Curriculum Learning for Compositional Visual Reasoning

Wafa Aissa

1,2

, Marin Ferecatu

and Michel Crucianu

Cedric Laboratory, Conservatoire National des Arts et M

etiers, Paris, France

XXII Group, Paris, France

Keywords:

Compositional Visual Reasoning, Visual Question Answering, Neural Module Networks, Curriculum

Learning.

Abstract:

Visual Question Answering (VQA) is a complex task requiring large datasets and expensive training. Neural

Module Networks (NMN) ﬁrst translate the question to a reasoning path, then follow that path to analyze the

image and provide an answer. We propose an NMN method that relies on predeﬁned cross-modal embeddings

to “warm start” learning on the GQA dataset, then focus on Curriculum Learning (CL) as a way to improve

training and make a better use of the data. Several difﬁculty criteria are employed for deﬁning CL methods.

We show that by an appropriate selection of the CL method the cost of training and the amount of training

data can be greatly reduced, with a limited impact on the ﬁnal VQA accuracy. Furthermore, we introduce

intermediate losses during training and ﬁnd that this allows to simplify the CL strategy.

1 INTRODUCTION

Visual Question Answering (VQA) consists in an-

swering potentially complex questions regarding the

content of images. Datasets like VQA2.0 (Goyal

et al., 2017) and GQA (Hudson and Manning, 2019)

were put forward in support of this task. These

datasets are very large, leading to expensive training.

However, since they are built from collected real im-

ages with (possibly assisted) human labeling, they in-

evitably contain many biases. Integrated approaches

like (Xiong et al., 2022; Wang et al., 2021) have the

highest overall accuracies on these databases but are

prone to taking bias-promoted “shortcuts”, as shown

e.g. by their lower performance on out-of-distribution

data (Kervadec et al., 2021). Furthermore, integrated

approaches lack transparency in the reasoning pro-

cess, even though some limited explanations can be

obtained by following the ﬂow of attention.

Alternatively, Neural Module Networks (NMN)

were introduced (Hu et al., 2017) with the aim to

make the reasoning explicit. They were quite success-

ful for visual reasoning on synthetic image datasets

like CLEVR, where word grounding is comparatively

easy and there is signiﬁcant control over scene com-

position. NMNs are nevertheless hard to train on

real images where grounding is difﬁcult, attributes

are more diverse and data biases are hard to control.

To make learning more effective and less expensive,

we rely on NMN but employ predeﬁned cross-modal

embeddings to “warm start” the training process on

GQA, then explore Curriculum Learning to improve

learning of such a complex task and reduce both the

cost and the amount of data required.

Curriculum Learning (CL) (Elman, 1993; Soviany

et al., 2022; Wang et al., 2022) consists in learning the

easier parts of the task ﬁrst, rather than the entire task

at once. However, adequate difﬁculty criteria are not

easy to deﬁne. We show that by an appropriate se-

lection of these criteria for VQA, the cost of training

can be signiﬁcantly reduced and less training data is

required to reach a comparable level of accuracy.

To summarize, the contributions of our work are

three fold:

• First, we employ text and image object embed-

dings produced by a cross-modal transformer,

with the goal of aligning multi-modal features

to reinforce joint data patterns and thus help the

learning process to achieve results faster.

• Second, we propose several Curriculum Learning

strategies to reduce both the training cost and the

amount of data required for learning complex rea-

soning tasks.

• Third, we deﬁne and employ intermediate mod-

ule losses (one per module) during training, using

ground-truth labels generated from image graphs.

The aim is to stabilize the learning and help the

888

Aissa, W., Ferecatu, M. and Crucianu, M.

Curriculum Learning for Compositional Visual Reasoning.

DOI: 10.5220/0011895400003417

In Proceedings of the 18th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2023) - Volume 5: VISAPP, pages

888-897

ISBN: 978-989-758-634-7; ISSN: 2184-4321

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

modules converge to the expected behavior de-

ﬁned by the modules’ ground-truth and controlled

by the local loss.

The paper is organized as follows: the next sec-

tion situates our proposals in the context of existing

work on VQA and Curriculum learning, Sec. 3 de-

scribes the modular framework we employ and our

use of cross-modal features. Then in Sec. 4 we deﬁne

and motivate the CL strategies we propose. Evalua-

tion results are presented and discussed in Sec. 5.

2 RELATED WORK

We ﬁrst review some recent work on visual reasoning

for VQA. We then turn to the use of Curriculum learn-

ing for complex tasks, more speciﬁcally for VQA.

2.1 Visual Question Answering

VQA is usually addressed with either integrated

cross-modal frameworks or compositional neural

module networks.

