Verifying Data Integrity for Multi-Threaded Programs

Imran Pinjari

, Michael Shin

and Pushkar Ogale

Department of Computer Science, Texas Tech University, Lubbock, Texas, U.S.A.

Department of Computer Science, Stephen F. Austin State University, Nacogdoches, Texas, U.S.A.

Keywords: Integrity Breach Condition, Data Integrity, Message Communication, Malicious Code, Multi-Threaded

Program.

Abstract: This paper describes the Integrity Breach Conditions (IBCs) to identify security spots that might contain

malicious codes in message communications in multi-threaded programs. An attacker can inject malicious

code into a program so that the code would tamper with sensitive data handled by the program. The IBCs

indicate what functions might encapsulate malicious code if the defined IBC conditions hold true. This paper

describes the IBCs for multi-threaded based synchronous and asynchronous message communications in

which two threads communicate via message queues or message buffers. A prototype tool was developed by

implementing the IBCs to identify security spots in multi-threaded programs. An online shopping system was

implemented to validate the IBCs using the prototype tool.

1 INTRODUCTION

Malicious code can compromise sensitive data to

impact the business of an organization. In today’s

world of computers and networks, there are very high

chances for malicious code to be injected into the

program by an insider. Insiders (Wang et al., 2020;

Fadolalkarim et al., 2020; Jiang and Qu, 2020; Zhang

and Li, 2020; Rozi et al., 2020) could be software

engineers who have authorized access to the source

code of applications. Hence, malicious code should be

detected and removed during software development as

proactive measures.

A security spot is a code that may change either

the value of a sensitive variable in a class or sensitive

data in a database. Our previous work (Ogale et al.,

2018; Radhakrishnan et al., 2021) presented the

integrity breach conditions (IBCs) for non-

multithreaded programs to identify security spots

using sensitive variables (Ogale et al., 2018) and

object references (Radhakrishnan et al., 2021). This

paper extends our previous work by defining the IBCs

to identify security spots in multi-threaded programs,

where two threads communicate via message queues

or buffers asynchronously or synchronously.

Many real-world applications have been

developed with multi-threads, such as web servers,

database systems, networking, video, and audio

processing. Message queues or buffers are frequently

used in such applications for communication to handle

enormous volumes of messages or data efficiently.

The messages or data sent by one thread to another can

be tampered with if message queues or buffers are

breached by malicious codes. Also, malicious code

might be hidden in threads that communicate

messages or data. It is necessary to detect malicious

codes that might be hidden in the message queue or

buffer as well as the threads in the multi-threaded

programs.

This paper describes the IBCs to identify security

spots that may contain malicious code hidden in the

message queues and buffers and threads in multi-

threaded programs. Some methods or functions in

multi-threaded programs might contain malicious

code if the IBC holds for the methods or functions.

The IBCs are implemented as rules in the prototype

tool, which is extended from our previous tool. The

prototype tool is used to validate our research to detect

security spots. The identified security spots should be

manually reviewed to determine whether it is a benign

code or a malicious code.

This paper is organized as follows. Section 2

describes the background of our research. Section 3

describes the integrity breach conditions for the multi-

threaded programs for asynchronous message

communication, followed by the IBCs for

synchronous message communication in section 4.

Section 5 describes the prototype tool, and Section 6

588

Pinjari, I., Shin, M. and Ogale, P.

Verifying Data Integrity for Multi-Threaded Programs.

DOI: 10.5220/0012130000003538

In Proceedings of the 18th International Conference on Software Technologies (ICSOFT 2023), pages 588-595

ISBN: 978-989-758-665-1; ISSN: 2184-2833

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

validates this research. Section 7 describes the related

work, and section 8 describes the conclusions and

future work.

2 BACKGROUNDS

2.1 Glossary

The definitions of the terms used in this paper are as

follows:

 Message Queue (MQ) Connector is a queue used

for asynchronous message communication

between threads.

 Message Buffer and Response (MBR)

Connector stores the messages sent by the sender

thread to the receiver thread in a message buffer in

synchronous message communication. The

message response buffer stores the response sent

by the receiver thread to the sender thread.

