Cloud Inspector: A Tool-Based Approach for Public Administrations to

Establish Information Security Processes Towards Public Clouds

Michael Diener

and Thomas Bolz

University of Regensburg, Regensburg, Germany

IU International University of Applied Sciences, Erfurt, Germany

Keywords:

Cloud Computing, Public Administration, Information Security Management, Security Audits.

Abstract:

Digitization is on the rise in Europe’s public administrations. Since the Covid-19 pandemic began, public

cloud services have become essential in this domain. However, there are still security concerns about the usage

of external cloud resources in business processes of public authorities, although numerous technical concepts

for improving security are already available. In this paper, we focus on internal processes of information

security management systems (ISMS) in public administrations. We identiﬁed potential challenges such as

a lack of knowledge about cloud security and unclear roles and responsibilities when using ISMS tools in

this application domain. As a possible solution, we present a tool-based approach that is based on an easy-

to-use online questionnaire, which can be automatically evaluated based on predeﬁned sentiments. With this

approach, we can provide the required visibility into the status quo of public cloud security while integrating

various stakeholders within public administrations into a holistic ISMS process.

1 INTRODUCTION

Cloud computing opens the possibility for organiza-

tions to access services from a pool of theoretically

inﬁnite IT resources without the need for massive up-

front investments in data centers and infrastructure

(Mell et al., 2011). The public cloud (i.e., Amazon

Web Services, Google Workspace, Microsoft 365,

etc.) is one of the proposed deployment models and

is becoming more and more widely adopted. Gartner

forecasts cloud computing to reach nearly $600 bil-

lion in revenue by 2023 (Gartner, 2022). In general,

cloud computing offers two signiﬁcant advantages to

organizations: cost savings and ﬂexibility for business

processes (Armbrust et al., 2009).

Although cloud solutions have been on the mar-

ket for more than 10 years, this software model is

only now being increasingly implemented in public

administrations (Al-Shargabi et al., 2020). The rea-

sons for these developments are manifold. During the

Covid-19 pandemic, cloud services made it possible

for government agencies to quickly and easily pro-

vide tools to solve practical problems. Such as collab-

oration platforms and online calendars citizens could

schedule their vaccinations (Tambou and Pato, 2021).

Despite recent developments regarding cloud

computing in public administrations, the maturity of

digitization in European countries is still uneven (EU

Commission, 2022). The Digital Economy and Soci-

ety Index 2022 shows that Romania, Greece, Bulgaria

and Slovakia have the lowest scores in digital public

services within the European Union.

Nevertheless, the scope of digital public services

will sooner or later increase in all European coun-

tries. Regulation (EU) 2018/1724 enforces single dig-

ital gateways in European public authorities to en-

able citizens to access government services (European

Union, 2018). Consequently, public administrations

in Europe will also have to invest in innovative cloud

services, as not all of them have the capabilities them-

selves to provide their own IT resources to meet legal

requirements.

However, cloud computing in public administra-

tions also faces numerous security and privacy issues,

leading to enormous challenges as resources in public

clouds are accessible via the Internet (Armbrust et al.,

2009). In recent years, cyberattacks against public ad-

ministrations have increased dramatically (KonBrief-

ing Research, 2022). If sensitive or personal data is

processed in cloud infrastructures, well-established

information security processes must meet the basic

protection goals of conﬁdentiality, integrity and avail-

ability (Markus and Meuche, 2022; Samonas and

Coss, 2014).

Diener, M. and Bolz, T.

Cloud Inspector: A Tool-Based Approach for Public Administrations to Establish Information Security Processes Towards Public Clouds.

DOI: 10.5220/0011694900003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 543-551

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

543

For the reasons mentioned above, public adminis-

trations are in a dilemma. On one hand, they have to

rely on outsourcing strategies such as cloud comput-

ing to remain ﬁt for the future. On the other hand,

there are still major concerns about the security of

data in clouds. In addition, established approaches

such as FedRAMP

are unsuitable because they are

not adaptable within European public authorities due

to security concerns. European cloud projects such

as Gaia-X

are still in an early stage of development

and do not currently offer practical solutions for pub-

lic authorities. Cloud certiﬁcations, which are based

on established standards like the ISO 27000 family

or the German C5 standard, are mainly helpful dur-

ing the procurement phase of cloud services (Wang

and Bashir, 2022). Their validity becomes obsolete

over time and cloud customers must conduct regu-

lar internal audits of cloud services or Cloud Ser-

vice Providers (CSP) anyway. Furthermore, there are

many tools available on the market that can provide

support to organizations in implementing informa-

tion security management processes in the context of

cloud computing, but some issues are still unresolved

in our view, which we have identiﬁed in our practical

research work. Therefore, an appropriate approach

for public authorities is needed so that public clouds

can be integrated securely in business processes.