Cross-Modality Transformers. Transformer net-

works (Vaswani et al., 2017) have been widely ap-

plied to multiple language and vision tasks, and they

have been recently adapted for reasoning problems

such as VQA. Models like ViLBERT (Lu et al., 2019),

VisualBERT (Li et al., 2019b) and LXMERT (Tan

and Bansal, 2019) showcased good performances on

the VQA datasets VQA2.0 (Goyal et al., 2017) and

GQA (Hudson and Manning, 2019). These frame-

works start by extracting the text and image fea-

tures: word embeddings are obtained via a pretrained

BERT (Devlin et al., 2019) model, while Faster R-

CNN (Ren et al., 2015) produces image region bound-

ing boxes and corresponding visual features. Then, a

cross-attention mechanism allows to align word em-

beddings and image features after training on a wide

range of multi-modal tasks. One downside of inte-

grated visual reasoning models is their lack of inter-

pretability. Another drawback is their tendency to

make “shortcuts” in reasoning, by learning the bias

in the data as evidenced by their limited performance

on the out-of-distribution data in GQA-OOD (Ker-

vadec et al., 2021). However, an effective cross-

modal feature encoder can be obtained by discarding

the ﬁnal classiﬁcation component from an integrated

model. We employ here input features generated by

an off-the-shelf large-scale cross-modal transformer

encoder.

Neural Module Networks (NMN). To make the

reasoning process more transparent and human-like,

compositional NMNs (Hu et al., 2017; Li et al.,

2019a) perform multi-hop reasoning by decompos-

ing a complex reasoning task into several easier sub-

tasks. An NMN consists of a generator and an ex-

ecutor. The generator maps a question to a sequence

of reasoning instructions (called a program). The ex-

ecutor assigns each sub-task from this program to a

neural module and passes the results to the next mod-

ules. In (Chen et al., 2021) a meta-learning approach

is employed in the NMN framework to improve the

scalability and generalization of the resulting model.

The generator decodes the question into a program

whose sub-tasks are used to instantiate a meta mod-

ule. The image features are extracted by a visual

encoder implemented as a transformer network and

a cross-attention layer mixes word embeddings and

image features. While the combination of a gener-

ator and an executor in NMNs appears more com-

plex than an integrated model, the “hardwired” rea-

soning process of an NMN is inherently transparent

and has the potential to avoid part of the reasoning

“shortcuts” caused by data bias. Interestingly, it was

shown in (Kervadec et al., 2021) that by using the pro-

grams resulting from questions as additional supervi-

sion for the LXMERT integrated model allows to re-

duce sample complexity and improve performance on

GQA-OOD. In our work, we aim to take advantage

of both the transparency of NMN architectures and

the quality of transformer-encoded representations by

implementing a composable NMN over multimodal

transformer vision and language features.

2.2 Curriculum Learning

Curriculum learning was introduced in (Elman, 1993)

where the author shows that successful learning may

depend on “starting small” by ﬁrst learning a simple

grammar with a recurrent network and then gradually

learning more complex tasks such as relative clauses,

number agreement, etc. CL was later applied to var-

ious machine learning tasks and recently adapted to

textual question answering (QA) in (Liu et al., 2018).

The authors use a sampling function that gives higher

selection weights to simple QA pairs and then, as the

training advances, it selects more complex QA pairs.

A term frequency selector and a grammar selector as-

sess the difﬁculty of the training examples. In (Sachan

and Xing, 2016) CL is reframed as a self-paced learn-

ing (SPL) algorithm and the question loss is taken as

the measure of difﬁculty. The authors implement sev-

eral heuristics reminding of active learning in order to

improve SPL performance.

Curriculum Learning for Compositional Visual Reasoning

889

Curriculum Learning for VQA. The deﬁnition of

relevant difﬁculty criteria for VQA is challenging and

this may explain why there is little work on the use

of CL for VQA. The recent work in (Askarian et al.,

2021) applies CL in a modular VQA context to the

synthetic CLEVR dataset (Johnson et al., 2017a). The

base model is from (Johnson et al., 2017b), with an

LSTM generator and generic residual blocks for the

executor modules. The experiments were conducted

on the executor alone, using as input the ground-truth

programs directly. Several difﬁculty criteria were

evaluated, including program length, answer hierar-

chy, and question loss. The results demonstrated that

CL with a question loss difﬁculty criterion has a pos-

itive impact in a low data setting. However, the study

in (Askarian et al., 2021) was focused on the CLEVR

dataset (Johnson et al., 2017a) consisting of synthetic

images of simple 3D objects, with a limited number of

classes or attributes and reliable object detection. In

our work, we employ the GQA dataset that is based

on real-world images with many classes and several

names for some of them, as well as more complex

relations and more challenging object detection. We

thus have to completely redeﬁne the candidate CL

strategies.

3 MODULAR VQA FRAMEWORK

Our model takes as input a triplet composed of an im-

age, a question and a program, and predicts an an-

swer. We start by extracting aligned language and vi-

sion features for both the image and the question us-

ing a state-of-the-art cross-modal transformer. Then

the program, which is a sequence of modules, is used

to build the neural modules network that is executed

on the image to answer the question (see Fig. 1). In

the next subsections, we present the feature extraction

process and describe the program executor.

