Informed Consent as Patient Driven Policy for Clinical Diagnosis and

Treatment: A Smart Contract Based Approach

Md Al Amin

, Amani Altarawneh

and Indrajit Ray

Computer Science Department, Colorado State University, Fort Collins, Colorado, U.S.A.

Keywords:

Informed Consent, Patient, Provider, Clinical Treatment, Disease Diagnosis, Blockchain, Smart Contract.

Abstract:

Digitized healthcare systems improve services, make it easier for healthcare providers to work together, im-

prove the accuracy of diagnoses, and get the most out of each treatment. They provide healthcare services

that are better, faster, more reliable, and less expensive. With the help of information technology, comput-

ing resources, and digitized health records, medical researchers are trying to solve critical health problems

like COVID-19. However, electronic healthcare systems signiﬁcantly risk patients’ data privacy and security.

Anyone with credentials can access patients’ healthcare data. Patients grant consent to share or access data.

But they need a way to ensure informed consent is done right and on time. Due to the centralized authority

in present healthcare systems, healthcare-covered entities perform all operations. As a result, many unwanted

events and security incidents happen in healthcare systems. Patients must know how their data is accessed, by

whom, and when. Therefore, a blockchain and smart contract-based patient-informed consent management

system is proposed. Where patients provide informed consent to share or access their health records, as well as

methods to ensure that informed consent is properly completed. The immutability and auto-triggering proper-

ties of blockchain and smart contracts ensure the integrity and accountability of the given informed consent.

1 INTRODUCTION

Compared to paper-based systems, electronic health

record (EHR) systems make it easier for doctors to

work together, make diagnoses more accurate, speed

up treatment, and give doctors ready access to patient

medical records. As healthcare data become more

digitized, distributed, and interactive, the healthcare

ecosystem is increasingly becoming more concerned

about the security of EHR information and systems.

Several factors contribute to the increased vulnera-

bility of EHR systems. Health workers are often

under-trained and under-experienced in handling and

securely maintaining information systems. Software

bugs, security ﬂaws, and human errors allow unau-

thorized users to enter these databases. Insider ad-

versaries can also get their hands on protected med-

ical information, which can cause sensitive patient

information to be lost, misused, or shared. Conse-

quently, healthcare providers’ responsibility to pro-

tect patient privacy and health records conﬁdentiality

https://orcid.org/0000-0003-1700-7201

https://orcid.org/0000-0002-4885-350X

https://orcid.org/0000-0002-3612-7738

has increased signiﬁcantly due to these factors in elec-

tronic health data processing (Sulmasy et al., 2017).

While better security and privacy technology are

needed to better protect patient data from these types

of breaches, there is ample evidence that shows that

improper policy adoption, implementation, and en-

forcement cause a signiﬁcant amount of unauthorized

access – without a “need to know” – to EHR data

(Staff, 2016; Seh et al., 2020; Marchand-Melsom

and Nguyen Mai, 2020). Intentionally or unintention-

ally, access privileges are assigned to users when they

should not be. Policies are not followed correctly, and

access control rules are not checked or implemented

promptly. In some cases, it has been observed that

the same roles and privileges are assigned to all em-

ployees. Often, individual patient-level policies are

not enforced to the word. Gaps in auditing and moni-

toring have also been found; they are not done unless

there are serious complaints or a legal requirement to

do so. Informed consent policies, in particular, are

one group of policies that suffer considerably because

of such gaps in policy speciﬁcation and enforcement.

Informed consent (Parvin, 2022; Lorenzini et al.,

2022) is a legal and ethical concept in healthcare that

refers to the process in which a patient voluntarily

Al Amin, M., Altarawneh, A. and Ray, I.

Informed Consent as Patient Driven Policy for Clinical Diagnosis and Treatment: A Smart Contract Based Approach.

DOI: 10.5220/0012090600003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 159-170

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

159

agrees to a medical intervention, procedure, or treat-

ment after being fully informed of the risks, beneﬁts,

and alternatives or agree to share personal health data

to participate in clinical trials or research experiments

(Falagas et al., 2009). Informed consent empowers

patients to make decisions about their health and well-

being that are in their best interests. The purpose of

informed consent is to protect the autonomy and dig-

nity of the patient by giving them control over their

health and treatment decisions. It helps to build trust

between the patient and the healthcare provider. In-

formed consent is typically governed by laws and reg-

ulations such as the General Data Protection Regula-

tion (GDPR) in Europe or the California Consumer

Privacy Act (CCPA) in the United States to avoid fu-

ture legal issues and conﬂicts (Gopal et al., 2023).

While informed consent plays a critical role in the

patient’s healthcare, it is quite challenging to man-

age informed consent properly, preserving the privacy

and security of patient health data. Patients often

consent to users like treatment team members, physi-

cians, nurses, support staff, lab technicians, insurance

companies, family member(s), and other providers.

When patients need more advanced care or counsel-

ing from doctors, like specialists, they must go to a

different hospital. Due to work transfers and family

movements, patients must move to other regions, like

new states or countries. It is sometimes unavoidable

to change health plans or insurance company cover-

age. Patients must revoke access rights granted in the

past but no longer needed or valuable. Patients also

give emergency access permissions where there might

be an emergency, like an accident or life-and-death

situation, and patients cannot approve access permis-

sion instantly. In this case, assigned emergency treat-

ment team members must access admitted patients’

data without their consent (de Oliveira et al., 2023).

We believe the following problems must be ad-

dressed to protect healthcare data from unauthorized

access and preserve patients’ autonomy over their

consent and healthcare resources.

- Individual patient-level policies are not enforced

properly, otherwise known as informed consent.

- Centralized hospital system acts as a single point

failure and source of truth of access audit trails.

- Lack of consent provenance information or unal-

tered source of given consent execution.

- Patients are not assured that the intended users ex-

ecute given consents. Other requests are denied.

- No guarantee that consents are executed only

when included conditions are satisﬁed; otherwise,

denied.

- Patients lack control over their consent to control

their health record access.

