ZT-NIDS: Zero Trust, Network Intrusion Detection System

Abeer Z. Alalmaie

, Priyadarsi Nanda

and Xiangjian He

School of Electrical and Data Engineering, University of Technology Sydney, Sydney, Australia

School of Computer Science, University of Nottingham, Ningbo, China

Keywords: Zero Trust, Network Intrusion Detection, Network Security, CNN-BiLSTM, Attention, Cybersecurity.

Abstract: Zero Trust security can tackle various cyberthreats. Current trends in security monitoring must shift to a

“never trust, always verify” approach, as data security is threatened when cloud-based third parties access

network traces. Network Intrusion Detection System (NIDS) can be exploited to detect anomalous behaviour.

Convolution Neural Network (CNN), Bi-directional Long Short Term Memory (BiLSTM) based classifiers

and Auto-Encoder (AE) feature extractors have presented promising results in NIDS. AE feature extractor

can compress the important information and train the unsupervised model. CNNs detect local spatial

relationships, while BiLSTMs can exploit temporal interactions. Furthermore, Attention modules can capture

content-based global interactions and can be applied on CNNs to attend to the significant contextual

information. In this paper, we utilized the advantages of all AE, CNN and BiLSTM structures using a multi-

head Self Attention mechanism to integrate CNN features for feeding into BiLSTM classifier. We use the

bottleneck features of a pre-trained AE for an Attention-based CNN-BiLSTM classifier. Our experiments

using 10, 6 and 2 categories NID system on UNSW-NB15 dataset showed that the proposed method

outperforms state-of-the-art methods and achieved accuracy of 91.72%, 89.79% and 93.01%, respectively.

Plus, we introduced a balanced data sampler for training 10 categories of NIDS.

1 INTRODUCTION

Today, activities of many private sectors and

government organizations depend on technology.

Thus, due to the surge in number of attacks, the cyber

resilience of crucial infrastructures is vital.

Cybersecurity is the establishment and compilation of

methods to defend cyberspace from incidents. Hence,

it is considered as a crucial element in private and

government industries. Undoubtedly, technology and

cybersecurity are continuously evolving for better

user experience. In the same vein, attackers are also

advancing their techniques to exploit the critical

infrastructures for unauthorized access. Therefore, it

is important to prevent, detect, and respond to

cyberattacks quickly, so the damage to the critical

infrastructures can be reduced (Dabbaghzadeh, et al.,

2021). So, many organizations have initiated to

improve cybersecurity awareness (Newhouse, et al.,

2017).

https://orcid.org/0000-0001-7733-8163

https://orcid.org/0000-0002-5748-155X

https://orcid.org/0000-0001-8962-540X

Traditionally, organizations focused on perimeter

defence and give authorized access to network traffic

on the internal network. Hence, unauthorized lateral

movement within the environment has been one of

the biggest challenges for organizations networks.

Perimeter firewalls are less useful for detecting and

blocking attacks from inside of the network and

cannot protect subjects outside of the enterprise

perimeter. Network perimeters security alone can no

longer be effective for providing enterprise security

and organizations should incessantly focus on

improving cybersecurity management systems. There

is a persistent increment in types of cyber-attacks on

the ICT structure with the subsequent major

propensities (Sanandaji and Falahati, 2021).

Maturity models are used as consultants and

reference structures for information system

management in various types of companies. A

Cybersecurity Maturity Model (CMM) is a standard

to determine the maturity of a protection system and

guidance on how to attain the higher level. Therefore,

Alalmaie, A., Nanda, P. and He, X.

ZT-NIDS: Zero Trust, Network Intrusion Detection System.

DOI: 10.5220/0012080000003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 99-110

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

some cybersecurity maturity mechanisms have been

suggested to reduce the impact of cyberattacks,

considering country level protection. Moreover,

regional, and international organizations have

conducted other studies, but they aim on score and

ranking countries corresponding to their national-

level cybersecurity top systems. CMM aims to find

methods for developing the company's protection and

introduce a level-based advancement approach.

Zero Trust satisfies these significant

characteristics by treating all users, devices, data, and

service requests similarly. It shifts from the

traditional security policy of all assets in an

organization being open and accessible to requiring

continuous authentication and authorization for any

asset to be accessible. Most existing corporate

networks are flat. The weakness of the traditional

hub-and-spoke network model lies in its architecture.

Crossing the chasm from trust to distrust via a firewall

is inherently risky. Instead, Zero Trust no longer

distinguishes between “inside” and “outside” the

network perimeter. A Zero Trust Architecture (ZTA)

addresses this trend by focusing on protecting

resources, not network perimeters, as the network

location is no longer viewed as the prime component

to the security posture of the resource.

In other words, Zero Trust is a set of cybersecurity

principles used to create a strategy that focuses on

moving network defences from wide, static network

perimeters to concentrating more narrowly on users,

systems, and individual or small groups of resources.

In this respect, we are eliminating the concept of

trust within the network and believe there are no more

trusted interfaces, users, packets, and applications.

Across the industries, security professionals are

shifting the security diameter to zero security trust

state of mind and quick adopting the approach of Zero

Trust security network model. It is notable that Zero

Trust is more than just concept. It is a robust security

model that follows 7 security important principles:

Data, Devices, Workload, Automation and

Orchestration, Visibility and Analytics, Users, and

Network (Alalmaie, et al., 2022).

The rest of the paper is organized as follow. In

section 2, some of the main related works are studied.

In section 3, the Zero Trust concept is explained

briefly. The chosen approach and the proposed

method are presented in sections 4 and 5, respectively.

In section 6, the used evaluation methods are

mentioned. Next, experimental results are reported in

section 7. Eventually, in section 8, a conclusion and

some future works are given.

