Put Your PPE on: A Tool for Synthetic Data Generation and Related

Benchmark in Construction Site Scenarios

Camillo Quattrocchi

1 a

, Daniele Di Mauro

1,2 b

, Antonino Furnari

1,2 c

, Antonino Lopes

Marco Moltisanti

3 d

and Giovanni Maria Farinella

1,2,4 e

Next Vision s.r.l. - Spinoff of the University of Catania, Italy

Xenia Network Solutions s.r.l, Italy

ICAR-CNR, Palermo, Italy

Keywords:

Synthetic Data, Safety, Pose Estimation, Object Detection.

Abstract:

Using Machine Learning algorithms to enforce safety in construction sites has attracted a lot of interest in

recent years. Being able to understand if a worker is wearing personal protective equipment, if he has fallen in

the ground, or if he is too close to a moving vehicles or a dangerous tool, could be useful to prevent accidents

and to take immediate rescue actions. While these problems can be tackled with machine learning algorithms,

a large amount of labeled data, difﬁcult and expensive to obtain are required. Motivated by these observations,

we propose a pipeline to produce synthetic data in a construction site to mitigate real data scarcity. We present

a benchmark to test the usefulness of the generated data, focusing on three different tasks: safety compliance

through object detection, fall detection through pose estimation and distance regression from monocular view.

Experiments show that the use of synthetic data helps to reduce the amount of needed real data and allow to

achieve good performances.

1 INTRODUCTION

Construction sites are one of the most dangerous

place where to work

and the reduction of fatal acci-

dents is crucial in this context. In recent years, due to

the availability of low cost cameras, high bandwidth

wireless connections, as well as hardware and soft-

ware platforms to exploit computer vision and ma-

chine learning, methods to accomplish this goal have

gained attention. Monitoring the compliance to safety

measures and automatically triggering alarms are two

of the main areas where computer vision algorithms

can help reduce fatal accidents.

The main downside of approaches based on ma-

chine learning is “data hungriness”: to solve complex

problems, algorithms need a large amount of labeled

https://orcid.org/0000-0002-4999-8698

https://orcid.org/0000-0002-4286-2050

https://orcid.org/0000-0001-6911-0302

https://orcid.org/0000-0003-3984-9979

https://orcid.org/0000-0002-6034-0432

https://ec.europa.eu/eurostat/statistics-explained/

index.php?title=File:Fatal and non-fatal accidents 5.png

data from which to learn. More importantly, the re-

quired data tends to be domain-speciﬁc and hence a

new collection and labeling effort may be required

whenever a new task is considered or a new system

is installed. Acquiring and labeling a dataset is a

costly and time-consuming process and in some envi-

ronments, such as construction sites, it faces problems

which are not always surmountable, such as privacy

concerns and the inability to capture a good amount

of rare events such as accidents.

A consolidated way to get around the lack of data

is to exploit realistic but synthetic data. Such data can

be generated using a 3D simulator which can auto-

matically label different properties of the data, such

as the presence of objects and people in the scene,

thus leading to consistent savings in terms of time.

In this paper, we investigate a method for generating

synthetic data automatically labeled to address sev-

eral safety monitoring tasks in a construction site. The

proposed approach aims to generate synthetic data us-

ing the Grand Theft Auto V video game rendering en-

gine. We build on the work of (Di Benedetto et al.,

2019) who proposed to generate synthetic data to de-

656

Quattrocchi, C., Di Mauro, D., Furnari, A., Lopes, A., Moltisanti, M. and Farinella, G.

Put Your PPE on: A Tool for Synthetic Data Generation and Related Benchmark in Construction Site Scenarios.

DOI: 10.5220/0011718000003417

In Proceedings of the 18th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2023) - Volume 4: VISAPP, pages

656-663

ISBN: 978-989-758-634-7; ISSN: 2184-4321

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

tect PPEs (Personal Protective Equipment) used by

workers in a construction site using the same video

game rendering engine. More speciﬁcally we extend

this approach from different viewpoints: we generate

data both from ﬁrst-person perspective, which corre-

sponds to cameras placed on the workers’ helmets,

and from two third-person views, corresponding to

cameras mounted on the vehicles working on the con-

struction site and cameras placed at the top of the

four ends of the construction site. We also provide

a mechanism to randomize the generation of the sce-

narios subjected to some constraints: the construction

sites are built at different positions on the game map

and they vary both in the arrangement of the prop-

erty (i.e. quantity and type) and of the workers (i.e.

position, clothing, and physical attributes). Our tool

allows to generate automatic annotations and can be

used to train algorithms to tackle different tasks. The

tool was developed as a plugin for the Grand Theft

Auto V

game engine. This tool is able to generate

the synthetic dataset automatically.