In this paper, we propose a decentralized dis-

tributed ledger (DLT) (Altarawneh et al., 2020) pow-

ered with smart contracts (Buterin et al., 2014) to

address the above-mentioned challenges and require-

ments. We propose a blockchain and smart contract-

based informed consent management and enforce-

ment framework, which runs on top of a public

blockchain such as Ethereum (Buterin et al., 2014).

This smart contract-based approach provides an au-

tomated system and guarantees the integrity and ac-

countability of the given informed consent. However,

this proposed approach does not address patients’ pro-

tected healthcare data. For this reason, we do not fo-

cus on healthcare data security and privacy issues.

DLTs such as blockchain provide proofs that sub-

mitted acts are immutable; it keeps the audit trail’s in-

tegrity and can detect any changes that shouldn’t have

been made. Blockchain security properties, such as

nonrepudiation, are also guaranteed, where no partic-

ipants can deny submitting changes. Smart contracts

ensure the proper execution of informed consent and

prevent random access. Also, smart contracts emit

event information if there are any operations. To the

best of our knowledge, this work is the ﬁrst to cap-

ture patients’ informed consent for disease diagnosis

and clinical treatment. Our contributions include the

following:

- A novel way of implementing Informed Consent

for medical diagnosis and treatment. Also, storing

in decentralized and distributed networks to over-

come a single point of truth sources and failure.

- Enforcing mechanism to authorization module

ensuring informed consent is evaluated and en-

forced while making authorization to access pa-

tient health records.

- Some consent services are proposed with sample

graphical representations to provide patients with

concise and informative reﬂections on informed

consent.

- Certain fundamental consent management consid-

erations and operations to support patients’ treat-

ment ﬂow and avoid unwanted health data access.

The remainder of the paper is organized as fol-

lows. We discuss some related works in Section 2.

Section 3 explains the proposed system with required

components. Sections 4 and 5 discuss consent ser-

vices and management. Section 6 contains the exper-

imental evaluation of the proposed model. In Section

7, we wrap up the paper with what to do next.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

160

2 RELATED WORK

Several suggestions exist for adopting blockchain

technology in healthcare and e-health systems. So far,

this research has been on how blockchain can protect

medical information and store and share medical data,

analytics, and informed consent systems for clinical

or research experiments. Research on informed con-

sent for clinical diagnosis and treatment is focused to

some extent (Ploug and Holm, 2012). To our knowl-

edge, ours is the ﬁrst work on employing blockchain

and smart contracts for clinical treatment informed

consent management and enforcement.

Authors in (Cunningham et al., 2022) propose

Non-Fungible Tokens (NFTs) as the mechanism for

recording and transmitting records of patients’ con-

sent for medical data use. The proposed model en-

ables subjects to record signed documents of consent

that permit Data Consumers to request medical data

from Data Providers in line with the consent given

by the subjects to whom that data pertains. However,

how NFTs can be used for provenance with regulatory

policies such as HIPAA/GDPR remains to be seen.

In (Azaria et al., 2016), authors propose MedRec,

a blockchain-based healthcare data access and per-

mission management system to handle electronic

medical records. The model addressed four signif-

icant issues: fragmented, slow access to medical

data; system interoperability; patient agency; and im-

proved data quality and quantity for medical research.

MedRec gives patients a complete, unchangeable log

of their medical information and makes it easy to get

it from their providers and treatment sites. References

to different kinds of medical data are put together and

encoded on a blockchain ledger to create an accessi-

ble trail for medical history.

Xia et al. (Xia et al., 2017) propose a blockchain-

based data-sharing framework that addresses the ac-

cess control challenges associated with sensitive data

stored in the cloud using the blockchain’s immutabil-

ity and built-in autonomy properties. Yue et al. (Yue

et al., 2016) propose a blockchain-based app, Health-

care Data Gateway, where patients securely own, con-

trol, and share their data. Untrusted entities can han-

dle healthcare data using secure multi-factor comput-

ing to protect patient privacy. In (Fan et al., 2018),

the authors propose a blockchain-based information

management system, MedBlock, that allows efﬁcient

EMR access and retrieval. It protects users’ pri-

vacy with custom access control protocols and en-

cryption technology while sharing data. Zyskind et

al., (Zyskind et al., 2015) propose blockchain for ac-

cess control management and secure data storage. En-

crypted data is kept on servers that can be trusted.

A blockchain-based dynamic consent manage-

ment architecture, ConsentChain, is offered by (Al-

balwy et al., 2021) in facilitating the exchange of

clinical genomic data. ConsentChain is built on the

Ethereum platform, and smart contracts are used to

model the actions of patients (who can give or take

back permission to share their data), data creators

(who collect and store patient data), and data re-

questers (who need to query and access the patient

data). However, this work mainly focuses on pa-

tient genome data sharing with clinicians, researchers,

and bioinformaticians. Clinical treatment imposes

different requirements for consent management than

genome data sharing. Many users perform various op-

erations in treatment processes, such as reading, writ-

ing, modifying, and others, and access privileges are

assigned based on the role of the users. We propose

a consent management framework to address com-

plex permission assignment requirements for treat-

ment team members, insurance agents, external doc-

tors, pharmacists, etc.

The researchers,(Tith et al., 2020), propose an

e-consent management model that uses Hyperledger

Fabric blockchain and a purpose-based access control

scheme. All patient records, consents, and metadata

about data access are written on the blockchain and

are shared among the organizations taking part. A

Chaincode performs business logic for managing pa-

tient consent. Patients can create, update, and with-

draw their consent in the blockchain. The proposed

model can be used for data donation for biobank re-

search purposes besides sharing patient data. How-

ever, the Hyperledger blockchain is a permissioned

blockchain network where participants are limited

to the organizations. It doesn’t provide the public

eye to provide trust. We adopt the public Ethereum

blockchain network where participants with stakes

can join and maintain the ledger to provide immutable

information to untrusted network participants. Most

important, Ethereum’s public consensus mechanism

adds more transparency than a permissioned network.

In addition, Ethereum smart contracts are the most

used, and there are many projects of development and

reﬁnements.

