Evaluation of Approaches for Documentation in Continuous Software

Development

Theo Theunissen

1 a

, Stijn Hoppenbrouwers

1,2 b

and Sietse Overbeek

3 c

Department of ICT, HAN University of Applied Sciences, Arnhem, The Netherlands

Radboud University, Institute for Computing and Information Sciences, Nijmegen, The Netherlands

Department of Information and Computing Sciences, Utrecht University, Utrecht, The Netherlands

Keywords:

Artifacts, Continuous Software Development, Documentation, Executable Documentation, Just Enough

Upfront.

Abstract:

With the adoption of values, principles, practices, tools and processes from Agile, Lean, and DevOps, knowl-

edge preservation has become a serious issue because documentation is largely left out. We identify two

questions that are relevant for knowledge acquisition and distribution concerning design decisions, rationales,

or reasons for code change. The ﬁrst concerns which knowledge is required upfront to start a project. The

second question concerns continuation after initial development and addresses which knowledge is required

by those who deploy, use or maintain a software product. We evaluate two relevant approaches for alleviat-

ing the issues, which are ‘Just enough Upfront’ and ‘Executable Documentation’ with a total of 25 related

artifacts. For the evaluation, we conducted a case study supported by a literature review, organizational and

project metrics, and a survey. We looked into closed source-code and closed classiﬁed source-code. We found

two conclusive remarks. First, git commit messages typically contain what has been changed but not why

source-code has been changed. Design decisions, rationale, or reasons for code change should be saved as

close as possible to the source-code with Git Pull Requests. Second, knowledge about a software product is

not only written down in artifacts but is also a social construction between team members.

1 INTRODUCTION

This study concerns the evaluation of novel ap-

proaches to documentation in Continuous Software

Development (CSD). CSD is an umbrella term that

covers values, principles, practices, tools and pro-

cesses from Agile, Lean, and DevOps (Theunissen,

van Heesch, & Avgeriou, 2022). Characteristics of

CSD are that information about a software product is

distributed across all tools which hold code and other

(non)executable artifacts that stakeholders require to

start an iteration or keep continuing an iteration. An-

other characteristic is that knowledge is loose, infor-

mal, and communicated in meetings such as daily

stand-ups, leading to a risk of knowledge evapora-

tion. In a previous study (Theunissen, Hoppenbrouw-

ers, et al., 2022), we looked into information about

software products, primarily to Git commit messages

from open source repositories. In this study, we eval-

https://orcid.org/0000-0003-0681-8666

https://orcid.org/0000-0002-1137-2999

https://orcid.org/0000-0003-3975-200X

uate two approaches: ‘Just enough Upfront’ and ‘Ex-

ecutable Documentation’ concerning the characteris-

tics of CSD. The ﬁrst approach concerns ‘just enough

knowledge about stakeholder concerns, requirements,

and speciﬁcations to start development’. The dis-

tribution of knowledge takes place through the de-

livery of a design afterward, including design deci-

sions. This approach is typically used for fast Time-

to-Market (TTM) situations. The second approach

covers more mature projects where requirements and

speciﬁcations are used at the start of Test Driven De-

velopment (TDD) and Behavior Driven Development

(BDD).

To evaluate the approaches with artifacts, we stud-

ied practical usages in the industry of artifacts with

closed source code. ‘Closed source code’ refers to

software that is not publicly available, including in-

formation about the software. Moreover, some code

bases are also classiﬁed and are not even available

to everyone within the organization studied. Special

clearances were required, or developers had to be dis-

connected from the internet. Reasons were (national)

404

Theunissen, T., Hoppenbrouwers, S. and Overbeek, S.

Evaluation of Approaches for Documentation in Continuous Software Development.

DOI: 10.5220/0011846200003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 404-411

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

Exploring domain and issues in

academia and industry.

Preliminiary

Studies

Desk research: what have

others researched, published

using Systemac Mapping Study?

Literature

Review, SMS

Field research: Are outcomes

from lit. review applicable

in the industry?

Case

Studies

Create something new,

construcng theories.

Construcng

Novel Approaches

Academic research,

Industry pracces,

Educaonal lecturers

and students

Assessment of the results.

Does it work as intended,

are the assumpons valid?

