An NLP-Enhanced Approach to Test Comorbidities Risk Scoring

Based on Unstructured Health Data for Hospital Readmissions

Prediction

Tahir Hameed

, Haris Jamal Khan

, Saad Khan

, Mutahira Khalid

, Asim Abbas

and Syed Ahmad Chan Bukhari

Girard School of Business, Merrimack College, North Andover, MA, 01824, U.S.A.

School of Electrical Engineering and Computer Science, NUST, H-12, Islamabad, Pakistan

Division of Computer Science, St. John’s University, Queens, NY 11439, U.S.A.

mkhalid.msit20seecs@seecs.edu.pk, abbasa@stjohns.edu, bukharis@stjohns.edu

Keywords: Comorbidities, Hospital Readmissions, Clinical Decision Support Systems, Natural Language Processing,

Bert, Deep Learning.

Abstract: Hospital readmissions have emerged as a key healthcare quality indicator since the passing of the Affordable

Care Act in 2010. It is easier to predict the readmission risk of patients without complications, but

comorbidities, such as diabetes and cardiovascular diseases, make it difficult to accurately assess the

readmission risk. 30-days hospital readmissions (30DRA) risk models typically rely on demographic, socio-

economic, and medical variables from structured data, such as diagnosis, vitals, lab reports, and comorbidities,

etc. Comorbidity indices help in assessing overall disease burden by accounting for the disease codes in

electronic health records (EHRs). With the advent of natural language processing (NLP), there is a potential

to extract additional health related variables including the possibility of gleaning additional disease codes for

comorbidities in unstructured portion of the EHRs, such as clinical notes, medical history, and discharge

summaries. Whereas NLP has been applied heavily in healthcare information systems, to the best of our

knowledge, there is no research that identifies comorbidities from unstructured clinical texts. This paper

employs a Bidirectional Encoder Representation from Transfer (BERT) deep learning technique to predict

additional comorbid conditions in the unstructured portions of EHRs and evaluates the effectiveness in

comorbidity scoring. Comorbidity scores based on the NLP-predicted comorbidity codes (predicted) were

compared against the scores calculated from codes identified by the health providers (diagnosed), and also

against a combination of the two (diagnosed and predicted). We find NLP is effective in improving the

accuracy of comorbidity calculations, that in turn could improve predictive power of AI models for hospital

readmissions and mortality predictions. It is among the first papers employing NLP to predict ICD-10 codes

from unstructured EHRs for comorbidity index calculations.

1 INTRODUCTION

A good assessment of comorbidities aids healthcare

providers in performing better diagnosis and effective

treatments. Timely comorbidity assessment during

medical encounters also improves management of

risks and healthcare quality indicators, such as health

outcomes, mortality rates and hospital readmissions

rates (Goltz et.al, 2019; Hameed, 2020; Menendez et

https://orcid.org/0000-0002-6824-6803

https://orcid.org/0000-0001-8482-4004

https://orcid.org/0000-0001-6374-0397

https://orcid.org/0000-0002-6517-5261

al., 2014; Sharma et al, 2021). Comorbidity

assessment methods and their correct application,

therefore, have become critical in medical practice.

Two most popular measures to assess

comorbidities i.e. Charlson Comorbidity Index (CCI)

and Elixhauser Comorbidity Index (EHI) assess the

overall disease burden of primary diagnosed

conditions in a patient by accounting for any other

diseases among the most prevalent diseases and

Hameed, T., Khan, H., Khan, S., Khalid, M., Abbas, A. and Bukhari, S.

An NLP-Enhanced Approach to Test Comorbidities Risk Scoring Based on Unstructured Health Data for Hospital Readmissions Prediction.

DOI: 10.5220/0011944500003414

In Proceedings of the 16th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2023) - Volume 5: HEALTHINF, pages 649-659

ISBN: 978-989-758-631-6; ISSN: 2184-4305

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

649

conditions (Charlson et al, 1987, Elixhauser et.al,

1998). The occurence of multiple comorbid

conditions results in a higher CCI or EHI score

indicating higher overall diasese burden. Quite

intutively, the co-occurrence or severity of ceratin

diseases would imapct the health more negatively.

Some researchers have demonstrated that modified

summary CCI or EHI scores (a single number) based

on aggregated or weighted burden of comorbidities in

a patient are more valuable metrics of comorbidities

(Van Walraven et al, 2009, Thompson et al, 2015).

Higher the modified comorbidity score, higher the

risks to the patient’s health and vice versa. Even

though both frequency counting and weight adjusting

indices are effective when physicians make the

health decisions, it is not clear if they would be as

effective when it comes to AI-based clincal decision

support systems (CDSS). Moreover, it is not clear if

they would perform optimally in the wake of newer

data-driven healthcare delivery models such as

patient-centered healthcare models that require a lot

of individual patient details and customization, such

as value-based care and personalized medicine.

Electronic Health Records (EHRs) are the most

common data source containing the diagnosis of

primary diseases as well as comorbid conditions.

EHRs typically record ICD-9 or ICD-10 medical

codes as part of a classification structure titled

‘International Classification of Diseases’ (ICD). ICD-

9 codes are most prevalant as many healthcare IT

systems have trasnitioned or are in the process to

move to ICD-10 codes. ICD-11 codes have already

been annouced but they are not adopted yet. The most

common use of these codes is in medical billing

processes but with the advent of AI they have found

heavy use in CDSS.

Typically, physicians specify ICD-9 or ICD-10

codes of the primary disease in their clinical notes

along with other conditions which become part a

pateint’s medical history, often times part of EHRs.

