Attention-Based Explainability Approaches in Healthcare Natural

Language Processing

Haadia Amjad

, Mohammad Shehroz Ashraf

, Syed Zoraiz Ali Sherazi

, Saad Khan

Muhammad Moazam Fraz

, Tahir Hameed

and Syed Ahmad Chan Bukhari

Department of Computing, National University of Sciences and Technology, Islamabad, Pakistan

Department of Electrical Engineering, National University of Sciences and Technology, Islamabad, Pakistan

Girard School of Business, Merrimack College, North Andover, MA 01845, U.S.A.

Division of Computer Science, Mathematics and Science, St. John’s University, Queens, NY 11439, U.S.A.

skhan.msds20seecs@seecs.edu.pk, moazam.fraz@seecs.edu.pk, hameedt@merrimack.edu, bukharis@stjohns.edu

Keywords: Attention Mechanism, Explainability, Natural Language Processing, AI, Healthcare, Clinical Decision

Support Systems.

Abstract: Artificial intelligence (AI) systems are becoming common for decision support. However, the prevalence of

the black-box approach in developing AI systems has been raised as a significant concern. It becomes very

crucial to understand how an AI system makes decisions, especially in healthcare, since it directly impacts

human life. Clinical decision support systems (CDSS) frequently use Natural Language Processing (NLP)

techniques to extract information from textual data including Electronic Health Records (EHRs). In contrast

to the prevalent black box approaches, emerging 'Explainability' research has improved our comprehension

of the decision-making processes in CDSS using EHR data. Many researches use 'attention' mechanisms and

'graph' techniques to explain the 'causability' of machine learning models for solving text-related problems.

In this paper, we conduct a survey of the latest research on explainability and its application in CDSS and

healthcare AI systems using NLP. For our work, we searched through medical databases to find explainability

components used for NLP tasks in healthcare. We extracted 26 papers that we found relevant for this review

based on their main approach to develop explainable NLP models. We excluded some papers since they did

not possess components for inherent explainability in architectures or they included explanations directly

from the medical experts for the explainability of their work, leaving us with 16 studies in this review. We

found attention mechanisms are the most dominant approach for explainability in healthcare AI and CDSS

systems. There is an emerging trend using graphing and hybrid techniques for explainability, but most of the

projects we studied employed attention mechanisms in different ways. The paper discusses the inner working,

merits and issues in the underlying architectures. To the best of our knowledge, this is among the few papers

summing up latest explainability research in the healthcare domain mainly to support future work on NLP-

based AI models in healthcare.

1 INTRODUCTION

The development of AI systems has helped many

fields achieve benchmarks of efficiency. AI

technologies aim to provide faster and more accurate

results significantly improving the decision-making

process in many industries. These systems aid

professionals in making domain-related decisions in

https://orcid.org/0000-0003-0495-463X

https://orcid.org/0000-0002-6824-6803

https://orcid.org/0000-0002-6517-5261

nearly every field, from home lifestyle to banking, to

critical applications such as security and healthcare.

Their use in critical domains requires higher accuracy

as they directly impact human life. One common

issue in AI systems is they lack transparency about

inner working of the system. They typically follow a

black-box approach which makes it hard for the user

to comprehend their reasoning.

Amjad, H., Ashraf, M., Sherazi, S., Khan, S., Fraz, M., Hameed, T. and Bukhari, S.

Attention-Based Explainability Approaches in Healthcare Natural Language Processing.

DOI: 10.5220/0011927300003414

In Proceedings of the 16th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2023) - Volume 5: HEALTHINF, pages 689-696

ISBN: 978-989-758-631-6; ISSN: 2184-4305

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

689

AI systems make decisions based on criteria that

they can learn from the data and requirements of the

system. How these systems arrive at a decision is not

inherently interpretable, commonly referred as the

black-box approach of the AI (Castelvecchi, 2016).

This creates a lack of trust in the system for the user.