Evaluang

Approaches

Ulizing Results

Results

a. A wide range of tools are used for all steps in the life cycle of a soware product.

b. Informaon is distributed about the soware product across all those tools and not stored in a central repository.

c. To beer understand the soware products, the following media elements must be taken into account: the types of informaon, the

tools, tool-stacks and ecosystems to manage the (types of) informaon, and the amount of structure.

d. Tools include tool stacks, ecosystems, the types of informaon and amount of structure; they deﬁne the content of the message.

e. The amount of structural variety of informaon deﬁnes the value for informaon creaon and retrieval, including the tools to process

that informaon. Documentaon is considered an informaon type that is processed through tools in a soware development

ecosystem.

The pracce of minimal documentaon upfront combined with detailed design for knowledge transfer aerwards

The usage of executable documentaon

Modern tools and technologies to retrieve informaon and transform it into documentaon

Results

Just enough Upfront

Executable Documentaon

Automac Text Analycs

Figure 1: Phases in Research Project. This study concerns

the evaluation, depicted in green.

security, privacy, or protecting (national) infrastruc-

ture against threats.

1.1 Research Project and Related

Studies

This study concerns the evaluation of approaches

to knowledge preservation in a research project

that started with preliminary studies to explore the

IT-engineering domain and knowledge preservation

problems (Theunissen & van Heesch, 2016). Follow-

ing the preliminary study, a systematic mapping study

was performed to ﬁnd out what others have found al-

ready (Theunissen, van Heesch, & Avgeriou, 2022).

Following the literature review, the case studies in the

industry set out to validate the mapping studies and

discover new issues, including the distribution of in-

formation about software products across a software

development ecosystem (Theunissen et al., 2021).

In the construction phase, novel approaches such as

‘Just enough Upfront’ and ’Executable Documenta-

tion’, including artifacts concerned, were described to

cover the issues (Theunissen, Hoppenbrouwers, et al.,

2022). See Figure 1 for an overview.

In previous research, three novel approaches were

constructed in response to the ﬁndings (Theunissen,

Hoppenbrouwers, et al., 2022), of which two are eval-

uated and discussed in the current paper. These ap-

proaches are:

Just Enough Upfront. This approach leaves out a big

upfront design and encourages starting development

as soon as possible. Agility in adapting to change

is motivated by the progressive insight that leads to

modiﬁed requirements and speciﬁcations, as inherent

to CSD. There are no obstacles to applying this ap-

proach. Characteristics of the approach are that it is

best used for exploratory projects. Exploration is typ-

ical for Technology Readiness Levels (TRL) ≤3 with

Proof of Concept (PoC), but its exploration is also ap-

plicable to more mature phases such as prototyping,

doing pilots, and taking software into production. The

approach ﬁts Agile and Lean practices. There are six-

teen relevant artifacts, of which whiteboard sketches

and a Interface Deﬁnition Language (IDL) plan are

most relevant upfront. After delivery, design deci-

sions and accountability are most applicable.

Executable Documentation. This concerns any ar-

tifact related to a software product that is executable

and relatively easy to read by non-technical persons.

Conditions are requirements (what), and speciﬁca-

tions (how) that must be well-deﬁned upfront. Char-

acteristic of this approach is the use of pipelines

in Continuous Integration/Continuous Deployment

(CI/CD) (Theunissen, Hoppenbrouwers, et al., 2022).

The maturity level in TRL is 4≤9. It is suitable for

DevOps and accommodates fast TTM. Of the nine rel-

evant artifacts, frameworks, templates, libraries, and

Application Programming Interface (API)s are the

most relevant. Typical processes are TDD and BDD.

Developers and operators meet over infrastructure-

as-code where concerns match, for instance, for fast

TTM.

2 RESEARCH DESIGN

2.1 Research Questions

RQ1. What are the necessary and sufﬁcient condi-

tions for evaluating our novel approaches of doc-

umentation in CSD?

This question concerns the research method to

achieve rigor by demonstrating transparency and

repeatability.

RQ2. For both approaches, which of the artifacts

were used, are missing, or need adjustments of

conditions and characteristics?

This question examines in detail the claims for

merits.

RQ3. What are deﬁning characteristics of obstacles

that need to be resolved for implementing the

novel approaches in the industrial and educational

contexts?

This question is a preparation for utilizing the ap-

proaches in actual usage.