Cross-Modal Features. Compositional visual rea-

soning aims to perform logical and/or geometrical in-

ferences involving several related objects in a com-

plex scene. To achieve this, the reasoning modules are

conditioned by text arguments. The visual and tex-

tual representations are vital to the reasoning process,

therefore having good bounding box features and

question text embeddings is crucial. To extract cross-

modal language and vision representations we rely

on LXMERT (Tan and Bansal, 2019), a transformer

model pretrained on multiple multi-modal tasks such

as Masked Cross-Modality language models, masked

object predictions, Cross-Modality Matching, and

VQA. LXMERT showcases high accuracy on the

training tasks, so we employ it as a feature extrac-

tor. It is worth mentioning that we only use the

cross-modality encoder representations and discard

the answer classiﬁcation component. More precisely,

we freeze LXMERT weights and we pass the im-

age I through the object-relationship encoder and the

question Q through the language encoder. Then, the

Cross-Modality Encoder aligns the representations to

ﬁnally output the object bounding box features v

each object o

in the image I and the embedding h

each word q

in the question Q.

Neural Modules. Our compositional reasoning

model allows to perform complex reasoning tasks by

decomposing them into easier sub-tasks. These sub-

tasks are inspired by the human generic reasoning

skills such as object detection, attribute identiﬁcation,

object relation recognition, object comparison, etc.

We designed a library of modules where each module

is responsible for performing a reasoning sub-task.

The modules were designed to be intuitive and eas-

ily interpretable, each of them being implemented by

a series of basic algorithmic operations such as dot

products and MLPs. Modules can be categorized into

three different groups based on their output type: at-

tention, boolean and answer modules. For instance,

an attention module such as Select is responsible of

detecting an object bounding box by rendering an at-

tention vector over the object bounding boxes con-

tained in the image. Boolean modules such as And or

Or make logical inferences and answer modules such

as QueryName give a probability distribution over the

answer vocabulary. Table 1 shows an example from

each module category. An exhaustive module list with

deﬁnitions is provided in the appendix.

Modular Network Instantiation. A program con-

sists of a sequence of modules implemented as neural

networks, as illustrated in Table 1. Each program is

instantiated as a larger NMN following the sequence

of program modules, where each module has depen-

dencies d

to get information from the previous one,

and arguments a

to condition its behavior. For ex-

ample, the FilterAttribute module depends on the

output of the Select module: it shifts the attention on

the selected objects corresponding to the input text ar-

gument. The program executor is responsible of man-

aging module dependencies by using a memory buffer

to save the outputs that serve as inputs for the next

modules. The design insures that a module can have

at most two dependencies.

The generic modules require a textual argument

m,i

to determine which facet of the module to use,

for example, the FilterAttribute module can be

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

890

Figure 1: The proposed modular VQA framework: The (question, image) pair is used by a transformer model to generate

aligned cross-modal embeddings for words and objects. These are used by a Program Generator module to produce a program

(represented as a sequence of sub-task modules), which will be then applied by the Program Executor module to the image

to answer the question. The proposed work focuses on improving the Program Executor by using several curriculum learning

(CL) strategies.

Table 1: Sample module deﬁnitions. S: softmax, σ: sig-

moid, r: RELU, W

: weight matrix, a: attention vector

(36 × 1), V: visual features (768 × 36), t: text features

(768 × 1), ⊙: Hadamard product.

Name Dependencies Output Deﬁnition

Select − attention

x = r(Wt)

Y = r(WV)

o = S(W(Y

x))

RelateSub [a] attention

x = r(Wt)

Y = r(WV)

z = S(W(Y

x))

o = S(W(x ⊙ y ⊙ z))

VerifyAttr [a] boolean

x = r(Wt)

y = r(W(Va)

o = σ(W(x ⊙ y))

And [b

] boolean

o = b

× b

ChooseAttr [a] answer

x = r(Wt)

y = r(W(Va)

o = S(W(x ⊙ y))

QueryName [a] answer

y = r(W(Va))

o = S(Wy)

called for multiple attribute categories such as color

and size. For instance, to ﬁlter the red objects we use

the argument word “red” and input its cross-modal

embedding to the module.

Module Execution Supervision. The executor net-

work takes as input an image in the form of a list

of object bounding boxes and their LXMERT em-

beddings. Every executor network ends with an an-

swer module, the output of which is compared to

the ground-truth to compute the output loss. To help

modules converge faster to their expected behavior we

also add the loss of each module to the output loss.

The ground truth for each module is extracted from

the image graphs given by the GQA dataset. Each

image graph has k assigned bounding boxes bbox

∗

1...k

with their names, coordinates, attributes, and rela-

tions. Since we have two different intermediate mod-

ule types, we deﬁne an intermediate loss for the atten-

tion modules and another for the boolean modules.

4 CURRICULUM LEARNING

FOR VQA

Our aim is to study CL for VQA and ﬁnd a CL method

that allows to signiﬁcantly reduce training cost while

making a better use of the data.

