Schfuzz: Detecting Concurrency Bugs with Feedback-Guided Fuzzing

Hiromasa Ito

, Yutaka Matsubara

and Hiroaki Takada

1,2 a

Institute of Innovation for Future Society, Nagoya University, Aichi, Japan

Graduate School of Informatics, Nagoya University, Aichi, Japan

Keywords:

Fuzzing, Concurrency Testing, Concurrency Bug Detection, Feedback-Guided Fuzzing,

Memory-Access-Guided Fuzzing.

Abstract:

It is challenging to detect concurrency bugs with fuzzing. There are two main reasons for this. First, manifest-

ing them by exploring input space is inefﬁcient because they only occur under speciﬁc interleavings. Second,

re-giving an input detected a bug in a fuzzing campaign does not necessarily reproduce the bug because typ-

ical runtimes do not schedule threads deterministically. This research proposes Schfuzz, a novel approach

for detecting concurrency bugs with feedback-guided fuzzing. This approach executes programs under test

deterministically based on test cases generated by fuzzers. In addition, it feeds back dynamic memory-access

orders to aid fuzzers in detecting concurrency bugs more efﬁciently and effectively. We evaluate Schfuzz with

a hand-made motivating example and four benchmark programs from SCTBench (Thomson et al., 2016). The

result shows that it can detect concurrency bugs more efﬁciently and effectively than traditional feedback-

guided fuzzing.

1 INTRODUCTION

System developers have to design concurrent systems

because it is challenging to increase the density of

semiconductor integration further in the post-Moore

era. Although concurrent systems enable us to use

computational resources effectively, developers often

suffer from concurrency bugs. They are errors in con-

current systems manifesting when the systems sched-

ule threads in particular interleavings. We need an

effective method to detect concurrency bugs because

it is more challenging to detect them than sequential

ones.

Although fuzzing is one of the most successful

automated software testing methods, detecting con-

currency bugs with fuzzing is not so straightforward.

There are two main reasons for this. First, exploring

input space is inefﬁcient for hunting concurrency bugs

because most inputs may run under the same inter-

leaving. Second, bugs detected in fuzzing campaigns

are hard to reproduce because typical runtimes sched-

ule threads non-deterministically.

This research proposes Schfuzz, a novel method

for detecting concurrency bugs with feedback-guided

fuzzing. This approach has two key points. First, it

executes programs under test deterministically based

on test cases generated by fuzzers. Second, it feeds

https://orcid.org/0000-0003-3544-2397

back dynamic memory-access orders to aid fuzzers in

detecting concurrency bugs more efﬁciently and ef-

fectively.

The contributions of the research are as follows:

• We propose Schfuzz, a novel approach to detect

concurrency bugs with feedback-guided fuzzing.

• We implement the prototypes of Schfuzz and sta-

tistically compare it with traditional fuzzing meth-

ods based on quantitative metrics retrieved from

the experimental results.

2 BACKGROUND AND

MOTIVATION

2.1 Concurrency Bug

A concurrency bug (e.g., data race, deadlock, and

atomicity violation) is one of the errors that can oc-

cur in concurrent systems. If a system has latent con-

currency bugs, the bugs can occur when the system

schedules threads in particular interleavings. The oc-

curred bug can propagate and ﬁnally fail the system.

Even if a system has latent concurrency bugs, it

is not easy to manifest them artiﬁcially. In order to

manifest them, the system must run under speciﬁc in-

terleavings. The number of such interleavings is tiny

Ito, H., Matsubara, Y. and Takada, H.

Schfuzz: Detecting Concurrency Bugs with Feedback-Guided Fuzzing.

DOI: 10.5220/0011722100003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 273-282

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

273

relative to the size of the interleaving space. In ad-

dition, the input which manifested the bug does not

necessarily reproduce the bug because most runtimes

do not schedule threads deterministically. Therefore,

there is a need for a novel method that can 1) efﬁ-

ciently explore interleaving space, 2) effectively de-

tect concurrency bugs, and 3) reproduce detected bugs

without extra effort.

2.2 Fuzzing

Fuzzing is one of the software testing methods. Gen-

erally, it repeats the following three steps:

1. A test case generator (fuzzer) generates a test case

and feeds it to a program under test (PUT).

2. The PUT runs with the test case.

3. The fuzzer checks the PUT’s liveness (e.g., status

code).

Although the concept of fuzzing proposed by Miller

et al. (1990) is so simple, it detected many bugs in

the UNIX utility programs. In recent years, many

researchers have studied how to detect various bugs

more efﬁciently and effectively with fuzzing (Bohme

et al., 2017; Rawat et al., 2017; Stephens et al., 2016;

Yun et al., 2018).

Feedback-guided fuzzing feeds back runtime in-

formation in the fuzzing loop. A feedback-guided

fuzzer evaluates a test case using the runtime infor-

mation gathered when the PUT ran with the test case.

It stores highly-rated test cases as seeds and uses them

to generate beneﬁcial descendant test cases. For ex-

ample, a code-coverage-guided fuzzer uses test cases

with improved code coverage in a fuzzing campaign

as seeds and generates new ones by mutating the

seeds. Amerian Fuzzy Lop

(AFL) and libFuzzer

are typical code-coverage-guided fuzzers that have

detected numerous bugs and vulnerabilities in real-

world programs.

