Clipaha: A Scheme to Perform Password Stretching on the Client

Francisco Blas Izquierdo Riera

1 a

, Magnus Almgren

1 b

, Pablo Picazo-Sanchez

2 c

and Christian Rohner

3 d

Chalmers University of Technology, 412 96 Göteborg, Sweden

School of Information Technology, Halmstad University, Sweden

Uppsala University, Box 534, 751 21 Uppsala, Sweden

Keywords:

Password Stretching, Password-based Authentication, IoT Security, Server Relief, Web Security, Argon2.

Abstract:

Password security relies heavily on the choice of password by the user but also on the one-way hash functions

used to protect stored passwords. To compensate for the increased computing power of attackers, modern

password hash functions like Argon2, have been made more complex in terms of computational power and

memory requirements. Nowadays, the computation of such hash functions is performed usually by the server

(or authenticator) instead of the client. Therefore, constrained Internet of Things devices cannot use such

functions when authenticating users. Additionally, the load of computing such functions may expose servers to

denial of service attacks. In this work, we discuss client-side hashing as an alternative. We propose Clipaha, a

client-side hashing scheme that allows using high-security password hashing even on highly constrained server

devices. Clipaha is robust to a broader range of attacks compared to previous work and covers important and

complex usage scenarios. Our evaluation discusses critical aspects involved in client-side hashing. We also

provide an implementation of Clipaha in the form of a web library

and benchmark the library on different

systems to understand its mixed JavaScript and WebAssembly approach’s limitations. Benchmarks show that

our library is 50% faster than similar libraries and can run on some devices where previous work fails.

1 INTRODUCTION

Despite being around for sixty years and having many

issues, passwords are still a prevalent authentica-

tion method (Corbató, 1963; Bauman et al., 2015;

Van Acker et al., 2017). Conceptually, a client pro-

vides its identity (username

) and a secret (password

) which is matched against a database entry on the

server to be accessed. Getting access to passwords has

ever since been a target for attacks (Lee et al., 1992).

Because users tend to reuse the same password on

different systems, a breach in one system can have

consequences over a much larger scope.

In particular, with the advent of the Internet of

Things (IoT), where potentially every embedded low-

power device acts as a server, the issues with pass-

words have become a dilemma. As IoT devices are

usually more vulnerable, getting access to their pass-

https://orcid.org/0000-0003-1509-142X

https://orcid.org/0000-0002-3383-9617

https://orcid.org/0000-0002-0303-3858

https://orcid.org/0000-0002-1527-734X

word database is relatively easy. Also, their ability

to handle password authentication is signiﬁcantly hin-

dered compared to traditional client/server systems

due to limited computation, energy and amounts of

memory available for code and data.

Nowadays, database breaches do not reveal the

password per se since stored passwords are protected

by a secure one-way function

f (.)

(e.g., a crypto-

graphic hash).

f (.)

includes a random salt

prepended

to the password to make the password unique and

avoid that equal passwords are easily recognized dur-

ing dictionary attacks. Since the database stores the

triplet

⟨u, s, f (s||p)⟩

, the hash function has to be com-

puted at every authentication. To prevent dictionary

attacks from being accelerated after a breach using

powerful GPU, FPGA, or ASIC implementations; pass-

word hashing functions have increased their complex-

ity.

Modern password hashing algorithms (e.g., Ar-

gon2 (Biryukov et al., 2017)) are speciﬁcally designed

to eliminate the possible attacker advantage gained

from accelerators. Removing such advantage comes at

the cost of excessive computation and memory usage

Izquierdo Riera, F., Almgren, M., Picazo-Sanchez, P. and Rohner, C.

Clipaha: A Scheme to Perform Password Stretching on the Client.

DOI: 10.5220/0011653200003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 58-69

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

Client Server

f (s

∗

||p) h(.)

u, p, s

∗

[u : h]

JavaScript Embedded

f (s||p)

u, p

[u : f , s]

Figure 1: Clipaha moves the resource-intensive hash func-

tion

f (s||p)

to the client. The salt

∗

is a deterministic string

derived from the username

and the server’s domain name.

(e.g., the speciﬁcation recommends

1 GiB

memory and

0.5 s

runtime for front-end authentication (Biryukov

et al., 2016)). However, there is still a lack of use of

such algorithms with strong security parameters on

regular systems and more so on resource-constrained

systems (Eliasen, 2019; Ntantogian et al., 2019).

Currently, most devices perform the password hash-

ing step in the server (or authenticator) (Blanchard

et al., 2019). This prevents low-power IoT devices

lacking either the memory or the power for running

the CPU long enough from using modern hash func-

tions with strong hash parameters. The huge resource

demand may also open non IoT devices to Denial

of Service attacks by allowing resource exhaustion

through multiple login attempts.

Clipaha. To address the security versus complexity

challenge in highly-constrained devices, we propose

moving the resource-hungry password hashing step to

the client. We propose Clipaha, a Client-side Password

Hashing scheme, based on Argon2, that allows user

authentication in highly-constrained devices. Figure 1

illustrates the concept of Clipaha in comparison to

server-side hashing. By moving the resource intensive

operation

f (s

∗

||p)

to the client, the server only needs

to compute a low cost one-way hash function

h(.)

(e.g.,

SHA-256) to prevent that leaked database entries can

directly be used to access the server. We provide an

implementation of Clipaha in the form of a web li-

brary

and benchmark it on different systems to under-

stand the limitations that its mixed JavaScript and We-

bAssembly implementation faces. Benchmarks show

that our library is

50%

faster than similar libraries and

can even run on some devices where others fail. We

also provide a proof-of-concept of the server-side of

Artifact available at: https://github.com/clipaha/clipaha

/releases/tag/ICISSP_2023.

the code for the ESP8266,

an embedded wireless de-

vice popular on Do It Yourself (DIY) environments

featuring an

80 MHz

processor and

80 KiB

of memory

for user data (Espressif Systems, 2020), and show that

also constrained server devices can beneﬁt from mod-

ern password hashing algorithms with their increased

security against brute force attacks.

Contributions. We summarize our contributions as

follows:

•

We present Clipaha, a Client-side Password Hash-

ing scheme that does not compromise on the

security compared with server-side approaches

and allows stronger user authentication in highly-

constrained devices. Clipaha is robust against a

wider range of attacks than existing client-side ap-

proaches.

