A Review of AutoML Software Tools for Time Series Forecasting and

Anomaly Detection

Christian O’Leary

, Farshad Ghassemi Toosi

and Conor Lynch

Department of Computer Science, Munster Technological University, Cork, Ireland

Nimbus Research Centre, Munster Technological University, Cork, Ireland

Keywords:

Machine Learning, Deep Learning, AutoML, Software, Time Series, Forecasting, Anomaly Detection.

Abstract:

Time series exist across a plethora of domains such as sensors, market prices, network trafﬁc, and health

monitoring. Modelling time series data allows researchers to perform trend analysis, forecasting, anomaly de-

tection, predictive maintenance, and data exploration. Given the theoretical and technical knowledge required

to implement mathematical and machine learning models, numerous software libraries have emerged to fa-

cilitate the programming of these algorithms via automated machine learning (AutoML). Comparatively few

studies compare such technologies in the context of time series analysis and existing tools are often limited

in functionality. This review paper presents an overview of AutoML software for time series data for both

forecasting and anomaly detection. The analysis considers 28 metrics that indicate functionality coverage,

code maturity, and community support across 22 AutoML libraries. These aspects of software development

are crucial for the uptake and utilisation of AutoML tools. This study proposes a means of deriving a func-

tionality score for correlation analysis between variables such as lines of code, package downloads from PyPi,

and GitHub issue completion rate. This review paper also presents an overview of AutoML library features

which can facilitate informed decisions on which tools are most appropriate in various instances.

1 INTRODUCTION

The growing ubiquity of time series data and effective

modelling approaches has co-evolved with the prolif-

eration of sensing technologies (Lu and Xu, 2019),

digitisation (Qiu et al., 2016), the development of

programming tools (Abadi et al., 2015), and ongo-

ing academic research. Time series modelling has use

cases in many industries including agriculture (Zhang

et al., 2020), computing (Wu et al., 2018) and en-

ergy (Kavanagh et al., 2017). Applied instances in-

clude point forecasting (Lynch et al., 2021), density

forecasting (Bergmann et al., 2018), anomaly detec-

tion (Hundman et al., 2018), time series classiﬁcation

(Ismail Fawaz et al., 2019) and exploratory analysis

urtler and Paulsen, 2018). Methodologies range

from traditional statistical models (Bergmann et al.,

2018) to more modern approaches such as machine

learning (ML). ML is a subtopic within Artiﬁcial In-

telligence (AI) and is a highly complex ﬁeld where

models applied to time series data include Random

Forests (Lago et al., 2018), K-Nearest Neighbours

(KNN) (O’Leary et al., 2021), Support Vector Ma-

chine (SVM) ensembles (Lynch et al., 2019), shal-

low neural networks (NNs) (Zhang et al., 2020) and

deeper NNs which are referred to by the term deep

learning (DL) (O’Leary et al., 2021).

Ordinarily, the process of implementing a time se-

ries model requires theoretical knowledge of the al-

gorithm itself, as well as proﬁciency in programming

and debugging. These prerequisites often present a

barrier to the ﬁeld of time series analysis, restrict-

ing the range of implementable experiments with-

out an in-depth ability of the extensive range of

tasks required. Empirical ML analysis often includes

data gathering, data exploration, data cleansing, data

augmentation, feature engineering, feature selection,

scaling, model hyperparameter search, model train-

ing, post-processing, (nested) cross-validation, model

selection, model testing, statistical signiﬁcance test-

ing, and reporting (He et al., 2021). To the author’s

knowledge, existing libraries reviewed in this paper

either exclude or only partially facilitate the major-

ity of these steps. Therefore, considerable manual ef-

fort is required to implement a solution that incorpo-

rates ML or statistical modelling. For instance, while

scikit-learn (Pedregosa et al., 2011) contains various

model implementations, end-users are required to re-

O’Leary, C., Toosi, F. and Lynch, C.

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection.

DOI: 10.5220/0011683000003393

In Proceedings of the 15th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2023) - Volume 3, pages 421-433

ISBN: 978-989-758-623-1; ISSN: 2184-433X

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

421

view, implement and test these functions in their re-

spective code.

In response to the innate difﬁculty of program-

ming for ML (Thessen, 2016), a wide range of auto-

mated ML (AutoML) libraries and frameworks have

emerged (see Section 3). The research presented here

evaluates the extent to which these tools fulﬁl the

needs of ML researchers with a particular focus on

time series forecasting and anomaly detection. The

analysis compares 22 Python-based libraries regard-

ing the functionalities these tools offer along with

the level of engagement from their developers and

the programming community at large. This compari-

son aims to provide a benchmark of quantitative and

qualitative metrics for selecting appropriate libraries

based on domain-agnostic information prior to exper-

imentation.

Section 2 provides an overview of time series fore-

casting and anomaly detection using traditional, ML

and DL approaches. Section 3 evaluates existing

Python-based AutoML libraries comparing the suit-

ability of each tool for forecasting and anomaly detec-

tion. The AutoML tools are discussed and contrasted

in Section 4 before conclusions are outlined in Sec-

tion 5.

2 BACKGROUND

A survey of ML for big data processing (Qiu et al.,

2016) revealed that ML, as a ﬁeld of research, has

exploded in popularity for domains such as medicine,

Internet of Things (IoT) systems, social media, cyber-

security, computer vision, and recommender systems.

A popular application of ML modelling within these

domains is time series analysis, which includes fore-

casting (Borovykh et al., 2018) and anomaly detection

(Wu et al., 2018).

2.1 Time Series Data

Time series vary signiﬁcantly in attributes depend-

ing on their source, even within the same organisa-

tion (Chatterjee et al., 2022). Time series datasets can

be decomposed into their respective base components

which often envelop trend, seasonality, cyclicity, and

irreducible noise. Trend refers to a long-term increase

or decrease in the mean series value. A time series

with a stable, unchanging trend is referred to as sta-

tionary. Time series seasonality denotes the regular

frequencies in the data. Time series may have mul-

tiple frequencies, e.g. temperatures follow both daily

and annual patterns. Cyclicity refers to cycles that oc-

cur irregularly; the period between cycles may vary.

Finally, irreducible noise or white noise refers to nat-

urally occurring minor ﬂuctuations in points of data.

A time series may also contain anomalies. There is no

universal consensus for the deﬁnition of an anomaly,

possibly because the distribution of anomalies is typi-

cally difﬁcult to determine given their sparsity (Goix,

2016). Anomalies are not guaranteed to be evenly dis-

tributed and may occur consecutively in bursts (Chat-

terjee et al., 2022).

2.2 Modelling Time Series Data

Exploratory analysis can be conducted on time se-

ries data using statistical methods and visual examina-

tion via plots such as autocorrelation function (ACF)

and partial autocorrelation function (PACF). Inher-

ently, visual scrutiny of these plots introduces sub-

jective error (O’Leary, 2020). Using these plots, a

feature set can be selected as a continuous window

of values (Lynch et al., 2019) or a smaller cohort of

highly correlated features (O’Leary, 2020). This pro-

cess can improve model accuracy and assist in pre-

venting overﬁtting (He et al., 2021). A feature set can

be augmented by the inclusion of engineered features

such as mapping features to Sine or Cosine waves

(Ugurlu et al., 2018) or by using Fourier Transforms

(Ghaderi and Kabiri, 2012). Feature sets can be opti-

mised further using dimensionality reduction methods

such as Principal Component Analysis (PCA) (Qiu

et al., 2016). While time series data is commonly as-

sociated with numeric data sources such as sensors

(Ahmad et al., 2017), prices (Ugurlu et al., 2018) and

trafﬁc speeds (Kim et al., 2018), it is also possible to

transform other data formats (e.g. text) into time se-

ries data using various transformations (Zhang et al.,

2019).