3 PROPOSED APPROACH

The main idea is to integrate components of informed

consent into the patient-provider agreement. Then

create and deploy smart contracts for informed con-

sent components in the blockchain network. The

authorization module calls the corresponding smart

contract for an access request to enforce informed

Informed Consent as Patient Driven Policy for Clinical Diagnosis and Treatment: A Smart Contract Based Approach

161

consent. The request speciﬁes which subject wants

to perform which operation on what objects under

what constraints or conditions. Once the smart con-

tract is called and the authorization module decides,

the corresponding event information is recorded as

logs in the blockchain network. Smart contracts

auto triggering feature automatically emits event or

activity data without missing any speciﬁed and re-

quired components. Event or activity data is stored

on the blockchain network. The blockchain net-

work provides a distributed, immutable, and decen-

tralized storage platform. This ensures that deployed

smart contracts provide original consent made with

the agreement of the patient and provider. It also

ensures that event logs are the same as created and

stored without any modiﬁcation. Figure 1 shows the

proposed approach. With the necessary parameters,

the following discusses the patient-provider agree-

ment, informed consent components, consent smart

contract generation, consent enforcement, and patient

interaction with the blockchain network services.

3.1 Patient-Provider Agreement (PPA)

The patient-provider agreement aims to determine

who is responsible for what in treatment. The goal

is to improve outcomes, lower risks, and educate pa-

tients better. A multi-center study (Pergolizzi et al.,

2017) evaluated the utility of the PPA, how readily pa-

tients understood it, its ability to educate patients in an

unbiased way about treatment, and the feasibility of

incorporating a PPA in clinical practice. Both patients

and doctors believe this PPA helped them decide on

a course of treatment and was fair in laying out the

treatment’s risks and beneﬁts. Most patients reported

the PPA to be ”somewhat helpful” or ”very helpful”

in deciding on a course of treatment and ”easy to un-

derstand.” A PPA, also known as a contract, differs

from organization to organization. Healthcare organi-

zations adjust what they need from patients and what

they expect from them to match those needs, treat-

ments, and responsibilities. This is done based on the

nature and needs of treatment and services. Also, the

components and representation of the PPA depend on

the hospital or clinic. Examples include general hos-

pitals, emergency rooms, urgent care or walk-in clin-

ics, dental care, cancer treatment, physiotherapy, etc.

The patient-provider agreement is depicted in Fig-

ure 1 with necessary components. The Patient-

Provider Agreement formally is composed of four tu-

ples:

PPA = (PC, PrC, ROC, ICC)

satisfying the following requirements:

(i) PC is a ﬁnite set of patient components contain-

ing patient’s personal information, contact in-

formation, mailing information, pharmacy infor-

mation, billing and insurance information, emer-

gency contact, and others. The patient is responsi-

ble for providing and maintaining valid informa-

tion for these components.

(i) PrC is a ﬁnite set of provider components, in-

cluding the treatment team, anonymous data shar-

ing for research, prescription, and others. Treat-

ment team members for a patient include doctors,

nurses, support staff, lab technicians, and billing

ofﬁcers. As the treatment period for a patient, ev-

erything from treatment to insurance coverage and

billing is considered.

(iii) ROC is a ﬁnite set of regulatory and other com-

ponents. It has applicable security and privacy

policy to comply with the local government, reg-

ulatory agencies (HIPAA, GDPR), federal gov-

ernment, and foreign government requirements if

necessary.

(iv) ICC is a ﬁnite set of informed consent compo-

nents. It indicates the permission given by the pa-

tient to access healthcare data.

This work mainly focuses on ICC and does not

consider and discuss PC, PrC, and ROC. They are

the future scope of this paper. Algorithm 1 shows the

step-by-step instructions for creating a PPA with PC,

PrC, ROC, and ICC. A patient-provider agreement is

formed when a patient visits a hospital. The terms and

conditions of the contract make it invalid after a cer-

tain period. There may be several contracts for a sin-

gle patient. Several patient-provider agreements must

be created and properly documented to deliver health-

care services. Managing many contracts involves var-

ious things, such as contract creation, development,

testing, updating, etc. If the requests contain con-

tracts, the authorization module must consider those

with other required policies when making access de-

cisions. From Figure 1, it is seen that the proposed

model stores the integrity of a PPA to the blockchain

network to ensure the detection of any modiﬁcation,

intentionally or unintentionally.

3.2 Informed Consent Components

Before giving consent, patients need to know every-

thing about the particular consent. Figure 2 shows

the informed consent conceptual framework structure.

The Informed Consent formally is composed of four

tuples:

IC = (U, O, OP, CON)

satisfying the following requirements:

SECRYPT 2023 - 20th International Conference on Security and Cryptography

162

Figure 1: Proposed Smart Contract-Based Informed Consent Management Framework.

Algorithm 1: Patient-Provider Agreement (PPA).

Input : Patient Components (PC), Provider Components (PrC),

Regulatory and Other Components (ROC), and

Informed Consent Components (ICC).

Output: An formal agreement between patient and provider

(PPA).

1 Input Parameters Initialization Patient-Provider Agreement

PPA

:= {PC

, PrC

, ROC

, ICC

} where i indicates patient

identity; PC := {PC

, PC

, ........PC

}

2 PrC := {PrC

, PrC

, ........PrC

}

3 ROC := {ROC

, ROC

, ........ROC

}

4 ICC := {ICC

, ICC

, ........ICC

}

5 Agreement Parameters Hash Calculation /* Hash(input) is

a function to calculate hash of input */

6 Hash

← Hash(PC

, PC

, ........PC

)

7 Hash

PrC

← Hash(PrC

, PrC

, ........PrC

)

8 Hash

ROC

← Hash(ROC

, ROC

, ........ROC

)

9 Hash

ICC

← Hash(ICC

, ICC

, ........ICC

)

10 Hash

PPA

← Hash(Hash

, Hash

PrC

, Hash

ROC

, Hash

ICC

)

11 Patient-Provider Agreement Finalization

12 if PPA

is complete then

13 /* complete means presence of PC, PrC, ROC,

and ICC */

14 add PPA

to patient-provider agreement repository and

return ID

PPA

;

15 add ID

PPA

and Hash

PPA

to blockchain network;

16 else

17 Error: PPA

can not be created

18 /* incomplete patient-provider agreement */

19 end if

(i) U is a ﬁnite set of authorized users denoted as

, u

, .....}. The user can perform certain

operations on healthcare resources when certain

conditions are satisﬁed.

