Vulnerabilities in IoT Devices, Backends, Applications, and Components

Rauli Kaksonen

, Kimmo Halunen

and Juha R

oning

University of Oulu, Oulu, Finland

Keywords:

IoT, Vulnerabilities, Cyber Security, Information Security, NVD, CVE, CWE, CVSS.

Abstract:

The Internet of Things (IoT) is the ecosystem of networked devices encountered in both work and home. IoT

security is a great concern and vulnerabilities are reported daily. IoT is mixed into other digital infrastructure

both in terms of sharing the same networks and using the same software components. In this paper, we analyze

Common Vulnerabilities and Exposures (CVE) entries, including known exploited vulnerabilities, to describe

the vulnerabilities in the IoT context. The results indicate that 88% of reported vulnerabilities are relevant

to IoT systems. Half of the vulnerabilities are in the backend or frontend systems while 10-20% concern the

IoT devices. HTTP servers are the vulnerability hotspots wherever they are located. Software components are

used in all IoT subsystems and tracking and updating them is essential for system security. The results can be

used to understand where and what kind of vulnerabilities are in IoT systems.

1 INTRODUCTION

The Internet of Things (IoT) is the heterogeneous

ecosystem of networked devices. IoT is deeply mixed

with networked infrastructure, such as home net-

works, intranets, control systems, or hospital net-

works. The IoT backend systems are connected with

the other business functions. The IoT mobile appli-

cations share the same smartphones as other applica-

tions. The security of IoT is a great concern, partly

because of this connection with critical infrastructure.

It is not only the IoT system and its data at stake but

the whole system of systems. Further, an IoT system

is largely assembled from open source and other soft-

ware components. Some of them are speciﬁc to IoT,

but most are truly general-purpose.

It is not practical to separate IoT security concerns

from the big picture of cyber security. In this paper,

we analyze reported vulnerabilities and their connec-

tion to IoT. The goal is to understand how vulnerabil-

ities are distributed and which are the most important

ﬂaw categories. This should be useful for security re-

searchers, administrators, authorities, and others who

want to understand IoT security better.

The common vulnerabilities and exposures (CVE)

program maintains public vulnerability informa-

tion (MITRE, 2022a). The National Vulnerability

https://orcid.org/0000-0001-8692-763X

https://orcid.org/0000-0003-1169-5920

https://orcid.org/0000-0001-9993-8602

Database (NVD) is US government repository that

further tracks and augments CVE data (NIST, 2022a).

NVD includes also IoT vulnerabilities, but they are

not explicitly identiﬁed. Some CVEs represent vul-

nerabilities which are used in cyber-attacks while

many are never exploited. US Cybersecurity & Infras-

tructure Security Agency (CISA) maintains a known

exploited vulnerabilities catalog which lists actively

exploited CVEs (CISA, 2022).

A CVE entry usually has Common Weakness Enu-

meration (CWE) value(s), which describes the type of

underlying weaknesses (MITRE, 2022b). The view

CWE-1003 “Weaknesses for Simpliﬁed Mapping of

Published Vulnerabilities“ is a hierarchy of CWEs in-

tended to be used in NVD (MITRE, 2022b; NIST,

2022a). The view has 35 root CWEs, which may

have child CWEs. We use this as compression and

only show the roots with child CWE counts summed

in. Common Vulnerability Scoring System (CVSS)

describes the characteristics of a vulnerability and cal-

culate its technical severity (FIRST, 2022). The Com-

mon Platform Enumeration (CPE) is intended to un-

ambiguously identify the vulnerable product or soft-

ware (NIST, 2022b).

Information about vulnerabilities in IoT is abun-

dant. Open Web Application Security Project

(OWASP) is perhaps best known for its Top 10 Web

Application Security Risks, but it has also published

Top 10 Internet of Things Vulnerabilities (OWASP,

2022). Khoury et al. inspected 27 IoT malware sam-

Kaksonen, R., Halunen, K. and Röning, J.

Vulnerabilities in IoT Devices, Backends, Applications, and Components.

DOI: 10.5220/0011784400003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 659-668

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

659

ples and identiﬁed the CVEs used by them to pre-

dict which are going to be used by future malware

(Khoury et al., 2021). Several technical reports list

CVEs used in IoT malware or botnets (Caspi, 2022;

Caspi, 2021; Luptak and Palotay, 2021). Chatzoglou

et. al. performed a thorough study of Android IoT ap-

plication security (Chatzoglou et al., 2022). Mathas et

al. analyzed vulnerabilities in open-source software

applicable to 5G IoT devices (Mathas et al., 2021).

Mirani et al. tested 13 IoT devices and discovered

vulnerabilities in all of them (Mirani et al., 2019). We

look closer at these studies in Section 3.4 and com-

pare them to our results.

To the best of our knowledge, there are no studies

which holistically analyze reported vulnerabilities in

the IoT context. Our research questions in this study

are: 1) In the IoT context, where would one ex-

pect the vulnerabilities to appear? 2) What are the

most frequent types of vulnerabilities in the IoT

context?

2 METHODS

We use the real vulnerability information from the

NVD (NIST, 2022a). A careful analysis of the CVEs

are required to understand what is vulnerable and

how. The amount of detail and presentation varies

greatly, so we chose to manually analyse the CVEs

for accuracy. With around 20 000 CVEs added in a

year, we can only analyze subsets. Table 1 summa-

rizes the analyzed CVE data sets.

Firstly, we analyzed a random set of CVEs from

2021. Later, we created additional “NVD++” data set

to get more insight to the IoT device vulnerabilities.

