Bypassing Multiple Security Layers Using Malicious USB Human

Interface Device

Mathew Nicho

and Ibrahim Sabry

Research and Innovation Centre, Rabdan Academy, Abu Dhabi, U.A.E.

College of Technology Innovation, Zayed University, Dubai, U.A.E.

Keywords: Arduino, USB, HID, Administrative, Controls, Bypass, Payload.

Abstract: The Universal Serial Bus (USB) enabled devices acts as a trusted tool for data interchange, interface, and

storage for the computer systems through Human Interface Devices (HID) namely the keyboard, mouse,

headphone, storage media and peripherals that use the USB port. However, with billions of USB enabled

devices currently in use today, the attacker’s potential to seamlessly leverage this device to perform malicious

activities by bypassing security layers presents serious risk to systems administrators. The paper thus presents

a comprehensive review of the multiple attacks that can be leveraged using USB devices and the

corresponding vulnerabilities including countermeasures. This is followed by the demonstration of five

attacks to validate the threat and the associated vulnerabilities by bypassing four security layers namely (1)

two server operating system (OS) controls, (2) one group policy control, and (3) antivirus. The attack was

performed by plugging in a USB that is connected with the Arduino Micro board to install three differently

crafted malwares into the victim machine (Windows Server 2012). As a result, the Arduino device that has

been programmed to act like a Human Interaction Device (HID) was able to bypass all the four layers

successfully, with execution on the first three layers. The attack-vulnerability theoretical model, the

demonstration of the five attacks, and the subsequent analysis of the attacks provide academics with multiple

domains (countermeasures) for further research, as well as practitioners to focus on critical IT controls.

1 INTRODUCTION

The threat posed by maliciously modified Universal

Serial Bus (USB) devices is real, potent,

unsuspecting, relatively easy to execute with deadly

consequences, and with a high rate of success. The

USB is the most commonly used standard in 5G

generation computer systems for peripheral

communications (Singh, Biswal, Samanta, Singh, &

Lee, 2022). Attackers can modify the firmware of a

USB device to masquerade a generic USB flash drive

to act as an attacker-controlled, automated, mouse

and keyboard (Cronin, Gao, Wang, & Cotton, 2022).

In January 2022, the FBI issued a public warning over

a USB attack campaign in which numerous USB

drives, embedded with malicious codes, were sent to

employees at organizations in the transportation,

defense, and insurance sectors between August and

November 2021 (Hill, 2022). From a global

perspective, more than half (54%) of global

https://orcid.org/0000-0001-7129-3988

https://orcid.org/0000-0001-9886-9414

organizations reported USB-based attacks in 2021, up

more than 15 percent from 2020 (Rose, 2022). USB

device malware is being leveraged as part of larger

cyber-attack campaigns against industrial targets

such that 81% of malware seen on USB drives in

industrial facilities can disrupt industrial control

systems (Honeywell, 2022). From an infection

perspective, removable media were responsible for

nine percent of all incidents responded to in January

2022, increasing to 20 percent for incidents where the

initial infection vector involved a physical endpoint

(Mir, Wong, & Manahan, 2022). USB connections

and associated devices are inherently trusted (Davis,

2011) and assumed secure by the users partly due to

assumed secure ownership and physical proximity of

the device (Yang et al., 2015).

The USB enabled peripherals have become an

attractive tool for launching cyber-attacks (Nissim,

Yahalom, & Elovici, 2017) since a programmable

USB device can be used to masquerade as a Human

Nicho, M. and Sabry, I.

Bypassing Multiple Security Layers Using Malicious USB Human Interface Device.

DOI: 10.5220/0011677100003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 501-508

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

501

Interface Device (HID) (Lawal, Gresty, Gan, &

Hewitt, 2021). With billions of USB devices currently

in use, the USB protocol is among the most widely

adopted protocols today due to its plug-and-play

capabilities and the vast number of devices which

support the protocol (Denney, Erdin, Babun, Vai, &

Uluagac, 2019). As the USB port on a computer

system can be considered an open port, it gets

exposed to malware with weakened defenses from

anti-virus, or security control (Wahanani, Idhom, &

Kurniawan, 2020). Furthermore, attackers can design

malicious USB devices so that once the USB

handshake is completed, and malicious scripts or

activities can be executed on the host (Cronin et al.,

2022).

