Process Mining and Perceived Privacy Violations: A Pilot-Study

Evelyn Zuidema-Tempel

, Faiza Allah Bukhsh

, Robin Effing

and Jos van Hillegersberg

Research Group Digital Intelligence & Business, Saxion University of Applied Sciences,

M. H. Tromplaan 28, Enschede, The Netherlands

Faculty of Electrical Engineering, Mathematics and Computer Science, University of Twente,

Drienerlolaan 5, Enschede, The Netherlands

Faculty of Behavioural, Management and Social Sciences, University of Twente,

Drienerlolaan 5, Enschede, The Netherlands

Keywords: Process Mining, Privacy, Perceived Privacy, Process Model Abstraction, BPM, GDPR.

Abstract: Despite the existence of various methods and abstraction techniques to reduce the privacy risk of process

models generated by process mining algorithms, it is unclear how process mining stakeholders perceive

privacy violations. In this pilot-study various process model visualisations were shown to 6 stakeholders of a

travel expense claim process. While changing the abstraction levels of these visualisations, the stakeholders

were asked whether they perceived a violation of their privacy. The results show that there are differences in

how individual stakeholders perceive privacy violations of process models generated via process mining

algorithms. Results differ per type of visualization, type of privacy risk reducing methods, changes of

abstraction level and stakeholder role. To reduce the privacy risk, the interviewees suggested to include an

authorization table in the process mining tool, communicate the goal of the analysis with all stakeholders, and

validate the analysis with a privacy officer. It is suggested that future research focuses on discussing and

validating process visualisations and privacy risk reducing methods and techniques with various process

mining stakeholders in organisations. This is expected to reduce perceived violations and prevents developing

techniques that are aimed at reducing privacy risk but are not considered as such by stakeholders.

1 INTRODUCTION

Process mining is a technique that is designed to

discover, monitor and improve actual processes by

extracting knowledge from event logs readily

available in today’s information systems (van der

Aalst, 2016). Process mining is increasingly being

adopted in industry as a data-driven innovation

(Grisold et al., 2021). With a forecasted growth of

40% to 50% for the coming years and passing $1

billion in revenues in 2022, the market is expected to

continue to rise (Gartner, 2020).

Like process mining, privacy is also gaining

attention in industry and society due to some recent

scandals. High profile cases such as the unwilling

exposure of user accounts at Yahoo and Facebook

and recent data breaches such as the case at the

Marriot hotel (Hill & Swinhoe, 2021) put the

spotlights on privacy. Also, data privacy is included

in many national and international legislations, such

as in the General Data Protection Regulation (GDPR)

in Europe (GDPR, 2022). The GDPR includes the

principle of privacy by design, meaning that

companies are encouraged to implement technical

and organizational measures necessary at the earliest

stage of the design of processing operations to ensure

the principles of privacy and data protection (GDPR,

2022).

Because event logs which are needed to mine

processes often contain personal information of

process stakeholders, the principles of privacy and

data protection also apply to process mining. In

academics, privacy and process mining as separate

research topics are gaining more attention, but

privacy preserving process mining is still in its

infancy (Mannhardt et al., 2019, Pika et al., 2020). To

the best of our knowledge, only a few studies have

been conducted to process mining and privacy

(Elkoumy et al., 2022, Sohail et al., 2021, Pika et al.,

2020, Rafiei & van der Aalst, 2020). These studies

mainly focus on privacy preserving methods and

abstraction techniques of process mining tools.

Abstraction is about simplifying process models

by removing edges, clustering nodes, and removing

Zuidema-Tempel, E., Bukhsh, F., Efﬁng, R. and van Hillegersberg, J.

Process Mining and Perceived Privacy Violations: A Pilot-Study.

DOI: 10.5220/0011745200003467

In Proceedings of the 25th International Conference on Enterprise Information Systems (ICEIS 2023) - Volume 2, pages 289-296

ISBN: 978-989-758-648-4; ISSN: 2184-4992

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

289

nodes to make the process model more

comprehensible for the person looking at it

(Maneschijn et al., 2022). Through abstraction,

irrelevant details in a process model can be reduced

(Polyvyanyy et al., 2015).

