An OWL Multi-Dimensional Information Security Ontology

Ines Meriah

1 a

, Latifa Ben Arfa Rabai

1 b

and Ridha khedri

2 c

Universit

e de Tunis, Institut Sup

erieur de Gestion de Tunis, SMART Laboratory, Tunis, Tunisia

Department of Computing and Software, McMaster University, Hamilton, Ontario, Canada

Keywords:

Information Security, Security Dimension, OWL Security Ontology, Multi-Dimensional Security Ontology,

Dimensional View.

Abstract:

To deal with problems related to Information Security (IS) and to support requirements activities and archi-

tectural design, a full conceptualisation of the IS domain is essential. Several works proposed IS ontologies

capturing partial views of the IS domain. These ontologies suffer from incompleteness of concepts, lack of

readability, portability, and dependability to a speciﬁc IS sub-domain. Following a rigorous and repeatable

process, we systematically developed a comprehensive IS ontology. This process includes four steps: con-

cept extraction, XML generation, OWL generation and dimensional view extraction. The obtained ontology

is multidimensional, portable and supports ontology modularization. It is presented under XML format and

OWL format. It comprises 2660 security concepts and 331 security dimensions.

1 INTRODUCTION AND

MOTIVATION

The need for an ontology that outlines the domain

knowledge related to information security is essen-

tial for several stages of software development. It can

be used to support the requirements stage to improve

traceability of non-functional requirements and elic-

itation and documentation of requirements. At the

architecture design stage, it helps the designer put

the necessary mechanisms to support non-function re-

quirements. Particularly, when the non-function re-

quirements that we are considering are those related

to security, any supporting tool is extremely valuable.

In this paper, we are concerned with the elicitation of

an information security ontology that is modular and

that support securing information systems in general.

The system’ security aspect has a major effect in

modern distributed software systems. For require-

ments management activities it is essential to an-

swer questions about the dependencies among non-

function requirements and particularly about secu-

rity requirements. One also would wonder whether

it is necessary to revise security in connection with

changes in the functional requirements and wonder

https://orcid.org/0000-0002-8713-0216

https://orcid.org/0000-0002-5657-4682

https://orcid.org/0000-0003-2499-1040

about which project artefacts are affected by the

change (Murtazina and Avdeenko, 2019). It is a trace-

ability issue and ontologies could be of great help for

requirements analysts in tackling this issue. More-

over, in IS domain, ontology presents security con-

cepts and provides details about their relationships.

An IS ontology is considered as a required container

for the security of systems and their applications. Ac-

cording to (Sanagavarapu et al., 2021), an IS ontol-

ogy facilitate threat intelligence, reasoning of attacks

and anomaly detection. The ontological representa-

tion of IS domain helps in contextual readiness and

awareness to defend a malicious attack and protect

IT assets. Another perspective on the need for a se-

curity ontology at the requirements level is related

to having a precise terminology to articulate secu-

rity requirements. In a business environment, security

and software stakeholders use existing IS ontologies

to determine security risks and articulated the appro-

priate requirements for the countermeasures (Meriah

et al., 2021). The security terminology should be efﬁ-

ciently organized in an IS ontology. Security concepts

are extremely large in number, dynamic and evolv-

ing over the time. However, it is necessary to obtain

comprehensible IS ontology to help resolve security

problems and write the correct security requirements.

Although there are several existing security machine

learning models to identify security requirements and

issues, most security stakeholders suffer from the lack

372

Meriah, I., Rabai, L. and khedri, R.

An OWL Multi-Dimensional Information Security Ontology.

DOI: 10.5220/0011841300003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 372-380

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

of readable view of IS domain (Meriah et al., 2021).

This problem arises from the complexity of the ﬁeld

on the one hand, and the lack of effective commu-

nication and collaboration between stakeholders on

the other hand. What aggravates further the issue is

that security decision makers interpret IS terminology

differently, which leads to misunderstanding among

them when they assess threats or evaluate security risk

scenarios (Pereira and Santos, 2012), (Martins et al.,

2020). For example, the security terms of attack,

threat and risk are confused and used as synonyms

(Li and Chen, 2020). The challenge for requirements

analysts is to remove ambiguities of IS concepts and

become familiar with security terminology that is in-

creasing and changing over the time (Elnagar et al.,

2020).

Security concepts can be observed and regrouped

regarding several dimensions (Jouini et al., 2021).