Based on this practice-inspired problem, we

started our research process that follows the principles

of the Action Design Research (ADR) methodology.

Together with the Chief Information Security Ofﬁcer

(CISO) and practitioners from departments of a public

administration, we researched and developed an inno-

vative artifact that tries to solve the described prob-

lem. To the best of our knowledge, this work is the

ﬁrst research paper that examines the application of

a tool-based approach, including an interactive ques-

tionnaire, for managing information security of public

clouds in the ﬁeld of public administrations.

The remainder of this paper is organized as fol-

lows: After examining related work on information

security management due to cloud computing within

public administrations (Section 2), we explain the

ADR methodology that guided the conceptual design

process (Section 3). Section 4 describes the concep-

tual design and requirements for a tool-based method.

Based on this we explain in Section 5 the develop-

ment of our prototype, which we named Cloud In-

spector. Next, we evaluate the improvements in terms

of information security processes of a public admin-

istration for managing public clouds (Section 6). The

last section concludes the paper and gives an outlook.

https://fedramp.gov

https://gaia-x.eu

2 RELATED WORK

2.1 Tool-Based Information Security

Management for Public Clouds

Although certiﬁcations of cloud services are supposed

to ensure security and other aspects of CSPs, they no

longer represent the actual status quo of a cloud. In

their research, Lins et al. investigate the requirements

for the application of continuous monitoring of cloud

services (Lins et al., 2019). This is understood to be

an ongoing process to monitor the implemented sys-

tems and applications of a cloud service and to detect

deviations accordingly. Based on predeﬁned metrics,

which must be provided by CSPs, the evaluation is

carried out with the support of tool-based monitoring

systems, making it possible to carry out continuous

and dynamic cloud certiﬁcation. However, this as-

sumes that the metrics provided by the CSP are trans-

parent, complete, and trustworthy.

In contrast to this approach, external audits of

cloud services are often still carried out with classic

software applications (e.g., Verinice, Eramba, etc.) to

evaluate security processes based on predeﬁned con-

trols (Antunes et al., 2022). This makes it possible to

derive potential IT risks and coordinate the manage-

ment of security measures to improve the IT security

of cloud services. Recent approaches in research pur-

sue the automation of information security risk man-

agement processes (Sterbak et al., 2021).

In addition, speciﬁc cloud evaluation solutions

were developed by researchers to offer the possibil-

ity to check the compatibility of Software as a Ser-

vice (SaaS) solutions in accordance with service level

agreements. For example, the tool Clouditor allows

predeﬁned checks to be performed against various

public clouds such as Microsoft Azure (Stephanow

and Banse, 2017). In their research, Diener et al. pre-

sented an AI-based tool to support the selection of ap-

propriate cloud services depending on the sensitivity

of data (Diener et al., 2016). Furthermore, numer-

ous self-assessment tools have been designed and re-

searched, which give IT managers the possibility to

evaluate their cloud services with the help of concrete

questionnaires. For example, Cidres et al. have de-

veloped a self-assessment tool that can support public

administrations in Portugal in the selection of CSPs

(Cidres et al., 2020).

2.2 Information Security Management

in Public Administrations

Szczepaniuk et al. conducted an empirical study be-

tween 2016 and 2019 to explore the nature of the

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

544

implementation of information security management

systems in public administrations in Poland (Szczepa-

niuk et al., 2020). As part of their work, they found

that the prevalence of information security manage-

ment systems correlates strongly with legal require-

ments. Particularly the introduction of GDPR reg-

ulation and the NIS Directive. The authors of the

study recommend the implementation of several dif-

ferent procedures and models to increase information

security in public administrations. Chodakowska et

al. conducted a comprehensive online survey with

Polish municipalities and cities regarding the imple-

mentation of security policies (Choodakowska et al.,

2022). The evaluation revealed that there is indeed

a lack of practical implementation of cybersecurity

rules, which increases the risk of cyberattacks.

Another study was conducted by Rehbohm et al.

in which several CISOs in Germany were interviewed

about the management of information security in gov-

ernmental organizations (Rehbohm et al., 2019). The

study results show that there is a great need for re-

search in this ﬁeld to prepare authorities and govern-

mental institutions for the requirements of cyber se-

curity.

In addition, Moses et al. surveyed several German

municipalities regarding the implementation of infor-

mation security management (Moses et al., 2022).