Remarkably, privacy preserving methods and

abstraction techniques to reduce the privacy risk have

hardly been evaluated from a stakeholder’s

perspective. We have not been able to identify

research that addresses perceived privacy violations

of stakeholders when abstraction techniques are being

applied to process models. As of yet, it is unclear how

stakeholders perceive a violation of privacy when

these methods and abstraction techniques are being

applied. And given the increased focus on privacy and

the fast growth of the process mining market, it is

vital that more research is conducted to process

mining privacy from a stakeholder's perspective. To

this end, the objective of this research is to identify

and evaluate perceived privacy with respect to

different abstraction levels from a stakeholder’s

perspective.

This paper is one of the first studies that

investigates perceived privacy in process mining

from a stakeholder’s perspective. Given the novelty

of the topic and thus the lack of theories and

experiences, we conducted an explorative pilot-study.

In this study, perceived privacy is identified and

evaluated by showing 6 process mining stakeholders

3 different process model visualisations of a travel

expense claim process. The process mining software

tool Disco is used to generate the process model

visualisations. When changing the abstraction level of

the visualisations, the 6 stakeholders are asked

whether they perceive a violation of privacy. Also,

the stakeholders are asked to give recommendation on

how to make the process mining visualisations more

privacy proof. The remainder of this research paper is

structured as follows; Section 2 highlights the

background research, and section 3 will discuss the

methodology used. Section 4 contains results and

section 5 contains the discussion and future work.

2 THEORETICAL

BACKGROUND

In this section we define perceived privacy and

survey which privacy preserving techniques for

process mining generated by process mining

algorithms are currently available in scientific

literature.

2.1 Process Models and Perceived

Privacy

Westin (1967) defines privacy as “the claim of

individuals, groups or institutions to determine for

themselves when, how, and to what extent

information about them is communicated to others”

(as cited by Könings et al., 2016). The definition of

privacy differs from the definition of perceived

privacy, which is the individual’s perception that their

personal information is safe from potential

compromise (Johnson et al., 2020). The risk of

violating perceived privacy is measured by

identifying participant’s willingness to share their

data (Bhatia & Breaux, 2018). In process models that

are generated using process mining algorithms,

various abstraction techniques can be applied to

reduce the privacy risk (Elkoumy et al., 2022, Pika et

al., 2020). The majority of process mining abstraction

techniques focus on the data preparation phase and

the data visualisation phase (Maneschijn et al., 2022).

It is important to note that these techniques aim at

reducing risk of privacy, but not on how reduced

privacy risk is being perceived by stakeholders.

2.2 Process Models Abstraction at the

Data Preparation Phase

Several abstraction techniques for process models

exist to reduce the privacy risk. First, process models

are abstracted by using external domain knowledge

taken from existing process documentation to semi-

automatically match events and process activities

(Baier et al., 2014). Second, clustering of data,

supervised learning techniques and behavioural

pattern modelling are used to reduce the privacy risk

in the data preparation phase (Diba et al., 2020, Rafiei

& van der Aalst, 2020, Bose & van der Aalst, 2009).

Third, Rafiei & van der Aalst (2021) describe various

group-based privacy preservation techniques to

improve privacy in the data extraction and

preparation phase. These are 𝑘-anonymity (remove

all the trace variants occurring less than 𝑘 times), and

𝑙-diversity (reducing granularity of data

representation) and t-closeness (further refinement of

l-diversity).

Also, various algorithms and web-based tools

exist to anonymize data for process mining, hence

reducing the privacy risk. These are among others

PC4PM (Rafiei et al., 2021) and PRETSA

(Fahrenkrog-Petersen, 2019). Sohail et al. (2021)

mention that higher preservation of privacy is realized

by applying various noise-adding plugins in the

academic process mining tool PRoM. These plug-ins

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

290

add noise to log filters, add k-frequent randomly

positioned activities, filter out high-frequency

activities and reverse process traces. Furthermore,

Van Zelst et al. (2021) identify seven different

dimensions of event abstraction techniques in the data

preparation phase of process mining. These are based

on supervision strategy, fine-granular event

interleaving, probabilistic nature of the outcome, data

nature, use of alternative perspectives, event class/

activity class relation and event instance/activity

instance relations. Finally, Pika et al. (2020) state that

case identifiers and activity labels can be encrypted in

data to increase privacy.