•

We implement, test, and publicly release an imple-

mentation of Clipaha in the form of a Javascript

library.

Our prototype is

50%

faster than existing

approaches.

•

We thoroughly evaluate Clipaha and demonstrate,

based on a set of eight scenarios, that it is ready to

be deployed in practical settings.

The rest of the paper is structured as follows. Sec-

tion 2 covers the related work. Section 3 introduces the

adversarial model. We present the objectives and mo-

tivation for Clipaha in Section 4. Section 5 describes

the implementation while in Section 6 we evaluate the

library. Finally, Section 7 concludes the paper.

2 BACKGROUND AND RELATED

WORK

Modern password hashing schemes use three tech-

niques to slow down attackers. First, they combine a

unique string, i.e., the salt, with the password before

using a one-way function (e.g., a cryptographic hash)

to make each password entry unique so that ofﬂine

attackers performing a dictionary attack have to exe-

cute the hash once per guess and entry (Wilkes, 1968).

Second, signiﬁcant processing power is used to ensure

each hash execution is slow to execute (Morris and

Thompson, 1979). Third, signiﬁcant amounts of mem-

ory space and bandwidth are utilized in a way that

prevents efﬁcient use of GPUs, FPGAs, or ASICs to

compute the hash (Hatzivasilis, 2017).

In 2013, Argon2 (Biryukov et al., 2016) won a

competition aiming to modernize one-way functions

for hashing passwords concerning new attack method-

ologies (Aumasson et al., 2013). Argon2 has two main

variants, Argon2d and Argon2i, and various supple-

mentary variants, including Argon2id.

Clipaha: A Scheme to Perform Password Stretching on the Client

Table 1: Impact of security and functional issues over crack-

station, libsodium and Clipaha’s approaches.

✓

means the

approach is not affected;

✗

means it is, and; (

✓

) means it is

partially affected.

Salt User Ref.

Coll. Enum. Lib.

Crackstation ✗ ✓ ✗

Libsodium ✓ ✗ (✓)

Clipaha ✓ ✓ ✓

Argon2d uses data-dependent memory accesses,

whereas Argon2i uses data-independent memory ac-

cesses. The consequence is that Argon2d is vulnerable

to side-channel attacks but offers the best resistance to

Time-Memory Trade-Offs (TMTOs), while Argon2i

is secure against side-channel timing attacks but is

weaker against TMTOs (Alwen and Blocki, 2017;

Biryukov et al., 2017).

Argon2id works as Argon2i for the ﬁrst half of

the ﬁrst iteration over the memory and as Argon2d

for the rest, thus providing both protection against

side-channel attacks and against cost savings due to

TMTOs (Biryukov et al., 2017).

Inherent to Argon2, and modern password hashing

functions in general, is that one can parametrize the

“hardness” of the hash function in different ways to

make it more resistant to attacks, e.g., by specifying

the needed memory and iterations to create the hash.

In particular, Argon2 has various input parameters

relevant to our use: password, salt, memory required,

execution time (iterations), the maximum degree of

parallelism allowed (lanes), and hash length.

The high memory and execution time parameters

needed to deter attackers using powerful systems en-

tail that constrained IoT systems cannot run the al-

gorithm natively. A possible solution is using server

relief, one of the evaluation criteria of PHC, so that

the server can ofﬂoad the computation to the client.

Thus, more constrained systems can beneﬁt from these

algorithms. However, server relief is not commonly

deployed (Blanchard et al., 2019).

There are two mechanisms to implement server re-

lief: crackstation (Security, 2019) and libsodium (De-

nis, 2019). Crackstation’s approach (Security, 2019)

does not recommend separating nor distinguishing the

parameters used to generate the hash’s salt, which

could result in the same salt value being used for dif-

ferent accounts on different sites. In Clipaha we ensure

a unique salt is used; we provide a comparison with

Clipaha in Table 1.

Libsodium’s approach (Denis, 2019) has three

main issues. First, compared to Crackstation’s and

Clipaha, it introduces an additional step (and the cor-

responding round trip time) to obtain the user’s salt.

Second, it is prone to user enumeration attacks. For

example, an attacker can detect a registration by notic-

ing the change in the salt belonging to the user. Fur-

thermore, when following the recommendations, an

attacker may also guess whether users are registered on

systems where usernames are canonicalized (converted

into a standard representation) when the pseudoran-

dom salt remains the same for different inputs resulting

in the same canonical username. In Clipaha, we re-

move the risk for user enumeration. Third, libsodium

only provides the tools to perform the authentication

ﬂow but has no recommendations on parameter values.

We provide a user-friendly API with preset parameters

and a security analysis of several use cases. We have

also compared the client performance of Clipaha with

Libsodium and can show that the former is

25%

–

50%

faster.

Aside from modern password hashes, other tech-

niques to protect password-based authentication ex-

ist, such as Multi-Factor Authentication (MFA) and

Password-Authenticated Key Exchange (PAKE). MFA

uses factors other than the user’s knowledge of a pass-

word to protect an account. Similarly, PAKE is com-

plementary to Clipaha in that it protects against an

attacker snifﬁng the password in transit or imperson-

ating the authentication server. Clipaha is compatible

with MFA and PAKE and can be combined with them

(see Subsection 6.5).

3 THREAT MODEL

In our adversarial model, the attackers’ primary ob-

jective is obtaining valid user credentials. This would

give them access to the system and the ability to move

laterally to other systems where the credentials have

been reused. In most cases, attackers also have as an

objective to access the service without authorization.

Our model considers both online attackers and of-

ﬂine attackers. Online attackers have access to the

ers have read access to the entire database of users’

password hashes (Bai and Blocki, 2021). They may

also have write access to the database or access to the

service. However, in this case, their objective is not

accessing the service, which would be trivial, but re-

covering the original credentials. We explain below

the concrete attacks these attackers can perform.

In credential bruteforcing, online attackers make

requests to the server to ﬁnd a valid <user, password>

pair (Saad and Mitchell, 2020). Ofﬂine attackers

have full read access to the user database, including

their hashed passwords, and therefore can utilize opti-

mizations, e.g., TMTO techniques like rainbow tables

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

(Oechslin, 2003). This is particularly relevant because

it allows them to exploit salt collisions. In general, the

effort for successful credential bruteforcing depends

linearly on the computational cost of the hash function

and exponentially on the entropy of the passwords.