 Sensitive Variable (SV) is a variable that stores

sensitive value and whose value must not be

changed maliciously. An SV is exclusively a

variable of a primitive type in Java.

 Non-Sensitive Variable (NSV) is a variable with

no sensitive value.

 Sensitive Object (SO) is an object of a class

whose value must not be changed maliciously.

 Non-Sensitive Object (NSO) is an object that

does not contain any sensitive values.

 Sensitive Class (SC) is a class that contains a

sensitive variable or sensitive object (SV/SO).

 Non-Sensitive Class (NSC) is a class that does

not contain any SV/SO.

 Reference to Sensitive Variable (RSV) refers to

a sensitive variable (SV) in a class.

 Reference to Sensitive Object (RSO) refers to a

sensitive object (SO) in a class.

 Reference to Non Sensitive Variable (RNSV)

refers to a non-sensitive variable in a class.

 Reference to Non Sensitive Object (RNSO)

refers to a non-sensitive object in a class.

 Security Spot is code that changes either an

SV/SO value in a class or sensitive data in a

database.

 Sensitive Method (SM) is a method that contains

at least one security spot.

 Non-Sensitive Method (NSM) is a method that

does not change the value of an SV/SO in a class

or the sensitive data in a database.

2.2 Approach

Fig. 1 depicts the overview of our approach in which

a list of sensitive variables or objects declared in

classes and sensitive data stored in a database are

given as input together with the multi-threaded

programs. Using the IBCs, the programs are analyzed

for data integrity to identify the security spots. The

Integrity Breach Conditions (IBCs) are defined to

identify the security spots in multi-threaded

programs. The IBCs are the criteria for determining

the security spots. If a method in a program holds an

integrity breach condition, then it becomes a security

spot, and the method becomes a sensitive method

(SM). The security spots may be either malicious or

benign. Hence, security spots should be verified

manually to determine whether they are malicious or

benign.

Figure 1: Overview of Our Approach.

3 INTEGRITY BREACH

CONDITIONS FOR

ASYNCHRONOUS MESSAGE

COMMUNICATION

A message queue (MQ) connector (Gomaa, 2011) is

used in asynchronous message communication

between threads, which communicate messages via a

message queue. An asynchronous message is sent by

a sender thread to a receiver thread via an MQ

connector and is stored in the MQ until the receiver

reads the message. The sender thread can continue to

send the next message to the receiver if the MQ is not

full.

Fig. 2 depicts a message queue (MQ) connector

for asynchronous message communication between

the sender and receiver threads. The MQ connector

provides the threads with two operations: the send()

operation, called by the sender thread to store a

Code

Analysisfor

Data

Integrity

SensitiveVariablesorObjectsinClasses

SensitiveDatainDatabase

SecuritySpots

Integrity

Breach

Conditions

Multi‐

Threaded

Program

Verifying Data Integrity for Multi-Threaded Programs

589

message in the MQ, and the receive() operation,

called by the receiver thread to read a message from

the MQ. The send() operation has an incoming

message as a parameter, and the receive() operation

returns an outgoing message read from the MQ.

Figure 2: Message Queue Connector.

When a sender thread method (i.e., the run()

function of a sender thread in Java) sends a message

to a receiver thread method (i.e., the run() function of

a receiver thread in Java) via a message queue (MQ)

connector, the message can be an SV, NSV, RSV,

RSO, RNSV or RNSO. However, RNSV is not

possible in our focused programming language.

Suppose a method in an MQ connector is a method

M. Under these circumstances, the following IBCs

are specified to identify security spots in

asynchronous message communication between two

threads.

IBC 1: If a sender thread method sends a message,

which is either an SV or NSV, to a receiver thread

method, a method M changes the message, and the

receiver thread method is an SM to use the changed

message, the MQ connector class becomes an SC, and

the message becomes an SV in the class.

Because the message is used by an SM in the

receiver thread, a change in the message will affect

the SM. The message becomes an SV in the MQ

connector and must not be changed in the MQ

connector. As the message is stored in the MQ

connector class, the class becomes an SC.

