Fast-Flux Malicious Domain Name Detection Method Based on Domain

Resolution Spatial Features

Shaojie Chen

1 a

, Bo Lang

1,2

and Chong Xie

State Key Laboratory of Software Development Environment, Beihang University, Beijing, China

Zhongguancun Laboratory, Beijing, China

Keywords:

Fast-Flux Domain Name Detection, Domain Resolution Spatial Features, Resolution Spatial Relationship

Graph, GCN, Botnet.

Abstract:

Fast-Flux malicious domain names evade detection by quickly changing the resolved IP addresses of the

domain name, and play an important role in cyberattacks. In order to improve the performance of the Fast-

Flux domain name detection, this paper explores and uses the rich spatial features contained in the domain

name resolution process, and proposes a Fast-Flux malicious domain name detection method based on the

domain resolution spatial features. In this method, the CNAMEs and IPs in the resolution results obtained by

multiple requests are used as nodes to construct the resolution spatial relationship graph (RSRG). Then the

NS record of the second-level domain name, Geographical locations and Autonomous System Numbers of

the resolved IPs, and WHOIS information of the domain name are further extracted as the node features in

the RSRG. Finally, a GCN model with Max Pooling algorithm is used to extract spatial features from RSRG

and perform classiﬁcation. Our method achieves an accuracy of 94.98% and an F1 value of 92.02% on the

self-constructed dataset, and the overall performance is signiﬁcantly better than the current best methods.

1 INTRODUCTION

Botnet infects a large number of hosts and uses mal-

wares to form a one-to-many control network be-

tween the Command and Control (C&C) server and

the infected hosts. Early botnets usually directly

wrote the domain name or Internet Protocol (IP) ad-

dress (abbreviated as IP) of the C&C server in the

malwares to establish communications between the

infected hosts and the C&C server, which make it

easy to be discovered. In order to improve the con-

cealment of the C&C server, attackers use the Domain

Name System (DNS) protocol to build Fast-Flux ser-

vice Networks (FFSNs). In an FFSN, the C&C server

controls multiple infected hosts as relay servers, and

quickly updates the IPs of the malicious domain name

that belongs to the C&C server. In this way, the

malicious domain name is resolved to different relay

servers, thereby hiding the real C&C server. The ma-

licious domain names used in the FFSNs are called

the Fast-Flux malicious domain names. The hidden

C&C servers could perform various types of attacks,

such as DDoS, spam, and espionage, causing huge

https://orcid.org/0000-0002-1974-6019

losses to organizations and individuals. Therefore, it

is of great signiﬁcance to detect the Fast-Flux domain

names for discovering cyberattacks.

The traditional detection method of malicious do-

main names is to use a blacklist or whitelist; however,

FFSN rapidly changes the IPs, making the blacklist

ineffective. Compared with domain names generated

by Domain Generation Algorithm (DGA) which show

obvious text randomness, Fast-Flux domain names

show relatively weak randomness in the domain name

text, making it difﬁcult to be detected only based on

the domain name itself. The DNS protocol data is im-

portant for the detection of Fast-Flux domain names.

According to the acquisition of data used for detec-

tion, detection methods are mainly divided into pas-

sive detection methods and active detection methods.

The passive detection methods are generally based

on real-time or historical DNS data obtained from the

actual network. Such methods do not generate addi-

tional trafﬁc in the network, which is not easy to be

discovered by attackers. However, such methods usu-

ally need to analyze a large amount of historical data,

resulting in a large amount of computation, and the

attack cannot be detected before the FFSN infects the

monitored devices (Zhauniarovich et al., 2018). The

240

Chen, S., Lang, B. and Xie, C.

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features.

DOI: 10.5220/0011872700003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 240-251

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

active detection methods generally obtain DNS data

through actively resolving the domain name to per-

form detections, and some methods additionally ac-

quire information from third-party databases. There-

fore, active detection methods do not rely on large

amounts of passive DNS trafﬁc, and could complete

the detection process with a single domain name. Al-

though it would cost a certain amount of time to ac-

tively acquire the DNS and third-party data, active

methods can obtain data for the domain names in a

targeted manner, thus effectively reduce the amount

of data processing. In addition, such methods could

detect the domain names before their actual malicious

uses; and do not use network trafﬁc of individual

users, which effectively protect user’s privacy (Zhau-

niarovich et al., 2018). Therefore, active detection

methods have attracted much attention of researchers,

and this paper also researches effective active detec-

tion method.

For current active detection methods, the acquisi-

tion sources of features are divided into the follow-

ing three types: 1) Actively obtain resolved IP infor-

mation of domain names, such as resolving through

the dig command; 2) Acquire information from third-

party databases, such as IP locations, WHOIS, and

results from search engine, etc.; 3) Actively access

the resolved IPs of the domain names to obtain infor-

mation, such as response time of the IPs, data trans-

mission paths obtained by traceroute command, etc.

Among them, the information from the third type,

which are obtained by actively access the resolved

IPs, will be affected by the network ﬂuctuations; and

such methods will leave a large amount of data on

the corresponding IPs, which make it easy to be dis-

covered by attackers. Therefore, this paper mainly

conducts detection based on the former two types of

information mentioned above. In addition, compared

with traditional machine learning models, deep learn-

ing models could discover potential features. There-

fore, we study deep learning methods for Fast-Flux

domain name detection.

Fast-Flux malicious domain name is usually re-

solved to a large number of changing IPs, and these

IPs are widely distributed, which usually shows dif-

ferences from normal domain names in the spatial re-

lationships. Therefore, we propose to perform detec-

tion based on the resolution spatial features of domain

names. The resolution of a domain name is a com-

plex process, and the information returned from the

resolution includes Canonical Name (CNAME), re-

solved IPs, etc. Such information could be presented

as a radial structure centered on the domain name,

which contains rich spatial information. Therefore,

we ﬁrst request to resolve the IPs of the domain name,

and build a relationship graph based on the returned

CNAMEs, IPs, and their dependencies in resolution

results. Here, we name the relationship graph as the

resolution spatial relationship graph (RSRG). In order

to measure the changes of resolved IPs, and to distin-

guish Fast-Flux domain names from Content Delivery

Network (CDN) domain names more effectively, re-

ferring to the idea of Chen et al. (Chen et al., 2019),

we obtain the resolution information from two dif-

ferent cities for ﬁve times respectively, to construct

the ﬁnal RSRG. In addition, Fast-Flux domain names

are usually different from normal domain names in

the distribution of authoritative nameservers (NS), ge-

ographical locations (Geo) and autonomous system

numbers (ASN) of resolved IPs, and WHOIS infor-

mation of domains, etc. We additionally obtain such

information to construct 16-dimensional features for

each node in the RSRG. Finally, the graph convolu-

tional networks (GCN) with Max Pooling algorithm

is used to extract the spatial features from the RSRG,

and perform classiﬁcation to obtain the ﬁnal detection

results.