In salt collisions, two or more passwords are

hashed using the same salt, hash function, and hash

parameters. Such collisions are problematic because

attackers can test all colliding accounts performing

only one hash operation per guess. This cost reduction

makes affected accounts more likely to be targeted by

attackers who try to minimize the economic costs of

their attack. Also, salt collisions allow an attacker to

see if various accounts have the same password since

the resulting hash will be the same in that case.

In user enumeration, attackers check for the ex-

istence of users in the system by directly querying

the targeted system or detecting differences in re-

sponses (Skowron et al., 2021).

Client-side approaches, including server relief, in-

troduce the risk for so-called pass-the-hash attacks. In

a pass-the-hash attack, the (ofﬂine) attacker tries to use

the already hashed credential stored in the breached

database. Such an attack would work not only on the

site but also on other sites with the same salt, password,

and hash parameters.

4 DESIGN OF Clipaha

In this section, we discuss the requirements behind

our work and then present the design of Clipaha, a

Cli

ent-side

ssword

shing scheme that allows user

authentication in highly-constrained devices.

4.1 Objectives

In Table 2, we list the main objectives of Clipaha.

We sorted them into three categories: security-related,

functional, and performance-related. The ﬁrst three

security-related objectives are related to the threat

model: guarantee password hashes are unique across

accounts and systems (RQ-S1), ensure server behav-

ior does not allow to ﬁnd if users are present or not

(RQ-S2), and make sure the hash stored in the database

cannot be used directly as input for authentication (RQ-

S3). As for credential bruteforcing, we assume that an

attacker cannot circumvent the limitations imposed by

the hashing algorithm but is not limited otherwise.

To guarantee overall security, the algorithm needs

to be at least as secure as if performed by a server

(RQ-S4). This objective implies that we consider

a use case with constrained servers but sufﬁciently

powerful clients. This aspect is closely related to the

Table 2: The security (S), functional (F) and performance

(P) objectives for Clipaha.

Label Description

RQ-S1 Resistance to salt collisions

RQ-S2 Resistance to user enumeration

RQ-S3 Resistance to pass-the-hash attacks

RQ-S4 Ensure the algorithm is at least as

secure as if performed by the server

RQ-F1 Not require software developers to

choose security relevant parameters

RQ-F2 Suitable for the many contexts where

passwords are used

RQ-P1 Limit the delay of the authentication

process for legitimate users

Algorithm 1: Clipaha’s client-side password hashing pro-

cess.

function CLIPAHAHASH(Domain, Username, Pass-

word)

NUsername ← CANONICALIZE(Username)

Salt ← DELIMIT(Domain, NUsername)

return PASSWORDHASH(Salt, Password)

end function

performance-related objective that the adopted library

must keep a reasonable delay (RQ-P1) no matter which

type of client device they use.

To increase the use and deployment of modern

password hashing techniques without putting security

at risk, we need to provide a reference library which is

easy-to-use for software developers who may not be

security experts (RQ-F1). Clipaha should work with

other techniques (MFA, PAKE) and be compatible

with a range of important use cases, e.g., changing

the passwords or authentication of non-human devices

(RQ-F2).

4.2 Password Hashing Algorithm

We propose an algorithm to perform password hash-

ing on the client. With server relief, the client will

provide the brunt of the work to hash the password.

Hence, the client must be provided with all necessary

parameters, including the salt. Traditionally, said salt

would be stored in the password database on the server

and looked up when the client provides the username.

However, this would open the system to enumeration

Algorithm 2: Clipaha’s server-side hashing process.

function CLIPAHASERVERHASH(ClipahaHash)

return HASH(ClipahaHash)

end function

Clipaha: A Scheme to Perform Password Stretching on the Client

Table 3: Proposed security levels. Iterations is the number of

rounds the algorithm runs; Memory is the amount of memory

used by the hash function.

Level low medium high ultra

Iterations 6 5 3 3

Memory (MiB) 192 384 1024 2016

attacks, as online attackers can easily detect the lack

of salt for unregistered users or see how they change

over time.

To circumvent enumeration attacks (RQ-S2), as

well as avoiding salt collisions (RQ-S1), Clipaha does

not involve the server in the hashing process and lets

the client calculate the salt locally based on a determin-

istic database identiﬁer (e.g., the server’s domain) and

the username. This choice deviates from the standard

approach of using a random salt. We argue that only

uniqueness, and not randomness, is required to avoid

salt collisions. Therefore, credential bruteforcing will

not gain a signiﬁcant structural advantage by having

a predictable, low-entropy salt compared to the case

where it has access to a random, high-entropy one.

Figure 1 depicts the general idea behind Clipaha’s

design while Algorithms 1 and 2 describe respectively

the client- and server-side hash more formally.

As can be seen on Algorithm 1, CLIPAHAHASH

performs three steps. First, the function translates the

username into its canonical representation using the

CANONICALIZEUSERNAME function (e.g., lowering

the case to attain case-insensitive usernames). This

ensures the system will return the same hash for user-

names that should be considered equivalent. Second,

to further reduce the risk of salt collisions, the func-

tion DELIMIT must ensure the database identiﬁer and

the canonical username cannot be mixed when their

strings are concatenated (RQ-S1). Clipaha does so by

prepending the 32-bit Little Endian representation of

the size of the strings. Finally, it computes and returns

the hash of the password and the salt using a strong

hash function PASSWORDHASH.

Continuing with Algorithm 2, the input to CLI-

PAHASERVERHASH would be the output of CLIPA-

HAHASH. This function only performs a call to a

one-way function HASH, which does not need to be

computationally expensive. This prevents pass-the-

hash attacks (RQ-S3). Otherwise, an ofﬂine attacker

(with read-only access to the database) could replay

the entry in the database to access the service.

4.3 Client API and Security Levels

We implemented a JavaScript server relief library

called clipaha.js that developers can include in their

projects on the client side.

