Automatic Test-Based Assessment of Assembly Programs

ıs Tavares

, Bruno Lima

1,2

and Ant

onio J. Ara

ujo

1,2

Faculty of Engineering of the University of Porto, Porto, Portugal

INESC TEC, Porto, Portugal

Keywords:

Arm, Assessment, Programming, Assembly.

Abstract:

As computer science and engineering programs continue to grow in enrollment, automatic assessment tools

have become prevalent. Manual assessment of programming exercises can be time-consuming and resource-

intensive, creating a need for such tools. In response, this paper proposes a tool to assess assembly exercises,

speciﬁcally ARM64 programs, and provide real-time feedback to students. The tool includes features for

evaluating, analyzing, and detecting plagiarism in student submissions. After two years of intensive usage

in a higher education environment, the results and analysis show a positive impact and potential beneﬁts

for teachers and students. Furthermore, the tool’s source code is publicly available, making it a valuable

contribution to building more effective and efﬁcient automatic assessment tools for computer science and

engineering schools.

1 INTRODUCTION

In the last half-century, there has been a growing

interest in developing and deploying automatic as-

sessment tools, ranging from assembly language pro-

grams on punched cards to web-based platforms. Pro-

gramming assignments have become essential for un-

derstanding programming languages (Douce et al.,

2005). Today, programming courses are offered in

nearly all engineering schools in addition to computer

science programs (Caiza and

Alamo Ramiro, 2013).

As the number of students enrolling in computer

science and engineering programs continues to in-

crease, teachers face the challenge of providing ac-

curate and timely feedback in a time-efﬁcient manner

(Marchiori, 2022). This paper proposes the AEAS

(ARM [Extensible] Assessment System) tool for au-

tomatically evaluating ARM64 programs to address

the time-consuming manual assessment of assembly

exercises. The AEAS tool is a web-oriented plat-

form designed to assess assembly exercises automat-

ically and provide students with immediate feedback

on their performance. The tool is built on top of the

AOCO command-line system (Damas et al., 2021),

containing features for plagiarism detection, analysis,

and evaluation of student submissions.

The AEAS tool goes beyond traditional automatic

assessment systems that offer only teacher-speciﬁc

features. It provides a web-oriented platform that al-

lows students to test their assembly programs’ ﬂow on

the browser without installing any compiler or Inte-

grated Development Environment. Assembly devel-

opment environments, such as DS-5 (ARM, 2010),

can be complex to conﬁgure, which may discourage

novice users. The AEAS tool addresses this challenge

by providing an intuitive platform for testing assem-

bly exercises.

The main contribution of this paper is to present

the AEAS assessment tool and its features.

Section 2 provides an overview of automatic as-

sessment systems’ background, while section 3 de-

scribes the system’s functionalities from the perspec-

tives of both students and teachers. The system’s ar-

chitecture is presented in section 4, and the grading

process is discussed in section 5. Section 6 reports on

the AEAS tool’s experiences and analyses its results

in an educational setting. Finally, section 7 concludes

the paper and points out some future work.

2 BACKGROUND

Douce et al. (Douce et al., 2005) deﬁned three gener-

ations of assessment systems. Firstly, the early as-

sessment systems are grader programs that test the

students’ programs with either correct or wrong re-

sults. Secondly, tool-oriented systems are more com-

plex grader programs, usually encapsulated in a ter-

572

Tavares, L., Lima, B. and AraÃžjo, A.

Automatic Test-Based Assessment of Assembly Programs.

DOI: 10.5220/0012129100003538

In Proceedings of the 18th International Conference on Software Technologies (ICSOFT 2023), pages 572-579

ISBN: 978-989-758-665-1; ISSN: 2184-2833

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

minal interface or GUI. The second-generation tools

also introduce features to students themselves to test

their assignments. Lastly, web-oriented systems are

the latter approach to automatic assessment systems.

Typically, these last-generation tools focus on

more than just testing assignments. These tools

propose utilities for managing and maintaining the

assessments to permit teachers to understand how

students are progressing, thus entitling teachers to

make corrective efforts against students who may

be encountering difﬁculties. The AEAS tool is a

third-generation tool and has evolved from a second-

generation one.

