An Evaluation Method and Comparison of

Modern Cluster-based Highly Available Database Solutions

Raju Shrestha

and Tahzeena Tandel

Oslo Metropolitan University (OsloMet), Oslo, Norway

Keywords:

High Availability, Database, Cloud Computing, Replication, Multi-Master, Clustering, Evaluation,

Comparison.

Abstract:

High availability in cloud computing is a top concern which refers to keeping a service operational and

available for the maximum amount of time without downtime. In any given application and service, the high

availability of the database plays a critical role in the application’s high availability as a whole. Modern

cluster-based multi-master technologies provide high availability database solutions through synchronous

replication. Different database management systems offer different technologies and solutions for high

availability. This paper proposes a comprehensive method for the evaluation of high availability database

solutions. As a comparative case study, two modern high availability database solutions which are open-source

and available for free use, namely the Percona XtraDB Cluster and the MySQL NDB Cluster are used.

Benchmark tests with standard CRUD database operations and analysis of the test results show that no single

solution is superior to the other in all scenarios and needs. Therefore, one should choose an appropriate

solution wisely depending on the needs for an application or service. The proposed evaluation method would

be useful to get insights into which solution is effective for a given application and hence it can be used in

making an informed choice among different solutions at hand.

1 INTRODUCTION

An application or service is said to be highly available

if it is operational and available for a higher than

normal period without downtime (Endo et al., 2016).

Availability is usually expressed as apercentage of

uptime in a given year (e.g., 99.999%) (Piedad and

Hawkins, 2008). As most of the modern cloud-based

applications and services are database driven, high

availability of database or highly availabe database

(HADB) is critical to the high availability of the

application or service as a whole.

Data replication techniques are primarily used

for making databases highly available in distributed

systems (Gopinath and Sherly, 2018) such as

peer-to-peer systems (Ez

echiel et al., 2017), mesh

networking (Milani and Navimipour, 2017) and

distributed data management systems (Liu and

Vlassov, 2013). Many technologies and solutions

have been proposed for achieving database high

availability ranging from simple and traditional

data replication to clustering for providing as

highly available as 99.999%. HADB aims for

https://orcid.org/0000-0001-6409-8893

reduced downtime as well as for reduced response

time and increased throughput (Hvasshovd et al.,

1995). Different applications demand different

levels of availability (Dahiya and Ahlawat, 2015).

While mission-critical applications cannot afford any

downtime and demand continuous service uptime,

i.e., 100% availability of both read and write access.

The higher the level of availability needed, the higher

will be the level of complexity and cost associated

with it.

In recent years, modern cluster-based

architectures have gained much attention as

alternatives to traditional master-slave architectures

because of their promising features to deliver

continuous availability and enhanced performance.

They are mostly based on multi-master technology

and synchronous replication to address data

inconsistency, eliminate single point of failure, and

use architectures designed to provide higher levels of

availability. Percona XtraDB Cluster (Percona, 2022)

and MySQL NDB Cluster (MySQL, 2022) are the

two examples of major cluster-based technologies

that are available open-source.

Shrestha, R. and Tandel, T.

An Evaluation Method and Comparison of Modern Cluster-Based Highly Available Database Solutions.

DOI: 10.5220/0011714400003488

In Proceedings of the 13th International Conference on Cloud Computing and Services Science (CLOSER 2023), pages 131-138

ISBN: 978-989-758-650-7; ISSN: 2184-5042

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

131

Having many different solutions available, an

obvious challenge one has to face is the selection

of a suitable solution among them. In this paper, a

comprehensive method for evaluating and comparing

HADB solutions is provided. We believe the method

helps get insight into the different technologies and

in turn, helps choose a suitable HADB solution for

a given application. As a case study, two popular

technologies, Percona XtraDB Cluster and MySQL

NDB, Cluster, are evaluated and compared both

quantitatively and qualitatively.