Numerous studies have compared implementa-

tions for ML, algebraic and statistical models with

each family of algorithms proving to be advantageous

under different conditions (Javeri et al., 2021). Curve

ﬁtting and statistical models are computationally in-

expensive and can yield explainable results (Thessen,

2016). In contrast, ML models are difﬁcult to inter-

pret for structural reasons, resulting in explainable

AI being an active ﬁeld of research (Amarasinghe

et al., 2018). They also suffer from increased com-

putational complexity and slow ﬁtting times (San-

turkar et al., 2019), necessitating optimisation strate-

gies to limit the number of model instances trained

(He et al., 2021). As none of the modelling ap-

proaches achieved supremacy across all problems in

forecasting and anomaly detection, both ML and non-

ML models are examined in this review paper.

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

422

2.3 Mathematical Models

In a review of algebraic, semiparametric, statistical

and conventional ML models applied to milk yield

forecasts, Zhang et al. (2018) acknowledged the dif-

ﬁculty in comparing results across different use cases

where datasets and metrics differ. Cubic splines have

been found to be effective forecasting models, al-

though they are highly sensitive to outliers (Zhang

et al., 2018). For higher dimensional data, Multiple

Linear Regression (MLR) models can be effective as

forecasting models (Kaytez et al., 2015). Statistical

models can be ﬁtted to time series data using princi-

ples of ACF/PACF analysis, autoregression, moving

averages, and smoothing or a combination thereof.

Other mathematical models include Autoregressive

(AR) (Lago et al., 2018), Dynamic Regression (DR)

(Lago et al., 2018), Holt-Winters (Kavanagh et al.,

2017) and hybrid models of the aforementioned.

Lago et al. (2018) compared 27 statistical and

ML models for electricity price forecasting observing

“a clear division” between the two families of algo-

rithms. The ML models achieved statistically signif-

icantly better accuracies than their counterparts, but

other studies (Kavanagh et al., 2017) have demon-

strated cases where statistical models can outper-

form ML models. The time taken to ﬁt ML models

can be considerable (O’Leary and Lynch, 2022) and

they are less interpretable than statistical approaches

(Thessen, 2016).

Time series models can be applied to anomaly de-

tection by measuring the residuals of predictions ver-

sus newly observed data (Smith, 2017). Where the

residual exceeds a speciﬁed threshold, an anomaly is

assumed. Statistical error thresholds for anomaly de-

tection can be static (LinkedIn, 2022) or dynamically

calculated (Choudhary et al., 2017). Anomaly detec-

tion scores can also be calculated via PCA (Zhang

et al., 2019) or Robust PCA (RobustPCA or RPCA)

(Choudhary et al., 2017). To benchmark model run-

times for anomaly detection, Choudary et al. (2017)

implemented a series of statistical, ML, and time

series-based mathematical models, ﬁnding that mod-

els using thresholds calculated from streaming per-

centiles, mean, median, median absolute deviation or

autoregressive models may be preferable to ML under

extreme time constraints.

2.4 Machine Learning Models

ML is a data-driven approach where models attempt

to iteratively self-optimise from observed data. Time

series forecasting is supervised regression as past ob-

servations are used to train the model. Anomaly

detection is supervised classiﬁcation if labels are

available and unsupervised otherwise. In practice,

anomaly detection modelling must often be unsuper-

vised as anomaly labels are rarely available in pro-

duction (Goix, 2016). Instead of relying on sta-

tistical tests, ML model hyperparameters are opti-

mised using manual speciﬁcation or algorithms such

as grid search, randomised search, Genetic Algo-

rithms (GAs), etc. (He et al., 2021). ML models are

typically ﬁtted on training data and evaluated on test

data (which simulates out-of-sample data). For ML

modelling, a third partition called a validation set is

often introduced to rank trained model instances that

are using different hyperparameters before the short-

listed model is ﬁnally evaluated on the test set.

Ridge, Lasso, Elastic Net, and Bayesian Ridge ex-

pand on traditional MLR models by adding penalty

terms to tune coefﬁcients (Nguyen et al., 2020;

O’Leary et al., 2021). Such models adjust their pa-

rameters using a learning rate α. For ML models, the

value of a learning rate needs to be chosen carefully

(Ioffe and Szegedy, 2015). Overly large learning rates

may cause model parameters may fail to converge,

while small learning rates may slow training unnec-

essarily (Santurkar et al., 2019).

Support Vector Regression (SVR) models have

been used for forecasting as standalone models

(Grimes et al., 2014) and as part of ensembles such

as K-SVM-SVR (Lynch et al., 2019). The K-Nearest

Neighbour (KNN) model has been successfully used

for forecasting electricity prices (O’Leary et al., 2021)

and milk volumes (O’Leary and Lynch, 2022). Deci-

sion Trees are used for forecasting both as standalone

models (O’Leary and Lynch, 2022), and in ensem-

bles such as Random Forests (Lago et al., 2018) or

Extremely Randomised Trees (Extra Trees) (O’Leary

et al., 2021).

Dense neural networks (DNNs) are neuroscientiﬁ-

cally inspired models that consist of layers of neurons

(Singh and Mohanty, 2015). The inputs to each neu-

ron are multiplied by weights that the model learns

with a learning rate using algorithms such as back-

propagation. NNs have grown increasingly ‘deep’ in

terms of layers (He et al., 2021), although smaller

networks remain effective for time series forecasting

(Nguyen et al., 2020). The increased network depth

of DNNs allows them to learn complex and non-linear

relationships at the cost of longer training times (Ioffe

and Szegedy, 2015) and less explainable outputs (Yu

et al., 2019).

A limitation of DNNs is that they do not retain any

internal state based on memories of recently observed

data beyond their learned parameters. Recurrent Neu-

ral Networks (RNNs) solve this problem using a neu-

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection

423

ron’s output as an additional input connection. This

forms a feedback loop that makes RNNs and their

relatives particularly adept in dealing with sequen-

tial data, e.g. time series (Ugurlu et al., 2018) and

natural languages (Lynch et al., 2020). Other forms

of RNN include Long Short-Term Memory (LSTM)

(Hochreiter and Schmidhuber, 1997) and Gated Re-

current Unit (GRU) (Cho et al., 2014).

Conventional Neural Networks (CNNs) consist of

convolutional layers, pooling layers and ﬁnally one

or more densely connected layers. CNNs are most

commonly used for higher dimensional data which is

often required for image analysis (Lynch et al., 2020),

but they can be adapted to time series forecasting.

Firstly, the time series data can be formatted into a

2D matrix and passed as an image (Kim et al., 2018).

Alternatively, CNNs can use 1-dimensional ﬁlters for

feature identiﬁcation (O’Leary, 2020).

Autoencoders (AE) are a type of neural network

that can be used in both supervised and unsupervised

modelling and are commonly used in hybrid model ar-

chitectures (Wang et al., 2017). AE models include a

bottleneck that forces the network to learn a compact

representation of data. AE models can be used for

unsupervised anomaly detection by leveraging a re-

construction loss metric as a proxy for anomaly score

(Zhao et al., 2022).

In the ﬁeld of anomaly detection, it is widely ac-

knowledged that labelled data are generally unavail-

able, necessitating the use of unsupervised or semi-

supervised approaches (Ahmad et al., 2017). Alter-

natively, some researchers have used generative mod-

els to create synthetic labels for training models, al-

though these models are less effective at detecting real

anomalies (Chatterjee et al., 2022). Some proxy met-

rics for estimating the ranking of anomaly detection

models without labels via Mass-Volume and Excess-

Mass curves have been proposed, but follow-up re-

search has been sparse and inconclusive (Warzynski

et al., 2021).