The abovementioned abstraction techniques come

with several challenges. When leaving out details in

a process mining analysis or process data, the utility

of identifying outliers and variances and determining

on concrete measures to address these outliers and

variances may be affected. (Mannhardt et al., 2018,

Rafiei & van der Aalst, 2020, Elkoumy et al., 2022).

Also, the identity of a data subject might be at risk

and can be recognized or identified when singling out

individuals from a supposedly anonymized or

pseudonymized event log or when applying

encryption (Elkoumy et al., 2022, Mannhardt et al.,

2018). Remarkably, all the mentioned abstraction

techniques have hardly been validated by process

stakeholders in organisations. Hence, they do not

focus on how these techniques are perceived by

process mining stakeholders as techniques of

reducing privacy risk.

2.3 Process Models Abstraction at the

Data Visualization Phase

Process model abstraction in the analysis and data

visualisation phase of a process mining project can be

performed using various options of the academic

process mining tool PRoM. The fuzzy miner

abstraction pattern plug-in uses conflict- and edge

resolution to remove insignificant lower-level

information in the process map visualization (van der

Aalst and Günther, 2007). Using the fuzzy miner,

Maneschijn et al. (2022) defined four threshold

abstraction levels (A, B, C and D) based on the utility

ratio, edge cut-off score and node cut-off score in

process mining models. Mannhardt et al. (2018) have

created guidelines for using process mining in

human-centered industrial environments. These

guidelines focus on informed consent of data subjects

of among others which data is stored, withdrawal of

data, but also of having the option to change the

aggregation settings when using or analysing the data

by primary users. Finally, Rozinat (2017) provides

practitioner experience reports on privacy of process

mining in an organizational setting. These are

clarification of goals to various stakeholders, have

external parties sign an NDA, and use encrypted

analysis to ensure responsible process mining and

reducing privacy issues at the data analysis and

visualization phase. However, advice given in the

consultancy papers of Rozinat (2017) lack empirical

foundation and scientific validation.

The available literature about reducing the privacy

risk when conducting process mining in the data

visualisation phase is much scarcer than the available

literature applied to the data preparation phase. And

the technical possibilities that do exist to reduce the

privacy risk focus mainly on PRoM. This tool is

mostly used for research purposes and is not aimed at

organisations and business. Abstraction techniques

that go beyond the technical possibilities presented

are scarce and lack scientific validation. In addition,

even when applying the abovementioned techniques,

it remains unclear how stakeholders of a process

mining project perceive privacy and potential privacy

violations. And given the fast growth of the process

mining market and the high focus on privacy, it is

vital to understand and act on how various process

mining stakeholders perceive privacy.

3 METHODOLOGY

In this explorative pilot-study which is executed at

Saxion University of Applied Sciences (UAS) in the

Netherlands, perceived privacy in the data

visualization phase of a process mining project is

identified and evaluated. In order to follow a

structured research approach, the PM2 process

mining methodology of van Eck et al. (2015) is used.

This methodology includes a complete overview of

the steps to be executed when conducting a process

mining analysis. These steps are planning, data

extraction, data processing, analysis, evaluation and

improvement.

3.1 Planning

The planning phase of this research includes a

literature study, process selection, and stakeholder

identification and selection. The results of the

literature study to process mining privacy and

abstraction described in section 2 of this research

paper. The travel expense claim process is selected as

the process to visualize. This process has been

selected because of data availability, and it is assumed

that this process is relevant, understandable and

Process Mining and Perceived Privacy Violations: A Pilot-Study

291

recognizable for the interviewees.

Next, relevant stakeholders of the travel expense

claim process are identified and selected. These

stakeholders are firstly identified in the PM2

methodology of van Eck et al. (2015). These

stakeholders are a business expert having knowledge

of the process and a data analyst who prepares the

data, creates the visualizations and analyses the

results. In addition, stakeholder identification took

place by identifying the stakeholders available in the

travel expense process dataset used in this research.