The results show that the documentation processes are

a major challenge, especially for small local govern-

ments. In addition, there is a lack of appropriate tools

to drive the development and establishment of infor-

mation security management systems.

3 RESEARCH METHODOLOGY

For our research, we use the ADR method (Sein

et al., 2011), which is widely established as a re-

search approach for ﬁnding solutions to practical

problems. ADR relies on close collaboration between

researchers and practitioners. It provides a frame-

work for dynamic collaboration between the two par-

ties and deﬁnes four main stages with several princi-

ples.

Stage 1 focuses on the problem formulation, ini-

tiated by researchers, practitioners or end-users. Ini-

tially, it is necessary to establish an ADR team con-

sisting of practitioners, experts and researchers. An

important aspect of this stage is that the deﬁnition of

the problem is made as an instance of a class of prob-

lems. Consequently, the range of theories available

in research increases. Another principle in this stage

requires the development of an artifact that considers

existing theories.

In the following, stage 2 addresses activities in

building, intervention, and evaluation (BIE). In this

stage the reciprocal shaping of the artifact in an iter-

ative process is conducted. In general, the members

of the ADR team are heavily involved in the design

process as they continuously evaluate the emerging

artifact. It is therefore important that ADR teams are

made up of members that import different perspec-

tives and expertise to the design process. In our re-

search project, the ADR team consists of researchers

from business information systems and cloud secu-

rity, as well as of CISOs and business users from a

public administration.

While working on stages 1 and 2, the researchers

simultaneously carry out the reﬂection and learning

stage. This ensures that the knowledge can be con-

tinuously transferred to a broader class of problems.

Consequently, the artifact developed in this research

work does not only improve the establishment of se-

curity processes with respect to the usage of public

clouds in public administration, but also implemen-

tations (i.e., IoT-devices in the context of smart city

projects) within the overall information security man-

agement process.

Finally, the last stage formalization of learning

presents the results of the research, generated during

the development of the procedure and its adaptation to

the organizational context. In order to fulﬁll the ADR

principle generalized outcome, the knowledge of the

resulting artifacts was abstracted.

4 CONCEPTUAL DESIGN OF

THE TOOL-BASED APPROACH

By applying the ADR method, we ﬁrst start formulat-

ing the problem with the help of observations and sub-

sequent workshops with experts. Based on the identi-

ﬁed research questions, we perform stage 2 by itera-

tive cycles.

4.1 Problem Formulation

4.1.1 Findings in Security Management

Processes

We started our research in November 2021. One of

the authors of this paper is CISO at a city govern-

ment with more than 4,000 employees using more

than 800 different application processes. In his role

as CISO, he is responsible for information security

management and has a solid overview of ongoing IT

projects. In parallel to his work, he is conducting re-

search on cloud security.

Cloud Inspector: A Tool-Based Approach for Public Administrations to Establish Information Security Processes Towards Public Clouds

545

The trigger of our research was a series of requests

from various ofﬁces of the city government regard-

ing the adoption of external cloud services for dif-

ferent concerns. For example, the foreigners depart-

ment needed a cloud-based video conferencing solu-

tion that would allow external translators to be in-

volved in conversations with foreign citizens. Already

during COVID-19 pandemic, a cloud-based web ap-

plication was needed by the city government’s popu-

lation protection department to support appointment

management for vaccinations.

An even bigger challenge was the investigation of

a minor IT security incident in a public cloud used for

collaboration by more than 40 administered schools.

Speciﬁcally, the public cloud offers a SaaS applica-

tion that facilitates communication between school

administrators, parents, and students. The reason was

that it was not deﬁned which administrative tasks the

schools had to perform on their own responsibility.

Therefore, a regular update of the user management

in the SaaS application was not carried out for, which

led to the effect that users had access they should no

longer have.

All these use cases of public clouds in public ad-

ministration had in common that they did not start as

a traditional IT project, but more or less on demand.

In many cases, it was not clear which entity would as-

sume responsibility for a cloud that had already been

procured, or later for a planned cloud solution. Thus,

it was initially difﬁcult to identify the responsible ofﬁ-

cials in each case and to integrate them into the cloud

security audit process. Even more challenging was

the actual execution of the cloud security audit using

an existing ISMS tool that manages all IT assets of

this public administration.

During the problem formulation stage, we also de-

termined the composition of our ADR team. In ad-

dition to the researchers, practitioners from the pub-

lic administration from different areas are also in-

tegrated, e.g., Chief Information Ofﬁcer (CIO), E-

Government Manager, In-house Software Developer,

Data Protection Ofﬁcer (DPO), IT-Project Controllers

and the ﬁve people from the previous expert inter-

views. The latter will be considered as Cloud Product

Owners (CPO), each responsible for the IT security

of the adopted cloud. All members of the ADR team

will be intensively involved in the evaluation of the

emerging artifact in the BIE stage.

