Constraint-Logic Object-Oriented Programming with Free Arrays of

Reference-Typed Elements via Symbolic Aliasing

Hendrik Winkelmann

and Herbert Kuchen

Department of Information Systems, University of M

unster, Leonardo-Campus 3, M

unster, Germany

Keywords:

Constraint-Logic Object-Oriented Programming, Constraint Solving, Symbolic Execution, Symbolic Arrays.

Abstract:

Constraint-logic object-oriented programming is a young programming paradigm that aims to bring constraint-

solving techniques to an audience more accustomed to imperative programming. A prototypical language of

this paradigm, Muli, allows for the use not only of primitive-typed free variables, but also for free objects and

free arrays of primitive-typed elements. In the work at hand, we extend the current version of Muli so that it

supports free arrays of arrays and free arrays of objects. We do so by utilizing the concept of symbolic aliasing.

Our evaluation shows that the presented approach can speed up program validation and test case generation,

as well as solving complex constraint satisfaction problems.

1 INTRODUCTION

Constraint-Logic Object-Oriented Program-

ming (CLOOP) is a programming paradigm

combining the concepts of non-deterministic ex-

ecution and constraint solving, known from Prolog

(Wielemaker et al., 2012), with features known

from object-oriented programming languages.

These features comprise an imperative style of

coding with mutability, dynamic dispatch, as well

as inheritance (Dagef

orde and Kuchen, 2018;

Dagef

orde et al., 2021). Instead of purely logic

programming languages, CLOOP languages can

be deemed more accessible for programmers that

mainly use object-oriented languages and need to

solve constraint(-logic) problems as parts of their

applications. A particularly convincing example is

the use of the prototypical CLOOP language Muli

when applying these mechanisms to solve constraint

problems for generating test cases (Winkelmann

et al., 2022). One important feature of Muli is free

arrays, i.e., unbound logic variables of an array type

(Winkelmann et al., 2021). Up to now, the elements

of free arrays were restricted to primitive types. Our

main contribution in this paper is the extension of

Muli’s current runtime engine, Mulib (Winkelmann

and Kuchen, 2022), with a mechanism for symbol-

ically representing free arrays of primitive- as well

as reference-typed elements while accounting for

https://orcid.org/0000-0002-7208-7411

null values and mutability. The presented approach

is general in that not only Satisﬁability Modulo

Theories (SMT) solvers such as Z3 (De Moura and

Bjørner, 2008) but also Finite Domain (FD) solvers

such as JaCoP (Kuchcinski, 2003) can employ it.

We present use cases for free arrays in CLOOP and

furthermore evaluate the approach with regards to its

efﬁciency on several benchmark examples.

Subsequently, we ﬁrst describe the core concepts

of Muli and CLOOP, and motivate our contribution

in Section 2. In Section 3 the implementation is de-

scribed. In Section 4 we empirically compare the ap-

proach to an alternative and in Section 5, we contrast

it from related work. We end the paper by concluding

and outlining future work in Section 6. The overall

implementation is available as open source software.

2 AN OVERVIEW OF CLOOP

CLOOP is a paradigm that is based on symbolic ex-

ecution, a technique well-known in the software val-

idation and veriﬁcation community (Cadar and Sen,

2013). Hence, it has been shown that CLOOP lan-

guages are a good ﬁt for test case-generation (Winkel-

mann et al., 2022). Yet, they can also be used to rep-

resent search problems in an object-oriented manner.

https://github.com/NoItAll/mulib

412

Winkelmann, H. and Kuchen, H.

Constraint-Logic Object-Oriented Programming with Free Arrays of Reference-Typed Elements via Symbolic Aliasing.

DOI: 10.5220/0011849200003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 412-419

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

2.1 Approach of Muli

CLOOP, as implemented by Muli (Dagef

orde and

Kuchen, 2018), combines typical features of object-

oriented programming languages with features such

as non-deterministic execution and the native use of

constraints by executing code encapsulated in so-

called search regions. In these search regions, Muli

allows to use free variables, i.e., variables with a sym-

bolic value. If such a symbolic value is part of the

evaluation of, e.g., the condition of an if statement

(called if-condition in the sequel), a choice point with

two choice options is created. The ﬁrst option con-

tains a constraint, as described by the mentioned con-

dition. The other option contains the negation of the

condition. Both cases are regarded separately.

The respective constraint is pushed to a constraint

stack. An automated constraint solver, such as Z3

(De Moura and Bjørner, 2008), analyzes the satisﬁa-

bility of the constraints on the constraint stack. If the

constraints are satisﬁable, the choice option is further

evaluated, e.g., by entering the ﬁrst branch of the if

statement. The work at hand treats the improvement

of free arrays in Muli.