Medical coders convert these verbal or textual notes

into ICD codes and verify them for claims and billing

purposes. So, in addition to sturctured data, EHRs

also contain lot of textual data, such as clinical notes,

discharge summaries and specialist reports. They

often contain additional information on a patient’s

comorbid conditions. It happens quite often a patient's

medical history and past health records are not

immediately visible to the physician during a medical

encounter. Also, the comorbidities inlcuded as text

but not as ICD codes maybe hard to identify upfront.

Lastly, older EHRs have ICD-9 codes that have not

been updated to the ICD-10 codes yet.

Since, the available Elixhauser comoridity

algorithms (EHI) are based on ICD codes only, they

are are being limited by losing valuabe uncoded

information. With the advent of AI and NLP

techniques in computer-assisted coding (CAC) area,

it is high time that the uncoded information in

unstructured portions of EHRs could also be

leveraged with an aim to improve the accuracy of

comorbidity algorithms. That, in turn, should

improve the predictive performance of CDSS

designed for health outcomes, mortality and hospital

readmissions rate, etc.

Our research aims to develop and test an NLP

based deep learning approach to glean (predict) ICD-

10 medical codes in the unstructured portions of

EHRs, generate Elixhauser Index comorbidity scores

(EHI) by including the newly predicted codes in

them, and test these richer comorbidity scores in 30-

days hospital readmissions (30DRA) prediction

models. To that end, we employed a Bidirectional

Encoder Representation from Transfer (BERT)

model for gleaning ICD-10 codes from the textual

part of the EHRs.

Once the codes were extracted, several tests were

performed on the EHI comorbidity soring and

30DRA classification. At first, chi-square test of

independence was used to assess the dependence of

30DRA on each one of the thirty diseases/conditions

in the EHI comorbidity scores with the newly

predicted codes. Next, we also performed principal

component analysis to assess the effect of each

comorbid condition in classifying the 30DRA and the

top components that explain most of the variance.

Multi-logistic regression-based feature scoring was

conducted to further clarify the influence (weight) of

each comorbid condition in 30DRA classification.

Finally, student T-tests were done to compare the

classification performance of existing codes, the

newly predicted codes and a combination of the two.

In general, we have found NLP approaches to be

effective in extracting comorbidity codes from

unsturctured portions of EHRs. They improve CDSS

predictive models that consider combobidties index

scores as feature/s. Detailed findings are included in

the results and analysis. This paper is a first in the

CDSS area employing NLP technique to predict

additional comorbid conditions. It is also among the

first in the healthcare area to predict ICD-10

comorbidity codes using NLP. Rest of the paper is

organized as follows. Section 2 covers current

litearure on relevant topics. Section 3 describes the

data and the methods. Section 4 presents the results

and analysis while section 5 concludes with pointers

to limitations and future research.

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

650

2 LITERATURE REVIEW

2.1 Comorbidity Indices and Their

Application in Clinical Decision

Support Systems

The most commonly referred definition of

comorbidities identify them as, “Any distinct

additional entity that has existed or may occur during

the clinical course of a patient who has the index

disease under study” (Feinstein, 1970). So,

comorbidities are additional diseases or conditions a

patient is suffering from in addition to the disease or

condition they are being treated for. Another

approach is considering “the co-occurrence of

multiple chronic or acute diseases and medical

conditions within one person” disregarding direct

relationships between a primary disease and

comorbid diseases (Bayliss et al, 2008). Whether

primary or comorbid, the diseases and conditions are

identified by International Classification of Diseases

(ICD) Codes, commonly used for medical billing.

The current version of ICD-codes is ICD-10 with

ICD-11 codes already announced, but most health IT

systems are still using ICD-9 codes or they are

transitioning from ICD-9 to ICD-10 codes.

Comorbidity indexes typically use ICD codes in

EHRs to measure the frequency, co-occurrence and

severity of the diseases in a patient. The most

prevalent comorbidity scoring methods in clinical

practice include the Charlson Comorbidity Index

(CCI) and the Elixhauser Comorbidity Index (EHI).

CCI’s mortality risk was based on review of patient

medical records for the 17 diseases and conditions

that caused mortality (Charlson et al, 1987). EHI

takes ICD codes into accounts for mortality risk in 30

different diseases organized in multiple diagnosis

related groups (DRGs) recognized by the Centres for

Medicare and Medicare Services (CMS). Agency for

Healthcare Research and Quality (AHRQ) provides a

software algorithm on its website to calculate the

Elixhauser comorbidity score (AHRQ, n.d.)

Both these indices have been quite effective in

their prognostic value in clinical settings. Therefore,

they have been widely adopted in medical practice.

The performance of both CCI and EHI comorbidity

indices has been somewhat similar for ICD-9, ICD-9

CM and ICD-10 codes but Elixhauser has proven to

be better in terms of overall prognostic value (Quan

et.al, 2005). There have been some concerns raised

about the above-mentioned approaches on

discounting the nature of diseases and their

chronological order of progression, etc. (Valderas,

2009) but generally they have remained the

predominant tools for measuring comorbidity with

good prognostic outcomes.

There is a long list of other comorbidity indices

developed or calibrated according to the outcomes of

interest, relation to primary diseases, and regulations

governing regional health systems, etc. The

performance of the same comorbidity indices varies

when applied in different diseases. For instance, one

comorbidity index may perform well for a specific

type of cancer but not for hip-joint replacement. Some

other broader but prominent comorbidity indices

include Chronic Disease Score (CDS) by Von Korff

(1992), ICED Index of Co-existing Diseases by

Greenfield (1993), Health-related Quality of Life

Comorbidity Index (HRQL-CI) by Mukherjee et al

(2011), the National Institute on Aging (NIA) and

National Cancer Institute (NCI) comorbidity index

(Havlik et al, 1994), and the Adult Comorbidity

Evaluation-27 (ACE-27) by Piccirillo et al (2004).