The IBC 1 can be detailed into IBC 1a, 1b, and 1c:

IBC 1a: If the message is an SV declared as a class

variable in the sender thread class, the sender thread

class is already an SC.

IBC 1a is trivial because it is a kind of SC

definition.

IBC 1b: If the message is an NSV declared in the

sender thread class, the sender thread class becomes

an SC.

The message must not be changed in the sender

thread as well as the MQ connector class because an

SM in the receiver thread method uses the message.

The message declared as an NSV in the sender thread

must become an SV, and the sender thread class must

become an SC.

IBC 1c: If the message is a local variable declared in

the thread method, the sender thread method can be

an SM.

Although the message becomes an SV, only the

sender thread method can be an SM because the

message is declared as a local variable in the sender

thread method.

IBC 2: If a sender thread method sends a message,

which is either an RSV or RSO, to a receiver thread

method via an MQ connector, and a method M in the

MQ connector class changes the message, the MQ

connector class becomes an SC.

Because the message is an RSV or RSO in the

sender thread, it must not be changed by any method

in the MQ connector class. The value of the RSV or

RSO in the sender thread changes if the MQ

connector tampers with the RSV or RSO. Therefore,

the MQ connector class becomes an SC.

Suppose the variables a and b in the Message class

in Fig. 3 are SVs. The msg declared in the Sender

class is an RSO because the variables a and b are SVs.

The Message Queue class becomes an SC if the

send() operation in the Message Queue class changes

the value of the message msg sent by the Sender

thread to the Receiver thread.

Under IBC 2, the following IBC 2a, 2b, 2c, and

2d are defined.

IBC 2a: The receiver thread method becomes an SM

if it is an NSM and changes the value of the RSV or

RSO.

When the receiver thread method changes the

value of the RSV or RSO, the RSV or RSO in the

sender thread method is affected. Thus, the receiver

thread method becomes an SM. In Fig. 3, the

Receiver thread method is an NSM and it changes the

value of the variable msg1.a by increasing by 2000,

where the msg1 is assigned the msg. The Receiver

thread method becomes an SM.

IBC 2b: Both the receiver thread method and method

N become SMs if the receiver thread method is an

NSM and calls the method N with an RSV or RSO

parameter whose value is changed in the method N.

aSenderThread

aReceiverThread

«connector»

aMessageQueue

send (in message)

receive (out

message)

«connector»

MessageQueue

+ send (in message)

+ receive (out message)

- messageQ: Queue

ICSOFT 2023 - 18th International Conference on Software Technologies

590

If the RSV or RSO value is maliciously changed by

method N, the RSV or RSO in the sender thread

method is affected. Also, the receiver thread method

calls method N, which can tamper with the RSV or

RSO. Both the receiver thread method and method N

must be SMs. In Fig. 3, the Receiver thread method

calls the method N with the message msg1, which

changes the value of msg1. The method N becomes

an SM. At the time, the Receiver thread method also

becomes an SM if it is an NSM.

Figure 3: Multi-threaded Code for Asynchronous Message

Communication.

IBC 2c: A method N becomes an SM if the receiver

thread method is an SM and calls the method N with

an RSV or RSO parameter whose value is changed in

the method N.

Method N can change the value of the RSV or

RSO maliciously. This change will affect the value of

the RSV or RSO in the sender thread method as well

as the receiver thread method. The method N must be

an SM.

IBC 2d: The class that contains the receiver thread

method becomes an SC if the receiver thread method

assigns the RSV or RSO to a reference to a variable

or object declared in the class.

As the RSV or RSO is assigned to a reference to

a variable or object declared in the receiver thread

class, the value of RSV or RSO can be changed

maliciously by some methods in the class. This

change will affect the RSV or RSO in the sender

thread method. In Fig. 3, the message msg1 is

assigned to the obj1, which is a reference to the

Message object. The Receiver class becomes an SC.

IBC 3: Via the MQ connector class, a sender thread

method sends an RNSO message to a receiver thread

method that is an SM and uses the RNSO, and a

method M in the MQ connector class changes the

RNSO. In this case, the MQ connector class becomes

an SC, and the RNSO becomes an RSO in the MQ

class.