(i) O is a ﬁnite set of protected objects otherwise

known as protected healthcare resources. A

ﬁnite set of protected objects (O) denoted as

, o

, .....}.

(iii) OP is a ﬁnite set of operations denoted by

{op

, op

, ...}. Operations represent the sys-

tem actions that authorized users can perform on

the objects. Examples of operations are read,

write, and update.

(iv) CON is a ﬁnite set of conditions. It indicates the

conditions that must be satisﬁed by the user to

perform operations on the protected objects. A

ﬁnite set of conditions, CON, can be denoted as

{con

, con

, ...}.

There are many users in the healthcare system.

Each user plays a different role and responsibility in

performing their job. Treatment team members for a

patient include doctors, nurses, support staff, lab tech-

nicians, billing ofﬁcers, the patient’s emergency con-

tact person, and other hospital employees assigned by

the authority. Some outsider members are insurance

agents, pharmacists or pharmacy technicians, doctors

or lab technicians from another hospital. As the treat-

ment period for a patient, everything from treatment

to insurance coverage and billing is considered. In-

formed consent users can be anyone from ﬁve groups

of people: (i) treatment team member, (ii) emergency

contract, (iii) external users, (iv) insurance company

agent, and (v) pharmacy. External users are from dif-

ferent hospitals when a patient is transferred for better

treatment if the situation demands it. Usually, exter-

nal users have temporary access to admitted patients’

health records.

The term object refers to an electronic version of a

patient’s medical history kept on ﬁle by the healthcare

provider over time. It may include all the administra-

Informed Consent as Patient Driven Policy for Clinical Diagnosis and Treatment: A Smart Contract Based Approach

163

Figure 2: Informed Consent Components.

tive and clinical information pertinent to the patient’s

care under a speciﬁc provider, such as demographics,

progress notes, issues, medications, vital signs, previ-

ous medical history, immunizations, laboratory infor-

mation, and radiology reports. These objects must be

protected from unauthorized users. The main purpose

of informed consent permitting by patients to users to

perform certain operations.

Many operations are executed by the authorized

in the healthcare industry to perform required op-

erations. Some common operations are view/read,

add/write, update/modify, delete, etc. In the view

operation, users can only view or read healthcare

records or resources if the request is valid and com-

plies with all applicable policies. The state of the

data is not changed in this operation, ensuring data

integrity. But it can compromise conﬁdentiality and

privacy if the access requested is granted without ap-

propriate credentials. On the other hand, the write op-

eration changes the state of the records or healthcare

data. If proper policy enforcement is not ensured, it

breaks the integrity of the data.

There might be various constraints or conditions

under which certain consent can be enforced, rejected,

revoked, and others. The conditions can be but are not

limited to:

(i) Time Constraints. In time constraints, any user

can access a patient’s healthcare data within a cer-

tain time. For example, the time condition for

consent is regular ofﬁce hours: 8 am-5 pm. In this

case, the request is rejected if any subject wants to

access the patient’s record beyond this time. The

attempt is recorded as an audit trail event.

(ii) Date Constraints. The date constraints limit the

calendar date. No access request is granted be-

yond the intended date.

(iii) Day Constraints. Day conditions can in-

clude work days (Monday-Friday), weekends

(Saturday-Sunday, holidays, etc. Based on the

day, the subject can access data. Suppose a reg-

ular doctor has a duty on workdays. On weekends

no access is given to that doctor.

(iv) Location-Based Constraints. The location-based

condition allows users to access information from

a certain location, like a hospital building, inside

an emergency room for treating emergency pa-

tients, and others.

(v) IP-Based Constraints. IP-based condition lim-

its healthcare users from accessing resources from

certain IPs. Devices IPs must be from the known

list; otherwise, no access is granted.

(vi) Access Frequency Dependent. A user can op-

erate for a certain number in access frequency-

dependent conditions. Suppose an external doctor

is given ﬁve times view permission. Once the doc-

tor reads the patient’s speciﬁed records ﬁve times,

the given consent is expired, and access is denied.

There is no access without getting new consent.

The above mentions list is not ﬁxed for the con-

ditions, but we consider them for this study. There

might be other conditions depending on the treatment

SECRYPT 2023 - 20th International Conference on Security and Cryptography

164

nature, patient characteristics, provider business pol-

icy, nature, etc. With sophisticated technology, ma-

licious attackers can spoof the conditions to fool the

system into accessing healthcare data and other com-

promised credentials. Proper layered defense mecha-

nisms must be deployed to ensure that conditions’ cre-

dentials are accurate, not fabricated or manipulated.

3.3 Consent Smart Contract Generation

Once a patient-provider agreement or PPA is cre-

ated and stored in the repository, all informed consent

components are deployed as smart contracts. The pa-

tient owns all the deployed contracts. The authoriza-

tion module needs to access these smart contracts to

make decisions with other components such as sub-

ject attributes, object attributes, operations attributes,

environmental attributes, organizational policies, reg-

ulatory and other policies, and others required. Algo-

rithm 2 shows the steps to develop and deploy smart

contracts for informed consent components. The

smart contract deployment unit, SCDU, collects all

consent components from PPA and checks integrity

to conﬁrm that collected consents are not modiﬁed de-

liberately or inadvertently. In step 3 in Figure 1, PPA

integrity as the hash from Algorithm 1 (Hash

PPA

) is

stored in the blockchain network along with PPA id.

To verify PPA integrity, SCDU calls the corre-

sponding smart contract function to retrieve the PPA

hash value stored in the network. Any modiﬁcation of

consent components voids the consent. If there is no

modiﬁcation, then SCDU creates and deploys smart

contract(s) to the blockchain network. Once the con-

tracts are deployed, the contract addresses are added

to the patient’s proﬁle and hospital systems. The con-

tract address is an identiﬁer for a smart contract in the

blockchain network.