The HID that is a component of the user interface

system can be exploited using a micro controller

embedded with a malicious code to perform

malicious actions leading to Malicious HID (MHID).

Commonly used HID devices can be identified by

many Operating Systems (OS) without the need for

specific setup or configuration. Furthermore, the

concept of Plug-and-Play (PnP) feature in HIDs

(Techopedia, 2019) amplifies the attack surface

thereby exposing the vulnerability. Despite the

critical nature of USB device attacks, papers focusing

on a holistic perspective of analyzing multiple

vulnerabilities associated with HID devices is lacking

in this domain.

This research takes an exploit and vulnerability

approach by presenting a taxonomy of vulnerabilities

attributed to HID via the USB protocols through the

demonstration of successful attacks bypassing

multiple security layers. In this respect, this paper

makes the following contributions.

 Provides an overview of attacks on the USB

ecosystem by identifying the computer based

attacks and vulnerabilities.

 Demonstrates a simulated attack on a server

bypassing multiple security layers.

 Analyses the vulnerability associated with the

four security layers with suggested

countermeasures.

 Demonstrates the criticality of the threat to

security practitioners through the exploited

vulnerabilities to take appropriate measures.

The paper is structured as follows. Section two

and three discusses existing research on HID based

attacks and vulnerabilities. Section four and five

illustrates the HID based simulated attacks and

corresponding countermeasures followed by a final

section concluding the research.

2 USB ATTACKS USING HID

Attackers have used USB peripherals to launch

cyberattacks, exploiting the vulnerabilities,

properties, and capabilities of these devices (Davis,

2011). In this respect, the USB protocol is the most

widely-used connector to connect a range of

peripheral devices to computers (Neuner, Voyiatzis,

Fotopoulos, Mulliner, & Weippl, 2018). It uses a

tiered-star topology, where the center of the star is the

USB host, which defines the USB, that is

implemented as a combination of hardware,

firmware, and software residing inside the computer.

The HIDs have elevated privileges, because the

systems’ OS assumes that commands executed from

the HID are coming from an authorized user. Altering

a USB device to simulate keyboard or mouse is a

method to emulate an HID by hiding malicious codes

for malicious actions (Nasution, Purwanto, Virgono,

& Alam, 2014). Attack techniques using peripheral

devices may use USB devices by emulating a USB

Ethernet adapter. This enables the USB device to act

as a DHCP server that directs traffic through a

malicious DNS (Tischer et al., 2016). Attacks

deploying social engineering methods leveraging

USB are aimed at organizations to make the attack

happen (Anderson & Anderson, 2010; Davis, 2011;

Pham, Syed, & Halgamuge, 2011).

The USB Rubber Ducky is a keyboard emulator

hidden within a USB thumb drive case. Since 2010,

IT professionals, penetration testers, and hackers

have used the Rubber Ducky to create the most

widely used commercial keystroke injection attack

(Nissim et al., 2017). BadUSB attacks are initiated

when the host performs a malicious firmware update

in which the USB device’s firmware is modified by

the attacker where it acts according to how it was

programmed by the attacker (Cannoles & Ghafarian,

2017). Another type of USB-based attack is a driver-

related attack, in which an attacker inserts a

compromised malicious USB device into the host,

causing the host to download a malicious driver

crafted to execute malicious code or exploit a buffer

overflow vulnerability (Caudill & Wilson, 2014). The

attack methodology deployed for the use of bad USBs

is through reprogramming the device’s USB protocol

stack. Using micro controller devices namely the

Raspberry pi Pico, Intel 8051, the micro controller’s

logic circuit programming is altered, and the primal

functioning of a simple IoT device is transitioned to

be used in cyber-attacks. There are also attacks that

are oriented toward the Denial of Service (DoS) of the

host computer. Once such attack is termed the USB

Killer attack where a look alike flash drive acts as an

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

502



electric discharger capable of destroying sensitive

components on the host (Nissim et al., 2017). This

attack was successfully demonstrated through the

‘Stuxnet’ worm attack.

