A Multi-Perspective Framework for Smart Contract Search in

Decentralised Applications Design

Ada Bagozi

, Devis Bianchini

, Valeria De Antonellis

, Massimiliano Garda

and Michele Melchiori

Dept. of Information Engineering, University of Brescia, Via Branze 38, 25123, Brescia, Italy

Keywords:

Multi-Perspective Model, Blockchain, Decentralised Applications, Smart Contracts, Semantic.

Abstract:

With the advent of blockchain technology, many interorganisational collaborative processes that demand trust

requirements (e.g., food supply chain, smart grid energy distribution and clinical trials) are being implemented

as decentralised applications (DApps). Indeed, blockchain technology provides decentralised control and

immutable transaction history, thereby improving security and accountability between parties. In this vision

paper, we consider cooperative processes where a subject, which acts as a regulator of the process, promotes

the use of blockchain for increasing transparency, while reducing the burden in controlling trustworthiness

among participants. To the scope, the regulator provides a registry of basic smart contracts, including both

actual deployed ones and code templates, that can be used and extended by the process stakeholders (e.g.,

retailers, energy providers, researchers) to build up DApps. The adoption of a blockchain and the deﬁnition

of the registry favour the compliance with best practices and obligations demanded by the regulator, as well

as that all relevant information and documents cannot be tampered. To support semantic-based smart contract

search in the registry, we propose a multi-perspective framework that, in addition to classiﬁcation and technical

characteristics of smart contracts, takes into account the past experience of developers who have used smart

contracts of the registry to develop DApps.

1 INTRODUCTION

With the advent of blockchain technology, many in-

terorganisational collaborative processes demanding

trust requirements (e.g., food supply chain, smart

grid energy distribution and clinical trials) are be-

ing implemented as decentralised applications (D-

Apps) (Cai et al., 2018). DApps are conceived

as web applications that orchestrate smart contracts

(SCs) to implement the business logic of the applica-

tions and also provide a Graphical User Interface to

ease interactions among participants. Leveraging the

blockchain, a DApp provides decentralised control

and immutable transaction history, thereby improving

security and accountability between parties. Smart

contracts, along with distributed ledger technologies,

have the potential to enforce automated negotiations

https://orcid.org/0000-0002-0193-6500

https://orcid.org/0000-0002-7709-3706

https://orcid.org/0000-0002-3634-0213

https://orcid.org/0009-0006-5823-6595

https://orcid.org/0000-0001-8649-4192

and agreements between parties without the direct in-

volvement and intermediation of central authorities,

by providing public and trusted functionalities exe-

cuted on top of the blockchain.

In this vision paper, we consider cooperative

processes occurring in domains, e.g., clinical trials,

where a subject, which acts as a regulator (i.e., that

carries out regulatory activities in a given domain)

of the process, promotes the use of blockchain for

increasing transparency, while improving the trust-

worthiness among participants. In these processes,

the regulator is in charge of overseeing the fulﬁl-

ment of the necessary requirements for safety, quality

and efﬁcacy of the assets being supplied, providing

also rules, authorisations and, possibly, technological

frameworks to the involved parties.

To the purpose, the regulator subject may provide

a registry of basic SCs that can be used and extended

by stakeholders to set up DApps. Actually, in order to

develop real-world DApps, reuse of SCs published in

open access registries has become a common practice,

as investigated in recent efforts (Tran et al., 2019; He

et al., 2020).

Bagozi, A., Bianchini, D., De Antonellis, V., Garda, M. and Melchiori, M.

A Multi-Perspective Framework for Smart Contract Search in Decentralised Applications Design.

DOI: 10.5220/0011992000003467

In Proceedings of the 25th International Conference on Enterprise Information Systems (ICEIS 2023) - Volume 1, pages 229-236

ISBN: 978-989-758-648-4; ISSN: 2184-4992

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

229

In this setting, we propose a multi-perspective

framework to support search and reuse of SCs that,

in addition to classiﬁcation and technical character-

istics of SCs, takes into account the past experience

of developers who have used SCs from the registry to

develop DApps. The framework supports semantic-

based search (Bianchini et al., 2009) and ranking of

SCs according to three search scenarios apt to support

development of DApps at different phases.