The set is made up from randomly selected CVEs,

which were analyzed in-depth only if they appeared

to be relevant for IoT devices.

At the time of our research, the CISA set con-

tains 143 known exploited vulnerabilities for the year

2021 (CISA, 2022). Vulnerabilities used in IoT mal-

ware, mainly device vulnerabilities, are listed by

many sources (Caspi, 2022; Caspi, 2021; Khoury

et al., 2021; Luptak and Palotay, 2021). We analyzed

all these CVEs.

The frequency of mobile applications in the afore-

mentioned CVE sets is low. To understand mo-

bile application vulnerabilities better, we searched

for CVE descriptions with the words “mobile”, “an-

droid”, “ios” or “phone” followed by “app” from

years 2020-2021. The returned CVE set allows us to

analyze applications in general, but unfortunately not

speciﬁc to IoT. This search also discovered CVEs for

other subsystems when the search words were men-

Table 1: Sets of analyzed CVEs.

Set Years CVE selection criteria

NVD 2021 Random

NVD++ 2021 NVD with additional IoT device vulns.

CISA 2021 CISA known exploited vulnerabilities

IoT malware 2018-21 Vulnerabilities used in IoT malware

Mobile apps 2020-21 CVEs for mobile applications

Search hits 2021 CVEs with > 5000 Google search hits

tioned in the CVE.

Finally, we performed a Google search using

Google API Client python library using all CVE iden-

tiﬁers for the year 2021 (form “CVE-2021-dddd[d]”)

(Google, 2022). This gives us a view into CVEs by

their web presence. The set “Search hits” is the list of

CVEs with more than 5000 search hits.

As the data sets are selected with different crite-

ria, we cannot derive conclusions about vulnerability

proportions between the data sets. Thus, we focus on

variations within each data set.

2.1 Inferring Subsystems

To place the vulnerabilities in the IoT context, we use

a simple model with the following subsystems.

• Devices located on user premises, e.g. homes, fac-

tories, or hospitals. A network device provides

general-purpose network connectivity and an IoT

device delivers a special function or service.

• Backend system providing the business logic, data

store, and other services required by the IoT sys-

tem. A backend is typically located inside cloud

service provider data centers.

• Frontend is the interface of the backend towards

Internet. A frontend is connected by IoT devices,

applications, or web browsers.

• Mobile applications acting as the user interface for

the system.

• Operating system (OS) controls hardware and

provides the basic functionality to build devices,

services, applications, etc.

• Finally, all subsystems are built from a large num-

ber of general-purpose software components.

Devices are located outside of dedicated server rooms

and connected by a network. They can be often

reached by outsiders, either from the Internet, over

a wireless network, or physically. We separate the In-

ternet protocol (IP) network devices such as routers,

switches, and ﬁrewalls from the “true” IoT devices,

such as IP cameras, remote-controlled valves, and

smart sockets. An IoT hub or gateway acting as an

intermediary between IoT devices and/or IP-network

is considered an IoT device.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

660

The distinction between frontend and backend al-

lows differentiating the vulnerabilities exposed over

the Internet and the ones exploitable internally. IoT

devices typically connect to frontend by a web Appli-

cation Programming Interface (API) over HyperText

Transfer Protocol (HTTP). As the frontend is open to

the Internet, it is experiencing constant scanning and

intrusion attempts. To be categorized to the frontend,

a component must be intended to be Internet-facing,

otherwise it is backend. In practice, the division is

hard to make and the differences between the two sub-

system results are indicative rather than conclusive.

Many CVEs are for the major operating systems:

Android, iOS, MacOS, Windows, and Linux variants.

Android is well-known as a mobile phone OS, but it

is also used in IoT. Linux is used everywhere, in de-

vices, desktops, and servers. Windows is used in the

desktop, servers, but also in IoT devices. Apple’s iOS

is used in mobile phones, pads, and other personal de-

vices. MacOS is to the best of our knowledge not used

outside desktops. Apple has also tvOS.

When a vulnerability is reported in the interaction

between a frontend and a device or mobile applica-

tion, it is categorized as the CVE describes the situa-

tion. A CVE for a software component is categorized

by the primary function of the component with the ex-

plicit software component category as a fallback. For

example, a web API component goes to the frontend

and a mobile application framework goes to the mo-

bile. An image rendering component would be cat-

egorized as a component. Many vulnerabilities in a

subsystem are actually in software components.

2.2 Inferring Attack Vectors

For our study, we identify the attack vector(s) which

enable the exploitation of a vulnerability. CVSS al-

ready contain an Attack Vector metric, but it does not

give details like the network protocol (FIRST, 2022).

We infer a more detailed attack vector.

Browsing the CVE data quickly reveals that the

most common attack vector is Hypertext Transfer

Protocol (HTTP). HTTP is so prevalent that it is often

not explicitly mentioned, but it must be deduced from

the description. Vulnerabilities are also reported on

Domain Name System (DNS), Server Message Block

(SMB), Transport Layer Security (TLS), X.509 cer-

tiﬁcate handling, Internet Protocol (IP), Wireless Lo-

cal Area Network (WLAN), Bluetooth, etc.

Some vulnerabilities are in the parsing of differ-

ent ﬁle formats, with the vector of delivering the ﬁle

into the system often unknown. This includes failing

to properly sanitate stored ﬁles. Many vulnerabilities

are local, they cannot be exploited unless the attacker

Table 2: CVSS version 3 metrics and values, with an aster-

isk marking the worst value for the defender.

