Detecting Outliers in CI/CD Pipeline Logs

Using Latent Dirichlet Allocation

Daniel Atzberger

1 a

, Tim Cech

2 b

, Willy Scheibel

1 c

, Rico Richter

2 d

and J

urgen D

ollner

University of Potsdam, Digital Engineering Faculty, Hasso Plattner Institute, Germany

University of Potsdam, Digital Engineering Faculty, Germany

Keywords:

Log Analysis, Anomaly Detection, Event-Streaming, Latent Dirichlet Allocation.

Abstract:

Continuous Integration and Continuous Delivery are best practices used in the context of DevOps. By using

automated pipelines for building and testing small software changes, possible risks are intended to be detected

early. Those pipelines continuously generate log events that are collected in semi-structured log ﬁles. In prac-

tice, these log ﬁles can amass 100 000 events and more. However, the relevant sections in these log ﬁles must

be manually tagged by the user. This paper presents an online learning approach for detecting relevant log

events using Latent Dirichlet Allocation. After grouping a ﬁxed number of log events in a document, our ap-

proach prunes the vocabulary to eliminate words without semantic meaning. A sequence of documents is then

described as a discrete sequence by applying Latent Dirichlet Allocation, which allows the detection of outliers

within the sequence. By integrating the latent variables of the model, our approach provides an explanation

of its prediction. Our experiments show that our approach is sensitive to the choice of its hyperparameters in

terms of the number and choice of detected anomalies.

1 INTRODUCTION

Continuous Integration (CI) is a set of best practices

in agile software development, in which developers

frequently push changes to the source code to the

project’s main branch, which is then built and tested

by an automated processing pipeline (Fitzgerald and

Stol, 2017). Continuous Delivery (CD) is built on

CI, i.e., “Continuous Delivery is a software develop-

ment discipline where you build software in such a

way that the software can be released to production at

any time”

, and therefore allows a user or customer to

interact with the software early. As a result, CD im-

proves the overall “execution efﬁciency, cross-team

communication, product-market ﬁt, agility, and orga-

nizational transparency”

through iterative feedback

loops between the users and the engineering team. In

Continuous Deployment (CDE), an extension of CD,

the builds that successfully pass the tests are auto-

https://orcid.org/0000-0002-5409-7843

https://orcid.org/0000-0001-8688-2419

https://orcid.org/0000-0002-7885-9857

https://orcid.org/0000-0001-5523-3694

martinfowler.com/bliki/ContinuousDelivery.html

atlassian.com/continuous-delivery/principles

matically deployed in an actual production environ-

ment (Shahin et al., 2017).

CI/CD pipelines rely on various coding, building,

testing, deployment, and monitoring tools. Each step

in the CI/CD pipeline provides a status message, a so-

called log event, to inform the developers about the

results of the step, e.g., whether a test was success-

ful or failed. The individual log events are collected

in a single log ﬁle in a semi-structured form during

the execution of the pipeline. In the case of com-

plex pipelines, which can take several days to exe-

cute, the log ﬁles can have a length of several 100 000

lines. In order to get relevant feedback faster, it would

be desirable to stop the pipeline execution early af-

ter the ﬁrst anomaly and detect the relevant sections

in the log ﬁle that correlate with the problematic be-

havior. Rule-based methods that search for keywords

are not applicable in our use case because the vocab-

ulary depends heavily on the team and the tools they

use. Modern approaches relying on Machine Learn-

ing achieve good results but provide no explanation to

the user, thus complicating their use in practice (Zhao

et al., 2021).

We present an unsupervised approach that detects

anomalies in individual log events. For this purpose,

Atzberger, D., Cech, T., Scheibel, W., Richter, R. and Döllner, J.

Detecting Outliers in CI/CD Pipeline Logs Using Latent Dirichlet Allocation.

