Data Protection and Security Issues with Network Error

Logging

Libor Pol

and Kamil Je

abek

Brno University of Technnology, Faculty of Information Technology, Bo

zet

echova 2, 612 66 Brno, Czech Republic

Keywords:

Network Error Logging, Data Protection, Web Server Management, Web Privacy, Service Worker.

Abstract:

Network Error Logging helps web server operators detect operational problems in real-time to provide fast and

reliable services. This paper analyses Network Error Logging from two angles. Firstly, this paper overviews

Network Error Logging from the data protection view. The ePrivacy Directive requires consent for non-

essential access to the end devices. Nevertheless, the Network Error Logging design does not allow limiting

the tracking to consenting users. Other issues lay in GDPR requirements for transparency and the obligations

in the contract between controllers and processors of personal data. Secondly, this paper explains Network

Error Logging exploitations to deploy long-time trackers to the victim devices. Even though users should be

able to disable Network Error Logging, it is not clear how to do so. Web server operators can mitigate the

attack by conﬁguring servers to preventively remove policies that adversaries might have added.

1 INTRODUCTION

Web server operators need to monitor their servers for

availability, which is a crucial success factor (Franke,

2012). Network Error Logging (NEL) (W3C, 2021)

detects failures in the reachability of web servers, in-

cluding failures during domain name resolution (Bur-

nett et al., 2020). Each HTTP server can employ each

visiting browser

for NEL by adding a NEL header

into the HTTP reply. Consequently, the web server

operator can learn about future failed attempts of the

browser to reach the web server. NEL also allows

to report of successful visits and provides a fallback

mechanism for unreachable logging servers.

The current NEL editor’s standard draft (W3C,

2021) covers various privacy implications of NEL.

For example, an attacker can distribute unique re-

porting URLs for each user; consequently, NEL can

be misused as a supercookie. The paper describing

NEL (Burnett et al., 2020) provides four security, pri-

vacy, and ethical principles: (1) NEL logs existing in-

https://orcid.org/0000-0001-9177-3073

https://orcid.org/0000-0002-5317-9222

At the time of the writing of this paper, Chromium-

based browsers like Google Chrome, Chrome for Android,

Microsoft Edge, Opera, and Opera GF support NEL. Brave

is the only Chromium-based browser that we discovered

does not support NEL.

formation in a different place, (2) NEL logs only re-

quests users voluntarily make, (3) end users can opt

out of NEL, and (4) third parties must not be able to

use NEL to monitor sites they do not control.

This paper has two goals. Firstly, we go through

the law requirements of NEL in the European Eco-

nomic Area (EEA) and show that web server opera-

tors should seek consent from users before installing

NEL policies to browsers. Secondly, we review the

security, privacy, and ethical expectations of the orig-

inal NEL paper (Burnett et al., 2020) and check their

correctness from the user’s perspective.

This paper has several contributions:

1. We are the ﬁrst to analyze NEL law requirements

in EEA.

2. We provide arguments disputing the security,

privacy, and ethical expectation of NEL au-

thors (Burnett et al., 2020) not covered by the cur-

rent NEL editor’s standard draft (W3C, 2021).

3. We are ﬁrst to suggest that web server operators

that do not deploy NEL should conﬁgure their

servers to remove policies that adversaries might

have added. (Je

abek and Pol

ak, 2023) revealed

only a few domains removing NEL, so such con-

ﬁguration is not deployed in the wild.

This paper is organized as follows. Section 2 ex-

plains how NEL works. Section 3 overviews related

PolÄ Ã ˛ak, L. and JeÅ

ZÃ ˛abek, K.

Data Protection and Security Issues with Network Error Logging.

DOI: 10.5220/0012078100003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 683-690

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

683

work. Section 4 analyzes the requirements stemming

from the EEA law. Section 5 disputes the security,

privacy, and ethical expectation of NEL. Section 6

discusses the implications of the results of this paper.

Section 7 concludes this paper.

2 NEL BACKGROUND

NEL was introduced by researchers mostly afﬁliated

with Google (Burnett et al., 2020). The World Wide

Web Consortium (W3C) is in the process of standard-

izing NEL (W3C, 2021). NEL introduces NEL HTTP

header sent by an HTTP server that contains the NEL

policy of the server. In addition, Report-To HTTP

header determines web servers that collect NEL re-

ports for the visited domain.