Metric Values

AV Attack Vector Physical, Local, Adjacent, Network*

AC Attack Complexity Low*, High

PR Privileges Required None*, Low, High

UI User Interaction None*, Required

S Scope Unchanged, Changed*

I, A

Conﬁdentiality, In-

tegrity, Availability

High*, Low, None

has access to the system, e.g. as a regular user. Vul-

nerabilities requiring physical access to the vulnera-

ble systems are included to the local attack vector. For

some CVEs, it is not possible to infer the attack vector

from the available information.

2.3 CVSS Metrics

CVSS is used to estimate the technical severity of

vulnerabilities (FIRST, 2022). The CVSS version

3 Base metric group contains the context and time-

independent information, see Table 2.

The metric Attack Vector deﬁnes the context

where exploitation is possible. (As said, we infer a

more detailed attack vector for analyzed CVEs.) At-

tack Complexity is high if exploitation requires con-

ditions beyond attacker control and low if it does not.

Privileges Required describes the level of privileges

the attack requires. A vulnerability may require User

Interaction to succeed. Scope indicates if the security

impact crosses security domains. Finally, the impact

metrics Conﬁdentiality, Integrity, and Availability es-

timate the effect of successful exploitation on the sys-

tem security goals. The value we consider the worst

value from the defender’s point of view is marked by

an asterisk in Table 2.

In the results, we highlight how the CVSS met-

rics vary between different CVE data sets and sub-

systems. To avoid the problem of converting CVSS

metrics into numeric values, we use the proportion of

the worst value. In NVD data the worst value is the

most common value for all but the Scope metric, as

the value Unchanged is more common than Changed.

The proportions are compared to the averages from

CVEs in 2020 and 2021.

2.4 Margin of Error

We calculate the margin of error (MOE) for some

resulting proportions M

= z

p(1 − p)/n, where p

is the proportion, n is the number of samples, and

z = 2.57 for 99% conﬁdence level or z = 1.96 for 95%

conﬁdence (Sheldon M., 2004, p. 260-262).

Vulnerabilities in IoT Devices, Backends, Applications, and Components

661

Table 3: Division of the vulnerabilities in subsystems by

analyzed CVE data sets.

NVD CISA hits

Total 156 143 135

Device 10% 14%

Mobile app 1%

Frontend 18% 16% 25%

Backend 31*% 24% 13%

OS 13% 24*% 31*%

Other 12% 17% 13%

Component 15% 13% 23%

95% margin ±7% ±7% ±8%

Table 4: Vulnerabilities reported in identiﬁed OSes in 2021

based on CPE information. MacOS and non-kernel Linux

vulnerabilities are not added to the total.

NVD all CISA Search hits

OS total 11% 25% 30%

Android 4.1%

Linux kernel 0.8% 1.5%

(Linux all) (4.5%) (9.1%) (23%)

Windows 2.7% 15% 22%

Apple iOS 1.6% 9.8% 6.7%

Apple tvOS 1.0% 2.8% 3.0%

(Apple MacOS) (2.0%) (8.4%) (8.1%)

Other OS 1.9%

3 RESULTS

The CVEs were selected for different data sets and a

total of 577 CVEs were analyzed. 484 were from the

year 2021, but some were older up to 2018. Table

3 gives the proportions of CVEs in different subsys-

tems in NVD data, CISA known exploited data, and

top search hit data. Some CVEs are in multiple data

sets and/or subsystems, thus there is overlap. The OS

row includes Android, Linux kernel, Windows, Apple

iOS and tvOS, and other OSes considered relevant in

the IoT context. Table 4 shows the breakdown of all

CVEs 2021 by OS.

In the generic NVD data, the vulnerabilities are

distributed 31% to backend, 18% to frontend, 15% in

components, 13% in OSes, 10% in devices, and 1%

in mobile. Thus, half of the CVEs are for the frontend

or backend. Most of the 12% of CVEs not considered

relevant are for desktop software or MacOS.

In CISA exploited vulnerabilities, the OS cate-

gory is increased to 24% share and in search hits to

31%. The frontend vulnerabilities overtake the back-

end 25% to 13%. Component vulnerabilities are in-

creased to 23% share.

The high search data share of OSes and compo-

nents is likely due to the high visibility of Windows

and Linux-related vulnerabilities. This can be ob-

served in the large share of “Linux all” row in Table

4 for the search result. Many exploited vulnerabilities

are in Windows, which remains the most exploited OS

in this study, as well. The results indicate that while

there are more vulnerabilities in backend components,

the vulnerabilities in the frontend may be considered

more serious. Many frontend components are closely

followed and their vulnerabilities are widely reported,

e.g. HTTP servers and security gateway products.

The last row of Table 3 gives the largest margin of

error with a 95% conﬁdence interval for each set.

In table 4 the OS breakdown is based on the CPE

information in all CVEs from 2021, not on analyzed

CVEs only. The row “Linux all” contain CVEs for

major Linux variants including various utilities which

are not really part of the OS. For this reason, we

only include kernel vulnerabilities in the OS count.

MacOS is not included in the OS count. The “Other

OS” row in the table does not capture those smaller

OSes, which we did not encounter in our analysed

CVEs, as we do not know their CPEs. Thus, the real

proportion is likely higher. This also explains why the

total proportion is 11% while in Table 3 it is 13%.

3.1 Common Attack Vectors

Table 5 shows the distribution of vulnerabilities by

subsystems and attack vectors. The table presents

CVE data set per row with the row percentages sum-

ming up to 100%.