A CL method is usually deﬁned by a difﬁculty

criterion, a scheduler and a sampling function. The

difﬁculty criterion allows to characterize the samples:

training starts with the easiest samples, then progres-

sively moves toward more difﬁcult samples. Ques-

tion loss was employed with some success as a difﬁ-

culty criterion in (Sachan and Xing, 2016) for QA and

in (Askarian et al., 2021) for VQA. However, com-

puting question loss requires a ﬁrst training iteration

over all the training data. To make our own difﬁ-

culty criteria, we assume that reasoning about a sin-

gle object and its properties is simpler than examining

the relations between several objects and comparing

their attributes. The number of different objects in

Curriculum Learning for Compositional Visual Reasoning

891

the question should then be a good indication of the

complexity of reasoning and thus a relevant a priori

difﬁculty criterion for CL. Program length is another

potentially relevant criterion that takes into account

the ﬂow of gradient in module networks correspond-

ing to longer programs and is related to the previous

criterion (more objects in the question require longer

programs). Note that several criteria can be combined

to deﬁne the increasing difﬁculty of the training sam-

ples in CL. When employing the number of objects

as a primary criterion, we also evaluate its reﬁnement

based on program length: for each number of objects

in the question, we start with the short programs, then

continue with the medium length ones and end with

the long programs.

The scheduler in CL decides when the curriculum

should be updated. A simple solution is to employ a

ﬁxed sample size for each difﬁculty level. The evolu-

tion of the loss can be employed to adjust this size.

The sampling function allows to modulate the se-

lection of training samples within each difﬁculty level

and works by assigning weights to all the examples. A

relevant choice is to balance the occurrence probabili-

ties of the different types of answer modules. Another

criterion, used in boosting, is to privilege programs

that lead to higher errors.

When the curriculum is updated, the new training

sample has a higher level of difﬁculty than the pre-

vious ones. This does not mean that it subsumes the

past samples and this is particularly true for the com-

plex task of VQA. To avoid catastrophic forgetting,

we add to the current sample (corresponding to the

current difﬁculty level) a random selection from the

past samples.

5 EXPERIMENTS

5.1 Experimental Setup

GQA Dataset. GQA (Hudson and Manning, 2019)

features over 18M compositional questions and 113K

real-world images. The reasoning steps of the ques-

tions are represented by functional programs. The

questions and programs are generated by a question

engine from the corresponding image graph. The im-

age graphs are composed from ground-truth object

bounding boxes together with their names, attributes,

and relations. GQA is based on the Visual Genome

dataset.

The GQA dataset has two versions: a balanced

version (with a uniform distribution over the answers)

and an unbalanced one. For the unbalanced version,

the train-all split has over 14M examples and the

testdev-all has 172,174 examples, while the bal-

anced version has over 943,000 examples for train,

132,062 for val and a testdev of 12,578 examples.

To have a larger number of examples available for

CL, we use the unbalanced GQA dataset. The exper-

iments trained on the balanced dataset use the union

of train and val as done in (Tan and Bansal, 2019),

this combination also allows us to get over 1M ex-

amples when training on the balanced set. We follow

the recommendations of the dataset authors by evalu-

ating the performance on the test-dev split instead

of the val split when using the object-based features

because they were trained on some images from the

val set (Anderson et al., 2018).

In the GQA dataset, each question/image pair

in the train, val, and testdev sets is associated

with a functional program. The programs use 124

distinct modules, some of which only correspond

to very few questions. We consider that modules

should only differ when they correspond to operations

that are different. We thus group speciﬁc modules

into more general ones. For example, modules like

ChooseHealthier and ChooseOlder are grouped in

a ChooseAttribute module. This results in only

32 modules, the list of which is presented in the ap-

pendix.

Metrics. Several metrics are employed to compare

CL and standard learning. Since our focus is on

reducing the cost of training, we measure the to-

tal number of example presentations during training

(Comp. cost). We also mention the maximal number

of different examples seen during training (# exam-

ples), as different methods can make use of larger or

smaller portions of the training set. While we focus

on the cost of training, we nevertheless want to reach

an accuracy that is close to the one obtained by stan-

dard learning, so we also report the accuracy of the

predicted answers.

5.2 Evaluated Methods

When describing the different performed exper-

iments, we use the following notations, which

correspond to different algorithmic choices:

– Unbalanced: We train on all the examples from the

unbalanced GQA train split, we use the traditional

random batch training strategy and the model sees all

the data examples in every epoch.

– Balanced: We train on the balanced version of the

GQA dataset. At every epoch, the model is trained on

all the balanced dataset examples.

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

892

– Random: Instead of training on all the dataset

examples, only 1M random examples from the

unbalanced dataset are presented to the model at

every iteration.

– CL: The model is trained using Curriculum Learn-

ing and the ﬁltering is driven by the number of objects

in the programs. At every CL iteration the model sees

1M examples ﬁltered from the unbalanced dataset

by the curriculum sampler. The training needs 4 CL

iterations to be complete, where each iteration has an

increased difﬁculty given by the number of objects of

its programs (ranging from 1 to 4).

– Length (L): The curriculum sampler ﬁlters the pro-

grams by their lengths for every number of objects, a

CL-iteration is deﬁned by a number of objects and a

program length (short or medium or long).

– Weights (W): We use several sampling weights

for the ﬁltered programs: ‘uniform’ indicates that

the sampling is uniform, so the sampling with

replacement results in a sample that is uniformly

distributed over all the dataset. To make the answer

modules distribution of the resulting sample more

uniform we use the ‘answer module’ weighting

(denoted by W.a); this balances the answer modules

appearances in the result sample so that the model

equally sees all the deﬁned answer modules. The

‘modules loss’ weighting (denoted by W.b) indicates

that the example’s weight is proportional to the sum

of the average losses of the modules composing its

program, to focus the model on hard examples.