2.2 Research Methods

In previous research, we used Design Science (DS)

to construct and validate the novel approaches

(Wieringa, 2014). We will continue with DS for eval-

uating the approaches using case studies as proposed

by Wieringa (2014). Case studies are used for data

collection, following Yin (2016); see Figure 2. Ac-

cording to Wieringa (2014, p. 31), validation con-

Evaluation of Approaches for Documentation in Continuous Software Development

405

Single-case

Designs

Holisc

(single-unit

of analysis)

Embedded

(mulple

units of

analysis)

Muplple-case

Designs

Organizaon E

Organizaon N

Organizaon B

Organizaon A

Organizaon M

Characteriscs:

Long lifecycle (>30y),

Agile in Operaons

Teamlead (1)

Business Analyst (1)

Product Owner (4)

Architects (2)

Developers (3)

Architects (2)

Intern (1)

Teamlead (2)

Teamlead (1)

Product Owner (2)

Architects (1)

Developers (3)

Students (2)

Lecturers (3)

Characteriscs:

Only Dev, no Ops,

Senior level

Characteriscs:

Government,

Regulaons, fast

me-to-market

Characteriscs:

Transparancy &

Privacy

Characteriscs:

Transparancy &

Privacy,

CONTEXT

Case 9

CONTEXT

Embedded

Unit of

Analysis 1

CONTEXT

Embedded

Unit of

Analysis ...

CONTEXT

Embedded

Unit of

Analysis 28

CONTEXT

Case ...

CONTEXT

Case 1

CONTEXT (5)

Case

Figure 2: Units of Analysis in Case Studies.

cerns the assessment of potential usage of (in our

case) novel approaches and their construction. Evalu-

ation is the assessment of novel approaches, justiﬁed

by assessing the actual outcomes compared with the

intended outcomes. Assessment methods for valida-

tion are formative and summative judgments (Gonza-

lez & Sol, 2012; Lee & Hubona, 2009). Below, deﬁ-

nitions for the judgments are given.

1. Theory evaluation includes formative validity and

summative validity (Gonzalez & Sol, 2012).

2. Formative validity refers to the process of building

a new theory or approach. A key characteristic is

transparency (Lee & Hubona, 2009).

3. Summative validity refers to the sum of the re-

sults of the theories or approaches. It is achieved

through artifact evaluation (Lee & Hubona, 2009).

3 DATA COLLECTION

We conducted nine case studies in ﬁve organizations

with 28 units of analysis. One organization is com-

mercial, one organization is educational, and three

others are governmental. From ﬁve organizations,

we consulted the participants with semi-structured

interviews, studied non-executable artifacts such as

documentation in tools (including Git commit mes-

sages), and reviewed source code. In Figure 2, the

case studies are presented. In selecting the organiza-

tions, we targeted two speciﬁc approaches, i.e., ex-

clusively ‘Just enough Upfront’ or ’Executable Doc-

umentation’.

3.1 A Myriad of Tools That Contain

Information

The motivation for collecting this data is that it con-

tributes to answering RQ2 and RQ3. A second mo-

Conﬂuence

Jira

Git

Organizaon A

Organizaon B

Organizaon E

Organizaon N

Organizaon M

100%

25%

75%

50%

Figure 3: Usage of knowledge tools including design deci-

sions. Git includes GitHub, GitLab, and Bitbucket.

tivation for collecting this data is that in previous re-

search (Theunissen et al., 2021), we found that mod-

ern software development ecosystems include many

tools that hold information about software products.

This ranges from tools for capturing loose and in-

formal communication, such as whiteboard sketches

and natural language, to constructing source code and

conﬁguration data. For knowledge management, all

organizations use Conﬂuence, Jira, and Git. Conﬂu-

ence is the designated tool for all kinds of documenta-

tion, including design decisions. Jira is typically used

for task and process management, and Git is used for

source management control. See Figure 3 for the col-

lected data.

3.2 Tenure of Team and Age of

Repositories

The motivation for collecting this data is that it sup-

ports answering RQ2 and RQ3. A second motivation

is that knowledge preservation becomes more rele-

vant with applications aging because of the risk of

knowledge vaporization. A team with senior devel-

opers working for years on an application or in the

same organization shares embodied and tacit knowl-

edge about values, principles, practices, and tools and

processes, including changes over the years. See Fig-

ure 4 for the collected data.

< 1 year

> 15 year

1 - 3 year

4 - 8 year

9 - 15 year

None

Few

Moderate

Many

All

Year

Repositories

Tenure of IT team Age of Reposotories

8 9

13-15

16-20

21-25

>25

Figure 4: Tenure of team members for all organizations.