DOI: 10.5220/0011858500003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 461-468

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

461

our algorithm groups a ﬁxed number of log events,

i.e., lines in the log ﬁle, into single documents and

cleans them from words with no semantic meaning,

e.g., stopwords. The corpus generated in this way is

used for training a Latent Dirichlet Allocation (LDA)

model, which results in a description of the log ﬁles

as a discrete sequence. By detecting anomalies in the

sequence, our algorithm detects suspicious entries.

It furthermore explains its result by taking the topic

word distributions into account. We showed that our

approach can detect relevant sections within large log

ﬁles through interviews with domain experts. Further-

more, we investigated the inﬂuence of the hyperpa-

rameters on the results.

Our work has the following structure: In Sec-

tion 2, we present existing approaches for detecting

anomalies in log ﬁles. In Section 3, we present de-

tails about LDA required for our approach, which is

presented in Section 4. Our conducted experiments,

their results, and threats to validity are presented in

Section 5. We conclude this work in Section 6.

2 RELATED WORK

Numerous approaches for detecting log anomalies,

i.e., relevant parts in semi-structured log ﬁles, have

been proposed (Wittkopp et al., 2022). Supervised

and unsupervised techniques have been developed,

both usually following the same four steps (Le and

Zhang, 2022): (1) log parsing, (2) log grouping,

(3) the formalization of log events by semantic vec-

tors, and (4) the application of a Deep Learning (DL)

model for detecting outliers in sequences of vectors

or discrete values. In our considerations, we present

modern supervised and unsupervised algorithms for

detecting log anomalies and ideas for explaining the

results. For a detailed survey on automated log anal-

ysis, we refer to (He et al., 2021).

Supervised Approaches. Zhang et al. proposed

a log anomaly detection algorithm that has shown

promising results in dealing with unstable log data,

i.e., changing logging statements and processing

noise (Zhang et al., 2019). Their approach LogRo-

bust derives a vector representation for a log event us-

ing pre-trained word embeddings and a subsequent tf-

idf aggregation scheme. Subsequently, log anomalies

are detected using an attention-based Bi-LSTM net-

work. Yang et al. applied a similar approach for cre-

ating a semantic vector embedding for log ﬁles (Yang

et al., 2021). Their approach PLELog further incor-

porates knowledge about historical log ﬁles that are

marked as normal to estimate the class label of a set

of historical log ﬁles. The labeled data is then used to

train an attention-based GRU neural network for de-

tecting outliers. The approach presented by Lu et al.

relies on sequences of so-called log keys, i.e., fre-

quently occurring constants in log ﬁles recognized by

a log parser, and speciﬁc vector embeddings trained

for such log keys (Lu et al., 2018). The authors devel-

oped two supervised DL methods, one relying on a

Convolutional Neural Network (CNN) and the other

on a Multi-layer Perceptron (MLP). The approach

LogBERT presented by Guo et al., also starts with a

description of logs derived from log keys (Guo et al.,

2021). Using Bidirectional Encoder Representation

from Transformers (BERT), their approach aims to

learn patterns of normal log sequences and detects

suspicious log sequences that deviate from normal

ones. Shao et al. further developed LogBERT by uti-

lizing a DL model. A comparison of different super-

vised DL approaches for log anomaly detection was

presented by Le et al. (Le and Zhang, 2022).

Unsupervised Approaches. Meng et al. proposed

LogAnomaly, an unsupervised approach for model-

ing a stream of log data, where each log event is de-

scribed using a vector space embedding derived from

Word2Vec (Meng et al., 2019). Their approach con-

sists of a DL component trained ofﬂine and an online

outlier detection algorithm. A similar concept was

proposed by Chen et al., whose approach also con-

sists of an ofﬂine training mode and an online out-

lier detection algorithm (Chen et al., 2020). Further-

more, their approach combines labels from a source

system and a target system using a transfer learning

algorithm to reduce the noise in log sequences. In

current work, Li et al. showed that the results of unsu-

pervised DL approaches can further be improved by

employing Part-of-Speech and Named Entity Recog-

nition into account (Li et al., 2022).