The paper is organised as follows. Section 2

presents a motivating scenario and Section 3 describes

the multi-perspective DApp model. SC search scenar-

ios and ranking are illustrated in Section 4. Section 5

emphasises the cutting-edge features of our approach,

with respect to the state of the art. Finally, Section 6

closes the paper, sketching future research directions.

2 MOTIVATING SCENARIO

In this paper, we consider a reference scenario from

the healthcare domain, regarding clinical trial pro-

cesses. A clinical trial is articulated over different

phases, aimed at introducting a New Chemical En-

tity (NCE) to the market, initially administered to a

limited number of volunteers. Participants in a clini-

cal study may incur in research-related injuries, which

should be minimised by researchers steering the trial.

In such cases, individuals would be compensated if

the injury descends from their participation in the

trial. As also discussed in recent research (Wong

et al., 2019) published on Nature Communications,

the use of blockchain in this scenario is relevant and

promising. It improves traceability and auditing of

data to the beneﬁt of processes, like the compensa-

tion one, that may occur within a clinical trial (Omar

et al., 2021). In particular, we focus on the follow-

ing challenges that, without loss of generality, can be

extended to other application contexts.

Trustworthy inspection of exchanged data.

Normally, for compensation to be recognised,

data related to the clinical trial (e.g., protocol

setup and registration, individuals enrolment, data

collection methods) must ensure a transparent and

trustworthy inspection by: (i) the trial regulator

subject, which oversees and monitors whether the

steps are adhering to the demanded standards and

requirements; (ii) Health Insurance Organisations

(HIOs), which are involved in the clinical trial

as responsible for corresponding the refund to

individuals when the conditions speciﬁed in

the health contract subscribed by individuals

participating in the trial are met. Exploiting

notarisation on-chain of data exchanged by the

parties helps reducing veriﬁcation time for those

events necessitating mandatory inspection by the

regulator (e.g., in the case of injuries regarding

adverse events).

Automated compliance to standards and rules.

In order to comply with rules and/or standards

established and promoted by the regulator, the

DApps used in the context of the process should

reuse, and possibly extend, SCs provided by the

regulator and made available by means of the

registry. For example, according to this approach,

the implementation of a compensation process as

a DApp would favour the automated compliance

to rules and standards promoted by the regulator.

Assisted DApp design. In order to reduce coding

time and effort, a developer should be supported

in: (a) specifying the features of the SCs to search

from the registry; (b) developing with a proac-

tive support, i.e., specifying the characteristics of

the DApp under development and then being sug-

gested with SCs from the registry that can be in-

cluded into the DApp. For example, through a

proactive support, the developer may be proposed

with the following two SCs, whose adoption per-

mits to comply with the best practices in the devel-

opment of a compensation DApp: a SC providing

a mechanism to temporarily disable compensation

(e.g., in the case the HIO has to modify the com-

pensation policies) and a SC to record data related

to the occurred injuries with the required level of

detail for later inspection (e.g., in the case of com-

plaints).

3 THE MULTI-PERSPECTIVE

DApp MODEL

In the following, we describe the multi-perspective

framework aimed at supporting SC search for DApps

development. As anticipated in the previous section,

SCs are described in a registry, containing both

SCs speciﬁc for the application domain and general

purpose SCs (e.g., from third party registries, such

as OpenZeppelin

). In the application context

considered in this paper, the registry is populated and

maintained over time by a group of expert developers

belonging to/afﬁliated with the regulator subject. SCs

are aimed at addressing common issues a developer

may encounter while creating a DApp compliant

with the standards and procedures envisaged by

the collaborative process. The model (Figure 1) is

http : / / github.com / OpenZeppelin / openzeppelin -

contracts

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

230

Smart Contract

perspective

(SCs)

function call

extends

Legend

Application

perspective

(DApps)

Experience

perspective

(Developers)

Composed Of

Developed By

Has Rated

SCs

relationship

Deployed

Library

Template

DAppDApp

Figure 1: Multi-perspective DApp model.

organised according to three perspectives, describing:

(i) smart contracts; (ii) DApps and (iii) developers.

Smart Contract Perspective. Let SC be the set of

SCs described in the registry. The types of SCs and

their features are represented considering the concep-

tual model in Figure 2, described in detail in the fol-

lowing, and which considers as reference the widely

adopted Ethereum blockchain.

Smart Contracts Model. In our model we use the

term SC in a general sense and hence a SC can be ei-

ther a TemplateContract or a DeployedContract.

