Analyzing Software Architecture Documentation Models According to

Agile Characteristics

Leonardo Barreto and Tayana Conte

Institute of Computing, Federal University of Amazonas, Manaus, Brazil

Keywords:

Software Architecture, Agile Architecture, Architecture Documentation.

Abstract:

Background: Software companies that use agile practices and methods usually postpone architecture

design activities in favor of accelerated development and idea validation, especially in uncertain and

dynamic contexts. However, this attitude leads to the accumulation of different types of technical debt,

including architectural and documentation debt. As the company evolves, the architecture created during

development becomes complex and hard to maintain, affecting the company’s performance, the product’s

quality, and the knowledge transfer. Aim: Support the software architecture planning and documentation by

verifying the feasibility of software architecture description approaches in the context of agile development.

Method: We evaluated six approaches using the DESMET Feature Analysis method, with features related

to implementation cost, ﬂexibility, adaptation to dynamic requirements, usefulness, description consistency,

decision analysis, and system modularity. Results: Two approaches had the best scores, with a minor

percentage difference between them. These results are due to the low implementation cost of the two

approaches, the factor that most inﬂuenced the score. Conclusions: The results provide evidence about the

feasibility of applying the studied approaches, in agile contexts, besides reducing the number of possible

alternatives for conducting experimental studies in this context.

1 INTRODUCTION

The software development process has changed over

the years. Today, new software companies compete

for market share by value delivery to customers

through the launch of innovative high-tech products,

using agile methods and practices (Kuhrmann et al.,

2021). Most of these companies launch their

solution idea to the market early to collect feedback

from potential users. In this context, product

ideas and features change constantly, as well as the

requirements it must meet (Klotins et al., 2019b).

These companies spend resources and time on fast

prototype development and early product versions.

Quality-related aspects, such as architecture planning

and automated tests, have low priority due to the

dynamic and uncertain context those companies are

in (Giardino et al., 2016). They also do not consider

recording knowledge about the product so valuable

due to constant changes altering or discarding the

recorded knowledge leading to resources and time

waste (Giardino et al., 2016). Furthermore, these

companies consider documentation waste when it

does not add value to the end product and measure

the productivity as the amount of working software,

turning documentation into a counter-productive task

(Theunissen et al., 2022).

However, when the company grows and scales

its product, it seeks to attract more investment,

hire more employees, and deﬁne more organized

development processes (Klotins et al., 2019b). The

architecture developed was not optimally planned,

and its knowledge, previously restricted to the

company’s founders, needs to be maintained by

the new team members (Giardino et al., 2016).

Additionally, the high amount of tacit knowledge

makes it difﬁcult to make decisions related to

software architecture (Dasanayake et al., 2015),

and it can create discrepancies between what the

development team thinks about the system and how

it works (Klotins et al., 2018).

In this sense, this research aims to verify,

through a Feature Analysis (Kitchenham et al., 1996),

the feasibility of applying software architecture

documentation approaches in agile contexts. We

evaluated the approaches according to relevant

characteristics of software companies working in

dynamic contexts, using agile practices or methods,

Barreto, L. and Conte, T.

Analyzing Software Architecture Documentation Models According to Agile Characteristics.

DOI: 10.5220/0011852300003467

In Proceedings of the 25th International Conference on Enterprise Information Systems (ICEIS 2023) - Volume 2, pages 75-85

ISBN: 978-989-758-648-4; ISSN: 2184-4992

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

like software startups. As a contribution, this paper

provides evidence about the evaluated approaches

and narrows down the alternatives for software

architecture documentation in agile contexts.

We divided the paper as follows: Section 2

presents the relevant theoretical background for this

study; Section 3 describes the methodology; Section

4 presents the results; Sections 5 and 6 contain the

discussion about the results and the limitations of the

study, respectively, and we describe the conclusions

in Section 7.

2 BACKGROUND

2.1 Agile Software Development

The Agile Manifesto (Beck et al., 2001) guides

systems development to satisfy customers with

rapid and continuous value delivery. Dynamic

requirements are accepted and incorporated into

software development, and the progress metric is the

amount of software working. Some agile practices

are iterative and incremental development, with new

versions at short intervals and refactoring code from

previous versions (Yang et al., 2016). Additionally,

some methods aggregate these practices and help in

the organization of the development process, such

as Scrum, with sprints, to build incremental releases

into one or two-week intervals, daily meetings

for progress monitoring (Schwaber, 1997) and XP,

through pair programming, continuous integration

and refactoring and some other practices (Beck,

1999).

We can ﬁnd the agile context in many companies,

such as software startups (Klotins et al., 2021), due

to the pressure of time-to-market, the need to acquire

customers, and the uncertainty about the product’s

functionality and target audience. Pantiuchina

et al. (2017) also state that software startups apply

agile practices aimed at the speed of product

delivery, such as frequent releases and short-term

planning. However, quality-related practices, such as

refactoring and automated testing, are neglected.

2.2 Agile Software Architecture and

Documentation

ISO 42010:2022 describes software architecture as

“the set of fundamental concepts or properties of

a system, composed of its elements, relationships,

and principles of design and evolution” (International

Organization for Standardization, 2022).

Agile software architecture satisﬁes this deﬁnition

and responds better to changing requirements,

external factors, and uncertain contexts because it is

easier to modify in an iterative, incremental manner

(Waterman et al., 2015). Some strategies for creating

agile architectures are to design just what is essential

for the iteration, delay decision-making, accept an

emergent architecture, and only plan the next iteration

(Waterman et al., 2015).

Additionally, ﬁnding the balance between prior

architecture planning and emergent architecture is a

critical problem because professionals should make

important decisions early, allowing the product to

evolve and adapt (Wohlrab et al., 2019).