To summarize, our method has the following con-

tributions:

1) This paper proposes for the ﬁrst time to de-

tect Fast-Flux malicious domain names based on the

domain resolution spatial features. The topology of

resolution spatial relationship graph (RSRG) is ﬁrst

constructed based on the CNAME and IP records in

the resolution results. Then nameserver and WHOIS

information of the domain name, and Geographical

locations and Autonomous System Numbers of the

resolved IPs are obtained. They are then be used

as the node features of the RSRG, to describe the

spatial information of the nodes from multiple per-

spectives. Finally, the graph convolutional networks

(GCN) is used to extract domain resolution spatial

features from RSRG for classiﬁcation.

2) We construct a dataset, which requests the re-

solved IPs from different locations for multiple times,

to differentiate Fast-Flux and CDN domain names

and measure the changes of the resolved IPs. Our

method achieves an accuracy rate of 94.98% and an

F1 value of 92.02% on the dataset, which is signiﬁ-

cantly higher than the existing active detection meth-

ods.

The remainder of the paper is organized as fol-

lows. Section 2 introduces the related work of Fast-

Flux domain name detection, and mainly focuses

on active detection methods. Section 3 introduces

the motivation and Fast-Flux domain name detection

framework based on domain resolution spatial fea-

tures. Section 4 shows the construction of the datasets

and the experiments of the model on the datasets, and

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features

241

compares our method with the existing methods. Sec-

tion 5 summarizes the paper.

2 RELATED WORK

In recent years, researchers have conducted lots of

methods on Fast-Flux malicious domain name detec-

tion. These methods can be mainly divided into pas-

sive and active detection methods, according to the

acquisition manner of the detection data. Passive de-

tection methods are designed to detect Fast-Flux traf-

ﬁc from actual passive trafﬁc, and usually extract fea-

tures from a single packet or packet set for detection.

Active detection methods aim to determine whether

a given domain name is a Fast-Flux domain name.

These methods usually need to actively obtain the res-

olution result of the domain name, or additionally ob-

tain data from third-party databases, such as WHOIS

and IP geographical locations, and extract features

from them for detection. The two types of detection

methods are introduced respectively in the following.

(1) Active Detection Methods.

Active detection methods usually actively acquire in-

formation from third-party databases. Common data

sources include actively obtained DNS data, addi-

tional information provided by third-party databases,

and information obtained by actively accessing the re-

solved IPs of the domain names.

Some methods perform detection only based on

actively obtained DNS data (Chen et al., 2019; Holz

et al., 2008; Berger et al., 2016). The FCDR methods

proposed by Chen et al. (Chen et al., 2019) obtained

domain name resolution results from two different

DNS servers for 5 times respectively, and retained 1

CNAME record and 2 IP records for each resolution

result. For each time of request, 2 CNAME and 4

IP records from two DNS servers were combined to

form a 102-dimensional feature vector. Finally, a fea-

ture sequence with length of 5 was constructed, and

an LSTM model was used for classiﬁcation. This

method highlighted the differences between Fast-Flux

and CDN domain names through requests from two

different DNS servers, and effectively measured the

changes of IPs through 5 requests. Berger et al.

(Berger et al., 2016) used DNSMap to extract the

corresponding relationships between FQDNs and IPs

that have changed within a certain period of time, con-

structed a bipartite graph between FQDNs and IPs,

and obtained the agile groups of FQDNs and IPs with

pruning method to perform detection.

In addition to DNS data, there are methods obtain

additional information, such as geographical loca-

tions, ASNs, WHOIS, or results returned from search

engines as detection basis. The FluxOR method pro-

posed by Passerini et al. (Passerini et al., 2008) ex-

tracted 9-dimensional features of each domain name,

including domain name registration features, network

availability features, and agent heterogeneity features,

and then used a Naive Bayes Classiﬁer to perform

classiﬁcation. Huang et al. (Huang et al., 2010) de-

tected Fast-Flux domain names based on the spatial

relationships of resolved IPs. They obtained the lo-

cation information of each resolved IP obtained from

the DNS packets, and calculated 6-dimensional fea-

tures, such as time zone entropy and the average of

minimal service distances, and then classiﬁed them

based on Bayesian network. Al-Duwairi et al. (Al-

Duwairi et al., 2015) used the Google search engine

to detect Fast-Flux domain names. They ﬁrst ob-

tained the resolved IPs of the domain name, searched

each IP through the Google search engine, and re-

garded the numbers of hits as features for detection.

In the PASSVM method proposed by Al-Duwairi et

al. (Al-Duwairi et al., 2021), the Censys (Durumeric

et al., 2015) was used to obtain the opening port num-

bers of the IPs, etc., which are named censys-based

features, and obtained the IP geolocation-based and

DNS response-based features. They then combined

the third parts of features, and perform classiﬁcation

with Support Vector Machine (SVM).

In addition, some studies try to access the resolved

IPs of the domain names to obtain features, such as

response time (Cafuta et al., 2018; Hsu et al., 2014;

Lin et al., 2013; Chandavarkar et al., 2018; Nagunwa

et al., 2022). Cafuta et al. (Cafuta et al., 2018) used

the network delay and server processing time as the

basic features, and additionally obtained results from

search engine to detect Fast-Flux domain names. Hsu

et al. (Hsu et al., 2014) believed that the response time

of each visit to the Fast-Flux domain name would

be ﬂuctuating, they made multiple requests to the re-

solved IPs to obtain the response time, and then cal-

culated a value named FF-Score and performed clas-

siﬁcation with a threshold. Nagunwa et al. (Nagunwa

et al., 2022) integrated various types of features, they

extracted 6 types of features including temporal fea-

tures, spatial features, and DNS features, etc., and

perform classiﬁcations with various machine learning

models.

Overall, current active detection methods are usu-

ally based on actively obtained DNS data and third-

party databases. The features obtained by actively ac-

cessing the resolved IPs of the domain name may be

interfered by network ﬂuctuations, and such methods

will leave access records on the relay servers of the

FFSN, making it easier to be discovered by attackers.

In addition, most of the current detection methods ex-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

242

tract features based on the feature engineering, and

perform detection based on rules or traditional ma-

chine learning methods, while seldom use deep learn-

ing models. However, deep learning models could

discover potential features. Therefore, our method is

based on the actively obtained DNS data and infor-

mation from third-party databases, trying to use deep

learning methods to extract the potential spatial fea-

tures of domain names to improve the detection ef-

fect.

(2) Passive Detection Methods.

Passive detection methods generally use the actual

DNS trafﬁc as the detection content. These meth-

ods usually extract the internal features of a single

packet or packet set for detection; some passive meth-

ods used additional databases to extract features as a

supplement to the trafﬁc features for detection.

