Secure Joint Querying Over Federated Graph Databases Utilising SMPC

Protocols

Nouf Al-Juaid

1,2

, Alexei Lisitsa

and Sven Schewe

Department of Information Technology, College of Computers and Information Technology, Taif University, Saudi Arabia

Department of Computer Science, University of Liverpool, Liverpool, U.K.

{n.aljuaid, lisitsa, sven.schewe}@liverpool.ac.uk

Keywords:

Graph Databases, Secure Multi-Party Computation, Federated Databases, Secure Data Processing.

Abstract:

We present a methodology for secure joint querying over federated graph databases based on secure multiparty

computation (SMPC). Using SMPC instead of (or in addition to) encryption lifts reliance on the security of

the encryption mechanism. The secret keeping is, instead, guaranteed by an SMPC protocol that protects the

information required to answer a given query so that it is not shared in full on any communication line. We have

recently outlined how this could be done in principle in a position paper, albeit with a sluggish implementation

with an enormous computational overhead that rendered it unusable in practice. In this paper, we proposed

an approach by better integrating it with the SMPC protocol, implementing it in JIFF, and covering the joint

functionalities and languages of Conclave, Neo4j Fabric, and APOC. When implementing our prototype, we

demonstrate how small queries can be served in fractions of a second, thus improving the performance of

secure joint querying by two orders of magnitude compared to the implementation in previous work while

also signiﬁcantly extending its set of supported queries.

1 INTRODUCTION

Secure multiparty computation (SMPC) is an active

research area that has recently gained popularity in

securing the privacy of data. According to (Cramer

et al., 2015), SMPC is a cryptographic technique that

divides computing among several parties in order to

ensure that no one party may see or infer the pri-

vate information of other participants. This is differ-

ent from traditional cryptography techniques in that

it focuses on developing protocols for coordinating

the processing of distributed data without joining the

data, rather than data or databases. The main bene-

ﬁts of SMPC are that no third parties (no matter how

trusted) see the data, the trade-off between data us-

ability and data privacy is eliminated, and process-

ing can be conducted with high accuracy. Today,

SMPC is used for many real-life applications, such as

detecting ﬁnancial fraud, the aggregating model fea-

tures across private datasets, and predicting heart dis-

ease (inpher.io, ). Furthermore, it can help to solve

such trust issues in contexts such as secure elections

(Alwen et al., 2015), auctions (Aly and Van Vyve,

2016), and secret sharing (Evans et al., 2018). Thus

far, in the context of databases, SMPC has mainly

been used to secure relational databases such as Con-

clave (Volgushev et al., 2019). This raises the ques-

tion of whether SMPC queries are restricted to rela-

tional databases or can transcend the database type.

Against that background, in this paper, we explore

the opportunity to apply SMPC to graph databases, a

type of NoSQL database. Graph databases were cre-

ated to address the limitations of relational databases

(Salehnia, 2017), and they have found multiple appli-

cations in which the graph paradigm has been bene-

ﬁcial, such as on social media platforms (e.g. Insta-

gram, Twitter, and Facebook) (Ciucanu and Lafour-

cade, 2020). In (Al-Juaid et al., 2022), we have pro-

posed a design for secure multiparty graph databases.

In this paper, we propose a fully automatic system to

handle additional queries by using the Neo4j Fabric

functionality extended with the Awesome Procedures

on Cypher (APOC) library. Furthermore, we mea-

sure the execution times in experiments to validate our

SMPQ system, and we review its overheads compared

to Neo4j and Conclave.

The remainder of this paper is organised as fol-

lows: the following section 2 presents the background

to this work, followed by the proposed approach in

Section 3. Then, Section 4 is devoted to system im-

210

Al-Juaid, N., Lisitsa, A. and Schewe, S.

Secure Joint Querying Over Federated Graph Databases Utilising SMPC Protocols.

DOI: 10.5220/0011798900003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 210-217

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

plementation. Following this, Section 5 evaluates the

performance of the system based on the results of our

experiments. Next, the related literature is reviewed

to understand how a query can be secured with dif-

ferent types of data models in section 6. Finally, the

paper concludes in Section 7, and we offer directions

for future work.

