Sophos: A Framework for Application Orchestration in the

Cloud-to-Edge Continuum

Angelo Marchese

and Orazio Tomarchio

Dept. of Electrical Electronic and Computer Engineering, University of Catania, Catania, Italy

Keywords:

Cloud-to-Edge Continuum, Containers, Kubernetes Scheduler, Resource-Aware Scheduling, Network-Aware

Scheduling, Orchestration.

Abstract:

Orchestrating distributed applications on the Cloud-to-Edge continuum is a challenging task, because of the

continuously varying node computational resources availability and node-to-node network latency and band-

width on Edge infrastructure. Although Kubernetes is today the de-facto standard for container orchestration

on Cloud data centers, its orchestration and scheduling strategy is not suitable for the management of time

critical applications on Edge environments because it does not take into account current infrastructure state

during its scheduling decisions. In this work, we present Sophos, a framework that runs on top of the Kuber-

netes platform in order to implement an effective resource and network-aware microservices scheduling and

orchestration strategy. In particular, Sophos extends the Kubernetes control plane with a cluster monitor that

monitors the current state of the application execution environment, an application conﬁguration controller

that continuously tunes the application conﬁguration based on telemetry data and a custom scheduler that de-

termines the placement for each microservice based on the run time infrastructure and application states. An

evaluation of the proposed framework is presented by comparing it with the default Kubernetes orchestration

and scheduling strategy.

1 INTRODUCTION

Modern applications such as Internet of Things (IoT),

data analytics, video streaming, process control and

augmented reality services demand strict quality of

service (QoS) requirements, especially in terms of

response time and throughput. The orchestration of

such applications is a complex problem to deal with

(Oleghe, 2021; Calcaterra et al., 2020). Traditional

Cloud computing paradigm does not satisfy properly

the new computational demands of the applications,

characterized by the need for a nearby computation

paradigm. Edge computing has emerged as an in-

novative paradigm able to take advantage of this dis-

tributed and close to the end user processing capabil-

ities, thus complementing the Cloud computing ones

(Varghese et al., 2021). By combining the Cloud and

Edge computing paradigms both the high computa-

tional resources of the Cloud and the close to the end

user processing capabilities of the Edge are used for

the execution of distributed applications.

https://orcid.org/0000-0003-2114-3839

https://orcid.org/0000-0003-4653-0480

Kubernetes

is a widely adopted orchestration

platform that supports the deployment, scheduling

and management of containerized applications (Burns

et al., 2016). However, Kubernetes has not been

designed to work in geo-distributed and heteroge-

neous clusters such as the aforementioned Cloud-

Edge infrastructures (Kayal, 2020; Manaouil and Le-

bre, 2020). Cloud-Edge infrastructures are dynamic

environments, characterized by heterogeneous nodes,

in terms of available computational resources, and un-

stable network connectivity (Khan et al., 2019). In

this context, the default Kubernetes scheduling and

orchestration strategy presents some limitations be-

cause it does not consider the ever changing resource

availability on cluster nodes and the node-to-node net-

work latencies (Ahmad et al., 2021). Furthermore Ku-

bernetes does not implement a dynamic application

reconﬁguration and rescheduling mechanism able to

adapt the application deployment to the current in-

frastructure state and the load and distribution of end

user requests. This can lead to degraded applica-

tion performances and frequent violations on the QoS

https://kubernetes.io

Marchese, A. and Tomarchio, O.

Sophos: A Framework for Application Orchestration in the Cloud-to-Edge Continuum.

DOI: 10.5220/0011972600003488

In Proceedings of the 13th International Conference on Cloud Computing and Services Science (CLOSER 2023), pages 261-268

ISBN: 978-989-758-650-7; ISSN: 2184-5042

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

261

requirements of latency-sensitive applications (Bulej

et al., 2020; Sadri et al., 2021).

To deal with those limitations, in this work,

based on our previous preliminary works presented

in (Marchese and Tomarchio, 2022b; Marchese and

Tomarchio, 2022a) we propose Sophos, a framework

that runs on top of Kubernetes and extends its control

plane to adapt its usage on node clusters distributed in

the Cloud-to-Edge continuum. Sophos enhances Ku-

bernetes by implementing a dynamic application or-

chestration and scheduling strategy able to consider

the current infrastructure state when determining a

placement for each application microservice and to

continuously tune the application conﬁguration and

placement based on the ever changing infrastructure

and application states and also the current load and

distribution of end user requests.

