An Empirical Study on the Possible Positive Effect of Imperative

Constructs in Declarative Languages: The Case with SQL

Seyfullah Davulcu, Stefan Hanenberg

, Ole Werger

and Volker Gruhn

University of Duisburg–Essen, Essen, Germany

Keywords:

SQL, Imperative, Declarative, Empirical Study.

Abstract:

Today, imperative programming languages are often equipped with declarative constructs (such as lambda

expressions in Java or C++). The underlying assumption (which is partly conﬁrmed by experiments) is that

imperative languages beneﬁt from such constructs. This gives the impression that declarative programming

languages are better suited for programming than imperative languages. However, the question is whether

this statement holds vice versa as well, i.e., whether declarative languages beneﬁt from imperative constructs.

The present paper introduces a crossover trial where 24 students were equipped with an SQL extension that

gives the illusion of imperative assignments. It turned out with high conﬁdence (p<.001) that this construct --

although in principle already contained in a declarative fashion in SQL -- lets students solve a given task in

only 52% of the time in comparison to the time required in standard SQL.

1 INTRODUCTION

Programming languages follow design principles and

one of the fundamental principles is whether a lan-

guage should rather be imperative or declarative. The

traditional distinction between both is that code writ-

ten in an imperative language describes step by step

how an algorithm is executed. Code written in a

declarative language rather speciﬁes how the result

looks like. Today’s examples of declarative lan-

guages are functional programming languages such

as Haskell, F#, Scala, etc., while today’s examples of

imperative languages are C, C++, or Java.

While imperative languages dominated the soft-

ware market, the situation changed over the years:

The functional construct “lambda expression” be-

came integrated in different imperative languages.

Moreover, tools such as IDEs also seem to see a

beneﬁt in lambda expressions. For example, already

in 2009 the IDE IntelliJ visualized anonymous in-

ner classes as lambda expressions. Hence, it looks

like there is some common agreement that impera-

tive languages beneﬁt from the integration of declar-

ative constructs – besides the fact, that there are only

few studies that measured the effect of declarative fea-

https://orcid.org/0000-0001-5936-2143

https://orcid.org/0009-0007-3226-1271

https://orcid.org/0000-0003-3841-2548

tures in imperative languages (see for example (Ues-

beck et al., 2016; Lucas et al., 2019; Hanenberg and

Mehlhorn, 2021; Mehlhorn and Hanenberg, 2022)).

However, one could also ask whether declarative lan-

guages beneﬁt from imperative language constructs.

And among the set of declarative languages, there is

one language that plays a major role in software de-

velopment: the database language SQL.

The present paper introduces an experiment where

SQL is equipped with a quasi–extension which gives

the illusion to assign queries to variables – an exten-

sion that is not necessary, because it already exists in

SQL to a certain extent. But by giving 24 subjects

a task where a query consists of a number of sub-

queries, it turned out that the subjects required only

52% of the time they needed using standard SQL.

2 SQL, WITH AND SQL

Assign

SQL is an ISO standardized language for relational

database systems

that is widely taught and applied

today. In relational databases, the fundamental data

structures are (named) tables having named (and

typed) attributes where the actual data is represented

by rows. The result of a SQL query is again a table.

The selection of data from tables is done via SE-

See iso.org/standard/63555.html

428

Davulcu, S., Hanenberg, S., Werger, O. and Gruhn, V.

An Empirical Study on the Possible Positive Effect of Imperative Constructs in Declarative Languages: The Case with SQL.

DOI: 10.5220/0012092300003538

In Proceedings of the 18th International Conference on Software Technologies (ICSOFT 2023), pages 428-437

ISBN: 978-989-758-665-1; ISSN: 2184-2833

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

LECT statements where within a FROM statement ta-

bles are combined by a number of different JOIN op-

erators. From the table that is the result of such oper-

ations certain rows can be selected via the WHERE

clause and ﬁnally, the SELECT statement deﬁnes

the resulting columns. Additional constructs are the

GROUP BY and HAVING clauses that permit to de-

ﬁne subtable. Moreover, SQL contains aggregate

functions, i.e., functions that are applied on all ele-

ments of (sub-) tables.

SQL is a declarative language in the sense that de-

velopers specify the conditions that hold on the result-

ing table without specifying how the underlying data

is iterated. An SQL query is one single expression.

Queries can be quite difﬁcult and it is possible that

parts of queries need to be used multiple times within

one SQL statement. This can be done, for example,

using the WITH clause. The WITH clause is one ex-

pression consisting of a header where a name is given

to one expression that later on can be used in the ex-

pression’s body.

WITH Amounts AS (SELECT C ust o m e r Id , SUM( Amount ) Res

FROM Payme nt

WHERE C u s t o m e r I d ! = 42

GROUP BY C u s t o m e r I d )

SELECT Custome r I D

FROM Amounts

WHERE Res > 12345

Figure 1: The result of one SELECT statement is given the

name Amounts that is used in the body of the WITH expres-

sion to refer to that statement.

An example for the WITH clause is given in Fig-

ure 1. One characteristic of the WITH clause is, that it

is still one single expression. I.e., one reads the whole

expression as one single execution step.

We are involved in SQL teaching and have the

impression that students have problems with WITH.

Our impression is, that WITH hinders students to

think about the clause as a step-by-step introduction

of names for expressions. As a consequence, we think

that students do not use WITH and rather formulate

SQL statements with subqueries – and we think this

makes students less efﬁcient.

