A Game Theoretic Analysis of Cyber Threats

Paul Tavolato

, Robert Luh

1,2

and Sebastian Eresheim

1,2

Research Group Security and Privacy, University of Vienna, Kolingasse 14-16, A-1090 Vienna, Austria

Department of Computer Science, UAS St. Pölten, A-3100 St. Pölten, Austria

Keywords: Cyber Threat Analysis, Game Theory.

Abstract: Cyber threat analysis is crucial to securing modern IT systems. In the ongoing project described here a strictly

mathematical method for threat analysis is sketched. The threat landscape between an attacker (hacker) and a

defender (system owner) is modeled along the formalisms of stochastic game theory, thus opening the way

for a rigorous formal analysis. The key benefit of the project is its applicability to real-world situations.

Therefore, the information about possible attack and defense actions is taken from several proven data sources

resulting in a large number of actions (173 attack actions and 115 defense actions). We present an adaptation

of the so-called Princess-and-Monster game to model the problem. Various problems with the formalization

are discussed. To keep the model manageable despite the claim of practicality, it is applied only to specific

scenarios mimicking real-world situations.

1 INTRODUCTION

Threat analysis, as part of cyber risk analysis, is a key

factor in today’s IT management. Risk analysis

studies the probability of potential risks and what

impact they would have if, in fact, they were to occur.

Such analysis is an indispensable requirement for the

planning of preventive and counteractive measures.

As these measures are generally financially relevant,

a quantitative approach to risk analysis is preferable.

This implies that threat analysis, too, must rest on a

strong quantitative foundation.

This paper focuses on the process of assessing the

capabilities and activities of unknown intelligence

entities or criminals aimed at an organization’s IT

system. In other words, we consider malicious acts

that seek to disrupt proper operation of an IT system

by violating one or more of the central cybersecurity

properties: the CIA triad – confidentiality, integrity

and accessibility as defined in (Keyser, 2018).

In the literature some methods for threat analysis

have been proposed, including STRIDE and Pasta

(see for example (Shostack, 2014), (Tarandach &

Coles, 2020), or (Swiderski & Snyder, 2004)). These

methods, albeit useful in practice, have an essential

drawback: they are mainly of an informal or semi-

formal nature and thus lack a strong mathematical

background. We suggest using game theory as the

mathematical framework for a rigorous treatment of

threat analysis.

By formally defining the situation of an attacker

and a defender as a game, one can analyze essential

properties of the situation, giving valuable input

regarding the costing and planning of a defense

strategy together with the necessary measures to

enforce this strategy with the aim to detect, mitigate

or – at best – prevent attacks on the system.

The main objectives of the project are to develop

a rigorous mathematical framework for analyzing

real-world threat scenarios. The mathematical

framework is based on game theory. A high degree of

practical relevance is achieved by mimicking real-life

situations in cyber security by taking information

about attack and defense activities from several

proven data sources. Another innovative element of

the project is the incorporation of stochastic features

in the game theoretic model: Each action by one of

the players is assigned a success probability. Only if

the action succeeds, the effects associated with that

action are realized.

The current state of the project comprises a game

theoretic model representing the threat landscape of a

defender and an attacker as a game. The game is

based on a so-called Princess-and-Monster game,

which is adapted to fit cyber threat situations.

Furthermore, a complete list of attack actions is

compiled containing for each action a description, the

706

Tavolato, P., Luh, R. and Eresheim, S.

A Game Theoretic Analysis of Cyber Threats.

DOI: 10.5220/0011792700003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 706-713

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

skill requirements of the action, a success probability,

and the damage effect in case of a successful

execution of the action. A complete list of defense

actions is compiled, too, containing the skill

requirements of the action, a success probability, and

eventually a mitigating (“healing”) effect of the

action.

2 RELATED WORK

Some formal aspects of threat and/or attack modeling

are described in (Guelzim & Obaidat, 2015). A

method widely used in threat analysis is based on

attack-defense trees (ADT). Lately, semi-formal and

formal treatments of ADTs were developed; see

Wideł et al. (Wideł, Audinot, Fila, & Pinchinat, 2019)

for an overview of the use of formal models in

security.

