On the Implementation of a Lattice-Based Revocable

Hierarchical Ibe

Mikael Carmona, Doryan Lesaignoux and Antoine Loiseau

Univ. Grenoble Alpes, CEA, Leti, MINATEC Campus, F-38054 Grenoble, France

Keywords: Revocable Hierarchical Identity-Based Encryption, Lattice-Based Cryptography, Software Implementation,

Performances.

Abstract: Identity Based Encryption (IBE) is a serious alternative of Public Key Infrastructure when considering

distributed systems such as wireless sensors network, multi-site enterprise, manufacturing sites, and so on. In

particular, Revocable Hierarchical IBE (RHIBE) provides all functionalities required for an operational

cryptography deployment. This paper proposes a parameter analysis, and a software implementation of one

of the most advanced post-quantum RHIBE. The objective is to quantify the performances in software and to

provide a concrete set of parameters for a given level of security. For the best of our knowledge, this was not

done from previous works that only provide order of magnitudes about parameters and instances sizes.

Regarding applications and from today, post-quantum RHIBE lead to very large keys and ciphertext size,

letting it difficult to consider such cryptosystems for constraint devices.

1 INTRODUCTION

Identity Based Encryption (IBE) is an alternate to

Public Key Infrastructures (PKI) for deploying

asymmetric cryptography. Based on centralized

master public and master private keys, it avoids the

use of certificates by using the identity directly (i.e.

an identifier) of the recipient as a public key to

encrypt messages. Public keys, secret keys and

decryption keys are derived from the master keys

through a hierarchal structure. Each node of the

structure is able to enroll and revoke new devices

belonging to its substructure. This appears useful to

deploy cryptography in IoT-Cloud context, for

example. IBE simplifies the deployment by avoiding

need of certificates and by only requiring to the

sender the knowledge of the receiver identifier.

IBE state-of-the-art starts in 1984 with Shamir’s

pioneer article (Shamir, 1984). First practical

cryptosystems emerge in 2001 with Weil’s pairing

(Boneh and Franklin, 2001) and residues (Cocks,

2001). Then, several cryptosystems appear to include

more functionalities such as delegation in

Hierarchical IBE (HIBE) in (Gentry and Silverberg,

2002) and Revocation (RIBE and RHIBE) in

(Boldyreva and al., 2008).

The emergence of the quantum threat, breaking

asymmetric cryptography, hurry the NIST to engage

a transition to quantum-resistant cryptography (NIST,

2017). Cryptosystems standardized first around 2024

will be key encapsulation mechanisms and the digital

signatures. In continuity, other cryptosystems such as

IBE are following this transition. However, the post-

quantum transition comes with its issues. The sizes of

keys and ciphertexts of post-quantum (R)(H)IBE are

significantly higher than classical schemes.

From today, it exists quite light ideal-lattice-

based IBE (Ducas and al., 2014) compliant with IoT

devices. However, such post-quantum IBE does not

provide today the functionality of revocation and

delegation. On the other hand, post-quantum RHIBE

are too heavy for constrained devices but have the

required functionalities. However, they are compliant

with cloud resources and it is interesting to have a

better quantification of their performances,

parameters setting and features (sizes of instances).

From the authors' knowledge, only orders of

magnitude are available regarding such post-quantum

RHIBE.

The purpose of this paper is to study one of the

most advanced post-quantum RHIBE (Wang and al.,

2019) named WZH+ scheme from authors’ names.

The objective is to provide concrete parameter sets

and to deduce the sizes and the performances of the

Carmona, M., Lesaignoux, D. and Loiseau, A.

On the Implementation of a Lattice-Based Revocable Hierarchical Ibe.

DOI: 10.5220/0012047800003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 617-623

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

617

scheme with a real implementation on a target

dedicated to embedded applications. The results

highlight the heavy aspect of the scheme that is today

only applicable in a cloud context and cannot be

deployed on IoT devices.

