Quality Engineering Framework for Functional Safety Automotive

Projects

Mădălin-Dorin Pop

and Dianora Igna

Computer and Information Technology Department, Politehnica University of Timișoara, Bvd. Vasile Pârvan,

Timișoara, Romania

Faculty of Automation and Computers, Politehnica University of Timișoara, Bvd. Vasile Pârvan, Timișoara, Romania

Keywords: Automotive Software, Dependent Failure Analysis (DFA), Freedom from Interference, Functional Safety,

Quality Engineering, Vehicle Sensors.

Abstract: Safety evaluations represent an important aspect in the development of functional safety (FuSa) automotive

projects. The present paper aims to propose a quality engineering framework for automotive projects that uses

as input the Failure Mode Effects Analysis (FMEA) and Fault Tree Analysis (FTA) and further applies the

Dependent Failure Analysis (DFA) method. More focused attention is also directed toward the impact analysis

step during the development phase of a project and not only. By combining both these goals and with the help

of the APIS IQ-RM interface, in the end, the paper presents a case study on how to improve an existing system.

Furthermore, the proposed approach ensures complete traceability within the project by adding links between

the APIS model and the representative test cases for each component.

1 INTRODUCTION

Safety is the most important aspect considered in the

development of automotive projects. Anticipation of

possible system failures and implementation of safety

measures will save lives. As stated by Sini et al.

(2022), functional safety (FuSa) represents “the

ability of a cyber-physical system to react on time and

adequately to the external environment”. Its

definition and application rules originate from IEC

61508 (International Electrotechnical Commission,

2010), representing the basis for the development of

multiple standards adjusted to the needs of software

developed for different fields of industry. In this

sense, the development of airborne systems must

comply with DO-178C (Radio Technical Committee

for Aeronautics, 2011), railway systems with EN

50126 (Iteh Standards, n.d.), and automotive systems

with ISO 26262 (International Organization for

Standardization, 2018).

This article focuses on the FuSa assessment of the

development of automotive embedded systems. It

considers previous research by Igna and Pop (2023)

consisting of an impact analysis conducted using a

model-based approach in the APIS IQ-RM tool (Apis

https://orcid.org/0000-0002-2524-3370

Iq-Software | Fmea | Drbfm | Functional Safety, n.d.),

which has as a case study the functions and failures

of a Central Processing Unit (CPU) that exists in an

automotive system. Following this approach, the

model obtained unifies both qualitative and

quantitative analyses related to ISO 26262

compliance. The current research aims to improve the

previous approach of the authors (Igna and Pop,

2023) by adding the links between each component

and its specific test cases. In this way, complete

traceability is ensured between requirements,

developed components, and testcases, allowing

failure and its impact on other components to be

easily identified. Furthermore, the model proposed in

this paper uses the existing Fault Tree Analysis (FTA)

as input for a Dependent Failure Analysis (DFA).

This paper achieves the mentioned goals through

the following five sections, a brief of each section

being further given. The second section presents

recent research related to the FuSa concept. This

discussion follows three directions, such as

developing FuSa-related functionalities, innovative

processes, and approaches using quality engineering

tools for FuSa projects.

Pop, M. and Igna, D.

Quality Engineering Framework for Functional Safety Automotive Projects.

DOI: 10.5220/0012119300003538

In Proceedings of the 18th International Conference on Software Technologies (ICSOFT 2023), pages 463-469

ISBN: 978-989-758-665-1; ISSN: 2184-2833

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

463

Section III presents the theoretical background

necessary to understand the context and the proposal

of the quality engineering framework from this paper.

The discussion begins with a description of APIS

model and is followed by the definition of the

freedom from interference concept, and, in the end,

by a discussion on how DFA is developed by using

the safety analysis.

The fourth section describes the proposed quality

engineering framework that aims to improve the

APIS model. It is followed, in the fifth section, by a

practical application of the proposed framework on a

generic Electronic Control Module (ECM) schema

developed in the APIS IQ-RM tool (Apis Iq-Software

| Fmea | Drbfm | Functional Safety, n.d.).

The last section summarizes the contributions of

this research and designates the directions of future

research.