The goal of NEL is to let web server operators

instruct their visitors to report failures in attempt-

ing to visit the service as well as successful vis-

its. A web server operator can control the fraction

of failures (failure fraction) and success reports

(success fraction), and other parameters in a NEL

policy. The policy is valid for a limited time (max age

parameter of a policy). By default, the policy ap-

plies to the visited domains, but a server can also in-

struct the clients to apply the policy to subdomains

(include subdomains parameter of a policy).

A NEL collector can deploy NEL on its own.

Hence, once a browser learns the NEL policy of a do-

main and sends a report, it learns the NEL policy of

the collector (if deployed). Reports about the collec-

tor are called meta reports (Burnett et al., 2020).

Figure 1 shows an example of a NEL report. The

client reports the age of the error (the browser often

sends messages with a delay) and its type. Addition-

ally, the report contains other information about the

event so that an operator can react to the message.

Browsers store only the last policy retrieved for

each domain.

3 RELATED WORK

(Je

abek and Pol

ak, 2023) analyze HTTP Archive

in a longitudinal study. 11.73 % (almost 2,250,000

unique domains) deployed NEL in February 2023.

Cloudﬂare is the largest NEL provider according to

the study. To our best knowledge, all other papers

concerning NEL utilize NEL as a tool. This paper

is the ﬁrst that puts the NEL design decisions under

scrutiny. Nevertheless, the privacy considerations of

the current NEL editor’s standard draft (W3C, 2021)

cover several issues that this paper does not repeat.

{

"age": 0,

"type": "network-error",

"url": "https://www.example.com/",

"body": {

"sampling_fraction": 0.5,

"referrer": "http://example.com/",

"server_ip": "2001:DB8:0:0:0:0:0:42",

"protocol": "h2",

"method": "GET",

"request_headers": {},

"response_headers": {},

"status_code": 200,

"elapsed_time": 823,

"phase": "application",

"type": "http.protocol.error"

}

Figure 1: An example of a NEL report (W3C, 2021).

Online tracking is omnipresent (Krishnamurthy

and Wills, 2011; Mayer and Mitchell, 2012; Acar

et al., 2020; Information Commissioner’s Ofﬁce,

2019). Cookies holding unique identiﬁers may be ac-

companied or replaced with ETags and other track-

ing mechanisms like browser ﬁngerprinting (Mayer

and Mitchell, 2012). Indeed, NEL can be misused for

online tracking as covered by the privacy considera-

tions of the current NEL editor’s standard draft (W3C,

2021).

The original request-response nature of HTTP has

already been accompanied by other techniques that

allow browsers to communicate with servers without

any explicit user action initiating such communica-

tion. For example, Push API (W3C, 2022b) allows a

previously visited server to push a message without

the user needing to open the web page in the browser.

Nevertheless, the user must consent to allow a site

to access Push API. Hyperlink auditing

allows web

page creators to force the browser to report that the

user clicked a link.

Previous research shows that 48–75 % of web-

sites unintentionally leak identiﬁers and other pri-

vate information in URLs (Krishnamurthy and Wills,

2011; Mayer and Mitchell, 2012). A NEL report

contains both the URL of the previously visited page

(referrer) and the page just visited (success) or bro-

ken page (error report), url. As Referer HTTP

header leaks the previously visited web page URL,

NEL would log the same information as detected

by (Krishnamurthy and Wills, 2011). Nevertheless,

https://html.spec.whatwg.org/multipage/links.html#

hyperlink-auditing

SECRYPT 2023 - 20th International Conference on Security and Cryptography

684

the Referer header already went through scrutiny,

and web pages can regulate the content of the header

NEL applies the same restrictions to the referrer ﬁeld

as the Referer header (W3C, 2021).

An adversary with access to the communication

channel between a web visitor and a web server ac-

cessed by the visitor can deploy a Man In The Mid-

dle (MitM) attack (Conti et al., 2016). As NEL

can be deployed only on TLS channels (W3C, 2021;

Burnett et al., 2020), an adversary would need to

spoof a valid certiﬁcate (Conti et al., 2016), hope that

the victim ignores the error (Sunshine et al., 2009;

Raman et al., 2020), exploit a broken implementa-

tion (Stricot-Tarboton et al., 2016), or remove the en-

cryption (Li et al., 2018). Section 6 builds on the idea

that MitM attacks appear in practice.