Although existing fuzzing methods and various

fuzzers have detected many sequential bugs, detecting

concurrency bugs is not straightforward. First, explor-

ing input space is inefﬁcient for detecting concurrency

bugs. Even though various inputs indirectly explore

interleaving space because PUTs can run under vari-

ous interleavings with them, it is less efﬁcient than di-

rect exploration. Second, even if an input in a fuzzing

campaign manifests a bug, the input does not neces-

sarily reproduce the bug due to the non-determinism

of thread scheduling. Therefore, there is a need for

a novel approach to detecting concurrency bugs with

fuzzing.

https://lcamtuf.coredump.cx/aﬂ/

https://llvm.org/docs/LibFuzzer.html

1 void

2 main_task(intptr_t exinf)

3 {

4 while (1) {

5 char c; // character input

6 if (!read_data(&c, sizeof(char))) {

7 continue;

8 }

9 if ((c & 0b00001111) == 0b1111) {

10 consume_time(1000);

12 // acquire lock

13 loc_cpu();

14 lock = 1;

15 unl_cpu();

17 // do nothing

19 // release lock

20 loc_cpu();

21 lock = 0;

22 unl_cpu();

24 consume_time(1000);

25 } else {

26 consume_time(1000);

27 }

28 }

29 }

Figure 1: Main task of the motivating example.

2.3 Motivating Example

Figures 1 and 2 show the source codes of an appli-

cation program of TOPPERS/ASP3

, an open-source

real-time operating system that runs on GR-PEACH

an RZ/A1H SoC development board. The applica-

tion consists of a task and an interrupt service routine

(ISR).

Figure 1 shows the code for the main task of the

example. It consists of a single inﬁnite loop. In the

loop, it repeatedly reads input, and if its last four bits

are all one, it acquires and releases the lock repre-

sented by the variable lock.

Figure 2 shows the code for the ISR of the exam-

ple. It checks the state of the lock, and if its value is

one, it increments the value of the global variable shm.

Because the access to shm is not synchronized, other

threads (i.e., ISR instances) can overwrite its value be-

tween its increment and its reload for assertion check-

ing. In other words, data race can occur because the

ISR is not reentrant.

In order to manifest the bug, threads must inter-

leave to satisfy the following two conditions:

https://toppers.jp/asp3-kernel.html

https://www.renesas.com/us/en/products/

gadget-renesas/boards/gr-peach

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

274

1 void

2 intno1_isr(intptr_t exinf)

3 {

4 intno1_clear();

6 unsigned int lock_state = 0;

8 // check the lock state

9 iloc_cpu();

10 lock_state = lock;

11 iunl_cpu();

13 // iff. the task have the lock, increment

shm.

14 if (lock_state) {

15 unsigned int buf = 0;

16 buf = shm;

17 shm++;

18 assert(shm == (buf + 1));

19 }

20 }

Figure 2: Interrupt service routine (ISR) of the motivating

example.

1. Firing the ﬁrst interrupt when the value of lock is

one.

2. Firing the second interrupt between incrementing

shm and reloading it for assertion checking.

The number of such interleavings is minimal relative

to the size of the interleaving space. In addition, since

input rarely contributes to interleaving space explo-

ration in this example, it is hard to satisfy condition

2 with traditional fuzzing methods. In order to efﬁ-

ciently explore the latent bug in this example, fuzzers

should also explore the interleaving space.

3 SCHFUZZ

This research proposes Schfuzz, a novel method

to detect concurrency bugs with feedback-guided

fuzzing. There are two critical points of the method.

• It executes PUTs deterministically based on test

cases generated by fuzzers.

• It feeds back dynamic memory-access orders to

fuzzers.

Figure 3 shows an overview of Schfuzz. A sched-

uler receives a test case generated by a fuzzer and

interprets it as a series of schedules. A runtime en-

vironment (e.g., a system emulator) executes a PUT

under the schedule, records orders of shared-memory

access, and feeds them back to the fuzzer.

Algorithm 1 shows how schedulers and runtime

environments execute PUTs deterministically based

on test cases generated by fuzzers. If a bug occurs

with a test case, running the PUT with the test case

can reproduce the bug. The algorithm repeats until

it exhausts data in a test case (lines 2 - 9). A sched-

ule consists of addr, maxHitCount, and maxInstCount

and a scheduler retrieves it from the test case (line

4). A runtime environment executes a PUT under the

schedule and pauses the execution when the value of

the program counter matches addr’s value the number

of times as maxHitCount’s value (line 6). The value

of maxInstCount is the upper bound of the number

of instructions executed before pausing. After that,

the runtime environment saves the current thread con-

text (line 7) and gets the next available thread (line

8). Note that the function transformToValidAddr val-

idates the value of addr because it is likely to be un-

reachable if addr is allowed to take any value. If addr

takes an invalid value, transformToValidAddr trans-

forms its value into a valid one (line 5). Testers must

determine the valid value range because it depends on

PUTs.