Isolation Forests are unsupervised tree-based

models that work by partitioning the dataset under

the assumption that anomalies are uncommon and are

measurably different from normal data. Time series

bitmaps are effective for unsupervised anomaly de-

tection and visualisation. Time series bitmaps pro-

cess sliding windows of data of a ﬁxed length which is

set via hyperparameter. One-Class SVM (OCSVM) is

an unsupervised variant of the traditional SVM model

that assumes one normal and one anomalous class.

It should be noted that standard regression models

such as NNs, KNR, SVR, etc. can also be adapted

for unsupervised anomaly detection if combined with

a threshold algorithm. Where a time series fore-

casting model’s predictions experience an error be-

yond a threshold, an anomaly can be assumed. Such

thresholds can be static, based on the modelling error

(Hundman et al., 2018), or learned as hyperparame-

ters (Chatterjee et al., 2022).

Choudhary et al. (2017) found ML models to be

superior in terms of accuracy to statistical models, al-

beit at the cost of greater runtimes for both anomaly

detection and forecasting. The disparity in accuracy is

attributed to a lack of robustness in statistical models

to concept drift.

2.5 Modelling in Practice

The Python programming language (Python, 2022)

has a rich ecosystem of open-source libraries and

frameworks available on public Git repository sites

such as GitHub (Github, 2022) and the Python Pack-

age Index (PyPI, 2022). A 2021 Stack Overﬂow (SO)

survey (StackOverﬂow, 2021) of over 80,000 pro-

grammers indicated Python as the prevailing ML pro-

gramming language. The survey reported that 48.24%

of programmers use Python while other programming

languages used for scientiﬁc computing such as R and

MATLAB were used by 5.07% and 4.66% of users

respectively. Python libraries used for ML can be

high-performance as they are built on C libraries and

can run models on Graphics Processing Units (GPU)

using Compute Uniﬁed Device Architecture (CUDA)

(NVIDIA, 2017).

Scikit-learn is a popular ML library containing

many model implementations. The scikit-learn main-

tainers do not recommend scikit-learn for training

NNs at scale as the library is not CUDA compat-

ible. TensorFlow is a framework for constructing

NNs via lower-level tensor manipulation (Abadi et al.,

2015). TensorFlow is compatible with CUDA en-

abling NNs to be trained using NVIDIA GPUs which

signiﬁcantly reduces training times. TensorFlow also

incorporates the Keras library (Francois, 2022). Other

NN frameworks include PyTorch (Paszke et al., 2017)

and MXNet (Chen et al., 2015). Anomaly detection

libraries include PyOD (Zhao et al., 2022), Lumi-

nol (LinkedIn, 2022) and Prophet (Facebook, 2022).

The statsmodels library contains functionality for sta-

tistical modelling including ARIMA, SARIMA, etc.

(Seabold and Perktold, 2010).

3 AutoML LIBRARIES AND

FRAMEWORKS

AutoML can incorporate many phases of a typical ML

pipeline including data cleaning, data augmentation,

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

424

feature selection, model training, HO and AO (Bahri

et al., 2022). AutoML systems tend to be highly

conﬁgurable, although increased conﬁguration can

be overwhelming for some practitioners (Thessen,

2016).

AutoML may use data augmentation which in-

volves generating synthetic data to enlarge a dataset.

Data augmentation is typically used for image data

(He et al., 2021) but has been successfully applied

to time series data by Javeri et al. (2021). Javeri et

al. effectively doubled the size of a COVID dataset

in their AutoML pipeline by transitioning from daily

to half-day forecasts; half-day values were imputed

using a Seasonal Auto-Regressive Integrated Moving

Average (SARIMA) model. This improved the over-

all accuracy of their model and has a regularisation

effect.

AutoML pipelines use a variety of model opti-

misation methods that can be categorised into archi-

tecture optimisation (AO) and (HO). AO is speciﬁc

to NN models and is synonymous with Neural Ar-

chitecture Search (NAS). It refers to the automatic

optimisation of a NN’s architecture which can con-

sist of many low-level operations, e.g., convolution,

pooling and concatenation (He et al., 2021). A wide

variety of NAS methods have emerged including re-

inforcement learning, gradient descent, and evolu-

tionary algorithm approaches. It should be noted

that NAS is still an open problem as there are cases

where sophisticated AO algorithms may not outper-

form randomised searches (He et al., 2021). There are

many advanced HO methods including contracting

grid searches (Hesterman et al., 2010), randomised

searches (Bergstra and Bengio, 2018) and Bayesian

approaches. Hyperparameter searches are inherently

limited by their speciﬁed search spaces (Bahri et al.,

2022). HO and AO can occur jointly or separately

via a two-stage process (He et al., 2021). In the two-

stage approach, NAS is conducted using a ﬁxed set

of hyperparameters. Having achieved a local opti-

mum, hyperparameter tuning is then applied to the

model (He et al., 2021). The majority of research on

NAS has, however, traditionally focused on non-time

series-related problems such as image classiﬁcation

(He et al., 2021). As a result, some researchers noted

that conventional NAS algorithms are not appropriate

for anomaly detection AutoML workﬂows (Li et al.,

2020a).

Given one dataset in isolation, it is computation-

ally costly to train and test many models, but the avail-

ability of multiple datasets allows for the use of meta-

learning (Feurer et al., 2021). Meta-learning involves

recording the performances of models across various

datasets to learn to predict (via a meta-learner model)

what models are suitable for an unseen dataset (Bahri

et al., 2022). By predicting what model and hyperpa-

rameters should be employed, costly search space ex-

ploration can be partially avoided (Bahri et al., 2022).

For time series data, meta-features may include statis-

tics such as the number of instances, autocorrelation,

seasonality, or trend (Chatterjee et al., 2022). The

meta-learner used for model selection used can vary;

Feurer et al. (Feurer et al., 2021) used a policy se-

lector, while Chatterjee et al. (Chatterjee et al., 2022)

used a Random Forest classiﬁer and one multi-task

NN per algorithm. Multiple studies have espoused

AutoML via meta-learning as a means of rapidly

training models more effectively with respect to time

than manually speciﬁed algorithms (Chatterjee et al.,

2022). However, creating a training dataset for meta-

learners is expensive (Feurer et al., 2021) and the

effectiveness of meta-learning is tied to the level of

similarity between encountered datasets (Bahri et al.,

2022). For anomaly detection, it is possible to em-

ploy unsupervised models, but existing meta-learner

models are still based on supervised algorithms (Bahri

et al., 2022).

In practice, AutoML libraries vary in function-

ality, scope, and community engagement as pre-

sented in Tables 1 and 2. The 22 AutoML libraries

selected include some of the most popular open-

source Python-based AutoML libraries. AdaNet is

a TensorFlow-based AutoML framework for learn-

ing NN-based ensembles (Cortes et al., 2017). Au-

toGluon is a library for deep learning and ensem-

bles for text, image, and tabular data (Erickson et al.,

2020). AutoKeras (or Auto-Keras) is a library that

automates the optimisation of a selection of Keras

models (Jin et al., 2019). Auto-PyTorch jointly per-

forms both hyperparameter and architecture optimisa-

tion of DL models (Zimmer et al., 2021). The auto-

sklearn library is an AutoML library built on scikit-

learn using meta-learning (Feurer et al., 2021). Au-

toTS is a library for developing statistical, ML and

DL forecasting models at scale (Catlin, 2022). ETNA

is a time series AutoML framework with a wide va-

riety of forecasting functions and some for anomaly

detection (Tinkoff.AI, 2022). EvalML is a general

AutoML framework with statistical and ML models

with some time series functionality (Alteryx, 2022).