2 RELATED WORKS

Recent research on the development of automotive

projects concentrates on the application of the FuSa

concept for various functionalities or Electronic

Control Units (ECUs), such as steering and braking

systems (Rana et al., 2014), electric vehicle charging

systems (Kivelä et al., 2021), battery management

systems (Chen et al., 2021), combustion engine

control and calibration (Isermann and Sequenz,

2016), autonomous driving systems (Gilbert et al.,

2018; Liu et al., 2022), etc. Safety evaluations are

usually performed using model-based approaches

(Chaari et al., 2015; Debbech et al., 2019; Isermann

and Sequenz, 2016; Martin et al., 2020; Rupanov et

al., 2014; Weissnegger et al., 2016), which simplify

the identification of the root cause of a system fault.

Martin et al. (2020) propose a framework that

provides guidance and links the concepts of safety

and security from a system engineering perspective.

This approach is compliant with ISO 26262

(International Organization for Standardization, 2018)

and SAE J3061 (Society of Automotive Engineers,

2016), the last standard being responsible for defining

the cybersecurity process.

The production system also plays an important

role in FuSa assurance. Customer expectations relate

to a short lead time to market but maintain high

quality, especially for safety-relevant products. This

can be feasible only if the manufacturing process is

continuously adapted to the changes coming from the

market or the customer, the integration of the latest

technologies being crucial in this sense. Vater et al.

(2019) provide a systematic review of the use of

prescriptive analytics in intelligent manufacturing

systems. Kampker et al. (2019) proposed an improved

general methodology for multiple ramp-up in scalable

production systems that can be easily adapted to the

needs of the production line and the manufactured

product while complying with all safety-relevant

aspects.

Open innovation practices are also the subject of

recent research in the automotive industry. Ettabaa et

al. (2019) provide an overview of open innovation

ecosystems and their connections with academia or

other institutions that can generate ideas.

Additionally, they provide a discussion of the

effectiveness of open innovation practices in the

automotive industry.

Quality engineering is very important in FuSa-

related projects, with several approaches available in

the scientific literature. The preventive approach is

the most used because it ensures a reduced probability

of possible quality deviations and a real-time

application of corrective measures in the case of their

appearance. The statistical process control, known as

a preventive measure, assists qualitative evaluations.

Godina and Matias (2018) improved the

identification of non-conformity by replacing the

initial Kolmogorov-Smirnov test with a Shapiro-Wilk

test. Da Anunciação et al. (2022) applied the focus

group technique to discuss the interactions between

the main dimensions in FuSa related to the needs of

industry 4.0. The authors emphasized the limitations

of the technique chosen for their research and defined

the paths for its validation in future studies.

Several studies apply Failure Modes, Effects, and

Diagnostic Analysis (FMEDA) (Chaari et al., 2015;

Igna and Pop, 2023; Kymal and Gruska, 2021; Lu et

al., 2018; Tichkiewitch and Riel, 2014) in FuSa

evaluations. Usually, these studies integrate FMEDA

with Failure Mode and Effects Analysis (FMEA) and

FTA (Igna and Pop, 2023; Kymal and Gruska, 2021).

Lu et al. (2018) proposed a framework that uses Fault

Injection and Data Analysis (FIDA) in the generation

of the FMEDA report. The use of DFA (Park et al.,

2021; (Young and Walker, 2018) or driver-in-the-

loop systems (Liu et al., 2022) is also proposed by

researchers in the analyses of compliance with ISO

26262. Tichkiewitch and Riel (2014) proposed a

more complex and general framework that allows the

integration of FuSa with Automotive Software

Process Improvement and Capability Determination

(ASPICE) (Automotive SPICE, 2015), and lean six

sigma.

ICSOFT 2023 - 18th International Conference on Software Technologies

464

3 METHODOLOGY

Even if in the automotive industry, there are many

tools capable of implementing safety analyses (e.g.,

Vector PREE Vision, Ansys medini analyze, ENCO

SOX and LDRA tool (Embitel-admin, 2021)), APIS

IQ-RM promises to bring to market one of the best

tools in this area (Apis Iq-Software | Fmea | Drbfm |

Functional Safety, n.d.). Another reason for choosing

this tool in this research is the recognition of the major

automotive worldwide companies that trusted in

using the tool (i.e., these companies are listed in the

“Our Customer” section in the APIS website (Apis Iq-

Software | Fmea | Drbfm | Functional Safety, n.d.).