The paper is organized in two sections. Section 2

recalls some basics about IBE. A brief survey of post-

quantum schemes (R)(H)IBE is presented and

highlights the WZH+ as the most efficient post-

quantum RHIBE. Section 3 introduces a software

implementation of the WZH+ with an analysis of the

parameters generation and performances.

2 (R)(H)IBE: CONCEPT AND

POST-QUANTUM SCHEMES

A (H)IBE can be seen as a centralized system based

on a master public key and a master secret key. PKG

(Public Key Generator), also called KGC (Key

Generator Center), generates a master key pair. From

the master secret key, a secret key is derived level-by-

level for each user in the hierarchy. Furthermore, all

users can encrypt a message with the identity of the

recipient and the master public key. The hierarchical

structure is fully dependent on the application

(wireless sensor networks, multi-site enterprise,

manufacturing site, etc.).

A (H)IBE is composed of four primitives:

• Setup for generating the master public key

𝐏𝐏 and the master private key 𝐌𝐊

• Derive (sometimes call KeyGen for a

simple IBE) for secret key generation 𝐒𝐊

from the parent to the children.

• Encrypt for ciphering a message from a user

to another by using the identity of the

recipient

• Decrypt to decrypt a message using the

secret key 𝐒𝐊.

It is important to notice that a (H)IBE does not include

the primitive managing the transmission of the derive

secret key from the generator (the parent) to the user

(the child). The (H)IBE avoids the use of certificates

by dealing only with identity to encrypt messages.

The constraints are mainly deferring on the PKG,

which has to be strongly secure with respect to all

known attacks.

As for all centralized systems, a (H)IBE is not

flexible when a user/an object has to be revoked. The

first approach is to regenerate the entire master and

users keys, except for revoking ones. This full

regeneration of keys is not applicable in practice. In

2008 (Boldyreva and al., 2008), introduce a

mechanism allowing revocation for an IBE. Such

cryptosystems are called R(H)IBE for Revocable

(H)IBE. In practice, a R(H)IBE is composed of the

four primitives composing a (H)IBE and three new

primitives:

• KeyUp to generate the update of the

decryption key when a revocation occurs.

• GenDK to update the decryption key which

uses the secret key 𝐒𝐊 and the update

KeyUp.

• Revoke to update the revocation list

RHIBE and PKI provide the same hierarchical and

revocation features. However, RHIBE gives the

simplest key management, which is balanced by key

sizes.

The security of a (R)HIBE relies on the following

issues: the master public key must not leak

information on the master private key, the ciphertext

confidentiality, and, the decryption key of a child

node shall not leak information on the parent secret

key. (Seo and Emura, 2013) introduced a new

security notion: the resilience regarding decryption

key exposure (DKER). This indicates that if a

decryption key is corrupted at a given time and the

associated users are revoked, this does not

compromise future exchanges between unrevoked

users.

The ability for a (R)(H)IBE to satisfies all these

conditions depends on assumptions of the underlying

problems defining the scheme. There exists two types

of models: the Standard model based on NP-Hard

problems, and, the Random Oracle Model (ROM)

where the security is based on the indistinguability of

the output of a given function/oracle (a hash function

in many cases) with a random uniform instance.

In (Wang and al., 2019), the coexistence of two

models (standard and ROM) is due to the confidence

of the Standard Model is higher than the Random

Oracle Model but this latter provides more efficient

and compact IBE. In particular, for this work, we

study the parameters setting and performances in

software of the WZH+ in the ROM version.

3 STUDY OF WZH+ SCHEME

3.1 Basics on Lattices for (R)(H)IBE

A lattice Λ of ℝ



is a discrete additive subgroup of

ℝ



. Λ is spanned over ℤ by a set of 𝑚 vectors

𝒂



,…,𝒂



of ℝ



, where 0<𝑚≤𝑛, and define a

basis of Λ . Let 𝑨∈ℝ

×

be the matrix whose

columns are vectors 𝒂



,…,𝒂



. By definition Λ(𝑨)

SECRYPT 2023 - 20th International Conference on Security and Cryptography

618

is the lattice of ℝ



spanned by the columns of 𝑨.