For methods only use the features of trafﬁc itself

(Rana and Aksoy, 2021; Almomani, 2018; Truong

et al., 2020; Wang and Chen, 2019a), to ensure the

real-time detection performance, some methods only

use a single packet for detection. Rana et al. (Rana

and Aksoy, 2021) used the TCP/IP packet of DNS

protocol as the detection unit. They extracted fea-

tures from TCP/IP packet headers, and obtained best

feature selection with genetic algorithm. Finally,

they performed classiﬁcation with multiple classi-

ﬁers, such as random forest. However, the methods

using only a single packet cannot effectively describe

the changing behaviors of the resolved IPs. There-

fore, most passive methods perform detection based

on the packet sets (Almomani, 2018; Truong et al.,

2020; Wang and Chen, 2019a). Almomani et al. (Al-

momani, 2018) made statistics on the trafﬁc of a do-

main name for one month, extracted 14-dimentional

features such as source and destination IPs, and av-

erage TTL values, and performed classiﬁcation based

on adaptive evolving fuzzy neural networks.

In addition, some methods use additional

databases as supplement, such as geographical

locations, ASNs, etc. (Almomani et al., 2021;

Al-Nawasrah et al., 2018; Lombardo et al., 2018;

Surjanto and Lim, 2020; Kumar and Xu, 2018; Wang

and Chen, 2019b) Almomani et al. (Almomani et al.,

2021) and Al-Nawasrah (Al-Nawasrah et al., 2018)

extracted 7-dimensional features from DNS response

packets, such as number of resolved IPs, number of

ASNs, and packet size, and perform classiﬁcation

with AdeSNN algorithm they proposed. Lombardo et

al. (Lombardo et al., 2018) extracted 6-dimensional

static features and 4-dimensional history-based

features, including maximum answer length, number

of IPs, and number of ASNs. Each dimension of

the features was normalized, then they calculated

the weighted summation to obtain the Aggregation

value A, and performed detection according to the

threshold.

3 METHOD

3.1 Motivation

Fast-Flux domain names usually correspond to a large

number of changing resolved IPs, and these IPs are

widely distributed. Hence, Fast-Flux domain names

are different from normal domain names in terms

of spatial information, such as geographical distribu-

tions and network characteristics. Therefore, we per-

form detection based on spatial features, which are

extracted from resolution results we actively obtained.

We use the dig command in Linux system to obtain

the resolution result. Dig command provide functions

of A record request and NS record request. The A

record (recorded as the ”dig A”) request is used to

obtain the resolved IPs of the domain name, which

are stored in the Answer resource records (RRs) in

the response packets; while the NS record (recorded

as the ”dig NS”) request is used to obtain the author-

itative nameservers (NS) and the IPs of the name-

servers (stored in the Additional RRs in DNS re-

sponse packet). The Answer RRs of ”dig A” response

packets usually contain CNAME and A records (i.e.

IP record), in which CNAME record resolves the do-

main name to another domain name, and A record re-

solves the domain name or CNAME to an IP address.

The details of Answer RRs will be described in Sec-

tion 3.3.

We obtain the resolution results of domain name

based on the ”dig A” request, and use the CNAME

and IP records as nodes to construct the resolution

spatial relationship graph (RSRG). Since an important

characteristic of Fast-Flux domain name is the chang-

ing resolved IPs, and response packet of a single ”dig

A” request cannot reﬂect that. Therefore, we request

the domain name for multiple times, and construct the

RSRG with all response packets of the requests. In

addition, Content Distribution Network (CDN) uses

a distributed way to build a group of servers on the

Internet, and provides services for users through the

principles of nearest service, and load balancing, etc.

Therefore, a CDN domain name also corresponds to

a large number of resolved IPs in the RSRG, and

the IPs may be changed, which leads to interference

to the detection of Fast-Flux domain names (Chen

et al., 2019). For a CDN domain name, the resolved

IPs obtained in different locations would be different,

and the change frequency of the resolved IPs is rel-

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features

243

atively low; while for the Fast-Flux domain name,

the resolved IPs obtained in different location may

be the same, and the resolved IPs may be changed

rapidly. Therefore, in order to better distinguish Fast-

Flux from CDN domain names, we also execute the

”dig A” request for 5 times from two different loca-

tions according to the idea of Chen et al. (Chen et al.,

2019). And all IP and CNAME records are taken as

nodes to enrich the structural features of RSRG.

The object we process in the detection is

a single domain name, that is, an independent

Fully Qualiﬁed Domain Name (FQDN), such as

”www.myjaasceb.myjaacb.xjkuh.top”. The second-

level part of a domain name (such as ”xjkuh.top”)

usually represents the owner of the domain name.

And for large normal networks, there are usually more

nameservers. Therefore, we choose to extract the

second-level part of the domain name, and perform

an ”dig NS” request for the second-level part syn-

chronously every time we perform a ”dig A” request,

to obtain the nameserver information of the second-

level part. In addition, the geographical locations

(Geo) and autonomous system numbers (ASN) could

well reﬂect the distribution of the IPs, and WHOIS

information could provide the creation date of a do-

main. Therefore, we choose these four categories of

data as the detection basis, and our data acquisition

process is shown in Figure 1. First, we perform 5

”dig A” and 5 ”dig NS” requests from each of the 2

locations that is in different cities, and obtain infor-

mation including CNAME, IP, NS, Additional, etc.,

and make a one-to-one correspondence between the

”dig A” response packets and the ”dig NS” response

packets. After that, Maxmind (Maxmind Inc., 2022)

is used to acquire geographical locations and ASNs

of all IPs obtained from 10 requests in an ofﬂine way,

and WHOIS request is executed to acquire the cre-

ation date of the domain name.

Domain

names

Dig A

Dig NS

WHOIS

Request

CNAME

Creation

Date

Maxmind

2 locations,

5 times

Nameservers

Additionals

Geographical

Locations

Autonomous

System

Numbers

Domain

names

Dig A

Dig NS

WHOIS

Request

CNAME

Creation

Date

Maxmind

2 locations,

5 times

Nameservers

Additionals

Geographical

Locations

Autonomous

System

Numbers

Figure 1: Process of data acquisition.

After the data acquisitions, all the obtained

CNAME and IP records in the 10 ”dig A” requests

are regarded as nodes in RSRG, and we perform fea-

tures extraction for each node based on the ”dig A”

result, the corresponding ”dig NS” data packets, Geo,

ASN, and WHOIS information. Finally, deep learn-

ing method is used to extract the spatial features of the

domain name from the obtained RSRG. Graph convo-

lutional network (GCN) (Kipf and Welling, 2016) is a

commonly used graph classiﬁcation methods, which

updates the node features by the features of their

neighbors. Since GCN model is designed for node

feature calculation or node classiﬁcation, in order to

apply it to the classiﬁcation of the whole graph, we

refer to the idea of Knyazev et al. (Knyazev et al.,

2018) and use Max Pooling algorithm to extract fea-

tures of the whole graph, named domain resolution

spatial features, and conduct classiﬁcation based on a

fully-connected layer.