Explainability. In all the approaches presented so

far, the DL component was used as a black-box, i.e.,

the user cannot explain why a log snipped is marked

as an outlier. However, explaining anomalies is highly

desirable in practice (Zhao et al., 2021). Brown

et al. presented an unsupervised learning method for

anomaly detection that achieves the quality of a deep

learning model and further explains the decision-

making basis (Brown et al., 2018). Speciﬁcally, their

approach uses an Recurrent Neural Network (RNN)

based on the Long Short Term Memory (LSTM) units

to build a statistical model that learns vocabulary dis-

tribution within logs. At the same time, an attention

score is computed to indicate the presence of an out-

lier. Our method takes up the idea of explainability

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

462

LDA

Figure 1: Graphical model underlying LDA in plate nota-

tion. The shaded circles denote observed variables.

and allows the user to conclude on the level of words

within a log. To the best of our knowledge, we are the

ﬁrst to present a log anomaly detection algorithm that

provides explainability in this detail.

3 LATENT DIRICHLET

ALLOCATION

LDA is a probabilistic topic model proposed by Blei

et al., which is often used for capturing the seman-

tic structure within a collection of documents, a so-

called corpus (Blei et al., 2003). Given a corpus C ,

i.e., a set of documents {d

,...,d

} that share a vo-

cabulary V = {w

,...,w

}, LDA extracts semantic

clusters in its vocabulary, so-called topics φ

,...φ

as multinomial distributions over the vocabulary V .

Additionally, each document is described as a mix-

ture of the extracted topics, describing its semantic

composition. Given the number of topics K speci-

ﬁed as a hyperparameter together with Dirichlet pri-

ors α = (α

,...,α

), where α

> 0 for all 1 ≤ i ≤ K

and β = (β

,...,β

), where β

> 0 for all 1 ≤ j ≤ N

that capture the document-topic-distributions and the

topic-term-distribution respectively, LDA deﬁnes a

fully generative model for the creation of a corpus.

The plate notation of the generative process is shown

in Figure 1. The generative process operates as fol-

lows:

1. For each document d

, 1 ≤ i ≤ m, choose a distri-

bution over topics θ

∼ Dirichlet(α)

2. For each word w

, 1 ≤ j ≤ N, in d

, 1 ≤ i ≤ m,

(a) Choose a topic z

∼ Multinomial(θ

)

(b) Choose the word w

according to the probabil-

ity p(w

,β)

During the training phase LDA infers the top-

ics φ

,...,φ

and the document-topic-distributions

,...,θ

for the given corpus. As exact inference

is intractable, approximation techniques must be ap-

plied, e.g., Variational Bayes (Blei et al., 2003), its

online version (Hoffman et al., 2010), or (collapsed)

Gibbs Sampling (Grifﬁths and Steyvers, 2004). A sur-

vey of different approaches for utilizing LDA for min-

ing software repositories can be found in (Chen et al.,

2016).

4 APPROACH

Our approach aims to detect relevant sections within a

log ﬁle by utilizing LDA for describing a log ﬁle as a

discrete sequence. Log anomalies are detected using

an outlier detection algorithm by associating relevant

log sections with conspicuous subsequences. Further-

more, our approach supports the user in explaining

the results by viewing the latent variables of the LDA

model. Figure 2 shows the concept of our approach.

4.1 Corpus Creation

Log events are preprocessed immediately after they

are created to remove words that do not carry seman-

tic meaning. For this purpose, the following steps are

performed:

1. Removal of general log-data speciﬁc phrases, e.g.,

ERROR

ON WARNING,

2. Removal of symbols, e.g., parentheses, time

stamps, ﬁle paths, and number literals,

3. Lower-casing all words,

4. Removal of stop words, and

5. Lemmatization of the vocabulary to reduce the

size of the vocabulary.

