Improving NLP Model Performance on Small Educational Data Sets

Using Self-Augmentation

Keith Cochran

1,2 a

, Clayton Cohn

1,2 b

and Peter Hastings

1,2 c

DePaul University, Chicago IL 60604, U.S.A.

Vanderbilt University, Nashville TN 37240, U.S.A.

Keywords:

Educational Texts, Natural Language Processing, BERT, Data Augmentation, Text Augmentation, Imbalanced

Data Sets.

Abstract:

Computer-supported education studies can perform two important roles. They can allow researchers to gather

important data about student learning processes, and they can help students learn more efﬁciently and effec-

tively by providing automatic immediate feedback on what the students have done so far. The evaluation of

student work required for both of these roles can be relatively easy in domains like math, where there are

clear right answers. When text is involved, however, automated evaluations become more difﬁcult. Natu-

ral Language Processing (NLP) can provide quick evaluations of student texts. However, traditional neural

network approaches require a large amount of data to train models with enough accuracy to be useful in ana-

lyzing student responses. Typically, educational studies collect data but often only in small amounts and with

a narrow focus on a particular topic. BERT-based neural network models have revolutionized NLP because

they are pre-trained on very large corpora, developing a robust, contextualized understanding of the language.

Then they can be “ﬁne-tuned” on a much smaller set of data for a particular task. However, these models

still need a certain base level of training data to be reasonably accurate, and that base level can exceed that

provided by educational applications, which might contain only a few dozen examples. In other areas of arti-

ﬁcial intelligence, such as computer vision, model performance on small data sets has been improved by “data

augmentation” — adding scaled and rotated versions of the original images to the training set. This has been

attempted on textual data; however, augmenting text is much more difﬁcult than simply scaling or rotating

images. The newly generated sentences may not be semantically similar to the original sentence, resulting in

an improperly trained model. In this paper, we examine a self-augmentation method that is straightforward

and shows great improvements in performance with different BERT-based models in two different languages

and on two different tasks which have small data sets. We also identify the limitations of the self-augmentation

procedure.

1 INTRODUCTION

In educational contexts, researchers study student rea-

soning and learning processes. Some of this research

is more basic, and focuses on testing hypotheses about

what inﬂuences learning in various contexts. Other

research is more applied, intending to produce inter-

active environments that can provide students with

immediate feedback based on their progress and help

make their learning more effective and efﬁcient.

Some types of student data can be easily evalu-

ated computationally with simple programs. How-

https://orcid.org/0000-0003-0227-7903

https://orcid.org/0000-0003-0856-9587

https://orcid.org/0000-0002-0183-001X

ever, when student data is textual, evaluation is more

challenging. When done by hand, it can be quite

time-consuming and subjective. This negatively af-

fects basic research, requiring the researchers to

spend more time scoring student answers and less

time testing new hypotheses. For interactive learning

environments, either classroom-based or computer-

supported, manual grading of student work would

normally be done after the students have left the

classroom, delaying feedback and resulting in missed

learning opportunities while the subject is still fresh

in the students’ minds. Real-time computational eval-

uations of texts could improve student learning oppor-

tunities and facilitate the testing of learning theories.

One avenue of text-based basic research is moti-

vated by national and international literacy standards

Cochran, K., Cohn, C. and Hastings, P.

Improving NLP Model Performance on Small Educational Data Sets Using Self-Augmentation.

DOI: 10.5220/0011857200003470

In Proceedings of the 15th International Conference on Computer Supported Education (CSEDU 2023) - Volume 1, pages 70-78

ISBN: 978-989-758-641-5; ISSN: 2184-5026

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

(Achieve, Inc, 2013; OECD, 2021), which state that

students should learn to think critically about science-

related texts. Students should be able to deeply under-

stand scientiﬁc arguments that they have read, evalu-

ate the arguments, and produce sound written sum-

maries of their own. This connects with key soci-

etal issues beyond basic literacy, including bias, “fake

news”, and civil responsibility.

Discourse psychology researchers have posited

that reading is fundamentally inﬂuenced by the goal

of the reading (Britt et al., 2017). One way of test-

ing this theory is to ask participants to read short ar-

ticles on a topic that contain varying viewpoints, then

ask them to write what they think about that topic in

different contexts. For example, they could be asked

to do the writing in a lab or at home or to write “to

friends” or as an academic submission. Researchers

could measure the extent to which the participants

personalize their writings, express opinions, and cite

sources in different settings. Differences between the

conditions can show how the participants approach

the tasks. For example, prior research has shown that

students express themselves more personally when

they’re writing in a lab at a university vs. when they’re

doing the “same task” from home. Of particular inter-

est is the extent to which students consider different

viewpoints in different contexts or whether they fo-

cus only on a subset that may agree closely with their

prior biases.