4.1.2 Research Questions

Inspired by the practical issues and a continuous re-

view of prior research work on this topic, we identi-

ﬁed the following research questions (cf. table 1) to

address a broader class of problems in our studies.

Table 1: Research questions.

RQ 1 What needs to be changed in public admin-

istrations in order to keep CISOs up to date

regarding the security state of adopted pub-

lic cloud solutions?

RQ 2 How can cloud managers in public admin-

istration organizations be better integrated

into the information security management

processes?

RQ 3 What enhancements do ISMS tools need to

support non-experts in performing system-

atic and regular security audits of public

clouds?

4.2 Building, Intervention and

Evaluation

Between March and June 2022, we reciprocally

shaped the basic design of our tool-based method.

Our interdisciplinary ADR team was strongly in-

volved in this process, so that ideas of various roles

and stakeholders could be integrated into the ongoing

development process. We also forced a continuous

abstraction and reﬂection of the generated knowledge

from practice towards the state of the art of research.

During this time, we created a tool-based method

for public administrations, so that responsible parties

are enabled to improve the security of public clouds as

part of a guided ISMS process. To achieve this goal,

we conducted two workshops with the ADR team. In

addition, we have temporarily drawn on the knowl-

edge of other experts, including three external CISOs

and two certiﬁed ISO 27001 auditors.

The ﬁrst workshop focuses on the question of

how tool support in public administrations can be im-

proved to enhance the integration within ISMS pro-

cesses in context of public clouds. Speciﬁcally, the

results should identify features that can be used dur-

ing the intended prototype development. On this ba-

sis, a design prototype was then developed in the sec-

ond workshop with the focus on making it as easy

as possible for end users in public administrations

(i.e., cloud product owners in different departments)

to carry out regular and systematic security audits of

public clouds.

4.2.1 Workshop 1: Requirements for Enhanced

Tool-Support

In the ﬁrst workshop, the ADR team dealt with func-

tional requirements that are decisive for the devel-

opment of the prototype. The central question was

which enhancements and optimizations are required

so that cloud security audits can be carried out more

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

546

successfully with the support of our tool?

To identify requirements that are as relevant to

practice as possible, we simulated the performance of

a cloud security audit. For this purpose, we created a

simple questionnaire in our existing ISMS tool and at-

tempted to work through it with members of the ADR

team. Moreover, we observed together in the work-

shop how the use of the ISMS tool by individual team

members has been perceived. In parallel, interesting

observations or showstoppers were documented. We

have repeated the same process again with an open-

source ISMS tool, which is very similar in structure

and functionality to the ﬁrst one. Subsequently, we

discussed the observations identiﬁed with the stake-

holders.

In general, we were able to identify several short-

comings in both tools considered. Employees who

have limited IT knowledge and who obtain the role as

a CPO need a comprehensive instruction in the use of

an ISMS tool. In addition, ADR members agreed that

using an ISMS tool can become difﬁcult after a long

period of non-use.

It was noticeable in both tools that the applica-

tion of questionnaires for known standards (e.g., ISO

27001, ISO 27017, etc.) proved difﬁcult. Although

available templates for security requirements (e.g.,

sample questionnaires, check controls, etc.) can be

imported into the tools, the questions always refer

one-to-one to the entire requirement. If several differ-

ent requirements are described in a security require-

ment, the required granularity cannot be mapped with

classic questionnaires. However, this problem does

not only appear in the public administration sector.

Another problem was that the answers given by

CPOs to security requirements had to be reviewed in

detail by CISOs after the cloud audit was completed.

In all tools, it is necessary for CISOs to identify in-

sufﬁcient answers to derive appropriate suggestions

for security measures. By default, multiple choice an-

swers can be ﬁltered, but it is not possible to distin-

guish between good and bad answers. For example,

the value yes in one answer can be interpreted posi-

tively, while in a completely different scenario it must

be considered critical.

Taking all aspects into consideration, we were

able to derive ﬁve major requirements that are rele-

vant for a tool-based approach:

• Accountability. CPOs need to be aware of their

responsibilities in terms of organizational security

requirements for the services they are assigned

from public clouds.

• Duration. Since audits of information security

processes represent an additional time commit-

ment for CPOs, short and precise routines must

be developed to achieve high acceptance rates.