By not understanding the formation of intelligence of

a machine learning model, the user tends not to

believe in the correctness of the system (Nourani,

King, & Ragan, 2020). While a base understanding of

the working of a model could help this issue, the role

of the data segments that aided the learning process

remains unclear. Explainability is a concept that helps

in explaining the AI system to the user in such a

manner that they can understand how a model makes

a decision (IBM, n.d.). The use of Explainable

Artificial Intelligence (xAI) methods aids domain

experts in trusting these systems and making better

decisions, especially in healthcare AI and CDSS

(DeGrave et al., 2021; Savage, 2022).

In the medical domain, all decisions directly

impact human life. Any intelligent decision-support

system in this field should have high performance and

accuracy to be able to help a professional. While the

accuracy of the system is gravely important, the

understanding of their working directs the confidence

of the professional in using these systems (Cabitza et

al., 2021). While AI systems are involved in many

healthcare decisions and tasks, when it comes done to

the types of data being used, the two most typical are

medical images and clinical texts. Text data is

available in large amounts and formats. It is an

interesting task for a system to learn from these

documents and notes to make a decision.

Manually handling text data and using it to make

decisions in the healthcare domain is a lengthy

procedure, requiring massive attention to detail

(Wang et al., 2018). For an AI system to achieve this

with high accuracy, the model must have sufficient

data to train from and enough experimentation to

validate its use. The concept of manual attention

translates to AI systems in the form of attention

mechanism components (Hu , 2020). The attention

mechanisms, for text data, focus on the building

blocks of these texts, also called tokens. The tokens

could be words, phrases or even sentences. Putting

such attention on the data helps figure out the

importance of those segments that largely influence

the system's decision. Talking of manual decision-

making, this is how a domain expert would also do it,

by extracting the segments that point towards a

labelled decision. This attention mechanism aids

causable explanations for the AI system.

In our work, we review attention mechanisms

more closely for text data that is used in the healthcare

domain and summarise how different researchers

have made use of this component in AI architectures

to introduce explainability into their work. The paper

contributes mainly by reviewing latest literature on

emerging field of explainability approaches as

applied in the healthcare domain and by identifying

critical needs of improvement especially a need for

novel objective and comparable evaluation metrics

and criterion for explainability. In the rest of the

paper, we cover our methodology, a thorough

literature review, and our systematic observations and

findings of our review. We hope this helps guide

future researchers who aim to work in the area of

explainable AI and trust in AI systems.

2 METHODOLOGY

Attention mechanisms have been applied in a variety

of domains, including healthcare, resulting in

significant research content availability. Thus, it was

important to identify the scope of the papers being

presented in this review. To start with, the authors

jotted down the keywords that closely related to the

work being aimed for: ‘NLP’, ‘explainability’ and

‘clinical text’. These keywords were then used to

carry out searches on literary databases, namely

PubMed (J) and ScienceDirect (Hunter, 1998).

PubMed is a free search engine accessing primarily

the MEDLINE database of references and abstracts

on life sciences and biomedical topics, with

ScienceDirect being a website which provides access

to a large bibliographic database of scientific and

medical publications of the Dutch publisher Elsevier.

Furthermore, to ensure the relevancy of the work we

opted to include the research that has been carried out

between 2018 and 2022 inclusive. Any surveys and

papers that included research on medical images were

excluded as they did not fit the NLP explainability

theme. It resulted in 26 papers that matched the above

criteria.

The subset of papers was then passed through a

second layer of filtering. Papers in which the concepts

of explainability were vague, making it difficult for

users to comprehend the work, were excluded. The

finalized papers were then peer-reviewed by four

members to ensure that the selected papers apply

explainable NLP concepts as well as to identify a

common methodological trend being followed. In the

end, 16 out of 26 papers used attention mechanisms

in their architecture to emphasize explainable results.

This was concluded by looking at the base

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

690

architectures and the accompanying changes that

were carried out to incorporate attention. A focus was

also placed on the datasets being used, and the goal of

the base model on which attention is applied, mainly

because base model results determine the type of

attention to be used for explainability. Thus, this

directed our work to focus on the role of attention in

NLP for healthcare systems. The remaining 10 papers

did not fall into inherent explainable architectures.

They included descriptive explanations from medical

professionals and researchers themselves. Hence, we

decided not to include those in our review.

3 ATTENTION MECHANISM IN

HEALTHCARE INFORMATION

PROCESSING

In this section, we deeply review the work done in

healthcare to attain explainability in NLP problems.

