AI Marketplace: Serving Environment for AI Solutions Using

Kubernetes

Marc A. Riedlinger

, Ruslan Bernijazov

and Fabian Hanke

Fraunhofer IOSB-INA, Fraunhofer Institute of Optronics, System Technologies and Image Exploitation, Lemgo, Germany

Fraunhofer IEM, Fraunhofer Institute for Mechatronic Systems Design, Paderborn, Germany

Keywords:

Kubernetes, Service Mesh, Artiﬁcial Intelligence, Machine Learning, Cloud-Native.

Abstract:

Recent advances in the ﬁeld of artiﬁcial intelligence (AI) provide numerous potentials for industrial compa-

nies. However, the adoption of AI in practice is still left behind. One of the main reasons is a lack of knowledge

about possible AI application areas by industry experts. The AI Marketplace addresses this problem by pro-

viding a platform for the cooperation between industry experts and AI developers. An essential function of

this platform is a serving environment that allows AI developers to present their solution to industry experts.

The solutions are packaged in a uniform way and made accessible to all platform members via the serving

environment. In this paper, we present the conceptual design of this environment, its implementation using

Amazon Web Services, and illustrate its application on two exemplary use cases.

1 INTRODUCTION

Recent developments in the ﬁeld of Machine Learn-

ing (ML) and related areas accelerate the adoption of

ML in business as well as consumer-facing solutions.

Established software companies start integrating ML

into existing solutions and new start-ups that focus on

speciﬁc artiﬁcial intelligence (AI) application areas

are being formed. Especially in knowledge-intensive

application areas, like product creation, utilization of

ML promises great potentials in terms of efﬁciency

gains and quality improvements (Dumitrescu et al.,

2021), (Schr

ader et al., 2022). The term product cre-

ation refers to the development process of technical

systems and consists of the four main cycles, namely,

strategic product planning, product development, ser-

vice development, and production system develop-

ment. Figure 1 visualizes the main steps of this pro-

cess based on (Gausemeier et al., 2019).

As of yet, the practical application of AI in prod-

uct creation is still a major hurdle for the industry

(Bernijazov et al., 2021). A key challenge for the

adoption of ML solutions by industry companies is to

build a common understanding of the capabilities of

ML-based software solutions. Industry practitioners

often lack the required ML expertise to assess how

their processes can be supported by ML-based sys-

tems, whereas ML experts lack the required domain

knowledge to identify suitable use cases for ML in

product creation.

The project AI Marketplace

(AIM) addresses

these challenges by building a platform that facilitates

the collaboration between industrial companies with

AI experts and AI solution providers. One of the en-

visioned functionalities of the platform is a serving

environment that allows AI providers to demonstrate

their solutions to possible industrial customers by up-

loading a demo version to the platform. That way,

industrial customers can experience existing AI so-

lutions via a web-based user interface (UI) and get

in touch with the solution provider, if their business

might beneﬁt from a similar solution.

The development of this serving environment re-

quires a standard format for the provisioning of AI

solutions together with an infrastructure for the de-

ployment and operation of the solutions. The stan-

dard must assure that all uploaded demonstrators can

be handled in a uniform way by the platform but also

be applicable to the majority of existing AI solutions

to minimize the additional development overhead for

solution providers. The infrastructure must be able to

operate the uploaded demonstrators, support the addi-

tion and removal of them, and ensure that they do not

interfere with each other. Moreover, the amount of

available demo apps is not deﬁned a priori and is ex-

pected to grow as AI is being adopted more and more

ki-marktplatz.com

Riedlinger, M., Bernijazov, R. and Hanke, F.

AI Marketplace: Serving Environment for AI Solutions Using Kubernetes.

DOI: 10.5220/0011980800003488

In Proceedings of the 13th International Conference on Cloud Computing and Services Science (CLOSER 2023), pages 269-276

ISBN: 978-989-758-650-7; ISSN: 2184-5042

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

269

From initial

business

ideas...

