Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants

M. Umlauft

, M. Gojkovic, K. Harshina and M. Schranz

Lakeside Labs GmbH, Klagenfurt, Austria

Keywords:

Swarm Intelligence, Bio-Inspired Algorithm, Bee Algorithm, Bat Algorithm, Flexible Job-Shop Scheduling,

Agent-Based Modeling.

Abstract:

Scheduling in a production plant with a high product diversity is an NP-hard problem. In large plants, tradi-

tional optimization methods reach their limits in terms of computational time. In this paper, we use inspiration

from two bio-inspired optimization algorithms, namely, the artiﬁcial bee colony (ABC) algorithm and the bat

algorithm and apply them to the job shop scheduling problem. Unlike previous work using these algorithms

for global optimization, we do not apply them to solutions in the solution space, though, but rather choose a

bottom-up approach and apply them as literal swarm intelligence algorithms. We use the example of a semi-

conductor production plant and map the bees and bats to actual entities in the plant (lots, machines) using

agent-based modeling using the NetLogo simulation platform. These agents then interact with each other and

the environment using local rules from which the global behavior – the optimization of the industrial plant

– emerges. We measure performance in comparison to a baseline algorithm using an engineered heuristics

(FIFO, ﬁll fullest batches ﬁrst). Our results show that these types of algorithms, employed in a bottom-up

manner, show promise of performance improvements using only low-effort local calculations.

1 INTRODUCTION

In today’s production plants organized by the job shop

principle we face an increased complexity in schedul-

ing due to the dynamics of customized, ﬂexible, on-

demand production combined with a high product di-

versity. Throughout this paper, we consider the semi-

conductor manufacturer Inﬁneon Technologies

that

additionally deals with typical low-volume batches

of integrated circuits in the logic and power sector.

Exemplary, they produce 1500 products in around

300 process steps using up to 1200 stations (Schranz

et al., 2021; Khatmi et al., 2019). These production

plant conditions lead to an NP-hard problem where

linear optimization methods reach their limits for a

global plant optimization due to the excessive com-

putation time (Lawler et al., 1993). Centrally pre-

computed swarm intelligence algorithms have already

been used for the optimization of industrial produc-

tion plants. They show good performances and thus,

are used as an alternative or extension for linear op-

timization methods (for a comprehensive review, the

reader is referred to Gao et al. (Gao et al., 2019)).

Nevertheless, they face the same problems in terms

https://orcid.org/0000-0002-0118-2817

https://orcid.org/0000-0002-0714-6569

Inﬁneon Technologies, https://www.inﬁneon.com/

of calculation time and complexity (Khatmi et al.,

2019). As proposed in (Schranz et al., 2021), we use

the novel approach to model the production plant as

a self-organizing system of agents, using local rules,

local knowledge and local interactions. This transfers

the problem of computing an overall solution to en-

gineering a distributed algorithm that produces a so-

lution from the bottom-up. An optimization from the

bottom-up is able to dynamically react on changing

environmental conditions (e.g., tool downs, product

priorities) and to produce near-optimal solutions for

NP-hard problems.

In this paper, honeybees and microbats serve as in-

spiration to derive two distributed swarm intelligence

algorithms. Honeybees live in a colony, search for

pollen, and transport it back to their hive. To attract

other bees for the same food source, they perform a

waggle dance that shows the direction and distance to

the food source. They also use pheromones to com-

municate a possible attack. Microbats use echoloca-

tion signals to search for nearby prey. They update

the loudness, rate of pulse and the frequency of the

signal based on the distance of the bats to the prey.

Our contribution is related to exactly this natural bee

and bat behaviour originally designed as the artiﬁcial

bee colony algorithm (ABC) (Karaboga and Basturk,

2007) and the bat algorithm (Yang, 2010), but engi-

Umlauft, M., Gojkovic, M., Harshina, K. and Schranz, M.

Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants.

DOI: 10.5220/0011693400003393

In Proceedings of the 15th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2023) - Volume 1, pages 59-70

ISBN: 978-989-758-623-1; ISSN: 2184-433X

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

neered onto the problem of the semiconductor pro-

duction plant. For the ﬁrst time, the ABC and the bat

algorithm are not used as a centrally computed op-

timization approach, but rather the rules are adapted

and used as local rules to perform the optimization

from the bottom-up. In this paper we introduce a

model of the production plant and the problem to op-

timize in Section 2. In Section 3, we describe the

general, global optimizer version of the ABC and bat

algorithms and their main characteristics. Then, we

use the novel approach of bottom-up production plant

optimization by engineering the ABC and bat algo-

rithms to the problem statement (Section 4), and eval-

uate the resulting algorithms in a NetLogo framework

to show their performance compared to an engineered

baseline algorithm using FIFO queues and ﬁll-least-

empty-batch ﬁrst principles (Section 5). The paper is

closed out with sections on related work (Section 6)

and the conclusion (Section 7).

2 MODEL

We model the semiconductor production plant as fol-

lows: there are a number of so-called lots L

, l

, . . . } (comprised of 25 wafers each), which

need to be produced. The lots follow a speciﬁc recipe

related to their product type t. This recipe pre-

scribes which process steps P = {p

, p

, . . . } to take

in which order. The plant has a set of machines M

where m indicates the machine type that is related to

the process step P

. Each machine M

has a queue

. In conclusion, the recipes imply a directed graph

G = (V, E) of possible movements between the ma-

chines of the plant, where the nodes V consist of all

machines M

and the edges E are deﬁned between

two machines M

and M

if there exists a lot l

with

a recipe R

containing processes P

and P

in direct

succession. A set of machines M

that can run the

same process P

form a workcenter W

⊂ M. The

modeled production plant contains several workcen-

ters of machines W

= {M

, M

, . . . }. As there typi-

cally are multiple machines per workcenter W

, a lot

must choose which (or be assigned to one) of the

suitable machines M

∈ W

to use for each necessary

process step P

∈ R

. The machines M

can be one

of two kinds: either single-step (processing one lot

after the other), or batch-oriented (processing a batch

of several lots at once, such as a furnace). In a pro-

duction cycle, single-step and batch machines follow

each other. This makes optimization especially hard

because in the optimal case batch machines would

like to accumulate a full batch of lots of a product type

before starting their process. If these lots are all in the

same queue of one of the preceeding single-step ma-

chines, the batch machine would have to either wait

a long time to ﬁll the batch or to run with a partially

ﬁlled batch to avoid idling. Conversely, for single-

step machines theory suggests that high utilization is

only possible when arrival times are uniform (Stid-

ham Jr, 2002). I.o.w. single-step machines would op-

timally be “fed” by a stream of lots with an evenly

spaced arrival rate instead of waves of lots from pre-

ceeding batch machines. Therefore, these switches

between batch and single-step processing introduces

so-called WIP (work in progress) waves between ma-

chines which are a major obstacle to production opti-

mization.

