Enhancing Unit Tests in Refactored Java Programs

Anna Derezińska

and Olgierd Sobieraj

Warsaw University of Technology, Institute of Computer Science, Nowowiejska 15/19, Warsaw, Poland

Keywords: Code Refactoring, Test Maintenance, Unit Tests, Eclipse, IntelliJ IDEA, Java, JUnit.

Abstract: Refactoring provides systematic changes to program code in order to improve its quality. These changes could

also require modifications of unit tests associated with a refactored program. Developer environments assist

with many code refactoring transformations, which also support some modifications of the tests. Two popular

environments for Java programs have been found to be unable to update these tests for all refactoring in a

satisfactory way. The flaws in refactoring, the adaptation of the tests after refactoring, and possible

improvements were discussed. A tool extension has been introduced to integrate with a refactoring in the

Eclipse environment and maintain the corresponding tests. For selected refactorings, additional test cases

could also be created to increase code coverage and improve the testing of a refactored program. Experiments

have been conducted to evaluate the proposed solutions and verify their limitations.

1 INTRODUCTION

Refactoring of programs is one of the important

activities in software development and maintenance

(Fowler, 2018), (Mens and Tourwe, 2004).

Refactoring is associated with program testing in

different ways. First, tests are essential for verifying

the refactoring. However, refactoring a program can

cause changes in the structure of the program.

Therefore, unit tests associated with the refactored

area can become outdated (Gao, et al., 2015). They

require modification according to the completed

refactorings. Moreover, new tests can supplement the

refactored code if it was not covered by tests. In this

paper, we focus on the latter problem: the

maintenance of tests in refactored programs.

We have compared the realization of code

refactoring in two commonly used environments that

support refactoring of Java programs: IntelliJ IDEA

(IntelliJrefactoring, 2023) and Eclipse (Eclipse –

Refactoring, 2023). Many refactorings have been

found to update the tests in a satisfactory way.

However, in several cases, the tests were not modified

or could provide errors. For those refactorings that do

not modify tests or make insufficient adaptations,

refactoring enhancements were proposed.

To solve this problem, we developed a prototype

tool, called RefactorPlugin, that extends the Eclipse

https://orcid.org/0000-0001-8792-203X

IDE. It has been designed to act transparently for a

user and automatically update tests after a refactoring,

if necessary. Besides, in selected refactorings,

additional tests are created to cover the refactored

code and improve the program testing. We conducted

experiments to evaluate the test enhancements and

discuss the limitations of the solution.

The paper is structured as follows. The next

section gives an overview of the background and

related work. In Section 3, we discuss the impact of

refactorings in two Java IDEs on tests and propose

modifications to the test cases. The main features of

RefactorPlugin are presented in Section 4. In Section

5, we discuss the experimental evaluation of the

approach. Finally, Section 6 concludes the paper and

presents future work.

2 BACKGROUND AND RELATED

WORK

We can identify four different ways in which the

refactoring can be combined with a program tests.

1. A subset of tests can be used to verify a

refactoring transformation (Fowler, 2018).

2. Refactoring of the code has an impact on the

code of several tests that should be adjusted in

the corresponding way (Gao, et al., 2015).

734

Derezi

nska, A. and Sobieraj, O.

Enhancing Unit Tests in Refactored Java Programs.

DOI: 10.5220/0011997800003464

In Proceedings of the 18th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2023), pages 734-741

ISBN: 978-989-758-647-7; ISSN: 2184-4895

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

3. During refactoring, new code units (classes,

fields, and methods) could be created, and

therefore, new unit tests could be built that are

devoted directly to those code units.

4. Specialized refactoring transformations can be

designed and applied directly to the code of test

cases (Garousi and Kucuk, 2018).

Experimental verification of any transformation

could be based on checking some invariant

conditions. These invariants could be specified as

tests that a program should pass before and after a

refactoring transformation. Only selected tests of a

program satisfy this requirement. Moreover, such

tests could be designed aimed at a specific refactoring

(Walter and Pietrzak, 2004).