...to start

of series

production

Strategic Product

Planning

Product

Development

Service

Development

Production System

Development

Cross-Sectional Processes

Figure 1: Illustration of the 4-cycle model of product creation. Adapted from (Gausemeier et al., 2019).

by industry. Therefore, the platform must be able to

scale and handle increasing workloads in the future.

The present work explores the question of how

such a platform could look like from a technologi-

cal point of view. As a result, this paper contributes

a production-ready serving environment for web ap-

plications based on Kubernetes (Google, 2014) along

with a standardized packaging approach to facilitate

the deployment of apps onto the provided platform.

The remainder of the paper is organized as fol-

lows. First, the related work is analyzed in Section 2.

Next, the requirements towards the platform and the

hosted AI apps are deﬁned in Section 3. Thereafter,

an implementation of the serving environment is out-

lined using a managed Kubernetes instance of Ama-

zon Web Services (AWS) and validated using two dif-

ferent use cases of varying complexity regarding host-

ing in Section 4. Finally, the topic is concluded with

an outlook about future work in Section 5.

2 RELATED WORK

In recent years, the adoption of AI solutions in small

and medium-sized enterprises (SMEs) has been ob-

structed by the lack of expertise in developing and

deploying ML models (Schauf and Neuburger, 2021),

(Salum and Abd Rozan, 2016). As companies in-

creasingly turn towards AI applications to support

their business processes, the pressure to keep up with

competition and meet customer demand has led to an

increase in complexity and shorter production times

(Kreuzberger et al., 2022), (Schauf and Neuburger,

2021), (Salum and Abd Rozan, 2016).

This section explores the current state of ML

in SMEs and the challenges they face, as well as

the potential solutions offered by machine learning

operations (MLOps) to overcome these challenges

(Kreuzberger et al., 2022). In contrast to usual

software development processes, the development of

ML solutions entails additional challenges. As high-

lighted by SCULLEY ET AL., there are speciﬁc ML-

speciﬁc risk factors that must be taken into account

in system design, such as boundary erosion, entangle-

ment, hidden feedback loops, undeclared consumers,

and data dependencies. Additionally, the software en-

gineering framework of technical debt applies to ML

systems as well (Sculley et al., 2015). ZHOU ET AL.

also noted that the deployment of ML solutions can

be challenging, especially when it comes to keeping

the development phase short and offering the product

to customers quickly (Zhou et al., 2020).

DevOps has seen increasing attention in recent

years as organizations aim to bridge the gap be-

tween software development (Dev) and operations

(Ops). MLOps is the consistent further development

of DevOps to address the ML-speciﬁc challenges that

DevOps does not meet. MLOps provides best prac-

tices, concepts, and the development culture needed

to effectively manage the end-to-end life cycle of ML

applications (Symeonidis et al., 2022). The emer-

gence of MLOps from the DevOps approach has high-

lighted the unique challenges posed by ML, such as

concerns around data complexity and model devel-

opment and training. As MLOps offers a solution to

these challenges, this led to the integration of MLOps

processes into development (M

akinen et al., 2021).

ZHOU ET AL. present a functional ML platform built

with DevOps capabilities using existing continuous

integration (CI) and continuous delivery (CD) tools

together with Kubeﬂow (Zhou et al., 2020).

In recent years, there has been a shift in the ap-

proach to deploying applications, with the current

state of the art being the use of Docker (Merkel,

2014) containers along with a microservice archi-

tecture (Dragoni et al., 2016). On the one hand,

Docker provides a Platform-as-a-Service (PaaS) so-

lution via containers at the operating system level.

On the other hand, the microservice architecture aims

to combine small, self-contained units of system ele-

ments. When both concepts are combined, microser-

vices are deployed as individual containers in a net-

work, increasing the modularity of the system but also

the complexity of the deployment process (Richard-

son, 2018). KARABEY AKSAKALLI ET AL. identi-

ﬁed several challenges related to the deployment of

microservices, such as architectural complexity and

fault tolerance. Besides, further challenges were iden-

tiﬁed related to the communication concerns of a mi-

croservice platform, e.g. service discovery, and load

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

270

balancing (Karabey Aksakalli et al., 2021).