The rest of the paper is organized as follows. In

Section 2 we provide some background information

about the Kubernetes platform and discuss in more

detail some of its limitations that motivate our work.

In Section 3 we present the Sophos framework and

provide some implementation details of its compo-

nents, while in Section 4 we provide results of our

prototype evaluation on a testbed environment. Sec-

tion 5 examines some related works and, ﬁnally, Sec-

tion 6 concludes the work.

2 BACKGROUND AND

MOTIVATION

Kubernetes is today the de-facto container orches-

tration platform for the execution of distributed

microservices-based applications (Gannon et al.,

2017) on node clusters. Kubernetes has been ini-

tially thought as a container orchestration platform for

Cloud-only environments.

Although new distributions for Edge environ-

ments have emerged like KubeEdge, K3s and Mi-

croK8s, Kubernetes is not yet ready to be fully

adopted in the Cloud-to-Edge continuum, due to some

limitations of its default orchestration and scheduling

strategy.

The ﬁrst limitation is related to the fact that the

Kubernetes scheduler does not consider the current

state of the infrastructure when taking its decisions.

Since the scheduler does not monitor the current CPU

and memory utilization on each node, the estimated

resource usage may not match its run time value. If re-

source usage on a node is underestimated, more Pods

end up being scheduled on that same node, causing an

increase in the shared resource interference between

Pods and consequently a decrease in overall applica-

tion performances. Furthermore, the current network

latencies between cluster nodes are not considered

when evaluating inter-Pod afﬁnities. This means that

although an inter-Pod afﬁnity rule is satisﬁed by plac-

ing the respective microservices on the same topol-

ogy domain, the two microservices are not guaranteed

to communicate with low network latencies. High

communication latencies between microservices lead

to high end-to-end application response times. Con-

sidering the run time cluster state and network con-

ditions during Pod scheduling decisions is critical in

dynamic environments like the Cloud-to-Edge contin-

uum, where node resource availability and network

latencies are unpredictable and highly variable fac-

tors.

The second limitation is related to the fact that,

although Kubernetes allows application developers to

specify the set of application conﬁguration parame-

ters, it does not offer a mechanism to automatically

adapt the application conﬁguration based on the cur-

rent state of the infrastructure and the application it-

self. All the application conﬁguration is delegated to

application developers, who need to predict ahead of

time how many resources are required by each mi-

croservice and what are the most involved microser-

vices communication channels, in order to determine

CPU and memory requirements and inter-Pod afﬁnity

weights respectively. However, this is a complex task,

considering that microservices resource requirements

and communication afﬁnities are dynamic parameters

that strongly depend on the run time load and distri-

bution of user requests. Deﬁning Pod resource re-

quirements and inter-Pod afﬁnities before the run time

phase can lead to inefﬁcient scheduling decisions and

then reduced application performances. Overestimat-

ing resource requirements for Pods reduces the prob-

ability that these are scheduled on constrained Edge

nodes near to end users, while underestimating re-

source requirements increase Pod density on cluster

nodes and then their interference. Errors in estimat-

ing inter-Pod afﬁnities can lead to situations where

microservices that communicate more are not placed

near to each other. Then automatically updating the

application conﬁguration at run time is a critical re-

quirement in order to adapt the application deploy-

ment based on the current state of the infrastructure

and user request patterns.

Finally, another important limitation is related to

the fact that Kubernetes does not implement schedul-

ing policies that consider the end user location for the

placement of microservices. This is a critical aspect

considering that users are typically geo-distributed

and the network distance between microservices, es-

pecially the frontend ones, and the end user can affect

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

262

the application response time.