3 USB BASED

VULNERABILITIES

Attacks exploiting USB ecosystem vulnerabilities are

varied (see figure 1) with the most recent and potent

being the Rubber Ducky. The Rubber Ducky

vulnerability (Nohl & Lell, 2014) that is

demonstrated in this research makes use of the weak

threat detection by the OS and host machine, even

with various controls in place. This is possible due to

the configuration flexibility provided by the Arduino

microcontroller in order to run malicious scripts that

can control the host machine through the input of

PowerShell commands embedded into the Arduino

C++ script, resulting in the download and execution

of the malicious payload. Since, USB devices are

innocuous by their nature and ubiquity, their

architecture of the USB ecosystem is ‘complex’ and

deeply ‘embedded’ in the OS. Furthermore, the

features of the USB protocol that resemble wide-area

networking protocols can be ‘underappreciated’. This

combination of complexity, embeddedness, and

under appreciation is the foremost vulnerability

feature of MHID (Johnson, 2014).

3.1 Encryption & Data Misplacement

Attacks by MHIDs exploiting the OS in computer

systems is a serious risk due to the inherent trust given

by the OS to HIDs. In this respect, the use of

malicious HID devices has exposed critical

vulnerabilities in OS (Zhao & Wang, 2019). HID

vulnerabilities that can be exploited include poor

encryption and data misplacement, systems

misconfiguration, unpatched and outdated software.

Since HIDs are not inherently malicious, USB device

firmware (drivers) are not typically scanned by OS.

In addition, OS embedded antimalware systems are

unable to detect or defend against these types of

attacks. Therefore, HIDs are more susceptible to

manipulation as they gain seamless access to the host

machine. Once connected to the computer system,

they can pose as a peripheral such a mouse or

keyboard or download the malicious payload or

execute a code on the host machine that would further

weaken the system. The USB protocol vulnerability

that could allow a USB device to impersonate

peripheral devices occurs due to the lack of device

authentication, authorization and a security

mechanism that needs to verify the data or the

messages received from a device (Ticu, 2021). A Man

in the Middle (MITM) attack can also be effected

using MHID due to the lack of appropriate end-to-end

encryption. Hence, when a MHID is plugged in (Ex.

Rubber Ducky), it can tap into the duplex

communication pathway and steal sensitive

information (Acar, Lu, Uluagac, & Kirda, 2019).

3.2 Systems Misconfiguration

This vulnerability is portrayed by system assets such

as operating systems where their internal settings may

be vulnerable. In addition, the application or

operating system settings may be disparate in terms

of security (Scaife, Peeters, & Traynor, 2018).

Additionally, while running the research experiment

it evident that the policy integrated into the GPO is to

deny access of “all removable storage classes”, which

means that it does not include removable peripheral

HIDs namely keyboard and mouse.

3.3 Unpatched/Outdated Software

Outdated OS pose serious threat in relation to the use

of malicious HID devices since the unpatched

software is outdated with less security update support

from the vendor. Thus, cybercriminals will tend to

track users that use unpatched or outdated system

software as it will be easy to compromise and to

access and retrieve sensitive information and data

(Zhao & Wang, 2019). Figure 1 summarizes the

vulnerabilities and the associated attack vectors.

4 SIMULATION AND ANALYSIS

In this simulated experiment, we target the USB

protocol function drivers namely the device function,

function driver, and device controller driver. We

opted to go with the Arduino Micro board, as it is one

of the boards with built in USB capabilities, that

would allow us to use its connection to act as an

external keyboard or mouse when connecting to a

machine. Thereafter, we used a male-to-male USB

adapter which allows for easy plug and play

functionality to the Arduino board. To upload the

script onto the board we used the Arduino IDE

environment that acts as a communication bridge

between the host machine and the board.