A TemplateContract is conceived as a kind of SC

used as a base to build other SCs. In particular,

an AbstractSC is a TemplateContract represent-

ing a template code pattern (i.e., a partially imple-

mented SC or a SC containing at least one func-

tion without any implementation). A Template-

Contract is usually part of a registry publicly avail-

able on the Web (e.g., the OpenZeppelin registry for

the Ethereum blockchain) for which Documentation

is also provided. One or more TemplateContract

may be employed to build (expressed through the

extends relationship in the model) a Deployed-

Contract. As well, a TemplateContract can be

also extended from one or more TemplateContract.

As the name suggests, a DeployedContract re-

sides on the blockchain and, thus, it is endowed

with Endpoint deployment information (i.e, address,

chain ID, network ID for the contract, to locate it

on the blockchain) and with an ABI (Application Bi-

nary Interface), that is metadata describing the SC

interface. A DeployedContract can be either a

ConcreteSC or a LibraryContract, the latter con-

ceived as a SC containing only callable functions,

with no state variables. The functions contained in

a LibraryContract can be called by a ConcreteSC

(function call relationship). Oracle contracts (ei-

ther Abstract or Concrete) are used to access data

from the world outside the blockchain.

Semantic Tags. To provide a semantic characterisa-

tion for SCs, semantic tags are fostered to tackle both

polisemy and homonymy issues of traditional tagging

when searching SCs from the registry. Semantic

tagging is performed by those developers who add

the SC to the registry. During the assignment of tags,

sense disambiguation techniques based on WordNet

lexical database are applied. In WordNet, terms

with the same meaning are grouped into synsets.

Amongst the others, WordNet contains hyponymy

and hypernymy relationships between synsets, used to

represent specialisation and generalisation between

two terms, respectively. A synset has a human

readable deﬁnition and a set of synonyms. When the

developer assigns a tag, all synsets containing that

term are retrieved from WordNet. Each semantic tag

is composed of: (i) the term extracted from WordNet;

(ii) the set of terms in the same synset; (iii) the human

readable description.

In our model, SCs are associated with a descriptor,

which contains information enabling each contract

to be searched by a developer, for subsequent em-

ployment within the DApp under construction. The

descriptor has classiﬁcation features (the type of SC

and the semantic tags) and technical features (e.g.,

the coding language). Depending on the type of SC,

also contract-speciﬁc features may be available (the

attributes belonging to the sub-classes of Smart-

Contract of the conceptual model in Figure 2). The

SC descriptor is formalised as follows.

Smart Contract Descriptor. The descriptor of a SC

https://wordnet.princeton.edu/

A Multi-Perspective Framework for Smart Contract Search in Decentralised Applications Design

231

Smart Contract

Concrete SC

variables[]

constructors[]

functions[]

events[]

balance

DApp

name

description

status

URL

tags[]

Endpoint

address

network_id

chain_id

1..* 1

deployed at

1..*

Usage Rating

rating score

Oracle Smart Contract

ABI

0..1

associated with

Smart Contract

Descriptor

name

author

description

language

tags[]

Library Contract

functions[]

Template Contract

variables[]

constructors[]

functions[]

events[]

0..*

Abstract SC

Deployed Contract

0..*0..*

function call

0..*

extends

Abstract Oracle SC

Developer

skills

Documentation

documentation URL

URL

repository name

extends

0..1

Figure 2: Smart contracts conceptual model for DApps development.

∈ SC is denoted by a tuple

= ⟨type

,{t

},name

,lang

,desc

,CF

⟩

where: (i) type

is the type of the SC; (ii) {t

} is a

set of semantic tags; (iii) name

is the name of the

SC; (iv) lang

is the coding language and (v) desc

is a textual description for the SC. Contract-speciﬁc

features, depending on type

, are included in the set

(if any) and represented as pairs { f eature

{value

}}.