An alternative way to formulate the above SQL

statement is to use subqueries. Figure 2 describes

the previous statement with a subquery. While the

statement is shorter, the potential problem is that it

no longer gives a clear description of the subquery:

just ﬁnding the name of the subquery (Amounts) is

not trivial, because it requires to identify the start and

the end of the subquery. On the other hand, due to its

shorter representation, it might seem attractive to stu-

dents to use this presentation instead of using WITH.

SELECT Custome r I D

FROM (SELECT Cus t o m e rId , SUM( Amount ) R e s u l t

FROM Payme nt

WHERE C u s t o m e r I d ! = 42

GROUP BY C u s t o m e r I d ) Amounts

WHERE R e s u l t > 12 345

Figure 2: Previous example using an inner statement.

Our idea was to give students a different construct

that comes (syntactically) closer to the idea of imper-

ative languages. Instead of writing a WITH clause,

we give them the illusion of a variable assignment in

a style known from languages such as Java, etc.: a

variable name on the left-hand side to which an ex-

pression is assigned. Additionally, in order to give an

impression of a sequence, we used (similar to Java)

the semicolon to separate different statements.

Amounts = (SELECT C us t o m e r Id , SUM( Amount ) R e s u l t

FROM Payme nt

WHERE C u s t o m e r I d ! = 42

GROUP BY C u s t o m e r I d ) ;

SELECT Custome r I D

FROM Amounts

WHERE R e s u l t > 1 2 3 4 5 ;

Figure 3: Previous example using SQL

Assign

Figure 3 illustrates the previous example using the

syntax of SQL

Assign

. Obviously, it is possible to trans-

late SQL

Assign

into SQL, where in front of an assign-

ment only the keyword WITH has to be introduced,

the equal operator has to be replaced by the keyword

AS and the semicolon has to be deleted. Again, it is

obvious that SQL

Assign

is only a different syntactical

representation of SQL that actually does not add any-

thing new. The only difference is, that it gives the

impression that different statements are sequentially

executed and it gives developers the illusion that the

complete SQL statement can be read line by line.

The obvious research question is:

RQ: Do Developers Beneﬁt From The Intro-

duction of SQL

Assign

in Comparison to Standard

SQL?

To answer this question, much more details are

required in order to understand under what circum-

stances such difference might appear, etc.

3 RELATED WORK

We are not aware of experiments that focus on im-

perative features in declarative languages. But some

studies analyze the effect of introducing declarative

An Empirical Study on the Possible Positive Effect of Imperative Constructs in Declarative Languages: The Case with SQL

429

features in imperative languages (despite the fact

that empirical studies in programming languages are

rather rare in general, see for example (Kaijanaho,

2015)). Additionally, we consider studies that focus

on the usability of SQL.

3.1 Studies on Imperative versus

Declarative Language Constructs

Uesbeck et al. (Uesbeck et al., 2016) tested on 58

participants whether there are differences in develop-

ment times for iterating collections using lambda ex-

pressions in C++ in comparison to traditional itera-

tors. It turned out that lambda expressions required

on average signiﬁcantly more time. The study also

took a look into error ﬁxing times and the number of

compiler errors. The results with respect to these de-

pendent variables again favored traditional iterators.

Mehlhorn et al. studied the effect of Java’s Stream

API in comparison to the imperative loops on read-

ability (Mehlhorn and Hanenberg, 2022) by measur-

ing the time until the correct result for some code was

detected. The study on 20 participants revealed the

opposite effect of Uesbeck’s study: the Stream API

code required less time than the imperative loops.

Another study on lambda expressions in Java was

performed by Lucas et al. (Lucas et al., 2019). The

authors evaluated code snippets before and after the

introduction of lambdas and compared it to some

source code complexity measures. Additionally, they

asked 28 developers to evaluate code snippets. The

main results of the study was that about 50% of the

developers considered the introduction of lambda ex-

pressions as an improvement. While the applica-

tion of readability and understandability metrics did

not ﬁnd signiﬁcant differences, developers perceived

some code migrations towards lambda expressions

negatively, especially when for-loops were replaced.

Pichler et al. (Pichler et al., 2011) studied dif-

ferences between declarative and imperative business

model languages. 28 students were given two types of

tasks and four questions per task

. The models were

formulated either using a declarative or an imperative

business process language. The language had an ef-

fect on the response times as well as on the correct-

ness of the answers (p<.001).

Although not explicitly meant to test whether a

declarative or imperative speciﬁcation is better (in

terms of development time, answer time, or correct-

ness), Kokuryo et al. studied how often imperative

code was written using the conﬁguration management

From the paper, it cannot be derived what questions

were asked or to what extent the questions were related to

the declarative or imperative nature of the given model.

tool Ansible (Kokuryo et al., 2020), a tool that is in-

tended to deﬁne conﬁgurations in a declarative man-

ner but that still provides imperative modules. The

study revealed, that about 50% of the studied codes

still used imperative modules.

3.2 Usability Studies on SQL

A study by Ahdi et al. tested common mistakes done

by more than 2000 students across eight years on a

data set consisting of more than 160 thousand snap-

shots of SQL queries. It turned out that a large per-

centage of errors was caused by syntactical errors –

approximately 54% of faulty queries even on trivial

statements contained syntax errors. The authors con-

clude from the study that “a syntactic error and not a

semantic error is what in most cases causes a student

to abandon answering a question. Syntax errors [...]

are the most common mistakes that novices make in

writing their SQL statements” (Ahadi et al., 2016).

A comparable study by Poulsen et al. (Poulsen

et al., 2020) followed the approach of Ahdi et al.

and studied a data set consisting of homework sub-

missions from 286 students. Again, the SQL state-

ments were classiﬁed according to their nature (joins,

outer joins, etc.), but additionally, slightly more com-

plex constructs (such as triggers or stored procedures)

were considered as well. Again, it turned out that in

almost all categories the number of syntax errors was

higher than the number of semantic errors.