2 RELATED WORKS

The Systems Security Engineering Capability

Maturity Model (SSE-CMM) was designed on the

CMM paradigm to evaluate assurance of security

engineering procedures and capability for customers

as a standard mechanism. THE SSE-CMM prevents

organizational security by having various features

(Nahari and Krutz, 2003).

The Community Cyber Security Maturity Model

(CCSMM) was proposed to tackle various problems

related to information sharing, metrics, training,

testing, technology, random threats, structured risks,

and well-structured risks. The CCSMM is designed

based on comprehensive working experience with

communities/states emerging and implementing

cybersecurity practices, and it has five maturity levels

as security awareness, process development,

information availability, tactics development, and full

security operational capability (White, 2011).

In (Eusgeld, et al., 2011), researchers examined

the weaknesses associated with the combination of

industrial control systems and the underlying critical

infrastructures. Plus, an integrated model was

suggested to address the selection of the suitable

method, and it investigate interdependencies between

the critical infrastructures.

In (Mettler and Blondiau, 2012), authors

proposed a maturity model to measure the skill levels

of federal important infrastructure safety attempts,

taking the maturity measures based on the obtained

core causes into consideration. The model did analyse

of data concerning to nationwide cybersecurity

developments through base level technique to obtain

the fundamental reasons of the vulnerability of vital

infrastructures to cyber risks. More, it confirms the

maturity standards by proposing the effects to

specialists according to a Delphi survey.

In (Karabacak, et al., 2016), authors have focused

on the advancement of a wide-ranging maturity

mechanism to apply in the Hospital Information

System (HIS) environment. Thus, they discussed on

different problems, like most important influencing

factors by information system managers, which are

associated to the maturity phases and maturity-

affecting element assessment in the perspective of the

maturity periods. Plus, they suggested HIS Maturity

Model (HISMM). They prepared a questionnaire to

understand the critical infrastructure requirements,

using the design science research methodology.

Further, they conducted a survey, considering

different categories and designed an initial maturity

model. Moreover, they implemented a qualitative

assessment technique for interviews to attempt and

SECRYPT 2023 - 20th International Conference on Security and Cryptography

100

analyse the existence or the unavailability of one or

many attributes in the text. The final maturity model

stage was designed based on data analysis, strategy,

people, systems and its infrastructure, electronic

medical record, and information security.

In (Nussbaum and Park, 2018), they noticed that

the difficulties in traditional IT agreement are

generally obvious in cybersecurity, as they have

exclusive cybersecurity products and services. Thus,

they suggested a prototype, explaining a set of

measures and restrictions that have influence on the

decision-making process of local government

towards the cybersecurity agreement. Further, they

discussed different conditions for government

contract and challenges of cybersecurity contracting.

In (Saleem, et al., 2019), authors suggested a

multidimensional holistic model to confirm

protection through all aspects of the information

resilience, by innovative technologies, intellectual

procedures, and constant evaluations. This layered

defence model was integrated to assess the security

strengths of critical infrastructures and suggest the

best procedures for cybersecurity analysts towards a

robust method before combining third-party products.

In (Renteria, et al., 2019), authors came up with

an enabler-founded digital administration maturity

framework, considering three criteria as digital

government, multidimensional, and availability.

Hence, this model is comprised of 7 aspects:

leadership, regulatory regime, and data to provide

more precise and specific suggestions, strategy,

governance, technology, and organization.

In (Gourisetti, et al., 2019), authors designed the

cybersecurity weakness improvement framework

through empirical model (CyFEr), using multi-

scenario criteria-based vulnerability analysis and

multitiered constraint-based optimization. CyFEr was

implemented on the NIST cybersecurity structure,

checking with a practical cyberattack. It also provides

potential solutions to focus on the user requirements

to reach an essential cybersecurity maturity, finding

the top-ranking solution based on the scalar values.

In (Niazi, et al., 2020), authors suggested a

Requirement Engineering Security Maturity Model

(RESMM) to support software-based industries,

suggesting specific requirements in a better way for

secure software advancement. They studied to know

the security needs and improved Sommerville’s

requirements engineering procedures. Further, they

also did a questionnaire study, considering identified

requirements into account. Eventually, they

considered related works, improved Sommerville’s

procedures and feedback from the security experts.

In (Bazi, et al., 2017), authors suggested a cloud

migration maturity model to ensure dynamism in

cloud migration procedures. It helps managers for a

complete migration overview to present a strategic

plan, achieving an effective management.

As weaknesses, maturity mechanisms only offer

a least compliance framework instead of a required

cybersecurity standard that work in an emerging

cyber environment. Thus, the mechanism should be

practiced not only by the management, but by security

specialists to evaluate the complete protection of the

group/structure and considering measure to reinforce

limitations of any explicit features of the organisation

as recognised by the valuation.

3 ZERO TRUST

The proliferation of cloud computing, mobile device

use, and the Internet of Things has dissolved

traditional network boundaries. Hardened network

perimeters alone are no longer effective for providing

enterprise security in a world of increasingly

sophisticated threats. Zero Trust concept compiles

strict identity-based verification for every user and

device trying to access resources on a private network

as well as cloud, regardless of whether they are sitting

within or outside of the network perimeter. No single

specific technology is associated with Zero Trust; it

is a holistic approach to network security that

incorporates different principles and technologies.

ZTA is designed to protect digital environments by

leveraging network segmentation, preventing lateral

movement, providing Layer 7 threat prevention, and

simplifying granular user-access control.

Zero Trust is a cybersecurity paradigm focused on

resource protection and the premise that trust is never

granted implicitly but must be continually evaluated.

Zero Trust implies not to trust any entity inside or

outside of network perimeter at any time. It is focused

on eliminating trust from within an organization,

dictates that no implicit assumptions should be made

about the credibility of users, devices, applications, or

data accessing or being accessed on an organization’s

network. It provides the visibility and IT controls

needed to secure, manage, and monitor every device,

user, application, and network belonging to or being

used by the organization and its employees to access

data. Zero Trust scrutinizes any incoming or outgoing

traffic. The difference between this and other security

models is that even internal traffic, meaning traffic

that does not cross the perimeter of the organization,

must be treated as a potential danger as well.