Each dimension takes a speciﬁc manageable perspec-

tive on IS, where one can have a better understand-

ing of the characteristics of concepts by accurately

deﬁning concepts with their features or attributes. For

example, the security dimension of conﬁdentiality

represents the concept of conﬁdentiality with its at-

tributes such as conﬁdentiality impact, conﬁdentially

key and conﬁdentiality mode, and the security dimen-

sion of network represents the concept of network

with its details like network access, network ﬁle, net-

work trafﬁc and network defense. In general, an on-

tological dimension is a component of the ontology

that has a high level of cohesion between its con-

cepts. The concepts of such component present a

level of connectivity (through the relationships be-

tween them), which makes the component presents a

sub-domain of the domain under consideration. An-

other way to consider the dimension in an ontology

is to take as possible dimensions the concepts that

are immediately connected to the root. For instance,

in our case, the concepts attack, threat, or risk re-

lated to the root concept ”Thing” (as shown in Fig-

ure 5) are possible dimensions that can give perspec-

tives on the domain of IS. According to the design

principle of low coupling and high cohesion, an ontol-

ogy that exhibits high cohesion between its elements

and low coupling with other components is deemed

to be well designed. Decomposing ontologies into

modules (i.e., sub-ontologies) using dimensions could

be considered as an approach to ontology modularisa-

tion (LeClair et al., 2019; LeClair et al., 2022; LeClair

et al., 2020). These dimensions help focus the atten-

tion of the requirement analyst to one aspect of the

system security by eliciting the requirement from one

aspect at the time. This paper proposes an IS ontology

that has several dimensions and modules.

In this paper, we propose a multi-dimensional on-

tology of IS domain. The ontology is presented under

an OWL format, in which several dimensional views

can be extracted according to the user’s security re-

quirements and needs. The proposed ontology would

support security stakeholders to use only the views

that are relevant to their concerns, which reduces the

burns of partially using a large ontology. Several soft-

ware programs are used to support the generation of

multi-dimensional IS ontology in OWL format. We

used python for writing view extraction programs and

prot

e editor to visualise the obtained ontology in

the form of dimensional views.

The paper is structured as follows: Section 2

presents related works. In this section, we describe

existing IS ontologies, detail their structure in term

of security concepts, and provide a critical analysis

of them regarding security dimensions. Section 3

presents an overview of the systematic process of the

multi-dimensional IS ontology generation. Section 4

gives an illustrative example of OWL ontology gen-

eration process and the dimensional views obtained.

Section 5 compares the proposed ontology with three

OWL IS ontologies. Section 6 presents the highlights

of the proposed IS ontology and point to related future

works.

2 RELATED WORK

Several IS ontologies have been presented in the lit-

erature. This section discusses the organization of se-

curity concepts under existing IS ontologies.

Herzog et al. (Herzog et al., 2007) propose the

ﬁrst OWL-based IS ontology for security researchers

and professionals. The ontology models the ba-

sic concepts of security risk analysis namely Asset,

Threat, Countermeasure, Vulnerability, Security goal,

and Defence strategy. Each basic concept is hierar-

chically classiﬁed into speciﬁc sub concepts. In (Ra-

manauskait

e et al., 2013), a generic ontology based

IS standards is developed to optimize the use of sev-

eral standards in organization. The proposed ontology

includes ﬁve classes: Organization, Asset, Threat,

Vulnerability and Countermeasure(Meriah and Rabai,

2019). The standard mapping and the hierarchy struc-

ture of each class enable to provide details relevant

to the high level IS cited concepts. In these ontolo-

gies, the authors consider only the organizational and

risk assessment perspectives for modeling IS domain.

We should consider other security aspects to provide

a complete view of IS domain.

Other IS ontologies provide speciﬁc security as-

pects for modeling security knowledge. For example,

An OWL Multi-Dimensional Information Security Ontology

373

the OWL security ontology in (Solic et al., 2015) is

used to estimate the level of system’s security. Thus,

by considering the IS elements of Network security,

Software and hardware issues, Human inﬂuence, Se-

curity policy, and Disaster recovery plan. These con-

cepts model involved security issues in information

systems. In addition, the ontology proposed in (Li and

Chen, 2020) organizes the security requirement as-

pects of IS to four concepts Asset, Security property,

Countermeasure, and Security requirements. The au-

thors provide details of each security requirement

concept using key words extracted from IS documents

and standards. In fact, concepts in these ontologies

are dependent to IS sub-domains as they are used to

support IS models and frameworks.