In particular, the paper (Aslanyan, Nielson, &

Parker, 2016) describes a formal system for analyzing

quantified properties of attacks while in a paper by

Gadyatskaya et al. (Gadyatskaya, Hansen, Larsen,

Legay, Olesen, & Poulsen, 2016) Priced Timed

Automata are used to formalize attack trees.

However, defense actions are not included, and no

stochastic aspects were used in this approach.

A stochastic analysis of attack trees is discussed

in (Pekergin, Tan, & Fourneau, 2016). In (Buldas,

Gadyatskaya, Lenin, Mauw, & Trujillo-Rasua, 2020)

constraint programming is used to evaluate attack

trees with incomplete information.

The first paper suggesting stochastic game theory

(Shapley, 1953) in connection with cyber security

was published in 2002 (Hamilton, Miller, Ott, &

Saydjari, 2002). Kordy et al. (Kordy, Mauw,

Melissen, & Schweitzer, 2010) formally proved the

equivalence of attack-defense trees and game theory.

There are several papers about the application of

game theory to various aspects of security: a good

overview, though restricted to cyber-physical

systems, is given in (Etesami & Basar, 2019). Other

game-theoretic approaches are discussed in

(Bommannavar, Alpcan, & Bambos, 2011), (He,

Zhuang, & Rao, 2012), (Luo, Szidarovszky, Al-

Nashif, & Hariri, 2010), (Nguyen, Alpcan, & Başar,

2009), (Sallhammar, Helvik, & Knapskog, 2006),

(Sajjan, Sankardas, & Dipankar, 2010), (Tabatabaei,

2016), (Zhang, Wang, & Zhuang, 2021), (Li, Peng,

Zhu, & Basar, 2021), (Jie, Choo, Li, Chen, & Guo,

2019), and (Han, Niyato, Saad, & Başar, 2019).All

the papers give some small examples to illustrate the

viability of the method, but do not cover threat

analysis for real-world situations.

The paper closest to our work is by Attiah et al.

(Attiah, Chatterjee, & Zou, 2018); they study

achievable mixed strategy Nash equilibria, but do not

incorporate success probabilities.

3 GAME THEORY AND THREAT

ANALYSIS

3.1 The Game

As a mathematical approach to rigorously model

threat situations, game theory for non-cooperative

games suggests itself. In cyber threat scenarios there

are two opponents playing (i.e., fighting) against each

other. Each opponent has an arsenal of actions,

though there are different actions available to the two

opponents (attack and defense actions, respectively).

The structure of the game discussed here is

adopted from PenQuest (Luh, Eresheim, Großbacher,

Petelin, Mayr, Tavolato & Schrittwieser, 2022), a

digital cyber security role-playing game, where an

attacker attempts to compromise an IT infrastructure

and the defender tries to prevent or mitigate the threat.

The attacker has a predefined goal (violating one part

of the CIA triad), and the defender has a given

infrastructure he wants to defend against attacks. The

distinct strength of this game, which distinguishes it

from others, is its closeness to real world situation: to

render it as realistic as possible the attack and defense

actions that are part of the game are taken from

several proven data sources such as STIX (Structured

Threat Information eXpression language) (MITRE

Corporation, D), the APT kill chain by Hutchinson

(Hutchins, Cloppert, & Amin, 2011), the CAPEC

(Common Attack Pattern Enumeration and

Classification) attack patterns (MITRE Corporation,

A), the MITRE ATT&CK (Adversarial Tactics,

Techniques & Common Knowledge) attack and

mitigation patterns (MITRE Corporation, B), the

NIST SP 800-53 Countermeasures (Joint Task Force

Transformation Initiative, 2015), and MITRE

D3FEND (MITRE Corporation, C). In the game

mentioned above there are 173 different attack

actions and 115 different defense actions defined.

