Git Workﬂow for Active Learning: A Development Methodology

Proposal for Data-Centric AI Projects

Fabian Stieler

and Bernhard Bauer

Institute of Computer Science, University of Augsburg, Germany

Keywords:

Active Learning, Software Engineering for Machine Learning, Machine Learning Operations.

Abstract:

As soon as Artiﬁcial Intelligence (AI) projects grow from small feasibility studies to mature projects,

developers and data scientists face new challenges, such as collaboration with other developers, versioning

data, or traceability of model metrics and other resulting artifacts. This paper suggests a data-centric AI

project with an Active Learning (AL) loop from a developer perspective and presents ”Git Workﬂow for AL”:

A methodology proposal to guide teams on how to structure a project and solve implementation challenges.

We introduce principles for data, code, as well as automation, and present a new branching workﬂow. The

evaluation shows that the proposed method is an enabler for fulﬁlling established best practices.

1 INTRODUCTION

More and more AI projects are emerging in compa-

nies across all industries, as several surveys

have

shown. The growing interest in AI systems stems

from the promise that, given enough data, machine

learning (ML) algorithms can learn to make decisions

that are impossible, or at least hard to code manually.

Even in critical domains, such as healthcare, new use

cases are constantly emerging, and not just because

research has shown that ML models are already able

to outperform humans at particular tasks (Rajpurkar

et al., 2022).

Besides AI projects, an ecosystem of methods,

concepts, and tools have been developed around tra-

ditional software projects. However, these solutions

cannot be directly transferred to AI projects, as AI-

and traditional software projects differ fundamentally

in one aspect: In traditional software projects, the

source code is sufﬁcient to create the artifacts. AI

projects, whose artifacts include a trained ML model,

have two types of inputs: code and data (Sculley et al.,

2015). Since data is usually more volatile than code,

the ML artifacts have to be recreated more frequently.

The research community has identiﬁed this gap

https://orcid.org/0009-0004-3827-9809

https://orcid.org/0000-0002-7931-1105

(Deloitte, 2020): State of AI in the Enterprise 3rd

Edition, (Capgemini, 2020): The AI-powered enterprise,

(McKinsey Analytics, 2021): The state of AI

and is beginning to make its way into the ﬁeld of

MLOps (Lwakatare et al., 2020). In emerging con-

cepts, such as CRISP-ML(Q) (Studer et al., 2021),

the focus is on what a developer has to do next, but

there is a lack of concrete instructions for teams how

it can be implemented. However, due to the vast spec-

trum of domains for AI projects, this is understand-

able. Traditional software projects have answered the

how in terms of development models and method-

ologies. For example, modern development methods

such as DevOps build on GitFlow or trunk-based de-

velopment Git workﬂows (Driessen, 2010). However,

there is still a need to adapt established development

methodologies for AI projects (Haakman et al., 2021).

This is reinforced by the recent trend in the AI

community, which is facing a shift in mindset towards

increasing awareness of data dependency in imple-

menting powerful AI systems (Paleyes et al., 2022).

In this context, AL is gaining popularity. This method

addresses the problem of data labeling, which is of-

ten referred to as the most costly and time-consuming

part of building an AI system. Here, the annotation

process should be made effective by having the model

iteratively select the data in a smart way that will con-

tribute to the highest possible information gain during

training.

However, such a technique leads to a further in-

crease in the dynamics of artifacts, which is why it is

necessary to develop methodologies for implement-

ing AI projects with an AL loop. This paper aims to

present a Git workﬂow for Active Learning (GW4AL)

202

Stieler, F. and Bauer, B.

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects.

DOI: 10.5220/0011988400003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 202-213

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

in a way that makes it easier for a development team

to solve emerging implementation challenges. To this

end, section 2 recaps the basics of the AL lifecycle.

Section 3 outlines the relevant software engineering

(SE) concepts and presents the proposed workﬂow.

Finally, the methodology is discussed in Section 4.

2 ACTIVE LEARNING

LIFECYCLE

In general, AL is deﬁned as a method in which the ML

model can select the data for training (Settles, 2009).

These data points are then labeled by an oracle and

added to the annotated data pool. Given the model’s

request for annotations, the goal is to make the data

labeling process more effective and iteratively train

an increasingly powerful algorithm through ongoing

feedback. Looking at this interaction from a software

developer’s perspective, both existing concepts, such

as DevOps, and currently emerging concepts from

MLOps and DataOps are involved in the implemen-

tation.

We use the foundations of these three concepts

to present our approach to an AL lifecycle, which

emerged during the development of a three-year data-

centric AI project and is shown in Figure 1. It is in-

tended to synchronize the established practices and

show individual phases, iterations, and their interre-

lationships in the AL loop. The core cycle gives a

system view of AL: All steps to train the ML model

are found in the ML iteration. Traditional phases of

software development have been implemented in the

development iteration. Operational tasks are adapted

to the circumstances of an AI project. The selection

and annotation of new data take place in the data iter-

ation shown in blue.

2.1 Data Iteration

Currently, various speciﬁcations of a data pipeline for

AI projects can be found in the literature. In (Fis-

cher et al., 2020), data preparation in the AI Modeling

Cycle is deﬁned as curation, labeling, and augmenta-

tion. The terminology of data collection as a stage

of the data iteration is used in (Idowu et al., 2021;

Tamburri, 2020; Ashmore et al., 2019; Amershi et al.,

2019), while this is usually followed by a phase called

data transformation (Morisio et al., 2020), sometimes

more speciﬁcally named to the respective tasks pro-

cessing, formatting or cleaning (Idowu et al., 2021).

(Amershi et al., 2019) identify in their ML workﬂow

the three data-oriented phases of collection, cleaning,

and labeling, which were also used by (Studer et al.,

OPS

DATA

DEV

Figure 1: Active Learning Lifecycle.

2021) for their ML process methodology for the mod-

iﬁcation of CRISP-DM (Wirth and Hipp, 2000). We

conclude that the core is about the three phases Ex-

tract, Transform and Load of the ETL process and

bundle the data engineering activities on them.

According to (Settles, 2009), we will merge data

extraction with differentiated AL query scenarios and

distinguish between batch-based and stream-based

scenarios: The former can be classiﬁed as pool-based

sampling, which describes a scenario in which data

points are selected from an unlabeled dataset to be an-

notated by the oracle (Lewis and Gale, 1994). These

Query-scenarios represent the link between ML and

data iteration in the AL lifecycle. The other query

scenario differs from the batch-based method and in-

volves stream-based sampling (Cohn et al., 1994).