3 SOPHOS FRAMEWORK

3.1 Overall Design

Considering the limitations described in Section 2, in

this work we present Sophos, a framework that ex-

tends the Kubernetes platform with a dynamic orches-

tration and scheduling strategy, in order to adapt its

usage to dynamic Cloud-to-Edge continuum environ-

ments. The main idea of the proposed approach is

that in this context the application orchestration and

scheduling task should consider the dynamic state of

the infrastructure where the application is executed

and also the run time application requirements. To

this aim, Sophos monitors the current state of the

infrastructure and continuously tunes the application

conﬁguration, in terms of microservices resource re-

quirements and inter-Pod afﬁnities, based on the run

time application state. Unlike the default Kubernetes

platform, in Sophos the conﬁguration of microser-

vices resource requirements and inter-Pod afﬁnities is

not anymore delegated to application developers, who

should make predictions for these parameters, but it

is a dynamic and automated task. Furthermore, the

application scheduling strategy is not anymore based

on static estimation of node resource availability and

network distances between them, but it considers the

current node resource usage and the node-to-node net-

work latencies. Finally, in Sophos the application

scheduling strategy considers also the end user po-

sition. This is a critical aspect to take into account

considering the geo-distribution of end users in the

Cloud-to-Edge continuum.

Figure 1 shows a general model of the Sophos

framework. The current infrastructure and applica-

tion states are monitored and all the telemetry data

are collected by a metrics server. For the infrastruc-

ture, node resource availability and node-to-node la-

tencies are monitored, while for the application, mi-

croservices CPU and memory usage and the trafﬁc

amount between them are monitored. Based on the

infrastructure telemetry data the cluster monitor com-

ponent determines a cluster graph with the set of

available resources on each cluster node and the net-

work latencies between them. The application conﬁg-

uration controller uses application telemetry data to

determine an application conﬁguration graph whose

nodes represent application microservices with their

resource requirements and the edges the communica-

tion afﬁnities between them each with a speciﬁc afﬁn-

ity weight. The cluster and application graphs are

then used by the application scheduler to determine

a placement for each application Pod. Further details

on the Sophos framework components are provided in

the following subsections.

3.2 Cluster Monitor

The cluster monitor component periodically deter-

mines the cluster graph with the available CPU and

memory resources on each cluster node and the node-

to-node network latencies. This component runs

as a Kubernetes operator and it is activated by a

Kubernetes custom resource, in particular the Clus-

ter custom resource. A Cluster resource contains a

spec property with two sub-properties: runPeriod and

nodeSelector. The runPeriod property determines the

interval between two consecutive executions of the

operator logic. The nodeSelector property represents

a ﬁlter that selects the list of nodes in the cluster that

should be monitored by the operator. During each ex-

ecution of the operator the list of Node resources that

satisfy the nodeSelector condition are fetched from

the Kubernetes API server. Then for each node n

the CPU and memory currently available on it, cpu

and mem

respectively, are determined. These values

are fetched by the operator from a Prometheus

met-

rics server, which in turn collects them from node ex-

porters executed on each cluster node. The cpu

and

mem

parameters are then assigned as values for the

labels available.cpu and available.memory of node n

Then for each pair of nodes n

and n

their net-

work cost nc

i, j

is determined. The nc

i, j

parameter is

an integer value in the range between 1 and 100 and it

is proportional to the network latency between nodes

and n

. Network latency metrics are fetched by the

operator from the Prometheus metrics server, which

in turn collects them from network probe agents exe-

cuted on each cluster node. These agents are conﬁg-

ured to periodically send ICMP trafﬁc to all the other

cluster nodes in order to measure the round trip time

value. For each node n

the operator assigns to it a set

of labels network.cost.n

, with values equal to those

of the corresponding nc

i, j

parameters. The cluster

graph with the updated CPU and memory available

resources and the network cost values is then submit-

ted to the Kubernetes API server.