Many post-quantum (R)(H)IBE schemes use full rank

lattices Λ(𝑨).

Let 𝑞 an integer and 𝛽>0 a real, a trapdoor of a

matrix 𝑨 is a non-zero vector 𝒙∈ℤ



such that 𝑨𝒙 =

𝟎



mod 𝑞 and 

𝒙

<𝛽 where

 is the Euclidean

norm. For some tuples (𝑛,𝑚,𝑞,𝛽), finding a

trapdoor is a NP-complete problem. A strong

trapdoor is a matrix 𝑻∈ℤ

×

such that 𝑨𝑻 =

𝟎

×

mod 𝑞 and all vectors of 𝑻 have a norm lower

than 𝛽. We denote by

(

𝑨, 𝑻

)

=𝐓𝐫𝐚𝐩𝐆𝐞𝐧(𝑛,𝑚,𝑞,𝛽)

a primitive generating a random uniform matrix 𝑨∈

ℤ



×

and a strong trapdoor 𝑻 of 𝑨. This primitive is

common in lattice-based cryptography for generating

a couple of public key (𝑨) / private key (𝑻).

For a lattice-based HIBE, the delegation relies on

generating a random and strong trapdoor 𝑻′ for a

children node from the strong trapdoor 𝑻 of the

parent node. In the ROM, 𝑻 and 𝑻′ are related to

matrices 𝑨 and 𝑨.𝑹 , respectively, where 𝑨 is a

random uniform matrix and 𝑹 is a pseudo-random

uniform matrix depending on the identity of the node.

The generation of 𝑹 uses the ROM. The primitive

generating 𝑻′ knowing 𝑻 , 𝑨 and 𝑹 , is commonly

called BasisDel (Agrawal and al., 2010).

Two other important notions in lattice-based IBE

are the Hermite Normal Form (HNF) (Micciancio and

Goldwasser, 2002) and the Gram-Schmidt

Orthogonalization (GSO).

For two given matrices 𝑩 and 𝑺 it exists an

algorithm 𝑨 = 𝐓𝐨𝐁𝐚𝐬𝐢𝐬(𝑩, 𝑺)that computes a basis

𝑨 of Λ(𝑩) such that 𝑨







≤𝑺







. This algorithm

allows generating basis of a lattice with a controlled

Gram-Schmidt norm. This is fundamental for

Gaussian sampling as introduced in the next

paragraphs.

By definition, the discrete Gaussian distribution

𝐷

,𝒄,

on a lattice Λ, with standard deviation 𝜎>0

and center 𝒄∈ℝ



is defined as 𝐷

,𝒄,

(

𝒙

)

𝜌

,𝒄

(

𝒙

)

/𝜌

,

(

)

for all 𝒙∈Λ with 𝜌

,

(

𝒙

)

exp

(

−𝜋

‖

𝒙−𝒄

‖



/𝜎



)

, and 𝜌

,

(

)

∑

𝜌

,

(

𝒙

)

𝒙∈

We will note 𝒙←𝐷

,𝒄,

a variable of distribution

𝐷

,𝒄,

. Discrete Gaussian distribution is widely used

in lattice-based cryptography to define the LWE.

A strong property of discrete Gaussian vector 𝒙∈

Λ is the control of the norm: the probability that

‖

𝒙−𝒄

‖

<𝜎

√

𝑛

writes 1−𝜖(𝑛) where 𝜖(𝑛) is a

negligible function with respect to 𝑛.