These and several others are used by providers as a

single or combination comorbidity measures when

dealing with various medical areas or diseases.

Since the decision on diagnosis and treatments has

to come from the physician/s, the role of these

indices, whether calculated manually or

automatically, is mainly clinical decision support

during admission, on the patient bed-side, during

discharge and adherence monitoring, etc. Physicians

use comorbidity indices, especially CCI and EHI, to

measure severity of illness, mortality risk, prognosis,

treatment difficulty, need for intervention, required

resource intensity, and hospital readmissions risk, etc.

in these situations.

2.2 NLP in Healthcare AI and Clinical

Decision Support Systems

Current EHR-based health information systems are

able to streamline workflows, boost productivity and

improve doctor-patient interactions. They also play a

major role in emerging AI-based predictive analytics

and deep learning models for clinical decision

support. The diversity of information, however,

comes with the cost of varying structured and

unstructured storage formats. Patient demographics,

weight, height, blood pressure, binary lab results, and

administered medications are a few examples of the

structured data. Contrarily, narrative data found in

EHRs such as surgical records, clinical notes,

discharge summaries, and pathology and radiology

reports are not amenable to computational analysis

and it needs to be transformed or integrated with

structured data points to increase their usability. The

integration of diverse data types opens up avenues for

An NLP-Enhanced Approach to Test Comorbidities Risk Scoring Based on Unstructured Health Data for Hospital Readmissions Prediction

651

research but is not free from its own challenges.

These challenges include heterogeneous data formats,

non-flexible storage structures, and the lack of a big

data pipeline (Evans, 2016). Thus, the conversion of

unstructured health information into standards-

compliant, comparable, and consistent data are

essential for health informatics research.

Over the years, researchers have tapped into

Natural Language Processing (NLP) models for

comprehension of unstructured data in the medical

domain. NLP is a range of computational techniques

for the automatic analysis and representation of

human language (Cambria and White, 2014). They

allow computer systems to comprehend free text by

transforming it into a format that is machine-readable.

In the medical domain, NLP is in a period of robust

development, with 100 publications annually with an

incremental trend (Wang et al, 2020). Some notable

venues of NLP research have been discussed in the

following paragraphs.

Named Entity Recognition (NER) is a semantic

information extraction technique that locates and

categorizes relevant entity data from the text at scale

(Aya, 2020). Named entities include everything from

names, brands, addresses, locations, and virtually any

classifiable textual information. NER makes these

specific entities usable in NLP models. Unstructured

clinical notes often contain valuable information such

as tumor location, diagnosis explanations, and at

times ICD codes, that when present in a structured

format would allow for quicker analysis. Several

attempts have been made to convert these notes into

a structured format with the help of NER modeling.

In (Tome et al, 2017), a rule-based NER that consists

of two phases was used for dietary recommendations.

The first one involves the detection and determination

of the entities mentioned, and the second one involves

the selection and extraction of the entities. Bio-NER

(Soomro et al, 2017) is another NER model for

biomedical entities. Parts of speech tags and N-grams

were used to enhance the performance compared to

previously existing NERs. Panchendrarajan &

Amaresan’s (2018) NER technique combined deep

learning and Bidirectional LSTM-CRF model. This

model includes bidirectional LSTM with a

bidirectional Conditional Random Field that is able to

capture both the word level and sentence level

encodings along with the positional encodings of text.

Combined with the context from LSTM, the

encodings are then fed to the CRF for classification.

BI-CRF has improved performance in comaprison to

unidirectional CRF and backward CRF.

Transformer models are also being used for NER.

BERT (Bidirectional Encoder Representation from

Transfer), is one of the most popular transformer

models that produce a state-of-the-art result for NER

task (Devlin et.al., 2018). BioBERT is the biomedical

version of the BERT language model for the

biomedical text and is widely used by the biomedical

text-mining domain experts for NER, question

answering and summarization tasks (Lee et al., 2020).

The BERT model has been finetuned on Wikipedia,

PMC and PubMed articles. ClinicalBERT (Alsentzer

et al, 2019) is another extension of BioBERT and has

been further trained on the MIMIC III dataset. All

discharge summaries (880M words) were used to

finetune this BERT to create embeddings for tasks

associated with BERT.

Knowledge graphs (KG) are increasingly being

used to further enrich information contained in EHRs.

Vafajoo et al (2018) investigated the risk factors of

cancer and chronic disease by creating KGs from

biomedical literature. The suggested methodology

included KG, disease-specific word embedding using

NLP approaches, and literature-based discovery

(LBD). The developed KG revealed that the clinical

characteristics were the main emphasis of the breast

cancer literature rather than the conventional

chemical recommendations. KG built from EHRs has

been offered as a diagnostic tool also Chaudhri,

2022). Using string matching on the two datasets

provided by Beth Israel Deaconess Medical Center.

the mentions of diseases and their symptoms were

manually retrieved from both organised and

unstructured data. Google Health Knowledge Graph

(GHKG) was used to compare the disease-symptom

edge that was generated for the constructed KG,

based on evaluation metrics including recall and

precision. Esteban et al (2017) proposed the Clinical

Knowledge Graph (CKG), an open-source platform

with more than 16 million nodes and 220 million

relationships, to represent the experimental data, the

literature, and public databases. Using CKG with

statistical and machine learning approaches

significantly accelerated the analysis and

interpretation of conventional proteomics procedures.

NLP is also being used to deduce or predict

patient health outcomes from clinical texts so that

appropriate interventions could be made in time.

Conventional prognostic scores usually require

predefined clinical variables to predict health

outcomes (Sung et al, 2021). They have used free text

on the history of the present illness and computed

tomography reports to build NLP-based machine

learning models to predict the poor functional

outcome at 90 days post-stroke. Similarly, Arnaud et

al, (2021) employed convolutional neural networks

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

652

(CNN) to provide an early prediction of the medical

specialities at hospital admission.