And even

in the ﬁnal submissions (where students had the abil-

ity to double check their statements), still 27% of the

statements had syntax errors.

4 EXPERIMENT DESCRIPTION

4.1 Initial Considerations

SQL

Assign

was built upon the assumption that devel-

opers have the tendency to use inner statements in

SQL instead of applying the WITH clause. We be-

lieve that this happens in situations where develop-

ers write rather complicated queries that are based on

each other. For example, when it is clear from a task

description that a statements such as S1 needs to be

formulated whose results are required by a statement

S2, we think that developers have the tendency to start

with S1, but then, instead of giving it an explicit name,

just use the whole statement S1 within the body of S2.

There was one exception to this rule: in the group “Join

and Where” 39% of statements were syntactically incorrect,

while 43% of these statements had a semantic errors.

ICSOFT 2023 - 18th International Conference on Software Technologies

430

−− STEP1 : S t a r t i n g w i t h some c o m p l i c a t e d q u e r y

SELECT a , b , c

FROM A JOIN B USING( x )

WHERE d=42

GROUP BY a , b , c

HAVING sum ( e ) >666

−− STEP 2 : U s i n g f i r s t S t a t e m e n t as I n n e r S t a t e m e n t

SELECT a , sum ( b )

FROM (SELECT a , b , c

FROM A JOIN B USING( x )

WHERE d=42

GROUP BY a , b , c

HAVING sum ( e ) >66 6 ) c omplexQ u e r y

GROUP BY a

HAVING sum ( b ) > 999

Figure 4: Stepwise formulation of SQL queries using inner

statements.

Figure 4 illustrates the described situation. If the

task consists of multiple steps, we think that a number

of people start with the ﬁrst step and start with step 2

when they think they have ﬁnished step 1. But in-

stead of just using the WITH clause, we think people

rather continue writing the query by adding the addi-

tional code to the statement – as a consequence, the

ﬁrst statement becomes an inner statement. We think

that this approach becomes more problematic if the

inner statement requires some changes later on. From

that we conclude that for the comparison of standard

SQL and SQL

Assign

non-trivial queries are necessary

that should be formulated in a step-wise manner.

Having the previous considerations in mind, we

took two different approaches into account. First, our

idea was to give people code to read that consists of

inner queries, WITH clauses or the assignment ex-

pressions using SQL

Assign

. Actually, we do believe

that SQL

Assign

has already some (small) positive ef-

fect on readability, but we still think that such an ex-

periment is not trivial, because one has to deﬁne under

what circumstances a developers has actually under-

stood the semantics of the query. Additionally, we

do not think that the measured effect is large, because

we think a larger, positive effect predominantly shows

up when developers need to interact with the code

(rewriting a query, replacing parts of a query, etc.).

We have chosen a different alternative. Instead

of reading code, we let developers formulate a query.

While one approach could be to give developers a ﬁ-

nite amount of time and check how many developers

have ﬁnished the task, it could also be an alternative

to give developers multiple tasks in order to test, how

many tasks each developer has fulﬁlled (an approach

that has been used for example in (Uesbeck et al.,

2016)), and ﬁnally, one could in principle check, what

percentage of the task was fulﬁlled (an approach that

was for example chosen in (Müller, 2005; Hanenberg,

2010)). Having the assumed beneﬁt of SQL

Assign

mind, we followed the approach to give developers

one (or more) programming tasks and to measure how

much time was required to fulﬁll the task.

Next, the question is, what experiment setup is

required. Although we had the impression that the

differences between SQL and SQL

Assign

are not tiny,

we were afraid that the deviation between develop-

ers could possibly hide this effect. However, so-

called crossover trials (see for example (Senn, 2002;

Kitchenham et al., 2003)) – experiments where devel-

opers are tested under different treatments – are an

often applied technique to reduce this problem.

4.2 Task Description

As noted, we are not convinced that a variable assign-

ment has a positive effect in all situations. We think

the beneﬁt shows up if queries are formulated step by

step and if SQL tempts developers (for unknown rea-

sons) to use inner statements. Hence, the task should

be a query where its parts are deﬁned step by step.

Next, the query should be easily testable and the prob-

ability to achieve a correct query by luck should be

low. Because of that we decided to ask for a state-

ment that heavily relies on aggregate functions.

Figure 5 contains a corresponding task.

It is de-

scribed in terms of subtasks – each one can be de-

scribed by a corresponding query. The different ele-

ments of the query are articulated as distinct subtasks,

each deﬁned with a clear name (such as Quotient,

Debt, etc.). Furthermore, the query is not trivial and

it is plausible that even experienced SQL developers

spend 20-30 minutes on the solution. And ultimately,

the ﬁnal query is based on aggregate functions (sums

and averages). The underlying banking schema con-

sists of ﬁve tables with rather trivial ﬁelds.

Figure 6 illustrates a possible solution using

WITH. Although the task description consists of three

steps, we think it is plausible to add some more steps

to the solution, because, for example, the actual pay-

ment of customers can be more easily understood if

deﬁned in a separate variable. Figure 7 describes a

different, possible solution using SQL

Assign

. Actually,

there are no major differences between both solutions:

in the end, it is just a question where the variable

Such approach was already applied in the ﬁrst steps

of experimentation in programming such as the experiment

described by Lucas and Kaplan from 1976 (Jr. and Kaplan,

1976) and is up to today often applied.

The original task description was in German – we

translated the text to English in order to ease the readability

of the present paper.