2 BACKGROUND

2.1 Secure Multi-Party Computation

(SMPC)

SMPC allows a set of parties to jointly compute a

mutually agreed function on their data while keeping

their inputs private. Assume:

P : P

, P

........., P

X : X

, X

........., X

Y = F(X

, X

......., X

)

Where is P is a set of parties, each of them has a se-

cret data X, and they want to compute some function

F of their joint inputs. However, they do not trust each

other and want to keep their input private. If the par-

ties could agree on some trusted third party, Z, they

would have to hand their data to Z, who would com-

pute the function on their behalf and send them their

prescribed part of the result Y. An SMPC protocol of-

fers to compute F secretly with guarantees that the re-

sult will be the same as Z would get. Figure.1. shows

an example of SMPC between 5 parties.

Figure 1: Multi-party computation between 5 parties.

Assuming that we have 5 parties, want to compute

F using their private individual data without exposing

it. SMPC helps to accomplish that with a guarantee

of this.

2.2 Implementation of SMPC

SMPC was mainly the focus of theoretical study un-

til recently, but there has been a signiﬁcant effort

lately to bring SMPC to applications in the real world

(Evans et al., 2018). One of those implementations is

JIFF(Albab et al., 2019).

JIFF is a JavaScript library that implements

SMPC. It can carry out safe computing by utilis-

ing data that has been dispersed across several parts.

JIFF uses a server to store and forward any encrypted

messages sent between the various participants. It

assumes the honest-but-curious security model and

uses Shamir’s secret sharing as the threshold (Shamir,

1979).

Each party runs as a client when JIFF is run as a

server. SMPC operates by splitting each party’s pri-

vate information into smaller pieces—or shares— and

then distributing those shares amongst several parties.

Each share is useless alone, but when they are all

combined, then the original secret is reconstructed.

Once the computation ﬁnishes, the results are dis-

played for all parties without revealing their data used

in the computation. The architecture of JIFF is illus-

trated in Figure.2.

Figure 2: JIFF architecture and components.

As shown in Figure.2, when three parties, A, B,

and C, want to compute something using their private

data without exposing those to others after they con-

nect to JIFF, the library will generate a JIFF client for

each party to connect to the JIFF server. The input

data from the parties are split into shares, distributed

in encrypted form using the three parties’ public keys

(generated by the JIFF when all parties are connected)

so that each party (client) holds one share for each of

the other parties, as well as one of their own.

3 SYSTEM DESIGN

3.1 Overview

The architecture of our system is illustrated in

Figure.3, in which multiple data owners, named

Secure Joint Querying Over Federated Graph Databases Utilising SMPC Protocols

211

Figure 3: SMPQ workﬂow.

, p

, . . . , p

, own different graph databases but want

to execute a single query jointly. To do so, ﬁrstly, all

parties should agree on a joint query and then sub-

mit it to the system. After they submit the query,

the system will automatically generate a conﬁgura-

tion ﬁle for each party, containing the party’s sub-

query and the information on their Neo4j database.

Then, the Conclave system (Volgushev et al., 2019)

runs these conﬁguration ﬁles using the protocol, and

by doing so, executes the query for each party. At

this stage, the system passes the results of the query

to the JIFF server to apply SMPC protocols. Within

the JIFF server, SMPC splits each party’s private in-

formation into smaller pieces—or shares—and then

distributes those shares amongst several parties, as

shown in Figure.2. In our current system, we use Con-

clave(Volgushev et al., 2019) for the backend, which

in turn, uses JIFF (Albab et al., 2019) for SMPC

queries. After the JIFF server ﬁnds the ﬁnal result of

the query, the system sends it out to the data owners

who ﬁrst initiated the joint query.