To compare the performance of the models trained

with the synthetic images with respect to the ones

trained on real data, a set of real data has also been ac-

quired and manually labeled. We studied the robust-

ness of synthetic data for construction side domain

in a range of applications related to safety monitor-

ing. In particular we focused on the following tasks:

safety compliance through object detection, fall de-

tection through pose estimation and distance regres-

sion from monocular view. The experiments show

that the proposed paradigm is effective in ﬁlling the

lack of real labeled data to tackle the considered tasks.

Speciﬁcally, results show a strong contribution of syn-

thetic data to improve the performances of the algo-

rithms. To summarize, the contributions of the paper

are the following:

1. A tool capable of generating large amounts of syn-

thetic labelled data related to construction sites in

a short time through randomly generated scenar-

ios;

2. A benchmark that describes and shows that the

use of the synthetic data can be useful to improve

the performance of different algorithms;

3. A tool able to detect the use of PPE by work-

ers, to evaluate distances within a construction site

(e.g., distance between a worker and a working

vehicle), and to recognize a worker on the ground

(e.g., due to an accident).

https://www.rockstargames.com/gta-v

2 RELATED WORKS

Our work focuses on machine learning algorithms

to monitor safety compliance in a construction site

through the use of synthetic data for training purpose.

Both safety monitoring and synthetic data generation

have been investigated in recent years, and several

works have tackled these tasks. In the following para-

graphs, we present some of the works most relevant

to ours.

Safety Monitoring. The use of machine learning

algorithms for safety monitoring is becoming in-

creasingly popular. Many existing computer vision

tasks can be exploited to reduce accidents and in-

crease safety in workplaces (Sandru et al., 2021;

Wu et al., 2019). (Kim et al., 2021) uses a

YOLOv4 ((Bochkovskiy et al., 2020)) object detec-

tor to recognize workers and equipment from aerial

images, in order to undestrand dangerous situations

within a work site. (Taufeeque et al., 2021; Juraev

et al., 2022) use the OpenPifPaf (Kreiss et al., 2021;

Kreiss et al., 2019) algorithm to capture situations of

domestic falls, managing to calculate the pose of the

subjects and to assign a “Fall” or “No-Fall” label from

the pose. (Jayaswal and Dixit, 2022) monitor distance

between people in order to mantain social distancing

in real time during the period of the Covid-19 pan-

demic.

Synthetic Data Generation. Thanks to the evolu-

tion of rendering engines and the greater availability

of GPUs, the use of synthetic data in computer vision

is a de-facto standard to obtain data for tasks which

are hard to label. The synthetic data can be gener-

ated using 3D graphics tools (i.e. Blender, Maya, etc),

or can be generated through the use of customizable

video game engines (i.e. GTA-V, Unreal, etc). (Quat-

trocchi et al., 2022) used Blender to generate syn-

thetic data to automatically and simultaneously ob-

tain synthetic frames paired with ground truth seg-

mentation masks to use for the Panoptic Segmenta-

tion task in an industrial domain. (Leonardi et al.,

2022) also used synthetic data in an industrial do-

main, but focused on the Human Object Interaction

task, where the goal was to simulate hand-object in-

teractions. (Di Benedetto et al., 2019) used the ren-

dering engine of Grand Theft Auto V to generate data

in the scenario of a construction site in order to train

an object detector capable of detecting the presence

or absence of PPE. (Savva et al., 2019; Szot et al.,

2021) simulate agents which navigate within 3D envi-

ronments and perform many different tasks. The work

ofgi (Sankaranarayanan et al., 2018) tackles the prob-

Put Your PPE on: A Tool for Synthetic Data Generation and Related Benchmark in Construction Site Scenarios