An Empirical Study on the Possible Positive Effect of Imperative Constructs in Declarative Languages: The Case with SQL

431

Return all customers who are uneconomical from the point

of view of a particular insurance agency.

Output: CustomerID, DegreeOfUneconomicalness.

Consider three variables:

Quotient: The fee deﬁned for a contract added to the

surcharge received by a customer divided by the fee of the

contract. In this case, the quotient of a customer must be

greater than the average quotient of all customers,

otherwise the customer is economical.

Debt: The sum of the not yet paid requested money of a

customer. In this case, the debt of a customer must be

greater than his quotient multiplied by the sum of his paid

requested money, otherwise the customer is economical.

Loss: The sum of the costs for all incidents of a customer.

In this case, the loss of a customer must be greater than his

debt added to the sum of the values of his securities,

otherwise the customer is economical.

This insurance agency wants to terminate a customer, if his

DegreeOfUneconomicalness fulﬁlls (quotient * debt +

loss) > 150,000.

Figure 5: Task description of Task 1. The actual task de-

scription used in the experiment was not in English but in

the language of the university where the experiment was

performed.

names appear and how the end of an assignment looks

like (semicolon versus brackets).

The experiment was deﬁned as a crossover trial

that potentially suffer from carry–over effects (see

(Kitchenham et al., 2003; Hanenberg and Mehlhorn,

2021)). As a consequence, our goal was to deﬁne a

second task that is quite close to the ﬁrst task in terms

of required steps, but where the computations of the

different steps are different. We came up with a task

from the ﬁeld of formula one, where drivers should

be selected. For reasons of completeness, Figure 8

illustrates the task description.

4.3 Measurement

We implemented a (small) tool for entering SQL

statements. The tool used a Postgres database server

version 11. Additionally, the tool showed the textual

task description as well as the available tables in a

tree view. We started the measurement once a par-

ticipant articulated that he was willing to start with

the task. The time measurement stopped once the re-

sult of a query matched the expected outcome. The

measurement was done in seconds. Part of the mea-

surement was all time spent on the task including po-

tential searches on the Internet. After 80 minutes, the

tool showed that the participant was permitted to go

to the next task (respectively to stop the experiment).

We gave a short description of SQL

Assign

before

the experiment and gave a simple task that should re-

quire 10 to 15 minutes. Finally, we screen recorded

the sessions to have later on the opportunity to view

again solution steps. Additionally, we observed the

participants during the sessions.

4.4 Experiment Layout

The experiment had the following dependent and in-

dependent variables:

Dependent Variable: Time to completion (the time

required by developers to deﬁne a requested query).

Independent Variable: Language (with the treat-

ments SQL and SQL

Assign

), where language is a

within-subject variable.

Random Variable: Group Assignment, where sub-

jects were either assigned to the group standard SQL

ﬁrst or SQL

Assign

ﬁrst.

We deﬁned a time limit (see (Feitelson, 2021)) for

each task of 80 minutes assuming that 80 minutes are

enough to solve the task. In case a participant did not

ﬁnish within 80 minutes, we entered 80 minutes as

his result. Since we assumed that this would happen

only in SQL and not in SQL

Assign

this is a penalty for

SQL

Assign

, because the subject would have probably

required more time using standard SQL.

4.5 Experiment Execution

We executed the experiment on 24 volunteers (stu-

dents) based on purposive sampling (Patton, 2014)..

The requirements for the volunteers was that they

passed a database course at our institute. Hence,

we assumed that they were familiar with SQL and

the WITH clause. Each volunteer was tested in an

individual session starting with an introduction into

SQL

Assign

and software used in the experiment. We

explicitly articulated that Internet search was per-

mitted (and recommended) in case a participant had

questions concerning SQL. We explicitly articulated

that the used SQL dialect was Postgres. We did not

deﬁne a time limit for the introduction and answered

there all questions a student possibly had.

5 RESULTS

Table 1 contains for each participant the measured

times. One participant (No 4) ran into the time limit.

As explained before, we accepted that the time limit

was reached and still included him in the data set.

ICSOFT 2023 - 18th International Conference on Software Technologies

432

WITH Q u o t i e n t AS ( SELECT C u s t ome r I d , ( C o n t r a c t . Amount + S u r c h a n g e . Amount ) / C o n t r a c t . Amount AS Q u o t i e n t

FROM Customer NATURAL JOIN C o n t r a c t JOIN S u r c h a n g e USING( C u s t o m e r I d ) ) ,

Demand AS (SELECT C u s tom e r I d , SUM( DemandedAmout ) AS Demand FROM Cl a im GROUP BY Cu s t o m e rI d ,

P a i d AS (SELECT C u s tom e r I d , SUM( Pay ment ) AS P a i d FROM P aym ent GROUP BY C u s t o m e r I d ) ,

Loss AS (SELECT C u s tom e r I d , SUM( Cos t ) AS L o s s FROM I n c i d e n t GROUP BY C u s t o m e r I d ) ,

Va lue AS (SELECT C u s tom e r I d , SUM( Value ) a s Value FROM A s s e t GROUP BY C u s t o m e r I d )

SELECT Cus tomerID , Q u o t i e n t

( Demand − P aym ent ) + Loss AS D e g r e e O f U n e c o n o m i c a l n e s s

FROM Q u o t i e n t

NATURAL JOIN Demand NATURAL JOIN P a i d NATURAL JOIN L o s s NATURAL JOIN Value

WHERE Q u o t i e n t > (SELECT AVG( Q u o t i e n t ) FROM Q u o t i e n t

AND Demand − P a i d > Q u o t i e n t

P a i d

AND Loss > ( Demand − P a i d ) + Value

AND Q u o t i e n t

( Demand − P a i d ) + V alue > 15 0 0 0 0 ;

Figure 6: Possible solution for Task 1 using standard SQL using WITH.