Note that the diagram is skewed for < 1 year for the edu-

cational organization because students are only involved for

one term (8-16 weeks). The scale of the right diagram is not

proportional.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

406

3.3 Just Enough Upfront

The reason for collecting this data is that it contributes

to answering RQ2 and RQ3. Furthermore, this data

supports and suggests modifying conditions, charac-

teristics, practices, and use cases for the previously

(Theunissen, Hoppenbrouwers, et al., 2022) deﬁned

artifacts. See Figure 5 for the usage of the artifacts.

Interviewees mentioned knowledge elicitation, which

compensates for missing artifacts, as an upfront activ-

ity in an educational context.

References

Results Planning

Descipon of Concepts

Plan of Approach

Interface Descripon Language

Presentaons

Yellow Pages

Whiteboard Sketches

Lists

Sandwich of Happiness

Git Commits

Comapred Planning versus ...

Soware

Full Detailed Design

Design Decisons

Final Sandwich of Happiness

All

None

Few

Many

Moderate

Upfront

Building

Figure 5: Usage of Artifacts for ’Just enough Upfront’

across all organizations.

3.4 Executable Documentation

The reason for collecting this data is that it contributes

to answering RQ2 and RQ3. Furthermore, this data

supports and suggests modifying conditions, charac-

teristics, practices, and use cases for the previously

(Theunissen, Hoppenbrouwers, et al., 2022) deﬁned

artifacts. See Figure 6 for the data. This data is

skewed because it is not used in educational organi-

zations.

Executable requirements

Executable speciﬁcaons

Templates, Frameworks, Libraries, APIs

DoD, SMART criteria, KPIs

Infrastructure-as-code

Reverse engineering

Enhanced Templates, &c.

Accountability and Aconable Data

Tests (TDD, BDD, ATDD)

All

None

Few

Many

Moderate

Upfront

Aerwards

Figure 6: Usage of Artifacts for ’Executable Documenta-

tion’ across all organizations.

4 DATA ANALYSIS

Data analysis concerns the process of bringing order,

structure, and meaning to the pile of collected data

(Marshall & Rossman, 2015, p. 399). Furthermore,

remarkable results and omissions are mentioned. For

this study, we assessed if the approaches and artifacts

did have the intended outcomes. With this, we follow

the summative assessment from DS.

4.1 A Myriad of Tools That Contain

Information

Using a software development ecosystem entails that

information about the software product is distributed

across all tools in the ecosystem. Designated tools

are used for speciﬁc types of information. For this re-

search project, we are interested in design decisions.

Only three tools were used for this type of informa-

tion in all organizations studied. These tools are Con-

ﬂuence, as a repository for knowledge about the soft-

ware product, Jira, for task management; and Git, pri-

marily for source code. For the range of types of in-

formation, varying from loosely communicated natu-

ral language and sketches on one side of the spectrum,

to constructed source code that can compile to run-

ning applications on the other, design decisions are

not stored in other tools. It may very well be possible

that descriptions, interpretations, and explanations as

answers to questions might be stored in chats, emails,

or spoken language. However, we excluded these

types of communication since they are not realisti-

cally retrievable. A typical workﬂow mentioned by

Conﬂuence

Jira

Git

• Epics

• User Stories

• Design Decisions

• Tasks

• Subtasks

• Source-code

• Commit Messages

• Pull Requests

Figure 7: Typical workﬂow across all studied organizations.

the participants outlines the process of writing epics

and user stories in Conﬂuence. Tasks from the user

stories are managed with Jira, source code is stored in

Git, and the comments can be limited to just the task

number from Jira. Within this ﬂow, code traceability

from task to user story to epic should be guaranteed

for knowledge preservation, such as design decisions.

See Figure 7. The ﬂow matches with literature (The-

unissen, van Heesch, & Avgeriou, 2022) and sugges-

tions from Atlassian

https://www.atlassian.com/agile/project-management/

user-stories

Evaluation of Approaches for Documentation in Continuous Software Development

407

Observations from the case studies are as follows:

1. No Conﬂuence or Jira for Running Software

Products. One of the organizations shuts down

instances of Conﬂuence and Jira at the end of a

project. The end of a project does not entail the

retirement of the software product, only that in-

formation is lost about the software product. For

that organization, the Git commit messages only

contain a task number, and the rationale for the

code changes could not be retrieved. This leads to

knowledge evaporation.

2. Tooling Without Design Decisions. Another or-

ganization did not store design decisions and had

to rely on a rather fuzzy vision without require-

ments or speciﬁcations for implementation. This

organization became aware of the lack of recorded

design decisions and started to store these deci-

sions in hindsight.