Thereby it is evaluated for each data point individu-

ally whether the label should be queried by the ora-

cle. Based on the deployed application, we ﬁnd the

Stream of new data in the AL lifecycle as the second

possible stage to enter data iteration.

As soon as new data is provided, it can be made

versioned available for the subsequent phases. For

this purpose, we follow the usual order and combine

procedures from the area of Data Transformation.

Rule-based tasks are applied to the extracted raw data.

This includes data cleaning, which occurs in most

data pipeline proposals, and primarily improves the

quality of the data (Li et al., 2021; Ilyas and Chu,

2019).

In an AL setup, one or more query strategies (QS)

exist, regardless of whether they are single batches

or a data stream. There are essentially three oppos-

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects

203

ing forces in deciding which samples are best for the

model: informativeness and representativeness (Du

et al., 2017), and the diversity of a new data point.

Some QS are based on certainty (Angluin, 1988) and

focus on the model’s predictive ability for unknown

data points. Other approaches are more decision-

theoretic in nature and combine multiple models (Se-

ung et al., 1992). Once the data has been selected

by the QS and passed to data transformation, the new

instances must be labeled by an oracle. This stage,

represented as Label, can be done by a human or the

model itself. The latter is often referred to as auto-

mated data labeling or semi-supervised learning (Zhu,

2008). Based on the initial human annotations, if the

model reaches a certain threshold in its prediction, la-

bels are continuously assigned automatically. How-

ever, the human-in-the-loop is especially necessary

for domains e.g., with medical tasks, on the one hand,

to build up a sufﬁciently large ground truth dataset

and, on the other hand, to catch edge cases in the qual-

ity assurance process as well as to assign the correct

label for rarely occurring cases (Karimi et al., 2020).

Therefore, combining human- and automated annota-

tion is a promising method (Desmond et al., 2021).

To complete the data iteration, the goal of Load

is to make the results of the data iteration available in

other stages of the AL lifecycle in a standardized way.

Additional aspects need to be undertaken regarding

the split into training, test, and validation datasets, as

these could be subject to dynamics as well. With this

result, we follow the AL lifecycle clockwise to the

ML iteration.

2.2 Machine Learning Iteration

As new data or labels are available, the ML model

would be continuously (re-)trained in the AL loop.

Usually, the required ML pipeline consists of different

substeps, which can differ depending on the problem

domain and application. All tasks related to the ML

model are part of the green-colored ML iteration in

ﬁgure 1. During the implementation of an AL project,

they can be executed periodically or event-based in an

automated manner, represented as Trigger, as well as

experimentally, which is the connection from the di-

rection of the develop iteration. Experimental tasks

typically fall within the scope of a data scientist, who

may want to test the performance of a new model

architecture or the conﬁguration of new parameters

(Kreuzberger et al., 2022).

Regardless of the application-related stages of an

ML pipeline, the data required for the model are ﬁrst

analyzed. This phase, identiﬁed as Exploration in

the AL lifecycle, can be executed manually manually

for the experimental case or manifested in the form

of an analysis during the automated execution of the

ML iteration. Although the tasks are data-driven, the

focus here shifts in the model-oriented direction, for

example, the recognition of attributes, statistical eval-

uations, or outlier detection.

Subsequently, further steps take place, which are

summarized in ﬁgure 1 under Process. The data pre-

processing for the ML model is also very domain- and

use-case-speciﬁc (Studer et al., 2021). Techniques

such as normalization and standardization are used,

complemented by weighting and resampling, which

are more generally summarized as feature engineer-

ing.

Training means optimizing the ML model to its

objective function, reﬂecting the deﬁned problem so-

lution. In this process, the previously preprocessed

data is fed into the model to identify patterns. The re-

sult is an algorithm that is used in an AI application

as a prediction service and is successively retrained in

an AL project. The path in the AL lifecycle then sep-

arates, where the ML iteration can be preceded by an

optimization or - if a further improvement is to query

new data and labels - to return to the data iteration.

As a continuation or additional ML iteration, a model-

oriented Optimization usually includes activities that

focus on repeating the training process itself and im-

proving the model performance e.g., by adjusting hy-

perparameters.(Ashmore et al., 2019)

Once a suitable version of a trained model is

found, it is chosen via Model Selection Strategy and

made available to the next iteration or to dive into the

development process.

2.3 Develop Iteration

Different objectives could can be pursued with the ex-

ecution of the ML pipeline, resulting in requirements

for the implementation of the ML pipeline to converge

both, for fast feedback loops in the sense of agile soft-

ware development and to converge to a good model

for the problem (Amershi et al., 2019). In the area of

SE for ML systems, there is growing interest in the re-

search community. Regarding Development, (Arpteg

et al., 2018) describe SE challenges of Deep Learn-

ing applications and identify the strong data depen-

dency compared to traditional software development.

(Nascimento et al., 2020) provide a comprehensive

literature review in software development for AI.

Another characteristic of developing systems with

ML, especially with an AL loop in addition to data-

driven AI development, is the continuous feedback

from stakeholders in the form of new data and Re-

quirements, which the team of software develop-

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

204

ers, data engineers, and data scientists respond to and

Plan changes in their system.

Figure 1 shows the yellow-colored Develop iter-

ation next the Build phase, in which the new incre-

ment is merged with the project. Developing a ML

application with continuous integration is investigated

by (Karla

s et al., 2020) in their practice-oriented re-

search, where they called this methodology a ”de-

facto standard for building industrial-strength soft-

ware”.

Like in traditional software development, a suc-

cessful build is followed by a phase in which a se-

ries of manual and automated Tests are performed. In

AL projects, these go beyond the application code and

also include data dependency and the selected model

(Rukat et al., 2020). Within the context of ML Test-

ing, (Zhang et al., 2019) published an extensive sur-

vey. (Breck et al., 2016) provide a set of actionable

tests for AI projects with their rubric-based ML Test

Score.

We enter the Operations by completing or skip-

ping the development iteration once we pass the tests

with the selected retrained model and proceed to the

release stage.

2.4 Operations

All operational tasks, colored pink in ﬁgure 1, will

typically be carried out from the release to the deploy-

ment of a ML model and will be performed continu-

ously in a production environment. Here, Feedback

may come not only in the form of direct feedback

from AL stakeholders but also through hidden feed-

back in form of measurable behavioral differences of

model consumers. A possible response would be to

reconﬁgure the current release. (Sculley et al., 2015)

describe in their research the importance of Conﬁgu-

ration in ML systems and establish principles, such

as the necessary ability to implement a reconﬁgura-

tion as a small change.

Monitor is about managing the productive model

and data. Evaluation and Validation tasks result

from the (re-)conﬁguration and can also be character-

ized as continuous jobs of the productive AL system.

