A New Approach for Software Quality Assessment Based on Automated

Code Anomalies Detection

Andrea Biaggi, Umberto Azadi and Francesca Arcelli Fontana

Universit

a degli Studi di Milano-Bicocca, Milano, Italy

Keywords:

Empirical Study, Software Quality Assessment, Software Evolution, Code Anomalies Detection, Artiﬁcial

Immune Systems.

Abstract:

Methods and tools to support quality assessment and code anomaly detection are crucial to enable software

evolution and maintenance. In this work, we aim to detect an increase or decrease in code anomalies leveraging

on the concept of microstructures, which are relationships between entities in the code. We introduce a tools

pipeline, called Cadartis, which uses an innovative immune-inspired approach for code anomaly detection,

tailored to the organization’s needs. This approach has been evaluated on 3882 versions of ﬁfteen open-source

projects belonging to three different organizations and the results conﬁrm that the approach can be applied to

recognize a decrease or increase of code anomalies (anomalous status). The tools pipeline has been designed

to automatically learn patterns of microstructures from previous versions of existing systems belonging to

the same organization, to build a personalized quality proﬁler based on its codebase. This work represents a

ﬁrst step towards new perspectives in the ﬁeld of software quality assessment and it could be integrated into

continuous integration pipelines to proﬁle software quality during the development process.

1 INTRODUCTION

Code anomalies is a term that refers to several cat-

egories of code sub-optimalities that include code

smells, bugs, antipatterns and several other software

issues (Fowler, 2018). A system containing such

anomalies should be maintained to avoid progressive

software degradation. Therefore, methods and tools

to support quality assessment and code anomaly de-

tection are crucial during both software development

and software evolution and maintenance. In fact, dur-

ing the development of large software systems where

several developers are involved, it is useful to have

tools that report a kind of software quality proﬁle so

that the team leader can monitor and correct some as-

pects (such as code anomalies) during the develop-

ment process.

This work aims to identify a decrease or increase

in software quality through an approach based on

code anomaly detection. We decided to accomplish

this objective by using a rule-based approach that ex-

ploits a particular kind of structure, called the mi-

crostructure (MS). These MSs are deﬁned as facts or

relationships between two entities in the code (e.g.

classes, attributes, methods) (Arcelli Fontana et al.,

2013). Examples of microstructures are Data Man-

ager (Gil and Maman, 2005), which is a MS that rep-

resents a class where all methods are either getters or

setters, and Empty Method, a MS that occurs when a

method does not contain any implementation except

for returning a primitive type. The advantage of using

these metrics instead of the classical ones (LOC, CC,

...) (Fenton and Bieman, 2014) is that the microstruc-

tures incorporate information about architectural and

design decisions, and they can be directly inﬂuenced

by changes that concern these aspects. Therefore,

our goal is to extract rules, expressed in terms of mi-

crostructures, that could be able to predict an increase

or a decrease in code anomalies. These rules can be

seen as patterns of microstructures, which we will call

in this paper Microstructure Patterns (MSP). Further-

more, we require human-readable rules to allow de-

velopers to understand why our tools pipeline could

suggest an increase or decrease of code anomalies in

order to understand which problems caused a given

rule to be triggered.

The problem deﬁned in this way can be tackled as

a problem of anomaly detection. To understand this

conceptual jump we can use an example that inten-

tionally exasperates this concept: if we analyze the

history of a system and we observe that usually 100

code anomalies are identiﬁed, and then in the next re-

546

Biaggi, A., Azadi, U. and Fontana, F.

A New Approach for Software Quality Assessment Based on Automated Code Anomalies Detection.

DOI: 10.5220/0011965200003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 546-553

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

lease of the system we identify 1000 code anomalies,

we could state that the status of the system is anoma-

lous. The objective is to identify some rules that can

describe why such anomalous status has occurred and

allow developers to take the right decisions. These

rules represent the kind of anomaly that we aim to

detect: an anomalous status represented through an

increase of code anomalies in the monitored system.

In the context of data mining, a paradigm used to de-

scribe problems of anomaly detection is through the

artiﬁcial immune systems (AIS) (Dasgupta, 2012),

which represent a class of rule-based machine learn-

ing systems, inspired by the principles and processes

of the human immune system, which is particularly

suited to obtain human-readable results.