3 ORIGINAL ALGORITHMS

3.1 The ABC Algorithm

The artiﬁcial bee colony (ABC) algorithm is inspired

by the foraging behavior of honeybees introduced in

(Karaboga and Basturk, 2007; Karaboga, 2010) for

the optimization of numerical problems. It uses typ-

ical swarm concepts: recruitment of foragers to rich

food sources resulting in positive feedback and aban-

donment of poor sources by foragers causing negative

feedback. For the ABC you consider an optimization

problem that is ﬁrst converted to the problem of ﬁnd-

ing the best parameter vector, which minimizes an ob-

jective function. It uses different kinds of agents:

• Food source: is described with several parame-

ters, including distance and orientation to the nest,

quality of the food and concentration, and ease of

extracting the food.

• Employed foragers: are bees that are associated

with the food source they are “employed” at. They

hold the information about the food source they

are associated with (distance and orientation from

the nest). They share the information of the food

source with a certain probability by performing

so-called waggle dances. For each food source

there is only one employed bee (number of em-

ployed bees equals the number of food sources).

• Unemployed foragers: are bees that continuously

look for a food source. We differ between (1)

scouts that search for a new food source in the sur-

rounding of the nest, and (2) onlookers that wait in

the nest and get information about the food source

from the employed foragers. They watch several

waggle dances by employed foragers and decide

on the most proﬁtable source.

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

Generally, the ABC algorithm as global optimizer has

following steps (for more formal details, the reader is

referred to (Karaboga, 2010)):

Algorithm 1: ABC as global optimizer.

1: Initialization Phase (population of the food

source)

2: repeat

3: Employed Bees Phase

4: Onlooker Bees Phase

5: Scout Bees Phase

6: Memorize the best solution

7: until Cycle = Maximum Cycle Number or a Max-

imum CPU time

Several research works already used the ABC

algorithm in job scheduling applications (see Sec-

tion 6). Summarized, they typically use population

of bees that present a solution space, and make cal-

culations centrally. Instead, in this paper, we do not

create a solution space, but rather choose the bottom-

up approach, where bees represent agents (instead of

solutions) that work with local rules from which a

global behavior (optimization of the industrial plant)

emerges. Thus, we follow a completely new approach

of the ABC algorithm application.

3.2 The Bat Algorithm

The bat algorithm was ﬁrst introduced in (Yang, 2010)

and was inspired by the behavior of microbats that use

echolocation to detect and hunt their prey. Like other

metaheuristic nature-inspired algorithms, it is primar-

ily used for optimization problems. The algorithm is

based on three idealized rules of the behavior of mi-

crobats:

1. Bats use echolocation to measure the distance to

the prey.

2. Bats move with a velocity v

at a certain position

with a ﬁxed frequency f

min

and they can adjust

the loudness A

and the rate of pulse r ∈ [0, 1] of

their signal depending on their proximity to the

prey.

3. The loudness of the emitted signal varies from

maximum A

to minimum A

min

, depending on the

proximity of the bat to the prey.

The movement and frequency of the bats are de-

scribed by equations 1 – 3. The ﬁrst equation denotes

the pulse frequency f

of the signal, where β ∈ [0, 1] is

a vector drawn from a uniform distribution. The up-

date rules for the positions x

and velocities v

of bats

are deﬁned by Equations 2 and 3. The positions and

velocities are updated at every time step t. In Equa-

tion 2, x

∗

denotes to the best current global solution.

= f

min

+ ( f

max

− f

min

) · β (1)

= v

t−1

+ (x

− x

∗

) · f

(2)

= x

t−1

+ v

(3)

Once the current best global solution is found, a

new solution for each bat is generated by a random

walk. Equation 4 describes how the new solution is

achieved, where ε ∈ [−1, 1] is a random number and

is the average loudness of bats at the current time

step.

new

= x

old

+ εA

(4)

The loudness A

of the emitted signal and the pulse

rate r

are updated according to Equations 5 and 6,

where α and γ are constant values. The loudness de-

creases the closer the bat is to its prey. On the con-

trary, the pulse rate increases when the bat homes in

on the target. The pseudo code for the original bat

algorithm is described in Algorithm 2.

t+1

= A

· α (5)

t+1

= r

· [1 − exp(−γt)] (6)

Just as with the ABC algorithm, the original bat

algorithm is applied to the problems within the solu-

tion space and is used as a global optimizer. For the

objective of our problem adjustments have been made

to adapt the algorithm to the bottom-up approach.

Algorithm 2: Bat algorithm as global optimizer.

1: Initialization Phase (initialization of the bat pop-

ulation x

, objective function f(x), frequency f

, pulse rate r

, velocity v

and loudness A

)

2: repeat

3: Generate new solutions by adjusting position

, frequency f

and velocity v

according to

Equations 1 – 3

4: Evaluate solutions and select the best one

5: Generate new local solution around the best

solution

6: Generate new random solution (random ﬂy)

7: Adjust loudness A

and pulse rate r

8: Select the best solution x

∗

9: until Cycle = Maximum Cycle Number or a Max-

imum CPU time

Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants

4 THE ALGORITHMS IN A

BOTTOM-UP APPROACH

4.1 The ABC Algorithm

For the needs of our use case of production schedul-

ing, the following mapping has been chosen:

• food source = machine, M

∈ W

, i = 1, 2, . . . , I

• bees = lot from one product, l

∈ L

, n = 1, 2, . . . , N

where machine M

belongs to a workcenter W

⊂ M

and M represents all machines in the fab. Each lot

∈ L

has access to its R

(sequence of process steps

) and thus, a list of the machines that are used by

the lot.

Therefore lots, which we modeled as bees, need

to choose the next machine M

out of the set W

to perform their next process P

∈ R

. For this, it is

important to distinguish between l

modeled as scout

bee l

and onlooker bee l

, due to each lot type

choosing machines differently.

The scout bees are those that explore the food

sources. They share their experience and knowledge

of food quality with all other bees. In the beginning of

our simulation, there is no a-priori quality knowledge

of any machine. For this reason, our simulation starts

with the Scout Bees Phase, due to scout bees selecting

their food source randomly. This leads to l

modeled

as l

starting the search for their machines ﬁrst, to

collect quality information. The collected informa-

tion will be later used to attract l

. Upon ﬁnishing

the process P

∈ R

at the chosen machine M

∈ W

will evaluate the quality of the machine M

fol-

lowing Equation 7:

Q(M

) =

(7)

where w

represents queuing time and processing

time of a previous l

that has chosen machine M

∈

to perform its next process P

∈ R

. Therefore,

the longer it took machine M

to process the previous

, the lower the quality Q(M

) will be.