3.2 DB Query Language

Although any graph-based database can use our tech-

nique, we chose the Neo4j environment as our start-

ing point. Neo4j is a popular graph database (L

opez

and De La Cruz, 2015), with a graph data model,

which is presented as a collection of nodes represent-

ing data and arrows indicating the connections be-

tween them (Miller, 2013). Neo4j uses Cypher query

language to deal with the data in such a graph(Francis

et al., 2018). In our SMPQ system, the Cypher

query language is then extended with the Neo4j Fab-

ric functionality (Gu et al., 2022) and the APOC

library (Needham and Hodler, 2019). The opera-

tional principle of Neo4j Fabric offers a way to issue

Cypher queries that target more than one Neo4j graph

database at once, which it implemented in federated

databases. The APOC library, meanwhile, contains

more than 450 procedures and functions to help with

common tasks such as data integration, cleaning, and

conversion, alongside general help functions. APOC

is the standard library for Neo4j.

Our system’s current functionality supports run-

ning multiple cypher queries, each in a separate

database, extending with the Neo4j Fabric function-

ality, then applying an aggregation procedure from

the APOC library. Furthermore, we tried slightly ex-

tending some of the APOC library’s functionality. For

example, the intersection procedure of APOC is sup-

ported to deal with two input sets, while in our sys-

tem, we use the same syntax to express the intersec-

tion of three or more input sets.

4 SYSTEM IMPLEMENTATION

The SMPQ model was implemented using a Python

API. It was built on top of the Conclave system (Vol-

gushev et al., 2019); which uses SMPC with a rela-

tional database. Our model uses it as an interface

between the data source and the implementation of

SMPC protocols such as JIFF. This prototype used

multiple graph databases from multiple data owners

and applied one of the SMPC protocols (Evans et al.,

2018) to provide a joint query. In practice, three

data owners can perform a query jointly and can be

adapted to be two or more data owners. Initially,

three different Neo4j databases were built. In (Al-

Juaid et al., 2022), we have proposed a system that

was running manually from the start to generate the

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

212

conﬁguration ﬁles and pass them to Conclave (Volgu-

shev et al., 2019) and run it. Currently, the function-

ality of our system is limited to the functionality that

the Conclave system supports. To extend our work,

we intend to increase the functionality to support all

cypher queries that can be covered by the JIFF server

extended with fabric architecture and apply the APOC

procedures.

4.1 System Interface

The implementation of the proposed method interface

can be observed in Figure. 4. As shown, after deter-

mining how many parties are involved in performing

the query using SMPC protocol, they should agree on

a computation ID which can be considered an agree-

ment to apply the query using their database. When

the Query button is pushed, behind the scene, the sys-

tem will generate the conﬁguration ﬁle for each party,

pass it to the Conclave system to run using the JIFF

server, and return the result as shown in Figure.4.

Figure 4: SMPQ system interface.

5 PERFORMANCE EVALUATION

5.1 Data Sets

To validate our proposed SMPQ system and investi-

gate its efﬁciency, we ran several queries with three

data sets, each from three parties that used different

Neo4j databases. In the following, we describe each

data set:

5.1.1 Professor and Students Data-Set

In this data-set, for all the databases, there were 58

nodes in total with 29 relationships between nodes.

All three databases had the same nodes, Professor and

Student, with the same two properties— name and

ID —as well as an additional property for the Stu-

dent—score.

5.1.2 Movie Data-Set

In the second data-set, we used the movie data-set af-

ter updating the nodes to add extra ones and remove

others, to establish different sizes of parties. In total,

there were 563 nodes, with 785 relationships between

nodes. All three databases had the same nodes, Ac-

tors and Movie. The properties for node Actors were:

name and born, while for node Movie, they were:

tagline, title, and released.

Due to the Conclave system’s limitations, which

limit it to just numerical data, we employ a third data

set that only contains numerical data to compare our

system with the Conclave.

5.1.3 Car-Location Data-Set

In this data set, for all the databases, there were 100

nodes in total, with 63 relationships between nodes.

All three databases had the same nodes Car and Lo-

cation. The property for both node Car and Location:

is the car id, location id, respectively. Table 1 shows

further information about each data set, including the

number of nodes and relationships for each database

from different data owners.

Table 1: Information about all the three data-sets used to

establish the experiments.