2 BACKGROUND AND RELATED

WORKS

Data replication is a primary approach used for highly

available databases. There are basically two data

replication technologies: master-slave replication and

cluster-based multi-master replication. In master-

slave database replication, a master database server

handles data writes, while multiple slave servers are

used to read data, thus supporting read scalability

(Wiesmann and Schiper, 2005; Curino et al., 2010).

Any changes in the master database are replicated

in the slaves asynchronously. When the master

fails, one of the slaves is automatically promoted

to the master. Asynchronous replication doesn’t

guarantee the delay between applying changes on

the master and propagation of changes to the

slaves, which may cause data inconsistencies when

something goes wrong in the master database server

in the middle of a transaction. Thus, master-slave

replication doesn’t guarantee consistency, one among

the three: consistency, availability, and partition

tolerance in Brewer’s CAP theorem (Brewer, 2012).

Some database systems support semi-synchronous

master-slave replication (Dimitri, 2017) to mitigate

the problem. Multi-master cluster-based database

replication techniques address data inconsistency

problems through synchronous replication. In

synchronous replication, users can both read from and

write to any of the replicas (Ez

echiel et al., 2017).

For high availability databases, different database

management systems support different solutions.

Section 3 gives an overview of some of the

major HADB solutions offered by different Database

Management Systems (DBMSs).

A performance-based comparative study between

master-slave and cluster-based HADB solutions

showed that master-slave replication performs equal

or better in terms of throughput and response

time (Shrestha, 2017). However, cluster-based

solution is superior when it comes to high avail-

ability, data consistency, and scalability as it offers

instantaneous failover, no loss of data, and both

read and write scalability. Another study found that

container-based setup performed better compared to

virtual machine-based setup (Shrestha, 2020). In both

studies, performance was evaluated through Sysbench

online transaction processing benchmark tests using

two quantitative performance metrics, throughput,

and response time.

(Ha et al., 2016) compared performance of

HADB in PostgresSQL with two different replication

managers, same-containment Keepalived-RepMgr

and cross-containment HAProxy-PgBouncer. They

deﬁned different workloads for performance testing

using Apache JMeter and reported results for

throughput, and response time. They concluded that

the performance of HAProxy-PgBouncer is better for

throughput with load balancing abilities as compared

to Keepalived-RepMgr.

Literature study showed that most of the previous

studies on HADB solutions use one particular

database management system and they mainly use

quantitative metrics in their evaluation. In this

paper, we tried to address this through a systematic

evaluation of HADB solutions both quantitatively

and qualitatively, and at the same time focusing on

modern cluster-based solutions.

3 OVERVIEW OF HIGH

AVAILABILITY DATABASE

SOLUTIONS

Among open-source databases, MySQL and Mari-

aDB are embedded with solutions such as data

replication for data backup, clustering with shared

storage, shared-nothing architecture, and clusters

replicated in geographical locations. Master-slave

architecture has been in the ecosystem for a long time

as a HADB solution in databases such as MariaDB,

MySQL, and Microsoft SQL Server. MongoDB

provides master-slave replication through replica sets,

which use elections to support high availability (Gu

et al., 2015). Elections occur when the primary

becomes unavailable and replica set autonomously

select a new primary. MongoDB can also use

sharding to distribute large data to multiple instances.

Most of the modern DBMSs support cluster-based

multi-master replication for highly available

databases. Microsoft SQL Server supports multi-

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

132

master Peer-to-Peer (P2P) replication

, in which

each node is both a publisher and a subscriber.

Data is replicated in multiple nodes and apply the

changes to the destination in near real-time. It is

a good scaling solution for reads as they can be

serviced through multiple nodes. High availability

is achieved by routing the writes from the failed

node to the live node. P2P replication has an issue

in that there could be some latency while applying

data changes to other nodes and hence data loss

can occur (Mishra et al., 2008). Microsoft SQL

Server offers a new high availability solution, called

Failover Cluster Instances (FCI) with always-on

Availability Groups (AGs). FCI leverages Windows

Server Failover Cluster (WSFC), which is a group of

independent servers that work together to increase

the availability of applications and services to support

always-on availability groups (Parui and Sanil,

2016). The always-on availability groups feature is a

high-availability and disaster-recovery solution that

provides an enterprise-level alternative to database

mirroring. An FCI is used to host an availability

replica for an availability group.