Unlike the original ABC algorithm, in our model

of the industrial use case, there is no employed bee

concept as such, due to all l

, only moving forward

and not coming back to the hive to bring the infor-

mation about machines (i.e., to perform the waggle

dance). Instead, we model this function of an em-

ployed bee as the machine’s own memory of its qual-

ity communicated by the l

. Lots modeled as on-

looker bees, i.e. l

, and interested in having their

process performed on one of the machines M

∈ W

can access the machines’ memory and read the quality

information left by the l

. Therefore, our model uses

stigmergy as communication media, i.e., no messages

are exchanged among the swarm members.

Once l

provides quality information of possible

next machines, l

will probabilistically choose the

best-quality machine. The probability P

) with

which l

choose the best solution, which is one M

out of the set W

, is described in (Karaboga, 2010)

and given as follows:

) =

ﬁt(M

)

∑

i=1

ﬁt(M

)

(8)

where ﬁt(M

) denotes the ﬁtness value of ma-

chine M

over the sum of ﬁtness values of all I ma-

chines in workcenter W

In the original ABC algorithm, bees in the Em-

ployed Bees Phase try to ﬁnd a new better solution

in the neighborhood of an existing solution. The new

solution is generated randomly and then compared to

the existing one. If the newly selected food source has

better quality, greedy selection will be applied.

In our adaptation, in the Employed Bees Phase the

neighborhood consists of lots waiting in Q

of a cho-

sen M

. Namely, when lots choose their preferred

∈ W

they are put in Q

to wait for their pro-

cessing turn. By default, the l

at the beginning of the

will be processed ﬁrst, following a simple First-

In First-Out algorithm. In our model, when queued

and in case their next step P

∈ R

corresponds to a

batch machine, all such lots enter the Employed Bees

Phase. The reasoning for this is the different mode of

processing of single-step and batch machines. Since

batch machines wait for a certain time period for lots

to accumulate, it may happen that there are some lots

that could have ﬁlled the batch machine if they had

been processed ﬁrst at the previous single-step ma-

chine.

Lastly, in the original ABC algorithm, employed

bees abandon their food sources due to the food

source having poor quality or becoming poor quality

due to excessive exploitation. As already stated be-

fore, in our model there is no concept of an employed

bee, therefore we use a predeﬁned limit value l that

serves as a machine’s quality value timeout. After a

certain number of onlooker lots l

have visited and

exploited the chosen M

∈ W

, its quality Q(M

)

will have to be re-evaluated by another l

In contrast to the original ABC algorithm, our

variant implements different phases wrt. the differ-

ent process steps in R

of l

. For each processing step

in R

, the l

moves from M

to M

, and go through

the following steps:

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

Algorithm 3: Bottom-up ABC.

1: Initialization Phase (population of lots and ma-

chines)

2: repeat

3: switch m

→ m

4: case 0 → SingleStep:

Scout Bees Phase;

Onlooker Bees Phase;

5: case 0 → Batch:

Scout Bees Phase;

Onlooker Bees Phase;

6: case SingleStep → SingleStep:

Scout Bees Phase;

Onlooker Bees Phase;

7: case SingleStep → Batch:

Employed Bees Phase;

8: case Batch → Batch:

Scout Bees Phase;

Onlooker Bees Phase;

9: case Batch → SingleStep:

Scout Bees Phase;

10: until all lots have found their last machine

4.1.1 Initialization Phase

Firstly, a number of lots and machines in a fab is set,

as well as the limit l after which a machine’s quality

will have to be updated. The machine’s memory gets

initialized as well.

4.1.2 Case 0 to SingleStep

At the beginning of our simulation, there is no a-

priori information on machines, as already explained.

Therefore lots that are ﬁrst to choose a machine M

∈

, must do it without comparing their quality value

given that it does not exist yet. For this reason, ﬁrstly

are allocated. After the machine M

processes

them, it will be evaluated by the l

. Once all ma-

chines in W

had been evaluated, the Onlooker Bees

Phase will begin. Namely, l

will choose probabilis-

tically, the best one from the W

4.1.3 Case 0 to Batch

Given the difference in the mode of operation for both

single-step and batch machines, the implementation

of the concept described above is slightly changed.

Namely, instead of calculating the machine’s quality

as in Equation 7, after a random l

allocation, l

lots will choose M

∈ W

as follows: Firstly, all ma-

chines in W

that already have some other lots in their

queues of the same product type (i.e., belonging to the

same group L

), will be inspected. Then a number of

free places n

(until the full batch) in such machines,

will be counted. If there is a batch-oriented machine

∈W

with n

= 1, the lot l

will choose this ma-

chine. If there is more than one machine with n

= 1,

then the best machine is considered the one with the

shortest remaining wait time t

for lots to accumu-

late, before M

processes a semi-ﬁlled batch. If there

is not one M

∈ W

with n

= 1, then the l

lot will

search for machines having n

= 2 places missing,

etc.

4.1.4 Case SingleStep to SingleStep

Assuming lots have progressed with their production

following R

, some of the machines with good quality

Q(M

) will be chosen more frequently than others in

the same workcenter W

. This will eventually lead

to accumulated lots in the queues of such machines,

therefore the total waiting time w

will increase. To

maintain w

up to date, the limit value l of a ma-

chine M

gets decreased each time M

gets chosen

by a lot. When the limit value l becomes equal to

0, this M

will lose its “evaluated” status. This will

mean that some of the incoming l

will choose this

randomly, and upon ﬁnishing the process will re-

evaluate it. This will provide a new, updated Q(M

)

value for the incoming l

. Additionally, since l

chooses the best M

∈ W

probabilistically, there is a

1 − P

) chance, that this l

will change its status

to an l

. Namely, instead of exploiting the best ma-

chine, it will explore the W

and select one machine

randomly.

4.1.5 Case SingleStep to Batch

Since the inﬂuence of batch machines on the produc-

tion of industrial plants is severe, it is important to

optimize this change in each lot’s recipe. As already

mentioned earlier in this section, it may happen that

some lots waiting in a queue of a single-step machine

could have ﬁlled out a batch machine if they had been

processed ﬁrst. In the original ABC algorithm, in the

Employed Bees Phase, a new solution gets generated

and compared to the existing one and then a better

one gets selected following the greedy selection ap-

proach. Therefore, in our algorithm, we model a bet-

ter solution generated in the Employed Bees Phase

and greedy selection as follows:

All lots in queue Q

of a single-step machine

Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants

that have next machine M

batch-oriented, will

be compared. Instead of processing the ﬁrst lot in

the Q

, single-step machine M

will process the

lot which gives the minimum values from the set

[ n

, t

] , as described in case 0 → Batch.

4.1.6 Case Batch to Batch

The concept here is similar to the one described in

case 0 → Batch. Instead of a single l

, here we con-

sider the whole batch of lots processed by a batch-

oriented M

. Since the next process step P

of these

lots corresponds to another batch-oriented M

, the

group of lots will choose one M

∈ W

as given

above.

