Towards Pattern Recognition with Network Science and Natural

Language Processing for Information Retrieval

Muskan Garg

1 a

, Mukesh Kumar

2 b

and Debabrata Samanta

3 c

Artiﬁcial Intelligence & Informatics, Mayo Clinic, Rochester, MN, U.S.A.

University Institute of Engineering & Technology, Panjab University, Chandigarh, India

Department of Computational Information Technology, Rochester Institute of Technology, Kosovo

Keywords:

Co-Word Analysis, Graph Theory, Information Retrieval, Linguistic Analysis, Pattern Recognition.

Abstract:

A surge in text-based information retrieval such as topic detection and tracking has increasingly shown growth

from static to dynamism in the last decade. We posit the need of investigating an interdisciplinary approach of

network science and natural language processing for graph-based information extraction. Post-lockdown era, it

makes sense to consider Graph of Words (GoW) evolved from user-generated text from social media platforms

amid increase in the internet trafﬁc. The idea is to unfold the latent patterns in graph-based text representation

with limited resource availability resulting in effective models, in comparison of computationally expensive

pre-trained models, limited to a certain type of information extraction. As a solution towards advancing sta-

tistical approach for language independent models, we plot three different information retrieval applications:

(i) Structural analysis: ﬁnd unique patterns in domain/ language/ genre-speciﬁc GoW for keyword extraction,

(ii) Language independence: design objective function for language-independent information retrieval, (iii)

Dynamism: mathematical modeling for concept-drift and evolving trends/ events in dynamic GoW evolved

from streaming data. We associate recent developments and open challenges with our position as potential

research direction.

1 INTRODUCTION

Evolution of text mining from rule-based analysis to

learning based mechanism has enriched this domain

with NLP-centered applications. To investigate latent

associations among words, we pose the integration

of network science and natural language processing

for syntactic pattern analysis. Such patterns facili-

tate information retrieval and suggest the viability of

NLP-centered information retrieval applications with

cost and time-effective solutions for NLP-centered

applications with streaming data. The development

in the ﬁeld of natural language processing points

to responsible AI information extraction methods.

The pre-trained model inherit theoretical limitations

of its ability to model certain type of information,

to transformer-based models (Chernyavskiy et al.,

2021). The sizeable improvements in existing models

are expensive hindering the environment with design

https://orcid.org/0000-0003-0075-9802

https://orcid.org/0000-0002-4920-670X

https://orcid.org/0000-0003-4118-2480

of the next generation deep NLP architectures. A ma-

jor challenge with use of learning-based mechanisms

and transformer-based models for NLP-centered ap-

plications is the language dependency. To handle this,

we need a Layer of Language-Independence (LLI).

We post this LLI as a potential encoding of any given

language in a high-dimensional vector. We further

discuss its applicability to real-time streaming data.

The structural analysis of complex networks enables

mathematical modeling of its dynamics through pref-

erential attachment model. Thus, formalizing dif-

ferent languages through network science facilitates

many NLP-centered applications such as inferring

mental states, topic detection and tracking, concept

drift, NLP-based recommendation systems and many

more.

Motivation. Past studies perform spectral analysis

for GoW through adjacency matrix to gleam eigen-

values. The proportion of difference between sub-

sequent eigenvalues is inversely proportional to the

size of GoW (Liang, 2017). To this end, a set of

all eigenvalues deﬁnes spectrum. Eigenvalues depicts

semantics of GoW which is a key component in ex-

Garg, M., Kumar, M. and Samanta, D.

Towards Pattern Recognition with Network Science and Natural Language Processing for Information Retrieval.

DOI: 10.5220/0011779700003411

In Proceedings of the 12th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2023), pages 495-500

ISBN: 978-989-758-626-2; ISSN: 2184-4313

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

495

isting random-walk based keyword extraction mech-

anisms (Campos et al., 2020). (Garg and Kumar,

2018a) illustrates the signiﬁcance of edge weights

over node degree distributions in path-based networks

such as GoW superseding the traditional random walk

mechanism on hub-authority based core-periphery

structure. To this end, we examine structural differ-

ence in GoW evolved for documents of various pre-

deﬁned languages.