Code refactoring can treat tests as any other code

module of the project. This kind of test modification

could be sufficient in some cases, e.g., for the rename

refactoring. However, in many cases, additional

maintenance of unit tests is necessary to adjust to the

change of code structure; otherwise, the tests become

obsolete (Gao, et al., 2015).

In general, test generation can give quite

satisfactory results (Ramler, Klammer, and

Buchgeher, 2018), (Olsthoorn, 2022). Though,

application of generated tests can be associated with

certain drawbacks, such as a higher maintenance cost,

a larger number of tests than those manually created,

and difficulties in including expert knowledge

(Shamshiri et al., 2018). However, the number of

generated tests is limited, their creation is triggered

by a refactoring, and they are bound to the elements

involved in the refactoring.

Unit test cases, like any other code, could be

analyzed and refactored. There is wide research on

the identification of specialized smells in tests and on

the improvement of tests (Garousi and Kucuk, 2018).

In this paper, we aim only at the second and third

ways of combining refactoring with program tests.

There are different tools that support code

refactoring in an automated way. However, as shown

also in recent research (Eilertsen and Murphy, 2021),

developers still have problems with their basic

usability. One of these directions is automation, both

in the identification of refactoring needs and in

refactoring itself, as proposed with Spartanizer

developed in Eclipse (Gil and Orrù, 2017).

On the other hand, developers often disregard

simple refactoring of test cases that could be

completed by existing tools (Aniche, Treude, and

Zaidman, 2022).

The impact of refactoring on tests was

investigated in experiments (Peruma, et al., 2022). In

a study on three Java projects and regression tests

conducted by (Rachatasumrit and Kim, 2012) was

reported that only 22% of refactored methods and

fields were covered by regression tests. The need for

automated refactoring validation and test update was

suggested due to failed tests after refactoring.

Refactoring in eight open source projects was

identified using RefactoringMiner, and logs of test

execution were investigated (Kashiwa, et al., 2021).

It was observed that most refactoring operations do

not break tests, but occasionally small fixes are

required. The problems mainly referred to add

parameter, change parameter type, and change

return type, i.e., changing a method signature.

There were attempts to extend the refactoring

tools to improve tests influenced by refactoring.

In (Kiran, 2011), TAPE: Test Code Adaptation

Plug-in for Eclipse was reported. It supports only four

transformations (move method, inline method, pull up

method, and rename method) and helps in

synchronizing tests after refactoring. Client code

adaptation is not incorporated in TYPE. Moreover,

the tool works on legacy versions of Eclipse.

An approach based on the detection of changes in

the AST was presented in (Passier, Bijlsma, and

Bockisch 2016). It was implemented in a prototype

for Eclipse. However, the performance could be

questionable if many other changes in the code are

performed, not just refactoring.

Another tool combined with Eclipse was

presented in (Jaradat and Qusef, 2019). A current

version of the tool GreenRef supports three types of

refactoring:

rename method, add parameters, and

remove parameters. It was shown that it noticeably

saved development time compared to manual test

maintenance. The automated maintenance of tests

was based on running tests after refactoring, detection

of misused tests, and their recovery.

3 HOW CODE REFACTORING

DOES INFLUENCE TESTS?

In common practice, a set of unit tests is associated

with a program. After a refactoring transformation

had been realized, the program code would not only

be changed, but in many cases, the corresponding

tests could be automatically modified.

When using tool support, a preview of the code

transformation could be presented to a user before

performing a refactoring. In the interactive mode,

there are usually windows that show the code before

and after refactoring, where the changes can be

observed and accepted. However, the implied test

Enhancing Unit Tests in Refactored Java Programs

735

modifications are not shown altogether, even though,

they are also completed immediately after the

refactoring has been accepted.

3.1 Modifications of Tests

IntelliJ IDEA and Eclipse are popular IDEs that

support refactoring of Java programs. We compared

all available refactorings and investigated their

impact on unit tests. In the analysis and experimental

verification of the impact, unit tests implemented in

JUnit5 were used (JUnit, 2023).

