Proctoring Online Exam Using Eye Tracking

Waheeb Yaqub

, Manoranjan Mohanty

and Basem Suleiman

School of Computer Science, The University of Sydney, Australia

Center for Forensic Science, University of Technology Sydney, Australia

School of Computer Science and Engineering, University of New South Wales, Australia

Keywords:

Online Teaching, Online Proctoring, Student’s Privacy.

Abstract:

Online proctoring is required for online teaching. Typically, third-party video-based crowd-sourced online

proctoring solutions are being used for monitoring exam-takers (e.g., students). This approach, however, has

privacy concerns as an exam-taker’s face is shown to the third-party provider. In this paper, we propose

to address this concern using face hiding, and then monitoring the face hidden exam takers via eye (gaze)

tracking. The eye tracking is used to detect if the exam-taker is reading from computer screen, e.g., from

ChatGPT. The face is hidden by exposing the eyes such that eye tracking is possible.

1 INTRODUCTION

The dramatic increase in online teaching necessitates

online proctoring for exam-takers. Proctoring a large

number of exam-takers online is daunting for educa-

tional organizations, such as universities. As a re-

sult, universities are outsourcing the proctoring task to

third-party companies like ProctorU. Figure 1 demon-

strates how employees remotely monitor exam-takers

by reviewing videos of the exam rooms.

Figure 1: A widely used proctoring system, ProctorU, proc-

tors are monitoring exam takers. ( from (Dimeo, 2017)).

Outsourcing the proctoring task to a third-party

company raises privacy concerns (Nigam et al., 2021;

Furby, 2020). Exam-takers’ faces and background

information in the videos are readily available to

the company employees. There is a risk of these

videos being leaked to the public, including social

media (Balash et al., ; Milone et al., 2017). Conse-

quently, some exam-takers are uncomfortable sharing

their videos with third-party proctors.

One way to address privacy concerns is by blur-

ring or masking the face of an exam-taker (Yaqub

et al., 2022). However, it is crucial to ensure that

proctoring is still possible. Yakub et al. (Yaqub et al.,

2022) previously proposed a method to hide the face

of an exam-taker while enabling proctoring through

observing their body movements. However, their

work did not consider cheating by the exam-taker

through reading from another computer screen. In

this paper, we propose a proctoring approach that de-

tects such cheating by identifying when the exam-

taker is reading from another computer screen. We

consider this behavior as an anomaly and detect it

using eye-tracking. We do not hide the eyes of the

exam-taker, only the face.

One major challenge in this area of research is the

lack of a public exam-taking video dataset. Similar to

Cote et al.’s (Cote et al., 2016) work, we systemati-

cally collect an in-house dataset of ﬁve exam-taking

and cheating-attempting videos for our study. Exper-

imental results demonstrate that the proposed scheme

outperforms the work of Yaqub et al. (Yaqub et al.,

2022), which is one of the pioneering studies in this

ﬁeld. The proposed work represents an initial at-

tempt to address a new and practical research prob-

lem: privacy-preserving online proctoring. Further

research is necessary to enhance the results, such as

utilizing a larger exam-taking video dataset.

The rest of this paper is organized as follows: Sec-

738

Yaqub, W., Mohanty, M. and Suleiman, B.

Proctoring Online Exam Using Eye Tracking.

DOI: 10.5220/0012120600003555

In Proceedings of the 20th International Conference on Security and Cryptography (SECRYPT 2023), pages 738-745

ISBN: 978-989-758-666-8; ISSN: 2184-7711

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

tion 2 discusses related work. Section 3 provides an

overview of the proposed method. Section 4 explains

the Initialization stage, Section 5 explains face hid-

ing, and Section 6 explains anomaly detection. Sec-

tion 7 presents experimental results. Section 8 con-

cludes and discusses future work.

2 BACKGROUND AND RELATED

WORK

Current online proctoring systems generally fall into

three categories: Live Proctoring, Recorded Proctor-

ing, and Automated Proctoring (Hussein et al., 2020).