A Gaussian sampler is a primitive 𝒙=

𝐒𝐚𝐦𝐩𝐥𝐞𝐆(𝑩, 𝜎, 𝒄) where 𝒙←𝐷

,𝒄,

and where 𝑩 is

a basis of Λ. In this work, we use the GPV sampler

(Gentry, 2008) that requires a condition on 𝜎 and

‖

𝑩

‖



to converge: 𝜎≥

‖

𝑩

‖



𝜂





(ℤ) with: 𝜀 =



/(2𝑛) , 𝑛 the dimension of lattice 𝛬(𝑩), 2



the

statistical distance between 𝐷

,,

and the distribution

obtained from the sampler and 𝜂





(

ℤ

)

proportional to

the smoothing parameter of ℤ.

A pre-image of a vector 𝒖∈ℤ





by a matrix 𝑨∈

ℤ



×

is a vector 𝒆∈ℤ





such that 𝑨𝒆 = 𝒖 mod 𝑞.

We denote by 𝒆=𝐒𝐚𝐦𝐩𝐥𝐞𝐏𝐫𝐞(𝑨,𝑻,𝒖,𝜎) the

primitive generating a random pre-image of 𝑨 and 𝒖

with distribution 𝐷

,𝟎,(𝑻)

and using a trapdoor 𝑻 of

𝑨.

Finally, we introduce the LWE (Learning With

Error) problem mainly used in IBE for the encryption

primitive. A LWE instance is based on an uniform

random public matrix 𝑨∈ℤ



×

where 𝑚, 𝑛 and 𝑞

are strictly positive public integers, a random uniform

secret vector 𝒔∈ℤ





, a random discrete Gaussian

(error) vector 𝒆∈ℤ





of known standard deviation 𝛼

and the public vector 𝒕=𝑨 𝒔+𝒆 ∈ℤ





. LWE is NP-

hard if 𝛼𝑞 > 2

√

𝑛

(Regev, 2009). It is important to

know that the concrete security (i.e., computational

complexity to solve a LWE instance) of LWE can be

evaluated from dedicated programs such as LWE-

Estimator (Albrecht, 2015, and dedicated website).

3.2 Parametrization of the WZH+

The WZH+ studied in this paper is a lattice-based,

RHIBE in the ROM (Wang and al., 2019).

WZH+ scheme is parameterized by:

• 𝝀: level of security, specific to the

application

• 𝒅 : maximum depth of the hierarchal

structure, specific to the application

• 𝒏 : number of rows of the public key,

strongly related to the level of security 𝜆.

• 𝒒: arithmetic modulus

• 𝜶: standard deviation of discrete Gaussian

variables in LWE instances

• 𝒎 : determines the private key size and

parameter for TrapGen

•

(

𝝈

𝒊

)

𝒊𝟎,…𝒅

: standard deviations for the

discrete Gaussian variables

• 𝑵: maximum of child nodes for one parent

node

In a complement, we denote 𝜏

ℓ

𝜎

ℓ

√

𝑚

𝜔(



log

(

𝑚

)

), the standard deviation used to

sample Gaussian secret vectors.

The parameters of a cryptosystem are constrained

in four ways: the application, functionality, level of

security and performances. For the WZH+ the

parameters setting needs a specific care to fulfill all

On the Implementation of a Lattice-Based Revocable Hierarchical Ibe

619

requirements. Note that (Wang and al., 2019) only

gives an order of magnitude to set the parameters. In

this section, we provide concrete values for the

parameters of WZH+ for two commonly used levels

of security. The five conditions driving the

parameters constraints are as follows:

1. Achieving a given level of security λ.

2. Be in the conditions where LWE is NP-hard

3. Having a low decryption failure rate

4. Ensuring the convergence of SampleG

5. Ensuring the functionality of TrapGen

About condition 1, the level of security 𝜆 is related to

parameters 𝑛,𝛼 and 𝑞 . 𝜆 is the computational

complexity to solve LWE instances parametrized by

𝑛,𝛼 and 𝑞 . This writes 𝜆= 𝐋𝐖𝐄_𝐄𝐬𝐭(𝑛,𝛼,𝛼𝑞)

where 𝐋𝐖𝐄_𝐄𝐬𝐭 is the best known algorithm for

solving LWE. 𝑛, 𝛼 and 𝑞 has to be to choose to

achieve a level of security greater or equal to 𝜆.