A ﬁxed number of preprocessed log events are merged

into a document and stored in the Bag of Words

(BOW) form. The documents generated in this way

form the corpus for subsequent analysis by LDA.

During the execution of the pipeline, the corpus is per-

manently extended by new documents.

4.2 Sequence Modelling

Since not the entire corpus is available at the begin-

ning, we apply the online version of Variational Bayes

for training the LDA model. As a result, each docu-

ment is described by a K-dimensional vector whose

components represent the expression in the respec-

tive topic. By choosing a symmetric Dirichlet prior α

with α

,...,α

/K, the inference algorithm favors

topic distributions with strong expressions in a few

topics. We, therefore, identify each document with

the number 1, . ..,K of its dominant topic as proposed

by Panichela et al. (Panichella et al., 2013). This way,

Detecting Outliers in CI/CD Pipeline Logs Using Latent Dirichlet Allocation

463

CI / CD

Pipeline

LogEv

1 1 2 1

4 5 8 1

1 1 3 3

. . .

Developer

Topic #1 Topic #2 . . .

. . . . . . . . .

. . . . . .

Window

Creation

Sequence Modeling

using LDA

Outlier

Detection

Annotations

Root-Cause Analysis

Improve Development or Deployment

Figure 2: Process Overview of our approach. The log events from a CI/CD pipeline are pruned and grouped into documents.

A discrete sequence is generated using LDA, and outliers are detected. The resulting topics and the topic-term assignments in

the conspicuous document are presented to the developer.

we obtain a discrete sequence with values in 1,...,K,

created during the pipeline execution.

Our implementation is based on the gensim li-

brary

, which is actively maintained and widely used

in the industry. We further apply the NLTK

for pre-

processing the data.

4.3 Outlier Detection

A discrete sequence S is an ordered list (s

,...,s

)

of elements from a ﬁnite set. Different deﬁnitions

for anomalies in the context of discrete sequences ex-

ist (Chandola et al., 2012):

1. An entire sequence S = (s

,...,s

) is anomalous

if it is signiﬁcantly different from a set of other

sequences.

2. A subsequence S

= (s

,...,s

i+k−1

) within the se-

quence S is anomalous if it is signiﬁcantly dif-

ferent from the other subsequences within S of

length k. Here the window size k is a hyperpa-

rameter of the model and needs to be set by the

user.

3. An element s

, 1 ≤ i ≤ N, within S is anomalous

if it signiﬁcantly differs from an element expected

at position i.

Our application scenario relates to the second case.

The ﬁrst case is not applicable in our scenario as our

https://radimrehurek.com/gensim/

https://www.nltk.org/

approach is intended to detect anomalies as they occur

and not after the entire pipeline has ﬁnished. The third

deﬁnition does not consider the sequence structure,

which has shown relevant information during our ex-

periments.

Numerous online outlier detection algorithms for

subsequences were proposed (Chandola et al., 2012).

They all involve the same two steps: (1) the calcu-

lation of an anomaly score for the respective subse-

quence and (2) the comparison of the anomaly score

with a speciﬁed threshold λ. The subsequence is

marked as an outlier if the anomaly score exceeds

the threshold. To ensure the explainability of our ap-

proach, we decided to use a trivial anomaly score.

The inverse frequency of the subsequence in the set of

previous subsequences gives our anomaly score. By

choosing the threshold 0.5 < λ < 1, a subsequence is

marked as an outlier if and only if it occurs for the ﬁrst

time. In our experiments, we always look at windows

comprising four documents. To avoid too many out-

liers at the beginning of a new run, we assume a min-

imum number of 1,000 documents before ﬁrst com-

paring the anomaly score with the threshold.

4.4 Explaining Results

After the detection of an outlier, the corresponding

log sections, i.e., the k elements of the subsequence,

are displayed to the user to derive the root cause for a

conspicuous pipeline. Thereby, the reason behind this

needs to be explained to the user by two additional

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

464

Table 1: Three extracted topics from our dataset. For each

topic, the ten most probable terms are displayed.