Moreover, companies expressing growing inter-

est in cloud computing have identiﬁed its potential

beneﬁts, as well as the challenges in deploying soft-

ware on Infrastructure-as-a-Service (IaaS) platforms

(Karabey Aksakalli et al., 2021). Cloud comput-

ing offers many beneﬁts, such as on-demand use and

the ability to scale infrastructure according to needs.

However, deploying software on IaaS platforms can

be challenging and requires expertise in operations.

SMEs often lack the personnel to put these services

into operation (Schauf and Neuburger, 2021), (Salum

and Abd Rozan, 2016).

In addition to traditional DevOps and MLOps

tools, several specialized tools have been developed

speciﬁcally for managing ML models. Container or-

chestration tools are also playing a key role in de-

ploying scalable solutions. These technologies, in

combination with cloud computing environments, en-

able the full potential of microservices to be lever-

aged. Hereby, Kubernetes is one of the most widely

used open-source container orchestration platforms.

Developed by Google in 2014 and now operated by

the Cloud Native Computing Foundation (CNCF),

Kubernetes is designed to automate the deployment,

scaling, and management of containerized applica-

tions (Google, 2014). It is often used as the founda-

tion for building MLOps platforms and workﬂows. In

the following, multiple of these frameworks for serv-

ing AI solutions are presented.

KServe originated from Kubeﬂow and is now

a stand-alone Kubernetes-native model serving plat-

form. It allows for the deployment and management

of ML models and is designed to work seamlessly

with Kubernetes and other cloud-based technologies

to provide a complete MLOps solution (Kubeﬂow

Serving Working Group, 2021).

Seldon Core is another popular platform for de-

ploying and managing ML models on Kubernetes. It

provides a set of tools and frameworks for building,

deploying, and monitoring ML models in production

(Seldon Technologies Ltd., 2018).

BentoML is an open-source platform for deploy-

ing ML models to various serving platforms, in-

cluding Kubernetes. It provides a consistent inter-

face for packaging and deploying models, as well as

tools for monitoring and managing deployed models.

BentoML also facilitates the integration with other

MLOps tools and workﬂows (BentoML, 2019).

Overall, these tools provide a variety of options

for deploying and managing ML models on Kuber-

netes and other cloud-based platforms. They help to

automate many of the complex tasks associated with

MLOps and provide a more efﬁcient and effective

way to manage ML models in production.

However, in contrast to the described frameworks

for providing AI solutions, the solution presented in

this paper aims at providing a generalized approach.

The presented frameworks, such as KServe, focus

on the deployment of ML models, but, generally-

speaking, an AI solution does not necessarily consist

of an ML model alone. With the generic approach

presented in this work, it is possible to deploy various

software components necessary for web-based AI so-

lutions. For instance, this could be a web-based front

end that is linked to an AI algorithm.

3 CONCEPT

The motivation for the present work is to design a

platform for the AIM that enables the hosting of an

undeﬁned number of AI solutions. Hereby, these so-

lutions are created by AI authors and serve as demon-

strators that are publicly hosted on the platform.

On a conceptual level, the requirements towards

such a serving environment are addressed in the next

sub-section which is followed by the packaging ap-

proach that uniﬁes hosting of AI applications.

3.1 Requirements and Implications

An AI solution can be everything from a mere ML

model with a web interface to a full-ﬂedged web ap-

plication. Moreover, the serving environment shall

host an indeﬁnite number of these solutions. There-

fore, the environment has to be hosted using a cloud-

provider offering this degree of elasticity. This way,

computing resources can automatically be added on-

demand which prevents manual scaling of the cluster.

As a result of being a cloud-deployment, the serv-

ing environment is designed in accordance with the

cloud-native principles as postulated by the CNCF

(CNCF, 2018b), such as observability, security and

loose coupling. Furthermore, to design a cloud-

platform with inherent interoperability, only open-

source components of the CNCF cloud-native land-

scape (CNCF, 2018a) are chosen. Additionally, a ser-

vice mesh using the open-source container orchestra-

tion system Kubernetes is considered to achieve an

observable and secure platform. Hereby, AI apps are

deployed as isolated microservices which results in a

decoupled architecture.