In the literature, another category of IS ontologies

are presented in the form of modules. Fenz and Ekel-

hart in (Fenz and Ekelhart, 2009) present a uniﬁed IS

ontology to support security risk management in in-

formation systems. The proposed ontology is divided

in three subontologies: Security, Enterprise, and Lo-

cation. Security subontology includes four classes

Threat, Vulnerability, Attribute, and Rating. Enter-

prise subontology includes three classes Asset, Enter-

prise and Person while the location subontology in-

cludes only the Location class. Souag et al. (Souag

et al., 2015) present a core security ontology which

model security requirement concepts with their rela-

tionships. The structure of the ontology is based on

three dimensions: Organization, Risk, and Treatment.

In (de Franco Rosa et al., 2018), an OWL ontology

called Security Assessment Ontology (SecAOnto) is

developed to describe security assessment aspects in

organizations. The concepts are organized in three di-

mensions: System assessment, Information security,

and Security assessment.

All the cited ontologies in this section provide an

intuitive description of security dimensions and con-

cepts without providing how the dimensional decom-

position of their ontologies is established. In addition,

we ﬁnd that a clear ontological view of these dimen-

sions is missed, which might affect the interpretation

of the IS domain.

To the best of our knowledge, we lack a well deﬁned

systematic and/or automatic methodology to classify

the ontology concepts into several IS speciﬁc aspects

to generate multiple views regarding the ﬁnal on-

tology user needs. Then, developing and propos-

ing a multidimensional ontology to present dimen-

sional views for most ontology concepts is undoubt-

edly needed by the IS ontology community.

3 THE PROPOSED OWL

ONTOLOGY GENERATION

PROCESS

To overcome the lack of a systematicly generated

multiple views of an IS ontology, we propose in

this section a multi-dimensional ontology that con-

tains domain concepts with their hierarchical rela-

tionships. The generation process of this ontology

starts with online IS dictionary and leads to dimen-

sional views generated from OWL ontology concepts.

The dimensional views obtained provide an overview

of the IS domain and help organizations to have de-

tails about particular IS concepts and identify their

security needs and requirements. For example, from

the OWL multi-dimensional ontology generated, on-

tology users can extract dimensional views such as

control, privacy, and authentication dimensions. The

generation process of OWL multi-dimensional IS on-

tology is fully automatic. As presented in Figure 1, it

includes four steps:

1. Concept extraction: It is for the extraction of do-

main concepts from web dictionary.

2. XML generation: It leads to a hierarchical repre-

sentation between concepts in the form of XML doc-

ument.

3. OWL generation: It transforms the XML structure

of the ontology into its corresponding OWL represen-

tation.

4. Dimensional view extraction: It supports the ex-

traction of dimensional views relevant to a given con-

cepts in OWL ontology.

Figure 1: The proposed generation process of OWL Multi-

dimensional IS ontology.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

374

3.1 Concept Extraction

We have focused on online dictionaries presenting a

large number of concepts in IS domain. Domain dic-

tionaries provide to their users a well-deﬁned vocabu-

lary for searching and indexing. For constructing do-

main ontologies, dictionaries are often used to rec-

ognize domain concepts and identify such similarity

between them (Harjito et al., 2018).

Domain concepts in dictionary are particularly

noisy including an amount of useless information.

Pre-processing tasks are necessary to exclude worth-

less symbols and obtain a cleaned space of concepts.

To extract domain concepts, the classical tasks of pre-

processing adapted in this stage consist of:

• Filtering useful domain concepts while excluding

punctuation characters, special characters, numbers,

abbreviations, and stop words.

• Removing some domain concepts that include ad-

jectives or adverbs.

• Removing words with less than three characters.

• Converting the string-labels of the obtained con-

cepts to lowercase.

In this ﬁrst step that of concept extraction, we have

used different Python libraries to identify required

concepts. BeautifulSoup library is used to gather con-

cepts from HTML pages while the re library is used

to identify abbreviations. In other hand, we use NLP

techniques like tokenization, POS and stop word re-

moval to identify concept patterns. In fact, tokeniza-

tion splits compound terms into a list of words called

tokens. Then, POS is used to assign the correspond-

ing POS tagging to each token. It consists of identify-

ing the grammatical category of words such as noun

(NN), verb (VB), adjective (JJ). Stop words removal

is another method, which manages textual data and

removes compound words including stop words (CC)

(e.g., after, before, and, or).