FEDOT automates ML pipeline development using

evolutionary algorithms (Nikitin et al., 2022). The

Fast and Lightweight AutoML Library (FLAML) is

a lightweight AutoML library with HO (Wang et al.,

2021). H2O is an open-source AutoML framework

for distributed learning (H2O, 2022). Hyperopt-

sklearn is a Python library that combines the func-

tionality of Hyperopt and scikit-learn for automatic

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection

425

model optimisation (Komer et al., 2019). Kats (Kits

to analyse time series) is a library speciﬁcally for

time series analysis including forecasting (Facebook,

2022), anomaly detection, (Meta, 2022) and meta-

learning (Chatterjee et al., 2022). LightAutoML is a

general AutoML library for supervised classiﬁcation

and regression (Vakhrushev et al., 2022). Ludwig is

a general-purpose toolbox for ML modelling on tabu-

lar data for problems such as classiﬁcation, forecast-

ing, natural language processing, etc. (Molino et al.,

2019). Active Anomaly Detection with Meta-Policy

(Meta-AAD) uses a meta-policy with reinforcement

learning to optimise anomaly detection models (Zha

et al., 2020). Outlier Detection via Meta-Learning

(MetaOD) is a Python tool using meta-learning for

outlier detection (Zhao et al., 2021). MLBox is an

AutoML Python library with both optimisation and

preprocessing features (De Romblay, 2022). The ml-

jar library is an AutoML Python package for tabular

data with options for (paid) remote learning (Plonska

and Pło

nski, 2021). PyCaret is a low-code ML li-

brary for generic ML modelling including some func-

tionality for time series modelling and anomaly de-

tection (Ali, 2020). Python system for Outlier De-

tection with Database Support (PyODDS) is a super-

vised outlier detection library with database support

(Li et al., 2020b). Tree-based Pipeline optimisation

Tool (TPOT) is a Python AutoML tool that uses Ge-

netic Algorithms for model optimisation (Olson et al.,

2016).

Statistics from the 19

of August 2022 are pre-

sented for each software tool in Table 1. These ﬂuc-

tuate given the dynamic nature of software develop-

ment. The metrics in Table 1 present an approximate

view of the maturity, popularity, and community en-

gagement behind each project. The lines of code met-

ric counts lines of Python code. The Stars, Forks,

and Commits correspond to their respective values

on GitHub. The last update time corresponds to the

time since the last commit on the main/master branch.

GitHub Issues correspond to user-submitted bug re-

ports, feature requests, questions, and other issues.

The issue completion rate is calculated as the num-

ber of closed issues divided by the total. Most of the

GitHub-related ﬁgures are subject to regular change

but provide some quantiﬁable estimates of both de-

veloper and user engagement. As PyPi is the main

repository for publicly available Python packages, the

number of package downloads from PyPi is also in-

cluded as both a total and from the previous month

from PyPi Stats (Flynn, 2022). SO is a Q&A web-

site with over 21 million recorded questions and mil-

lions of monthly visits, making it one of the most

prominent programming resources available (Stack-

Overﬂow, 2021). The SO tag count represents the

number of user-submitted questions relating to a par-

ticular software package. It should be assumed that

this count will not include questions where the library

was not tagged.

Table 2 compares the libraries in terms of selected

functionality. Resource limits refer to the capability

of the software to impose constraints via limits on

overall runtime, CPU, RAM, or GPU usage. Most of

the libraries use a parameter specifying the number of

iterations or models, but these do not guarantee that

the simulations will end within a speciﬁc timeframe.

Preprocessing includes features such as aggregation,

feature scaling, imputation, etc. Model/output visual-

isation refers to the presence of incorporated classes

or functions to visualise or tabulate results automat-

ically. Data augmentation may include resampling

methods, generative NNs or any method for extend-

ing a dataset with new data. Feature engineering in-

volves the creation of feature sets through extrapo-

lation or collecting historical values to use as a slid-

ing ‘window’. Feature selection involves the shortlist-

ing of features from the prospective feature set based

on metrics such as feature importance scores. The

availability of statistical, ML, and DL models are also

listed with an additional ‘anomaly detection’ column

presented to clarify which of these libraries offer in-

tegrated anomaly detection. HO and AO indicate the

model self-tuning capabilities of the software. The

following time series-speciﬁc functionality are also

examined: time-based cross-validation (TCV), time

series formatting features, and multi-output regres-

sion predictions which are required for forecasting

beyond one period. Finally, the presence of built-in

pipeline Serialisation functionality is recorded. Fea-

tures are ignored where virtually all of the libraries

have such capabilities, thus making the comparison

redundant. Feature implementation was determined

by scanning existing library documentation for the

relevant functionalities. Where a feature was not out-

lined in the documentation, the Python source code

was also manually examined for any undocumented

functionality. Where a library has dedicated AutoML

modules, only those modules are considered for ex-

amination. For example, the H2O library has some

feature selection functionalities that may not be sup-

ported by the H2OAutoML class.

4 DISCUSSION

Section 3 describes 22 AutoML libraries using 28

technical and non-technical characteristics. The fea-

sibility of examining these variables via statistical

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

426

Table 1: Statistics on AutoML Tools.

Software Name

Lines of

Code

Repository Activity GitHub Issues PyPi Downloads SO

Tag

Count

Stars Forks Commits Last

Update

Open Closed Total Close

Rate

Last

Month

Total

AdaNet 28,106 3,417 531 440 2 years 63 49 112 0.44 659 158,503 4

AutoGluon 86,748 4,729 621 1,069 6 hours 152 582 734 0.79 118,763 2,335,813 0

AutoKeras 18,513 8,586 1,373 1,322 2 days 94 743 837 0.89 41,271 837,509 60

Auto-PyTorch 63,141 1,740 216 249 29 days 37 193 230 0.84 920 15,578 0

auto-sklearn 62,864 6,440 1,175 2,742 1 hour 108 806 914 0.88 35,344 838,285 15

AutoTS 28,639 560 51 233 2 months 10 40 50 0.80 39,163 923,229 0

ETNA 38,636 562 53 467 2 hours 54 295 349 0.85 5,507 37,426 0

EvalML 92,561 525 71 1,815 7 minutes 253 1,414 1,667 0.85 7,948 169,491 1

FEDOT 50,474 427 48 635 2 hours 90 261 351 0.74 1,160 26,882 0

FLAML 26,202 2,023 296 369 4 days 44 191 235 0.81 29,579 632,880 0

H2O 185,282 5,939 1,924 31,136 23 hours 65 6,161 6,226 0.99 428,906 17,173,047 1,857

Hyperopt-sklearn 11,730 1,362 253 399 3 months 70 53 123 0.43 8,422

1,167,652 0

Kats 83,507 3,901 392 553 1 day 34 100 134 0.75 44,990 607,668 4

LightAutoML 35,595 231 12 28 11 days 0 3 3 1 3,372 115,869 0

Ludwig 91,121 8,475 1,002 2,806 15 hours 188 624 812 0.77 2,429 124,023 19

Meta-AAD 1,194 34 10 6 15 months 0 1 1 1 0 0 0

MetaOD 1,685 106 17 38 6 months 3 3 6 0.50 252 7,775 0

MLBox 22,043 1,343 270 1,121 2 years 18 74 92 0.80 6,469 177,362 0

mljar 22,043 2,023 285 1,010 3 days 95 398 493 0.81 8,288 797,714 3

PyCaret 74,142 6,132 1,411 3,997 6 days 271 1,429 1,700 0.84 902,608 6,650,713 124

PyODDS 5,215 199 34 115 2 years 6 0 6 0 155

14,240 0

TPOT 12,233 8,705 1,498 2,390 21 days 252 605 857 0.71 47,993 1,650,310 9

SO = Stack Overﬂow. Data accurate as of the 19

of August 2022.