Usually, this includes techniques for concept drift de-

tection. It can identify both data and model drift and

derive possible requirements for the operations team.

To this end, (Renggli et al., 2021) give a data quality-

driven view of MLOps in their research. Drift detec-

tion is also addressed by (Klaise et al., 2020), who

also present concepts of explainability for deployed

models.

An overview of operations in the end-to-end AI

lifecycle is given by (Arnold et al., 2020), where De-

ployment is deﬁned as ”a stage of the seamless roll-

out of ML models”. In the study by (Paleyes et al.,

2022), the deployment of ML models is divided into

several stages in more detail.

The AL loop’s inherent character of continuity ne-

cessitates the consideration of continuous training to

automate ML iterations, continuous integration as a

de facto standard of software development, and con-

tinuous deployment of the newly trained model. For

its implementation, we propose the methodology pre-

sented in the following section.

3 GIT WORKFLOW

FOR ACTIVE LEARNING

While the proliferation of DevOps principles and

best practices has spawned methods such as Git-ﬂow

and trunk-based software development, speciﬁc ap-

proaches are just emerging in developing projects

with ML. Derived from the previously deﬁned AL

lifecycle, we propose GW4AL, an agile development

methodology for AL projects that provides guidelines

for a team of developers and data scientists to struc-

ture their work, focusing on a data-driven develop-

ment.

A central idea is the fusion of runners for Contin-

uous Integration (CI), -Delivery (CD), and -Training

(CT). Furthermore, we present a branch-based work-

ﬂow concept in which we introduce data- and code-

focused levels as well as new types of branches. To

realize this, we ﬁrst present the necessary principles

related to data, code, and the runners.

3.1 Basic Concepts

In an AL project, a wide range of different ML

frameworks are used. We have therefore created a

development approach as generic as possible. Below,

we present concepts enabling the branching workﬂow

described in the following section 3.2.

3.1.1 Data Principle

From a process perspective, AL usually starts with

collecting the raw data. Similar to the code, the data

will change over the project’s lifetime - either due to

additional data or changing requirements, which in

turn lead to new data being collected. In more con-

crete terms, new raw data may be imported, or new la-

bels may be acquired through the next iteration. Thus,

the artifacts of an AL project depend not only on the

code, but essentially on the data, which means that

the data has to be versioned. Although this can be

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects

205

Full Dataset(s)

Dev Dataset(s)

Time

full_a1 full_b1

full_a1 full_b2

full_a2 full_b3

dev_1

dev_2

Dev-

Dataset

Creator

Figure 2: Development Dataset Con-

cept.

project

ml_pipeline_configuration

runner_executions

ml_pipeline_code

process

train

model_architectures

model_1

model_2

...

train_model

load

...

data

...

processed

train

models

model_1_artifact

full_dataset_ref

raw

dev_dataset_ref

...

Figure 3: Proposed Project Structure.

SCM

Server

Deployment

Host

CI/CD/CT

Runner

Data

Server

Developer

Host

commit

progress

artifacts

data sets

artifacts

trigger

release

query artifacts

data

progress

commit

Figure 4: Minimal Infrastructure Setup.

done manually (e.g., by naming different versions of

the dataset with timestamps), it is advisable to use a

data versioning tool.

Developing a ML pipeline with complete, often

massive, datasets renders an implementation inefﬁ-

cient from many points of view. Both, the data se-

lection and the long computation time slow down the

developer’s work, therefore we recommend creating

a development dataset. This is a small subset of the

original data with the goal that the entire ML pipeline

takes only a few minutes to execute. This allows

developers to use the development dataset for local

development on their machine and to provide quick

feedback to the runner about whether a recent com-

mit breaks the ML pipeline.

The development dataset described above has

to be reproducible and version-safe and, therefore,

should not be created manually. The ideal solution

is a separate code module that samples from the com-

plete original dataset and enables automatic updates

to the subset as the original dataset changes. Sup-

pose this code module enables the possibility to in-

clude speciﬁc (groups of) samples into the develop-

ment dataset. In that case, this could serve as a basis

for regression testing, where samples that previously

broke the ML pipeline are now checked from the be-

ginning of the model training.

In addition to the established requirements for

datasets in ML engineering (Hutchinson et al., 2021),

there are additional requirements for this development

dataset considering the highly dynamic nature of the

data in an AL project. It should ideally approximate

the distribution of the underlying full datasets and

contain outliers and corrupted samples in some sce-

narios. Figure 2 illustrates the concept of develop-

ment datasets. The full datasets are shown on the left,

with changes over time at three iterations. The Dev-

Dataset-Creator code module ensures that the devel-

opment dataset is generated automatically. This can

be triggered manually, or fully automated as soon as

the distribution has changed signiﬁcantly between the

iterations, as shown in the ﬁgure.

3.1.2 Code Principle

Usually, a traditional ML pipeline consists of differ-

ent stages, regardless of the used ML framework or

use case. As shown in the AL lifecycle, an ML iter-

ation includes, among other tasks, the logic for pre-

processing as well as model training. At a very early

stage, for example, for prototyping, it is often com-

mon to implement all these steps in a single script or

notebook (Rule et al., 2018). These artifacts are of-

ten local to the developer’s workspace or are poor at

identifying version differences.

To enable a team of developers to collaborate

on an AI project, it has become established prac-

tice to split up the sub-steps of a pipeline (O’Leary

and Uchida, 2020). Individual code modules reﬂect

the stages of an ML pipeline, as shown in ﬁgure

3. Therefore, it is advisable to identify the required

stages when setting up an ML pipeline and then de-

ﬁne the necessary dependencies between the individ-

ual stages. It is essential to ensure that data ﬂows

through the pipeline early in the development process,

even if neither the data itself nor the resulting arti-

facts (e.g., the trained model) produce no meaningful

results. In this way, developers are able to work in

parallel on the different stages.

A sustainable implementation of the ML pipeline

code is to enable conﬁguring the stages via feature-

ﬂags and parameters. In this way, different implemen-

tations and settings of each stage can be systemati-

cally compared later on, while several developers col-

laborate on the same ML pipeline stage at the same

time. In this context, the conﬁguration of the ML

pipeline must be stored in ﬁles that can be tracked

using a version control system (e.g., Git).

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

206

To meet other requirements related to traceabil-

ity, the ”version number” of the input dataset must

also be treated as part of the conﬁguration. Some

data versioning tools provide this by storing hashes

of the records as version numbers in the conﬁguration

ﬁles. Other concepts use references, e.g., to a data

catalog. In addition these tools often have the capa-

bility to cache any artifact of the ML pipeline stages

(e.g., preprocessed data, trained model, evaluation re-

port) and can restore these artifacts if an execution

with identical code and data occurred in the past.