In this process, the system information and

architecture decisions are available. However,

companies do not value architecture documentation

practices because, in their vision, they do not

add value to the end product (Theunissen et al.,

2022). The short-term focus also forces the

team to focus on developing and maintaining the

system (Theunissen et al., 2022). Professionals

use informal communication and source code

descriptions, hindering knowledge transfer, making

it difﬁcult to understand the system, especially for

new members (Theunissen et al., 2022), and to make

decisions about the architecture (Dasanayake et al.,

2015).

Wohlrab et al. (2019) seek to solve the problems

cited above by improving the consistency and

usefulness of architecture descriptions with the

following guidelines:

• Establish purposes and audiences for the

descriptions, delimiting the levels of abstraction

and the elements present in it.

• Separate the current architecture and future

versions to facilitate the transition and the

understanding of changes’ impact.

• Document the minimum of elements of the future

architecture, with only the most relevant that

affect different parts of the company.

• Team evaluates architectural decisions before

implementation.

• Integrate architects into the different teams to

collect feedback, identify inconsistencies, and

capture emerging aspects of the architecture as the

system evolves.

3 METHODOLOGY

We performed a DESMET Feature Analysis (FA)

to verify the feasibility of software architecture

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

documentation approaches in agile contexts.

DESMET is a methodology for evaluating software

engineering methods and tools proposed by

Kitchenham et al. (1996). Examples of using

DESMET Feature Analysis to evaluate techniques

are the work of Parizi et al. (2020), in which the

authors compared the proposed tool’s features with

other related tools using DESMET, and Marshall

et al. (2014), where the authors compared, using

DESMET, four tools that support the Systematic

Review process to evaluate them. We chose this

technique due to the restriction of time and resources

for experimentation or questionnaire application on

the six approaches in one company, as recommended

by Kitchenham et al. (1996). The DESMET Feature

Analysis requires a previously deﬁned set of relevant

features for a target audience. The steps for its

realization involve candidates selection, features,

subfeatures, weights and importance levels deﬁnition

for each Feature Set, and candidates scoring using

judgment scales.

3.1 Selected Candidates for Evaluation

We selected the approaches after an exploratory

review in TOSEM, JSS, TSE, IST, and TOIS

journals, searching for articles that present software

architecture description approaches. Among the

articles found, Hofmeister et al. (2007) present

a framework for building architecture description

models derived from ﬁve description approaches:

4+1, Siemens’ 4 Views, Attribute Driven Design

(ADD), BAPO/CAFCR, and Architecture Separation

of Concerns (ASC). The ﬁrst four are present in the

Feature Analysis, and we did not include ASC due

to the absence of the original article, and it is not

possible to evaluate it.

Yang et al. (2016) present a mapping between

agile methods and software architecture. One of the

articles selected by the authors describes an approach

that met the inclusion criteria, the C3A Agile

Architecture, which we also evaluated. Finally, we

performed a grey literature search to ﬁnd approaches

not described in articles published in the journals

explored earlier. In this way, we found the C4 Model

(Brown, 2022) approach and used it for evaluation.

We listed the evaluated approaches below and further

described them in Section 4.

Siemens’ 4 Views. The approach proposed by Soni

et al. (1995) has four main views: conceptual,

module, execution, and code, describing elements,

behaviors, and technologies used in the system.

Kruchten’s 4+1. The 4+1 approach contains ﬁve

views of a system’s architecture, each related to

different aspects of the system, like its structure or

behavior. The views present are logical, process,

development, physical, and scenario (Kruchten,

1995).

BAPO/CAFCR. The BAPO/CAFCR approach has

ﬁve main views about different aspects of the system:

business, application, functional, conceptual, and

realization. It also has variations for the views, which

role is to deal with usage scenarios (America et al.,

2003).

Attribute Driven Design. The Attribute Driven

Design approach has several recursive stages, done

iteratively. The model focus on the quality attributes

relevant to the stakeholders and the architecture.

The views generated are the module, connector-

component, and allocation views. (Wojcik et al.,

2006).

C3A Agile Architecture. This approach has two

mandatory levels of abstraction for the architecture

and its separation into a reference version, which

deals with major versions of the system, and an

implementation version, which deals with future

iterations (Hadar and Silberman, 2008).

C4 Model. The C4 approach has four main views,

consisting only of boxes and lines that can represent

any element. The views are system context,

containers, components, and code. Besides these, the

author presents other complementary views, such as

the dynamic view and the development view (Brown,

2022).

3.2 Features, Weights, and Importance

Levels Deﬁnition

In DESMET, it is necessary to deﬁne each set of

features (Feature Set – FS) and their importance

weight (IW). We deﬁned and revised these weights

iteratively, seeking adequacy to the context under

study. In this study, the weights describe the relevance

of the FS for agile contexts and based on (Marshall

et al., 2014), the sum of the FS weights was equal to

1.0. Table 1 presents the FS with the description and

weights associated with each.

We derived the features and importance weights

from characteristics described in the literature about

agile software development (Paternoster et al.,

2014; Giardino et al., 2016; Klotins et al., 2019a;

Analyzing Software Architecture Documentation Models According to Agile Characteristics

Theunissen et al., 2022), agile software architecture

(Waterman et al., 2015) and consistency and

usefulness of architecture descriptions (Wohlrab

et al., 2019).

The FS related to documentation (FS1 –

= 0.15) is intended to evaluate the support for

recording knowledge about the software architecture

provided by the candidate approaches. This set

was also constructed to verify that the evaluated

approach meets the criteria for a useful and consistent

description (Wohlrab et al., 2019), in addition to

the guidelines for building an agile architecture

(Waterman et al., 2015): minimizing the number

of planned elements in the architecture (FS1-02),

the separation of audiences and purposes of the

architecture views (FS1-03), and the differentiation

between current and future instances of the

architecture (FS1-04).