The number of CVEs per row is in the column

“Data size”. The attack vectors summed in the

“Other” column are listed in the column “Other vec-

tors”. Devices are split into IoT devices and network

devices with the former containing the networking de-

vices and the latter the “true” IoT devices. As the

share of IoT devices in NVD data is low, an additional

“NVD++” data set was created to analyze them better.

In the NVD data, the attack vectors for IoT de-

vices were quite scattered as 41% are in “Other” at-

tack vector. The HTTP server is the most frequent

vector with 27% share in NVD data.

In the IoT malware data set all but one exploited

vulnerability is in HTTP servers. The attack vectors

for network devices are similar.

The CVEs for mobile applications were searched

using keywords, as explained earlier. The largest

group is the locally exploitable vulnerabilities. These

are weaknesses which allow e.g. a rogue applica-

tion to access sensitive data or functionality within the

phone. Many of the issues with unknown attack vec-

tor are likely to be either local or HTTP connection

issues, but the CVEs fail to pronounce this.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

662

Table 5: Vulnerability distribution in subsystems and attack vectors.

Subsystem Data set Data HTTP HTTP File Local Other Unknown Other vectors

size server client

IoT device NVD++ 22 27% 14% 41% 18% bluetooth dns ieee-1905 ip

mqtt ntp wiﬁ

IoT malw. 12 92% 8% upnp

Network device NVD 10 40% 30% 30% ip layer-2 tftp

IoT malw. 21 95% 5% smb

Mobile app Mobile app 61 3% 3% 5% 34% 20% 34% tls wiﬁ

Frontend NVD 28 82% 4% 14%

CISA 23 74% 26%

Mobile app 10 90% 10%

Backend NVD 48 52% 2% 8% 12% 10% 15% ip tls udp

CISA 34 74% 3% 12% 3% 9% ssh

OS NVD 21 5% 71% 14% 10% bluetooth sftp smb

CISA 35 23% 9% 57% 3% 9% smb

Component NVD 24 12% 25% 8% 4% 50% tls

CISA 19 95% 5%

Most of the frontend vulnerabilities are in HTTP

servers, which is expected for the wide use of HTTP

in connections. For the exploited frontend vulnerabil-

ities, the share of HTTP servers is lower, but many

of the unknown attack vectors are likely also HTTP.

Nine HTTP server frontend vulnerabilities were also

found by the mobile application CVE search. HTTP

is the most important attack vector also for the back-

end, but there are several locally exploitable vulnera-

bilities, too. In operating systems, most vulnerabili-

ties are locally exploitable, both in generic NVD data

and CISA exploited vulnerability data.

Many of the generic software components are in-

tended to handle input data in various unspeciﬁed sit-

uations and the attack vector is set to ﬁle or unknown.

The large number of HTTP client vulnerabilities in

CISA data are for Chromium web browser component

(The Chromium Projects, 2022).

3.2 Common Weaknesses

Table 6 gives CWE distribution per subsystem and

selected data sets. Only root CWEs from the view

CWE-1003 are shown, with possible child CWEs in-

cluded in the count. Proportions are given for sub-

system and data set, i.e. per row. When there are no

CWEs for speciﬁc subsystem and data set, the value

is omitted. The table includes the CWEs with at least

11% share in at least one row. This includes all root

CWEs with at least 2% share among all CVEs in 2020

and 2021. Asterisk marks cells, where the proportion

differs from the baseline with 99% conﬁdence.

Table 7 lists the names of the shown CWEs.

For IoT devices the most common weakness type

in NVD data is CWE-119 “Improper Restriction of

Operations within the Bounds of a Memory Buffer”.

For the IoT malware data set, the dominating weak-

ness is CWE-74 “Improper Neutralization of Special

Elements in Output Used by a Downstream Compo-

nent (’Injection’)”. For network devices the size of

NVD data does not allow much interpretation, but the

most common CWE in malware is also CWE-74.

For mobile applications there are many authenti-

cation and access control issues by CWE-287 “Im-

proper Authentication” and CWE-200 “Exposure of

Sensitive Information to an Unauthorized Actor” and

to some extent in CWE-863 “Incorrect Authoriza-

tion”. There are no CWE-119 issues, likely due to

the use of managed languages, like Java.

Frontend NVD data set top weakness is CWE-74

for command injection. The exploited vulnerabili-

ties are distributed to several CWEs. In the backend

the top weakness in both NVD and in CISA data is

CWE-74. Operating system top weakness is CWE-

119, there are no CWE-74 vulnerabilities. In the ex-

ploited OS vulnerabilities, the top weakness is CWE-

269 “Improper Privilege Management”. Component

weaknesses roughly follow the baseline distribution.

The peak weakness CWE-672 is due to Chromium

browser issues (The Chromium Projects, 2022).

3.3 CVSS Scores

Table 8 shows the CVSS version 3 scores and base

metrics for IoT vulnerabilities in selected CVE sets

and subsystems. Only the CVEs with CVSS scores

are included. The metrics are compared to the worst

value proportions in baseline CVEs 2020-2021. The

table shows the signiﬁcant (99% conﬁdence level)

base metric changes with the minimal difference of

0.2. Base metrics are identiﬁed by abbreviation (see

Table 5) followed by the delta to the baseline value.

For example, in the CISA data set the proportion of

CVEs with the worst value High in Conﬁdentiality,

Vulnerabilities in IoT Devices, Backends, Applications, and Components

663

Table 6: CWE distribution per subsystem and selected data sets. CWE proportions are given for subsystem and data set.