3.2 Model Structure

We propose a Fast-Flux malicious domain name de-

tection model based on the domain resolution spatial

features. The structure of our model is shown in Fig-

ure 2. The model mainly contains 3 layers, which are

the data acquisition layer, RSRG construction layer,

and spatial feature extraction and classiﬁcation layer.

Domain Name

Data Acquisition

CNAME, IP

GCN+Max Pooling

Results

NS, ADD

Geo, ASN,

WHOIS

RSRG

Graph Topology

Construction

Node Feature

Extraction

...

Data

Acquisition

RSRG

Construction

Spatial Feature

Extraction &

classification

64-Dimensional

Spatial Features

Domain Name

Data Acquisition

CNAME, IP

GCN+Max Pooling

Results

NS, ADD

Geo, ASN,

WHOIS

RSRG

Graph Topology

Construction

Node Feature

Extraction

...

Data

Acquisition

RSRG

Construction

Spatial Feature

Extraction &

classification

64-Dimensional

Spatial Features

Figure 2: Structure of the Fast-Flux domain name detection

method.

In the data acquisition layer, operations including

”dig A”, ”dig NS” and WHOIS are used to obtain the

IP resolution results, NS information and WHOIS in-

formation of the domain name, and Maxmind (Max-

mind Inc., 2022) is used to obtain the geographical

locations and ASNs of the resolved IPs, as described

in Section 3.1. In RSRG construction layer, we ﬁrst

construct the topology of the RSRG based on the ”dig

A” results, which will be introduced in Section 3.3;

we then construct a 16-dimensional feature vector for

each node in the RSRG from the original results of

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

244

”dig A”, ”dig NS” and WHOIS, etc., which will be

introduced in Section 3.4. In spatial feature extrac-

tion and classiﬁcation layer, we ﬁrst adopt multi-layer

GCN model and Max Pooling algorithm to extract 64-

dimensional spatial features, which will be introduced

in Section 3.5; and ﬁnally, a fully-connected layer is

used to output a 2-dimensional feature vector, which

is the classiﬁcation result of the domain name.

3.3 Topology Structure Construction of

RSRG

First, we select CNAME and A records from the An-

swer RRs in ”dig A” results as the CNAME nodes

and IP nodes in the RSRG. Each CNAME or IP is as-

sociated with the domain name node or the CNAME

node, which is in accordance with the relations ex-

ist in the Answer RRs. And ﬁnally, we obtain the

topology of RSRG, which is a divergent tree struc-

ture graph, in which the domain name is the central

node. As shown in Figure 3, assume that the de-

tected domain name is ”domain.com” and we perform

”dig A” request twice. The Answer RRs is shown

in Figure 3(a) and Figure 3(b), which contain 5 and

4 records respectively. Each record contains the do-

main name, time to live (TTL), class, type, and result.

In Figure 3(a), the CNAME node ”cname1.com” de-

pends on the requested domain name ”domain.com”,

and the four IP nodes depend on the CNAME node

”cname1.com”. Since the results returned from each

”dig A” request may be different, we choose to re-

tain all the results to build the RSRG. We believe that

each correlation between domain name, CNAME and

IP nodes has bidirectional inﬂuences, and the GCN

model we use is based on undirected graph. There-

fore, we deﬁne the RSRG as an undirected graph. The

ﬁnal RSRG for ”domain.com” we construct is shown

in Figure 3(c).

domain.com. 474 IN CNAME cname1.com.

cname1.com. 69 IN A IP1

cname1.com. 69 IN A IP2

cname1.com. 69 IN A IP3

cname1.com. 69 IN A IP4

Domain name TTL Class Type Result

domain.com. 474 IN CNAME cname2.com.

cname2.com. 69 IN A IP5

cname2.com. 69 IN A IP6

cname2.com. 69 IN A IP7

Domain name TTL Class Type Result

(a) Answer of First Query

(b) Answer of Second Query

IP7

IP3

IP2

IP5

IP6

Cname

Domain

Name

IP1

IP4

Cname

domain.com. 474 IN CNAME cname1.com.

cname1.com. 69 IN A IP1

cname1.com. 69 IN A IP2

cname1.com. 69 IN A IP3

cname1.com. 69 IN A IP4

Domain name TTL Class Type Result

domain.com. 474 IN CNAME cname2.com.

cname2.com. 69 IN A IP5

cname2.com. 69 IN A IP6

cname2.com. 69 IN A IP7

Domain name TTL Class Type Result

(a) Answer of First Query

(b) Answer of Second Query

IP7

IP3

IP2

IP5

IP6

Cname

Domain

Name

IP1

IP4

Cname

Figure 3: Example of RSRG topology structure construc-

tion.

3.4 Node Feature Extraction in RSRG

In terms of node features, we design 16-dimensional

features for each node based on the obtained data,

including 5-dimensional IP resolution features, 4-

dimensional NS resolution features, 6-dimensional

geographical and ASN features, and 1-dimensional

WHOIS feature. There are three types of nodes,

which are domain name node, CNAME node, and IP

node. Different types of nodes have different ways of

feature calculation. Each dimension of the node fea-

tures is ﬁnally divided by the maximum value of such

dimension in the dataset for normalization, to improve

the effect of the features extracted by the GCN model.

(1) IP Resolution Features.

The IP resolution features of nodes are extracted from

the ”dig A” response packets, and the 5-dimensional

features we extracted are shown in Table 1. Among

them, Times A1 and Times A2 are used to measure

the changes of resolved IPs. If such 2-dimensional

features of all nodes are 5, it proves that all the

records have not changed; on the contrary, the re-

solved IPs have changed for many times. TTL value

indicates the valid time of a resolved CNAME or IP.

The resolved IPs of Fast-Flux domain name changes

quickly, so the TTL value is relatively small. Since

that TTL value changes periodically, the maximum

value of the TTL could better reﬂect the valid time of

the result. In addition, Fast-Flux domain name is usu-

ally only accessed by infected hosts, it is more likely

that the local DNS server cannot ﬁnd the resolution

result and needs to perform iterative query, which re-

sults in a longer response time. Moreover, the packet

size is also related to the number of results contained

in the packet. Therefore, we believe that the response

time and packet size have important value for Fast-

Flux domain name detection. For a CNAME or IP

node, the 5-dimensional features are extracted accord-

ing to the ”dig A” response packets containing such

CNAME or IP resolution result; for the domain name

node, they are extracted according to all the 10 ”dig

A” response packets.

Table 1: Description of IP resolution features.

Name

Meaning

Times A1 Times resolved at location 1

Times A2 Times resolved at location 2

Max ttl Maximum of TTL value

Min A time

Minimun response time of

A requests

Max A size

Maximun packet size of

A requests

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features

245

(2) NS Resolution Features.

The NS resolution features of nodes are extracted

from the ”dig NS” response packets of the second-

level part of the domain name. The 4-dimensional

features we extracted are shown in Table 2. The NS

records store the nameservers, while the Additional

records stores the IP addresses of the nameservers.