To perform the detection of such anomalies, this

work introduces a tools pipeline called Cadartis,

(Code Anomalies Detection using ARTiﬁcial Immune

Systems). The pipeline analyzes the evolution in

terms of versions of Java software systems to infer

rules that measure the quality of the system, which are

then used to assess newer versions. The main beneﬁt

of this approach is that the rules are automatically in-

ferred through machine learning algorithms based on

existing systems’ history belonging to the same orga-

nization, thus deﬁning a kind of personalized quality

proﬁler tailored for the organization’s needs. Further-

more, such a quality proﬁler can be used both on ex-

isting projects, during the maintenance phase, and on

new projects during development.

The paper is organized through the following sec-

tions: in Section 2 we introduce some related works

on code anomalies detection and works on the ex-

ploitation of AIS, in Section 3 we describe the dif-

ferent components of the Cadartis pipeline, and two

main Research Questions, in Section 4 we describe

the results obtained in the evaluation of Cadartis on 15

projects of different organizations (Apache, Eclipse

and Google). Finally, we report the threats to validity

of our work and the possible future developments.

2 RELATED WORK

In the past few years, artiﬁcial immune systems have

been applied in different areas of software engineer-

ing, from software cost estimation (SCE) (Lee and

Kwon, 2009), software testing, to software mainte-

nance and evolution (Parrend et al., 2018). For in-

stance, the work of Gharehchopogh et al. (Gharehcho-

pogh et al., 2014) proposes a hybrid model for SCE

based on the combination of AIS and genetic algo-

rithms. Regarding software testing, there are sev-

eral works involving AIS. For example, the work of

Liaskos and Roper (Liaskos and Roper, 2008) in the

context of search-based test case generation. As for

software maintenance and evolution, the work of Has-

saine et al. (Hassaine et al., 2010) proposes an AIS-

based model for software design smell detection to

compare it with state-of-art approaches such as the

DECOR tool (Moha et al., 2009). According to our

knowledge, we have not found approaches for code

anomaly detection based on artiﬁcial immune sys-

tems, as the one described in this paper, used to build

a personalized software quality proﬁle. While accord-

ing to code anomalies detection, the most commonly

detected anomalies are code smells, software bugs

and other issues/code violations such as those com-

puted for example by the tool SonarQube

. Many

approaches have been proposed for code smells de-

tection implemented in a variety of tools which ex-

ploit different techniques, such as: static code analy-

sis, refactoring identiﬁcation e.g., JDeodorant (Tsan-

talis and Chatzigeorgiou, 2011) or metrics compu-

tation, used by many tools e.g., inFusion, inCode,

PMD, Checkstyle, and JCodeOdor. These approaches

rely on a single metric or a combination of metrics

that correspond to code properties relevant to a given

smell. Other tools exploit techniques based on a dedi-

cated domain-speciﬁc language (DSL), that use high-

level abstractions to uncover design anomalies, e.g.,

DECOR (Moha et al., 2009); machine learning clas-

siﬁers (Arcelli Fontana et al., 2016; Azadi et al., 2018;

Maiga et al., 2012); techniques based on Bayesian be-

lief networks (Khomh et al., 2009), on the analysis

of software repositories (Palomba et al., 2013; Rapu

et al., 2004) and on design change propagation prob-

ability (Rao and Reddy, 2007).

The variety of approaches leads to considerable

differences in the anomalies detected (Mantyla, 2005;

Arcelli Fontana et al., 2012), which make it difﬁcult to

analyze anomalies and compare the results. Through

our AIS-based approach, we aim to provide a new

perspective in this area.

3 CADARTIS

Cadartis (Code Anomalies Detection using ARTiﬁcial

Immune Systems) is a tools pipeline designed for or-

ganizations interested in building an artiﬁcial immune

system (AIS) based on their codebase. As illustrated

in Figure 1, the pipeline consists of two main compo-

nents: the ﬁrst one, called AIS Automated Learner,

is responsible for analyzing the dataset through a

machine learning process and reporting a rule-based

https://www.sonarqube.org/

A New Approach for Software Quality Assessment Based on Automated Code Anomalies Detection

547

Dataset

AIS

Automated

Learner

Model

Artificial

Immune

System

Evaluation

New

Version

Figure 1: Cadartis pipeline.

human-readable model from which it is possible to

infer the microstructure patterns (MSP), that are the

rules used to identify a possible system degradation

of the system (an increase of anomalies). The sec-

ond one, Artiﬁcial Immune System, is the component

that is responsible for analyzing the versions to be as-

sessed to report an evaluation according to the MSP

reported in the model, as explained in Section 3.4.