Lastly, NLP techniques can also be seen in models

aiming to improve the quality of life of patients and

assist the overall healthcare system. For instance,

deep learning techniques have been regularly applied

to clinical notes to predict their ICD labels (Bao et al,

2021). Moreover, Le et al (2020) aimed to evaluate

the hypothesis that possible future medical concepts

can be predicted from a patient’s EHR. By using

time-based prefixes and suffixes, where each prefix

or suffix was a set of medical concepts from a medical

ontology, comparisons between prefixes of patients in

the collection were done with the state of the current

patient using various interpatient distance measures.

Their study shows that indications of future events

using this methodology are feasible.

In the above sections, not only have we discussed

the criticality of comorbidities in clinical decicions

but we have also comprehensivley discussed several

applications of traditional and emerging NLP

approaches in the healthcare information systems

area. We did notice a few cases of medical codes

extraction and labelling from narrative portions of

EHRs. However, we are not aware of, to the best of

our knowledge, research that has attempted to extract

ICD-10 codes for comorbidities from unsturctured

data. In the next section, we attempt at developing and

testing such an approach.

3 DATA AND METHODS

3.1 NLP-Enhanced Approach to

Calculate Comorbidity Scores

based on Extracted ICD-10 Codes

Our proposed model consists of four major steps. The

first step involves extracting and pre-processing patient

dataset for hospital readmissions with ample structured

variables of intertest also containing rich unstructured

texts such as clinical notes or discharge summaries.

Second step involves extracting additional ICD-10

codes from unstructured text using an NLP technique.

To that end, we planned to employ an HLAN

(Hierarchical Label-wise Attention Network) deep

learning technique. However, in this particular

instance, we have used a transfomer-based BERT

model to predict additional comorbid conditions. The

third step focuses on re-organizing data in a way that

enables calculations, and comparative evaluations. The

highlight of this part is to assign, clean and organize the

extracted comorbid codes to patient records in a clean

and consistent manner. The final step requires that

comorbidity scores for each disease included in the

selected comorbidity index are calculated and made

available as features of the target variable in our model

i.e. hospital readmissions. That involves

operationalization of either tested summary

comborbidity indices such as Elixhauser (EHI), VW

(vanWalraven, 2009) and Thompson score

(Thompson,2015), or devising own algorithms based

on diseases and outcomes of interest. Since our

research focuses on all-cause hospital readmissions

and general adminsitrative data, therefore we limit

oursleves to diseases/comorbidities specified in EHI

comorbdity index for now. But we do plan to devise

own weighted adjustments in the future.

For testing and evaluation step, that is not a regular

part CDSS pipeline , we plan to employ statistical

testing. At first, chi-squared test of independence will

identify the dependence of the 30-days hospital

readmissions on each of the thirty Elixhauser index

cormobidities or otherwise. Logistic regression based

feature scoring will then calculate the weighted

influence of each comorbidity on the 30-days hospital

readmissions classification. Principal component

analysis will show the top 5 components affecting

hosiptal readmissions prediction and alignment of

identified comorbisities with those key components.

They help us in comparing infleunetial comorbidities

in different datasets as well as comparative evaluation

of the variance explained by multiple models (based

on datasets explained in the next sub-section). It is

dreiterate that the purpose of PCA is not to suggest new

prinicipal components but deomstrate the alignment of

various diseases/comorbidities included in Elixhauser

model with the logistic regression feature scores

(weights). Lastly, a t-test of summary Elixhauser

comorbidity scores calculated from these datasets

based on the diagnosed codes, NLP-extracted codes,

and a combination of the two types of codes, enable a

comparative assessment of each.

3.2 Data Preparation

We used MIMIC-III clinical database containing over

58976 all-cause admissions records of aorund 40,000

patients staying at Beth Israel Deaconess Hospital

between 2001 and 2012 (Johnson et al, 2016, 2019).

The database is anonymized and the calendars of all

the events have been off-set. The dataset is open to

public with terms and conditions of use. It contains

sturctued EHR data on patient’s admissions, labs,

treatments, medicines, transfer, and discharges as

well as unstructured textual discharge summaries

dictateted or narrated by physicians.

An NLP-Enhanced Approach to Test Comorbidities Risk Scoring Based on Unstructured Health Data for Hospital Readmissions Prediction

653

Records with 30-days readmissions were identified

by scanning multiple admission IDs for the same

patient ID and the days between the discharge and next

admission. Patients readmitted within 30 days of

discharge were labelled ‘1’ while others were labelled

‘0’. Since it is mainly an emergency room database,

filters were applied to exclude NEWBORN or

ELECTIVE admissions, leaving only 37812 records.

After counting the frequency of admitted patients

against specific diseases, the records were filtered only

for those diseases where the patient count was 100 or

more, leaving us with only 29528 records.

Clinical notes for each admission were then

extracted from NOTEEVENTS. Even though they

contain lab reports, discharge summaries, and nursing

reports, etc., we only considered discharge summaries

for each admission since they contain all the

information for this analysis. If there were multipe

discharge summaries against an admission ID, only

the most recent one was kept. That brought down the

dataset to 21368 entries. After balancing the numbers

of readmitted and non-readmitted patients for the

final sample dataset, it was reduced to 3213 patients

with discharge summaries.

3.2.1 ICD-10 Code Extraction (Prediction)

from Unstructured Texts

Predicting appicable ICD-10 codes correctly from the

discharge summaries played a key role in calculating

Elixhauser comorbidity score. Since the process of

training a BERT would take a lot of time and

computational resources, a pre-trained BERT model

was acquired from the Hugging face community to

predict ICD-10 codes from the discharge summaries

against each admission (Devlin et,a;, 2018; Hugging

face, n.d.). The BERT model extracted multiple codes

successfully from the unstructured text of each

discharge summary.