657

lem of the shift between real domain and synthetic

domains, proposing an approach based on Generative

Adversarial Networks (GANs). (Pasqualino et al.,

2021) considers the problem of unsupervised domain

adaptation for object detection in cultural sites be-

tween real images of the cultural site and synthetic

images. (Dosovitskiy et al., 2017) introduced an

open-source driving simulator for autonomous driv-

ing. The simulator runs on Unreal Engine 4 (UE4)

and allows to have full control of different parameters,

such as the positioning of vehicles and pedestrians, as

well as changes in weather conditions. (Fabbri et al.,

2021; Hu et al., 2019; Hu et al., 2021; Kr

ahenb

uhl,

2018; Richter et al., 2017) also use a video game to

generate synthetic data, but adopt a slightly different

approach as compared to the proposed method and

those presented previously. These works extract g-

buffers from the GPU in order to extract intermediate

representations from the rendering pipeline. In this

way, they are able to automatically extract informa-

tion such as depth maps, segmentation masks, optical

ﬂows. This approach was not used in our work due

to the need to modify and generate custom entities,

as well as the cameras. Also, the g-buffers extrac-

tion approach would not have allowed the extraction

of worker keypoints.

3 DATA GENERATION

The video game Grand Theft Auto V (GTAV) is a

popular video game based on Rockstar Advanced

Game Engine (RAGE). It is set in a real world and

thus it contains thousands of assets which are suit-

able in different domains. A third party developer

distributed the RAGE Plugin Hook (RPH)

compo-

nent that allows to hook pieces of custom source code,

called plugins. Such plugins allow to manipulate the

running game instance and perform actions such as

the spawn of polygonal models (characters, vehicles,

buildings, objects), as well as the ability to assign

a behavior to each model, in the form of action se-

quences deﬁned through the script. We relied on this

component to create a plugin to extract and automati-

cally annotate frames.

The plugin is composed of three main modules:

Location Collector. We generate data in different lo-

cations of the game map. The location collector

takes care of collecting, within the game map, the

positions in which the scenarios to be acquired

will be generated.

https://ragepluginhook.net/

Figure 1: Plugin workﬂow. The plugin executes, in order,

the processes of reading the locations, generating the sce-

nario and acquiring the scenario. The scenario generation

process includes several stages, such as the teleportation to

the current location, the generation of the scenario perime-

ter, and the generation of workers and work items.

Figure 2: Synthetic construction site.

Scenario Creator. This module deals with the gener-

ation of random scenarios. The construction site,

workers, vehicles, and objects are then generated

for each location collected by the Location Col-

lector.

Auto Labeling. This module takes care of the data

acquisition process: for each construction site,

images are collected from all points of view de-

ﬁned in the script, both from the ﬁrst person and

third person points of view. The module is also

responsible for automatic annotation of the gener-

ated images.

The execution of the plugin follows the ﬂow de-

picted in Figure 1. In Figure 2 is reported an example

of a synthetic image generated by the plugin.

The ﬁrst step is to read the ﬁrst available position

of the map available from the location collector mod-

ule. Once the location is read, the playable charac-

ter is teleported to the corresponding location. Once

the playable character has been teleported, the con-

struction site is generated randomly, positioning the

cones that delimit the construction site, the vehicle,

the objects (e.g., pneumatic hammer, concrete mixer,

etc), the workers (with random body attributes and

random clothing), and the cameras. Synthetic data

are generated from different kinds of cameras: four

third-person cameras, one for each corner of the con-

struction site; four vehicle-centric cameras for each

vehicle, one for each corner of the generated vehicle;

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

658

ﬁrst-person cameras positioned at eye level for each

of the generated workers. Once the construction site

and the actors have been generated, the active camera

is iterated over all deployed camerad and all the an-

notations corresponding to the entities present inside

the frames are saved. The stored data are realted to

the 2D and 3D bounding boxes, the distance between

the entity and the camera, the body joints of the work-

ers. Once the iteration of all the generated cameras is

ﬁnished, the entities are deleted and the playable char-

acter is moved to the next position to be visited on the

map until termination of all positions in the list.

As described above, the generated cameras can

be grouped into three categories: third-person cam-

eras (TPV), ﬁrst-person cameras (FPV), cameras po-

sitioned on vehicles.

The third-person cameras mimic the cameras that are

usually placed on the perimeter of the construction

site to have a top view of the area (usally used for

surveillance purpose). These cameras are positioned

at an height of 6 meters. Third-person cameras simu-

late wide cameras whit a Field of View (FoV) of 120

degrees. The images are acquired at a resolution of

1280x720 pixels.