This setup creates synergies in terms of ML

pipeline runtimes across the AL Project in the lo-

cal development environment, when experimenting

on the entire dataset, or in production. For example,

if newly annotated data ﬂows into the pipeline, the

model may be re-trained and, if necessary, optimized

and evaluated. On the other hand, the computationally

intensive preprocessing is not necessarily repeated on

the entire dataset. Skipping this step enables a fast

re-deployment of the new model.

3.1.3 Automation Principle

An increasing area of MLOps research comprises the

management of different environments and effective

scaling of hardware resources as well as the asso-

ciated concepts and tools (Ruf et al., 2021; Giray,

2021). We designed our development proposal as

agnostic as possible to the underlying technologies,

where ﬁgure 4 outlines a minimal infrastructure setup.

It shows the necessary components and depicts a triv-

ial implementation of a distributed system for AL

projects.

First, the raw data and the created dev-dataset

must be provided to the data server. Usually, this

upload does not happen directly from the developer’s

client, but is done via an import of the respective data

source in case of large datasets. The development

dataset remains on the developer’s client and should

be small enough to allow quick iterations for ongoing

work. Developers commit and pass their code to the

source control management (SCM) system at regular

intervals. An SCM application is then able to trigger

a runner, which we call CI/CD/CT-Runner. This can

be hosted on a powerful machine (e.g., with GPUs).

Here, the scheduling, management, and scaling of the

computational resources required for ML pipeline ex-

ecution are taken into account, which is necessary as

soon as the required resources exceed the capacities

of the developer’s computer, for example, training the

model on the entire dataset.

Each job is uniquely associated with a trigger-

ing commit, so it is easy to decide whether certain

long-running jobs can be aborted. Existing tools and

frameworks from traditional software projects can be

reused to manage and monitor the actual servers host-

ing the runners. The runner checks out the version

of the dataset speciﬁed in the conﬁguration ﬁles and

executes the ML pipeline. After executing the ML

pipeline, the runners upload the artifacts to the data

server. This could occur when the developer provides

new code, when an experiment is computed on the

entire dataset, or when an automatic job is triggered,

such as a nightly scheduled re-training.

The SCM application provides access to the run-

ner’s logs, which is the simplest solution for moni-

toring the progress of the ML pipeline. This can be

extended with suitable tools such as MLfLow (Za-

haria et al., 2018), which may require new compo-

nents (Chen et al., 2020). Again, this infrastructure

concept is just the minimum and can be enhanced

in several ways: Separate runners for CI, CD, and

CT can be replaced by powerful clusters, a feature

store and/or a model registry can be added to the data

server, and much more.

Also, the implementation of the deployment, as

represented in ﬁgure 4, could be more sophisticated.

The deployment host covers the part of an AL sys-

tem dedicated for data labeling. The interface to the

oracle, in this case, could be realized in the form of

a model serving component in the stream-based sce-

nario or via the deployment of a query set for the an-

notation UI in the pool-based labeling scenario. Jobs

for execution in the runner can be re-triggered. Data,

such as acquired labels or new raw data from the

client, are uploaded to the data server.

3.2 Branching Workﬂow

The core idea of GW4AL is to introduce different

namespaces for the branches. Depending on which

of these levels a new branch lives in, it focuses on

the code or data dimensions. The runners behave dif-

ferently depending on which branch namespace they

were triggered to. To explore the branching workﬂow,

we consider an example project in ﬁgure 5, which can

begin once the setup described in Section 3.1 exists

and the code for the initial ML pipeline has been com-

mitted to the main branch.

3.2.1 Main Branch

The main branch contains, as usual for software

projects, the most complete version of the code. At

the beginning of the AL project, this may consist

only of stubs and interfaces for each ML pipeline

stage. Later on, the essential requirement for the

main branch is consistently to provide a clean, exe-

cutable and stable version of the ML pipeline. Re-

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects

207

garding to this, the runners in its namespace focus on

the quality of the code: They run the ML pipeline

on the development dataset as a form of integration

testing. Since the conﬁguration ﬁles contain informa-

tion about the allowed values of all parameters, they

are able to check the code across the allowed combi-

nations, which could turn out to be time-consuming,

even with the development dataset. In addition, tradi-

tional unit tests and other code analysis steps should

be performed to keep the quality in the main branch

at the desired high level.

3.2.2 Feature Branches

As soon as the development team plans a new feature

or the need arises from changed requirements, a fea-

ture branch is created following the established con-

cept of traditional software projects. Using ﬁgure 5

as an example, an initial function is to be developed.

This need is documented in an issue in the SCM appli-

cation and the feature branch is created through com-

mitting A1 , where the implementation takes place.

The developer creates a new feature ﬂag as well as

the necessary parameters and implements the func-

tion using the development dataset. After each push

commit, the runner veriﬁes that the ML pipeline is

working as expected by referring to the development

dataset for code execution. Static code checks as well

as unit tests are executed, similar to a CI pipeline in

classic software development. However, the results

of the ML pipeline are not important, which is why

any experiment tracking service used in the project

remains disabled.

Once the developer considers the issue resolved,

they start a merge request in the SCM application.

These requests allow other team members to provide

feedback and review the code before it is merged with

the main branch and becomes version 1.0 from com-

mit A2 . At this point, it is not always necessary that

the new feature actually improves the performance

of the model. As illustrated by the example of the

initial feature branch, sometimes, feature implemen-

tation and testing sufﬁce, since this allows for other

team members to build on the new features as quickly

as possible. In some cases a combination of different

features is required to actually enhance ML perfor-

mance. Since the project follows the code structure

described in Section 3.1, it is well feasible for multi-

ple developers to collaborate on different features in

different branches.

However, when implementing certain features in

an AL project, their execution on the entire datasets

is necessary, even before starting the merge request.

This could be the case when implementing a new

model architecture, as illustrated in our example of

Feature

Experiment

Main

Release

Full Dataset(s)

Dev-Dataset(s)

New Features

ML (Re)-

Configuration

Code focused

Data focused

Figure 5: Branching Workﬂow in an AL Project.

ﬁgure 5 in the second feature branch at B1 . There,

the developer decides to start an experiment and

branches off with the respective code version into one

or more experiment branches.

3.2.3 Experiment Branches

GW4AL introduces the concept of custom branch

namespaces. These include experiment branches

where runners execute the ML pipeline on the com-

plete datasets rather than the development datasets.