Asterisk marks cells, where the proportion signiﬁcantly differs from the baseline.

Subsystem Data set Data CWE

size 74 119 287 20 672 706 200 269 863

IoT device NVD++ 26 8% 38%* 12% 12% 8% 4% 8%

IoT malw. 11 82%* 18% 9%

Network device NVD 10 40% 20% 10%

IoT malw. 20 80%* 5% 5% 10%

Mobile app Mobile app 51 8% * 39%* 2% 4% 16%* 8%*

Frontend NVD 27 48%* 4% 4% 7% 11%*

CISA 16 19% 12% 19% 19%* 19%*

Backend NVD 40 42%* 10% 5% 2% 5% 2% 5% 5%

CISA 31 35% 3% 13% 13%* 3% 10%

OS NVD 16 38%* 6% 6% 6% 19%* 12%*

CISA 33 * 12% 9% 12%* 3% 52%*

Component NVD 22 18% 27% 9% 5% 9%

CISA 16 6% 31% 12% 38%*

All 2020-2021 38902 20% 14% 5% 4% 3% 3% 3% 3% 2%

Table 7: Names of the shown root CWEs.

CWE-74 Improper Neutralization of Special Elements in Output Used

by a Downstream Component (’Injection’)

CWE-119 Improper Restriction of Operations within the Bounds of a

Memory Buffer

CWE-287 Improper Authentication

CWE-20 Improper Input Validation

CWE-672 Operation on a Resource after Expiration or Release

CWE-706 Use of Incorrectly-Resolved Name or Reference

CWE-200 Exposure of Sensitive Information to an Unauthorized Actor

CWE-269 Improper Privilege Management

CWE-863 Incorrect Authorization

Integrity, and Availability is risen by 0.3, 0.4 and 0.3,

respectively. In the NVD data set, there are no signif-

icant changes, which is expected as NVD is a random

sample over the year 2021. This applies also in full

data over the years 2018 and 2021, the yearly vari-

ation in all metrics is less than 0.2, thus the shown

differences are not caused by trends.

The CVSS scores are elevated for the IoT mal-

ware, CISA, and top search hit CVEs. This is by the

bigger CIA impact but for IoT malware also due to

an increase in the Attack Vector (AV), User Privileges

(PR), and User Interaction (UI) proportions, i.e. vul-

nerabilities exploitable through the network without

user priorities or interaction. The exploitation of vul-

nerabilities in mobile applications also requires only

a few user privileges.

For subsystems, device vulnerability CVSS scores

did not signiﬁcantly differ from the baseline, thus they

are omitted. Subsystem CVEs are from the NVD data

set, except the mobile apps which have their dedi-

cated data set. AV is larger for frontends, as expected

since those are publicly exposed. The backend and

OS vulnerabilities often require initial user privileges

to be exploited. OS vulnerabilities also have reduced

AV. However, component vulnerabilities on average

Table 8: CVSS base metric changes in different CVE sets

and subsystems, proportion of worst value.

CVEs Score Metrics, worst value proportion

Baseline

2020-2021

37131 7.1 AV=0.7 AC=1.0 PR=0.6 UI=0.7

S=0.2 C=0.6 I=0.5 A=0.6

By CVE sets

NVD 156 6.9

CISA 143 8.5 C+0.3 I+0.4 A+0.3

IoT malw. 48 9.4 AV+0.3 PR+0.2 UI+0.3 C+0.4

I+0.5 A+0.4

Mobile app 82 6.7 PR+0.3 A-0.4

Search hits 134 8.2 C+0.3 I+0.3 A+0.3

By subsystems (Mobile app or NVD sets)

Mobile app 61 6.5 PR+0.2 A-0.4

Frontend 28 6.5 AV+0.3 A-0.3

Backend 48 6.8 PR-0.2

OS 21 7.0 AV-0.5 PR-0.3 UI+0.2 C+0.4

Component 24 7.4 PR+0.3 UI-0.3 A+0.3

require few privileges.

3.4 Comparison to Related Work

Table 9 presents vulnerability or risk categories from

selected other sources. The rank or frequency of each

category is shown, as given in the source. The re-

sults are mapped to our study by giving the number of

CVEs for each category per relevant CVE data sets, if

any. Also, a total count over the data sets is given. The

mapping is performed using subsystems and/or CWE

numbering. The entry “Not in CVE data” is used

when the category cannot be expected to be found

from CVEs.

OWASP Top 10 Internet of Things vulnerabili-

ties is intended to describe the whole IoT system,

thus we map it into CVEs in data sets NVD, CISA

and Search hits. The highest vulnerability category

is Weak, Guessable, or Hardcoded Passwords which

covers all credentials, not just passwords. Just 9% of

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

664

Table 9: IoT vulnerability or risk categories from selected sources mapped into analyzed CVE sets, if possible.