A l l C u s t o m e r s = SELECT Cus t o m e rId , ( C o n t r a c t . Amount + S u r c h a n g e . Amount ) / C o n t r a c t . Amount AS Q u o t i e n t

FROM Customer NATURAL JOIN C o n t r a c t JOIN S u r c h a n g e USING( C u s t o m e r I d ) ) ;

Average = SELECT AVG( Q u o t i e n t ) FROM A l l C u s t o m e r s ;

Q u o t i e n t T = SELECT C u s tom e r I d , Q u o t i e n t FROM A l l C u s t o m e r s WHERE Q u o t i e n t > A v e r a g e ;

Demand = SELECT C u s t o me r I d , SUM( DemandedAmount ) AS Demanded FROM Clai m GROUP BY C u s t o m e r I d ;

P a i d = SELECT C u s tom e r I d , Sum( PayedAmount ) AS P a i d FROM P ayment GROUP BY C u stomer I D ;

DebtT = SELECT C u s t ome r I d , Demanded − P a i d AS D e bt FROM Demand NATURAL JOINT P a i d NATURAL JOIN Q u o t i e n t T

WHERE Demanded − P a i d > Q u o t i e n t

P a i d ;

Cu s t o me r L o s s = SELECT C u sto m e r I d , SUM( Va lue ) a s Los s FROM I n c i d e n t GROUP BY C u s t o m e r I d ;

Cu s t o me r V a lu e = SELECT C u sto m e r I d , SUM( Va lue ) a s Valu e FROM A s s e t GROUP BY C u s t o m e r I d ;

LossT = SELECT C u s t o me r I d , Loss , FROM C u s to m e r Lo s s NATURAL JOIN C u s to m e r Va l u e NATURAL JOIN Debt s T

WHERE Loss > D e b t s + Valu e ;

SELECT Cus tomerID , Q u o t i e n t

Deb t + Loss AS D e g r e e O f U n e c o n o m i c a l n e s s

FROM Q u o t i e n t T NATURAL JOIN DebtT NATURAL JOIN L ossT

WHERE Q u o t i e n t

Deb t + Loss > 1 5 0 0 0 0 ;

Figure 7: Possible Solution for Task 1 using SQL

Assign

Table 1: Measurements: Times for Task1 and Task2 in sec-

onds. Group SQL started with standard SQL and solved the

second task with SQL

Assign

, group SQL

Assign

vice versa.

Group No Training Task1 Task2 Sum

(Task1+Task2)

SQL 2 656 3905 1778 5683

SQL 4 918 4800 2634 7434

SQL 6 1330 3546 2425 5971

SQL 8 590 3324 2102 5426

SQL 10 655 2164 1298 3462

SQL 12 943 2702 1305 4007

SQL 14 827 3612 1757 5369

SQL 16 860 4052 1785 5837

SQL 18 502 3502 1333 4835

SQL 20 757 4239 1748 5987

SQL 22 1138 4613 2077 6690

SQL 24 1314 3036 1442 4478

SQL

Assign

1 873 2314 4183 6497

SQL

Assign

3 671 1498 3465 4963

SQL

Assign

5 730 2259 3143 5402

SQL

Assign

7 812 2058 4269 6327

SQL

Assign

9 645 1652 4273 5925

SQL

Assign

11 508 1959 2916 4875

SQL

Assign

13 748 1822 3593 5415

SQL

Assign

15 604 1567 2081 3648

SQL

Assign

17 648 1866 3674 5540

SQL

Assign

19 653 1657 3316 4973

SQL

Assign

21 777 1585 3014 4599

SQL

Assign

23 653 1752 1633 3385

The ﬁrst impression of the data is that times below

2000 seconds appear most often in task 2 for group

SQL (where task 2 was solved with SQL

Assign

) while

the same phenomenon appeared mainly in task 1 for

group SQL

Assign

. One participant (No. 23) solved the

task faster with SQL than with SQL

Assign

5.1 Informal Observations

Since each participant was tested in an individual ses-

sion, we were able to observe how they solved the

tasks. This observation was informally done.

All participants except participant 4 were able to

solve the tasks in time. The experimenter had the im-

pression that participant 4 (who was not able to ﬁnish

the task using standard SQL) was overwhelmed by

the difﬁculty of the task (which was not the case for

the task solved in SQL

Assign

). Actually, one require-

ment of the different steps got lost in the participant’s

query and the participant was subsequently not able

to detect this missing requirement in time.

No single participant used the WITH clause – nei-

ther in the group starting with standard SQL nor in

the group starting with SQL

Assign

. For almost all sub-

An Empirical Study on the Possible Positive Effect of Imperative Constructs in Declarative Languages: The Case with SQL

433

Return all racers who, from the point of view of a

particular F1 team, are considered worthy to be recruited

as drivers.

Output: DriverID, LevelOfAttractiveness.

Consider three variables:

Signiﬁcance: The points of a driver’s team added to the

points of the driver divided by the points of his team. In

this case, the signiﬁcance of a driver must be greater than

the average signiﬁcance of all drivers, otherwise the driver

is unattractive.

Difference: The difference between the sum of the expected

positions by analysts and the sum of the actual positions

won by a driver. In this case, the driver’s difference must

be greater than the sum of his expected positions divided

by his signiﬁcance, otherwise the driver is unattractive.

PodiumPoints: The accumulated points by podium

positions of a driver. In this case, the driver’s podium

points added with his difference must be more than the sum

of the costs of the driver due to racing incidents /

1,000,000, otherwise the driver is unattractive.