2 OUR POSITION

Although, the tools of Natural Language Processing

(NLP) experienced a major shift during 1990’s in

transitioning from rule-based methods to statistical

approaches, most of today’s NLP research focuses on

20 of the 7000 languages of the world, leaving the

vast majority of languages under-explored (Maguer-

esse et al., 2020). We posit the integrated studies of

network science and natural language processing in

three categories:

1. Structural Analysis: ﬁnd unique patterns in do-

main/ language/ genre-speciﬁc GoW for keyword

extraction.

2. Language Independence: design objective func-

tion for language-independent information re-

trieval.

3. Dynamism: mathematical modeling for concept

drift and evolving trends/ events in dynamic GoW

evolved from streaming data.

For any given document D, consider a Graph of

Words (GoW) G representing unique words in vocab-

ulary as nodes V = {1, 2,3,...,n} and co-occurring

words in a given document as edges E = {E

),E

),...,E

= (V

n−1

)}. The net-

work science metrics and models on GoW glean in-

sights for information retrieval tasks. Based on latent

patterns, we further pose an objective function to op-

timize the parameters such that a given text T

that

belongs to one of the languages given in predeﬁned

set L is processed through objective function and con-

verted in low-dimensional embedding vector. Then,

pre-trained models for information retrieval tasks in-

cluding keyword extraction, topic detection, and con-

cept drift are provided an input of a low-dimensional

embedding vector.

3 STRUCTURAL ANALYSIS

In graph-based representations, complete graph

among all words of a sentence is often avoided in past

studies because its a common belief from linguistic

studies that a gap between two words is inversely pro-

portional to their relevancy (Hulth, 2003). A graph-

based textual representation are (i) Sliding window-

based GoW, (ii) Context aware graph, (iii) Multi layer

network, (iv) Line graphs (Garg, 2021), (v) Knowl-

edge graphs and (vi) Semantic graphs which we dis-

cuss as follows:

1. Sliding Window-Based GoW. A graph-based

text representation with edges between two words

co-occurring within a predeﬁned window called

sliding window n. A special case of GoW con-

struct Word-Adjacency Graph (WAG) or Word

Co-occurrence Network (WCN) for sliding win-

dow n = 2 delineating connections between adja-

cent terms.

2. Context Aware Graph. Entailment is deﬁned as

a phenomenon where consecutive sentences use

the context set by a given sentence, imparting con-

tinuity in communication (Duari and Bhatnagar,

2019). A window slides over two consecutive sen-

tences to (i) capture the contextual co-occurrence

of words, and (ii) eliminate the need of integer-

valued window-size parameter.

3. Multilayer Network. A potential network con-

struction happens in multiple layers to represent

words, syllable and grapheme in different lay-

ers for natural language understanding for differ-

ent languages such as Croatian and English (Mar-

tin

c-Ip

c et al., 2016).

4. Line Graphs. Line graphs represents co-

occurrence as a node in and word as an edge of

in the graph (Harary and Norman, 1960).

5. Knowledge Graph. Knowledge graphs use a

graph-based data model to capture knowledge

in NLP-centered applications employing beneﬁts

of graph-based abstraction over relational mod-

els (Hogan et al., 2021).

6. Semantic Graph. Semantic languages and mod-

els are increasingly used in order to describe,

represent and exchange data in multiple domains

and forms through RDF knowledge bases (

Cebiri

et al., 2019).

Inferences. We observe network science metrics for

the structural aspects of GoW evolved for different

genres: (i) Microblogs, (ii) essays, (iii) novels, (iV)

science articles, and (v) news reports in Table 1. We

study the chief characteristic feature of WCN to ex-

amine the behavioural aspects of GoW. The nature of

graph-based text representation is un-directed and un-

weighted. We use First Story Detection (FSD) dataset

(Petrovi

c et al., 2010) to compare structural aspects

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

496

Table 1: Network metrics in GoW for different genres.