• Self-Explaining Approaches. Efﬁciency also

plays an important role in conducting various

cloud security audits as these must be well orga-

nized and understandable for CPOs, applying ba-

sic principles.

• Simplicity. The evaluation of answers from the

questionnaire on speciﬁc security requirements

must be quick and precise. This means that de-

scriptive statements about the status of security

requirements must be avoided. This is necessary

from the point of view of CPOs and CISOs be-

cause regular and recurring security audits require

an enormous amount of time.

• Automation. It must be possible to process and

evaluate the CPOs’ responses automatically. On

the one hand, this should prevent time-consuming

revisions. The time saved can be used for more

important topics in information security. On the

other hand, it can also reduce errors regarding the

interpretation of statements from the CPOs, since

the mindless evaluation of recurring facts is no

longer necessary.

4.2.2 Workshop 2: Graphical User Interface of

the Prototype

Based on the knowledge gained so far during the BIE

stage, the ADR team elaborates the graphical user in-

terface of the prototype in the following workshop.

We have come to the conclusion that for security au-

dits of public clouds, the traditional ISMS tools must

be used, but with an improved self-explaining and

easy-to-use concept of the web-based questionnaire.

This part of an ISMS tool must include the developed

requirements (cf. workshop 1) so that the identiﬁed

shortcomings can be eliminated.

In several cycles within this workshop we have

advanced the development of the prototype graph-

ical user interface by considering existing research

work (cf. stage 3: reﬂection and learning). Essen-

tially, three central design principles have inspired our

thinking:

1. Central Asset Repository. All data relating to

information security management processes need

to be stored in a central database (M

uller et al.,

2011). In our case that means, that public cloud

data must be assignable to one or more organiza-

tional units of a public administration. In addition,

the states of the respective security requirements

need to be documented for each of these relations.

2. Web-Based Questionnaire. These question-

naires are easily accessible for all stakeholders

Cloud Inspector: A Tool-Based Approach for Public Administrations to Establish Information Security Processes Towards Public Clouds

547

and the processing of online-supported dialogues

is a very simple and quick way to collect the re-

quired data on existing conditions in a structured

manner (Taniguchi et al., 2018). In relation to our

problem situation, we can use computer assisted

web interviews (CAWI) to obtain the necessary

answers to questions about concrete security re-

quirements. In our prototype, it should be possible

to map relations as follows: Standard → Require-

ment → Question → Answer option. In addition,

we have considered using placeholders in ques-

tions so that CPOs can keep track of what they are

always providing information about when editing

the questionnaires. This meets the demands for

simplicity.

3. Sentiment Analysis. To carry out a computer-

aided evaluation of the security level of a pub-

lic cloud, we will apply the principles of senti-

ment analysis (Feldman, 2013). Using predeﬁned

classes of sentiments (e.g., positive, neutral, nega-

tive, etc.), it is possible to derive an attitude about

the existing level for a concrete security require-

ment. For example, a response is considered neg-

ative if there is a lack of current IT documentation

for an application. In this respect we have created

the prerequisites for automated veriﬁcations of the

given answers.

Ultimately, the considerations were incorporated into

the design of the user interface of the web-based ques-

tionnaire (cf. ﬁgure 1).

Figure 1: Proposed design for questionnaire.

The picture shows two security requirements of

BSI IT-Grundschutz-Compendium. This standard

was assigned for the audit of a public cloud. The ﬁrst

security requirement refers to the control ORP.4.A3

Documentation of User IDs and Rights Proﬁles, the

second to the following control ORP.4.A4 Distribu-

tion of Tasks and Separation of Roles. The inter-

viewed CPO can thus easily keep track of the re-

viewed security requirements. The security require-

ments are delimited from each other by graphical

frames. In the left part of the frame, the detailed in-

formation on the security requirement is presented in

a structured manner. In the right part, the individual

questions are listed. These can be answered by click-

ing on the button ”Reply”. After a click, a modal di-

alog opens in which the predeﬁned answer options of

the selected question are displayed.

5 PROTOTYPE DEVELOPMENT

Based on the elaborated results, in the following we

describe the structure and functionality of the devel-

oped prototype. For this purpose, we ﬁrst look at

the backend of Cloud Inspector, then at the end-user

frontend that is used by CPOs. Finally, we outline

how our tool was implemented in the actual approach

within our public administration. We designed the

prototype by utilizing the programming frameworks

laravel

and livewire

. Apache is used as web server

while data is stored in a MySQL database. The proto-

type was developed between May and July 2022.

5.1 Question Management

In this sub-section we describe the backend of our

prototype. It is also used to launch security audits of

public clouds. A relationship is established between

the public cloud (asset), the CPO (auditor) and the

security requirements (audit template). Through this

assignment, auditors automatically receive an email

with the link to the online questionnaire.