4.1.7 Case Batch to SingleStep

Finally, since a batch machine waits and then pro-

cesses several lots at once, this results in waves of lots

being introduced to the following machines. In or-

der to evenly distribute these lots and not create over-

whelming queues of lots for single-step machines, we

modeled this case by randomly distributing lots over

the whole set W

of the next possible machines.

4.2 The Bat Algorithm

As with the ABC algorithm, we propose a mapping

for the bottom-up bat algorithm to the production

scheduling problem as follows:

• bats = machine, M

∈ W

, i = 1, 2, . . . , I

• prey = lot from one product, l

∈ L

, n = 1, 2, . . . , N

where machine M

belongs to a workcenter W

⊂ M

and M represents all machines in the fab. Each lot

∈ L

has access to its R

(sequence of process steps

) and thus, the machine types that have to be used

to produce the lot.

In the original bat algorithm, the population of

bats is initialized with a certain position, velocity and

frequency, as well as loudness and pulse rate of the

echolocation, which varies depending on the distance

of the bat to the prey. With each iteration new so-

lutions are generated by adjusting these parameters,

then the bats are evaluated and the best solution is

chosen.

When mapping the original algorithm to this par-

ticular production scheduling problem parts of the al-

gorithm have been adapted and simpliﬁed. First of

all, since the bats or the machines in the factory are

static, as opposed to the original algorithm where the

bats ﬂy and change their position and velocity, there

is no need to use the before mentioned equations 1

– 3. The bats are static in said environment due to

the fact that the machines in the production are them-

selves static, and the lots are the ones that are dynamic

and move throughout the factory from one work cen-

ter to the next. Thus, the problem is reconﬁgured from

bats having to search and hunt their prey, to prey be-

ing “lured” by the bat that is closest to them. In other

words, the lot to be processed is being chosen by the

most optimal machine in the work center. The mech-

anism behind the choice is further described in the

following section.

The distance from the bat to the prey is calculated

based on the Equation 9.

Dist = min

∑

(α · P

distr

+ β · Q

distr

) (9)

In terms of production, the equation corresponds

to the minimum value of the sums of the product

distr

) and queue (Q

distr

) distributions of a speciﬁc

work center. The equation is calculated before the lot

chooses a queue of a current work center, depending

on the lot’s recipe.

Product distribution is calculated for each ma-

chine in the work center. In Equation 10 the sum in

the nominator corresponds to the number of the lots

with the same product type as the lot choosing the

queue for each machine. The sum in the denominator

corresponds to the number of the lots with the corre-

sponding product type for the whole work center.

distr

∑

num(M

)

j=1

∑

k=1

(10)

Queue distribution is also calculated for each ma-

chine in the work center. As shown in Equation 11

it is achieved by dividing the queue length of each of

the machines in the work center by the sum of all the

queue lengths of the work center.

distr

qlen(M

)

∑

j=1

qlen

)

(11)

The product and queue distributions for each ma-

chine in the work center are saved in the memory of

their respective machines. Once both distributions are

calculated for each machine, as described in Equa-

tion 9, they are multiplied by their respective weights,

added up and saved in the memory again, thus creat-

ing a list of values for each machine. The machine

with the minimum distribution value then is chosen to

process the lot.

Parameters α and β are the weights that are ap-

plied to the product and queue distributions respec-

tively. For this version of the algorithm α and β are

constant values (α = 0.7, β = 0.3). The values were

chosen based on testing.

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

The before mentioned solution is proposed for the

case of a work center with single-step machines. To

choose the optimal machine in a work center with

batch machines we use the same mechanism as the

cases “0 to Batch” and “Batch to Batch” in the ABC

bottom-up algorithm described in Sections 4.1.3 and

4.1.6.

The pseudo code for the bottom-up bat algorithm

is shown in Algorithm 4.

Algorithm 4: Bottom-up bat algorithm.

1: Initialization Phase (initialization of the alpha,

beta parameters, memory)

2: repeat

3: switch m

singleStep

→ m

batch

4: case SingleStep:

Calculate Q

distr

for the WC;

Calculate P

distr

for the WC;

Save Q

distr

and P

distr

to the memory of

each machine of the WC;

Calculate the weighted sum of the queue

and product distributions for each machine in the

WC;

Save the weighted sum of the distribu-

tions (the distance) to memory of each machine

of the WC;

Choose the machine with the minimum

weighted sum value (Choose the bat with the

minimum distance to the prey);

5: case Batch:

Analogous to bottom-up ABC cases

“case 0 → Batch” and “case Batch → Batch”;

6: until all lots have found their last machine

5 EVALUATION AND RESULTS

5.1 Simulation Environment

We use NetLogo(Wilensky, 1999) which is one of the

most-used agent-based simulation platforms world-

wide and free to use. On top of this we implemented

a simulation framework which models the machines,

queues, and products in the fab and supports differ-

ent plug-in algorithms to optimize and control product

movement, queue management and process schedul-

ing. Machines, their queues, and the lots to be pro-

duced are each modelled as agent types (NetLogo

“breeds”) with their own, respective attributes. The

main simulation loop is run once per time tick and

drives the movement of lots through the factory: ﬁrst,

each lot not currently being processed or in a queue

gets to choose the next queue. This is facilitated by

the choose-queue callback to the currently active al-

gorithm. Then, every machine that is not currently

processing chooses the next lot (or set of lots, in

case of a batch machine) from its respective queue.

This decision is made via the take-from-queue call-

back to the currently active algorithm. After the

lot(s) has/have ﬁnished processing, the algorithm is

called again (move-out callback) to facilitate commu-

nications or other updates before the lot(s) move to

the next queue. At the beginning and end of every

tick, two more algorithm callbacks (tick-start, tick-

end) enable time-based updates (such as, e.g., the

degradation of pheromones). We use NetLogo Be-

haviorSpace to control the simulation runs and result

log ﬁle creation and the R statistics package to post-

process the results. A detailed description of our sim-

ulation framework can be found in (Umlauft et al.,

2022) and the source code plus necessary conﬁgura-

tion ﬁles can be obtained at our GitHub repository at

https://swarmfabsim.github.io.

5.2 The Baseline Algorithm

Baseline is a memoryless/stateless algorithm pro-

vided as reference for performance comparisons. The

idea of the baseline algorithm is to use simple heuris-

tics which use only local information to calculate its

decisions like the swarm algorithms that it is com-

pared to. We choose this model of only using local in-

formation/computation because we want to consider

problem sizes that would be too large to calculate an

optimal global solution in feasible time.

For single-step oriented machines, assigning a lot

to the machine with the shortest queue out of the

possible machines for the next step and to run these

queues in FIFO mode fulﬁlls these requirements. In

real-world production plants, such as Inﬁneon Tech-

nologies, of course more sophisticated approaches are

used, typically involving several priority levels to re-

shufﬂe lots in a queue. The underlying principle on

which those approaches are based, can in its most

simple form be abstracted to “shortest queue/FIFO”.