Speciﬁcally, a microstructure pattern represents a

recurring scheme of microstructures expressed by a

set of conditions that are associated with an increase

or a decrease of the anomalies.

More formally, a MSP is expressed as: MS

≤

& MS

> k

−→ variation, where MS

and MS

are instances of microstructures, i.e. one of the fea-

tures of the dataset described in Section 3.2, k

and

are the numbers of instances of the corresponding

microstructure and variation is the target variable and

it can assume two possible values: “Increase”, if the

number of code anomalies has increased compared to

the previous version, “Decrease” otherwise (see Sec-

tion 3.3.1).

Thanks to these patterns it is possible 1) to assess

whether there is a relationship between the variation

of the code anomalies and the microstructures and

2) to understand which microstructures contribute the

most in the variation of code anomalies. The compo-

nents are released as standalone Java applications

so that they can be used separately, for example in a

continuous integration pipeline.

3.1 Problem Statement

This work aims to answer the following research

questions (RQs):

RQ1: Can the microstructures patterns (MSP) de-

scribe and help to predict an anomalous state of the

system?

RQ2: Which microstructures in the MSP are the

most effective to describe the overall code quality?

The answers to these research questions are use-

ful to understand if the approach proposed in this

study can be applied to the problem issued (RQ1),

thus opening new perspectives in the ﬁeld of software

quality assessment. Moreover, answering RQ2 allows

Replication package available here

us to understand whether speciﬁc microstructures are

more useful than others to recognize code anomalies.

3.2 Collected Data

In this work, we analyze the evolution, in terms

of versions, of entire software systems of speciﬁc

organizations to collect the microstructures and the

number of code anomalies. The dataset is made

of 47 features variables and one target variable

The features are the microstructures, which are di-

vided into three categories: Elemental Design Pat-

terns (EDP) (Arcelli Fontana et al., 2013), Micro Pat-

tern (MP) (Gil and Maman, 2005) and Design Pattern

Clues (DPC) (Arcelli Fontana et al., 2013). The target

variable in this step is the number of code anomalies

as reported by the PMD tool, which will be then dis-

cretized to represent the variation from one version to

the next one (see Section 3.3.1). The following sec-

tions explain how all the data are collected.

3.2.1 Microstructure Extraction

Since we were not able to ﬁnd any tool for the mi-

crostructure extraction suitable for our purposes, a

new one has been developed. It is distributed as a

standalone Java application and takes as input the di-

rectory of the Git repository to be analyzed using

static analysis. Since the microstructures are meant

to be mechanically recognizable (Gil and Maman,

2005), this approach has already been used and tested

in several other applications (Zanoni et al., 2015) (Ar-

celli Fontana et al., 2005) in the context of speciﬁc

tools or Eclipse plug-ins. The deﬁnitions of the con-

sidered 47 MS can be found in the replication pack-

age.

3.2.2 Code Anomalies Extraction

In this work, the number of code anomalies has been

considered as a target and they are extracted using a

tool called PMD

. This tool is able to recognize sev-

eral anomalies belonging to different categories ac-

cording to the PMD Java rule reference

. We consid-

ered the following categories: Design, Security, Per-

formance, Multithreading, Error Prone. We selected

PMD as a tool for software quality assessment be-

cause it is widely employed (Allier et al., 2012) and it

can be easily used standalone from a command line,

hence particularly suitable for our purposes. As a pre-

liminary analysis, we computed squared Pearson cor-

relation (R

) between the variable and the target and

Dataset available inside replication package

https://pmd.github.io/

https://pmd.github.io/latest/pmd rules java.html

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

548

Parameter

Optimization

Training

Paired

corrected t-test

Feature

Selection

Best

classifier

Preprocessing

Dataset

(a)

(b)

(c)

Performance

Evaluation

AIS Automated Learner

Figure 2: Pipeline of the AIS Automated Learner.

measured how well a variable predicts the value of

the target. The R

value ranges from 0 to 1, where

0 means that a variable is independent from the tar-

get, while 1 means that a variable accurately predicts

the value of the target. The results showed near-zero

values for each variable, so we can conclude that the

features are almost independent by the target.