In the following, we will look at the management

of questions (cf. ﬁgure 2). A question essentially

consists of the question text, the deﬁnition of an an-

swer type and the assignment to a security require-

ment. A security requirement can comprise of several

questions. A question can include several answer op-

tions if a checkbox or radio button has been selected

as the answer type. Placeholders can be integrated in

the question text in order to display dynamic identi-

ﬁers such as the name of the public cloud in the online

https://laravel.com

https://laravel-livewire.com

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

548

questionnaire.

In ﬁgure 2, the dialog for an answer options is dis-

played in the foreground. For each answer option,

an individual sentiment can be predeﬁned. In this

respect, a one-time deﬁnition of the sentiment for a

given response option already takes place before se-

curity audits are performed. Consequently, highly au-

tomated evaluations of the questionnaires can be car-

ried out to the greatest possible extent. This saves a

great deal of time and avoids interpretation errors.

Figure 2: Sentiment speciﬁcation of an answer option.

5.2 Frontend of Cloud Inspector

In this subsection we explain the user frontend of

Cloud Inspector which is used by CPOs to answer

questions about security requirements due to the sta-

tus quo of public clouds. As a result of the creation

of a new security audit, CPOs receive an email that

is automatically sent by Cloud Inspector. This email

contains a comprehensive explanation of why the au-

ditor is receiving this email and what activities need

to be done next. This approach avoids unnecessary

queries regarding the facts and the operation of the

questionnaire.

This email contains a link that leads to an

overview in the frontend in which the assigned se-

curity audits are displayed. The main interface was

deliberately designed to be simple so that CPOs can

quickly ﬁnd their way around. The central overview

clearly shows the progress made in answering the

questionnaire for each public cloud security audit.

During the development phases, we repeatedly

had direct contact with members of the ADR team

and presented and discussed the status of the fron-

tend. In this respect, we lived up to the principle of

an authentic and concurrent evaluation of our results.

Based on these interactions, we were able to make a

few signiﬁcant improvements to Cloud Inspector.

One essential change was the replacement of the

grates a secure Kerberos authentication. This allowed

us to lower the barriers to entry, getting CPOs to com-

plete the questionnaires. In addition, we have im-

proved the online questionnaire so that the answers

entered by CPOs do not have to be answered all at

once. This had the advantage for CPOs that they

could work on individual questions successively with-

out having to worry about losing the data already col-

lected.

6 EVALUATION

Between July and August 2022, we reviewed the pro-

posed tool-based approach. Our goal was to deter-

mine to what extent we could achieve improvements

in our public administration by implementing Cloud

Inspector as part of our information security pro-

cesses. For this purpose we tested the applicability

and acceptance of Cloud Inspector in our public ad-

ministration with several CPOs. In this context, we

have conducted security audits for several adopted

public clouds by applying the developed tool-based

approach.

6.1 Use Case

A typical use case for performing a security audit is

checking the validity of user identities within an ap-

plication or computer system (Osliak et al., 2021).

Since we apply the German BSI standard as ISMS

framework in our public administration, we have se-

lected the module ORP.4 Identity and Access Man-

agement from the compendium (BSI, 2021) to per-

form this security audit.

The objective of this module is to validate that

only those user IDs have access to a cloud system for

which they are authorized. Access for a user who is

no longer authorized must be revoked promptly. To

ensure this objective is achieved, regular security au-

dits must be performed to detect user identities that

are no longer authorized. The department that uses

the application must decide whether a user is autho-

rized or not.

Cloud Inspector: A Tool-Based Approach for Public Administrations to Establish Information Security Processes Towards Public Clouds

549

For the evaluation of our tool-based approach, we

applied the basic requirement ORP.4.A3 Documen-

tation of User IDs and Rights Proﬁles to verify the

validity of user identities in adopted public clouds.

The BSI requirement ORP.4.A3 includes several sub-

requirements. Using the Cloud Inspector’s question

manager, the CISO was able to create multiple sub-

questions at a ﬁne granular level. By using placehold-

ers in the question texts, it was possible to generate in-

dividual question texts for each unique public cloud.

During the evaluation, we observed that this feature

signiﬁcantly improved comprehensibility among the

CPOs.

With respect to the basic requirement ORP.4.A3,

we derived 4 detailed questions. All questions con-

sisted of multiple choice answers, each deﬁned with a

speciﬁc sentiment value. We asked 2 CISOs to model

this issue in the question manager of Cloud Inspec-

tor. On average, this activity took no longer than

10 minutes. Under real conditions, we modeled 3

public cloud assets in the repository. Based on this,

each CISO had to start a security audit on each public

cloud asset with the baseline requirement ORP.4.A3.