FS2 (IW

= 0.05) comprises the ability to

analyze architectural decisions through the candidate

approach, which includes recording the decisions

made in artifacts and the reasoning performed

during the decision-making. This FS was chosen

to meet a criterion proposed by Wohlrab et al.

(2019), to create useful and consistent descriptions.

Additionally, agile companies postpone architectural

decision-making as long as possible, due to the

short-term focus, changing context, new objectives

and new team members (Theunissen et al., 2022).

However, the required and created knowledge for

those goals disappears over the following iterations.

Thus, facilitating analysis and decision-making in the

early stages can contribute to the product evolution,

reducing the debt that will accumulate.

FS3 (IW

= 0.10) is intended to evaluate

candidates on their ability to design modular systems.

This Feature Set was deﬁned because modular

construction of systems is a characteristic found in

agile contexts, by allowing the removal or alteration

of functionality, in a context of uncertain needs

(Paternoster et al., 2014).

The fourth Feature Set (FS4 – IW

= 0.35)

evaluates ﬂexibility and adaptability to changing

requirements, a characteristic very present in agile

contexts (Giardino et al., 2016).

Finally, FS5 (FS05 – IW

= 0.35) evaluates the

cost of applying the approaches, measured by the

number of mandatory tasks to design the architecture.

We deﬁned this Feature Set because time is one of the

most relevant resources for agile companies (Giardino

et al., 2016). Furthermore, because working software

is more important than documentation for these

companies, this task can not take too much time and

resources (Theunissen et al., 2022).

Development time and adaptation to dynamic

requirements are of great importance for agile

software companies (Giardino et al., 2016; Klotins

et al., 2019a,b). Therefore, the FS related to them

(FS4 and FS5) has an importance weight equal to

0.35, higher than the weight of the other FS. Since

modular development (FS3) is a more encountered

aspect than architectural decision-making (FS2), the

weight of FS3 (0.10) is greater than that of FS2 (0.05).

The weight of FS1 (0.15) is higher because it has

more important subfeatures, such as the presence of

few elements in the initial planning (FS1-02), ideal in

the context of dynamic requirements.

We also need to deﬁne the Importance Level

(IL) of each subfeature, inside the Feature Sets.

It contemplates the relevance of the presence of

a subfeature in the evaluated tool, for the target

audience. The ILs have a multiplier value, used

in the calculation of each candidate’s score. The

levels are 4-Mandatory, 3-Highly Desirable, 2-

Desirable, and 1-Interesting. For example, we

deﬁned the subfeature FS4-01 (“The approach must

be ﬂexible and adaptable to changing requirements

and architectural decisions.”) as mandatory, then it

has IL

FS4−01

= 4.

3.3 Candidates Evaluation

To evaluate the candidate approaches (Subfeature

judgment – SFJ

) according to the deﬁned features, it

is necessary to deﬁne judgment scales. In this study,

we used two scales: for FS1, FS2, FS3 and FS4, the

scale is:

• Yes - score 1, if the subfeature is completely met

by the approach.

• Partially - score 0.5, if the subfeature is not

completely present or is implemented differently

by the candidate.

• No - score 0, if the subfeature is not met.

For FS5, we assigned the score comparatively

among the candidates, with scores from 1 to 6. We

ordered the approaches in ascending order according

to the number of mandatory tasks. We scored 6 for

ﬁrst place, 5 for the second, and so on. In the case of

a tie, the candidates had the same evaluation. In this

way, the approach with the fewest tasks would get the

best score. When the approach does not present the

tasks, we counted the number of mandatory views,

presented by the authors of the candidate approach.

The Feature Set’s maximum score (MS

) is the

sum of the maximum values of its subfeatures. For

example, FS1 has four subfeatures. FS1-01 was rated

as Desirable (IL

FS1

= 2). FS01-02 was rated Highly

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

Table 1: Feature Sets and subfeatures evaluated in the FA.

ID Feature Set SF Description Importance Level (IL) Importance Weight (IW)

FS1 Documentation

The approach should support the registration of knowledge about the system architecture. Desirable (2)

0.15

The approach should allow the documentation of a small amount of elements in the initial planning. Highly Desirable (3)

The approach should have different descriptions of the architecture for different audiences and purposes. Interesting (1)

The approach must be able to separate current and future architectures. Interesting (1)

FS2 Decision Rationale The approach should facilitate the analysis of architectural decisions. Interesting (1) 0.05

FS3 System The approach must allow modularity of the system architecture. Desirable (2) 0.10

FS4 Requirements The approach must be ﬂexible and adaptable to changing requirements and architectural decisions. Mandatory (4) 0.35

FS5 Cost The approach should allow the architecture to be built with the least amount of mandatory tasks. Mandatory (4) 0.35

Desirable (IL

FS1

= 3). The next two subfeatures

were rated as Interesting (IL

FS1

= IL

FS1

= 1). In

this case, it will be MS

FS1

= ((2 × 1) + (3 ×1) + (1 ×

1) + (1 ×1)) = 7.

The Feature Set x score (%FS

Score

) and the overall

score (OS) of the applicants are calculated using the

equations 1 and 2.

%Score

∑

(IL

× SFJ

)

(1)

OS =

∑

(%Score

× IW

) (2)

The ﬁrst author documented a system using all

approaches, to understand their application. Then

the ﬁrst author evaluated each approach, and all the

authors discussed the scores.

4 RESULTS

In this section, we describe and justify the results of

the Feature Analysis, using the information present

in the seminal papers for each candidate approach.

They can also be found in the tables at the end of each

approach.