An example of a text-based interactive research

project is the SPICE curriculum for science learn-

ing curriculum (Zhang et al., 2020). Its goal is to

strengthen students’ understanding of concepts and

processes in earth sciences. In one example lesson,

students are given a diagram that ostensibly comes

from another student. They are asked to analyze the

diagram, identifying and explaining any mistakes.

The students’ responses range from a few words

to one or two sentences. Research based on analyz-

ing these responses can shed light on the students’

depth of understanding of the relevant concepts and

processes. At a deeper level, this research also shares

the goal of shedding light on students’ abilities to per-

form causal reasoning in complex situations to inform

educational advances. More immediately, automatic

computational evaluation of the student’s answers can

be used as formative feedback, helping them to im-

prove their answers and learn more in the process.

Typically, student responses in both of these con-

texts will have a certain structure or intent, which

aligns with a grading rubric and shows the extent to

which the material has been understood. The pre-

ferred answer will contain certain concepts that can

be simple in form, such as if the answer contains a

certain keyword or not, or it can be complex, such

as showing a causal reasoning chain of information

that shows the student can put together complex con-

cepts in the correct order. If the student response lacks

that particular structure, feedback from the teacher,

or a software system, could provide meaningful in-

formation on what the student is lacking so that they

can improve their analysis of the given task on their

next try. Natural Language Processing (NLP) tech-

niques such as sentence classiﬁcation show promise

in analyzing both simple and complex causal reason-

ing to help facilitate quicker feedback on student per-

formance (Hastings et al., 2014).

Traditional NLP techniques include neural net-

works that are created for a speciﬁc task, then trained

on large amounts of data in order to make the neural

model accurate enough to provide meaningful feed-

back. In the past, Recurrent Neural Networks have

been shown to be able to identify causal reasoning

chains, but they require a large amount of data to train

the model (Hughes, 2019). The model must be trained

using a certain quantity of examples of each type of

student response the grading rubric identiﬁed. This

training data is typically evaluated by a human, en-

suring the answer falls into a certain category. It is

then labeled to establish if the answer is correct or

falls into one or more sub-categories of partially cor-

rect or incorrect responses. In order for the model to

be accurate enough to be useful in analyzing student

responses, there must be a large enough quantity of

these hand-evaluated student responses to make the

model accurate enough for the given task. Unfortu-

nately, educational studies do not necessarily provide

a large amount of data to be used for NLP training —

they collect only enough data to aid the researchers in

their evaluation of the systems they are creating. Fur-

thermore, those data sets are often focused on narrow,

customized tasks so the language in them might not

correspond to general usage.

BERT-based models changed the landscape of

NLP data requirements because they come pre-trained

using very large data sets such as Wikipedia and the

BooksCorpus (Devlin et al., 2018). This gives them

robust knowledge of the words in a language and how

they are used in context. These models are then “ﬁne-

tuned” on a speciﬁc task — that is, an additional layer

is added to the network, and the weights in this layer

are trained to perform the chosen task. This ﬁne-

tuning requires some labeled training data from the

task, but a much smaller data set is required because

of the prior language “knowledge” already present in

the model due to the initial pre-training. What’s more,

pre-trained BERT-based models have been created in

many languages, allowing for a wide range of applica-

Improving NLP Model Performance on Small Educational Data Sets Using Self-Augmentation

tions. However, although the amount of data needed

for ﬁne-tuning is much less, these models still need

a certain base level quantity of hand-evaluated train-

ing data for a particular task to enable the model to

perform accurate evaluations.

A traditional method used to improve model per-

formance on insufﬁcient data in other areas of artiﬁ-

cial intelligence, such as computer vision, is to aug-

ment the data set (Shorten and Khoshgoftaar, 2019).

In this setting, data augmentation is done by scaling,

ﬂipping, or otherwise modifying the existing images,

producing similar images that can make the models

more robust. Augmentation techniques have been at-

tempted on text-based data (Chen et al., 2021). How-

ever, augmenting text data is much more difﬁcult than

simply scaling or rotating an image. When new tex-

tual data is created from existing data (i.e., student re-

sponses), the newly generated responses are not guar-

anteed to be semantically similar to the original re-

sponses.

Some current augmentation techniques make

modiﬁcations from original responses by misspelling

words that have the effect of injecting noise, or by

replacing words in the response with another similar

word (Wu et al., 2022). These techniques attempt to

create new data with a low probability of changing

semantic intent. However, the possibility still exists

that the newly generated response has been altered so

much that the label associated with it, i.e., the cate-

gory it is intended to augment, is no longer applica-

ble. Using data augmentation on text in this fashion

does not guarantee that the original sentence’s seman-

tic intent remains intact. As more aggressive forms of

data augmentation are employed, for example, using a

text generator that creates a response from keywords,

more care must be exercised to ensure that seman-

tic intent has not been signiﬁcantly altered. Seman-

tic similarity between responses can be measured to

some extent but is still an ongoing area of research

(Chandrasekaran and Mago, 2021).