We noted a couple of limitations working with

BERT here. The first one was the limited size of

unstructured text a BERT model could take as an

input. To overcome that, larger discharge summaries

were broken down into smaller blocks and serially

processed through BERT. Second, if certain portions

or types of textual summaries are richer than others in

terms of terminologies related to the diseases, they

will generate more codes, hence lot of overlapping

codes to be dealt with. In ICD-10 codes, it is common

to have extended codes adding depth to the diseases

classification. Therefore, keeping the codes used for

predictions uniform is another challenge.

Extended codes were removed from the extracted

codes and results were saved as ‘PREDICTED_

COMORBIDITIES’ dataset. Similarly, ICD-10 data

was obatined for the specific diagnosis made by the .

The ICD-10 codes were the saved as ‘DIAGNOSED’

dataset. A third data set was constucted by combing

the two above datasets. This combined dataset

was titled ‘DIAGNOSED + PREDICTED

COMORBIDITIES’.

3.2.2 Final Data Parsing for Comorbidities

Risk Calculation and Hospital

Readmissions Prediction Model

Next, each of the 30 diseases listed in the Elixhauser

comoribidity index was separtaetd in a column

against 3213 patient-admission rows. If an ICD-10

code was found for a disease, it was marked 1

otherwise 0. In this way, not only multiple ICD-10

codes for the diseases in the same disease related

groups (DRGs) were eliminated in a pateint, but the

correct count of comoborbidities a patient had was

also recorded in a table format that could be readily

input to a classfier.

Since the above data pasing was done first for the

codes of diseases directly entered into the EHRs, it

only prepared one dataset DIAGNOSED. The above

parsing steps were repeated on BERT extracted codes

and saved as PREDICTED_CORMORBIDITIES’

dataset with its own 30 columns for the diseases and

count of comorbidities based on the extracted codes.

Lastly, the codes from both the above datasets were

logically “ORed” to keep one instance from either

DIANOSED or PREDICTED_CORMORBIDITIES’

and the newly formed dataset was saved as

DIAGNOSED+PREDICTED_ COMORBIDITIES’.

Elixhauser comoridity score was also calculated

for each patient-admission in three separate columns

just for comparitive evaluation of the three scenarios

covered in the above datasets.

Our holistic 30-days hospital readmissions

prediction model takes into account variables

(features) from multiple areas. However, for the

purpose of measuring direct effect of each comorbidity

listed in Elixhausers’s index on hospital readmissions,

we used simple logistic regression model with 30DRA

as target variable and all the thirty comorbid diseases

as features. For compartiave evaluation purposes

between physician diagnosed, NLP extracted and a

combination of both, the model was tested on the three

above datasets separately. In this way, it was a reduced

model of the original just to test the effectiveness of

NLP-extracted comorbidities from unsturctued text.

The aim is to incoporate a summary cormobdity score

as one a single feature into the holistic 30-days-

hospital-readmissions prediction model.

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

654

4 RESULTS AND ANALYSIS

As mentioned earlier, several statistical tests were

conducted on the diseases/comorbidities datasets

including chi-square test for independence, logistic

regression feature scoring and principal component

analysis (PCA). Many statistical tests were performed

mainly because we wanted to leverage the pros of

multiple techniques to analyse the performance from

various angles. The above tests were conducted on

three different datasets mentioned above i.e.

DIAGNOSED, PREDICTED COMORBIDITIES and

DIAGNOSED + PREDICTED COMORBIDITIES

datasets in relation with 30-days hospital readmissions

predictions. Table 1 presents the complete results of

these tests attached at the end of the paper due to its

size and format. The results reported in Table 2 have

been sorted (rank-ordered) as per logistic regression

feature scores of the comorbidities based on NLP-

predicted codes.

4.1 Comorbidities Diagnosed by the

Physicians

A chi-square test of independence was performed to

test the relation between each Elixhauser comorbid

condition and 30-days hospital re-admission. With N

= 3213, df = 30, the critical value for the chi-square

distribution comes out at 43.773. For the

DIAGNOSED scenario, the names of the diseases

(along with their ICD-9 does) are diagnosed by the

physicians. All values of chi-square statistics are

below the critical value indicating significant

relationship between all comorbidity measures in the

EHI and hospital readmissions at p<0.5 significance

level. The logistic features scores on its right-side

highlight Hypertension, Congestive Heart Failure,

Hyperthyroidism, Renal Failures and Peripheral

Vascular Disorders as the top five contributing

comorbidities to hospital readmissions. However,

there are at least 10 features that have NaN values

which implies there are several conditions that are not

commonly diagnosed (or ignored) by the physicians.

There is a possibility that this could be due to the

Emergency Room data of MIMIC-III that certain

types of diseases or conditions were not common

among this group. Furthermore, even though top 5

principal components identified by PCA analysis

explain 74% of the variance (See Table 1), they are

not very well-aligned with the key features

highlighted by the logistic regression.

Table 1: Cumulative variance explained by principal

components.