To make AI architectures explainable, researchers

make additions to existing architectures or use

Explainable AI (xAI) models to attain interpretable

results.

Naylor et al (2021) used multiple classifiers with

varying interpretability and complexity on the

MIMIC-III dataset, a dataset including 40,000

records published by Beth Israel Deaconess Medical

Center. These classifiers include Logistic Regression

(LR), Explainable Boosting Machine (EBM),

Random Forest (RF), DL8.5, Boosted Rule Sets,

Bayesian Rule Lists, Optimal Classification Trees,

Certifiably Optimal RulE ListS (CORELS) and

BigBird. For LR, RF, and EBM, they use Local

Interpretable Model-agnostic Explanations (LIME)

and SHapley Additive exPlanations (SHAP) for

explainability. For other models, they considered

techniques such as saliency and integrated gradients.

To conclude their work, they used the Local Lipschitz

metric for evaluation. They concluded that a trade-off

may exist between model quality and interpretability

for models not typically used for text classification.

Xu et al. (2018) predict ICD-10 diagnostic codes

using a multimodal architecture making an ensemble

of Text-CNN, Decision Tree and a combination of

Char-CNN and Bidirectional LSTM. For their

interpretability section, they extracted training parts

and calculated an influence score for text features.

They employed LIME for tabular features. Their

interpretability results using Jaccard Similarity

Coefficient (JSC) are 0.1806 on text data and 0.3105

on tabular data. For most work in this area,

researchers use attention mechanism and knowledge

graphs that have been covered in the following

paragraphs.

3.1 Transformer-Based Architectures

Attention mechanisms are used for selective

concentration on feature extractions in deep learning

networks. The following studies induce novelty in

transformer-based architectures using attention

layers. Liu et al. (2022) introduced a novel

architecture in their work known as Hierarchical

Label-wise Attention Transformer Model (HiLAT).

They made ICD-9 code predictions on clinical

documents using HiLAT with an explainability

component. HiLAT uses a two-level label-wise

attention mechanism in a hierarchical manner that

produces label-specific representations of the

document. They also employed XLNet-Base on

clinical notes to develop ClinicalplusXLNet. HiLAT

+ ClinicalplusXLNet attained an F1 score of 73.5.

Mayya et al (2021) developed LATA, a neural

model built upon Label Attention Transformer

Architectures. The model comprises of multiple

encoder layers based on BERT model. The target

automatic assignment on ICD-10 codes using

CodiEsp dataset. Their model outperformed BERT

by 33-49% in precision, recall and F1 scores. The

label attention mechanism in LATA introduced the

explainability components in prediction. Feng et al.

(2020) proposed a novel architecture pipeline to

predict ICD-9 codes with an explainability

component. They used MIMIC-III discharge

summaries for testing their model. Their architecture

extracted sentences from documents and tokenized

them before passing them through BERT feature

extractor. This process generated word embeddings

that were input to a base Text-CNN resulting in

sentence features that were fed into a transformer.

The encoded features from the transformer were

passed on to a label-wise attention layer. The

attention representations were ultimately given to a

classifier for multi-label code predictions. Biswas et

al. (2021) also predicted explainable ICD-9 codes

with a transformer-based architecture combined with

a code-wise attention mechanism. They put deeper

attention to tokens of the clinical documents and

extracted code-specific representations. They achieve

a micro-AUC score of 0.923. Nguyen et al. (2021)

experimented with biomedical text classification and

pre-trained language models with label attention.

They developed a transformer-based architecture

with label attention for text classification. The label

attention mechanism was used in the fine-tuning

Attention-Based Explainability Approaches in Healthcare Natural Language Processing

691

process of pre-trained language models. The base

architecture used in this work is pre-trained BERT.

3.2 Convolutional Neural Networks

Some studies made use of traditional CNN models

and placed attention layers in the architecture to

achieve interpretability in multi-label classifiers.

Feucht et al. (2021) predicted explainable ICD-9

codes using description-based label attention. Their

model learnt code embeddings by integrating code

descriptions and then later assigning those

embeddings to text representation which in turn

resulted in a label-wise attention mechanism.