3.1 APIS Model

As stated in the introduction, the goal of this paper is

to improve the approach followed by Igna and (2023)

in their developed APIS model. This model presents

the block diagram of Electronic Throttle Control

(ETC) that was used embedded on a Toyota Lexus

during a hazardous event (Igna and Pop, 2023;

NHTSA, 2011). By using the APIS IQ-RM (Apis Iq-

Software | Fmea | Drbfm | Functional Safety, n.d.)

interface, it is possible to develop the model in

arborescent form (Fig. 1). In this way, different levels

were described: the first level represents the engine,

the second one is for actuators, the ECU is on the third

level, and the last one presents the components of

each module. The model focuses more on the ECM,

which has a generic structure that is used even today

in the automotive industry.

Figure 1: Function connection for main CPU (Igna and Pop,

2023).

The main purpose of the model is to determine for

each subsystem or component its feature and failure

mode. One of the key features used by automotive

engineers while working in APIS is the connection of

each component function/failure mode with the top-

level component/subsystem. This stage is important

because, by having these connections, it also

completes the first phase of the following safety

analysis: FMEA, FMEDA, and FTA.

Another important point that should not be missed

is the introduction of a safety mechanism that acts as

protection against various faults. At the top of each

system, there are one or more safety goals that must

be protected against violations. However, there are

situations where the malfunction of one component

could corrupt the next component up to the top level,

which results in a violation of the safety goal.

Fortunately, there is a feature that helps engineers to

establish which malfunction could lead to a cascading

failure, and this will be discussed in the next section.

3.2 Freedom from Interference and the

Role of DFA

ISO 26262 (International Organization for

Standardization, 2018) defines the freedom from

interference as “absence of cascading failures

between two or more elements that could lead to the

violation of a safety requirement”.

As mentioned previously, because nowadays

vehicles are equipped with multiple ECUs that use a

communication channel, the malfunction of one

component could easily be transferred to another one.

The ISO 26262 (International Organization for

Standardization, 2018) standard requires vehicle

components to have zero dependences, as well as

interference. Those two properties mentioned before

are in interest of DFA which focuses on finding the

dependent failures.

According to (International Organization for

Standardization, 2018), DFA aims at identifying

failures that may hamper the required independence

or freedom from interference between given elements

(hardware/ software/ firmware) which may ultimately

lead to violation of safety requirement or safety goal.

During the development of DFA (Fig.2), two types of

failures can be noticed:

 Common cause failures (CCF) appear during

one faulty event that caused a fault in one

component and another fault in a different

component. In this case, the components do not

have dependence (Schnellbach, 2016).

 Cascaded failures (CF) are represented by a

fault event that corrupts one component,

Quality Engineering Framework for Functional Safety Automotive Projects

465

causing a fault, and the same fault interacts

with another component, causing another

failure. In this case, the components interact

(Schnellbach, 2016).

As mentioned previously, DFA have two

properties: independence and freedom from

interference. By achieving freedom from

interference, it can be said that the system has no

cascading failures. However, the independence

property covers both cascading failure and common

cause of failure.

Figure 2: Dependent Fault Analysis (DFA) -

methodological overview.

3.3 Develop a DFA Using Safety

Analysis

In the first section of this chapter, the APIS model

was presented along with the introduction of safety

analysis. Another aim of this paper is to develop a

DFA using FTA and FMEA as a starting point.

As mentioned in (Igna and Pop, 2023), FMEA is

an inductive analysis used to identify potential

failures and their effect. In other words, this analysis

can highlight all components with similar failures that

could eventually cause a dependent failure. On the

other hand, the FTA analysis follows a top-down

approach based on which undesired hazards are

analyzed using Boolean logic. When the FTA is used,

the identical faulty event that could trigger the

component and produce a cascading failure is

highlighted.

With both analyses, it can be assumed that all the

inputs needed for DFA are present. After finding all

the dependent failures, the DFA ends by performing

an improvement of the system, to have the minimum

interaction of the components as possible.

Furthermore, engineers can also apply additional

safety mechanisms to cover the remaining failures, if

any.

4 IMPROVEMENT OF APIS

MODEL

One of the important topics noticed by safety

engineers in the automotive industry is impact

analysis between different phases of the project.

Several types of event could trigger an impact

analysis. For example, the component shortage

presented in (Loftus, 2021) caused many problems

for hardware engineers. This type of incident puts

them in front of one single choice: replacement of

components. In these cases, in order to ensure that the

components do not interfere in a bad way with the

system, an impact analysis made by the safety team is

mandatory. One general example which triggers an

impact analysis, and which happens very often during

the development phase is receiving new requests from

the customer.