ZT-NIDS: Zero Trust, Network Intrusion Detection System

101

Zero Trust provides an occasion for scalable

protection structure throughout numerous distinct

associations. In (Kindervag, 2010) stated that keeping

trust on the cloud and networks is too critical job and

then, suggested that it is better to eliminate the idea of

trust. Further, author proposed a Zero Trust

mechanism to improve the protection technologies

for forthcoming changeability. By looking at failures

inside organizations to stop cyberattacks, especially

lateral movements of threats inside their networks,

they realized the traditional security model operated

on the outdated assumption that everything inside an

organization’s network could be trusted. Instead,

Zero Trust inverts model, directing IT teams

according to the guiding principle of “never trust,

always verify” and redefining the perimeter to include

users and data inside the network. In this broken trust

model, it is assumed that a user’s identity is not

compromised, and all users act responsibly and can

be trusted. In the Zero Trust model trust is a

vulnerability. So, network users (threat actors and

malicious insiders) are free to move laterally and

access/exfiltrate whatever data they are not limited to.

In ZTA, none of the pillars are reliable, no

question what kind of unit it is, even though it is part

of the network. Zero Trust absolutely redefines the

method to resource separation – a fundamental theory

where resources must be remained safe, are

categorized all together, and separated carefully or

kept unconnected from illegal contact at any type of

areas. These mechanisms also present the occasion to

micro-segment systems, allowing groups to change

their demands with not reforming their whole

network. In micro-segmentation, networks are carved

into small granular nodes all the way down to a single

machine or application. Security protocols and

service delivery models are designed for each unique

segment. The free flow of data that was once one of

the cornerstones of the Internet needs to be confined

to protect networks from penetration, customers from

privacy violations, and organizations from attacks on

infrastructure and operations.

ZTA is an end-to-end approach to network/data

security that encompasses identity, credentials,

access management, operations, endpoints, hosting

environments, and the interconnecting infrastructure.

The focus should be on restricting resource access to

those with a “need to know.” Traditionally, agencies

have focused on perimeter defence, and authorized

users are given broad access to resources. Hence,

unauthorized lateral movement within a network is

one of the biggest challenges for organizations. The

Trusted Internet Connections (TIC) and agency

perimeter firewalls provide strong Internet gateways.

This helps block attackers from the Internet, but the

TICs and perimeter firewalls are less useful for

detecting and blocking attacks from inside the

network. Thus, the Zero Trust separation access

framework can be thought the next generation

mechanism of a firewall, expanding micro

subdivision of the networks to achieve flexibility,

scalability, and virtualization easiness.

4 THE CHOSEN APPROACH

Our model is proposed against a semi-honest

adversary who will be conducting the task of IDS but

might have various incentives to disclose the identity

or the exact value of some attributes of some records.

Our assumptions are: Firstly, the adversary is semi-

honest. Secondly, the adversary can observe the

anonymized version of the data. The adversary also

knows the underlying anonymization algorithm.

Thirdly, the adversary knows the original version of

a subset of the records. He/she has collected this

information through running some semantic attacks.

Accordingly, we assume that the adversary knows the

original prefix values of α% of the prefixes. Finally,

the adversary objective is to find the original version

of the most possible number of the anonymized

records. We call these estimations of the adversaries

of the original version of the anonymized records

“matches”. The larger the number of true matches is,

the higher the adversary advantage will become, and

the higher privacy leakage incurs.

4.1 IDS in Third-Party Setting

Undeniably, conducting reliable IDS greatly depends

on the accuracy of the received dataset compared to

its original version. Specifically, most of detection

algorithms rely on learning the benign from the high-

dimensional and large-size datasets. So, only defence

mechanisms with minimal modification to the

format/entries in the dataset can lead to trustworthy

intrusion detection. Beside the existing homomorphic

encryption and computation over aggregated data

techniques, Multi-View (MV) approach

(Mohammady, et al., 2018) has been introduced as an

effective method to maximally benefit the best of

both worlds. This approach outputs a prefix

preserving version of IP address attributes, and an

accurate copy of values in other attributes. Such a

minimally modified version of the network traces can

be used to accurately conduct analyses. Moreover, is

ensured through hiding that real view among a set of

indistinguishable fake views.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

102

4.2 Defence: The MV Approach

We first need to formally introduce the prefix

preserving anonymization PP (-, K) which is basically

a cryptographic mapping function like CryptoPAn

(Mohammady, et al., 2018) that relies on a secret key

K. The most important property of this function is that

it can preserve the prefixes of numeric-value

attributes. Thus, if two real addresses share first X

bits, e.g., 150.10.10.1, 150.10.20.1 share 14 bits in

their prefixes, are mapped to another two anonymized

addresses, e.g., 97.61.5.252, 97.61.5.252, which

share first X bits. As we showed in previous sections,

PP is vulnerable to different classes of semantic

attack, and the MV approach presented in the

following was designed to secure its output. The

schema of the MV approach is presented in Figure 1.

There are 7 steps to this approach, the first five

are initiated on the data owner side and the final three

steps involve the data analyst side. We note that this

approach assumes that the confidential attribute is the

IP address, and if IPs are kept secure, the adversary

cannot infer any sensitive information.

4.2.1 Implementing Effective Zero Trust

Model at the Data Owner Side

Step 1: Data owner generates two 256 bits

Cryptographic keys (K0 & K1), and the original data

is anonymized using PP (-, K0).

Step 2: The anonymized trace is partitioned.

Step 3: Each partition is anonymized but repeated for

a different number of times at different partitions.

Therefore, seed trace is not prefix-preserved.