A change to the RNSO message affects the

receiver thread method because the method is an SM.

If a method M in the MQ connector class can tamper

with the value of the RNSO, the breached RNSO is

used by the receiver thread method, which is an SM.

As the RNSO is stored in the MQ connector class, the

MQ connector class becomes an SC, and the RNSO

comes to be an RSO in the MQ connector.

The following IBC 3a and IBC 3b hold under the

IBC 3:

IBC 3a: The sender thread method becomes an SM if

it changes the RNSO. If the message is an RNSO

declared in the sender class (but not in the method),

the sender thread class becomes an SC. The RNSO

becomes an RSO in the sender thread class.

Because the RNSO message is used by the

receiver thread method, the change to the RNSO

message in the sender thread method affects the

receiver thread method, which is an SM. Thus, the

sender thread method must become an SM if it

changes to the RNSO. At this time, the RNSO

declared in the sender thread class must be an RSO in

the sender thread class, which also becomes an SC.

IBC 3b: The sender thread method becomes an SM

if it changes the RNSO. If the message is a local

object declared in the thread method, the sender

thread method becomes an SM.

When the RNSO is declared in the sender thread

method, the sender thread class cannot be an SC.

However, the sender thread method must be an SM.

Class Message{

double a; //Assume a is an SV

double b; //Assume b is an SV

}

Class MessageQueue

{

…

public synchronized void send(Message message) {

……

message.a = message.a - 500.00;

……

}

public synchronized Message receive(){

…

return message;

}

Class Sender implements runnable {

MessageQueue queue;

Message msg;

…

public void run()

{

msg = new Message()

msg.a = 100.00;

msg.b = 200.00;

queue.send(msg);

}

Class Receiver implements runnable {

MessageQueue queue;

Message obj1;

……

public void run(){

Message msg1 = new Message();

msg1 = queue.receive();

msg1.a = msg1.a + 2000.00;

msg1 = methodN(msg1);

obj1 = msg1;

}

public Message methodN (Message msg) {

msg.b = msg.b - 100.00;

return msg

}

Verifying Data Integrity for Multi-Threaded Programs

591

4 INTEGRITY BREACH

CONDITIONS FOR

SYNCHRONOUS MESSAGE

COMMUNICATION

In synchronous message communication, a sender

thread method sends a message to a receiver thread

via a message buffer and response (MBR) connector

(Gomaa, 2011) and waits for a reply from the

receiver. When a reply arrives from the receiver, the

sender can continue to work and send the next

message to the receiver. The MBR connector class

provides the send(), receive(), and reply() operations

that enable synchronous message communication

between the sender and receiver threads. A sender

thread calls the send() operation to store a message in

a message buffer, while the receiver thread calls the

receive() operation to read a message from the buffer.

The receiver thread returns a reply to the sender

thread by calling the reply() operation.

Using the IBCs for asynchronous message

communication, the IBCs for synchronous message

communication can also be specified for both sending

a message from a sender thread to a receiver thread

and replying from the receiver to the sender. When a

sender sends a message to a receiver, a message can

be an SV, NSV, RSV, or RSO. The IBCs for

asynchronous message communication are utilized

for a sender to send a message to a receiver to identify

SMs. Similarly, the IBCs are used to detect SMs

relating to replying to the sender from the receiver. In

this case, a reply can be an SV, NSV, RSV, or RSO,

and the IBCs are applied reversely, meaning that a

sender comes to be a receiver, and a receiver becomes

a sender.

5 PROTOTYPE TOOL

A prototype tool was developed to validate the IBCs

specified for multi-threaded Java programs. We

extended our previous prototype tool to develop a new

prototype tool for this research. The prototype tool

(Fig. 4) consists of the GUI, code scanner, data

integrity relation database, and data integrity analyzer.

5.1 GUI

The GUI (Fig. 4) is used to input a text file containing

SVs, NSVs, RSOs, and RNSOs in a multi-threaded

Java program; and a program folder encompassing

the multi-threaded Java program code. The input can

be entered via GUI in a format that includes the

package names, class names, SVs, NSVs, RSOs, and

RNSOs in each class.