To continue with the example: Subsequent to the im-

plementation of the executable code of a new model

architecture is its training and evaluation of a per-

formant model. The developer creates one or more

branches under the Experiment namespace and con-

ﬁgures the ML pipeline by modifying the conﬁgu-

ration ﬁles by enabling the feature ﬂag and specify-

ing the parameters. While one experiment is reserved

for hyperparameter optimization, another experiment

might have enabled an extension, such as additional

data augmentation. Commit C1 contains a modi-

ﬁed conﬁguration of the actual feature commit B1

and triggers the runner with access to the complete

datasets. When the ML pipelines have been com-

pleted, the runner stores the artifacts on the data server

using the data versioning system, as visualized in ﬁg-

ure 4. This ensures that for each artifact in the ML

pipeline, all circumstances such as data version, code

version, and execution environment used to create it,

are documented.

Commit C1 could be perceived as a feasibility ex-

periment that provides early feedback to the developer

on whether further pursuing the current feature is de-

sirable. It could be useful to trigger proof-of-concept

experiments, where the initial focus shifts from ﬁne-

tuning the model to roughly evaluating ML perfor-

mance. In case of failure, the overhead of a merge

request and code reviews is omitted.

In addition, experiment branches support the re-

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

208

conﬁguration of the ML pipeline. Here, the develop-

ment team can directly fork a new branch D1 from

the main branch into the experiment namespace to

modify the conﬁguration ﬁle. Runners triggered by

the commit of an experiment branch should enable an

experiment tracking service by default. This work-

ﬂow makes the development team’s reconﬁguration

decision transparent and reproducible at all times.

3.2.4 Release Branches

If the results of an experiment outperform the current

best model, it is time to open a merge request from

the main branch to the release branch. At this stage,

both the code and the artifacts can be reviewed by

other team members. In our example, a new runner

is triggered on the release branch when the merge re-

quest is accepted at version 1.1 . Using the caching

feature of a data versioning tool, this runner can re-

store the artifacts from the experiment run C1 from

the data server. If errors or undesirable conditions

occur during or after deployment, familiar counter-

measures from traditional software projects, such as

rolling back the release branch to a previous commit,

can be applied.

To address the continuous change of data and la-

bels in an AL project, we introduce the second spe-

cial branch, that lives in the data-centric level of the

project as a code-version-twin to the release branch.

3.2.5 Active Learning Branch

The AL Branch in GW4AL is deﬁned as the mirrored

provided code version of a branch, referencing a pos-

sibly more recent version of the corresponding data

artifacts. The characteristics of the AL Branch corre-

spond to those of a deployed data branch. This con-

dition arises from the consistent use of the runners,

which are also used for continuous training, transfer-

ring the data artifacts to the data server after execution

of the ML pipeline, and committing the version refer-

ence of the hashes back to their AL Branch.

Making this description more concrete, we con-

tinue referencing ﬁgure 5 and the previously pre-

sented example for experiments D1 and D2 ,

whereas we now focus on the new blue-colored AL

Branch of our Release Branch. AL simulations or

Live-Experiments go beyond classical ML experi-

ments, e.g., they have to be performed to evaluate new

label QS. Here, it is no longer sufﬁcient to switch

from development datasets to full datasets, but the

runner of the experiment branches must be able to

check out the updated published dataset version.

Now we leverage the synergy mentioned above of

the data versioning tool’s caching feature and artifact

reuse in the other direction. When a runner in an ex-

periment branch is triggered, it is able to pull itself

the current version of the data reference ﬁle from the

AL Branch and download any existing data artifacts

from the data server. The code of the experiments

is now executed with the current data and offers the

development team the capability to make their deci-

sion based on consistently traceable and reproducible

results. If the team decides to introduce further modi-

ﬁcations to the code, the branching workﬂow remains

the same: A merge request is derived from D2 , and

the newer version of the ML-conﬁguration is propa-

gated through the merge in the Main Branch as ver-

sion 1.2 , deployed via the Release Branch in the AL

Branch.

4 EVALUATION

In order to assess the practicality of GW4AL, its eval-

uation is performed in two phases: While in sec-

tion 4.1, the comparison with existing literature pro-

vides an alignment to established concepts, we use

the results of interviews in section 4.2 to incorporate a

practice-oriented assessment with people from the in-

dustry. A detailed overview of all best practices com-

pliance is provided in table 3 in the appendix.

4.1 Best Practices

To evaluate the proposed principles and the branch-

ing workﬂow, we draw on the best practices collected

from present literature by (Serban et al., 2020). The

authors focus on peer-reviewed publications that pro-

pose, collect, or validate engineering best practices

for ML. Their method resulted in 29 engineering best

practices categorized into data, training, coding, de-

ployment, team, and governance. We consider which

of the available aspects are (a) entirely fulﬁlled by

GW4AL, (b) can enable a team to follow the best

practice, but further action is required, or (c) not vi-

able.

(a) We consider 12 of 29 Best Practices to be fully

satisﬁed. These include, for example, ”Use Con-

tinuous Integration”, ”Enable Parallel Training

Experiments”, and ”Use Versioning for Data,

Model, Conﬁgurations and Training Scripts”.

(b) GW4AL does not per se fulﬁll 17 of the 29

enumerated best practices in its implementation.

However, our proposed development methodol-

ogy can be an enabler for their implementation.

These include, for example, ”Run Automated Re-

gression Tests” (cf. 3.1.1), ”Continually Measure

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects

209

Model Quality and Performance” (cf. 3.1.3), and

”Use Static Analysis to Check Code Quality” (cf.

3.2.2).

their implementation by GW4AL. In other words,

teams using GW4AL are not be impeded in adher-

ing to the speciﬁc best practices, although further

methodological steps are required to achieve full

compliance.

4.2 Interviews

In addition to academia, experts from industry have

been interviewed in various studies to ﬁnd answers to

practice-oriented questions, such as in the area of SE

for ML (Giray, 2021). For our evaluation, we follow

that lead and exploit knowledge of such experienced

experts to discuss GW4AL in semi-structured inter-

views. All interviewees from various industries and

different company sizes, as seen in Table 1, received

slides

with information about GW4AL in advance.

In a 60 min face-to-face interview, the subjects were

asked about their implementation of projects and their

assessment of the applicability of GW4AL.

Maturity models are often used to categorize

projects in the traditional SE context. In order to

the interviewees professional background, we asked

them to assign their projects to a maturity model with

various aspects. Table 2 in the appendix provides a

detailed overview of their proﬁles, whereby the as-

sessment reﬂects a subjective perception and is not

based on any hard criteria. It is noticeable that the

interview partners from R&D agreed on data science-

driven processes and that technology aspects corre-

spond to a lower maturity level. The distribution of

the eight interviewees is balanced in technology- and

process-related implementations. On the other hand,

concerning people-related factors, a large proportion

attributes a higher level of project maturity to them-

selves. This investigation conﬁrms, limited to the re-

duced group of interviewees, the thesis that method-

ological problems in the development of AL projects

currently prevail mainly in process and technology

and less in people-related working practices.