Live Proctoring is a real-time system where a crowd-

sourced human proctor monitors students’ activities

during the exam through live webcams, as shown in

Figure 1. It resembles on-campus exam proctoring,

recording minimal information about the exam taker.

With the rise of computer vision deep learning

models, a new form of live online proctoring has

emerged, monitoring all the exam takers’ movements

automatically using a software tool (Conijn et al., ).

The heavy reliance on such automated online proc-

toring solutions has also recently increased due to the

COVID-19 pandemic.

e et al. (2016) proposed a video summariza-

tion method for remote proctoring of online exams.

Their solution eliminates the need for a real-time

proctor by detecting abnormal behavior through head-

pose estimation and a two-state hidden Markov model

(HMM). Suspicious snippets are then forwarded to

proctors for further review. While addressing stu-

dents’ concerns about invasiveness, this approach

raises privacy concerns as snippets expose students

without any form of veiling (Balash et al., ).

The system developed by (Atoum et al., 2017)

veriﬁes the test-taker’s identity by continuously

matching their face with a database to prevent sub-

stitution during the exam. Text detection ensures the

absence of textual resources in the user’s surround-

ings, while speech detection aims to identify audible

speech. To detect cheating on the user’s computer,

tracked windows include those currently opened by

the user. Gaze estimation is used to detect anoma-

lous eye movements. However, unlike (Yaqub et al.,

2021), who relied solely on the webcam, this system

utilizes both the webcam and a wearable camera. The

portable camera is also employed to detect mobile

phones within the user’s ﬁeld of view.

The work by Masud et al. aimed to develop a fully

automated exam proctoring assistance system (Ma-

sud et al., 2022). The system relied solely on visual

data to detect cheating. The classiﬁer was trained

to detect cheating based on a multi-variate time se-

ries. To evaluate its performance, they collected 20

non-cheating and cheating behavior sample videos,

each a few seconds long and consisting of frames

varying from 75 to 250. Since the classiﬁer required

uniform-length training data, longer videos were split

into shorter ones for evaluation. The videos were

grouped based on length and evaluated individually

against the classiﬁer. Datasets with shorter videos

consistently performed better, achieving at least 80%

accuracy. However, as the video length increased, the

performance noticeably declined. The dataset with

videos of length 250 frames demonstrated accuracies

ranging from 60% to 80%. This decline indicates the

model’s limited ability to handle longer videos as they

are more likely to exhibit complex behavior, which

was not considered during training or dependent on

auditory input.

However, students’ privacy has not yet been ad-

dressed by researchers. The systems by (Irfan et al.,

2021; Masud et al., 2022; Cote et al., 2016; Atoum

et al., 2017) and commercial solutions are typically

built with the objective of maximizing cheating de-

tection, and without consulting students about their

concerns (Selwyn et al., 2021). The list of private in-

formation that an exam taker gives up can be unan-

ticipated and intrusive. Some of the examples of in-

formation collected during online exams are audio,

video, screen sharing, keyboard strokes, room pan-

ning videos, etc.

3 PROPOSED METHOD

Figure 2: Architecture of the proposed system.

Figure 2 shows the overall architecture of the pro-

posed system. There are four main players: a stu-

dent (i.e., exam-taker), a trusted entity, an honest-but-

curious third-party proctor, and a trusted university

staff. We assume that the trusted entity can access

the student’s information, such as exam videos, pho-

tos, ID cards, in plain-text. This entity can either

be present at the student-end (such as a trust-zone

in student’s computing device) or at the university-

end (such as a highly secure dedicated machine).

The third-party proctor is assumed to be honest-but-

Proctoring Online Exam Using Eye Tracking

739

curious as it does its task honestly but can be curious

to know information without any authorization. Com-

munications between different entities are assumed to

be secured.

Workﬂow: The proposed system consists of two

main stages: the one-time initialization stage and the

run-time eye-tracking-based anomaly detection stage.

In both stages, the exam taker is required to switch on

their webcam or selﬁe camera.