Schfuzz feeds back shared-memory access or-

ders to fuzzers for detecting concurrency bugs ef-

fectively and efﬁciently. Typical feedback-guided

fuzzing feeds back basic-block level paths and prefers

test cases that improve code coverage. However,

this strategy is not suited for detecting concurrency

bugs. There are two main reasons for this. First, a

context switch can occur in concurrent programs in

the middle of a basic block. Because of this fea-

ture, static-basic-block level paths imprecisely rep-

resent PUT’s executions. Likewise, the number of

dynamic-basic-block level paths increases exponen-

tially to the number of instructions and threads. Sec-

ond, a concurrency bug occurs when threads access

shared memories in particular orders. Generally, im-

proving code coverage helps to detect latent concur-

rency bugs. Meanwhile, even if a test case improves

the code coverage of a fuzzing campaign, it does

not contribute to concurrency bug detection if the

newly covered codes do not access shared memory.

Therefore, Schfuzz feeds back access orders to shared

memory and prefers test cases that access the memory

in an order not yet observed in a fuzzing campaign.

For the evaluation described in section 4, we have

implemented two prototypes of Schfuzz. They use

American Fuzzy Lop (ver. 2.52b) as a feedback-

guided fuzzer and Unicorn (ver. 1.0.3) and Qiling

(ver. 1.4.3) as ﬁne-controllable runtime environments

based on schedules. It depends on runtime environ-

ments how to control executions and gather runtime

information. In order to run fuzzing for our moti-

vating example, we have implemented the ﬁrst proto-

Schfuzz: Detecting Concurrency Bugs with Feedback-Guided Fuzzing

275

Feedback-guided fuzzer

Seeds

EvaluatorMutator

Schedules

addr = 0xdeadbeef

maxHitCount = 0x01

maxInstCount = 0xffff

addr = 0xdeadbeef

maxHitCount = 0x01

maxInstCount = 0xffff

addr = 0xdeadbeef

maxHitCount = 0x01

maxInstCount = 0xffff

Test case

00001111

10100010

11100111

PUT

Runtime environment

Scheduler

0xdeadbeef

0xdefec8ed

0xfacefeed

...

Access logs to shared memory

Figure 3: Overview of Schfuzz. For prototyping, we use American Fuzzy Lop (AFL) as a feedback-guided fuzzer and Unicorn

and Qiling as runtime environments for PUTs. For the ﬁrst prototype, we have implemented the scheduler in the code of the

test driver. On the other hand, for the second prototype, we have integrated the scheduler into Qiling’s code.

Input: testCase, mainThread

1: currrentThread ← mainThread

2: while testCase is not EOF do

3: ctx ← loadContext(currentThread)

4: addr, maxHitCount, maxInstCount ← getSchedule(testCase)

5: validAddr ← transformToValidAddr(addr)

6: new ctx ← run(ctx, validAddr, maxHitCount, maxInstCount)

7: saveContext(new ctx)

8: currentThread ← getNextThread()

9: end while

Algorithm 1: Deterministic execution based on a test case.

type with Unicorn

, a multi-architecture CPU emula-

tion framework. We use its APIs to implement Algo-

rithm 1 because they enable us to control and execute

PUTs at the instruction level. In addition, they en-

able us to hook various runtime events (e.g., memory

access). The prototype records runtime information

with the APIs. Although the ﬁrst prototype enables us

to run fuzzing for the motivating example, we should

apply Schfuzz to more various PUTs for evaluation.

Many real-world concurrent programs run on the Lin-

ux/pthread environment, but it is not straightforward

to run Linux/pthread software on vanilla Unicorn be-

cause it is just a CPU emulator (i.e., an instruction-set

simulator). Hence we have implemented the second

prototype with Qiling

, a binary emulation framework

that uses Unicorn as its backend. Although we can-

not control PUT’s execution via Qiling as ﬁnely as

Unicorn, we modiﬁed it to enable test-case-based de-

terministic execution. The second prototype records

runtime information with the APIs of Qiling as those

of Unicorn.

https://github.com/unicorn-engine/unicorn

https://github.com/qilingframework/qiling

4 EVALUATION

4.1 Experimental Setup

We experimentally evaluate Schfuzz. It is clear that

Schfuzz has better reproducibility of bugs than exist-

ing fuzzing methods because it deterministically exe-

cutes PUTs based on test cases generated by fuzzers.

In the experiment, we evaluate the effectiveness of us-

ing access orders to shared memory as runtime feed-

back. We run fuzzing campaigns many times for ﬁve

PUTs using three different runtime feedback and dis-

cuss the effectiveness of Schfuzz based on quantita-

tive metrics of the results. All of the experiments run

on Ubuntu 18.04 (Linux 5.4.0) on Intel(R) Core(TM)

i9-9960X CPU @ 3.10GHz and 32 GiB RAM.

Research Question. There are two research ques-

tions in the experiment.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

276

RQ1. Does Schfuzz improve the efﬁciency of

detecting concurrency bugs compared to ex-

isting fuzzing methods?