This team is interested in a driver, if his

LevelOfAttractiveness fulﬁlls (signiﬁcance * difference +

podiumPoints) > 500.

Figure 8: Task description of Task 2. The actual task de-

scription used in the experiment was not in English but in

the language of the university where the experiment was

performed.

jects using standard SQL the results were compara-

ble: the different steps were formulated as individual

queries and then either the resulting query was com-

pletely copied into a subquery or the conditions for

each step were copied into the WHERE clause (and

the tables were then joined).

Another observation was that some participants

had problems when deﬁning subqueries where either

the time consuming problem was to give subqueries

names or participants where confused what parts of a

subquery should end up in the FROM or the WHERE

clause, leading to problems in ﬁxing errors caused by

copying a query as a subquery (subject 1, 2, 3, 5, 7,

9, 16, 17, 19, 21, 22, 24). However, we also observed

that for a number of subjects (subject 6, 10, 11, 12, 14,

15) the pure observation of the way how they solved

the tasks did not reveal anything noticeable. However,

for all these subjects, it still turned out that the use of

SQL

Assign

required less time.

5.2 Quantitative Results

Before analyzing the results we check whether a

carry-over effect could be detected. Thereto, we run

a one-way ANOVA on the sum of times (dependent

variable)

with the independent variable group (with

treatments group 1 and group 2, see Table 2). For

the sum of times for both tasks, the resulting ANOVA

does not indicate a carry-over effect (F(1, 22)=.514,

p=.481, η

=.023), i.e. it is possible to consider the

times in a combined analysis.

In order to study the effect of the language, we run

a repeated measures ANOVA (see Table 2) with the

within-subject variable language (with the treatments

SQL and SQL

Assign

) and the between subject variable

group (with the treatments group 1 and group 2).

The

difference between both groups is signiﬁcant and the

difference is almost factor 2 (

M(SQL)

M(SQL

Assign

)

3,460.25

1,819.71

1.90): Solving the task using SQL

Assign

required only

52% of the time required for standard SQL.

However, one subject (who started with

SQL

Assign

) required less time using SQL. We

cannot exclude that this is the result of an individual

learning effect. Or it could just mean that there are

still single subjects to whom the introduction of the

assignment operation is counterproductive. Or it

could be just the result of luck.

It is noteworthy that the differences between stan-

dard SQL and SQL

Assign

are quite large. As a con-

sequence, it is questionable, whether our rather cau-

tious design using a crossover experiment was already

larger than necessary. Consequently, we ask our-

selves, whether the effect would have already shown

up when the second round (i.e. where the crossover

appeared) would not be considered.

In order to test this, we run a simple, un-

paired t-test on the ﬁrst round and get a simi-

lar result as the previously reported one. Again,

the variable language is signiﬁcant (t(13.676)=7.655;

p < .001; M

SQL

=3,624.58; M

SQL

Assign

=1,832.42;

SQL

Assign

SQL

=50,56%)

and again SQL

Assign

required

only approximately 50% of the time required by stan-

dard SQL.

6 THREATS TO VALIDITY

We see a obvious threats with respect to the generaliz-

ability of the results. First, we explicitly assume that a

language construct as the proposed one has probably

only a positive effect if the requested query is deﬁned

The analysis was performed using SPSS v27.

Taking the result of the previous test into account, there

is no need to use group as an independent variable any

longer – we still do it here for reasons of completeness.

The degrees of freedom were adapted, because the

Levene test turned out signiﬁcant (p<.001):

ICSOFT 2023 - 18th International Conference on Software Technologies

434

Table 2: Repeated measures ANOVA on the within-subject variable Language (L) and the between-subject variable Group

(G). Conﬁdence intervals (CI), means (M), and standard deviation (SD) are given in seconds.

Variable df F p η

Treatment N CI

95%

M SD

Language (L) 1 141.416 <.001 .865

SQL 24 [3,124.41; 3,796,84] 3,460.625 794.61

SQL

Assign

24 [1,666.08; 1973.34] 1,819.71 355.17

Group (G) 1 .514 .481 .023

SQL Start 24 [2,461.78; 2,969.80] 2,715.79 1111.85

SQL

Assign

Start 24 [2,310.53; 2818.55] 2,564.54 948.57

L * G 1 .982 .327 .022

SQL | SQL Start 12 [3,265.36; 3,983.81] 3,624.58 765.15

SQL | SQL

Assign

Start 12 [2,937.44; 3,655.89] 3,296.67 822.26

SQL

Assign

| SQL Start 12 [1,447.78; 2,166.22] 1,807.00 437.15

SQL

Assign

| SQL

Assign

Start 12 [1,473,19; 2,191.64] 1,832.42 268.89

in a rather step by step manner. In other words, if a

more imperative deﬁnition of a problem is given, we

think a more imperative way to solve such problem is

more appropriate. However, to what extent common

SQL problems are rather formulated in an imperative

or rather in terms of a declarative problem description

is unclear to us. Second, we are aware that the query

used in the experiment is rather difﬁcult – at least, it

is not a trivial SELECT–FROM–WHERE statement.

However, to what extent this query is actually difﬁcult

and to what extent queries of such difﬁculty can be

found in the real world is unclear to us. Our personal

perception (having some background in writing SQL

queries) is that real world queries easily have the dif-

ﬁculty of the given tasks. Third, it is unclear whether

the more general claim – adding an imperative con-

struct to a declarative language – actually holds to

other languages as well. The here chosen language

SQL is just one example of a declarative language and

we do not know whether the effect is special to SQL.