Cumulative variance

1 PC 2 PCs 3 PCs 4 PCs 5 PCs

DIAGNOSED 0.29 0.44 0.58 0.68 0.74

PREDCITED_

COMORBIDITIES

0.25 0.47 0.6 0.71 0.78

DIAGNOSED +

PREDCITED

COMORBIDITIES

0.27 0.47 0.61 0.71 0.77

4.2 Comorbidities Extracted by NLP

The Chi-square test performed on the PREDICTED

COMORBIDITIES dataset also returns chi-square

statistics for all the co-morbidities well below the

critical value. Therefore, the relation between EHI

comorbidities predicted by the NLP is significant at

p<0.05. However, there are conspicuous differences

in the diseases/comorbidities highlighted as most

influential ones in this dataset in comparison to the

DIAGNOSED dataset. Except for the AIDS/HIV

Lymphoma which is life-threatening, rest of them

appear to be chronic but slowly developing conditions

gradually affecting patient’s quality of life. It is not

surprising that Psychoses, Hypothyroidism,

Rheumatoid Arthritis, Peptic ulcer diseases, and drug

abuse have been noted in the unstructured parts of the

EHRs but not in the main diagnosis. The doctors

would typically note the most prevalent and billed

comorbidities in their diagnoses while discussing the

other notable historical conditions in the notes.

It shows the effectiveness of NLP techniques in

identifying conditions that are otherwise side-lined.

But what is even more notable are the 78% variance

explained by principal components as well as much

better alignment between the logistic regression

features and the principal components. This looks like

a stronger model than the first one. But at the same, it

is surprising that well-known comorbidities leading

to early mortality, such as congestive heart failure and

hypertension have not been identified as key factors

behind early hospital readmissions. There are few

overlaps between the significant principal

components of the two datasets.

4.3 Combined Comorbidities

The Chi-square test performed on this combined

dataset yields the same significant results for p<0.5

that all considered comorbidities are related to

hospital readmissions. However, these are even better

An NLP-Enhanced Approach to Test Comorbidities Risk Scoring Based on Unstructured Health Data for Hospital Readmissions Prediction

655

Table 2: Results of Chi-square, Logistic Regression Feature Scoring and Principal Component Analysis – sorted on Logistic

Regression Features Scores of Predicted Codes.

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

656

since quite intuitively, this dataset has fewer NaN

values i.e. only two compared to the eight and ten of

the other two models. In other words, there are more

significant relations between comorbidities and

hospital readmissions in this dataset. The logistic

regression feature scores definitely overcome the

limitations shown by each of the earlier models. For

instance, the top five influential features include

Congestive Heart Failure and AIDS/HIV lymphoma

on one hand and on the other hand they also check

slowly progressing diseases like psychoses, paralysis

and drug abuse. The combined variance explained by

top 5 principal components is not improved further

staying at 77% but it is evident visually that many

more features are contributing to an align with these

principal components.

4.4 Comparative Classification

Performance of the Three EHI

Models

The student T-tests for independent samples were

performed on the three variants of the Elixhauser

comorbidity scoring models discussed in the previous

sub-sections. Each data set (N=3123) was broken

into a 75% training (n= 2395) and 25% test dataset

(n=728). A logistic regression classifier was trained

with the training dataset and then tested for

classification performance (0,1) with the test dataset.

The results are shown in Figs 1 a-c.

The t-statistic of classification done by scoring

model using diagnosed codes appears better but with

p>.05 it becomes insignificant. Scoring models based

on predicted codes (stand-alone or combination) are

significant at p<0.5 hence they tend to perform better

for hospital readmissions classification.

Overall, it is abundantly clear that NLP-enhanced

comorbidity scoring has merit and potential to

improve performance of the CDSS employing

comorbidities and comorbidity summary scores.

5 CONCLUSIONS

Improved comorbidity scoring is valuable as one of

the features in AI-based decision models. This

research aimed to test if comorbidity scoring can be

improved using NLP-enhanced approaches,

especially by gleaning additional ICD-10 codes from

unstructured portions of the EHRs. Such

improvements have huge implications for better

healthcare delivery, cost savings, and patient

outcomes.

Figure 1: a, b and c: Classification performance of the three

datasets based on calculated Elixhauser comorbidity scores

(a) Diagnosed, (b) Predicted_Comorbidities, and (c)

Combination of Diagnosed + Predicted_Comorbidities.

We employed a BERT model to glean additional

ICD-10 codes from unstructured portions of the

MIMIC-III patient EHRs. The comorbidities

represented by these codes and included in Elixhauser

index were then tested for hospital readmission

classification, separately as well as in combination

with existing codes diagnosed by the physians. We

noted improvements both in comorbidity

measurements as well as 30-days hospital

readmissions predictions. It is anticipated that better

NLP techniques, such as HLAN and KGs will offer

An NLP-Enhanced Approach to Test Comorbidities Risk Scoring Based on Unstructured Health Data for Hospital Readmissions Prediction

657

even more improvements. We also demostrated any

improvements in Computer-assisted coding (CAC)

especially for ICD-10 and ICD-11 codes will also

support other venues in the CDSS area. There is room

for building user trust in CDSS.

Like every research study, we faced limitations.

At first, the MIMIC-III dataset is primarily an

emergency admissions database. The physicians’

healthcare goals in emergency settings are different

from those in a general admissions so they may view

comorbidites and some variables differently from the

physicians handling regular admissions. The high

variations in logistic regression features scores

between DIAGNOSED and

PREDICTED_COMORBIDITIES could partly be

stemming from such differences. Another limitation

could be using a binary classifier for 30-days hospital

readmissions. The performance and effects would

have been more practical if a 30-days risk scoring

model was used using comorbidity summary score/s

as feature/s.

Methods and pipelines for testing and analysis can

also be improved. The effects of most diseases are

caclulated separately. Multimorbidity indices are

considered more relevant for assessing risks in some

medical areas. Co-occurene and covariances would

have be to accounted in comborbidy risk calculations.

We do intend to revisit and improve this research

using an HLAN (Hierarchical Label-wise Attention

Network) technique and a holistic 30-days risk

scoring model (including medical, demographic and

socio-economic features) as the final output of our

hospital readmission risks score cosidering alternate

care facilities.