In sum, this activity could be completed in less than 1

minute.

During the period of the security audit, we re-

ceived feedback from the CPOs that they were able

to open the Cloud Inspector front end without any

problems and start working on the assigned question-

naires. No further explanation of how our tool-based

method works was required. Because we had in-

formed the participating CPOs about our laboratory

experiment, all respondents completed the question-

naires within one working day. Compared to the situ-

ation prior to our research project, applying our devel-

oped tool-based approach enhances the collaboration

between CISO, DPO and CPO in a simple and self-

explanatory manner.

6.2 Formalization of Learning

Overall, our work has enabled us to identify three as-

pects that are relevant for functioning ISMS processes

in public administrations in the context of cloud secu-

rity auditing.

• Regulations. Clear regulations are needed with

regard to roles and responsibilities in connection

with the procurement, implementation and the use

of public cloud services.

• Awareness. Employees of a public administration

need to have a basic understanding of cloud com-

puting and information security. This is the only

way to identify deviations in the security process

at an early stage by all parties involved.

• Tool Support. ISMS processes must be simple,

transparent and automatable in order to achieve

a high acceptance rate among the involved stake-

holders. Public clouds must be regularly audited

for security, which means that data must be reg-

ularly collected using established organizational

processes.

7 CONCLUSION AND FUTURE

WORK

In this research paper, we have addressed the prob-

lem of implementing security audits of public clouds

in the holistic information security management pro-

cess within public administrations. To address this

practical problem, we chose to apply the Action De-

sign Research method. Based on the derived research

questions, we have been able to address several scien-

tiﬁc aspects of the identiﬁed practical problem.

Our work provides several research contributions.

We clearly identiﬁed various classes of problems that

occur in public administrations. In interdisciplinary

workshops, we identiﬁed technical requirements for

managing security of public clouds in public adminis-

trations. The main contribution of this research work

deals with the optimization of information security

processes for more efﬁcient conduction of cloud secu-

rity audits within public administrations. For this pur-

pose, we developed a tool-based method based on a

web-based questionnaire with predeﬁned answer op-

tions tagged with a sentiment. We have developed

and evaluated Cloud Inspector, which can meet these

requirements in public administrations. We evalu-

ated the developed Cloud Inspector against the de-

ﬁned practical requirements and found that this ap-

proach opens a way for public administrations to use

public clouds more securely. In general, our approach

could help public administrations to implement a se-

cure digitization strategy based on public cloud ser-

vices.

With respect to our tool-based method, we have

identiﬁed several issues that should be investigated in

future research. One is to develop a technique to help

public administrations keeping track of the security

state of adopted public clouds. Secondly, a concept

for the simple and rapid implementation of security

processes in public administrations needs to be devel-

oped to avoid unnecessary loss of time in the real-

ization of urgent security measures. In addition, we

found a lack of literature regarding concepts of rais-

ing awareness of employees in public administrations

in the secure handling of cloud services.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

550

REFERENCES

Al-Shargabi, B., Al-Jawarneh, S., and Hayajneh, S. (2020).

A cloudlet based security and trust model for e-

government web services. Journal of Theoretical and

Applied Information Technology, pages 27–37.

Antunes, M., Maximiano, M., and Gomes, R. (2022). A

Client-Centered Information Security and Cybersecu-

rity Auditing Framework. Applied Sciences.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R. H., Konwinski, A., Lee, G., Patterson, D. A.,

Rabkin, A., Stoica, I., et al. (2009). Above the clouds:

A berkeley view of cloud computing.

BSI (2021). IT-Grundschutz-Compendium. Standard, Fed-

eral Ofﬁce for Information Security, Bonn, DE.

Choodakowska, A., Ka

nduła, S., and Przybylska, J. (2022).

Cybersecurity in the Local Government Sector in

Poland: More Work Needs to be Done. Lex Localis.

Cidres, E., Vasconcelos, A., and Leit

ao, F. (2020). Cloud

calculator: a cloud assessment tool for the public ad-

ministration. In Proc. of the 21st Annual International

Conference on Digital Government Research, pages

130–137.

Diener, M., Blessing, L., and Rappel, N. (2016). Tackling

the cloud adoption dilemma - A user centric concept

to control cloud migration processes by using machine

learning technologies. In Proc. of the 11th Int. Conf.

on Availability, Reliability and Security (ARES), pages

776–785. IEEE.