Attack actions are subdivided into three

categories along the attack stages: Reconnaissance,

Initial Access, and Execution. A stage can only be

entered if the preceding stage has been completed

successfully. Each action requires a minimum skill

level of the attacker (1, 2, 3, 4or 5) and has a success

probability. Effects of a successful attack action may

be twofold:

A Game Theoretic Analysis of Cyber Threats

707

a) the damage achieved within the defender’s

system in the three dimensions

Confidentiality, Integrity, Availability.

Damage is measured with a number between 0

and 3, where 3 designates maximum damage

and means that the attacker has reached his/her

goal; damage accumulates throughout the

game; and

b) a gain of insight into the defender’s

configuration, enabling a more specific choice

of subsequent actions and thus resulting an

increase in the success probabilities of those

actions.

Table 1 shows some examples of attack actions

listing the action name, the attack stage, the necessary

skill requirement of the attacker, the success

probability, and the damage caused by the successful

action.

Table 1: 7 Examples out of the 173 attack actions

Action Stage

Skill

eq.

Success

prob.

C/I/A

damage

Vulnerability Scan Recon. 2 0,6 0/0/0

Brute Force

ccess 1 0,4 0/0/1

Spearphishing

ccess 3 0,5 1/1/0

Manipulate Website Execution 2 0,3 0/3/2

Buffer Overflow Execution 3 0,5 1/2/3

Wipe Disk Execution 3 0,3 0/0/3

Man in the Middle Execution 2 0,4 1/1/1

Defense actions are subdivided into three

categories as well: Prevention, Detection, and

Response. Response actions are only effective when

an attack has already been detected and therefore are

available only in such a situation. Each action

requires a minimum skill level of the defender (1, 2,

3, 4 or 5) and has a success probability. Effects of a

successful defense action may be twofold:

a) the “healing” effect triggered by the successful

action in the dimensions Confidentiality,

Integrity, and Availability, thus undoing some

or all of the damage already inflicted on the

defender’s system, which means that the

damage number is decreased again. Such

healing can only happen as a result of a

successful response action.

b) a decrease of the success probability of certain

attacker actions (e.g., awareness training

reduces the success probability of the attacker

action “phishing”) and/or an increase in the

success probabilities of other defense actions.

Table 2 shows some examples of defense actions

including the action name, the action category, the

necessary skill requirement of the defender, the

success probability of the action, and the healing

effects with respect to Confidentiality, Integrity and

Availability triggered by the (response) action.

Table 2: 7 Examples out of the 115 defense actions.

ction

Action

type

Skill

eq.

Success

prob.

C/I/A

healing

2-Factor-

uthentication Prev. 2 0,5 0/0/0

Encrypt Transmission Prev. 2 0,7 0/0/0

Check Driver Integrity Prev. 2 0,5 0/0/0

nalyze Network Protocol Det. 3 0,5 0/0/0

nalyze File Access Det. 2 0,3 0/0/0

Terminate Connection Resp. 2 0,7 -1/-1/-1

Restore Configuration Resp. 2 0,6 0/-1/-1

As game theory is applicable to a wide variety of

quite different situations, one must specify the

characteristics of the game under consideration:

 It is a non-cooperative game (quite obvious).

 It is a two-player game between an attacker

and a defender.

 It is an asymmetric game. The two players

have different actions to choose from.

 It is a game of perfect recall. Each player

never forgets what s/he has done so far.

 Whether it is a zero-sum game or not depends

on the details of the utility function. However,

there is always a winner and a loser, there are

no ties: either the attacker achieves her/his goal

and wins, or the defender wins, if the attacker

gives up without reaching her/his goal (time-

out).

 It is a non-deterministic game: each player can

in most situations choose between a number of

possible actions non-deterministically,

restricted only by some predefined constraints.

 It is a stochastic game: the success of a player’s

action is defined by a probability distribution.

 It is a game with imperfect information: the

current state of the game and its history is

mostly unknown to the players. In the

beginning of the game, for example, the

defender does not even know that the game has

already started, and an attack is well under-

way; and the attacker has no knowledge of the

defender’s configuration. In addition, neither

player knows which actions are available to the

opponent. Moreover, the defender does not

know which actions the attacker has already

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

708

carried out successfully and the attacker does

not know what defensive actions are already in

place. It is only during the course of the game

that parts of this information may gradually

become unveiled. For example, the attacker

may gain insight into the defender’s

configuration by conducting successful

reconnaissance actions and the defender may

somewhen find out that he or she is under

attack.