Besides, by choosing Kubernetes as orchestration

system, a certain level of independence from cloud-

providers is baked into the platform as additional ben-

eﬁt. Moreover, the whole infrastructure of the serving

AI Marketplace: Serving Environment for AI Solutions Using Kubernetes

271

environment is laid out in code which facilitates its

automatic deployment.

Furthermore, the trafﬁc between the user of an AI

service and the service itself has to be encrypted us-

ing transport layer security (TLS) to avoid potentially

sensitive data from being transmitted in plain text.

In addition to that, the communication between mi-

croservices inside the Kubernetes cluster shall also be

encrypted to maximize security.

3.2 Standardized Solution Packaging

The AI solutions must follow a standardized pack-

aging in order to be deployed on the serving envi-

ronment. Hereby, the requirements demanded by the

packaging process are designed to be only as restric-

tive as necessary to provide maximum freedom to the

AI developer. On the other hand, certain restrictions

have to be employed to achieve a uniﬁed deployment.

Since the AI applications are hosted on the cloud,

resources are expensive. Therefore, it is recom-

mended that apps should be as conservative as pos-

sible in terms of resource consumption. Furthermore,

efﬁcient apps have a minimal latency on startup and

teardown which improves the scaling process and, in

the end, beneﬁts the user experience.

Figure 2: Solution Packaging.

Figure 2 illustrates the standard format of how an

AI app has to be packaged so that it can be deployed

on the serving environment. First, the application and

its logic or AI model can be created with any language

and AI framework as long as a representational state

transfer (REST) application programming interface

(API) can be integrated. The REST API is a widely

used and platform-agnostic standard in web develop-

ment and therefore well suited as interface implemen-

tation. The API denotes the interface to talk to the AI

model beneath and provides all relevant functionali-

ties to work with it. Second, the AI application along

with the API are wrapped by a Docker image. This

image is responsible for storing all necessary depen-

dencies to run the solution once a container is instanti-

ated. Thereby, the Docker container must expose port

8080 that is used to consume external trafﬁc which is

then routed to the application.

Another requirement to the AI application is that

it has to host a web page under its root path. This way,

a user accessing the app via the browser sees a visual

representation of what’s included in the solution. For

example, a web page displaying the OpenAPI speci-

ﬁcation (OpenAPI Initiative, 2011) of the REST API

along with the functionality to test each given end-

point is well-suited under the root path (see Fig. 6).

Lastly, the AI solution has to be stateless. There-

fore, no data should be aggregated within the applica-

tion. The rationale behind this restriction is two-fold.

On the one side, storage, i.e. a database, does not

scale similarly to other services since only one sin-

gle source of truth is allowed. Different concepts are

needed to accomplish scaling of storage in contrast to

scaling stateless apps. On the other side, the Docker

container could grow indeﬁnitely which complicates

the scheduling on resource-bounded cloud resources.

This issue could be solved by providing a separate

storage service which manages the state of stateful AI

apps and scales on its own. However, in this paper,

the focus is on stateless applications and incorporat-

ing stateful apps is left for future work.

4 IMPLEMENTATION

The following section demonstrates the implementa-

tion of the serving environment using a managed Ku-

bernetes instance of AWS. First, the architectural de-

sign of the environment is provided. Next, the de-

ployment of two different use cases are discussed in

the follow-up sub-section.

4.1 Serving Environment Architecture

The serving environment is designed as microservice

architecture that is deployed onto a Kubernetes clus-

ter. Consequently, each AI application is deployed as

separate service which allows automated scaling of

these services only where it is needed. Hereby, Ku-

bernetes provides the heavy lifting of managing the

scaling of the individual services and the cluster as a

whole when further compute resources are needed.