In the initialization stage, the exam taker’s identity

is ﬁrst checked by the Identity Check module of the

Trusted Entity to determine if they are enrolled for the

exam, similar to an ofﬂine exam. Proxy exam takers

are not allowed to take the exam. Enrolled exam tak-

ers then undergo a one-time eye calibration process

using the Eye Calibration module before the start of

the actual exam. This calibration is essential for un-

derstanding how the exam taker will interact with the

computer screen during the exam.

After the calibration, the plain-text eye calibration

data is sent by the Trusted Entity to the Third-Party

Proctor (Step 1). During the live exam stage, the exam

taker’s live exam-taking video is sent to the Trusted

Entity in plain-text (Step 2). The Face Hiding module

of the Trusted Entity then hides the facial information

to minimize privacy leaks. The face-hidden video is

sent to the Third-Party Proctor (Step 3).

The Third-Party Proctor runs anomaly detection

on the face-hidden video to detect potential cheating.

This anomaly detection tool serves as a triaging tool.

If the exam taker is ﬂagged by this tool, they are re-

ported to the Trusted Entity for another round of iden-

tity check, which is carried out automatically. This is

to ensure that a proxy has not replaced the exam taker

after their identity was previously veriﬁed. If a proxy

is found, their plain-text video clip is sent to Univer-

sity Staff for further action (Step 6).

If a proxy is not found, the ﬂagged exam taker un-

dergoes another round of manual check for malprac-

tice at the third-party proctor’s end by reviewing the

video clip showing the potential malpractice. Those

conﬁrmed by the third-party proctor are reported to

the trusted university staff (Step 5). University staff

obtain the plain-text video clip from the Trusted En-

tity (Step 6) and take any further actions.

Our proposed system is made of various modules

as shown in Figure 2. In the following sections, the

details of the initialisation and anomaly detection will

be discussed.

4 INITIALIZATION

4.1 Identity Check

This module can be divided into two parts: face ver-

iﬁcation and OCR. The face veriﬁcation part con-

ﬁrms the identity of the examinee and detects surro-

gate exam-takers before the exam. The OCR part ex-

tracts the student ID number to establish a connection

between the student sitting for the exam and the ID

photos in the database. It also labels the student with

their student ID number instead of their full name for

anonymization purposes. Figure 4 depicts separate

ﬂowcharts for the ID veriﬁcation part and the OCR

part.

The ﬂowchart for ID veriﬁcation illustrates the

process of face veriﬁcation. First, the images of stu-

dents’ photos are fed into the face detection algorithm

- MTCNN - to detect faces in the pictures. If faces

are detected, the system proceeds to the next stage;

otherwise, the process is terminated. Once the faces

are detected, the system utilizes the pre-trained face

recognition model - FaceNet - to convert them into

128-dimensional face embeddings. Subsequently, the

system employs the Siamese network, trained from

scratch, to improve data representation. Finally, the

system computes cos-similarity scores to determine

whether the examinee is genuine or if there is a surro-

gate exam-taker.

The ﬂowchart for OCR illustrates the text detec-

tion/recognition algorithm. Initially, the images of

students’ ID cards are input into the text detection

and recognition algorithm - EasyOCR - to detect the

student IDs on the cards. If the correct IDs are de-

tected, the system conﬁrms the detection; otherwise,

it prompts the human proctor to recheck.

Figure 3: The initialisation process in live system on student

side interface.

4.1.1 Face Detection

In Figure 4, the system utilizes MTCNN to cap-

ture accurate bounding boxes of faces. The pre-

trained face recognition algorithm, FaceNet, is then

employed to extract face embeddings, which repre-

sent the features of faces. However, face embeddings

SECRYPT 2023 - 20th International Conference on Security and Cryptography

740

Start

Fit ID?

Yes

Text Detection and

Recognition

EasyOCR

Images

End

Correct ID

Output

Start

Detected?