2.2 Motivation for Free Arrays

Free arrays (Winkelmann et al., 2021) are a feature of

Muli that allows for

1. accessing arrays with indices that are symbolic

values,

2. initializing arrays with a symbolic length, and/or

3. initializing arrays that again have symbolic en-

tries.

Free arrays in CLOOP can be used to express the

element constraint, known from constraint program-

ming, and combine it with mutability to express

search problems in an elegant manner. Consider the

following code depicting a search region in Muli:

1 public static int[] assign(

2 int[] mCaps, int[] workloads) {

3 int[] as = new int[workloads.length];

4 for (int i=0; i<workloads.length; i++) {

5 int indexOfM free;

6 int capOfM = mCaps[indexOfM];

7 if (workloads[i] > capOfM) {

8 throw Muli.fail(); }

9 mCaps[indexOfM] = capOfM-workloads[i];

10 as[i] = indexOfM; }

11 return as; }

In the search region, we look for an assignment of ma-

chines to workloads. The capacities of the machines,

mCaps, as well as the set of workloads, workloads,

are encoded as an array of integer values.

We assume that a machine ﬁnishes an assigned

workload completely and not just a fraction of it. An

assignment array, as, is initialized in line 3. Then, we

iterate over all workloads to assign them (lines 4–10).

For this, we ﬁrst spawn a free index variable (line 5)

and use it to select an entry of mCaps that we store

in capOfM (line 6). The value capOfM represents the

remaining capacity of some machine represented by

mCaps. Thereafter, we create a choice point with two

options (line 7). If the chosen machine has an insuf-

ﬁcient capacity, a special exception is thrown declar-

ing the choice option to be invalid (line 8). Thus, the

runtime evaluates the choice option with the negation

of the condition in line 7. If this constraint, in con-

junction with constraints for earlier iterations that are

already on the constraint stack, is satisﬁable, we can

assign the current workload to a machine: We store

the difference of the machine’s capacity and the cur-

rent workload in the array (line 9). This is done to

evaluate whether the chosen machine can still work

on other workloads in later iterations. Finally, we

store the index of the machine at the position of the

current workload (line 10). There are two outcomes

to this procedure. The ﬁrst outcome is that, at some

point, there is no way to make the negated if-condition

workloads[i] > capOfM satisﬁable. In this case,

there are no valid paths to reach line 11 and Muli

terminates without giving a solution to the user. The

other outcome is that we reach line 11 and return the

assignments. The solver is asked to assign a concrete

value to each of the elements in as.

This simple example demonstrates the applicabil-

ity of free arrays to a variety of scheduling and plan-

ning problems (Drexl and Kimms, 1997). The orig-

inal implementation of Muli is already able to repre-

sent such problems (Winkelmann et al., 2021). How-

ever, it is not yet possible to represent reference typed-

arrays, such as int[][] or Machine[] symbolically.

While single int values are immutable, accounting

for object identity, symbolic length, and mutability of

the array elements is non-trivial. State-of-the-art tools

areanu and Rungta, 2010; Winkelmann et al.,

2021) have left a symbolic representation for future

work. Instead, simpliﬁcations are used that can lead to

path explosion and can better be delegated to the con-

straint solver. Nevertheless, it is desirable to allow for

a symbolic treatment of such arrays: Consider, for in-

stance, an assignment problem where there are multi-

ple periods and it is allowed to preproduce workloads

of later periods. The machine capacities might then

be represented via an int[][] array where the ﬁrst

dimension is the period in which the workload is to be

worked on, while the second dimension is the capac-

ity of a machine in this period. Moreover, in the con-

Constraint-Logic Object-Oriented Programming with Free Arrays of Reference-Typed Elements via Symbolic Aliasing

413

text of object-oriented programming, it might be even

more desirable to represent machine capacities as an

array of Machines, exhibiting speciﬁc behavior using

dynamic polymorphism (Dagef

orde et al., 2021). An-

other reason is that, in the context of symbolic exe-

cution, built-in procedures for dealing with array con-

straints oftentimes are not as performant as custom-

tailored ones (Perry et al., 2017). In the following sec-

tion, we describe a solver-independent high-level ap-

proach for treating array constraints. We then extend

this approach to allow for arrays of reference types

while speciﬁcally accounting for null-values, arrays

of arrays, and arrays of other object-types. For space

reasons, we will assume arrays with a concrete length

in the subsequent elaborations.