In this paper, we examine a “self-augmentation”

method, similar to stratiﬁed sampling (Neyman,

1992), where items from the data set are replicated to

allow balancing of the different classes and provide

a comparison for other augmentation types (Cochran

et al., 2022). Bootstrapping (Xu et al., 2002) is an-

other technique, however, it requires human interven-

tion to ﬁll in areas where the existing data is missing,

which is not practical in our application of these tech-

niques. This technique increases the training data set

using the same data set provided for a given problem

many times. Similar techniques have been applied to

computer vision with improved model performance

(Seo et al., 2021). Examining this technique will iden-

tify levels of augmentation that are appropriate and

provide a baseline measurement that can be used for

comparison when additional augmentation techniques

are studied in the future. Performance is evaluated at

each new level of augmentation to determine if it is

improving the model or degrading it.

2 BACKGROUND AND

RESEARCH QUESTIONS

Transformer-based NLP architectures, such as BERT

(Devlin et al., 2018), and GPT-3 (Brown et al., 2020),

are now the industry standard for modeling many

NLP tasks. BERT-based models are plentiful and

have been trained using many different corpora. Some

models are trained on general corpora, and some on

speciﬁc types of texts, e.g., medical articles. Some

models have been trained on texts from a single lan-

guage, and others on multilingual corpora. When se-

lecting a model, at a minimum, one must choose a

model which includes the words from the language

of the target task. For instance, if you are evaluat-

ing French data, the original BERT model, which was

pre-trained solely on English texts, would be useless

because it has no training on the French language. So

a language-speciﬁc model or a multilingual model is

required. For the evaluations in this paper, multilin-

gual models were chosen to compare performance on

two data sets that were in different languages, French

and English. Using the same set of models removes

one variable in the comparison of the models and how

they perform with each data set.

When comparing models using different data sets,

another variable that might affect performance is the

speciﬁc data the models were pre-trained on. The data

sets in this research focus on topics in STEM- and

argumentation-related ﬁelds. However, the domain-

speciﬁc subject matter often includes esoteric jargon

not well-represented in the canonical corpora that the

large transformer models are pre-trained on. This can

reduce performance because the task-based vocabu-

laries differ considerably from the data the model was

initially pre-trained on (Cohn, 2020).

Many educational study responses by school-age

children use informal syntax and are written more col-

loquially. This makes it difﬁcult to match a BERT-

based model pre-trained with highly scientiﬁc data

with a student’s STEM topic because the model will

be typically trained on advanced texts related to that

particular topic. For this reason, we chose to use

less speciﬁc models that were more widely used for

sentence classiﬁcation as opposed to models which

were pre-trained solely on scientiﬁc texts. Using more

generic models will be less likely to have perfor-

CSEDU 2023 - 15th International Conference on Computer Supported Education

mance issues due to a mismatch between the subject

on which the students are being evaluated and the one

on which the model was pre-trained.

Data scarcity is often encountered when evaluat-

ing school essays because such studies are typically

focused narrowly on one aspect of learning or eval-

uation. This makes it difﬁcult to train neural net-

work models to accurately differentiate the intent of

the student responses. To help with this problem,

researchers performing data classiﬁcation problems

often transform the problem into a binary selection

problem (true/false, right/wrong, answer-A/answer-

B) as opposed to a multi-class problem (one involv-

ing three or more classes, e.g., answer-A/answer-

B/answer-C) which provides an increase in perfor-

mance at the cost of a more accurate conclusion. In

this study, we use data sets that have both binary and

multi-class solutions to see if augmentation levels are

affected by the type of classiﬁcation encountered.

As mentioned above, one frequent solution to mit-

igate data scarcity issues is data augmentation. Data

sets encountered in student essays are not only small

but are often imbalanced as well. Imbalanced data is

deﬁned as the situation where one class of answers

is dominant for a given question, such as the case

where most students get that particular question right

or most get it wrong. It is rare that all possible labels

corresponding to the conclusion of the evaluation are

equally represented across the data set. Often, there

may be only a few or even no cases where an example

of one answer type is given in the data. This makes

it difﬁcult to train a model to look for a speciﬁc label

if there are only a handful of examples in the data —

there is simply not enough data for the model to learn

from. To overcome the data scarcity and imbalance

issues, larger, more balanced data sets are needed to

improve model performance on the original small and

imbalanced data sets. Since such situations are fre-

quent in educational contexts, a method for augment-

ing small text-based data sets is needed to artiﬁcially

create a larger training data set from a smaller one.