Might not be maintained,

Not updated since ﬁrst upload,

There are, however,

118 matches for “hyperopt” some of which have clear references to the package.

analysis was evaluated by examining the variables

with regard to the linearity of relationships, outliers,

and monotonicity. The relationships between each

of the 12 variables in Table 1 were determined to be

non-linear and some variables were not normally dis-

tributed or had outliers. Thus, Spearman rank correla-

tion was selected to measure the monotonicity of the

relationship between variables. To facilitate the incor-

poration of the 16 variables in Table 2, feature cate-

gorisations were converted into an ordinal encoding:

0 indicates a feature is not implemented, 0.5 indicates

some implementation with limitations and 1 indicates

a full implementation for general usage in an AutoML

pipeline. These functionality scores are subjective

and are used for comparative purposes only. For ex-

ample, the auto-sklearn library receives a score of 0.5

for DL as it only supports MLPs via scikit-learn. The

scores for each library or framework were summed

and included in the Spearman rank correlation anal-

ysis which is presented in Table 3 (a p value of 0.05

is assumed for all statistical testing). The Stack Over-

ﬂow (SO) Tag Count was excluded because the data

was sparse as many of the packages do not seem to

have an associated tag on SO.

The analysis presented in Table 3 offers insights

into the relationships between the aforementioned

variables. Lines of code strongly correlate with the

functionality score (0.77, p=3.03e − 05). This sug-

gests that repository size could be useful as a proxy

metric for total functionality coverage, although this

does not necessarily indicate the universal applicabil-

ity of functionality to all users. For example, the H20

library is by far the largest tool with 185,000 lines

of code, but some of the functionality is unrelated to

time series analysis, e.g. image preprocessing. As this

study focuses on time series forecasting and anomaly

detection, H2O’s functionality score is lower than

smaller but more specialised libraries such as ETNA.

The lines of code metric has a moderate correlation

with the number of GitHub commits (0.58, p=0.005)

which implies a large degree of variability in commit

size. There is a moderate correlation between func-

tionality score and the number of closed GitHub is-

sues (0.54, p=0.0091) and the total number of GitHub

issues (0.52, p=0.0122). While many closed issues

may be an indicator of functionality, the correlation

is weaker than with lines of code. A possible rea-

son is that not all closed issues result in code ﬁxes or

new features. Many GitHub issues relate to user ques-

tions, documentation changes or are simply closed by

maintainers. The 0.99 correlation (p=6.55e − 17) be-

tween total issues and closed issues may indicate re-

dundancy between the two variables. Similar redun-

dancy may exist between the PyPi download metrics;

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection

427

Table 2: AutoML Library/Framework Functionality.

Software Name Resource

Limits

Pre-

processing

Serialisation MOV Data

Augmentation

Feature

Engineering

Feature

Selection

Statistical

Models

AdaNet No No Yes Yes

No No No No

AutoGluon Time, presets Yes Yes Yes Yes Yes Yes No

AutoKeras No

Yes SO No Images Only Yes No No

Auto-PyTorch Time, memory Yes Yes Yes Resampling Yes Not for TS Not for

forecasting

auto-sklearn Time, memory,

CPU

Yes SO No Resampling Yes Yes No

AutoTS No Yes Yes Yes No Yes No Yes

ETNA No Yes No Yes Resampling Yes Yes Yes

EvalML Time Yes Yes Yes No Yes Yes Yes

FEDOT Time Yes Yes Yes No Yes No Yes

FLAML Time Yes SO No Not for TS No No Yes

H2O Time, memory Yes Yes Yes Not via API

Yes No Limited

Hyperopt-sklearn Time Yes No No No Yes No No

Kats No Yes Yes Yes Resampling

Yes Yes Yes

LightAutoML Time Yes SO Yes No Yes Yes No

Ludwig Time Yes Yes Yes No Not for TS No No

Meta-AAD No Yes Yes No No Yes N/A

MetaOD No Yes Yes No No Yes N/A

Yes

MLBox No Yes No No No Yes Yes No

mljar Time, modes Yes Yes Yes No Yes Yes No

PyCaret Time Yes Yes Yes No Yes Not for TS Yes

PyODDS No Yes No Yes No No No A.D. only

TPOT Time Yes SO No No Yes Yes No

AD = Anomaly Detection, MOV = Model Output Visualization, SO = returns Serialisable Object, TS = Time series.

Uses trials,

TensorBoard,

Possible via GUI,

Some resampling by statistical models and for the meta-learner,

uses meta-features,

Not in AutoML module, available otherwise

Software Name ML

Models

AD HO Architecture

Optimisation

TCV Formats

Data for TS

prediction

Multi-

output

prediction

AdaNet Yes

Yes No No Yes No No Yes

AutoGluon Yes Yes No Yes Yes No Yes Yes

AutoKeras No Yes No Yes Yes No Yes Yes

Auto-PyTorch No forecasting Yes No Yes Yes No Yes Yes

auto-sklearn Yes MLP* No Yes MLP only No No Yes

AutoTS Yes Yes No Yes No Yes Yes Yes

ETNA Yes Yes Outliers only Yes No Yes Yes Yes

EvalML Yes No No Yes No Yes Yes Yes

FEDOT Yes Yes No Yes No Yes Yes Yes

FLAML Yes Yes No Yes No No No Yes

H2O Yes Yes Supervised Yes No No Yes Yes

Hyperopt-sklearn Yes MLP* No Yes MLP only No Yes No

Kats Forecasting

only

Forecasting

only

Yes Yes Limited No Yes Yes

LightAutoML Yes No No Yes No Yes Yes No

Ludwig No Yes Binary Supervised Yes Yes No Yes Yes

Meta-AAD No Yes Semi-supervised No No No No No

MetaOD Yes No Semi-supervised Yes No No No No

MLBox Yes Encoders

only

No Yes No No No No

mljar Yes MLP* No Yes MLP only Custom

available

No No

PyCaret Yes MLP* Yes Yes MLP only Yes Yes Yes

PyODDS AD only AD only Supervised Yes Yes No Yes No

TPOT Yes Yes

No Yes No No No No

AD = Anomaly Detection, HO = Hyperparameter Optimisation, MLP = scikit-learn’s MLP class, TCV = Time-based Cross-Validation,

TS = Time series.

Linear Estimator,

They recommend custom validation,

In progress (https://github.com/EpistasisLab/tpot/pull/1001)

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

428

the monthly and total download ﬁgures have a corre-

lation of 0.93 (p=0.0007).

The GitHub issue close rate was included as a po-

tential proxy metric for developer engagement, but

it did not statistically signiﬁcantly correlate with the

other metrics in Table 3. One potential reason for the

lack of correlation is that some of the smaller libraries

have GitHub issue completion rates with high vari-

ability due to having few issues. The other GitHub-

related metrics of stars, forks, commits, open issues,

and closed issues all correlate strongly with each

other. There is a statistically signiﬁcant moderate cor-

relation between PyPi downloads from the last month

and the functionality score (0.47, p=0.0273). The rel-

ative weakness of the correlation may be caused by

the discrepancy between the time series-based func-

tionalities evaluated in this review versus the needs

of the broader research community, e.g. natural lan-

guage processing, and image classiﬁcation. The start-

ing year of a project on PyPi was originally consid-

ered as a metric but was excluded due to noisy data;

some packages were renamed or deprecated.