3 APPROACH &

IMPLEMENTATION

In a Muli program, some variables and data must be

represented in a constraint solver. For instance, when

we have a constraint such as i < 0, we must create

a solver-speciﬁc representation of i, 0, and the con-

straint i < 0 to push to the constraint stack of the

solver. For primitive data types and operations, this

is rather straight-forward. In the following, we de-

scribe how we represent objects and/or their content.

We follow the Java denomination where arrays are ob-

jects and thus have an object identity. Content is used

to either describe the elements in the case of an array,

or, in the case of a non-array object, its ﬁeld values.

Note that we deliberately use the phrase representing

an object for the solver. This is because the object it-

self is not represented in some solver-speciﬁc fashion,

e.g., via algebraic data types or an array theory often-

times supported by SMT-type constraint solvers (Bar-

rett et al., 2017). Instead, we create a representation

that transforms accesses to the object to constraints,

which then are forwarded to the solver.

3.1 Representing Selects and Stores

For representing operations on an integer array a we

must support two operations: Selecting from a with

index i and storing an element e in a with index i.

Algorithm 1 depicts the devised high-level proce-

dure (compare with Perry et al. (2017)) where the

goal is to encode a select operation a[index] as a con-

straint. This constraint is then added to the constraint

stack to assure that the selected value, here passed

as Sprimitive val (line 4), is a valid element of the

respective array at index (line 3). An instance of

Sprimitive represents either a concrete primitive value

or a symbolic value. An instance of its subtype, Sint,

represents either a concrete integer value, or a sym-

bolic one (Winkelmann and Kuchen, 2022).

Algorithm 1: Simpliﬁed procedure for encoding a select

constraint.

1 select(ArrayHistory ah,

2 Constraint selectGuard,

3 Sint index,

4 Sprimitive val) : Constraint

5 List[(Sint,Sprimitive)] initial =

6 ah.getInitialState ();

7 Constraint result = true;

8 foreach (i,v) ∈ initial do

9 Constraint implication =

10 (index == i) =⇒ (val == v);

11 result = result ∧ implication;

12 List[(Constraint,Sint,Sprimitive)] stores =

13 ah.getStores ();

14 foreach (c,i,v) ∈ stores do

15 Constraint validStore =

16 (c ∧ index == i);

17 Constraint implication =

18 (validStore =⇒ (val == v));

19 result = implication

20 ∧(¬(validStore) =⇒ result);

21 return selectGuard =⇒ result;

To better understand this algorithm, consider the

following example with an integer array a:

int[] a = new int[] {4, s};

int index free;

int val0 = a[index];

We create an array a, select from it using a free index

index, and store the value in val0. This access can

effectively be encoded by the following constraint:

index ≥ 0 ∧ index < 2 ∧ (index = 0 =⇒ val0 = 4)

∧(index = 1 =⇒ val0 = s)

The constraint index ≥ 0 ∧ index < 2 is necessary

to ascertain that index is in the valid index range of

a. In the following, we abstract from this length-

constraint. This condition, together with the follow-

ing two implications, ﬁx val0 to be either 4 or s with-

out prematurely assigning a ﬁxed value to index or

val.

Effectively, this constraint is generated by execut-

ing lines 5-11 in Algorithm 1. ArrayHistory here is

a well-known representation of the respective array

(Perry et al., 2017) containing two lists. The ﬁrst list,

the one that is used in lines 5–11, contains the index-

value pairs of the array at the time it was represented

for the solver. Thus the initial set of index-value pairs

is retrieved (lines 5 and 6) and implications are cre-

ated and conjoined (lines 7–11). Each time index

equals one of the indices i, the selected value val must

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

414

equal the value v (lines 9 and 10). index has been re-

stricted to a valid range before entering Algorithm 1.

The second list, which is empty in this example,

contains triples of store statements executed for the

array. As an example for stores, again consider the

array a and the following operations performed on it:

int i0 free; int i1 free;

a[i0] = 5;

int val1 = a[i1];

In this example, we store 5 in a using the free index

i0. The subsequent select operation using the free

index i1 must take into account that some value in

a has been overwritten. To achieve this, the store

adds a triple to the aforementioned second list of

ArrayHistory. For now, we assume the ﬁrst element

of the triple as well as selectGuard to equal true. The

second and third element of the triple again form a

key-value pair. In the example, the triple (true, i0, 5)

is added to the second list of ArrayHistory. The sub-

sequent select operation a[i1] now effectively gen-

erates the following constraint:

(i0 = i1 =⇒ val1 = 5) ∧ (i0 ̸= i1 =⇒

((i1 = 0 =⇒ val1 = 4) ∧ (i1 = 1 =⇒ val1 = s)))

(i0 = i1 =⇒ val1 = 5) is an implication using the

stored index and value. The second part of this con-

straint, (i0 ̸= i1 =⇒ ...), is the constraint in the form

known from the previous scenario guarded by the

condition that the index used for selecting, i1, does

not equal the index used for storing, i0. Algorithm 1

implements the effect of the store statement in lines

12–20. We encode overwriting a value via an impli-

cation. If the antecedent of the implication (lines 15

and 16) holds, val must equal v of this store (lines 17

and 18). Otherwise, validStore must not hold, and the

non-overwritten prior key-value pairs must be consid-

ered (line 20). Finally, we return the overall constraint

(line 21).