The ﬁrst-person cameras represent the cameras that in

the real settings can be worn by the workers (e.g., on

the helmets). A ﬁrst-person camera is simulated for

each worker generated within the construction site.

The workers “on the ground” were not equipped with

a camera in the ﬁrst person, since their being lying

on the ground led to acquire frames with artifacts due

to interpenetration with the ground. The ﬁrst-person

cameras, simulating the cameras mounted on the hel-

mets, have a FoV of 64.67 degrees, in order to sim-

ulate a HoloLens2 camera. The images captured by

the cameras from the ﬁrst person point of view are ac-

quired at a resolution of 1280x720 pixels.

The cameras positioned on the vehicles are four per

vehicle and they are positioned at an elevated position

and rotated in order to have a view of everything that

surrounds the vehicle. The cameras were positioned

as if they were physically present at the 4 corners of

the vehicle to understand if a worker is too close to

a moving vehicle. The cameras positioned on the ve-

hicles have a FoV of 120 degrees. The images are

captured by the cameras positioned on the vehicles at

a resolution of 1280x720 pixels.

While the plugin is running, different views of the

scene are displayed, one for each acquisition point.

These views are obtained by activating, deactivating

and moving the created virtual cameras. For each

generated view two ﬁles are created: a screen cap-

ture saved in JPG format and a text ﬁle containing the

annotations for each entity present within the view.

The 2D and 3D bounding boxes are labeled with

the following 12 classes: head with work helmet,

worker, torso with high visibility vest, pneumatic

hammer, vehicle, head without work helmet, torso

without high visibility vest, cone, worker on the

ground, shovel, wheelbarrow, concrete mixer.

For each labeled entity, distance from the camera

was measured as the length of the segment connecting

the camera position to the center of the 3D bounding

box of the entity.

The worker joints that have been labeled are the

following: nose, neck, left clavicle, right clavicle,

left thigh, right thigh, left knee, right knee,

left ankle, right ankle, left wrist, right wrist,

left elbow, right elbow.

4 BENCHMARK

We tested the quality of the synthetic dataset gener-

ated by the proposed plugin running benchmarks on

three tasks: safety compliance through object detec-

tion, fall detection through pose estimation and dis-

tance regression from monocular view. Experiments

have been performed on both synthetic dataset and an-

notated real data. These last have been used for ﬁne-

tuning and for the evaluation of the algorithms.

4.1 Dataset

The dataset was collected by generating 200 build-

ing sites within the game map. In total, 76,580

frames were generated, with 44,580 in FPV (work-

ers), 16,000 frames in FPV (vehicles) and 16,000

frames in TPV (construction site corners). The

dataset contains 2,438,566 labels distributed as fol-

lows: 333,856 workers, 168,686 heads with helmet,

165,867 busts without high visibility vest, 20,454

pneumatic hammers, 35,850 vehicles, 165,170 heads

without helmet, 167,989 busts without high visibil-

ity vest, 1,085,729 cones, 135,084 ground work-

ers, 78,584 shovels, 39,999 wheelbarrows and 41,298

concrete mixers. Some of these images were dis-

carded for occlusions or other glitches, bringing the ﬁ-

nal count to 51,081 synthetic images splitted in train-

ing (30,019), and validation (21,062).

The ﬁnal dataset contains also a grand total of

9,698 real images splitted in training set (9,212) and

validation (486).

Put Your PPE on: A Tool for Synthetic Data Generation and Related Benchmark in Construction Site Scenarios

659

Table 1: Object Detection mAP.

Real Synthetic + Real

10% 0.819 0.853

25% 0.852 0.875

50% 0.875 0.889

75% 0.885 0.900

100% 0.888 0.905

Figure 3: Object Detection mAP.

4.2 Safety Compliance Through Object

Detection

In order to understand if all the workers in a con-

struction site wear Personal Protective Equipment

(PPE), we performed experiments using the YOLO

object detector (Bochkovskiy et al., 2020) and post-

processing the inferred bounding boxes to distinguish

whether or not a worker is wearing a helmet and a

high visibility jacket. As a ﬁrst step, we analyze if

and how the synthetic data can improve the quality of

object detection, then we study the results obtained on

the safety task.