The second-level part of the domain name usually

represents the owner of the domain name. For a

large normal network, there are generally more name-

servers, that is, more NS records and more Additional

records. Since each ”dig A” response packet is one-

to-one corresponded with a ”dig NS” response packet,

for a CNAME or IP node, the 4-dimensional features

are extracted from the ”dig NS” response packets cor-

responding to the ”dig A” response packets that con-

tains such CNAME or IP record; for the domain name

node, they are extracted according to all the 10 ”dig

NS” response packets.

Table 2: Description of NS resolution features.

Name

Meaning

Num NS Number of NS records

Num ADD Number of additional records

Min NS time

Minimun response time of

NS requests

Max NS size

Maximun packet size of

NS requests

(3) Geographical and ASN Features.

The geographical location indicates the location of an

IP in the real world, and the ASN indicates the owner

of the IP. The 6-dimensional features we extracted are

shown in Table 3. FFSN usually controls hosts in

other networks as relay servers, such hosts are usually

distributed in different locations, resulting in highly

dispersed IPs. The number of cities, countries, conti-

nents, postcodes, and registered countries of IPs can

measure the geographical dispersion of the resolved

IPs. In addition, the hosts controlled by FFSN usu-

ally belong to different owners, resulting in more dis-

tinct ASNs, so we use the number of ASNs to mea-

sure the number of IP owners. For an IP node, the

6-dimensional features are all 1; for a CNAME node,

they are statistically extracted according to its adja-

cent IP nodes; for the domain name node, they are

statistically extracted according to all IP nodes.

(4) WHOIS Feature.

The Fast-Flux domain name may change sometimes,

resulting in shorter registration time; while domain

names for normal services are relatively stable, result-

ing in longer registration time. The creation date of

the domain name is included in WHOIS information;

we choose to extract such time, and subtract the cre-

Table 3: Description of geographical and ASN features.

Name

Meaning

Num city Number of cities

Num country Number of countries

Num continent Number of continents

Num postal Number of postal numbers

Num reg country

Number of register countries

Num ASN Number of ASNs

ation date from the current time to get the Life time of

the domain name as one dimension of the node fea-

tures. If such WHOIS information is not found or

creation date is not included in the WHOIS informa-

tion, the Life time is set to 0. Since we only obtain the

WHOIS information of the domain name, the value

for all nodes in the RSRG is all set to the same value.

3.5 Spatial Feature Extraction from

RSRG

After the construction of the RSRG, we use the multi-

layer GCN to extract spatial features from it. Since

the GCN model updates features of each node based

on its adjacent nodes, in an n-layer GCN network,

each node features may be affected by the node fea-

tures within a distance (i.e., the shortest path in graph)

of n.

As shown in Figure 3(c), the RSRG we construct

contains 2 CNAME nodes and 7 IP nodes. When

there is no association between two CNAME nodes,

the maximum distance of nodes in the graph is the

distance between two IP node that associated with dif-

ferent CNAME nodes, such as distance between IP1

and IP5 in Figure 3(c), that is 4. However, in the ac-

tual RSRG, there may be associations between two

CNAME nodes, which leads to larger distance be-

tween nodes in the graph. For instance, in the RSRGs

in our dataset, the maximum distance between nodes

is 7. For common GCN model used for node classi-

ﬁcation, the number of layers is usually set to 2 or 3.

More GCN layers would lead to poor differentiation

of nodes, and the feature vectors of different nodes

tend to be consistent. However, our goal is to extract

the features of the whole graph, so we do not need to

consider the differentiation of node features. There-

fore, we choose to use GCN model with 1-10 layers

for feature extraction, and select the optimal num-

ber of GCN layers as 8 through experiments. Here,

the node features output by each GCN layer is set

to 64-dimensions, and the Max Pooling algorithm is

adopted to select the maximum value of each dimen-

sion from all nodes features output by the last GCN

layer, and the 64-dimensional features are ﬁnally ob-

tained as the spatial features of the RSRG.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

246

4 EXPERIMENTS

4.1 Datasets and Indicators

The dataset we used is self-constructed which is based

on the Alexa domain names, CDN domain names, and

Fast-Flux domain names collected by ourselves. The

Alexa and CDN domain names are regarded as nor-

mal domain names and be acquired from Alexa Top-

sites (Alexa Web Information Company, 2021) and

github (Vincent, 2021) respectively. For Fast-Flux

domain names, we ﬁrst obtained malicious domain

names from spam Archive (Guenter, 2022), phish-

stats (Phishstats, 2022), phishtank (Phishtank, 2022),

and cert.pl (Cert Polska, 2020). Then, dig com-

mand was used in Beijing to obtain the resolved IPs

from ”114.114.114.114” DNS server for 5 consecu-

tive days, and according to the idea of Nagunwa et

al. (Nagunwa et al., 2022), only the domain names

with resolved IPs and the resolved IPs have changed

at least one time were retained as the ﬁnal Fast-Flux

domain names. Finally, 9,674 Alexa domain names,

8,638 CDN domain names and 8,709 Fast-Flux do-

main names were selected as the ﬁnal dataset of this

paper.

For all the domain names in the dataset, we used

the ”dig A” command to obtain the resolution results

of the domain names for 5 consecutive days from Bei-

jing and Nanjing respectively, and used the ”dig NS”

command to obtain the NS records of second-level

part of each domain name. Then an ofﬂine database

named MaxMind (Maxmind Inc., 2022) is used to ac-

quire the geographical and ASN information for each

resolved IPs, and WHOIS information of the domain

name is acquired.

Both CDN and Fast-Flux domain names corre-

spond to a large number of resolved IPs, which may

affect the effectiveness of the detection model. To

better evaluate our detection method, we built three

sub-datasets based on the full dataset, which are Full

dataset (Alexa + CDN + Fast-Flux), Alexa FF dataset

(Alexa + Fast-Flux), and CDN FF dataset (CDN +

Fast-Flux). Finally, we used the average results of

5-fold cross-validation as the ﬁnal testing results. For

all the three sub-datasets, 4 indicators including accu-

racy (Acc), precision (Pre), recall (Rec) and F1 value

are used.

4.2 Experimental Settings

In this paper, two active detection methods with best

performance are selected for comparison, which are

FCDR (Chen et al., 2019) and FluxOR (Passerini

et al., 2008). In addition, we set up multiple ablation

experiments to verify the effectiveness of the virous

designs of our method.

We conducted 5 groups of experiments in total.

• Experiment 1, comparison experiment. We com-

pared the effects of our method with FCDR and

FluxOR on the three sub-datasets.

• Experiment 2, effectiveness experiment for node

features. Taking the IP resolution features as

the base, we successively added NS resolution

features, Geographical and ASN features and

WHOIS features, to prove the effectiveness of

each set of node features.