 Whether the game is one with incomplete

information is a more complex question.

Usually, in game theory “incomplete

information” means that the players don't know

each other’s utility or pay-off function. In

principle this information is clear on both sides:

the defender knows that an attacker wants to

violate at least one of the C-I-A dimensions and

the attacker knows that the defender wants to

prevent just that. In other words: the pay-off

function is comprised of the numbers that

represent the damage in the respective three

dimensions. The defender wants these numbers

to stay at zero and the attacker wants to increase

at least one of these numbers to three. But there

is some hidden information in the pay-off

functions, too: the opponents do not know each

other’s skill level, the defender does not know

about the attackers initiative - that is the time

(and budget) limit of the attacker which

determines when they will give up and stop

attacking.

 We restrict the game to being turn-based: only

one player can make a move at a time.

Moreover, the moves are executed alternately.

This property makes the game an extensive

form game: the sequence of moves can be

structured in a tree-like manner.

3.2 Game Theoretic Model

The game consists of the following information:

 The players: attacker and defender.

 The actions available to the respective players.

 A success probability for each action.

 A pay-off function that assigns rewards or

deals/heals damage points to the players.

Given this information we can view attacker-

defender scenarios as stochastic 2-player games:

= (Π, A, sp, S, U)

Π = {att, def} the players: attacker and

defender

A = A

att

∪ A

def

a finite set of actions of the

players (different actions for

attacker and defender)

sp: A  [0,1] the (dynamic) success

probability of an action

S = S

att

∪ S

def

the finite set of strategies for

the attacker respectively the

defender

U: S

att

X S

def

 ℝ

the utility function for the

players that assign pay-offs

to strategy combinations

When going through the various types of games

introduced in the literature, we chose some aspects of

the so-called “Princess and Monster Game” (Isaacs,

1965) and adapted it to the cyber threat domain. In the

original Princess-and-Monster game, two players, the

Princess and the Monster, are in a completely dark

room with defined boundaries. They don’t see each

other and move around in the dark. Usually, the

moving speed of the monster is defined as 1 and the

moving speed of the princess is ω < 1. The Monster

wins when it catches the princess in time (before an

initially defined time limit), that is when both are at

the same spot (or close enough to each other) in the

room. The utility function is the time it takes the

Monster to catch the Princess. The Monster tries to

minimize the catching time, the Princess tries to

maximize it (to survive as long as possible). There are

many variations of the game depending on the size of

the room, its metric, and the possible moves of the

players in it.

In our cyber-threat version of the game the

Princess is the defender (together with the system to

defend). The Monster – the attacker – is not in the

room but can remotely control the Princess’s moves.

The room is a three-dimensional cube with a discrete

net of size 4x4x4. The position of the defender is

hence a point (x,y,z) with three integer coordinates,

each in the range of 0 to 3. The coordinates

correspond to the three damage categories

Confidentiality, Integrity, Availability (see Figure 1).

The defender starts at point (0,0,0) and the game ends

when s/he reaches the target border of the room. In

other words, the attacker is victorious when the target

category defined at the beginning of the game reaches

the value 3. The main effect of a successful control

action of the attacker is to move the defender closer

to the target border (to increase the respective value),

while the defender can move farther away from it

when s/he successfully executes an appropriate action

with a healing effect. The utility function is the time

as in the original game, thus making it a zero-sum

game. But it has a predefined limit: if it takes the

A Game Theoretic Analysis of Cyber Threats

709

attacker too long to move the defender to the border,

he gives up: the game is over and the defender wins.

Besides the increase or decrease of the

coordinates the respective moves may have additional

effects such as dynamically changing success

probabilities (some defensive actions can reduce the

success probability of certain attack actions). In some

cases, the success probability could even be reduced

to 0.

Figure 1: The princess is in position (2,1,2) implying that

she is already in great danger in dimensions Confidentiality

and Availability.