3.2 XML Generation

A structural representation of domain concepts is re-

quired to capture concept relationships. In fact, XML

is a simple and ﬂexible data source which provides

to their intended users a common syntax (Nguyen,

2011). In general, the structure of XML represents in-

formation in the form of tags to relive the low seman-

tics of HTML. Tags in XML can be represented as a

structured tree giving a hierarchical representation of

concepts (BRAY, 2000), (Nguyen, 2011). To generate

an XML document in this second stage, two essential

tasks are performed. The ﬁrst is to map all extracted

concepts to XML Tags. The second is to provide con-

cept hierarchies. As a result, we obtain concept rela-

tionships as structured tree regarding hierarchical lev-

els. Table 1 shows concept patterns identiﬁed from

the generated XML document and illustrates exam-

ples of IS concepts with their hierarchical levels. Con-

cepts in level one present unique terms while concepts

in level two and three present compound terms. We

note that concepts in the second level of hierarchy in-

clude only two terms while concepts at the third level

include at least three terms. We follow this structure

to obtain concept relationships in the form of XML

document.

Table 1: Identiﬁcation of concept patterns from XML doc-

ument.

Concept patterns IS Concept examples Depth

NN computer 1

NN NN computer security 2

NN NN NN computer security incident 3

NN NN NN NN access security log man-

agement

3.3 OWL Generation

To obtain the graphical representation of the ontol-

ogy, it is needed to consider the XML document.

Then, we generate the OWL ﬁle as XML structure.

The obtained structure can be used for semantics and

for reasoning. With only the XML format of con-

cepts, it is difﬁcult to do operations like classiﬁcation,

check consistency, selection, and comparison. Fur-

thermore, to ensure the interoperability of concepts,

after converting the XML to OWL ontology, we use

the python library of MinDom for parsing XML as

a tree and mapping its elements to OWL classes (di-

mensions) and OWL sub-classes (attributes). Hier-

archical relationships in OWL ontology are the re-

quired components that reveal different security di-

mensions. In fact, RDF and RDFS support the under-

standing of the extracted information on the web. In

our obtained OWL ontology, RDF operates the graph-

ical representation of web resources using URI, while

RDFS provides vocabulary specifying classes (i.e.,

rdf: class) on the hierarchical relationship between

classes(i.e., rdfs: subclassof ) (Bikakis et al., 2013),

(Nguyen, 2011).

Figure 2 shows the corresponding OWL encoding of

the class computer and the subclass computer abuse.

The OWL format of the complete IS ontology gener-

ated is available in (Meriah et al., 2023a).

3.4 Multi-Dimensional View Extraction

A view is a fragment of a target ontology, which is

captured by ontology users (Lozano et al., 2014). A

An OWL Multi-Dimensional Information Security Ontology

375

Figure 2: Fragment of the OWL ﬁle generated showing

the security dimension of computer with its attribute com-

puter abuse.

dimensional view is considered as a portion of an

existing domain ontology, which presents details re-

lated to a root ontology concept. The purpose of this

stage consists of offering a well deﬁned terminology

regarding user security needs. As mentioned previ-

ously, the ontological representation helps ontology

users easily querying and searching for particular con-

cepts and details. Therefore, to extract dimensional

view, three main tasks are performed:

1. Search the root concept by browsing OWL ontol-

ogy.

2. Select the root concept, if it exists in the OWL on-

tology.

3. Visualize the dimensional view in which, all con-

cepts that are reachable from the selected concept are

involved.

In this ﬁnal stage of our ontology generation process,

we use the ontology implementation tool of prot

editor (Prot

e, 2020). This tool provides an interac-

tive graphical representation for a given OWL ontol-

ogy and offers an API access to user knowledge bases.

The automatic generation of a sub-ontology based

on words occurring after each other make security

concepts related to each dimension readable, clear

and precise. The proposed OWL multi-dimensional

ontology is a means that help security stackholders

efﬁciently interpret security concepts. It is useful to

deﬁne security dimensions and precise the relations

among them.

4 A USAGE SCENARIO OF THE

OWL ONTOLOGY

GENERATION PROCESS

The following example illustrates the generation pro-

cess of OWL multi-dimensional IS ontology and illus-

trates how users can exploit the obtained ontology to

precisely decompose the three IS concepts threat, at-

tack, and risk. Decision makers are often using these

three terms for identifying, analysing, and evaluating

their IS situation within the organization. The chal-

lenge for them is to remove ambiguities among these

terms in order to efﬁciently conduct risk assessment

and make suitable IS decisions.