Bypassing Multiple Security Layers Using Malicious USB Human Interface Device

503

Figure 1: USB Vulnerabilities exploited by HIDs.

4.1 USB Rubber Ducky Set up

In this paper, we selected the Rubber Ducky option

rather than the BadUSB, as the BadUSB can only be

executed on USB 3.0 flash drives that contain the

Phison 2303 micro-controller (with limited

availability) while the Rubber Ducky is a lot faster

than BadUSB and a Teensy and is readily available.

It does not contain any embedded malware, but only

executes commands to download it from specific IP

address via the victim’s browser. The environment set

up for the experiment consists of two virtual

machines, namely the Kali Linux VM (attacker), and

Windows Server 2012 (victim). The Server version of

Windows was used in order to create an active

directory, and simulate a direct attack on the Server

to gain administrative controls while logged in as the

admin (Figure 2).

In order to masquerade Arduino as an HID, we

connected the Arduino and configure it using the IDE

interface. The IDE interface allows the user to create

scripts using C++ programming language, which was

uploaded into the Arduino board to execute upon

reconnecting the board to the machine. This converts

the Arduino into a “rubber ducky” to take control of

the keyboard and uses it to run commands on the

victim machine.

Figure 2: Attack flowchart.

In the C++ script we also inserted a script to

disable the Windows Defender (Box 1).

Box 1: Script to disable Windows Defender.

Keyboard.print("powershell start

powershell -A 'Set-MpPreference -

DisableRea $true' -V

runAs"); typeKey(KEY_RETURN);

We also inserted the script to download the

malicious file via the victim’s browser (open the web

client and download the file from the Kali Apache

server) and execute it (Box 2). We ensured that the

script libraries for the keyboard are available, so that

the Arduino would be able to connect as a Rubber

Ducky. This can be seen with the #include

‘Keyboard.h’ function, which allows the Arduino to

gain access to the keyboard library scripts. The

Keyboard.press and Keyboard.release functions

control the victim machine’s keyboard in order to

type in the intended commands on PowerShell.

Thereafter, we created the malicious Windows

payload to open a reverse_tcp connection using

msfvenom.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

504



Box 2: Script for accessing and downloading the malware

from an external IP address.

Keyboard.print("powershell -

windowstyle hidden (New-Object

System.Net.WebClient).DownloadFile('h

ttp://192.168.100.6//share/whysoserio

us.exe','%TEMP%\\whysoserious.exe');

Start-Process

\"%TEMP%\\whysoserious.exe");

typeKey(KEY_RETURN);

// Ending stream

Keyboard.end();

}

/* Unused endless loop */

void loop()



Thereafter, we configured Windows Server 2012

to create the Active Directory in order to simulate the

server environment. We ensured that the Windows

Firewall and Windows Defender are up and running

as in a real environment. In order to simulate the

varied security layers in an organizational network we

conducted three simulated attacks (A, B, C) on

Windows Server 2012. In all first option the attack

was done with the two security layers namely

Windows firewall, and Windows Defender activated.

For B, we added a third security layer by configuring

Windows Group Policy Object (GPO) to disable USB

ports in the Server. In the last option a fourth security

layer was added by installing and activating an

antivirus.

4.2 Attack Option A

This option simulates the security structure of

Windows Server in a normal network scenario of

organizations where the use of USB is allowed. We

begin the experiment by plugging in the Arduino

board through the USB port and waiting for the script

to run. Thereafter, The Arduino automatically

downloaded and installed the malware onto the

Windows Server 2012 through the URL. This was

done without any human intervention via the

PowerShell command that was embedded in the

Arduino (See box 2). We were able to successfully

navigate the system33 folder which would only be

allowed for administrator access on the windows

machine. We also successfully ran the clearrev,

getuid, ps (process list) and ifconfig (Network

information) commands to simulate malicious actions

performed by hackers and get additional information

on the machine. The Arduino device was able to

bypass two security layers of admin controls in order

to download the payload onto the machine.