RQ2. Does Schfuzz improve the effective-

ness of detecting concurrency bugs compared

to existing fuzzing methods?

The time and the number of generated test cases to de-

tect bugs index the efﬁciency, and bug-detection rates

index the effectiveness.

PUT. In the experiment, we use ﬁve concurrent pro-

grams as PUT. One is the motivating example shown

in section 2.3, and we run 100 10-minute fuzzing

campaigns for it with each method described in the

paragraph below. The others (reorder 10 bad, re-

order 20 bad, safestack, and twostage 100 bad) are

benchmark programs in SCTBench (Thomson et al.,

2016), a set of buggy concurrent software run on the

Linux/pthread environment. Thomson et al. (2016)

have evaluated various methods to detect concurrency

bugs with SCTBench. In their evaluation, the number

of methods that detected the bugs in the four programs

is fewer than those that detected bugs in the others. In

other words, they are the four most challenging pro-

grams in SCTBench to detect bugs. They all have

assertion checks, and their checks can fail when they

run under speciﬁc interleavings. We run 30 6-hour

fuzzing campaigns for them with each method.

Method. We compare three methods, each of which

uses the following runtime information:

• Shared-memory access orders (Schfuzz).

• Basic-block level paths (code-coverage-guided

fuzzing).

• None (dumb fuzzing).

As shown in Algorithm 1, a test case is interpreted

as a series of schedules. However, when the PUT is

the motivating example, it is interpreted as a series of

inputs and schedules because we must give speciﬁc

inputs to manifest the bug. Table 1 shows the size of

each element that makes up a schedule and an input.

Limitations of the Prototypes. There are two lim-

itations of the prototypes.

1. A tester must provide shared memory addresses

to be monitored.

2. A tester must provide a range for the function

transformToValidAddr in Algorithm 1.

200

400

600

motivating_example

PUT

Time to detect the bugs [s]

Runtime info.

shm

Figure 4: Time distributions to detect the bug in the moti-

vating example.

Table 2 shows the shared variables to be monitored

in the experiments for each PUT. The range of trans-

formToValidAddr in the experiments is the address

range of their application codes. Note that we modi-

ﬁed the source code of safestack because of limitation

1. Since safestack dynamically allocates the memory

to be monitored and the prototypes cannot monitor

memory whose address is determined at runtime, we

modiﬁed the code to allocate it statically.

4.2 Result

Table 3 shows each method’s time to detect the la-

tent bugs in each PUT. In the fuzzing campaigns for

the motivating example, Schfuzz detected the bug on

average 2.36 times faster than code-coverage-guided

fuzzing. Figure 4 shows the box plot of the time dis-

tributions to detect the bug in the motivating example.

The p-value calculated by the Brunner-Munzel test

(Brunner and Munzel, 2000) for these distributions is

less than 2.2e

−16

, which means signiﬁcant differences

between them.

Table 4 shows the number of test cases each

method generates to detect the latent bugs in each

PUT. Note that the values are estimated by integrating

the number of test cases executed per second. In the

fuzzing campaigns for the motivating example, Sch-

fuzz detected the bug in 2.94 times fewer test cases on

average than code-coverage-guided fuzzing. Figure

5 shows the box plot of the distributions of the esti-

mated number of test cases generated to detect the bug

in the motivating example. The p-value calculated by

the Brunner-Munzel test (Brunner and Munzel, 2000)

for these distributions is 6.6e

−16

, which means signif-

icant differences between them.

Table 5 shows the bug detection rate of each

method in each PUT. Schfuzz has a higher bug de-

tection rate than the other methods for the motivating

Schfuzz: Detecting Concurrency Bugs with Feedback-Guided Fuzzing

277

Table 1: Size of each element that makes up a schedule and an input.

PUT

Size [byte]

numberOfInput input addr maxHitCount maxInstCount

motivating example 1 numberOfInput 4 1 2

reorder 10 bad 0 0 4 1 2

reorder 20 bad 0 0 4 1 2

safestack 0 0 4 1 2

twostage 100 bad 0 0 4 1 2

Table 2: Shared variables to be monitored in the experi-

ments for each PUT.

PUT Vars to be monitored

motivating example lock, shm

reorder 10 bad a, b

reorder 20 bad a, b

safestack stack_items, stack

twostage 100 bad data1Value, data2Value

0e+00

5e+04

1e+05

motivating_example

PUT

Est. #testcases

Runtime info.

shm

Figure 5: Distributions of the estimated number of test cases

generated to detect the bug in the motivating example.

example, reorder 10 bad and reorder 20 bad. On the

other hand, it could not detect the bugs in safestack

and twostage 100 bad as the other methods. Code-

coverage-guided fuzzing detected only the bug in the

motivating example in 33% of the fuzzing campaigns.

Regarding dumb fuzzing, it could not detect any bugs

in the PUTs.