4 LAW ANALYSIS

In EEA, ePrivacy Directive regulates publicly avail-

able services and networks (The European Parliament

and The Council of the European Union, 2002; The

European Parliament and The Council of the Euro-

pean Union, 2009; van Hoboken and Zuiderveen Bor-

gesius, 2015). ”Article 5(3) applies to anyone that

stores or accesses information, such as a cookie, on

a user’s device, including if no personal data are

involved.” (van Hoboken and Zuiderveen Borgesius,

2015) Article 29 Working Party (WP29) also consid-

ers ePrivacy Directive to apply to different technolo-

gies, not only cookies (WP29, 2012, Introduction).

In essence, Article 5(3) allows only strictly necessary

access to the user’s terminal device or the access is

needed to carry the communication (WP29, 2012).

Speciﬁcally, the necessity needs to be viewed from

the point of the user, not the service provider (WP29,

2012, Section 5).

Additionally, when personal data are processed,

GDPR (The European Parliament and The Council of

the European Union, 2016) regulates the processing

unless ePrivacy Directive overrides the speciﬁc provi-

sions (Court of Justice of the European Union, 2021,

Recital 74).

NEL requires storing policies in the

browser (W3C, 2021, Process policy headers, step

14). Hence, ePrivacy Directive applies. Although

web server operators view NEL as beneﬁcial (Burnett

et al., 2020), it is not strictly necessary from the point

of the user. One of the four principles of NEL is that

the user can opt out of NEL at any time (Burnett et al.,

2020, Section 3.2, point 3). (Je

abek and Pol

ak,

https://developer.mozilla.org/en-US/docs/Web/

Security/Referer header: privacy and security concerns

2023) show that most web servers do not need NEL to

function. Consequently, neither of the two exceptions

of the ePrivacy Directive applies. Hence, obtaining

consent is necessary before installing a NEL policy.

As the current NEL implementations do not obtain

consent (Burnett et al., 2020; W3C, 2021), the site

operator have to ﬁnd another way to seek consent

before adding NEL headers to its replies.

Additionally, the information reported by NEL

can consist of personal data:

1. Personal data can be embedded in URLs (Krish-

namurthy and Wills, 2011; Mayer and Mitchell,

2012; Commission Nationale de l’Informatique

et des Libert

es, 2022; The Ofﬁce for Personal

Data Protection, 2021). Although the original

NEL paper expects that NEL reports do not con-

tain URL parameters (Burnett et al., 2020, Section

3.4), such a requirement is missing in the current

NEL editor’s standard draft (W3C, 2021). Our ex-

periments conﬁrm that current Google Chrome re-

ports the URL parameters in NEL reports.

2. A dynamic IP address is personal data if there

is a mechanism that identiﬁes the person behind

the IP address (Court of Justice of the Euro-

pean Union, 2016). Up to 60–70 % of HTTP

user-agent strings (UAS) can accurately identify

hosts in some datasets, and the number rises to

80 % when augmented with an IP address (Yen

et al., 2012). Note that the UAS research (Yen

et al., 2012) is old, and today numbers are likely

lower as browser vendors limit the information in

UASes. Even so, later research revealed a long

tail of UASes that may reveal users (Kline et al.,

2017).

3. The latest NEL editor’s standard draft (W3C,

2021) allows operators to request embedding ad-

ditional headers in NEL reports by signaling op-

tional request

headers and response headers

policy members. Personal data can be a part of ad-

ditional HTTP headers reported to the server, such

as ETag (Mayer and Mitchell, 2012), if the origi-

nal server employs such headers for tracking.

Whenever the information collected by NEL con-

sists of personal data, the operator of the original

sever needs to apply additional provisions stemming

from GDPR, like the principle of data minimization,

transparency, and accountability. For example, the

minimization principle requires personal data to be

adequate, relevant and limited to what is necessary

in relation to the purposes for which they are pro-

cessed (The European Parliament and The Council of

the European Union, 2016, Art. 5(1)(c)). As the orig-

inal paper did not ﬁnd much use in reporting URL

Data Protection and Security Issues with Network Error Logging

685

paths (Burnett et al., 2020, Section 3.4), the controller

processing URLs with personal data by NEL would

have hard-time defending the necessity and relevancy

of the processing.

Moreover, the NEL collector operator needs to

follow the rules for processors or joint controllers, in-

cluding accepting a legal contract. As the NEL col-

lector can deploy its own NEL policy, operators of

the NEL meta report collectors are also processors

or joint controllers of the original web server (Eu-

ropan Data Protection Board, 2021) as they process

the IP addresses of the users (Commission Nationale

de l’Informatique et des Libert

es, 2022; Court of Jus-

tice of the European Union, 2016). Hence, they need

to conclude a legal contract as well.