Trigueros et al. (2022) developed a multi-label

classifier for electronic health records in Spanish with

convolutional attention. They used the OSA Spanish

dataset and the MIMIC-III dataset. They compared

the results of a baseline CNN, attentive CNN and

regularised CNN. Hu et al. (2020) proposed Shallow

and Wide Attention convolutional Mechanism

(SWAM) for explainable model code prediction.

They used convolution layers to extract informative

snippets and important features, and the model then

selected the snippets of each code using an attention

mechanism and ultimately made code predictions.

The base architecture used in many of the above-

noted architectures is the Convolutional Attention

Mechanism for Multi-Label classification (CAML)

presented by Mullenbach et al. (2018). They used a

label-wise attention mechanism on max pooling

layers in a convolutional neural network for

predicting ICD-9 codes using the MIMIC-III dataset.

Mayya et al. (2021) designed a multi-channel

convolutional neural network with an attention

mechanism for medical code prediction on

unstructured discharge summaries, known as

Enhanced Convolutional Attention Network for

Multi-Label classification (EnCAML). They

experimented using MIMIC-III and CodiEsp

datasets. The text embeddings pass through

convolutional layers of different kernel sizes

followed by individual attention mechanisms

concatenated and followed by dense layers ultimately

predicting ICD-9 code prediction groups. The

explainability metric is evaluated using the Jaccard

score.

3.3 Long Short-Term Memory (LSTM)

and Gated Residual Network

(GRN)

The use of attention layers can be said to achieve

different results based on their type and placement in

the architecture, as seen from the work mentioned

thus far. Researchers have also used multiple

attention mechanisms for the same purpose of

interpretability with variants of Recurrent Neural

Networks (RNNs) the works we mention going

forward. Wang et al. (2021) created a novel

architecture in their work using multi-head attention

with the gated residual network to predict ICD-10

codes. They used Chinese electronic health records as

their dataset. In their architecture, the data

embeddings passed through a gated residual network

for supervised predictions and employed dot and

additive attention mechanisms on dilated

convolutional layers for explainability. They

achieved an F-1 score of 92.11.

In the work of Dong et al. (2021), Hierarchical

Label-wise Attention (HLAN) is introduced with the

concept of quantifying the importance of words using

attention weights. Their architecture includes two bi-

directional gated residual units, one with word-wise

attention and the second with label-wise attention.

They tested it on the MIMIC-III dataset and achieved

an F1 score of 64.1. Li et al. (2021) introduced JLAN,

a joint learning architecture of attention and denoising

mechanisms for ICD-9 codes using the MIMIC-III

dataset. Their approach tended to reduce the noise at

code allocation along with attention-based

architectures. Specifically, they employed self-

attention and label-attention mechanisms.

3.4 Multimodal Architectures

including Knowledge Graphs

Knowledge graphs (KGs) organise data from multiple

sources, capture information about entities of interest

in a given domain or task and forge connections

between them (The Alan Turing Institute, n.d.).

Knowledge Graphs are considered to be

inherently explainable. For this reason, they have

been adapted to many explainability tasks specifically

in the healthcare domain. Teng et al. (2020) predicted

ICD-9 codes using knowledge graphs, adversarial

learning and an attention mechanism. They

introduced G-Coder, which takes two inputs, a

knowledge graph and medical documents. The

medical documents are processed with adversarial

samples resulting in sentence encodings and the

knowledge graph results in graph embeddings. Both

of these embeddings are passed through multiplied

attention mechanism which then passes down a

classifier to predict ICD codes. The architecture

achieves an F1 score of 69.92.

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

692

4 FINDINGS AND

OBSERVATIONS

We have observed that research work done so far on

text-related medical tasks using attention

mechanisms follows a standard pipeline (Figure 1).

The text-based data is converted into embeddings.

Then a combination of convolutional layers is used

along with an attention layer. This attention layer may

be token-wise, word-wise, label-wise or sentence-

wise. Putting attention on the embeddings or the

results of convolutional layers assists in interpreting

the parts of the documents that influence the

prediction or classification of labels.

Figure 1: A typical pipeline for NLP in healthcare using an

attention mechanism; key differences in the base

architecture.