Furthermore, the software was downloaded onto the

%temp% folder of the windows machine, which was

appropriate for the attacker for stealth reasons. This

demonstrates the significance of the USB

vulnerability, as the Arduino was easily able to

bypass admin controls just by connecting to the

victim machine as an external keyboard.

4.3 Attack Option B

In this phase of the attack we added a third security

layer by configuring the GPO to block USB ports on

the server by launching the GPO tool on the domain

controller. Once the gpupdate /force command to

enforce the GPO was executed, we tested the GPO by

connecting a USB drive to the OS where the USB was

denied (figure 6) access thus validating the

enablement of the GPO. When the experiment was

restarted by plugging in the Arduino board through

the USB port, the script was successful in executing

the malware. It’s important to note that even though

GPO was active, the Arduino micro masquerading as

a HID managed to bypass the GPO security control.

Subsequently, we repeated the commands in first

attack by successfully navigating to the system33, ran

the clearrev, getuid, ps (process list) and ifconfig

commands, getting the same outputs as in the

previous attack. This demonstrate that despite the

activation of the GPO blocking USB ports, the

Arduino script was successful in taking over the

victims’ machines’ keyboard and execute the

programmed powershell commands to download the

malicious software from the network and even

execute it.

4.4 Attack Option C

In this option, we build on the previous result by

adding a fourth security layer by downloading and

installing Webroot SecureAnywhere antivirus (listed

among the top ten in 2022) onto the Windows Server

2012 VM. When we ran our experiment, the Arduino

script was successful in penetrating the four defensive

layers. However, the antivirus (fourth defensive

layer) detected and blocked the malware when the

Arduino script attempted to download and execute the

malware, thus preventing the execution of the

malware.

This signifies that while the Arduino script was

successful in its initial operation, the infection was

unsuccessful. In this respect, the antivirus was unable

to detect the Rubber Ducky, but detected the malware

signature. Since we used msfvenom to create the

malware (C1), we repeated the same attack by

creating a second malware with FatRat (Option 6:

Bypassing Multiple Security Layers Using Malicious USB Human Interface Device

505

Create FUD Backdoor 1000% with PwnWinds). We

simulated the same experiment but with the same

result as in C1. Furthermore, we created a third

malware with Veil Evasion (Option 22:

poweshell/meterpreter/rev_tcp.py) and did the same

attack with the same result as in C1 and C2. Table 1

thus demonstrates the result of the five attacks. Since,

malwares are continuously evolving, so too are

antivirus endpoint security solutions. This is a

characteristic that makes every malware unique in its

signature or fingerprint. This identification

information is regularly updated onto the antivirus

database and stored as virus definitions This process

is done in order to be up to date with new versions of

malware signatures/fingerprints. If a match is

detected by the antivirus, it alerts the user while also

containing the virus in a sandbox environment

(Vigderman & Turner, 2022). However, when we

attempted to bypass this feature, with a modified

script, we were unsuccessful in installing and

executing the malware.

Table 1: The five attack configurations with the results.

GPO Firewall W

Defende

AV Result

A x Yes Yes* x S

B Yes Yes Yes* x S

C1 Yes Yes Yes* Yes U**

C2 Yes Yes Yes* Yes U**

C3 Yes Yes Yes* Yes U**

(‘Yes’ means that the security layer was active; ‘x’ signifies

it is inactive; S denotes that the attack is successful, while

U denotes its unsuccessful in executing the malware)

*The Windows Defender was running, but was disabled by

the Arduino with the embedded PowerShell script:

"powershell start powershell -A 'Set-

MpPreference -DisableRea $true' -V

runAs"

** The Arduino script ran successfully, but the malware

was detected as a Trojan.

In order to counter the fourth defensive layer

(bypass and/or disable the Webroot Realtime

antivirus), we added a powershell command to the

script, which would uninstall the antivirus software.

But, this method was unsuccessful due to the software

requiring the user to enter an auto generated

CAPTCHA code, which is an effective

countermeasure to avoid tampering with the antivirus

software. However, two methods can bypass the

above preventive method. First, a successful

penetration can be done using a zero day or near zero-

day malware to evade antivirus software. Secondly,

through the use of different malware authoring tools

to update the malware in the Apache Server folder

using the same malware name as in Box 2

(whysoserious.exe'

). With multiple malware

authoring tools readily available and with multiple

options in each of these tools, evasion is not difficult.