– Pretrain (P): The model’s parameters are initial-

ized from a model trained using the Random variant

described above.

– Repeat (R): We repeat the same CL-iteration twice.

5.3 Implementation Details

We perform the experiments using the pre-processed

GQA dataset programs and we focus on investigat-

ing the effect of several CL policies on the Program

Executor module. Although our system also uses a

transformer model as a generator to translate the ques-

tion to its corresponding program, its task is relatively

easy compared to the executor training and, simi-

lar to previous works (Li et al., 2019a; Chen et al.,

2021), we achieve near perfect translation results on

the testdev-all set.

We employ LXMERT as a feature extractor and

freeze its weights. LXMERT image inputs are the ob-

ject bounding boxes provided by a Faster R-CNN ob-

ject detection model (Anderson et al., 2018), where

the number of bounding boxes per image is ﬁxed to

36. We feed the questions and their corresponding ob-

ject bounding boxes to LXMERT; the encoding yields

36 object features and the question word embeddings

for each question/image pair. The extracted features

and embeddings have the size of the LXMERT hidden

size, i.e. 768.

During CL, we ﬁx the sample size to 1M ex-

amples per CL iteration. Starting from the second

CL iteration, 20% of the training sample is sam-

pled from the examples seen in the previous itera-

tion. Concerning the number of training examples,

it is worth mentioning that we sample the training ex-

amples with replacement. Therefore, the number of

distinct examples seen by the executor is lower than

the sample size. To reduce the complexity of our

proposed model, we allow weight sharing between

compatible modules. For example, the relateObj

and relateSub modules have similar structures and

functionalities, both have visual and textual layers to

project bounding box features and word embeddings

in a multi-modal reasoning space (they also have an

output layer to classify the answer). These two mod-

ules also have similar functionalities, i.e. they both re-

late to an object given an anchor object and a relation

but they have a different relation direction. Therefore,

we share the weights between the visual layers and the

textual layers of both modules respectively, but with-

out sharing the output layers to guarantee transitional

direction differences. For training all the models we

use SGD with a learning rate of 0.1 and a batch size

of 1024.

5.4 Evaluation Results

This section presents an analysis of the performance

and the cost of our modular VQA framework with

multiple CL training strategies, followed by a com-

parison with models not using CL to show the effec-

tiveness of our proposed training approach.

Comparison of CL Methods. We start by a com-

parative analysis of the proposed CL strategies as de-

scribed in Sec. 4. Table 2 reports the performance of

our model based on the different CL conﬁgurations

detailed in Sec. 5.2. The goal of CL is to make the

training more effective and to achieve the highest ac-

curacy while training for fewer iterations. Therefore,

for each model are shown the number of iterations and

training examples required to reach the highest accu-

racy.

From the results, it is clear that the ‘answer’

Curriculum Learning for Compositional Visual Reasoning

893

Table 2: Results on testdev-all for several CL strategies.

Model

CL conﬁguration

Iterations

Number of

Accuracy

weighting pretraining iterations/level examples (≤)

CL+W.a answer − 1 4 4 M 0.642

CL+W.b losses − 1 4 4 M 0.635

CL+W.a+P answer 2 iterations 1 [2] + 3 5 M 0.670

CL+W.a+P+R answer 2 iterations 2 [2] + 5 7 M 0.681

weighting is the most effective weighting function.

One can see this as a balancing of the answer mod-

ules presence over the training sample. The CL+W.a

model (using the ‘answer’ weighting) achieves higher

accuracy results than the CL+W.b model (with the

‘losses’ weighting), both reaching their top respective

accuracies after 4 training iterations only. The ‘an-

swer’ weighting also yields better accuracy than the

‘uniform’ weighting after the same number of train-

ing iterations. This is shown by comparing CL+L

and CL+L+W.a in Table 3. Moreover, the accuracy

of CL+L+W.a continues to increase after the 11th it-

eration to achieve its top at iteration 12. The supe-

rior performance of the ‘answer’ weighting function

in two different comparable settings makes us select

this weighting for the rest of the experiments.

The reﬁnement of the CL difﬁculty (or hard-

ness) measure using the number of question objects

(Length-CL difﬁculty measure) increases the CL+W.a

top accuracy by 1%, see the CL+L+W.a line in Ta-

ble 3. However, this improvement has a signiﬁcant

cost, as CL+L+W.a requires 12 training iterations

(12M examples) unlike CL+W.a which only needs 4

iterations (4M examples). This reinforces the idea

that with a more reﬁned difﬁculty measure the model

has more time to adjust to difﬁcult examples, and its

accuracy gradually increases to achieve a better top

accuracy in a CL setting. But training on 12M ex-

amples is expensive since the overall dataset size is

14M examples. We thus decided to explore different

options to obtain comparable results at a lower cost.