There are some cases where the impact is very

visible, but this is often not the case. In addition to the

unification of FMEA, FMEDA, and FTA presented in

(Igna and Pop, 2023), this article will try to improve

the existing APIS model, to make impact analysis

easier to manage, and to establish the actions needed

afterward.

Fig. 3 illustrates the proposed quality engineering

framework that aims to improve the APIS model. The

advantage of using the APIS IQ-RM tool is that it is

capable of keeping all the features within one view.

Moreover, once the system is placed in the

arborescent structure with all the functions and

failures, by making the connections the FMEA it is

available. Moving forward, FMEDA could be built

from FMEA, FTA is done from FMEDA, and DFA is

initiated based on FMEA and FTA. However, to

make the model more complete, it is also needed to

add the tests to be performed for each component to

ensure that the component and then the system are

working as expected.

Figure 3: Proposed quality engineering framework.

In this way, if it is established during an impact

analysis that the change or new request has an impact

ICSOFT 2023 - 18th International Conference on Software Technologies

466

on the system, it is easy to determine which tests need

to be re-performed.

5 CASE STUDY

Taking the example of the generic ECM schema (Fig.

4) developed in APIS IQ-RM (Apis Iq-Software |

Fmea | Drbfm | Functional Safety, n.d.), one power

supply failure will be taken as a case study. With all

this said, the main feature of the power supply is to

provide power in a controlled way in order for the

vehicle to start. One possible malfunction is sending

wrong information to the ECM. Undountebly, this

malfunction leads to a violation of the safety goal. As

is well known, inside one vehicle there are a larger

number of ECMs that communicate between them.

There are two points that can be noticed:

 One faulty event causes multiple failures in

different components, which means that the

common cause of the failure is established.

 By performing FTA and DFA, the failure will

be highlighted, and the action behind will be to

add a safety mechanism in front of the failure,

in order not to propagate it to the safety goal

and violate it.

During the development phase, there are multiple

cases in which a failure leads to a violation of the

safety goal. Consequently, the team is responsible for

preventing these situations, but this cannot be

possible without the appropriate tools. For this

reason, this article proposes a mixture of existing

tools designed to perform all safety analyzes, the

value-added of the proposed approach consisting of

the direct identification of the root cause of a safety

goal violation. The localization of the failure will

easier prevent its propagation to other modules and

allows the developers to isolate the defectuous

module until the problem is solved.

Following this approach, the engineer can

improve the schema by asking the software

developers to integrate one additional mechanism.

6 CONCLUSIONS

In this paper, a quality engineering framework for

FuSa automotive projects was proposed. This

approach improved the APIS model from (Igna and

Pop, 2023) by ensuring complete traceability inside

the impact analysis by linking the corresponding test

cases to each component. In this way, it is easy to

identify the requirement that was not implemented

correctly. Furthermore, the integration of DFA in the

proposed framework ensures the existence of

minimum dependences between the components and,

consequently, achieves the freedom of interference.

Figure 4: Dependent Fault Analysis (DFA) - methodological overview.

Quality Engineering Framework for Functional Safety Automotive Projects

467

The proposed framework simplifies the

identification of the root cause in the event of a

system fault, as demonstrated by the case study

described in this research.

Future research can focus on the automation of

DFA based on the results of FMEA and FTA.

ACKNOWLEDGEMENTS

This paper was financially supported by the Project

“Network of excellence in applied research and

innovation for doctoral and postdoctoral programs” /

InoHubDoc, project co funded by the European

Social Fund financing agreement no.

POCU/993/6/13/153437.

REFERENCES

Apis iq-software | fmea | drbfm | functional safety. (n.d.).

APIS Informationstechnologien GmbH. Retrieved

April 4, 2023, from https://www.apis-iq.com/

Automotive SPICE. (2015). Retrieved April 4, 2023, from

https://www.automotivespice.com/fileadmin/software-

download/Automotive_SPICE_PAM_30.pdf

Chaari, M., Ecker, W., Novello, C., Tabacaru, B.-A., and

Kruse, T. (2015). A model-based and simulation-

assisted FMEDA approach for safety-relevant E/E

systems. Proceedings of the 52nd Annual Design

Automation Conference, 1–6. https://doi.org/10.

1145/2744769.2747908

Chen, M., Xie, G., Ming, Z., Liu, G., and Li, W. (2021).

Functional safety research of battery management

system based on risk graph methods. IOP Conference

Series: Earth and Environmental Science, 645(1),

012058. https://doi.org/10.1088/1755-1315/645/1/

012058

Da Anunciação, P. F., De Lemos Dinis, V. M., Peñalver, A.