3.2 Representing Non-Aliasing Objects

When extending the representation approach from

Subsection 3.1 to arrays of reference types and, in

general, objects, it must be considered how we rep-

resent object identity symbolically. For this, we en-

dow each object with an additional integer variable of

type Sint. These integer variables represent the iden-

tity of an object and subsequently are called (object)

identiﬁers. If an object identiﬁer equals another ob-

ject identiﬁer, these two objects are considered to be

aliases of one another.

Each object created by ’usual’ means, i.e., in Java

by using the new operator, receives a unique concrete

integer number as its identiﬁer. In consequence, no

two objects that are created in this fashion can be

aliases of one another.

We represent the elements of an array a as follows:

If a is an array with primitive-typed elements, such as

an int[], the initial elements of a are represented as a

list. Values that are stored in the array are added to the

aforementioned list of stores to account for symboli-

cally overwriting the initial values. Objects are repre-

sented via maps. The keys of the map are the names

of the object’s ﬁelds. If a ﬁeld is primitive-typed, we

directly store its value at the time of representation.

On the other hand, if the ﬁeld’s type is a reference

type, we instead store the identiﬁer of the referenced

object in it. Analogously, arrays with reference-typed

elements are represented by storing the list of identi-

ﬁers of the elements in a. Nulls are represented by the

reserved identiﬁer −1.

As an example, consider the following code snip-

pet, creating an array with reference-typed elements:

T o0 = new T();

U u = new U(); u.f2 = 42.0;

o0.f0 = 7; o0.f1 = u;

T o1 = new T();

o1.f0 = 5;

T[] a = new T[] {o0, o1};

Here, we create an array a with two elements, o0

and o1. Their ﬁelds f0 and f1 are set to suitable val-

ues. If array a were to be represented for the solver,

the following representations, here depicted in JSON,

are the outcome:

= {”id” : 0, ”es” : {” f 0” : [[7], []], ” f 1” : [[1], []]}}

Ru = {”id” : 1, ”es” : {” f 2” : [[42.0], []]}}

= {”id” : 2, ”es” : {” f 0” : [[5], []], ” f 1” : [[−1], []]}}

Ra = {”id” : 3, ”len” : 2, ”es” : [[0, 2], []]}

The representation of o0, Ro

, consists of a con-

crete identiﬁer, here 0, and its ﬁelds es. The represen-

tation for each ﬁeld consists of a pair of lists. The ﬁrst

list represents the initial value of the ﬁeld. The second

element of the pair is the aforementioned list of store

triples for when the ﬁeld is set to a new value. For

o0.f1, we store the identiﬁer of Ru, here, 1. For o1,

we proceed similary, except that o1.f1 is null, and

thus the identiﬁer −1 is stored. Finally, the represen-

tation of the array a, Ra, contains an identiﬁer, and the

length of a, len. Moreover, it contains the identiﬁers

of its represented elements in the same data structure

that is used for arrays with primitive typed-elements.

Consider Algorithm 2 in which we describe how

we can retrieve the ﬁeld value from the representation

for the solver of a non-array object. Since we only

represent a single ﬁeld value, index of Algorithm 1

is always set to 0. In turn, setting a new value adds

a new triple (guard,0, val) to the list of stores of the

array history. For array objects, each representation

only has one ArrayHistory and index is not always 0.

Constraint-Logic Object-Oriented Programming with Free Arrays of Reference-Typed Elements via Symbolic Aliasing

415

Algorithm 2: Simpliﬁed procedure for getting a ﬁeld’s

value.

1 getField(Constraint guard,

2 String ﬁeldName,

3 Sprimitive val) : Constraint

4 ArrayHistory ah =

5 this. f ields.get ( f ieldName);

6 return select (ah, guard, 0, val);

3.3 Representing Aliasing Objects

It becomes necessary to represent an object for the

constraint solver if it is

1. an array that is accessed with a free index for the

ﬁrst time,

2. contained in an object that is in the process of be-

ing represented for the solver, or if it is

3. stored into an object that is already represented for

the solver.