So far, we have made an additional restriction: we

assume the game to be turn-based. The players

execute their actions alternatingly one after the other.

This is necessary to precisely localize the effects of

actions in time, as these effects might have

consequences on actions executed thereafter.

3.3 Strategies

A prerequisite for game theoretic analysis is the

definition of strategies and strategy combinations. A

strategy is a sequence of actions chosen by a player;

a strategy combination is the combination of the

respective strategies of the two players. A pure

strategy defines a fixed course of actions that a player

will stick to. In many cases, especially in games with

imperfect and/or incomplete information, it is better

for a player not to use the same strategy all the time,

but to mix strategies according to some probability

distribution. A mixed strategy of a player p is a

probability distribution q

over the set of his/her pure

strategies:

: S

 [0,1] where P ∈ Π = {att, def}

All the probabilities of the strategies of one player

sum up to 1. In a game of perfect recall mixed

strategies are equivalent to behavioral strategies

which define a probability distribution over actions at

each decision point of a player. We will use

behavioral strategies as they are easier to understand

in the context of this game. Furthermore, we assume

that the number of strategies is finite. To guarantee

this we do not allow a player to repeat an action

within a strategy.

Nevertheless, the number of possible strategies is

huge, taking into account the number of 173 attack

actions and 115 defense actions. This huge number of

strategies makes a straightforward game theoretic

analysis leading to a Nash equilibrium in mixed

strategies (which according to Nash’s famous

theorem always exists in a finite game) practically

infeasible. To reduce the number of strategies the

following aspects could be used:

 The actions are assigned a skill requirement (1,

2, 3 or 4) necessary to play this action. Given a

predefined type of attacker and defender some

actions can be excluded for the scenario under

consideration.

 Strategies for an attacker must consist of three

consecutive stages: reconnaissance, initial

access, and execution. All actions are assigned

to one of these stages. Entering the next stage

requires the successful completion of the

previous stage.

 Defense actions, too, have a type: prevention,

detection, response. The use of certain actions

is restricted by the progress of the game so far.

One problem to solve is the combination of the

probability distribution over the actions at a certain

point in the game (as defined in the behavioral

strategy) and the success probabilities of these

actions. An action is chosen due to the probability

distribution; but to realize the effects of this action it

must be successful, too. If the action chosen is not

successful, it has no effects whatsoever: the pay-off

does not change, and other effects are not realized

either (the only exception is the attacker’s initiative

which decreases with unsuccessful attacker actions as

well). To accomplish this, we multiply the

probabilities governing the choice of actions with the

success probabilities of the respective actions and

then normalize the results for the interval [0,1] such

that the probabilities sum up to 1 (at least one action

must be chosen). This gives the adapted probability

distribution for a successful behavioral strategy.

Even with the simplifications mentioned above, a

game theoretic analysis is only possible for clearly

Confidentiality

Availability

(0,0,0)

(3,3,3)

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

710

Figure 2: Set of attack actions available in a simplified ransomware scenario. Actions highlighted in grey deal only minor

damage (+1), while yellow actions (Execution stage) have a high damage potential in the game (+2). Defense actions are

exemplified on the right.

defined scenarios. Such a scenario defines the

following characteristics of a game and thereby

reduces the number of possible actions and strategies

of the players:

 The skill level of the attacker

 The skill level of the defender

 The attacker’s goal: which part of the CIA triad

s/he wants to attack

 The configuration of the defender

3.4 Example Scenario

Let’s have a short look at one such scenario, a

ransomware attack on a conventional IT network

configuration: a hacker with skill level 2 wants to

infiltrate the defender’s system in order to encrypt

substantial data and make the system inoperable.

Hence, the goal of the attack is the availability of the

system. Within the game, this means that the attacker

wants to drive the defender towards the third border

of the game room – s/he wants to increase the third

dimension of the defender’s position to a value of 3.