Step 4: The seed trace and some supplementary

parameters are outsourced to data analyst. The pseudo

vector and the seed view generation are designed such

that after “r” number of times view generation, the

real view (which is identical to the view in step one

will be retrieved.

4.2.2 Accuracy Guarantee at the Data

Analyst side

Step 5: Analyst generates N views based on seed

view and supplementary parameters.

Step 6: Analyst analyses all N views and generates

corresponding reports.

Step 7: Data owner retrieves report corresponding to

the “real view”, using a private information retrieval

(PIR) protocol in a way that analyst cannot identify

which view was retrieved.

Clearly, the quality of the views generated in the

MV approach is the main factor of the adds-on

confidentiality the network trace will receive.

Specifically, if all other (fake) generated views are

too far or too close from the original trace (prefix-

wise and in the presence of some adversary

knowledge), the MV approach may end up

compromising a high level of privacy. In particular,

the adversary can discard many of the (far) fake views

by looking at the prefix relations in IP addresses and

compare them to his/her adversary knowledge to

identify any inconsistency. Conversely, a design with

fake views generated too close to the real view incurs

drastic privacy leakage. In the latter case, the fake

views are not fake. Therefore, in (Mohammady, et al.,

2018), authors proposed a metric called “the

indistinguishability” to reflect the distance of each

view from the real view. Based on this formalization,

they suggest two schemes for their partitioning

algorithms, i.e., IP-based, and distinct IP based

partitioning: each with their own partition sizes. They

conclude that a distinct IP based partitioning with a

customized pseudo vector can significantly (50 times

less) reduce the privacy violation. We will detail on

these methodologies in our next report.

Figure 1: MV approach (Mohammady, et al., 2018).

ZT-NIDS: Zero Trust, Network Intrusion Detection System

103

4.3 Operations Required for IDS

The accuracy of the required analyses must be

guaranteed alongside its confidentiality because the

first motivation of such outsourcing models is to

benefit from more accurate analysis tasks. For this

purpose, we believe the MV approach is an ideal

candidate. In contrast to other solutions, MV allows

third-party analysts to receive and interact with the

raw data. Nevertheless, as MV anonymization entails,

the original versions of some of the attributes must be

replaced with a cryptographic prefix preserving

version. We now shed light on the impact of such

transformation over the outcomes of certain classes

of IDS algorithms. Since our focus is network traces,

and we only apply PP on the IP address attributes, all

traffic-level analyses (packet level) are expected to

return trustworthy results, e.g., the traffic of the entire

network, or the traffic on a certain port. With a similar

reasoning, the flow level analyses also remain intact.

The main issue regards the graph-level set of

analyses, e.g., subnet-based analyses, throughputs of

a subnet, and reachability analyses.

Recently, solutions with Deep Neural Networks

(DNN) and optimisation algorithms have undertaken

machine learning approaches in various applications

(Abolghasemi, et al., 2022; Ghezelji, et al., 2022;

Tohidi, et al., 2022), due to their success (Tohidi and

Rustamov, 2020), and IDS is not an exception.

In (Kumar, et al., 2020), a misuse-based intrusion

detection system was proposed to detect 5 categories

in a network called: Probe, Exploit, DOS, Generic

and Normal. This system could act as a firewall with

some extra information added to it. Moreover, unlike

most related works, in their paper UNSW-NB15

dataset was considered as the offline dataset to design

own integrated classification-based model for

detecting malicious activities in the network. Plus,

they generated their own real-time data set at NIT

Patna CSE lab (RTNITP18) that acted as the working

example of their intrusion detection model.

In (Cao, et al., 2022), a network intrusion

detection model was introduced which fused a CNN

and a gated recurrent unit. Their main was to tackle

the problems associated with the low accuracy of

existing intrusion detection models for the multiple

classification of intrusions and low accuracy of class

imbalance data detection. In their method, a hybrid

sampling technique combining adaptive synthetic

sampling and repeated edited nearest neighbours was

applied for sample processing to solve the positive

and negative sample imbalance issue in the original

dataset. The Feature Selection (FS) was carried out

by combining RF algorithm and Pearson correlation

analysis to address the feature redundancy problem.

Afterwards, the spatial features were extracted by

using a CNN, and then extracted by fusing Average-

pooling and Max-pooling, by using attention

mechanism to assign different weights to the features,

therefore, reducing the overhead and improving the

model performance. At the same time, a Gated

Recurrent Unit (GRU) was applied to extract the

long-distance dependent information features to

achieve comprehensive feature learning. Eventually,

a Softmax function was used for classification.

We consider employing such NN-IDS in our

ZTA-IDS, and therefore, we will elaborate on the

accuracy of these special types of IDS.

4.4 Criteria on Security and Accuracy

Clearly, the characteristics of the framework, rely on

the IDS task. If the IDS task is independent of the

prefix relation of the IP addresses, e.g., counting the

number of packets with the size of larger than 300KB,

then we can strengthen the confidentiality aspect of

the solution arbitrarily. On the other hand, if the IDS

task depends on the trustworthiness of the prefix

relations, an appropriate degree of MV must be

applied. Interpreting one IDS task’s requirements is

one of the main contributions of our ZTA_IDS

framework. For an NN-IDS, depending on the type of

intrusion, the learning module may require

fingerprinting a larger number of attributes to predict

the malicious activities from the benign ones.

Therefore, partitioning algorithm, number of

partitions, and number of attributes involved in the

partitioning must be carefully selected to guarantee a

maximal level of accuracy for an NN-IDS. These are

the most important parts of our experiments which we

will elaborate on in the next report.

4.4.1 Privacy Preservation

On the data owner side, ZTA_IDS performs like the

MV approach. The only modification is that the

partitioning algorithm (mainly the parameters) is

defined based on both security and accuracy

requirements. An appropriate choice of partitioning

could vary from distinct IP based partitioning for the

prefix groups of with length three octets when

conducting anomaly-based IDS, to distinct IP based

partitioning for the prefix groups of with length only

one or even less when conducting packet/flow level

analyses. The overview is depicted in Figure 2.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

104

Figure 2: Overview of the ZTA-IDS approach.