Such an object, or its content, is a potential target for

symbolic aliasing. In the following, we say that we

return an aliasing object where the elements of the ar-

ray are aliasing targets thereof. To account for alias-

ing, while running the program, each time the con-

tent of an aliasing object or an aliasing target is to be

accessed, instead its representation for the constraint

solver is accessed.

Aliasing objects are created either when

1. an array of reference-typed elements is selected

from with an unknown index,

2. an aliasing array of reference-typed elements is

selected from, or

3. an object is retrieved from a reference-typed ﬁeld

of a non-array aliasing object.

The identiﬁer of aliasing objects is a symbolic in-

teger. Consider an array a = {o0, o1} of type T[],

where T is a reference type. Every time a is accessed

via an unknown symbolic index i, we spawn an object,

, of type T. The identiﬁer of o

is a symbolic integer

value. The domain of o

.id is determined by selecting

from the representation of a. Effectively, the follow-

ing constraint is pushed onto the constraint stack:

((i = 0) =⇒ (o

.id = o

.id))

∧((i = 1) =⇒ (o

.id = o

.id))

In consequence, o

.id equals either o

.id or o

.id. In

other words: o

is an aliasing object and o

and o

are

aliasing targets.

Aliasing objects are immediately represented for

the solver. When representing the aliasing object, we

generate a metadata constraint. The metadata con-

straint enforces that the object can only be null if one

of its aliasing targets can be null, and, in case of an

array, that the length is equal to the length of one of

its aliasing targets. It does so by restricting the identi-

ﬁer of the aliasing object to be in the set of identiﬁers

of the aliasing targets, and implies the respective state

using the symbolic identiﬁer identiﬁer.

After setting its identiﬁer and pushing the meta-

data constraint, the aliasing object is returned to the

search region.

If an instance method is called or the content of

is accessed, it is checked if the identiﬁer o

.id can

equal −1. If this is the case, we create a choice point.

The choice options are that either a null-pointer ex-

ception is thrown or that we continue assuming that

.id ̸= −1.

itself does not have any content of its own:

Again, consider array a of type T []. Here, the se-

lected aliasing object o

is of type T . If we get a value

val from the ﬁeld o

. f , Algorithm 2 is executed on o

and o

. Additionally, we add guards based on the o

’s

symbolic identiﬁer to these calls, effectively generat-

ing the following constraint:

(Ro

.getField(o

.id = o

.id, f , val))

∧(Ro

.getField(o

.id = o

.id, f , val))

Here, Ro

and Ro

are the respective representations

of o

and o

for the constraint solver. Note that we

pass the constraint o

.id = o

.id or o

.id = o

.id to the

guard parameter of Algorithm 2. By using this guard,

and since we restricted o

.id to be in {o

.id, o

.id},

the result is a correct select constraint given that o

an alias of o

or o

. The constraint-generating proce-

dure is described in more detail in Algorithm 3. The

algorithms for selecting and storing in arrays or set-

ting a ﬁeld value for an aliasing object behave anal-

ogously. In it, we iterate over the set of representa-

tions of aliasing targets (lines 5–12). Since we access

the aliasing target’s getField-method, we must add

a guard for showing that this is a conditional select

statement (lines 7 and 10). Since this guard is used in

Algorithm 1, line 21, as the argument to selectGuard,

it is stated that val is only restricted by the content

of o

or o

, if this is an alias of the current aliasing

target a. It may even occur that the current aliasing

object is the aliasing target of another aliasing object.

Thus, we have to conjoin this guard with the guard

constraint passed via the parameter guard of Algo-

rithm 3 (line 8). Thereafter, we call getField on the

aliasing target a (lines 9–11). We conjoin the outcome

of this method call to the result (line 12). Finally, we

return the resulting constraint (line 13).

On the other hand, setting a new value for the

content of an aliasing object modiﬁes each alias-

ing target’s representation. Recall that the triple has

the form (c, i, v) where i and v are the index and value

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

416

Algorithm 3: Simpliﬁed procedure for getting an aliasing

non-array object’s ﬁeld value.

1 getField(Constraint guard,

2 String ﬁeldName,

3 Sprimitive val) : Constraint

4 Constraint result = true;

5 Set[NonArrayRep] at = this.aliasingTarget;

6 foreach a ∈ at do

7 Constraint idEq = a.id == this.id;

8 Constraint guards = idEq ∧ guard;

9 Constraint g f =

10 a.getField (guards, a. f ields,

11 f ieldName, val);

12 result = result ∧ g f ;

13 return result;

of the store statement. c is the guard statement us-

ing the identiﬁer of the aliasing object and the iden-

tiﬁer of the aliasing target. In other words, storing

a value in an aliasing object o

also is a conditional

store for an aliasing target, e.g., o

, based on the con-

straint o

.id = o

.id. The validity of a store statement

is considered in Algorithm 1 in lines 15–18, where the

added guard statement is used to evaluate whether the

store is valid for the current select call. Thus, by do-

ing so we also can reuse Algorithm 1 for representing

conditional ﬁeld updates.