Yes

Face Detection

MTCNN

Images

End

Output

Embeddings

Face Embeddinngs

Compute Cos-

similarity

Siamese Network

ID Verification

OCR

Train it by Triplet

Loss

FaceNet

Figure 4: The detailed ﬂowchart of ID veriﬁcation module.

alone are insufﬁcient for distinguishing different in-

dividuals’ faces using cosine similarity scores. To

improve data representation, a one-shot learning face

recognition algorithm is applied to project the face

embeddings onto another hyperplane.

The main objective is to establish the Siamese

Network. There are three identical layers for every in-

put face embedding, and the face embeddings are con-

catenated to compare their cosine similarity scores.

The weight vectors are used to compare the face veri-

ﬁcation by computing the cosine similarity score. The

Triplet loss training criterion is utilized for randomly

selecting a batch of triplets: anchor, positive, and neg-

ative. The triplet loss is given by:

Triplet Loss =

∑

i=1

[( f

− f

)

+ ( f

− f

)

+ α],

where f

represents the output of the anchor data,

refers to the output of the positive data, f

repre-

sents the output of the negative data, and α is a hyper-

parameter that separates the distance between the pos-

itive and negative data as much as possible. The hy-

perparameters are as follows: Input Dimension = 128,

Output Dimension = 64, Batch size = 1000, Epochs =

100, Steps per epoch = 10, and α = 0.2.

The anchor and the positive embedding must be

of the same class, while the negative embedding must

be of a different class. The core concept of the triplet

loss is to minimize the difference between the weight

vectors of the anchor and the positive, and maximize

the difference between the anchor and the negative.

4.1.2 OCR

EasyOCR was selected to implement text detec-

tion and recognition in our system. The Easy-

OCR pipeline includes image input, pre-processing,

CRAFT for detection models, mid-processing,

ResNet + LSTM + CTC for recognition models, and

post-processing for text output. However, EasyOCR’s

efﬁciency is low due to the long execution period. To

address this issue, we implemented a ﬂag mechanism.

The fundamental concept of the ﬂag mechanism is to

terminate the process once the system detects the cor-

rect student ID, and continue capturing until the stu-

dent’s ID is detected if necessary.

The lower half of Figure 4 shows the ﬂowchart

of how the OCR system functions. The input is stu-

dent ID images. After EasyOCR scans the student ID

photos, the output data type is text, and the system

compares the text with the student ID in the database.

If the text matches the student ID in the database, the

process will terminate. Otherwise, it will continue to

search for the text that matches the student ID using

the ﬂag mechanism.

During the initialisation stage, students will use

the ID veriﬁcation UI system to take photos of their

faces for ID veriﬁcation purposes. This process aims

to prevent exam surrogate takers from attending ex-

ams. The ID veriﬁcation module will detect any exam

surrogate takers present during the exams. Figure 3

illustrates the UI of the module functions during the

initialization process.

Proctoring Online Exam Using Eye Tracking

741

4.1.3 Performance of ID Veriﬁcation

The ID veriﬁcation module is validated using a self-

made test dataset to assess the performance of face

veriﬁcation and OCR algorithm. The dataset con-

sists of ﬁve distinct student IDs, each with the follow-

ing sampled frames and lengths: P1

(230 frames, 9

secs), P2

(271 frames, 17 secs), P3

(372 frames,

12 secs), P4

(285 frames, 9 secs), and P5

(304

frames, 10 secs).

4.2 Eye Calibration

The student’s sitting pattern is initially recorded

through her sitting position and eye interaction with

the computer. The correct sitting position is estab-

lished by displaying a real-time camera view to the

student and instructing her to adjust her sitting posi-

tion. A method similar to the approach proposed by

Yaqub et al. (Krafka et al., 2016) is then employed to

accurately record the eye interaction.

5 FACE HIDING

This module hides the student’s facial information

from a video to minimize privacy leaks. We use blur-

ring and masking techniques to conceal the face (Fig-

ure 5). In anonymized videos, the eyes remain visible

to facilitate anomaly detection, speciﬁcally cheating

detection. Firstly, the face and eyes are detected, and

then blurring or masking is applied. The eye detection

and subsequent blurring or masking are performed us-

ing Yaqub et al.’s method (Yaqub et al., 2022). The

eyes are not concealed to ensure gaze detection (eye

tracking).