Example. Let us consider Alice, a developer in

charge of designing the compensation DApp intro-

duced in Section 2, on behalf of a HIO, to deploy

the compensation process on-chain. Speciﬁcally,

Alice decides to structure her DApp according to two

core SCs providing the functionalities to: (i) retain

information regarding the policy terms of health

contracts signed by individuals at the beginning

of the trial with the HIO; (ii) encapsulate all the

rules related to compensation logic. To develop

the two former SCs, Alice resorts to the registry

containing, amongst the others the following two

abstract SCs: (a) HealthPolicyContract (in brief,

HPC) which deﬁnes the minimum policy terms each

health contract must hold to be eligible within the

clinical trial, as demanded by the regulator subject;

(b) RecordInjuriesDetailsContract (in brief,

RID), providing the functions to record data related to

the occurred injuries on the blockchain. An excerpt

of the two descriptors for HPC and RID is reported in

the following:

HPC

= ⟨type

HPC

: AbstractSC;

HPC

: ⟨health, {}, “the general condition of body and mind”⟩;

HPC

: ⟨policy, {insurance}, “written contract or certiﬁcate⟩;

of insurance”;

desc

HPC

: “The Health Policy SC speciﬁes minimal data

which is mandatory to be recorded for health contracts”;

[...]

lang

HPC

: Solidity;

HPC

= {variables : {dateStart,dateEnd,

liabilityLimit},...}⟩

RID

= ⟨type

RID

: AbstractSC;

RID

: ⟨health, {}, “the general condition of body and . . . ”⟩;

RID

: ⟨injury,{hurt,harm,trauma},“any physical

damage to the body . . . ”⟩;

desc

RID

: “The Record Injuries Details SC provides base

functions to record injuries-related data”;

[...]

lang

RID

: Solidity;

RID

= { f unctions : {storeInjuryDetails,

storeInjuryType},...}⟩

In the example, contract-speciﬁc features for the two

former AbstractSC are enlisted (e.g., contract vari-

ables and functions).

Application Perspective. Let DA be the set of

DApps built using SCs from the set SC. In our model,

a DApp DA

∈ DA: (i) contains the set of SCs from

the registry {C

} ⊂ SC used to build the DApp;

(ii) has a set {t

} of semantic tags and (iii) is as-

sociated with several technical features like the de-

ployment status status

(e.g., prototype, live), the

description desc

and the URL URL

where the

DApp is published (if it is not a prototype).

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

232

Example. The DApp for the compensation process

from Section 2 is represented as:

Comp

= [

Comp

: ⟨insurance,{indemnity},“protection against

future loss”;⟩;

Comp

: ⟨payment,{},“a sum of money paid or a claim

discharged”;⟩;

Comp

: ⟨refund, {return, repay, give back}, “pay back”⟩;

status

Comp

: prototype;

Comp

} : {IndividualsHCContract :

(HealthPolicyContract),

HIOCompensationContract :

(AccessControlContract,PausableContract,

RecordInjuriesDetailsContract)}]

SCs enclosed by round brackets are the ones coming

from the registry provided by the trial regulator

subject, used for creating the core ones, and consti-

tute the content of the set {C

Comp

}. For instance,

PausableContract and AccessControlContract

are base SCs made available from the OpenZep-

pelin SCs web registry. SCs from the registry are

leveraged by Alice to create the core SCs of her

DApp: IndividualsHCContract retains informa-

tion regarding the policy terms of health contracts,

whereas HIOCompensationContract implements

the compensation logic.

Experience Perspective. Each developer d

∈ D

who uses the SCs from the registry to build her

DApps, is modelled through: (i) the skill σ

for devel-

oping DApps; (ii) a set of usage ratings ⟨C

,DA

,µ

⟩

expressing that the developer rated with a score µ

∈ [0,1] the SC C

when used within the DApp DA

to consider the fact that a SC could be suitable

to be used only in speciﬁc DApps. Developer’s

skill is asked during the registration to the system

according to a discrete set of values (one among

expert, high confidence, medium confidence,

low confidence, unexperienced corresponding to

a value of 1.0, 0.8, 0.5, 0.3, 0.0, respectively). The

score µ

is selected according to a scoring sys-

tem with nine rating options

, to increase reliability

and consistency, ranging from poor (score = 0.2) to

exceptional (score = 1.0).