4 EVALUATION

In the following, we will compare the symbolic ap-

proach described in this paper with an eager ap-

proach. The eager approach works as follows: As

soon as an array of objects, for instance an int[][],

is selected from or stored within using a symbolic

index, choice options are created. Each choice op-

tion is the choice of a concrete value for the sym-

bolic index. Internally, for each of these choice op-

tions subsequent operations are considered to be on

disjoint paths, i.e., the eager approach creates one

path for each chosen value for such array accesses.

In summary, in the eager approach we eagerly de-

cide on an index value for a given array operation

while in the symbolic approach proposed in this pa-

per, we delegate this choice to the constraint solver

using the mechanisms described in Section 3. In con-

sequence, the need to create the mentioned paths is re-

moved for such symbolic array accesses. In the past,

approaches similar to the eager approach have been

used in symbolic execution tools such as Symbolic

Pathﬁnder (P

areanu and Rungta, 2010).

For evaluating symbolic index accesses, we have

devised six scenarios of varying complexity, where

each one represents an assignment problem. We exe-

cuted all scenarios on an HP ProBook 445 G7 laptop

with an AMD Ryzen 5 4500U CPU and 16 GB of

working memory. Each scenario has been executed

20 times. We then removed the ﬁrst ﬁve measure-

ments to assure that the ﬁrst few iterations, oftentimes

exhibiting a more variable run time proﬁle, do not

skew the results. A time budget is set so that after

30 seconds no new explorations of the search region

are started.

The ﬁrst scenario, PCAP, is the initial motivational

example from Subsection 2.2 executed with 18 ma-

chines and 24 workloads. MPCAP is a scenario in

which we have two periods. There are a total of

nine machines working on 12 workloads in each of

the two periods. Machines are represented as an

int[][], where the ﬁrst dimension determines the

period in which a machine works and the second di-

mension determines the concrete machine. MCAP is

the same as PCAP, only that we now encode the ma-

chines as objects, i.e., we use Machine[] instead of

int[], where Machine has a single int-ﬁeld. Hence,

instead of int values, we retrieve Machine objects

and access their ﬁelds. This scenario serves the pur-

pose of evaluating the computational cost associated

with introducing a layer of indirection, thus making

use of symbolic aliasing (see Subsection 3.3). On

the other hand, MPMCAP analogously uses an array of

type Machine[][] instead of an int[][] argument.

MCAP-RED deﬁnes a smaller variant of MCAP with eight

machines and eleven workloads. Finally, DLSPV de-

notes a variant in which certain workloads can only be

worked on by certain machines and each machine can

only work on one single workload in a given period,

i.e., it is a simpliﬁcation of the Discrete lot-sizing

and scheduling problem (Drexl and Kimms, 1997).

This example contains nine machines and four peri-

ods, each with nine workloads. Z3 (De Moura and

Bjørner, 2008) is used as an incremental constraint

solver to evaluate the valid paths through the program.

We evaluate multiple conﬁgurations for solving

the scenarios. The results are given in Table 1. For

each conﬁguration we specify the mean time needed

to ﬁnd a ﬁrst path solution as well as the standard de-

viation in the ﬁrst row, and the mean time to extract

further paths until there are no more valid paths and

its standard deviation in the second row of a cell. The

next column shows the total number of found path so-

lutions, followed by the number of explicit fails (see

line 8 in the example of Subsection 2.2).

For the PCAP scenario, we compare the high-

level procedure described in Algorithm 1 (HL) with

an implementation using the array theory of Z3

(Solver-specific). Compared to the Z3 implemen-

tation our high-level approach is able to retrieve a ﬁrst

Constraint-Logic Object-Oriented Programming with Free Arrays of Reference-Typed Elements via Symbolic Aliasing

417

path solution and validate that there are no more paths

in the search region considerably faster. Furthermore,

the standard deviation here is lower than for the Z3

implementation. Z3 employs heuristics that result in

comparatively high, yet reproducible, differences in

the various run times, causing a high standard devia-

tion in both cases.

In the MPCAP scenario we compare our purely

symbolic approach, described in Section 3, with the

aforementioned eager approach. After retrieving an

array of type int[] from the set of machines, repre-

sented as an int[][], the arrays with primitive-typed

elements are treated with the high-level array theory.

