M., and Rathgeb, E. P. (2019). Survey for se-

cure iot group communication. In 2019 IEEE Interna-

tional Conference on Pervasive Computing and Com-

munications Workshops (PerCom Workshops), pages

1026–1031.

ProvenRUN (2022). Firmware update is a must, but needs

also to be secured. https://provenrun.com/products/

provenfota/. Last checked on Oct 05, 2022.

Shah, P. G., Huang, X., and Sharma, D. (2010). Analyti-

cal study of implementation issues of elliptical curve

cryptography for wireless sensor networks. In 2010

IEEE 24th International Conference on Advanced In-

formation Networking and Applications Workshops,

pages 589–592.

Sovyn, Y., Khoma, V., and Podpora, M. (2020). Compar-

ison of three cpu-core families for iot applications in

terms of security and performance of aes-gcm. IEEE

Internet of Things Journal, 7(1):339–348.

STMicroelectronics (2021a). Generic iot cloud soft-

ware expansion for stm32cube. https://www.st.com/

en/embedded-software/x-cube-cld-gen.html. Last

checked on Sep 05, 2021.

STMicroelectronics (2021b). Secure boot & secure

ﬁrmware update software expansion for stm32cube.

https://www.st.com/en/embedded-software/

x-cube-sbsfu.html. Last checked on Sep 05,

2021.

STMicroelectronics (2021c). STM32L4 discovery kit

iot node, low-power wireless, BLE, NFC, Sub-

GHz, Wi-Fi. https://www.st.com/en/evaluation-tools/

b-l475e-iot01a.html. Last checked on Sep 05, 2021.

Sung, B.-Y., Kim, K.-B., and Shin, K.-W. (2018). An aes-

gcm authenticated encryption crypto-core for iot secu-

rity. In 2018 International Conference on Electronics,

Information, and Communication (ICEIC), pages 1–3.

Tsai, M.-H., Hsu, Y.-C., and Lo, N.-W. (2020). An efﬁcient

blockchain-based ﬁrmware update framework for iot

environment. In 2020 15th Asia Joint Conference on

Information Security (AsiaJCIS), pages 121–127.

Vinayaga Sundaram, B., M., R., M., P., and J., V. S.

(2015). Encryption and hash based security in inter-

net of things. In 2015 3rd International Conference

on Signal Processing, Communication and Network-

ing (ICSCN), pages 1–6.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

380