Example. The following example reports the rat-

ings assigned by the developer Alice from Example 3

to a subset of SCs from the registry, used in DA

Comp

Alice

= ⟨0.8 (high confidence),{⟨HealthPolicyContract,

Comp

,0.8 (excellent)⟩,

⟨RecordInjuriesDetailsContract,

Comp

,0.7 (very good)⟩}.

https://grants.nih.gov/grants/policy/review/rev prep/

scoring.htm

4 SMART CONTRACT SEARCH

AND RANKING

To develop a DApp with the support of our frame-

work, a developer performs three main steps: (i) as-

signment of a set of semantic tags to describe the

functionalities of the DApp; (ii) search of basic SCs

from the registry and composition of these SCs in the

DApp; (iii) assignment of a rating to the SCs from

the registry used for the DApp. Among the three

steps, the challenge we focus on regards the second

step, for which we conceive iterative and progressive

search scenarios for SCs, to support DApps develop-

ers, who start by selecting a single SC and proceeds

composing incrementally the DApp. Indeed, search

scenarios could be fostered either for ﬁnding already

deployed SCs (e.g., to perform a call to a function in a

deployed library) or for the reuse of template SCs. In

a search scenario, we distinguish between the target

and the modality, summarised in Table 1. In particu-

lar, the choice of invoking a search scenarios is tightly

coupled with the development phase of the DApp, as

explained in the following.

4.1 Search Scenarios

The target of the search task could be a single selec-

tion (e.g., when the developer starts the design of a

new DApp) or completion (e.g., looking for SCs to

complete the DApp). Instead, the modality qualiﬁes

how the search is performed:

• simple Search: the developer looks for a SC by

specifying only a set of semantic tags and it is

meant for DApps in their early stage of develop-

ment;

• Advanced Search: it is a variant of the simple

search, fostered by a developer having in mind

also the DApp where the SC will be used, spec-

iﬁed by a set of semantic tags and, possibly, with

the set of SCs already included in the DApp. Ad-

vanced search is suitable for DApps already gath-

ering more than one SC;

• Proactive Search: the developer speciﬁes only the

semantic tags of a DApp and the set of SCs from

the registry included in the DApp, expecting the

system to provide suggestions about SCs to be

added to the DApp, given similar DApps devel-

oped in the past by other developers. Also proac-

tive search is suitable for DApps already gathering

more than one SC.

For advanced and proactive search, there is also the

possibility for a developer to specify the type

the desired SCs, thus resulting in a typiﬁed search

A Multi-Perspective Framework for Smart Contract Search in Decentralised Applications Design

233

Table 1: Speciﬁcation of the request C

depending on the search scenario.

Target

Single Selection

Completion

Simple

〈{𝑡

𝒞

𝑟

}〉

𝑛. 𝑎.

Modality

Advanced

(Typified)

〈{𝑡

𝒞

𝑟

}, {𝑡

𝐷𝐴

𝑟

}〉

(〈𝑡𝑦𝑝𝑒

𝒞

𝑟

, {𝑡

𝒞

𝑟

}, {𝑡

𝐷𝐴

𝑟

}〉)

〈{𝑡

𝒞

𝑟

}, {𝑡

𝐷𝐴

𝑟

}, {𝐶

𝐷𝐴

𝑟

}〉

(〈𝑡𝑦𝑝𝑒

𝒞

𝑟

, {𝑡

𝒞

𝑟

}, {𝑡

𝐷𝐴

𝑟

}, {𝐶

𝐷𝐴

𝑟

}〉)

Proactive

(Typified)

𝑛. 𝑎.

〈{𝑡

𝐷𝐴

𝑟

}, {𝐶

𝐷𝐴

𝑟

}〉

(〈𝑡𝑦𝑝𝑒

𝒞

𝑟

, {𝑡

𝐷𝐴

𝑟

}, {𝐶

𝐷𝐴

𝑟

}〉)

(these variants are conceived for developers with

advanced skill, having a clear idea about the type of

SC needed). Search scenarios are guided through

a set of similarity metrics detailed in the next sections.

Smart Contract Search Request. The general struc-

ture of a search request for SC is deﬁned as the fol-

lowing tuple:

= ⟨type

,{t

},{t

},{C

}⟩ (1)

where: (i) type

is the type of requested SC (only

for typiﬁed search variants); (ii) {t

} is the set of

semantic tags for the searched SC; (iii) {t

} is the

set of semantic tags denoting the DApp DA and (iv)

} is the set of SCs already part of the DApp DA

that is being developed, if any. Elements in Equa-

tion (1) are not all mandatory, as they depend on the

type of search scenario the developer will undertake

(Table 1).