3.3 AIS Automated Learner

This section describes the component responsible for

analyzing the dataset to infer the microstructure pat-

terns that deﬁne the rule set of the artiﬁcial immune

system. Thanks to this component it is possible to

personalize the analysis to report feedback based on

the systems’ history for each organization. To do this,

the collected data are the input of the machine learn-

ing process illustrated in Figure 2 and explained in

the following sections. In particular, Section 3.3.1

explains which preprocessing operations are made on

the dataset before the machine learning analysis and

the feature selection criteria to reduce the dimension-

ality of the dataset (Figure 2 (a) and (b)); Section 3.3.2

explains which algorithms are used in this study, how

the parameter optimization is performed and how the

trained models are compared to ﬁnd the best one (Fig-

ure 2 (b) and (c)).

3.3.1 Preprocessing and Feature Selection

The dataset target variable is discretized to be suit-

able for a classiﬁcation task. The discretization con-

sists in computing the difference between the number

of anomalies per class in the current version and the

number of anomalies per class in the previous ver-

sion so that the target becomes Increase if the dif-

ference is positive, or Decrease otherwise. More-

over, the features related to the microstructures have a

very high variance, which can cause a decrease in the

performance of the classiﬁcation task. To overcome

this problem, the dataset has been normalized ac-

cording to the min-max feature scaling method (Han

et al., 2011) that consists of scaling all the values in a

ﬁxed range [a, b]. After that, we reduced the dimen-

sionality of the dataset to remove redundant features

and to consequently improve the performance dur-

ing the classiﬁcation task and avoid the phenomenon

known as curse of dimensionality (Bellman and Drey-

fus, 2015). The ﬁrst step was performing a correla-

tion analysis to understand the degree of correlation

among features to have an insight into which thresh-

old could be suitable for a correlation-based feature

selection. In this work, the feature selection is made

by using a correlation interval instead of a single value

to perform the classiﬁcation, and the optimal thresh-

old in this interval is chosen through an iterative pro-

cess (Figure 2 (b)).

3.3.2 Algorithms Selection and Comparison

The choice of the algorithm has been guided by the

need of having a human-readable model. Thanks to

this kind of models it is possible to infer human-

readable rules, the microstructures patterns, that as-

sociate a combination of microstructures with an out-

come. As a consequence, three well known al-

gorithms have been chosen: J48 (Quinlan, 2014),

RandomForest (Breiman, 2001) and JRip (Cohen,

1995). All of them have been used with and without

the boosting techniques AdaBoostM1 (Freund et al.,

1996), therefore in total six models have been trained

and tested. Furthermore, we used pruning techniques

to reduce the depth of rules/trees, in order to make

them easier to be manually inspected. For each al-

gorithm, a step of parameter optimization has been

performed. The goal of this phase is to ﬁnd the best

combination of parameters to achieve the most per-

forming classiﬁer for each algorithm at every step of

classiﬁcation to be computed in the correlation inter-

val. For each possible conﬁguration the classiﬁer is

trained in a 10-fold cross-validation and the best pa-

rameters are chosen according to the minimum error

rate. To evaluate the overall best classiﬁer, the six

classiﬁers took part in a paired corrected t-test that

produces a ranking of algorithms. To achieve this,

the dataset has been divided into two partitions: the

training partition consists of four out of ﬁve projects

belonging to the organization, while the test partition

is the ﬁfth. This separation has been chosen because

it simulates the introduction of a new project in the

organization’s codebase. The test compares the clas-

siﬁers to one another and computes whether the dif-

ference in performances among algorithms is statisti-

cally signiﬁcant, producing a ranking ordered by the

number of victories, that is the number of times that a

classiﬁer outperformed another. The paired corrected

t-test with ranking was performed by using the im-

plementation provided by Weka Experimenter (Hall

et al., 2009).

A New Approach for Software Quality Assessment Based on Automated Code Anomalies Detection

549

3.4 Artiﬁcial Immune System

The artiﬁcial immune system (AIS) is the component

responsible for assessing new versions of systems. As

shown in Figure 1, this component takes as input the

model reported by the learner that has been trained on

the existing codebase of a speciﬁc organization and

contains the microstructure patterns.

Model

New Version

Artificial Immune System

Build set of

Predictors

Micro-Structure

Patterns (MSPs)

Extract Features

Instance

Find a MSP that

matches the

instance

MSP

matched

Figure 3: AIS Component Workﬂow.

As illustrated in Figure 3, whenever a new version

of a system of an organization is ready, that can be

either a new version of an existing system used for

the analysis or a version of a new system that the or-

ganization wants to proﬁle during the development,

the system analyzes the new version and extracts the

features, as explained in Section 3.2, thus building an

instance of the dataset. The artiﬁcial immune system

ﬁnds the MSP that matches the input instance and re-

ports an evaluation that consists of the outcome for

that instance together with the MSPs that have been

matched.