4.2.1 Object Detection

In order to analyze the use of synthetic data in the ob-

ject detection task, we trained and tested the object

detection algorithm in two different settings. In the

ﬁrst setting, the model is trained using only the real

data. In the second one, we train the model using syn-

thetic data and then the real data is used to ﬁne-tune

it. In both settings, we vary the amount of real data

used for training (10%, 25%, 50%, 75%, 100%) in or-

der to assess the amount of real data needed to have a

working model.

Table 1 reports the results in terms of mAP metric.

Figure 3 depicts the graph showing the trend of the

mAP for varying quantities of real data used to train

the model.

As can be seen, the use of synthetic data helps to

increase the performance of the model. We can ob-

serve that when we use all the synthetic data and ﬁne-

Table 2: No Helmet mAP.

Real Syn + Real

10% 0.723 0.759

25% 0.757 0.799

50% 0.800 0.798

75% 0.796 0.807

100% 0.799 0.819

Table 3: No Vest mAP.

Real Syn + Real

10% 0.880 0.889

25% 0.892 0.899

50% 0.913 0.904

75% 0.906 0.904

100% 0.918 0.915

tune using 50% of the real data, the detector performs

at the same manner than when using 100% of only

real data (88.9% vs 88.8%).

4.2.2 No Vest / no Helmet

The settings of the experiments are the same of object

detection. Tables 2 and 3 show the detection results

of the absence of the helmet and absence of the high

visibility vest, whereas Figure 4 shows a qualitative

example using a real image.

Results show that helmets detection takes advan-

tage from the synthetic data. With 25% of real data

for ﬁne-tuning, the detector reaches an accuracy value

close to 100% of only real data.

Vest detection, on the other hand, beneﬁts less

from synthetic data, with best results obtained with

only real data.

4.3 Fall Detection Through Pose

Estimation

The estimated positions of the human joints in con-

junction with the bounding box around the human can

be used to classify workers in two classes: “no Fall”

and “Fall”. The choice to use both the bounding boxes

and the human body joints was driven by the fact that

human pose estimation algorithms could ﬁnd only a

subset of joints at inference time, thus the exploita-

tion of bounding box can improve the ﬁnal quality.

We used OpenPifPaf (Kreiss et al., 2021) to in-

fer human pose and a simple Multilayer Perceptron to

classify worker status. We performed four tests, the

results of which are reported in Table 4:

1. Training joint ground truth labels (GT) and testing

on validation joint ground truth labels (GT). This

is the baseline case.

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

660

Figure 4: No Vest/No Helmet detection on a real image.

2. Training joint ground truth labels (GT) and test on

inferred joint validation labels (INF). In this case

ground truth labels and inferred labels may vary a

lot, e.g. many keyponts are not found.

3. Training on inferred joint labels (INF) of the

training-set and testing on the validation ground

truth labels (GT). In this case, we measure what

happen when there are no labels for training data.

4. Training on inferred joint labels (INF) of the

training-set and testing on the validation set in-

ferred labels (INF).

In Table 5 and Table 6 we present the performance

on the experiments (2 - 4) varying the distance from

the camera of the worker annotated boxes. Best re-

sults are for workers at a distance under 5 meters from

the camera. Learning from the inferred labels increase

robustness to missing values. Figure 5 shows a quali-

tative example using a synthetic image.

Figure 5: Fall detection on a synthetic image.

4.4 Distance Regression from

Monocular View

We evaluated distance regression using monocular

view on the created synthetic dataset. We followed

the work in (Haseeb et al., 2018) who used a multi-

layer perceptron of 3 hidden layers with 100 neurons

each. The network to regress the distance needs the

average 3D bounding box size in the real world, for

the Worker class. It has been set an average dimen-

sions of 1.75 m, 0.55 m, 0.30 m. In Table 7 we show

the results with 3 different training setups: using im-

ages with boxes at every distance, at no more than

10m and at no more than 5m. In the ﬁrst case an av-

erage error of 1.73m is obtained.

Table 4: Results of the four test for fall detection.

Train Test no Fall Boxes Fall Boxes Accuracy no Fall Accuracy Fall Average Accuracy

GT Labels GT Labels 100,562 41,105 0.996 0.938 0.979

GT Labels INF Labels 41,317 2,666 0.708 0.551 0.698

INF Labels GT Labels 100,562 41,105 0.968 0.236 0.756

INF Labels INF Labels 41,317 2,666 0.979 0.877 0.973

Table 5: GT Labels vs INF Labels varying distance.