Network Metrics Microblogs Essays Novels Science Articles News Reports

Length 183466 1142 5224 961 748

#Nodes 34925 440 1314 426 343

#Edges 116477 826 3199 734 581

Average degree 2.166 3.26 4.69 3.32 3.35

ASPL/ASPL

1.258/ 3.366 3.61/ 4.70 3.29/ 4.60 3.92/ 5.04 3.91/ 4.83

CC%/CC

% 0.493/ 0.00039 10.61/ 0.97 17.62/ 0.45 8.15/ 0.87 7.16/ 1.02

of the Microblog WCN with different genres: essays,

novels, popular science articles, and news reports. We

use ﬁrst 25000 tweets in FSD for experiments and

evaluation. With decrease in the number of nodes

in GoW, the value of CC for WCN to Erdos-Renyi

model decreases suggesting scalability for all gen-

res. The GoW for all genres follow the small-world

property. Furthermore, we enlist following open chal-

lenges and research gaps for handling different gen-

res:

1. Variations in the average degree of nodes in GoW

for different genre illustrates the disparity in vo-

cabulary and thus, patterns among words.

2. The extent to which observed metrics differs plays

a pivotal role in tracking behavioral and structural

aspect for different genres.

4 LANGUAGE INDEPENDENCE

With evolving digitization and surge in globalization

in multilingual countries having more than one ofﬁ-

cial languages points to a dire need of constructing the

language-independent platforms for NLP-centered

applications. N-gram a language-independent method

paves a path to exploit statistical measures and graph

theory to ﬁnd interesting patterns among words of

different languages (Majumder et al., 2002). On the

other hand, pre-trained models for NLP-centered ap-

plications have proved their effectiveness for different

languages, genres and problem domains. To resolve

language-dependency, we pose a Layer for Language

Independence (LLI) which converts a given text in of

any language from predeﬁned set of languages into a

common representation. Consider a given text T

T = {T

1(L

)

2(L

)

3(L

)

4(L

)

5(L

)

,...T

x(L

)

} (1)

where a text T

for i = {1,2,3,...,x} belongs

to a predeﬁned set of given languages L = {L

English,L

: Spanish,L

: Hindi....}. Consider GoW

) for a given text T

of language L

, we encode the

graph-based representation of T

by employing vector

embedding such as graph2vec or node2vec such that

the ﬁnal embedding results into alike outputs for ev-

ery text having similar information in any predeﬁned

language.

4.1 Related Work

Centrality-based network metrics derive many

language-independent methods for NLP-centered

applications (Beliga et al., 2015) deducing the need

of natural language understanding with latent patterns

among words in GoW. The graph-based information

extraction moves from graph theory to soft computing

by deploying well-known traditional methods such

as Random-walk (Vega-Oliveros et al., 2019; Biswas

et al., 2018) and Markov decision process (Garg and

Kumar, 2022). Recent advancements with semantic

graphs, knowledge graphs and pre-trained models,

enrich this domain even more. We unify different

languages by structuring given texts in graph-based

representation enabling vector embeddings such as

node2vec, graph2vec and x2vec (Grohe, 2020).

4.2 Inferences

The structural variations in GoW for different lan-

guages is illustrated in Table 2 through average de-

gree, Average Shortest Path Length (ASPL), and

Clustering Coefﬁcient (CC). The GoW construction

for parallel texts of 12 Slavic languages and 2 non-

Slavic languages compare and contrast the behaviour

of GoW for formal texts in different language (Liu

and Cong, 2013). To test the robustness of informal

texts, (Garg and Kumar, 2018b) examines the struc-

ture of Microblog WCN thereby introducing BArank,

a keyphrase extraction mechanism. We compare the

structure of WCN in 14 different languages as shown

in Table 2.