PostgresSQL supports bidirectional replication

(BDR) as an enhanced feature for high availability

multi-master solutions (Raja and Celentano, 2022). It

uses a standby replica for each master, with a master

replica forming a cluster. Data ﬂows from both master

to standby and from standby to master with streaming

logical replication. BDR, thus, has both physical

and logical replication providing strong resiliency.

BDRv3 supports fully automatic replication of both

Data Manipulation Language (DML)) and Data

Deﬁnition Language (DDL). Commit At Most Once

(CAMO) ensures that any in-ﬂight transactions with

unknown states are fully resolved.

Oracle offers various architectures for different

level of high availability

. Among them, cluster-

based Oracle Real Application Clusters (RAC) and

Oracle Data Guard is the most comprehensive

architecture, which reduces downtime for scheduled

outages with premention, detection, and recovering

mechanisms from unscheduled outages, and provides

the highest level of availability. Oracle RAC is

a shared everything database, which uses Oracle

Clusterware, a cluster management solution that binds

a pool of servers into the cluster, providing maximum

Microsoft SQL Sever Peer-to-Peer Transactional

Replication, https://learn.microsoft.com/en-us/sql/

relational-databases/replication/transactional/peer-to-

peer-transactional-replication

Oracle High Availability Architectures and Solutions,

https://docs.oracle.com/cd/E11882 01/server.112/e17157/

architectures.htm

write-scalability. It is recommended that Oracle

RAC and Oracle Data Guard reside on separate

clusters and data centers. Oracle Data Guard supports

both synchronous mode for maximum protection and

availability of data, and asynchronous mode for better

response time in systems with a network bottleneck.

Among others, MariaDB Galera Cluster (Mari-

aDB, 2022), Percona XtraDB Cluster (Percona,

2022), and MySQL NDB Cluster (MySQL, 2022),

are three widely used open-source cluster-based

multi-master HADB solutions. Percona XtraDB

Cluster is a variant of Galera Cluster

. We used

Percona XtraDB Cluster and MySQL NDB Cluster

as a case study in our comparative study in this

paper because they are free, modern, and open source

and they use different storage engines. The two

technologies are described brieﬂy below.

Percona XtraDB Cluster (PXDB) is a synchronous

multi-master clustering technology, which uses

certiﬁcation-based replication. It uses the Percona

server for MySQL and Galera library with write

set replication (wsrep). Recommended conﬁguration

is to have at least 3 nodes, but one can make

it run with 2 nodes as well (Tkachenko, 2012).

For data consistency, the XtraDB storage engine,

a drop-in equivalent to the InnoDB storage engine

with an enhanced set of features, is used and data

is kept synced in all the nodes through synchronous

replication of Data Deﬁnation Language (DDL)

and Data Manipulation Language (DML) actions.

PXDB uses Galera replication protocol for DML

actions and total order isolation for DDL actions

to ensure consistency in the cluster (Krunal, 2016).

The binary log format is set to row for row-level

replication. Certiﬁcation-based replication is used

to avoid transaction conﬂicts. Figure 1 shows the

architecture of Percona XtraDB Cluster.

Read

Write

Node1

Node2

Node3

Group

communication

Figure 1: Percona XtraDB Cluster architecture (Tkachenko,

2012).

Galera Cluster - A new type of highly consistent MySQL

Cluster architecture, https://www.programmersought.com/

article/6193909457

An Evaluation Method and Comparison of Modern Cluster-Based Highly Available Database Solutions

133

MySQL NDB Cluster (MNDB) is a HADB solution

for MySQL database system with an underlying stor-

age engine used is NDB (Network DataBase), which

is implemented using a distributed, shared-nothing

architecture with automatic failover and self-healing,

providing high levels of availability (MySQL, 2022).