Data sets Database No of Nodes No of Relationships

Profrssor-student

Data-set

DB1 32 16

DB2 10 5

DB3 16 8

Movie Data-set

DB1 203 269

DB2 172 254

DB3 188 262

Car -location

Data- set

DB1 44 31

DB2 24 15

DB3 32 17

5.2 Queries

We executed the following list of queries using the

previous data sets.

• Q1: Count how many students there are in com-

mon between all DBs.

• Q2: Count how many students there are in com-

mon between all of the DBs that score 7.

• Q3: Find the names of the students there are in

common between all the DBs with scores of 9 or

above.

• Q4: Find the students’ names in common be-

tween all the DBs that score 7.

Secure Joint Querying Over Federated Graph Databases Utilising SMPC Protocols

213

• Q5: Count how many movies with the actor Tom

Hanks there are in common between all DBs.

• Q6: Find the names of the movies in common

with the actor Tom Hanks.

• Q7: Finds names of all actors born in 1974.

• Q8: Finds the sum of all nodes in the movie DB

for all parties.

• Q9: Count how many cars are in each location.

• Q10: Count how many cars with ID = 1 in all the

DBs.

• Q11: Union two databases using the node name

of the Professors whose students have a grade ≥

9.0 in either database.

• Q12: Project two databases using the scores for

all students in both databases in the Math course.

5.3 Results

This subsection of the paper presents the results ob-

tained when executing the above queries. We mea-

sured the execution times (i.e. the times taken for all

parties to get the results of the query) using the time

function supported by Python. Table 2 and Figure.5

highlight the execution times taken for all parties to

get the results of Q1–Q8 using the previously men-

tioned datasets, with a comparison of the overheads

of our system versus using Neo4j Fabric to run the

same queries without SMPC protocols. As shown in

the Table, the overheads are higher for our system; al-

ternatively, using Neo4j Fabric to execute the query

is clearly a better option, though our system offers

greater security for the user since the data are en-

crypted using SMPC protocols. In the future, we in-

tend to decrease the overheads of SMPQ by removing

Conclave and instead directly connecting to the JIFF

server to apply SMPC protocols.

Table 2: Execution times for Q1– Q8 when using SMPQ

and Neo4j Fabric.

SMPQ system Neo4j Fabric

Query

party 1

(DB1)

party 2

(DB2)

party 3

(DB3)

Avg

Time (s)

Q1 1.52 1.49 1.49 1.5 0.136

Q2 1.95 1.93 1.94 1.94 0.147

Q3 2.02 2.02 2.01 2.01 0.161

Q4 1.84 1.85 1.85 1.84 0.132

Q5 1.78 1.79 1.74 1.77 0.182

Q6 3.05 2.96 3.08 3.03 0.012

Q7 2.74 2.76 2.77 2.75 0.154

Q8 0.87 0.86 0.83 0.85 0.278

When seeking to compare our system with the

Conclave system, due to the limitation explained in

(Al-Juaid et al., 2022) where Conclave supports only

numerical data, we could not execute Q1–Q8. For

Figure 5: Execution times for Q1– Q8 when using SMPQ

and Neo4j Fabric.

this reason, we used the third data set, which con-

tained only numerical data, to run Q9–Q12. When

running these queries using the Conclave system, the

execution time took almost 10 minutes for a database

with 100 nodes. We optimised the execution time for

a query by removing the sorting function after ﬁnd-

ing the result for a query, which helped to reduce that

time, bringing it down to 16 seconds. As further en-

hancements, we removed the waiting time until all

parties were connected, and ran the queries for all par-

ties simultaneously, which reduced the execution time

to almost nearly 3 seconds. Table 3, and Table 4, and

Figure.6 show the execution times for Q9–Q12 when

using SMPQ and Conclave.

Table 3: Execution times for Q9– Q12 when using SMPQ.

Execution time using SMPQ

Query

Party 1

(DB1)

Party2

(DB2)

Party3

(DB3)

Avg

Time(s)

Q9 2.06 2.05 2.03 2.04

Q10 2.76 2.70 2.65 2.70

Q11 2.18 2.20 2.24 2.20

Q12 3.80 3.66 3.94 3.8

Table 4: Execution times for Q9– Q12 when using Con-

clave.