During the discussions about GW4AL and its

Technology-related tasks, [α, β, γ, ε] suggested that a

large focus should be placed on requirements for the

selection of suitable development datasets. [α] contin-

ued the discussion on the data principle further in the

interview and suggested a kind of A/B testing with

different-sized development datasets up to the full

datasets could be a compromise between fast feed-

mediastore.rz.uni-augsburg.de/get/poze0tjOHv

Table 1: Proﬁles of interviewees.

No. Role/Position Industry (Employees)

α SE Team Lead Technology (> 100k)

β SE Quality Manager Technology (< 500)

γ AI Project Manager R&D (≈ 30k)

δ Data Scientist R&D (≈ 2k)

ε Head of AI Consulting (< 500)

ζ ML Engineer Consulting (< 500)

η Data Scientist Automotive (> 100k)

θ Head of AI Automotive (> 100k)

back and testing on complete datasets. Thus, the gen-

eral idea to provide minimal datasets for development

on the developer client and inside the code-related CI-

runners nevertheless appears promising.

In terms of the Process and its scalability, [α, β, η]

pointed out that it could be confusing to have a wide

range of experiment branches and possibly several

parallel-living AL branches on large projects. This

issue should be discussed on an organizational level

to develop a satisfactory solution. [β, γ, δ, ε, ζ] ex-

pressed skepticism regarding the methodology’s re-

alization for smaller projects with team sizes of less

than ﬁve members. The main issue to consider here

is the signiﬁcant overhead in the early stages, as small

ML and AL projects today are often still proof of con-

cepts.

Related to People, [δ] said that, the necessary vari-

ety of technologies and implementation of automated

processes for GW4AL, result in an increase in com-

plexity for team members, for which some developers

might lack the expertise. In this regard, [ζ] suggested

that when implementing projects with GW4AL and

away from the experiment branches, a kind of labo-

ratory environment for notebooks should be provided

for data scientist-driven tasks.

Through the interviews, it became apparent that

GW4AL creates a solid basis for developers of data-

centric AI projects with AL. The mentioned require-

ments for the development dataset offer potential for

discussion. Furthermore, it should be stated that

GW4AL introduces an unavoidable overhead into a

project that may outweigh the beneﬁts, especially in

the early exploratory phase. The team needs a mem-

ber capable of setting up the required infrastructure,

and each team member needs to be familiar with both

code and data version control systems. Developers or

data scientists not used to working with a data version

control system will face a steep learning curve and

common pitfalls, such as overly large merge requests.

Feature branches will likely require a different conﬁg-

uration than the current best model, such as a smaller

number of training epochs to facilitate the rapid feed-

back loop. These two conﬁgurations will require ad-

ditional management. Teams can still beneﬁt from the

principles provided, and traceability improves.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

210

5 CONCLUSIONS

When implementing projects with an AL loop, ad-

dressing the requirements that arise with the addi-

tional dimension of data dependency is essential. To

this end, we ﬁrst presented the AL lifecycle, which or-

chestrates current concepts from DataOps, DevOps,

and MLOps for these human-in-the-loop projects.

Second, we introduced GW4AL, a proposed develop-

ment methodology to help teams realize data-centric

AI projects with AL. In particular, it enables the

growth process of projects from feasibility studies to

mature projects, as realized by us in a three-year data-

centric AI project.

GW4AL provides a transparent method to collab-

orate for all stakeholders in developing data-centric

AI projects. In doing so, projects can beneﬁt from

tools and best practices from the traditional SE do-

main. Different branching namespaces enforce a

strict separation between the ”data experiments” and

the ”feature implementation”. The AL branch imple-

ments the loop characteristic so that the currently data

version can be more upstream compared to the current

released code version. Future investigations could ad-

dress how to implement quality gateways along the

AL lifecycle. Additional suggestions from the in-

terviews on requirements, related to the development

dataset and reducing the organizational overhead for

Data Scientists provide room for future research.

ACKNOWLEDGEMENTS

This work was funded by the German Federal Min-

istry of Education and Research (BMBF) under refer-

ence number 031L9196B.

REFERENCES

Amershi, S., Begel, A., Bird, C., DeLine, R., Gall, H., Ka-

mar, E., Nagappan, N., Nushi, B., and Zimmermann,

T. (2019). Software Engineering for Machine Learn-

ing: A Case Study. In 2019 IEEE/ACM 41st Interna-

tional Conference on Software Engineering: Software

Engineering in Practice (ICSE-SEIP), pages 291–300,

Montreal, QC, Canada. IEEE.

Angluin, D. (1988). Queries and concept learning. Machine

Learning, 2(4):319–342.

Arnold, M., Boston, J., Desmond, M., Duesterwald, E.,

Elder, B., Murthi, A., Navratil, J., and Reimer, D.

(2020). Towards Automating the AI Operations Life-

cycle. arXiv:2003.12808 [cs].

Arpteg, A., Brinne, B., Crnkovic-Friis, L., and Bosch, J.

(2018). Software Engineering Challenges of Deep

Learning. In 2018 44th Euromicro Conference on

Software Engineering and Advanced Applications

(SEAA), pages 50–59. arXiv:1810.12034 [cs].

Ashmore, R., Calinescu, R., and Paterson, C. (2019). As-

suring the Machine Learning Lifecycle: Desiderata,

Methods, and Challenges. arXiv:1905.04223 [cs,

stat].

Breck, E., Cai, S., Nielsen, E., Salib, M., and Sculley, D.

(2016). What’s your ML Test Score? A rubric for

ML production systems. 30th Conference on Neural

Information Processing Systems (NIPS 2016).

Chen, A., Chow, A., Davidson, A., DCunha, A., Ghodsi,

A., Hong, S. A., Konwinski, A., Mewald, C., Murch-

ing, S., Nykodym, T., Ogilvie, P., Parkhe, M., Singh,

A., Xie, F., Zaharia, M., Zang, R., Zheng, J., and Zu-

mar, C. (2020). Developments in MLﬂow: A Sys-

tem to Accelerate the Machine Learning Lifecycle. In

Proceedings of the Fourth International Workshop on

Data Management for End-to-End Machine Learning,

Portland OR USA. ACM.

Cohn, D., Atlas, L., and Ladner, R. (1994). Improving gen-

eralization with active learning. Machine Learning,

15(2):201–221.