Textual data augmentation methods include such

techniques as adding noise in the form of substitu-

tion or deletion of words or characters (Wei and Zou,

2019), performing “back translation” where data is

translated into another language and then translated

back to the original language, producing alternate re-

sponses based on the original response, and using

BERT’s masking feature to substitute words. But each

of these runs the risk of generating an alternate ver-

sion of the text that is different in meaning and would

therefore have a different label. In order to reduce or

remove the chances of the generated responses having

a label mismatch, self-augmentation is exclusively ex-

plored in this paper to work toward establishing a

baseline for augmentation so that more radical or ag-

gressive types of augmentation can be compared to

this baseline.

In this paper, we examine the beneﬁts of textual

self-augmentation for evaluating student responses in

two different educational contexts in two different

languages. The data sets are relatively small (less

than 100 responses per question or concept) and ex-

hibit varying degrees of imbalance. Recent research

on text augmentation found balancing the data set im-

perative when augmenting small data sets as leaving

the data set unbalanced caused instability in model

performance. (Cochran et al., 2022). Since the ulti-

mate goal is to provide appropriate, timely feedback

to students, teachers, and researchers, accurate mod-

els are required so that the feedback can be trusted.

Toward that goal, we formulate three research ques-

tions:

RQ 1. Is self-augmentation of a balanced data set

sufﬁcient to improve the classiﬁcation of student an-

swers?

Hypothesis H1 is that the technique of in-

creasing the amount of data on a balanced data set will

improve classiﬁcation accuracy by ensuring at least a

minimal number of training examples for each label

exist.

RQ 2. Does the BERT-based model variant affect per-

formance when the data sets are augmented and bal-

anced? Our hypothesis H2 is that the BERT model

used for sentence classiﬁcation will have some perfor-

mance differences, but will not signiﬁcantly change in

performance when using data augmentation.

RQ 3. Does self-augmentation have a limit where

performance drops, or does it stabilize with additional

augmentation? H3 proposes that self-augmentation

would beneﬁt the model performance at ﬁrst but then

would tend to overﬁt because it is being constantly

trained on the same information, and performance

would degrade with additional augmentation beyond

that point. Previous work has shown similar results.

3 DATA SETS

The two data sets analyzed in this paper were pro-

vided from different studies and are referred to herein

as Task 1 and Task 2. Task 1 was done as part of

the SPICE (Science Projects Integrating Computation

How good is good enough? In this paper, we are ar-

bitrarily choosing an F

score of 0.9 or above, under the

assumption that that would allow a system to provide feed-

back that is usually correct. Appropriate language can be

used to indicate some level of uncertainty in the evaluation,

e.g., “It looks like . . . ”.

Improving NLP Model Performance on Small Educational Data Sets Using Self-Augmentation

and Engineering). This data set contained responses

to three questions. These were further divided into

six different concepts because some of the questions

requested multiple answers. The data originates from

-grade students and is in English and contained 95

responses by students in the United States. The av-

erage length of the student responses was about 15

words. This research curriculum focused on rain wa-

ter runoff and measured if the student could formulate

a mental model of how runoff worked based on the re-

sponses given. Each of the six concepts for this task

has a binary label indicating if the concept was correct

or incorrect in the response. The responses to the six

concepts were imbalanced to varying degrees with the

data label quantities shown in Table 1. The majority

label quantity is shown in bold.

Table 1: Task 1 Student Response Data Split per Question.

Concept Incorrect Correct

1 10 85

2a 25 70

2b 64 31

3a 44 51

3b 73 22

3c 57 38

In Task 2, French university students were given

a social psychology article describing links between

personal aggression and the playing of violent video

games. The participants were asked to read the arti-

cle and then write a message to friends (in the “per-

sonal” condition) or colleagues (in the “academic”

condition)

which summarized the connections made

in the article. We evaluated one question of interest to

the researchers here, which is whether or not the stu-

dent’s text expressed an opinion about the presence of

a link between aggression and violent video games.

This data set contained 40 responses with an aver-

age length of about 90 words. The data label quanti-

ties are shown in Table 2. Since there was only one

question, the possible outcomes are listed with their

label, description, and quantities for each label in the

data set. The majority label quantity, which is “No

Opinion”, is shown in bold.

Table 2: Task 2 Student Response Data Split for the One

Question.

Label Deﬁnition Quantity

0 No Opinion 32

1 Link Exists 3

2 No Link Exists 2

4 Partial Link Exists 3

We do not further examine the differences between the

conditions here.