The models discussed above primarily use two

benchmark datasets, MIMIC-III and CodiEsp and are

compared based on their F1 score. The base

architecture for these research works is primarily

Text-CNN, BERT or CAML. From these base

models, CAML comes with an inherent attention

layer while Text-CNN and BERT are used due to

their performance and increased usage across various

tasks. These models also vary based on their layer

assembly and learning techniques, such as joint,

adversarial or others. (See Table 1).

While some of these works include an evaluation

for the explainable components, such as by using

Jaccard scores, these papers follow a pattern of

depicting their results using graphs containing either

highlighted text visualisation over documents, heat

maps or other graphs. The idea is to depict the local

features identified by different attention mechanisms

to emphasise the explainability of their models.

(Table 2).

Table 2: Evaluation techniques used for explainability

components in different research work.

Reference Explainability

Technique

Explainability Metric/

Evaluation Criteria

Xu et al.

(2019)

LIME,

Influence scores

Jaccard Similarity

Coefficient (0.1806 on

text and 0.3105 on tabular

data)

LATA Layer-wise

attention

Jaccard Similarity

Coefficient

HiLAT +

Clinicalplu

sXLNet

Label-wise

attention

Visualization of attention

weights

DLAC Description-

based label

attention

Visualization of attention

weights

Feng et al.

(2020)

Label-wise

attention

Medical Professional +

Novel approach finding

attention weights

Specifically, for the use of attention mechanisms

for explainability, researchers have experimented

with types of attention, such as dot attention or

concatenation, the focus of attention, such as label or

word, their placement in the pipeline and their

occurrence. These innovations combined with base

architectures, techniques of embeddings and

architectural variations have resulted in achievements

in explainability for text-related tasks in the

healthcare domain.

We must highlight that the evaluation of

explainability components in all the work we have

reviewed is not directly comparable. There has been

no benchmark against which to measure the

correctness of the explainable results. Hence, we

cannot rate one above another. For aspiring

researchers in this direction, it is important to include

a detail of their explainability evaluation either with a

comparison of the work included in this paper or

using metrics such as the Jaccard Similarity

Coefficient or document similarity index. We can,

however, assume that a model with the highest F1

score, or another performance metric, would have

picked the optimal features from the text data. Hence,

we believe the attention scores that are highlighted in

a visualization using the attention mechanism of the

model explain the results of the model better.

Attention-Based Explainability Approaches in Healthcare Natural Language Processing

693

Table 1: Comparison of the attention mechanisms, base architectures, datasets and their performance.

Research Work Model Dataset Base

Architecture

Attention Mechanism Results

(F1-Score)

Liu et al (2022) HiLAT +

ClinicalplusXLNet

MIMIC-III [28]

XLNet, BERT Label-wise

attention

73.5

Feucht et al

(2021)

DLAC MIMIC-III BERT, CNN Description-based label

attention

62.2

Mayya et al

(2021)

LATA CodiEsp BERT Label-wise attention 64.3

Wang et al

(2021)

MA-GRN Chinese

electronic health

records

GRN Self-attention (dot and

additive), Label-wise

attention

92.11

Li et al (2021) JLAN MIMIC-III LSTM Self-attention, Label-wise

attention

66.5

Mayya et al

(2021)

EnCAML MIMIC-III,

CodiEsp

CAML Layer-wise attention 85.59

Dong et al

(2021)

HLAN MIMIC-III GRN Label-wise attention,

Word-wise attention

64.1

Mullenbach et al

(2018)

CAML MIMIC-III CNN Label-wise attention 88.0

Feng et al (2020) - MIMIC-III BERT, Text-

CNN

Label-wise attention 78.9

Biswas et al

(2021)

TransICD MIMIC-III Transformer Code-wise attention 56.2

Nguyen et al

(2021)

LAME Hallmarks of

Cancers (HoC),

Medical

abstracts of

diseases

(

Disease5

)

BERT Label-wise attention 83.3

Trigueros et al

(2022)

- Osa, MIMIC-III CNN Layer-wise attention 64.4

Hu et al (2021) SWAM MIMIC-III CAML Label-wise attention 59.3

*macro: computed usin

the arithmetic mean o

all the pe

-class F1 scores

5 CONCLUSIONS

In our work, we have reviewed the cutting-edge

applications of the explainability components in NPL

tasks in the healthcare domain. Based on our review

and analysis of the work done from 2018 to 2022, we

have found that around 60% of the work uses

attention mechanisms. There was some research on

graphs and hybrid approaches but attention remains

the dominant one.