• Experiment 3, effectiveness experiment for data

acquisition methods. First, based on acquisition

in 2 locations, we compared the detection effects

of model when using data of 1-5 days, to show the

impact of the data acquisition times on the perfor-

mance. Then, based on acquisition for 5 times,

we compared the detection effects of model when

acquiring data in 1 or 2 locations, to show the ef-

fectiveness of data acquisition in 2 locations.

• Experiment 4, effectiveness experiment for node

feature preprocessing. We compared the detec-

tion effects of non-normalization of node features,

normalization, and adding an additional fully-

connected layer, and selected the best node feature

preprocessing method.

• Experiment 5, effectiveness experiment for num-

ber of GCN layers. We compared the detection ef-

fects of GCNs with number of layers ranging from

1 to 10 respectively, to select the optimal number

of GCN layers.

4.3 Results

4.3.1 Comparison Experiment

In this experiment, our method is compared with

two existing methods, which are FCDR (Chen et al.,

2019) and FluxOR (Passerini et al., 2008). FCDR

(Chen et al., 2019) acquired resolution data for 5

times from 2 DNS server, which is the same as our

method. They extracted 2 CNAME and 4 IP records

from the 2 resolution results of each time to construct

102-dimensional features, and ﬁnally obtained a fea-

ture sequence with length of 5, and then performed

classiﬁcation using LSTM model. In this method,

the 102-dimensional features include 6-dimensional

features to indicate whether the CNAMEs and IPs

are in the whitelist. Since we did not construct the

whitelist, we consider two ways to deal with such 6-

dimensional features: directly remove them to form

96-dimensional features, or set all of them to 0. By

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features

247

comparing the experimental results, we found that the

overall effect is relatively better when setting all 6-

dimensional features to 0, so such result is taken as the

ﬁnal effect of the method. FluxOR (Passerini et al.,

2008) extracted 9-dimensional features for each do-

main name, including domain name registration fea-

tures, network availability features, and agent hetero-

geneity features, and used Naive Bayes Classiﬁer to

perform classiﬁcation. Our method iterates 50 epochs

in the training process without setting dropout, and

the initial learning rate is set to 0.001, and is decayed

to 0.1 of the current learning rates after the 25

and

epochs. The results of each comparison method

are shown in Table 4.

Table 4: Performance of comparison experiments.

Dataset

Indic-

ator

FCDR FluxOR Ours

Full

Acc 90.30% 66.39% 94.98%

Pre 86.12% 48.67% 94.16%

Rec 83.25% 78.52% 89.38%

F1 84.66% 60.09% 92.02%

Alexa

Acc 87.95% 60.86% 94.26%

Pre 85.72% 55.97% 94.73%

Rec 88.15% 81.50% 93.05%

F1 86.91% 66.36% 93.88%

CDN

Acc 93.34% 84.22% 95.24%

Pre 92.84% 79.84% 95.90%

Rec 93.99% 91.73% 94.56%

F1 93.41% 85.37% 95.22%

From the results, our method achieved signiﬁ-

cantly better effect than the existing two methods,

when comparing on the three sub-datasets using 5-

fold cross-validation. For FluxOR method, the fea-

tures they constructed are relatively simple, which

achieved poor detection effect. The FCDR method

only considered 1 CNAME and 2 IP records in each

resolution result, such features ignored the spatial fea-

tures of the resolved IPs, such as the number and dis-

tribution of the resolved IPs. And the overall effect is

also lower than our method.

4.3.2 Effectiveness Experiment for Node

Features

The node features in RSRG are mainly divided into

four sets: IP resolution features (marked as ”IP”),

NS resolution features (marked as ”NS”), Geograph-

ical and ASN features (marked as ”Geo ASN”) and

WHOIS features. In this experiment, each method

constructed RSRG based on the data of all the 5-days,

and used an 8-layer GCN to extract spatial features

and perform classiﬁcation. The experiment results are

shown in Table 5.

From the results, when only using IP resolution

features, our model reached accuracies of more than

90% on the three sub-datasets, which proves the effec-

tiveness of the IP resolution features. After adding NS

resolution features, the effects on three sub-datasets

are signiﬁcantly improved, indicating that the NS res-

olution features are of great value in distinguishing

between Fast-Flux and normal domain names. Af-

ter adding Geographical and ASN features, the effect

on Alexa FF dataset changed little, but the effect on

CDN FF dataset was signiﬁcantly improved, indicat-

ing that such features are of great value in distinguish-

ing between Fast-Flux and CDN domain names. Fi-

nally, after adding WHOIS features, the effects of the

three sub-datasets are signiﬁcantly improved, which

proves the effectiveness of WHOIS features.

4.3.3 Effectiveness Experiment for Data

Acquisition Methods

This paper performs resolutions for 5 times in 2 loca-

tions, and obtains 10 times of resolution data to con-

struct RSRG for Fast-Flux domain name detection.

Among them, acquisition from 2 locations is mainly

used to distinguish between Fast-Flux and CDN do-

main names, and acquisition for 5 times is mainly

used to measure the changes of the resolved IPs. This

experiment was used to compare the detection effects

of our spatial features with data of different request

times. In this experiment, each method constructed

RSRG with 16-dimensional node features, and used

an 8-layer GCN to extract spatial features and per-

form classiﬁcation. The experiment results are shown

in Table 6.

Comparing the result of data acquisition in 2 lo-

cations for 1-5 days, the detection effect of the model

was on the rise with the increase of days. Moreover,

it is found that the difference of detection effects be-

tween data of 1-day and 2-day is signiﬁcantly higher

than that between other contiguous pairs. After anal-

ysis, we believe that using data of 1-day, i.e. only

one group of resolution result is reserved, the chang-

ing behavior of IPs cannot be described. However,

when using data of 2-days, there are two groups of

resolution results, changes of IPs can be effectively

discovered. Therefore, the detection effect is greatly

improved. When continuously increasing the days of

data, it would be better to describe the changes of IPs,

but the increase was relatively small compared to the

increase of 1 to 2 days.

Comparing the result of data acquisition for 5

days in 1 and 2 locations, it shows that for Alexa FF

dataset, the detection effects of the two conﬁgurations

are similar, indicating that it has no signiﬁcant impact

on the dataset when acquiring data from 2 locations.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

248

Table 5: Performance of different node features.

Dataset Indicator IP IP + NS

IP +NS +

Geo ASN

IP +NS +

Geo ASN + WHOIS

Full

Acc 92.13% 93.56% 93.59% 94.98%

Pre 91.04% 94.15% 94.40% 94.16%

Rec 83.83% 85.34% 85.16% 89.38%

F1 87.28% 89.52% 89.55% 92.02%

Alexa FF

Acc 92.10% 93.43% 93.18% 94.26%

Pre 92.01% 94.57% 94.28% 94.73%

Rec 91.24% 91.38% 91.14% 93.05%

F1 91.62% 92.94% 92.68% 93.88%

CDN FF

Acc 90.46% 91.70% 92.92% 95.24%

Pre 92.18% 92.60% 92.15% 95.90%

Rec 88.53% 90.78% 93.90% 94.56%

F1 90.30% 91.66% 93.02% 95.22%

Table 6: Performance of different data acquisition methods.