5 COUNTERMEASURES

While, tools and techniques for detecting USB-

related attacks have been proposed and implemented,

currently there are no fool proof technique for fully

guarding against potential USB malicious attacks, as

most solutions may be circumvented. As with most

security systems, applying specific IT control

corresponding to each security layer offers the best

chance to increase security as discussed below. The

sub sections below provide a categorised discussion

on the security that can be applied at the different

USB system layers.

5.1 USB Functional Layer

The USBFILTER system, which is a packet-level

access control (firewall) for USB, can allow or deny

USB device functionality by defining specific

measures (Tian, Bates, Butler, & Rangaswami, 2016).

The researchers instrumented the host's USB stack

between the USB device driver and the USB

controller, allowing them to filter packets at the

operating system's low level (kernel). Furthermore,

USBFILTER can specify which programs (e.g.,

Zoom) are permitted to use which USB devices (e.g.,

webcams, speakers, and microphones), preventing

malicious software on the host from enabling or

accessing protected USB devices (Neuner, 2017).

Cinch is based on the same principles as

USBFILTER. However, it isolates all USB devices

from the host and routes communication through a

virtual machine that acts as a gateway, enforcing

access policies (Angel et al., 2016). There are certain

scripts like DuckHunter that are designed to run in the

background and monitor the typing speed. The

program effectively blocks keyboard input when a

Rubber Ducky attack is detected (Pmsosa, 2020).

While a tool such as SandUSB acts as a middleman

between the device and connected host, the tool

places the connected USB into a sandbox

environment to detect any malicious activity, by

scanning and analyzing the device. The tool looks at

three different aspects that may be detected as

malicious such as keyboard typing speed or pattern,

any attempts to change OS configuration, and finally

the detection of malicious payload on the storage

device (Loe, Hsiao, Kim, Lee, & Cheng, 2016).

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

506



5.2 USB Physical Layer

USB port blockers are an efficient way to prevent

users from connecting unauthorized USB devices

with malicious payloads. An attacker is less likely to

target systems with USB port blockers in the case of

a Rubber Ducky attack. USB port blockers, which

come with a special key that unlocks and locks the

device once installed, can be installed on critical

systems in a network that contains sensitive files. The

disadvantage of USB port blockers is that they are

still vulnerable to physical tampering if not

monitored. Rubber Ducky devices operate at speeds

that are impossible to detect by standard users in a

company. Various payload scripts are readily

available for download from the internet, allowing

even those with no computer experience to carry out

a Rubber Ducky attack (Karystinos, Andreatos, &

Douligeris, 2019).

5.3 USB Link Layer

Commercial Rubber Ducky attack countermeasures

makes it impossible for Rubber Ducky devices to

emulate a keyboard. When a USB device connects to

the computer and the Operating System recognizes it

as a keyboard, the anti-virus prompts the user to enter

a numerical challenge code generated by the anti-

virus from the 'new' USB keyboard. Keyboard

authorization is a term used to describe such a

procedure. As a result, the anti-virus will only allow

the use of a keyboard that has been authorized and

will block any other keyboard that has not been

authorized. Even if it could not detect the Rubber

Ducky device, it can detect the malware launched by

the Rubber Ducky (Raghavan, 2020).

From an encryption perspective, commercial

solutions exist where if the USB device manufacturer

is trusted and the signing key is kept secure, the

firmware is considered trusted.

Another potential way

to prevent the Rubber Ducky attack is by restricting

access to elevated Command Prompt (cmd). Running

cmd as an administrator unlocks a whole set of

actions that can be performed on a computer. That’s

why an administrator should set a password for using

elevated cmd to stop any Rubber Ducky programmed

to seek out administrative privileges.