In our setting, the defender has the same skill level of

2. Figure 2 shows the available actions independent

of skill level. The strategies available to the attacker

in our example are composed of a subset of these

attack actions and are structured in three stages:

Table 3 shows the possible attack actions in the

reconnaissance stage, named after the corresponding

MITRE ATT&CK technique: “Phishing”, “Gather

various victim Info”, “Search various info”,

“Vulnerability Scanning”. Table 4 shows the possible

attack actions in the initial access stage:

“Compromise Software Supply Chain” (i.e. provide a

malicious update) and “Remote Access Software”

(i.e. asking the user for a remote desktop connection);

others, like “Use removable media“, “Drive by

compromise” or “Exploitation for client execution”

require a higher skill level than 2. Table 5 shows the

possible attack actions in the execution stage: “Data

Encrypted for Impact” and “Disk Wipe”. Again, the

action “Firmware corruption” is not mentioned as it

requires a too high skill level.

For the defender side there are more options

available. In the prevention stage, out of more than 40

possible actions we can remove 16, since they require

a higher skill level than 2. Some of the remaining

actions would not prevent the ransomware attack, so

they could be removed from the scenario, too, leaving

13 actions in total. In the detection stage we have a

similar picture: out of 48 actions we can remove 15

because of a too high skill bar; and some more actions

could be removed in view of the details of the

configuration. In the response stage, there are 20

actions that fulfill the skill requirement.

Table 3: Reconnaissance actions in the example.

ction Stage

Skill

req.

Success

prob.

C/I/A

damage

Phishing Recon. 2 0,5 1/1/0

Gather victim id info Recon. 1 0,7 0/0/0

Gather victim network info Recon. 1 0,5 0/0/0

Gather victim org. info Recon. 1 0,7 0/0/0

Gather victim host info Recon. 1 0,7 0/0/0

Search open websites Recon. 1 0,7 0/0/0

Search victim websites Recon. 1 0,7 0/0/0

Search open technical DB Recon. 1 0,7 0/0/0

Search closed sources Recon. 1 0,5 0/0/0

Vulnerability scanning Recon. 2 0,6 0/0/0

Table 4: Initial access actions in the example.

ction Stage

Skill

req.

Success

prob.

C/I/A

damage

Compromise supply chain

ccess 2 0,5 1/1/1

Remote access software

ccess 2 0,1 0/1/0

A Game Theoretic Analysis of Cyber Threats

711

Table 5: Execution actions in the example.

Action Stage

Skill

req.

Success

prob.

C/I/A

damage

Data encryption for impact Exec. 2 0,5 0/1/2

Disk wipe Exec. 2 0,3 0/0/3

Only a path of attack actions, which results in a

damage value of 3 will render the attack successful.

However, the defender has the opportunity to mitigate

a current damage level by taking appropriate

defensive actions, which could lower the damage

level if successfully executed.

The analysis of the scenario should then yield

information on optimal strategies (for the defender).

Due to the success probabilities attached to the

actions there will not be a single best strategy, but

rather a set of probabilities denoting the success

probability of a specific attack and how this

probability would change due to specific defense

actions.

4 CHALLENGES AND FUTURE

WORK

The formalism for modeling attack-defense scenarios

as described in this paper makes threat analysis

possible in a strictly mathematical way. The main

innovation here is that concepts of mathematical

game theory are applied to tactical threat analysis for

real-world situations. To keep the analysis as close to

practice as possible we collected attack and defense

actions from accepted data sources and vocabularies.

As mentioned earlier the model so far contains 173

different attack actions and 115 defense actions that

can be used in modeling attack and defense strategies.

Subsuming all these aspects into one single model

would clearly lead to too large a model, and hence

render a reasonable mathematical treatment

impossible. To keep the model in a manageable size

we break down the model into scenarios along the

lines of kill-chains (Hutchins, Cloppert, & Amin,

2011).

The main challenges that remain are on one side

the definitions of more elaborate scenarios

considering detailed configurations of the system

under attack and on the other side a detailed game

theoretic analysis of these scenarios. Such analysis

must be of stochastic nature as one of the main

analysis goals is the investigation of the influence of

specific defense actions on the success probabilities

of various attack strategies. Due to the huge number

of possible actions in a realistic scenario a traditional

game theoretic analysis might be very difficult, if not

infeasible. The application of formal methods, such

as stochastic model checking, could potentially be

considered as a viable alternative.