As per literature, the GoW evolved from informal

(social media Twitter data) is deﬁned as Microblog

WCN for edges among words in sliding window of

2. A consistent value of ASPL validates the average

length of words in the range of 3 and 4 for various

languages, both formal and informal. The value of av-

erage degree and CC in Microblog WCN and English

Towards Pattern Recognition with Network Science and Natural Language Processing for Information Retrieval

497

Table 2: The structural aspect for GoW evolved for various

languages, both formal and informal.

Language Average

Degree

ASPL CC

Microblog 2.166 3.144 0.076

Belarusian 4.819 3.797 0.100

Bulgarian 5.690 3.354 0.186

Chinese 8.684 2.944 0.283

Croatian 5.353 3.479 0.151

Czech 4.945 3.627 0.199

English 9.043 2.964 0.299

Macedonian 6.206 3.225 0.220

Polish 4.983 3.628 0.118

Russian 4.504 3.891 0.091

Serbian 5.348 3.485 0.147

Slovak 5.166 3.592 0.128

Slovenian 5.367 3.406 0.164

Ukrainian 4.865 3.814 0.096

Upper-Sorbian 5.347 3.550 0.131

WCN is approximately in the ratio of 1 : 4. Such vari-

ations illustrate difference in semantics of GoW for

different languages. We thus, pose the need to study

the structural aspects of texts for different language,

domain and genres. Furthermore, we enlist following

open challenges and research gaps for handling dif-

ferent languages to construct LLI:

1. Language. The words and grammar which are

used in a language are based on the script which it

follows. Every script may have latent patterns of

connectivity among words.

2. Script. There are variations in the number of ba-

sic units (Alphabets) and the number of dialects.

3. Vocabulary. The active vocabulary may vary for

each language may vary such as only 33% of the

total words in English dictionary is actively used

by human beings. This active vocabulary lim-

its the perplexity facilitating strong connections

among words with latent patterns and thus, better

understanding.

4. Case Variations: Challenging special features

such as Hungarian words have 18 to 35 cases that

presume meaning of the a speciﬁc through the

context of its use.

5. Word Order: Most languages depend on word

order to convey meaning such as Warlpiri, a lan-

guage of indigenous Australians. Semantics of

GoW may illustrate the latent patterns in word or-

ders.

5 DYNAMISM

With major focus on Television Rating Point (TRP)

by traditional news media, they broadcast viewers’

choices in lieu of current happenings (Petrovi

c et al.,

2010). After extensive academic research on ret-

rospective event detection from Twitter (Atefeh and

Khreich, 2015), NLP research community shifts the

focus to streaming data (Garg and Kumar, 2016).

Network science metrics such as k-core decompo-

sition (Meladianos et al., 2015), network cliques

(Rousseau, 2015) and assortativity (Garg and Kumar,

2018b) glean cohesiveness in GoW for information

extraction. The cohesiveness in GoW captures dense

sub-graphs and thus paves a path to construct dy-

namic models. The structural analysis set foundation

to model dynamism of words and their connectedness

through dynamic models such as preferential attach-

ment. Recently, (Saeed et al., 2019) contribute to-

wards dynamics of GoW through heartbeat graph ap-

proach.

For a set of i documents D = {d

,...,d

consider a Graph of Words (GoW) G representing

unique words in vocabulary as nodes V

V = {1,2,3,...,n} (2)

and co-occurring words in a given document as

edges E:

E = {E

: (V

),E

),...,E

= (V

n−1

)}

(3)

We further introduce growth and decay mecha-

nism for G as follows:

1. Growth. A graph G is updated for every time

interval (t

) where a chunk of documents is col-

lected, every word and connections are identiﬁed

to connect them with G resulting in graph at time

instance (t

) as G

2. Decay. For computational efﬁciency, it becomes

seemingly important to eliminate unimportant

nodes and edges from G

This iterative process of growth and decay func-

tion highlights signiﬁcant information as we observe

dense sub-graphs due to high cohesiveness among

nodes in sub-graphs. We suggest employing approxi-

mation algorithms for information retrieval.