The H2O library has the largest codebase with ap-

proximately twice as many lines of code as the sec-

ond largest tool, i.e. EvalML. H2O also has the most

commits (>31,000), the largest GitHub issue comple-

tion rate (>98%), and the greatest number of total

downloads from PyPi (>17 million) although PyCaret

has the most downloads from the previous month

(>900,000).

Table 2 compares the 22 libraries in terms of func-

tionality. While this study weighs features equally,

users may value features differently, which would re-

sult in varying functionality scores. For example,

some may prefer statistical to DL models for time-

sensitive applications, whereas other users may only

use ML and DL models if their data experiences con-

cept drift. Under Resource Limits, it can be observed

that libraries offer varying constraints on model ex-

ploration via input parameters, e.g. not all libraries

support time limits but may instead rely on spec-

ifying the number of iterations which is less pre-

cise. H2O, auto-sklearn, and Auto-PyTorch also of-

fer memory limits which may prove beneﬁcial for

hardware-constrained environments such as micro-

controllers. All of the libraries except for AdaNet pro-

vide some level of pre-processing. Larger libraries are

not necessarily more popular amongst users as sug-

gested by the lack of a statistically signiﬁcant correla-

tion between lines of code and total downloads.

Data augmentation functions for time series are

uncommon except via resampling. While feature se-

lection is not supported by many of the libraries, it

is implicitly irrelevant for those using meta-features

(e.g. Meta-AAD, MetaOD). Some libraries such as

H2O do offer feature selection outside of their Au-

toML functionality. unsupervised anomaly detection

models are atypical although supervised implementa-

tions are more commonly supported (e.g. Ludwig and

PyODDS). Support for fully unsupervised anomaly

detection via metrics such as Excess-Mass is non-

existent. While PyCaret offers unsupervised anomaly

detection models, these require a contamination hy-

perparameter to be manually speciﬁed which may not

be possible for unseen data. The meta-learning mod-

ule in Kats can simulate labelled data but this may be

less effective than modelling using real data (Chatter-

jee et al., 2022).

Most of the libraries do not support AO outside of

scikit-learn’s CPU-based MLP classes despite NAS

being a popular research topic (He et al., 2021). Con-

versely, statistical models are less prominent in Au-

toML papers but there are several AutoML libraries

that offer implementations of statistical models in

some capacity (e.g. PyCaret and Kats). Most libraries

do not support time-based cross-validation.

5 CONCLUSIONS

The prevalence of time series data has motivated re-

search of statistical and ML approaches for forecast-

ing and anomaly detection. Time series data is com-

plex to model due to temporal correlations, a lack

of anomaly labels, high dimensionality from lagged

data, and the sheer volume of data being produced.

Statistical, ML and DL approaches have all been

shown to be effective time series models under dif-

ferent experimental conditions (Javeri et al., 2021).

AutoML approaches have beneﬁted from increased

attention from the research community (Xu et al.,

2017), but there are still open problems around efﬁ-

ciency compared to more basic approaches (He et al.,

2021). While AutoML has been applied to time series

forecasting and anomaly detection, most AutoML re-

search appears to have been applied to more popular

research problems such as image and language mod-

elling (He et al., 2021), necessitating a comprehensive

review of how effective existing AutoML tools are for

time series modelling.

The Python programming environment contains

many software libraries that can be used for effec-

tive data preprocessing, feature selection, ML and

DL modelling, etc. As AutoML tools offer varying

degrees of automation and relevancy to time series

modelling, this paper presents a review of 22 such

libraries across 28 metrics. The lines of code met-

ric correlates strongly with a functionality score de-

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection

429

Table 3: Spearman Rank Correlations on AutoML Tool Statistics.

Metric

Lines of

Code

Repository Activity GitHub Issues PyPi Downloads Func.

ScoreStars Forks Commits Open Closed Total Close Rate Last Month Total

Lines of Code - 0.38 0.41 0.58 0.47 0.65 0.61 0.29 0.42 0.32 0.77

Stars 0.38 - 0.96 0.77 0.70 0.72 0.73 0.04 0.69 0.70 0.16

Forks 0.41 0.96 - 0.84 0.70 0.77 0.79 0.05 0.74 0.77 0.17

Commits 0.58 0.77 0.84 - 0.84 0.92 0.91 0.15 0.64 0.64 0.38

Open Issues 0.47 0.70 0.70 0.84 - 0.86 0.89 -0.01 0.54 0.58 0.40

Closed Issues 0.65 0.72 0.77 0.92 0.86 - 0.99 0.36 0.66 0.60 0.54

Total Issues 0.61 0.73 0.79 0.91 0.89 0.99 - 0.25 0.67 0.63 0.52

Close Rate 0.29 0.04 0.05 0.15 -0.01 0.36 0.25 - 0.19 0.08 0.25

Downloads Last Month 0.42 0.69 0.74 0.64 0.54 0.66 0.67 0.19 - 0.93 0.47

Total Downloads 0.32 0.70 0.77 0.64 0.58 0.60 0.63 0.08 0.93 - 0.27

Functionality Score 0.77 0.16 0.17 0.38 0.40 0.54 0.52 0.25 0.47 0.27 -

Functionality scores are derived from Table 2: 0=not implemented, 0.5=partially implemented, 1=fully implemented. Statistically signiﬁcant (p ≤ 0.05)

results are presented in bold and strong correlations are underlined. Correlations (?): <0.1 = Negligible, 0.1-0.39 = Weak,

0.4-0.69 = Moderate, 0.7-0.89 = Strong, ≥0.9 = Very Strong

rived from a quantitative analysis of features (0.77,

p=3.03e − 05). Some other metrics proved to be less

useful for the correlation-based analysis employed in

this study. For example, the GitHub issue completion

rate did not correlate signiﬁcantly with any other met-

ric. The repository-related metrics such as the number

of stars, forks, etc. correlated most strongly with each

other which may suggest redundancy. A limitation of

the approach taken in this work is that the method of

scoring functionality is manual and is therefore time-

consuming and open to human error.

AutoML libraries are lacking in terms of fully un-

supervised anomaly detection using metrics such as

Mass-Volume and Excess-Mass curves (Goix, 2016).

Approaches that use unsupervised models rely on

synthetic data or manually speciﬁed hyperparameters

indicating the proportion of expected anomalies.

The presented evaluation could be deepened by

the use of automatic code quality scanning tools

such as SonarQube (SonarQube, 2022) or GitHub’s

(Github, 2022) Dependabot for identifying security

issues, bugs, test coverage, portability issues, and cy-

clomatic complexity. The measures chosen in this

study do not directly capture the documentation qual-

ity of each software tool, but clone detection and cov-

erage analysis have been proposed in other studies

(Wingkvist et al., 2010). The number of academic

citations relating to a project may be a useful met-

ric for future works, although this is limited to mea-

suring the activity of publishing researchers and may

exclude many industry-based practitioners. Alterna-

tive metrics for analysis could also include the date of

the ﬁrst commit on GitHub to indicate project lifespan

or a ’time-to-ﬁx’ metric where start and end dates of

GitHub issues are used to assess maintainer activity.

Another avenue for future work could compare the

aforementioned libraries via empirical analysis across

a range of common time series datasets for forecast-

ing and anomaly detection. ML models can have

long training times and are highly energy-intensive

(Lacoste et al., 2019). Empirical experiments could

therefore be expanded to evaluate the environmental

impact of training ML models via proxy metrics such

as CPU/GPU usage or computation runtimes.

ACKNOWLEDGEMENTS

The authors acknowledge the contribution of Morgain Siede

for guidance on statistical analysis. Thanks are extended to

MTU for their support via the Recurrent Funding Allocation

Model (RFAM) program.