4.4.2 Actions on Data Analyst Side

On this side, ZTA-IDS follows the MV approach to

generate different dataset views. Next, the analyst

pre-processes all views to a format suitable for the

operations. Plus, the analyst may need to reorder the

entire trace based on time after generating the views.

The prefix-to-prefix communication is another set of

queries for which the analyst must run some pre-

processing to reduce the impact of anonymization.

He/she will then run the IDS algorithms on each of

views and returns the outcomes to the data owner.

5 THE PROPOSED MODEL

The architecture consists of 4 modules: AE feature

extractor, Convolution blocks, Attention mechanism

and LSTM layers. The proposed model is inspired

from AE-CNN for binary NID. Thus, we use the

extracted features as the input to our neural network

for categorical intrusion detection. We also utilize

Attention module to focus on important features and

LSTM layers to handle temporal dynamics.

5.1 AE Feature Extraction

The compressed bottleneck features of network traces

are extracted via a pre-trained deep AE. The AE

bottleneck layer maps the original input into a

compressed representation where the input features

are more correlated. AE consists of 2 components: the

encoder that compress input features, and the decoder

which is discarded after pre-training. Thus, a deep AE

can be used to extract a combined and compressed

feature from network trace attributes. In the AE, the

bottleneck feature z is extracted using the encoder

function from the original data X. The decoder

function - maps the bottleneck z to the output 𝑋



The

decoder is expected to reconstruct the input as Eq. (1).

𝜓𝑋 ⇒𝑧 ,

𝜙𝑧 ⇒ 𝑋



(1)

𝜓 ,𝜙  𝑎𝑟𝑔𝑚𝑖𝑛𝑋



𝜙𝜓



𝑋







Mean Squared Error (MSE) loss function of the

AE is as Eq. (2). Where 𝑋 𝑋



is usually averaged

over a mini-batch input training set. W, 𝑊



are weight

matrices and b, 𝑏



are bias vectors for encoder and

decoder, respectively. Bias is not used for encoder

part to aggregate input feature only.

𝐿



𝑋,𝑋





𝑋𝑋









‖

𝑋𝜎



𝑊



𝜎𝑊𝑋  𝑏



𝑏





‖



(2)

In the structure of the AE (Figure 3), dotted lines

are discarded after training the AE. The bottleneck

features of the trained AE, which are more spatially

related, are used as input to CNN-LSTM.

Figure 3: AE feature extractor for network traces.

Since AE with a bottleneck layer accepts any

numerical value and compresses the information

available in the input numerical values, pre-

processing and FS is not needed.

5.2 Convolutional Neural Network

(CNN)

We use a CNN to consider spatially related features

extracted using the AE. The classifier is applied on a

bottleneck feature extracted from a trained AE for

NID because CNNs work well with data that has a

spatial relationship. The CNNs are also known to be

ZT-NIDS: Zero Trust, Network Intrusion Detection System

105

good feature extractors because of local convolution

filters, repetitive filters among whole input data, and

pooling layers which make it robust. Here, we also

use a tuned 1D CNN to handle spatial dependencies

within traces of data. Our proposed CNN structure is

shown in Figure 4, and LeakyReLU

with 0.2

negative slope is considered as activation function for

hidden layers. In convolution layers, the first number

is for filters and the number in parentheses is the

convolution filter size, e.g., first layer has 128 filters,

where 11 is the convolution filter size. A pooling with

size of 2 is only applied on the first convolution layer.

In the CNN layer output, we have 256*5 features,

which its knowledge needs to be aggregated together,

since it has a high dimension of feature vector to feed

into any regular layer.

Figure 4: The proposed CNN to handle spatial

dependencies of network traces.

5.3 Attention Module

We apply a multi-head Self Attention module to

aggregate the information available in extracted

features and handle the relation between the CNN

features and LSTM components (subsequent layers).

The attention module dimension is the number of

channels from the last CNN layer (256) and uses 8

heads. The output is mapped into 64 dimension to

limit the features. The attention learns to focus on

intrusion related features. The alternative structure for

multi-head self-attention on top of CNN, would be a

linear Flatten layer, which maps the CNN multi-

dimensional features into one large dimension. The

total number of features in this layer, is the same as

the total number of CNN features in all dimensions.

We also report the results of the proposed method

with a linear Flatten layer instead of Attention

mechanism. Plus, we use BiLSTM layers after the

Attention to handle the temporal dynamics between

the sequences of network traces.

https://pytorch.org/docs/stable/generated/torch.nn.Leaky

ReLU.html

5.4 BiLSTM Classifier

Since LSTMs can hold or forget information for a

long time, we propose to use LSTMs to handle the

temporal dynamics. Also, BiLSTM is able to take

forward and backward sequences into consideration

which can be important in handling temporal

dynamics. We use 2 BiLSTM layers with 128-

dimensional representations. A dropout with

probability of 0.2 is applied between 2 layers of

BiLSTM. Finally, a linear layer with the number of

neurons same as target categories is applied (from 2

to 10). In the subsequent paragraphs, we will review

the training and test conditions along with the

evaluation results.

6 EVALUATION METHODS

In this section, we explain the chosen evaluation

metrics and data.

6.1 Training Setup

All experiments are implemented in PyTorch and

conducted on Colab platform with a batch size of 32.

The AE is trained to minimize MSE criterion as loss

function, which is also known as reconstruction error.

Both encoder and decoder parameters are considered

and trained independently. The dimension of the

bottleneck features is considered as 64, which is

compact enough to compress input features. We used

the Adam optimizer with learning rate of 1e-4 and

weight decay of 1e-5 to minimize the reconstruction

loss. The model is trained until no more improvement

is possible according to validation results. All data

attributes are normalized to numerical values between

0 and 1. Thus, non-numerical attributes are converted

into numerical values using one-hot encoding. The

training dataset is set to prevent over-fitting.