Siemens’ 4 Views. Siemens’ 4 Views approach

(Table 2) supports architecture documentation

(Score

FS1−01

= 1) but does not discuss how many

elements should be present in the initial architecture

planning and design (Score

FS1−02

= 0) (Soni et al.,

1995). According to the authors, different teams

(software architects, developers, operational staff,

and others) use the four views because they address

the results of decisions inﬂuenced by organizational

and technical factors (Score

FS1−03

= 1). Finally, the

approach does not provide any separation between

current and future architecture (Score

FS1−04

= 0),

it does not discuss how to document architectural

decisions (Score

FS2−01

= 0) or how to analyze a

decision-making process.

This approach allows the construction of

a modular architecture through functional

decomposition and layering. The functional

decomposition captures the system’s distribution

among modules, subsystems, and abstract units

and the relationships between components through

interfaces that can be exported and imported. The

layered layout reﬂects the design decisions based on

the import and export relationships, the constraints

created, and the reduction and isolation of internal

and external dependencies (Score

FS3−01

= 1).

The authors state that the execution view tends

to be modiﬁed the most among the others due to

the need to support software and hardware evolution

(Score

FS4−01

= 1). The approach does not describe

tasks to create the architecture descriptions. In this

case, we counted the proposed mandatory views

(four). On the scale adopted for FS5, we scored the

approach (Score

FS5−01

) as described below.

Score

FS5−01

= 5 ∴ %Score

FS5

5 ∗ 4

= 83.33%

Table 2: FA results for the Siemens 4 Views approach.

S4V

Feature

Set

FS Importance

Weight

Subfeature

Importance

Weight

(IW)

Max.

Score

(MS)

Subfeature

Judgement

(SFJ

)

Feature Set

Score

(Score

)

%Score

FS1 0.15

FS1-01 2

3.00 42.86%

FS1-02 3 0

FS1-03 1 1

FS1-04 1 0

FS2 0.05 FS2-01 1 1 0 0.00 0.00%

FS3 0.10 FS3-01 2 2 1 2.00 100.00%

FS4 0.35 FS4-01 4 4 1 4.00 100.00%

FS5 0.35 FS5-01 4 24 5 20.00 83.33%

Overall Score (OS) 80.60%

Kruchten’s 4+1. The 4+1 approach (Table 3)

supports the documentation of the system architecture

(Score

FS1−01

= 1) based on scenarios that cyclically

generate the views for small sets (Score

FS1−02

1). Then the artifacts are validated by stakeholders,

and the cycle repeats, with the scenarios not yet

addressed (Kruchten, 1995). Each view has different

purposes and audiences (Score

FS1−03

= 1): system

engineers use the Physical and Process views. End-

users, customers, and data experts use the Logic view.

Project managers and the implementation team see

the system through the Development view.

As for the separation of current and future

architecture instances, the author does not describe

Analyzing Software Architecture Documentation Models According to Agile Characteristics

any approach to this (Score

FS1−04

= 0) (Kruchten,

1995).

The scenario view combines the other views and

assists in the design validation for a given scenario.

The design guidelines document stores the relevant

decisions made, the architectural objectives, the

scenarios, and the quality attributes, among other

aspects of the system (Score

FS2−01

= 1) (Kruchten,

1995).

The 4+1 approach allows the description of

modular architectures through the development view,

which contains the modular organization of the

system (Score

FS3−01

= 1). This view organizes

subsystems into a hierarchy of layers, each providing

a well-deﬁned interface for communication with

higher layers.

The authors guide the approach’s usage iteratively

because, after the ﬁrst views, professionals know little

to validate the architecture. At each iteration, it

will be possible to insert or remove elements of the

architecture and to accommodate changes that arise

for whatever reason (Kruchten, 1995) (Score

FS4−01

1).

Finally, the approach captures the most

important functionalities in scenarios. In this

sense, the approach describes four steps to build the

architecture:

1. Deﬁne from a small set of scenarios based on their

risks and importance.

2. Create abstractions that address the scenarios

(classes, subsystems, and others).

3. Lay out the architectural elements in the four main

views.

4. Implement, test, and validate the system,

detecting ﬂaws to correct.

On the scale adopted for FS5, we scored

(Score

FS5−01

) as described below.

Score

FS5−01

= 5 ∴ %Score

FS5

5 ∗ 4

= 83.33%

Table 3: FA results for the 4+1 approach.

4+1

Feature

Set

FS Importance

Weight

Subfeature

Importance

Weight

(IW)

Max.

Score

(MS)

Subfeature

Judgement

(SFJ

)

Feature Set

Score

(Score

)

%Score

FS1 0.15

FS1-01 2

6.00 85.71%

FS1-02 3 1

FS1-03 1 1

FS1-04 1 0

FS2 0.05 FS2-01 1 1 1 1.00 100.00%

FS3 0.10 FS3-01 2 2 1 2.00 100.00%

FS4 0.35 FS4-01 4 4 1 4.00 100.00%

FS5 0.35 FS5-01 4 24 5 20.00 83.33%

Overall Score (OS) 92.02%

BAPO/CAFCR. The BAPO/CAFCR approach

(Table 4) (America et al., 2003) allows the

architecture construction (Score

FS1−01

= 1) through

ﬁve views, using only the main scenarios to build

the initial planning (Score

FS1−02

= 1). The business

view addresses the proposed value to customers,

their motivations, and their needs. The application

view describes the system’s usage scenarios through

activity ﬂows, quality requirements, and domain

models. The functional view describes the system’s

properties using, for example, a list of important

system features or a matrix that maps them to the

cost of implementing them. The conceptual view

documents the essential concepts of the system to

show the parts of the system and how they cooperate,

as well as the design patterns and principles that

govern development. Finally, the realization view

contains the technologies used to implement the

designed system aimed at the development team

(Score

FS1−03

= 1).

The approach does not distinguish between

current and future architectures (Score

FS1−04

= 0).

The ﬁve main views and their variations help

the architectural decision analysis at any point in

the architecture design (Score

FS2−01

= 1). The

conceptual view describes modular systems, with

the elements and their relationships presented in the

system decomposition (Score

FS3−01

= 1).