Future work will consider additional parameters

in the game, especially budgets: if costs are attached

to defense actions, what is the relation between an

increase in the defender’s budget and the overall

success probability of an attack strategy? Another

option for future work would be giving up the turn-

based property of the game at least partially: attacker

and defender could execute more than one action in a

row before the other player makes a move, especially

in the beginning of the game. So far, the

consequences of this have not yet been analyzed.

The main goal of the project is strategy synthesis

for defenders: Given a configuration with real-world

circumstances such as a given system configuration,

budgets, skill levels and the like, what is the optimal

defense strategy for anticipated threats?

ACKNOWLEDGEMENT

This work is part of the project INODES funded by

the Austrian Science Fund (FWF), whose support is

gratefully acknowledged.

REFERENCES

Aslanyan, Z., Nielson, F., & Parker, D. (2016). Quantitative

Verification and Synthesis of Attack-Defence

Scenarios. IEEE 29th Computer Security Foundations

Symposium, CSF 2016, (S. 105-119).

doi:10.1109/CSF.2016.15

Attiah, A., Chatterjee, M., & Zou, C. (2018). A Game

Theoretic Approach to Model Cyber Attack and

Defense Strategies. IEEE International Conference on

Communications (ICC).

Bommannavar, P., Alpcan, T., & Bambos, N. (2011).

Security risk management via dynamic games with

learning. IEEE International Conference on

Communications (ICC). doi:10.1109/icc.2011.5963330

Buldas, A., Gadyatskaya, O., Lenin, A., Mauw, S., &

Trujillo-Rasua, R. (2020). Attribute Evaluation on

Attack Trees with Incomplete Information. Computers

and Security 88/101630.

Etesami, S. R., & Basar, T. (2019). Dynamic Games in

Cyber-Physical Security: An Overview. Dynamic

Games and Applications, S. 884–913.

doi:doi.org/10.1007/s13235-018-00291-y

Gadyatskaya, O., Hansen, R. R., Larsen, K. G., Legay, A.,

Olesen, M., & Poulsen, D. B. (2016). Modelling

Attack-defense Trees Using Timed Automata. In M.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

712

Fränzle, & N. Markey (Hrsg.), FORMATS 2016,

LNCS 9884. 9884, S. 35–50. Springer LNCS. doi:DOI:

10.1007/978-3-319-44878-7 3

Guelzim, T., & Obaidat, M. S. (2015). Formal methods of

attack modeling and detection. In Modeling and

Simulation of Computer Networks and Systems -

Methodologies and Applications (S. 841-860). Elsivier.

Hamilton, S., Miller, W., Ott, A., & Saydjari, O. (2002).

The role of game theory in information warfare. 4th

Information Survivability Workshop, (S. 1-4).

Han, Z., Niyato, D., Saad, W., & Başar, T. (2019). Game

Theory for Next Generation Wireless and

Communication Networks - Modeling, Analysis, and

Design. Cambridge University Press.

He, F., Zhuang, J., & Rao, N. (2012). Game Theoretic

Analysis of Attack and Defense in Cyber-Physical

Network Infrastructures. Proceedings of the Industrial

and Systems Engineering Research Conference.

doi:10.1.1.719.2652

Hutchins, E., Cloppert, M., & Amin, R. (2011).

Intelligence-driven computer network defense infor-

med by analysis of adversary campaigns and intrusion

kill chains. Lead. Issues Inf. Warf. Secur. Res. 1/80.

Isaacs, R. (1965). Differential Games. New York: John

Wiley and Sons.

Jie, Y., Choo, K.-K. R., Li, M., Chen, L., & Guo, C. (2019).

Tradeoff gain and loss optimization against man-in-the-

middle attacks based on game theoretic model. Future

Generation Computer Systems, Volume 101, S. 169-

179. doi:doi.org/10.1016/j.future.2019.05.078

Joint Task Force Transformation Initiative. (2015). SP 800-

53 rev. 4. Recommended Security Controls for Federal

Information Systems and Organizations. Gaithersburg.