The bottleneck features extracted from the trained

AE are fed into the CNN for further training and

processing while the AE is frozen. Since the compact

features of input attributes are available in the

bottleneck layer with 64 neurons, the CNN input

spatial dimension is 64 and the sequence number

equals the size of mini batch.

The CNN modules are trained with learning rate

of 1e-3, while the Attention and BiLSTM modules are

trained with learning rate of 1e-4 for a maximum 50

SECRYPT 2023 - 20th International Conference on Security and Cryptography

106

epochs. We used cross-entropy loss as the classifier

loss function and Adam optimizer.

6.2 Data

We evaluate the proposed method on the UNSW-

NB15 dataset (Moustafa and Slay, 2015), which is

comprised of a hybrid of real modern normal

activities and synthetic contemporary attack

behaviours. This is an upgraded version of the KDD

cup dataset which is a more balanced dataset. The

UNSW-NB15 dataset contains 10 classes, namely:

Normal, Fuzzers, Analysis, Back-doors, DoS,

Exploits, Generic, Reconnaissance, Shell Code, and

Worms. We use the train and test subsets of this

dataset with 175343 and 82337 records respectively.

In this dataset each record has a 42-dimensional

feature, which 3 features of them are non-numerical

values and need pre-processing to be fed into Neural

Networks since the input should be a digital matrix.

These 3 features are protocol, service, and state with

133, 13, and 11 symbol attributes, respectively.

One-hot encoding is used to map non-numerical

attributes of the data set to numerical feature vectors.

In total, the pre-processed input feature size would be

196. Then, the features are normalized between 0 and

1 which are used to train the AE unsupervised. The

64-dimensional bottleneck features extracted from

the trained AE are used for next experiments.

Since classes of attacks are unbalanced, most

studies reduced it by merging or removing some

categories. Binary classification means 9 categories

are merged into 1 class as Intrusion, consequently the

classes would be Intrusion/Non-Intrusion in this

scenario. However, some works tried to merge the

categories that are not far from each other. Some

others reduced the imbalance data by removing the

categories with fewer number of existing items

including Backdoor, Analysis, Shellcode, Worms and

sometimes Fuzzers which make the data imbalance.

We compare the results of 10 categories

classification with related works and report the result

of removing imbalanced data attributes to have a fair

assessment. To show the advantage of the proposed

structure we report the binary classification results

using the same data structure, which train, and test

data are used in reverse, so, have a few training

samples. Additionally, we propose a nearly balanced

sampling procedure to enhance the detection of the

categories with fewer samples in the CNN module.

Due to the sequential nature required to train the

LSTM, we cannot use any sampling strategy to train

it. The UNSW-NB15 dataset is highly imbalanced,

the Normal category has 56000 samples for training

while the Worms category only has 130 samples. We

reduce the impact of this imbalance by sampling

based on a smoothing probability function as Eq. 3.

𝑃



𝑐𝑙







#





 #



#





∑

#





 #

#









(3)

In this equation, 𝑐𝑙



means ith category, so 𝑃𝑐𝑙





is the probability of choosing a sample from ith

category, calculated using number of samples in each

category #𝑐𝑙



 and median of the number of samples

per category. We use a small 𝜖 (0.1) to prevent zero

addition for the category with minimum number of

samples. The minimum number of samples is 130

associated with category Worms, and the median is

11378. The proposed sampling strategy keeps the

ordering of the number of the categories but make the

sampling more balanced by reducing the distance

between number of items in each category.

7 EXPERIMENTAL RESULTS

In this section, we report the experimental results of

NID methods for ten, six, and two categories.

7.1 Ten Categories CNN-BiLSTM Data

Classification

For hyper parameter optimization, we explored the

optimal number of layers and neurons for each part of

CNN-BiLSTM with Attention module. To evaluate

the effect of each module, the results of BiLSTM,

CNN-BiLSTM, and Attention-based CNN-BiLSTM

are compared to related methods in Table 1 for 10

categories data classification. Since the results of the

baseline CNN model using AE features are not

available for categorical classification, we

implemented it and reported the results for

Figure 5: Confusion matrix of ten categories for CNN-

BiLSTM with AE feature extractor.

ZT-NIDS: Zero Trust, Network Intrusion Detection System

107

comparison. Attention-based CNN-BiLSTM using

AE bottleneck features out-performed other related

works using deep learning methods for 10 categories

NID. The confusion matrix is shown in Figure 5.

Accordingly, most errors of Analysis, Backdoor

and Exploits Attacks are misclassified as DoS. More,

Fuzzers and Exploits are misclassified

interchangeably. None of Analysis and Backdoor

records are predicted correctly. Only 3 records of

Worms class are predicted correctly. Consequently,

removing imbalanced data attributes including

Backdoor, Analysis, Shellcode and Worms should

obviously improve the accuracy. Thus, removing

Fuzzers may lead to better accuracy.

7.2 Pre-Train CNN Using Balanced

Data Sampler

We use a balanced data sampler to pre-train the CNN

for later usage in CNN-BiLSTM with Attention

module instead of reducing the number of categories.

Our goal is to improve the discrimination of the

model to learn discriminate the data better even when

the number of training samples are imbalanced.

Hence, we use the trained CNN in CNN-BiLSTM

with Attention module to enhance the detection of

network intrusion. The accuracy results of CNN-

BiLSTM with Attention module with and without

balanced sampler are compared in Table 1.

Table 1: Accuracy of 10 categories NID on test data.

Method Accuracy

BiLSTM 77.46%

CNN 78.23%

CNN-BiLSTM 78.76%

CNN-Attention + BiLSTM 87.76%

CNN-Attention 88.13%

Proposed method (Standard Sampler) 87.76%

Proposed method (Balanced Sampler) 91.72%

We compare Recall, Precision and F-measure of

the proposed method (balanced sampler) in Table 2.