3.3 Application Conﬁguration

Controller

The application conﬁguration controller periodically

determines the application conﬁguration graph with

https://prometheus.io/

Sophos: A Framework for Application Orchestration in the Cloud-to-Edge Continuum

263

Application

Configuration

Controller

Application

Scheduler

Application Configuration Graph

Cluster Monitor

Cluster Graph

Metrics Server

infrastructure telemetry

application telemetry

Kubernetes Cluster

Pod to schedule

Figure 1: Overall Sophos architecture.

the set of inter-Pod afﬁnity rules between the appli-

cation microservices. As in the case of the cluster

monitor, this component runs as a Kubernetes op-

erator and it is activated by an instance of the Ap-

plication Kubernetes custom resource. An Applica-

tion resource contains a spec property with three sub-

properties: runPeriod, name and namespace. The

runPeriod property determines the interval between

two consecutive executions of the operator logic. The

name and namespace properties are used to select the

set of Deployment resources that compose a speciﬁc

microservices-based application. The Deployments

selected by the Application custom resource are those

created in the namespace speciﬁed by the namespace

property of the custom resource and with a label app-

group whose value is equal to the value of the name

property in the custom resource.

During each execution of the operator, the list

of Deployment resources selected by the name and

namespace properties are fetched from the Kuber-

netes API server. Then for each Deployment D

its

CPU and memory requirements, cpu

and mem

re-

spectively, are determined. These values are equal

to the average CPU and memory consumption of all

the Pods managed by the Deployment D

and are

fetched by the operator from the Prometheus met-

rics server, that in turn collects them from CAd-

visor agents. These agents are executed on each

cluster node and monitor current CPU and mem-

ory usage for the Pods executed on that node. The

cpu

and mem

parameters are then assigned as val-

ues for the properties spec.resources.requests.cpu and

spec.resources.requests.memory of the Pod template

Then, the operator determines for each Deploy-

ment D

the set of inter-Pod afﬁnity weights a f f

i, j

with all the other Deployments D

of the application

and the set of inter-Pod afﬁnity weights pa f f

i, j

with

the set of Pods P

managed by the inputProxy Dae-

monSet Kubernetes resource. This DaemonSet de-

ploys on each cluster node n

a proxy Pod P

that in-

tercepts all the user requests arriving at that node and

forwards them to the ﬁrst microservice in the applica-

tion graph, like for example an API gateway microser-

vice. The a f f

i, j

weight is proportional to the trafﬁc

amount exchanged between microservices µ

and µ

while the pa f f

i, j

weight is proportional to the trafﬁc

amount exchanged between the microservice µ

and

the proxy Pod P

. Both a f f

i, j

and pa f f

i, j

parameters

are integer values normalized in the range between

1 and 100. Trafﬁc metrics are fetched by the opera-

tor from the Prometheus metrics server, which in turn

collects them from Envoy proxy containers injected

by the Istio

platform on each application Pod. By

injecting Envoy proxies also on the inputProxy Pods

the source of user requests and the distribution of user

trafﬁc among the different sources can be traced.

Each a f f

i, j

and pa f f

i, j

parameter of the Deploy-

ment D

is assigned by the operator as the weight of

a corresponding preferredDuringSchedulingIgnored-

DuringExecution inter-Pod afﬁnity rule in the Pod

template Pt

. The application conﬁguration graph

with the set of updated afﬁnity rules is then submit-

ted by the controller to the Kubernetes API server. If

at least one afﬁnity rule in the Pod template section of

a Deployment has changed with respect to the last it-

eration, a rolling update process is activated and new

Pods with the updated resource conﬁgurations are cre-

ated.

3.4 Application Scheduler

The proposed application scheduler is a custom

scheduler, based on the Kubernetes scheduling frame-

work, that extends the default Kubernetes scheduler

by implementing a set of plugins. In particular, a Re-

sourceAware plugin that extends the scoring phase of

the Kubernetes scheduler and a NetworkAware plu-

gin that extends both the sorting and scoring phases

https://istio.io

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

264

are proposed. The node scores calculated by the Re-

sourceAware and NetworkAware plugins are added to

the scores of the other scoring plugins of the default

Kubernetes scheduler.

The Score() function of The ResourceAware

scheduler plugin is invoked during the scoring phase

to assign a score to each cluster node when schedul-

ing a Pod p. The function evaluates the Pod p CPU

and memory resource requirements, cpu

and mem

as speciﬁed by the Pod spec.resources.requests.cpu

and spec.resources.requests.memory properties, and

for each node n

the currently available CPU and

memory resources, cpu

and mem

, as speciﬁed by

the node available.cpu and available.memory labels.