The general findings of our research are

summarized in Table 1. In columns ‘Eclipse’ and

‘IntelliJ_Idea’, a refactoring is indicated by ‘+’ if it is

supported in the IDE, accordingly. The column ‘Test

modified’ includes ‘Yes’ if the corresponding unit

tests were automatically modified after completion of

the refactoring mentioned in this row. If a refactoring

is implemented in both IDEs, then both tools also

modify the tests. If a refactoring is implemented only

in one IDE, then ‘Yes’ confirms the modification of

the test using this tool only. The value ‘No’ stands for

tests that have not been modified in the tool(s) that

implement the refactoring. An ‘Err’ sign indicates

situations that cause errors in tests.

Based on our research, we list the details of the

automated modifications in tests that are caused by

code refactorings in the IDEs (1-17).

While considering the potential influences on

tests, we found that, for selected refactorings, the tests

they affect need some improvements. These cases are

denoted with Roman numerals in the last column of

Table 1. Below, we present our recommendations for

test improvements (I-IX) that should be

complemented. Some recommendations were

evaluated using our tool (Sects 4 and 5).

1. Rename – a name is changed in all places where

a code item is declared, defined, or referenced;

so also in the test code is fixed automatically.

2. Move – Move field/method moves a code

element and automatically adjusts the test code

to the movement of the element.

3. Pull up (I) - if a field or a method is moved to

a base class, a test is automatically modified.

However, there is a problem with duplicated

fields or methods being pulled up to the upper

classes in the inheritance tree. The tools give an

opportunity to block such transformations, but

this could be skipped by a developer. These

duplicates cause errors in tests. Therefore, the

situation should be identified and avoided.

4. Push down (II) - in order to modify tests,

moved methods and fields have to be located,

and their classes should be changed into the

current ones. Additionally, fields and methods

in subclasses could be duplicated due to Push

down. The tools generate warnings about this,

but they could be ignored by a user. Therefore,

in tests, a class that uses a field or method

should be substituted by a current one.

5. Extract (III) - extracted methods do not have

their own dedicated tests; hence, they could not

have to be modified. But, new tests could be

created to cover these new methods.

Table 1: Update of tests after code refactoring.

Reafactoring Eclipse IntelliJ_Idea Tests

modifie

Recommended

test update

1 Rename + + Yes -

2 Move + + Yes -

3 Pull u

++No/Er

4 Push down + + No II

5 Extract + + No III

6 Change method signature + + No IV

7 Convert local variable to fiel

+ - No V

8 Inline metho

++Yes/Er

9 Enca

sulate fields + + Yes -

10 Introduce

aramete

++ No VII

11 Find and replace code duplicates - + Yes -

12 Generalize declared type + - No VIII

13 Re

lace constructor with builde

-+Yes -

14 Infer

eneric t

e ar

uments + - Yes -

15 Re

lace tem

with

uer

-+Yes IX

16 Remove middleman - + Yes -

17 Wrap method return value - + Yes -

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

736

6. Change method signature (IV) - after changes

to method arguments, the method calls in tests

are not changed accordingly. Null values are

substituted instead of values with specific

types. Therefore, a test should be modified in

two cases: (i) the return type of a method was

changed, and it has to be modified consistently

in tests; (ii) the number and types of arguments

of a method were changed; then the method in

tests should be called with the consistent types

of arguments and random values.

7. Convert local variable to field (V) - based on a

local variable, a field is created. Local variables

are not used in tests, that is way, they are not

spoiled. But new fields could be created that are

not covered by the tests. Therefore, the tests

should be extended or additional tests created.

8. Inline method (VI) - the automated

modification of tests could provide errors in

both IDEs. Inline method results in substituting

calling a method by the method body.

Therefore, the code could be simplified, and

some unnecessary methods could be removed.

The refactored tests could be erroneous when

private fields encounter; hence, they should be

corrected in order to compile the tests.