4 RESULTS

Cadartis has been tested by analysing 15 projects,

taken from 3 different organizations: Apache, Eclipse

and Google. All the projects can be found on GitHub

and they are described in the replication package. In

this section, we provide an overview of the perfor-

mance of the best classiﬁer for the three different

organizations (Section 4.1), to evaluate and discuss

strong and weak points that emerged during the learn-

ing of the patterns. Moreover, we illustrate the mi-

crostructure patterns (MSP) reported for each orga-

nization (Section 4.2). The replication package con-

taining the tools developed and the data collected is

available

4.1 Performance Evaluation

We analyze the performance of the three models, il-

lustrating the best-performing algorithm as a result

https://github.com

Data available inside replication package

Table 1: Resulting performance metrics of the best classiﬁer

for each organization.

Metric Decrease Increase Best

Apache

Precision 84.26 % 55.36 %

J48

Recall 78.45 % 64.58 %

F-measure 81.25 % 59.62 %

Accuracy 74.39 % 74.39 %

Eclipse

Precision 85.00 % 32.26 %

JRip

Recall 66.93 % 57.14 %

F-measure 74.89 % 41.24 %

Accuracy 64.81 % 64.81 %

Google

Precision 89.23 % 22.00 %

J48

Recall 74.84 % 44.00 %

F-measure 81.40 % 29.33 %

Accuracy 70.56 % 70.56 %

of the paired corrected t-test with ranking discussed

in Section 3.3.2 and the performance achieved by the

classiﬁers using the most common performance met-

rics: Precision, Recall, F-measure and Accuracy. Ta-

ble 1 reports the resulting performance metrics of the

best classiﬁer for each organization. From the metrics

reported in Table 1 regarding all the organizations,

it is possible to conclude that the classiﬁers perform

better when predicting instances that belong to the

“Decrease” class, while the performances decrease,

with different degrees, when it comes to predicting

instances of “Increase” class, but the overall perfor-

mance for each organization remains satisfactory.

4.2 Results on MSPs

The outcome of this experimentation is a catalog of 73

MSPs, which is available inside replication package

Each MSPs has been manually validated to assess

whether the microstructures involved in a pattern can

affect positively or negatively the software quality ac-

cording to known object-oriented programming prin-

ciples (Savitch, 2000) object-oriented design princi-

ples (Martin, 2002), software quality attributes or bad

practices (Brown et al., 1998).

These principles have been used to understand

whether the presence of a microstructure can lead to

a better or worse software quality and according to

which principles. This process allowed us to ﬁnd sev-

eral interesting facts (F) on the MS related to the prin-

ciple enforced or violated. By analyzing the deﬁnition

of each microstructure

, we observed that some MSs

can be seen as indicators of good or bad programming

practices.

Microstructure Patterns detected available here

Microstructure catalog available here

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

550

An example of MSP and the related facts found

through the analysis follows, where Record, Re-

vert Method and Data Manger are the names of

three MS: Record ≥ 49 & RevertMethod ≥ 12 &

DataManager ≥ 76 −→ Increase.

F1: Record instances represent classes that de-

clare only public ﬁelds without methods. Instances

of this MS represent a bad practice. Hence, many

Record instances could cause an increase in anoma-

lies.

F2: Revert Method instances involve bypassing

the current class’ implementation of a method, instead

using the superclass’ implementation, thus violating

the encapsulation principle.

F3: Data Manager is a MS that represents classes

composed only by private ﬁelds, getters and setters.

This is considered bad practice because it corresponds

to the Data Class code smell, hence many instances

of this MS could lead to an increase in anomalies.

These MS provide hints of bad quality, hence a pos-

sible increase of code anomalies. We did the same

analysis on all the other MSs involved in all the 73

MSPs. It is important to note that not all the MSPs

can be explained with the aforementioned criteria, in

fact around 40% of them cannot be explained with any

of the principles taken into consideration. The reason

is that some of the deﬁnitions of the MS are neutral,

meaning that it is not possible to assess whether many

or few instances of them could cause an increase or a

decrease in the anomalies.