As can be seen, for MPCAP, the eager approach times

out and does not ﬁnd any path solution. This can be

attributed to a high number of costly constraint solver

calls where the constraint stack is unsatisﬁable. In

contrast, the purely symbolic approach can solve the

problem and extract a solution in about one second.

Table 1: The mean run times and their standard deviation

for ﬁnding a ﬁrst and for enumerating all path solutions,

as well as the mean number of found path solutions and

fails for the benchmark examples. The times are given in

seconds rounded to two digits, the number of path solutions

and fails are rounded to a full number. TO denotes a time

out for all runs.

Scenario

Setting Time #PS+#Fails

PCAP

Solver

-speciﬁc

10.83 (4.22)

11.35 (4.28)

1+23

2.90 (2.00)

3.04 (2.02)

1+23

MPCAP

Eager

0+5

Symbolic

0.92 (0.21)

1.18 (0.26)

1+35

MCAP

Eager

0+266572

Symbolic

4.16 (3.97)*

4.28 (3.97)

1+23

MPMCAP

Eager

18.67 (0.07)

1+217550

Symbolic

0.43 (0.09)

0.50 (0.11)

1+32

MCAP

-RED

Eager

4.60 (0.02)

144+333752

Symbolic

0.05 (0.02)

0.06 (0.02)

1+10

DLSPV Eager

2.40 (0.01)

2.48 (0.01)

1+12082

Symbolic

0.30 (0.03)

0.36 (0.04)

1+96

The MCAP scenario was designed to evaluate the

cost of the additional identiﬁer guard constraints.

Since we use free indices for selecting from an ob-

ject, i.e., we select from Machine[], the eager ap-

proach here is forced to perform a brute-force search

and times out. Hundreds of thousands of fails were

encountered without ﬁnding a single path solution. It

must be noted that for Symbolic one of the ﬁfteen

measurements timed out. The depicted times do not

consider this time out. For the eager conﬁguration,

MPMCAP enforces a brute-force approach: When com-

paring the number of paths, one can see that the eager

approach suffers from path explosion and takes much

longer to ﬁnd its ﬁrst solution.

Finally, DLSPV shows a scenario in which there

is a reasonable number of overall paths, so that no

approach times out. The symbolic approach outper-

forms the eager approach. Compared to the eager ap-

proach, the symbolic approach has to regard far fewer

paths, as it summarizes the decision on an index.

5 RELATED WORK

The use of free arrays in CLOOP is novel with the ex-

ception of primitive free arrays using the array theory

available in some SMT solvers (Winkelmann et al.,

2021). There are, however, related subjects in the area

of constraint programming and software validation.

In the area of constraint programming, tools

(Kuchcinski, 2003) offer the element constraint. By

means of the element constraint, it can be checked

whether a certain value is located in a list in a declar-

ative manner. This resembles selecting from an ar-

ray with a free index. However, since constraint pro-

gramming is declarative, it does not directly account

for mutating objects or overwriting values in the list.

Also, Muli allows for deﬁning custom data structures

instead of using integer encodings.

Similarly, approaches like JSetL (Rossi and

Bergenti, 2015) offer non-deterministic programming

with logical variables in the form of a library, mak-

ing use of a custom API and focus on lists and sets.

For instance, to add a new choice point, the Solver-

API must be called. In contrast, Muli allows for

mutability and uses native language constructs such

as if-conditions to automatically create choice points

where a free variable is involved. Furthermore, via

the contributions of this paper, Muli enables the use

of objects of user-deﬁned classes in arrays which can

also represent set operations.

Muli can be used to generate test cases (Winkel-

mann et al., 2022). As can be seen in Section 4, us-

ing our approach for symbolic arrays can signiﬁcantly

reduce the number of encountered paths. This is in

line with research for path merging conducted, for in-

stance, by Java Ranger (Sharma et al., 2020), where,

e.g., if-then-else-constructs are summarized and

the differentiation of various paths through the pro-

gram is delegated to the constraint solver. In conse-

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

418

quence, more complex constraints are pushed to the

constraint stack, yet, fewer paths have to be evaluated

by the tool. While promising, Java Ranger does not

treat purely symbolic arrays (Sharma et al., 2020).

Our approach draws from past research on speed-

ing up array constraints (Perry et al., 2017). This

research is comparable to Algorithm 1. Our imple-

mentation differs in that we use implication opposed

to nested if-then-else statements with summarized

index ranges as the latter has reduced the performance

for our benchmark examples. Furthermore, we pro-

vide a mechanism to express symbolic aliasing, thus

enabling a purely symbolic treatment of arrays of ob-

jects for all solvers supporting negation, disjunction,

and conjunction of constraints as well as value equal-

ity.