Figure 5: Frame-by-frame blurring or masking (Yaqub

et al., 2022).

6 ANOMALY DETECTION

Anomaly detection is used to detect anomalies even

when the student’s face is blurred or masked. Gaze

detection is used for this purpose. In the following

section, we discuss gaze detection in detail.

6.1 Gaze Estimation

The gaze detection module determines if the student’s

gaze is within the screen boundaries. It utilizes the

output of the gaze detection model and information

about the examinee’s screen size to assess if the ex-

aminee is looking beyond the physical range of the

screen, which is considered anomalous behavior. The

gaze estimation module relies on two sub-modules:

iTracker and the calibration model.

iTracker submodule was trained using a dataset of

single portrait photos taken by an Apple mobile de-

vice. The training was done using CNN. The core

CNN-based neural network of iTracker is referred to

as the iTracker model in the paper. Inputs to the model

include left eye, right eye, and face images from the

original frame, as well as a face grid calculated based

on the spatial position of the face image. The ﬁnal

output of the iTracker model is the coordinate of the

estimated gaze point on the photo frame. The spatial

features prevented us from using the iTracker mod-

ule directly. Therefore, we calibrated the output of

iTracker for various laptop and desktop screens. The

calibration model is a linear model that takes the raw

output of the iTracker model as input and provides the

calibrated point position as output.

Calibrating Gaze Estimation Module. We intro-

duced a simpler linear calibration model compared

to existing Support Vector Regression (Krafka et al.,

2016). Unlike traditional iTracker, we expect the

screen size of the examinee to vary at most 20 inches

in the real world. To overcome this, we further im-

proved performance by developing a personalized cal-

ibration model. For this, a single calibration model

per examinee was used. We assessed the linear model

using 25 pictures collected by us, corresponding to a

5 x 5 grid on the screen. Figures 6 and 7 show the esti-

mated gaze location compared to the ground truth for

subjects with and without glasses. All red points rep-

resent the raw prediction points of the iTracker, while

the corresponding black points represent the ground

truth points. We also employed a linear model to re-

duce incorrect gaze estimations by mapping the pixel

locations to the closest original ground truth.

We examined various personalised linear calibra-

tion models based on the Euclidean distance metric

(Krafka et al., 2016). The ﬁve models used to assess

the effectiveness of personalised linear calibration are

listed below, along with the results in Table 1.

I. lm(x, y): X

, Y

∝ Linear(X

, y

)

SECRYPT 2023 - 20th International Conference on Security and Cryptography

742

Figure 6: Incorrect estimated gaze location by Itracker be-

cause of screen size (subject1) without glasses.

Figure 7: Incorrect and irregularities estimated gaze loca-

tion by Itracker because of screen size and screen light re-

ﬂection on glasses (subject1).

II. lm(x, y, nx): X

, Y

∝ Linear(X

, y

, n

)

III. lm(x, y, ny): X

, Y

∝ Linear(X

, y

, n

)

IV. lm(x, y, nx, ny): X

, Y

∝ Linear(X

, y

, n

)

V. lm(x, y, nx, ny, nz): X

, Y

∝ Linear(X

, y

, n

)

Data X

and Y

represent the raw output of the

iTracker. n

, n

, and n

represent the nose coordinates

provided by Mediapipe. Nose coordinates are used to

indicate the model’s response to the examinee’s head

turning.

From the table, the most robust model is lm(x, y),

which signiﬁcantly reduces errors for situations with

and without glasses-wearing examinee. The adjusted

error is, on average, 42% of the raw error, equivalent

to 3.97cm on a 14-inch-screen laptop. This error is

considered acceptable on a large screen compared to

mobile phones.

Gaze Estimation Anomaly Detection Module.

The combination of the itracker model and the person-

alized calibration model serves as the gaze estimation

module for the anomaly detection system. The perfor-

mance of the gaze estimation module is tested using a

self-made gaze video, as demonstrated in the upcom-

Table 1: Performance summary for 3 different anomaly de-

tection modes with 2 different privacy preserving modes.