3.4 Consent Enforcement

Enforcing informed consent is essential to protect pa-

tient’s rights and autonomy and ensure that medical

treatments are performed with the patient’s complete

understanding and agreement. Healthcare organiza-

tions and providers must take the informed consent

process seriously and provide patients with all the

information they need to make informed decisions

about their medical care. Consent enforcement en-

sures that related consents are executed while mak-

ing access decisions for the requests. In the proposed

model, all consents are stored on the blockchain net-

work as smart contracts and can not be enforced un-

til they are called. The authorization module (AM)

considers a patient’s consent while making an autho-

Algorithm 2: Informed Consent Smart Contract.

Input : Informed Consent Component ICC.

Output: Smart contract contains informed consents elements

ICC from patient-provider agreement PPA.

1 Initialization Informed Consent IC

:= {Sub, Op, Ob j, Cond}

where Sub, Op, Ob j, Cond represent one or more individual

attribute(s) and i represents patient identity; Subject Attributes

Sub := {SubAttr

, SubAttr

, ........SubAttr

} Operation

Attributes Op := {OpAttr

, OpAttr

, ........OpAttr

} Object

Attributes Ob j := {Ob jAttr

, Ob jAttr

, ........Ob jAttr

}

Conditions Cond := {CondAttr

, CondAttr

, ........CondAttr

}

2 Smart Contract Generation and Deployment if IC

is complete

then

3 /* complete means presence of Sub, Op, Ob j,

and Cond with patient consent */

4 IC

is added to smart contract

5 else

6 Denied: smart contract for IC

can not be created and

deployed

7 /* incomplete informed consent component */

8 end if

rization decision. The user submits requests to AM

for authorization to operate on an object. The user

also must provide the required credentials for identi-

ﬁcation purposes. The AM needs to consider differ-

ent attributes with required policies for making deci-

sions. It also requires considering informed consent

from the patient for that requested subject. The other

points are subject, object, operation, and environmen-

tal attributes.

Figure 3: Informed Consent Enforcement Process.

Figure 3 shows the sequence diagram of AM and

informed consent interaction. When a subject submits

a request to AM. Then the AM queries the blockchain

Informed Consent as Patient Driven Policy for Clinical Diagnosis and Treatment: A Smart Contract Based Approach

165

network through the corresponding smart contract to

get the informed consent information for the sub-

ject. If the subject has consent from the patient for

the requested resources and other conditions, then the

AM evaluates other parameters and informed consent

to make ﬁnal authorization. Finally, the AM gen-

erates the granted decision otherwise rejected for a

legitimate request. After deciding, AM sends audit

trail information to the smart contract to write in the

blockchain network. For this study, it is considered

that the authorization module is not compromised or

tampered with. Also, the communication channel be-

tween AU and the smart contract access points or apps

is secured from malicious users.

3.5 Patient Interaction

Patients must interact with the proposed system using

a GUI, apps, or abstraction. Different wallets, such as

Coinbase and MetaMask, interact with the blockchain

network to sign the transactions and manage cryp-

tocurrencies or tokens (He et al., 2020). Wallets store

private keys and other credentials for the users. Var-

ious types of users need to use the system. Some

users need specially designed software interfaces or

apps to interact with the systems (Mtshali and Khu-

bisa, 2019). These users include older adults or se-

nior citizens with limited knowledge of information

technology, physically disabled people, minors, and

other notable people. However, this work focuses on

designing mechanisms to record patients’ informed

consent for disease diagnosis and clinical treatment.

Hospitals or healthcare providers can serve the unique

needs of particular users for their patients. Patients

do not need to understand the underlying technolo-

gies, such as blockchain, smart contracts, distributed

systems, consensus mechanisms, etc. We assume that

patients’ devices, as well as apps, are protected from

intruders. Also, communication between patients’ de-

vices/apps and blockchain network nodes is secured.

3.6 Consent Operational Costs

Some blockchain-based frameworks need transaction

fees, like Gas in Ethereum. The gas consumption or

transaction fee is considered for research and techni-

cal aspects, not from the patients’ or users’ perspec-

tive. Healthcare providers can spend on infrastructure

expenses such as blockchain network nodes, apps for

mobile devices to interact with hospitals, blockchain

systems, and others. There are direct costs regarding

storing informed consent on public blockchain net-

works like Ethereum. The patients, insurance com-

panies, and others can cover these costs, like doctors’

fees, medications, pathology lab tests, radiology lab

tests, and other direct/indirect costs related to treat-

ment. In blockchain networks, state change opera-

tions require spending money, while reading from the

network does not need monetary expenditure. Once

informed consents are deployed to the blockchain net-

works, relevant users can access them without spend-

ing charges.

3.7 Consent Indexing and Query

We know the importance of informed consent index-

ing and query mechanism to provide efﬁcient queries

for consent enforcement and patient interaction. For

this work, we assume that the search operations are

done by the corresponding smart contracts efﬁciently

from the blockchain network. However, detailed in-

dexing and search mechanisms are our future com-

munication.

4 CONSENT SERVICES

Patients need to know they can get information about

their consent given to whom, for what purpose, on

what resources, and under what conditions. They

can also learn how their consent is carried out, such

as who does what operation and when. This section

discusses user and resource-oriented consent services

available for patients through the proposed framework

with the required credentials. There might be other

services for given and executed consents, such as

operation-oriented, date-oriented, and so on (Albalwy

et al., 2021). Additional services are not discussed

in this paper because of space limitations. However,

there should be some assurances regarding the given

and executed consents. Guarantees can be served

through different consent services. The main objec-

tive is to provide patients with concise and informa-

tive reﬂections on informed consent.

User-Oriented Services. In this service mode, a

patient is aware of a speciﬁc user’s consent. It dis-

plays a list of resources for which the user has ob-

tained the patient’s permission to perform certain op-

erations. The application conditions, such as access

frequency, start and end dates, and other speciﬁc re-

quirements, are also included. The audit trails are

available to the patient if a user performs any opera-

tion on any resource. So that the patient can check all

of the user’s consents. Figure 4 depicts all given con-

sents for a doctor, David, on patient Jordan

′

s health

records: Visit Notes, Prescription, Radiology Lab Re-

port, Pathology Lab Report, and Immunization His-

tory with operations and conditions. While all exe-

SECRYPT 2023 - 20th International Conference on Security and Cryptography

166

cuted consents are shown in Figure 5 with operations,

access frequency, and access time.