Attackers exploit system vulnerabilities to launch

attack programs or multihost attacks that target com-

puter resources in a progressive way (Meriah and

Rabai, 2018). In organizations, the popular forms

of attacks like phishing, malware and DoS/DDoS at-

tacks make unauthorized access of information assets

in order to use, steal or destroy sensitive data (Sing-

hal and Ou, 2017; ISO Central Secretary, 2018). For

example, DoS attack deactivates servers by gaining

access to particular services from internet and mak-

ing computer resources like disk space, processor and

bandwidth unavailable. In addition, malicious attack-

ers pose potential threats in information systems. In

(Stoneburner et al., 2002), a threat refers to ”a cir-

cumstance that cause damage to information system’s

assets”. It can be an undertaken action performed by

attacker or adversary to makes business losses. Sig-

niﬁcant threats that are commonly known include de-

struction, fraud, penetration, theft, disclosure, extor-

tion, vandalism, and espionage.

In general, IS attacks and potential threats affect

security objectives and make business prone to risk.

According to (Jones and Ashenden, 2005), risk is an

unexpected event that makes us at least losing one of

the security requirements. As an initiative to address

such risk, it is relevant to outline security threats in

business environment and identify attacker’s traces in

a security context. In ISMS, a risk is deﬁned as the

effect of uncertainty on IS objectives (Alanen et al.,

2022). It is considered as the potential of security

threats to cause security breakdowns in an enterprise.

The risk is measured by the likelihood and impact

caused by attackers and IS threats. Therefore, model-

ing threat, attack and risk concepts as IS dimensions

helps to improve their perceptions in IS domain and

organizations.

We apply the OWL ontology generation process to

INFOSEC dictionary (Center, 2022). This dictionary

includes terminology changing in a continuous way

and varying based on the IS sub-ﬁelds being consid-

ered. Related terms and deﬁnitions are mainly cap-

tured from IS security standards and guidelines like

NIST Special Publications (SPs) and Federal Infor-

mation Processing Standards (FIPS). We have con-

sidered IS concepts under the above dictionary (i.e.,

dictionary of (Center, 2022)) as it respects most of the

requirements and hypothesis regarding the proposed

ontology generation process.

In the ﬁrst stage, we extract IS concepts regarding

several tasks of pre-processing. In the second stage,

we have offered a hierarchical representation between

these IS concepts using XML document. The XML

identiﬁes the security dimensions as a root concepts

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

376

Figure 3: Screenshot of attack, threat and risk dimensions

in XML ﬁle.

Figure 4: OWL IS Ontology generated.

organized with their features called attributes. In Fig-

ure 3, we present screenshots from XML document

generated. The screenshots show the risk dimension

with 17 attributes, the threat dimension with 7 at-

tributes and the attack dimension with 3 attributes. To

visualize the ontology, the XML structure of IS con-

cepts is mapped to OWL ontology. As shown in Fig-

ure 4, ontology dimensions are fuzzy, ambiguous and

unreadable due to the huge amounts of the stored con-

cepts. Therefore, IS dimensions still difﬁcult to read

and interpret. To solve this problem, it is required to

present attack, threat, and risk concepts as a dimen-

sional views in order to perceive them correctly within

information systems.

At the end of the ontology generation process, we

have speciﬁed and visualized security concepts view

by view. First, we have searched the required dimen-

sion by browsing the ontology itself. Second, we have

selected the dimension in OWL ontology and ﬁnally

we have displayed the view using OntoGraph plugin

from prot

e editor. Figure 5 shows attack, threat,

and risk dimensional views. Attack view is repre-

sented with red box. Threat view is represented with

blue box and risk view is represented by orange box.

The low number of attributes of attack dimension is

an indication about its limited perception in the IS

domain. In other hand, the high number of attributes

of threat and risk dimensions is an indication of their

wide scope in the domain. We note that all the con-

cepts that are reachable from threat dimension are in-

volved in threat dimensional view.