A high-level overview of the architecture of the

serving environment including its main components

is given in Fig. 3. The Kubernetes cluster is di-

vided into two different node groups General and So-

lutions. Thereby, each node group is associated to

one instance type that deﬁnes the compute and storage

capabilities, processor type and operating system of

the underlying virtual machine (VM). Within a node

group, only nodes of the associated instance type can

be created. Kubernetes automates the scaling of node

groups whenever compute resources have to be added

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

272

Figure 3: Serving Environment Architecture.

or removed. The clear distinction between the two

node groups is achieved with Kubernetes taints, toler-

ations and afﬁnities. These settings can be attached to

node groups and pods to avoid that pods are scheduled

in the wrong node group.

Node group General hosts general Kubernetes

pods (visualized as rectangles) that provide core func-

tionality, such as trafﬁc routing, or extend the features

of the cluster, such as TLS, auto-scaling, and service

mesh capabilities. On the other hand, node group

Solutions only hosts AI pods and therefore needs a

more powerful VM type than General. If further node

groups are required to match different resource re-

quirements, they can be added to the cluster alongside

Solutions. By providing different node groups, AI au-

thors can select the group that best suits the needs

of their AI solutions. Additionally, only related AI

pods are hosted per node to avoid having underuti-

lized nodes after AI solutions are shut down.

The entry point of external trafﬁc, e.g. a browser

or a script, into the cluster is denoted by the Ingress

resource sitting at the edge of the Kubernetes cluster

and deﬁning the mapping between routes and corre-

sponding services. Each ingress resource is associ-

ated with an Ingress Controller that actually does the

trafﬁc routing deﬁned in the ingress resource. Hereby,

certain limiters such as rate limits or request size lim-

its can be employed in the controller to protect the

internal AI services from becoming exhausted.

The Cert Manager (Jetstack, 2017) pod is respon-

sible for generating a free certiﬁcate issued by Let’s

Encrypt and automatically keeping the certiﬁcate up-

to-date. For the serving environment, a wildcard cer-

tiﬁcate is utilized which allows TLS communication

not only for the main domain associated to the envi-

ronment, but also for sub-domains which are created

for each AI solution. As a result, the communication

between the calling party and the Ingress Controller

is encrypted and secure. Due to the usage of a wild-

card certiﬁcate, Cert Manager needs access to the do-

main name system (DNS) provider where the domain

is registered so the DNS challenge can be conducted.

This is needed by Let’s Encrypt to verify that the do-

main belongs to the party requesting the certiﬁcate.

The Cluster Autoscaler enables automatic scal-

ing of the node groups when there are not enough

compute resources for incoming workloads such as

freshly scheduled pods. Additionally, the Cluster

Autoscaler also terminates underutilized pods to im-

prove costs.

Linkerd (Buoyant, 2016) is a light-weight and fast

service mesh implementation. It improves the observ-

ability of a cluster by making the trafﬁc between pods

visible. This is achieved by injecting sidecar prox-

ies into the respective pods. This meshing of pods is

exemplarily visualized for the ingress pod and an AI

pod in Fig. 4. Hereby, both containers do not directly

communicate with each other anymore, but via proxy

containers that gather trafﬁc metrics alongside. By

using Linkerd, these performance metrics are stored

to the Prometheus database (SoundCloud, 2012) and

can also be visualized in the Linkerd dashboard.

Figure 4: Meshing of Pods according to Linkerd.

Furthermore, since TLS is terminated at the

AI Marketplace: Serving Environment for AI Solutions Using Kubernetes

273

Ingress Controller, the internal communication inside

the cluster takes place unsecured via the hypertext

transfer protocol. To remedy this security concern,

Linkerd provides mutual TLS for cluster-internal

communication. Thereby, the communication be-

tween two proxies (see Fig. 4) is bi-directionally en-

crypted adding an extra layer of security to the cluster

in case a node becomes compromised.

Kubernetes Event-driven Autoscaling (KEDA)

(Microsoft and Red Hat, 2019) extends the condi-

tions upon which auto-scaling of pods is triggered.