Furthermore, they are constraints by the inequality

𝛼𝑞 ≥ 2

√

𝑛

ensuring that LWE can be reduced to the

NP-hard problem SVP (condition 2). Condition 3

involves parameters used in a Gaussian sampler and

writes 𝛼

[

1+𝑚

(

𝜏



∑

𝜏

…

)

]

<1/5 with

𝜏



=𝜎



√

𝑚

log (𝑚) In addition, the convergence of

Gaussian sampler (condition 4) is verified with 𝜎

ℓ

𝑚

.ℓ.

log(𝑛)

ℓ.

. Finally, parameters 𝑚, 𝑛 and

𝑞 are strongly linked by the condition ensuring the

functionality of TrapGen from (Micciancio and

Peikert, 2012) 𝑚=2𝑘𝑛 ceil

[

log

(

𝑞

)

]

where 𝑘 is an

arbitrary strictly positive integer. This corresponds to

condition 5.

From the conditions recalled above, it is easy to

see that setting all parameters is highly constrained.

We develop a configuration setting software

providing parameters set for a given level of security

𝜆 and depth 𝑑. The used degrees of freedom are 𝑛, 𝛼

and 𝛿. This latter, introduced in (Wang and al., 2019)

is such that 𝑚



=6𝑛



and 𝑚 the closest integer of

𝑚



satisfying condition 5 (equation 4) with the same

𝑞 used for 𝑚. Precisely and firstly, 𝑞 is set at 𝑞=

2𝛼



√

𝑛

ensuring condition 2. Then, a value of 𝑛 and

𝛿 are chosen arbitrarily (in practice, the use of LWE

estimator allows initializing the first values). 𝑚 is

initialized to 6𝑛



and 𝛼 such that inequality of

condition 3 is equality. This is possible because the 𝜎



only depend on 𝑚,𝑛 and 𝑞 which are determined. If

the level of security is not achieved, we increase 𝑛

until achieving it. Then, we decrease 𝛿 and 𝛼 to

ensure that condition 3 is still valid. Then, we find

integer 𝑘 verifying that 2𝑘𝑛log

(

𝑞

)

is the closest to

𝑚=6𝑛



. Then, we modify 𝑚=2𝑘𝑛log

(

𝑞

)

and

check those conditions 3 and 4 are still valid. If it is

not the case, variations on 𝛿 and 𝛼 have to be done

until satisfying all conditions.

Below, we first give two practical parameters set

(i.e., respecting conditions listed above) for two

security levels 𝜆. In table 2, we provide instances size.

This table reveals that for security level that is

commonly used in applications, the sizes of instances

are high. They cannot be considered for embedded

applications but they are compliant with resources

used for cloud computing.

Table 1.

𝒏 = 𝟒𝟎𝟗𝟔, 𝑳 = 𝟐, 𝝀 = 𝟏𝟎𝟓, 𝒌 = 𝟒

𝑚 = 2752512

𝜎



= [2277964473455.1304,

1497970532864220383412224,

985052990719398563678057032830681088]

𝜏



= [80848020546021168,

53164987351470310553961889792,

34960854464866698234190555100447493849088]

𝛼 = 4.0108458310149454𝑒 − 49

log

(

𝑞

)

= 168

𝑞 = 31913467979797562669220565259669898554220729

2834747

𝒏 = 𝟖𝟏𝟗𝟐, 𝑳 = 𝟐, 𝝀 = 𝟐𝟗𝟗, 𝒌 = 𝟔

𝑚 = 8847360

𝜎



= [16035367938144.068,

71315869687241918377885696,

317170974115877910165520524985791152128]

𝜏



= [1100681478931855232,

4895182774817576965287012466688,

217708890878450861416777359785350168188026

88 ]

𝛼 = 2.0261448549063876𝑒 − 52

log(𝑞) = 180

𝑞 = 8716268720886410993567486135302925431631690

55281512793

Table 2: Sizes for a given security level.