Figure 4: Prototype Tool.

5.2 Code Scanner

As our previous research selects Java code, we select

a multi-threaded program in Java as our target

program. The code scanner (Fig. 4) scans all classes,

including the thread classes in the multi-threaded

program, to build the data integrity relations used to

analyze the IBCs. The class names, methods and their

parameter names, and variable names are scanned and

stored in the data integrity relation database. The local

variables in each method are also scanned for some

IBCs that are checked with the local variables. The

code scanner can handle synchronized methods that

communicate with each other via MQ or MBR

connectors.

5.3 Data Integrity Relations Database

The data integrity relation database (Fig. 4) stores the

data integrity relations extracted by the code scanner

from a multi-threaded Java program. The database is

a relational database containing relations handled by

the SQLite3 database. The data integrity relation

database contains four new data integrity relations:

local variables, class objects declared at the class

level, and local objects declared in methods. Also, we

modified existing integrity data relations for method

calls, changed variables, and used variables in each

method to identify security spots in a multi-threaded

Java program using the IBCs specified in this paper.

5.4 Data Integrity Analyzer

The data integrity analyzer (Fig. 4) identifies the

security spots in a multi-threaded Java program using

Code Scanner

Data Integrity

Relation Database

Data Integrity

Analyzer

OUTPUT

Security spots listed out as

Package/Class/Method/Line

number of security spots, Log

file, DB file

GUI

Java Code

Package folder location

List Of SVs and SOs

ICSOFT 2023 - 18th International Conference on Software Technologies

592

the data integrity relation database. The data integrity

analyzer detects the SMs if any method in the given

program holds any specified IBC. We implemented

the IBCs for both asynchronous and synchronous

message communications as the data integrity

analyzer to detect the security spots.

The data integrity analyzer processes all the data

integrity relations in the database to identify all the

SMs. When the data integrity analyzer identifies an

SM, it inserts them into an output file that contains

the package, class, method, message string explaining

why it is SM, and line number. The data integrity

analyzer repeats until all the classes in the given

package are analyzed. The data integrity analyzer also

creates a log file that contains information on every

step executed from the beginning to the end of finding

SMs.

6 VALIDATIONS

A multi-threaded online shopping system was

developed to validate our approach using the

prototype tool. The online shopping system consists of

the Browse catalog, Make Order, Confirm Shipment

and Bill Customer, Process Delivery Order, View

Order, and Notify Shipment use cases. A customer can

orders, while a supplier can log in to confirm

shipment, bill the customer, process delivery orders,

and notify the customer of shipment. All the use cases

except the notify shipment are designed with

synchronous message communication. The Notify

Shipment use case is an example of asynchronous

message communication, where the Supplier Interface

sends the shipment status message to the Customer

Interface asynchronously.

The IBCs specified in this paper were tested two-

fold with simplified test cases for each IBC and then

those for use cases in the multi-threaded online

shopping system. Simplified test cases were used to

check if the IBCs had been implemented correctly in

the data integrity analyzer. We intentionally added at

least one malicious code to the MQ and MBR

connector classes or Sender and Receiver thread

classes to verify each IBC. In the second round of

testing, we implemented the use cases in the multi-

threaded online shopping system and created the test

cases for those use cases.

As there was only one asynchronous

communication Notify Shipment use case in the multi-

threaded online shopping system, 11 test cases were

designed to test each IBC specified in this paper. We

added one malicious code to the Notify Shipment use

case and ran the use case 11 times separately. For

comprehensive testing (11 times), the total methods

recorded are 46, and the SMs identified are 7. All the

SMs are correctly identified. In addition, the tool has

identified 6 SCs as designed in the test cases.

The test cases for synchronous message

communication were designed for Browse catalog,

Make Order, Confirm Shipment and Bill Customer,

Process Delivery Order, and View Order use cases.

We added at least four malicious codes to the test

cases for each use case. The tool has identified the

unique 18 SMs and 16 SCs correctly as per the

malicious code we added along with the other

methods, which hold true to the IBCs specified in this

paper.