For batch machines, the most important idea is to

use the machine at maximum capacity and neither run

it with semi-ﬁlled batches nor have it sit idle. There-

fore, in the real world, there is a waiting time W T that

a batch machine will wait for enough lots of the same

type to arrive to ﬁll a whole batch. When only using

information local to the current machine (the smallest

information horizon), the best a simple algorithm can

do is to start the machine immediately once enough

lots of a type have arrived to ﬁll a batch or to wait for

Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants

the waiting time W T and to then take the largest semi-

ﬁlled batch available. In real life, this basic princi-

ple would be enhanced by corporate secret algorithms

that additionally take other information into account,

like deadlines that lots have to conform to.

In our version of baseline, we try to keep the infor-

mation horizon as small as possible and therefore do

not implement such communications. We also delib-

eratey do not consider the interplay between single-

step machines and batch machines as described in

Section 2, because we want to investigate the potential

for performance improvement inherent in addressing

these alternating processing modes.

In detail, the baseline algorithm works as fol-

lows: for the choose-queue callback it differentiates

between single-step and batch machines. For ma-

chines that process lot-by-lot, it simply chooses the

shortest queue. For batch machines it looks for the

queue where the least amount of lots of the current

type is missing to ﬁll an already waiting, semi-ﬁlled

batch. If there are no partially ﬁlled batches of this

type in any of the potential queues, it chooses the

queue with the least overall queue length.

For the take-from-queue callback, it uses a FIFO

approach on single-step machines, while on batch ma-

chines, if a full batch is available, that batch is chosen.

If several full batches exist, one is chosen at random.

If no full batch exists, the machine waits up to a max-

imum waiting time W T . After timeout, the largest

batch is chosen (in case of contention, one is chosen

at random). If a batch ﬁlls up during W T , it is chosen

and processed immediately.

5.3 Simulation Settings

We evaluated the algorithms in three scenarios, a

small (SFAB), a medium-sized (MEDIUM), and a

large (LFAB) model of a fab with different numbers

of machines and machine types. The LFAB scenario

also has a higher number of product types and lots per

type than the SFAB and MEDIUM scenarios. The pa-

rameters for these scenarios are shown in Table 1.

Table 1: Parameters used to create the three evaluation sce-

narios.

Parameter SFAB MEDIUM LFAB

Mach. types 25 50 100

Mach. / type U(2, 5) U(2, 10) U(2, 10)

Product types 50 50 100

Recipe length U(90, 110) U(90, 110) U (90, 110)

Lots per type U (1, 10) U(1, 10) U (2, 10)

Table 2 depicts the distribution parameters used

to create machines, where N(µ,σ

) denotes a Normal

Distribution and U (a, b) a uniform distribution. Neg-

ative values from the normal distribution have been

capped for parameters that cannot be negative, like

process time.

Table 2: Machine parameters used in the simulation.

Machine Parameter Value

Raw process time N(µ,σ

) with µ =

1.16, σ

= 0.32

Probability batch machine 50%

Batch size batch machines U(2, 8)

Waiting time batch machines U(1, 2)

5.4 Results and Discussion

For the evaluation, each scenario setting has been run

30 times, and averaged.The algorithms are evaluated

according to four performance metrics: makespan,

average ﬂow factor, average tardiness, and average

machine utilization. Tables 3, 4, and 5 depict a com-

parison between the performance of the reference al-

gorithm “Baseline” and the ABC and bat inspired al-

gorithms.

Makespan (MS): represents the total time for the pro-

duction plant to produce all lots from start to ﬁnish (in

simulation ticks). All lots are introduced into the fab

at the same time at the start of the simulation.

textbfFlow factor (FF): describes the relation between

the actual production time (including queue waiting

times) and the theoretical minimum production time

(sum of raw processing times of all required steps in

the recipe). The result is averaged over all lots.

Tardiness (TRD): describes how much additional

time (due to lots waiting in a queue) has been accu-

mulated until production of the lot compared to the

theoretical minimum production time. The result (in

simulation ticks) is averaged over all lots.

Machine utilization (UTL): represents how much

percent of time an average machine has been in op-

eration. For this, the total sum of working time of all

machines is divided by the simulation time and nor-

malized by the number of machines.

Table 3: Small Scenario (SFAB). Changes in %, positive

values denote improvement over Baseline.

Baseline ABC Change Bat Change

MS 10398 10838 -4.2% 9851 5.3%

FF 6.51 6.55 -0.6% 5.24 19.6%

TRD 6971.1 7031.5 -0.9% 5312.5 23.8%

UTL 35.90 33.74 6.0% 32.58 9.2%

Although the ABC and the bat algorithm are not

new alogrithms, we engineer them as literal swarm in-

telligence algorithms: instead of performing a global

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

Table 4: Medium Scenario (MEDIUM). Changes in %, pos-

itive values denote improvement over Baseline.

Baseline ABC Change Bat Change

MS 4536 5403 -19.1% 5604 -23.5%

FF 3.21 3.36 -4.9% 3.30 -2.8%

TRD 2481.8 2656.0 -7.0% 2576.9 -3.8%

UTL 23.87 19.58 18.0% 19.34 19.0%

Table 5: Large Scenario (LFAB). Changes in %, positive

values denote improvement over Baseline.

Baseline ABC Change Bat Change

MS 6207 6528 -6.0% 5790 6.7%

FF 3.47 3.54 -1.9% 2.78 20.0%

TRD 3126.8 3210.38 -2.7% 2244.0 28.2%

UTL 22.71 20.37 10.3% 23.94 -5.4%

optimization by applying them to solutions in the so-

lution space, we chose a bottom-up approach where

a global behavior emerges from local rules in an

agent-based modeled plant. The performance evalua-

tion shows that the ABC algorithm performs slightly

worse than Baseline for the SFAB and LFAB sce-

narios and worse in the MEDIUM scenario. For the

bat algorithm, SFAB and LFAB scenarios depict very

promising improvements, while the MEDIUM sce-

nario performs worse.

As described in Section 2, our understanding is

that the job shop problem is exacerbated by the switch

between single-step oriented and batch machines.

Therefore, an algorithm like Baseline, that pursues

a strategy to best ﬁll semi-ﬁlled batches (and there-

fore reduces idling time and inefﬁcient use of batch

machines) is hard to beat by algorithms that only em-

ploy local calculations to decide queue assignment.