The processors or joint controllership brings fur-

ther obstacles to the operators of collectors that add

NEL headers. Consider that a group of distinct web

servers share a single collector C that adds a NEL

header. Furthermore, suppose that the visitor already

reported from web server A to C, so the NEL policy

for C to report to C

is already installed in the browser.

Later, the same visitor visits B and installs the NEL

policy from B to report to C. Afterwards, both B and C

become inaccessible. Consequently, the browser will

report an error to C

. Figure 2 shows the communica-

tion diagram.

Figure 2: The browser reports an error of C.

However, as the browser learned the policy for C

through communication with A, both A and B need

to share the same joint controllers and processors.

That is indeed legal. However, both A and B must

have the possibility to remove processors or joint con-

trollers from the processing chain (Europan Data Pro-

tection Board, 2023). Technically, different chains

of collectors can be formed by operating the collec-

tors for A and B with different domain names; for

example, A.C.example and B.C.example. The down-

side of such an approach is that the browser cannot

learn the collector of B.C.example through interaction

with A and its collectors, see Figure 3. Consequently,

should web server B and its collector B.C.example not

be accessible simultaneously (modiﬁed scenario from

above in Figure 3), the browser would not report the

problem with B.C.example.

Articles 12-14 of GDPR list requirements on the

Figure 3: The browser cannot report an error of

B.C(.example).

information that a data controller should reveal to

each data subject before the data processing starts or

in a reasonable time afterwards. Processing in the

scope of ePrivacy Directive yields the same require-

ments on transparency (ePrivacy Art. 5(3), GDPR

Art. 94(2)). Hence, each controller employing NEL

needs to reveal transparent information about data

collection, for example, in the privacy policy.

5 NEL SECURITY, PRIVACY, AND

ETHICS ANALYSIS

The original NEL paper (Burnett et al., 2020, Section

3.2) explains four security, privacy, and ethical princi-

ples. This section disputes the NEL design and argues

that the principles are not fulﬁlled. Furthermore, the

current NEL editor’s standard draft (W3C, 2021) does

not remedy the ﬁnding of this section.

5.1 Can NEL Data Leak to Third

Parties?

Principle 1 establishes that NEL stores existing in-

formation in a different place. NEL policy deter-

mines the storage. The 4th principle expects that third

parties must not monitor users through NEL. Hence,

third parties should not be able to install their col-

lectors. Nevertheless, the same paper (Burnett et al.,

2020, Section 3.3) warns that the assumption holds

only without any tampering with the certiﬁcate vali-

dation mechanism. The paper rightly points out that

an adversary having the power to circumvent the val-

idation mechanism can tamper with the HTTP data

by other means, for example, by injecting additional

JavaScript.

However, the original paper, as well as the current

NEL editor’s standard draft (W3C, 2021), does not

highlight the persistence of the NEL policy. The in-

jection capabilities of the adversary are effective only

during the time that the adversary is in the MitM po-

SECRYPT 2023 - 20th International Conference on Security and Cryptography

686

sition. Although the browser can cache the malicious

content and the JavaScript injection attack can be ef-

fective some time after the adversary leaves the MitM

position, the cached content is likely to be replaced

by updates on the server or evicted due to the limited

size of the cache.

Nevertheless, adversaries with the ability to insert

their JavaScript code can also deploy Service Work-

ers (W3C, 2022a) that can act as a proxy between the

visited page and its server. However, the scope of Ser-

vice Workers is limited to subpaths of the path where

their worker script is located. Consequently, a Service

Worker sees all requests and replies of the subpath on

the web server, can initiate requests, and can inﬂuence

the content of the replies.

Similarly, a NEL policy stays on the device for the

whole duration speciﬁed by the policy unless replaced

by a new policy sent by the server. The current NEL

editor’s standard draft (W3C, 2021) does not limit

the maximal duration of the policy, so it can effec-

tively be installed for eternity (for example, hundreds

of years). For domains that do not signal NEL, the

maliciously installed policy would be removed only

when the user clears data stored in the browser. Un-

like Service Workers, NEL policies do not have scope

limitations.

Neither the original paper nor the current NEL

editor’s standard draft (W3C, 2021) consider adver-

saries that appear on a minority of web servers that al-

low users to inject their content, like blogs or personal

web pages. For example, such a user can create their

content on a speciﬁc URL path on the server. Some

of these servers allow users to modify HTTP headers.

Such rogue content creators can deploy NEL (as well

as Service Workers) on their part of the web server.