6 CONCLUSION

The past work in (i) types of GoW (Garg, 2021),

(ii) examining semantics of languages-speciﬁc GoW

such as Chinese and English (Liang et al., 2009),

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

498

12 Salvic languages (Liu and Cong, 2013) and Mi-

croblogs (Garg and Kumar, 2018b); (iii) gleam in-

sights from GoW for various domains such as Text

Authorship (Akimushkin et al., 2017); (iv) applica-

bility of network science metrics such as power-law

(Choudhury et al., 2010), spectral distribution (Liang,

2017), has enriched this domain to investigate infor-

mation retrieval approach towards unifying language-

speciﬁc text in language-independent vector represen-

tation.

Due to versatility of the project and need of native-

language experts, a major challenge for introducing a

generic model on GoW is the construction of dataset:

samples and annotations. However, the access to

in-build NLTK corpus in Python language facilitates

the structural analysis of text documents in differ-

ent language. Furthermore, we found new multilin-

gual datasets for different NLP-centered tasks such

as MIRACL dataset

for information retrieval and

XCOPA

for causal commonsense. Such datasets fa-

cilitate structural analysis to ﬁnd unique patterns in

domain/ language/ genre-speciﬁc GoW for keyword

extraction. Structural analysis act as foundation to de-

sign language-independent objective function for in-

formation retrieval. An alternative application of dy-

namism construct mathematical modeling for concept

drift and evolving trends/events.

REFERENCES

Akimushkin, C., Amancio, D. R., and Oliveira Jr, O. N.

(2017). Text authorship identiﬁed using the dy-

namics of word co-occurrence networks. PloS one,

12(1):e0170527.

Atefeh, F. and Khreich, W. (2015). A survey of techniques

for event detection in twitter. Computational Intelli-

gence, 31(1):132–164.

Beliga, S., Me

strovi

c, A., and Martin

c-Ip

c, S. (2015).

An overview of graph-based keyword extraction

methods and approaches. Journal of information and

organizational sciences, 39(1):1–20.

Biswas, S. K., Bordoloi, M., and Shreya, J. (2018). A graph

based keyword extraction model using collective node

weight. Expert Systems with Applications, 97:51–59.

Campos, R., Mangaravite, V., Pasquali, A., Jorge, A.,

Nunes, C., and Jatowt, A. (2020). Yake! keyword

extraction from single documents using multiple local

features. Information Sciences, 509:257–289.

Cebiri

S., Goasdou

e, F., Kondylakis, H., Kotzinos, D.,

Manolescu, I., Troullinou, G., and Zneika, M. (2019).

Summarizing semantic graphs: a survey. The VLDB

journal, 28(3):295–327.

https://project-miracl.github.io/

https://github.com/cambridgeltl/xcopa#cite

Chernyavskiy, A., Ilvovsky, D., and Nakov, P. (2021).

Transformers:“the end of history” for natural lan-

guage processing? In Joint European Conference

on Machine Learning and Knowledge Discovery in

Databases, pages 677–693. Springer.

Choudhury, M., Chatterjee, D., and Mukherjee, A. (2010).

Global topology of word co-occurrence networks: Be-

yond the two-regime power-law. In Coling 2010:

Posters, pages 162–170.

Duari, S. and Bhatnagar, V. (2019). scake: semantic con-

nectivity aware keyword extraction. Information Sci-

ences, 477:100–117.

Garg, M. (2021). A survey on different dimensions for

graphical keyword extraction techniques. Artiﬁcial In-

telligence Review, pages 1–40.

Garg, M. and Kumar, M. (2016). Review on event detection

techniques in social multimedia. Online Information

Review.

Garg, M. and Kumar, M. (2018a). Identifying inﬂuential

segments from word co-occurrence networks using

ahp. Cognitive Systems Research, 47:28–41.