(Acc. for Accuracy, Rec. for Recall, Pre. for Precision).

Black background GUI Error(cm) Calibrated error(cm)(Cross-Validation)

Raw lm(x,y) lm(x,y,nx) lm(x,y,ny) lm(x,y,nx,ny) lm(x,y,nx,ny,nz)

Glasses Subject 1 7.85 4.07 4.24 3.71 4.16 4.89

Subject 1 7.86 4.3 4.27 5.16 5.21 5.71

Error 7.855 4.185 4.255 4.435 4.685 5.3

Error cut 46.72% 45.83% 43.54% 40.36% 32.53%

Subject 2 4.03 3.02 3.24 2.96 3.05 3.12

Subject 2 3.78 2.91 2.96 3.09 3.34 3.16

Error 3.905 2.965 3.1 3.025 3.195 3.14

Error cut 24.07% 20.61% 22.54% 18.18% 19.59%

Subject 3 17.17 6.62 5.97 5.73 5.2 5.04

Subject 3 16.37 5.49 5.07 7.6 6.52 6.58

Error 16.77 6.055 5.52 6.665 5.86 5.81

Error cut 63.89% 67.08% 60.26% 65.06% 65.35%

Glasses Free Subject 1 8.33 4.92 5 5.24 5 16.13

Subject 1 6.88 4.76 7.17 68.36 73.72 66.11

Error 7.605 4.84 6.085 36.8 39.36 41.12

Error cut 36.36% 19.99% -383.89% -417.55% 440.70%

Subject 2 4.4 2.91 4.29 4.35 5.31 5.95

Subject 2 3.32 3.61 2.35 3.35 3.49 7.41

Error 3.86 3.26 3.32 3.85 4.4 6.68

Error cut 15.54% 13.99% 0.26% -13.99% -73.06%

Subject 3 14.25 4.45 6.33 4.28 6.35 6.24

Subject 3 14.1 5.08 5.35 4.96 5.22 5.16

Error 14.175 4.765 5.84 4.62 5.785 5.7

Error cut 66.38% 58.80% 67.41% 59.19% 59.79%

Mean Error cut 42.16% 37.72% -31.65% -41.46% -56.08%

ing experiment section. We assessed the prediction

results of all videos and discovered a predictable pat-

tern in the module. It tends to predict points closer to

the coordinate origin, typically located at the top of

the screen where the camera is positioned. For exam-

ple, if the user is looking at the bottom edge of the

screen, the predicted gaze point will be higher than

the bottom edge. However, if the user is looking at

the top edge, there is no such gap. Therefore, we im-

proved the workﬂow of the gaze estimation module.

The image dataset is divided into a training set and

test set. The calibration model is trained on the train-

ing set and applied to the test set to estimate the error.

This estimated error is then used to adjust the left,

right, and bottom edges of the screen, forming the

anomaly decision boundary for the gaze estimation

anomaly detection module. By using the anomaly

decision boundary, the recall increases from 13% to

88% without affecting the F1-score compared to the

results obtained with the raw screen edges.

The practicability of the gaze estimation anomaly

detection module in the simulated test video has been

discussed. Figure 8 shows the ﬂow chart of this mod-

ule.

• In the ﬁrst stage, the training set provided by

the examinee is used to build a personalized

calibration model. Gaze pictures are processed

with their corresponding face and eye bounding

boxes provided by the privacy-preserving mod-

ule. The output of this step is the input for

iTracker. The raw coordinate prediction results

of iTracker are grouped with the corresponding

ground truth labels for training the personalized

calibration model of the examinee. The calibra-

tion model and the iTracker model are then com-

bined to form the gaze estimation module.

Proctoring Online Exam Using Eye Tracking

743

iTracker

Index with

Label

Data Collection GUI

Eye data (Photos,

Gaze Data)

Gaze Estimation Module

Personalized

Calibration Model

Training set

Test set

Split the Data

Personalized

Calibration Model

Train

Coordinates of face

and eyes

Monitor

Screen Size

Yes

First stage

iTracker

Start

Label the Frame as

‘Normal’

Privacy

Preserving

Estimated Error

Label the Frame as

‘Abnormal’

End

Judge?