4.3 Answers to the RQs

Concerning RQ1, we can observe that several MSPs

reﬂect well-known software quality attributes, object-

oriented principles or bad practices that have been

taken into consideration during the manual evaluation

of the MSPs. This result highlights that the obtained

rules are already useful and relevant and we can argue

that the MSP can already help to predict an anomalous

state since they are already able to detect when the

principles and practice mentioned above are violated.

However, we are also quite conﬁdent that several ad-

ditional insights might be extracted by those who de-

veloped and maintained the system since they were

familiar with the code and the development process.

Furthermore, we can argue that these insights might

be the most valuable since our purpose was to create

a customise quality proﬁler. We are also aware that

the performance of the classiﬁer are quite low how-

ever we still think that should be considered as a good

baseline for the problem issued in this research be-

cause 1) the classiﬁcation task tackled in this work

was particularly hard since it involved learning pat-

Table 2: Qualitative analysis of the results.

Result Related microstructures

Increase Data Manager, Record, Trait,

Empty Concrete Product Getter,

Controlled Instantiation, Revert

Method

Decrease Concrete Product Returned, Ex-

tend Method, Factory Parameter,

Conglomeration, Controlled Ex-

ception, Sink

Increase if Redirect, Delegate, Delegated

Conglomeration, Abstract Class,

Retrieve

lack or exceed

terns on a set of projects and validating the results on a

different set of projects and 2) we decided to use only

algorithms that output human-readable model, which

often performs worse compared to other algorithms

commonly used, such as Support Vector Machines

and Neural Network. Concerning RQ2, there is no

category of microstructures (EDP, MP, DPC) more

effective than another to describe the code quality.

All the patterns are composed of microstructures be-

longing to different categories. It’s worth mentioning

that speciﬁc categories of patterns are more present

in some organizations than others. This information

supports the decision to focus our work on the cus-

tomization of the AIS accomplished through the AIS

Automated Learner, described in Section 3.3. Finally,

we provide some examples of data that we were able

to extract from the manual evaluation of the MSPs

that support the answer to the RQs above, which are

reported in Table 2. An example concerns the MS

Data Manager, Record, Trait and others indicated in

the ﬁrst row of Table 2, that is MS whose presence

is always associated with a degradation of the system

quality because they all represent violations of differ-

ent object-oriented programming principles.

4.4 Threats to Validity

As for threats to internal validity, the usage of only

the number of one kind of anomaly as a target may

have affected the results, since the usage of other mea-

sures may produce different results. However, PMD

is one of the commonly used commercial tools for

code anomaly detection, so the choice of this tool

remains relevant. When it comes to external valid-

ity, the number of projects considered for each orga-

nization is limited and doesn’t consider every appli-

cation domain. For this reason, the results may be

affected by a lack of generalization within an orga-

nization, because it is possible that some MSPs can

A New Approach for Software Quality Assessment Based on Automated Code Anomalies Detection

551

be inferred only in relation to a speciﬁc application

domain. In any case, all the projects belong to rel-

evant and signiﬁcant organizations (Google, Eclipse,

Apache). Finally, we were not able to involve the de-

velopers of the three organizations taken into account

during the evaluation of the MSP, this is a limitation

since one of the aims of this work was to provide a

customized software quality assessment, that repre-

sents a more useful way than a generalized rule set,

but this aspect will be faced in a future extension of

this work. To mitigate this threat, well-known soft-

ware quality principles and best practices have been

taken into consideration during the evaluation of the

MSPs. This decision has led us to discover some pat-

terns that often reﬂect the well-known software qual-

ity issues that have been derived from those princi-

ples and practices. This result highlights that the ob-

tained rules are already useful and relevant and it is

very likely that a practitioner familiar with how the

code has been developed in each organization might

be able to notice several additional insights by analyz-

ing the MSPs. Moreover, all the data of this study can

be found in the replication package

5 CONCLUSIONS

In this work, we introduced a tools pipeline, called

Cadartis, for the detection of an anomalous status

of software systems (an increase of code anomalies)

based on an artiﬁcial immune system approach. It

is designed to automatically learn patterns from pre-

vious versions of existing systems belonging to the

same organization, to build a personalized quality

proﬁler based on its codebase. The patterns, that are

automatically inferred from the data, are composed

of MSs. The results have been evaluated on 3882 ver-

sions of ﬁfteen projects belonging to three different

organizations, thus building three different artiﬁcial

immune systems, one for each organization, to assess

1) whether this approach can be applied for software

quality assessment and 2) to understand which rela-

tionships exist between MS and the variation of the

code anomalies. The identiﬁed MS patterns can be

useful to developers, team leaders and quality analysts

involved in the software development or maintenance

process in order to understand which MSs affect the

quality and consequently plan a strategy of corrective

maintenance.