9. Encapsulate fields – the getter and setter

methods of fields are created. The direct access

to these fields is then substituted by the

methods. This kind of substitution is also made

in the tests in an automated way.

10. Introduce parameter (VII) – a new parameter

is introduced to a method signature. Therefore,

a new undeclared parameter can appear in tests.

After refactoring, calls of the refactored

method should be localized in tests and

modified by extending the method with a new

parameter and assigning a random value.

11. Find and replace code duplicates – the

refactoring removes duplicated code, which is

replaced by a method that has the same body.

As a result, the method signatures remain

unchanged, and the modifications in tests are

not provided and not required.

12. Generalize declared type (VIII) – a type is

generalized in the given code place only. When

a generalized field appears in a test or a method

returns a generalized type, then this field or

type should be adapted to the generalized type.

13. Replace constructor with builder – this

replacement of a constructor follows changes

in all places where the considered objects are

created. In IntelliJ IDEA, the appropriate

modifications are automatically provided in

any code, including the test cases.

14. Infer generic type arguments – the generic type

is automatically introduced in all

corresponding code places, including the tests.

15. Replace temp with query (IX) - creation of a

method that substitutes an equation could cause

problems. Therefore, the arguments of the

method used in the tests should be adjusted to

the refactored code.

16. Remove middleman –apart of the refactoring

item, other classes are adjusted accordingly.

Therefore, the tests are automatically modified.

17. Wrap method return value – an additional wrap

class is created during refactoring. This class is

also automatically used in the corresponding

places in the code, including tests.

3.2 Creation of New Tests

The improvement of tests for a refactored code could

not be limited by modification of existing tests. In

some refactorings, new classes, fields, or methods are

created that were not tested before the refactoring.

Therefore, we also suggested creation of additional

basic tests that are related to selected refactorings and

are based on the following principles.

A new test on a public field uses the assignment

of a variable of a consistent type. Then the field value

is compared to the correct value. In a unit test, the

assertEquals assertion is used (JUnit, 2023).

In new tests focused on methods, a method with

appropriate arguments is called. It is checked whether

no unexpected exception(s) is thrown, using the

assertAll or assertDoesNotThrow assertions.

On request, such new tests could be created for the

following refactorings (the numbers match those in

Table 1):

• Pull up (I): If a field or method moved to a

super class is not tested, an object of the super

class is created in a new test. In addition, the

field is verified or the method is tested

(assertAll).

• Push down (II): Apart from correction of tests,

this refactoring can be associated with new

tests. An object of a subclass is created and

either a field or a method is verified

(DoesNotThrow).

• Extract (III): A new method is created,

therefore, a dedicated test is build (assertAll).

• Change method signature (IV): If the changed

method was not used in the tests, a new one is

created (DoesNotThrow).

Enhancing Unit Tests in Refactored Java Programs

737

• Convert local variable to field (V): After

refactoring, a new field is created that is tested

with a variable assignment if it is public

(assertion Equals). Additionally, if the method

with this field was not tested, a new test is built

(DoesNotThrow).

• Introduce parameter (VII): If the modified

method is not used in tests, a new test could be

created (DoesNotThrow).

• Generalize declared type (VIII): If a new

public field is created in the refactoring, a new

test can check the assignment of a variable to

the field newly created. If the generalize refers

to a type returned by a method, in a new test,

the method should be called, and lack of an

exception verified (DoesNotThrow).

4 REFACTORPLUGIN TO

SUPPORT TESTING

The test modification could be combined with the

refactoring in different ways. Tests of a refactored

program could be maintained after a whole

development session, periodically, or on demand.

Alternatively, each refactoring that is accepted by a

developer could trigger an automatic reaction.

In the latter approach, a test suite could be

modified without disturbing the activity of a

developer. A disadvantage is that the modification

only takes into account a single refactoring, while

sometimes a series of correlated ones is made.

Apart from the modification of existing tests, a

tool could also create new tests if the refactored area

is not covered by unit tests. The tests could be added

after a series of refactoring transformations or just

after each refactoring.