REFERENCES

AHRQ, n.d., Agency for Healthcare Research and Quality

– Healthcare Cost and Utilization Project (AHRQ-

HCUP), Available at: https://www.hcup-us.ahrq.gov/

toolssoftware/comorbidityicd10/comorbidity_icd10.js

p, Last accesses: Nov 12, 2022.

Alsentzer, E., Murphy, J. R., Boag, W., Weng, W. H., Jin,

D., Naumann, T., & McDermott, M. (2019). Publicly

available clinical BERT embeddings. arXiv preprint

arXiv:1904.03323.

Arnaud, É., Elbattah, M., Gignon, M., & Dequen, G. (2021,

August). NLP-Based Prediction of Medical Specialties

at Hospital Admission Using Triage Notes. In 2021

IEEE 9th International Conference on Healthcare

Informatics (ICHI) (pp. 548-553). IEEE.

Aya (2020) Named entity recognition, Named Entity

Recognition, NER in NLP, NER Annotation. Available

at: https://www.ayadata.ai/service/named-entity-

recognition (Accessed: November 12, 2022).

Bao, W., Lin, H., Zhang, Y., Medical code prediction via

capsule networks and ICD knowledge. BMC Med

Inform Decis Mak 21 (Suppl 2), 55 (2021).

https://doi.org/10.1186/s12911-021-01426-9

Bayliss, E. A., Edwards, A. E., Steiner, J. F., & Main, D. S.

(2008). Processes of care desired by elderly patients

with multimorbidities. Family practice, 25(4), 287-293.

Bottle, A., & Aylin, P. (2011). Comorbidity scores for

administrative data benefited from adaptation to local

coding and diagnostic practices. Journal of clinical

epidemiology, 64(12), 1426-1433.

Cambria, E., & White, B. (2014). Jumping NLP curves: A

review of natural language processing research. IEEE

Computational intelligence magazine, 9(2), 48-57. doi:

10.1109/MCI.2014.2307227.

Chaudhri, V., Baru, C., Chittar, N., Dong, X., Genesereth,

M., Hendler, J., & Wang, K. (2022). Knowledge

Graphs: Introduction, History and, Perspectives. AI

Magazine, 43(1), 17-29.

Charlson, M. E., Pompei, P., Ales, K. L., & MacKenzie, C.

R. (1987). A new method of classifying prognostic

comorbidity in longitudinal studies: development and

validation. Journal of chronic diseases, 40(5), 373-383.

De Giorgi, A., Di Simone, E., Cappadona, R., Boari, B.,

Savriè, C., López-Soto, P. J., & Fabbian, F. (2020).

Validation and Comparison of a Modified Elixhauser

Index for Predicting In-Hospital Mortality in Italian

Internal Medicine Wards. Risk Management and

Healthcare Policy, 13, 443.

Devlin, J., Chang, M. W., Lee, K., & Toutanova, K. (2018).

Bert: Pre-training of deep bidirectional transformers for

language understanding. arXiv preprint

arXiv:1810.04805.

Elixhauser, A., Steiner, C., Harris, D. R., & Coffey, R. M.

(1998). Comorbidity measures for use with

administrative data. Medical care, 8-27.

Esteban-Gil, A., Fernández-Breis, J. T., & Boeker, M.

(2017). Analysis and visualization of disease courses in

a semantically-enabled cancer registry. Journal of

biomedical semantics, 8(1), 1-16.

Evans, R. Scott. “Electronic health records: then, now, and

in the future.” Yearbook of medical informatics 25.S 01

(2016): S48-S61.

Fabbian, F., De Giorgi, A., Maietti, E., Gallerani, M., Pala,

M., Cappadona, R., & Fedeli, U. (2017). A modified

Elixhauser score for predicting in-hospital mortality in

internal medicine admissions. European Journal of

Internal Medicine, 40, 37-42.

Feinstein, A. R. (1970). The pre-therapeutic classification

of co-morbidity in chronic disease. Journal of chronic

diseases, 23(7), 455-468.

Gasparini, A. (2018). Comorbidity: An R package for

computing comorbidity scores. Journal of Open Source

Software, 3(23), 648.

Ghazalbash, S., Zargoush, M., Mowbray, F., &

Papaioannou, A. (2021). Examining the predictability

and prognostication of multimorbidity among older

Delayed-Discharge Patients: A Machine learning

analytics. International Journal of Medical Informatics,

156, 104597.

CCH 2023 - Special Session on Machine Learning and Deep Learning for Preventive Healthcare and Clinical Decision Support

658

Greenfield, S., Apolone, G., McNeil, B. J., & Cleary, P. D.

(1993). The importance of co-existent disease in the

occurrence of postoperative complications and one-

year recovery in patients undergoing total hip

replacement: comorbidity and outcomes after hip

replacement. Medical care, 31(2), 141-154.

Goltz, D. E., Ryan, S. P., Howell, C. B., Attarian, D.,

Bolognesi, M. P., & Seyler, T. M. (2019). A weighted

index of Elixhauser comorbidities for predicting 90-day

readmission after total joint arthroplasty. The Journal

of arthroplasty, 34(5), 857-864.

Hameed, T., & Bukhari, S. A. C. (2020). Predicting 30-days

All-cause Hospital Readmissions Considering

Discharge-to-alternate-care-facilities. In HEALTHINF

(pp. 864-873).

Havlik, R. J., Yancik, R., Long, S., Ries, L., & Edwards, B.

(1994). The National Institute on Aging and the

National Cancer Institute SEER collaborative study on

comorbidity and early diagnosis of cancer in the

elderly. Cancer, 74(S7), 2101-2106.