Execution time using Conclave

Query

Party 1

(DB1)

Party2

(DB2)

Party3

(DB3)

Avg

Time(s)

Q9 405.9 402.38 398.7 402.3

Q10 384.6 382.4 380.1 382.3

Q11 89.48 86.91 84.27 86.88

Q12 7.14 73.85 71.21 74.1

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

214

Table 5: SMPC for data processing.

Framework

Parties

supported

SMPC

Framework

backend

Trust

Party

No.Data

owners

Data Model

Query

language/API

Available

implementation

Development

language

Conclave (Volgushev et al., 2019) >= 2 Secret Sharing JIFF Yes >= 2 Relational DB SQL/LINQ Yes Python

Congregation >= 2 Secret Sharing JIFF No >= 2 Relational DB SQL Yes Python

SMCQL (Bater et al., 2016) 2 Garbled Circuits/ ORAM ObliVM No 2 Relational DB SQL Yes Java

Senate (Poddar et al., 2020) 2 Garbled Circuits N/A No 2 Relational DB SQL No -

SAQE (Bater et al., 2020) 2 Garbled Circuits ObliVM No 2 Relational DB SQL No -

Shrinkwarp (Bater et al., 2018) 2 Garbled Circuits/ ORAM ObliVM No 2 Relational DB SQL No -

Secrecy (Liagouris et al., 2021) 3 Repl.Secret Sharing - No 3 Relational DB SQL No C

SDB (Wong et al., 2014; He et al., 2015)

N/A Secret Sharing N/A No 1 Relational DB SQL No -

GOOSE (Ciucanu and Lafourcade, 2020)

N/A Secret Sharing N/A No 1 GraphDB SPARQL Yes Python

SMPQ >= 2 Secret Sharing JIFF No >= 2 GraphDB Cypher No Python

*Both

and

use SMPC as backend over a database; they do not support multi-party user queries.

Figure 6: Execution times for Q9– Q12 when using SMPQ

and Conclave.

6 RELATED WORK

6.1 SMPC for Data Processing

There are initiatives to utilize SMPC with databases

to secure data. As an illustration, Conclave, a query

compiler used with a relational database, is suggested

by (Volgushev et al., 2019). It operates by convert-

ing the query into a series of short SMPC steps, lo-

cal cleartext processing in data-parallel, and local pro-

cessing. In this system, the queries are rewritten to re-

duce time-consuming SMPC processing and increase

scalability. They suggested sending the revised query

to JIFF, which serves as a backend SMPC system (Al-

bab et al., 2019).

Additionally,(Poddar et al., 2020) presents the

Senate system, which enables many participants to

conduct joint analytical SQL queries without dis-

closing their personal information to one another.

Their solution has the added beneﬁt of offering pro-

tection against malevolent actors above earlier ef-

forts, whereas those earlier systems employed a semi-

honest architecture. Additionally, a relational SMPC

system based on replicated secret sharing called Se-

crecy is presented by (Liagouris et al., 2021). The

main idea behind this method is to divide the data into

three parts, s1, s2, and s3, with each participant tak-

ing two of the shares and executing a portion of the

query-running code.

SMCQL is a system suggested by the authors of

(Bater et al., 2016) that converts SQL queries into

secure multi-party computing. The user sends their

query to a trustworthy broker who is thought to be

honest. The query is translated to a secure cluster by

an honest broker, who then returns the result to the

user. A later study of the SMCQL system (Bater et al.,

2020) adopts SMCQL and builds the SAQE system to

secure the SQL query on top of it. In this system,

the query is processed in two stages: the planning

stage and the execution stage. The query plan and

optimization are handled on the client side, and us-

ing SMPC on the server side, the query is executed

among the data owners. They jointly run database

queries and provide the client with the results. Sim-

ilarly, Bater et al. construct on top of SMCQL sys-

tem named Shrinkwrap (Bater et al., 2018). They

conduct their studies using two data owners and per-

form two-party secure computations. SMCQL’s per-

formance has been increased, albeit at the cost of re-

vealing some information in the process.