J. B., and Esteves, F. J. M. (2022). Functional Safety as

a critical success factor to industry 4.0. Procedia

Computer Science, 204, 45–53. https://doi.org/10.

1016/j.procs.2022.08.006

Debbech, S., Bon, P., and Collart-Dutilleul, S. (2019).

Conceptual modelling of the dynamic goal-oriented

safety management for safety critical systems:

Proceedings of the 14th International Conference on

Software Technologies, 287–297. https://doi.org/10.

5220/0007932502870297

Embitel-admin. (2021, April 7). Dependent failure analysis

in iso 26262—Freedom from interference. Embitel.

Retrieved May 24, 2023, from https://www.

embitel.com/blog/embedded-blog/how-important-is-de

pendent-failure-analysis-in-iso-26262

Ettabaa, R., Bouami, D., and Elfezazi, S. (2019). Open

innovation in the automotive industry. 2019 8th

International Conference on Industrial Technology and

Management (ICITM), 115–121. https://doi.org/

10.1109/ICITM.2019.8710715

Gilbert, A., Petrovic, D., Warwick, K., and Serghi, V.

(2018). Autonomous vehicle simulation model to assess

potential collisions to reduce severity of impacts:

Proceedings of the 4th International Conference on

Vehicle Technology and Intelligent Transport Systems,

243–250. https://doi.org/10.5220/0006663102430250

Godina, R., and Matias, J. C. O. (2018). Improvement of

the statistical process control through an enhanced test

of normality. 2018 7th International Conference on

Industrial Technology and Management (ICITM), 17–

21. https://doi.org/10.1109/ICITM.2018.8333912

Igna, D., and Pop, M. D. (2023). Impact analysis according

to iso 26262 standard using safety analysis integrated in

apis iq-rm tool. ACTA TECHNICA NAPOCENSIS -

Series: APPLIED MATHEMATICS, MECHANICS, and

ENGINEERING, 65(3S). https://atna-mam.utcluj.ro/

index.php/Acta/article/view/1954

International Electrotechnical Commission. (2010). IEC

61508-1:2010; Functional Safety of Electrical/

Electronic/Programmable Electronic Safety-Related

Systems—Parts 1. IEC:Geneva, Switzerland.

International Organization for Standardization (2018). ISO

26262-2018 Road vehicles - Functional safety, 26262.

Isermann, R., and Sequenz, H. (2016). Model-based

development of combustion-engine control and optimal

calibration for driving cycles: General procedure and

application. IFAC-PapersOnLine, 49(11), 633–640.

https://doi.org/10.1016/j.ifacol.2016.08.092

Iteh standards. (n.d.). ITeh Standards. Retrieved April 4,

2023, from https://standards.iteh.ai/catalog/standards/

clc/e5456892-eb2c-437e-8c4b-91c08007f0b4/en-5012

6-1-2017

Kampker, A., Kreiskother, K., Lutz, N., Gauckler, V., and

Hehl, M. (2019). Re-ramp-up management of scalable

production systems in the automotive industry. 2019

8th International Conference on Industrial Technology

and Management (ICITM), 137–141. https://doi.

org/10.1109/ICITM.2019.8710702

Kivelä, T., Abdelawwad, M., Sperling, M., Drabesch, M.,

Schwarz, M., Börcsök, J., and Furmans, K. (2021).

Functional safety and electric vehicle charging:

Requirements analysis and design for a safe charging

infrastructure system: Proceedings of the 7th

International Conference on Vehicle Technology and

Intelligent Transport Systems, 317–324.

https://doi.org/10.5220/0010398303170324

Kymal, C., and Gruska, O. G. (2021). Integrating fmeas,

fmedas, and fault trees for functional safety. 2021

Annual Reliability and Maintainability Symposium

(RAMS), 1–6. https://doi.org/10.1109/RAMS48097.