All the studies and projects included in this review

involved NLP tasks focused on CDSS and healthcare

applications and they shared some commonalities. All

of them used a base architecture for text label

prediction. This architecture was then modified with

attention layers, of various types and in different

numbers, to add explainability component. Then, they

created visualization of the attention results using

most suitable techniques that could effectively

demonstrate the results of these attention

mechanisms. It is important to note the researches

included in this study review a similar overall three-

set pipeline (See Fig. 1). However, the difference and

novelty lies in the base architectures and these

projects have carefully designed architectural

pipelines that help them strive for better performance

and results while addressing specific issues. Hence,

these base architectures are the source of performance

differences and which architectures may be suitable

for specific use cases.

We have summarized the contributions of

researchers and highlighted the base architectures

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

694

they used. We have also detailed how these

architectures vary in the use of attention mechanisms.

We have found that CAML, Text-CNN and BERT are

the most commonly used base architectures, while

label-wise and self-attention are the most common

mechanisms to develop such novel

architectures. Many of these studies build on

architectures from previous similar studies to

introduce a pipeline with better results in the area. We

can also see the popular use of attention mechanisms

with transformer models, CNNs and even RNNs.

However, all of these researches are focused on

evaluation of label predictions and visualization of

attention scores. In order to develop plausible

interpretability, a standard set of explainability

evaluations should be performed. We recognize an

immediate need to not only consider explainability

that is much more relatable to end-users’ cognition

and learning, but is also objective in terms of being

measurable and comparable. Such evaluation

measures combined with overall performance of the

NLP and AI models in the healthcare domain would

aid the readers as well as the end-users in

understanding the outputs better, hence working with

these AI models and systems with higher confidence

and trust.

REFERENCES

Biswas, B., Pham, T. H., & Zhang, P. (2021, June).

Transicd: Transformer based code-wise attention

model for explainable icd coding. In International

Conference on Artificial Intelligence in Medicine (pp.

469-478). Springer, Cham.

Cabitza, F., Campagner, A., & Datteri, E. (2021). To err is

(only) human. Reflections on how to move from

accuracy to trust for medical AI. In Exploring

Innovation in a Digital World (pp. 36-49). Springer,

Cham.

Castelvecchi, D. (2016). Can we open the black box of AI?.

Nature News, 538(7623), 20.

DeGrave, A. J., Janizek, J. D., & Lee, S. I. (2021). AI for

radiographic COVID-19 detection selects shortcuts

over signal. Nature Machine Intelligence, 3(7), 610-619

Dong, H., Suárez-Paniagua, V., Whiteley, W., & Wu, H.

(2021). Explainable automated coding of clinical notes

using hierarchical label-wise attention networks and

label embedding initialisation. Journal of biomedical

informatics, 116, 103728.

Feng, J., Shaib, C., & Rudzicz, F. (2020, November).

Explainable clinical decision support from text. In

Proceedings of the 2020 conference on empirical

methods in natural language processing (EMNLP) (pp.

1478-1489).

Feucht, M., Wu, Z., Althammer, S., & Tresp, V. (2021).

Description-based Label Attention Classifier for

Explainable ICD-9 Classification. arXiv preprint

arXiv:2109.12026.

IBM. Explainable AI (XAI). https://www.ibm.com/

watson/explainable-ai. Accessed [Nov, 2022]

Hu, D. (2019, September). An introductory survey on

attention mechanisms in NLP problems. In Proceedings

of SAI Intelligent Systems Conference (pp. 432-448).

Springer, Cham.

Hu, S., Teng, F., Huang, L., Yan, J., & Zhang, H. (2021).

An explainable CNN approach for medical codes

prediction from clinical text. BMC Medical Informatics

and Decision Making, 21(9), 1-12.