Dataset Indicator

2 locations

1 day

2 locations

2 days

2 locations

3 days

2 locations

4 days

2 locations

5 days

1 location

5 days

Full

Acc 93.64% 94.58% 94.80% 94.97% 94.98% 94.90%

Pre 93.44% 93.74% 93.83% 94.44% 94.16% 94.52%

Rec 86.34% 89.15% 89.76% 89.69% 89.38% 89.38%

F1 89.74% 91.38% 91.75% 92.00% 92.02% 91.87%

Alexa FF

Acc 93.03% 93.88% 94.07% 94.14% 94.26% 94.32%

Pre 94.29% 94.54% 94.85% 94.73% 94.73% 94.27%

Rec 90.79% 92.42% 92.50% 92.78% 93.05% 93.71%

F1 92.50% 93.47% 93.66% 93.74% 93.88% 93.98%

CDN FF

Acc 93.88% 94.73% 95.07% 94.94% 95.24% 94.70%

Pre 94.43% 95.50% 96.11% 95.71% 95.90% 95.73%

Rec 93.33% 93.93% 93.99% 94.16% 94.56% 93.62%

F1 93.87% 94.70% 95.04% 94.92% 95.22% 94.66%

For CDN FF dataset and Full dataset, it shows that

when using data of 2 locations, the detection effect

is signiﬁcantly higher than that of a single location.

Therefore, it is proved that obtaining data from two

locations is of great value in distinguishing between

Fast-Flux and CDN domain names.

4.3.4 Effectiveness Experiment for Node Feature

Preprocessing

Since we extract 16-dimensional features for each

node in the RSRG, the value distributions of differ-

ent dimensions are quite different, hence we choose

to divide each dimension of features by its maxi-

mum value for normalization. In addition, we con-

sider adding a fully-connected layer after normaliza-

tion to transform the node features. Here we com-

pared the detection effects before and after normaliza-

tion of node features, and the detection effects before

and after adding an additional fully-connected layer.

In this experiment, each method constructed RSRG

with 16-dimensional node features based on the data

of all 5-days, and used an 8-layer GCN to extract spa-

tial features and perform classiﬁcation. The experi-

ment results are shown in Table 7.

Table 7: Performance of different node features processing

methods.

Dataset

Indic-

ator

Non-

Normal

+ FC

Full

Acc 92.88% 94.98% 71.40%

Pre 93.90% 94.16% 61.88%

Rec 83.33% 89.38% 32.09%

F1 88.30% 92.02% 41.96%

Alexa

Acc 91.02% 94.26% 63.50%

Pre 93.64% 94.73% 64.59%

Rec 86.97% 93.05% 50.70%

F1 90.18% 93.88% 56.79%

CDN

Acc 93.38% 95.24% 77.18%

Pre 95.43% 95.90% 70.59%

Rec 91.19% 94.56% 94.26%

F1 93.26% 95.22% 80.61%

From the result, after normalization of node fea-

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features

249

tures, the detection effect of the model has signiﬁ-

cantly improved. However, after adding the additional

fully-connected layer, the detection effect decreased

signiﬁcantly. We believe that the 8-layer GCN already

has a high complexity, the additional fully-connected

layer further increases the complexity of the model,

resulting in the risk of overﬁtting or difﬁculty in con-

vergence, which leads to the decrease of the detection

effect. Therefore, we ﬁnally choose to only perform

normalization for node features of RSRG.

4.3.5 Effectiveness Experiment for Number of

GCN Layers

This experiment compares the effects of GCN models

with different layers on the effectiveness of the ex-

tracted spatial features. To select the optimal number

of GCN layers for spatial feature extraction, we tested

GCNs with layers ranging from 1 to 10 respectively.

In this experiment, each method constructed RSRG

with 16-dimensional node features based on the data

of all 5-days, and used different GCNs to extract spa-

tial features and perform classiﬁcation. The experi-

ment results are shown in Figure 4. Figure 4(a), (b),

and (c) respectively shows the change trend of each

indicator on Full, Alexa FF and CDN FF datasets,

when number of GCN layers range from 1 to 10.

(a) Full Dataset

(b) Alexa_FF Dataset

94.98%

92.02%

86%

88%

90%

92%

94%

96%

1 2 3 4 5 6 7 8 9 10

76%

81%

86%

91%

96%

1 2 3 4 5 6 7 8 9 10

92%

93%

94%

95%

96%

1 2 3 4 5 6 7 8 9 10

accuracy

precision

recall

Figure 4: Performance of different number of GCN layers.

From the results, with the increasing number of

GCN layers, the detection effect shows an increasing

trend on the whole, which proves that, GCN model

with more layers is helpful to improve the detection

effect. We believe that more GCN layers could effec-

tively fuse the features of nodes with farther distances,

and achieved deeper abstraction level of the extracted

feature, which result in higher efﬁciency of the model.

However, with the number of GCN layers increas-

ing, the improvement of the detection effect shows a

gradually decreasing trend in the three sub-datasets.

And the overall detection effect is the best when the

8-layer GCN is used. Moreover, when using the 10-

layer GCN, the model did not converge for twice in

the 5-fold cross-validation on the Alexa FF dataset,

resulting in an average accuracy of only 82%, which

is much lower than that of GCNs with 1 to 9 lay-

ers. We believe that the maximum distance between

nodes in the current RSRGs is 7, and more GCN lay-

ers could not integrate features of more nodes. In ad-

dition, the GCN model with more layers could im-

prove the abstraction ability of features; however, it is

more likely for such model to encounter problems of

overﬁtting and non-convergence, resulting in the de-

crease of the detection effect. Therefore, we choose

the 8-layer GCN as the ﬁnal model.

5 CONCLUSIONS

In this paper, a Fast-Flux malicious domain name de-

tection method using domain resolution spatial fea-

tures is proposed. The method obtains the resolution

information through dig command in Linux system,

and constructs the topology of the resolution spatial

relationship graph (RSRG) based on the CNAME and

IP records. Then the method extracts 16-dimensional

node features, including IP resolution features, NS

resolution features, geographical and ASN features,

and WHOIS feature. Finally, the GCN model com-

bined with Max Pooling algorithm is used to extract

spatial features from the RSRG and perform classiﬁ-

cation. The paper constructs a dataset based on 4 ma-

licious domain name websites, Alexa domain names

and CDN domain names, and perform testing based

on the dataset. The experimental result shows that

our method achieves an accuracy of 94.98%and an F1

value of 92.02%, which is higher than that of the ex-

isting similar methods.

At present, our method only considers the spa-

tial features of the domain names. We will consider

mining more relevant information from existing data,

such as text features in WHOIS information, to fur-

ther improve the detection effect of the model. And

then, we will deploy the detection model in actual net-

work to detect Fast-Flux domain names and discover

the attacks.