The score assigned to the node n

is given by Equation

(1) where α and β parameters are in the range between

0 and 1 and their sum is equal to 1:

score(p, n

) = α ×

cpu

−cpu

cpu

× 100 + β ×

mem

−mem

mem

× 100

(1)

The higher the difference between available re-

sources on node n

and those requested by Pod p, the

greater the score assigned to node n

. By excluding

the scoring results of the other scheduler plugins, Pod

p is placed on the node with the highest amount of

available resources. Unlike the default Kubernetes

scheduler that estimates resources availability on a

node based on the sum of the requested resources of

each Pod running on that node the ResourceAware

plugin considers current node resource usage based

on run time telemetry data. This allows to reduce

the shared resource interference between Pods result-

ing from incorrect node resource usage estimation and

then its impact on application performances.

The Score() function of the NetworkAware sched-

uler plugin is invoked during the scoring phase to as-

sign a score to each cluster node when scheduling a

Pod p. This function evaluates the inter-Pod afﬁnity

rules of the Pod p, where in our approach afﬁnity rules

are determined by the application conﬁguration con-

troller. Unlike the default Kubernetes scheduler, the

NetworkAware plugin does not evaluate the topolo-

gyKey parameter in the afﬁnity rules, but it takes into

account network cost labels of each cluster node de-

termined by the cluster monitor. Algorithm 1 shows

the details of the Score() function.

The algorithm starts by initializing the variable

cmc to zero. This variable represents the total cost of

communication between the Pod p and all the other

Pods (both microservices and proxy Pods) when the

Pod p is placed on node n. The algorithm iterates

through the list of cluster nodes cNodes. For each

cluster node cn the pcmc variable value is calculated.

This variable represents the cost of communication

between the Pod p and all the other Pods cn. pods cur-

rently running on node cmc when the Pod p is placed

on node n. For each Pod cnp the a f f

p,cnp

weight

of the corresponding afﬁnity rule (pa f f

p,cnp

in case

cnp is a proxy Pod) is multiplied by the network cost

n,cn

between node n and node cn and added to the

pcmc variable. The pcmc variable value is then added

to the cmc variable. The ﬁnal node score is repre-

sented by the opposite of the cmc variable value.

Algorithm 1: NetworkAware plugin Score function.

Input: p, n, cNodes

Output: score

1: cmc ← 0

2: for cn in cNodes do

3: pcmc ← 0

4: for cnp in cn. pods do

5: pcmc ← pcmc + nc

n,cn

× a f f

p,cnp

6: end for

7: cmc ← cmc + pcmc

8: end for

9: score ← −cmc

The Score() function assigns a score to each clus-

ter node n so that the Pod p is placed on the node, or in

a nearby node in terms of network latency, where the

Pods with which the Pod p has the greatest communi-

cation afﬁnity are executed. For each afﬁnity rule the

default Kubernetes scheduler assigns a score different

from zero only to the nodes that belong to a topology

domain matched by the topologyKey parameter of the

rule. The NetworkAware plugin instead scores all the

cluster nodes based on the current relative network

distance between them. This allows to implement a

more ﬁne-grained node scoring approach able to take

into account the ever changing network conditions in

the cluster instead of using node labels statically as-

signed before the run time phase.

The Less() function of the NetworkAware plugin

is invoked during the sorting phase in order to deter-

mine an ordering for the Pod scheduling queue. This

function takes as input two Pods resources and returns

true if the value of the index label on the ﬁrst Pod

is lesser than the value of the same label on the sec-

ond one, otherwise it returns false. This way Pods

with lower values of the index label are scheduled

ﬁrst. The index label is used to determine a topo-

logical sorting of the microservices graph and appli-

cation developers have to assign a value for this label

on the Pod templates of each application Deployment,

with lower values given to the frontend microservices.

By scheduling frontend microservices ﬁrst, communi-

cation afﬁnities between these microservices and the

proxy Pods are evaluated earlier during the scoring

phase, resulting in the application placement follow-

Sophos: A Framework for Application Orchestration in the Cloud-to-Edge Continuum

265

frontend

cartcatalogueuserpayment

order

shipping queue queue-master

user-dborder-db catalogue-db cart-db

Figure 2: Sock Shop application structure.

ing the end user position. If backend microservices

are instead scheduled before the frontend ones, only

internal communication afﬁnities between application

microservices are evaluated during the scoring phase

and this can lead to situations where the frontend mi-

croservices are placed far away the end user.