The variations presented deal with different

system usage scenarios, contain emerging

requirements, and represent future (or new) impacts

on the architecture. Changes in the architecture

should be treated as new scenarios and modeled as

existing scenarios (Score

FS4−01

= 1). The authors do

not deﬁne tasks to build the architecture (FS5-01). In

this case, we counted the mandatory views presented.

On this approach, there are ﬁve views (business,

application, functional, conceptual, and realization).

On the scale adopted to evaluate SF5-01, the CAFCR

approach had the Score

FS5−01

calculated as described

below.

Score

FS5−01

= 4 ∴ %Score

FS5

4 ∗ 4

= 66.67%

Table 4: FA results for the BAPO/CAFCR approach.

CAFCR

Feature

Set

FS Importance

Weight

Subfeature

Importance

Weight

(IW)

Max.

Score

(MS)

Subfeature

Judgement

(SFJ

)

Feature Set

Score

(Score

)

%Score

FS1 0.15

FS1-01 2

6.00 85.71%

FS1-02 3 1

FS1-03 1 1

FS1-04 1 0

FS2 0.05 FS2-01 1 1 1 1.00 100.00%

FS3 0.10 FS3-01 2 2 1 2.00 100.00%

FS4 0.35 FS4-01 4 4 1 4.00 100.00%

FS5 0.35 FS5-01 4 24 4 16.00 66.67%

Overall Score (OS) 86.19%

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

Attribute Driven Design. The Attribute

Driven Design (ADD) approach (Table 5)

helps in documenting the system architecture

(Score

FS1−01

= 1), focusing on quality attributes.

Score

FS1−02

= 0.5 because the stakeholders must

prioritize all requirements before the architecture

design begins. However, the authors also state that

this is hardly possible and recommend that the

architect work with the requirements he has at hand

(Wojcik et al., 2006). During the architecture design,

users create three views with different purposes

but without deﬁned audiences. Thus, SF1-03 is

partially satisﬁed and thus Score

FS1−03

= 0.5. The

module view is for documenting the static system’s

properties. The component-connector view is

concerned with the system’s execution behavior.

The allocation view maps the software elements to

the hardware components. The approach does not

have a separation of current and future architecture

(Score

FS1−04

= 0).

The approach has a step-by-step approach to

building the software architecture, and from the

fourth stage, the authors state that design decisions

start (Score

FS2−01

= 1). They involve the choice

of system design concepts, elements, allocated

resources, internal and external dependencies, and

the validation of quality attributes. ADD allows the

construction of modular systems (Score

FS3−01

= 1)

in the module view, which contains the system’s

elements. Users of ADD should address ﬂexibility

and adaptation to design changes at the end of

each task. They must analyze to verify if the

system’s architecture is according to the planned

and, if necessary, change and reﬁne the generated

architecture (Score

FS4−01

= 1).

About the cost of the ADD approach, it has eight

stages in each iteration. These are

1. The stakeholders prioritize all the requirements.

2. Conﬁrm that there is enough information to build

the architecture and rank all requirements in order

of importance for the stakeholders.

3. Choose and decompose a system element

according to the need.

4. Identify the requirements that drive the

development and rank them according to

their impact on the architecture and importance

to the stakeholders.

5. Choose a design concept that satisﬁes the

architectural drivers and evaluate and resolve

inconsistencies in the design concept.

6. Instantiate architectural elements and allocate

responsibilities in a module, component-

connector, and allocation views.

7. Exercise the functional requirements instantiated

in step VI, noting the inputs and outputs of the

elements and documenting the interface for each

element.

8. Verify and reﬁne the requirements.

Because it was the approach with the most tasks,

on the scale adopted for the SF5-01, we scored it with

the lowest value.

Score

FS5−01

= 2 ∴ %Score

FS5

2 ∗ 4

= 33.33%

Table 5: FA results for the ADD approach.

ADD

Feature

Set

FS Importance

Weight

Subfeature

Importance

Weight

(IW)

Max.

Score

(MS)

Subfeature

Judgement

(SFJ

)

Feature Set

Score

(Score

)

%Score

FS1 0.15

FS1-01 2

4.00 57.14%

FS1-02 3 0.5

FS1-03 1 0.5

FS1-04 1 0

FS2 0.05 FS2-01 1 1 1 1.00 100.00%

FS3 0.10 FS3-01 2 2 1 2.00 100.00%

FS4 0.35 FS4-01 4 4 1 4.00 100.00%

FS5 0.35 FS5-01 4 24 2 8.00 33.33%

Overall Score (OS) 70.24%

C3A Agile Architecture. The C3A (Table 6) serves

to build the architecture (Score

FS1−01

= 1) of the

system in agile contexts, with a minimum amount

of elements (Score

FS1−02

= 1). There are two

main views: the reference architecture (RA), which

shows a system’s overview, with the main modules

and their components, and the implementation

architecture (IA), describing the changes in the

architecture for new and minor versions, as well

as more details on how to develop the system.

The reference architecture contains the architecture

layers, with level 0 and level 1 elements, the

visionaries elements, and, optionally, deeper levels of

elements. Business analysts use the business layer to

record the system’s integration with external systems.

Software architects and project managers describe the

interfaces between systems and users in the functional

layer. Software architects use the system architecture

layer to comprise the system’s internal parts and

implement the functionality described in the previous

layer (Score

FS1−03

= 1). The C3A approach has

a clear separation between the current architecture

(Score

FS1−04

= 1), represented by the RA, and future

versions, projected in the IA.