An assumption of our solution was to make the

process transparent to a user who refactors a program.

Therefore, the following issues were concerned in the

plugin development:

1. Detection of an event that triggers the plugin.

2. Identification of the refactoring kind and its

attributes.

3. Handling of different kinds of launching a

refactoring that could be selected by a user.

4. Modification of the source code and tests.

The Eclipse framework has an open architecture,

and its functionality can be extended with a plugin

using the Eclipse Plugin Development Environment

(PDE). In Eclipse, there are different events that

could trigger the plugin:

a) change in the AST,

b) completion of a refactoring,

c) adding a log to the refactoring history.

A change in AST can be easily detected, but it

could refer to more than just refactoring. Information

about a just completed refactoring is necessary to

activate a preferred reaction. This information could

be extracted either from an event type detected by a

listener of a refactoring execution or from the recent

We have developed the RefactorPlugin for Eclipse,

which is launched every time when information about

a just completed refactoring is added to the refactoring

history. The refactoring details are extracted from the

argument passed to the history.

In the plugin, the following requirements were

assumed. A test is modified only if a refactoring

transformation has a direct impact on the fields or

methods used in the test. New tests are created for

these fields, methods, and classes that were used in a

refactoring but were not tested before. Therefore, the

tests ensure basic code coverage. Assertions are used

to verify conditions in tests. The recommendations

for the following cases were implemented: I, II, III,

IV, and VII (the numbers as in Table 1).

The RefactorPlugin consists of three main modules:

• refactorplugin – for cooperation with the

refactoring transformation,

• parser – for processing the source code and

building the AST,

• reafctortests – responsible for the modification

and creation of tests.

In order to effectively access and modify the

source code, an AST of the code can be used. There

are several tools that support the parsing of Java code,

such as ANTLR4 (ANTLR, 2023), JavaParser,

coreAST. In RefactorPlugin, parts of the source code

are analyzed using the AST created by ANTL4 with

the Java grammar. The source code of the tests is

modified at the AST level.

5 EXPERIMENTS

The given approach was experimentally evaluated.

5.1 Experiment Setup

The developed RefactorPlugin was applied to a set of

programs of various origins (Table 2) and different

maturity levels of test development. The three first

programs were implemented using Java 13, and the

last one with Java 8. The programs were selected to

require some refactoring because we want to verify

not an artificial but a real development activity. Each

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

738

program was processed with the following steps:

1. measuring the coverage of lines, statements,

and decisions in the code under test,

2. application of a series of refactoring

transformations, some of which caused an

automated modification or creation of tests

by RefactorPlugin,

3. testing with the modified test set,

4. measuring the coverage of lines, statements,

and decisions for the modified test set.

Table 2: Projects used in experiments.

Pro

ect Ori

Blackjac

https://vdawg97.github.io/Blackjack

Simple-Poker https://github.com/andyxhadji/Simple

-Poke

Unit test

enerato

A project of a course on Compiler

Techni

ues

Inheritance-

lesson

https://github.com/jversed/Lesson07_

inheritance

5.2 Experiment Results

Selected program measures calculated before and

after the experiments are given in Tables 3-6, for each

program, accordingly. The numbers of lines and

instructions provided in the top rows of a table refer

to the whole project, including production code and

initial tests (Before) or with all modified and added

tests (After). The values of code lines (LOC) are

counted without comments and white lines.

Table 3: Blackjack.

Pro

ect with tests Before Afte

LOC 319 356

Instruction numbe

1631 1791

Test numbe

2 12

Line covera

e 10.0% 45.8%

Instruction coverage 5.8% 43.6%

Decision covera

e 0% 13.8%

Refactored modules

LOC 237 250

Line covera

e 3.4% 43.2%

Instruction covera

e 1.5% 40.9%

Decision coverage 0% 15.7%

1. Change method signature

2. Convert local variable to field

3. Introduce parameter

4. Change method signature

5. Extract method

6. Introduce parameter

7. Extract method

8. Extract method

9. Change method signature

10. Extract method

In the Blackjack and Inheritance-lesson projects,

only subsets of project modules were refactored.