It has three different types of nodes: management

node – used to monitor, maintain, and manage the

cluster, data node – used to store data, and SQL

node – used to access data in data nodes. MySQL

Servers provide an SQL interface to access the data

stored in data nodes. The minimum recommended

number of nodes is four: one management, one SQL

node, and two data nodes. There can be several node

groups; each node group consists of one or more data

nodes. However, one can make it work with one data

node as well. The cluster is available till one node in

each node group is alive. MNDB has a built-in fault

tolerance with a heartbeat mechanism, where each

table created gets partitioned into data nodes, each

data node holding its own primary replica and also a

copy of secondary replica. Replication in data nodes

is performed synchronously using a protocal called

a two-phase commit. (Mether, 2013; King, 2015).

Figure 2 shows the MNDB Cluster architecture.

Applications

SQL Nodes

Data Nodes

Management

Node

Management

Client

Figure 2: MySQL NDB Cluster architecture (Mether,

2013).

4 EVALUATON METHOD

The proposed method for evaluating and comparing

HADB technologies or solutions consists of quali-

tative and quantitative evaluations based on various

attributes and metrics. They are described in the

following subsections.

4.1 Qualitative Evaluation

HADB solutions can be compared qualitatively based

on their type and support in terms of ﬁve different

attributes. They are architecture, replication type,

scale-out, level of availability, and automatic failover

support.

Architecture: Basically, architecture could be either

master-slave or multi-master. Some DBMSs use the

term primary-secondary for the master-slave. Archi-

tecture also deﬁnes the minimum or recommended

number of nodes required for a HADB setup.

Replication Type: A HADB could offer either

asynchronous or synchronous or both.

Scale-Out: Scale-out support is an essential feature

in a cloud infrastructure. The scale-out attribute

deﬁnes whether a HADB supports scaling of

read-only or both read and write.

Availability: Availability attribute indicates the level

of database availability. We have deﬁned three levels

as low (90% or below), medium (90-99%), and high

(above 99%).

Automatic Failover: Automatic failover is yet

another important feature in a HADB. Some HADBs

do not support failover at all, some support automatic

failover, while some other offer automatic failover.

Depending on the needs of the application at hand,

these attributes help make decisions in the selection of

an appropriate HADB solution.

4.2 Quantitative Evaluation

A quantitative comparison is done based on

performance evaluation of the HADB solutions under

benchmark tests with standard CRUD (Create, Read,

Update, and Delete) database operations. Most of

the previous studies (Ha et al., 2016; Shrestha, 2020)

used mainly two performance metrics, throughput

and response time in their performance evaluation.

Since resource usage such as CPU and memory are

also important factors that are commonly considered

while comparing different systems (Birke et al., 2012;

Kozhirbayev and Sinnott, 2017), we have added two

more metrics, CPU use and Memory use in our

quantitative comparison. The four metrics used are

deﬁned as follows.

Throughput: Throughput is deﬁned as the number

of transactions executed per second (tps). Higher

the throughput, the better the performance of the

HADB (Krzysztof, 2021).

Response Time: Response time (or latency) is the

time taken to execute a transaction. A lower response

time means better performance.

CPU Use: It is the percentage utilization of CPUs.

The lower the CPU use with similar setups, the better

the system is.

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

134

Memory Use: It is the percentage utilization of

system memory. Just like CPU use, a lower Memory

use with similar setups means a better system.

Based on these performance metrics obtained

through experiments with the two HADB setups using

MySQL NDB Cluster and Percona XtraDB Cluster,

the two HADB solutions are evaluated and compared.

5 EXPERIMENTAL SETUP AND

TESTS

This section describes the implementation and setups

of the two HADBs, and benchmark and failover tests

conducted to evaluate and compare them.