6 CONCLUSION AND FUTURE

WORK

We have described an approach for symbolically rep-

resenting arrays of arrays and, more generally, arrays

of objects. We have shown that the approach outper-

forms related work for retrieving path solutions. In

the future, it might be interesting to compare the per-

formance of other types of constraint solvers, such

as FD solvers, with SMT solvers in the context of

CLOOP. This is possible since the presented mecha-

nisms pose very few requirements towards employed

solvers.

REFERENCES

Barrett, C., Fontaine, P., and Tinelli, C. (2017). The SMT-

LIB Standard: Version 2.6. Technical report, Depart-

ment of Computer Science, The University of Iowa.

Available at www.SMT-LIB.org.

Cadar, C. and Sen, K. (2013). Symbolic execution for soft-

ware testing: Three decades later. Commun. ACM,

56(2):82–90.

Dagef

orde, J. C. and Kuchen, H. (2018). A constraint-logic

object-oriented language. In Proceedings of the 33rd

Annual ACM Symposium on Applied Computing, SAC

’18, page 1185–1194, New York, NY, USA. Associa-

tion for Computing Machinery.

Dagef

orde, J. C., Winkelmann, H., and Kuchen, H. (2021).

Free objects in constraint-logic object-oriented pro-

gramming. In 23rd International Symposium on

Principles and Practice of Declarative Programming,

PPDP 2021, New York, NY, USA. Association for

Computing Machinery.

De Moura, L. and Bjørner, N. (2008). Z3: An efﬁcient smt

solver. In Proceedings of the Theory and Practice of

Software, 14th International Conference on Tools and

Algorithms for the Construction and Analysis of Sys-

tems, TACAS’08/ETAPS’08, page 337–340, Berlin,

Heidelberg. Springer-Verlag.

Drexl, A. and Kimms, A. (1997). Lot sizing and schedul-

ing — survey and extensions. European Journal of

Operational Research, 99(2):221–235.

Kuchcinski, K. (2003). Constraints-driven scheduling and

resource assignment. ACM Transactions on Design

Automation of Electronic Systems, 8(3):355–383.

areanu, C. S. and Rungta, N. (2010). Symbolic

pathﬁnder: Symbolic execution of java bytecode. In

Proceedings of the IEEE/ACM International Confer-

ence on Automated Software Engineering, ASE ’10,

page 179–180, New York, NY, USA. Association for

Computing Machinery.

Perry, D. M., Mattavelli, A., Zhang, X., and Cadar, C.

(2017). Accelerating array constraints in symbolic

execution. In Proceedings of the 26th ACM SIG-

SOFT International Symposium on Software Testing

and Analysis, ISSTA 2017, page 68–78, New York,

NY, USA. Association for Computing Machinery.

Rossi, G. and Bergenti, F. (2015). Nondeterministic pro-

gramming in java with jsetl. Fundamenta Informati-

cae, 140(3-4):393–412.

Sharma, V., Hussein, S., Whalen, M. W., McCamant, S.,

and Visser, W. (2020). Java ranger: Statically sum-

marizing regions for efﬁcient symbolic execution of

java. In Proceedings of the 28th ACM Joint Meeting

on European Software Engineering Conference and

Symposium on the Foundations of Software Engineer-

ing, ESEC/FSE 2020, page 123–134, New York, NY,

USA. Association for Computing Machinery.

Wielemaker, J., Schrijvers, T., Triska, M., and Lager, T.

(2012). Swi-prolog. Theory and Practice of Logic

Programming, 12(1-2):67–96.

Winkelmann, H., Dagef

orde, J. C., and Kuchen, H. (2021).

Constraint-logic object-oriented programming with

free arrays. In Hanus, M. and Sacerdoti Coen, C.,

editors, Functional and Constraint Logic Program-

ming, pages 129–144, Cham. Springer International

Publishing.

Winkelmann, H. and Kuchen, H. (2022). Constraint-logic

object-oriented programming on the java virtual ma-

chine. In Proceedings of the 37th ACM/SIGAPP

Symposium on Applied Computing, SAC ’22, page

1258–1267, New York, NY, USA. Association for

Computing Machinery.

Winkelmann, H., Troost, L., and Kuchen, H. (2022).

Constraint-logic object-oriented programming for test

case generation. In Proceedings of the 37th

ACM/SIGAPP Symposium on Applied Computing,

SAC ’22, page 1499–1508, New York, NY, USA. As-

sociation for Computing Machinery.

Constraint-Logic Object-Oriented Programming with Free Arrays of Reference-Typed Elements via Symbolic Aliasing

419