Our results conﬁrm that this approach can be ap-

plied in this ﬁeld and since there is no other study to

compare the results with, the performance obtained

Replication package available here

represents a good baseline for other studies that aim

to apply the same approach, although they have been

affected by the constraint of choosing only intelligi-

ble learning algorithms. The results showed that there

is no category more useful than another, however, a

given category is more or less representative based on

the organization taken into account.

Considering the results, future developments will

focus on two main aspects. The ﬁrst one is improving

the performance of the models, either by using other

classes of algorithms or by experimenting with other

approaches (active and semi-supervised learning).

The second regards the reduction of the number

of rules that cannot be associated with the outcome.

To do this, it is necessary to introduce more informa-

tion in the dataset, such as the category of the anoma-

lies explained in Section 3.2.2. Another alternative

could be to change the target using other tools to ex-

tract code anomalies, using quality indices or techni-

cal debt indices (Roveda et al., 2018), for example al-

lowing organizations that already use a quality index

to use it as a target for learning the patterns.

As for the pipeline components’ development, the

introduction of new algorithms requires the develop-

ment of modules that can parse the output of the new

models to build the set of patterns of the AIS. More-

over, since Cadartis can be used during the develop-

ment of a pipeline of continuous integration, another

direction can be the development of plugins, for the

platforms that support it, to ease the distribution of

the Artiﬁcial Immune System component.

REFERENCES

Allier, S., Anquetil, N., Hora, A., and Ducasse, S. (2012).

A framework to compare alert ranking algorithms. In

2012 19th Working Conference on Reverse Engineer-

ing, pages 277–285.

Arcelli Fontana, F., Braione, P., and Zanoni, M. (2012).

Automatic detection of bad smells in code: An ex-

perimental assessment. Journal of Object Technology,

11(2):5–1.

Arcelli Fontana, F., Maggioni, S., and Raibulet, C.

(2013). Design patterns: a survey on their micro-

structures. Journal of Software: Evolution and Pro-

cess, 25(1):27–52.

Arcelli Fontana, F., M

antyl

a, M. V., Zanoni, M., and

Marino, A. (2016). Comparing and experimenting

machine learning techniques for code smell detection.

Empirical Software Engineering, 21(3):1143–1191.

Arcelli Fontana, F., Masiero, S., and Raibulet, C. (2005).

Elemental design patterns recognition in java. In 13th

IEEE International Workshop on Software Technology

and Engineering Practice (STEP’05), pages 196–205.

IEEE.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

552

Azadi, U., Arcelli Fontana, F., and Zanoni, M. (2018).

Poster: Machine learning based code smell detection

through wekanose. In 2018 IEEE/ACM 40th Interna-

tional Conference on Software Engineering: Compan-

ion Proceedings (ICSE-Companion), pages 288–289.

IEEE.

Bellman, R. E. and Dreyfus, S. E. (2015). Applied dy-

namic programming, volume 2050. Princeton univer-

sity press.

Breiman, L. (2001). Random forests. Machine learning,

45(1):5–32.

Brown, W. H., Malveau, R. C., McCormick, H. W., and

Mowbray, T. J. (1998). AntiPatterns: refactoring soft-

ware, architectures, and projects in crisis. John Wiley

& Sons, Inc.

Cohen, W. W. (1995). Fast effective rule induction. In Ma-

chine learning proceedings 1995, pages 115–123. El-

sevier.

Dasgupta, D. (2012). Artiﬁcial immune systems and their

applications. Springer Science & Business Media.

Fenton, N. and Bieman, J. (2014). Software metrics: a rig-

orous and practical approach. CRC press.

Fowler, M. (2018). Refactoring: improving the design of

existing code. Addison-Wesley Professional.

Freund, Y., Schapire, R. E., et al. (1996). Experiments with

a new boosting algorithm. In International Confer-

ence on Machine Learning, volume 96, pages 148–

156. Citeseer.

Gharehchopogh, F. S., Maleki, I., Ghoyunchizad, N., and

Mostafaee, E. (2014). A novel hybrid artiﬁcial im-

mune system with genetic algorithm for software cost

estimation. Magnt Research Report, 2(6):506–517.

Gil, J. Y. and Maman, I. (2005). Micro patterns in java code.