HADB Setups: Percona XtraDB Cluster (PXDB)

and MySQL NDB Cluster (MNDB) based HADBs

are set up on the OpenStack cloud at the university

(see Figures 3 and 4). Nodes in both setups are

implemented with a virtual machine (VM), created in

a private network. Necessary security rules and ports

are opened to allow TCP/IP communication between

them. The same speciﬁcation of the operating system:

Ubuntu 18.04, CPU: 1 VCPU, Memory: 2 GB, and

Storage: 20GB was used for all the database nodes.

For a fair comparison, the same total number of VMs

(four) were used in the two setups. The PXDB

setup has four database nodes and the MNDB setup

has two SQL nodes and one node group consisting

of two data nodes. MySQL NDB Cluster version

8 and Percona XtraDB version 8 were used in the

experimental setups. In both setups, a server with

HAProxy

was used as a load balancer as well as

an application server. ClusterControl

, a database

management tool, was used to deploy, manage, and

monitor clusters.

Node1

Node2

Node3Node4

HAProxy load balancer

and Application server

ClusterControl

Figure 3: Percona XtraDB Cluster (PXDB) setup.

Benchmark Tests: Sysbench v1.0.20

, a popular

and powerful database benchmarking tool, was used

to perform various benchmark tests under intensive

HAProxy - The Reliable, High Performance TCP/HTTP

Load Balancer, http://www.haproxy.org

ClusterControl, https://docs.severalnines.com/docs/

clustercontrol

Sysbench, https://github.com/akopytov/sysbench

ClusterControl

Management

Node

HAProxy load balancer

and Application server

SQL

Node1

SQL

Node2

Data

Node1

Data

Node2

Figure 4: MySQL NDB Cluster (MNDB) setup.

loads. Four different benchmark tests, ReadOnly,

ReadWrite, Update, and Delete, were performed

using the Online Transaction Processing (OLTP))

benchmark that comes with Sysbench. OLTP was

used as it is close to common real-world dynamic

database-driven web applications. OLTP ReadWrite

consists of a mix of about 70% read (SELECT) and

30% write (INSERT, UPDATE and DELETE). In

these tests, a test database was prepared with 50 tables

of size 10000 rows, which took about 134MB of

disk space. The size was set so that it ﬁts well in

the storage buffer pool in Percona XtraDB and data

memory in MySQL NDB.

Benchmark tests were run for different numbers

of threads (8, 16, 32, 64, 72) and each test was run for

120 seconds. Tests were repeated for ﬁve times and

average throughput and response time values were

used in the results and analysis. CPU and Memory

utilization were obtained using s9s ClusterControl

CLI command (Ashraf, 2017). For each test run,

average CPU and Memory usage were computed for

values taken every 30 seconds for two minutes. CPU

and Memory use amount to the resource consumption

by database engines, connection, communication,

data replication and synchronization between the

nodes, and operating system.

Failover Test: The two HADBs were also tested for

failover scenarios to see how they behave in case of

failures. PXDB was tested by abruptly disconnecting

one and two nodes from the network, while MNDB

was tested by disconnecting one SQL node and one

data node.

6 RESULTS AND DISCUSSION

Results from the study are presented and discussed

here in three different parts: benchmark test results,

failover test results, and qualitative evaluation.

Benchmark Test Results: Figures 5 and 6 show

benchmark test results in terms of throughput and

response time respectively.

An Evaluation Method and Comparison of Modern Cluster-Based Highly Available Database Solutions

135

620

1170

1720

2270

2820

3370

3920

8 16 32 64 72

Number of threads

170

270

370

470

570

8 16 32 64 72

Throughput (tps)

Number of threads

ReadOnly

ReadWrite

Update

Delete

PXDB MNDB

Figure 5: Benchmark test results in terms of throughput.

100

200

300

400

500

600

8 16 32 64 72

Response tIme (Milliseconds)

Number of threads

ReadOnly

ReadWrite

Update

Delete

PXDB MNDB

Figure 6: Benchmark test reults in terms of response time.

We observed that in ReadOnly and ReadWrite

tests on both HADBs, throughput didn’t increase

but rather decrease in some cases after increasing

the number of threads beyond 16 (see Figure 5).