Size in bytes

𝐿 = 2,

𝑛 = 4096,

𝜆 = 105

𝐿 = 2,

𝑛 = 8192,

𝜆 = 299

𝐏𝐏

(

2𝑚 + 1

)

𝑛lo

(

𝑞

)

5.4 𝑒



3.3 𝑒



𝐌𝐊 2𝑚



2.5 𝑒



2.0 𝑒



𝐒𝐊

𝐈𝐃

(

2𝑚 + lo

(

𝑁

)

𝑚 2.5 𝑒



2.0 𝑒



𝐊𝐔

𝐈𝐃

𝐭

(

2𝑑 + log(𝑁)

)

𝑚 2.0 𝑒



5.6 𝑒



𝐃𝐊

𝐈𝐃,

𝐭

(

2𝑑 + 1

)

𝑚 2.0 𝑒



5.6 𝑒



(

2𝑑 + 1

)

𝑚lo

(

𝑞

)

3.3 𝑒



1.0 𝑒



3.3 Implementation

The objective of this implementation of the WZH+ is

to quantify the performances in software and to

highlight implementation issues.

The implementation is in Python and we are using

different libraries:

• Cypari2 for linear algebra, such as the

HNF (Cypari2, 2022).

SECRYPT 2023 - 20th International Conference on Security and Cryptography

620

• Numpy for random continuous gaussian

sampling (Numpy, 1995).

• Anytree for the revocation module

(Anytree, 2020).

• Hashlib for hash primitives (Hashlib,

2001)

Our implementation has 256 bits of precision by

default for basic operations such that scalar product

or Euclidean norm computation. However, as

explained below, the precision needs to be strongly

increased within GSO due to numerical instabilities.

Table 3 summarizes the main primitives used for the

implementation.

3.3.1 SampleGaussian

For Gaussian sampling we use the GPV Sampler

(Gentry and al., 2008) instead of other samplers for

general lattices (Peikert, 2009) and (Micciancio and

Peikert, 2012). This sampler is easy to implement and

the convergence condition is part of the parameters

setting (Wang and al., 2019). A specific analysis is

required for two primitives called by the sampler:

GSO and SampleZ. This latter is the Gaussian

sampling in one dimension i.e., when the lattice is ℤ.

To deal with SampleZ and high value of the

standard deviations and centers, we used the Peikert

sampler (Peikert, 2009) applied in dimension 1. This

sampler remains on rounding a continuous Gaussian

random variable: if 𝑥 ~ 𝑁(0,1) then 𝑐 + 𝜎 ×

round

(

𝑥

)

~𝐷

ℤ,,

where round



(

𝑥

)

=round

(

𝑥/

𝑟

)

×𝑟 with 𝑥,𝑟 real. The convergence condition of

this sampler writes: 𝜎



>𝑟



=1. It is verified thanks

to the high standard deviations 𝜎 used in the scheme.

Using higher 𝑟>1 for rounding is possible for an

optimized implementation.

The rounding is realized with primitive floor of

Cypari requiring to maintain at a high level the

accuracy during the computation.

The GSO presents strong numerical instabilities.

During implementation tests, it was detected through

the Gaussian sampling which provides vectors with

norms that do not satisfy the expected bound because

of the instability of the GSO. This is a well-known

problem and is due to the iterative structure of the

computation. It has been shown in (Giraud and al.,

2005) that applying twice the GSO to a matrix

optimized for the stability of the computation.

However, this is not enough to stabilize the GSO

computation because of the high modulus 𝑞 involved

in the scheme (the size of the matrix is not a main

parameter rather than the size of numbers in the

matrix).