Example. If Alice from Example 3 wants to ﬁnd

a SC aimed at handling exchange rate issues when

corresponding the compensation amount for trial

individuals, she may issue a request compliant with

the completion target and advanced search: ⟨{t

} =

{⟨rate,{charge per unit},“amount of a charge [. . . ]”,

Comp

},{C

Comp

}⟩}.

4.2 Similarity Metrics

SC search leverages the combination of different

metrics, grounded on the elements of the request

and the features retained in the SCs descriptors.

In particular, we consider two distinct metrics, the

semantic Tag Similarity and the DApp Composition

Similarity, which are in turn exploited to compute

the contract and DApp similarity, as explained in the

following.

Semantic Tag Similarity. The semantic similar-

ity between two tags t

and t

is assessed accord-

ing to WordNet, relying on hyponymy/hypernymy

relationships between synsets. In this respect, the

similarity between two tags t

and t

, denoted with

Sim

), is calculated according to the widely

adopted Wu-Palmer semantic similarity score, be-

longing to the range (0,1] and based on the Word-

Net taxonomies (the rationale behind the score cal-

culation and further details can be found in (Wu

and Palmer, 1994)). A value of Sim

() close to 1

means high semantic relatedness between the two

tags. For instance, Sim

(refund,payment) = 0.94

whereas Sim

(rate,payment) = 0.46. Overall, the

similarity between two sets of tags T

and T

, denoted

with Sim

tag

) ∈ (0,1], can be obtained by calcu-

lating the pairwise similarity between a tag belonging

to T

and a tag belonging to T

, applying the formula:

Sim

tag

) =

2 ·

∑

∈T

Sim

)

|+|T

(2)

Pairs of tags to be considered for Sim

tag

are se-

lected in order to maximise the overall Sim

tag

thus ensuring that each tag from the ﬁrst set par-

ticipates in at most one pair with one of the tags

from the second set and vice versa (i.e., apply-

ing the Kuhn’s Hungarian algorithm). Hence, if

we have the two sets T

= {refund, payment}

and T

= {payment,charge} then

Sim

tag

) = 2 · [max(Sim

),Sim

)) +

max(Sim

),Sim

))]/4 = 0.97.

DApp Composition Similarity. To evaluate the simi-

larity between the composition of two DApps, the re-

lated sets of SCs, drawn from the registry, are con-

sidered. In particular, the similarity between a DApp

composed of a set of SCs {C

} and another DApp

composed of a set {C

} considers the number of

common registry SCs between the two sets. The sim-

ilarity Sim

comp

() ∈ [0,1] is assessed with the Dice’s

coefﬁcient over the sets of SCs of the two DApps.

Sim

comp

({C

},{C

}) =

2 · |{C

} ∩ {C

|{C

}|+|{C

(3)

Contract Similarity and DApp Similarity. Seman-

tic tags and DApp composition similarity are fos-

tered to compute two metrics: (i) ContractSim() ∈

(0,1] for evaluating the similarity between the re-

quest C

and a SC from the set SC, according to

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

234

the Smart Contract perspective; (ii) DAppSim() ∈

(0,1] for evaluating the similarity between the re-

quest and a SC in the scope of DApps where

the SC has been used, according to the Appli-

cation perspective. ContractSim(C

,C) considers

only SCs semantic tags, that is ContractSim() =

Sim

tag

({t

},{t

}). Instead, the similarity between the

request and a SC in the scope of a DApp is denoted as

DAppSim(C

,C, DA) and is obtained as follows:

· Sim

tag

({t

},{t

}) + w

· Sim

comp

({C

},{C

})

(4)

where C ∈ {C

} and the set {C

} is the set of

SCs of the DApp DA. For the weights, it holds that

1,2

∈ [0,1], w

+ w

= 1. In single selection target,

no information regarding the SCs used by the DApp

is provided, as a consequence w

= 0. Otherwise, to

balance equally the two terms, w

= w

= 0.5.

The overall similarity measure between the request C

and each SC C (denoted with Sim(C

,C) ∈ (0,1]) is

obtained as:

· ContractSim(C

,C)

(1 − w

)

∑

i=1

∑

|DA|

k=1

(σ

· DAppSim(C

,C,DA

)

|DA|

(5)

where C ∈ DA

and the term multiplied by the fac-

tor (1 − w

), with w

∈ [0,1], considers the fact that

the SC C has been adopted in different DApps by de-

velopers with different development skill σ

, in or-

der to ensure that past experiences of more expert

developers have a higher impact on Sim() calcula-

tion. Intuitively, the closest the σ

and DAppSim()

values to 1 (maximum value) for all the developers

∈ D

, the closest the second term in Equation (5)

to 1.0. The weight w

in Equation (5) is set ac-

cording to the search modality; if a simple search is

performed w

= 1 (no information regarding DApp)

while w

= 0 for a proactive search (only informa-

tion regarding the target DApp is provided). For all

the other cases, to balance equally the two aspects,

= 0.5.