Figure 4: User-Oriented Given Consents.

Figure 5: User-Oriented Executed Consents.

Resource-Oriented Services. Patients may need to

know the given and executed consent for a particu-

lar resource or object. In an object-oriented given

consent service, all permissions are listed, like who

has which operation consent under what conditions.

Figure 6 shows a sample presentation of an object-

oriented given consent. Each user has some opera-

tions and requirements for the object. While Figure

7 depicts the executed authorizations for an object. It

shows several events where each event contains which

subject performs what operation when and other in-

formation.

Figure 6: Object-Oriented Given Consents.

Patient consent service gives an overview of the is-

sued and executed consents. A patient needs to know

Figure 7: Object-Oriented Executed Consents.

the moment consent status. This service must be un-

ambiguous, uninterrupted, unaltered, real-time, and

easily understandable for the patients. In this work,

we present some possible applications of consent ser-

vices. In future directions, we want to implement

consent services using graph databases. Consent-

related information is collected from the blockchain

network and processed as graph databases to reﬂect

the consent status more presentable, understandable,

and meaningful for the patients.

5 CONSENT MANAGEMENT

This section brieﬂy explains consent management

requirements and various operations: consent gen-

eration, modiﬁcation, withdrawal, expiration, and

archiving. It is essential to ensure that operations do

not introduce privilege conﬂicts, leakages, or incom-

plete treatment teams. The most important point is

ensuring that consent modiﬁcation, withdrawal, or ex-

piration does not interrupt the treatment process. For

example, if consent for an insurance agent is revoked,

that agent cannot access or process patient coverage

billed by the hospital. They can refuse the treatment if

the hospital is not paid promptly. Consent can include

information about the people using it, the resources

it will use, the activities it will be used for, certain

conditions, and other relevant information. Due to

page constraints, technical mechanisms or speciﬁca-

tions for operations are not included, and they are the

future scope of this work.

Management Considerations. Consent manage-

ment is integral to providing healthcare services be-

cause it involves collecting, storing, and managing

information about patient consent. Effective consent

management requires paying close attention to sev-

eral important factors, such as: (i) legal and ethical

requirements; (ii) patient autonomy; (iii) data pri-

vacy and security; (iv) interoperability; (v) user ex-

perience; (vi) continuous improvement; and (vii) oth-

ers. Consent management is a complicated, multi-

step process that needs to be carefully thought out

to work well, be efﬁcient, and meet all relevant stan-

dards and requirements.

Informed Consent as Patient Driven Policy for Clinical Diagnosis and Treatment: A Smart Contract Based Approach

167

Consent Generation. In this process, new consent is

created or generated. The detailed functionalities are

given in section 3 with the necessary components and

their interactions. Further consent can cause conﬂict

with the existing consent. So, it needs to be checked

before adding permission to the repository to ensure

no conﬂict of privileges. Once the veriﬁcation is done,

the approval is activated for the users.

Consent Modiﬁcation. Sometimes, it is neces-

sary to update a consent for various reasons: (i) hav-

ing error(s), (ii) modifying current user(s), object(s),

or condition(s), (iii) adding new user(s), entity(s), or

condition(s), (iv) dropping user(s), object(s), or con-

dition(s), and others. If any modiﬁcation occurs, the

old consent is added to the consent archive reposi-

tory and referred to as a pointer to the new permis-

sion. When giving and taking consent, the wrong peo-

ple, resources, operations, or conditions can be added

unintentionally. This could lead to some unwanted

events, including security incidents. Once a mistake

is realized, it must be ﬁxed immediately to avoid un-

wanted incidents.

Consent Withdrawn. Approval withdrawal happens

if patients do not want to share their data anytime.

In another case, if consent is given to the wrong per-

son or includes some extreme conditions, the given

authorization can be revoked by the patient or hos-

pital authority. When consent is withdrawn, related

users or entities must be notiﬁed. It is added to the

consent archive database to solve legal and regulatory

problems if consent is ever taken away. If given con-

sents are essential to the patient’s treatment and are

taken out before the treatment is over, there may be

some consequences, like an interruption in treatment

or drug supply.

Consent Expiration. A given consent can be voided

if unmet conditions exist. Conditions could be a spe-

ciﬁc date, access frequency, and so on. For example,

a doctor consents to view or read healthcare data for a

particular patient. The approval includes a condition

that access can be granted ﬁve times. The consent ex-

pires when the doctor reads or views the patient’s data

ﬁve times. If the doctor tries to access it for the sixth

time, the system fails to authorize it since there is no

consent for this access attempt. There can be multiple

conditions for approval that keep the support active or

valid. All conditions should be checked automatically

by systems instead of manually. Manual checking can

introduce delays or be overlooked by the correspond-

ing users.

Consent Archiving. Modiﬁed, withdrawn, and ex-

pired consents are added to this read-only repository.

No consent is active in this database. The main goal

of this repository is to store consent metadata that can

be used to answer any questions that come up because

of legal or regulatory requirements. Patients can also

see all the previously given consents that have been

modiﬁed, withdrawn, or expired.

Implementation. We implement a smart contract,

”ConsentManagement,” in Ethereum using Solidity

language to perform consent management operations.

Consent generation is done by the proposed smart

contract deployment unit in Section 3.3 using Algo-

rithm 2. In addition, the ConsentManagement con-

tract would perform consent modiﬁcation and with-

drawal invoked by the consent owner or patient. Con-

sent expiration and archiving operations must be done

automatically as default functions when the condi-

tions are present.