Looking at the state of the art, there are several

automatic assessment evaluation tools with different

characteristics and focused on different programming

languages, such as:

• CodePost (codepost, 2023): CodePost is a web-

based commercial tool that provides automatic

grading and feedback for programming assign-

ments. It supports multiple programming lan-

guages (but not assembly) and integrates with

popular learning management systems(Mpungose

and Khoza, 2022) like Canvas and Blackboard.

• Gradescope (Turnitin, 2023): Gradescope is a

popular commercial platform for online grading

and assessment, including programming assign-

ments for multiple programming languages (but

not assembly). It allows for various question

types, including coding questions, and provides

automatic grading and feedback tools.

• CodeRunner (CodeRunner, 2022): CodeRunner

is a free open-source question-type plug-in for

Moodle that can run program code submitted by

students in answer to a wide range of program-

ming questions in many different languages (as-

sembly not supported). It is intended primarily

for computer programming courses, although it

can be used to grade any question for which the

answer is text.

• Web-CAT: (Edwards and Perez-Quinones, 2008):

Web-CAT is a web-based tool for automatically

assessing programming assignments. It supports

multiple programming languages (but not assem-

bly) and provides various testing options, includ-

ing input/output and black-box testing.

• BOSS (Joy et al., 2005): BOSS is a platform-

independent system for submitting and grading

programming assignments in C and Java. It in-

cludes a set of customizable program metrics, al-

lows for online marking and feedback delivery,

and has built-in plagiarism detection software.

• CourseMarker (Higgins et al., 2005): Course-

Marker is a Java-based client-server evaluation

tool that automatically evaluates Java and C/C++

programming assignments and diagrams.

Regarding these types of tools, (Tarek et al., 2022)

recently carried out an extensive review where they

identiﬁed a few more tools such as Mooshak (Leal

and Silva, 2003) and EvalSeer (Nabil et al., 2021).

However, none of the presented tools support the eval-

uation of assembly assignments.

However, in constructing this tool, we want to take

advantage of our previous tool, AOCO (Damas et al.,

2021), and what is best in current tools. The objec-

tive is to construct a free and open-source tool, thus

allowing the community to adapt it to its needs.

3 FUNCTIONALITIES

The AEAS tool offers functionalities for two distinct

types of users: students and teachers. Students use the

tool to test the assignments. Teachers use the system

to assess students’ work, maintain assignments, and

support administration demands. Before going into

detail about the system’s features, it is necessary to

make a few considerations about the general opera-

tion of the system and how it is modeled.

The AEAS tool does not provide a direct channel

for students to upload their assignments to be auto-

matically graded by the system. The system exclu-

sively provides students with a way to test their exer-

cises. When the assignments reach the grading pro-

cess, it is necessary to deliver and later store the stu-

dents’ solutions (typically a source ﬁle) in another in-

frastructure. This architectural decision is motivated

to avoid requiring students to log into the assessment

system. With these considerations in mind, it is possi-

ble to describe the grading progress of an assignment

with the following workﬂow.

1. The teacher creates an assignment in the system. The

assignment contains a set of public and private tests.

2. The teacher informs students that a new assignment is

available in the system.

3. Students access the system and develop solutions for

the assignment.

4. Students test their assignment solutions in the system

against a set of public tests.

5. Students upload their assignment solutions to an exter-

nal infrastructure before the deadline.

6. The teacher collects the assignment solutions from the

external infrastructure.

7. The teacher grades the assignment in the system with

the private tests and gives students feedback.

Automatic Test-Based Assessment of Assembly Programs

573

3.1 What Deﬁnes an Exercise?

This subsection deﬁnes an exercise inside the AEAS

tool, going through its deﬁnition and structure. Exer-

cises are the central component of grading students.

Exercises must have a description of how to design

the exercise, a list of parameters and returns, and a

list of tests that map each group of inputs to a spe-

ciﬁc output. Teachers can add a list of private tests.

These latter tests are merely used for student grad-

ing, while the system uses the default ones for student

public feedback.