A na

ıve assumption is that NEL does not increase

the powers of an adversary and only brings an addi-

tional tool. However, we identiﬁed three scenarios

where NEL creates additional risks compared with

Service Workers:

• A NEL policy applies to all pages on the domain

that deploys NEL (and possibly subdomains). In

contrast, the scope of Service Worker is limited.

Hence, NEL increases the powers of rogue con-

tent creators that control only limited paths on the

server as their NEL collector would see all brows-

ing activities of the visitors with the web server

after their visit of the malicious part of the web

server. In contrast, Service Worker would only see

HTTP trafﬁc concerning the subpath of the web

server.

• Some browser extensions block JavaScript

or Service Workers (Pol

ak et al., 2023;

Michael Schwarz and Gruss, 2018)

. We tested

NoScript 11.4.16 in Chrome, and the extension

does not block NEL. Consequently, NEL allows

adversaries like TLS MitM proxies and rogue

content creators to sniff on trafﬁc of users

protected from Service Workers.

• Suppose that an adversary ﬁnds a bug that allows

to inject HTTP headers and, thus, NEL headers.

Even if a single page on a domain was affected by

such a bug, the adversary would be able to moni-

tor the trafﬁc of the visitors of the vulnerable page

on the whole domain and its subdomains. Note

that the hypothetical bug does not require that the

attacker has the ability to run JavaScript code in

the visiting browsers that is needed to install Ser-

vice Workers.

Neither the original paper nor the current NEL ed-

itor’s standard draft (W3C, 2021) discuss such or sim-

ilar scenarios.

Web server operators that deploy NEL do not suf-

fer from the risk as the legitimate policy replaces the

malicious policy during the next visit. We recom-

mend that other web server operators add policies

with max age=0. The duration of 0 forces the browser

to remove any previously stored NEL policy for the

domain, including the policies adversaries may have

inserted in the past. (Je

abek and Pol

ak, 2023) re-

ports less than ten domains removing NEL policies in

each analyzed year, so we conclude that we are the

ﬁrst to promote the advice publicly.

We believe that signalling NEL policy removal

does not trigger the legal issues identiﬁed in Section 4

with NEL in EEA, as the recommended policy would

not remove any NEL policy under normal circum-

stances. Hence, ePrivacy Article 5(3) would not be

triggered. A malicious policy would not be requested

by the user, so it is not necessary to provide the ser-

vice. As the web server operator has to process per-

sonal data securely (GDPR, Art. 32), ensuring that

browsing history does not leak to an adversary is in

the spirit of the law.

5.2 Does NEL Provide Data Only when

Users Voluntarily Access the

Service?

A user or a network operator can deploy DNS ﬁre-

wall, for example, by changing the host ﬁle or the lo-

cal DNS resolver (

Spa

cek et al., 2019). Consequently,

For example, Google Store reports that

more than 100,000 users installed NoScript

(https://chrome.google.com/webstore/detail/noscript/

doojmbjmlfjjnbmnoijecmcbfeoakpjm).

Data Protection and Security Issues with Network Error Logging

687

the DNS ﬁrewall returns invalid IP addresses for do-

main queries of the blocked domains. So, for exam-

ple, if a web page A includes content from a blocked

domain D, the browser cannot access the server of D

as the DNS returns an invalid IP address.

However, NEL policies installed before the de-

ployment of such a DNS ﬁrewall stay in place. Hence,

the browser would report to the collector of the

blocked domain (if the collector is not also blocked)

that the IP address of the server changed, the IP ad-

dress to which the DNS ﬁrewall remaps the domain,

and the IP address of the computer running behind the

DNS ﬁrewall.

We argue that the user or the operator that de-

ployed the DNS ﬁrewall took active measures against

accessing the blocked domains. Despite this, NEL re-

veals the DNS ﬁrewall to the blocked party.

Another scenario where NEL can be exploited to

report to services that users do not access voluntarily

is online advertisement. Some data protection author-

ities (Information Commissioner’s Ofﬁce, 2019) re-

port that people are often not aware of the queries of

their browsers interacting with online advertisement

business. Suppose that one of these companies de-

ploys NEL. We argue that if the data protection au-

thorities claim that the online advertisement process-

ing is ”disproportionate, intrusive, and unfair” (In-

formation Commissioner’s Ofﬁce, 2019), users do not

voluntarily access such services. Hence, in this sce-

nario, NEL would track HTTP services that the users

are unaware of and thus do not access voluntarily.