Topic #1 Topic #2 Topic #3

state data external

change directory storage

stage local label

warning input cache

event class load

equal search click

mask missing path

road member warn

result interface error

archive dependency result

outputs.

On the one hand, the underlying concept can usu-

ally be derived from the most probable words of a

topic. Table 1 shows the top 10 words of three exem-

plary topics extracted from the dataset used in our ex-

periments. The ﬁrst topic concerns the abstract topic

Status Reporting, the second Data Inclusion, and the

third one Removed External Storage. A topic’s inter-

pretability can be further increased using a weighting

function (Sievert and Shirley, 2014).

The generative process underlying LDA makes it

clear that each word is derived from precisely one

topic. The latent variable z describes this assignment.

Our method marks all words derived from the domi-

nant topic in the given section to assist users further.

5 EVALUATION

Our dataset comprises log events originating from two

CI/CD pipelines. The dataset from project one con-

sists of approximately 3.6 million log events, and the

dataset from project two consists of approximately

9.9 million. Usually, anomaly detection methods are

evaluated on labeled log ﬁles. In our case, such data

was unavailable; only individual examples could be

discussed with domain experts. Therefore, we fo-

cus our considerations on two questions that inves-

tigate the inﬂuence of the two hyperparameters of the

method, i.e., the number of topics K and the number

s of log events grouped in one document.

5.1 Impact of the Hyperparameters on

the Number of Anomalies

Our ﬁrst experiment investigates the inﬂuence of the

choice of K and s on the number of anomalies de-

tected. For this purpose, we record the propor-

tion of documents marked as anomalies in the to-

tal number of documents for each combination of

0 100 200 300 400

0.5%

1.5%

Occurences

Probability

Project One

Figure 3: Results of our second experiment on the ﬁrst

project.

s,K ∈ {10, 20, 30, 40, 50, 60, 70, 80, 90, 100}. We re-

fer to this metric as η in the following. The results for

project one are shown in Table 2, and the results for

project two are shown in Table 3.

Both projects show that when the parameter s is

ﬁxed, the metric η tends to grow with increasing K,

especially for small values of s. This observation can

be explained by the fact that the logs are described

as a discrete sequence with values in {1,...,K}, and

as K grows, there are more possibilities for different

subsequences.

With ﬁxed topic number K, the metric η tends

to increase with increasing window size s, but not

strictly monotonically. For example, η reaches its

maximum at K = 70 in the ﬁrst project at s = 70. Both

projects also show that η seems to reach its maximum

in the investigated parameter range. It is striking that

η runs through a signiﬁcantly larger range of values

in project one than in project two, which leads to the

assumption that η shows a strong dependence on the

data set in addition to the hyperparameters.

5.2 Impact of the Hyperparameters on

the Detected Anomalies

Our second experiment investigates whether differ-

ent parameter conﬁgurations also lead to different de-

tected anomalies. For this purpose, we count for each

log event of both projects the frequency of how of-

ten it was marked as an outlier. With 100 possible

combinations for s and K and a ﬁxed subsequence

length of 4, a log event can be maximally marked as

an anomaly 400 times. From the count, we then derive

for 1 ≤ l ≤ 400 how many log events were marked as

outliers exactly l times. The normalized frequencies

are shown in Figure 3 and Figure 4.

Detecting Outliers in CI/CD Pipeline Logs Using Latent Dirichlet Allocation

465

Table 2: Results for the ﬁrst project in the ﬁrst experiment.