The approach’s users must create a contract

for each level 0 and level 1 element to register the

architectural decisions, with relevant information to

help in the analysis of the decisions: Name, Owners,

Responsibilities, Dependencies, Implementation,

API, Data structure, Technologies, among

others (Score

FS2−01

= 1). The Reference and

Analyzing Software Architecture Documentation Models According to Agile Characteristics

Implementation architectures enable the construction

of modular systems containing the level 0 and

1 elements, called modules and components,

respectively. The system is described in its main

modules and decomposed into smaller components,

which further explain the system’s operation

(Score

FS3−01

= 1).

The approach has visionary or strategic

components representing new features or changes,

which may or may not be added to the system. Their

presence helps align the position and value of the

new features with the overall system’s architecture

and the likely impact caused. These components are

only added to the RA when they are deemed mature

by the team (Score

FS4−01

= 1).

The step-by-step described to build the

architecture has six steps (Hadar and Silberman,

2008):

1. Collect architectural documents, technical

publications, manuals, and tacit knowledge,

and capture the ﬁrst architecture in a reference

architecture, with the deﬁnition of level 0

components.

2. Validate the design created so far, detailing

the status of the modules of future reference

architectures while maintaining the current one

to prevent it from being impacted by uncertain

components.

3. For each level 0 module, deﬁne the level

1 components and implement the incremental

releases of the RAs.

4. Map or provide gap analysis between the

upcoming releases and the current architecture,

and adjust the IA without impacting the RA. If

not possible, mitigate the impact on the RA.

5. Modify minor release schedules to ﬁt the current

architecture, then execute and implement the IA.

6. Estimate the effects of the IA on the next release

of the RA, propagating the gaps found in the last

IA. If necessary, return to step I. Otherwise, return

to step IV.

In the ranking adopted to score each candidate’s

FS5-01, C3A had the Score

FS5−01

calculated as

described below.

Score

FS5−01

= 3 ∴ %Score

FS5

3 ∗ 4

= 50.00%

C4 Model. The C4 approach (Table 7) allows the

documentation of the system architecture through

four main views (Score

FS1−01

= 1). With a small

set of information, it is possible to build the context

Table 6: FA results for the C3A approach.

C3A

Feature

Set

FS Importance

Weight

Subfeature

Importance

Weight

(IW)

Max.

Score

(MS)

Subfeature

Judgement

(SFJ

)

Feature Set

Score

(Score

)

%Score

FS1 0.15

FS1-01 2

7.00 100.00%

FS1-02 3 1

FS1-03 1 1

FS1-04 1 1

FS2 0.05 FS2-01 1 1 1 1.00 100.00%

FS3 0.10 FS3-01 2 2 1 2.00 100.00%

FS4 0.35 FS4-01 4 4 1 4.00 100.00%

FS5 0.35 FS5-01 4 24 3 12.00 50.00%

Overall Score (OS) 82.50%

and container views, generating an initial summary

system’s design with the main actors and components

(Score

FS1−02

= 1).

The views have different audiences and purposes

(Score

FS1−03

= 1): the context view involves only the

system in question, the external systems, and other

actors that interact with it, used by external people

or members of the development team; the container

view contains the system’s subsystems, main parts

and the actors that interact with them, used by the

development team, operational people and software

architects; the component and code views are more

technical and describe the elements that make up the

containers, and descriptions in lines of code or UML

diagrams with the system implementation, aimed at

developers and software engineers.

The approach does not distinguish between

current architecture and future architectures

(Score

FS1−04

= 0) and does not propose any

method for analyzing architectural decisions

(Score

FS2−01

= 0).

C4 allows the construction of modular

architectures with the container view (Score

FS3−01

1), describing the modules (subsystems) of the

system, their relationships to each other, and the

actors. Similarly, users can break the containers

into smaller modules called components. The author

states that each diagram will change at different

speeds (Score

FS4−01

= 1), with the component view

changing the most as the team adds or removes these

elements.

There are no deﬁned tasks to build the

architecture. In this case, we counted the mandatory

views. The approach has four views, but the author

states that only the context and container views

are necessary and will be used in most companies

and systems Brown (2022). On the scale used to

evaluate FS5-01, C4 had the Score

FS5−01

calculated

as described below.

Score

FS5−01

= 6 ∴ %Score

FS5

6 ∗ 4

= 100%

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

Table 7: FA results for the C4 approach.

Feature

Set

FS Importance

Weight

Subfeature

Importance

Weight

(IW)

Max.

Score

(MS)

Subfeature

Judgement

(SFJ

)

Feature Set

Score

(Score

)

%Score

FS1 0.15

FS1-01 2

6.00 85.71%

FS1-02 3 1

FS1-03 1 1

FS1-04 1 0

FS2 0.05 FS2-01 1 1 0 0.00 0.00%

FS3 0.10 FS3-01 2 2 1 2.00 100.00%

FS4 0.35 FS4-01 4 4 1 4.00 100.00%

FS5 0.35 FS5-01 4 24 6 24.00 100.00%

Overall Score (OS) 92.86%

Table 8: Ranking of the evaluated approaches.

# 1st 2nd 3rd 4th 5th 6th

Approach C4 4+1 CAFCR C3A S4V ADD

Overall Score (OS) 92,86% 92,02% 86,19% 82,50% 80,60% 70,24%

5 DISCUSSIONS

Giardino et al. (2016) report that accelerated

development causes startups and small companies

that adopt agile practices to postpone planning and

quality activities. Theunissen et al. (2022) also

state that the short-term focus is an obstacle to

documenting knowledge in agile contexts because

professionals can code or maintain the system without

registering decisions, rationale, and other aspects.

In this sense, it is possible to consider an

approach that allows architecture construction and

documentation in a little information context, with

dynamic and uncertain requirements, under time-to-

market pressure as a good solution for agile software

companies.

As seen in Table 8, the best-rated approaches that

perhaps ﬁt the above deﬁnition are the C4 (OS =

92.86%) and 4+1 (OS = 92.02%) approaches, and the

percentage difference between them is insigniﬁcant.