4.3 Discussion

We discuss the following three topics based on the

results:

1. The bugs which Schfuzz could not detect.

2. The answers to the research questions.

3. The threats to validity.

Undetected Bugs. We should discuss the bugs

which Schfuzz could not detect. It could not detect

the bugs in safestack and twostage 100 bad with 6-

hour fuzzing campaigns. Although the bug in safes-

tack is not false-positive, it is known to be challenging

to detect. No method could detect it in the evalua-

tion by Thomson et al. (2016). The most recent work

on concurrency bug detection (Wen et al., 2022) also

failed to detect the bug. twostage

100 bad concur-

rently runs 100 threads, which access the shared vari-

ables. A large number of threads has two adverse ef-

fects on Schfuzz. First, it slows down fuzzing speed.

In other words, PUTs run with fewer test cases. Sec-

ond, it makes detecting bugs more difﬁcult because it

increases the size of interleaving space.

Answers to Research Questions. We should an-

swer the research questions based on the results.

A1. Yes. Schfuzz can detect concurrency

bugs more efﬁciently than the existing fuzzing

methods.

In the experiment, Schfuzz detected the bugs in the

three PUTs faster and with fewer test cases than the

other methods. In addition, there are signiﬁcant dif-

ferences among the distributions of time and the num-

ber of test cases to detect the bugs.

A2. Yes. Schfuzz can detect concur-

rency bugs more effectively than the existing

fuzzing methods.

Schfuzz showed a higher bug-detection rate in the ex-

periment than the existing method for the three PUTs.

Threats to Validity. We should discuss the threats

to the validity:

• Fuzzing has randomness. Therefore, it is impos-

sible to get the same result as this. In order to

reduce the effect of the randomness, we have an-

alyzed the statistics based on many-times fuzzing

campaigns.

• The efﬁciency and effectiveness of Schfuzz de-

pend on the property and amount of knowledge

given by testers. For example, testers give knowl-

edge about shared-memory addresses to be mon-

itored and the range of the function transformTo-

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

278

Table 3: Statistics on time to detect the bugs. “Runtime info.” indicates the methods. “shm” denotes Schfuzz, “bb” denotes

code-coverage-guided fuzzing, and “none” denotes dumb fuzzing. “#samples” means the number of the fuzzing campaigns

that detected the bugs. In the columns of the statistical values, “NA” means no values.

PUT Runtime info. #samples Mean [s] S.D. [s] Median [s] Min [s] Max [s]

motivating example

shm 93 176.96 165.14 108 10 593

bb 33 418.28 127.31 441 171 588

none 0 NA NA NA NA NA

reorder 10 bad

shm 20 8546.10 5147.28 7554 1043 19593

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

reorder 20 bad

shm 21 10240.33 5953.48 8574 1843 19050

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

safestack

shm 0 NA NA NA NA NA

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

twostage 100 bad

shm 0 NA NA NA NA NA

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

Table 4: Statistics on the estimated number of test cases generated to detect the bugs. “Runtime info.” indicates the methods.

“shm” denotes Schfuzz, “bb” denotes code-coverage-guided fuzzing, and “none” denotes dumb fuzzing. “#samples” means

the number of the fuzzing campaigns that detected the bugs. In the columns of the statistical values, “NA” means no values.

PUT Runtime info. #samples Mean S.D. Median Min Max

motivating example

shm 93 30788.32 27817.70 17895 3250 133884

bb 33 61217.48 18446.95 63653 23165 88163

none 0 NA NA NA NA NA

reorder 10 bad

shm 20 10134.85 5949.11 9276 1196 22791

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

reorder 20 bad

shm 21 6769.76 3721.73 6693 1189 12216

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

safestack

shm 0 NA NA NA NA NA

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

twostage 100 bad

shm 0 NA NA NA NA NA

bb 0 NA NA NA NA NA

none 0 NA NA NA NA NA

ValidAddr. The property and amount of knowl-

edge would affect the result.

• Concurrency bugs must be observable to detect

them with Schfuzz. Although we can observe the

bugs in the experimental PUTs as assertion fail-

ures, some concurrency bugs, such as deadlocks

and starvations, are hard to generalize how to ob-

serve because their deﬁnition depends on system

requirements.

• Although we evaluated Schfuzz with the ﬁve

PUTs, more experiments with more realistic

PUTs would allow us to evaluate it more precisely.

5 RELATED WORK

5.1 Concurrency Bug Detection

Many researchers have published works to detect con-

currency bugs. According to Fu et al. (2018), we can

classify them into the following three categories:

• Random delay disturbance (Park et al., 2009;

Chew and Lie, 2010).

• Thread scheduling/switching (Musuvathi et al.,

2008; Musuvathi and Qadeer, 2007; Yu et al.,

2012; Burckhardt et al., 2010).

• Fuzzing (Sen, 2008; Joshi et al., 2009; Cai et al.,

2014).

Schfuzz: Detecting Concurrency Bugs with Feedback-Guided Fuzzing

279

Table 5: Detection rates of the bugs. “Runtime info.” in-

dicates the methods. “shm” denotes Schfuzz, “bb” denotes

code-coverage-guided fuzzing, and “none” denotes dumb

fuzzing.