Finally, to limit the number of SCs to be included in

the results, denoted as R(C

), a developer may set a

threshold τ ∈ (0, 1].

4.3 Smart Contract Ranking

The results R(C

) of a SC search are ranked accord-

ing to a function ρ : R(C

) → [0,1] which considers

both the scores given by developers who used the SCs

in their DApps and the technical features of SCs. The

ranking function is deﬁned as follows:

ρ(R(C

)) = α ·ρ

(R(C

)) +

∑

i=1

(R(C

)) (6)

where α ≥ 0, γ

1,...,3

≤ 1 and α +

∑

i=1

= 1 assume all

an equal weight in Equation (6). The computation of

∈ [0,1] adheres to the same rationale of the sec-

ond term of Equation (5), considering ratings as more

important if given by more expert developers:

(7)ρ

(R(C

)) =

∑

i=1

∑

|DA|

k=1

(σ

· µ

· DAppSim(C

′

,DA

)

|DA|

Equation (7) considers the ratings µ

of developers

∈ D

, who used the SC C

′

in DApps from DA.

The DAppSim() similarity is included in the equation

only for completion search target whereas for a simple

search the value of DAppSim() cannot be calculated,

and thus it is replaced with 1. Concerning the calcu-

lation of

(R(C

)), a subset on technical features of

SCs and DApps are considered. In our approach, we

consider the following: (i)

is based on the popu-

larity of the coding language (i.e., the number of SCs

coded with such languages); (ii)

2,3

are based on the

reuse frequency (i.e., the number of DApps the SC is

included in) for live (

) and prototype (

) DApps.

5 RELATED WORK

In the literature, recent research efforts have proposed

frameworks for modelling SCs features and enabling

their subsequent search for DApps deployment. The

reuse of existing SCs code for the development of

real-world DApps has been investigated in (He et al.,

2020), where similarity techniques based on SCs code

comparison are set up to ﬁnd clone SCs in a given

set. The approach in (Guida and Daniel, 2019) de-

vises a conceptual model to foster the reuse of SCs

in a model-driven development environment. With

the aim of understanding functionality and internal

mechanism of SCs, a Uniform Description Language

(named UDL-SC) is proposed in (Souei et al., 2021);

the underlying meta-model focuses on three perspec-

tives: (i) operational, for modelling operations and

events provided by a SC; (ii) technical, regarding

the information of the target blockchain; (iii) busi-

ness, including quality of service details and legal

information. To support collaborative development

in blockchain-oriented software engineering, He et

al. (He et al., 2018) present a speciﬁcation language

for SCs based on a model taking into account parties,

terms (obligations/rights associated with a party) and

A Multi-Perspective Framework for Smart Contract Search in Decentralised Applications Design

235

properties (regarding the object of the contract). To

help users checking their SCs by referencing existing

SCs created and saved in a blockchain platform, the

search engine in (Tran et al., 2019) treats SCs as tex-

tual documents applying Information Retrieval tech-

niques on contracts code to compute a similarity score

between the SC being created and already deployed

SCs. Description and invocation of SCs, in a way that

is independent of the speciﬁc blockchain platform, is

discussed in (Falazi et al., 2020). This work deﬁnes

a protocol for the integration of heterogeneous smart

contracts into application. In their approach, SC de-

scriptions are provided by a dedicated registry.

From a general point of view, our approach shares

some issues with (Guida and Daniel, 2019; He et al.,

2020; Souei et al., 2021; Falazi et al., 2020). How-

ever, with respect to (Guida and Daniel, 2019; Falazi

et al., 2020; Souei et al., 2021), the multi-perspective

framework presented in this paper also includes a se-

mantic and social characterisation of SCs and DApps,

and it provides examples of possible applications in

real search contexts. Additionally, we conceive sev-

eral search scenarios with different types and modali-

ties of search, to cope with developers needs and sup-

porting them in ﬁnding candidate SCs to be used for

DApps development.