Garg, M. and Kumar, M. (2018b). The structure of word co-

occurrence network for microblogs. Physica A: Sta-

tistical Mechanics and its Applications, 512:698–720.

Garg, M. and Kumar, M. (2022). Kest: A graph-based

keyphrase extraction technique for tweets summariza-

tion using markov decision process. Expert Systems

with Applications, 209:118110.

Grohe, M. (2020). word2vec, node2vec, graph2vec, x2vec:

Towards a theory of vector embeddings of structured

data. In Proceedings of the 39th ACM SIGMOD-

SIGACT-SIGAI Symposium on Principles of Database

Systems, pages 1–16.

Harary, F. and Norman, R. Z. (1960). Some properties of

line digraphs. Rendiconti del Circolo Matematico di

Palermo, 9(2):161–168.

Hogan, A., Blomqvist, E., Cochez, M., d’Amato, C., Melo,

G. d., Gutierrez, C., Kirrane, S., Gayo, J. E. L., Nav-

igli, R., Neumaier, S., et al. (2021). Knowledge

graphs. ACM Computing Surveys (CSUR), 54(4):1–

37.

Hulth, A. (2003). Improved automatic keyword extraction

given more linguistic knowledge. In Proceedings of

the 2003 conference on Empirical methods in natural

language processing, pages 216–223.

Liang, W. (2017). Spectra of english evolving word co-

occurrence networks. Physica A: Statistical Mechan-

ics and its Applications, 468:802–808.

Liang, W., Shi, Y., Chi, K. T., Liu, J., Wang, Y., and Cui, X.

(2009). Comparison of co-occurrence networks of the

chinese and english languages. Physica A: Statistical

Mechanics and its Applications, 388(23):4901–4909.

Liu, H. and Cong, J. (2013). Language clustering with word

co-occurrence networks based on parallel texts. Chi-

nese Science Bulletin, 58(10):1139–1144.

Magueresse, A., Carles, V., and Heetderks, E. (2020). Low-

resource languages: A review of past work and future

challenges. arXiv preprint arXiv:2006.07264.

Majumder, P., Mitra, M., and Chaudhuri, B. (2002). N-

gram: a language independent approach to ir and nlp.

Towards Pattern Recognition with Network Science and Natural Language Processing for Information Retrieval

499

In International conference on universal knowledge

and language.

Martin

c-Ip

c, S., Margan, D., and Me

strovi

c, A. (2016).

Multilayer network of language: A uniﬁed frame-

work for structural analysis of linguistic subsystems.

Physica A: Statistical Mechanics and its Applications,

457:117–128.

Meladianos, P., Nikolentzos, G., Rousseau, F., Stavrakas,

Y., and Vazirgiannis, M. (2015). Degeneracy-based

real-time sub-event detection in twitter stream. In Pro-

ceedings of the international AAAI conference on web

and social media, volume 9, pages 248–257.

Petrovi

c, S., Osborne, M., and Lavrenko, V. (2010). Stream-

ing ﬁrst story detection with application to twitter. In

Human language technologies: The 2010 annual con-

ference of the north american chapter of the associa-

tion for computational linguistics, pages 181–189.

Rousseau, F. M. (2015). Graph-of-words: mining and re-

trieving text with networks of features. PhD thesis.

Saeed, Z., Abbasi, R. A., Razzak, M. I., and Xu, G.

(2019). Event detection in twitter stream using

weighted dynamic heartbeat graph approach [applica-

tion notes]. IEEE Computational Intelligence Maga-

zine, 14(3):29–38.

Vega-Oliveros, D. A., Gomes, P. S., Milios, E. E., and

Berton, L. (2019). A multi-centrality index for graph-

based keyword extraction. Information Processing &

Management, 56(6):102063.

ICPRAM 2023 - 12th International Conference on Pattern Recognition Applications and Methods

500