A promising ﬁnding was that pretraining the mod-

els for a few iterations with a randomly sampled 1M

examples each leads to an accuracy increase of over

1.5%, as shown by the CL+W.a+P model which was

pretrained for only 2 iterations. This “warms up” the

model to the modular aspect of our VQA framework,

Table 3: Results on testdev-all with program length as

a reﬁnement for the CL difﬁculty measure. Computation

cost is the number of seen examples per iteration times the

number of iterations.

Model Comp. cost # examples Accuracy

CL+L 11 11 M 0.650

CL+L+W.a 12 12 M 0.655

allowing it to be more general and effective before

starting the CL. An interesting ﬁnding was that the

model reached peak accuracy before iterating over the

full CL conﬁguration. The accuracy drop resulting af-

ter the 4th iteration may be explained by model over-

ﬁtting on the questions with 4 objects. Indeed, in the

GQA dataset these questions have a substantially un-

balanced answer distribution.

A further ﬁnding is that repeating the same CL-

iteration twice (as in CL+W.a+P+R) improves the

top accuracy results by 1.1%, while only moderately

increasing the number of iterations. This can be

explained by the fact that doubling the number of

training iterations helps the model better understand

the structure of training data without augmenting the

training data size. As detailed in Sec. 5.3, when sam-

pling with replacement we obtain a number of distinct

examples that is slightly lower than the sample size,

therefore the reported number of examples (# exam-

ples) is an upper bound of the # examples actually

employed.

As a general conclusion, we consider the

CL+W.a+P+R model as the best modular VQA model

that scores the best accuracy of 68.1% after 7 training

iterations using less than 7M distinct examples, i.e.

less than half of the training data.

Impact of CL. We perform several experiments to

assess the impact of the CL on our compositional vi-

sual reasoning framework. We do this by training our

model without CL (Unbalanced, Balanced, and Ran-

dom), then comparing the accuracy performance and

the experiment cost in terms of computation cost and

training data examples. In Table 4 we report the ac-

curacy and cost results of the conducted experiments

and compare them to the performance of our best CL

model CL+W.a+P+R.

The Unbalanced model (trained on the entire un-

balanced training set of 14M) achieves the highest ac-

curacy value of 70.2%. This model also has the high-

est training cost among the evaluated models.

The Balanced model, trained on the balanced

dataset for a large number of epochs, achieves lower

results than the Unbalanced model. This is partly due

to the fact that the balancing reduces not only the

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

894

number of questions in the dataset, but also the di-

versity of the programs. Also, to the use of the unbal-

anced testdev-all for evaluation.

By comparing our best CL model

(CL+W.a+P+R) to the models trained without

CL (no-CL), we ﬁnd very signiﬁcant gains in terms

of computational cost, e.g. an 18-fold reduction

compared to the top contender, the model trained on

the Unbalanced dataset. The price to pay—a drop

of only 2% in accuracy—appears reasonable. The

Random model, trained on randomly sampled 12M

examples, performs almost as well as the Unbalanced

model, an expected result since both models use a

similar amount of distinct training examples (12M

vs 14M). The Unbalanced model requires an almost

9 times more expensive training than Random, but

the improvement in accuracy (70.2 % vs. 69.4%)

hardly justiﬁes it. However, the proposed CL model

has an almost 2 times lower computational cost than

Random, conﬁrming the superiority of curriculum

learning in this type of application.

Table 4: Comparaison of our CL model (CL+W.a+P+R)

with no-CL models (Unbalanced, Balanced, and Random)

on the testdev-all set.

Model Comp. cost # examples Accuracy

Unbalanced 9 × 14 M 14 M 0.702

Balanced 50 × 1.4 M 1.4 M 0.678

Random 12 × 1 M ≤ 12 M 0.694

CL+W.a+P+R 7 × 1 M < 7 M 0.681

6 CONCLUSION

In this work we present several Curriculum Learn-

ing (CL) strategies within a Neural Module Net-

work (NMN) framework for Visual Question An-

swering (VQA). Our visual reasoning approach lever-

ages a cross-modal Transformer encoder to extract

aligned question/image features along with question

programs to perform multi-step reasoning over the

image and predict an answer. Our model employs

an NMN architecture composed of multiple neural

modules, each capable of performing a reasoning sub-

task. We compare several CL strategies for VQA. Our

model is evaluated on the GQA dataset and shows

very interesting results in terms of computational cost

reduction. To drive the CL strategy, we introduce a

difﬁculty measure based on the number of objects in

the question and we achieve close accuracy results by

training on a judiciously sampled 50% of the training

data, compared to an NMN model trained without CL

on the entire training set.

ACKNOWLEDGEMENTS

We thank Souheil Hanoune for his insightful com-

ments. This work was partly supported by the French

Cifre fellowship 2018/1601 granted by ANRT, and by

XXII Group.

REFERENCES

Anderson, P., He, X., Buehler, C., Teney, D., Johnson, M.,

Gould, S., and Zhang, L. (2018). Bottom-up and top-

down attention for image captioning and visual ques-

tion answering. In CVPR.