3. Short Lived Projects. For educational orga-

nizations, knowledge preservation is not rele-

vant. The lifetime from start to retirement is only

one term (8, 16 weeks). Students are required

to learn to use standards like a Software Re-

quirements Speciﬁcation (SRS) (Standards Com-

mittee, 1998), Software Architecture Description

(SAD) (Technical Committee, 2011) or Software

Design Description (SDD) (Standards Commit-

tee, 2009). Knowledge vaporization is immanent

in this context.

4. Migrations of Tools over the Years. One orga-

nization has used software for dozens of years.

Information about the software product must be

available for over 40 to 50 years. Migration of

tools did happen from paper to photocopies orga-

nized in a hierarchical ﬁle structure on disks to op-

tical character recognition and eventually to Con-

ﬂuence.

5. No Design Decisions in Git. No organization

mentioned keeping design decisions in Git. Dis-

cussing this made sense for participants, but it is

no actual practice.

4.2 Tenure of Team and Age of

Repositories

Compared with data from the U.S. (Bureau of La-

bor Statistics, U.S. Department of Labor, 2022), team

members in the studied organizations keep working

for the same organization much longer, except for

the educational organization. This is a big difference

compared to the tenures for developers in big tech

companies, which is less than three years (Anony-

mous, 2017).

Observations from the case studies are as follows:

1. Educational Contexts Require no History nor

Seniority. Students are involved in a project for

a short time, and maintenance or support is not

part of the program. The teams investigated are

larger than in the industry. The team in the edu-

cational organization consists of 20 to 25 devel-

opers and is divided into sub-teams working on

sub-systems. The primary objective for students

is to pass the course and project, not to maintain

or support a software product. Students remember

tools, techniques, and processes rather than design

decisions.

2. Team with History in an Organization - Shar-

ing Knowledge. One of the participants ex-

plained that employees in non-proﬁt organizations

earn less money than in commercial companies

but are more loyal to the organization. Some or-

ganizations have a network of family members.

Employees stay much longer in the three govern-

mental organizations than in commercial organi-

zations. Team members have a history of past de-

cisions, which is relevant because not all decisions

are documented. This positively affects know-

ledge preservation, even if it is not documented.

The memory of undocumented historic decisions

is not identiﬁed as an artifact in the literature.

3. Life Span of Software. The moderate age of soft-

ware repositories is six years, with a Gaussian dis-

tribution ranging from 1 year to 12 years (Has-

selbring et al., 2020). The distribution is skewed

with mode and median left from the mean because

newer software is in use more than older soft-

ware. The software can age for dozens of years

for one of the studied organizations. This software

is part of cyber-physical systems such as frigates

and submarines.

4.3 Just Enough Upfront

Observations from the case studies are as follows:

1. Artifacts Always Used. Some artifacts were

always used, for example, presentations, source

code, and commit messages. Presentations are

helpful in transferring knowledge that can serve

as input for a project or iteration because the mix

of high-level diagrams supports an understanding

of causal and logical relations between concepts.

Depth can be obtained by supporting text accom-

panying the diagrams (Ainsworth, 2006). Source

code serves as a single source of truth and reveals

what the software product does and how it works

through close reading by (experienced) develop-

ers. It does not explain why the software prod-

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

408

uct works. Tools like Conﬂuence or Jira are often

used to record the reasons for modiﬁcations. For

Git, individual commit messages were not valu-

able, as mentioned by several respondents. How-

ever, Pull Requests are in use that “should con-

tain design decisions” instead of ordinary commit

messages.

2. Artifacts Never Used. Some artifacts, such as

references and a ﬁnal Sandwich of Happiness

(SoH), were never used. The artifacts SoH and

Result Planning (RP) are not familiar in most or-

ganizations, but assessments and retrospection are

common across all organizations.

3. Knowledge Distributed Across Software De-

velopment Ecosystem. In previous studies, we

found that nowadays, many tools are in use that

store pieces of information about software prod-

ucts (Theunissen et al., 2021), which remains true.

However, design decisions, rationales, and rea-

sons for change are typically stored in tools like

Conﬂuence or Jira.

4. Design Decisions Keeping Close to Source

Code. Source code is the Single Source of Truth

(SSOT). Developers can read the source code and

understand what it does and how it works. How-

ever, the reason why the source code is as it cannot

be retrieved from the source code itself. Typical

tools in use are Conﬂuence and Jira. We incor-

rectly expected that design decisions were stored

as close as possible to source code, and not in

other tools. To emphasize this point: one orga-

nization decided to turn off Conﬂuence and Jira

because the project was operational. As a result,

the knowledge related to the project was gone.