In addition to the external threats, we see inter-

nal threats with respect to the chosen participants and

their background. As discussed, it turned out that no

single participant used SQL’s WITH clause. We can-

not exclude that this is just the results of the partic-

ipants’ background (since each participant was from

the same institute): we cannot exclude that it is an

institute-dependent characteristic of students that the

construct WITH is rather not appreciated.

We see a more serious internal threat. It is com-

monly accepted to introduce a new language construct

to participants in order to test the language construct

in an experimental way. But actually, just the in-

troduction of the construct could already introduce a

bias: subjects could feel the need to use this language

feature. Consequently, it is possible that the urge to

use the assignments in the queries (when the experi-

ment gives the opportunity to do so) is not the result

of the language feature itself. And it is possible that

the absence of the WITH clause in solutions delivered

by subjects is no indicator for the inferiority of the

WITH clause. Actually, we think that this is a serious

threat that exists in general in experiments where new

language features are tested (and introduced through-

out the experiment). However, one also has to take

into account that the test only on the ﬁrst round (the

last test in Section 5.2) also revealed a positive effect

of the variable language. This reduces the potential

threat that the experiment result was mainly driven by

the additional teaching of the construct, because in the

ﬁrst round this is not relevant for the control group.

7 SUMMARY AND DISCUSSION

In the present study, we tested whether the introduc-

tion of the imperative language construct variable as-

signments (in addition to sequences) would provide a

beneﬁt to SQL developers. With this extension (that

we called SQL

Assign

) we designed a crossover experi-

ment where 24 students had to solve two queries. The

task descriptions of both queries were given in mul-

tiple steps. The experiment revealed that the time to

solve a task using SQL

Assign

just required 52% of the

time in comparison to standard SQL. And while 23

participants solved a task faster with SQL

Assign

, one

participant experienced the opposit.

What makes the results of the experiment from our

point of view surprising is, that in principle no such

language construct is required. First, there is already

a language construct such as WITH available in SQL

that permits to deﬁne a named term as the result of

an SQL expression – which is actually exactly what

the proposed language construct does. Second, such

terms and term replacements are not really required

in SQL, because subqueries already provide some-

thing similar. However, while all participants used

subqueries in standard SQL, not a single participant

felt the need (or saw any reason) to use WITH.

Actually, we see two interpretations from the ex-

periment in the context of SQL. First, it is possible

that participants underestimate the difﬁculty of SQL

while deﬁning difﬁcult queries. Once one query is

done, participants think that just adding an additional

query on top of it does not do any harm. While the

proposed language construct is quite similar to the

WITH clause, we think that it still gave participants

the impression that it is easier to use than a WITH

An Empirical Study on the Possible Positive Effect of Imperative Constructs in Declarative Languages: The Case with SQL

435

clause – probably, because the proposed syntax gave

participants more the impression that the solution is

executed statement by statement.

Of course, it could also be the case that the value

of the WITH clause is just underestimated by students

– and it could rather be interpreted as a critique of the

students’ education in SQL, where they are used to

write difﬁcult queries, but where they are maybe not

well–trained in the reduction of a query’s difﬁculty.

However, this leads to an even more general ques-

tion. Actually, inner queries provide similar to the

WITH clause an additional abstraction, because both

permit to give a name to a query. It is possible that just

the position of this name in a query is the result why

it is not considered as a relief but rather as a burden –

and it could be the case that the syntactical representa-

tion of the proposed assignments (where the variable

names appear in the beginning of each line) is consid-

ered as a better and more explicit representation for

such named queries.

Actually, the last argument seems to match to

some extent the mentioned related work that indicates

that SQL’s syntax seems to be hard to understand (see

(Ahadi et al., 2016; Poulsen et al., 2020)) which leads

to the situation that most errors in SQL are syntax er-

rors. On a more abstract level, this could be a hint

that language designers should spend more effort into

the design of syntax structures or even into the de-

sign keywords – which is in line with studies such as

the one by Steﬁk and Siebert that revealed that even

the choice of keywords in languages can make a large

difference (Steﬁk and Siebert, 2013).

And on an even more abstract level, the designed

experiment raises the question, whether declarative

languages could beneﬁt from the introduction of im-

perative language constructs. While today mainly

the tendency in programming language design can be

found that declarative language features appear in im-

perative language (such as the introduction of lambda

expressions in main stream imperative languages), it

is not often the case that people ask whether declara-

tive languages could beneﬁt from imperative features

as well. However, we mentioned already in the related

work section the study by Pichler et al. that showed

that students have some tendency toward imperative

language constructs (Pichler et al., 2011).

Our general conclusion with regard to this discus-

sion is rather that the whole discussion about whether

a language should be declarative or imperative is

slightly misleading: there are works that have given

evidence that the introduction of declarative features

in imperative languages causes some beneﬁt (see for

example (Mehlhorn and Hanenberg, 2022)) while

the present paper also gives evidence that a declara-

tive language could beneﬁt from imperative features.

Probably, it is worth to think about whether the dis-

cussion should rather go into the direction of declar-

ative versus imperative task descriptions – and the

resulting question, what the effect of language con-

structs on the solution of such tasks actually is.

Altogether, we think that the present paper gives

some food for thought for the design of languages.

While language designers have the tendency to think

a lot about language semantics, it might be the situ-

ation that rather simple syntactical differences in the

representation of a language make a huge difference.

And maybe the present study motives language de-

signers to put additional effort into studying language

features using empirical methods.

8 CONCLUSION

The here presented study gives evidence that the in-

troduction of a quasi-imperative language construct

in terms of a variable assignment reduces the time re-

quired to deﬁne a difﬁcult query that was given to the

experiment’s participants in terms of a step by step

description: the introduction of that language feature

reduced the time effort for the deﬁnition of a query by

about 48%.