We used the Argon2id

(Biryukov et al., 2017) hash algorithm to demonstrate

that state-of-the-art algorithms can be moved from the

server to the client side. Depending on the parame-

ters’ conﬁguration, Argon2id can run on a wide range

of devices. However, the choice of these parameters

directly impacts the security level and is, therefore,

sensitive.

Our library, clipaha.js, leverages the lessons

learned from (Wijayarathna and Arachchilage, 2018)

to provide a developer-friendly API (RQ-F1). We

simplify the usage by hidding the parameters of the un-

derlying hash function and instead provide four secu-

rity levels (RQ-P1 and RQ-S4) which allow balancing

between security and compatibility. The four levels

represent parameter settings to target different classes

of devices:

low

is intended to maximize the support for ancient

devices, like smartphones, ebook readers, or even

computers from the early 2000s.

medium

targets all computers from the mid-2000s and

most smartphones and ebooks from the last 5 years.

high

is the value that we would recommend for new

developments where only computers from the last

5 years are considered.

ultra

uses the maximum amount of RAM possible

currently (a bit less than

2 GiB

due to browser

limits as explained on Subsection 5.1) and will run

ﬂawlessly on most modern laptops with at least

3 GiB of RAM.

The parameters used when hashing the password

with Argon2id in the current implementation of cli-

paha.js are chosen to ﬁt the memory of the device

class and use as many/few iterations to keep the exe-

cution time below 20 seconds (RQ-P1). Since higher

memory requirements involve more computation per

iteration, the number of iterations needed in lower

security levels is higher (see Table 3).

Introducing security levels represents a potential

security threat. An attacker preferably targets sys-

tems using the

low

security level, which has lower

requirements on computation and memory. Therefore,

allowing a powerful ofﬂine attacker to execute cre-

dential bruteforcing at a higher rate. However, the

execution time on the

low

security level still requires a

non-trivial amount of computing time (e.g.,

200 ms

a Core i7-7700k) compared to conventional server-side

hash functions. Also, the legacy devices targeted with

the

low

security level are expected to be phased out,

increasing security requirements over time.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

5 IMPLEMENTING THE Clipaha

LIBRARY

We implemented and publicly released an implemen-

tation of Clipaha.

We brieﬂy describe the server im-

plementation in MicroPython, followed by a more

detailed discussion of the challenges for the client im-

plementation in Javascript/WebAssembly.

Server Implementation. We implemented a proof-

of-concept of the server part of Clipaha on an ESP8266

with

80 KiB

of user data SRAM using MicroPython

1.11.0 and created a web interface for user login.

Client Implementation. One critical objective of

Clipaha is to keep authentication times reasonable

(RQ-P1). Our implementation of the client side is

based on the Emscripten framework (Zakai, 2011) to

use WebAssembly (Haas et al., 2017), when available,

and fall back to JavaScript otherwise. Clipaha also

leverages workers, when available, to ensure the main

thread can process events as the hashing proceeds.

Performing password hashing in JavaScript presents

various challenges which arise mainly because we aim

for our library to be compatible with various devices.

Below, we discuss the four major challenges we

found while implementing the library: memory, multi-

threading, performance, and data remanence.

5.1 Memory

Most JavaScript virtual machines limit the program-

mer’s ability to make huge allocations, e.g., for Array-

Buffers, the size is limited to

− 1

bytes (Pierron

et al., 2020). However, a paging approach could help

overcome the limitation. On WebAssembly, work is

in progress to support 64-bit addressing (Smith et al.,

2020).

In any case, manual testing in conjunction with our

evaluation (Subsection 6.3) shows that those memory

limits are more stringent in reality. On desktops, the

limit is

2 GiB

for the whole memory stack (reason

behind our use of

2016 MiB

of memory instead of

2048 MiB

for

ultra

in Table 3) on both Firefox and

Chrome. On mobile phones, the limits are signiﬁcantly

lower. For example, the mobile version of Chrome

limits available memory to a bit over

1 GiB

even if

the device has more. On such devices, the memory

requirements for

high

1 GiB

, or

ultra

, almost

2 GiB

cannot be attained even when allocating memory early.

Instead of a statically allocated buffer, we also use

malloc

because the generated code will otherwise in-

clude very large memory ﬁles (Zakai, 2017), which are

undesirable. Providing the statically allocated buffer

would allow for disabling

malloc

and reduce the risk

of an allocation failure caused by fragmentation. How-

ever, as we did not see fragmentation issues on any

browsers in our evaluation, and the only

malloc

al-

location done is the huge buffer used by Argon2, we

have opted for not using a statically allocated buffer.

5.2 Multithreading

After discovering the SPECTRE vulnerability (Kocher

et al., 2019), some browsers disabled the possibility

of using shared memory buffers across web workers

to avoid side-channel attacks. The situation has now

improved, with some browsers allowing their usage

under certain speciﬁc conditions (van Kesteren, 2020).

Even in such cases, to allow threads to share memory,

it is necessary to send speciﬁc headers on the web

application which isolate the application and restrict

its ability to add external resources. Not all browsers,

e.g., Safari, support this currently. Nevertheless, to

prepare for future threading support, we raised the

number of parallelizable work units (called lanes by

Argon2) to allow for up to 256 simultaneous threads.

5.3 Performance

JavaScript supports only 32-bit integer operations.

This conﬂicts with the core of Argon2: Lyra2’s

BlaMka hash function (Andrade et al., 2016), which

heavily uses 64-bit arithmetic. This, together with

the fact that JavaScript is usually interpreted by the

browser, makes the pure Javascript implementation of

Clipaha slow (see Subsection 6.3).

To address this, Clipaha relies on WebAssembly,

which increases the performance by providing 64-bit

integer support and compilation into native code. Nev-

ertheless, WebAssembly presents certain performance

limitations over native code. As it becomes more

widely available, SIMD support and other similar im-

provements will bring WebAssembly’s performance

more on par (Rossberg et al., 2018). For example, pre-

liminary testing hints that support for 128-bit vector

SIMD provides an improvement in run time of around

20%.

5.4 Data Remanence

JavaScript does not provide any guarantees regarding

the lifetime of variables and handles strings as im-

mutable objects. Consequently, the password to be

hashed may remain unmodiﬁed on memory over a

large period of time until it is eventually overwritten.