ACM SIGPLAN Notices, 40(10):97–116.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reute-

mann, P., and Witten, I. H. (2009). The WEKA data

mining software: an update. SIGKDD Explorations,

11(1):10–18.

Han, J., Pei, J., and Kamber, M. (2011). Data mining: con-

cepts and techniques. Elsevier.

Hassaine, S., Khomh, F., Gu

eneuc, Y.-G., and Hamel, S.

(2010). Ids: An immune-inspired approach for the

detection of software design smells. In 2010 Sev-

enth International Conference on the Quality of Infor-

mation and Communications Technology, pages 343–

348. IEEE.

Khomh, F., Vaucher, S., Gu

eneuc, Y.-G., and Sahraoui,

H. (2009). A bayesian approach for the detection

of code and design smells. In 2009 Ninth Interna-

tional Conference on Quality Software, pages 305–

314. IEEE.

Lee, J.-k. and Kwon, K.-T. (2009). Software cost estimation

using svr based on immune algorithm. In 2009 10th

ACIS International Conference on Software Engineer-

ing, Artiﬁcial Intelligences, Networking and Paral-

lel/Distributed Computing, pages 462–466. IEEE.

Liaskos, K. and Roper, M. (2008). Hybridizing evolu-

tionary testing with artiﬁcial immune systems and lo-

cal search. In 2008 IEEE International Conference

on Software Testing Veriﬁcation and Validation Work-

shop, pages 211–220. IEEE.

Maiga, A., Ali, N., Bhattacharya, N., Sabane, A., Gue-

heneuc, Y.-G., and Aimeur, E. (2012). Smurf: A svm-

based incremental anti-pattern detection approach. In

2012 19th Working Conference on Reverse Engineer-

ing, pages 466–475. IEEE.

Mantyla, M. V. (2005). An experiment on subjective evolv-

ability evaluation of object-oriented software: ex-

plaining factors and interrater agreement. In 2005 In-

ternational Symposium on Empirical Software Engi-

neering, 2005., pages 10–pp. IEEE.

Martin, R. C. (2002). Agile software development: princi-

ples, patterns, and practices. Prentice Hall.

Moha, N., Gueheneuc, Y.-G., Duchien, L., and Le Meur,

A.-F. (2009). Decor: A method for the speciﬁcation

and detection of code and design smells. IEEE Trans-

actions on Software Engineering, 36(1):20–36.

Palomba, F., Bavota, G., Di Penta, M., Oliveto, R., De Lu-

cia, A., and Poshyvanyk, D. (2013). Detecting bad

smells in source code using change history informa-

tion. In Proceedings of the 28th IEEE/ACM Interna-

tional Conference on Automated Software Engineer-

ing, pages 268–278. IEEE Press.

Parrend, P., Guigou, F., Navarro, J., Deruyver, A., and Col-

let, P. (2018). For a refoundation of artiﬁcial im-

mune system research: Ais is a design pattern. In

2018 IEEE Symposium Series on Computational In-

telligence (SSCI), pages 1122–1129. IEEE.

Quinlan, J. R. (2014). C4.5: programs for machine learn-

ing. Elsevier.

Rao, A. A. and Reddy, K. N. (2007). Detecting bad smells

in object oriented design using design change propa-

gation probability matrix.

Rapu, D., Ducasse, S., G

ırba, T., and Marinescu, R. (2004).

Using history information to improve design ﬂaws de-

tection. In Eighth European Conference on Software

Maintenance and Reengineering, 2004. CSMR 2004.

Proceedings., pages 223–232. IEEE.

Roveda, R., Arcelli Fontana, F., Pigazzini, I., and Zanoni,

M. (2018). Towards an architectural debt index. In

2018 44th Euromicro Conference on Software Engi-

neering and Advanced Applications (SEAA), pages

408–416. IEEE.

Savitch, W. J. (2000). Java: an introduction to computer

science and programming. Prentice Hall PTR.

Tsantalis, N. and Chatzigeorgiou, A. (2011). Identiﬁcation

of extract method refactoring opportunities for the de-

composition of methods. Journal of Systems and Soft-

ware, 84(10):1757–1782.

Zanoni, M., Arcelli Fontana, F., and Stella, F. (2015). On

applying machine learning techniques for design pat-

tern detection. Journal of Systems and Software,

103:102–117.

A New Approach for Software Quality Assessment Based on Automated Code Anomalies Detection

553