Thus, the order between them can change through

further analysis.

Generally, most approaches allow the description

of the architecture with few elements. However, ADD

is the only approach that requires the elicitation of all

system requirements before the architecture design.

Still, the authors also state that this context is almost

unachievable (Wojcik et al., 2006).

Regarding purposes and audiences separation for

the designed visions, most approaches explain which

stakeholders beneﬁt from each view and the system

elements in each. We highlight CAFCR, C4, and 4+1

because they describe both abstract and more speciﬁc

visions.

The Commercial view (America et al., 2003) and

the Context view (Brown, 2022) aim at a general

audience, with few internal and technical elements,

describing the motivations and needs of the users,

as well as the main system’s elements and parts

that interact with it. In the 4+1 (Kruchten, 1995)

approach, the views detail different aspects of the

system that, in the scenario view, are integrated

to describe and validate how the system will meet

different system usage scenarios.

The ADD (America et al., 2003), C3A Agile

Architecture (Hadar and Silberman, 2008), and 4+1

(Kruchten, 1995) approaches stand out regarding

architectural decision analysis. The former (America

et al., 2003) proposes to validate what has been

designed, against system and stakeholder needs, in

half of the tasks required to build the architecture. The

C3A (Hadar and Silberman, 2008) suggests creating

contracts for the system elements with relevant

information from the modules and components. The

4+1 (Kruchten, 1995) also guides the creation of a

document called Design Guidelines, containing the

major decisions made.

All the evaluated approaches provide means of

building modular architectures for systems. Contracts

and diagrams describe the system’s elements with

generic boxes and arrows or in UML language.

We highlight Siemens’ 4 Views (Soni et al., 1995)

and 4+1 (Kruchten, 1995) approaches, which in

1995 already had the architecture description of

system modules. The ﬁrst approach allows this

description through functional decomposition and

layered organization, while the second approach

organizes the modules in the logical view of the

architecture.

Regarding ﬂexibility and the ability to adapt

the architecture to possible changes, all approaches

proved to be capable of being modiﬁed. The

approaches C3A (Hadar and Silberman, 2008) and

CAFCR (America et al., 2003) have similar ways

of changing the system architecture. The ﬁrst has

an implementation architecture containing visionary

components, whose function is to describe new

functionalities or changes, evaluated as to the impact

on the architecture until they reach maturity for

inclusion in the reference architecture. The CAFCR

proposes the use scenarios to store the emerging

requirements and represent future or new impacts on

the architecture.

Regarding the implementation cost, we evaluated

ADD and C3A as the most expensive. ADD has

eight main steps (Wojcik et al., 2006) and C3A (Hadar

and Silberman, 2008) have six tasks involving, for

example, collecting information about the system and

its functionalities, deﬁning the ﬁrst versions of the

architecture, detailing and combining the planned

future modules with the current version of the system.

Analyzing Software Architecture Documentation Models According to Agile Characteristics

6 LIMITATIONS

The limitations of this study are the choice of the

evaluated features, the weight deﬁnition, and each

candidate’s cost evaluation. The risk generated by

these limitations is that the weights used may not

reﬂect the true importance of the factors, and the

results cannot be generalized. To minimize this risk,

we extracted the features and weights used from the

characteristics reported in the literature by the work

performed with interviews and surveys in the context

of agile development.

Additionally, we can relate the cost of

implementing an approach to the complexity of

each task. However, its measurement may differ

depending on who performs the task. Therefore, we

only used the number of required tasks to evaluate

this aspect more objectively. Still, we could not

measure the number of mandatory tasks (FS5) of all

candidates due to the absence of this information in

the original articles. We used only the number of

mandatory views to circumvent this problem since

they are the artifacts to be generated and the task to

which the team will allocate their effort.

7 CONCLUSIONS

Although agile companies value working software

over system documentation, it can help with product

evolution and quality improvement in future releases.

In this sense, we evaluated six software architecture

documentation approaches in agile contexts through

a DESMET Feature Analysis process, deﬁning a set

of features the approaches must possess according to

the agile software development context described in

the literature.

The C4 (Brown, 2022) and 4+1 (Kruchten,

1995) approaches obtained the highest scores and

may be the best recommended for application

in agile companies. These companies can use

the C4 approach to register an initial software

architecture, including relevant actors, subsystems,

and components, evolving it in release cycle

iterations. They can also use the 4+1 approach

to document physical aspects, system behavior, use

scenarios, or code organization.

In the future, we will use these two approaches

in experimental studies with industry professionals to

collect participants’ perceptions about the approaches

and to evaluate the results presented in this paper.

We appreciate the reviewers’ suggestions and added

a study about the correlation between development

tools and agile architecture to future work plans.

ACKNOWLEDGEMENTS

We thank the ﬁnancial support granted by Research

and Development (R&D) project 001/2020, signed

with Universidade Federal do Amazonas and FAEPI,

Brazil, which has funding from Samsung, using

resources from the Informatics Law for the Western

Amazon (Federal Law No. 8.387/1991) and its

disclosure is following article 39 of Decree No.

10.521/2020. We also thank the support provided by

Universidade Federal do Amazonas (UFAM), CAPES

- Financing Code 001, CNPq process 314174/2020-

6, FAPEAM process 062.00150/2020, S

ao Paulo

Research Foundation (FAPESP) process 2020/05191-

2, and the USES research group.

REFERENCES

America, P., Rommes, E., and Obbink, H. (2003). Multi-

view variation modeling for scenario analysis. In

International Workshop on Software Product-Family

Engineering, pages 44–65. Springer.

Beck, K. (1999). Embracing change with extreme

programming. Computer, 32(10):70–77.