4 METHODS

4.1 Augmentation

The data sets were augmented by replicating the pro-

vided data to create an augmented data pool. Previous

studies have indicated that a balanced data set is rec-

ommended prior to data augmentation (Cochran et al.,

2022). Therefore, the data sets were ﬁrst balanced and

evaluated. In order to balance the data set, the lowest

minority label quantity was used for each label in that

particular data set. We deﬁne this as an augmentation

amount of 0x. For example, in task 1, concept 1, there

were 10 incorrect answers. To obtain the augmenta-

tion amount of 0x and maintain a balanced data set,

the correct answers were reduced to match the level

of the incorrect numbers. So, 75 of the 85 correct re-

sponses were removed so the data set only contained

10 correct and 10 incorrect student responses.

The amount of data used for augmentation above

0x was determined by measuring of the majority label

quantity in each data set, and augmenting the minority

labels enough to match the majority label. This cre-

ated a 1x level of data augmentation. In a multi-class

data set, each label that was not the majority label was

augmented to equal the quantity of the majority label.

Performance was measured as the augmentation level

was increased up to 34x by adding more data from the

augmented pool and balancing the training data set so

that all labels had equal representation.

Augmented data was only used for training, not

for testing the models. For each question or concept,

a separate BERT model was ﬁne-tuned for classiﬁ-

cation on the training data by adding a single feed-

forward layer. We used the micro-F

metric as the

performance measurement.

In all experiments, the models were trained and

evaluated 10 times, with each training iteration using

a different seed (a Fibonacci series starting at 5) for

the random number generator, which partitions the

training and testing instances. During training, the

train/test split was 80/20. Batch size, learning rate,

and other parameters were tuned to provide the best

performance for the given data set but ﬁt within the

recommendations of the original BERT ﬁne-tuning

suggestions (Devlin et al., 2018).

4.2 Models

Since these two data sets are in different languages,

a fair comparison between them was established by

using multi-lingual BERT-based models. Four multi-

lingual BERT-based models were chosen that can per-

form sentence classiﬁcation. These four models were

CSEDU 2023 - 15th International Conference on Computer Supported Education

ﬁne-tuned separately for each data set using the meth-

ods described by (Devlin et al., 2018) in order to pro-

vide a comparison of the self-augmentation method.

For Task 1, six separate models were created for each

of the 6 concepts using binary classiﬁcation: either

right or wrong. For Task 2, a single multi-class model

was trained. Since both tasks together needed seven

models, and there were four base models used in

testing, this resulted in 28 models being trained and

tested.

The BERT-based models used in this research are

all from the Hugging Face library

, and are shown

in Table 3. They were chosen because they could

perform both French and English sentence classiﬁ-

cation. Each model was pre-trained for a speciﬁc

purpose. The ambeRoad (model “A”) is trained us-

ing the Microsoft MS Marco corpus. This train-

ing data set contains approximately 400M tuples of

a query, relevant and non-relevant passages. Model

A has been used in various works (Schumann et al.,

2022; Litschko et al., 2022; Vikraman, 2022) and is

owned by amberSearch (previously ambeRoad) — a

private, German NLP enterprise. The cross-encoder

(model “C”) was pre-trained on the MMARCO cor-

pus which is a machine-translated version of MS

MARCO using Google Translate to translate it to 14

languages (Reimers and Gurevych, 2020). The Mi-

crosoft (model “M”) generalizes deep self-attention

distillation by using self-attention relation distillation

for task-agnostic compression of pre-trained Trans-

formers (Wang et al., 2020). Model M has also been

used in various works (Verma et al., 2022; Nguyen

et al., 2022). Finally, the nlptown (model “N”) is a

multilingual uncased model ﬁne-tuned for sentiment

analysis on product reviews in six languages: English,

Dutch, German, French, Spanish, and Italian. It pre-

dicts the review’s sentiment as a number of stars (be-

tween 1 and 5) and is intended for direct use as a sen-

timent analysis model for product reviews. Model N

is owned by a private enterprise, NLP town, and is

referenced in several works (S¸as¸maz and Tek, 2021;

Nugumanova et al., 2022; Casa

n et al., 2022). Models

were prioritized based on their prevalence in research

and widespread adoption on HuggingFace.

4.3 Baseline Evaluation

For each concept or question, we created two dif-

ferent baseline models without augmentation. The

a priori model simply chose the majority classiﬁca-

tion for each concept. In other words, this model is

purely statistical — there is no machine learning in-

volved. For our unaugmented baseline model, we ap-

https://huggingface.co/models

plied BERT in a prototypical way, without data aug-

mentation, but the data set was balanced in that each

label had equal representation. We performed this by

getting the count of the least represented label and re-

ducing the quantity of the other labels in the data set

to match that label, previously deﬁned as 0x augmen-

tation. This removed the possibility of data imbalance

affecting the baseline measurement.