This dataset contains an employee, supervisor,

administrator, budget owner and a director. An

elaboration on the dataset can be found in section 3.2

and 3.3. At Saxion UAS the supervisor is the budget

owner. Therefore, the budget owner as a separate

stakeholder will not be included in this research. In

addition, the director at Saxion UAS is not directly

involved in the travel expense claims process.

Therefore the director will also not be considered as

a stakeholder in this research. The stakeholders that

are identified and taken into account in this research

are the employee, supervisor, administrator and the

analyst. Purposeful sampling is used to select the

interviewees from the direct network of the

researchers. The participants are known to be

involved in the travel expense process at Saxion UAS.

Although the sampling method has generalizability

issues, purposeful sampling is not costly and not time-

consuming, hence fits with the explorative nature of

this research (Stratton, 2021).

3.2 Data Extraction

The second step is data extraction. Due to

confidentiality reasons, no permission is given to use

data of travel expense claims from Saxion UAS.

Therefore, the publicly available travel expense

process data of the BPI challenge of 2020 (van

Dongen, 2020) is used to visualise the travel expense

claim process. The five available CSV datafiles of

this process contain events pertaining to two years of

travel expense claims of Eindhoven University of

Technology. In 2017 events are collected for two

departments, in 2018 for the entire university. The

datafiles are explored by converting the CSV datafiles

to an Excel file and compared with each other on

similarities, differences, and relevance of included

variables. Because the datafiles show overlap in

included variables, only the datafile Permit log has

been selected. This datafile includes most variables

with personal information from stakeholders, such as

variables of total declared amount, requested

expense, and overspent amount. These variables are

not always completely included in the other datafiles.

3.3 Data Processing

Data processing consists of data cleaning. By placing

a filter on the variables of the Permit log datafile, the

quality of the process data is investigated. The data is

cleaned by removing variables without attributes,

empty rows, and columns. Variable formats are

adjusted to be able to fit the process mining tool. The

result of the data cleaning process is a datafile

containing 86,582 rows of process data. In this

research the process mining software tool Disco is

used for creating the process visualisations. Disco

focuses on enterprises and we are investigating

perceived privacy from an organisational stakeholder

perspective. The cleaned data is imported to Disco.

3.4 Analysis

In the analysis phase the process model visualisations

were created using Disco and shown to the 6

interviewees. The interviews took place in June 2022

at Saxion UAS. In total 4 employees and 2

supervisors are interviewed. The administrator and

analyst are excluded from this research due to their

unwillingness to participate. The interviewees all

work at the same academy at Saxion UAS. Because

of the confidentiality and traceability of the

interviewees, more information on the interviewees

will not be provided.

To identify whether the interviewees perceive

privacy violations, 3 main process visualizations were

shown to the interviewees. Following the interface

design of Disco, these visualizations contain a

process map with frequency statistics and

performance statistics, a statistics overview with

variable frequency, and a statistics overview showing

the process data variables per variant and per

individual case. When the interface settings allowed

it, the abstraction levels of the visualisations were

modified. Table 1 contains the methods used in this

research to change the abstraction level of process

mining visualisations in Disco. These alterations in

abstraction level are described in the literature review

as l-diversity (Rafiei & van der Aalst, 2021), conflict

and edge resolution (van der Aalst & Günther, 2007)

and changing the aggregation settings of a process

visualization (Mannhardt et al., 2018). The numbers

in the table correspond with the available abstraction

techniques in Disco as shown in figure 1 in section 4.1.

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

292

Following the measurement of perceived privacy

by Bhatia & Breaux (2018), the interviewees were

asked whether they perceived a violation of their

privacy when the visualizations would be shown to

their supervisor, fellow employees, administrator or

process analysts. The same question was asked after

the abstraction level of the process visualization

changed. Next, the interviewees were asked for

suggestions on how to reduce the privacy risk of the

visualizations when they perceived such a risk.