7 RELATED WORK

Several methods have been suggested to examine the

vulnerabilities in a program that deals with

confidentiality, integrity, privacy, and availability of

applications. The following discusses some of the

approaches:

The Integrity Breach Conditions (IBCs) that

compromise the sensitive data in an application are

described in (Ogale et al., 2018). IBCs are developed

using couplings associated with the language

features. The authors (Radhakrishnan et al., 2021)

extended the approach in (Ogale et al., 2018) by

specifying IBCs by object reference (SOs and RSOs).

However, the IBCs and prototype tools developed in

previous work focused on general programming and

did not handle multi-threaded programming. Also,

local variables in methods were not handled.

The study by (Jovanovic et al., 2006) discusses the

problem of vulnerable web applications by static

source code analysis. This approach targets the

tainted data inserted by malicious users to cause

security problems. When the tainted data is used for

the execution of dangerous commands, a prototype

developed by (Jovanovic et al., 2006) warns about the

possible vulnerabilities through data flow analysis.

This approach aims at data confidentiality, integrity,

and privacy.

The authors (Camps et al., 2019; Wang et al.,

2020; Zhang et al., 2019) utilized machine learning to

detect malicious code. The research (Camps et al.,

2019) classified C source code to distinguish

malicious code from benign code. In (Wang et al.,

2020), the study caught malicious code based on

malicious code metadata using a random forest

classification algorithm. In (Zhang et al., 2019), the

authors have proposed an Android malware detection

Verifying Data Integrity for Multi-Threaded Programs

593

method based on the application’s abstracted API

calls’ method-level correlation. Different behavioral

patterns of malicious and benign apps are identified

by combining machine learning with the detection

system. Instead of machine learning techniques, our

approach specified the IBCs to identify malicious

code that might compromise the integrity of multi-

threaded programs.

Authors (Fadolalkarim et al., 2020) proposed an

anomaly detection system, AD-PROM, which would

protect relational database systems against malicious

application programs that steal data by tracking the

calls made by application programs on data extracted

from the database. The approach proposed by

(Fadolalkarim et al., 2020) aims at data

confidentiality, but our research focuses on data

integrity in a program.

In (Jiang and Qu, 2020), the authors proposed an

approach to detecting malicious code using behavior

patterns identified by network behavior analysis. A

memory tracking method is used to realize the real-

time tracking of network behavior. The study (Jiang

and Qu, 2020) focused on an outsider’s attack on a

network to detect malicious code. However, our

approach deals with an insider’s attack on a software

program.

The authors (Zhang and Li, 2020) described

malicious code detection using code semantic

structure features to reflect semantic information.

They utilized a deep learning technique with code

semantic structure features to detect malicious code.

In contrast, our approach used the IBCs to determine

security spots that might contain malicious code.

The authors (Rozi et al., 2020) proposed a deep

neural network for detecting malicious JavaScript

codes by examining their bytecode sequences to

protect users from cyberattacks. The study (Rozi et

al., 2020) used Java bytecode, but our research used

Java source code to detect malicious code.

In (Ognawala et al., 2016), the authors present a

tool (MACKE) that analyzes vulnerabilities with

symbolic execution and directed inter-procedural

path exploration. The tool is developed using KLEE,

a coverage-first symbolic execution tool for covering

paths in a program. The MACKE performs a

compositional analysis using symbolic execution on

the functional level first and then combines the results

using static code analysis based on a targeted path

search. However, our tool identifies security spots

using the IBCs specified for multi-threaded programs.

String analysis by (Yu et al., 2014) determines

possible dangerous string constructs and provides a

warning if there is a vulnerability. Malicious user

input without proper input sanitization is vulnerable

to attacks. String analysis focused on analyzing input

strings to detect vulnerabilities in string manipulating

programs. In contrast, our approach focused on the

malicious code introduced by insiders in a program.

The authors (Zhioua et al., 2014) have assessed

the static code analysis approaches and available tools

to determine their effectiveness. The authors

demonstrated that the static code analysis tools could

not cover all the security issues.