Second stage

Third stage

Exam

Video

Frame

Figure 8: The ﬂowchart of gaze estimation anomaly detection module.

• In the second stage, the post-processed test set

passes through the gaze estimation module to ob-

tain the estimated error.

• In the ﬁnal stage, the estimated error is used

to adjust the monitor size to the anomaly deci-

sion boundary. Like previous stages, exam video

frames are processed with face detection bound-

ing boxes. The data then goes through the gaze

estimation module to obtain the calibrated coor-

dinate prediction result. The adjusted prediction

result is compared to the decision boundary to de-

termine if the frame is an anomaly and is marked.

7 RESULTS

The experiment used a test dataset comprising three

exam-taking videos from different participants to

measure the performance of Yaqub et al.’s image-

hashing-based anomaly detection method, our gaze

detection-based anomaly detection method, and the

combined anomaly detection method (both hashing

and gaze). Each video had a duration of two to three

minutes. Detailed instructions on how to emulate an

exam and attempt cheating were provided to each par-

ticipant. Each frame of the video was manually la-

beled as either a normal or anomaly pose. The partic-

ipants were asked to perform the following actions for

each direction: left, right, up, and down, to test Yaqub

et al.’s image-hashing-based method.

MediaPipe and Dlib were used for face and eye

detection, Gaussian blurring, single-white masking,

and dHashing-based image hashing with a hash size

of 12. The experiment was conducted on a Windows

10 computer with 16 GB RAM and an i7-10710U

CPU. Each video frame was processed using Medi-

aPipe and Dlib for face and eye detection, followed

by the blurring or masking-based face hiding module,

and ﬁnally the dHashing-based image hashing mod-

ule. The obtained anomaly results were compared to

the ground truth.

Table 2: Performance summary for 3 different anomaly de-

tection modes with 2 different privacy preserving modes

(Acc. for Accuracy, Rec. for Recall, Pre. for Precision).

Blur Mask

Mode Acc. Rec. Pre. Acc. Rec. Pre.

1 dHash 67.4% 41.2% 83.3% 76.6% 64.7% 83.3%

Gaze 78.3% 57.6% 96.1% 73.7% 52.9% 88.2%

Combined 85.1% 80.0% 88.3% 85.1% 87.1% 83.1%

2 dHash 76.6% 54.1% 95.8% 77.7% 61.2% 89.7%

Gaze 73.7% 51.8% 89.8% 72.6% 49.4% 89.4%

Combined 88.6% 84.7% 91.1% 85.7% 83.5% 86.6%

3 dHash 78.2% 60.0% 92.3% 80.6% 63.8% 94.4%

Gaze 78.8% 67.5% 85.7% 78.8% 65.0% 88.1%

Combined 87.3% 90.0% 84.7% 90.3% 92.5% 88.1%

The proctoring system is designed to perform

anomaly detection on anonymized images such as

blurred and masked images. It is essential to evaluate

the model’s performance on anonymized video clips.

We propose two main anonymization functions: the

image hashing model will be evaluated on blurred and

masked images, respectively.

The dHash model maintains its performance on

SECRYPT 2023 - 20th International Conference on Security and Cryptography

744

anonymized data, performing even better on mask-

ing images compared to blurred anonymization. The

running time of the model on anonymized data re-

mains at the same level as the original one. Table 2

presents the performance of the proposed method for

three participants. The running time of the entire sys-

tem was also measured in terms of FPS (frames per

second), which are 31 and 35 FPS, respectively. As

expected, the masking approach performed better, al-

though both approaches can be easily executed on

normal PCs.

8 CONCLUSION AND FUTURE

WORK

Online student proctoring is a reality in online exams.