The exercise requires two deﬁnitions that work

symbiotically, a viewing deﬁnition and a technical

deﬁnition. The technical one includes the exercise pa-

rameter types, return types, and the list of tests. On

the other hand, teachers must deﬁne a viewing deﬁ-

nition that contains a name, a description of the work

to be done, and, optionally, a label to categorize it-

self. Below are the explanation and examples of each

viewing deﬁnition and the technical deﬁnition.

Name. This is the name of the exercise. It is the

main ﬁeld to identify an exercise.

Example: Sum of odd numbers in an array

Description. The description provides the students

with a complete exercise description. It should guide

students on the details of the exercise and contain all

the information needed to develop it. Additionally,

the system supports L

X, Markdown, and code snip-

pets on this ﬁeld to allow teachers to point more efﬁ-

ciently to particular aspects.

Example: Develop a subroutine to calculate the

sum of the odd integers in an array. If there

are no odd numbers, return 0.. A subroutine call

can be as follows oddSum(array, length) where

int array = {1,4,7} and int length = 3 and

the expected output would be 8.

Label. This optional ﬁeld categorizes exercises. It

can be helpful to differentiate distinct types of exer-

cises and allow students to identify them better.

Example: Array problems

Technical Deﬁnition. The technical deﬁnition of

the exercise deﬁnes how the exercise’s solution must

be modeled and how it should perform. The AEAS

tool module that uses this technical deﬁnition pro-

vides an instruction manual

on deﬁning an exercise.

Repository of the AEAS grading module with the in-

struction manual on deﬁning exercises. github.com/luist18/

areas

Listing 1: Example of an exercise’s technical deﬁnition.

# e x e r c i s e d e f i n i t i o n

sumOdd :

params : [ a r r a y i n t , i n t ]

r e t u r n : [ i n t ]

# t e s t s d e f i n i t i o n

sumOdd :

− i n p u t s : [ [ ] , 0 ]

o u t p u t s : [ 0 ]

w e i g h t : 0 . 5

− i n p u t s : [ [ 2 , 5 , 7 ] , 3 ]

o u t p u t s : [ 1 2 ]

w e i g h t : 0 . 2 5

− i n p u t s : [ [ 5 , 7 ] , 2 ]

o u t p u t s : [ 1 2 ]

w e i g h t : 0 . 2 5

3.2 Student Functionalities

Students interact through the web interface. In the

system, students have access to a list of the exercises,

together with a succinct description and a pointer to

their page. The name, description, label, author, and

publication date are some properties that deﬁne an ex-

ercise. The students see these properties and an inte-

grated code editor that allows them to develop their

solutions inside the browser. Then, students can sub-

mit their approaches and acquire immediate feedback

from the system on how their solution performed on

the public tests. When students submit their exercise

solutions, a set of unit tests veriﬁes the program’s va-

lidity. These unit tests are public tests that teachers

deﬁne and do not cover all possible program ﬂows.

While students may use this as a means to test their

exercises more efﬁciently, it is important to note that

passing all public tests does not guarantee the com-

plete validity of their solutions.

Submit

2 tests failed

Expected [0] for input [[],0], instead got [1]

Expected [12] for input [[2,5,7],3], instead got [14]

Test passed. Input == [[5,7],2]. Output == [12]

Practice your code in a friendly environment

Pages

Home

Exercises

Report an issue

WIP

Useful pages

Moodle

SIFEUP

ldr w0, [sp, 28]

add sp, sp, 32

ret

Figure 1: Output for the exercise and solution mentioned

above.

Considering the previously deﬁned exercise in the

examples of section 3.1 that is assumed to sum odd

integers, and a program which sums all integers re-

gardless of their parity. Also, assume that the pro-

gram does not check if the array is empty before read-

ing from it. Thus, it will fail on the edge case of the

empty array since it will try to read from an invalid

memory address. With these considerations, the out-

put for three test cases can be observed in ﬁgure 1.

ICSOFT 2023 - 18th International Conference on Software Technologies

574

3.3 Teacher Functionalities

Teachers have access to a large set of functionalities.

This happens because teachers are the main actors

maintaining and managing the system. Hence, this

leads to a few distinct categories of functionalities that

a teacher can perform. This section explains teachers’

functionalities in each area.

Teachers are privileged users in the system.