EU Commission (2022). The Digital Economy and Society

Index (DESI).

European Union (2018). Regulation (EU) 2018/1724 of the

European Parliament and of the Council of 2 October

2018 establishing a single digital gateway to provide

access to information, to procedures and to assistance

and problem-solving services and amending Regula-

tion (EU) No 1024/2012.

Feldman, R. (2013). Techniques and applications for sen-

timent analysis. Communications of the ACM, pages

82–89.

Gartner (2022). Umsatz mit Cloud Computing weltweit von

2010 bis 2021 und Prognose bis 2023. Statista.

KonBrieﬁng Research (2022). Statistics: Major cyber at-

tacks on the public sector 1st quarter 2022. Technical

report.

Lins, S., Schneider, S., Szefer, J., Ibraheem, S., and Sun-

yaev, A. (2019). Designing monitoring systems for

continuous certiﬁcation of cloud services: deriving

meta-requirements and design guidelines. Commu-

nications of the Association for Information Systems,

pages 460–510.

Markus, H. and Meuche, T. (2022). IT-Sicherheit, Daten-

schutz und Vergaberecht als Bremsen der Digital-

isierung der

offentlichen Verwaltung? In Auf dem Weg

zur digitalen Verwaltung: Ein ganzheitliches Konzept

ur eine gelingende Digitalisierung in der

offentlichen

Verwaltung, pages 205–242. Springer.

Mell, P., Grance, T., et al. (2011). The NIST deﬁnition of

cloud computing.

Moses, F., Sandkuhl, K., and Kemmerich, T. (2022). Em-

pirical Study on the State of Practice of Information

Security Management in Local Government. In Proc.

of the Conference on Human Centred Intelligent Sys-

tems (HCIS), pages 13–25. Springer.

uller, I., Han, J., Schneider, J.-G., and Versteeg, S. (2011).

Idea: a reference platform for systematic information

security management tool support. In Prof. of the third

Int. Symposium on Engineering Secure Software and

Systems (ESSoS), pages 256–263. Springer.

Osliak, O., Saracino, A., Martinelli, F., and Dimitrakos, T.

(2021). Towards Collaborative Cyber Threat Intelli-

gence for Security Management. In Proc. of the 7th

Int. Conf. on Information Systems Security and Pri-

vacy (ICISSP), pages 339–346.

Rehbohm, T., Sandkuhl, K., and Kemmerich, T. (2019).

On challenges of cyber and information security man-

agement in federal structures - the example of ger-

man public administration. In Proc. of the Joint Int.

Conf. on Perspectives in Business Informatics Re-

search Workshops and Doctoral Consortium (BIR-WS

2019), volume 2443, pages 1–13. CEUR-WS.

Samonas, S. and Coss, D. (2014). The CIA strikes back:

Redeﬁning conﬁdentiality, integrity and availability

in security. Journal of Information System Security,

pages 21–45.

Sein, M. K., Henfridsson, O., Purao, S., Rossi, M., and

Lindgren, R. (2011). Action design research. MIS

quarterly, pages 37–56.

Stephanow, P. and Banse, C. (2017). Evaluating the per-

formance of continuous test-based cloud service cer-

tiﬁcation. In Proc. of the 17th IEEE/ACM Interna-

tional Symposium on Cluster, Cloud and Grid Com-

puting (CCGRID), pages 1117–1126. IEEE.

Sterbak, M., Segec, P., and Jurc, J. (2021). Automation

of risk management processes. In Proc. of the 19th

Int. Conf. on Emerging eLearning Technologies and

Applications (ICETA), pages 381–386. IEEE.

Szczepaniuk, E. K., Szczepaniuk, H., Rokicki, T., and

Klepacki, B. (2020). Information security assessment

in public administration. Computers & Security.

Tambou, O. and Pato, A. (2021). Covid-19 vaccination

and data protection issues: A european comparative

study with focuses on france, germany, belgium, and

switzerland. MPILux Research Paper.

Taniguchi, T., Maruyama, Y., Kurita, D., and Tanaka, M.

(2018). Analysis and classiﬁcation of university stu-

dents’ educational skills using a computer-assisted

web-interviewing questionnaire. Procedia computer

science, pages 2021–2029.

Wang, T. and Bashir, M. N. (2022). An Analysis of Cloud

Certiﬁcations’ Performance on Privacy Protections. In

Proc. of the 8th Int. Conf. on Information Systems Se-

curity and Privacy (ICISSP), pages 299–306.

Cloud Inspector: A Tool-Based Approach for Public Administrations to Establish Information Security Processes Towards Public Clouds

551