This is because of row locking and internal resource

contention with the further increase in the threads.

In the case of Update and Delete tests, throughput

still increases slightly beyond threads 16, possibly

due to lesser resource contention. Since ReadOnly

and ReadWrite are the two most common database

operations in OLTP applications, we consider 16

threads as optimal in terms of throughput in our

setups. In terms of response time, as expected,

response time increases with the increase in the

number of threads in all the tests, though with

different degrees. ReadWrite tests have the lowest

throughput and highest response time in both

HADBs. This is because when data is written, it

needs to be replicated and synchronized with the other

nodes in a cluster which takes more time and hence

lowers throughput and increased response time.

Among the two HADBs, PXDB had signiﬁcantly

higher throughput in ReadOnly tests compared to

MNDB, but the scenario was opposite in Update and

Delete tests. Both HADB performed more or less the

same in ReadWrite tests. Similar performance was

observed from the two HADBs in terms of response

time also.

Figures 7 and 8 show CPU and Memory usage

in the two HADBs under four benchmark tests. As

anticipated, CPU use increased gradually with the

increase in the number of threads in both HADBs

under all four tests. Similar behavior was observed

with PXDB in ReadWrite and Delete tests. While

memory use remained more or less constant in other

tests in both HADBs.

8 16 32 64 72

CPU use (%)

Number of threads

ReadOnly

ReadWrite

Update

Delete

PXDB MNDB

Figure 7: CPU use in different benchmark tests.

8 16 32 64 72

Memory use (%)

Number of threads

Readonly

ReadWrite

Update

Delete

PXDB MNDB

Figure 8: Memory use in different benchmark tests.

MNDB used less or similar CPU and Memory

compared to PXDB in all the tests, indicating its

superiority in terms of both CPU and Memory use.

To provide a general overview of the performance

of the two HADBs, Table 1 gives benchmark test

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

136

results in terms of all four metrics when the number

of threads was 16. From the table, we see that MNDB

outperforms PXDB in all the tests except in ReadOnly

test, where PXDB has higher throughput and lower

response time.

Table 1: Comparative results from benchmark tests with

the two HADBs when the number of threads was 16.

Numbers shown in green indicate better performance over

the corresponding ones shown in red.

HADB

Benchmark test

Metric

ReadOnly ReadWrite Update Delete

Throughput (tps) 489 89 530 515

Response time (ms) 33 204 30 32

CPU use (%) 78 64 79 71

Memory use (%) 71 62 67 51

Throughput (tps) 175 131 2434 3529

Response time (ms) 91 122 7 5

CPU use (%) 50 54 67 64

Memory use (%) 50 44 55 50

PXDB

MNDB

Failover Test Results: Failover tests show that

PXDB continued to be operational and was available

even when two random nodes were disconnected,

keeping the three minimum nodes as required by

PXDB. No failure-related hiccups were observed.

MNDB was also available and working normally

when one SQL node and one data node were

disconnected. This test conﬁrmed that both HADBs

supported automatic failover making them highly

available as long as the minimal number of nodes are

there.

Qualitative evaluation: Comparing the two HADBs

in terms of the qualitative attributes described in

Section 4, both PXDB and MNDB are based on

multi-master architecture, with the former requiring

three recommended nodes while the latter requires

four recommended nodes (1 management node, 1

SQL node, and 2 data nodes). Both HADBs

use synchronous replication, support both read and

write scaling, with built-in automatic failover, thus

providing higher level of availability.

Based on the qualitative and quantitative evalua-

tion of the two HADBs, one can select an appropriate

solution according to the need for the application

or service at hand. For a side-by-side comparison

between different solutions (PXDB and MNDB in our

case study), we can create a simplistic comparative

table as shown in Table 2, where numeric metric

values are translated as low, moderate, and high.

The experiments conducted in the case study with

two HADB solutions, PXDB and MNDB, were based

on the setups in the OpenStack cloud setup at the

university with certain resource limitations. However,

Table 2: Comparion table between two HADBs. Better

indicators are shown in green, while relatively worse

indicators are shown in red.