REFERENCES

Abadi, M., Agarwal, A., Barham, P., Brevdo, E., Chen,

Z., Citro, C., and Corrado, G. S. (2015). Tensor-

Flow: Large-Scale Machine Learning on Heteroge-

neous Distributed Systems.

Ahmad, S., Lavin, A., Purdy, S., and Agha, Z. (2017). Un-

supervised real-time anomaly detection for streaming

data. Neurocomputing, 262.

Ali, M. (2020). PyCaret.

Alteryx (2022). Evalml.

Amarasinghe, K., Kenney, K., and Manic, M. (2018).

Toward Explainable Deep Neural Network Based

Anomaly Detection. In 11th Intl. Conf. on Human

System Interaction. IEEE.

Bahri, M., Salutari, F., Putina, A., and Sozio, M. (2022).

AutoML: state of the art with a focus on anomaly de-

tection, challenges, and research directions. Intl. Jour-

nal of Data Science and Analytics, 14.

Bergmann, D., Connor, D., and Thuemmel, A. (2018). An

Evaluation Of Point And Density Forecasts For Se-

lected Eu Farm Gate Milk Prices. Intl. Journal of Food

and Agricultural Economics, 6.

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

430

Bergstra, J. and Bengio, Y. (2018). Random Search for

Hyper-Parameter Optimization. Journal of Machine

Learning Research, 13.

Borovykh, A., Bohte, S., and Oosterlee, C. W. (2018). Con-

ditional Time Series Forecasting with Convolutional

Neural Networks. arXiv:1703.04691 [stat].

Catlin, C. (2022). AutoTS.

Chatterjee, S., Bopardikar, R., Guerard, M., Thakore, U.,

and Jiang, X. (2022). MOSPAT: AutoML based

Model Selection and Parameter Tuning for Time Se-

ries Anomaly Detection. arXiv:2205.11755.

Chen, T., Li, M., Li, Y., Lin, M., Wang, N., Wang, M., and

Xiao, T. (2015). Mxnet.

Cho, K., van Merrienboer, B., Gulcehre, C., Bahdanau,

D., Bougares, F., Schwenk, H., and Bengio, Y.

(2014). Learning Phrase Representations using RNN

Encoder-Decoder for Statistical Machine Translation.

Choudhary, D., Kejariwal, A., and Orsini, F. (2017). On

the Runtime-Efﬁcacy Trade-off of Anomaly Detection

Techniques for Real-Time Streaming Data.

Cortes, C., Gonzalvo, X., Kuznetsov, V., Mohri, M., and

Yang, S. (2017). AdaNet: Adaptive Structural Learn-

ing of Artiﬁcial Neural Networks. In Proc. of the 34th

Intl. Conf. on Machine Learning.

De Romblay, A. (2022). MLBox.

Erickson, N., Mueller, J., Shirkov, A., Zhang, H., Larroy,

P., Li, M., and Smola, A. (2020). AutoGluon-Tabular:

Robust and Accurate AutoML for Structured Data.

Facebook (2022). Prophet.

Feurer, M., Eggensperger, K., Falkner, S., Lindauer, M., and

Hutter, F. (2021). Auto-Sklearn 2.0.

Flynn, C. (2022). PyPI Stats.

Francois, C. (2022). Keras: the Python deep learning API.

Ghaderi, H. and Kabiri, P. (2012). Fourier transform and

correlation-based feature selection for fault detection

of automobile engines. In The 16th CSI Intl. Sympo-

sium on Artiﬁcial Intelligence and Signal Processing.

Github (2022). Github.

Goix, N. (2016). How to Evaluate the Quality

of Unsupervised Anomaly Detection Algorithms?

arXiv:1607.01152.

Grimes, D., Ifrim, G., O’Sullivan, B., and Simonis, H.

(2014). Analyzing the impact of electricity price fore-

casting on energy cost-aware scheduling. Sustainable

Computing: Informatics and Systems, 4.

urtler, M. and Paulsen, T. (2018). The effect of wind and

solar power forecasts on day-ahead and intraday elec-

tricity prices in Germany. Energy Economics, 75.

H2O (2022). H2O.ai.

He, X., Zhao, K., and Chu, X. (2021). AutoML: A survey of

the state-of-the-art. Knowledge-Based Systems, 212.

Hesterman, J. Y., Caucci, L., Kupinski, M. A., Barrett,

H. H., and Furenlid, L. R. (2010). Maximum-

Likelihood Estimation With a Contracting-Grid

Search Algorithm. IEEE Trans. on Nuclear Science.

Hochreiter, S. and Schmidhuber, J. (1997). Long Short-term

Memory. Neural computation, 9.

Hundman, K., Constantinou, V., Laporte, C., Colwell, I.,

and Soderstrom, T. (2018). Detecting Spacecraft

Anomalies Using LSTMs and Nonparametric Dy-

namic Thresholding. Proc. of the 24th ACM SIGKDD

Intl. Conf. on Knowledge Discovery & Data Mining.

Ioffe, S. and Szegedy, C. (2015). Batch Normalization: Ac-

celerating Deep Network Training by Reducing Inter-

nal Covariate Shift. arXiv:1502.03167 [cs].

Ismail Fawaz, H., Forestier, G., Weber, J., Idoumghar, L.,

and Muller, P.-A. (2019). Deep learning for time series

classiﬁcation: a review. Data Mining and Knowledge

Discovery, 33.

Javeri, I. Y., Toutiaee, M., Arpinar, I. B., Miller, J. A., and

Miller, T. W. (2021). Improving Neural Networks

for Time-Series Forecasting using Data Augmentation

and AutoML. In 2021 IEEE Seventh Intl. Conf. on Big

Data Computing Service and Applications.

Jin, H., Song, Q., and Hu, X. (2019). Auto-Keras: An Ef-

ﬁcient Neural Architecture Search System. In 25th

Conf. on Knowledge Discovery & Data Mining. As-

sociation for Computing Machinery.

Kavanagh, K., Barrett, M., and Conlon, M. (2017). Short-

term electricity load forecasting for the integrated sin-

gle electricity market (I-SEM). In 2017 52nd Intl.

Universities Power Engineering Conf.

Kaytez, F., Taplamacioglu, M. C., Cam, E., and Hardalac, F.

(2015). Forecasting electricity consumption: A com-

parison of regression analysis, neural networks and

least squares support vector machines. Intl. Journal

of Electrical Power & Energy Systems, 67.

Kim, Y., Wang, P., Zhu, Y., and Mihaylova, L. (2018). A

Capsule Network for Trafﬁc Speed Prediction in Com-

plex Road Networks. arXiv:1807.10603.

Komer, B., Bergstra, J., and Eliasmith, C. (2019).

Hyperopt-Sklearn. In Automated Machine Learning:

Methods, Systems, Challenges.

Lacoste, A., Luccioni, A., Schmidt, V., and Dandres, T.

(2019). Quantifying the Carbon Emissions of Ma-

chine Learning.

Lago, J., De Ridder, F., and De Schutter, B. (2018). Fore-

casting spot electricity prices: Deep learning ap-

proaches and empirical comparison of traditional al-

gorithms. Applied Energy, 221.

Li, Y., Chen, Z., Zha, D., Zhou, K., Jin, H., Chen, H.,

and Hu, X. (2020a). AutoOD: Automated Outlier De-

tection via Curiosity-guided Search and Self-imitation

Learning.

Li, Y., Zha, D., Venugopal, P., Zou, N., and Hu, X. (2020b).

PyODDS: An End-to-end Outlier Detection System

with Automated Machine Learning. In Companion

Proc. of the Web Conf.