4.4 Augmentation Approach

The self-augmentation technique is an oversampling

method using multiple copies of each instance in the

data set for augmentation. To augment the data con-

sistently, the majority label quantity in Table 4 and

Table 5 became the majority quantity of reference

for that particular data set. For example, in Table 4,

concept C1 has a majority of the answers as correct

(89%). Since responses were graded as either right or

wrong, this means there were 85 correct answers and

10 incorrect answers. Therefore, the majority quan-

tity of reference for concept C1 is 85. Augmenting

the incorrect answers so that the quantity equals 85

(adding 75 incorrect responses) balanced the data set

is referred to as 1x augmentation. We balanced each

data set in this manner by augmenting the minority la-

bel(s) to equal the quantity of the majority label for 1x

augmentation. The data sets maintained an equal bal-

ance across all possible values and were augmented

in multiples of the majority quantity using multiples

3x, 5x, 8x, 13x, 21x, and 34x.

5 RESULTS

The results from Task 1 are presented in Table 4, and

the results from Task 2 are in Table 5. Each row cor-

responds to a question or concept. The baseline re-

sults are shown in the middle columns. The maximum

micro-F

for each model along with the data augmen-

tation level where that maximum occurred is shown in

the right columns. Bolded values show the maximum

performance for each question/concept for each data

set.

Figure 1 illustrates how the level of data aug-

mentation affects performance for Task 1. Each line

shows the performance with a different model. The x-

axis shows the amount of augmentation applied from

0x to 34x. The models corresponding to the codes in

the legend are listed in Table 3. As augmentation in-

creases, there is a maximum performance achieved at

different augmentation levels which depended on not

only the concept but was also a function of the base

model used. Each of the models appeared to peak

Improving NLP Model Performance on Small Educational Data Sets Using Self-Augmentation

Table 3: BERT-based models used in this research.

Letter Designation Hugging Face Model

C cross-encoder/mmarco-mMiniLMv2-L12-H384-v1

M microsoft/Multilingual-MiniLM-L12-H384

A amberoad/bert-multilingual-passage-reranking-msmarco

N nlptown/bert-base-multilingual-uncased-sentiment

Table 4: Task 1 Performance (micro-F

) of Baseline vs All Augmented Models.

% Baseline Max Performance

Concept Correct a priori Unaug. F

Aug. Level Model

C1 89 0.940 0.563 0.837 3x N

C2a 73 0.850 0.795 0.995 13x N

C2b 33 0.670 0.658 0.921 3x N

C3a 54 0.700 0.779 0.789 3x N

C3b 23 0.770 0.784 0.968 5x N

C3c 40 0.600 0.784 0.889 13x N

early, then drop off. For Task 1, the NLPTown model

seemed to perform well across all questions and con-

cepts whereas the Microsoft model performed poorly.

Figure 1: Task 1 Model Performance as a Function of Aug-

mentation Level for All Models.

Figure 2 illustrates how the level of data augmen-

tation affects performance for Task 2. In this task,

where the student texts were considerably longer than

in Task 1, (recall that the average length of student re-

sponses was 90 words for Task 2, but only 15 words

for Task 1) the performance of most models continued

to increase or only diminished slightly with increas-

ing levels of augmentation. For Task 2, the Microsoft

model appeared to outperform all other models, and

the NLPTown model had the worst performance.

6 DISCUSSION

Recall RQ 1 which asked whether the performance

could be improved with an augmented and balanced

data set. Table 4 and Table 5 show that data aug-

Figure 2: Task 2 Model Performance as a Function of Aug-

mentation Level for All Models. The x-axis shows the

amount of augmentation applied from 0x to 34x.

mentation does improve classiﬁcation performance in

all cases except for on Task 1’s Concept C1 which

is so unbalanced that the best performer is the a pri-

ori baseline of simply guessing the student response

was always correct. All the other results show im-

provement over every model’s unaugmented base-

line. Model performance where the micro-F

score is

above 0.9 is ideal, but there are two instances where

this level of performance could not be achieved. This

indicates that self-augmentation may not be enough

to ﬁne-tune a model for all contexts, and additional

augmentation techniques will be required in order to

generalize a procedure for textual data augmentation.

H1 states that the effect of a balanced data set and

larger amounts of data improve classiﬁcation accu-

racy. Our results show that balancing and augmen-

tation improves performance. In Task 1, Concept 1,

there was such a high percentage of majority label

quantities (>90%), that guessing the majority label

every time outperformed any model used in our ex-

CSEDU 2023 - 15th International Conference on Computer Supported Education

Table 5: Task 2 Performance (micro-F

) Baseline vs All Augmented Models.

% Baseline Max Performance

Question No Opinion a priori Unaug. F

Aug. Level Model

1 80 0.850 0.309 0.994 34x M

periment. Therefore, H1 was almost completely con-

ﬁrmed. The only exception was for concept 1, where

the majority label represented over 90% of the given

responses.