Overwritting the memory ourselves is also unfeasible

Clipaha: A Scheme to Perform Password Stretching on the Client

Table 4: An overview of the evaluations of Clipaha.

Label Description

Eval-1: Security analysis

Eval-2: Server-side: Proof-of-concept with a

microcontroller

Eval-3: Client-side: performance comparison of

WebAssembly vs Javascript

Eval-4: Client-side: baseline performance

comparison in 35 settings

Eval-5: Analysis of Clipaha in real scenarios

since the password is provided as an immutable ob-

ject. Consequently, trying to reduce the lifetime in

memory of intermediate results by overwritting them

is futile as it will not necessarily reduce the amount of

time during which password derived data will remain

in memory but will impact performance signiﬁcantly.

Therefore, Clipaha does not clean-up the stack nor the

allocated hash memory after a computation as doing

so will not improve security.

6 EVALUATION

To comprehensively evaluate Clipaha, we have consid-

ered the work from four complementary perspectives

with a total of ﬁve parts, as shown in Table 4. Eval-1

analyzes the security of Clipaha according to our threat

model. Eval-2 focuses on the server, with a proof-of-

concept of Clipaha running on very constrained hard-

ware (as found on certain IoT devices) with appropriate

measurements. Eval-3 provides a comparison between

WebAssembly and Javascript. Eval-4 is a performance

comparison between the state-of-the-art and Clipaha

on a total of 35 devices/softwares grouped into three ca-

pability classes: phone, tablet, and computer. Finally,

Eval-5, considers the deployment requirements of pass-

word systems and discuss how Clipaha addresses them

in several scenarios.

The experiments on Eval-3 and Eval-4 were run

ﬁve times on each setup, using different salt and pass-

word values on each run. We used the median to repre-

sent each setup’s result.

6.1 Security Analysis

In the following, we discuss the security requirements

presented in our threat model.

Regarding Salt collisions (RQ-S1), Clipaha’s se-

curity stems from its salt components being unam-

biguously delimited (see Subsection 4.2). Due to the

unique database identiﬁer, Clipaha’s salts are secure

against collisions even across systems using the same

salt calculation method. Confronted with systems us-

ing different ways of choosing their salt, it is unlikely

that salts will collide since Clipaha preﬁxes the unique

database identiﬁer with its size as a 32-bit integer.

For normal usage, i.e., with database identiﬁers under

65536 bytes, the size preﬁx will contain a sequence of

two consecutive null bytes. Such a sequence is uncom-

mon in text strings and would appear randomly with

probability

−16

. If we tackle the full string, the prob-

ability of a full match on a random string is

32+8∗n

where

is the length in bytes of the database identiﬁer.

To avoid timing side-channels leading to User enu-

meration attacks (RQ-S2), an implementation should

perform all extra server-side steps, even if the pass-

word is wrong. Similarly, an attacker may detect

changes in password hashing parameters or salts pro-

vided by the server for a speciﬁc user. Consequently,

an approach must ensure all provided data is either

global and not depending on the username or constant

for a speciﬁc username during the whole database life.

Regarding the ﬁrst attack solving it will always de-

pend on the way the system is implemented. Clipaha

minimizes the risk of this issue by choosing Argon2id

which masks the side-channels by ﬁrst doing a data-

independent pass. Also, we take the issue into account

when designing the scenarios and clearly explain how

to implement them avoiding timing side-channels. As

for the second attack, Clipaha only uses globally pub-

lic parameters and user-provided inputs without any

server-side processing as described in Subsection 4.2

and is, consequently, not affected by it.

In Pass-the-hash attacks (RQ-S3), the (ofﬂine) at-

tacker tries to use the already hashed credential stored

in the breached server database. Clipaha avoids this

by adding an additional lightweight hash on the server

side. As a result, the attacker would still need to revert

this hash to be able to use the credentials stored in

the database. Since the result of Argon2 should be

indistinguishable from a random string, this means the

attacker will need to perform on average

n−1

guesses

where

is the length in bits of the Argon2 computa-

tion. We provide a performance measure of such an

extra hash in Eval-2.

Credential bruteforcing becomes signiﬁcantly

more difﬁcult when using modern password hashing al-

gorithms like Argon2 (RQ-S4). This is a consequence

of increasing signiﬁcantly the amount of resources,

i.e., CPU time and memory amount and bandwidth,

needed for each guess attempt. Argon2 explicitly tar-

gets optimizations and TMTOs (Hatzivasilis, 2017)

to ensure that the guess time does not depend on the

attacker’s ability to use accelerators. With Clipaha,

online attackers now have to perform the computation

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

themselves instead of moving it to the authentication

server. Ofﬂine attackers still have to perform the com-

putation themselves and, since all the hash parameters

would be known beforehand, could try to precompute

valid outputs (Bernstein and Lange, 2013).

An ofﬂine attacker trying to precompute password

hashes will see a reduction of the actual, i.e., wall, time

needed to perform the attack since the attacker could

create beforehand a hash table mapping hash function

outputs to inputs. Nevertheless, the CPU time, memory

bandwidth and amount, and long term storage costs

for an attacker would be raised signiﬁcantly. First,

the attacker would need to target a speciﬁc, i.e., linear,

number of usernames as the unique salt would increase

the cost of the attack with the number of targeted user-

names. Similarly, even for the single username case,

the attacker will need to calculate the hash for all the

password guesses.

Finally, Clipaha provides a reference library (RQ-

F1)

with an easy-to-use API and pre-deﬁned security

levels to minimize implementation mistakes by soft-

ware developers and make Clipaha readily deployable.

6.2 Microcontroller Proof-of-Concept

To show the feasibility of deploying our approach,

we created a proof-of-concept in MicroPython tar-

geting the login and registration processes on an

ESP8266 (Espressif Systems, 2020) with only

80 KiB

of SRAM available. Thus, we could successfully show

that the server side of Clipaha can run even on such

constrained hardware.

Next, we benchmarked two versions of our code.

The ﬁrst uses an additional locally executed hash func-

tion, SHA256, to avoid pass-the-hash attacks (RQ-S3).

The second performs a raw string comparison with a

locally stored password.