10 20 30 40 50 60 70 80 90 100

10 1.0 3.2 4.4 5.9 6.2 7.3 8.8 8.6 8.7 9.8

10%

15%

20%

25%

20 1.7 4.2 8.1 8.0 9.8 10.1 12.9 13.8 15.5 13.2

30 1.7 6.1 9.0 11.5 12.4 17.6 15.4 14.5 18.0 16.2

40 2.0 7.6 10.8 14.0 14.6 16.1 15.2 16.6 18.2 18.7

50 3.7 8.3 11.1 13.1 14.3 18.7 20.6 16.9 20.0 19.7

60 2.4 9.4 11.5 16.7 17.2 19.6 19.7 19.7 20.8 19.9

70 3.2 9.9 12.3 18.2 18.7 18.8 25.2 21.4 23.3 23.5

80 3.9 11.6 14.1 18.8 19.4 18.9 19.4 22.3 24.4 21.3

90 4.3 9.2 15.5 17.1 18.1 19.9 21.7 19.4 21.7 21.7

100 4.3 11.2 14.7 18.2 17.8 20.3 20.6 22.5 23.6 23.9

Table 3: Results for the second project in the ﬁrst experiment.

10 20 30 40 50 60 70 80 90 100

10 0.2 0.8 1.6 1.9 2.0 2.3 2.2 2.6 2.2 2.7

20 0.3 1.1 1.8 2.4 2.5 2.9 2.6 3.4 3.0 3.5

30 0.6 1.0 1.8 2.8 2.4 3.2 3.1 3.1 3.0 3.2

40 0.6 1.9 1.9 3.1 3.3 3.4 3.2 4.0 3.4 4.4

50 0.6 1.8 2.6 2.9 3.5 3.6 4.0 3.4 4.4 4.6

60 0.8 1.8 3.0 3.5 3.1 3.8 4.9 3.9 4.5 5.3

70 0.7 1.9 2.5 3.6 3.5 4.0 4.2 4.5 4.3 5.2

80 0.9 2.1 3.0 3.6 4.0 4.1 4.4 4.6 4.9 5.5

90 1.1 2.0 3.4 3.6 4.4 4.4 4.9 5.0 5.3 5.7

100 0.8 2.2 3.0 3.5 4.4 4.9 5.3 5.1 5.6 5.4

In both projects, the observation that lower occur-

rences are associated with higher probabilities holds.

In both projects, the maximum probability occurs at

l = 1 with 2,1% in project one and 13,2 % in project

two. Overall, different parameter conﬁgurations thus

lead to enormously different results. However, this

fact also depends strongly on the dataset. The maxi-

mum value of l is 362 in project one and 353 in project

two.

5.3 Threats to Validity

The main threat to internal validity lies in the imple-

mentation of our approach. Our LDA model relies

on the implementation provided by gensim, and it is

still being determined to what extent different infer-

ence algorithms would affect the results. Previous

experiments for bug triaging tasks have shown that

the chosen LDA implementation and its hyperparam-

eters can signiﬁcantly impact the results (Atzberger

et al., 2022). The main threat to generalization is

that we reported our observations only from the con-

ducted experiments on two datasets. However, it can

already be seen from the two experiments that the re-

sults strongly depend on the respective characteris-

tics of the data sets. Furthermore, it can be discussed

whether the assumption that anomalies in discrete se-

quences accompany relevant sections is justiﬁed. For

example, if only a few words occur within a docu-

ment, they will have little inﬂuence on the dominant

topic and, therefore will not be considered in the out-

lier detection.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

466

0 100 200 300 400

10%

Occurences

Probability

Project Two

Figure 4: Results of our second experiment on the second

project.

6 CONCLUSIONS AND FUTURE

WORK

The localization of anomalies in large log ﬁles is a

question that developers often confront. However,

this is enormously time-consuming and hardly pos-

sible with high volumes. Furthermore, an entire

pipeline run can take several hours to days, so it would

be desirable to detect relevant locations early on. Our

work presents an approach for the processing and

modeling of log events by LDA. Our approach de-

tects anomalies in the resulting discrete sequence and

localizes relevant log events. In addition, our method

provides explanations through the topics and topic-

word mappings, thereby concretely supporting the de-

veloper in root-cause analysis. The approach does

not require domain knowledge about the individual

speciﬁcs of the conﬁgurations of the pipelines. This is

essential because pipeline conﬁgurations are volatile

and can be changed by developers at any time. If the

approach were based on knowledge about the tools

being triggered during pipeline execution, the log an-

alytics approach would have to be adapted. The ap-

proach detects outlier characteristics in real data logs

while the log is consumed as a stream. Hence, the

outlier detection takes place early and could serve as

early feedback to the developers who have triggered

the pipeline execution. Our experiments show that our

method is susceptible to the chosen hyperparameters.