Askarian, N., Abbasnejad, E., Zukerman, I., Buntine, W.,

and Haffari, G. (2021). Curriculum learning ef-

fectively improves low data VQA. In Rahimi, A.,

Lane, W., and Zuccon, G., editors, Australasian

Language Technology Association Workshop (ALTA)

2021, pages 22–33. ACL.

Chen, W., Gan, Z., Li, L., Cheng, Y., Wang, W. Y., and Liu,

J. (2021). Meta module network for compositional

visual reasoning. In WACV.

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2019). BERT: Pre-training of deep bidirectional

transformers for language understanding. In Proc.

2019 Conf. ACL, pages 4171–4186.

Elman, J. L. (1993). Learning and development in neural

networks: the importance of starting small. Cognition,

48(1):71–99.

Goyal, Y., Khot, T., Summers-Stay, D., Batra, D., and

Parikh, D. (2017). Making the V in VQA matter:

Elevating the role of image understanding in Visual

Question Answering. In CVPR.

Hu, R., Andreas, J., Rohrbach, M., Darrell, T., and Saenko,

K. (2017). Learning to reason: End-to-end module

networks for visual question answering. In ICCV.

Hudson, D. A. and Manning, C. D. (2019). GQA: A new

dataset for real-world visual reasoning and composi-

tional question answering. In CVPR.

Johnson, J., Hariharan, B., van der Maaten, L., Fei-Fei, L.,

Zitnick, C. L., and Girshick, R. B. (2017a). CLEVR:

A diagnostic dataset for compositional language and

elementary visual reasoning. In CVPR.

Johnson, J., Hariharan, B., Van Der Maaten, L., Hoff-

man, J., Fei-Fei, L., Zitnick, C. L., and Girshick, R.

(2017b). Inferring and executing programs for visual

reasoning. In ICCV.

Kervadec, C., Wolf, C., Antipov, G., Baccouche, M., and

Nadri, M. (2021). Supervising the transfer of reason-

ing patterns in VQA. In NeurIPS.

Li, G., Wang, X., and Zhu, W. (2019a). Perceptual visual

reasoning with knowledge propagation. In ACM MM,

MM ’19, page 530–538, New York, NY, USA. ACM.

Li, L. H., Yatskar, M., Yin, D., Hsieh, C., and Chang, K.

(2019b). VisualBERT: A simple and performant base-

line for vision and language. CoRR, abs/1908.03557.

Curriculum Learning for Compositional Visual Reasoning

895

Liu, C., He, S., Liu, K., and Zhao, J. (2018). Curricu-

lum learning for natural answer generation. In IJCAI.

AAAI Press.

Lu, J., Batra, D., Parikh, D., and Lee, S. (2019). ViL-

BERT: Pretraining task-agnostic visiolinguistic repre-

sentations for vision-and-language tasks. In NeurIPS.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster R-

CNN: Towards real-time object detection with region

proposal networks. In NeurIPS.

Sachan, M. and Xing, E. (2016). Easy questions ﬁrst? A

case study on curriculum learning for question an-

swering. In Proc. 54th Annual Meeting of the ACL,

pages 453–463, Berlin, Germany. ACL.

Soviany, P., Ionescu, R. T., Rota, P., and Sebe, N. (2022).

Curriculum learning: A survey. Int. J. Comput. Vis.,

130(6):1526–1565.

Tan, H. and Bansal, M. (2019). LXMERT: Learning cross-

modality encoder representations from transformers.

In Inui, K., Jiang, J., Ng, V., and Wan, X., editors,

EMNLP/IJCNLP (1), pages 5099–5110. ACL.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, L., and Polosukhin, I.

(2017). Attention is all you need. In NeurIPS.

Wang, J., Ji, Y., Sun, J., Yang, Y., and Sakai, T. (2021).

MIRTT: learning multimodal interaction representa-

tions from trilinear transformers for visual question

answering. In Moens, M., Huang, X., Specia, L.,

and Yih, S. W., editors, Findings of the Association

for Computational Linguistics: EMNLP 2021, Vir-

tual Event / Punta Cana, Dominican Republic, 16-20

November, 2021, pages 2280–2292. Association for

Computational Linguistics.

Wang, X., Chen, Y., and Zhu, W. (2022). A survey on cur-

riculum learning. TPAMI, 44(9):4555–4576.

Xiong, P., Shen, Y., and Jin, H. (2022). MGA-VQA: multi-

granularity alignment for visual question answering.

CoRR, abs/2201.10656.

APPENDIX

In this appendix, for reference purposes, we present

the exhaustive list of modules together with their de-

pendencies, types, and deﬁnitions (see Table 5). The

column ‘output’ represents the module type: Atten-

tion, Boolean, or Answer.

Attention modules produce an attention vector a

where each element represents the relevance of the

attended image object. Boolean modules make log-

ical inferences and output a scalar representing the

probability of the outcome. Answer modules give a

probability distribution over the answer classes.

As mentioned in Section 5.3, we used a weight

sharing technique to reduce the number of the model

parameters; this also allows the shared layers to have

a better deﬁned behavior and to be updated based on a

larger number of training examples. The overall prin-

ciple is that a transfer is made only between some of

the textual and visual layers, each module having a

distinct output layer to guarantee its ﬁne-tuning to the

module’s sub-task.