6 CONCLUSION

This paper demonstrated a simulated attack by an

USB drive masquerading as a malicious human

interface device using Arduino micro-controller. Our

device was able to bypass four security layers namely

the OS Firewall, the OS Antivirus, the OS security

control (GPO), and partly evade the installed

antivirus. The identified and analyzed vulnerabilities

provide valuable insights into probable

countermeasures that can be deployed providing

greater visibility of the threat and corresponding

countermeasures. This shows the critical nature of

USB based HID attacks that can penetrate networks

through a malicious or an unsuspecting insider.. The

experiment shows the severity of the USB

vulnerability.

While our paper is not without its limitations, each

of these listed limitation provides avenues for further

research. First, since we did a direct attack on a

server, an attack simulating a system in a network via

a secure remote connection can provide network

based vulnerabilities as well. Second, we created

malware using three malware authoring tools. With

numerous malware authoring tools available to

hackers, the fourth security layer can be fully

bypassed using zero day or near zero-day malware.

Third, we used a script to de activate the Windows

Defender. Research on innovative script can

deactivate similar antivirus programs. Fourth, the

research can be extended to include experimental

methods for gaining domain admin users rights in

LDAP or active directory and illustrate more about

the extent to which admin domain privileged can be

controlled. Finally, we did not specifically test the

countermeasures against specific attacks for

validating the countermeasures.

REFERENCES

Acar, A., Lu, L., Uluagac, A. S., & Kirda, E. (2019). An

analysis of malware trends in enterprise networks.

Paper presented at the International Conference on

Information Security.

Anderson, B., & Anderson, B. (2010). Seven deadliest USB

attacks: Syngress.

Angel, S., Wahby, R. S., Howald, M., Leners, J. B., Spilo,

M., Sun, Z., . . . Walfish, M. (2016). Defending against

malicious peripherals with Cinch. Paper presented at

the 25th USENIX Security Symposium (USENIX

Security 16).

Cannoles, B., & Ghafarian, A. (2017). Hacking experiment

by using usb rubber ducky scripting. Journal of

Systemics, 15(2), 6671.

Caudill, A., & Wilson, B. (2014). Making BadUSB work

for you. Paper presented at the presented at Derbycon

4.0. Available online from.

Cronin, P., Gao, X., Wang, H., & Cotton, C. (2022). Time-

print: Authenticating USB flash drives with novel

Bypassing Multiple Security Layers Using Malicious USB Human Interface Device

507

timing fingerprints. Paper presented at the 2022 IEEE

Symposium on Security and Privacy (SP).

Davis, A. (2011). USB-undermining security barriers.

Black Hat Briefings.

Denney, K., Erdin, E., Babun, L., Vai, M., & Uluagac, S.

(2019). Usb-watch: a dynamic hardware-assisted usb

threat detection framework. Paper presented at the

International Conference on Security and Privacy in

Communication Systems.

Hill, M. (2022). BadUSB explained: How rogue USBs

threaten your organization. CSO Online. Retrieved

from https://www.csoonline.com/article/3647173/

badusb-explained-how-rogue-usbs-threaten-your-

organization.html

Honeywell. (2022). Honeywell Industrial USB Threat

Report. Retrieved from Houston: https://

honeywellprocess.blob.core.windows.net/public/Mark

eting/Honeywell-USB-Threat-Report.pdf

Johnson, P. C. (2014). How USB Does (and Doesn’t)

Work: A Security Perspective. Security, 39(4), 12-15.

Karystinos, E., Andreatos, A., & Douligeris, C. (2019).

Spyduino: Arduino as a HID exploiting the BadUSB

vulnerability. Paper presented at the 2019 15th

International Conference on Distributed Computing in

Sensor Systems (DCOSS).

Lawal, D., Gresty, D. W., Gan, D., & Hewitt, L. (2021).

Have You Been Framed and Can You Prove It? Paper

presented at the 2021 44th International Convention on

Information, Communication and Electronic

Technology (MIPRO).

Loe, E. L., Hsiao, H.-C., Kim, T. H.-J., Lee, S.-C., &

Cheng, S.-M. (2016). SandUSB: An installation-free

sandbox for USB peripherals. Paper presented at the

2016 IEEE 3rd World Forum on Internet of Things

(WF-IoT).