We performed

1000 m

easurements of the time it

took to hash and securely compare the encrypted pass-

word on the device along with the time it took to

process a login request without the local hash. We

measured that the hash measured for

3.7%

of the

time it took to perform the request with a median of

735.425 µs

for the hash and

19604.25 µs

for the full

requests. Requests without the hash had a median of

19005.1 µs

in comparison. As expected, with server

relief, the code on the server side is fast even when run

on a microcontroller (less than 20 ms).

6.3 WebAssembly vs JavaScript

Our client implementation of Clipaha uses WebAssem-

bly and only falls back to JavaScript when necessary,

as the latter is very slow. With Eval-3, we compare the

native speeds on a desktop, a Core i7-4710HQ with

16 GiB

of RAM, with WebAssembly and Javascript.

As seen in Table 5, on a Desktop, WebAssembly incurs

slowdowns of around 2-3.5x compared to native code,

while JavaScript imposes a less consistent penalty of

30-130x. WebAssembly’s penalty may be caused by

optimization choices when compiling the middle code,

the lack of native SIMD support, and other minor over-

heads. The JavaScript one is consistent with the ex-

pected impact of using an interpreted language.

6.4 Baseline Performance Comparison

Clipaha moves the complexity to the client-side. We

have shown in Eval-2 that IoT devices can handle

the remaining computation at the server side. In this

section we focus on the complexity for the client-side

devices, which we expect to be: mobile phones, tablets,

and computers, with the aim to investigate Clipaha’s

portability and ability to run on them. This allows us

to validate the security levels presented in Table 3.

We also use this opportunity to compare Clipaha

with the similar libsodium (see Section 2). In par-

ticular we are comparing the benchmarks against a

similar implementation using lisodium.js (Denis et al.,

2020). We chose libsodium.js because it is the only

library providing Argon2id support that we could ﬁnd

available for browsers.

We run Clipaha and libsodium on a total of 21

devices, using different combinations of browsers and

devices. This resulted in the 35 different benchmarks

summarized in Table 6, where we roughly grouped the

results based on the capability of the hardware. On

the phone category, devices ranged from a Fairphone

2 with a Sanpdragon 801 CPU and

2 GiB

of RAM to a

Samsung S10+ with an Exynos 9820 CPU and

8 GiB

of RAM. On the tablet category, devices ranged from

an iPad with an A12 Bionic CPU and

3 GiB

of RAM

to a Surface Pro with a Core i5-7300U CPU and

8 GiB

of RAM. Finally, on the computer category, device

CPUs ranged from a Core i7-4710HQ CPU to a Core

i5-9400T, including also an AMD Ryzen7 4700U and

an ARM M1, while RAM amounts varied from

8 GiB

to 24 GiB.

We see that phones are up to ten times slower than

computers. Such a difference may be caused by slower

phone memory, a slower processor, or worse code

During benchmarking we found that Internet Explorer

11 and Edge are unable to run the libsodium.js code in-

side a dedicated web worker because the cryptographic

getRandomValues

API is not exposed. Since libsodium.js

does not use this API when computing Argon2id hashes, we

provided a trivial polyﬁll returning the input

TypedArray

be able to proceed.

Clipaha: A Scheme to Perform Password Stretching on the Client

Table 5: Native speed versus WebAssembly and JavaScript on a Core i7-4710HQ with

16 GiB

of RAM. “Factor” is normalized

for the ﬁrst row with native code. Chromium version is 85.0.4183.83 while Firefox version is 68.12.0esr.

Browser Impl.

low medium high ultra

Time (s) Factor Time (s) Factor Time (s) Factor Time (s) Factor

Native AVX2 0.653 1 1.446 1 2.083 1 4.068 1

Chromium

WebAssembly 1.873 2.87 3.181 2.20 5.269 2.53 10.845 2.67

JavaScript 80.507 123.29 133.685 92.45 215.930 103.66 422.795 103.93

Firefox

WebAssembly 2.228 3.41 3.770 2.61 6.040 2.90 11.912 2.93

JavaScript 29.109 44.58 47.909 33.13 77.254 37.09 151.300 37.19

optimization by phone-based browsers. Aiming at the

best intercompatibility, we can appreciate that

low

which improves on currently used defaults, did work

on a vast majority of devices, providing delays of up

20 s

. Although this may look long (see RQ-P1),

we ﬁnd it acceptable as it allows even fairly obsolete

clients to beneﬁt from the security provided by Argon2.

With caching the hashed credentials (see Eval-5), this

could also be a one-time cost amortized over a larger

number of logins. Given the relatively low failure

rate,

medium

is well suited for most modern mobile

devices with 3 GiB of RAM or more where such large

allocations can be performed. Finally,

high

and

ultra

are restricted to browsers like Firefox which do not

limit allocation size. These two security levels also

require either a high-end mobile device with enough

RAM or a desktop system.

We also observe that Clipaha is

50%

faster

than libsodium.js. This difference may be caused by

additional overhead in libsodium.js, or by Clipaha’s

use of ﬁxed Argon2 parameters allowing the compiler

to produce faster code. Clipaha also completed the

benchmarks on certain devices on which libsodium.js

failed, probably because of the early allocation of

memory made by Clipaha to avoid fragmentation.

6.5 Real Scenarios

Our ﬁnal evaluation of Clipaha is concerned with its

suitability for the many contexts where passwords are

used (RQ-F2). While most systems will need a pro-

cess for users to log in and, maybe, register and change

their passwords, more complex requirements may also

arise. As with any other authentication approach, im-

plementing these requirements carelessly may result

in new security problems. To address this risk and

ensure that Clipaha is deployed in such systems, we

provide implementation scenarios with an analysis of

those security issues that Clipaha cannot solve.

As shown in Table 7, we consider: three sever-side

authentication scenarios; three purely client-side sce-

narios; and two orthogonal techniques that can be used

in conjunction with Clipaha: Password-Authenticated

Key Exchange and Multi-Factor Authentication.

Registration. During the registration of a new user,

the server sends the database identiﬁer to the client.

The client then sends the password in plain text and

hashed.

The server validates all ﬁelds, including that

the plaintext password matches the password policy.