5 EVALUATION OF THE

PROPOSED ONTOLOGY

In this section, we evaluate the proposed multi-

dimensional ontology by comparing it with the most

known and available OWL IS ontologies for the re-

lated community. We have focused on the impor-

tance of the multi-dimensional ontology obtained in

terms of concepts, attributes and dimensions using a

qualitative analysis. In fact, three OWL IS ontologies

were selected for the ontological analysis: Herzog et

al. ontology (Herzog et al., 2007), Fenz et al. on-

tology (Fenz and Ekelhart, 2009) and De Franco et

al. ontology (de Franco Rosa et al., 2018). In Her-

zog et al. ontology (Herzog et al., 2007), concepts

are derived from security databases and cryptographic

models related to IS risk analysis and access control

sub-domains. In other hand, the structure of Fenz

et al ontology (Fenz and Ekelhart, 2009) highlights

the relationships among top-level security concepts to

ensure security compliance and IS risk management

in organization. Most relevant concepts in Fenz et

al. ontology are obtained from IT Grundschutz Man-

ual, the french EBIOS and ISO/IEC 27001 standards.

For modeling IS assessment sub-domain, SecAOnto

ontology in (de Franco Rosa et al., 2018) presents

terms from existing security taxonomies, ontologies

and guidelines.Although the presented ontologies de-

ﬁne an extensive list of security concepts, they still

fragile as they highly dependent on speciﬁc IS sub-

ﬁelds like access control, risk assessment and risk

management. None of them covers a large number

of IS sub-domains. It can be noticed that the ontol-

ogy generated provides a major coverage of IS area

because it incorporates concepts extracted from se-

curity dictionary (CSRC dictionary). Following the

proposed process of ontology generation, the multi-

dimensional ontology can update and interrelate their

security terms in a continuous way. Thus, it enables

ontology users to generate speciﬁc ontologies relevant

to IS sub-ﬁelds. For instance, we can derive the secu-

rity dimensions of threat, asset, vulnerability and con-

trol and then represent relevant details to IS risk man-

agement sub-domain. The main ontology elements

considered for comparing ontologies are: the num-

ber of concepts, the number of attributes and the total

number of security dimensions providing hierarchical

An OWL Multi-Dimensional Information Security Ontology

377

Figure 5: The dimensional views of attack, threat, and risk.

relationships. prot

e editor metrics have been used

to obtain quantitative data of these ontology elements.

Table 2: Data of comparison results of OWL IS ontologies.

OWL IS ontology elements

References Concepts Attributes Dimensions

(Herzog et al., 2007) 460 752 -

(Fenz and Ekelhart, 2009) 641 1051 3

(de Franco Rosa et al., 2018) 157 167 3

Proposed ontology 2660 1613 331

Table 2 compares the number of concepts, at-

tributes and dimensions for each cited ontology and

the proposed one. As results, De Franco et al. on-

tology has the least number of concepts, while the

proposed multi-dimensional ontology has the largest

number of security concepts and attributes. Regard-

ing the dimensional aspect in these ontologies, the se-

curity dimensions are very low in Fenz et al. and De

Franco et al. ontologies, while the proposed OWL

ontology provides 331 security dimensions as sub-

ontologies. Each security dimension precises generic

security concept with its attributes. In fact, the di-

mensional aspect in ontology helps interpreting ter-

minologies and domain concepts. In general, security

dimensions make readable, shared and reusable the

generic concepts like threat, risk and control.

Furthermore, dimensions in the proposed OWL IS

ontology are used to remove ambiguities of security

concepts. Their main purpose is to specify security

concepts in an organized and detailed way.

6 CONCLUSIONS AND FUTURE

WORKS

This paper proposes an OWL multi-dimensional IS

ontology. The proposed ontology is comprehensive

and extendable as it can be further enriched with con-

cepts from IS corpuses. The overall ontology shows

the ontological links between the dimensions of IS,

which gives IS stakeholders an idea about the depen-

dencies among the dimensions and their criticality on

the security.

Following a rigorous and repeatable process that

is discussed in Section 3, we developed an ontology

covering the IS domain. This ontology is easily de-

composable into modules each presenting a security

dimension and providing a security perspective. The

ontology is available at (Meriah et al., 2023b) under

an XML format and at (Meriah et al., 2023a) under

an OWL format. The process used in obtaining the

proposed ontology can be applied to get ontologies in

other natural languages. For instance, for an ontol-

ogy in French one starts from a French dictionary for

security and uses similar Python scripts as the ones

we used (after adapting them to the speciﬁcs of the

language) to extract the concepts and their relation-

ships. Using the notion of ontology dimensions, we

can decompose the proposed IS ontology into sev-

eral modules. This modularization is essential when

we want to focus on speciﬁc security concerns such

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

378

as management, risk, or threats. In (LeClair et al.,

2019; LeClair et al., 2020), we ﬁnd several ontology

modularization techniques. The dimensionalities in-

troduced in this paper could play a signiﬁcant role in

support of methods such as the view traversal modu-

larization technique. ontology metrics of prot

e edi-

tor are considered. Our future work aims at exploring

further enrichment of the current ontologies with con-

cepts and relationship extracted from other sources

such as ISO standards, wiki-data, and several other

corpuses. Our objective is to have the most current

and complete IS ontology.