Distance no Fall Boxes Fall Boxes Accuracy no Fall Accuracy Fall Average Accuracy

< 2m 625 62 0.242 0.998 0.930

< 5m 6,123 767 0.939 0.494 0.890

< 10m 19,999 2,329 0.800 0.564 0.775

All 41,317 2,666 0.708 0.551 0.698

Table 6: INF Labels vs INF Labels varying distance.

Distance no Fall Boxes Fall Boxes Accuracy no Fall Accuracy Fall Average Accuracy

< 2m 625 62 0.978 0.903 0.971

< 5m 6,123 767 0.986 0.952 0.982

< 10m 19,999 2,329 0.981 0.905 0.973

All 41,317 2,666 0.979 0.877 0.973

Put Your PPE on: A Tool for Synthetic Data Generation and Related Benchmark in Construction Site Scenarios

661

Table 7: Results of the network using as training set images of workers at all possible distances (a), with workers at no more

than 10m (b) and at no more than 5m (c).

Distance All Images (a) Under 10m (b) Under 5m (c)

< 1m 0.76m (91%) 0.48m (57%) 0.37m (44%)

< 2m 0.83m (63%) 0.60m (44%) 0.52m (37.15%)

< 5m 1.21m (39%) 0.93m (30%) 0.53m (18%)

< 10m 2.28m (35%) 0.88m (16%) -

all 1.73m (16%) - -

5 CONCLUSIONS

In this work, we presented a pipeline to generate syn-

thetic data in the domain of construction sites using

the Grand Theft Auto V videogame graphics engine.

A benchmark of the generated dataset on three differ-

ent tasks has been also performed. We focused the

study on training machine learning algorithms using

a large amount of synthetic data and a small set of

real images with the aim of measuring the usefulness

of such data to reduce real labeling effort without de-

creasing inference quality, evaluating algorithms be-

haviour varying the amounts of real data used. The

results show that the use of synthetic data is a viable

way to reduce the need to acquire and label new real

data.

ACKNOWLEDGEMENTS

This research is supported by project SAFER devel-

oped by Xenia Network Solutions s.r.l. (GRANT:

CALL N3 ARTES 4.0 - 2020) and by Next Vision

s.r.l.

REFERENCES

Bochkovskiy, A., Wang, C.-Y., and Liao, H.-Y. M. (2020).

Yolov4: Optimal speed and accuracy of object detec-

tion. arXiv preprint arXiv:2004.10934.

Di Benedetto, M., Meloni, E., Amato, G., Falchi, F., and

Gennaro, C. (2019). Learning safety equipment de-

tection using virtual worlds. In International Confer-

ence on Content-Based Multimedia Indexing (CBMI),

pages 1–6. IEEE.

Dosovitskiy, A., Ros, G., Codevilla, F., Lopez, A., and

Koltun, V. (2017). Carla: An open urban driving sim-

ulator. In Conference on robot learning, pages 1–16.

PMLR.

Fabbri, M., Bras

o, G., Maugeri, G., Cetintas, O., Gasparini,

R., O

sep, A., Calderara, S., Leal-Taixe, L., and Cuc-

chiara, R. (2021). Motsynth: How can synthetic data

help pedestrian detection and tracking? In Proceed-

ings of the IEEE International Conference on Com-

puter Vision, pages 10849–10859.

Haseeb, M. A., Guan, J., Ristic-Durrant, D., and Gr

aser,

A. (2018). Disnet: a novel method for distance esti-

mation from monocular camera. 10th Planning, Per-

ception and Navigation for Intelligent Vehicles (PP-

NIV18), IROS.

Hu, Y.-T., Chen, H.-S., Hui, K., Huang, J.-B., and Schwing,

A. G. (2019). Sail-vos: Semantic amodal instance

level video object segmentation-a synthetic dataset

and baselines. In IEEE/CVF Conference on Computer

Vision and Pattern Recognition, pages 3105–3115.

Hu, Y.-T., Wang, J., Yeh, R. A., and Schwing, A. G. (2021).

Sail-vos 3d: A synthetic dataset and baselines for ob-

ject detection and 3d mesh reconstruction from video

data. In IEEE/CVF Conference on Computer Vision

and Pattern Recognition, pages 1418–1428.