3.5 Evaluation and Improvement

Per visualization, answers given by the interviewees

on perceived privacy, perceived privacy violations

and suggestions to reduce the privacy risk were

described and compared. The results of this

evaluation can be found in section 4.

4 RESULTS

In this section the interview results per process

visualization which follows the Disco interface

design are described and compared.

4.1 Process Map Visualisation

Figure 1 shows the visualization of the travel expense

claim process that was shown to the interviewees,

hence executing the analysis phase (step 4) of the

research methodology. The numbers 1 until 4 in

figure 1 are added manually and correspond to the

methods to change the abstraction level of the process

model as described in table 1.

Table 1: Methods to change the abstraction level of a

visualisation in Disco.

Nr. Methods

1 Activity slider to reduce the number of shown

activities in a process map visualisation

2 Path slider to reduce the number of shown

paths in a process map visualisation

3 Showing frequency statistics (yes/no)

4 Showing performance statistics (yes/no)

Figure 1: Process map of a travel expense claim process.

Results show that the 6 interviewees differ in how

they perceive privacy and whether they perceive a

violation of privacy when the abstraction level of the

process map changed. Two employees perceived no

violation of privacy when sharing the process map

visualization with employees, supervisors,

administrators and analysts. These employees claim

that sharing such a visualization that includes their

own data is beneficial for the organization as it helps

to detect fraud. In addition, these interviewees

mentioned that sharing the process map with all

process stakeholders increases transparency in the

organization. Changing the level of abstraction in the

process map via the activity slider and path slider, or

showing the frequency- or performance statistics did

not yield different results. Also, these interviewees

did not perceive differences in perceived privacy or

any violations of privacy if cases in the process map

could be linked to individuals.

The other two employees perceived a violation of

their privacy when it was possible to identify

individual cases. This privacy violation was only

perceived if the process map would be shown to

employees. Showing the process map including

traceability to individual cases to supervisors,

administrators or analysts did not lead to a perceived

privacy violation. According to these interviewees,

working with individual process data is considered

part of the job of these stakeholders. The activity

slider and path slider were considered suitable

methods to make the process map more privacy proof

as long as individual cases could not be logically

identified and traced back to individuals. Showing the

frequency statistics and performance statistics to all

stakeholders was not perceived as a violation of

privacy. The two supervisors agreed by stating that

privacy is not being violated when cases cannot be

traced back to individuals by employees.

Process Mining and Perceived Privacy Violations: A Pilot-Study

293

4.2 Statistics Interface

The statistics interface of Disco shows frequency

statistics and relative frequency statistics per variable

in the dataset. The two interviewees that did not

perceive any violations of their privacy at the process

map visualization also did not perceive privacy

violation when the statistics interface was shown to

stakeholders. Instead, perceived organizational

benefits such as fraud detection and increased

transparency were perceived. One of these two

employees did mention that when names of people

are included in the resource stream while this was not

pre-discussed in advance, this employee would

perceive a violation of privacy when the interface was

shown to employees.

The remaining two employees perceived a privacy

violation when the statistics interface was shown to

employees and contained an employee number,

declaration number, organizational entities and

declaration amounts. Especially in a small team the

interviewees expected that declaration amounts could

be traced back to individuals. According to the

interviewees this is undesirable, because it is unclear

where the information ends up and what the intention

is of people that share this information. The

interviewees expect that fellow colleagues are going

to form an opinion on the declarations, resulting in

gossip and rumor that the employees feel

uncomfortable with. The employees mentioned that

when managers, analysts and administrators see the

statistics interface with all its variables, privacy was

not being violated. Working with the data is

considered part of the job.

The two interviewed managers mentioned that

privacy of employees is being violated when sharing

declarations and amounts with employees if the data

can be traced back to an individual employee or user

ID. On the one hand it was mentioned that employees

could use this information for purposes other than the

process optimization, but on the other hand it was

mentioned that when working towards a more

transparent organization where teams want to

improve their own processes, then this information

must all be shared.