We plan to use other ontology evaluation metrics

like precision, recall and f-measure to more evalu-

ate the performance of our ontology generation ap-

proach. Furthermore, we aim to use the proposed

ontology combined with DIS formalism (Marinache

et al., 2021) in analysing security-log data to learn

about the security situation surrounding the system

under consideration.

ACKNOWLEDGMENT

This study was funded by Natural Sciences and Engi-

neering Research Council of Canada –NSERC– (CA)

(RGPIN-2020-06859).

REFERENCES

Alanen, J., Linnosmaa, J., Malm, T., Papakonstantinou, N.,

Ahonen, T., Heikkil

a, E., and Tiusanen, R. (2022).

Hybrid ontology for safety, security, and dependabil-

ity risk assessments and security threat analysis (sta)

method for industrial control systems. Reliability En-

gineering & System Safety, 220:108270.

Bikakis, N., Tsinaraki, C., Gioldasis, N., Stavrakantonakis,

I., and Christodoulakis, S. (2013). The xml and se-

mantic web worlds: technologies, interoperability and

integration: a survey of the state of the art. In Se-

mantic hyper/multimedia adaptation, pages 319–360.

Springer.

BRAY, T. (2000). Extensible markup language (xml) 1.0 ,

w3c rec-xml. http://www. w3. org/TR/REC-xml/.

Center, C. S. R. (2022). Glossary. https://csrc.nist.gov/

glossary/.

de Franco Rosa, F., Jino, M., and Bonacin, R. (2018). To-

wards an ontology of security assessment: A core

model proposal. In Information Technology-New Gen-

erations, pages 75–80. Springer.

Elnagar, S., Yoon, V., and Thomas, M. (2020). An auto-

matic ontology generation framework with an orga-

nizational perspective. In Proceedings of the 53rd

Hawaii International Conference on System Sciences.

Fenz, S. and Ekelhart, A. (2009). Formalizing information

security knowledge. In Proceedings of the 4th inter-

national Symposium on information, Computer, and

Communications Security, pages 183–194.

Harjito, B., Cahyani, D. E., and Doewes, A. (2018). An au-

tomatic approach for bilingual tuberculosis ontology

based on ontology design patterns (odps). TELKOM-

NIKA Telecommunication Computing Electronics and

Control, 16(1):282–289.

Herzog, A., Shahmehri, N., and Duma, C. (2007). An ontol-

ogy of information security. International Journal of

Information Security and Privacy (IJISP), 1(4):1–23.

ISO Central Secretary (2018). Information technology —

security techniques — information security manage-

ment systems — overview and vocabulary. Standard

ISO/IEC 27000:2018, ISO, Geneva, CH.

Jones, A. and Ashenden, D. (2005). Risk management for

computer security: Protecting your network and in-

formation assets. Elsevier.

Jouini, M., Ben Arfa Rabai, L., and Khedri, R. (2021).

A quantitative assessment of security risks based on

a multifaceted classiﬁcation approach. International

Journal of Information Security, 20(4):493–510.

LeClair, A., Khedri, R., and Marinache, A. (2019). Toward

measuring knowledge loss due to ontology modular-

ization. In Dietz, J., Aveiro, D., and Filipe, J., ed-

itors, In Proceedings of the 11th International Joint

Conference on Knowledge Discovery, Knowledge En-

gineering and Knowledge Management (IC3K 2019),

volume 2 of IC3K, pages 174–184, Vienna, Austria.

SCITEPRESS Science and Technology Publications,

Lda.

LeClair, A., Khedri, R., and Marinache, A. (2020). Formal-

izing graphical modularization approaches for ontolo-

gies and the knowledge loss. In Knowledge Discov-

ery, Knowledge Engineering and Knowledge Manage-

ment, volume 1297 of Communications in Computer

and Information Science series, chapter 18, pages 1–

25. Springer.

LeClair, A., Marinache, A., Ghalayini, H. E., MacCaull, W.,

and Khedri, R. (2022). A review on ontology modu-

larization techniques - a multi-dimensional perspec-

tive. Transactions on Knowledge and Data Engineer-

ing, pages 1–28.