This has also been observed in our previous work

(Umlauft et al., 2022), where we show how a hor-

mone algorithm that spreads information (in the form

of artiﬁcial hormones) back several machines is able

to consistently beat Baseline while an ant algorithm

that uses only local pheromones (at the current work-

center) is not. In general, an optimal algorithm for

this problem should take these switches from single-

step to batch machines and vice versa explicitly into

account. We are therefore planning to improve on

the proposed algorithms in the future by increasing

the size of the local neighborhood by looking several

machines “ahead” and anticipating switches between

machine kinds.

6 RELATED WORK

The following paragraphs gives a summary of the

currently available research activities on the ABC

algorithm. Multiple considerations and variants of

the ABC algorithm for job-shop scheduling problem

(JSSP) exist: (Karaboga and Basturk, 2007) uses the

ABC algorithm for optimizing multivariable func-

tions. (Yao et al., 2010) (Han et al., 2012) propose

the improved artiﬁcial bee colony (IABC) algorithm

that can transform roles during the search process and

enhance convergence rate. By comparing with Ge-

netic algorithm (GA) and the simple ABC, IABC is

also examined to be an effective and efﬁcient method

for solving the JSSP. (Gupta and Sharma, 2012) use

additional mutation and crossover operator of GA in

the classical ABC algorithm. They add a crossover

operator after the employed bee phase and a muta-

tion operator after onlooker bee phase of ABC algo-

rithm, with the criterion to decrease the maximum

completion time. (Zhang et al., 2013) apply the

ABC algorithm with the objective of minimizing to-

tal weighted tardiness. (Alvarado-Iniesta et al., 2013)

examine how to optimize the time and effort required

to supply raw material to different production lines

in a manufacturing plant in Juarez, Mexico by min-

imizing the distance an operator must travel to dis-

tribute material from a warehouse to a set of differ-

ent production lines with corresponding demand. The

ABC algorithm is applied in order to ﬁnd the opti-

mal distribution of material with the aim of estab-

lishing a standard time for this duty by examining

how this is applied in a local manufacturing plant.

(Pan et al., 2011) aim at minimizing total weighted

earliness and tardiness penalties for the lot-streaming

JSSP with equal sized sublots. examine the problem

under both the idling and no-idling cases and pro-

pose a novel discrete artiﬁcial bee colony (DABC)

algorithm. (Li et al., 2014) proposes the DABC al-

gorithm for solving the multi-objective ﬂexible JSSP

with maintenance activities. Due to the reasonable

hybridization of the ABC search and tabu search (TS)

based local search, the proposed DABC algorithm has

the ability to obtain promising solutions for the prob-

lem considered. (Tasgetiren et al., 2013) they ex-

pand the DABC to solve the no-idle permutation JSSP

with the total tardiness criterion by applying a novel

speed-up method for the insertion neighborhood. (Liu

and Liu, 2013) use the hybrid DABC algorithm for

minimizing the makespan in permutation JSSP. Also

(Pan et al., 2014), they use the DABC with a hybrid

representation and a combination of forward decod-

ing and backward decoding methods for solving the

problem. (Wang et al., 2012) introduce an enhanced

Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants

Pareto-based artiﬁcial bee colony (EPABC) algorithm

to solve the multi-objective ﬂexible JSSP with the

criteria to minimize the maximum completion time,

the total workload of machines, and the workload of

the critical machine simultaneously. (Kumar et al.,

2014) outline a new hybrid of ABC algorithm with

GA. The proposed method integrates crossover op-

eration from GA with original ABC algorithm. The

proposed method is named as Crossover based ABC

(CbABC). The CbABC strengthens the exploitation

phase of ABC as crossover enhances exploration of

search space. (Yurtkuran and Emel, 2014) propose

the modiﬁed artiﬁcial bee colony (M-ABC) algorithm

to solve p-center problems. The proposed approach

has two main contributions: random key-based en-

coding for solution representation and a new multi

search strategy in which different search strategies are

employed in one overall search process. (Li and Pan,

2015) present a novel hybrid algorithm (TABC) that

combines the ABC and TS to solve the hybrid ﬂow

shop (HFS) scheduling problem with limited buffers.

The main advantages of the proposed algorithms are

as follows: the TS-based self-adaptive neighborhood

strategy is embedded in TABC, which can balance

the exploitation and exploration abilities of the al-

gorithms; (2) the TS-based local search is applied

to the employed bees and onlookers with different

functions, which can further enhance the exploita-

tion ability of the proposed algorithm. In (Gao et al.,

2015) the TABC is compared against and outperforms

eleven heuristic and meta-heuristics algorithms. Fur-

ther, (Gao et al., 2016) investigate the FJSP with fuzzy

processing time. (Sharma and Pant, 2017) introduce a

hybrid version of ABC and shufﬂed frog-leaping al-

gorithm. (Sharma et al., 2018) present a modiﬁed

ABC algorithm to solve JSSP, in the onlooker bee

phase of ABC, to maintain a proper harmony amid

exploration and exploitation capabilities, beer froth

phenomenon inspired position update is incorporated.

The proposed strategy is named as Beer froth artiﬁcial

bee colony algorithm. (Zhuang et al., 2019) present

JSSPs with two sequence-dependent setup times. The

problem is different from the traditional open JSSP,

with higher complexity. The mixed integer linear

programming model is proposed to solve small-scale

problems and get exact solutions. Compared with

other four intelligent algorithms, such as GA, PSO,

ant colony optimization and cuckoo search algorithm,

two experiments have been conducted and the com-

putational results shows that the proposed artiﬁcial

bee colony algorithm can achieve the best result in

the large-scale problems A detailed review on ABC

variants on data clustering can be found in (Kumar

et al., 2017). They state that the ABC is a simple

and ﬂexible algorithm and requires less parameters to

be tuned in comparison to other meta-heuristic algo-

rithms. Furthermore, in (Khader et al., 2013) present

a thorough and extensive overview of most research

work focusing on the application of ABC, with the

expectation that it would serve as a reference material

to both old and new, incoming researchers to the ﬁeld.

Further applications are presented in (Karaboga et al.,

2014).