5.3 Can end Users Opt out of NEL?

Both the original NEL paper (Burnett et al., 2020) and

the current NEL editor’s standard draft (W3C, 2021)

expect that the users can opt out of NEL. However,

we cannot ﬁnd any option to disable NEL in Google

Chrome 110 either in settings or in chrome://flags,

even though we went through the settings option-by-

option. Moreover, we tried to seek help from Google

Search. However, the engine did not return any result

for queries ”chrome disable network error logging”

and ”chrome disable nel” neither on the whole web

nor on stackoverﬂow.com; for each query, we went

through the ﬁrst 50 results offered by the search en-

gine. Even more, we asked a long-term Chrome user

who is a Ph.D. student of IT to help us. He was not

able to deactivate NEL during 15 minutes of active

trying.

We argue that if Chrome offers a setting to dis-

able NEL, it is hidden and cannot be easily located by

regular users.

6 DISCUSSION

This section discusses the results of this paper.

6.1 A Ticking Data Protection Bomb

(Je

abek and Pol

ak, 2023) report that more than

11.7 % of domains deploy NEL. Yet, Section 4 argues

that users in EEA need to consent to NEL. Conse-

quently, the operators of the web servers deploying

NEL may be in conﬂict with the law. However, the

number of 11.7 % is an upper bound. Not all of the

domains are in the scope of the ePrivacy Directive.

Additionally, previous work (Trevisan et al., 2019)

shows a heterogeneous implementation of the ePri-

vacy Directive by the EU (European Union) member

states. Hence, some operators in the EU might not vi-

olate the law due to the incorrect implementation of

the ePrivacy Directive in their state.

The plan is to replace ePrivacy Directive with a

Regulation

. Initially, the plan was to replace the Di-

rective on the same day as GDPR entered into force.

Yet, as of the writing of this paper in February 2023,

the ﬁnal text of the new Regulation is not known. Nei-

ther the text proposed by The European Commission

nor the proposed amendments by The European Par-

liament (EP) change the requirement for consent to

store NEL policy in a browser. However, The Coun-

cil of the European Union (Council) version provides

amendment Article 8(1)(da) that would allow using

storage capabilities of terminal equipment to detect

technical faults for the duration necessary.

The authors of this paper interpret the Council Ar-

ticle 8(1)(da) as allowing NEL policies with 0 success

fraction, provided that the operator erases the logged

data when each failure is detected and mitigated.

As of the time of the writing of this text, it is not

clear if an exception like the Council Article 8(1)(da)

propagates to the ﬁnal ePrivacy Regulation. Once the

Council and the EP agree on the ﬁnal text of the Reg-

ulation, there should be a 2-year transition period be-

fore the new Regulation takes effect.

6.2 Cloudﬂare

Cloudﬂare is the largest NEL collector

provider (Je

abek and Pol

ak, 2023). Let us

focus on their data protection information.

The public information on NEL support is con-

fusing. The Get started guide looks like the web op-

See the procedure and related documents at https:

//eur-lex.europa.eu/legal-content/EN/HIS/?uri=CELEX:

52017PC0010

SECRYPT 2023 - 20th International Conference on Security and Cryptography

688

erators need to explicitly enable NEL

. However, on

another page, Cloudﬂare informs its customers that

they ”can opt out of having their end users consume

the NEL headers by emailing Cloudﬂare support”

Some customers report that they cannot see NEL an-

alytics on their dashboard

. The customers speculate

that Cloudﬂare uses NEL data internally.

Cloudﬂare stores IP addresses only in volatile

memory to estimate the physical and network location

of the user and determine if the user changed the IP

address recently

. It seems that Cloudﬂare interprets

the law that the volatility of the storage means that it

does not process personal data. However, the French

data protection authority (Commission Nationale de

l’Informatique et des Libert

es, 2022) recently treated

IP addresses in Google Analytics as personal data.

Even though Google Analytics trims the addresses

shortly after the arrival, there is a period when full ad-

dresses are available, and consequently, personal data

are processed.

If Cloudﬂare enabled NEL without the awareness

of their customers, Cloudﬂare would be guilty of

breaching the ePrivacy Directive and likely breach-

ing GDPR Art. 28(3)(a) as it processes personal data

without such instructions of the controller during pro-

cessing that is in the scope of the supposedly breached

EEA law.

An analysis of other NEL players’ data protection

issues is out of the scope of this paper as each deploy-

ment needs to be analyzed individually. Furthermore,

we are not Cloudﬂare customers, so the data pro-

tection analysis did not consider information agreed

upon between Cloudﬂare and its customers, like the

contracts.