REFERENCES

Al-Duwairi, B., Al-Hammouri, A., Aldwairi, M., and Pax-

son, V. (2015). Gﬂux: A google-based system for fast

ﬂux detection. In 2015 IEEE Conference on Com-

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

250

munications and Network Security (CNS), pages 755–

756. IEEE.

Al-Duwairi, B., Jarrah, M., and Shatnawi, A. S. (2021).

Passvm: A highly accurate fast ﬂux detection system.

Computers & Security, 110:102431.

Al-Nawasrah, A., Al-Momani, A., Meziane, F., and Alauth-

man, M. (2018). Fast ﬂux botnet detection framework

using adaptive dynamic evolving spiking neural net-

work algorithm. In 2018 9th International Conference

on Information and Communication Systems (ICICS),

pages 7–11. IEEE.

Alexa Web Information Company (2021). Topsites.

https://www.alexa.com/topsites.

Almomani, A. (2018). Fast-ﬂux hunter: a system for ﬁl-

tering online fast-ﬂux botnet. Neural Computing and

Applications, 29(7):483–493.

Almomani, A., Al-Nawasrah, A., Alauthman, M., Al-Betar,

M. A., and Meziane, F. (2021). Botnet detection

used fast-ﬂux technique, based on adaptive dynamic

evolving spiking neural network algorithm. Interna-

tional Journal of Ad Hoc and Ubiquitous Computing,

36(1):50–65.

Berger, A., D’Alconzo, A., Gansterer, W. N., and Pescap

A. (2016). Mining agile dns trafﬁc using graph anal-

ysis for cybercrime detection. Computer Networks,

100:28–44.

Cafuta, D., Sruk, V., and Dodig, I. (2018). Fast-ﬂux botnet

detection based on trafﬁc response and search engines

credit worthiness. Tehni

cki vjesnik, 25(2):390–400.

Cert Polska (2020). List of malicious domains.

https://cert.pl/en/posts/2020/03/malicious domains/.

Chandavarkar, B. et al. (2018). Maldetect: A framework to

detect fast ﬂux domains. In 2018 IEEE Distributed

Computing, VLSI, Electrical Circuits and Robotics

(DISCOVER), pages 141–146. IEEE.

Chen, X., Li, G., Zhang, Y., Wu, X., and Tian, C. (2019). A

deep learning based fast-ﬂux and cdn domain names

recognition method. In Proceedings of the 2019 2nd

International Conference on Information Science and

Systems, pages 54–59.

Durumeric, Z., Adrian, D., Mirian, A., Bailey, M., and Hal-

derman, J. A. (2015). A search engine backed by

internet-wide scanning. In Proceedings of the 22nd

ACM SIGSAC Conference on Computer and Commu-

nications Security, pages 542–553.

Guenter, B. (2022). Spam archive.

http://untroubled.org/spam/.

Holz, T., Gorecki, C., Rieck, K., and Freiling, F. C. (2008).

Measuring and detecting fast-ﬂux service networks. In

Ndss.

Hsu, F.-H., Wang, C.-S., Hsu, C.-H., Tso, C.-K., Chen, L.-

H., and Lin, S.-H. (2014). Detect fast-ﬂux domains

through response time differences. IEEE Journal

on Selected Areas in Communications, 32(10):1947–

1956.

Huang, S.-Y., Mao, C.-H., and Lee, H.-M. (2010). Fast-ﬂux

service network detection based on spatial snapshot

mechanism for delay-free detection. In Proceedings

of the 5th ACM symposium on information, computer

and communications security, pages 101–111.

Kipf, T. N. and Welling, M. (2016). Semi-supervised clas-

siﬁcation with graph convolutional networks. arXiv

preprint arXiv:1609.02907.

Knyazev, B., Lin, X., Amer, M. R., and Taylor, G. W.

(2018). Spectral multigraph networks for discovering

and fusing relationships in molecules. arXiv preprint

arXiv:1811.09595.

Kumar, S. A. and Xu, B. (2018). A machine learning based

approach to detect malicious fast ﬂux networks. In

2018 IEEE Symposium Series on Computational In-

telligence (SSCI), pages 1676–1683. IEEE.

Lin, H.-T., Lin, Y.-Y., and Chiang, J.-W. (2013). Genetic-

based real-time fast-ﬂux service networks detection.

Computer Networks, 57(2):501–513.

Lombardo, P., Saeli, S., Bisio, F., Bernardi, D., and Massa,

D. (2018). Fast ﬂux service network detection via

data mining on passive dns trafﬁc. In International

Conference on Information Security, pages 463–480.

Springer.

Maxmind Inc. (2022). Geoip databases & ser-

vices: Industry leading ip intelligence.

https://www.maxmind.com/en/geoip2-services-

and-databases.

Nagunwa, T., Kearney, P., and Fouad, S. (2022). A ma-

chine learning approach for detecting fast ﬂux phish-

ing hostnames. Journal of Information Security and

Applications, 65:103125.

Passerini, E., Paleari, R., Martignoni, L., and Bruschi, D.

(2008). Fluxor: Detecting and monitoring fast-ﬂux

service networks. In International conference on de-

tection of intrusions and malware, and vulnerability

assessment, pages 186–206. Springer.

Phishstats (2022). Phishstats. https://phishstats.info/.

Phishtank (2022). Phishtank. https://www.phishtank.com/.

Rana, S. and Aksoy, A. (2021). Automated fast-ﬂux detec-

tion using machine learning and genetic algorithms.

In IEEE INFOCOM 2021-IEEE Conference on Com-

puter Communications Workshops (INFOCOM WK-

SHPS), pages 1–6. IEEE.

Surjanto, W. and Lim, C. (2020). Finding fast ﬂux trafﬁc

in dns haystack. In International Conference on Criti-

cal Information Infrastructures Security, pages 69–82.

Springer.

Truong, D.-T., Tran, D.-T., and Huynh, B. (2020). Detecting

malicious fast-ﬂux domains using feature-based clas-

siﬁcation techniques j. J Internet Technol., 21:1061–

72.

Vincent, Y. (2021). Domainfrontinglists.

https://github.com/vysecurity/DomainFrontingLists.

Wang, J. and Chen, Y. (2019a). Detection method of fast

ﬂux service network based on decision tree algorithm.

In Journal of Physics: Conference Series, volume

1325, page 012112. IOP Publishing.

Wang, J. and Chen, Y. (2019b). Fast-ﬂux detection method

based on dns attribute. In Journal of Physics: Confer-

ence Series, volume 1325, page 012049. IOP Publish-

ing.

Zhauniarovich, Y., Khalil, I., Yu, T., and Dacier, M. (2018).

A survey on malicious domains detection through

dns data analysis. ACM Computing Surveys (CSUR),

51(4):1–36.

Fast-Flux Malicious Domain Name Detection Method Based on Domain Resolution Spatial Features

251