4.4 Executable Documentation

Observations from the case studies are as follows:

1. Artifacts Always Used.There are no artifacts

concerning Executable Documentation (ED) that

are always used across all organizations.

2. Artifacts Never Used. ED is not used in many

organizations, see Figure 6. Only a few organi-

zations practice it. An exception concerns TDD.

The highest score is because participants prefer

other tests, especially unit tests. This type of test-

ing often concerns the ‘happy ﬂow’. TDD aims

at writing tests that fail. In the case studies, one

organization used ED for all projects in their divi-

sion. This organization did not use any other doc-

umentation for knowledge acquisition or knowl-

edge transfer. This implies a lack of testing of the

software product. Developers mentioned reasons

such as test cases that made it possible to reverse-

engineer software that should be kept secret. An-

other organization with long-term software prod-

ucts (> 30 years) relies solely on its developers.

Developers are not connected to the internet to

‘google’ an answer or use publicly available li-

braries and frameworks for security reasons.

5 DATA INTERPRETATION

In this section, the most remarkable results will be

presented, being either a conﬁrmation or a rejection

of proposed artifacts. Artifacts such as presentations,

whiteboard sketches, software, and git commits are

used by all participants. Furthermore, following RQ3,

deﬁning characteristics for obstacles to implementa-

tion will be mentioned.

1. Relax on Design Upfront. Developers can start

a project or iteration as soon as requirements and

speciﬁcations are sufﬁcient. Longer contempla-

tion does not prevent progressive insights, espe-

cially in an educational context where progressive

insights are implicit in the process and objectives.

No obstacle hinders the implementation of relax-

ing on upfront design. Relaxing does not imply

becoming sloppy. The effort starts with remem-

bering values, principles, practices, and tools and

processes to make proper judgments on require-

ments and priorities.

2. Strict on Codiﬁed Interface Description. Inte-

gration of (sub)systems is always hard, it also hap-

pens at the end (when deadlines are approaching),

and the blame falls on others. Starting with, and

holding on to, a codiﬁed interface prevents inte-

gration issues.

Barriers to integration are related to being ac-

countable for results one has no control over the

other (sub)systems, teams, or external parties.

This leads to short-sighted vision, losing the big

picture, and shared responsibilities.

3. Knowledge is Social. Not all knowledge is stored

in artifacts. Participants across all organizations

mentioned that design decisions, rationales, or

reasons for change are not documented. For some

organizations where security, reliability, or con-

ﬁdentially are critical, knowledge about the soft-

ware product is in the hearts and minds of se-

nior developers. Knowledge is shared in meet-

ings, conversations, or presentations. People are

loyal to their organization, and knowledge stays

within the organization. This supports knowledge

preservation.

A risk for accepting that knowledge could be

found in social interaction concerns teams with

Evaluation of Approaches for Documentation in Continuous Software Development

409

a high change rate of team members, including

changes caused by internal reorganizations. The

organizations we researched do not pay the high-

est salaries, but team members have been loyal to

the organization over the years.

4. Knowledge is Primarily NOT Distributed

Across a Software Development Ecosystem.

Information about the software product is dis-

tributed across all tools in a software development

ecosystem in an organization. However, some

types of information, such as design decisions, ra-

tionales, or reasons for change, are kept in a single

place.

There is no barrier to this result. A communi-

cated modus operandi supports knowledge preser-

vation.

5. Saving Design Decisions in Git. It is com-

mon practice across all organizations to use Git

(GitHub, GitLab, Bitbucket) for keeping source

code. Typically, commit messages do not add

much information about the source code changes

as they mention what has been changed or how

it works. As design decisions cannot be retrieved

from source code, the best option for keeping this

type of information is git commit messages. Some

participants mention that Pull Requests are the

designated commit types.

We could not identify a hurdle for keeping design

decisions as close to the source code as possible.

Participants could not give a clear reason why not

to do so. Speculation from the participants in-

cludes the way of working and tooling. The way

of working is a behavioral change, and tooling is

a management decision.