Therefore, to access their features, teachers must be

previously registered in the system and then log in to

the system’s dashboard to access those features.

3.3.1 Administrative Functionalities

To give teachers an overall summary of the system’s

performance and operations, the AEAS tool offers

teachers a dashboard to monitor information about

the system’s status. These details include CPU usage,

memory usage, server uptime, and request trafﬁc. In

addition, the system also presents a functionality to

set up other teachers’ accounts.

3.3.2 Managing Functionalities

As teachers are the only administrative user of the

system, they are responsible for managing almost ev-

ery data stored in the system’s database. This data

includes the exercises as well as other information

entries related to them. Exercises are the central in-

formation element of the system. Each database en-

try, except for teachers’ authentication entries, is con-

nected to an exercise. The system’s information ele-

ments are the following:

• Exercise - represents the central information element

of the system. Holds the exercise deﬁnition;

• Label - represents a designation to label exercises;

• Submission - represents an exercise submission. This

element is mostly used for statistical purposes and later

explained in section 3.3.4;

• Batch Result - represents the information of an assign-

ment batch evaluation. The following section details

this element. Holds the information about each stu-

dent’s unit-test results, plagiarism, and instruction.

The assessment system allows teachers to perform

CRUD operations (Create, Read, Update, Delete) on

the above items. Filling out forms on the system’s

dashboard enables teachers to create new instances

of these information items. To read the information

from the system, teachers can access a set of listings

in the dashboard. Listings allow them to view the data

stored and have a menu of quick actions to delete the

element or navigate to the element’s update/edit page.

3.3.3 Grading Functionalities

The grading functionalities are an important set of the

system’s functionalities. These are assessment sys-

tems’ characteristic functionalities. This group com-

prises functionalities to test student assignments in

three ways: unit-test-wise, plagiarism-wise, and in-

struction presence-wise. In addition, it also features

an option to grade student assignments in a batch

mode, allowing teachers to test unit tests, plagiarism,

and instruction present at once. Details about the in-

ternal functioning of these functionalities are given in

section 4.

The AEAS tool evaluates student assignments us-

ing unit tests. As previously stated, students have a

collection of public tests to work with when design-

ing exercises’ solutions. Most of the time, public tests

only cover some potential program ﬂow of an exer-

cise solution, leaving edge situations to private test-

ing. The teachers then use a different set of tests,

known as private tests, to evaluate the student’s re-

sponses. With this in mind, the system enables teach-

ers to design exercises that include the two kinds of

tests. While students can only test their solutions in a

public setting, teachers can evaluate the assignments

in a more conﬁdential conﬁguration.

Delivering the same exercises to multiple students

could lead to plagiarism. Plagiarism in coding assign-

ments differs from other types of plagiarism (Agrawal

and Sharma, 2016). It often happens that if the ex-

ercise assignment is very objective and, since there

are not many workarounds in assembly solutions,

students’ programs are similar (Kustanto and Liem,

2009). Given this, the evaluation system allows teach-

ers to choose a similarity level between pairs of as-

signments for each plagiarism analysis. The preced-

ing allows teachers to raise the barrier when exercise

solutions are likely identical and lower the thresh-

old when solutions are expected to be highly diverse.

The results of a plagiarism analysis advise the teacher

on which pair of students exceed the deﬁned barrier.

These examples, however, are not free from manual

analysis by the teacher because they may turn out to

be false positives.

Another grading functionality is to check whether

students have used a speciﬁc assembly instruction in

their code submissions. Teachers may intend to evalu-

ate the use of particular instructions in an assignment.

For example, a teacher may want students to imple-

ment an activity with SIMD (Single Instruction Mul-

tiple Data) instructions. However, it could be pos-

sible to implement the same program without SIMD

instructions. Despite completing the work, doing so

would be immoral. Thus, to prevent these circum-

stances, the system checks for speciﬁc instructions in

Automatic Test-Based Assessment of Assembly Programs

575

User

PATH /

NGINX

(reverse proxy)

Website

Backend

Plagiarism

Detector

Unit

Testing

MongoDB

Database

HTTP Requests

Socket connections

PATH /api

Figure 2: Architecture diagram of the AEAS tool.

assignment solutions and creates a report for each stu-

dent.