In this paper, we proposed a privacy-preserving online

proctoring system using gaze-based anomaly detec-

tion. Experiments showed promising results. There

are several ways this preliminary work can be further

improved. The ﬁrst requirement is creating a large

dataset of exam-taking students. Secondly, the pro-

posed method can be improved by exploring other

privacy-preserving measures and considering other

anomalies such as audio.

ACKNOWLEDGEMENTS

This work is supported by UTS New Faculty Startup

Grant 261011.0226628. We also thank Jason, Yang,

Mill, Doris, and Vivi for implementing/testing algo-

rithms on their dataset.

REFERENCES

Atoum, Y., Chen, L., Liu, A. X., Hsu, S. D., and Liu, X.

(2017). Automated online exam proctoring. IEEE

Transactions on Multimedia, 19(7):1609–1624.

Balash, D. G., Kim, D., Shaibekova, D., Fainchtein, R. A.,

Sherr, M., and Aviv, A. J. Examining the examiners:

Students’ privacy and security perceptions of online

proctoring services. In Seventeenth Symposium on Us-

able Privacy and Security (SOUPS 2021).

Conijn, R., Kleingeld, A., Matzat, U., and Snijders, C. The

fear of big brother: The potential negative side-effects

of proctored exams. Journal of Computer Assisted

Learning, n/a(n/a).

Cote, M., Jean, F., Albu, A. B., and Capson, D. (2016).

Video summarization for remote invigilation of online

exams. In 2016 IEEE Winter Conference on Applica-

tions of Computer Vision (WACV), pages 1–9. IEEE.

Dimeo, J. (2017). Online exam proctoring catches cheaters,

raises concerns. https://www.insidehighered.

com/digital-learning/article/2017/05/10/

online-exam-proctoring-catches-cheaters-raises-concerns.

Furby, L. (2020). Are you implementing a remote proctor

solution this fall? recommendations from nln testing

services. Nursing education perspectives, 41(4):269–

270.

Hussein, M. J., Yusuf, J., Deb, A. S., Fong, L., and Naidu,

S. (2020). An evaluation of online proctoring tools.

Open Praxis, 12(4):509–525.

Irfan, M., Aslam, M., Maraikar, Z., Jayasinghe, U., and

Fawzan, M. (2021). Ensuring academic integrity of

online examinations. In 2021 IEEE 16th Interna-

tional Conference on Industrial and Information Sys-

tems (ICIIS), pages 295–300.

Krafka, K., Khosla, A., Kellnhofer, P., Kannan, H., Bhan-

darkar, S., Matusik, W., and Torralba, A. (2016). Eye

tracking for everyone. In Proceedings of the IEEE

conference on computer vision and pattern recogni-

tion, pages 2176–2184.

Masud, M. M., Hayawi, K., Mathew, S. S., Michael, T., and

El Barachi, M. (2022). Smart online exam proctoring

assist for cheating detection. In International Con-

ference on Advanced Data Mining and Applications,

pages 118–132. Springer.

Milone, A. S., Cortese, A. M., Balestrieri, R. L., and Pit-

tenger, A. L. (2017). The impact of proctored on-

line exams on the educational experience. Currents

in Pharmacy Teaching and Learning, 9(1):108–114.

Nigam, A., Pasricha, R., Singh, T., and Churi, P. (2021).

A systematic review on ai-based proctoring systems:

Past, present and future. Education and Information

Technologies, pages 1–25.

Selwyn, N., O’Neill, C., Smith, G., Andrejevic, M., and Gu,

X. (2021). A necessary evil? the rise of online exam

proctoring in australian universities. Media Interna-

tional Australia, page 1329878X211005862.

Yaqub, W., Mohanty, M., and Suleiman, B. (2021).

Image-hashing-based anomaly detection for privacy-

preserving online proctoring. arXiv preprint

arXiv:2107.09373.

Yaqub, W., Mohanty, M., and Suleiman, B. (2022). Privacy-

preserving online proctoring using image-hashing

anomaly detection. In 2022 International Wireless

Communications and Mobile Computing (IWCMC),

pages 1113–1118.

Proctoring Online Exam Using Eye Tracking

745