4 EVALUATION

The proposed solution has been validated using the

Sock Shop

application executed on a test bed en-

vironment. As shown in Figure 2 the application is

composed of different microservices, database servers

and a message broker. The frontend service repre-

sents the entry point for external user requests that

are served by backend microservices that interact be-

tween them by means of network communication.

The application can be thought of as composed of dif-

ferent microservice chains, each activated by requests

sent to a speciﬁc application API.

The test bed environment for the experiments con-

sists of a Rancher Kubernetes Engine (RKE) clus-

ter with one master node and four worker nodes,

These nodes are deployed as virtual machines on a

Proxmox

physical node and conﬁgured with 4GB

of RAM and 2 vCPU. In order to simulate a realis-

tic Cloud-to-Edge continuum environment with geo-

distributed nodes, network latencies between cluster

nodes are simulated by using the Linux trafﬁc con-

trol (tc

) utility. By using this utility network latency

delays are conﬁgured on virtual network cards of the

cluster nodes.

https://microservices-demo.github.io

https://www.proxmox.com

https://man7.org/linux/man-pages/man8/tc.8.html

We evaluate the end-to-end response time of the

Sock Shop application when HTTP requests are sent

to the frontend service. Requests to the application

are sent through the k6

load testing utility. Each

experiment consists of 5 trials, during which the k6

tool sends requests to the frontend service for 25 min-

utes. For each trial, statistics about the end-to-end

application response time are measured and are aver-

aged with those of the other trials of the same exper-

iment. The trial interval is partitioned into 5 minutes

sub-intervals. During each sub-interval the k6 tool

sends requests to a different worker node and in the

last sub-interval requests are equally distributed to all

the nodes. This way a realistic scenario with vari-

ability in the user requests distribution is simulated

by dynamically changing the source of trafﬁc at dif-

ferent time intervals. For each experiment we com-

pare both cases when the proposed scheduler and op-

erators of the Sophos framework are deployed on the

cluster and when only the default Kubernetes sched-

uler is present. The α and β parameters of the Re-

sourceAware plugin of the Sophos application sched-

uler are assigned the same value of 0.5. We consider

three different scenarios based on the network latency

between cluster nodes: 10ms, 50ms, 100ms.

Figure 3 illustrates the results of the three experi-

ments performed, each for a different scenario, show-

ing the 95th percentile of the application response

time as a function of the number of virtual users that

send requests to the application. In all the cases, the

Sophos framework performs better than the default

Kubernetes platform with average improvements of

28%, 43% and 54% in the three scenarios respec-

tively. Furthermore, the improvement is higher for

higher node-to-node network latencies. This can be

explained by the fact that for low node-to-node laten-

cies, network communication has no signiﬁcant im-

pact on the application response time. However, when

network latencies increase, network communication

becomes a bottleneck for application performances

and the lack of a network-aware scheduling strategy

causes an increase in the application response time.

5 RELATED WORK

In the literature, there is a variety of works that pro-

pose to extend the Kubernetes platform in order to

adapt its usage to Cloud-Edge environments.

A network-aware scheduler is proposed in (Santos

et al., 2019), implemented as an extension of the ﬁl-

tering phase of the default Kubernetes scheduler. The

https://k6.io

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

266

100

150

200

250

300

100

500

1,000

2,000

3,000

4,000

Virtual users

95th percentile response time (ms)

10ms network latency

Sophos Framework

Kubernetes platform

100

150

200

250

300

100

500

1,000

2,000

3,000

4,0004,000

Virtual users

95th percentile response time (ms)

50ms network latency

Sophos Framework

Kubernetes platform

100

150

200

250

300

100

500

1,000

1,500

2,000

3,000

4,000

Virtual users

95th percentile response time (ms)

100ms network latency

Sophos Framework

Kubernetes platform

Figure 3: Experiments results.

proposed approach makes use of round-trip time la-

bels, statically assigned to cluster nodes, in order to

minimize the network distance of a speciﬁc Pod with

respect to a target location speciﬁed on its conﬁgu-

ration ﬁle. One problem with this solution relates to

the fact that round-trip time labels are statically pre-

assigned to cluster nodes, not reﬂecting the run-time

variability of network latencies.