6 EXPERIMENTAL EVALUATION

We implement smart contracts to interact with the

Ethereum test network, Goerli, to store and retrieve

given informed consent. We use the Python web3

framework Brownie and Ethereum solidity. We set

up a multi-signature wallet to perform consent man-

agement operations. It is two members and two out

of two (2 out of 2) control. Every member must sign

in to store the consent in the blockchain network. The

Healthcare Provider System deploys smart contracts

in the Goerli network and transfers ownership to the

corresponding patients. We use Metamask wallet to

sign the transaction to interact with the Goerli net-

work. Goerli faucet ethers are used as gas to send the

transaction. We leverage Infura API to interact with

the blockchain networks.

The Ethereum blockchain platform is selected for

the experimental purpose. It offers Turing complete

smart contract language, Solidity, and Vyper, to im-

plement the logic for the proposed model. Since de-

ployed codes stay in the blockchain network and can

not be changed. Deploying smart contract to the main

network with bugs or errors cost money and reputa-

tion. So it is essential to test smart contracts before

deploying them to the Ethereum main network. Go-

erli and Sepolia Ethereum test networks (Sivaselvan

et al., 2023) are currently available for testing smart

contracts. In the following, we discuss the main re-

sources: (i) time, (ii) computational, and (iii) gas re-

quired to deploy and evaluate the functionalities of

the proposed approach. Other resources are not con-

sidered for this work.

Time. Smart contract deployment and execution

stages are the basis of the time cost associated with

on-chain activities. Since the time it takes to double-

check and sign a transaction is entirely up to the user,

SECRYPT 2023 - 20th International Conference on Security and Cryptography

168

it is disregarded. The duration of a smart contract’s

deployment and execution is determined mainly by

how long it takes for the appropriate transaction to

be included in a block by miners. So, on average,

the duration of either process is about the same as

the time it takes for a transaction to be conﬁrmed on

the blockchain technology of ones choosing. A new

block is added to the Ethereum blockchain every 12

seconds, which is ideal for our purposes. It was 15

seconds in 2019 (Pierro and Rocha, 2019). So long

as there is sufﬁcient place in new blocks, a new trans-

action would take, on average, no more than 12 sec-

onds. The time it takes for a transaction to propagate

is more difﬁcult in practice. If block congestion oc-

curs, the time it takes for a transaction to be included

in a block might increase. However, blockchain users

can inﬂuence this time by paying more gas for faster

conﬁrmation. Given that users may artiﬁcially extend

the conﬁrmation time of their transactions.

Computational Resource. To deploy smart contracts

on the Ethereum test network, Goerli, the proposed

method uses Infura blockchain API services. Infura

(Panda and Satapathy, 2021) is a suite for building

blockchain applications. It has tools for developers

and application programming interfaces (APIs). In-

fura also gives developers quick and reliable access

to the Ethereum network, which lets them build so-

phisticated next-generation software and Web3 apps

that can grow to meet user demand. So, there is no

need to keep a blockchain node running to use smart

contracts. We assume that other resources like the

CPU, HDD, and communication bandwidth on the lo-

cal machine are negligible.

Gas Consumption. All the read calls of smart con-

tracts are gas-free. Gas is needed for any activity

on Ethereum that involves writing or changing data

(Wood et al., 2014). Some functions are sending ether

(or any other ERC20 token), minting and sending

NFTs, deploying smart contracts, changing the state

of the blockchain, and so on. For this work, we only

need to consider smart contract deployment and func-

tion calling costs to write data on the blockchain net-

work. The cost of smart contract deployment is pro-

portional to the size of the code. This is a one-time

cost for a single-contract deployment. How much it

costs to call a function depends on how many times

it is called and how much data needs to be stored or

changed on the blockchain network. Code optimiza-

tion is crucial to reduce gas costs. But instead of re-

ducing gas use, we focus on the model’s functions.

7 CONCLUSIONS

Consent to treatment is a crucial aspect of ethical and

practical healthcare delivery. It is necessary to ensure

that patients are fully informed, involved, and in con-

trol of their health and treatment decisions. Therefore,

healthcare providers must take the necessary mea-

sures to ensure patients understand their treatment

options and make educated decisions regarding their

treatment processes. In addition, it helps build trust,

empower patients, and improve the quality of care

provided. Informed consent is an ongoing process;

patients can change their minds and withdraw their

consent anytime. Also, it is not a one-time event but a

continuous process that starts before the intervention

and continues throughout the patient’s care.

Smart contract-based patient consent management

frameworks are emerging as a promising solution to

the challenges of managing health data in a secure and

privacy-preserving manner. Such frameworks ensure

that patients have control over their protected health

information (PHI) and can provide informed consent

for its use by healthcare providers, researchers, and

other stakeholders. In addition, blockchain technolo-

gies can ensure that consent is managed securely and

efﬁciently. At the same time, they can provide decen-

tralization, transparency, and immutability that can be

leveraged to improve healthcare auditability and ac-

countability for all stakeholders involved. Such in-

herent characteristics make it a potential solution for

healthcare data systems concerning sharing and pa-

tient privacy.

This work identiﬁes some important consent man-

agement operations for the uninterrupted treatment

process. However, there is a need for those oper-

ations to be speciﬁed and executed technically. In

the future direction, the detailed technical approach

will be worked on. Future research could also exam-

ine the ethical considerations of using blockchain and

smart contract technology in healthcare, implement-

ing and adopting smart contract-based systems in ac-

tual healthcare settings, and integrating smart con-

tracts with other emerging technologies.

ACKNOWLEDGEMENTS

This work was partially supported by the U.S. Na-

tional Science Foundation under Grant No. 1822118

and 2226232. Any opinions, ﬁndings, and conclu-

sions or recommendations expressed in this material

are those of the authors and do not necessarily re-

ﬂect the views of the National Science Foundation,

or other federal agencies.

Informed Consent as Patient Driven Policy for Clinical Diagnosis and Treatment: A Smart Contract Based Approach

169

REFERENCES

Albalwy, F., Brass, A., Davies, A., et al. (2021). A

blockchain-based dynamic consent architecture to

support clinical genomic data sharing (consentchain):

Proof-of-concept study. JMIR medical informatics,

9(11):e27816.