By default, the Kubernetes Horizontal Pod Autoscaler

(HPA) can only scale pods based on their memory or

CPU consumption. As a result, trafﬁc-based scaling is

not possible without an extension like KEDA. Further-

more, HPA cannot scale down to zero pods. There-

fore, at least one replica of a pod must always remain

active even though it might not be needed. KEDA pro-

vides scaling down to zero and also scaling up from

zero maximizing cost efﬁciency.

Trafﬁc-based scaling is realized by having the

Ingress Controller store request-related events to

Prometheus. Subsequently, each request to the sub-

domains, where the AI solutions are hosted, are stored

along with a timestamp. From there, KEDA can query

those metrics and decide about scaling. For example,

each AI pod that has not received any requests in the

past 30 minutes is removed. Since only related AI

pods are hosted per node, all pods are terminated and

consequently, the node is removed by the Cluster Au-

toscaler as well afterwards which optimizes costs. On

the other hand, KEDA detects requests regarding ter-

minated pods and re-schedules them accordingly.

The AI applications are hosted in the node group

Solutions. However, before a new AI app can be

hosted, it needs to be packaged according to the stan-

dardized solution packaging presented in Section 3.2.

After packaging, the AI app has to be uploaded to a

Container Registry the Kubernetes cluster has access

to. Next, the new AI service has to be added to the

cluster via a Kubernetes manifest. Finally, the Ingress

resource needs to be extended and re-applied to the

cluster to include the routing to the new AI service.

4.2 Use Cases

This section demonstrates two exemplary engineer-

ing apps of varying complexity that are hosted on the

serving environment presented in the last section.

On the one hand, this demonstrates the capabil-

ities of the serving environment but also serves as

guidance about how an actual AI application has to

be designed to be hosted on the platform.

4.2.1 Natural Language Processing

The ﬁrst use case addresses the hosting of a natural

language processing (NLP) model. Such models are,

for example, often employed to analyze requirements

in the scope of strategic product planning and product

development. Possible applications are the classiﬁca-

tion of existing requirements or the search for similar

requirements from prior projects. In our use case, the

Universal Sentence Encoder (USE) (Cer et al., 2018)

is utilized to compute embeddings of text. These em-

beddings can then, in a follow-up step, be used to

compute the similarity between two pieces of text.

Figure 5: USE Deployment.

Figure 5 illustrates how the USE web application

is designed in order to be hosted on the serving en-

vironment. For that, the TensorFlow (Abadi et al.,

2015) model of the USE is wrapped in a Python-based

REST API using the FastAPI library (Ram

ırez et al.,

2018). This API exposes two different endpoints, one

that expects a mere string input and another for taking

care of text ﬁles. In summary, these endpoints take the

input from the request, compute the embeddings and

return them to the caller.

Following the standardized packaging established

in Section 3.2, the whole application is packaged as

Docker image along with all necessary dependen-

cies for execution. Afterwards, the resulting im-

age is pushed to an AWS container registry acces-

sible by the serving environment. Once the image

is downloaded to the environment and executed, the

REST API is made available on a Uvicorn web server

Figure 6: USE Swagger UI.

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

274

(Christie et al., 2017) in the container that is hosted

within the scheduled Kubernetes pod.

FastAPI automatically generates a Swagger UI

from the speciﬁed REST API. This UI of the USE

web application is depicted in Fig. 6. Moreover,

the given endpoints can also directly be tested in the

browser using that web page facilitating quick testing.

Users can integrate this service in their apps by

calling the API functions and using the embeddings

e.g. for a similarity analysis. Also, this hides the com-

plexity of creating such a service from the user.

4.2.2 Intelligent Part Comparison

The intelligent part comparer is a tool with which

CAD models can be evaluated with respect to their

similarity. The evaluation is mainly based on the ge-

ometry of the models. This AI-based application in-

tends to relieve the challenges coming with the man-

agement of identical parts which is especially a con-

cern in companies that work in product development.