In (Caminero and Mu

noz-Mansilla, 2021) an ex-

tension to the Kubernetes default scheduler is pro-

posed that uses information about the status of the net-

work, like bandwidth and round trip time, to optimize

batch job scheduling decisions. The scheduler pre-

dicts whether an application can be executed within

its deadline and rejects applications if their deadlines

cannot be met. Although information about current

network conditions and historical job execution times

is used during scheduling decisions, communication

interactions between microservices are not considered

in this work.

The authors of (Cao and Sharma, 2021) propose to

leverage application-level telemetry information dur-

ing the lifetime of a distributed application to cre-

ate service communication graphs that represent the

internal communication patterns of all components.

The graph-based representations are then used to gen-

erate colocation policies of the application workload

in such a way that the cross-server internal communi-

cation is minimized. However, in this work schedul-

ing decisions are not inﬂuenced by the cluster network

state.

In (Pusztai et al., 2021) Pogonip, an edge-aware

scheduler for Kubernetes, designed for asynchronous

microservices is presented. Authors formulate the

placement problem as an Integer Linear Programming

optimization problem and deﬁne a heuristic to quickly

ﬁnd an approximate solution for real-world execu-

tion scenarios. The heuristic is implemented as a set

of Kubernetes scheduler plugins. Also in this work,

there is no Pod rescheduling if network conditions

change over time.

In (Wojciechowski et al., 2021) a Kubernetes

scheduler extender is proposed that uses applica-

tion trafﬁc historical information collected by Service

Mesh to ensure efﬁcient placement of Service Func-

tion Chains (SFCs). During each Pod scheduling,

nodes are scored by adding together trafﬁc amounts,

averaged over a time period, between the Pod’s mi-

croservice and its neighbors in the chain of services

executed on those nodes. As in our work, histori-

cal application trafﬁc is measured, but the proposed

scheduler does not take into account current node-

to-node latencies, neither communication patterns be-

tween microservices.

In (Fu et al., 2021) Nautilus is presented, a run-

time system that includes, among its modules, a

resource contention aware resource manager and a

communication-aware microservice mapper. While

the proposed solution migrates application Pod if

computational resources utilization is unbalanced

among nodes, there is no Pod rescheduling in the

Sophos: A Framework for Application Orchestration in the Cloud-to-Edge Continuum

267

case of degradation on the communication between

microservices.

6 CONCLUSIONS

In this work we proposed Sophos, a framework that

extends the Kubernetes platform in order to adapt its

usage to dynamic Cloud-to-Edge continuum environ-

ments. The idea is to add a layer on top of Kubernetes

to overcome the limitations of its mainly static appli-

cation scheduling and orchestration strategy. Orches-

trating applications in the Cloud-to-Edge continuum

requires a knowledge of the current state of the infras-

tructure and to continuously tune the conﬁguration

and the placement of the application microservices.

To this aim in Sophos a cluster monitor operator mon-

itors the network state and the resource availability on

cluster nodes, while an application conﬁguration op-

erator dynamically assigns inter-Pod afﬁnities and re-

source requirements on the application Pods based on

application telemetry data. Based on the current in-

frastructure state and the dynamic application conﬁg-

uration, a custom scheduler determines a placement

for application Pods.

As a future work we plan to improve the in-

frastructure and application monitoring modules with

more sophisticated techniques that allow to do predic-

tive analysis on the infrastructure and the application

state and to make proactive application reconﬁgura-

tion and rescheduling actions. To this aim time series

analysis and machine learning techniques will be ex-

plored in the future.

REFERENCES

Ahmad, I., AlFailakawi, M. G., AlMutawa, A., and Al-

salman, L. (2021). Container scheduling techniques:

A survey and assessment. Journal of King Saud Uni-

versity - Computer and Information Sciences.

Bulej, L., Bures, T., Filandr, A., Hnetynka, P., Hnetynkov

I., Pacovsky, J., Sandor, G., and Gerostathopoulos, I.

(2020). Managing latency in edge-cloud environment.