On the other hand, the authors in (He et al., 2015;

Wong et al., 2014) and (Ciucanu and Lafourcade,

2020), suggested systems to illustrate how single-

party querying can be implemented using SMPC. The

SDB system in (He et al., 2015; Wong et al., 2014) is a

cloud database system on relational tables. It has two

parties: the server provider (SP) and the data owner

(DO). Each item of sensitive data is divided into two

shares: one held at the DO, known as the item key,

and another at the SP, known as the ciphertext. In this

system, the DO and SP share secrets using SMPC.

When the SDB proxy in the DO part receives a SQL

query from the user, it rewrites any queries with sen-

sitive columns to their respective UDFs at SP. The

rewritten queries are then sent to the SP, and the en-

crypted result is sent back to the SDB proxy for de-

cryption before being sent to the user.

Likewise, the GOOSE framework in (Ciucanu and

Lafourcade, 2020) is a solution that uses SMPC secret

sharing to protect data outsourcing in the RDF graph

Secure Joint Querying Over Federated Graph Databases Utilising SMPC Protocols

215

database. Here, the data owner uploads the graph data

to the cloud in a certain format: it is divided into three

pieces and sent to separate locations in the cloud in

encrypted form. All of these components are regarded

as multi-party, and none of them can independently

know the entire graph, a query, or its result. Addi-

tionally, the AES algorithm is used to encrypt every

message sent between them.

Although SMPC has been used in relational

databases and graph databases in the past, multi-party

queries over graph databases are new. We, there-

fore, suggested a system called SMPQ. It helps to

secure multi-party computation on graph databases.

In order to conduct queries over graph databases,

the SMPQ uses SMPC protocols. To show how well

an SMPC query performed on a graph database, we

implemented a prototype top on the Conclave system.

Table 5 compares our proposed system, SMPQ, to all

of the earlier systems.

7 CONCLUSION AND FUTURE

WORK

In this paper, we have proposed a system for se-

cure joint querying over federated graph databases

based on secure multiparty computation (SMPC) pro-

tocols called SMPQ. We implemented our system us-

ing Conclave and enhanced a query’s execution time

until it was as close as possible to that of Neo4j Fab-

ric. Furthermore, we expanded our system to be fully

automatic and handle more queries than it did pre-

viously by using the Neo4j Fabric functionality ex-

tended with the APOC library. The current system

remains to be tested on some Cypher query language,

which was beyond the scope of this paper, such as

a correlated query, and we have yet to add support

for dealing with different databases separately. In fu-

ture work, we will extend this system to handle traver-

sal queries between all databases using SMPC proto-

cols. Furthermore, we intend to reduce the overheads

of SMPQ by removing Conclave and instead directly

connecting to the JIFF server to apply SMPC proto-

cols.

REFERENCES

Al-Juaid, N., Lisitsa, A., and Schewe, S. (2022). SMPG:

Secure multi party computation on graph databases.

In ICISSP, pages 463–471.

Albab, K. D., Issa, R., Lapets, A., Flockhart, P., Qin, L.,

and Globus-Harris, I. (2019). Tutorial: Deploying se-

cure multi-party computation on the web using JIFF.

In 2019 IEEE Cybersecurity Development (SecDev),

pages 3–3. IEEE.

Alwen, J., Ostrovsky, R., Zhou, H., and Zikas, V. (2015).

Incoercible multi-party computation and universally

composable receipt-free voting. In Advances in

Cryptology–CRYPTO 2015: 35th Annual Cryptology

Conference,, volume 9216, pages 763–780. Springer

Berlin Heidelberg.

Aly, A. and Van Vyve, M. (2016). Practically efﬁcient

secure single-commodity multi-market auctions. In

International Conference on Financial Cryptography

and Data Security, pages 110–129. Springer.

Bater, J., Elliott, G., Eggen, C., Goel, S., Kho, A., and

Rogers, J. (2016). SMCQL: secure querying for fed-

erated databases. arXiv preprint arXiv:1606.06808.