Hunter, K. (1998). ScienceDirect™. The Serials Librarian,

33(3-4), 287-297.

Johnson, A. E., Pollard, T. J., Shen, L., Lehman, L. W. H.,

Feng, M., Ghassemi, M., ... & Mark, R. G. (2016).

MIMIC-III, a freely accessible critical care database.

Scientific data, 3(1), 1-9.

Li, X., Zhang, Y., Dong, D., Wei, H., & Lu, M. (2021).

JLAN: medical code prediction via joint learning

attention networks and denoising mechanism. BMC

bioinformatics, 22(1), 1-21.

Liu, L., Perez-Concha, O., Nguyen, A., Bennett, V., &

Jorm, L. (2022). Hierarchical Label-wise Attention

Transformer Model for Explainable ICD Coding. arXiv

preprint arXiv:2204.10716.

Mayya, V., Kamath, S. S., & Sugumaran, V. (2021,

October). Label Attention Transformer Architectures

for ICD-10 Coding of Unstructured Clinical Notes. In

2021 IEEE Conference on Computational Intelligence

in Bioinformatics and Computational Biology (CIBCB)

(pp. 1-7). IEEE.

Mayya, V., Kamath, S., Krishnan, G. S., & Gangavarapu,

T. (2021). Multi-channel, convolutional attention based

neural model for automated diagnostic coding of

unstructured patient discharge summaries. Future

Generation Computer Systems,

118, 374-391.

Mullenbach, J., Wiegreffe, S., Duke, J., Sun, J., &

Eisenstein, J. (2018). Explainable prediction of medical

codes from clinical text. arXiv preprint

arXiv:1802.05695.

Naylor, M., French, C., Terker, S., & Kamath, U. (2021).

Quantifying explainability in nlp and analyzing

algorithms for performance-explainability tradeoff.

arXiv preprint arXiv:2107.05693.

Nguyen, B., & Ji, S. (2021). Fine-tuning Pretrained

Language Models with Label Attention for Explainable

Biomedical Text Classification. arXiv preprint

arXiv:2108.11809.

Nourani, M., King, J., & Ragan, E. (2020, October). The

role of domain expertise in user trust and the impact of

first impressions with intelligent systems. In

Proceedings of the AAAI Conference on Human

Computation and Crowdsourcing (Vol. 8, pp. 112-121).

Savage, N. (2022). Breaking into the black box of artificial

intelligence. Nature, March 2022 https://doi.org/10.10

38/d41586-022-00858-1

Attention-Based Explainability Approaches in Healthcare Natural Language Processing

695

The Alan Turing Institute. Knowledge Graphs, How do we

encode knowledge to use at scale in open evolving

systems, decentralised systems? https://www.turing.

ac.uk/research/interest-groups/knowledge-graphs.

Accessed [Nov, 2022]

Teng, F., Yang, W., Chen, L., Huang, L., & Xu, Q. (2020).

Explainable prediction of medical codes with

knowledge graphs. Frontiers in Bioengineering and

Biotechnology, 8, 867.

Trigueros, O., Blanco, A., Lebeña, N., Casillas, A., &

Pérez, A. (2022). Explainable ICD multi-label

classification of EHRs in Spanish with convolutional

attention. International Journal of Medical Informatics,

157, 104615.

Wang, X., Han, J., Li, B., Pan, X., & Xu, H. (2021,

December). Automatic ICD-10 Coding Based on Multi-

Head Attention Mechanism and Gated Residual

Network. In 2021 IEEE International Conference on

Bioinformatics and Biomedicine (BIBM) (pp. 536-

543). IEEE.

Wang, Y., Kung, L., & Byrd, T. A. (2018). Big data

analytics: Understanding its capabilities and potential

benefits for healthcare organizations. Technological

Forecasting and Change, 126, 3-13.

White, J. (2020). PubMed 2.0. Medical Reference Services

Quarterly, 39(4), 382-387.

Xu, K., Lam, M., Pang, J., Gao, X., Band, C., Mathur, P.,

& Xing, E. P. (2019, October). Multimodal machine

learning for automated ICD coding. In Machine

learning for healthcare conference (pp. 197-215).

PMLR.

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

696