Li, T. and Chen, Z. (2020). An ontology-based learning ap-

proach for automatically classifying security require-

ments. Journal of Systems and Software, page 110566.

Lozano, J., Carbonera, J., Abel, M., and Pimenta, M.

(2014). Ontology view extraction: an approach based

on ontological meta-properties. In 26th International

Conference on Tools with Artiﬁcial Intelligence, pages

122–129. IEEE.

Marinache, A., Khedri, R., Leclair, A., and MacCaull, W.

(2021). DIS: A data-centred knowledge representa-

tion formalism. In IEEE International Conference on

Reconciling Data Analytics, Automation, Privacy, and

Security (RDAAPS), pages 1–8, Hamilton, Ontario,

Canada. IEEE Computer Society.

Martins, B. F., Serrano, L., Reyes, J. F., Panach, J. I., Pastor,

O., and Rochwerger, B. (2020). Conceptual character-

ization of cybersecurity ontologies. In IFIP Working

An OWL Multi-Dimensional Information Security Ontology

379

Conference on The Practice of Enterprise Modeling,

pages 323–338. Springer.

Meriah, I. and Rabai, L. B. A. (2018). A survey of quanti-

tative security risk analysis models for computer sys-

tems. In Proceedings of the 2nd International Con-

ference on Advances in Artiﬁcial Intelligence, pages

36–40.

Meriah, I. and Rabai, L. B. A. (2019). Comparative study of

ontologies based iso 27000 series security standards.

Procedia Computer Science, 160:85–92.

Meriah, I., Rabai, L. B. A., and Khedri, R. (2021). Towards

an automatic approach to the design of a generic on-

tology for information security. In 2021 Reconciling

Data Analytics, Automation, Privacy, and Security: A

Big Data Challenge (RDAAPS), pages 1–8. IEEE.

Meriah, I., Rabai, L. B. A., and Khedri, R.

(2023a). Multi-dimensional Information Secu-

rity Ontology. https://github.com/inesmeriah/

Multi-dimensional Information Security Ontology/

blob/main/owl Ontology.owl.

Meriah, I., Rabai, L. B. A., and Khedri, R.

(2023b). Multi-dimensional Information Secu-

rity Ontology. https://github.com/inesmeriah/

Multi-dimensional Information Security Ontology/

blob/main/xml Ontology.xml.

Murtazina, M. and Avdeenko, T. (2019). An ontology-

based approach to support for requirements traceabil-

ity in agile development. Procedia Computer Sci-

ence, 150:628–635. Proceedings of the 13th Inter-

national Symposium “Intelligent Systems 2018” (IN-

TELS’18), 22-24 October, 2018, St. Petersburg, Rus-

sia.

Nguyen, V. (2011). Ontologies and information systems: a

literature survey.

Pereira, T. and Santos, H. (2012). An ontological approach

to information security management. In 7th Interna-

tional Conference on Information Warfare and Secu-

rity. Seattle. University Washington, pages 368–375.

Prot

e (2016 (accessed January 5, 2020)). A free, open-

source ontology editor and framework for building in-

telligent systems. https://protege.stanford.edu/.

Ramanauskait

e, S., Olifer, D., Goranin, N., and

Cenys, A.

(2013). Security ontology for adaptive mapping of se-

curity standards. International Journal of Computers,

Communications & Control (IJCCC), 8(6):813–825.

Sanagavarapu, L. M., Iyer, V., and Reddy, Y. R. (2021).

Ontoenricher: a deep learning approach for ontology

enrichment from unstructured text. arXiv preprint

arXiv:2102.04081.

Singhal, A. and Ou, X. (2017). Security risk analysis of

enterprise networks using probabilistic attack graphs.

In Network Security Metrics, pages 53–73. Springer.

Solic, K., Ocevcic, H., and Golub, M. (2015). The informa-

tion systems’ security level assessment model based

on an ontology and evidential reasoning approach.

Computers & security, 55:100–112.

Souag, A., Salinesi, C., Mazo, R., and Comyn-Wattiau,

I. (2015). A security ontology for security require-

ments elicitation. In International symposium on engi-

neering secure software and systems, pages 157–177.

Springer.

Stoneburner, G., Goguen, A., Feringa, A., et al. (2002).

Risk management guide for information technology

systems. Nist special publication, 800(30):800–30.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

380