Desmond, M., Duesterwald, E., Brimijoin, K., Brachman,

M., and Pan, Q. (2021). Semi-Automated Data Label-

ing. Journal of Machine Learning Research, 133:156–

169.

Driessen, V. (2010). A successful Git branch-

ing model. https://nvie.com/posts/a-successful-git-

branching-model/.

Du, B., Wang, Z., Zhang, L., Zhang, L., Liu, W., Shen, J.,

and Tao, D. (2017). Exploring Representativeness and

Informativeness for Active Learning. IEEE Transac-

tions on Cybernetics, 47(1):14–26.

Fischer, L., Ehrlinger, L., Geist, V., Ramler, R., Sobiezky,

F., Zellinger, W., Brunner, D., Kumar, M., and Moser,

B. (2020). AI System Engineering—Key Challenges

and Lessons Learned. Machine Learning and Knowl-

edge Extraction, 3(1):56–83.

Giray, G. (2021). A software engineering perspective on

engineering machine learning systems: State of the

art and challenges. Journal of Systems and Software,

180.

Google Inc. (2020). MLOps: Continuous delivery

and automation pipelines in machine learning.

https://cloud.google.com/architecture/mlops-

continuous-delivery-and-automation-pipelines-in-

machine-learning.

Haakman, M., Cruz, L., Huijgens, H., and van Deursen,

A. (2021). AI lifecycle models need to be revised:

An exploratory study in Fintech. Empirical Software

Engineering, 26(5).

Hutchinson, B., Smart, A., Hanna, A., Denton, E., Greer,

C., Kjartansson, O., Barnes, P., and Mitchell, M.

(2021). Towards Accountability for Machine Learn-

ing Datasets: Practices from Software Engineering

and Infrastructure. arXiv:2010.13561 [cs].

Idowu, S., Str

uber, D., and Berger, T. (2021). As-

set Management in Machine Learning: A Survey.

arXiv:2102.06919 [cs].

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects

211

Ilyas, I. F. and Chu, X. (2019). Data Cleaning. Association

for Computing Machinery, New York, NY, USA.

Karimi, D., Dou, H., Warﬁeld, S. K., and Gholipour, A.

(2020). Deep learning with noisy labels: Exploring

techniques and remedies in medical image analysis.

Medical Image Analysis, 65.

Karla

s, B., Interlandi, M., Renggli, C., Wu, W., Zhang, C.,

Mukunthu Iyappan Babu, D., Edwards, J., Lauren, C.,

Xu, A., and Weimer, M. (2020). Building Contin-

uous Integration Services for Machine Learning. In

Proceedings of the 26th ACM SIGKDD International

Conference on Knowledge Discovery & Data Mining,

pages 2407–2415, Virtual Event CA USA. ACM.

Klaise, J., Van Looveren, A., Cox, C., Vacanti, G., and

Coca, A. (2020). Monitoring and explainability of

models in production. arXiv:2007.06299 [cs, stat].

Kreuzberger, D., K

uhl, N., and Hirschl, S. (2022). Machine

Learning Operations (MLOps): Overview, Deﬁnition,

and Architecture. https://arxiv.org/abs/2205.02302.

Lewis, D. D. and Gale, W. A. (1994). A sequential algo-

rithm for training text classiﬁers. In Annual Interna-

tional ACM SIGIR Conference on Research and De-

velopment in Information Retrieval, pages 3–12, Lon-

don. Springer-Verlag.

Li, P., Rao, X., Blase, J., Zhang, Y., Chu, X., and Zhang,

C. (2021). CleanML: A Study for Evaluating the Im-

pact of Data Cleaning on ML Classiﬁcation Tasks.

arXiv:1904.09483 [cs].

Lwakatare, L. E., Crnkovic, I., R

ange, E., and Bosch, J.

(2020). From a data science driven process to a contin-

uous delivery process for machine learning systems.

In Morisio, M., Torchiano, M., and Jedlitschka, A.,

editors, Product-Focused Software Process Improve-

ment, pages 185–201, Cham. Springer International

Publishing.

Microsoft Corporation (2021). MLOps with Azure Machine

Learning - Accelerating the process of building, train-

ing, and deploying models at scale.

Morisio, M., Torchiano, M., and Jedlitschka, A., editors

(2020). Product-Focused Software Process Improve-

ment: 21st International Conference, PROFES 2020,

Turin, Italy, November 25–27, 2020, Proceedings,

volume 12562 of Lecture Notes in Computer Science.

Springer International Publishing, Cham.

Nascimento, E., Nguyen-Duc, A., Sundbø, I., and Conte,

T. (2020). Software engineering for artiﬁcial intelli-

gence and machine learning software: A systematic

literature review. arXiv:2011.03751.

O’Leary, K. and Uchida, M. (2020). Common Problems

with Creating Machine Learning Pipelines from Ex-

isting Code. In Workshop on MLOps Systems.

Paleyes, A., Urma, R.-G., and Lawrence, N. D. (2022).

Challenges in Deploying Machine Learning: a Survey

of Case Studies. arXiv:2011.09926 [cs].

Rajpurkar, P., Chen, E., Banerjee, O., and Topol, E. J.

(2022). AI in health and medicine. Nature Medicine,

28(1):31–38.

Renggli, C., Rimanic, L., G

urel, N. M., Karla

s, B., Wu, W.,

and Zhang, C. (2021). A Data Quality-Driven View of

MLOps. arXiv:2102.07750 [cs].

Ruf, P., Madan, M., Reich, C., and Ould-Abdeslam, D.

(2021). Demystifying MLOps and Presenting a

Recipe for the Selection of Open-Source Tools. Ap-

plied Sciences, 11(19).

Rukat, T., Lange, D., Schelter, S., and Biessmann, F. (2020).

Towards automated ml model monitoring: Measure,

improve and quantify data quality. In MLSys 2020

Workshop on MLOps Systems.

Rule, A., Tabard, A., and Hollan, J. D. (2018). Exploration

and Explanation in Computational Notebooks. In

Proceedings of the 2018 CHI Conference on Human

Factors in Computing Systems, Montreal QC Canada.

ACM.

Sculley, D., Holt, G., Golovin, D., Davydov, E., Phillips,

T., Ebner, D., Chaudhary, V., Young, M., Crespo, J.-

F., and Dennison, D. (2015). Hidden technical debt in

machine learning systems. In Cortes, C., Lawrence,

N., Lee, D., Sugiyama, M., and Garnett, R., editors,

Advances in Neural Information Processing Systems,

volume 28. Curran Associates, Inc.

Serban, A., van der Blom, K., Hoos, H., and Visser, J.