4.3 Cases Interface

The Cases interface of Disco shows all individual

attributes of the variables per process variant and per

case. At the Cases interface, more interviewees

perceived a violation of their privacy. Only one

respondent mentioned that showing individual cases

to all stakeholders was solely beneficial for

transparency reasons and detecting fraud. Also,

showing the cases visualization to all stakeholders

was perceived to accomplish a damping effect when

submitting a travel expense claim. The interviewee

considered this to be positive for the financial

situation of the organization. In addition, it was

expected that when people know that everyone could

see the data, then people would behave better and

more fairly.

The remaining employees felt that their privacy

was being violated when the variables and attributes

of individual cases was being shared with direct

colleagues (employees) and analysts. This mainly

goes for variables that are related to identify (resource

and organizational entity) and variables related to

declaration amount. The main arguments mentioned

for privacy violation were that having this

information is not part of their jobs and uncertainty

on the ethical behavior of colleagues.

The interviewed supervisors agreed with the

majority of the employees and mentioned that the

cases interface should only be accessible to managers

and administration. The main reason mentioned was

that insight on case level is needed to help to detect

fraud. Privacy is considered being violated when

analysts and employees see the individual cases and

their attributes. Especially when these stakeholders

see the resources and amount, individual privacy is

being violated.

The findings on whether each individual

interviewee perceived privacy violations (yes or no)

are summarized in table 2. In this table a distinction

has been made between the visualizations that were

shown to the interviewees.

Table 2: Perceived privacy violations per interviewee.

Interviewee Process map Statistics Cases

Employee 1 No No No

ee 2 No No Yes

ee 3 Yes Yes Yes

ee 4 Yes Yes Yes

Supervisor 1 Yes Yes Yes

Supervisor 2 Yes Yes Yes

4.4 Reducing the Privacy Risk

Various methods were suggested by the interviewees

to reduce the privacy risk of the process

visualizations. First, various employees and

supervisors suggested to include an authorization

table in the process mining tool. This is expected to

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

294

prevents undesired curiosity by stakeholders. In

addition, an authorization table is expected to help in

only showing travel expense claim information to

stakeholders that need information on case level to

execute their jobs. To improve transparency in the

organization and eliminate perceived privacy

violations, it was suggested by the supervisors to

communicate and discuss the goal and output

characteristics of the process mining visualization

with all process stakeholders. Objections to the

analyses and visualizations can be discussed in

advance. Validating the analysis with a privacy

officer to verify whether the analysis adheres to the

GDPR regulations and communicating about the

validation with all involved stakeholders is also

mentioned as an option to eliminate perceived privacy

violations. Pseudonymizing or anonymizing the data

in the statistics interface or cases interface was not

considered a suitable option by all interviewees to

eliminate perceived privacy violations. As the team in

which the employees and supervisors operate is

relatively small, the interviewees mentioned that it is

highly likely that pseudonymized or anonymized data

can be traced back to individuals. In addition,

pseudonymization and anonymization is expected to

make it harder for supervisors and administrators to

do their job and detect fraud.

5 DISCUSSION AND FUTURE

RESEARCH

The objective of this research was to identify and

evaluate perceived privacy with respect to different

abstraction levels from a stakeholder’s perspective.

The results show that there are differences in whether

individual stakeholders perceive privacy violations

when they are shown process models generated via

process mining techniques. Perceived privacy

violations vary between type of visualization, type of

technical privacy reducing method, change of

abstraction level and also between role of the

stakeholder.

This research has practical relevance as it shows

the importance of addressing perceived privacy with

process mining stakeholders in organizations.

Identifying difference and similarities in how various

process mining stakeholders perceive privacy could

help organizations decide which privacy preserving

methods and techniques can and cannot be applied.

Communicating with these stakeholders on perceived

privacy and taking actions to reduce or prevent

privacy violations could benefit the adoption of

process mining in organizations. This research is

scientifically relevant as it is one of the first research

conducted on stakeholders perceive process mining in

organizations. Not all currently available techniques

to reduce the privacy risk are perceived by

stakeholders as techniques that actually reduce the

privacy risk. Suggestions given by the interviewees

to reduce the privacy risk were only a fraction of the

identified techniques in literature to reduce this risk.