6 THREATS TO VALIDITY

Threats to validity in DS is not a mature discipline

(Larsen et al., 2020). We follow Gonzalez and Sol

(2012) with formative and summative assessments to

evaluate the treatments. Formative assessment con-

cerns the process of how a result is achieved, and sum-

mative assessment refers to the result (’does it work?’)

of the treatment. Wieringa (2014, pp. 128, 138) men-

tions the following threats for treatment design:

1. Inference Support. What are reasoning or statis-

tical schemes to draw valid conclusions based on

assumptions and observations?

2. Repeatability. Can data sampling and reasoning

be reproduced several times, leading to the same

conclusions by other researchers?

3. Ethics. Does the research harm participants?

4. Interpretation. Does the reader accept the inter-

pretation as a fact?

Inference Support. This risk is mitigated by the ver-

iﬁcation of assumptions and hypotheses with the par-

ticipants. An assumption is a statement that is consid-

ered to be valid and proven in an inference of taking

to be invalid, which leads to an invalid conclusion by

applying the principle of excluded middle. A hypoth-

esis is considered to be true when it is not possible to

falsify it. Some artifacts, as can be seen in Figures 5

and 6, were valid (value ‘All’) and some were not

valid (value ‘None’). Some were inconclusive (other

values than ‘None’ or ‘All’). For this threat, both for-

mative and summative assessments are relevant. The

formative assessment considers the validity of the rea-

soning process. The summative assessment concerns

the validity of assumptions and hypotheses.

Repeatability. This risk is partially mitigated. For

the data sampling, it is mitigated in principle. How-

ever, because of the classiﬁed source code of some

organizations, clearance level is required

or legal re-

quirements

are required. For this threat, summative

assessments are relevant. With this assessment, the

repeatability is evaluated as to whether results can be

reproduced, partially when a situation is changed or

can not be reproduced.

Ethics. Internal processes mitigate this risk in organi-

zations by excluding privacy-sensitive data from the

research. Some organizations have a legal task to use

violence (military) or detect acts of crime. This could

harm people (enemies, criminals) involved but not so-

ciety as such. We take a utilitarian ethical viewpoint

that values the happiness of society above the hap-

piness of the individual. We consider the formative

assessment applicable where the process is evaluated.

Interpretation. This risk is mitigated by method and

data triangulation. We used a literature review, case

studies, and a survey to have several methods. Fur-

thermore, we used semi-structured interviews, exe-

cutable and non-executable artifacts, and data from a

survey. For this threat, both formative and summative

assessments are applicable. The formative assessment

concerns the process of collecting and interpreting the

data. For the summative assessment, results might

differ because of progressing insight, whereas a dif-

ferent result might emerge with identical assumptions

and hypotheses.

‘Verklaring omtrent Gedrag’ (VOG, Certiﬁcate of

Conduct) or ‘Verklaring van geen bezwaar’ (VGB, Certiﬁ-

cate of no Objection).

‘Wet op de Openbaarheid van Bestuur’ (WOB, ‘Dutch

Freedom of Information Act’).

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

410

7 CONCLUSIONS

We have three research questions to answer. The

ﬁrst research question concerns the necessary and

sufﬁcient conditions to use approaches and artifacts.

Shared values, principles, practices, tools, and pro-

cesses are critical for necessary and sufﬁcient condi-

tions. The second research question assesses the ac-

tual usage of approaches and artifacts. ’Just enough

Upfront’ is an approach that is used across all orga-

nizations or is considered appealing. Some artifacts

are constantly in use: presentations, whiteboard dia-

grams, plans of approach, software, and commit mes-

sages. Some are never used, such as references and

ﬁnal SoH. For the approach ‘Executable Documenta-

tion,’ no conclusive artifacts are included or excluded.

The artifacts that were most in use were tests. The

third research question concerns the deﬁning charac-

teristics of barriers to implementing the approaches

and artifacts. An obstacle mentioned across all or-

ganizations concerns unconﬁrmed, loose deviations

from prescribed processes or interfering objectives.

Examples of loose deviations of prescribed processes

are left-outs of ceremonies of textbook deﬁnitions of

Scrum or Scaled Agile Framework (SAFe). Conclu-

sive remarks concern one observation and one consid-

eration. The observation is about the social construc-

tion of knowledge, where knowledge is not a mere act

of intellect or rational or intelligible epistemic con-

templation. The consideration concerns design deci-

sions, rationales, or reasons for change that should be

saved as close as possible to the source code in Git.

What and how of the source code can be read in the

code. A rationale cannot be retrieved from the source

code. Separation of source code and design decisions

does not contribute to knowledge preservation.