RQ 2 asks if the chosen BERT model affects per-

formance when the data sets are augmented and bal-

anced. H2 predicted that the BERT model used would

not signiﬁcantly affect performance. Figures 1 and

2 reveal that performance does vary based on the

BERT model. These empirical observations show

that the N model (nlptown/bert-base-multilingual-

uncased-sentiment) performed the best for Task 1, and

the M Model (Microsoft) performed the best for Task

2. No clear winner was evident in which model to

choose because the winning model in each study was

the worst performer in the other study. Thus, H2

was not supported, which means the model chosen

for the particular task is important, and experimenting

with more than one model is imperative for a given

data set. Several factors were different across the two

tasks. The languages were different, the length of the

responses was different, and the age of the students

was different in each data set, all potentially causing

performance changes between the two tasks.

RQ 3 speculated that the level of augmenta-

tion might either drop off or stabilize model perfor-

mance. Model performance did reach a maximum,

then drop off with additional augmentation for Task

1. This shows that there is a limit to how much self-

augmentation can be applied before the model levels

off and begins to degrade in performance. This degra-

dation in performance is likely due to the over-ﬁtting

of the model as the data used to train the model is be-

ing repeated, and the model is not generalizing, but

specializing classiﬁcation outcomes that are speciﬁc

to the given data set. Task 2 had two models continue

to increase even at the highest level of augmentation

tested, but the results were approaching a micro-F

of 1.0, so additional augmentation could not possi-

bly improve performance beyond that limit. For these

results, H3 was mostly supported with the exception

of two models in Task 2 that continued to increase at

maximum augmentation.

7 CONCLUSION

Using self-augmentation to increase the data quan-

tity from student responses in two different studies,

in two different languages (French and English), then

training seven different models and measuring perfor-

mance, we found that a balanced and augmented data

set improved performance over an unaugmented data

set. Binary classiﬁcation peaked in performance with

less augmentation but degraded as the model began to

overﬁt. The highest level of augmentation for a binary

classiﬁcation task was 13x. Multi-class classiﬁcation

on the other hand was able to handle higher levels of

self-augmentation, making all models tested stabilize

and achieve high performance over the unaugmented

model. Multi-class classiﬁcation models in our exper-

iment did not degrade signiﬁcantly as we continued to

add augmentation up to 34 times the initial majority

label quantities.

8 FUTURE WORK

Since the ideal performance was not achieved by self-

augmentation alone in all cases, further analysis will

be performed using additional augmentation methods.

This might allow sentence similarity variance so the

models can tolerate additional augmentation before

overﬁtting. Our hypothesis is that this will aid the

model training so that it does not begin to degrade so

quickly, and a micro-F

performance of greater than

0.9 can be consistently achieved. More experimenta-

tion will be performed comparing binary and multi-

class classiﬁcation to see if there are general guide-

lines that can be established for both types of classiﬁ-

cation. This may also determine if augmentation lev-

els tolerated by a model are a function of the number

of classes in the data set. A comparison of language-

speciﬁc models versus multi-lingual models needs to

be performed to determine if performance is affected

by matching language type to the speciﬁc model or if

a more generic model sufﬁces.

Improving NLP Model Performance on Small Educational Data Sets Using Self-Augmentation

REFERENCES

Achieve, Inc (2013). Next Generation Science Standards.

Britt, M. A., Rouet, J. F., and Durik, A. M. (2017). Literacy

Beyond Text Comprehension: A Theory of Purposeful

Reading. Routledge, New York.

Brown, T. B., Mann, B., Ryder, N., Subbiah, M., Kaplan,

J., Dhariwal, P., Neelakantan, A., Shyam, P., Sastry,

G., Askell, A., et al. (2020). Language models are

few-shot learners. arXiv preprint arXiv:2005.14165.

Casa

n, R. R., Garc

ıa-Vidal, E., Grimaldi, D., Carrasco-

Farr

e, C., Vaquer-Estalrich, F., and Vila-Franc

es, J.

(2022). Online polarization and cross-fertilization in

multi-cleavage societies: the case of spain. Social Net-

work Analysis and Mining, 12(1):1–17.

Chandrasekaran, D. and Mago, V. (2021). Evolution of se-

mantic similarity—a survey. ACM Computing Surveys

(CSUR), 54(2):1–37.

Chen, J., Tam, D., Raffel, C., Bansal, M., and Yang,

D. (2021). An empirical survey of data augmenta-

tion for limited data learning in nlp. arXiv preprint

arXiv:2106.07499.

Cochran, K., Cohn, C., Hutchins, N., Biswas, G., and Hast-

ings, P. (2022). Improving automated evaluation of

formative assessments with text data augmentation. In

International Conference on Artiﬁcial Intelligence in

Education, pages 390–401. Springer.