Table 2: Results of NID on test data.

Method Precision Recall F-measure

Decision Tree C5 (Kumar, et al., 2020) - 75.8% 75.54%

Rule-

ased

(Kumar, et al., 2020)

- 65.21% 68.13%

FS + ANN

(Kasongo and Sun, 2020)

79.50% 77.53% 77.28%

Pro

osed metho

60.24% 78.5% 62.62%

As Table 2 presents, the recall of the proposed

model outperforms related works which means that it

detects most of the relevant results.

It is seen that pre-training CNN using balanced

sampler outperforms related works in terms of

accuracy. The confusion matrix of the proposed

method (10 categories) is shown in Figure 6. The

number of misclassifications for each category is low,

especially for Normal category.

Figure 6: Confusion matrix of pre-trained CNN via

balanced sampler, Attention and BiLSTM with AE feature

extractor.

7.3 Six Categories CNN-BiLSTM Data

Classification

Since recent works removed imbalanced data and

reported 6 categories, we have removed 4 imbalanced

categories too. The results are reported in Table 3.

Table 3: Accuracy of 6 categories NID on test data.

Method Accuracy

CNN 82.01%

BiLSTM 83.11%

MLP + IGRF-RFE (Yin, et al., 2022) 84.24%

Rule-

ased (Kumar, et al., 2020) 84.84%

CNN-GRU + RFP (Cao, et al., 2022) 86.25%

CNN-BiLSTM 86.28%

CNN-Attention 87.54%

CNN-Attention + BiLSTM 89.79%

Figure 7: Confusion matrix of 6 categories for CNN-

BiLSTM with AE feature extractor.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

108

As seen, the proposed method outperforms

related methods for 6 categories classification

(confusion matrix in Figure 7).

7.4 Binary CNN-BiLSTM Data

Classification

The hyper parameters for binary classification model

have been kept same as the multi-class model. To

evaluate each module, the results of BiLSTM, CNN-

BiLSTM, and Attention-based CNN-BiLSTM are

compared to the most related work using CNN with

AE bottleneck features for NID in Table 4.

For a fair comparison, our data should be similar.

We used train and test data interchangeably to have a

fair comparison with CNN and AE method.

As Table 4 depicts, using BiLSTM decreases the

accuracy, especially in combination of CNN. It can

be due to the high dimension of CNN output, which

is fed into the BiLSTM layers. However, using an

Attention module on CNN to aggregate the CNN

features for feeding into BiLSTM layers

outperformed CNN and BiLSTM models. Since other

binary classification methods using original train and

test dataset for NID have reached almost 100%

accuracy, more experiments are not needed.

Table 4: Accuracy of NID (binary classification).

Method Accuracy

CNN-BiLSTM 78.93%

FS + DNN (Kanimozhi and Jacob, 2019) 89%

BiLSTM 90.84%

CNN 92.23%

CNN-Attention + BiLSTM 93.01%

According to the results, CNN and BiLSTM both

perform well for NID using AE bottleneck features.

However, an Attention module is needed to handle

the relation between the components of these two

structures and compose them together.

8 CONCLUSIONS

In this paper, we have introduced a new CMM with

Zero Trust. The proposed model effectively protects

various systems, crucial infrastructure, networks,

data, services, end-users from critical security risks,

achieving different security requirements.

Further, we have proposed an Attention CNN with

Bi-directional Long Short Term Memory (CNN-

BiLSTM) using Auto-Encoder Bottleneck features

for Network Intrusion Detection System. We utilized

the compressed bottleneck features of the Auto-

Encoder. We also used a CNN to consider the spatial

relation between extracted features. A multi-head Self

Attention module is applied on CNN to aggregate the

features and attend to the most important parts of the

CNN feature maps for BiLSTM in the next layer.

Finally, two BiLSTM layers are used for

classification. To reduce the problem of data

imbalance, we also propose a balanced sampler for

pre-training the CNN. Our experimental results

showed that our proposed approach outperforms

state-of-the-art methods for 2, 6 and 10 categories

with classification accuracy of 93.01%, 89.79% and

91.72% on test set of UNSW-NB15 dataset.

As future works, we will apply transfer learning

methods and metaheuristic methods to reduce the

number of parameters in such a complicated

structures which can be run on edge devices.

REFERENCES

Alalmaie, Abeer Z.; Nanda, Priyadarsi; He, Xiangjian.

(2022). Zero Trust-NIDS: Extended Multi-View

Approach for Network Trace Anonymization and Auto-

Encoder CNN for Network Intrusion Detection. IEEE

International Conference on Trust, Security and

Privacy in Computing and Communications

(TrustCom). Wuhan, China: IEEE.

Abolghasemi, Majid; Dadkhah, Chitra; Tohidi, Nasim.

(2022). HTS-DL: Hybrid Text Summarization System

using Deep Learning. The 27th International Computer

Conference, the Computer Society of Iran. Tehran,

Online. Retrieved from https://ieeexplore.ieee.

org/abstract/

document/9780395

Bazi, Hamid reza; Hassanzadeh, Alireza; Moeini, Ali.

(2017). A comprehensive framework for cloud

computing migration using Meta-synthesis approach.

Journal of Systems and Software, 128, 87-105.

Cao, Bo; Li, Chenghai; Song, Yafei; Qin, Yueyi; Chen,

Chen. (2022). Network Intrusion Detection Model

Based on CNN and GRU. Applied Sciences, 12(9).

Retrieved from https://doi.org/10.3390/app12094184

Dabbaghzadeh, Hamed; Falahati, Abolfazl; Sanandaji,

Nader;. (2021). CBTC Systems Safety Enhancement by

Employing an IoT-Based Spread Spectrum Technique.