PUT Runtime info. Rate [%]

motivating example

shm 93.0

bb 33.0

none 0.0

reorder 10 bad

shm 66.7

bb 0.0

none 0.0

reorder 20 bad

shm 70.0

bb 0.0

none 0.0

safestack

shm 0.0

bb 0.0

none 0.0

twostage 100 bad

shm 0.0

bb 0.0

none 0.0

Random delay disturbance (Park et al., 2009;

Chew and Lie, 2010) is a category of methods that

randomly insert delays in PUT’s execution. Delays

induce various interleavings and can manifest latent

concurrency bugs. Stress testing is a common prac-

tice in this category. Nevertheless, methods in this

category are considered inadequate because they tend

to execute PUTs under similar interleavings.

Thread scheduling/switching (Musuvathi et al.,

2008; Musuvathi and Qadeer, 2007; Yu et al., 2012;

Burckhardt et al., 2010) is a category of methods that

control thread scheduling to execute PUTs under var-

ious interleavings. Schfuzz is classiﬁed into this cate-

gory because it controls thread scheduling based on

test cases generated by fuzzers. This category has

two sub-categories, systematic and non-systematic.

Systematic methods (Musuvathi et al., 2008; Musu-

vathi and Qadeer, 2007) explore interleaving space

systematically (i.e., exhaustively). However, it is in-

feasible to explore interleaving spaces of large-scale

real-world programs because the size of interleav-

ing space increases exponentially to the number of

threads and instructions in PUTs. Hence they often

have some budget limits (e.g., a time limit for explo-

ration) in practice. Although Thomson et al. (2016)

applied some systematic methods to the four PUTs we

used in our experiments to detect the bugs, no meth-

ods succeeded in detecting the bugs within a sched-

ule bound of 100,000. Non-systematic methods (Bur-

ckhardt et al., 2010) do not exhaustively explore in-

terleaving space. Schfuzz is non-systematic because

fuzzing has randomness and does not guarantee to ex-

plore the space exhaustively. Although it is similar to

random schedule generators, we can expect it can de-

tect concurrency bugs more efﬁciently and effectively

than random schedulers when we target complicated

programs because it is feedback-guided. In the exper-

iment by Thomson et al. (2016), a random scheduler

failed to detect the bugs in the four PUTs we used in

our experiments.

Fuzzing (Sen, 2008; Joshi et al., 2009; Cai et al.,

2014) is a category of methods to manifest potential

bugs reported by other methods, such as data-race de-

tectors. Although Fu et al. (2018) named the category

“fuzzing,” note that its meaning differs from that used

in the context of bug detection in sequential programs.

The efﬁciency and effectiveness of the methods in this

category to manifest bugs depend on methods to re-

port potential bugs.

Our research aims to apply feedback-guided

fuzzing to concurrency bug detection. Although it is

also an exciting research topic to compare Schfuzz to

them with quantitative metrics, that is currently out of

the scope.

5.2 Fuzzing Concurrent Software

As mentioned in section 2.2, though most fuzzing

studies aim to detect sequential bugs, some works tar-

get concurrency bugs like Schfuzz:

• ConAFL (Liu et al., 2018).

• MUZZ (Chen et al., 2020).

• AutoInter-fuzzing (Ko et al., 2022).

• CONZZER (Jiang et al., 2022).

• ConFuzz (Vinesh and Sethumadhavan, 2020).

Table 6 shows compare them to Schfuzz in summary.

Unfortunately, it is almost impossible to verify them

and to fairly compare them to Schfuzz with quantita-

tive metrics because their tools, except ConAFL

, are

publicly unavailable now

. In addition, ConAFL tar-

gets programs that process some input and run on Lin-

ux/pthread, so our motivating example and the pro-

grams in SCTBench (Thomson et al., 2016) are out of

the scope.

ConAFL (Liu et al., 2018) runs fuzzing campaigns

for PUTs, which are instrumented to run under vari-

ous interleavings and to induce to manifest potential

concurrency vulnerabilities. There are two main dif-

ferences between ConAFL and Schfuzz:

• ConAFL uses test cases generated by fuzzers only

for input-space exploration and explores inter-

leaving space by randomly varying threads’ prior-

ities. On the other hand, Schfuzz uses them to ex-

plore interleaving space. It deterministically de-

cides when to switch contexts based on test cases.

https://github.com/Lawliar/ConAFL

Feb. 06, 2023.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

280

Table 6: Comparing Schfuzz with the existing fuzzing studies. ✓

⋆

means partially yes because AutoInter-fuzzing controls

thread scheduling when it runs fuzzing in its interleaving mode.

Property ConAFL MUZZ AutoInter-fuzzing CONZZER ConFuzz Schfuzz

Directly exploring interleaving space ✓ ✓

Handling non-determinism in fuzzing ✓

⋆

✓ ✓

Reproducibility of detected bugs ✓ ✓ ✓

• ConAFL is a typical code-coverage-guided

fuzzer. It prefers test cases that improve the code

coverage in a fuzzing campaign.

MUZZ (Chen et al., 2020) runs fuzzing campaigns

for PUTs, which are instrumented to run under vari-

ous interleavings and to record runtime information

about thread interleavings. There are three main dif-

ferences between MUZZ and Schfuzz:

• MUZZ does not exclude the non-determinism of

thread scheduling, and Chen et al. (2020) do not

mention the reproducibility of detected bugs.