Altarawneh, A., Herschberg, T., Medury, S., Kandah,

F., and Skjellum, A. (2020). Buterin’s scalability

trilemma viewed through a state-change-based classi-

ﬁcation for common consensus algorithms. In 2020

10th Annual Computing and Communication Work-

shop and Conference (CCWC), pages 0727–0736.

Azaria, A., Ekblaw, A., Vieira, T., and Lippman, A. (2016).

Medrec: Using blockchain for medical data access

and permission management. In 2016 2nd Inter-

national Conference on Open and Big Data (OBD),

pages 25–30. IEEE.

Buterin, V. et al. (2014). A next-generation smart contract

and decentralized application platform. white paper,

3(37):2–1.

Cunningham, J., Davies, N., Devaney, S., Holm, S., Hard-

ing, M., Neumann, V., and Ainsworth, J. (2022). Non-

fungible tokens as a mechanism for representing pa-

tient consent. Studies in Health Technology and Infor-

matics, 294:382–386.

de Oliveira, M. T., Verginadis, Y., Reis, L. H., Psarra, E., Pa-

tiniotakis, I., and Olabarriaga, S. D. (2023). Ac-abac:

Attribute-based access control for electronic medical

records during acute care. Expert Systems with Appli-

cations, 213:119271.

Falagas, M. E., Korbila, I. P., Giannopoulou, K. P., Kondilis,

B. K., and Peppas, G. (2009). Informed consent: how

much and what do patients understand? The American

Journal of Surgery, 198(3):420–435.

Fan, K., Wang, S., Ren, Y., Li, H., and Yang, Y. (2018).

Medblock: Efﬁcient and secure medical data shar-

ing via blockchain. Journal of medical systems,

42(8):136.

Gopal, R. D., Hidaji, H., Kutlu, S. N., Patterson, R. A., and

Yaraghi, N. (2023). Law, economics, and privacy:

Implications of government policies on website and

third-party information sharing. Information Systems

Research.

He, D., Li, S., Li, C., Zhu, S., Chan, S., Min, W., and

Guizani, N. (2020). Security analysis of cryptocur-

rency wallets in android-based applications. IEEE

Network, 34(6):114–119.

Lorenzini, G., Shaw, D. M., Arbelaez Ossa, L., and El-

ger, B. S. (2022). Machine learning applications in

healthcare and the role of informed consent: Ethical

and practical considerations. Clinical Ethics, page

14777509221094476.

Marchand-Melsom, A. and Nguyen Mai, D. B. (2020). Au-

tomatic repair of owasp top 10 security vulnerabil-

ities: A survey. In Proceedings of the IEEE/ACM

42nd International Conference on Software Engineer-

ing Workshops, pages 23–30.

Mtshali, P. and Khubisa, F. (2019). A smart home appliance

control system for physically disabled people. In 2019

Conference on Information Communications Technol-

ogy and Society (ICTAS), pages 1–5. IEEE.

Panda, S. K. and Satapathy, S. C. (2021). An investigation

into smart contract deployment on ethereum platform

using web3. js and solidity using blockchain. In Data

Engineering and Intelligent Computing: Proceedings

of ICICC 2020, pages 549–561. Springer.

Parvin, A. (2022). Jurisprudential justiﬁcation of informed

consent in medical practice: A critical approach. Issue

5 Int’l JL Mgmt. & Human., 5:956.

Pergolizzi, J. V., Curro, F. A., Col, N., Ghods, M. P.,

Vena, D., Taylor, R., Naftolin, F., and LeQuang, J. A.

(2017). A multicentre evaluation of an opioid patient–

provider agreement. Postgraduate medical journal,

93(1104):613–617.

Pierro, G. A. and Rocha, H. (2019). The inﬂuence factors on

ethereum transaction fees. In 2019 IEEE/ACM 2nd In-

ternational Workshop on Emerging Trends in Software

Engineering for Blockchain (WETSEB), pages 24–31.

IEEE.

Ploug, T. and Holm, S. (2012). Pharmaceutical infor-

mation systems and possible implementations of in-

formed consent-developing an heuristic. BMC Medi-

cal Ethics, 13(1):1–12.

Seh, A. H., Zarour, M., Alenezi, M., Sarkar, A. K., Agrawal,

A., Kumar, R., and Ahmad Khan, R. (2020). Health-

care data breaches: insights and implications. In

Healthcare, volume 8, page 133. Multidisciplinary

Digital Publishing Institute.

Sivaselvan, N., Bhat, V., Rajarajan, M., and Das, A. K.

(2023). A new scalable and secure access control

scheme using blockchain technology for iot. IEEE

Transactions on Network and Service Management.

Staff, C. P. S. (2016). Regulatory compliance/lessons

learned from hipaa enforcement. Journal of the Cali-

fornia Dental Association, 44(11):703–704.

Sulmasy, L. S., L

opez, A. M., and Horwitch, C. A. (2017).

Ethical implications of the electronic health record: in

the service of the patient. Journal of general internal

medicine, 32(8):935–939.

Tith, D., Lee, J.-S., Suzuki, H., Wijesundara, W., Taira, N.,

Obi, T., and Ohyama, N. (2020). Patient consent man-

agement by a purpose-based consent model for elec-

tronic health record based on blockchain technology.

Healthcare Informatics Research, 26(4):265–273.

Wood, G. et al. (2014). Ethereum: A secure decentralised

generalised transaction ledger. Ethereum project yel-

low paper, 151(2014):1–32.

Xia, Q., Sifah, E. B., Smahi, A., Amofa, S., and Zhang,

X. (2017). Bbds: Blockchain-based data sharing for

electronic medical records in cloud environments. In-

formation, 8(2):44.

Yue, X., Wang, H., Jin, D., Li, M., and Jiang, W. (2016).

Healthcare data gateways: found healthcare intelli-

gence on blockchain with novel privacy risk control.

Journal of medical systems, 40(10):218.

Zyskind, G., Nathan, O., et al. (2015). Decentralizing pri-

vacy: Using blockchain to protect personal data. In

2015 IEEE Security and Privacy Workshops, pages

180–184. IEEE.

SECRYPT 2023 - 20th International Conference on Security and Cryptography

170