Attributes PXDB MNDB

Architecture

Multi-master;

Min. 3 nodes

Multi-master;

Min. 4 nodes

Replication type Synchronous Synchronous

Scale-out Both read write Both read write

Data consistency Yes Yes

Availability High High

Throughput for Read only High Low

Throughput for ReadWrite Low High

Throughput for Update & Delete Low High

Response time for ReadOnly Low High

Response time for ReadWrite High Low

Response time for Update & Delete High Low

CPU use High Moderate

Memory use High Moderate

the results from the benchmark tests provide a general

idea about the performance of the two HADBs.

Since none of the two HADBs shows superior

performance in all aspects, one should make a wise

decision while selecting a HADB. For example, if an

application will have signiﬁcantly much more read

than write, update, and delete in its database, then

it’d be wise to select PXDB over MNDB as it has

signiﬁcantly better throughput and response time.

Otherwise, MNDB would be a better choice.

7 CONCLUSION

The proposed evaluation method comprising both

qualitative and quantitative evaluation provides a

systematic and comprehensive evaluation of high

availability database technologies and solutions.

Both the modern cluster-based high availability

database solutions tested and compared in our

case study, Percona XtraDB Cluster and MySQL

NDB Cluster use multi-master architecture and

synchronous replication enabling data consitency and

high availability and support both read and write

scaling. Performance-wise Percona XtraDB Cluster

has been found to offer high throughput and low

response time for ReadOnly tests while MySQL NDB

Cluster has shown superior performance with high

throughput and low response time and lower CPU and

Memory use in ReadWrite, Update, and Delete tests.

By following the proposed evaluation method, one

can evaluate, compare, and select a suitable solution

from among different solutions available at one’s

disposal, for a given application or service.

An Evaluation Method and Comparison of Modern Cluster-Based Highly Available Database Solutions

137

REFERENCES

Ashraf, S. (2017). The Command Line Interface to Clus-

terControl. Serverlines, Online: https://severalnines.

com/blog/command-line-interface-clustercontrol/.

Birke, R., Chen, L. Y., and Smirni, E. (2012). Data centers

in the cloud: A large scale performance study. In

2012 IEEE Fifth International Conference on Cloud

Computing, pages 336–343.

Brewer, E. (2012). Pushing the CAP: Strategies for

Consistency and Availability. Computer, 45(2):23–29.

Curino, C., Jones, E., Zhang, Y., and Madden, S. (2010).

Schism: A workload-driven approach to database

replication and partitioning. Proc. VLDB Endow.,

3(1-2):48–57.

Dahiya, S. and Ahlawat, P. (2015). Choosing between high

availability solutions in Microsoft SQL Server. 4:387–

391.

Dimitri, V. (2017). Different types of MySQL replication

solutions. Percona Database Performance Blog,

Online: https://www.percona.com/blog/2017/02/07/

overview-of-different-mysql-replication-solutions.

Endo, P. T., Rodrigues, M., Gonc¸alves, G. E., Kelner,

J., Sadok, D. H., and Curescu, C. (2016). High

availability in clouds: Systematic review and research

challenges. Journal of Cloud Computing, 5.

echiel, K. K., Agarwal, R., and Kaushik, B. N.

(2017). Synchronous and asynchronous replication. In

International Conference On Machine Learning and

Computational Intelligence.

Gopinath, S. and Sherly, E. (2018). A comprehensive

survey on data replication techniques in cloud

storage systems. International Journal of Applied

Engineering Research, 13:15926–15932.

Gu, Y., Wang, X., Shen, S., Ji, S., and Wang, J. (2015).

Analysis of data replication mechanism in NoSQL

database MongoDB. In Proeedings of the IEEE

International Conference on Consumer Electronics

(ICCE), pages 66–67, Taiwan. IEEE.