Besides the frequency of occurring anomalies, the de-

tected log events are also affected.

In future work, we plan to develop modiﬁcations

to our approach that are more stable under changes

in parameters. Furthermore, an evaluation on labeled

data and a comparison withDL methods are highly

relevant. In addition to the hit rate, a user study will

be conducted to investigate the extent to which the re-

sults’ explainability supports the root cause analysis.

ACKNOWLEDGEMENTS

This work was partially funded by the Federal Min-

istry of Education and Research, Germany through

grant 01IS22062 (“AI research group FFS-AI”), and

grant 01IS20088B (“KnowhowAnalyzer”).

REFERENCES

Atzberger, D., Schneider, J., Scheibel, W., Limberger, D.,

Trapp, M., and D

ollner, J. (2022). Mining devel-

oper expertise from bug tracking systems using the

author-topic model. In Proceedings of the 17th In-

ternational Conference on Evaluation of Novel Ap-

proaches to Software Engineering, ENASE ’22, pages

107–118. INSTICC, SciTePress.

Blei, D., Ng, A., and Jordan, M. (2003). Latent Dirichlet

Allocation. Journal of Machine Learning Research,

3:993–1022.

Brown, A., Tuor, A., Hutchinson, B., and Nichols, N.

(2018). Recurrent neural network attention mech-

anisms for interpretable system log anomaly detec-

tion. In Proceedings of the 1st Workshop on Machine

Learning for Computing Systems, MLCS ’18, pages

1–8. ACM.

Chandola, V., Banerjee, A., and Kumar, V. (2012).

Anomaly detection for discrete sequences: A survey.

IEEE Transactions on Knowledge and Data Engineer-

ing, 24(5):823–839.

Chen, R., Zhang, S., Li, D., Zhang, Y., Guo, F., Meng, W.,

Pei, D., Zhang, Y., Chen, X., and Liu, Y. (2020). Log-

transfer: Cross-system log anomaly detection for soft-

ware systems with transfer learning. In Proceedings of

the 31st International Symposium on Software Relia-

bility Engineering, ISSRE ’20, pages 37–47. IEEE.

Chen, T.-H., Thomas, S. W., and Hassan, A. E. (2016). A

survey on the use of topic models when mining soft-

ware repositories. Empirical Software Engineering

(Springer), 21(5):1843–1919.

Fitzgerald, B. and Stol, K.-J. (2017). Continuous software

engineering: A roadmap and agenda. Journal of Sys-

tems and Software (Elsevier), 123:176–189.

Grifﬁths, T. L. and Steyvers, M. (2004). Finding scientiﬁc

topics. Proceedings of the National Academy of Sci-

ences, 101(1):5228–5235.

Guo, H., Yuan, S., and Wu, X. (2021). LogBERT: Log

Anomaly Detection via BERT. In In Proceedings

of the International Joint Conference on Neural Net-

works, IJCNN ’21, pages 1–8. IEEE.

He, S., He, P., Chen, Z., Yang, T., Su, Y., and Lyu, M. R.

(2021). A survey on automated log analysis for relia-

bility engineering. ACM Computing Surveys, 54(6).

Detecting Outliers in CI/CD Pipeline Logs Using Latent Dirichlet Allocation

467

Hoffman, M., Bach, F., and Blei, D. (2010). Online learn-

ing for latent dirichlet allocation. Advances in Neural

Information Processing Systems, 23:856–864.