To decide what layers from which modules will

share parameters, we assess the similarity between the

modules by analyzing their functional and architec-

tural properties. The former is derived from the mod-

ule reasoning sub-task and the latter is derived from

the module layer architectures. We cannot exhaus-

tively describe here all the performed analysis, but in

the following, we exemplify our strategy by compar-

ing some of the modules and explaining their inher-

ent similarities and differences. The Select mod-

ule detects a relevant bounding box (given the name

of an object) and the FilterAttr detects a relevant

bounding box given an attribute. Functionally, they

both solve a detection problem but have different tex-

tual argument semantics. Architecturally, they both

have the same layer structure: a textual layer, a vi-

sual layer, and an output layer. We decide to share the

visual layer between these two modules but use differ-

ent textual layers to respect the semantic differences

between the textual arguments.

However, FilterAttr can share its textual layer

with other modules having an attribute as a textual

argument (VerifyAttr, FilterNot).

The Same and Different boolean modules assess

whether or not two selected objects share the same

characteristic (provided by the textual argument). The

probability p of two objects being similar is the oppo-

site of them being different. Therefore, they share the

same layers including the output layer and we use the

relation p(Different) = 1 − p(Same) to differentiate

them.

The object relations modules such as RelateSub

and RelateObj have similar functionalities and neu-

ral structures. They share their visual layers to get a

common scene representation and they share the tex-

tual layer due to the semantic similarity of their argu-

ments (a relation).

VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications

896

Table 5: Exhaustive module deﬁnitions. S: softmax, σ: sigmoid, r: RELU, W: weight matrix, a: attention vector (36 × 1),

b: boolean scalar, V: visual features (768 × 36), t: text features (768 × 1), ⊙: Hadamard product, [a∥b]: concatenation,

min: element-wise minimum.

Name Dependencies Output Deﬁnition

Select − attention

x = r(W t), Y = r(WV),

o = S(W(Y

x))

FilterAttr [a] attention

x = r(W t), Y = r(WV), z = S(W(Y

x)),

o = min(a, z)

FilterNot [a] attention

x = r(W t), Y = r(WV), z = S(W(Y

x)),

o = min(a, 1 − z)

FilterPos [a] attention

x = r(W t), Y = r(WV), z = S(W(Y

x)),

o = min(a, z)

RelateSub [a] attention

x = r(W t), Y = r(WV), z = S(W(Y

x)),

o = S(W(x ⊙ y ⊙ z))

RelateObj [a] attention

x = r(W t), Y = r(WV), z = S(W(Y

x)),

o = S(W(x ⊙ y ⊙ z))

RelateAttr [a] attention

x = r(W t), Y = r(WV), z = S(W(Y

x)),

o = S(W(x ⊙ y ⊙ z))

Fusion [a

] attention o = min(a

, a

)

And [b

] boolean

o = b

× b

Or [b

] boolean

o = b

+ b

− b

× b

Same [a

] boolean

x = r(W t), y = r(W(Va

)), z = r(W(Va

)),

o = σ(W(x ⊙ y ⊙ z))

SameAll [a] boolean

x = r(W t), y = r(W(Va)),

o = σ(W(x ⊙ y))

Different [a

] boolean

o = 1 − same(a

, a

)

DifferentAll [a] boolean

o = 1 − same(a)

Exist [a] boolean

o = σ(W([a ∥ max(a) ∥ min(a) ∥ mean(a)]))

VerifyRelSub [a

] boolean

x = r(W t), y = r(W(Va

)), z = r(W(Va

)),

o = σ(W(x ⊙ y ⊙ z))

VerifyRelObj [a

] boolean

x = r(W t), y = r(W(Va

)), z = r(W(Va

)),

o = σ(W(x ⊙ y ⊙ z))

VerifyAttr [a] boolean

x = r(W t), y = r(W(Va),

o = σ(W(x ⊙ y))

VerifyPos [a] boolean

x = r(W t), y = r(W(Va),

o = σ(W(x ⊙ y))

ChooseName [a] answer

x = r(W t), y = r(W(Va),

o = S(W(x ⊙ y))

ChooseAttr [a] answer

x = r(W t), y = r(W(Va),

o = S(W(x ⊙ y))

Compare [a

] answer

x = r(W t), y = r(W(Va

), z = r(W(Va

o = S(W(x ⊙ y ⊙ z))

ChoosePos [a] answer

x = r(W t), y = r(W(Va),

o = S(W(x ⊙ y))

ChooseRel [a

] answer

x = r(W t), y = r(W(Va

), z = r(W(Va

o = S(W(x ⊙ y ⊙ z))

Common [a

] answer

x = r(W(V a

), y = r(W(Va

o = S(W(x ⊙ y))

QueryName [a] answer

x = r(W(V a), o = S(W(x))

QueryAttr [a] answer

x = r(W(V a),

o = S(W(x))

QueryPos [a] answer

x = r(W(V a),

o = S(W(x))

AnswerLogic [b] answer

yes

= b, o

= 1 − b

Curriculum Learning for Compositional Visual Reasoning

897