Despite allowing to run the actions aforesaid in-

dividually, the system can run these actions in batch

mode. The batch mode is advantageous when grading

a whole assignment for a group of students, allowing

the teacher to obtain a combined report for each stu-

dent with all the task information.

3.3.4 Progress Functionalities

Tracking students’ progress and performance are

functionalities that third-generation systems should

offer (Douce et al., 2005). The AEAS tool is no ex-

ception. The system offers a method to supervise stu-

dents’ progress.

Through a statistics section in the dashboard, the

teacher can track how students progress in an exer-

cise. For each exercise submission, the system stores

the score for that exercise in the database. Later, the

teacher can observe which tests students fail most and

some score metrics for that exercise. The previous

helped teachers shift efforts and tackle problems that

students might encounter.

4 INTERNAL ARCHITECTURE

OF THE AEAS TOOL

The AEAS tool is complex and substantially large.

This section uses four made-up modules to help clar-

ify the assessment system: web interface, backend,

unit testing, and plagiarism detector. These modules

do not exist in practice since they grow in more ad-

ditional microservices. However, for explaining pur-

poses, they are convenient.

As it is possible to observe in ﬁgure 2, apart from

the modules mentioned above, two additional archi-

tectural modules represented in the diagram appear

– reverse-proxy (NGINX) and the database (Mon-

goDB). Firstly, the system uses a reverse proxy to

Home Exercises

Practice assembly exercises

Follow the tutorial to learn how to submit your ﬁrst

exercise or explore the exercises list

Read tutorial Exercises list

How do I submit an exercise?

Follow the steps below to learn how to submit your ﬁrst exercise

Select an exercise

Select an exercise from the

exercises list

Read the instructions

Read, carefully, the instructions of

the exercise

Develop a solution

Develop a solution to the exercise

Test locally

When you have got your solution

ready, test it locally

Evaluate your solution

Finally, submit your solution and

evaluate it against the exercise

tests

Practice your code in a friendly environment

Pages

Home

Exercises

Useful pages

Moodle

Figure 3: The AEAS tool Web-interface main page.

proxy requests from the outside environment to the

inner system backend environment and the website.

Secondly, the system’s database is a MongoDB clus-

ter running alongside the system. The system’s open-

source architecture is available at github.com/luist18/

computers-architecture-platform.

4.1 Web-Interface

The web-interface module communicates between

end-users (students and teachers) and the system’s

backend. It is accountable for most of the system’s

functionalities, while some administration and main-

tenance features are exclusively accessible via back-

end API.

The web interface communicates between the

users and the assessment system. This way, the inter-

face supplies the essential features for users to com-

municate with the system. The functionalities avail-

able to students and teachers signiﬁcantly differ in

ﬁnality and complexity. Consequently, their visual

interface implementation follows the same rationale.

The student interface is designed to be simple and

user-friendly, allowing them to select and complete

exercises quickly. In contrast, the teacher interface is

more complex, requiring a manual for initial interac-

tion. The teacher interface mainly consists of forms

and data listings for managing system data, accompa-

nied by helpful text hints or instructions when neces-

sary. Figure 3 shows the web platform implementa-

tion main page.

4.2 Backend

The backend of the system is essentially the core of

the system, it does most of the work, and all system

requests pass by it through the API. In this subsection,

the responsibilities of the backend are discussed in the

following order: providing endpoints through an API,

ICSOFT 2023 - 18th International Conference on Software Technologies

576

communicating with the internal modules, and man-

aging ﬁles in the system’s storage.

4.2.1 Rest API

The API is the external facade of the system and is ac-

countable for all the communication between an end-

user and itself. All interactions from the outside en-

vironment that affect the assessment system must go

through the API. The API endpoints, which follow the

RESTful architecture, must be used to communicate

with the assessment system. Essentially, the API of-

fers endpoints to create, read, update, and delete data

either in the database or stored in the system, together

with various endpoints to perform grading operations

that do not necessarily impact the data already in the

system.