Ha, L. Q., Xie, J., Millington, D., and Waniss,

A. (2016). Comparative performance analysis

of PostgreSQL high availability database clusters

through containment.

Hvasshovd, S. O., Torbjørnsen, O., Bratsberg, S. E., and

Holager, P. (1995). The ClustRa Telecom Database:

High availability, high throughput, and real-time

response. In Proceedings of the 21st International

Conference on Very Large Data Bases, VLDB ’95,

pages 469–477, San Francisco, CA, USA. Morgan

Kaufmann Publishers Inc.

King, C. (2015). The trade-offs between MySQL

cluster and Master/Slave content. White paper,

https://www.datavail.com/resources/the-trade-offs-

between-mysql-cluster-masterslave.

Kozhirbayev, Z. and Sinnott, R. O. (2017). A performance

comparison of container-based technologies for the

cloud. Future Generation Computer Systems, 68:175

– 182.

Krunal, B. (2016). How Percona XtraDB cluster certiﬁ-

cation works. Percona Database Performance Blog,

Online: https://www.percona.com/blog/2016/04/17/

how-percona-xtradb-cluster-certiﬁcation-works.

Krzysztof, K. (2021). How to measure database

performance. Online: https://severalnines.com/

database-blog/how-measure-database-performance.

Liu, Y. and Vlassov, V. (2013). Replication in distributed

storage systems: State of the art, possible directions,

and open issues. In Proceedings of the International

Conference on Cyber-Enabled Distributed Computing

and Knowledge Discovery, pages 225–232.

MariaDB (2022). What is MariaDB Galera Cluster?

Online: https://mariadb.com/kb/en/what-is-mariadb-

galera-cluster/.

Mether, M. (2013). MySQL cluster internal

architecture. Online: https://mariadb.com/

ﬁles/MySQL

Cluster Internal Architecture -

MariaDB White Paper - 08-26-13-001 1.pdf.

Milani, B. A. and Navimipour, N. J. (2017). A systematic

literature review of the data replication techniques in

the cloud environments. Big Data Research, 10:1–7.

Mishra, S., Mehra, P., Rao, V., and Ashok, G. (2008).

Proven SQL Server architectures for high availability

and disaster recovery.

MySQL (2022). MySQL NDB cluster 8.0. Online:

https://dev.mysql.com/doc/mysql-cluster-

excerpt/8.0/en/mysql-cluster-overview.html.

Parui, U. and Sanil, V. (2016). Introduction to Windows

Server Failover Clustering. Pro SQL Server Always

On Availability Groups, pages 45–52.

Percona (2022). Percona XtraDB cluster 8.0 documenta-

tion. Online: https://www.percona.com/doc/percona-

xtradb-cluster/LATEST/index.html.

Piedad, F. and Hawkins, M. (2008). High availability:

Design, techniques, and processes. Harris Kern’s

Enterprise Computing Institute Series. Prentice Hall.

Raja, Y. and Celentano, P. (2022). PostgreSQL

bi-directional replication using pglogical. Online:

https://aws.amazon.com/blogs/database/postgresql-

bi-directional-replication-using-pglogical.

Shrestha, R. (2017). High availability and performance

of database in the cloud: Traditional Master-slave

replication versus modern Cluster-based solutions. In

Proceedings of the 7th International Conference on

Cloud Computing and Services Science, CLOSER,

pages 413–420, Portugal. SciTePress.

Shrestha, R. (2020). Performance of cluster-based

high availability database in cloud containers. In

Proceedings of the 10th International Conference on

Cloud Computing and Services Science, CLOSER,

pages 320–327. SciTePress.

Tkachenko, V. (2012). Percona XtraDB Cluster

Feature 1: High availability. Online:

https://www.percona.com/blog/2012/01/17/xtradb-

cluster-feature-1-high-availability/.

Wiesmann, M. and Schiper, A. (2005). Comparison of

database replication techniques based on total order

broadcast. IEEE Transactions on Knowledge and

Data Engineering, 17(4):551–566.

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

138