LinkedIn (2022). Luminol.

Lu, Y. and Xu, L. D. (2019). Internet of Things (IoT) Cy-

bersecurity Research: A Review of Current Research

Topics. IEEE Internet of Things Journal, 6.

Lynch, C., Kehoe, J., Bain, R., Zhang, F., Flynn, J.,

O’Leary, C., and Smith, G. (2019). Application of a

SVM-based model for day-ahead electricity price pre-

diction for the single electricity market in Ireland. In

39th Intl. Symposium on Forecasting.

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection

431

Lynch, C., O’Leary, C., Smith, G., Bain, R., Kehoe, J.,

Vakaloudis, A., and Linger, R. (2020). A review of

open-source machine learning algorithms for twitter

text sentiment analysis and image classiﬁcation. In

Intl. Joint Conf. on Neural Networks.

Lynch, C., O’Leary, C., Sundareshan, P. G. K., and Akin,

Y. (2021). Experimental Analysis of GBM to Expand

the Time Horizon of Irish Electricity Price Forecasts.

Energies, 14.

Meta (2022). Kats.

Molino, P., Dudin, Y., and Miryala, S. S. (2019). Ludwig.

Nguyen, Q. T., Fouchereau, R., Fr

enod, E., Gerard, C., and

Sincholle, V. (2020). Comparison of forecast mod-

els of production of dairy cows combining animal and

diet parameters. Computers and Electronics in Agri-

culture, 170.

Nikitin, N. O., Vychuzhanin, P., Sarafanov, M., Polonskaia,

I. S., Revin, I., Barabanova, I. V., and Maximov, G.

(2022). Automated evolutionary approach for the de-

sign of composite machine learning pipelines. Future

Generation Computer Systems, 127.

NVIDIA (2017). CUDA Zone.

O’Leary, C. (2020). Capsule Networks for Electricity Price

Forecasting. Master’s thesis, MTU.

O’Leary, C. and Lynch, C. (2022). An Evaluation of Ma-

chine Learning Approaches for Milk Volume Predic-

tion in Ireland. In Irish Signals and Systems Conf.

O’Leary, C., Lynch, C., Bain, R., Smith, G., and Grimes,

D. (2021). A Comparison of Deep Learning vs Tra-

ditional Machine Learning for Electricity Price Fore-

casting. In 2021 4th Intl. Conf. on Information and

Computer Technologies. IEEE.

Olson, R. S., Bartley, N., Urbanowicz, R. J., and Moore,

J. H. (2016). Evaluation of a Tree-based Pipeline Op-

timization Tool for Automating Data Science. In Proc.

of the Genetic and Evolutionary Computation Conf.

Paszke, A., Gross, S., Chintala, S., Chanan, G., Yang, E.,

DeVito, Z., and Lin, Z. (2017). Automatic differenti-

ation in PyTorch.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., and Blondel, M. (2011).

Scikit-learn: Machine Learning in Python. Journal

of Machine Learning Research.

Plonska, A. and Pło

nski, P. (2021). MLJAR.

PyPI (2022). The Python Package Index.

Python (2022). Python.org.

Qiu, J., Wu, Q., Ding, G., Xu, Y., and Feng, S. (2016). A

survey of machine learning for big data processing.

EURASIP Journal on Advances in Signal Processing.

Santurkar, S., Tsipras, D., Ilyas, A., and Madry, A. (2019).

How Does Batch Normalization Help Optimization?

arXiv:1805.11604.

Seabold, S. and Perktold, J. (2010). Statsmodels: Econo-

metric and Statistical Modeling with Python. Proc. of

the 9th Python in Science Conf.

Singh, N. and Mohanty, S. R. (2015). A Review of Price

Forecasting Problem and Techniques in Deregulated

Electricity Markets. Journal of Power and Energy En-

gineering, 03.

Smith, T. (2017). ARIMA estimators for Python.

SonarQube (2022). Code Quality and Code Security.

StackOverﬂow (2021). Stack Overﬂow Developer Survey.

Thessen, A. (2016). Adoption of Machine Learning Tech-

niques in Ecology and Earth Science. One Ecosystem.

Tinkoff.AI (2022). Etna.

Ugurlu, U., Oksuz, I., and Tas, O. (2018). Electricity Price

Forecasting Using Recurrent Neural Networks. Ener-

gies, 11.

Vakhrushev, A., Ryzhkov, A., Savchenko, M., Simakov, D.,

Damdinov, R., and Tuzhilin, A. (2022). LightAu-

toML: AutoML Solution for a Large Financial Ser-

vices Ecosystem.

Wang, C., Wu, Q., Weimer, M., and Zhu, E. (2021).

FLAML: A Fast and Lightweight AutoML Library.

Wang, L., Zhang, Z., and Chen, J. (2017). Short-Term Elec-

tricity Price Forecasting With Stacked Denoising Au-

toencoders. IEEE Trans. on Power Systems, 32.

Warzynski, A., Falas, L., and Schauer, P. (2021). Excess-

Mass and Mass-Volume anomaly detection algorithms

applicability in unsupervised intrusion detection sys-

tems. In IEEE 30th Intl. Conf. on Enabling Technolo-

gies: Infrastructure for Collaborative Enterprises.

Wingkvist, A., Ericsson, M., Lincke, R., and L

owe, W.

(2010). A Metrics-Based Approach to Technical Doc-

umentation Quality. In 2010 7th Conf. on the Quality

of Information and Communications Technology.

Wu, J., Zeng, W., and Yan, F. (2018). Hierarchical Tem-

poral Memory method for time-series-based anomaly

detection. Neurocomputing, 273.

Xu, D., Wang, Y., Meng, Y., and Zhang, Z. (2017). An

Improved Data Anomaly Detection Method Based on

Isolation Forest. In 2017 10th Intl. Symposium on

Computational Intelligence and Design, volume 2.

Yu, L., Liu, L., Pu, C., Gursoy, M. E., and Truex, S.

(2019). Differentially Private Model Publishing for

Deep Learning. Symposium on Security and Privacy.

Zha, D., Lai, K.-H., Wan, M., and Hu, X. (2020). Meta-

AAD: Active Anomaly Detection with Deep Rein-

forcement Learning.

Zhang, F., Shine, P., Upton, J., Shaloo, L., and Murphy,

M. D. (2018). A Review of Milk Production Forecast-

ing Models: Past & Future Methods. In Dairy farming

operations management, animal welfare and milk pro-

duction.

Zhang, F., Upton, J., Shalloo, L., Shine, P., and Murphy,

M. D. (2020). Effect of introducing weather parame-

ters on the accuracy of milk production forecast mod-

els. Information Processing in Agriculture, 7.

Zhang, X., Xu, Y., Lin, Q., Qiao, B., Zhang, H., Dang, Y.,

and Xie, C. (2019). Robust log-based anomaly detec-

tion on unstable log data. In Joint Meeting on Euro-

pean Software Engineering Conf. and Symposium on

the Foundations of Software Engineering. ACM.

Zhao, Y., Nasrullah, Z., and Li, Z. (2022). PyOD: A Python

Toolbox for Scalable Outlier Detection.

Zhao, Y., Rossi, R. A., and Akoglu, L. (2021). Automating

Outlier Detection via Meta-Learning.

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

432

Zimmer, L., Lindauer, M., and Hutter, F. (2021). Auto-

Pytorch: Multi-Fidelity MetaLearning for Efﬁcient

and Robust AutoDL. IEEE Trans. on Pattern Anal-

ysis and Machine Intelligence, 43.

A Review of AutoML Software Tools for Time Series Forecasting and Anomaly Detection

433