8 CONCLUSIONS

This paper has described an approach to identify the

security spots in multi-threaded programs that might

contain malicious code. The IBCs for multi-threaded

programs were specified by considering both

asynchronous and synchronous messages

communicated via the MQ and MBR connectors. A

prototype tool was developed by extending our

previous tool. The IBCs were validated with a multi-

threaded online shopping system case study using the

prototype tool.

We envision our future work as follows. Our

future work will specify more IBCs for advanced Java

language features, including an interface, inner class,

and lambda expression. Also, we can extend the IBCs

for smart contracts in blockchain applications, which

are developed in Java or JavaScript. In addition, we

can investigate artificial intelligence techniques to

automatically classify benign and malicious codes in

the security spots. Our approach must manually

review the security spots to filter malicious codes

from benign ones.

REFERENCES

Camps, G. S., Agostini, N. B., and Kaeli, D., 2019,

December. Discovering Programmer Intention Behind

Written Source Code. In 18th IEEE International

Conference on Machine Learning and Applications

(ICMLA), Florida, USA.

Fadolalkarim, D., Bertino, E., and Sallam, A., 2020, April.

An Anomaly Detection System for the Protection of

Relational Database Systems against Data Leakage by

Application Programs. In IEEE 36th International

Conference on Data Engineering (ICDE), Dallas,

Texas.

Gomaa, H., 2011. Software modeling and design: UML,

use cases, patterns, and software architectures.

Cambridge University Press.

Jiang, C., and Qu, Q., 2020, June. A New Automatic

Detection System Design of Malicious Behavior Based

on Software Behavior Sequence. In 10th International

ICSOFT 2023 - 18th International Conference on Software Technologies

594

Conference on Information Science and Technology

(ICIST) Lecce, Italy.

Jovanovic, N., Kruegel, C., and Kirda, E., 2006. Pixy: A

Static Analysis Tool for Detecting Web Applications

Vulnerabilities. In IEEE Symposium on Security and

Privacy, Washington DC, pp. 258-263.

Ogale, P., Shin, M., and Abeysinghe, S., 2018, July.

Identifying Security Spots for Data Integrity. In the 13th

IEEE International Workshop on Security, Trust,

and Privacy for Software Applications (STPSA/

COMPSAC), Tokyo, Japan.

Ognawala, S., Ochoa, M., and Pretschner, A., 2016,

September. MACKE: Compositional analysis of low-

level vulnerabilities with symbolic execution. In 31st

IEEE/ACM International Conference on Automated

Software Engineering (ASE), Singapore.

Radhakrishnan, R., Shin, M., and Ogale, P., 2021, July. Data

Integrity Security Spots Detected by Object Reference.

IEEE 45th Annual Computers, Software, and

Applications Conference (COMPSAC), pp 469-474.

Rozi, M. F., Kim, S., and Ozawa, S., 2020, July. Deep

Neural Networks for Malicious JavaScript Detection

Using Bytecode Sequences. In International Joint

Conference on Neural Networks (IJCNN), Glasgow,

UK.

Wang, Z., Cong, P., and Yu, W., 2020, July. Malicious

Code Detection Technology Based on Metadata

Machine Learning. In IEEE Fifth International

Conference on Data Science in Cyberspace, Hong

Kong, China.

Yu, F., Alkhalaf, M, Bultan, T., and O. H. Ibarra, O. H.,

2014. Automata-Based Symbolic String Analysis for

Vulnerability Detection. Formal Methods in System

Design, Vol. 44.

Zhang, H., Luo, S., Zhang, Y., and Pan, L., 2019. An

Efficient Android Malware Detection System Based on

Method-Level Behavioral Semantic Analysis. IEEE

Access, Volume: 7.

Zhang, Y., and Li, B, 2020. Malicious Code Detection

Based on Code Semantic Features. IEEE Access,

Volume: 8.

Zhioua, Z., Short, S., and Roudier, Y., 2014, July. Static

Code Analysis for Software Security Verification:

Problems and Approaches. In COMPSACW’14

Proceedings of the 2014 IEEE 38th International

Computer Software and Applications Conference

Workshops. Washington, USA, pp 102-109.

Verifying Data Integrity for Multi-Threaded Programs

595