• MUZZ induces various interleavings by randomly

varying threads’ priorities. This strategy corre-

sponds to random delay disturbance in the clas-

siﬁcation of Fu et al. (2018) and is commonly in-

efﬁcient.

• MUZZ uses test cases to explore input space as

ConAFL.

AutoInter-fuzzing (Ko et al., 2022) prefers test

cases with which PUTs access shared memory from

many dispersed threads. There are two main differ-

ences between AutoInter-fuzzing and Schfuzz:

• AutoInter-fuzzing does not control thread

scheduling when it runs fuzzing in its normal

mode, so its non-determinism affects fuzzing

campaigns. Therefore, it can pick up a useless test

case as a seed by chance, resulting in inefﬁcient

and ineffective exploration.

• As ConAFL and MUZZ, AutoInter-fuzzing uses

test cases to explore input space.

CONZZER (Jiang et al., 2022) explores data races

by mutating pairs of function calls concurrently ex-

ecutable (concurrent call pair). There are two main

differences between CONZZER and Schfuzz:

• Although CONZZER tries to manifest data races

by executing various concurrent call pairs, it

might waste time exploring codes that have noth-

ing to do with data races because it does not con-

sider whether an executed concurrent call pair can

be involved in the data race (i.e., whether it ac-

cesses shared memory). On the other hand, Sch-

fuzz prefers to explore codes involved in concur-

rency bugs because it employs test cases that ac-

cess shared memory in an unobserved order as

seeds.

• As MUZZ, Jiang et al. (2022) do not mention the

reproducibility of detected bugs.

ConFuzz (Vinesh and Sethumadhavan, 2020) stat-

ically assigns weights to each basic block based on

distances from thread function call sites (e.g., mutex

lock/unlock). The weight of a test case is the sum of

the weights of executed basic blocks, and ConFuzz

prefers high-weight test cases. There are two main

differences between ConFuzz and Schfuzz:

• ConFuzz does not handle the non-determinism of

thread scheduling. As MUZZ and CONZZER,

Vinesh and Sethumadhavan (2020) do not men-

tion the reproducibility of detected bugs.

• As ConAFL, MUZZ, and AutoInter-fuzzing,

ConFuzz uses test cases to explore input space.

6 CONCLUSION

This research proposed Schfuzz, a novel method

to detect concurrency bugs with feedback-guided

fuzzing. It has two key points. First, it controls PUTs’

execution with test cases generated by fuzzer and

guarantees the reproducibility of detected bugs. Sec-

ond, it feeds back dynamic orders of shared-memory

access to explore interleaving space efﬁciently and ef-

fectively. For evaluation, we ran fuzzing campaigns

for the ﬁve concurrent programs with Schfuzz, code-

coverage-guided fuzzing, and dumb fuzzing. Schfuzz

detected the bugs in three of the ﬁve PUTs most ef-

fectively and efﬁciently. Although Schfuzz failed to

detect the bugs in the two PUTs, the other methods

also failed to detect them. This result shows that Sch-

fuzz can detect concurrency bugs more effectively and

efﬁciently than the other methods.

There are some future works derived from this re-

search. First, how to improve the efﬁciency and ef-

fectiveness of Schfuzz? It failed to detect the bugs in

the two PUTs in the experiment. This result means we

can further improve Schfuzz. Second, how to improve

the applicability of Schfuzz? Source code or binary

analysis may enable Schfuzz to automatically retrieve

information about PUTs currently given by testers.

Finally, can we extend the results of this research to

general? We evaluated Schfuzz with the hand-made

motivating example and the four most challenging

Schfuzz: Detecting Concurrency Bugs with Feedback-Guided Fuzzing

281

programs in SCTBench (Thomson et al., 2016) to de-

tect bugs. Experiments with various real-world soft-

ware will let us evaluate its generality more precisely.

REFERENCES

Bohme, M., Pham, V.-T., and Roychoudhury, A.

(2017). Coverage-Based Greybox Fuzzing as Markov

Chain. IEEE Transactions on Software Engineering,

45(5):489–506.

Brunner, E. and Munzel, U. (2000). The Nonparametric

Behrens-Fisher Problem: Asymptotic Theory and a

Small-Sample Approximation. Biometrical Journal,

42(1):17–25.

Burckhardt, S., Kothari, P., Musuvathi, M., and Na-

garakatte, S. (2010). A randomized scheduler with

probabilistic guarantees of ﬁnding bugs. In Proceed-

ings of the Fifteenth International Conference on Ar-

chitectural Support for Programming Languages and

Operating Systems, ASPLOS XV, pages 167–178,

New York, NY, USA. Association for Computing Ma-

chinery.

Cai, Y., Wu, S., and Chan, W. K. (2014). ConLock: A

constraint-based approach to dynamic checking on

deadlocks in multithreaded programs. In Proceed-

ings of the 36th International Conference on Software

Engineering, ICSE 2014, pages 491–502, New York,

NY, USA. Association for Computing Machinery.