To prevent developing techniques that are aimed at

reducing privacy risk but are not considered as such

by stakeholders in organizations, it is suggested to

keep validating privacy risk reducing techniques with

process mining stakeholders in organizations. This

validation can contribute to designing techniques to

reduce the privacy risk of process mining that are

valued by stakeholders in organizations. Also, the

PM2 process mining methodology of van Eck et al.

(2015) does not include privacy in relation to a

process mining projects. This research shows that

privacy is of importance when executing a process

mining project. Therefore it is suggested that future

research on process mining methodologies takes

privacy into account.

The main limitation of this research is the sample

size of 6 interviewees. Based on the rule of logic it is

possible to deduce knowledge on how various process

mining stakeholders perceive privacy. But more

research on perceived privacy related to process

mining is needed to justify and develop claims that

are generalizable to other processes, organisations,

stakeholders and process mining tools. Furthermore,

no validated questionnaire or list of interview

questions exist on perceived privacy violations in

relation to process mining. As a result, a list of

questions was developed based on the available

interfaces of Disco. This method has issues related to

construct validity. Future research should emphasize

on expanding the questionnaire to other tools and

contexts to gain more in-depth knowledge on

perceived privacy related to process mining.

REFERENCES

Baier, T., Mendling, J., & Weske, M. (2014). Bridging

abstraction layers in process mining. Information

Systems, 46, 123–139. https://doi.org/10.1016/j.is.

2014.04.004

Bhatia, J., & Breaux, T. D. (2018). Empirical measurement

of perceived privacy risk. ACM Transactions on

Computer-Human Interaction, 25(6). https://doi.

org/10.1145/3267808

Process Mining and Perceived Privacy Violations: A Pilot-Study

295

Bose, R. P. J. C., & Van Der Aalst, W. M. P. (2009).

Context aware trace clustering: Towards improving

process mining results. Society for Industrial and

Applied Mathematics - 9th SIAM International

Conference on Data Mining 2009, Proceedings in

Applied Mathematics, 1, 397–408. https://doi.org/

10.1137/1.9781611972795.35

Diba, K., Batoulis, K., Weidlich, M., & Weske, M. (2020).

Extraction, correlation, and abstraction of event data for

process mining. Wiley Interdisciplinary Reviews: Data

Mining and Knowledge Discovery, 10(3), 1–24.

https://doi.org/10.1002/widm.1346

Elkoumy, G., Fahrenkrog-Petersen, S. A., Sani, M. F.,

Koschmider, A., Mannhardt, F., Von Voigt, S. N.,

Rafiei, M., & Waldthausen, L. Von. (2022). Privacy

and Confidentiality in Process Mining: Threats and

Research Challenges. ACM Transactions on

Management Information Systems, 13(1), 1–17.

https://doi.org/10.1145/3468877

Fahrenkrog-Petersen, S. A. (2019). Providing privacy

guarantees in process mining. CEUR Workshop

Proceedings, 2370, 23–30.

Gartner. (2020). Market Guide for Process Mining.

Gartner, September, 1–33. https://www.gartner.

com/doc/reprints?id=1-SBXXPQO&ct=190625&st=sb

GDPR. (2022). GDPR. General Data Protection

Regulation. https://gdpr.eu/

Grisold, T., Mendling, J., Otto, M., & vom Brocke, J.

(2021). Adoption, use and management of process

mining in practice. Business Process Management

Journal, 27(2), 369–387. https://doi.org/10.1108/BPMJ

-03-2020-0112

Hill, M., & Swinhoe, D. (2021). The 15 biggest data

breaches of the 21st century. https://www.cso

online.com/article/2130877/the-biggest-data-breaches-

of-the-21st-century.html

Johnson, V. L., Woolridge, R. W., Wang, W., & Bell, J. R.

(2020). The Impact of Perceived Privacy, Accuracy and

Security on the Adoption of Mobile Self-Checkout

Systems. Journal of Innovation Economics &

Management, n°31(1), 221. https://doi.org/10.391 7/jie.

pr1.0065

Könings, B., Schaub, F., & Weber, M. (2016). Könings, B.,

Schaub, F., & Weber, M. (2016). Privacy and trust in

ambient intelligent environments. Next Generation

Intelligent Environments (Pp. 133-164). Springer, Cham.