Le, V.-H. and Zhang, H. (2022). Log-based anomaly de-

tection with deep learning: How far are we? In

Proceedings of the 44th International Conference on

Software Engineering, ICSE ’22, pages 1356–1367.

IEEE/ACM.

Li, Z., Zhang, J., Zhang, X., Lin, F., Wang, C., and Cai,

X. (2022). Natural language processing-based model

for log anomaly detection. In Proceedings of the

2nd International Conference on Software Engineer-

ing and Artiﬁcial Intelligence, SEAI ’22, pages 129–

134. IEEE.

Lu, S., Wei, X., Li, Y., and Wang, L. (2018). De-

tecting anomaly in big data system logs using con-

volutional neural network. In Proceedings of the

16th International Conference on Dependable, Au-

tonomic and Secure Computing, 16th International

Conference on Pervasive Intelligence and Comput-

ing, 4th International Conference on Big Data In-

telligence and Computing and Cyber Science and

Technology Congress, DASC/PiCom/DataCom/Cy-

berSciTech ’18, pages 151–158. IEEE.

Meng, W., Liu, Y., Zhu, Y., Zhang, S., Pei, D., Liu, Y.,

Chen, Y., Zhang, R., Tao, S., Sun, P., et al. (2019).

LogAnomaly: Unsupervised detection of sequential

and quantitative anomalies in unstructured logs. In

Proceedings of the International Joint Conference on

Artiﬁcial Intelligence, volume 19 of IJCAI ’19, pages

4739–4745.

Panichella, A., Dit, B., Oliveto, R., Di Penta, M., Poshy-

nanyk, D., and De Lucia, A. (2013). How to ef-

fectively use topic models for software engineering

tasks? an approach based on genetic algorithms.

In Proceedings of the 35th International Conference

on Software Engineering, ICSE ’13, pages 522–531.

IEEE/ACM.

Shahin, M., Ali Babar, M., and Zhu, L. (2017). Continu-

ous integration, delivery and deployment: A system-

atic review on approaches, tools, challenges and prac-

tices. IEEE Access, 5:3909–3943.

Sievert, C. and Shirley, K. (2014). LDAvis: A method for

visualizing and interpreting topics. In Proceedings of

the Workshop on Interactive Language Learning, Vi-

sualization, and Interfaces, pages 63–70. ACL.

Wittkopp, T., Wiesner, P., Scheinert, D., and Kao, O.

(2022). A taxonomy of anomalies in log data. In

Proceedings of the 20th International Conference on

Service-Oriented Computing, ICSOC ’22, pages 153–

164. Springer.

Yang, L., Chen, J., Wang, Z., Wang, W., Jiang, J., Dong,

X., and Zhang, W. (2021). Semi-supervised log-

based anomaly detection via probabilistic label esti-

mation. In Proceedings of the 43rd International Con-

ference on Software Engineering, ICSE ’21, pages

1448–1460. IEEE/ACM.

Zhang, X., Xu, Y., Lin, Q., Qiao, B., Zhang, H., Dang, Y.,

Xie, C., Yang, X., Cheng, Q., Li, Z., Chen, J., He,

X., Yao, R., Lou, J.-G., Chintalapati, M., Shen, F.,

and Zhang, D. (2019). Robust log-based anomaly de-

tection on unstable log data. In Proceedings of the

27th Joint Meeting on European Software Engineer-

ing Conference and Symposium on the Foundations

of Software Engineering, ESEC/FSE ’19, pages 807–

817. ACM.

Zhao, N., Wang, H., Li, Z., Peng, X., Wang, G., Pan, Z.,

Wu, Y., Feng, Z., Wen, X., Zhang, W., Sui, K., and

Pei, D. (2021). An empirical investigation of practical

log anomaly detection for online service systems. In

Proceedings of the 29th Joint Meeting on European

Software Engineering Conference and Symposium on

the Foundations of Software Engineering, ESEC/FSE

’21, pages 1404–1415. ACM.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

468