4.2.2 Communication with Internal Modules

Aside from communicating with the end-users, the

backend has to communicate with the modules encap-

sulated internally in the system’s environment: pla-

giarism detector and unit testing module. These small

modules perform extensive operations such as check-

ing plagiarism between assignments or testing them

against a set of use cases. Internally, a RESTful API

encapsulates both modules. This way, the commu-

nication between the backend and these modules is

performed via HTTP requests.

4.2.3 Managing System Local Storage

At last, another backend’s responsibility is managing

and storing information. For most data, the system

stores it in the database. Although, student assign-

ment ﬁles are not stored in the database but directly

in the system’s ﬁle system. Whenever a teacher evalu-

ates a set of students, the system generates a directory

with the students’ ﬁles. Later, the database record for

that evaluation holds a pointer to the ﬁles stored.

4.3 Unit Testing

As said in the previous subsection, the unit testing

module is a RESTful API. Internally, the module

uses an extended Python library built on the AOCO

tool (Damas et al., 2021). Apart from performance

changes, the modiﬁcations made to the tool add new

data types to the exercise deﬁnition and JSON output

to facilitate communication via HTTP. The API in this

module only offers one endpoint employed to test an

assignment against a set of test cases.

The library typically receives an exercise deﬁni-

tion (i.e., name, parameters’ types, and return type),

a set of tests, and an exercise solution. After receiv-

ing that data, the library runs the unit tests against the

solution received in the parameter. It returns a JSON

object containing information about the result of the

unit tests.

4.4 Plagiarism Detector and Instruction

Presence

In the same way as the unit testing module, the pla-

giarism detector module is also a RESTful API. This

module offers two operations available through two

endpoints: verifying occurrences of instructions in as-

signment ﬁles and checking plagiarism between as-

signment ﬁles.

The ﬁrst operation veriﬁes the occurrences of in-

structions, a simple operation that reads an assign-

ment ﬁle and searches for any instruction dynamically

speciﬁed as a parameter. The operation searches in-

structions in the code and determines if an instruction

is in a student’s code ﬁle.

The second operation veriﬁes plagiarism between

students’ submission ﬁles. The AEAS tool imple-

ments a plagiarism detection system natively. The

detection system uses a token comparison approach,

one of the simplest and most effective source code

plagiarism detection methods (Agrawal and Sharma,

2016). The system converts each ﬁle into tokens

in a tokenization process to detect plagiarism. Tok-

enization removes comments and transforms equiva-

lent code into the same token (e.g., registers x0 and

x1 are converted to REG). After tokenization, the to-

kens present in all submissions, such as the return to-

ken RET, are removed. The previous is made to avoid

similarity smoothing. Finally, the approach uses the

Sørensen–Dice coefﬁcient to gauge the similarity be-

tween each pair of token sets.

5 GRADING

The AEAS tool grading system is semi-automatic

when considering plagiarism detection. The previ-

ous means that, in some cases, it is inconceivable to

grade students based on the system’s output automat-

ically. As plagiarism detections often come as false

positives, it is impossible to directly map the system’s

results to a student’s grade. Thus, this section covers

an assignment’s grading process without considering

plagiarism detection. When using the tool, teachers

should handle detected plagiarism manually and sep-

arately, and the ﬁnal decision is up to each teacher’s

belief about each case.

Automatic Test-Based Assessment of Assembly Programs

577

The grading process of an assignment in the

AEAS tool takes advantage of the batch mode ex-

plained in section 3.3.3. Teachers collect students’

assignments and upload them to the system’s batch

mode. After the batch mode is complete, the system

generates a report containing the information repre-

sented in table 1. There is also an option to export the

report to a spreadsheet format.

Table 1: Assignment report example.