Chen, H., Guo, S., Xue, Y., Sui, Y., Zhang, C., Li, Y.,

Wang, H., and Liu, Y. (2020). MUZZ: Thread-aware

Grey-box Fuzzing for Effective Bug Hunting in Mul-

tithreaded Programs. In Proceedings of the 29th

USENIX Security Symposium, SEC’20, pages 2325–

2342, USA. USENIX Association.

Chew, L. and Lie, D. (2010). Kivati: Fast detection and pre-

vention of atomicity violations. In Proceedings of the

5th European Conference on Computer Systems, Eu-

roSys’10, pages 307–320, New York, NY, USA. As-

sociation for Computing Machinery.

Fu, H., Wang, Z., Chen, X., and Fan, X. (2018). A system-

atic survey on automated concurrency bug detection,

exposing, avoidance, and ﬁxing techniques. Software

Quality Journal, 26(3):855–889.

Jiang, Z.-M., Bai, J.-J., Lu, K., and Hu, S.-M.

(2022). Context-Sensitive and Directional Concur-

rency Fuzzing for Data-Race Detection. In Proceed-

ings of the 29th Annual Network and Distributed Sys-

tem Security Symposium, NDSS 2022, Reston, VA. In-

ternet Society.

Joshi, P., Park, C.-S., Sen, K., and Naik, M. (2009). A

randomized dynamic program analysis technique for

detecting real deadlocks. ACM SIGPLAN Notices,

44(6):110–120.

Ko, Y., Zhu, B., and Kim, J. (2022). Fuzzing with automat-

ically controlled interleavings to detect concurrency

bugs. Journal of Systems and Software, 191:111379.

Liu, C., Zou, D., Luo, P., Zhu, B. B., and Jin, H. (2018).

A Heuristic Framework to Detect Concurrency Vul-

nerabilities. In Proceedings of the 34th Annual Com-

puter Security Applications Conference, pages 529–

541, New York, NY, USA. Association for Computing

Machinery.

Miller, B. P., Fredriksen, L., and So, B. (1990). An empiri-

cal study of the reliability of UNIX utilities. Commu-

nications of the ACM, 33(12):32–44.

Musuvathi, M. and Qadeer, S. (2007). Iterative context

bounding for systematic testing of multithreaded pro-

grams. ACM SIGPLAN Notices, 42(6):446–455.

Musuvathi, M., Qadeer, S., Nainar, P. A., Ball, T., Basler,

G., and Neamtiu, I. (2008). Finding and reproducing

heisenbugs in concurrent programs. In Proceedings

of the 8th USENIX Conference on Operating Systems

Design and Implementation, OSDI’08, pages 267–

280, USA. USENIX Association.

Park, S., Lu, S., and Zhou, Y. (2009). CTrigger: Ex-

posing atomicity violation bugs from their hiding

places. ACM SIGARCH Computer Architecture News,

37(1):25–36.

Rawat, S., Jain, V., Kumar, A., Cojocar, L., Giuffrida, C.,

and Bos, H. (2017). VUzzer: Application-aware Evo-

lutionary Fuzzing. In Proceedings of the 24th Annual

Network and Distributed System Security Symposium,

NDSS 2017, Reston, VA. Internet Society.

Sen, K. (2008). Race directed random testing of concurrent

programs. ACM SIGPLAN Notices, 43(6):11–21.

Stephens, N., Grosen, J., Salls, C., Dutcher, A., Wang, R.,

Corbetta, J., Shoshitaishvili, Y., Kruegel, C., and Vi-

gna, G. (2016). Driller: Augmenting Fuzzing Through

Selective Symbolic Execution. In Proceedings of the

23rd Annual Network and Distributed System Security

Symposium, NDSS 2016, Reston, VA. Internet Soci-

ety.

Thomson, P., Donaldson, A. F., and Betts, A. (2016). Con-

currency testing using controlled schedulers: An em-

pirical study. ACM Transactions on Parallel Comput-

ing, 2(4):1–37.

Vinesh, N. and Sethumadhavan, M. (2020). ConFuzz—A

Concurrency Fuzzer. In Proceedings of the 1st In-

ternational Conference on Sustainable Technologies

for Computational Intelligence, volume 1045 of Ad-

vances in Intelligent Systems and Computing, pages

667–691, Singapore. Springer Singapore.

Wen, C., He, M., Wu, B., Xu, Z., and Qin, S. (2022). Con-

trolled concurrency testing via periodical scheduling.

In Proceedings of the 44th International Conference

on Software Engineering, ICSE 2022, pages 474–486,

Pittsburgh Pennsylvania. Association for Computing

Machinery.

Yu, J., Narayanasamy, S., Pereira, C., and Pokam, G.

(2012). Maple: A coverage-driven testing tool for

multithreaded programs. ACM SIGPLAN Notices,

47(10):485–502.

Yun, I., Lee, S., Xu, M., Jang, Y., and Kim, T. (2018).

QSYM: A practical concolic execution engine tai-

lored for hybrid fuzzing. In Proceedings of the 27th

USENIX Security Symposium, SEC’18, pages 745–

761, USA. USENIX Association.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

282