If all went well, the server inserts the password hash

along with the new user in the database (and proceeds

with any further steps). If the veriﬁcation fails, the

server returns an error to the client. To avoid user

enumeration, if the user is already present, we notify

the user through an alternative communication channel

without showing a different error message. Also, the

timing of the insertion and any operations done after-

wards must be the same whether the user is present or

not.

tiﬁer and processes and sends the resulting hash and

the username to the server. The server veriﬁes the

hash against the database. The user is allowed in if

the username exists and the hash matches. To avoid

user enumeration, the same message, e.g., Invalid user-

name or password, must be displayed whether the user

does not exist or the provided password is incorrect.

Also, to avoid timing side-channel attacks, the verify

operation should take the same amount of time if the

user does not exist or the password is incorrect.

We assume that communications between client and

server are secure. One example of such a channel is a TLS

connection. This avoids eavesdropping attacks.

We assume that the client can be trusted to send the

hashed password matching the sent plaintext password. If

these were different, the client could bypass the password

policy veriﬁcation by sending instead a policy-breaking

hashed password. Since this would only impact the user

purposefully trying to break the policy and would be against

the user’s interest, the risk of this issue should be deemed

low. Despite that, this could be avoided by either computing

the hash on the server or, alternatively, by delegating this

computation to a trusted and more powerful server. The

server would then ensure the hashes match the ones sent.

Given the resources needed to compute the hash, this may

open the server for a DoS attack if clients repeatedly send

requests.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

Table 6: Benchmark results summary. Number of failures (F), minimum (Min) and maximum (Max) seconds taken to run are

presented for each security level, device type and library. Only devices with at least a success are considered. Each security

level was tested 5 times per device and browser.

Device

type

Total Library

low medium high ultra

F Max Min F Max Min F Max Min F Max Min

Phone 15

clipaha 0 19.134 7.362 1 31.571 12.228 13 25.900 20.012 13 54.175 41.648

libsodium 0 33.313 12.611 2 54.887 21.076 13 48.320 34.648 13 100.377 69.114

Tablet 2

clipaha 0 2.279 2.015 0 4.048 3.739 0 7.689 5.940 1 17.674 17.674

libsodium 0 4.287 3.440 0 7.253 5.739 1 11.913 11.913 1 25.857 25.857

Computer 18

clipaha 0 3.032 1.126 0 4.979 1.873 0 8.054 3.328 0 15.717 6.124

libsodium 0 6.654 1.993 0 11.097 3.348 0 18.010 5.464 0 34.015 11.080

Table 7: An overview of the 8 evaluated scenarios.

Type Description

Server Registration, Login,

Password change

Client Client-side caching, Password

managers, Non-human authentication

Support Password-Authenticated Key

Exchange, Multi-Factor Authentication

Password Change. To change passwords, the server

sends the database identiﬁer and the current session’s

username. The client then asks for the original pass-

word and the new password and hashes both. The

client sends both passwords in plaintext

and their cor-

responding hashes to the server. The server proceeds

to verify that the old password hash matches the one

of the current user. If it does not, it returns an error

message to the client. Otherwise, it checks that the

new password plaintext complies with the password

policy. If all goes through correctly, the server updates

the database using the new password.

A Cross-Site Request Forgery (CSRF) (Watkins,

2001; KirstenS, 2020) attack allows an attacker to

change the password to take over an account when the

old password is not requested and veriﬁed. In such a

case, appropriate measures must be taken, like using

a CSRF token. Because this process depends on an

authenticated session being already in place and will

only affect the user, other security issues, e.g., user

enumeration, are not a direct concern.

Client-Side Caching. To save resources (RQ-P1),

client-side code using Clipaha may decide to cache the

password hash computation. This may indeed be the

case for obsolete devices as the login process otherwise

can take almost 20 s (see Eval-4).

Since cached entries would be returned almost in-

stantly, attackers with access to the shared cache could

use a timing side-channel to see which entries it con-

tains. Therefore, to avoid timing side-channels, caches

should ensure the cached results are only provided

once the same amount of time it initially took to cal-

culate the hash has elapsed. Similarly, the keys and

the contents of the cache could be used to impersonate

users. Therefore, caches should be careful with data

remanence and remove old entries periodically.

Password Managers. Password managers can inter-

act with the client-side code using Clipaha and provide,

along with the plaintext password, the already hashed

password and the parameters used. The client can then

use this hash to avoid doing the calculation. Similarly,

the client-side code can send new hashes, along with

the input parameters, to the manager for later retrieval.

To avoid pass-the-hash attacks, the manager must

store the hashed passwords using the same security

measures used for the plaintext. Similarly, the manager

should also use the same access policies it would use

for the plaintext password.

Non-Human Authentication Services using Cli-

paha may need to be available to embedded devices

that try to authenticate themselves. Assuming accounts

are not shared, such devices could replace the hashed

password with a hash-length, i.e., 256-bit, token sam-

pled from a good random source and registered during

provisioning. The token would replace the Clipaha

hashed password during veriﬁcation. From a security

perspective, this approach will work well if the token

is stored securely and protected from physical access

attacks and access by other domains or applications

running on the device.

Password-Authenticated Key Exchange Inte-

gration. Clipaha is compatible with Password-

Authenticated Key Exchange (PAKE), where a

cryptographic key is negotiated using the password.

Several steps must be done in constant time to avoid

timing side-channels, even if the user does not exist. If

the PAKE is well designed, it will also not be possible

for the attacker to use server veriﬁers to impersonate

the client.

Multi-Factor Authentication Integration. If Multi-

Factor Authentication (MFA) is in place, the client

Clipaha: A Scheme to Perform Password Stretching on the Client

should provide its codes before veriﬁcation along with

the hashed password. These codes would be validated

during veriﬁcation. If extra actions from the server

are required for MFA, they have to be performed after

veriﬁcation succeeds but before any further actions

are carried out. Additional server actions and MFA

value validation should be in constant time and look

the same even when the user has no MFA or does not

exist in order to prevent side-channels attacks.

7 CONCLUSIONS

This paper introduces Clipaha, an scheme for server

relief. Clipaha allows using modern password hash-

ing functions with high security parameters even on

resource constrained IoT devices by moving the com-

putation away from them and into the client.

We test Cliapaha’s performance, security, and

readiness to be deployed. We specify and analyze

the security of eight authentication-related scenarios

which leverage this scheme and publicly release an

implementation

From the security analysis, we conclude that Cli-

paha is a key solution to help build more secure authen-

tication systems since it is resistant to salt collisions

and user enumeration attacks as opposed to prior work.