Huggingface, n.d., Huggingface BERT model, available at:

https://huggingface.co/docs/transformers/model_doc/b

ert, [Last accessed: Nov 12, 2022]

Johnson, A. E., Pollard, T. J., Shen, L., Lehman, L. W. H.,

Feng, M., Ghassemi, M., ... & Mark, R. G. (2016).

MIMIC-III, a freely accessible critical care database.

Scientific data, 3(1), 1-9.

Johnson, A. E., Pollard, & Mark, R. G. (2019). MIMIC-III

Clinical Database Demo (version 1.4). PhysioNet.

http://doi.org/10.13026/C2HM2Q.

Le, N., Wiley, M., Loza, A., Hristidis, V., & El-Kareh, R.

(2020). Prediction of Medical Concepts in Electronic

Health Records: Similar Patient Analysis. JMIR

Medical Informatics, 8(7), e16008. https://doi.org/

10.2196/16008

Lee, J., Yoon, W., Kim, S., Kim, D., Kim, S., So, C. H., &

Kang, J. (2020). BioBERT: a pre-trained biomedical

language representation model for biomedical text

mining. Bioinformatics, 36(4), 1234-1240.

Menendez, M. E., Neuhaus, V., van Dijk, C. N., & Ring, D.

(2014). The Elixhauser comorbidity method

outperforms the Charlson index in predicting inpatient

death after orthopaedic surgery. Clinical Orthopaedics

and Related Research®, 472(9), 2878-2886.

Moore, B. J., White, S., Washington, R., Coenen, N., &

Elixhauser, A. (2017). Identifying increased risk of

readmission and in-hospital mortality using hospital

administrative data. Medical care, 55(7), 698-705.

Mukherjee, B., Ou, H. T., Wang, F., & Erickson, S. R.

(2011). A new comorbidity index: the health-related

quality of life comorbidity index. Journal of clinical

epidemiology, 64(3), 309-319.

Piccirillo, J. F., Tierney, R. M., Costas, I., Grove, L., &

Spitznagel Jr, E. L. (2004). Prognostic importance of

comorbidity in a hospital-based cancer registry. Jama,

291(20), 2441-2447.

Quan, H., Sundararajan, V., Halfon, P., Fong, A., Burnand,

B., Luthi, J. C., & Ghali, W. A. (2005). Coding

algorithms for defining comorbidities in ICD-9-CM

and ICD-10 administrative data. Medical care, 1130-

1139.

Quan, H., Li, B., Couris, C. M., Fushimi, K., Graham, P.,

Hider, P., & Sundararajan, V. (2011). Updating and

validating the Charlson comorbidity index and score for

risk adjustment in hospital discharge abstracts using

data from 6 countries. American journal of

epidemiology, 173(6), 676-682.

Panchendrarajan, R., & Amaresan, A. (2018). Bidirectional

LSTM-CRF for named entity recognition. In

Proceedings of the 32nd Pacific Asia Conference on

Language, Information and Computation.

Sharabiani, M. T., Aylin, P., & Bottle, A. (2012).

Systematic review of comorbidity indices for

administrative data. Medical care, 1109-1118.

Sharma, N., Schwendimann, R., Endrich, O., Ausserhofer,

D., & Simon, M. (2021). Comparing Charlson and

Elixhauser comorbidity indices with different

weightings to predict in-hospital mortality: an analysis

of national inpatient data. BMC health services

research, 21(1), 1-10.

Soomro, P. D., Kumar, S., Shaikh, A. A., & Raj, H. (2017).

Bio-NER: biomedical named entity recognition using

rule-based and statistical learners. International

Journal of Advanced Computer Science and

Applications, 8(12).

Sung, S. F., Chen, C. H., Pan, R. C., Hu, Y. H., & Jeng, J.

S. (2021). Natural Language Processing Enhances

Prediction of Functional Outcome After Acute

Ischemic Stroke. Journal of the American Heart

Association, 10(24), e023486. https://doi.org/10.1161/

JAHA.121.023486

Tome Eftimov, Barbara Koroušić Seljak, and Peter

Korošec. “A rule-based named-entity recognition

method for knowledge extraction of evidence-based

dietary recommendations”. In: PloS one 12.6 (2017),

e0179488

Vafajoo, A., Salarian, R., & Rabiee, N. (2018).

Biofunctionalized microbead arrays for early diagnosis

of breast cancer. Biomedical Physics & Engineering

Express, 4(6), 065028.

Valderas, J. M., Starfield, B., Sibbald, B., Salisbury, C., &

Roland, M. (2009). Defining comorbidity: implications

for understanding health and health services. The

Annals of Family Medicine, 7(4), 357-363.

van Walraven, C., Austin, P. C., Jennings, A., Quan, H., &

Forster, A. J. (2009). A modification of the Elixhauser

comorbidity measures into a point system for hospital

death using administrative data. Medical care, 626-633.

Von Korff, M., Wagner, E. H., & Saunders, K. (1992). A

chronic disease score from automated pharmacy data.

Journal of clinical epidemiology, 45(2), 197-203.

Wang, J., Deng, H., Liu, B., Hu, A., Liang, J., Fan, L.,

Zheng, X., Wang, T., & Lei, J. (2020). Systematic

Evaluation of Research Progress on Natural Language

Processing in Medicine Over the Past 20 Years:

Bibliometric Study on PubMed. Journal of medical

Internet research, 22(1), e16816.

https://doi.org/10.2196/16816

Wolff, J. L., Starfield, B., & Anderson, G. (2002).

Prevalence, expenditures, and complications of

multiple chronic conditions in the elderly. Archives of

internal medicine, 162(20), 2269-2276.

An NLP-Enhanced Approach to Test Comorbidities Risk Scoring Based on Unstructured Health Data for Hospital Readmissions Prediction

659