A lack of precision in GSO leads to instability in

the Gaussian sampler SampleGaussian, especially

when it is used in a primitive SamplePre with a non-

zero mean. The stability of primitive

SampleGaussian depends on precision within the

GSO of the use basis. When basis coefficients are

bigger, its GSO need to be computed with even more

precision to guarantee stability Gaussian sampler. In

our implementation of the WZH+ with a depth of 2,

we used precision of 2048 bits in the GSO

computation for first-level Derive and KeyUp of

KGC, 3000 bits for second-level Derive and first-

level KeyUp and 4096 bits for second-level DKGen.

3.3.2 BasisDel

For BasisDel, we use the procedure described in

(Agrawal and al., 2010). Implementation of primitive

ToBasis follows original construction in lemma 7.1

of (Micciancio and Goldwasser, 2002). This

algorithm performs matrix calculations in ℤ. It uses

SolveRight primitive that find an integer matrix 𝑿

satisfying the linear system 𝑻𝑿 = 𝑺 where 𝑻 and 𝑺

are known square matrix. Cypari didn’t provide such

a primitive so we implemented SolveRight from

method written in (Hung and Rom, 1990).

Table 3: Summary of all primitives.

Primitive Implementation

Linear Algebra

HNF C

ari

GSO Self-im

lemente

SolveRight mod

Cypari

SolveRight in ℤ

Hung and Rom, 1990

MatrixInversion Cypari

Lattice-Cr

Sam

leZ Peikert, 2009

Sam

leGaussian Gentr

, 2008

TrapGen Miccianci and Peikert, 2012

BasisDel Agrawal and al., 2010

ToBasis

Micciancio and Goldwasser, 2002

RandBasis Cash and al., 2010

Sam

lePre Gentr

, 2008

General-Cr

Seed generation TRNG

Seed extension SHAKE-256

Random Oracle SHAKE-128

Tree

CS.Setup

tree

CS.Assign

tree

CS.Path

tree

CS.Cover

tree

On the Implementation of a Lattice-Based Revocable Hierarchical Ibe

621

Primitive RandBasis, introduced in (Cash and

al., 2010), is used to randomizes basis output by

ToBasis avoiding deterministic construction of

trapdoors. RandBasis outputs, from a given basis, a

new basis that is random with discrete Gaussian

random vectors. It relies on several (but bounded with

𝜎√(𝑚)) calls to Gaussian sampling until generating

a set of linearly independent vectors.

3.4 Performances Analysis

The main feature analyzed for performance analysis

is the timing of each primitive. Due to the huge size

of instances and the global computational complexity,

the performances are computed for a non-practical

(i.e., very low) security level (< 20 bits) with: 𝑑= 2,

𝑛 = 2 , 𝑘 = 2 , 𝑚 = 288 and 𝑞=

79466497377483581 . Illustrations for security

level > 80 bits leads to unpractical computational time

and memory sizes. The implementation run on an

Intel(R) Xeon(R) Platinum 8168 CPU @ 2.70GHz.

To get execution time, we took the average of the

times recorded on 50 executions for each primitive.

Table 4 below provides the execution time of all

primitives of the scheme. The primitives Derive,

KeyUp and DKGen are highly time consuming.

However, in real deployment, these primitives are

called sparsely during the operating lifetime of the

application. To highlight the bottlenecks leading to

such time performances, a specific look to Derive,

KeyUp, DKGen primitives shall be done.

Table 4: Execution of the main primitive of the scheme for

the security level of (< 20 bits) and 2 hierarchical levels.

Primitives Execution time

Setup

Derive 𝑑 = 1

5min17

Derive 𝑑 = 2

10min19

KeyUp KGC

1min50

KeyUp 𝑑 = 1

6min44

DKGen 𝑑 = 2

5min11

Encrypt

15 ms

Decrypt

0.65 ms

For DKGen at the second level ( 𝑑 = 2), it

appears that the main bottlenecks are the following

(linear algebra and lattices) primitives: Inverse matrix

(25%), GSO (14.3%), HNF (42%) and Trapdoor

Generation (15.7%). By doing the same analysis on

other primitives such as KeyUp and Derive, GSO and

HNF also appears as the main and common

bottlenecks.