ID Compiled Test

Test

Instruction Score

student

true 1 1 0 0 true 0.5

student

true 1 1 1 1 true 1

student

false 0 0 0 0 true 0

student

true 0 0 1 0 true 0.25

student

true 1 1 1 1 false 0

The score value for each student depends on unit

tests and instruction presence. Considering an assign-

ment a and an arbitrary student i, the score for a stu-

dent in a speciﬁc assignment is the following:

score(s

, a) = [

∑

j=1

test

( j, s

) × w

( j)] × instruction(l, s

)

(1)

test

( j, s

) =

(

0, if s

does not pass test j

1, if s

passes test j

(2)

instruction(l, s

) =

(

0, if s

does not contain l

1, if s

contains l

(3)

∑

j=1

( j) = 1 (4)

Where s

is the source code solution for the stu-

dent i, test

( j, s

) is the result of the unit test j for

the assignment a, T is the number of unit tests, w

( j)

is the weight of test j for the assignment a, and

instruction(l, s

) is the result of the instruction lookup

for the instruction l and the source code s

. The score

has a domain between 0 and 1. Sometimes, verifying

if an instruction is in the students’ assignments is un-

necessary. In those cases, the score function does not

consider the instruction function.

6 VALIDATION

Since the 2020 academic year, the Faculty of En-

gineering of the University of Porto has used the

AEAS tool in the Computers Architecture course of

the Bachelor in Informatics and Computing Engineer-

ing to help students progress and automatically grade

the assembly assignments. On both occasions, the

students had to complete weekly tasks to ease learn-

ing the assembly programming language.

To evaluate the AEAS tool’s effectiveness, stu-

dents answered a questionnaire regarding some as-

pects of the AEAS tool and the evaluation methodol-

ogy. This section ﬁrstly analyzes the common ques-

tions for the 2020/2021 (Y1) and 2021/2022 (Y2) aca-

demic years, and then each year separately. On a

563 students universe (257 from Y1; 306 from Y2),

93 students (46 from Y1; 47 from Y2) answered

the questionnaire – making an overall coverage of

16.52% (17.90% in Y1; 15.35% in Y2).

Table 2: Results for questions 3, 4, and 5.

Question 1 2 3 4 5

3 (Y1) 8.7% 8.7% 65.2% 8.7% 8.7%

4 (Y2) 8.5% 6.4% 17.0% 23.4% 44.7%

5 (Y2) 4.3% 10.6% 27.7% 31.9% 25.5%

The questionnaire questions are the following:

Q1 (Year 1 & 2) Do you consider mandatory weekly as-

signments would be beneﬁcial to the process of learning

ARM64 programming?

Q2 (Year 1) Did the web-oriented platform positively im-

pact the development of your solutions to the weekly

assignments?

Q3 (Year 1) On a scale of 1 (only used DS-5) to 5 (only

used the web-oriented platform), how do you use these

tools to test the assignments? (Level 3 corresponds to a

balanced use.)

Q4 (Year 2) On a scale of 1 (very difﬁcult) to 5 (very easy),

how would you evaluate the ease of programming in the

web-oriented test platform compared to the DS-5 IDE?

Q5 (Year 2) On a scale of 1 (only used DS-5) to 5 (only

used the web-oriented platform), how do you consider

your environment to develop and test the assignments?

(Level 3 corresponds to a balanced use.)

Table 3: Results for questions 1 and 2.

Question Yes No No opinion

1 (Y1) 93.5% 4.3% 2.2%

1 (Y2) 82.9% 12.8% 4.3%

2 (Y1) 89.1% 8.7% 2.2%

As shown in table 3, most students believed that

the weekly assignments positively impacted learning

the ARM64 programming language. Although, only

some of them considered that it had no impact on un-

derstanding the ARM64 programming language.

Table 3 also shows that almost nine in every ten

students feel that the AEAS system positively im-

pacted the solutions for the weekly assignments. The

previous conﬁrms the usefulness of the AEAS system

in helping students. Finally, regarding the ﬁrst year, it

is observed in table 2 that students took a balanced use

ICSOFT 2023 - 18th International Conference on Software Technologies

578

between DS-5 and the assessment system to develop

their solutions.

Concerning the second year, table 2 shows an

overall opinion that the web-oriented test platform is

easier to use than DS-5. Finally, the table also shows

that compared with the assessment system in the pre-

vious year, there was a shift towards using more the

assessment system than DS-5.

These results help conﬁrm the system’s validity

and that students can shift their programming envi-

ronment to mostly the assessment system with more

student-directed changes and easier processes to de-

velop exercises.