The deployability tests show that Clipaha is ready

to be used for web-based authentication. Clipaha’s

server-side is lightweight enough to work even on an

ESP8266 with only

80 KiB

of RAM. The benchmarks

show that client-side, Clipaha performs over two times

faster than the closest baseline: libsodium.js. Also,

thanks to Clipaha’s four security levels and the bench-

marks we have performed, developers can balance

between security and running Clipaha on most devices

from the last ﬁve years while addressing any compati-

bility issues caused by their technical limitations.

In conclusion, Clipaha has the potential to im-

pact embedded systems like SoHo network appliances

and IoT gateways which are resource constrained and

rarely require ﬂows more complex than registration

(during provisioning) and authentication.

ACKNOWLEDGEMENTS

This paper and most of the artifacts associated with

it have been developed as part of the the Resilient

IoT project and under a grant from The Swedish Civil

Contingencies Agency (MSB).

The ﬁrst author would like to acknowledge the

feedback received from Vicent Nos and Ignacio

Bedoya during his tenure as CISO for Lescovex when

the ideas behind this paper started taking shape. The

ﬁrst author also would like to acknowledge the co-

founders of Garmer Technologies OÜ for believing

that his research could have commercial use.

Finally, the authors would like to acknowledge the

benchmark data contributions from some members

of the Networks and Systems unit at Chalmers and

some individual members. The authors would like to

specially thank the contributions from Carlo Brunetta

(benchmarks on most Apple devices) and Elaine Mon-

teagudo Sánchez (benchmarks on most browsers using

her Xiaomi Redmi Note 8T and her Core i7-8750H

laptop).

REFERENCES

Alwen, J. and Blocki, J. (2017). Towards practical attacks

on argon2i and balloon hashing. In EuroS&P.

Andrade, E. R., Simplicio, M. A., Barreto, P. S., and dos

Santos, P. C. (2016). Lyra2: Efﬁcient password hashing

with high security against Time-Memory Trade-Offs.

IEEE Transactions on Computers, 65(10).

Aumasson, J.-P. et al. (2013). Password hashing competition

(phc).

Bai, W. and Blocki, J. (2021). Dahash: Distribution aware

tuning of password hashing costs. In FC.

Bauman, E., Lu, Y., and Lin, Z. (2015). Half a century of

practice: Who is still storing plaintext passwords? In

ISPEC.

Bernstein, D. J. and Lange, T. (2013). Non-uniform cracks

in the concrete: The power of free precomputation. In

ASIACRYPT.

Biryukov, A., Dinu, D., and Khovratovich, D. (2016). Ar-

gon2: New generation of memory-hard functions for

password hashing and other applications. In EuroS&P.

Biryukov, A., Dinu, D., and Khovratovich, D. (2017). Ar-

gon2: the memory-hard function for password hashing

and other applications. Technical report, Password

Hashing Competition.

Blanchard, E., Coquand, X., and Selker, T. (2019). Moving

to client-side hashing for online authentication. In

STAST.

Corbató, F. J. (1963). The Compatible Time-Sharing System:

A Programmer’s Guide. The MIT Press.

Denis, F. (2019). Libsodium documentation: Password hash-

ing.

Denis, F. et al. (2020). libsodium.js: README.

Eliasen, M. (2019). Developers, its 2019, hash passwords

accordingly.

Espressif Systems (2020). ESP8266EX datasheet. Datasheet,

Espressif Systems.

Haas, A., Rossberg, A., Schuff, D. L., Titzer, B. L., Holman,

M., Gohman, D., Wagner, L., Zakai, A., and Bastien, J.

(2017). Bringing the web up to speed with WebAssem-

bly. In PLDI.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

Hatzivasilis, G. (2017). Password-hashing status. Cryptog-

raphy, 1(2).

KirstenS (2020). Cross site request forgery (csrf).

Kocher, P., Horn, J., Fogh, A., Genkin, D., Gruss, D., Werner,

H., Hamburg, M., Lipp, M., Mangard, S., Prescher, T.,

Schwarz, M., and Yarom, Y. (2019). Spectre attacks:

Exploiting speculative execution. In S&P.

Lee, J. A. N., Rosin, R., Corbató, F. J., Fano, R. M., Green-

berger, M., Licklider, J. C., Ross, D. T., and Scherr,

A. L. (1992). The Project MAC interviews. IEEE

Annals of the History of Computing, 14(2).

Morris, R. and Thompson, K. (1979). Password security: A

case history. Communications of the ACM, 22(11).

Ntantogian, C., Malliaros, S., and Xenakis, C. (2019). Eval-

uation of password hashing schemes in open source

web platforms. Computers & Security, 84.

Oechslin, P. (2003). Making a faster cryptanalytic time-

memory trade-off. In Boneh, D., editor, CRYPTO.

Pierron, N. B., Scholz, F., and Kettner, P. (2020). Rangeerror:

invalid array length.

Rossberg, A. et al. (2018). Simd proposal for webassembly.

Saad, E. and Mitchell, R. (2020). Testing for account enu-

meration and guessable user account.

Security, D. (2019). Salted password hashing - doing it right.

Skowron, P. et al. (2021). Brute force attack.

Smith, B. et al. (2020). Memory64 proposal for webassem-

bly.

Van Acker, S., Hausknecht, D., and Sabelfeld, A. (2017).

Measuring login webpage security. In SAC.

van Kesteren, A. (2020). Safely reviving shared memory.

Watkins, P. (2001). Cross-site request forgeries (re: The

dangers of allowing users to post images).

Wijayarathna, C. and Arachchilage, N. A. G. (2018). Why

johnny can’t store passwords securely? a usability

evaluation of bouncycastle password hashing. In EASE.

Wilkes, M. V. (1968). Time-sharing computer systems. Num-

ber 5 in Computer monographs. American Elsevier,

New York, NY, USA.

Zakai, A. (2011). Emscripten: an LLVM-to-JavaScript com-

piler. In OOPSLA.

Zakai, A. (2017). What can cause the size of the .js.mem ﬁle

increase?

Clipaha: A Scheme to Perform Password Stretching on the Client