4 CONCLUSIONS

Post-quantum RHIBE are still heavy schemes, hard to

exploit except is some contexts such as cloud

computing. The proposed implementation provides a

complete parametrization strategy of a complex

scheme, the WZH+ in the ROM model, which is the

most efficient and compact post-quantum RHIBE

from today. The bottleneck (HNF) and critical

operations (such as GSO) require a specific attention

for performance issues. It exists acceleration strategy

that does not avoid the main issue regarding lattice-

based IBE: the size of the instances.

REFERENCES

Agrawal, S., Boneh, D., Boyen., X. (2010). Lattice basis

delegation in fixed dimension and shorter ciphertext

hierarchical IBE, In CRYPTO 2010.

Albrecht, R.M., Player, R., Scott, S. (2015). On the

concrete hardness of Learning with Errors, In Journal

of Mathematical Cryptology 2015. Related website:

https://lwe-estimator.readthedocs.io/en/latest/

Boldyreva, A., Goyal, V., Virendra., K. (2008). Identity-

based encryption with efficient revocation, In CCS’08.

Boneh, D., Franklin M. (2001). Identity-based encryption

from the Weil pairing, In CRYPTO 2001.

Cash, D., Hofheinz, D., Kiltz, E., Peikert, C. (2010). Bonsai

trees or how to delegate a lattice basis, In EUROCRYPT

2010.

Cocks, C. (2001). An identity based encryption scheme

based on quadratic residues, In Cryptography and

Coding 2001.

Ducas, L., Lyubachevsky, V., Prest, T.. (2014). Efficient

Identity-Based Encryption over NTRU Lattices, In

ASIACRYPT 2014.

Gentry, C., Silverberg, A. (2002). Hierarchical ID-Based

Cryptography, In ASIACRYPT 2002.

Gentry, C., Peikert, C., Vaikuntanathan, V. (2008).

Trapdoors for hard lattices and new cryptographic

constructions, In STOC’08.

Giraud, L., Langou, J., Rozloznik, M. The Loss of

Orthogonality in the Gram-Schmidt Orthogonalization

Process, In Computers & Mathematics with

Applications.

Hung, S., Rom, W.O. (1990). An application of the Hermite

normal form in integer programming, In Linear

Algebra and Its Applications.

Micciancio, D., Goldwasser, S. (2002). Complexity of

lattice problems: A cryptographic perspectives, In Book

2002.

Micciancio, D., Peikert, C. (2012). Trapdoors for Lattices:

Simpler, Tighter, Faster, Smaller, In EUROCRYPT

2012.

NIST. (2017). Requirements and Evaluation Criteria for the

PQC Standardization Process, In https://csrc.nist.gov/

Projects/post-quantum-cryptography.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

622

O. Regev. (2019). On lattices, learning with errors, random

linear codes, and cryptography, Journal of the ACM

2009.

Cypari2. (2022). Cypari2 official documentation:

https://cypari2.readthedocs.io/_/downloads/en/latest/p

df/

PARI. (2020). PARI/GP official site: https://pari.math.u-

bordeaux.fr/.

Numpy. (1995). Numpy official site: https://numpy.org/

Anytree. (2020), Anytree official site: https://anytree.readt

hedocs.io/en/2.8.0/

Hashlib, (2001), Hashlib official site: https://docs.python.o

rg/3/library/hashlib.html

Peikert, C. (2009). An Efficient and Parallel Gaussian

Sampler for Lattices, In CRYPTO 2010.

Seo, J.H., Emura., K. (2013). Revocable identity-based

encryption revisited: Security model and construction,

In PKC 2013.

Shamir, A. (1984). Identity-based cryptosystems and

signature schemes. In CRYPTO’84.

Wang, S., Zhang, J., He, J., Wang, H., Li, C. (2019).

Simplified Revocable Hierarchical Identity-Based

Encryption from Lattices, In CANS 2019.

On the Implementation of a Lattice-Based Revocable Hierarchical Ibe

623