While we see in the given experiment an indica-

tor that SQL – which is today still the leading lan-

guage for accessing databases – can be improved by

relatively simple syntactical elements, we also see in

the study a contribution to the discussion whether lan-

guages should be declarative or imperative: while in

the literatures more and more evidence is gathered

that imperative languages could beneﬁt from declar-

ative features, the present study gives ﬁrst indicators

that it is possible also the other way around.

Altogether, we think that the present study should

motivate language designers to test their languages

not only in terms of functionality, but also in terms of

usability. Because it might turn out that even small

syntactic differences have larger effects. And the

study could also motivate language designers to think

about improving existing languages. Again, not only

in terms of functionality, but also in terms of usability

– which could be just simple syntactical changes. And

the evidence for the usability of a language constructs

should not be based on plausibility but on measure-

ments – and from our perspective the use of random-

ized control trials should be the ﬁrst choice.

ICSOFT 2023 - 18th International Conference on Software Technologies

436

REFERENCES

Ahadi, A., Behbood, V., Vihavainen, A., Prior, J., and Lis-

ter, R. (2016). Students’ syntactic mistakes in writing

seven different types of sql queries and its application

to predicting students’ success. In Proceedings of the

47th ACM Technical Symposium on Computing Sci-

ence Education, SIGCSE ’16, pages 401–406, New

York, NY, USA. Association for Computing Machin-

ery.

Feitelson, D. G. (2021). Considerations and pitfalls in

controlled experiments on code comprehension. In

29th IEEE/ACM International Conference on Pro-

gram Comprehension, ICPC 2021, Madrid, Spain,

May 20-21, 2021, pages 106–117. IEEE.

Hanenberg, S. (2010). An experiment about static and dy-

namic type systems: Doubts about the positive impact

of static type systems on development time. In Pro-

ceedings of the ACM International Conference on Ob-

ject Oriented Programming Systems Languages and

Applications, OOPSLA ’10, pages 22–35, New York,

NY, USA. Association for Computing Machinery.

Hanenberg, S. and Mehlhorn, N. (2021). Two n-of-1 self-

trials on readability differences between anonymous

inner classes (aics) and lambda expressions (les) on

java code snippets. Empirical Software Engineering,

27(2):33.

Jr., H. C. L. and Kaplan, R. B. (1976). A structured pro-

gramming experiment. Comput. J., 19(2):136–138.

Kaijanaho, A.-J. (2015). Evidence-based programming lan-

guage design: a philosophical and methodological ex-

ploration. University of Jyväskylä, Finnland.

Kitchenham, B., Fry, J., and Linkman, S. (2003). The case

against cross-over designs in software engineering. In

Eleventh Annual International Workshop on Software

Technology and Engineering Practice, pages 65–67.

Kokuryo, S., Kondo, M., and Mizuno, O. (2020). An em-

pirical study of utilization of imperative modules in

ansible. In 2020 IEEE 20th International Conference

on Software Quality, Reliability and Security (QRS),

pages 442–449.

Lucas, W., Bonifácio, R., Canedo, E. D., Marcílio, D., and

Lima, F. (2019). Does the introduction of lambda

expressions improve the comprehension of java pro-

grams? In Proceedings of the XXXIII Brazilian Sym-

posium on Software Engineering, SBES 2019, pages

187–196, New York, NY, USA. Association for Com-

puting Machinery.

Mehlhorn, N. and Hanenberg, S. (2022). Imperative versus

declarative collection processing: An rct on the under-

standability of traditional loops versus the stream api

in java. In Proceedings of the 44th International Con-

ference on Software Engineering, ICSE 2022, Pitts-

burgh, PA, USA, May 22–27, 2022, to appear.

Müller, M. (2005). Two controlled experiments concerning

the comparison of pair programming to peer review.

Journal of Systems and Software, 78:166–179.

Patton, M. (2014). Qualitative Research & Evaluation

Methods: Integrating Theory and Practice. SAGE

Publications.

Pichler, P., Weber, B., Zugal, S., Pinggera, J., Mendling,

J., and Reijers, H. A. (2011). Imperative versus

declarative process modeling languages: An empir-

ical investigation. In Daniel, F., Barkaoui, K., and

Dustdar, S., editors, Business Process Management

Workshops - BPM 2011 International Workshops,

Clermont-Ferrand, France, August 29, 2011, Revised

Selected Papers, Part I, volume 99 of Lecture Notes

in Business Information Processing, pages 383–394.

Springer.

Poulsen, S., Butler, L., Alawini, A., and Herman, G. L.

(2020). Insights from student solutions to sql home-

work problems. In Proceedings of the 2020 ACM Con-

ference on Innovation and Technology in Computer

Science Education, ITiCSE ’20, pages 404–410, New

York, NY, USA. Association for Computing Machin-

ery.

Senn, S. (2002). Cross-over Trials in Clinical Research.

Statistics in Practice. Wiley.

Steﬁk, A. and Siebert, S. (2013). An empirical investiga-

tion into programming language syntax. ACM Trans.

Comput. Educ., 13(4).

Uesbeck, P. M., Steﬁk, A., Hanenberg, S., Pedersen, J., and

Daleiden, P. (2016). An empirical study on the im-

pact of c++ lambdas and programmer experience. In

Proceedings of the 38th International Conference on

Software Engineering, ICSE 2016, Austin, TX, USA,

May 14-22, 2016, pages 760–771.

An Empirical Study on the Possible Positive Effect of Imperative Constructs in Declarative Languages: The Case with SQL

437