2021 International Conference on Circuits, Controls

and Communications (CCUBE) (pp. 1-5). Bangalore,

India: IEEE.

Eusgeld, Irene; Nan, Cen; Dietz, Sven. (2011). “System-of-

systems” approach for interdependent critical

infrastructures. Reliability Engineering & System

Safety, 96(6), 679–686.

Ghezelji, Mazyar; Dadkhah, Chitra; Tohidi, Nasim;

Gelbukh, Alexander. (2022). Personality-Boosted

Matrix Factorization for Recommender Systems.

International Journal of Information and

Communication Technology Research (IJICTR), 14(1),

48-55.

ZT-NIDS: Zero Trust, Network Intrusion Detection System

109

Gourisetti, S.N.G.; Mylrea, M.; Patangia, H.; . (2019).

Cybersecurity Vulnerability Mitigation Framework

Through Empirical Paradigm (CyFEr): Prioritized Gap

Analysis. IEEE Systems Journal, 14(2), 1897-1908.

Kanimozhi, V.; Jacob, Prem. (2019). UNSW-NB15 dataset

feature selection and network intrusion detection using

deep learning. Journal of Recent Technology and

Engineering, 7(1), 443–446.

Karabacak, Bilge; Yildirim, Sevgi Ozkan; Baykal, Nazife.

(2016). A vulnerability-driven cyber security maturity

model for measuring national critical infrastructure

protection preparedness. International Journal of

Critical Infrastructure Protection, 15, 47-59.

Kasongo, Sydney M.; Sun, Yanxia;. (2020). Performance

Analysis of Intrusion Detection Systems Using a

Feature Selection Method on the UNSW-NB15

Dataset. Journal of Big Data, 105(7).

doi:https://doi.org/10.1186/s40537-020-00379-6

Kindervag, J. (2010). Build Security Into Your Network’s

DNA: The Zero Trust Network Architecture. For

Security & Risk Professionals, Forrester Research.

Kumar, Vikash; Sinha, Ditipriya; Das, Ayan Kumar;

Pandey, Subhash Chandra; Goswami, Radha Tamal.

(2020). An integrated rule based intrusion detection

system: analysis on UNSW-NB15 data set and the real

time online dataset. Cluster Computing, 23, 1397–

1418. Retrieved from https://doi.org/10.1007/s10586-

019-03008-x

Mettler, T.; Blondiau, A.;. (2012). HCMM-a maturity

model for measuring and assessing the quality of

cooperation between and within hospitals. 25th IEEE

International Symposium on Computer- Based Medical

Systems (CBMS).

Mohammady, M.; Wang, L.; Hong, Y.; Louafi, H.;

Pourzandi, M.; Debbabi, M.;. (2018). Preserving both

privacy and utility in network trace anonymization. The

2018 ACM SIGSAC Conference on Computer and

Communications Security.

Moustafa, Nour; Slay, Jill. (2015). UNSW-NB15: a

comprehensive data set for network intrusion detection

systems (UNSW-NB15 network data set). Military

Communications and Information Systems Conference

(MilCIS). Canberra, ACT, Australia: IEEE.

doi:10.1109/MilCIS.2015.7348942

Nahari H.; Krutz R. L.,. (2003). System Security

Engineering Capability Maturity Model (SSE-CMM)

Model Description Document. Version 3.0. Carnegie

Mellon University.

Newhouse, William; Keith, Stephanie; Scribner, Benjamin;

Witte, Greg. (2017). National Initiative for

Cybersecurity Education (NICE) Cybersecurity

Workforce Framework. Gaithersburg: National

Institute of Standards and Technology.

Niazi, Mahmood; Saeed, Ashraf Mohammed; Alshayeb,

Mohammad; Mahmood, Sajjad; Zafar, Saad. (2020). A

maturity model for secure requirements engineering.

Computers & Security, 95.

Nussbaum, B.; Park, S., . (2018). A tough decision made

easy? local government decision-making about

contracting for cybersecurity. . The 19th Annual

International Conference on Digital Government

Research: Governance in the Data Age.

Renteria, C.; Gil-Garcia, J.R.; Pardo, T.A.;. (2019). Toward

an Enabler-Based Digital Government Maturity

Framework: A Preliminary Proposal Based on Theories

of Change. The 12th International Conference on

Theory and Practice of Electronic Governance.

Saleem, D.; Sundararajan, A.; Sanghvi, A.; Rivera, J.;

Sarwat, A.I.; Kroposki, B.; . (2019). A

Multidimensional Holistic Framework for the Security

of Distributed Energy and Control Systems. IEEE

Systems Journal, 14(1), 17-27.

Sanandaji, Nader; Falahati, Abolfazl;. (2021). Lattice-

Based Coding to Enhance Error Performance of the

Hidden Direct Sequence Spread Spectrum. IETE

Journal of Research, 67(6), 754-766.

Tohidi, Nasim; Rustamov, Rustam B. (2022). Short

Overview of Advanced Metaheuristic Methods.

International Journal on Technical and Physical

Problems of Engineering (IJTPE), 14(51), 84-97.

Tohidi, Nasim; Rustamov, Rustam B.;. (2020). A review of

the machine learning in gis for megacities application.

In R. B. Rustamov, Geographic Information Systems in

Geospatial Intelligence (pp. 29-53). London:

IntechOpen.

White, G. (2011). The community cyber security maturity

model. IEEE international conference on technologies

for homeland security (HST).

Yin, Yuhua; Jang-Jaccard, Julian; Xu, Wen; Singh,

Amardeep; Zhu, Jinting; Sabrina, Fariza; Kwak, Jin.

(2022). IGRF-RFE: A Hybrid Feature Selection

Method for MLP-based Network Intrusion Detection

on UNSW-NB15 Dataset. arXiv:2203.16365.

Retrieved from https://doi.org/10.48550/arXiv.2203.

16365.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

110