Bat algorithm and various improved and modi-

ﬁed versions of the algorithm have been applied to

the job shop scheduling problem (JSSP) over the

last decade since the algorithm was ﬁrst introduced

in (Yang, 2010). In 2012 bat algorithm was used

in (Musikapun and Pongcharoen, 2012) to develop the

Bat Algorithm based Scheduling Tool to solve multi-

stage multi-machine multi-process scheduling prob-

lems. (Marichelvam et al., 2013) apply bat algorithm

to the multistage hybrid ﬂow shop (HFS) scheduling

problems. The results show the bat algorithm out-

performs both the genetic algorithm and the particle

swarm optimization algorithm. (Luo et al., 2014) de-

velop the discrete bat algorithm for optimal permuta-

tion ﬂow shop scheduling problem. (Xu et al., 2017)

developed an improved bat algorithm to solve a dual

ﬂexible job-shop scheduling problem (DFJSP). The

authors use a dual ﬂexible encoding strategy to pro-

duce the mapping between operations and bat popula-

tions. The experiment results show that the proposed

model and improved algorithm could be effectively

applied to DFJSP. (Zhu et al., 2017) proposed a modi-

ﬁed bat algorithm to solve multi-objective JSSP. They

were the ﬁrst to successfully apply the bat algorithm

to the multi-objective ﬂexible JSSP. (Dao et al., 2018)

put forward an optimization algorithm based on paral-

lel versions of the bat algorithm, random-key encod-

ing scheme and makespan scheme to solve JSSP. The

results show an improvement in the convergence and

accuracy compared to the original bat algorithm and

particle swarm optimization. (Lu and Jiang, 2019)

were the ﬁrst to apply the bat algorithm to the low-

carbon JSP. They propose a bi-population based dis-

crete bat algorithm, more speciﬁcally they propose a

parallel searching mechanism to divide the popula-

tion, as well as a modiﬁed discrete updating approach

to make the bat algorithm search within a discrete do-

main. More recently, (Chen et al., 2019) proposed

another improved bat algorithm for solving the JSSP,

which focuses on speeding up convirgance and deter-

mining the optimal global solution. They compare the

improved bat algorithm to the original bat algorithm

and particle swarm optimization algorithm and suc-

cessfully outperform them in minimizing makespan

and ﬁnding the optimal global solution. (Yang and

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence

He, 2013) provide a comprehensive review of differ-

ent variants of the bat algorithm and its applications,

as well as various case studies. A more recent review

was provided in (Jayabarathi et al., 2018). It focuses

on the usage of the bat algorithm and its application

to optimize various engineering problems.

7 CONCLUSION AND FUTURE

WORK

This paper has proposed the use of two bio-inspired

algorithms, namely the artiﬁcial bee colony (ABC)

and the bat algorithm in a bottom-up manner to tackle

the problem of optimization for a semiconductor fab

using the job-shop manufacturing principle. Unlike

previous work, where these algorithms are calculated

for global optimization, we do not apply them to

solutions in the solution space. Instead, we chose

a bottom-up approach and applied them as literal

swarm intelligence algorithms in a bottom-up manner.

This means that the active agents (artiﬁcial bees, bats)

were mapped to entities in the production plant and

only use information from their current local neigh-

borhood to take decisions from which the global so-

lution then emerges automatically. We used NetLogo

to simulate the fab and to measure the performance of

the proposed algorithms compared to an engineered

baseline algorithm. The evaluation was based on four

key performance indicators: makespan, ﬂow factor,

tardiness, and machine uptime utilization. Our results

show that these types of algorithms, employed in a

bottom-up manner, show promise of performance im-

provements using only low-effort local calculations.

The implementation of the simulation environment is

published as open source in a Git repository

Future work will expand on the details of the pro-

posed algorithms by investigating the impact of the

size of the local neighborhood used for calculations

(eg. by looking ahead or back several machines) and

adaptations to explicitly address the switching be-

tween single-step oriented machines and batch ma-

chines during the production process.

ACKNOWLEDGEMENT

This work was performed in the course of project

ML&Swarms supported by KWF-React EU un-

der contract number KWF-20214|34789|50819, and

SwarmIn supported by FFG under contract number

894072.

https://swarmfabsim.github.io

REFERENCES

Alvarado-Iniesta, A., Garcia-Alcaraz, J. L., Rodriguez-

Borbon, M. I., and Maldonado, A. (2013). Optimiza-

tion of the material ﬂow in a manufacturing plant by

use of artiﬁcial bee colony algorithm. Expert Systems

with Applications, 40(12):4785–4790.

Chen, X., Zhang, B., and Gao, D. (2019). An improved bat

algorithm for job shop scheduling problem. In 2019

IEEE International Conference on Mechatronics and

Automation (ICMA), pages 439–443. IEEE.

Dao, T.-K., Pan, T.-S., Pan, J.-S., et al. (2018). Parallel

bat algorithm for optimizing makespan in job shop

scheduling problems. Journal of Intelligent Manufac-

turing, 29(2):451–462.

Gao, K., Cao, Z., Zhang, L., Chen, Z., Han, Y., and

Pan, Q. (2019). A review on swarm intelligence and

evolutionary algorithms for solving ﬂexible job shop

scheduling problems. IEEE/CAA Journal of Automat-

ica Sinica, 6(4):904–916.

Gao, K. Z., Suganthan, P. N., Chua, T. J., Chong, C. S.,

Cai, T. X., and Pan, Q. K. (2015). A two-stage artiﬁ-

cial bee colony algorithm scheduling ﬂexible job-shop

scheduling problem with new job insertion. Expert

systems with applications, 42(21):7652–7663.

Gao, K. Z., Suganthan, P. N., Pan, Q. K., Tasgetiren, M. F.,

and Sadollah, A. (2016). Artiﬁcial bee colony algo-

rithm for scheduling and rescheduling fuzzy ﬂexible

job shop problem with new job insertion. Knowledge-

based systems, 109:1–16.

Gupta, M. and Sharma, G. (2012). An efﬁcient modiﬁed ar-

tiﬁcial bee colony algorithm for job scheduling prob-

lem. International Journal of Soft Computing and En-

gineering (IJSCE), 1(6).

Han, Y.-Y., Pan, Q.-K., Li, J.-Q., and Sang, H.-y. (2012).

An improved artiﬁcial bee colony algorithm for the

blocking ﬂowshop scheduling problem. The Interna-

tional Journal of Advanced Manufacturing Technol-

ogy, 60(9-12):1149–1159.

Jayabarathi, T., Raghunathan, T., and Gandomi, A. (2018).

The bat algorithm, variants and some practical engi-

neering applications: A review. Nature-inspired algo-

rithms and applied optimization, pages 313–330.

Karaboga, D. (2010). Artiﬁcial bee colony algorithm.

scholarpedia, 5(3):6915.

Karaboga, D. and Basturk, B. (2007). A powerful and ef-

ﬁcient algorithm for numerical function optimization:

artiﬁcial bee colony (abc) algorithm. Journal of global

optimization, 39(3):459–471.

Karaboga, D., Gorkemli, B., Ozturk, C., and Karaboga, N.

(2014). A comprehensive survey: artiﬁcial bee colony

(abc) algorithm and applications. Artiﬁcial Intelli-

gence Review, 42(1):21–57.

Khader, A. T., Al-betar, M. A., and Mohammed, A. A.

(2013). Artiﬁcial bee colony algorithm, its variants

and applications: a survey. Journal of Theoretical and

Applied Information Technology, 47(2):434–459.

Khatmi, E., Elmenreich, W., Wogatai, K., Schranz, M., Um-

lauft, M., Laure, W., and Wuttei, A. (2019). Swarm in-

Bottom-Up Bio-Inspired Algorithms for Optimizing Industrial Plants

telligence layer to control autonomous agents (swilt).