OWASP Top 10 IoT Rank NVD (156) CISA (143) Search hits (135) Total (381)

Weak, Guessable, or Hardcoded Passwords 1 11% 9% 7% 9%

Insecure Network Services 2 19% 23% 5% 17%

Insecure Ecosystem Interfaces 3 24% 31% 51% 33%

Lack of Secure Update Mechanism 4 Not in CVE data

Use of Insecure or Outdated Components 5 0%

Insufﬁcient Privacy Protection 6 Not in CVE data

Insecure Data Transfer and Storage 7 26% 34% 27% 27%

Lack of Device Management 8 Not in CVE data

Insecure Default Settings 9 Not in CVE data

Lack of Physical Hardening 10 Not in CVE data

Not mapped 46% 42% 40% 43%

OWASP Top 10 Web / Frontend Rank NVD (27) CISA (16) Search hits (20) Total (56)

Broken Access Control 1 44% 56% 45% 43%

Cryptographic Failures 2 0%

Injection 3 52% 25% 15% 36%

Insecure Design 4 25% 10% 7%

Security Misconﬁguration 5 0%

Vulnerable and Outdated Components 6 0%

Identiﬁcation and Authentication Failure 7 19% 10% 7%

Software and Data Integrity Failures 8 7% 5% 5%

Security Logging and Monitoring Failures 9 0%

Server-Side Request Forgery 10 6% 5% 2%

Not mapped 4% 12% 40% 20%

Mirani et. al / Device Frequency NVD (16) IoT malw. (31) Total (47)

Buffer Overﬂow 8% 31% 10% 17%

Cross-Site Scripting 92% 12% 4%

Command/SQL Injection 92% 25% 81% 62%

Authentication Bypass 38% 6% 6% 6%

Authorization Bypass 38% 12% 6% 9%

Cross-Site Request Forgery 38% 0%

File Upload Path Traversal 54% 12% 6% 9%

Not mapped 19% 0% 6%

Mathas et. al / IoT Devices # of vuln. NVD++ (36) IoT malw. (31) Total (67)

Improper Certiﬁcate Validation 2 8% 6% 7%

Buffer Overﬂow 104 33% 10% 22%

Weak cryptography 1 0%

Sensitive data exposure 22 3% 1%

Race condition 12 0%

Broken access control 0 3% 1%

Not mapped 53% 84% 67%

Chatzoglou et. al / Mobile app Frequency Mobile app (51) Total (51)

Permissions very common 20% 20%

APK signing and Janus 95% 0%

Network security and certiﬁcates 49% 16% 16%

CWE-311 100% 6% 6%

CWE-327 98% 2% 2%

CWE-330 100% 2% 2%

CWE-345 76% 2% 2%

CWE-732 98% 2% 2%

CWE-74 95% 8% 8%

CWE-287 46% 39% 39%

CWE-200 100% 16% 16%

CWE-749 55% 0%

CWE-919 39% 0%

Tracker analysis 95% Not in CVE data

Shared library analysis 95% Not in CVE data

Outdated software components 57% Not in CVE data

Not mapped 18% 18%

Vulnerabilities in IoT Devices, Backends, Applications, and Components

665

the CVEs are mapped to it.

Category Insecure Network Services maps to all

device vulnerabilities and Insecure Ecosystem Inter-

faces to frontend, and mobile. Lacking a category for

OSes, Windows and Linux is placed into the latter and

other OSes into the former category. With this, the

categories cover 17% and 33% of the analyzed CVEs,

respectively. The category Insecure Data Transfer

and Storage covers 27% of the CVEs. The other cat-

egories cannot be easily mapped into CVEs. In the

end, we are left with 43% of unmapped CVEs. These

are backend and general-purpose component vulnera-

bilities.

It may appear that the component and OS subsys-

tem vulnerabilities could be mapped into Use of In-

secure or Outdated Components category. However,

the category is for components which are not timely

updated or are insecure in another way. This informa-

tion is not available in the data.

OWASP Top 10 Web Application Security Risks

is a popular information source relevant for the fron-

tend subsystem (OWASP, 2022). The source lists the

CWEs for each category and we map the CVEs to

categories solely based on this. The resulting cov-

erage is fairly good, with just 20% of the CVEs left

unmapped. For general NVD data, this is only 4%.

Categories Broken Access Control and Injection

are the most prevalent in CVEs with frequencies of

43% and 36%. The category Cryptographic Failures

was not observed. Three other categories do not have

any CVEs, again the reason is likely that even when

these weaknesses are present no CVE is created.

Mirani et al. performed security testing on 13

home or small-ofﬁce network devices (Mirani et al.,

2019). We map the results to the device subsystem.

The vulnerabilities are all in HTTP servers, but we

did not limit the CVEs by HTTP attack vector, as we

wanted to get the frequencies over all vectors. The

mapping was very good with only 6% of CVEs left

unmapped. The result is so high as all CVEs used by

IoT malware were covered by vulnerabilities by the

Mirani et al. Still, even with generic NVD data only

19% of CVEs were unmapped.

Mathas et al. searched for vulnerabilities from 11

software modules in the context of 5G IoT devices by

source code analysis (Mathas et al., 2021). For each

category, we show the number of found vulnerabili-

ties. The relevant CWEs for categories are given and

used by us to ﬁnd the CVEs for the categories. Before

this, view CWE-1003 child CWEs are replaced by

their respective root CWEs for more loose matching.

As these are true IoT devices we use the larger IoT

device CVE data set NVD++. It appears that there

is consensus only for the buffer overﬂows, which are

found en masse by Mathas et al. and responsible for

22% of IoT device CVEs. Overall 67% of CVEs do

not fall into the categories presented by Mathas et al.

Chatzoglou et al. performed a comprehensive

study of various Android IoT applications (Chat-

zoglou et al., 2022). The analysis includes appli-

cation permissions, packaging, trackers, shared li-

braries, outdated components, taint analysis, and dy-

namic analysis. Static analysis was performed for 41

devices, but dynamic analysis only for 13. We only

include the former due to its larger coverage. This

material maps to our mobile app subsystem. The ﬁrst

category Permissions is an aggregate category indi-

cating that the studied applications tended to request

many permissions and/or failed to set proper permis-

sions. Suspicious permissions were discovered from

all applications, but some of them are indeed neces-

sary while some are not. For this, we did not put

“100%” as the frequency.