(2020). Adoption and Effects of Software Engineer-

ing Best Practices in Machine Learning. In Proceed-

ings of the 14th ACM / IEEE International Symposium

on Empirical Software Engineering and Measurement

(ESEM). arXiv:2007.14130 [cs].

Settles, B. (2009). Active learning literature survey. Com-

puter Sciences Technical Report 1648, University of

Wisconsin–Madison.

Seung, H. S., Opper, M., and Sompolinsky, H. (1992).

Query by committee. In Proceedings of the Fifth An-

nual Workshop on Computational Learning Theory,

COLT ’92, page 287–294, New York, NY, USA. As-

sociation for Computing Machinery.

Studer, S., Bui, T. B., Drescher, C., Hanuschkin, A.,

Winkler, L., Peters, S., and Mueller, K.-R. (2021).

Towards CRISP-ML(Q): A Machine Learning Pro-

cess Model with Quality Assurance Methodology.

arXiv:2003.05155 [cs, stat].

Tamburri, D. A. (2020). Sustainable MLOps: Trends and

Challenges. 22nd International Symposium on Sym-

bolic and Numeric Algorithms for Scientiﬁc Comput-

ing (SYNASC), pages 17–23.

Wirth, R. and Hipp, J. (2000). CRISP-DM: Towards a Stan-

dard Process Model for Data Mining.

Zaharia, M. A., Chen, A., Davidson, A., Ghodsi, A.,

Hong, S. A., Konwinski, A., Murching, S., Nykodym,

T., Ogilvie, P., Parkhe, M., Xie, F., and Zumar, C.

(2018). Accelerating the machine learning lifecycle

with mlﬂow. IEEE Data Eng. Bull., 41:39–45.

Zhang, J. M., Harman, M., Ma, L., and Liu, Y. (2019). Ma-

chine Learning Testing: Survey, Landscapes and Hori-

zons. arXiv:1906.10742 [cs, stat].

Zhu, X. (2008). Semi-Supervised Learning Literature Sur-

vey.

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

212

APPENDIX

Table 2: Inventory of project maturity levels and self-assessment of interviewees: Aspects, based on maturity models from

(Microsoft Corporation, 2021) and (Google Inc., 2020), were divided into three categories: Technology, Process, and Peo-

ple. The levels increase from Level 1 (= early project stage, most manual) to Level 4 (= highest mature, fully automated).

Interviewees were asked at the beginning of the interviews to use the table to rank the maturity of their projects.

Level 1 Level 2 Level 3 Level 4

Technology

Poor SCM

γ,δ

Standardized SCM

Integrated Monitoring

β,η,θ

Pipeline as product

α,ζ

Untracked Artifacts

β,δ

Artifact Mgmt. Tools

Toolset Integration

ζ,η,θ

Fully Automated

No Automation

Monitoring Tools

γ,ε,ζ

Analytic Tools

β,η,θ

Integrated Resilience

Manual Build

γ,δ,ε

Standardized Builds Autom. Builds

Autom. Test-Envs

α,β,η

Process

Ad Hoc Development

α,δ

Requirement Mgmt.

Agile Development

β,ζ

Lean Development

α,η,θ

Manual Handwork

Manual Release

δ,ε,ζ

Autom. Deliveries Continuous Deliveries

α,β,η,ζ

Stand-alone solutions

γ,δ

Modularity

Integrated Reporting

β,ζ,η

Predictive Pipeline

”Trail and error” Manual Testing

γ,δ,ε

Integrated Testing

β,ζ,η

-Maintenance

People

Knowledge Silos Semi-Cooperative

Knowledge Mgmt.

β,γ

Inter-Team Transfer

α,ε,ζ,η,θ

Poor Communication Written Knowledge Fast Feedback-Loops

α,ζ

Consult other Teams

β,γ,δ,ε

No Priority-Awareness Regular Communication Continuous Education

Ownership Mindset

γ,δ,ε,ζ,η,θ

Low Innovation Innov. by Requirement

β,ε

Innovation Strategy

Innovation as Vision

α,ζ,η,θ

Table 3: Best practices, collected by (Serban et al., 2020) and their fulﬁllment ranking for GW4AL: + + + matches a

complete fulﬁllment of GW4AL. Scores ++ and + are intended to provide an evaluation of whether GW4AL is an enabler

for achievement. For the best practice marked with o, GW4AL is no enabler, but in our view the compliance would not be

hindered.

Nr. Title Fulﬁllment Reference

1 Use Sanity Checks for All External Data Sources ++ Sec. 3.1.1

2 Check that Input Data is Complete, Balanced and Well Distributed ++ Sec. 3.1.1

3 Write Reusable Scripts for Data Cleaning and Merging +++ Sec. 3.1.1

4 Ensure Data Labelling is Performed in a Strictly Controlled Process +++ Sec. 3.2.5

5 Make Data Sets Available on Shared Infrastructure (private or public) ++ Sec. 3.1.3

6 Share a Clearly Deﬁned Training Objective within the Team +

7 Capture the Training Objective in a Metric that is Easy to Measure and Understand +

8 Test all Feature Extraction Code ++ Sec. 3.2.2

9 Assign an Owner to Each Feature and Document its Rationale +++ Sec. 3.2.2

10 Actively Remove or Archive Features That are Not Used +

11 Peer Review Training Scripts +++ Sec. 3.2.2

12 Enable Parallel Training Experiments +++ Sec. 3.2.3

13 Automate Hyper-Parameter Optimisation and Model Selection +++ Sec. 3.2.3

14 Continuously Measure Model Quality and Performance +

15 Share Status and Outcomes of Experiments Within the Team +++ Sec. 3.2.3

16 Use Versioning for Data, Model, Conﬁgurations and Training Scripts +++ Sec. 3.1.1

17 Run Automated Regression Tests ++ Sec. 3.2.2

18 Use Continuous Integration +++ Sec. 3.1.3

19 Use Static Analysis to Check Code Quality ++ Sec. 3.1.1

20 Automate Model Deployment +++ Sec. 3.2.4

21 Continuously Monitor the Behaviour of Deployed Models ++ Sec. 3.2.5

22 Enable Shadow Deployment ++ Sec. 3.2.4

23 Perform Checks to Detect Skews between Models ++ Sec. 3.2.5

24 Enable Automatic Roll Backs for Production Models +++ Sec. 3.2.4

25 Log Production Predictions with the Model’s Version and Input Data +++ Sec. 3.2.5

26 Use A Collaborative Development Platform ++ Sec. 3.1.2

27 Work Against a Shared Backlog +

28 Communicate, Align, and Collaborate With Multidisciplinary Team Members +

29 Enforce Fairness and Privacy o

Git Workﬂow for Active Learning: A Development Methodology Proposal for Data-Centric AI Projects

213