In STAF (Co-Located Events), pages 91–96.

Kumar, A., Kumar, D., and Jarial, S. (2017). A review on

artiﬁcial bee colony algorithms and their applications

to data clustering. Cybernetics and Information Tech-

nologies, 17(3):3–28.

Kumar, S., Sharma, V. K., and Kumari, R. (2014). A

novel hybrid crossover based artiﬁcial bee colony al-

gorithm for optimization problem. arXiv preprint

arXiv:1407.5574.

Lawler, E. L., Lenstra, J. K., Kan, A. H. R., and Shmoys,

D. B. (1993). Sequencing and scheduling: Algorithms

and complexity. Handbooks in Operations Research

and Management Science, 4:445–522.

Li, J.-q. and Pan, Q.-k. (2015). Solving the large-scale

hybrid ﬂow shop scheduling problem with limited

buffers by a hybrid artiﬁcial bee colony algorithm. In-

formation Sciences, 316:487–502.

Li, J.-Q., Pan, Q.-K., and Tasgetiren, M. F. (2014). A

discrete artiﬁcial bee colony algorithm for the multi-

objective ﬂexible job-shop scheduling problem with

maintenance activities. Applied Mathematical Mod-

elling, 38(3):1111–1132.

Liu, Y.-F. and Liu, S.-Y. (2013). A hybrid discrete ar-

tiﬁcial bee colony algorithm for permutation ﬂow-

shop scheduling problem. Applied Soft Computing,

13(3):1459–1463.

Lu, Y. and Jiang, T. (2019). Bi-population based discrete

bat algorithm for the low-carbon job shop scheduling

problem. IEEE Access, 7:14513–14522.

Luo, Q., Zhou, Y., Xie, J., Ma, M., and Li, L. (2014). Dis-

crete bat algorithm for optimal problem of permuta-

tion ﬂow shop scheduling. The Scientiﬁc World Jour-

nal, 2014.

Marichelvam, M., Prabaharan, T., Yang, X.-S., and Geetha,

M. (2013). Solving hybrid ﬂow shop scheduling prob-

lems using bat algorithm. International Journal of Lo-

gistics Economics and Globalisation, 5(1):15–29.

Musikapun, P. and Pongcharoen, P. (2012). Solving multi-

stage multi-machine multi-product scheduling prob-

lem using bat algorithm. In 2nd international confer-

ence on management and artiﬁcial intelligence, vol-

ume 35, pages 98–102. IACSIT Press Singapore.

Pan, Q.-K., Tasgetiren, M. F., Suganthan, P. N., and Chua,

T. J. (2011). A discrete artiﬁcial bee colony algorithm

for the lot-streaming ﬂow shop scheduling problem.

Information sciences, 181(12):2455–2468.

Pan, Q.-K., Wang, L., Li, J.-Q., and Duan, J.-H. (2014). A

novel discrete artiﬁcial bee colony algorithm for the

hybrid ﬂowshop scheduling problem with makespan

minimisation. Omega, 45:42–56.

Schranz, M., Umlauft, M., and Elmenreich, W. (2021).

Bottom-up job shop scheduling with swarm intelli-

gence in large production plants. In Proceedings of

the 11th International Conference on Simulation and

Modeling, Methodolgies, Technologies and Applica-

tions (SIMULTECH), pages 327–334.

Sharma, N., Sharma, H., and Sharma, A. (2018). Beer froth

artiﬁcial bee colony algorithm for job-shop scheduling

problem. Applied Soft Computing, 68:507–524.

Sharma, T. K. and Pant, M. (2017). Shufﬂed artiﬁcial

bee colony algorithm. Soft Computing, 21(20):6085–

6104.

Stidham Jr, S. (2002). Analysis, design, and control of

queueing systems. Operations Research, 50(1):197–

216.

Tasgetiren, M. F., Pan, Q.-K., Suganthan, P., and Oner, A.

(2013). A discrete artiﬁcial bee colony algorithm for

the no-idle permutation ﬂowshop scheduling problem

with the total tardiness criterion. Applied Mathemati-

cal Modelling, 37(10-11):6758–6779.

Umlauft, M., Schranz, M., and Elmenreich, W. (2022).

SwarmFabSim: a simulation framework for bottom-

up optimization in ﬂexible job-shop scheduling us-

ing netlogo. In Proc. 12th International Conference

on Simulation and Modeling Methodologies, Tech-

nologies and Applications (SIMULTECH), volume 1,

pages 271–279. INSTICC, SciTePress.

Wang, L., Zhou, G., Xu, Y., and Liu, M. (2012). An en-

hanced pareto-based artiﬁcial bee colony algorithm

for the multi-objective ﬂexible job-shop scheduling.

The International Journal of Advanced Manufactur-

ing Technology, 60(9-12):1111–1123.

Wilensky, U. (1999). Netlogo. Webpage. Center

for Connected Learning and Computer-Based Mod-

eling, Northwestern University, Evanston, IL, http:

//ccl.northwestern.edu/netlogo/.

Xu, H., Bao, Z., and Zhang, T. (2017). Solving dual ﬂexible

job-shop scheduling problem using a bat algorithm.

Advances in Production Engineering & Management,

12(1).

Yang, X.-S. (2010). A new metaheuristic bat-inspired al-

gorithm. In Nature inspired cooperative strategies for

optimization (NICSO 2010), pages 65–74. Springer.

Yang, X.-S. and He, X. (2013). Bat algorithm: literature

review and applications. International Journal of Bio-

inspired computation, 5(3):141–149.

Yao, B. Z., Yang, C. Y., Hu, J. J., Yin, G. D., and Yu, B.

(2010). An improved artiﬁcial bee colony algorithm

for job shop problem. In Applied Mechanics and Ma-

terials, volume 26, pages 657–660. Trans Tech Publ.

Yurtkuran, A. and Emel, E. (2014). A modiﬁed artiﬁcial bee

colony algorithm for-center problems. The Scientiﬁc

World Journal, 2014.

Zhang, R., Song, S., and Wu, C. (2013). A hybrid artiﬁ-

cial bee colony algorithm for the job shop scheduling

problem. International Journal of Production Eco-

nomics, 141(1):167–178.

Zhu, H., He, B., and Li, H. (2017). Modiﬁed bat algorithm

for the multi-objective ﬂexible job shop scheduling

problem. International Journal of Performability En-

gineering, 13(7):999.

Zhuang, Z., Huang, Z., Lu, Z., Guo, L., Cao, Q., and Qin,

W. (2019). An improved artiﬁcial bee colony algo-

rithm for solving open shop scheduling problem with

two sequence-dependent setup times. Procedia CIRP,

83:563–568.

ICAART 2023 - 15th International Conference on Agents and Artiﬁcial Intelligence