Therefore, the bottom rows of their tables include

data of only the refactored modules. In the two

remaining projects, all modules were refactored.

Below each table, a sequence of refactorings is

given that was executed on the program. Any

sequence is a real development phase, but others

could also be used, as each refactoring was a single

step, which means that after it, the tests were modified

and/or new ones created. The refactored program

with improved tests was an input for the next step.

Table 4: SimplePoker.

Pro

ect with tests Before Afte

LOC 214 244

Instruction numbe

890 1014

Test numbe

1 9

Line covera

e 1.9% 33.6%

Instruction coverage 0.9% 33.0%

Decision covera

e 0% 20.3%

1. Extract method

2. Change method signature

3. Convert local variable to field

4. Change method signature

5. Change method signature

6. Extract method

7. Introduce parameter

8. Extract method

9. Extract method

10. Change method signature

Table 5: Unit test generator.

Project with tests Before Afte

LOC 1505 1548

Instruction numbe

7752 7950

Test numbe

78 89

Line covera

e 93.1% 93.9%

Instruction covera

e 92.4% 93.2%

Decision coverage 83.2% 84.7%

1. Introduce parameter

2. Change method signature

3. Convert local variable to field

4. Extract method

5. Change method signature

6. Extract method

7. Introduce parameter

8. Convert local variable to field

9. Convert local variable to field

10. Change method signature

11. Extract method

12. Convert local variable to field

13. Extract method

14. Change method signature

15. Change method signature

Enhancing Unit Tests in Refactored Java Programs

739

Table 6: Inheritance-lesson.

Pro

ect with tests Before Afte

LOC 96 104

Instruction numbe

486 515

Test numbe

4 19

Line covera

e 33.3% 52.9%

Instruction coverage 45.3% 61.0%

Decision coverage 0% 5%

Refactored modules

LOC 78 83

Instruction numbe

373 393

Line covera

e 20.1% 43.4%

Instruction coverage 29.8% 49.9%

Decision covera

e 0% 5%

1. Pull up

2. Push down

3. Convert local variable to field

4. Pull up

5. Change method signature

6. Pull up

7. Push down

8. Push down

9. Extract method

10. Introduce parameter

5.3 Discussion

In experiments, all modifications to the tests existing

before a refactoring step were successfully

completed. Both kinds of tests were modified: those

initially delivered with a project and those created

during previous steps of the refactoring sequence. For

example, in the Unit test generator, 5 tests were

modified, while 3 of them were added by the given

refactoring sequence (e.g., after the 14

refactoring, a

test that was added in the 5

step was modified).

The code coverage of the refactored modules

increased considerably, especially for the programs

that did not have many tests before (about 20-40%).

We can also observe an increase in decision coverage,

although it is not as high as line coverage (from a few

percent to 20%). However, the modified or new tests

were not intended to maximize the decision coverage.

In the Blackjack project, each refactoring caused

the creation of a new test. We faced a problem with

fixed arrays specified in a constructor when tests with

random parameters were applied. To avoid this

situation, a detailed method analysis and parameter

tuning in new tests were necessary.

As a result of the refactoring of the Inheritance-

lesson project, 15 new tests were created, which is

more than the number of steps in the refactoring

sequence (10). It was correct due to processing the

push down refactoring (steps 3, 7, and 8). Pushing an

item down in the class hierarchy can move it into

several descendant classes. For each such class, a new

test was created.

5.4 Threats to Validity

As for threats to validity in the conducted studies,

only four programs were evaluated with 10-15

refactorings. Therefore, the sample was quite limited,

and the quantitative results could not be generalized

(external validity). It also causes low statistical

conclusion validity.

Each program was treated by a different

refactoring scenario as the selected transformations

were adjusted to the program structure and its

requirements. Any scenario consists of at least 10

refactoring steps but not all transformations

implemented in the RefactorPlugin were applied to

each program. However, considering the whole

experiment, all kinds of transformations were

covered, which helped alleviate the threat to construct

validity. Furthermore, all automated modifications to

the tests were also manually checked. Any

modification is made just after a refactoring step;

therefore, we could accept the internal validity.