Beck, K., Beedle, M., van Bennekum, A., Cockburn,

A., Cunningham, W., Fowler, M., Grenning, J.,

Highsmith, J., Hunt, A., Jeffries, R., Kern, J.,

Marick, B., Martin, R. C., Mellor, S., Schwaber, K.,

Sutherland, J., and Thomas, D. (2001). Manifesto for

agile software development.

Brown, S. (2022). The C4 model for visualising software

architecture. Leanpub.

Dasanayake, S., Markkula, J., Aaramaa, S., and Oivo,

M. (2015). Software architecture decision-making

practices and challenges: an industrial case study.

In 2015 24th Australasian Software Engineering

Conference, pages 88–97. IEEE.

Giardino, C., Paternoster, N., Unterkalmsteiner, M.,

Gorschek, T., and Abrahamsson, P. (2016). Software

development in startup companies: The greenﬁeld

startup model. IEEE Transactions on Software

Engineering, 42(6):585–604.

Hadar, E. and Silberman, G. M. (2008). Agile architecture

methodology: long term strategy interleaved with

short term tactics. In Companion to the 23rd

ACM SIGPLAN Conference on Object-oriented

Programming Systems Languages and Applications,

pages 641–652.

Hofmeister, C., Kruchten, P., Nord, R. L., Obbink,

H., Ran, A., et al. (2007). A general model

of software architecture design derived from ﬁve

industrial approaches. Journal of Systems and

Software, 80(1):106–126.

International Organization for Standardization (2022).

Software, systems and enterprise – architecture

description. Standard Iso/iec/ieee 42010:2022,

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

International Organization for Standardization,

Geneva, CH.

Kitchenham, B., Linkman, S., and Law, D. (1996).

DESMET: A method for evaluating software

engineering methods and tools. Technical report,

Department of Computer Science, University of

Keele, Keele, Staffordshire, ST5 5BG, U.K.

Klotins, E., Unterkalmsteiner, M., Chatzipetrou, P.,

Gorschek, T., Prikladnicki, R., et al. (2018).

Exploration of technical debt in start-ups. In

2018 IEEE/ACM 40th International Conference on

Software Engineering: Software Engineering in

Practice Track (ICSE-SEIP), pages 75–84. IEEE.

Klotins, E., Unterkalmsteiner, M., Chatzipetrou, P.,

Gorschek, T., Prikladnicki, R., et al. (2019a). A

progression model of software engineering goals,

challenges, and practices in start-ups. IEEE

Transactions on Software Engineering.

Klotins, E., Unterkalmsteiner, M., Chatzipetrou, P.,

Gorschek, T., Prikladnicki, R., et al. (2021). Use of

agile practices in start-up companies. e-Informatica

Software Engineering Journal, 15(1).

Klotins, E., Unterkalmsteiner, M., and Gorschek, T.

(2019b). Software engineering in start-up companies:

An analysis of 88 experience reports. Empirical

Software Engineering, 24(1):68–102.

Kruchten, P. B. (1995). The 4+1 view model of architecture.

IEEE Software, 12(6):42–50.

Kuhrmann, M., Tell, P., Hebig, R., Kl

under, J., M

unch, J.,

Linssen, O., Pfahl, D., Felderer, M., Prause, C. R.,

MacDonell, S. G., et al. (2021). What makes agile

software development agile? IEEE Transactions on

Software Engineering, 48(9):3523–3539.

Marshall, C., Brereton, P., and Kitchenham, B. (2014).

Tools to support systematic reviews in software

engineering: a feature analysis. In Proceedings of

the 18th International Conference on Evaluation and

Assessment in Software Engineering, pages 1–10.

Pantiuchina, J., Mondini, M., Khanna, D., Wang, X.,

and Abrahamsson, P. (2017). Are software startups

applying agile practices? the state of the practice

from a large survey. In International Conference

on Agile Software Development, pages 167–183.

Springer, Cham.

Parizi, R., da Silva, M. M., Couto, I., Marczak, S., and

Conte, T. (2020). A design thinking techniques

recommendation tool: An initial and on-going

proposal. In Viana, D. and Schots, M., editors,

19th Brazilian Symposium on Software Quality, SBQS

2020, S

ao Lu

ıs, Brazil, December, 2020, page 36.

ACM.

Paternoster, N., Giardino, C., Unterkalmsteiner, M.,

Gorschek, T., and Abrahamsson, P. (2014). Software

development in startup companies: A systematic

mapping study. Information and Software Technology,

56(10):1200–1218.

Schwaber, K. (1997). Scrum development process. In

Business Object Design and Implementation, pages

117–134. Springer.

Soni, D., Nord, R. L., and Hofmeister, C. (1995). Software

architecture in industrial applications. In 1995 17th

International Conference on Software Engineering,

pages 196–196. IEEE.

Theunissen, T., van Heesch, U., and Avgeriou, P. (2022).

A mapping study on documentation in continuous

software development. Information and Software

Technology, 142:106733.

Waterman, M., Noble, J., and Allan, G. (2015). How much

up-front? a grounded theory of agile architecture. In

2015 IEEE/ACM 37th IEEE International Conference

on Software Engineering, volume 1, pages 347–357.

Ieee.

Wohlrab, R., Eliasson, U., Pelliccione, P., and Heldal, R.

(2019). Improving the consistency and usefulness of

architecture descriptions: Guidelines for architects.

In 2019 IEEE International Conference on Software

Architecture (ICSA), pages 151–160. IEEE.

Wojcik, R., Bachmann, F., Bass, L., Clements, P., Merson,

P., et al. (2006). Attribute-driven design (ADD),

version 2.0. Technical report, Software Engineering

Institute, Carnegie-Mellon University.

Yang, C., Liang, P., and Avgeriou, P. (2016). A

systematic mapping study on the combination of

software architecture and agile development. Journal

of Systems and Software, 111:157–184.

Analyzing Software Architecture Documentation Models According to Agile Characteristics