Jayaswal, R. and Dixit, M. (2022). Monitoring social dis-

tancing based on regression object detector for re-

ducing covid-19. In 2022 IEEE 11th International

Conference on Communication Systems and Network

Technologies (CSNT), pages 635–640. IEEE.

Juraev, S., Ghimire, A., Alikhanov, J., Kakani, V., and Kim,

H. (2022). Exploring human pose estimation and

the usage of synthetic data for elderly fall detection

in real-world surveillance. IEEE Access, 10:94249–

94261.

Kim, K., Kim, S., and Shchur, D. (2021). A uas-based work

zone safety monitoring system by integrating internal

trafﬁc control plan (itcp) and automated object detec-

tion in game engine environment. Automation in Con-

struction, 128:103736.

ahenb

uhl, P. (2018). Free supervision from video games.

In IEEE/CVF Conference on Computer Vision and

Pattern Recognition, pages 2955–2964.

Kreiss, S., Bertoni, L., and Alahi, A. (2019). Pifpaf: Com-

posite ﬁelds for human pose estimation. In Proceed-

ings of the IEEE/CVF conference on computer vision

and pattern recognition, pages 11977–11986.

Kreiss, S., Bertoni, L., and Alahi, A. (2021). Openpifpaf:

Composite ﬁelds for semantic keypoint detection and

spatio-temporal association. IEEE Transactions on In-

telligent Transportation Systems.

Leonardi, R., Ragusa, F., Furnari, A., and Farinella, G. M.

(2022). Egocentric human-object interaction detection

exploiting synthetic data. In International Conference

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

662

on Image Analysis and Processing, pages 237–248.

Springer.

Pasqualino, G., Furnari, A., Signorello, G., and Farinella,

G. M. (2021). An unsupervised domain adapta-

tion scheme for single-stage artwork recognition in

cultural sites. Image and Vision Computing, page

104098.

Quattrocchi, C., Di Mauro, D., Furnari, A., and Farinella,

G. M. (2022). Panoptic segmentation in industrial en-

vironments using synthetic and real data. In Interna-

tional Conference on Image Analysis and Processing,

pages 275–286. Springer.

Richter, S. R., Hayder, Z., and Koltun, V. (2017). Playing

for benchmarks. In Proceedings of the IEEE Interna-

tional Conference on Computer Vision, pages 2213–

2222.

Sandru, A., Duta, G.-E., Georgescu, M.-I., and Ionescu,

R. T. (2021). Super-sam: Using the supervision signal

from a pose estimator to train a spatial attention mod-

ule for personal protective equipment recognition. In

Proceedings of the IEEE/CVF Winter Conference on

Applications of Computer Vision, pages 2817–2826.

Sankaranarayanan, S., Balaji, Y., Jain, A., Lim, S. N., and

Chellappa, R. (2018). Learning from synthetic data:

Addressing domain shift for semantic segmentation.

In Proceedings of the IEEE Conference on Computer

Vision and Pattern Recognition (CVPR).

Savva, M., Kadian, A., Maksymets, O., Zhao, Y., Wijmans,

E., Jain, B., Straub, J., Liu, J., Koltun, V., Malik, J.,

et al. (2019). Habitat: A platform for embodied ai re-

search. In Proceedings of the IEEE/CVF International

Conference on Computer Vision, pages 9339–9347.

Szot, A., Clegg, A., Undersander, E., Wijmans, E., Zhao, Y.,

Turner, J., Maestre, N., Mukadam, M., Chaplot, D. S.,

Maksymets, O., et al. (2021). Habitat 2.0: Training

home assistants to rearrange their habitat. Advances in

Neural Information Processing Systems, 34:251–266.

Taufeeque, M., Koita, S., Spicher, N., and Deserno, T. M.

(2021). Multi-camera, multi-person, and real-time fall

detection using long short term memory. In Medical

Imaging 2021: Imaging Informatics for Healthcare,

Research, and Applications, volume 11601, pages 35–

42. SPIE.

Wu, J., Cai, N., Chen, W., Wang, H., and Wang, G. (2019).

Automatic detection of hardhats worn by construction

personnel: A deep learning approach and benchmark

dataset. Automation in Construction, 106:102894.

Put Your PPE on: A Tool for Synthetic Data Generation and Related Benchmark in Construction Site Scenarios

663