6 CONCLUSIONS

Analysis of the impact of the code refactoring on unit

tests in two Java frameworks showed that in some

cases the tests needed to be maintained manually or

an additional tool support was necessary. This

requirement was partially fulfilled by RefactorPlugin,

which extends Eclipse. Moreover, the developed tool

can create additional tests, especially focused on

items that could not have tests before refactoring.

On the basis of the conducted experiments, we

have made some observations. After a refactoring, the

modified tests could be correctly applied to the

program, assuming the refactoring had not damaged

the code. The plugin is activated automatically after a

refactoring, and its operation is therefore transparent

to a user. The time overhead was not noticeable.

Simple new tests required further enhancements in

some conditions, otherwise they could fail. This poses

the question of whether all such limitations were

taken into account, that is, if all new tests pass. As

expected, the new tests can improve code coverage.

As future work, we can consider the modification

and generation of tests for other refactorings that were

not developed in the current version. However, the

implementation of some of them, like Generalize

declared type, requires keeping the program AST

before and after each modification, which could

ENASE 2023 - 18th International Conference on Evaluation of Novel Approaches to Software Engineering

740

degrade the tool’s performance.

Support for the refactoring process could be

extended, e.g., enhancement of tests could be done

not automatically after each refactoring, but on

demand after a selected refactoring, after a manual

refactoring, or once after a series of refactorings.

More sophisticated test cases could be built or

integrated unit test generators, e.g., EvoSuite,

Randoop, DSpot (Ramler, Klammer, and Buchgeher,

2018), (Roslan, Rojas, and McMinn, 2022).

REFERENCES

Aniche, M., Treude, C., Zaidman, A., 2022. How

Developers Engineer Test Cases: An Observational

Study, In: IEEE Transactions on Software Engineering.

vol. 48, no. 12, pp. 4925-4946. doi: 10.1109/TSE.2021.

3129889.

ANTLR [Online] [Accessed 25 Jan 2023] https://www.

antlr.org/, https://github.com/antlr/antlr4-tools

Baqais, B.A.A., Alshayeb, M., 2020. Automatic software

refactoring: a systematic literature review. Software

Quality Journal. 28, pp. 459-502. doi: 10.1007/s11219-

019-09477-y.

Eclipse – Refactoring [Online] [Accessed 25 Jan 2023]

https://www.tutorialspoint.com/eclipse/eclipse_refacto

ring.htm

Eilertsen, A.M., Murphy, G. C., 2021. The Usability (or

Not) of Refactoring Tools. In: IEEE International

Conference on Software Analysis, Evolution and

Reengineering (SANER), pp. 237-248. doi:

10.1109/SANER50967.2021.00030.

Fowler, M., 2018. Refactoring: improving the design of

existing code (2nd ed.). Addison-Wesley.

Garousi,V., Kucuk, B., 2018. Smells in software test code:

A survey of knowledge in industry and academia. J. of

Systems and Software. Vol. 138, pp. 52-81. doi:

10.1016/j.jss.2017.12.013

Gil, J., Orrù, M. (2017). The Spartanizer: Massive

automatic refactoring. In: IEEE 24th International

Conference on Software Analysis, Evolution and

Reengineering (SANER), pp. 477-481. doi:10.1109/

SANER.2017.7884657.

Gao, Y., Liu, H., Fan, X., Niu, Z., & Nyirongo, B., 2015.

Analyzing Refactoring' Impact on Regression Test

Cases. In: IEEE 39th Annual Computer Software and

Applications Conference (COMPSAC), vol. 2, pp. 222-

231. doi: 10.1109/COMPSAC.2015.16.