7 CONCLUSIONS

This paper proposes a novel and open-source au-

tomatic assessment tool for assembly exercises, the

AEAS tool. This highly conﬁgurable tool was devel-

oped to be used in a teaching environment and to sup-

port the assessment of exercises in courses with a high

number of students.

The results of the validation, carried out using the

students who used the system, revealed that it signif-

icantly impacted their understanding of the ARM64

assembly language. It allowed students to acknowl-

edge almost instantaneous feedback on a process that

before was slow and complex. The AEAS assessment

tool has become a compelling choice for automatic

assessment. Its functionalities were tested and reﬁned

in a higher education environment over two years.

The results show that it is a reliable tool for grading

programming assignments written in ARM64.

Overall, this work demonstrates the value and ef-

fectiveness of the AEAS tool as a solution for auto-

matic assessment in computer science and engineer-

ing. Having the system available and open-source

opens the possibility of community improvements

and usage of the same tool in other educational en-

vironments.

As future work, there should be work in improving

scalability, enhancing student features with more con-

ﬁgurable exercise listings, and improving accessibil-

ity to turn the system even more uncomplicated. Since

the system’s architecture is highly modular, there is

likewise an open way to add compatibility with other

assembly languages, such as RISC-V.

REFERENCES

Agrawal, M. and Sharma, D. K. (2016). A state of art on

source code plagiarism detection. In 2016 2nd Inter-

national Conference on Next Generation Computing

Technologies (NGCT), Dehradun, India.

ARM (2010). ARM DS-5 Getting Started with DS-5 Ver-

sion 1.0.

Caiza, J. C. and

Alamo Ramiro, J. M. d. (2013). Program-

ming assignments automatic grading: review of tools

and implementations.

codepost (2023). codePost. Available at https://codepost.

io/.

CodeRunner (2022). CodeRunner. Available at https:

//coderunner.org.nz/.

Damas, J., Lima, B., and Araujo, A. J. (2021). AOCO

- A Tool to Improve the Teaching of the ARM As-

sembly Language in Higher Education. In 2021 30th

Annual Conference of the European Association for

Education in Electrical and Information Engineering

(EAEEIE).

Douce, C., Livingstone, D., and Orwell, J. (2005). Auto-

matic test-based assessment of programming: A re-

view. Journal on Educational Resources in Comput-

ing.

Edwards, S. H. and Perez-Quinones, M. A. (2008). Web-

cat: automatically grading programming assignments.

In Proceedings of the 13th annual conference on Inno-

vation and technology in computer science education.

Higgins, C. A., Gray, G., Symeonidis, P., and Tsintsifas,

A. (2005). Automated assessment and experiences of

teaching programming. Journal on Educational Re-

sources in Computing.

Joy, M., Grifﬁths, N., and Boyatt, R. (2005). The boss on-

line submission and assessment system. Journal on

Educational Resources in Computing.

Kustanto, C. and Liem, I. (2009). Automatic Source

Code Plagiarism Detection. In 2009 10th ACIS In-

ternational Conference on Software Engineering, Ar-

tiﬁcial Intelligences, Networking and Parallel/Dis-

tributed Computing, Daegu.

Leal, J. P. and Silva, F. (2003). Mooshak: A web-based

multi-site programming contest system. Software:

Practice and Experience.

Marchiori, A. (2022). Labtool: A Command-Line Interface

Lab Assistant and Assessment Tool.

Mpungose, C. B. and Khoza, S. B. (2022). Postgraduate

students’ experiences on the use of moodle and canvas

learning management system. Technology, Knowledge

and Learning.

Nabil, R., Mohamed, N. E., Mahdy, A., Nader, K., Es-

sam, S., and Eliwa, E. (2021). Evalseer: An intel-

ligent gamiﬁed system for programming assignments

assessment. In 2021 International Mobile, Intelligent,

and Ubiquitous Computing Conference (MIUCC).

Tarek, M., Ashraf, A., Heidar, M., and Eliwa, E. (2022). Re-

view of programming assignments automated assess-

ment systems. In 2022 2nd International Mobile, In-

telligent, and Ubiquitous Computing Conference (MI-

UCC).

Turnitin, L. (2023). gradescope. Available at https://www.

gradescope.com/.

Automatic Test-Based Assessment of Assembly Programs

579