A total of 20% of CVEs was identiﬁed to be

caused by excessive permissions. APK signing and

Janus are about the ﬂaws in application packaging,

which were not present in the CVEs. Network secu-

rity and certiﬁcates are about the lack of encryption

or bad certiﬁcate handling. This mapped into 16% of

the app CVEs.

Chatzoglou et al. also listed the CWEs discov-

ered from the applications by static analysis. We

use them to pick relevant CVEs, but we again re-

place CWEs with the respective roots from the view

CWE-1003. The table lists the discovered CWEs ex-

cept for CWE-250 and CWE-913 as they were only

found from one app and are not present in CVEs.

Only two of the CWEs were frequently found from

the analyzed CVEs, CWE-287 “Improper Authentica-

tion” and CWE-200 “Exposure of Sensitive Informa-

tion to an Unauthorized Actor”. Many CWEs were

very common in the static analysis but much rarer

in CVEs. It may be that static analysis ﬁnds weak-

nesses which are not real vulnerabilities or at least not

exposed in the wild. Tracker analysis revealed that

IoT applications are littered with different tracking

modules which raise signiﬁcant concerns over user

privacy. This is not at all visible looking at CVEs.

Shared library analysis examined mostly if included

libraries were hardened against exploitation. Again,

these issues are not present in the CVE data. The

same goes for Outdated software components. Over-

all only 18% of CVEs were not mapped into any cat-

egory.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

666

3.5 Threats to Validity

As we use manual analysis for accuracy, the number

of analyzed CVEs is limited and we may have missed

some considered inﬂuential in some respect. How-

ever, as our focus was on the distribution of vulnera-

bilities, the role of individual CVE is small.

Some CVEs are somewhat vague and it is not pos-

sible to infer the subsystem or the attack vector. We

believe the only systematic error by this is that HTTP

appears less dominant as many CVEs fail to indicate

HTTP even when it is the vector.

The quality of CPE data looks low and different

values for the same product can be easily found. As

we only used CPEs for OS detection the impact in

our study is limited. A bigger worry is possible in-

consistencies in CWE assignments. We did not have

a chance to inspect this, but it is something which

should be kept in mind interpreting the results.

Mostly we used data from the year 2021, but some

data sets contain older material to get enough CVEs

to analyze. As old vulnerabilities can be used to com-

promise unpatched systems today, we do not think

this distorts the results. Further, when we looked at

CVSS data, we did not observe signiﬁcant changes in

CVE metrics since 2018.

4 DISCUSSION

In this study, we looked at the distribution and type of

vulnerabilities in IoT systems. IoT is fundamentally

mixed into other digital infrastructure both in terms of

sharing the same networks and using the same soft-

ware components. Thus, IoT vulnerabilities cannot

be easily isolated. We selected several sets of CVEs,

mainly from the year 2021. As the quality and quan-

tity of CVEs vary, we used careful manual analysis to

understand what is vulnerable and the type of the vul-

nerability in IoT context. In the end, only 12% of the

vulnerabilities we studied were not relevant to IoT.

In the ﬁrst research question, we ask how reported

vulnerabilities map into the IoT subsystems. The ex-

act distribution varies in data sets as their selection

criteria are different. Within generic NVD data, 31%

of the issues can be assigned to the backend, 18%

to the frontend, 15% to generic components, 13% to

OSes, 10% to devices, and 1% to mobile applications.

Looking at the exploited vulnerabilities, then the

proportion of backend vulnerabilities is reduced to

24%, frontend is risen to 16%, and OS to 24%.

In top search CVEs, these percentages are 13%,

25%, and 31%. There are no device issues in the top

search CVEs. It appears that frontend and OS security

problems are getting attention while IoT device secu-

rity is not. If we look at the results for the OWASP

IoT Top 10 then 17% of the CVEs are in devices and

33% in ecosystem interfaces. The numbers are differ-

ent as OS vulnerabilities are not separately counted.

Many, if not the majority, of the reported vulner-

abilities are in software components used in the sub-

systems. The 15% share of vulnerabilities in com-

ponents cover only the truly general-purpose compo-

nents. All subsystem categories include vulnerabili-

ties in domain-speciﬁc components or whose under-

lying cause is a ﬂaw in a component even when the

report is about a device or application. Further, three

out of ﬁve referred studies emphasize the use of bad

or outdated components as a major source of vulner-

abilities. Thus, monitoring and mitigating the vulner-

abilities in the component supply chain is essential.

This is not possible unless there is an up-to-date bill

of materials (BOM) identifying the used components.

The second research question was about the type

of vulnerabilities in IoT. The results indicate that

HTTP servers are the hotspot of vulnerabilities in de-

vices, frontends, and backends. This is not surpris-

ing as HTTP is such as common protocol. The most

signiﬁcant weakness category is CWE-74 “Improper

Neutralization of Special Elements in Output Used by

a Downstream Component (’Injection’)” and its child

CWEs. IoT malware mostly uses injection problems

in HTTP servers to propagate.

CWE-119 “Improper Restriction of Operations

within the Bounds of a Memory Buffer” is still fre-

quent in IoT devices and OSes. This is a bit frustrat-

ing as buffer overﬂow has been a problem for a long

time, one could have expected them to be eliminated

already.