2021.9605786

Liu, R., Lu, K., Zhu, Y., and Wu, Z. (2022). An evaluation

method of vehicle functional safety controllability

based on driver-in-the-loop platform. Journal of

Physics: Conference Series, 2173(1), 012054.

https://doi.org/10.1088/1742-6596/2173/1/012054

Loftus, D. (2021). The Automotive

SemiconductorShortage—An Accident

ICSOFT 2023 - 18th International Conference on Software Technologies

468

WaitingtoHappen? Electronic Components Industry

Association. Retrieved April 4, 2023, from

https://www.ecianow.org/assets/docs/Stats/IndustryIss

ues/ECIA%20Statement%20on%20Automotive%20S

emiconductor%20Shortage%20FINAL.pdf

Lu, K.-L., Chen, Y.-Y., and Huang, L.-R. (2018). Fmeda-

based fault injection and data analysis in compliance

with iso-26262. 2018 48th Annual IEEE/IFIP

International Conference on Dependable Systems and

Networks Workshops (DSN-W), 275–278. https://doi.

org/10.1109/DSN-W.2018.00075

Martin, H., Ma, Z., Schmittner, Ch., Winkler, B., Krammer,

M., Schneider, D., Amorim, T., Macher, G., and

Kreiner, Ch. (2020). Combined automotive safety and

security pattern engineering approach. Reliability

Engineering & System Safety, 198, 106773.

https://doi.org/10.1016/j.ress.2019.106773

NHTSA. (2011). Technical Support to the National

Highway Traffic Safety Administration (NHTSA) on the

Reported Toyota Motor Corporation (TMC)

Unintended Acceleration (UA) Investigation. Retrieved

April 4, 2023, from https://www.nhtsa.gov/staticfiles

/nvs/pdf/NASA-UA_report.pdf

Park, B., Joo, B., and Lee, S. (2021). Application of

dependent failure analysis for development of

automotive electronics complying with iso26262

standards. Transaction of the Korean Society of

Automotive Engineers, 29(10), 967–980.

https://doi.org/10.7467/KSAE.2021.29.10.967

Radio Technical Committee for Aeronautics (2011). RTCA

DO-178C; Software Considerations in Airborne

Systems and Equipment Certification. RTCA:

Parañaque, Philippines.

Rana, R., Staron, M., Berger, C., Hansson, J., Nilsson, M.,

and Törner, F. (2014). Early verification and validation

according to iso 26262 by combining fault injection and

mutation testing. In J. Cordeiro and M. Van Sinderen

(Eds.), Software Technologies (Vol. 457, pp. 164–179).

Springer Berlin Heidelberg. https://doi.org/10.1007/

978-3-662-44920-2_11

Rupanov, V., Buckl, C., Fiege, L., Armbruster, M., Knoll,

A., and Spiegelberg, G. (2014). Employing early

model-based safety evaluation to iteratively derive E/E

architecture design. Science of Computer

Programming, 90, 161–179. https://doi.org/10.1016/

j.scico.2013.10.005

Schnellbach, A. (2016). Fail-operational automotive

systems [Doctoral thesis, Graz University of

Technology]. Retrieved April 4, 2023, from

https://diglib.tugraz.at/download.php?id=5aa2484fb4b

cb&location=browse

Sini, J., Passarino, A., Bonicelli, S., and Violante, M.

(2022). A simulation-based approach to aid

development of software-based hardware failure

detection and mitigation algorithms of a mobile

robot system. Sensors, 22(13), 4665.

https://doi.org/10.3390/s22134665

Society of Automotive Engineers (2016). SAE J3061

cybersecurity guidebook for cyber-physical vehicle

systems.

Tichkiewitch, S., and Riel, A. (2014). Integration to face

modern quality challenges in automotive. Procedia

Engineering, 97, 1866–1874.

https://doi.org/10.1016/j.proeng.2014.12.340

Vater, J., Harscheidt, L., and Knoll, A. (2019). Smart

manufacturing with prescriptive analytics. 2019 8th

International Conference on Industrial Technology and

Management (ICITM), 224–228.

https://doi.org/10.1109/ICITM.2019.8710673

Weissnegger, R., Pistauer, M., Kreiner, C., Schuß, M.,

Römer, K., and Steger, C. (2016). Automatic testbench

generation for simulation-based verification of safety-

critical systems in uml: Proceedings of the 6th

International Joint Conference on Pervasive and

Embedded Computing and Communication Systems,

70–75. https://doi.org/10.5220/0005997700700075

Young, A., and Walker, A. (2018). Qualifying dependent

failure analysis within iso26262: Applicability to

semiconductors. In X. Larrucea, I. Santamaria, R. V.

O’Connor, and R. Messnarz (Eds.), Systems, Software

and Services Process Improvement (Vol. 896, pp. 331–

340). Springer International Publishing.

https://doi.org/10.1007/978-3-319-97925-0_27.

Quality Engineering Framework for Functional Safety Automotive Projects

469