Maneschijn, D. G., Bemthuis, R. H., Bukhsh, F. A., & Iacob,

M. E. (2022). A Methodology for Aligning Process

Model Abstraction Levels and Stakeholder Needs. In

ICEIS (1) (pp. 137-147).

Mannhardt, F., Koschmider, A., Baracaldo, N., Weidlich,

M., & Michael, J. (2019). Privacy-Preserving Process

Mining: Differential Privacy for Event Logs. Business

and Information Systems Engineering, 61(5), 595–614.

https://doi.org/10.1007/s12599-019-00613-3

Mannhardt, F., Petersen, S. A., & Oliveira, M. F. (2018).

Privacy Challenges for Process Mining in Human-

Centered Industrial Environments. Proceedings - 2018

International Conference on Intelligent Environments,

IE 2018, 64–71. https://doi.org/10.1109/IE.2018.00017

Pika, A., Wynn, M. T., Budiono, S., Hofstede, A. H. M. T.,

van der Aalst, W. M. P., & Reijers, H. A. (2020).

Privacy-preserving process mining in healthcare.

International Journal of Environmental Research and

Public Health, 17(5), 1–12. https://doi.org/10.3390/ijer

ph17051612

Polyvyanyy, A., Smirnov, S., & Weske, M. (2015).

Business process model abstraction. Handbook on

Business Process Management 1: Introduction,

Methods, and Information Systems, 147–165. https://

doi.org/10.1007/978-3-642-45100-3_7

Rafiei, M., Schnitzler, A., & van der Aalst, W. M. P. (2021).

PC4PM: A tool for privacy/confidentiality preservation

in process mining. CEUR Workshop Proceedings, 2973,

106–110.

Rafiei, M., & van der Aalst, W. M. P. (2020). Privacy-

preserving data publishing in process mining. Lecture

Notes in Business Information Processing, 392 LNBIP,

122–138. https://doi.org/10.1007/978-3-030-58638-6_8

Rafiei, M., & van der Aalst, W. M. P. (2021). Group-based

privacy preservation techniques for process mining. Data

and Knowledge Engineering, 134(April), 101908.

https://doi.org/10.1016/j.datak.2021.101908

Rozinat, A. (2017). Privacy, security and ethics in process

mining. https://fluxicon.com/blog/2017/11/privacy-secu

rity-and-ethics-in-process-mining-part-2-responsible-ha

ndling-of-data/

Stratton, S. J. (2021). Population research: convenience

sampling strategies. Prehospital and disaster Medicine,

36(4), 373-374

Sohail, S. A., Bukhsh, F. A., & van Keulen, M. (2021).

Multilevel privacy assurance evaluation of healthcare

metadata. Applied Sciences (Switzerland), 11(22).

https://doi.org/10.3390/app112210686

van der Aalst, W. M. P. (2016). Process Mining Data

Science in Action. Springer.

van der Aalst, W. M. P., & Günther, C. W. (2007). Finding

Structure in Unstructured Processes: The Case for

Process Mining. Proceedings - 7th International

Conference on Application of Concurrency to System

Design, ACSD 2007, Acsd, 3–12. https://doi.org/10

.1109/ACSD.2007.50

van Dongen, B. (2020). BPI Challenge 2020.

4TU.ResearchData. Collection. https://doi.org/10.4

121/uuid:52fb97d4-4588-43c9-9d04-3604d4613b51

van Eck, M., Lu, X., Leemans, S., & Van Der Aalst, W. M.

P. (2015). PM2: a process mining project methodology.

International Conference on Advanced Information

Systems Engineering, 297–313.

van Zelst, S. J., Mannhardt, F., de Leoni, M., &

Koschmider, A. (2021). Event abstraction in process

mining: literature review and taxonomy. Granular

Computing, 6

(3), 719–736. https://doi.org/10.1007/

s41066-020-00226-2

Westin, A. F. (1967). Special report: legal safeguards to

insure privacy in a computer society. Communications

of the ACM, 10(9), 533-537.

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

296