Backend systems and OSes have many issues with

the local attack vectors. These can be exploited by

insiders, e.g. by a legitimate user or attacker who al-

ready has a beachhead in the system. Patching local

issues is important to maintain the defence in depth.

Mobile applications vulnerabilities were infre-

quent compared to other subsystems. In them, many

CVEs are related to different authentication and au-

thorization weaknesses. These are exposed when con-

necting to frontend or IoT devices, which seems to be

challenging to get right. Applications have also lo-

cally exploitable issues allowing a malicious applica-

tion to compromise other applications in the smart-

phone. Chatzoglou et al. back this ﬁnding as most

IoT-related applications seem to request far more per-

missions than required and/or fail to limit access to

their resources by other apps.

Comparing our results to the other related stud-

ies give mixed signals. There is some consensus on

Vulnerabilities in IoT Devices, Backends, Applications, and Components

667

the big role of HTTP servers, authentication, autho-

rization, and injection issues in IoT vulnerabilities.

The danger of using outdated or bad software com-

ponents is mentioned by several referred studies. Be-

yond these, there are signiﬁcant differences in the re-

sults. This may be due to different assessment strate-

gies. Especially many weaknesses found by static

analysis do not seem to correspond to CVEs. It is

difﬁcult to say whether this is because static analy-

sis ﬁnds weaknesses which are not vulnerabilities or

because these vulnerabilities are hard to ﬁnd. Com-

parison is also complicated by the fact that results are

presented differently.

Finally, a reader should understand that there are

categories of vulnerabilities which are not visible in

CVE data. Many security ﬁxes are done by the vendor

silently without creating a CVE. Excessive data col-

lection and other privacy issues and all too frequent

private data disclosures are not tracked by CVEs.

Missing security functionality, such as lack of soft-

ware update mechanism or lack of audit log, is not

covered by CVEs, either.

5 CONCLUSIONS

We analyzed 577 CVEs to learn the distribution of

vulnerabilities in the IoT. IoT is fundamentally mixed

with networks and infrastructure and a total of 88%

of analyzed CVEs were potentially relevant for IoT

systems.

An estimated half of the vulnerabilities are in the

backend and frontend systems while only 10-20%

concern the IoT devices.

Protecting HTTP servers, wherever they are, is

a priority as they are vulnerability hotspots. Espe-

cially beneﬁcial would be the elimination of the com-

mand injection vulnerabilities. Many vulnerabilities

are in software components used in all IoT subsys-

tems. Tracking these vulnerabilities and timely mit-

igating new vulnerabilities in them is essential for

IoT security. Comparison to other IoT vulnerability

studies found common trends, but also notable differ-

ences. Categories vary between studies, making com-

parison difﬁcult. The use of consistent vulnerability

categories would be highly desirable.

ACKNOWLEDGMENTS

This work is supported by Finnish Scientiﬁc Advisory

Board for Defence (MATINE/2500M-0152).

REFERENCES

Caspi, O. (2021). Rapidly evolving IoT malware EnemyBot

now targeting Content Management System servers

and Android devices. Technical report, AT&T Alien

Labs.

Caspi, O. (2022). AT&T Alien Labs ﬁnds new Golang mal-

ware (BotenaGo) targeting millions of routers and IoT

devices with more than 30 exploits. Technical report,

AT&T Alien Labs.

Chatzoglou, E., Kambourakis, G., and Smiliotopoulos, C.

(2022). Let the cat out of the bag: Popular android iot

apps under security scrutiny. Sensors, 22:513.

CISA (2022). Known Exploited Vulnerabilities Cat-

alog, Cybersecurity & Infrastructure Security

Agency. https://www.cisa.gov/known-exploited-

vulnerabilities-catalog.

FIRST (2022). Common Vulnerability Scoring System

SIG. https://www.ﬁrst.org/cvss/.

Google (2022). Google API Client Python library.

https://pypi.org/project/google-api-python-client/.

Khoury, R., Vignau, B., Hall

e, S., Hamou-Lhadj, A., and

Razgallah, A. (2021). An Analysis of the Use of CVEs

by IoT Malware. In Foundations and Practice of Secu-

rity, pages 47–62, Cham. Springer International Pub-

lishing.

Luptak, G. and Palotay, D. (2021). IoT Botnet Report 2021:

Malware and Vulnerabilities Targeted. Technical re-

port, CUJO LLC.

Mathas, C.-M., Vassilakis, C., Kolokotronis, N., Zarakovi-

tis, C. C., and Kourtis, M.-A. (2021). On the design of

iot security: Analysis of software vulnerabilities for

smart grids. Energies, 14(10).

Mirani, S., Meyer, J., Ramgattie, R., and Sindermann, I.

(2019). SOHOpelessly Broken 2.0: Security Vulner-

abilities in Network Accessible Services. Technical

report, Independent Security Evaluators LLC.

MITRE (2022a). Common Vulnerabilities and Exposures

Home Page. https://cve.mitre.org/.

MITRE (2022b). Common Weakness Enumeration Home

Page. https://cwe.mitre.org/.

NIST (2022a). National Vulnerability Database.

https://nvd.nist.gov/.

NIST (2022b). Ofﬁcial Common Platform Enumeration

Dictionary. https://nvd.nist.gov/products/cpe.

OWASP (2022). Open Web Application Security Project

(OWASP) Foundation. https://owasp.org/.

Sheldon M., R. (2004). Introduction to Probability and

Statistics for Engineers and Scientists., volume 3rd ed.

Academic Press.

The Chromium Projects (2022). The Chromium Projects

Home Page. https://www.chromium.org/.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

668