7 CONCLUSION

Error monitoring is a crucial activity of web server op-

erators. Even though Chromium-based browsers have

supported NEL for several years, the ongoing NEL

standardization received little academic scrutiny. To

our best knowledge, neither the European Data Pro-

tection Board nor its predecessor WP29 issued any

opinion or guidelines about NEL.

This paper identiﬁed several NEL deﬁciencies

from the European data protection view. First of all,

https://developers.cloudﬂare.com/

network-error-logging/get-started/

https://support.cloudﬂare.com/hc/en-us/articles/

360050691831-Understanding-Network-Error-Logging

https://community.cloudﬂare.com/t/

access-to-network-error-logging/472139

See footnote 7.

the authors of this paper interpret the law as requir-

ing consent before an operator can install a NEL pol-

icy. However, NEL is supposed to be opt-out (Burnett

et al., 2020; W3C, 2021), so there is no built-in way to

seek consent (opt-in). Moreover, web operators need

to be cautious about personal data reported by NEL

as they trigger additional requirements on data mini-

mization, transparency, and accountability.

Although the security, privacy, and ethics analysis

of the original paper (Burnett et al., 2020) supposes

that NEL data cannot leak to third parties, NEL pro-

vides data only when users voluntarily access the ser-

vice, and end users can opt out of NEL, our paper pro-

vides counter-arguments explaining that the expecta-

tions are not valid in all cases. Most strikingly, we

failed to opt out of NEL in Chrome.

ACKNOWLEDGMENTS

This work was supported by the Brno University of

Technology grant Smart information technology for a

resilient society (FIT-S-23-8209).

REFERENCES

Acar, G., Englehardt, S., and Narayanan, A. (2020). No

boundaries: data exﬁltration by third parties embed-

ded on web pages. Proceedings on Privacy Enhancing

Technologies, 2020:220–238.

Burnett, S., Chen, L., Creager, D. A., Eﬁmov, M., Grig-

orik, I., Jones, B., Madhyastha, H. V., Papageorge, P.,

Rogan, B., Stahl, C., and Tuttle, J. (2020). Network

error logging: Client-side measurement of end-to-end

web service reliability. In 17th USENIX Symposium

on Networked Systems Design and Implementation,

NSDI 2020, pages 985–998. USENIX Association.

Commission Nationale de l’Informatique et des Lib-

ert

es (2022). EDPBI:FR:OSS:D:2022:330.

https://edpb.europa.eu/system/ﬁles/2022-08/

fr 2022-02 decisionpublic redacted 0.pdf.

Conti, M., Dragoni, N., and Lesyk, V. (2016). A survey

of man in the middle attacks. IEEE Communications

Surveys & Tutorials, 18(3):2027–2051.

Court of Justice of the European Union (2016). Case

C-582/14: Patrick Breyer v. Bundesrepublik Deutsch-

land. ECLI:EU:C:2016:779.

Court of Justice of the European Union (2021). Case

C-645/19: Facebook Ireland Ltd, Facebook Inc.,

Facebook Belgium BVBA v. Gegevensbescher-

mingsautoriteit. ECLI:EU:C:2021:483.

Europan Data Protection Board (2021). Guidelines 07/2020

on the concepts of controller and processor in the

GDPR. https://edpb.europa.eu/system/ﬁles/2021-07/

eppb guidelines 202007 controllerprocessor ﬁnal

en.pdf, Version 2.1.

Data Protection and Security Issues with Network Error Logging

689

Europan Data Protection Board (2023). 2022 Coordinated

Enforcement Action - use of cloud-based services by

the public sector . https://edpb.europa.eu/system/ﬁles/

2023-01/edpb 20230118 cef cloud-basedservices

publicsector en.pdf.

Franke, U. (2012). Optimal IT service availability: Shorter

outages, or fewer? IEEE Transactions on Network

and Service Management, 9(1):22–33.

Information Commissioner’s Ofﬁce (2019). Update

report into adtech and real time bidding. https://

ico.org.uk/media/about-the-ico/documents/2615156/

adtech-real-time-bidding-report-201906.pdf.

abek, K. and Pol

ak, L. (2023). Network error logging:

HTTP archive analysis. Preprint at https://arxiv.org/

abs/2305.01249.

Kline, J., Barford, P., Cahn, A., and Sommers, J. (2017). On

the structure and characteristics of user agent string. In

Proceedings of the 2017 Internet Measurement Con-

ference, page 184–190, New York, NY, USA. Associ-

ation for Computing Machinery.