Cohn, C. (2020). BERT Efﬁcacy on Scientiﬁc and Medi-

cal Datasets: A Systematic Literature Review. DePaul

University.

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2018). BERT: Pre-training of deep bidirectional

transformers for language understanding. arXiv

preprint arXiv:1810.04805.

Hastings, P., Hughes, S., Britt, A., Blaum, D., and Wal-

lace, P. (2014). Toward automatic inference of causal

structure in student essays. In International Confer-

ence on Intelligent Tutoring Systems, pages 266–271.

Springer.

Hughes, S. (2019). Automatic Inference of Causal Reason-

ing Chains from Student Essays. PhD thesis, DePaul

University, Chicago.

Litschko, R., Vuli

c, I., Ponzetto, S. P., and Glava

s, G.

(2022). On cross-lingual retrieval with multilin-

gual text encoders. Information Retrieval Journal,

25(2):149–183.

Neyman, J. (1992). On the two different aspects of the rep-

resentative method: the method of stratiﬁed sampling

and the method of purposive selection. Springer.

Nguyen, K. H., Dinh, D. C., Le, H. T.-T., and Dinh, D.

(2022). English-vietnamese cross-lingual semantic

textual similarity using sentence transformer model.

In 2022 14th International Conference on Knowledge

and Systems Engineering (KSE), pages 1–5. IEEE.

Nugumanova, A., Baiburin, Y., and Alimzhanov, Y. (2022).

Sentiment analysis of reviews in kazakh with trans-

fer learning techniques. In 2022 International Confer-

ence on Smart Information Systems and Technologies

(SIST), pages 1–6. IEEE.

OECD (2021). 21st-Century Readers. PISA, OECD

Publishing. https://www.oecd-ilibrary.org/content/

publication/a83d84cb-en.

Reimers, N. and Gurevych, I. (2020). Making monolin-

gual sentence embeddings multilingual using knowl-

edge distillation. In Proceedings of the 2020 Confer-

ence on Empirical Methods in Natural Language Pro-

cessing. Association for Computational Linguistics.

S¸as¸maz, E. and Tek, F. B. (2021). Tweet sentiment anal-

ysis for cryptocurrencies. In 2021 6th International

Conference on Computer Science and Engineering

(UBMK), pages 613–618. IEEE.

Schumann, G., Meyer, K., and Gomez, J. M. (2022). Query-

based retrieval of german regulatory documents for in-

ternal auditing purposes. In 2022 5th International

Conference on Data Science and Information Tech-

nology (DSIT), pages 01–10. IEEE.

Seo, J.-W., Jung, H.-G., and Lee, S.-W. (2021). Self-

augmentation: Generalizing deep networks to un-

seen classes for few-shot learning. Neural Networks,

138:140–149.

Shorten, C. and Khoshgoftaar, T. M. (2019). A survey on

image data augmentation for deep learning. Journal

of big data, 6(1):1–48.

Verma, A., Walbe, S., Wani, I., Wankhede, R., Thakare,

R., and Patankar, S. (2022). Sentiment analysis us-

ing transformer based pre-trained models for the hindi

language. In 2022 IEEE International Students’ Con-

ference on Electrical, Electronics and Computer Sci-

ence (SCEECS), pages 1–6. IEEE.

Vikraman, L. N. (2022). Answer similarity grouping and di-

versiﬁcation in question answering systems. Doctoral

Dissertation.

Wang, W., Wei, F., Dong, L., Bao, H., Yang, N., and Zhou,

M. (2020). Minilm: Deep self-attention distillation for

task-agnostic compression of pre-trained transform-

ers.

Wei, J. and Zou, K. (2019). EDA: Easy data augmentation

techniques for boosting performance on text classiﬁ-

cation tasks. arXiv preprint arXiv:1901.11196.

Wu, L., Xie, P., Zhou, J., Zhang, M., Ma, C., Xu, G., and

Zhang, M. (2022). Self-augmentation for named en-

tity recognition with meta reweighting. arXiv preprint

arXiv:2204.11406.

Xu, F., Kurz, D., Piskorski, J., and Schmeier, S. (2002). A

domain adaptive approach to automatic acquisition of

domain relevant terms and their relations with boot-

strapping. In LREC.

Zhang, N., Biswas, G., McElhaney, K. W., Basu, S.,

McBride, E., and Chiu, J. L. (2020). Studying the in-

teractions between science, engineering, and compu-

tational thinking in a learning-by-modeling environ-

ment. In International Conference on Artiﬁcial Intel-

ligence in Education, pages 598–609. Springer.

CSEDU 2023 - 15th International Conference on Computer Supported Education