Keyser, T. (2018). Security policy. In The Information

Governance Toolkit (S. 57-62). CRC Press.

Kordy, B., Mauw, S., Melissen, M., & Schweitzer, P.

(2010). Attack–Defense Trees and Two-Player Binary

Zero-Sum Extensive Form Games Are Equivalent. In

T. Alpcan, L. Buttyán, & J. Baras (Hrsg.), Decision and

Game Theory for Security. GameSec 2010. . Lecture

Notes in Computer Science, vol 6442. Springer.

doi:10.1007/978-3-642-17197-0_17

Li, T., Peng, G., Zhu, Q., & Basar, T. (2021). The

Confluence of Networks, Games and Learning - A

game-theoretic framework for multi-agent decision

making over networks. IEEE control system magazine,

special issue on Distributed Nash Equilibrium Seeking

over Networks.

Luh, R., Eresheim S., Großbacher S., Petelin T., Mayr F.,

Tavolato P., & Schrittwieser S. (2022). PenQuest

Reloaded: A Digital Cyber Defense Game for

Technical Education. EDUCON2022 – IEEE Global

Engineering Education Conference, 2022.

doi:10.1109/EDUCON52537.2022.9766700

Luo, Y., Szidarovszky, F., Al-Nashif, Y., & Hariri, S.

(2010). Game Theory Based Network Security. Journal

of Information Security 1/1, S. 41-44. doi:10.4236/

jis.2010.11005

MITRE Corporation. (A). CAPEC—Common Attack

Pattern Enumeration and Classification.

https://capec.mitre.org/

MITRE Corporation. (B). MITRE ATT&CK.

https://attack.mitre.org/

MITRE Corporation. (C). MITRE D3FEND.

https://d3fend.mitre.org/resources/D3FEND.pdf

MITRE Corporation. (D). STIX—Structured Threat

Information Expression | STIX Project Documentation.

https://oasis-open.github.io/cti-documentation/

Nguyen, K. C., Alpcan, T., & Başar, T. (2009). Stochastic

games for security in networks with interdependent

nodes. Proceedings of the 2009 International

Conference on Game Theory for Networks, GameNets

’09.

Pekergin, N., Tan, S., & Fourneau, J.-M. (2016).

Quantitative Attack Tree Analysis: Stochastic Bounds

and Numerical Analysis. International Workshop on

Graphical Models for Security, GraMSec 2016.

doi:DOI:10.1007/978-3-319-46263-9_8

Sajjan, S., Sankardas, R., & Dipankar, D. (2010). Game

theory for cyber security. CSIIRW '10: Proceedings of

the Sixth Annual Workshop on Cyber Security and

Information Intelligence Research.

doi:doi.org/10.1145/1852666.1852704

Sallhammar, K., Helvik, B. E., & Knapskog, S. J. (2006).

On stochastic modeling for integrated security and

dependability evaluation. Journal of Networks 1/5, S.

31-42. doi:10.4304/jnw.1.5.31-42

Shapley, L. S. (1953). Stochastic games. PNAS 39/10, S.

1095-1100.

Shostack, A. (2014). Threat Modeling: Designing for

Security. Wiley.

Swiderski, F., & Snyder, W. (2004). Threat Modeling.

Microsoft Press.

Tabatabaei, M. (2016). Games and Strategies in Analysis of

Security Properties. Dissertation. Université du

Luxembourg.

Tarandach, I., & Coles, M. J. (2020). Threat Modeling: A

Practical Guide for Development Teams. O'Reilly.

Wideł, W., Audinot, M., Fila, B., & Pinchinat, S. (2019).

Beyond 2014: Formal Methods for Attack tree-based

Security Modeling. ACM Computing Surveys. 52/4,

Article 75. doi:https://doi.org/10.1145/3331524

Zhang, J., Wang, Y., & Zhuang, J. (2021). Modeling multi-

target defender-attacker games with quantal response

attack strategies. Reliability Engineering & System

Safety, Volume 205.

A Game Theoretic Analysis of Cyber Threats

713