6 CONCLUDING REMARKS

In this paper, we proposed a framework to search

for smart contracts to develop distributed applications

(DApps). The considered context is the one of col-

laborative processes where a subject, like a regula-

tory subject, has an interest in stimulating the use

of blockchain to increase transparency and account-

ability among participants, while reducing the burden

of the regulator in controlling trustworthiness among

participants and the compliance with the process stan-

dards. To the scope, the regulator provides a reg-

istry of basic smart contracts that can be used and ex-

tended by stakeholders to set up DApps. The frame-

work, in addition to classiﬁcation and technical char-

acteristics of smart contracts, takes into account the

experience of developers who have used smart con-

tracts to develop DApps. A preliminary implemen-

tation and evaluation of the proposed framework is

in progress. Future research efforts regard the en-

richment of the SCs model, including also additional

features and statistics related to DApps (for instance,

inclusion of KPIs suitable for evaluating the trans-

action volume about a speciﬁc DApp or other usage

statistics). Moreover, experiments will be conducted,

comparing the performance of different variants of

the searching procedure, including other sense disam-

biguation systems (for instance, DBPedia or Babelfy)

for tags.

REFERENCES

Bianchini, D., De Antonellis, V., and Melchiori, M. (2009).

Service-based semantic search in P2P systems. In

ECOWS’09 - 7th IEEE European Conference on Web

Services, pages 7–16.

Cai, W., Wang, Z., Ernst, J. B., Hong, Z., Feng, C., and Le-

ung, V. C. (2018). Decentralized Applications: The

Blockchain-Empowered Software System. IEEE Ac-

cess, 6:53019–53033.

Falazi, G., Breitenb

ucher, U., Daniel, F., Lamparelli, A.,

Leymann, F., and Yussupov, V. (2020). Smart contract

invocation protocol (scip): A protocol for the uniform

integration of heterogeneous blockchain smart con-

tracts. In Advanced Information Systems Engineering:

32nd International Conference, CAiSE 2020, Greno-

ble, France, June 8–12, 2020, Proceedings 32, pages

134–149. Springer.

Guida, L. and Daniel, F. (2019). Supporting reuse of smart

contracts through service orientation and assisted de-

velopment. In 2019 IEEE International Conference on

Decentralized Applications and Infrastructures (DAP-

PCON), pages 59–68.

He, N., Wu, L., Wang, H., Guo, Y., and Jiang, X. (2020).

Characterizing Code Clones in the Ethereum Smart

Contract Ecosystem. In International Conference

on Financial Cryptography and Data Security, pages

654–675.

He, X., Qin, B., Zhu, Y., Chen, X., and Liu, Y. (2018).

SPESC: A speciﬁcation language for smart contracts.

In 2018 IEEE 42nd Annual computer software and ap-

plications conference (COMPSAC), volume 1, pages

132–137. IEEE.

Omar, I. A., Jayaraman, R., Salah, K., Yaqoob, I., and El-

lahham, S. (2021). Applications of Blockchain Tech-

nology in Clinical Trials: Review and Open Chal-

lenges. Arabian Journal for Science and Engineering,

46(4):3001–3015.

Souei, W. B. S., El Hog, C., Sliman, L., Djemaa, R. B., and

Amor, I. A. B. (2021). Towards a Uniform Description

Language for Smart Contract. In 2021 IEEE 30th In-

ternational Conference on Enabling Technologies: In-

frastructure for Collaborative Enterprises (WETICE),

pages 57–62.

Tran, H., Menouer, T., Darmon, P., Doucoure, A., and

Binder, F. (2019). Smart Contracts Search Engine in

Blockchain. In Proceedings of the 3rd International

Conference on Future Networks and Distributed Sys-

tems, pages 1–5.

Wong, D. R., Bhattacharya, S., and Butte, A. J. (2019). Pro-

totype of running clinical trials in an untrustworthy

environment using blockchain. Nature Communica-

tions, 10(1):1–8.

Wu, Z. and Palmer, M. S. (1994). Verb Semantics and

Lexical Selection. In Proceedings of the 32nd An-

nual meeting of the Associations for Computational

Linguistics (ACL), pages 133–138.

ICEIS 2023 - 25th International Conference on Enterprise Information Systems

236