Mir, H., Wong, S., & Manahan, B. (2022). Top Attack

Vectors: January 2022. Retrieved from https://expel.

com/blog/top-attack-vectors-january-2022/

Nasution, S. M., Purwanto, Y., Virgono, A., & Alam, G. C.

(2014). Integration of kleptoware as keyboard

keylogger for input recorder using teensy USB

development board. Paper presented at the

Telecommunication Systems Services and Applications

(TSSA), 2014 8th International Conference on.

Neuner, S. (2017). Bad things happen through USB. Wien,

Neuner, S., Voyiatzis, A. G., Fotopoulos, S., Mulliner, C.,

& Weippl, E. R. (2018). Usblock: Blocking usb-based

keypress injection attacks. Paper presented at the IFIP

Annual Conference on Data and Applications Security

and Privacy.

Nissim, N., Yahalom, R., & Elovici, Y. (2017). USB-based

attacks. Computers & Security, 70, 675-688.

Nohl, K., & Lell, J. (2014). BadUSB-On accessories that

turn evil. Black Hat USA, 1(9), 1-22.

Pham, D. V., Syed, A., & Halgamuge, M. N. (2011).

Universal serial bus based software attacks and

protection solutions. Digital Investigation, 7(3-4), 172-

184.

Pmsosa. (2020). Duckhunt: Prevent Rubberducky (or other

keystroke injection) attacks, DuckHunter. Retrieved

from https://github.com/pmsosa/duckhunt

Raghavan, R. (2020). An Introduction to Bad USB Attacks.

Retrieved from https://acodez.in/badusb-attack/

Rose, A. (2022). Cybercriminals bring the USB back,

with a vengeance. Retrieved from https://

www.itp.net/opinion/cybercriminals-bring-the-usb-back

-with-a-vengeance#:~:text=More%20than%20half%20

(54%25),environment%20as%20an%20acceptable%2

0option.

Scaife, N., Peeters, C., & Traynor, P. (2018). Fear the

reaper: Characterization and fast detection of card

skimmers. Paper presented at the 27th USENIX

Security Symposium (USENIX Security 18).

Singh, D., Biswal, A. K., Samanta, D., Singh, D., & Lee,

H.-N. (2022). Juice Jacking: Security Issues and

Improvements in USB Technology. Sustainability,

14(2), 939.

Techopedia. (2019, November). What Does Human

Interface Device (HID) Mean. Retrieved from

https://www.techopedia.com/definition/19781/human-

interface-device-hid

Tian, D., Bates, A., Butler, K. R., & Rangaswami, R.

(2016). Provusb: Block-level provenance-based data

protection for usb storage devices. Paper presented at

the Proceedings of the 2016 ACM SIGSAC Conference

on Computer and Communications Security.

Ticu, M. (2021). USB Traffic Analyzer-digUSB. Paper

presented at the 2021 12th International Symposium on

Advanced Topics in Electrical Engineering (ATEE).

Tischer, M., Durumeric, Z., Foster, S., Duan, S., Mori, A.,

Bursztein, E., & Bailey, M. (2016). Users really do plug

in USB drives they find. Paper presented at the 2016

IEEE Symposium on Security and Privacy (SP).

Vigderman, A., & Turner, G. (2022). How Does

Antivirus Software Work? Retrieved from https://

www.security.org/antivirus/how-does-antivirus-work/

Wahanani, H., Idhom, M., & Kurniawan, D. (2020). Exploit

remote attack test in operating system using arduino

micro. Paper presented at the Journal of Physics:

Conference Series.

Yang, B., Qin, Y., Zhang, Y., Wang, W., & Feng, D.

(2015). TMSUI: A trust management scheme of USB

storage devices for industrial control systems. Paper

presented at the International Conference on

Information and Communications Security.

Zhao, S., & Wang, X. A. (2019). A Survey of Malicious

HID Devices. Paper presented at the International

Conference on Broadband and Wireless Computing,

Communication and Applications.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

508