The web application consists of three compo-

nents, a JavaScript web UI the user can interact with

(see Fig. 8), a Python-based Flask server (Grinberg,

2018) that only exposes endpoints of the part com-

parer meant to be publicly available, and an ASP.NET

server (Microsoft, 2002) which provides the function-

ality to conduct the comparison of CAD models. Be-

sides, the ASP.NET server holds a static collection of

CAD models used to perform the comparison against.

Figure 7 illustrates how the components of the part

comparer are mapped to Kubernetes in order to be

hosted on the serving environment. Thereby, all ser-

vices are deployed on individual Kubernetes pods to

allow them to be scaled separately. Furthermore, each

service follows the standardized packaging presented

in Section 3.2 to facilitate the deployment and resides

as Docker image in an AWS container registry acces-

sible by the serving environment.

Figure 8: Intelligent Part Comparer UI.

Once a user opens the web link of the part com-

parer in the browser, it will be redirected to the web

UI service as depicted in Fig. 8. Then, the web page

is downloaded to the browser of the user and rendered

afterwards. Thereafter, the user can interact with the

web page by uploading a CAD ﬁle and pressing the

Compute Similarity button to receive a list of similar

CAD models. In the background, the web UI calls

functions exposed by the Flask server’s public REST

API. Finally, the Flask server calls the private compar-

ison function of the cluster-internal ASP.NET server

and returns the results back to the user’s browser.

5 CONCLUSION

Bringing AI applications into production is a chal-

lenging and costly task. In this paper, a serving envi-

ronment is outlined that can be used to host different

AI applications in a uniform way. It allows AI devel-

opers delivering their AI apps in a cost-effective way

and thereby increases the overall accessibility of AI.

The serving environment is implemented by utilizing

a managed Kubernetes instance of AWS and tested

with multiple AI applications. In future work, further

experiments are planned to gain a better understand-

Figure 7: Intelligent Part Comparer Deployment.

AI Marketplace: Serving Environment for AI Solutions Using Kubernetes

275

ing of the limitations of the approach (e.g. with re-

spect to scalability). Moreover, various functional im-

provements are to be done, like the integration of Ku-

bernetes StatefulSets to provide storage services and

the integration of role-based access control (RBAC)

for the applications. RBAC can be realized, for ex-

ample, using the identity and access management so-

lution Keycloak (Red Hat, 2014).

ACKNOWLEDGMENT

This work was supported by the research and devel-

opment project ”AI Marketplace” which is funded by

the Federal Ministry for Economic Affairs and Cli-

mate Action in Germany.

REFERENCES

Abadi, M., Agarwal, A., Barham, P., Brevdo, E., et al.

(2015). TensorFlow: Large-scale machine learning on

heterogeneous systems.

BentoML (2019). BentoML. https://www.bentoml.com

(accessed 9 December 2022).

Bernijazov, R., Dicks, A., Dumitrescu, R., Foullois, M.,

Hanselle, J. M., H

ullermeier, E., Karakaya, G.,

odding, P., Lohweg, V., Malatyali, M., and et al.

(2021). A meta-review on artiﬁcial intelligence in

product creation. In Proceedings of the 30th Inter-

national Joint Conference on Artiﬁcial Intelligence.

Buoyant (2016). Linkerd. https://linkerd.io (accessed 28

November 2022).

Cer, D., Yang, Y., Kong, S.-y., Hua, N., et al. (2018). Uni-

versal sentence encoder.

Christie, T. et al. (2017). Uvicorn. https://www.uvicorn.org

(accessed 28 November 2022).

CNCF (2018a). Cloud Native Landscape. https://landscape.

cncf.io (accessed 28 November 2022).

CNCF (2018b). Trail Map. https://github.com/cncf/trail

map (accessed 28 November 2022).

Dragoni, N., Giallorenzo, S., Lafuente, A. L., Mazzara, M.,

Montesi, F., Mustaﬁn, R., and Saﬁna, L. (2016). Mi-

croservices: yesterday, today, and tomorrow.