Krishnamurthy, B. and Wills, C. (2011). Privacy leakage vs.

protection measures: the growing disconnect. In Pro-

ceedings of the Web 2.0 Security and Privacy Work-

shop.

Li, X., Wu, C., Ji, S., Gu, Q., and Beyah, R. (2018). HSTS

measurement and an enhanced stripping attack against

HTTPS. In Security and Privacy in Communication

Networks, pages 489–509, Cham. Springer Interna-

tional Publishing.

Mayer, J. R. and Mitchell, J. C. (2012). Third-party web

tracking: Policy and technology. In 2012 IEEE Sym-

posium on Security and Privacy, pages 413–427.

Michael Schwarz, M. L. and Gruss, D. (2018). Javascript

zero: Real javascript and zero side-channel attacks. In

Network and Distributed Systems Security Symposium

2018.

Pol

ak, L., Salo

n, M., Maone, G., Hranick

y, R., and McMa-

hon, M. (2023). JShelter: Give me my browser back.

In Proceedings of the 20th International Conference

on Security and Cryptography. SciTePress - Science

and Technology Publications.

Raman, R. S., Evdokimov, L., Wurstrow, E., Halderman,

J. A., and Ensaﬁ, R. (2020). Investigating large scale

https interception in Kazakhstan. In Proceedings of

the ACM Internet Measurement Conference, IMC ’20,

pages 125–132, New York, NY, USA. Association for

Computing Machinery.

Stricot-Tarboton, S., Chaisiri, S., and Ko, R. K. (2016).

Taxonomy of man-in-the-middle attacks on HTTPS.

In 2016 IEEE Trustcom/BigDataSE/ISPA, pages 527–

534.

Sunshine, J., Egelman, S., Almuhimedi, H., Atri, N., and

Cranor, L. F. (2009). Crying wolf: An empirical

study of SSL warning effectiveness. In Proceedings of

the 18th Conference on USENIX Security Symposium,

SSYM’09, pages 399–416. USENIX Association.

The European Parliament and The Council of the European

Union (2002). Directive 2002/58/EC. Directive on pri-

vacy and electronic communications. Ofﬁcial Journal

L 201.

The European Parliament and The Council of the European

Union (2009). Directive 2009/136/EC. Ofﬁcial Jour-

nal L 337.

The European Parliament and The Council of the European

Union (2016). Regulation 2016/679/EU. General Data

Protection Regulation (GDPR). Ofﬁcial Journal of the

European Union L 119, 4.5.2016.

The Ofﬁce for Personal Data Protection (2021). State-

ment on the reservation system for covid-19 vacci-

nation. https://www.uoou.cz/en/vismo/dokumenty2.

asp?id org=200156&id=2011.

Trevisan, M., Travers, S., Bassi, E., and Mellia, M. (2019).

4 years of EU cookie law: Results and lessons

learned. Proceedings on Privacy Enhancing Tech-

nologies, 2019:126–145.

van Hoboken, J. and Zuiderveen Borgesius, F. (2015).

Scoping electronic communication privacy rules:

Data, services and values. Journal of Intellec-

tual Property, Information Technology and Electronic

Commerce Law, 6(3):198–210.

W3C (2021). Network error logging. The World Wide

Web Consortium (W3C) internal document, https://

w3c.github.io/network-error-logging/, Editor’s Draft

of 30th July 2021.

W3C (2022a). Push API. The World Wide Web Con-

sortium (W3C), Web Applications Working Group,

https://www.w3.org/TR/push-api/, Working Draft of

30 June 2022.

W3C (2022b). Service workers nightly. The World Wide

Web Consortium (W3C), Service Workers Working

Group, https://w3c.github.io/ServiceWorker/, Editor’s

Draft of 28 November 2022.

WP29 (2012). Opinion 04/2012 on Cookie Consent

Exemption. Article 29 Data Protection Working

Party, WP 194, https://ec.europa.eu/justice/article-29/

documentation/opinion-recommendation/ﬁles/2012/

wp194 en.pdf.

Yen, T.-F., Xie, Y., Yu, F., Yu, R. P., and Abadi, M. (2012).

Host ﬁngerprinting and tracking on the web: Privacy

and security implications. In Network and Distributed

System Security (NDSS) Symposium.

Spa

cek, S., La

stovi

cka, M., Hor

ak, M., and Plesn

ık, T.

(2019). Current issues of malicious domains blocking.

In 2019 IFIP/IEEE Symposium on Integrated Network

and Service Management (IM), pages 551–556.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

690