REFERENCES

Ainsworth, S. (2006). DeFT: A Conceptual Framework for

Considering Learning With Multiple Representations.

Learning and instruction, 16(3), 183–198. https://doi.

org/10.1016/j.learninstruc.2006.03.001

Anonymous. (2017). HackerLife. hackerlife. Retrieved

September 11, 2022, from https://hackerlife.co

Bureau of Labor Statistics, U.S. Department of Labor.

(2022). Employee Tenure in 2012: The Economics

Daily: U.S. Bureau of Labor Statistics. Retrieved

September 11, 2022, from https://www.bls.gov/opub

/ted/2012/ted20120920.htm

Gonzalez, R. A., & Sol, H. G. (2012). Validation and De-

sign Science Research in Information Systems. In M.

Mora (Ed.), Research methodologies, innovations and

philosophies in software systems engineering and in-

formation systems (pp. 403–426). IGI Global.

Hasselbring, W., Carr, L., Hettrick, S., Packer, H., &

Tiropanis, T. (2020). Open source research software.

Computer, 53(8), 84–88.

Larsen, K. R., Lukyanenko, R., Mueller, R. M., Storey, V.

C., VanderMeer, D., Parsons, J., & Hovorka, D. S.

(2020). Validity in Design Science Research. In S.

Hoffman, O. M

uller, & M. Rossi (Eds.), International

Conference on Design Science Research in Informa-

tion Systems and Technology (pp. 272–282). Springer.

https://doi.org/10.1007/978-3-030-64823-725

Lee, A. S., & Hubona, G. S. (2009). A Scientiﬁc Basis for

Rigor in Information Systems Research. MIS quar-

terly, 237–262.

Marshall, C., & Rossman, G. B. (2015, January 7). Design-

ing Qualitative Research. SAGE Publications, Inc.

Standards Committee. (1998). IEEE Recommended Prac-

tice for Software Requirements Speciﬁcations (Vol.

1998). http://www.math.uaa.alaska.edu/\%7B\%

\%7D7B\%7B

∼

\%7D\%7B\%\%7D7Dafkjm/cs4

01/IEEE830.pdf

Standards Committee. (2009). IEEE Std 1016-2009 (Re-

vision of IEEE Std 1016-1998), IEEE Standard for

Information Technology–Systems Design–Software

Design Descriptions. Joint Technical Committee

ISO/IEC JTC 1. https://doi.org/10.1109/IEEEST

D.2009.5167255

Technical Committee. (2011). ISO/IEC/IEEE 42010:2011

- Systems and Software Engineering – Architecture

Description (ISO/IEC/IEEE). Joint Technical Com-

mittee ISO/IEC JTC 1. Geneva, Switzerland. https:

//www.iso.org/standard/50508.html

Theunissen, T., Hoppenbrouwers, S., & Overbeek, S.

(2021). In Continuous Software Development, Tools

Are the Message for Documentation. In J. Filipe, M.

Smialek, A. Brodsky, & S. Hammoudi (Eds.), Pro-

ceedings of the 23th International Conference on En-

terprise Information Systems. SCITEPRESS - Sci-

ence; Technology Publications. https://doi.org/10.522

0/0010367901530164

Theunissen, T., Hoppenbrouwers, S., & Overbeek, S.

(2022). Approaches for Documentation in Continu-

ous Software Development. Complex Systems Infor-

matics and Modeling Quarterly (CSIMQ), 32, 1–27.

https://doi.org/10.7250/csimq.2022-32.01

Theunissen, T., & van Heesch, U. (2016). The Disappear-

ance of Technical Speciﬁcations in Web and Mobile

Applications. In B. Tekinerdogan & U. Zdun (Eds.),

Software Architecture (pp. 265–273). Springer Inter-

national Publishing. https://doi.org/10.1007/978-3-3

19-48992-620

Theunissen, T., van Heesch, U., & Avgeriou, P. (2022).

A Mapping Study on Documentation in Continuous

Software Development. Information and Software

Technology, 142, 106733. https://doi.org/10.1016/

j.infsof.2021.106733

Wieringa, R. J. (2014). Design Science Methodology

for Information Systems and Software Engineering.

Springer Berlin Heidelberg. Retrieved January 30,

2021, from https://doi.org/10.1007/978-3-662-438

39-8

Yin, R. K. (2016). Qualitative Research from Start to

Finish (Second edition). The Guilford Press OCLC:

935783468.

Evaluation of Approaches for Documentation in Continuous Software Development

411