CoRR, abs/2011.11450.

Burns, B., Grant, B., Oppenheimer, D., Brewer, E., and

Wilkes, J. (2016). Borg, omega, and kubernetes:

Lessons learned from three container-management

systems over a decade. Queue, 14(1):70–93.

Calcaterra, D., Di Modica, G., and Tomarchio, O. (2020).

Cloud resource orchestration in the multi-cloud land-

scape: a systematic review of existing frameworks.

Journal of Cloud Computing, 9(49).

Caminero, A. C. and Mu

noz-Mansilla, R. (2021). Quality of

service provision in fog computing: Network-aware

scheduling of containers. Sensors, 21(12).

Cao, L. and Sharma, P. (2021). Co-locating container-

ized workload using service mesh telemetry. In

Proceedings of the 17th International Conference on

Emerging Networking EXperiments and Technologies,

CoNEXT ’21, page 168–174, New York, NY, USA.

Association for Computing Machinery.

Fu, K., Zhang, W., Chen, Q., Zeng, D., Peng, X., Zheng,

W., and Guo, M. (2021). Qos-aware and resource efﬁ-

cient microservice deployment in cloud-edge contin-

uum. In IEEE International Parallel and Distributed

Processing Symposium (IPDPS), pages 932–941.

Gannon, D., Barga, R., and Sundaresan, N. (2017). Cloud-

native applications. IEEE Cloud Computing, 4:16–21.

Kayal, P. (2020). Kubernetes in fog computing: Feasibil-

ity demonstration, limitations and improvement scope

: Invited paper. In 2020 IEEE 6th World Forum on

Internet of Things (WF-IoT), pages 1–6.

Khan, W. Z., Ahmed, E., Hakak, S., Yaqoob, I., and Ahmed,

A. (2019). Edge computing: A survey. Future Gener-

ation Computer Systems, 97:219–235.

Manaouil, K. and Lebre, A. (2020). Kubernetes and the

Edge? Research Report RR-9370, Inria Rennes - Bre-

tagne Atlantique.

Marchese, A. and Tomarchio, O. (2022a). Extending the ku-

bernetes platform with network-aware scheduling ca-

pabilities. In Troya, J., Medjahed, B., Piattini, M.,

Yao, L., Fern

andez, P., and Ruiz-Cort

es, A., editors,

Service-Oriented Computing, pages 465–480, Cham.

Springer Nature Switzerland.

Marchese, A. and Tomarchio, O. (2022b). Network-aware

container placement in cloud-edge kubernetes clus-

ters. In 2022 22nd IEEE International Symposium

on Cluster, Cloud and Internet Computing (CCGrid),

pages 859–865, Taormina, Italy.

Oleghe, O. (2021). Container placement and migration

in edge computing: Concept and scheduling models.

IEEE Access, 9:68028–68043.

Pusztai, T., Rossi, F., and Dustdar, S. (2021). Pogonip:

Scheduling asynchronous applications on the edge. In

IEEE 14th International Conference on Cloud Com-

puting (CLOUD), pages 660–670.

Sadri, A. A., Rahmani, A. M., Saberikamarposhti, M., and

Hosseinzadeh, M. (2021). Fog data management: A

vision, challenges, and future directions. Journal of

Network and Computer Applications, 174:102882.

Santos, J., Wauters, T., Volckaert, B., and De Turck, F.

(2019). Towards network-aware resource provision-

ing in kubernetes for fog computing applications. In

IEEE Conference on Network Softwarization (Net-

Soft), pages 351–359.

Varghese, B., de Lara, E., Ding, A., Hong, C., Bonomi, F.,

Dustdar, S., Harvey, P., Hewkin, P., Shi, W., Thiele,

M., and Willis, P. (2021). Revisiting the arguments for

edge computing research. IEEE Internet Computing,

25(05):36–42.

Wojciechowski, L., Opasiak, K., Latusek, J., Wereski, M.,

Morales, V., Kim, T., and Hong, M. (2021). Netmarks:

Network metrics-aware kubernetes scheduler powered

by service mesh. In IEEE INFOCOM 2021 - IEEE

Conference on Computer Communications, pages 1–

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

268