IntelliJ refactoring [Online] [Accessed 25Jan 2023]

https://www.jetbrains.com/help/idea/refactoring-source-

code.html

Jaradat, A., Qusef, A., 2019. Automatic Recovery of Unit

Tests after Code Refactoring. In: International Arab

Conference on Information Technology (ACIT),

pp.202-208. doi: 10.1109/ACIT47987.2019.8990974.

JUnit [Online] [Accessed 12 Jan 2023] Available from

https://junit.org/junit5/docs/current/api/index.html

Kashiwa,Y., Shimizu,K., Lin, B., Bavota, G., Lanza, M.,

Kamei, Y., Ubayashi, N., 2021. Does Refactoring

Break Tests and to What Extent? In: IEEE International

Conference on Software Maintenance and Evolution

(ICSME), pp.171-182, doi: 10.1109/ICSME52107.

2021.00022.

Kiran, L., Lodhi, F., Basit, W., 2011. TAPE Test Code

Adaptation Plug-in for Eclipse. Corpus ID: 12838995.

Mens, T., Tourwe, T., 2004. A survey of software

refactoring. In: IEEE Transactions on Software

Engineering, vol. 30, no. 2, pp. 126-139. doi:

10.1109/TSE.2004.1265817.

Olsthoorn, M., 2022. More Effective Test Case Generation

with Multiple Tribes of AI, In: IEEE/ACM 44th

International Conference on Software Engineering:

Companion Proceedings (ICSE-Companion)

, pp. 286-

290. doi: 10.1145/3510454.3517066.

Passier, H., Bijlsma,L., Bockisch, C., 2016. Maintaining

Unit Tests During Refactoring. In: Proceedings of the

13th International Conference on Principles and

Practices of Programming on the Java Platform:

Virtual Machines, Languages, and Tools, no. 18, pp.1-

6. doi: 10.1145/2972206.2972223.

Peruma, A., Simmons, S., AlOmar, E.A. et al., 2022. How

do I refactor this? An empirical study on refactoring

trends and topics in Stack Overflow. In: Empir Software

Eng 27, 11. doi: 10.1007/s10664-021-10045-x.

Rachatasumrit, N., Kim, M., 2012. An empirical

investigation into the impact of refactoring on

regression testing. In: 28th IEEE International

Conference on Software Maintenance (ICSM), pp. 357-

-366. doi: 10.1109/ICSM.2012.6405293.

Ramler, R., Klammer, C., Buchgeher, G. 2018. Applying

automated test case generation in industry: a

retrospective. In: International Conference on Software

Testing, Verification and Validation Workshops, pp.

364-369, IEEE. doi: 10.1109/ICSTW.2018.00074.

Roslan, M.F., Rojas, J.M., McMinn, P., 2022. An Empirical

Comparison of EvoSuite and DSpot for Improving

Developer-Written Test Suites with Respect to

Mutation Score. In: Papadakis, M., Vergilio, S.R. (eds)

Search-Based Software Engineering. SSBSE 2022.

Lecture Notes in Computer Science, vol 13711.

Springer, Cham. doi: 10.1007/978-3-031-21251-2_2.

Shamshiri, S., Rojas, J. M., Galeotti, J. P., Walinshaw, N.,

Fraser, G., 2018. How do automatically generated unit

tests influence software maintenance? In: 11th

International Conference on Software Testing,

Verification and Validation, pp.250-261. IEEE Comp.

Soc. doi: 10.1109/ICST.2018.00033.

Shochat M., Raz O., Farchi, E., 2009. SeeCode – A Code

Review Plug-in for Eclipse. In: Chockler H., Hu A.J.

(eds) Hardware and Software: Verification and

Testing. HVC 2008. LNCS, vol 5394. Springer, Berlin,

Heidelberg. doi:10.1007/978-3-642-01702-5_21.

Walter, B., Pietrzak B., 2004. Automated generation of unit

tests for refactoring. In: Extreme Programming and Agile

Processes in Software Engineering, LNCS vol. 3092, pp.

211--214. Springer. doi: 10.1007/978-3-540-24853-

8_25.

Enhancing Unit Tests in Refactored Java Programs

741