Dumitrescu, R., Riedel, O., Gausemeier, J., Albers, A., and

(Eds.), R. (2021). Engineering in germany – status

quo in business and science.

Gausemeier, J., Dumitrescu, R., Echterfeld, J., Pf

ander, T.,

Steffen, D., and Thielemann, F. (2019). Innovationen

ur die M

arkte von morgen: Strategische Planung von

Produkten, Dienstleistungen und Gesch

aftsmodellen.

Hanser, M

unchen.

Google (2014). Kubernetes. https://kubernetes.io (accessed

28 November 2022).

Grinberg, M. (2018). Flask Web Development: Develop-

ing Web Applications with Python. O’Reilly Me-

dia, Inc.

Jetstack (2017). cert-manager. https://cert-manager.io (ac-

cessed 28 November 2022).

Karabey Aksakalli, I., C¸ elik, T., Can, A., and Tekinerdogan,

B. (2021). Deployment and communication patterns

in microservice architectures: A systematic literature

review. Journal of Systems and Software, 180.

Kreuzberger, D., K

uhl, N., and Hirschl, S. (2022). Ma-

chine learning operations (mlops): Overview, deﬁni-

tion, and architecture.

Kubeﬂow Serving Working Group (2021). KServe.

https://kserve.github.io/website (accessed 9 Decem-

ber 2022).

akinen, S., Skogstr

om, H., Laaksonen, E., and Mikkonen,

T. (2021). Who needs mlops: What data scientists

seek to accomplish and how can mlops help?

Merkel, D. (2014). Docker: lightweight linux containers for

consistent development and deployment. Linux Jour-

nal.

Microsoft (2002). ASP.NET. https://dotnet.microsoft.com/

en-us/apps/aspnet (accessed 9 January 2023).

Microsoft and Red Hat (2019). KEDA. https://keda.sh (ac-

cessed 28 November 2022).

OpenAPI Initiative (2011). OpenAPI. https://www.open

apis.org (accessed 28 November 2022).

Ram

ırez, S. et al. (2018). FastAPI. https://fastapi.tiangolo.

com (accessed 28 November 2022).

Red Hat (2014). Keycloak. https://www.keycloak.org (ac-

cessed 3 March 2023).

Richardson, C. (2018). Microservices Patterns: With exam-

ples in Java. Manning.

Salum, K. and Abd Rozan, M. Z. (2016). Exploring the

challenge impacted smes to adopt cloud erp. Indian

Journal of Science and Technology, 9.

Schauf, T. and Neuburger, R. (2021). Supplementarische

Informationen zum DiDaT Weißbuch, chapter 3.4

Cloudabh

angigkeit von KMU. Nomos.

Schr

ader, E., Bernijazov, R., Foullois, M., Hillebrand, M.,

Kaiser, L., and Dumitrescu, R. (2022). Examples

of ai-based assistance systems in context of model-

based systems engineering. In 2022 IEEE Interna-

tional Symposium on Systems Engineering (ISSE).

Sculley, D., Holt, G., Golovin, D., Davydov, E., Phillips, T.,

Ebner, D., Chaudhary, V., Young, M., and Dennison,

D. (2015). Hidden technical debt in machine learning

systems. NIPS.

Seldon Technologies Ltd. (2018). Seldon Core.

https://www.seldon.io/solutions/open-source-

projects/core (accessed 9 December 2022).

SoundCloud (2012). Prometheus. https://prometheus.io

(accessed 28 November 2022).

Symeonidis, G., Nerantzis, E., Kazakis, A., and Papakostas,

G. A. (2022). Mlops - deﬁnitions, tools and chal-

lenges. In 2022 IEEE 12th Annual Computing and

Communication Workshop and Conference (CCWC).

Zhou, Y., Yu, Y., and Ding, B. (2020). Towards mlops: A

case study of ml pipeline platform. In 2020 Interna-

tional Conference on Artiﬁcial Intelligence and Com-

puter Engineering (ICAICE). IEEE.

CLOSER 2023 - 13th International Conference on Cloud Computing and Services Science

276