Bater, J., He, X., Ehrich, W., Machanavajjhala, A., and

Rogers, J. (2018). Shrinkwrap: efﬁcient sql query pro-

cessing in differentially private data federations. Pro-

ceedings of the VLDB Endowment, 12(3):307–320.

Bater, J., Park, Y., He, X., Wang, X., and Rogers, J.

(2020). SAQE: practical privacy-preserving approx-

imate query processing for data federations. Proceed-

ings of the VLDB Endowment, 13(12):2691–2705.

Ciucanu, R. and Lafourcade, P. (2020). GOOSE: A se-

cure framework for graph outsourcing and sparql eval-

uation. In 34th Annual IFIP WG 11.3 Conference

on Data and Applications Security and Privacy (DB-

Sec’20). Accept

a para

ıtre.

Cramer, R., Damg

ard, I. B., and Nielsen, J. B. (2015). Se-

cure multiparty computation. Cambridge University

Press.

Evans, D., Kolesnikov, V., and Rosulek, M. (2018). A prag-

matic introduction to secure multi-party computation.

Found. Trends Priv. Secur., 2:70–246.

Francis, N., Green, A., Guagliardo, P., Libkin, L., Lin-

daaker, T., Marsault, V., Plantikow, S., Rydberg, M.,

Selmer, P., and Taylor, A. (2018). Cypher: An evolv-

ing query language for property graphs. In Proceed-

ings of the 2018 International Conference on Manage-

ment of Data, pages 1433–1445.

Gu, Z., Corcoglioniti, F., Lanti, D., Mosca, A., Xiao, G.,

Xiong, J., and Calvanese, D. (2022). A systematic

overview of data federation systems.

He, Z., Wong, W. K., Kao, B., Cheung, D., Li, R., Yiu, S.,

and Lo, E. (2015). SDB: A secure query processing

system with data interoperability. Proc. VLDB En-

dow., 8:1876–1879.

inpher.io. What is secret computing? https://inpher.io/

technology/what-is-secure-multiparty-computation.

Accessed: 2022-06-23.

Liagouris, J., Kalavri, V., Faisal, M., and Varia, M. (2021).

Secrecy: Secure collaborative analytics on secret-

shared data. arXiv preprint arXiv:2102.01048.

opez, F. M. S. and De La Cruz, E. G. S. (2015). Liter-

ature review about Neo4j graph database as a feasi-

ble alternative for replacing rdbms. Industrial Data,

18(2):135–139.

Miller, J. J. (2013). Graph database applications and con-

cepts with Neo4j. In Proceedings of the Southern

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

216

Association for Information Systems Conference, At-

lanta, GA, USA, volume 2324.

Needham, M. and Hodler, A. E. (2019). Graph algorithms:

practical examples in Apache Spark and Neo4j. Se-

mantic Web.

Poddar, R., Kalra, S., Yanai, A., Deng, R., Popa, R. A.,

and Hellerstein, J. M. (2020). Senate: A maliciously-

secure mpc platform for collaborative analytics. arXiv

e-prints, pages arXiv–2010.

Salehnia, A. (2017). Comparisons of relational databases

with big data : a teaching approach. pages 1–8. South

Dakota State University, Brookings.

Shamir, A. (1979). How to share a secret. Communications

of the ACM, 22(11):612–613.

Volgushev, N., Schwarzkopf, M., Getchell, B., Varia, M.,

Lapets, A., and Bestavros, A. (2019). Conclave: se-

cure multi-party computation on big data. In Pro-

ceedings of the Fourteenth EuroSys Conference 2019,

pages 1–18.

Wong, W. K., Kao, B., Cheung, D. W. L., Li, R., and

Yiu, S. M. (2014). Secure query processing with

data interoperability in a cloud database environment.

In Proceedings of the 2014 ACM SIGMOD inter-

national conference on Management of data, pages

1395–1406.

Secure Joint Querying Over Federated Graph Databases Utilising SMPC Protocols

217
